Outdoor Directional Quad-band Antenna ODI-065R15NB18JJ02-GQ V1 XXXX Pol, 65°Horizontal Beamwidth 694-806/824-960/1695-2690/1695-2690MHz 13.5/14.2/17.6/17.6dBi, E-Tilt: 2-14/2-14/2-12/2-12 Integrated RCU ©Comba Telecom. All rights reserved Information contained in this document is subject to confirmation at time of ordering. 1/3 Specifications may differ depending on region and customers’ requirements. DS-Control: 1-0-1 / 1121 Electrical Specifications Frequency Range (MHz) R1 694-806 R2 824-960 694-806 824-894 880-960 Polarization ±45° Electrical Downtilt (°) 2-14 2-14 Gain (dBi) Over All Tilts 13.3±0.5 13.6±0.6 13.7±0.6 Min Tilt 13.5 14.1 14.2 Mid Tilt 13.3 13.6 13.7 Max Tilt 13.1 13.2 13.3 Horizontal Beamwidth (°) 67±4 62±2 63±2 Vertical Beamwidth (°) 16.8±1.2 15.2±0.7 13.9±1.3 Electrical Downtilt Deviation (°) ≤1.0 ≤1.0 ≤1.0 1st Upper Sidelobe Suppression (dB) ≥15 ≥17 ≥17 Upper Sidelobe Suppression, Peak to 20° (dB) ≥16 ≥16 ≥18 Front-to-Back Ratio, 180°30° (dB) ≥25 ≥24 ≥25 Cross-polar Discrimination@0° (dB) ≥23 ≥23 ≥22 Cross-polar Discrimination over Sector (dB) ≥8 ≥6 ≥8 Isolation Intra-system (dB) ≥25 Isolation Inter-system (dB) ≥25(R1/R2) ≥28(R1/Other bands) ≥25(R2/R1) ≥28(R2/Other bands) Maximum Power per Port (W) 400 Frequency Range (MHz) Y1 1695-2690, Y2 1695-2690 1695-1880 1850-1990 1920-2170 2300-2500 2490-2690 Polarization ±45° Electrical Downtilt (°) 2-12 / 2-12 Gain (dBi) Over All Tilts 16.2±0.5 16.6±0.5 16.8±0.5 17.0±0.6 17.0±0.7 Min Tilt 16.3 16.7 17.0 17.4 17.6 Mid Tilt 16.2 16.6 16.8 17.0 16.9 Max Tilt 16.0 16.4 16.5 16.6 16.6 Horizontal Beamwidth (°) 65±5 62±6 64±5 68±3 68±4 Vertical Beamwidth (°) 7.9±0.8 7.4±0.6 7.0±0.6 6.1±0.4 6.0±0.6 Electrical Downtilt Deviation (°) ≤0.5 ≤0.5 ≤0.6 ≤0.8 ≤0.5 1st Upper Sidelobe Suppression (dB) ≥15 ≥15 ≥15 ≥14 ≥14 Upper Sidelobe Suppression, Peak to 20° (dB) ≥15 ≥15 ≥15 ≥14 ≥14 Front-to-Back Ratio, 180°30° (dB) ≥26 ≥27 ≥25 ≥25 ≥24 Cross-polar Discrimination@0° (dB) ≥24 ≥25 ≥21 ≥23 ≥22 Cross-polar Discrimination over Sector (dB) ≥12 ≥10 ≥8 ≥11 ≥6 Isolation Intra-system (dB) ≥28 Isolation Inter-system (dB) ≥28 Maximum Power per Port (W) 250 Values based on NGMN recommendations on Base Station Antenna Standards (BASTA). VSWR ≤1.5:1 IM3 (2x43 dBm Carrier) (dBc) ≤-150 Maximum Effective Power Whole Antenna (W) 800 Impedance (Ω) 50 Lightning Protection Direct Ground Outdoor Directional Quad-band Antenna ODI-065R15NB18JJ02-GQ V1 XXXX Pol, 65°Horizontal Beamwidth 694-806/824-960/1695-2690/1695-2690MHz 13.5/14.2/17.6/17.6dBi, E-Tilt: 2-14/2-14/2-12/2-12 Integrated RCU ©Comba Telecom. All rights reserved Information contained in this document is subject to confirmation at time of ordering. 2/3 Specifications may differ depending on region and customers’ requirements. DS-Control: 1-0-1 / 1121 Mechanical Specifications Outline Drawing Dimensions, HxWxD (mm) / (in) 1400x355x192 / 55.1x14.0x7.6 Shipping Dimensions, HxWxD (mm) / (in) 1715x440x265 / 67.5x17.3x10.4 Net Weight, Antenna (kg) / (Ib) 24.0 / 52.9 Net Weight, Mounting Kit (kg) / (Ib) 5.4 / 11.9 Shipping Weight (kg) / (Ib) 33.4 / 73.6 Connector Type 8 x 4.3-10 Female Connector Location Bottom Radome Material and Color Fiberglass, Light Grey Operational Temperature (°C) -40 to +65 Operational Humidity (%) ≤95 Max Wind Speed (km/h) 241 Wind Load @150km/h Frontal / Lateral / Rearside (N) 310 / 110 / 289 Max Wind Load @150km/h (N) 387 Mast Diameter Supported (mm) 50-115 RET Specifications RET Type Integrated motor, replaceable Protocol to CCU/TMA 3GPP / AISG 2.0 Input Voltage Range (V) +10 to +30 DC Power Consumption (W) ≤2(stand by); ≤13(operating) Connectors to CCU 2x8 pin connector, Male, conform to AISG 2.0 Connectors to RCU 2x8 pin connector, Female, conform to AISG 2.0 Dimensions, HxWxD (mm) / (in) (excluding connector) 171x165x34 / 6.7x6.5x1.3 Weight (kg) / (lb) 0.8 / 1.8 Outdoor Directional Quad-band Antenna ODI-065R15NB18JJ02-GQ V1 XXXX Pol, 65°Horizontal Beamwidth 694-806/824-960/1695-2690/1695-2690MHz 13.5/14.2/17.6/17.6dBi, E-Tilt: 2-14/2-14/2-12/2-12 Integrated RCU ©Comba Telecom. All rights reserved Information contained in this document is subject to confirmation at time of ordering. 3/3 Specifications may differ depending on region and customers’ requirements. DS-Control: 1-0-1 / 1121 Connector Position Configuration Types 355 192 Connector Labeling* Connect Code Frequency range Port number Array R1 694-806 1-2 c R2 824-960 3-4 c Y1 1695-2690 5-6 l Y2 1695-2690 7-8 r *R-Red, Y-Yellow, B-Blue, P-Purple, l-left array, r-right array, c-center array, t-top array, b-bottom array, m-middle array. Accessories Model Quantity Description 00-ZJ26A(12) 1 Mounting Kit, 0-12°tilt. IRCU-C414 1 Integrated RET Controller Optional Products (order separately) Model Quantity Description PCU-H002 1 Portable Control Unit R1 Y2Y1 R2
