Instruction manual Ensite Pro Configuration Tool Page 1
Instruction manual
Ensite Pro
Configuration Tool
Version: 2.0
June 2001
Part no.: 4416.593
Enraf B.V.
P.O. Box 812
2600 AV Delft
Netherlands
Tel.: +31 15 2698600, Fax: +31 15 2619574
Email: Info@enraf.nl
http://www.enraf.com
Offices in: Netherlands - France - Germany - Russia - UK - USA - China - Singapore

Page 2
Copyright 1999 - 2001 Enraf B.V. All rights reserved.
Reproduction in any form without the prior consent of Enraf B.V. is not allowed.
This instruction manual is for information only. The contents, descriptions and specifications are
subject to change without notice. Enraf B.V. accepts no responsibility for any errors that may
appear in this instruction manual.
The warranty terms and conditions for Enraf products applicable in the country of purchase are
available from your supplier. Please retain them with your proof of purchase.
Preface
Instruction manual Ensite Pro Configuration Tool Page 3
A Caution draws attention to an action which may damage
(the operation of) the equipment.
A Note points out a statement deserving more emphasis than the
general text.
Preface
This manual describes how to work with the configuration tool Ensite
Pro. It has been written for the technicians involved in the
commissioning and service of the series 880 CIU Prime and Plus.
Safety and prevention of damage
‘Cautions’ and ‘Notes’ have been used throughout this manual to
bring special matters to the immediate attention of the reader.
Legal aspects The information in this instruction manual is copyright property of
Enraf B.V., Netherlands.
Enraf B.V. disclaims any responsibility for personal injury or damage
to equipment caused by:
• Deviation from any of the prescribed procedures;
• Execution of activities that are not prescribed;
Additional information
Please do not hesitate to contact Enraf or its representative if you
require additional information.
Table of contents
Page 4
Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ensite Pro configuration tool - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Configuration Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Procedure steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Retrieving configuration data of gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Configuration of the Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Configuration of CIU Prime’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Configuration of CIU Plus’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Linking Gauges, Tanks and CIU’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Downloading configuration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Start Ensite Pro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Select site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Global settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Configure data inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Vapour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configure tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Vapour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Shell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
TCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configure CIU Prime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Table of contents
Instruction manual Ensite Pro Configuration Tool Page 5
HostPort 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
HostPort 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Hot standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
FieldPorts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Tambient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Configure CIU Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
HostPorts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Modbus settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 50
Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Entities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Hot standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
FieldPort 1 & 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Configure links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Data inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
CIU Prime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Communication setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Download configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Upload configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Service note(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Set date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Print configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Show diagnostic data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Tank viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Scan viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
User privileges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Stop Ensite Pro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Appendix A: related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Introduction
Page 6
Introduction
The configuration of the new tank inventory system consists of
modular parts:
• Entis Pro
• CIU Plus
• CIU Prime
• field instrumentation
Entis Pro This system displays calculated data from the CIU Plus.
It is a Windows NT based program, displaying data in windows,®
boxes, tables, graphs, etc.
CIU Plus This unit calculates volume and mass. It requests input data from the
CIU Prime and calculates all other data. It presents data to higher
layered systems like Entis Pro, SCADA, DCS, ENSITE, etc.
CIU Prime This unit is an interface between the field instrumentation
(e.g. 854 ATG, 873 SmartRadar, etc.) and inventory systems
(CIU Plus, PLC, ENSITE, etc.).
Field instrumentation
The instruments in the field collect data such as level, temperature,
density and/or pressure. The instruments are based on several
principles: mechanical, servo, radar, hydrostatic and capacitive or a
combination. The instruments measure the data and transmit it upon
request of higher layered systems.
Ensite Pro Ensite Pro is a configuration tool for commissioning, diagnostics and
documentation of the series 880 CIU Prime / Plus.
Commissioning Some information will be asked to fill in, needed to program the CIU
Prime / Plus. Ensite Pro automatically puts the input on the right
(default) positions.
Diagnostics The build in diagnostic data views, reads and writes data direct from
and to the CIU Prime / Plus.
Documentation The whole configuration can be printed to have a hard back-up.
See later in this manual.
Ensite Pro configuration tool - General
Instruction manual Ensite Pro Configuration Tool Page 7
Ensite Pro configuration tool - General
The configuration tool works with windows. Within these windows are
buttons, on which the function is written. One of the characters on a
button is underlined.
Throughout the configuration tool, common buttons are used.
Their description is given once:
Press the ‘Ok’-button to set the parameters and work with it
accordingly.
Press the ‘Cancel’-button to ignore any changes made. The program
returns to the previous window. In some cases this button has been
renamed into Close”
Press the ‘Apply’-button to set the parameters and work with it
accordingly, but remain in the active window.
Check the ‘Advanced’-button to activate the advanced part in the
active window.
Activate functions The function of a button can be activated in several ways:
- mouse • move the mouse pointer to the button and click the left mouse
button
- ‘Alt’-key • press the ‘Alt’-key simultaneously with the underlined character
key of the text on the button
- ‘Tab’-key • press the ‘Tab’-key to scroll over all buttons. When the desired
button is reached (marked), press the ‘Enter’-key
Configuration procedure
Page 8
Configuration Procedure
This chapter describes the general configuration procedure for the
880 CIU Prime, CIU Plus. For programming the 880 series CIU’s, it is
necessary to use Ensite Pro.
It is programmable to communicate via one of the higher levels, i.e.
via a CIU Plus to a CIU Prime, or even via Entis Pro to any of the
connected CIU’s.
Procedure steps The complete configuration procedure consists out of the
following steps:
• Preparation
• Retrieving configuration data of gauges.
• Configuration of Tanks
• Configuration of the CIU Prime(s)
• Configuration of CIU Plus(‘s)
• Linking Gauges, Tanks and CIU’s
Preparation Before you start configuring 880 series CIU and possible one or
more Entis Pro stations, certain preparations are necessary.
Be sure that the following information is available:
• Site layout
• Field cabling information (which gauges are connected on the
same pair of field wires, etc.)
• Tag names of field devices (gauges, CIU and tanks)
• Tank information (strapping tables, or tank capacity tables, roof
details, etc.)
• Information on the types of stored product
• Host communication setup
(if applicable, i.e. modbus memory maps, etc.)
• Modems and possible other communication hardware connected
to the CIU’s
The first step in Ensite Pro is the creation of a site.
This allows the program to store multiple configuration sets, with each
a separate database. After a new site has been created, the program
will prompt for a set of global settings. These settings are required for
initiating the configuration database.
Once the global settings are entered, Ensite Pro will create a site
database. If there is a .LOG file available for this gauge it can be
extracted by Ensite Pro. The data extraction pre-sets all the relevant
configuration parameters. The next step is the creation off all tanks.
Configuration procedure
Instruction manual Ensite Pro Configuration Tool Page 9
Retrieving configuration data of gauges
As first step the gauges should be configured correctly. This can best
be done by means of the DOS program ENSITE.
With ENSITEthe so called .LOG files can be created. These .LOG
files contain all the programmable settings of relevant gauge.
If no gauges are installed yet, it is also possible to prepare these in
ENSITE. They can then later be down loaded into the gauge.
Configuration of the Tanks
Also the creation of the tanks is a straightforward process.
At the creation of a new tank, the user is always prompted for a name.
Preferably use the same name as the name already in use on site.
Once the tank has been created, the user has to enter specific tank
details, like Tank shape, Roof details, etc.
Tank strapping tables or capacity tables can be linked via an external
file. This file needs to be conform the TCT specification as specified
in this manual. The format is a simple ASCII, comma delimited format.
The straps can either be manually entered, or be calculated out of a
formula, depending on what information is available. The strapping file
can contain a maximum of 2000 straps. The total capacity of the CIU+
is 20000 straps.
The data can best be prepared by means of a spreadsheet program
like Excel or Lotus 123. Users already using Entis+, can contact the
factory for a TCT extraction program.
This program extracts the strapping table out of the internal Entis+
database, and converts it into an Ensite Pro compatible format.
Once all the tanks are created in the database, the user can either
start with the configuration of the CIU Primes or the CIU Pluses.
Configuration of CIU Prime’s
In the 880 series CIU Prime, the following parts can be configured:
• HostPort 1
• HostPort 2
• Hot standby (if applicable)
• Field ports
• The hot stanby settings are required if redundant CIU Primes
are installed.
The Field ports settings depend on the type of interface card installed
in the CIU Prime.
Configuration procedure
Page 10
Always make a backup of the site database before making any
modifications. In doubt upload the configuration.
Configuration of CIU Plus’s
In the 880 series CIU Plus, the following parts can be configured:
• Hostports
• Hot standby (if applicable)
• FieldPort 1
• FieldPort 2
• The hot standby settings are required if redundant CIU Primes
and/or CIU Pluses are installed.
The host port setting are required to make the CIU Plus compatible
with the connected hardware and software, i.e. a PLC, Entis Pro or a
DCS system. The FieldPort settings inform the CIU Plus about the
communication setting to one or more CIU Primes.
Linking Gauges, Tanks and CIU’s
After all the data inputs, Tanks, CIU Primes and CIU Pluses are
configured the linking of all devices can commence. On basis of the
actual or planned installation, the user has now to link the hardware:
• the data inputs to the tanks,
• the tanks to the CIU Primes,
• the CIU Primes to the CIU Pluses.
Downloading configuration data
Once you have verified all the settings of all the devices, you can
download the configuration database into the respective CIU’s.
The first time it is advised to do downloading directly on the targeted
CIU (Prime of Plus). Ensite Pro offers this downloading as a standard
feature, even over modem lines.
Later modifications on the CIU configuration can also be done via a
CIU Plus into a CIU Prime, or even via Entis Pro from any of the
network stations.
Start Ensite Pro
Instruction manual Ensite Pro Configuration Tool Page 11
Start Ensite Pro
Ensite Pro can be started in the following way:
Windows 95/98/NT • press ‘Start’-button
• select ‘Programs’
• activate ‘Ensite Pro’-shortcut
The splash screen is shown, followed by the login window:
Ensite Pro login
Start Ensite Pro
Page 12
When the correct password is given (the Administrator’s default
password is ‘Ensite Pro’), the program starts up with the following
window:
Only three buttons are illuminated:
Select site
 A site gives an overview of the configuration at a specific customer’s
site. Selecting a site gives you access to a database
Help
The build in help document assists at any time.
User privileges
Access parameters for different users can be set or selected.
A site must be created to be able to work with the configuration tool.
Press the upper left button to illuminate all other buttons.
Select site
Instruction manual Ensite Pro Configuration Tool Page 13
Select site
A site gives an overview of the configuration at a specific customer’s
site. Selected sites are highlighted.
Press this button to copy the highlighted site from the list.
Only specific data must be changed afterwards.
When the site is not in the list (yet), a new site has to be created.
Press the ‘New’-button to add a site:
Press the ‘Ok’-button to let the new site appear in the listbox.
Press this button to select the highlighted site to work with. You can
also double click on the highlighted site name.
Press this button to import an earlier made site database.
Press this button to remove the highlighted site from the list.
Global settings
Page 14
Data in the fields ‘Dimensions’ and ‘Text’ can only be changed/set
after a new site has been created, all other data can also be
changed/set at a later stage.
Level and volume dimensions entered must be consistent with the
dimensions of the tank strap tables intend to use.
Global settings
This window automatically pops up after a site has been created. In
this window, global settings for the selected site can be programmed.
These global settings cover the way data is represented.
Dimensions
Level Select: m, mm, ft, in, in/16, fis or 1/256 in
Temperature Select: °C, °F
Density Select: kg/m , °API, lbs/ft , dens60/60 or lbs/USgal3 3
Pressure Select: kgf/m , Pa, kPa or psi (lbf/in )2 2
Flow Select: m /min, m /h, l/min, bbls/min, bbls/h, USgal/min, Usgal/h3 3
or UKgal/h
Volume Select: l, m , USgal, bbls or UKgal3
Mass Select: kg, metric ton, USton, lbs or long ton
Std. ambient air pressure Enter ambient air pressure in kPa (default = 101.325 kPa).
Air density Enter air density in kg/m (default = 1.226 kg/m ).3 3
Global settings
Instruction manual Ensite Pro Configuration Tool Page 15
After all global settings are made, the program warns the user that it
is not possible to change the settings anymore:
When confirmed, the program displays the following window:
The following buttons are available:
Select site.
A site gives an overview of the configuration at a specific customer’s
site.
Global settings.
Global settings cover the way data is represented, as well as some
local figures. These settings are valid for the particular site only.
Configure data inputs.
The data inputs collect data such as level, temperature, density and/or
pressure.
26 Configure tanks.
A tank is a (large) container to store liquids or gases.
Configure CIU Prime.
The CIU Prime is an interface between the field instrumentation and
inventory systems. To setup the CIU Prime, the port configuration
must be programmed.
Configure CIU Plus.
The CIU Plus calculates volume, standard volume, mass, density,
flow rate etc. To setup the CIU Plus, the port configuration must be
programmed.
Global settings
Page 16
Configure links.
After all individual components (CIU Prime, CIU Plus, tanks and data
inputs) have been configured, they have to be linked to each other.
Communication setup.
To be able to communicate via the configuration tool, communication
parameters must be set.
Download configuration.
The (new) programmed configuration must be downloaded for the CIU
Prime / Plus to work with.
Upload configuration.
The upload function is standard disabled in the toolbar.
Service note(s).
The build in text editor gives the possibility to store information about
the current site.
Set date and time.
The current date and time of the CIU Prime / Plus , can be (re-)set.
Print configuration.
The whole configuration can be printed to have a hard copy.
Show diagnostic data.
The build in diagnostic data views, reads and writes data direct from
and to the CIU Prime / Plus.
Tank viewer.
All measured and calculated data from one tank can be viewed.Scan viewer.
The field scan can be viewed.
Help.
The build in help document assists at any time.
User privileges.
Access parameters for different users must be set.
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 17
Configure data inputs
The data inputs (instruments in the field) collect data such as level,
temperature, density and/or pressure. The instruments measure the
data and transmit it upon request of higher layered systems.
Press the ‘Copy’-button to copy the highlighted data input from the list.
Only specific data must be changed afterwards.
When the data input is not in the list (yet), a new data input has to be
created. Press the ‘New’-button to add a data input:
Press the ‘Edit’-button to edit data from the highlighted data input:
- Gauge - Water - Density - Vapour
- Level - Temperature - Pressure - Scan
Press the ‘Delete’-button to remove the highlighted data input from the
list.
Configure data inputs
Page 18
A warning is generated before a log file is extracted while settings
have been entered already.
All dimensions in a gauge log file must be compatible with the
system dimensions.
Gauge
Gauge LOG file
Press the ‘Browse’-button to select a gauge log file.
Press the ‘Extract’-button to fill in the data from the gauge log file in
the next tabs.
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 19
Gauge types ‘816' and ‘818' are only supported via 858 CIU.
Gauge type ‘829' is only supported in 867 emulation mode.
All three gauge types require the extended field address for 858 CIU
or 867 receiver (TOI 858 = P or R, TOI 867 = L).
Gauge type ‘999' is a generic Enraf gauge with no special
processing (default processing used).
General limits:
All instruments from one tank must be connected to the same
FieldPort.
Using BPM cards:
Up to 50 data inputs can be equally divided over the four FieldPorts
of the CIU Prime, with a maximum of 15 data inputs per line.
The instrument address on each port is free selectable between
00...99. The instrument address must be unique for all data inputs on
the same CIU.
Using RS232/485 cards:
Field addresses may contain 3 digit address numbers.
Gauge
 Gauge type Select:: Unknown, 802, 811, 812, 813, 816, 818, 829, 854, 865,
866, 872, 873, 877, 894, 973 or 999
 Gauge details Select:: h for 854 gauges using the ZLQ record
(up to software version SPUA1.0)
 - for 854 gauges
(with software version SPUA2.0 onwards)
Allowed gauge commands
Test gauge Check if allowed (TG; 811, 854, 894 only)
Block gauge Check if allowed (BL; 811, 854, 894 only)
Tank profile Check if allowed (TP; 854, 894 only)
Gauge alarm test Check if allowed (AT; 873 only)
Lock test Check if allowed (LT; 811, 854, 894 only)
Water dip Check if allowed (I3; 811, 854, 894 only)
Interface profile Check if allowed (IP; 854, 894 only)
Verify command Check if allowed (CA; 854, 894 only)
Reset gauge Check if allowed (RS)
Interface 2 command Check if allowed (I2; 854, 894 only)
Configure data inputs
Page 20
Level
Level enabled Check to enable level scan.
 0.1 mm level Check to enable. This selection is only possible if the level dimension
resolution is set to ‘m’ or ‘mm’ and if the gauge type is not 811, 813, 866 or 872.
Negative levels Check to enable. This selection is only possible for gauge types
enabled 854, 872, 873 and 894.
No alarm when gauge in test
Check to disable gauge alarms during operational commands.
Level killed Check to disable level scan.
Manual overwrite Enter manual product level.
First enable level.
Level address Enter level transmission address
Level TOI Select: A, B, C, E or M
Level TOR Select: B, J, L, M or ZLQ (the combination of level TOR ‘ZLQ’ and
level type ‘Ullage’ is not possible. With level type ‘Ullage’,
use level TOR ‘L’).
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 21
Water
Water probe enabled Check to enable water level scan from external probe.
Water dipping enabled Check to enable water level scan from servo gauge.
Offset Enter water level offset
Min. water level Enter minimum water level.
This value is used when no water level is found.
 Manual overwrite Enter manual water level. Only possible if water probe or dip
is enabled
First enable water dip or water probe.
Water address Enter water level transmission address
Water TOI Select: A, B, C, E or M
Water TOR Select: B, J, L, M or ZLQ (the combination of water TOR ‘ZLQ’
and level type ‘Ullage’ is not possible. With level type
‘Ullage’, use water TOR ‘L’)
Water in foreground scan
Check to enable
Configure data inputs
Page 22
Temperature
Temperature enabled Check to enable product temperature scan.
Element type Select: No element available, MRT, MRT with bottom spot, MRT
with bottom and top spot, One spot element, Two spot
element or MTT
Lowest element position
Enter lowest temperature element position.
Product temp. killed Check to disable product temperature scan.
Manual overwrite Enter manual product temperature
First enable temperature.
Temp. address Enter product temperature transmission address
Temp. TOI Select: A, B, C, E or M
Temp. TOR Select: C or ZAG
Temp. in foreground scan
Check to enable
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 23
Density
HIMS (HTMS) enabled Check to enable density scan from HIMS configuration.
Density dip enabled Check to enable density scan from servo gauge.
Min. dip level Enter minimum density level
Manual overwrite Enter manual (=observed) density together with the observed
temperature.
Firs enable HIMS/HTG or Density dip
Density address Enter density transmission address
Density TOI Select: B, C or E
Density TOR Select: ZQQ
Density in foreground scan
Check to enable
Configure data inputs
Page 24
Pressure
Pressure enabled Check to enable vapour pressure scan.
Absolute pressure Select if applicable
Relative pressure Select if applicable
Vapour pressure killed Check to disable vapour pressure scan.
Manual overwrite Enter manual vapour pressure
First enable Pressure
Pressure address Enter vapour pressure transmission address
Pressure TOI Select: A, B, C, E or M
Pressure TOR Select: ZP3
Pressure in foreground scan
Check to enable
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 25
Vapour
Vapour temperature enabled
Check to enable vapour temperature scan.
Vapour temp. killed Check to disable vapour temperature scan.
Manual overwrite Enter manual vapour temperature
First enable vapour temperature.
V. Temp. address Enter vapour temperature transmission address
V. Temp. TOI Select: A, B, C, E or M
V. Temp. TOR Select: C or ZAG
V. Temp. in foreground scan
Check to enable
Configure data inputs
Page 26
Scan
Field Display Indicator Scan enable
Check to enable indicator scan.
Scan address Enter FDI transmission address
Scan TOI Select: A, B, C, E or M
Scan TOR Select: B, C, J, L, M, ZAG, ZLQ, ZP3 or ZQQ
Scan in foreground scan
Check to enable
Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 27
Tank
Linked to tank This field displays the tank name on which the level gauge is
connected. This box is not editable.
Configure tanks
Page 28
Configure tanks
Select or enter a tankname. All tank related data can be entered in
this section.
Press the ‘Copy’-button to copy the highlighted tank name from the
list. Only specific data must be changed afterwards.
When the tank is not in the list (yet), a new tank has to be created.
Press the ‘New’-button to add a tank:
Press the ‘Edit’-button to edit data from the highlighted tank:
- Tank - Vapour - Flow - TCT
- Product - Shell - Roof
Press the ‘Delete’-button to remove the highlighted tank from the list.
Configure tanks
Instruction manual Ensite Pro Configuration Tool Page 29
Tank
Shape Select the tank shape, visualising icon for this tank.
 0...7: Enraf default (0 = No shape defined, 1 = Cylindrical fixed
roof, 2 = Cylindrical with floating roof, 3 = Cylindricalwith
internal floater, 4 = Spherical tank, 5 = Bullet,
6 = Underground bullet, 7 = Irregular cavern)
 8...99: reserved for future expansion by Enraf
100...255: user defined tank shapes. Create your own tank icon,
name it ‘TankShape<nr.>.ico’ and place it in the
‘\Pictures’-subdirectory.
Level type Select: Innage or Ullage/Outage
Volume corr. Select: - None (no Vapour Mass)
- S&W corr. (Liq. Mass from NSV; no Vap. Mass)
- Vapour calc. Liq/Vol Ratio ISO/TC28/SC-3-N
- Vapour calc. Molar Method ISO/TC28/SC-3-N
- Vapour calc. Method API research proj. 44
- Vapour calc. Molar Method ISO 6578
Tank status
Tank available Check if available
Tank scan disabled Check to disable
Configure tanks
Page 30
Air density In case the air density for this tank deviates from the one entered in
global settings it can be manually be edited per tank.
Product
Product name Enter the product’s name
Corrections
 API/ASTM Table Select: - No GSV calculation
- Dref/VCF D1250-1980 T5/6
- Dref/VCF D1250-1980 T23/24
- Dref/VCF D1250-1980 T53/54
- DCF calculation
- TCF calculation
- VCF D4311-1990 T1
- VCF D4311-1990 T2
- Manual VCF entry
- VCF D4311-1996 T1
Prod. Code Select: N.A., A, B, C, D or E
TC Enter expansion factor in 10 /°C (in case of product code ‘C’)-7
Range checking Check to enable temperature and density range checkings
VCF Enter volume correction factor
TCF Enter temperature correction factor
DCF Enter density correction factor
Configure tanks
Instruction manual Ensite Pro Configuration Tool Page 31
Mass Calculation
in air Select if applicable
in vacuum Select if applicable
HIMS/HTMS not allowed
Check to enable
HTG Check to enable
Manual ref. density Enter the product’s reference density
Ref. temperature Enter local reference temperature
S&W Enter sediment and water percentage
Press the ‘Advanced’-button to enable/disable volume calculation
details:
VCF A selection can be made between a calculation in 4 or 5 decimals
Configure tanks
Page 32
Vapour
Data in this tab can only be filled in if in the ‘Tank’-tab the ‘Volume
corrections’ is set to ‘Vapour’.
Vapour calc. details
Liq/Vol. ratio Enter liquid to volume ratio (default = 250).
Molar value Enter molar weight of gas composition (default = 0).
Vapour mass calculation
in air Select if applicable
in vacuum Select if applicable
Configure tanks
Instruction manual Ensite Pro Configuration Tool Page 33
Shell
Tank shell calibrated (W&M)
Check to enable
CTSh correction (acc. API Chapter 12.1)
Check to enable tank shell expansion correction
Tank shell exp. coeff. Enter tank shell expansion coefficient
Tank shell ref. temperature
Enter tank shell reference temperature
Insulation factor Enter tank shell insulation factor. This can be a figure between 0 and
1, in which 1 is for fully insulated tanks.
Configure tanks
Page 34
Flow
Moving detection interval Enter interval time (in s) after which level increase/decrease must be
checked (default = 30 sec).
Moving detection trip level
Enter minimum trip level after which level increase/decrease will be
indicated (default = 0 ).
Flow calculation interval Enter interval time (in s) after which volume increase/decrease must
be checked (default = 60 sec).
Flow calculation damping Enter damping factor (0...1) for stable read-out (default = 0.15).
Configure tanks
Instruction manual Ensite Pro Configuration Tool Page 35
High/low zones
The program will issue a warning if the low value is higher than the
high value.
Roof
Zone 1 Enabled Check to enable
No GOV calculation Check to disable volume calculation when level is in zone 1
No Water Volume calculation
Check to disable
Weight Enter roof weight
High Enter no-go-zone 1 high level
Low Enter no-go-zone 1 low level
Zone 2 Enabled Check to enable
No GOV calculation Check to disable volume calculation when level is in zone 2
No Water Volume calculation
Check to disable
Extra Weight Enter roof weight
High Enter no-go-zone 2 high level
Low Enter no-go-zone 2 low level
Configure tanks
Page 36
TCT
Tank Capacity Table The format of this file can be found in the ‘Instruction manual series
880 CIU Plus’.
Press the ‘Browse’-button to select a tank capacity tableBrowse
Press the ‘View’-button to view the tank capacity tableView
Water volume if no water found
Enter water volume
Shell capacity Enter shell capacity
High level Enter level that corresponds with high TOV (for graphical purposes)
High TOV Enter volume that corresponds with high level
(for graphical purposes in Entis Pro)
Low level Enter level that corresponds with low TOV
(for graphical purposes in Entis Pro)
Low TOV Enter volume that corresponds with low level
(for graphical purposes in Entis Pro)
Configure tanks
Instruction manual Ensite Pro Configuration Tool Page 37
Links
Data in this tab can only be viewed. No entry is possible.
Linked via
Primary CIU Plus The name of the primary CIU Plus is displayed, via which the tank is
connected.
Linked via CIU Prime
Primary The name of the primary CIU Prime is displayed, via which the tank is
connected.
Secondary The name of the secondary CIU Prime is displayed, via which the tank
is connected.
Linked via
Secondary CIU Plus The name of the secondary CIU Plus is displayed, via which the tank
is connected.
Linked via CIU Prime
Primary The name of the primary CIU Prime is displayed, via which the tank is
connected.
Secondary The name of the secondary CIU Prime is displayed, via which the tank
is connected.
Configure CIU Prime
Page 38
Configure CIU Prime
The CIU Prime is an interface between the field instrumentation
(e.g. 854 ATG, 873 SmartRadar, etc.) and inventory systems
(CIU Plus, DCS, PLC, etc.).
Input boards There are four slots available in the CIU Prime. These slots can
handle two different types of boards:
• BPM ( Bi-Phase Mark) to interface the Enraf field bus.
• RS-232C/RS485 input board to interface the 858 CIU.
Output boards Two fixed RS-232C/RS485 output boards interface to a CIU Plus,
DCS, PLC, etc.
Press the ‘Copy’-button to copy the highlighted CIU Prime from the
list. Only specific data must be changed afterwards.
When the CIU Prime is not in the list (yet), a new CIU Prime has to be
created. Press the ‘New’-button to add a CIU Prime:
Configure CIU Prime
Instruction manual Ensite Pro Configuration Tool Page 39
Press the ‘Edit’-button to edit data from the highlighted CIU Prime:
- HostPort 1 - Hot standby - Tambient
- HostPort 2 - FieldPorts
Press the ‘Delete’-button to remove the highlighted data input from the
list.
HostPort 1
Config. name Enter the name of the connected device (up to 10 characters).
RTU address Enter the RTU address (default = 31)
Baudrate Select: 1200, 2400, 4800, 9600 or 19200
Modbus mapping
CIU Plus compliant Select if a CIU Plus is connected to this port. All data will be filled in
on pre-defined positions.
W&M sealed Check if applicable
User specified Select if no CIU Plus is connected to this port. All data will be filled in
on user specified positions. Press the ‘Settings’-button to program
these positions (refer to the chapter ‘Modbus settings’).
Configure CIU Prime
Page 40
If ‘RS-232C’ is selected, while in reality RS-485 hardware is applied,
communication can not be established.
Stop bits Select: 1 or 2
Parity Select: Odd, Even or None
Turn-around delay Enter reply waiting time in ms (default = 100 ms)
Duplex mode Select: Full or Half
Mode Select: RS-232C or RS-485
Multi Party Select: Point-to-point or Multi-drop
HostPort 2
Config. name Enter the name of the connected device (up to 10 characters).
RTU address Enter the RTU address (default = 31)
Baudrate Select: 1200, 2400, 4800, 9600 ,19200 or 38400.
Configure CIU Prime
Instruction manual Ensite Pro Configuration Tool Page 41
If ‘RS-232C’ is selected, while in reality RS-485 hardware is applied,
communication can not be established.
Modbus mapping
CIU Plus compliant Select if there is a CIU Plus connected to this port. All data will be
filled in on pre-defined positions.
W&M sealedCheck if applicable
User specified Select if there is no CIU Plus connected to this port. All data will be
filled in on user specified positions.
Press the ‘Settings’-button to program these positions
(refer to the second next chapter, ‘Modbus settings’).
CIU 858 compatible Check to enable CIU emulation
MSU mode Check to enable
Stop bits Select: 1 or 2
Parity Select: Odd, Even or None
Turn-around delay Enter reply waiting time in ms (default = 100 ms)
Duplex mode Select: Full or Half
Mode Select: RS-232C or RS-485
Multi Party Select: Point-to-point or Multi-drop
Configure CIU Prime
Page 42
If any changes are made to any of the CIU Prime settings (while a
hot standby counterpart is defined), the program will generate a
warning to keep the configurations of both units synchronous.
If ‘Primary’ is selected, while no secondary CIU Prime exists, the hot
standby facility can not be established.
Hot standby
Hot standby enabled Check to enable hot standby functionality
Counterpart Select name of other CIU Prime
Hot standby mode Select: Primary or Secondary
Configure CIU Prime
Instruction manual Ensite Pro Configuration Tool Page 43
The setting in ‘Poll strategy’ determines the sequence in which the
FieldPorts are scanned:
P = FieldPort scans parallel, without waiting for other FieldPorts
1 = FieldPort scans in sequence with other FieldPorts with code 1
2 = FieldPort scans in sequence with other FieldPorts with code 2
Examples:
PPPP = all ports scan parallel (= default)
P111 = port 1 scans parallel; others scan sequentially
1122 = ports 1 and 2 and ports 3 and 4 scan in a separate sequence
PPP1 = all ports scan parallel (sequence 1 contains only one port)
FieldPorts
FieldPort 1, 2, 3, 4
Type Select: None, CIU-GPU (= RS-communication) or BPM-GPU
(= Enraf fieldbus)
Poll strategy Select: 1, 2 or P.
Configure CIU Prime
Page 44
Press the ‘Settings’-button to set the FieldPort communication
settings:
CIU-GPU BPM-GPU
- FieldPort Here the name of the FieldPort is displayed.
- Type Here the type of the FieldPort is displayed.
- Baudrate Select: 1200, 2400, 4800, 9600 Select: 1200 or 2400
or 19200
Configure CIU Prime
Instruction manual Ensite Pro Configuration Tool Page 45
If ‘RS-232C’ is selected, while in reality RS-485 hardware is applied,
communication can not be established.
Note 1
When a field communication fail occurs it is possible to maintain last
valid scan data in the CIU Prime database during a configurable
amount of time. The communication fail delay mechanism is reset on
the reception of data. A field communication fail can be caused by:
- modem delays bad cabling
- no answer because of a re
- initializing gauge
Note 2
When a data fail occurs it is possible to maintain the last valid scan
data in the CIU Prime database during a configurable amount of
time. The data fail mechanism is reset on the reception of valid data.
A data fail can be caused by:
- re-initialization of a gauge
- 802/811 digitizer failure
CIU-GPU BPM-GPU
- Stopbits Select: 1 or 2 N.A.
- Parity Select: Odd, Even or None N.A.
-Turn-around delay Enter reply waiting time in ms (default = 20 ms)
- Handshake Select: Full or Half N.A.
- Mode Select: RS-232C or RS-485 Select: EN-BPM
- FieldPort time-out Enter timeout in ms Enter timeout in ms
(default = 200 ms) (default = 75 ms)
- FieldPort sensitivity N.A. Enter sensitivity (default = 7)
- FieldPort retries Enter number of retries (default = 3)
-Communication fail delay Enter a time between 0 and 255 seconds See note 1
- Data fail delay Enter a time between 0 and 255 seconds See note 2
= Enabled Check to enable N.A.
Configure CIU Prime
Page 46
Tambient
Tamb. Broadcast enable Check to enable
Ambient temperature scan
Tamb. scan enable Check to enable ambient temperature scan.
Tamb. Address Enter ambient temperature transmission address
Tamb. TOI Select: A, B, C, E or M
Tamb. TOR Select: C or ZAG
Configure CIU Plus
Instruction manual Ensite Pro Configuration Tool Page 47
Configure CIU Plus
The CIU Plus calculates volume, standard volume, mass, density,
flow rate, etc. It receives data from the CIU Prime and calculates all
other data. It presents data to higher layered systems like Entis Pro,
SCADA, DCS, etc.
Input boards Two fixed RS-232C/RS485 input boards interface to a CIU Prime.
Output boards Up to four RS-232C/RS485 output boards can be installed to interface
host communication (Modbus) to Entis Pro, SCADA, DCS, etc.
For a description of the Modbus protocol, refer to the related
instruction manual.
Press the ‘Copy’-button to copy the highlighted CIU Plus from the list.
Only specific data must be changed afterwards.
When the CIU Plus is not in the list (yet), a new CIU Plus has to be
created. Press the ‘New’-button to add a CIU Plus:
Configure CIU Plus
Page 48
Press the ‘Edit’-button to edit data from the highlighted CIU Plus:
- HostPorts - FieldPort 1 - Hot standby - FieldPort 2
Press the ‘Delete’-button to remove the highlighted data input from the
list.
HostPorts
HostPort 1, 2, 3, 4
Config. name Enter a name, identifying the connected device (up to 10 characters).
Type Select: None or Modbus RTU
Press the ‘Settings’-button to set HostPort communication settings:
Configure CIU Plus
Instruction manual Ensite Pro Configuration Tool Page 49
Config. name Here the name of the connected device is displayed.
RTU address Here the RTU address of the HostPort is displayed (default = 41).
Baudrate Select: 1200, 2400, 4800, 9600 ,19200 or 38400.
Mode Select: RS-232C or RS-485 (Check the hardware)
Parity Select: Odd, Even or None
Stopbits Select: 1 or 2
Duplex mode Select: Full or Half
Turn around delay Enter reply waiting time in ms (default = 100 ms)
Multi party Select: Point-to-point or Multi-drop
Modbus mapping
Entis Pro conform Select if Entis Pro is connected to this port. All data will be filled in on
pre-defined positions.
W&M sealed Check if applicable
User specified Select if Entis Pro is not connected to this port. All data will be filled in
on user specified positions. Press the ‘Settings’-button to program
Modbus settings.
Modbus settings
Page 50
Modbus settings
Data
Data Orientation Select: Tank oriented (= data grouped by tank) or Data oriented
(= data grouped by entity)
Start address Enter start address (default = 0)
Record interval Enter the number of registers between tank records
(default = 0050 for the Plus/Prime)
Advanced
Always force Data output to Fail if validity indicates failure.
Select to force the modbus registers to FFFFF in case of invalid data.
If not selected the last measured value will be stored
Upon Prime Plus comm.fail. Force data output to Fail
Select to force the modbus registers to FFFFF in case of invalid data.
If not selected the last measured value will be stored
Modbus settings
Instruction manual Ensite Pro Configuration Tool Page 51
Tanks
Tanks Available This column displays all available tanks.
Press the ‘arrow up’-button to move the highlighted tank in the
‘Tanks in User Record’-column one position up.
Press the ‘arrow down’-button to move the highlighted tank in the
‘Tanks in User Record’-column one position down.
Press the ‘arrow right right’-button to move all tanks to the
‘Tanks in User Record’-column.
Press the ‘arrow left left’-button to move all tanks to the
‘Tanks Available’-column.
Press the ‘arrow right’-button to move the highlighted tank in the
‘Tanks Available’-column to the ‘Tanks in User Record’-column.
Press the ‘arrow left’-button to move the highlighted tank in the
‘Tanks in User Record’-column to the ‘Tanks Available’-column.
Tanks in User Record This column displays all tanks, selected for communication.
Modbus settings
Page 52
When links are changed (adding, moving or deleting tanks) after
having the Modbus mapping input, the Modbus mapping of tanks will
be reset to default.
Press the ‘Default’-button to restore all default settings.
Entities
Available Entities This column displays all available entities.
Pressthe ‘arrow up’-button to move the highlighted entity in the
‘ID’-column one position up.
Press the ‘arrow down’-button to move the highlighted entity in the
‘ID’-column one position down.
Press the ‘arrow left left’-button to move all entities in the
‘ID’-column to the ‘Available Entities’-column.
Press the ‘arrow right right’-button to move all entities in the
‘Available entities’-column to the ‘ID’-column.
Modbus settings
Instruction manual Ensite Pro Configuration Tool Page 53
If any changes are made to any of the CIU Plus settings
(while a hot standby counterpart is defined), the program will warn
to keep the configurations of both units synchronous.
Press the ‘arrow left’-button to move the highlighted entity in the
‘ID’-column to the ‘Available Entities’-column.
Press the ‘arrow right’-button to move the highlighted entity in the
‘Available entities’-column to the ‘ID’-column.
# Entity ID number
Name Entity name
type Entity type / dimension
Size Number of registers
Scale Scaling factor
offset Offset value
Entity When in the list an entity is highlighted, it is possible to change the
type, size, scale and/or offset.
Press the ‘Default’-button to restore “Entis Pro default’ default
settings.
Hot standby
Modbus settings
Page 54
If ‘Primary’ is selected, while no secondary CIU Plus exists, the hot
standby facility can not be established.
Hot standby enabled Check to enable hot standby functionality
Counterpart Select name of other CIU Plus
Hot standby mode Select: Primary or Secondary
Connection
Ciu Prime connected to one Plus only
The ports of the CIU Primes and Pluses must be connected according
to the diagram.
CIU Primes connected to both primary and secondary Plus
The ports of the CIU Primes and Pluses must be connected according
to the diagram.
Modbus settings
Instruction manual Ensite Pro Configuration Tool Page 55
If ‘RS-232C’ is selected, while in reality RS-485 hardware is applied,
communication can not be established.
FieldPort 1 & 2
Baudrate Select: 1200, 2400, 4800, 9600 or 19200
Parity Select: Odd, Even or None
Stop bits Select: 1 or 2
Turn around delay Enter reply waiting time in ms (default = 0 ms)
Mode Select: RS-232C or RS-485
Retries Enter number of retries (default = 3)
FieldPort timeout Enter timeout in ms (default = 1100 ms)
Duplex mode Select: Full or Half
Break signal Check to enable
Multi party Select: Point-to-point or Multi-drop
Configure links
Page 56
Configure links
After all individual components (CIU Prime, CIU Plus, tanks and data
inputs) have been configured, they have to be linked to each other.
Data inputs
The left column displays the available tanks, the right column displays
the available data inputs.
Drag a data input from the right list to the tank where it is physically
connected to.
Configure links
Instruction manual Ensite Pro Configuration Tool Page 57
Tanks
The left column displays the available CIU Primes, the right column
displays the available tanks.
Expand the structure of the CIU Prime by clicking the ‘plus’. Now the
four FieldPorts appear.
Drag a tank from the right list to the FieldPort of the CIU Prime where
it is physically connected to.
Configure links
Page 58
CIU Prime
The left column displays the available CIU Pluses, the right column
displays the available CIU Primes.
Expand the structure of the CIU Plus by clicking the ‘plus’. Now the
two FieldPorts appear.
Drag a HostPort of the CIU Prime from the right list to the FieldPort of
the CIU Plus where it is physically connected to.
Press the ‘Overview’-button to have a site overview.
Communication setup
Instruction manual Ensite Pro Configuration Tool Page 59
Communication setup
To be able to communicate via the configuration tool, communication
parameters must be set.
Connected to
Entis Pro Select if connected to Entis Pro
CIU Plus Select if connected to CIU Plus; select CIU Plus name
= HostPort Select CIU Plus HostPort
CIU Prime Select if connected to CIU Prime; select CIU Prime name
= HostPort Select CIU Prime HostPort
PC Port Settings
Comm. port Select communication port of PC where configuration tool is installed
Baudrate Select: 1200, 2400, 4800, 9600, 19200 or 38400.
Parity Select: Odd, Even or None
Stopbits Select: 1 or 2
Turn around delay Select reply waiting time in ms (default = 10 ms)
Retries Enter the number of retries (default = 2)
Reply timeout Enter the reply waiting time (default = 3000 ms)
Communication setup
Page 60
Press the ‘Monitor’-button to view communication.
The following window is shown:
Stop presentation Check to freeze data on the monitor.
Messages
Received
Total Number of received messages
In failure Number of failing messages
Transmitted
Total Number of transmitted messages
Press the ‘Reset’-button to reset the message counters.
Client application Displays the number of applications (programs) running
simultaneously.
Download configuration
Instruction manual Ensite Pro Configuration Tool Page 61
The ‘Unknown’ condition includes the situation where an earlier
attempt to retrieve the CRC has failed due to a communication error.
In case of such an error, the CRC status is always unchanged,
whether it was green, orange or red.
Download configuration
The (new) programmed configuration must be downloaded for the CIU
Prime / Plus to work with. In case a CIU Prime is connected to a Plus
the CIU Prime must be downloaded first as the Plus requires the
CRC’s of Prime.
CIU Prime/CIU Plus These panes displays the following columns
Name Displays the name of the available CIU’s. Click on the name to select.
CRC The CIU Prime / Plus calculates an overall CRC over the settings.
Ensite Pro fetches this CRC after a download and saves it in its
database. The CRC status can be:
Situation Color Text
CRC OK Green Ok
CRC unknown (not yet retrieved) Orange Unknown
CRC wrong Red Mismatch
Changed The Changed status can be ‘Y’ or ‘N’ (Yes/No). The status is ‘Y’ if a
new CIU is created or if any CIU setting is changed. The CRC status
and the Changed status can change independently.
Download configuration
Page 62
When downloading through Entis Pro, the CIU Plus must be
connected to HostPort 1.
After a successful download, all manual overwrite values in the
Ensite Pro settings database will be cleared.
Press the ‘Monitor’-button to view communication. The following
window is shown. For details see the “ Communication setup” chapter.
Press to show Kill CRC’s window. The “Kill CRCs button forces a full
download for the selected CIU.
Press the ‘INI-File’-button to generate a number of files, needed for
Entis Pro. The INI-files can only be generated after the whole
configuration is downloaded in the CIU’s.
Press the ‘Check CRC’-button to refresh the CRC status of the
highlighted CIU. This means that the overall CRC is fetched from the
CIU and compared with the stored CRC in the database.
Press the ‘Download’-button to download the settings of the
highlighted CIU. Depending on the CRC status and the Changed
status a full or a partial (= only changed settings) download will be
started.
Hot standby In case of Hot standby proceed as follows:
• download the Primary CIU Prime
• download the secondary CIU Prime
• download the Primary CIU Plus
• download the Secondary CIU Plus
Upload configuration
Instruction manual Ensite Pro Configuration Tool Page 63
The ‘Unknown’ condition includes the situation where an earlier
attempt to retrieve the CRC has failed due to a communication error.
In case of such an error, the CRC status is always unchanged,
whether it was green, orange or red.
Upload configuration
This function is standard disabled in the toolbar. It is only available for
experienced users. Contact factory. An existing configuration of a
CIU Prime / Plus can be uploaded to work with.
CIU Prime/CIU Plus These panes displays the following columns
Name Displays the name of the available CIU’s. Click on the name to select.
CRC The CIU Prime / Plus calculates an overall CRC over the settings.Ensite Pro fetches this CRC after a download and saves it in its
database. The CRC status can be:
Situation Color Text
CRC OK Green Ok
CRC unknown (not yet retrieved) Orange Unknown
CRC wrong Red Mismatch
Upload configuration
Page 64
When uploading through Entis Pro, the CIU Plus must be connected
through HostPort 1.
Changed The Changed status can be ‘Y’ or ‘N’ (Yes/No). The status is ‘Y’ if a
new CIU is created or if any CIU setting is changed. The CRC status
and the Changed status can change independently.
Press the ‘Monitor’-button to view communication. The following
window is shown. For details see the “ Communication setup” chapter.
Press to show Kill CRC’s window. In case you want to force a full
Upload for the selected CIU.
Always grayed.
Press the ‘Check CRC’-button to refresh the CRC status of the
highlighted CIU. This means that the overall CRC is fetched from the
CIU and compared with the stored CRC in the database.
Press the ‘Upload’-button to upload the settings of the
highlighted CIU.
Service note(s)
Instruction manual Ensite Pro Configuration Tool Page 65
Service note(s)
When information about the current site must be stored, the build in
text editor gives the possibility to do that.
Set date and time
Page 66
The CIU does not switch automatically from winter time to summer
time and back again.
Set date and time
With this menu, the internal clock of a CIU Prime and/or CIU Plus can
be set. Selecting a CIU from the list to see and/or (re-)set the current
data and time.
New Date & Time
 New date and time Check to set new date and time:
= hours select: 00...23
= mins select: 00...59
= secs select: 00...59
= month select: January, February, March, April, May, June, July, August,
September, October, November, December
= year select: 0000...9999
Daylight Saving Time ON
Check to change between summer- and wintertime.
Print configuration
Instruction manual Ensite Pro Configuration Tool Page 67
Print configuration
The whole (site, CIU Prime, CIU Plus, tank, data input) configuration
can be printed to have a hard back-up.
Site Select print template (default = Site.rpt)
Global settings Check to print global settings
CIU Plus Check to print CIU Plus settings; select name and HostPort
CIU Prime Check to print CIU Prime settings; select name and HostPort
Tank settings Check to print tank settings; select name
Data inputs Check to print data input settings; select name
Print configuration
Page 68
Link information Select print template (default = LinkOverview.rpt)
Modbus mapping Select print template (default = ModbusMapping.rpt)
Service notes Select print template
Entity definition Select print template (default = Entity97.rpt)
Press the ‘Preview’-button to see how the print-out will look like.
Press the ‘Print’-button to activate the printer and print the
configuration.
Press the ‘Printer Setup’-button to set the printer parameters.
Show diagnostic data
Instruction manual Ensite Pro Configuration Tool Page 69
Show diagnostic data
This window displays all diagnostic data (serial number, software
version, run hours, last fatal error) of the selected CIU Prime/Plus.
Column description
Entity = entity number
Description = entity name
Index = entity index value
DataSetIndex = where does this data come from
Value = entity value
Press the ‘Print’-button to activate the printer and print the diagnostic
data.
Database analysis In order to analyse an erroneous database of the CIU a printout can
be made. To avoid sending a fax and files separately it is possible to
store the diagnostic printouts into files by pressing the envelope icon
of the report form. Pressing this icon the “Export window” will pop up.
Select the Format and the Destination.
Change the file name and store it. If you now create a ZIP-file of the
complete site the diagnostic is included. You can now e-mail the file.
Backup This can done as follows:
• Use the Widow explorer and locate the root directory of the site
(C:\program\files\Ensite Pro\....)
• Select the site directory, click right and select “add to zip”
(only if WinZIp is installed). Normally the Zip-file will fit on a
floppy disk. If not use the MbdTools to compress the database.
You can find this utility on the Ensite Pro installation CD.
Show diagnostic data
Page 70
Press the ‘R/W Data’-button to read from and/or write to the
CIU Prime/Plus:
The entity detail information can be enabled by pressing the “books” icon.

Request
Press the ‘Jump to’-button to select the entity, matching the number in
the field ‘Entity’. The text of the ‘Jump to’ button will change into ‘Filter’
Press the ‘Filter’-button to select the entities, starting with the number
in the field ‘Entity’.
Entity Enter the required entity number.
Index Enter the entity’s index value.
Data set index Select the tank number where this index relates to.
Value Enter the value to be written. This can be either in Dec. or Hex.
Response
 Value Here the response to the request above is given.
Press the ‘Enter conf’-button to go into configuration mode. It is now
possible to write entities.
Press the ‘Exit conf’-button to go out of configuration mode. It is now
not possible o write entities.
Press the ‘Read’-button to retrieve the value of the requested entity.
Press the ‘Write’-button to overwrite the value of the requested entity.
This is only possible in configuration mode.
Show diagnostic data
Instruction manual Ensite Pro Configuration Tool Page 71
Press the ‘Reset Diagn. Counters’-button to .....
Press the ‘Update’-button to fetch the current values from the selected
CIU Prime/Plus and fill in the ‘Value’-column.
Clear Configuration The clear configuration procedure should only be done when a an
existing database must be replaced by a new one. This procedure
should not be done in case of modifying an existing database.
Click on the R/W button in the “Diagnostic window”. Enter 7502 in the
Entity/name field and hex 30 in the value field and press Write.
Within a few seconds the CIU will be reset. The CIU Prime will
indicate this by simultaneous flashing of the receive and transmit
Led’s of the installed IP modules.
On the CIU Plus a window will pop up with the message
“Letterbox empty caused by reset of CIU”
To be sure that the CIU has completed the previous command, read
the CIU name (Prime entity 502 and Plus entity 602)
The name should be default (“DefPrime” for the CIU prime and
“DefPlus” for CIU Plus).
Clear Novram The clear Novram procedure should only be done when a an existing
database must be replaced by a new one. This procedure should not
be done in case of modifying an existing database.
Click on the R/W button in the “Diagnostic window”. Enter 7507 in the
Entity/name field and press Write. Within a few seconds the CIU will
be reset. The CIU Prime will indicate this by simultaneous flashing of
the receive and transmit Led’s of the installed IP modules.
On the CIU Plus a window will pop up with the message “Letterbox
empty caused by reset of CIU”
To be sure that the CIU has completed the previous command, read
the CIU name ( Prime entity 502 and Plus entity 602) The name
should be default (“0” for the CIU prime and “CIUPlus” for CIU Plus).
Tank viewer
Page 72
Tank viewer
The tank viewer displays all details for a single tank.
CIU Select the CIU Prime/Plus
Tank Select the tank
Product Here the product name is displayed
(CIU) (Tank) (Product)
Global settings
Field data Inventory data Reference data
Press the ‘Print’-button to activate the printer and print the current
view.
Scan viewer
Instruction manual Ensite Pro Configuration Tool Page 73
Scan viewer
The scan viewer displays the scanning sequence, showing the data
inputs being requested.
CIU Select CIU to work with
Column description Tank name = tank name
AT = ambient temperature # = scan sequence nr.
VP = vapour pressure PL = product level
OD = observed density WL = water level
PT = product temperature VT = vapour temperature
FG-tim = time oflast foreground scan
BG-tim = time of last background scan
Measured data statuses The displayed status is build up out of two characters, being:
1st character: F = foreground scan
B = background scan
X = not scanned
2nd character: - = measured data
K = killed data
& = manual data
F = communication fail
Press the ‘Print’-button to activate the printer and print the current
view.
Help
Page 74
Help
Click on this icon for on-line assistance.
User privileges
Instruction manual Ensite Pro Configuration Tool Page 75
User privileges
The configuration tool can be operated by different users. The list box
displays all users that already exist.
Press the ‘New User’-button to add a new user to the list
Name Enter user name
Password Enter password
Confirm password Enter password again to confirm
Press the ‘Change Password’-button to change the password of a
user that already exists:
Old password Enter the old password
New password Enter the new password
Confirm new password Enter new password again to confirm
Press the ‘Delete’-button to remove the highlighted user from the list.
Stop Ensite Pro
Page 76
XX Stop Ensite Pro
To stop the configuration tool, press the ‘X’-button in the upper right
corner of the configuration tool window. Next, the action has to be
confirmed:
After confirmation, the configuration tool window will be closed. To
use the configuration tool again, is has to be (re-)started.
Appendix A
Instruction manual Ensite Pro Configuration Tool Page 77
Appendix A: related documents
Title
Installation guide Ensite Pro configuration tool
Instruction manual series 880 CIU Prime
Instruction manual series 880 CIU Plus
Notes
Page 78
Notes
Instruction manual Ensite Pro Configuration Tool Page 79
: +31 15 2698600
: info@enraf.nl
: http://www.enraf.com
We at Enraf are committed to excellence.
Enraf is a registered trademark� Enraf B.V. Netherlands�
Your Enraf distributor
Information in this publication is subject to change without notice.
Röntgenweg 1
2624 BD, Delft
Tel.
E-mail
Website
P.O. Box 812
2600 AV, Delft
Netherlands
Page 80
	Preface
	Table of Contents
	Introduction
	Ensite Pro configuration tool - General
	Configuration Procedure
	Procedure steps
	Preparation
	Retrieving configuration data of gauges
	Configuration of the Tanks
	Configuration of CIU Prime’s
	Configuration of CIU Plus’s
	Linking Gauges, Tanks and CIU’s
	Downloading configuration data
	Start Ensite Pro
	Select site
	Global settings
	Configure data inputs
	Gauge
	Level
	Water
	Temperature
	Density
	Pressure
	Vapour
	Scan
	Tank
	Configure tanks
	Tank
	Product
	Vapour
	Shell
	Flow
	Roof
	TCT
	Links
	Configure CIU Prime
	HostPort 1
	HostPort 2
	Hot standby
	FieldPorts
	Tambient
	Configure CIU Plus
	HostPorts
	Modbus settings
	Data
	Tanks
	Entities
	Hot standby
	FieldPort 1 & 2
	Configure links
	Data inputs
	Tanks
	CIU Prime
	Communication setup
	Download configuration
	Upload configuration
	Service note(s)
	Set date and time
	Print configuration
	Show diagnostic data
	Tank viewer
	Scan viewer
	Help
	User privileges
	Stop Ensite Pro
	Appendix A: related documents
