Philips-Chassis-TPM15 6L-LA

Prévia do material em texto

Published by YPC/SC 1528 Quality Printed in the Ne herlands Subject to modification EN 3122 785 19771
2015-July-10
 © TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Colour Television Chassis
TPM15.6L
LA
Contents Page Contents Page
1 Revision List 2
2 Technical Specs Diversity and Connections 2
3 Precautions Notes and Abbreviation List 7
4 Mechanical Instructions 11
Cable dressing (24" PHG4100 series) 11
Cable dressing (32" PFG5000 series) 12
Cable dressing (32"PHG5000 series) 12
Cable dressing (40" 5000 series) 13
Cable dressing (48" 5000 series) 13
5 Service Modes Error Codes and Fault Finding 20
6 Alignments 28
7 Circuit Descriptions 30
8 IC Data Sheets 35
9 Block Diagrams
Block diagram 4100 & 5000 series 41
10 Circuit Diagrams and PWB Layouts Drawing PWB
A 715G6550 PSU 42 44-45
A 715G6863 PSU 46 47-48
A 715G6934 PSU 49 51-52
A 715G6338 PSU 53 58-59
B 715G6836 SSB 60 76-77
J 715G61767 IR/LED Panel 78 79
J 715G7325 IR/LED Panel 80 81
E 715G6316 Keyboard control panel 82 83
11 Styling Sheets
5000 series 32" 84
4100 series 24" 85
5000 series 40" 86
5000 series 48" 87
Revision List 2 TPM15.6L LA1.
2015-July-10 back to
div.table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 2: Updated table 2.1 Technical Specifications and
connection 2.4 Connections (for 4100 series).
• Chapter 4: Added figure 4-1 Cable dressing (24"
PHG4100 series) and section 4.4 Assembly/Panel
Removal (for 4100 series).
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview.
• Chapter 7: Updated table 7-1 Connector overview.
• Chapter 10: Added circuit diagram 10.7 J 715G7325
IR/LED Panel.
• Chapter 11: Added styling sheet 11.2 4100 series 24".
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections (for 5000 series)
2.4 Connections (for 4100 series)
2.5 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in back to
div.table 2-1. Here is product information available, as well as
getting started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
2 4 9 10 11
C
o
n
n
ec
ti
o
n
 O
ve
rv
ie
w
Mechanics
B
lo
ck
 D
ia
g
ra
m
Schematics
S
ty
lin
g
W
ir
e
D
re
ss
in
g
R
ea
r
C
o
ve
r
R
em
o
va
l
S
ta
n
d
 R
em
o
va
l
S
S
B
 R
em
o
va
l
P
o
w
er
 S
u
p
p
ly

S
S
B
J
(I
R
/L
E
D
)
E
 (
K
ey
 b
o
ar
d
/L
ea
d
in
g
 E
d
g
e)
24PHG4100/77 2-5 4-1 4-10 4-10 4-12 9.1 10.2 10.5 10.7 10.8 11 2
32PFG5000/77 2-1 4-2 4-7 4-6 4-9 9.1 10.1 10.5 10.6 10.8 11.1
32PHG5000/77 2-1 4-3 4-7 4-6 4-9 9.1 10.2 10.5 10.6 10.8 11.1
40PFG5000/77 2-1 4-4 4-7 4-6 4-9 9.1 10.3 10.5 10.6 10.8 11 3
48PFG5000/77 2-1 4-5 4-7 4-6 4-9 9.1 10.4 10.5 10.6 10.8 11.4
http://www.p4c.philips.com/cgi-bin/dcbint/cpindex.pl?ctn=24PHG4100/77&dct=PSS&scy=GB
http://www.p4c.philips.com/cgi-bin/dcbint/cpindex.pl?ctn=32PFG5000/77&dct=PSS&scy=GB
http://www.p4c.philips.com/cgi-bin/dcbint/cpindex.pl?ctn=32PHG5000/77&dct=PSS&scy=GB
http://www.p4c.philips.com/cgi-bin/dcbint/cpindex.pl?ctn=40PFG5000/77&dct=PSS&scy=GB
http://www.p4c.philips.com/cgi-bin/dcbint/cpindex.pl?ctn=48PFG5000/77&dct=PSS&scy=GB
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
Technical Specs, Diversity, and Connections 3TPM15.6L LA 2.
2015-July-10back to
div.table
2.3 Connections (for 5000 series)
Figure 2-1 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.3.1 Side Connections
1 - USB2 2.0
Figure 2-2 USB (type A)
1 - +5V �
2 - Data (-) ��
3 - Data (+) ��
4 - Ground Gnd �
2- Head phone (Output)
Bk - Head phone 80 - 600 W / 10 mW
 ��
3 - EXT: Video YPbPr - In, Audio - In
Gn - Video - CBVS2 1 VPP / 75 W ��
Wh - Audio - L 0.5 VRMS / 10 kW ��
Rd - Audio - R 0.5 VRMS / 10 kW ��
2.3.2 Rear Connections
4- TV ANTENNA - In
Signal input from an antenna, cable or satellite.
5 - Service / UART
1 - Ground Gnd �
2 - UART_TX Transmit �
3 - UART_RX Receive �
6- HDMI 2: Digital Video - In, Digital Audio with ARC - In/Out
Figure 2-3 HDMI (type A) connector
1 - D2+ Data channel �
2 - Shield Gnd �
3 - D2- Data channel �
4 - D1+ Data channel �
5 - Shield Gnd �
6 - D1- Data channel �
7 - D0+ Data channel �
8 - Shield Gnd �
9 - D0- Data channel �
10 - CLK+ Data channel �
11 - Shield Gnd �
12 - CLK- Data channel �
13 - Easylink/CEC Control channel ��
14 - ARC Audio Return Channel �
15 - DDC_SCL DDC clock �
16 - DDC_SDA DDC data ��
17 - Ground Gnd �
18 - +5V �
19 - HPD Hot Plug Detect �
20 - Ground Gnd �
TV ANTENNA
L
R
USB
CVBS
HDMI 1
HDMI 2
ARC
SERV.U
19770_001 eps
4
3
2
1
5
8
7
Side ConnectorsRear Connectors
6
SPDIF
 OUT
1 2 3 4
10000_022_090121 eps
090121
10000_017_090121.eps
090428
19 1
18 2
Technical Specs, Diversity, and Connections 4 TPM15.6L LA2.
2015-July-10 back to
div.table
7- HDMI 1: Digital Video - In, Digital Audio with ARC - In/Out
Figure 2-4 HDMI (type A) connector
1 - D2+ Data channel �
2 - Shield Gnd �
3 - D2- Data channel �
4 - D1+ Data channel �
5 - Shield Gnd �
6 - D1- Data channel �
7 - D0+ Data channel �
8 - Shield Gnd �
9 - D0- Data channel �
10 - CLK+ Data channel �
11 - Shield Gnd �
12 - CLK- Data channel �
13 - Easylink/CEC Control channel ��
14 - ARC Audio Return Channel �
15 - DDC_SCL DDC clock �
16 - DDC_SDA DDC data ��
17 - Ground Gnd �
18 - +5V �
19 - HPD Hot Plug Detect �
20 - Ground Gnd �
8 - Cinch: Digital Audio - Out
BK - Coaxial 0.4 - 0.6VPP / 75 W ��
10000_017_090121.eps
090428
19 1
18 2
Technical Specs, Diversity, and Connections 5TPM15.6L LA 2.
2015-July-10back to
div.table
2.4 Connections (for 4100 series)
Figure 2-5 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.4.1 Side Connections
1 - USB2 2.0
Figure 2-6 USB (type A)
1 - +5V �
2 - Data (-) ��
3 - Data (+) ��
4 - Ground Gnd �
2- Head phone (Output)
Bk - Head phone 80 - 600 W / 10 mW
 ��
3 - EXT: Video YPbPr - In, Audio - In
Gn - Video - CBVS2 1 VPP / 75 W ��
Wh - Audio - L 0.5 VRMS / 10 kW ��
Rd - Audio - R 0.5 VRMS / 10 kW ��
2.4.2 Rear Connections
4- TV ANTENNA - In
Signal input from an antenna, cable or satellite.
5 - Service / UART
1 - Ground Gnd �
2 - UART_TX Transmit �
3 - UART_RX Receive �
6- HDMI 2: Digital Video - In, Digital Audio with ARC - In/Out
Figure 2-7 HDMI (type A) connector
1 - D2+ Data channel �
2 - Shield Gnd �
3 - D2- Data channel �
4 - D1+ Data channel �
5 - Shield Gnd �
6 - D1- Data channel �
7 - D0+ Data channel �
8 - Shield Gnd �
9 - D0- Data channel �
10 - CLK+ Data channel �
11 - Shield Gnd �
12 - CLK- Data channel �
13 - Easylink/CEC Control channel ��
14 - ARC Audio Return Channel �
15 - DDC_SCL DDC clock �
16 - DDC_SDA DDC data ��
17 - Ground Gnd �
18 - +5V �
19 - HPD Hot Plug Detect �
20 - Ground Gnd �
TV ANTENNA
L
R
USB
CVBS
HDMI 1
HDMI 2
ARC
SERV.U
VGA / DVI
AUDIO IN(RGB/CVBS)SCART
19771_001.eps
4
3
2
1
5and Service Alignment Mode to
be accessed.
5.8.3 No Picture
When you have no picture, first make sure you have entered
the correct display code. See paragraph 6.4 Option Settings for
the instructions. See also back to div.table 6-3.
5.8.4 Unstable Picture via HDMI input
Check (via ComPair or factory mode) if HDMI EDID data is
properly programmed.
5.8.5 No Picture via HDMI input
Check if HDCP key is valid. This can be done in CSM.
5.8.6 TV Will Not Start-up from Stand-by
Possible Stand-by Controller failure. Re-flash the software.
5.8.7 Audio Amplifier
The Class D-IC U606 has a powerpad for cooling. When the IC
is replaced it must be ensured that the powerpad is very well
pushed to the PWB while the solder is still liquid. This is needed
to insure that the cooling is guaranteed, otherwise the Class
D-IC could break down in short time.
5.8.8 CSM
When CSM is activated and there is a USB memory stick
connected to the TV, the software will dump the complete CSM
content to the USB memory stick. The file (Csm.txt) will be
saved in the root of the USB memory stick.
5.8.9 Loudspeakers
Make sure that the volume is set to minimum during
disconnecting the speakers in the ON-state of the TV. The
audio amplifier can be damaged by disconnecting the speakers
during ON-state of the set!
5.8.10 Display option code
Attention: In case the SSB is replaced, always check the Panel
Code in CSM, even when picture is available. Performance
with the incorrect display option code can lead to unwanted
side-effects for certain conditions.
Layer-2 error code Defective device
13 General I2C bus error on the SSB
16 +12 V missing or low, PSU defective
27 Channel decoder error on the SSB
34 Tuner I2C bus error on the SSB
35 EEPROM I2C error on SSB, M24C64
Alignments 28 TPM15.6L LA6.
2015-July-10 back to
div.table
6. Alignments
Index of this chapter:
6.1 General Alignment Conditions
6.2 Hardware Alignments
6.3 Software Alignments
6.4 Option Settings
6.5 Reset of Repaired SSB
6.1 General Alignment Conditions
Perform all electrical adjustments under the following
conditions:
• Power supply voltage: 90 - 264 VAC, 50/ 60 ± 3 Hz.
• Connect the set to the mains via an isolation transformer
with low internal resistance.
• Allow the set to warm up for approximately 15 minutes.
• Measure voltages and waveforms in relation to correct
ground (e.g. measure audio signals in relation to
AUDIO_GND).
Caution: It is not allowed to use heat sinks as ground.
• Test probe: Ri > 10 MW, Ciloading of the
CTN and production code can also be done via ComPair
(Model number programming).
In case of a display replacement, reset the “Operation hours
display” to “0”, or to the operation hours of the replacement
display.
Remark:
- After the NVM has been replaced, go to SAM and scroll to the
 (see figure 1*).
- Select the item and press on the RC.
6.5.1 Reset of Repaired SSB
Instruction
After NVM replacement, reload MAC address via SAM
menu.This ensures the correct MAC address to be available in
CSM for future repair actions.
Way of working:
• After the NVM has been replaced, go to SAM and scroll to
the .
• Select the item and press on the RC.
• Only applicable to all related models that are “Smart TV
level 0”enabled (only YouTube access). For models
without internet connection feature, no action is needed.
• HDCP keys are located in the NVM. If you are loading NVM
with the ComPair tool, there is warning message displayed.
New NVM EEPROMs are shipped with pre-loaded HDCP keys.
6.5.2 SSB Identification
SSB’s of this chassis are identified by a “715” code on the SSB.
715Axxxx-Nnn-MMM-OOOO
• 715 main category, Printed Wiring Board
• Axxxx sub category, sequential coding number
• Nnn Version code
• N Development number
• nn Production number
• MMM Mounting variation code
• OOOO Optional variation code
Make sure when replacing an SSB the SSB identification codes
match the replacement panel.
Notes:
CTN ALT BOM# Panel Type Display Code
24PHG4100/77 TPM236H3-BJ1L01 188
32PFG5000/77 TPT315B5-EUJFFE S1J 185
32PHG5000/77 TPT315B5-0TU3A.Q S11E 172
32PHG5000/77 TPT315B5-XVN02 S900J 178
40PFG5000/77 TPT400LA-J6PE1 SC1AN 173
40PFG5000/77 TPT400LA-J6PE1 SC1AL 186
48PFG5000/77 TPT480H2-HWU23 SC2C 174
48PFG5000/77 TPT480H2-HWU23 SC2G 183
48PFG5000/77 TPT480LS-HN05.S SB01J 189
Circuit Descriptions 30 TPM15.6L LA7.
2015-July-10 back to
div.table
7. Circuit Descriptions
Index of this chapter:
7.1 Introduction
7.2 Power Supply
7.3 DC/DC Converters
7.4 Front-End Analogue and DVB-T, DVB-C; ISDB-T reception
7.5 HDMI
7.6 Video and Audio Processing - MT5561LVNT/B PBGA-329
Notes:
• Only new circuits (circuits that are not published recently)
are described.
• Figures can deviate slightly from the actual situation, due
to different set executions.
• For a good understanding of the following circuit
descriptions, please use the wiring, block (see chapter
9. Block Diagrams) and circuit diagrams (see chapter
10. Circuit Diagrams and PWB Layouts).Where necessary,
you will find a separate drawing for clarification.
7.1 Introduction
The TPM15.6L LA is a new chassis launched in LATAM in
2015. The whole range is covered by MT5561.
The major deltas versus its predecessor support NTSC;
PAL-M; PAL-N AND ISDB-T with also multi-media, CEC,
ARC, SPDIF functionality.
The TPM15.6L LA chassis comes with the following stylings:
• series xxPxG5000xx
• series xxPHG4100xx
7.1.1 Implementation
Key components of this chassis are:
• SCALER MT5561LVNT/B PBGA-329
• FLASH TC58NVG1S3HTAI0 2GB TSOP-48
• Tuner: RF V/T 5P 1*1 - 9mm
• Silicon Tuner MxL661-AG-R
• DEMODULATOR TC90537FG LQFP-48 for tuner signal
demodulation
• AUDIO TAS5729MDDCAR 10W TSSOP-48 for AUDIO
Amplifier.
7.1.2 TPM15.6L LA Architecture Overview
For details about the chassis block diagrams refer
to 9. Block Diagrams.
Circuit Descriptions 31TPM15.6L LA 7.
2015-July-10back to
div.table
7.1.3 SSB Cell Layout
Figure 7-1 SSB layout cells (top view)
19770_200.eps
USB
Headphone
SERVICE
CONNECTOR
HDMI
HDMI
ANALOG I/O
MT5561
TUNER
DDR
DC/DC
SPDIF
OUT
Circuit Descriptions 32 TPM15.6L LA7.
2015-July-10 back to
div.table
7.2 Power Supply
Refer to figure Figure 7-2 for the power architecture of this
platform.
Figure 7-2 Power Architecture
7.2.1 Power Supply Unit
All power supplies are a black box for Service. When defective,
a new board must be ordered and the defective one must be
returned, unless the main fuse of the board is broken. Always
replace a defective fuse with one with the correct
specifications! This part is available in the regular market.
Consult the Philips Service web portal for the order codes of the
boards.
Important delta’s with the TPM15.6L LA classis platform are:
• New power architecture for LED backlight
• “Boost”-signal is now a PWM-signal + continuous variable.
The control signals are:
• Stand-by (PS_ON)(only for 48 inch-715G6338)
• Lamp “on/off”
• Backlight adjust (DIM) (not for PSDL)
In this manual, no detailed information is available because of
design protection issues.
The output voltages to the chassis are:
• 12V output (stand-by and on-mode for 32 and 40 inch)
• 8.5V output (stand-by for 48 inch)
• 12V output (on-mode for 48 inch)
• +12V_audio (audio AMP power) (on-mode)
• Output to the display; in case of
- IPB: High voltage to the LCD panel
- PSL and PSLS (LED-driver outputs)
- PSDL (high frequent) AC-current.
7.2.2 Diversity
The diversity in power supply units is mainly determined by the
diversity in displays.
The following displays can be distinguished:
• CCFL/EEFL backlight: power panel is conventional IPB
• LED backlight:
- side-view LED without scanning: PSL power panel
- side-view LED with scanning: PSLS power panel
- direct-view LED without 2D-dimming: PSL power panel
- direct-view LED with 2D-dimming: PSDL power panel.
PSL stands for Power Supply with integrated LED-drivers.
PSLS stands for a Power Supply with integrated LED-drivers
with added Scanning functionality (added microcontroller).
PSDL stands for a Power Supply for Direct-view LED backlight
with 2D-dimming.
19770_201 eps
Display power
Platform
MTK5561
PFC
Platform power
1 power- PCB
LVDS AMP
Low stby
power
Ac-input + Mains filter
BL-ON/OFF
AC IN
CN9901
CN8802(FOR 715G6550)
CN8601(FOR 715G6934)
CN8101(FOR 715G6338)
DIM
12V
12V-Audio
12V
CN701
 AMP
12V
CN8604(FOR 715G6863)
Circuit Descriptions 33TPM15.6L LA 7.
2015-July-10back to
div.table
7.2.3 Connector overview
Table 7-1 Connector overview
7.3 DC/DC Converters
The on-board DC/DC converters deliver the following voltages
(depending on set execution):
• +3V3SB, transform from +12V and +5VSB by DCDC,
permanent voltage for the Stand-by controller, LED/IR
receiver and controls.
• +12V, input from the power supply for the panel common
(active mode)
• +12V, input from the power supply for audio amplifier
• VCCK,AVDD1V2, core voltage supply for MT5561
• +DDRV(1.5V),for the DDR integrated in Scaler IC
• +3V3, general supply voltage
• +5V_sw, supply voltage for USB
• TUNER3.3V, supply voltage for tuner
• TUNER3.3V TUNER1V8, voltage for ATV single decoder.
• +1V2, voltage for DTV single decoder.
Figures gives a graphical representation of the DC/DC
converters with its current consumptions :
Figure 7-3 DC/DC converters
Number
Connector
32"PFG5000 32"PHG5000 & 32"PHG4100 40" 48"
CN9101 CN8602 CN9101 CN8604 CN9101 CN8601 CN9301 CN8101
Description to SSB to Panel to SSB to Panel to SSB to panel to SSB to panel
Pin 14 6 14 6 14 9 14 12
1 D M VLED+ DIM VLED+ DIM VLED+ D M VLED+
2 ON/OFF VLED+ ON/OFF VLED+ ON/OFF n.c. ON/OFF n.c.
3 PS_ON n.c. PS_ON n c. PS_ON n.c. PS_ON VLED_1
4 n c. n.c. n.c. n c. n.c. n.c. n c. VLED_1
5 GND LED- GND LED_ GND n.c. GND- n.c.
6 GND LED- GND LED_ GND VLED- GND n.c.
7 GND - GND - GND VLED- GND n.c.
8 GND - GND - GND n.c. GND n.c.
9 +12V_AUDIO - +12V_AUDIO - +12V_AUDIO VLED- +12V_AUDIO VLED_2
10 +12V_AUDIO - +12V_AUDIO - +12V_AUDIO - +12V_AUDIO VLED_2
11 +12V - +12V - +12V - +12V n.c.
12 +12V - +12V - +12V - +12V VLED+
13 +12V - +12V_AL - +12V_AL - +12V -
14 +12V - +12V_AL - +12V_AL - +12V -
15 - - - - - - - -
16 - - - - - - - -
19770_202.eps
+12V_AMP
FB403
FB414
5V_Normal
FB702
AVDD_AU
Q701
DVDD3V3
AVDD3V3
U116
APL3511
FB601
U601
AD87588
AVDD_DMPLL
U702
G903T63UF
+12V
PVDD_L
U706
SY8104ADC VCCK (1.2V)
FB602
FB703
VCC3.3VA_A1
+12VSB_PRE
U503
G529A1TP1U
+5V_SBWi-Fi_VCC
+3.3V_SB
AO3401A
U703
M5723B-33F61U
U705
G5695T11U
FB413
PVDD_R
R719
AVDD1V2 (1.2V)
FB504
MHL
Circuit Descriptions 34 TPM15.6L LA7.
2015-July-10 back to
div.table
7.4 Front-End Analogue and DVB-T, DVB-C;
ISDB-T reception
7.4.1 Front-End Analogue part
The Front-End for analogue tuner consist of the following key
components:
• Tuner: RF V/T 5P 1*1 - 9mm
• Silicon Tuner MxL661-AG-R
• SCALER MT5561LVNT/B PBGA-329
Below find a block diagram of the front-end application for
analogue part.
Figure 7-4 Front-End Analogue block diagram
7.4.2 DTV part
The Front-End for DVT part consist of the following key
components:
• Tuner: RF V/T 5P 1*1 - 9mm
• Silicon Tuner MxL661-AG-R (NTSC,PAL-M, PAL-N and
ISDB-T)
• SCALER MT5561LVNT/B PBGA-329
• DEMODULATOR TC90537FG LQFP-48 for tuner signal
demodulation
Below find a block diagram of the front-end application for DTV
part.
Figure 7-5 Front-End DVB-T2 DTV block diagram
7.5 HDMI
Refer to figure 7-6 HDMI input configuration for the application.
Figure 7-6 HDMI input configuration
The following HDMI connector can be used:
• HDMI 1: HDMI input ( TV digital interface support HDCP)
with digital audio/PC DVI input/ARC
• Rear HDMI: HDMI input ( TV digital interface support
HDCP) with digital audio/PC DVI input
• +5V detection mechanism
• Stable clock detection mechanism
• Integrated EDID
• HPD control
• Sync detection
• TMDS output control
• CEC control
7.6 Video and Audio Processing - MT5561LVNT/B
PBGA-329
The MT5561LVNT/B is the main audio and video processor (or
System-on-Chip) for this platform. It has the following features:
• Multi-standard digital video decoder (MPEG 1-2, H.264,
MPEG-4)
• A transport de-multiplexer
• A muti-standard video decoder
• Rich format audio codec
• HDMI 1.4a receiver with 3D support
• 2D/3D converter
• Local dimming (LED backlight)(0ption)
• Panel overdrive control
• Two-link LVDS
The MT5561LVNT/B combines front-end video processing
functions, such as ATSC,DVB-T/T2,DVB-C,DVB-S2 channel
decoding, MPEG 1-2/H.264 decode, analog video decode and
HDMI reception, with advanced back-end video picture
improvements. It also includes next generation Motion Accurate
Picture Processing High flat panel screen resolutions and
refresh rates are supported with formats including 1360 × 768
@ 60Hz and 1920 x 1080 @ 60Hz.It integrates high-quality
HDMI 1.4a, USB 2.0 receiver, Ethernet MAC+PHY, Single core
CPU. Professional error-concealment provides stable, smooth
and mosaic-free video quality
For a functional diagram of the MT5561LVNT/B, refer
to Figure 8-2.
IF
X
IF_AGC
RF_AGC
RF_AGC
MTK5561
IF_AGC
MxL661-AG-R
I2C
I2C
19770_203 eps
IF
IF-AGC
TS DATA
XRF_AGC
RF_AGC
MTK5561
TC90537FG
LQFP-48
IF_AGC
MxL661-AG-R
I2C
I2C
19770_204 eps
19770_205.eps
MTK5561
HDMI Side
REAR HDMI
CN502
CN501
RX
RX
I2C
I2C
IC Data Sheets 35TPM15.6L LA 8.
2015-July-10back to
div.table
8. IC Data Sheets
This chapter shows the internal block diagrams and pin
configurations of ICs that are drawn as “black boxes” in the
electrical diagrams (with the exception of “memory” and “logic”
ICs).
8.1 Diagram 10-5-1 System Power B01, M5723B (IC U703)
Figure 8-1 Internal block diagram and pin configuration
19770_300.eps
Block diagram
Pinning information
FB1
10
8
7
1
2
3
4
EN1
AGND
AGND
LX
PGND
IN1
OUT2
9
65EN2 IN2
Thermal
PadFB1
10
8
7
1
2
3
4
EN1
AGND
AGND
LX
PGND
IN1
OUT2
9
65EN2 IN2
Thermal
PadFB1
10
8
7
1
2
3
4
EN1
AGND
AGND
LX
PGND
IN1
OUT2
M5723B
9
65EN2 IN2
Thermal
Pad
N1
+
CONTROL
HDRV
A1
+
100mΩ
80mΩ
LDRV
R
S
Q
Thermal
Shutdown
UVLO
OSC
Compensation
+
EA
VREF
LX
Zero Current Detect
Current Sense
OC
0.6V
FB1
N2
OUT2
SHUTDOWN
LOGIC
1.25V
Vref
ERROR
AMP
OVER CURRENT
PROTECT & DYNAMIC
FEEDBACK
AGND
R1
R2
OVER TEMP.
PROTECT
EN1
PGND
EN2
N1
+
CONTROL
HDRV
A1
+
100mΩ
80mΩ
LDRV
R
S
Q
Thermal
Shutdown
UVLO
OSC
Compensation
+
EA
VREF
LX
Zero Current Detect
Current Sense
OC
0.6V
FB1
N2
OUT2
SHUTDOWN
LOGIC
1.25V
Vref
ERROR
AMP
OVER CURRENT
PROTECT & DYNAMIC
FEEDBACK
AGND
R1
R2
OVER TEMP.
PROTECT
EN1
PGND
EN2
IC Data Sheets 36 TPM15.6L LA8.
2015-July-10 back to
div.table
8.2 Diagram 10-5-2 Peripheral, B02, MT5561LVNT (IC U401B)
Figure 8-2 Internal block diagram
19620_300_140111 eps
140111
Block diagram
MT5561LVNT
NTSC/
PAL/
SECAM
ATD
TV
Decoder
TS
Demux
Video
ADC
Video
Input
De-
interlace
HDMI Rx
Audio
Input
Audio
Demod
Audio
ADC
SPDIF
In
Grapihc
DDR3
Controller
OSD
scaler
Audio DSP Audio
I/F Audio DAC
JTAG IrDA
PCR
I2C
RTC UART SDIO
USB2.0 PWM
Ethernet
Watchdog Serial Flash
NAND Flash
Servo ADC
SPDIF Out, I2S
ADAC L/R x 2
TS
Input
Tuner
Input
CVBS/YC
Input
Component
Analog Input
SIF
Audio
Input
Panel
16-bit
Embedded
DDR3
T8032
Smart
Card
MHL Rx
JPEG/MP2/MP4/
DivX/H.264/VC-1/
RM/AVS/VP8
Decoders (option)
LVDS/min-LVS/
EPI
OD, TCON
(option)
2D/3D Converter
Post Processing
(option)
HDMI
Input/
MHL
Demod
ARM
Vplane
scaler
IC Data Sheets 37TPM15.6L LA 8.
2015-July-10back to
div.table
Figure 8-3 Internal pin configuration [1/2]
19620_301_140111 eps
140111
Pinning Information
MT5561LVNT
329 1 22 3 44 5 66 7 8 99 10
A DVSS AO0P AOCKP AE1P DVSS CI_A3
BB GPIO0 AO0N AOCKN AE1N CI_D0 CI_REG#
CC TCON4 TCON2 AO1P AO2P AO3P AE0P AE2P AE3P CI_A1 CI_MOVAL
DD TCON5 TCON7 AO1N AO2N AO3N AE0N AE2N AE3N CI_A0 CI_A4
E TCON3 TCON0 GPIO1 OPWM0 CI_MDO1 CI_MDO2 CI_A12 CI_A5
F TCON8 TCON1 TCON6 OSCL1 OSDA1 DVSS CI_CD2# CI_D2 CI_A2
G PDD6 PDD0 PDD3 PDD1 OPWM1 OPWM2 DVSS DVSS
H PDD4 GPIO4 GPIO3 DVSS DVSS
J POOE
#
POCE1# PDD7 POCE0# POWE# PDD5 DVSS VCCK DVSS
KK PACLE PAALE PDD2 PARB# VCCK VCCK VCCK VCCK DVSS DVSS
L VCCK VCCK VCCK VCCK VCCK VCCK VCCK VCCK DVSS DVSS
MM DVSS DVSS DVSS DVSS DVSS DVSS VCCK VCCK DVSS DVSS
N DDRV DDRV DDRV DDRV DDRV DDRV DVSS DVSS DVSS VCC3IO
P DDRV
REF
ZQ
AOLRC
K
OSDA0 DVSS ADIN1 VCC3IO VCC3IO
R AOBC
K
AOMCLK
AOSDAT
A0
ASPDIF
O
OSCL0 DVSS ADIN7
AVDD33_E
TH
AVDD33_HD
MI
T OPWRSB OIRI
AOSDAT
A1
DVSS ADIN6 ADIN0 ADIN4
UU U0TX U0RX
OPCTRL
0
OPCTRL
4
ADIN5 ADIN3 HDMI_0_SCL ADIN2
HDMI_0_R
X_1B
HSYNC
V OPCT
RL3
OPCTRL1
OPCTRL
2
VGA_SD
A
VGA_SCL
HDMI_0_S
DA
HDMI_0_RX_
0B
HDMI_0_RX_0
HDMI_0_R
X_1
VSYNC
W RXVN RXVP
REXT_E
TH
HDMI_0_HPD
HDMI_0_RX_
CB
HDMI_0_R
X_2B
ORESETB
Y TXVN TXVP DVSS
AVDD12
_ETH
AVDD12_HDM
I_0
HDMI_0_RX_
C
HDMI_0_R
X_2
AVDD10_LD
O
1 2 3 4 5 66 7 8 99 10
IC Data Sheets 38 TPM15.6L LA8.
2015-July-10 back to
div.table
Figure 8-4 Internal pin configuration [2/2]
19620_303_140111.eps
140111
Pinning Information
MT5561LVNT
11 12 13 14 15 16 17 18 19 20
A CI_MCLKO CI_MDI4 CI_A14 CI_MDI0 CI_IORD# CI_A10 FSRC_WR
B CI_A6 CI_MIVAL CI_WE# CI_A13 CI_A11 CI_CE1# CI_D7
CC CI_WAIT# CI_RESET CI_MDI3 CI_MDI2 CI_MDI1 CI_A8 CI_A9 CI_OE# CI_MDO7 CI_MDO6
DD CI_MOSTRT CI_A7 CI_D1 CI_MCLKI CI_MISTRT CI_IOWR# CI_D6 CI_MDO5 CI_D5
E CI_MDO0 CI_MDI5 CI_MDI7 CI_MDO3 CI_D3 CI_CD1# CI_D4 CI_MDO4
F CI_IREQ# CI_MDI6 ASPDIFI GPIO5 CI_PWR_EN USB_DP1 DVSS
GG GPIO2 DVSS USB_DM1
H DVSS DVSS DVSS DVSS DVSS USB_DP0 USB_DM0 AVDD12_HDMI_1
J DVSS DVSS DVSS HDMI_2_SDA IF_AGC HDMI_2_HPD_CBUS HDMI_2_SCL HDMI_1_SCL HDMI_2_RX_2 HDMI_2_RX_2B
KK DVSS DVSS HDMI_1_SDA MHL_SENCE HDMI_CEC HDMI_2_RX_0 HDMI_2_RX_1 HDMI_2_RX_1B
L DVSS DVSS DVSS AVDD33_CAP RF_AGC HDMI_1_HPD HDMI_2_RX_0B
M DVSS DVSS DVSS AVDD33_AADC AVDD33_ADAC HDMI_2_RX_C HDMI_2_RX_CB HDMI_1_RX_2 HDMI_1_RX_2B
N DVSS DVSS DVSS AVSS33_CLN DVSS DVSS HDMI_1_RX_1 HDMI_1_RX_1B
PP DVSS DVSS DVSS AR0_ADAC HDMI_1_RX_0 HDMI_1_RX_0B HDMI_1_RX_C HDMI_1_RX_CB
R DVSS DVSS DVSS DVSS AL0_ADAC AIN_R1 AIN_R3 AIN_R2 AIN_R0
T AVSS33_RGB DVSS AVSS33_VIDEO DVSS VMID_AADC AVDD33_REG_STB AL1_ADAC AIN_L3 AIN_L2
UU SOG SOY1 COM1 Y0 PB0 DVSS AVDD33_VIDEO_STB AR1_ADAC AIN_L0
VV BP RP Y1 SOY0 COM0 DVSS AVDD33_RGB_STB CVBS0 XTALI AIN_L1
W GP PB1 PR0 VDAC_OUT ADCINP_DEMOD DVSS XTALO
Y COM PR1 CVBS_COM CVBS1 ADCINN_DEMOD AVDD12_DEMOD11 12 13 14 15 16 17 18 19 20
IC Data Sheets 39TPM15.6L LA 8.
2015-July-10back to
div.table
8.3 Diagram 10-5-4 Speaker Amp B04, TAS5729MDDCAR (IC U601)
Figure 8-5 Internal block diagram and pin configuration
19690_301.eps
Block diagram
Pinning information
Thermal Pad
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
PGND
SPK_OUTA
BSTRPA
PVDD
TEST1
TEST2
DR_INA
DR_OUTA
DR_OUTB
DR_INB
DRVSS
DR_CN
DR_CP
DRVDD
PLL_GND
PLL_FLTM
PLL_FLTP
ANA_REG1
AVDD
ADR / SPK_FAULT
MCLK
OSC_RES
OSC_GND
DIG_REG
SPK_OUTB
BSTRPB
BSTRPC
SPK_OUTC
PGND
SPK_OUTD
BSTRPD
PVDD
GVDD_REG
DR_SDI
SSTIMER
ANA_REG2
AGND
DGND
DVDD
TEST3
RST
NC
SCL
SDA
SDIN
SCLK
LRCLK
PDN
Digital Audio Processor
Clock
Monitoring
Open Loop
Digital PWM
Modulator
Full Bridge
Power
Stage B
Serial
Audio
Port
Internal Control Registers and State Machines
Over-
Current
Protection
Full Bridge
Power
Stage A
Gate
Drives
Gate
Drives
Die Temp. Monitor
PWM Power Stage
SPK_OUTC
SPK_OUTD
SPK_OUTA
SPK_OUTBSCLK
SD N
MCLK
LRCLK
DVDD DRVDD GVDD_REGPVDD
DR_SDI SCLRST SDA
Gate Drive
Regulator
Digital Equalizer, Two-Band
AGL, Coarse/Fine Volume
Control, THD Manager, PWM
Level Meter
Charge Pump
DRVSSDR_CPDR_CN
DR_OUTB
DR_OUTA
DR_INB
DR_INA
ANA_REG1 ANA_REG2 DIG_REG
Digital Supply Regulator
PDNADR / SPK_FAULT
Stereo HP / Line Driver
DRVDD
DR_INx
+ DR_OUTx
DRVSS
-
AVDD
Analog Supply
Regulators
TAS5729MD
IC Data Sheets 40 TPM15.6L LA8.
2015-July-10 back to
div.table
8.4 Diagram 10-5-6 Video YPbPr/CVBS B09, MxL661 (IC U104)
Figure 8-6 Internal block diagram and pin configuration
19760_301 eps
Block diagram
Pinning information
24 23 22 21 20 19
18
17
16
15
14
13
7 8 9 10 11 12
1
2
3
4
5
6
LNA_INP
LNA_INN
A
S
G
N
D
_X
TA
L
CLK_OUT
XT
A
L_
P
XT
A
L_
N
VD
D
_1
p8
VDD_IO
AGC_1
AGC_2/GPO_3
MxL661
VDD_3p3
RE
SE
T_
N
VD
D
_1
p8
VDD_1p8
GND_DIG
VDD_1p2
IF
_O
U
TN
_1
IF
_O
U
TP
_1
IF
_O
U
TP
_2
/G
PO
_1
IF
_O
U
TN
_2
/G
PO
_2
SDA
SCL
VD
D
_3
p3

Crystal
ReferenceI2C Voltage
Regulator
AGC1RF
Synth
Gain
Control
IF
Synth
Synth
Calibration
LNA
AGC2
Channel
Filtering
CLK_OUT
IF1 Out
IF2 Out
RF Input Balun
Block Diagrams EN 41TPM15.6L LA 9.
2015-July-10 back to
div table
9. Block Diagrams
9.1 Block diagram 4100 & 5000 series
19770_400.eps
5W SPK
L
CVBS / L / R
AUDIO AMP
KeyPad
Silicon Tuner MxL661-AG-R
HDMI1
Headphone AMP
L/R
MT5561
ATV LVDS
UART
CN103
(Side)
IF+/-
HDMI2 w/ARC
USB2
CN501
(Side) TI 31100
R
PC Audio in
HeadphoneAPA2176A
CN502
Rear
USB1
(Share to Wi-Fi modul)
Remote Control
5W SPK
L/R
VGA
SPIDF Out
CN104
(Rear)
DTV
DEMODTC90537
TSB Demod
EN 42TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10. Circuit Diagrams and PWB Layouts
10 1 A 715G6550 PSU
19770_500 eps
PowerA01 A01
201 -12 01
715G6550POWER
+12V_A
NC
R
99
08
R9909
U9901
NC
1
D1
2
D1
3
NC
4
NC
5D2
6D2
7NC
8
C9906
+12VS
D9107
SR515-04
1 2
R9110
47R 1%
D9108
SR515-04
1 2
R9140
22 OHM 1/4W
!
PS_ON
C9307
C9308
R9141
680R 1/8W 1%
A
R9104
82K OHM 1%
R9125
620K 1/8W 1%
U9101
PF6003AS
BNO
1
FB
2
CS
3
GND
4
OUT
5VCC
6NC
7VCC
8
R
9129
470O
H
M
 +
-5%
 1/8W
FB9302
BEAD
1 2
R9121
2K4 1/8W 5%
!
DIM
R9111
10K OHM -5% 1/8W
!
PS_ON
R9131
1K 1/8W
R9144
R9122
9.1K OHM
+18V
CN9901
SOCKET
12
PS_ON
R9901
620K +-1% 1/4W
R
9124
10K
 O
H
M
 +
-5%
 1/8W
!
+12V
FB9301
1 2
L9901
18MH
1
2
4
3
R9105
82K OHM 1%
C9140
R9145
HS9101
HEAT SINK
1
2
3
4
Q9106
+12VS
NC
R9115
22 OHM 1/4W
R9345
U9102
EL817M(X)
1
23
4
+12VS
!
D9105
1N4007
!
R9143
R9902
620K -1% 1/ W
D9109
SR34H
1 2
!
t
NR9901
2.5R
1
2
+5.2V
C9103
2.2NF
R9903
620K +-1% 1/4W
! !!
R9904
620K -1% 1/ W
!!
!
R9106
82K OHM %
F9901
T4AL 250V_NC
+12V_A
+12V
+12V_A
R9127
3.3M 1/4W
+12V
+12V_A
R9109
10R 1/8W 5%
+18V
FB9901
127R
1
2
+12V
C9904
1NF 250V
PS_ON
R9107
82K OHM %
! !
C9908
NC
ON/OFF
ON/OFF
U9103
AS431AN-E1
DIM
C9902
220PF 250V
C9903
220PF 250V
NC
- +
BD9902
GBL408-C
2
3
4
CN9102
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
NC
Full range:BD9901/093G 50460938
low and high side:BD9902/393G0050460A03
L9101
3UH
+
C9121
470uF 25V
C9801
Full range:367G215X121PKY
low side:367G215X331MKY
high side:367G215X101PKY
Q9101
Full range:357G0667650004/TK8A65D
or 357G0667650006/TK11A65D
low and high side:357G06119080HF/TK6A65D R9116
22 OHM 1/4W
R9307
C9124
1NF
RV9901
680V
R9126
9.31K +-1% 1/8W
+
C9109
470uF 25V
C9128
1N 50V
T9101
POWER X'FMR
1
2
3
5
6
7
8
9
0
4
C9127
1N 50V
For Q9101
R9 46
0 %
- +
BD9901
2
1
3
4
C9107
3.3NF 500V
NC
C9113
2.2NF
C9907
100PF 250V
C9910
100PF 250V
Q9306
!!
+12V_A
+12V
+
C
9116
330U
F
 35V
D9104
1N4148W
CN9101
CONN
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
+5.2V
D9103
FR107G-A0
FB9908
BEAD
1 2
FB9906
NC
1 2
R9907
CN9902
1
1 2
2
C9119
100N 50V
C9129
NC
FB9902
127R
1
2
Q9102
BTN5551A3
SG9902
D9106
1N4148W
SG9901
C9306
C9323
C9336
R9130
1K OHM
ZD9101
BZT52-B22
1
2
Q9101
TK6A65D(STA ,X,M)
R9112
510K 1/4W
T4AH/250V
C9108
470pF 1KV
R9142
3.3M 1/4W
R9102
510K 1/4W
R9103
510K 1/4W
+
C9105
0U 50V
+
C9102
2.2UF 50V
R9302
C9125
1NF
D9110
SR510-22
1 2
R9117
NC
D9111
SR510-22
1 2
R9304
D9112
SR510-22
1 2
D9101
SR510-22
1 2
R9113
1K 1/4W
L9301
R9358
R9342
L9903
4mH
1
2
4
3
C9330
R9361
+
C9331
C9106
330P 50V
R
9344
N
C
/3K
 O
H
M
 1%
U9301
PGND
1
VIN
2
AGND
3
VCC
4
FB
5COMP
6LX
7EN
8
+ C9332
R9347
C9333
COLDHOT
C9335
C9334
+
C
9122
330U
F
 35V
!
R9118
NC
R9348
F9902
1
2
3
4
R9138
22 OHM 1/4W
R9906
620K -1% 1/ W
R9905
620K +-1% 1/4W
R9139
NC
+
C9101
NC
JUMPER
R9120
22 OHM 1/4W
C9110
100N 50V
R9119
NC
C9901
470nF 275V
C9126
100PF
R9123
43K 1/8W 1%
C9117
220N 50V
+
C9801
82uF 450V
!
C9104
100N 50V
R9149
22 OHM 1/4W
Q9305
R9148
22 OHM 1/4W
R9150
NC
R9108
4R7 1/4W 5%
ZD9104
BZT52-B16
1
2
C9112
100N 50V
R9128
3.3M 1/4W
JUMPER
A
ZD9301
12
R9101
0.27R 2W
R9114
110K
+
C9111
470UF 25V
NC NC
D9102
SR515-04
1 2
!
NC
Circuit Diagrams and PWB Layouts EN 43TPM15.6L LA 10.
2015-July-10 back to
div table
10-1-2 LED DRIVER
19770_501 eps
LED DRIVERA01 A01
201 -12 01
715G6550LED DRIVER
C8617
100PF 500V
ZD8601
BZT52-B18
1
2
R8603
33K 1/8W 5%
ZD8602
BZT52-B18
1
2
C8603
47N 50V
C8621
100N 50V
C8623
NC
R8605
1K 1/8W
NC
R8606
330K 1/8W 5%
D8602
1N4148
+C8601
330UF 35V
+18V
U8601
PF7708BS
LED
1
VCC
2
CS/OVP
3
OUT
4
GND
5DIM
6GM
7FB
8
OUT
R8604
33R 1/8W 5%
CN8601
CONN_NC
1
2
3
4
5
R8608
 4.7KOHM +-1% 1/8W
C8605
100N 50V
D8603
1N4148W
C8611
0.47UF 50V
+12V
Q8603
DTA144WN3/S
Q8602
2N7002K
D8604
1N4148W
C8609
100N 50V
C8604
0.47UF 50V
Vcc2
Vcc2
ON/OFF
R8602
NC
R8616
0 OHM +-5% 1/8W
R8617
62K 1/8W 1%
R8655
1R6 1%
L8603
33uH
D8601
SR510-22
1 2
R8656
1oHM 1% 1/4W
DIM
C8607
220P 50V
C8606
1NF
R8611
NC
R8612
100K
R8601
0R05
FB8605
BEAD
1 2
+
C
8616
220uF
 50V
C8610
22pF 50V
R8647
10K OHM +-5% 1/8W CN8602
CONN
1
2
3
4
5
6
7
8
Q8601
SM1A23NSUC-TRG
OUT +
C
8612
220uF
 50V
R8654
1oHM 1% 1/4W
C8602
220nF50V
R8609
10R 1/8W 5%
R8652
1R6 1%
R8653
1R6 1%
VLED+
VLED+LED-
LED-
L8602
R8615
22K 1/4W
EN 44TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-1-3 Power layout top
19770_502.eps
201 -06
715G6550
LAYOUT TOP
U
91
02
R9101
R8601
SU1
J9
2
SU4
D9102
D9107
D9108
L9903
D
91
10
D
91
12
J9 02
D
91
11
D
91
03
SU2
C9102
D
91
01
J9
8
J9 0
J9109
J9
J9
6
J9
9
J9
7
J9
0
J9
3
SU3
F9901
J9
5
D
86
01
J9 07
J9 08
J9
04
J9 20
J9 06
J9
03
T9101
BD9901
BD9902
D
R
8
DR10
D
R
1
M
H
28
D
R
3
D
R
2
D
R
4
D
R
7
D
R
5
DR11
D
R
6
M
H
8
C8601C
91
03
C9109
C9111
C
9116
C9121
C
9122
C9126
CN8602
CN9902
FB9906
HS9101
L8602
L8603
L9101
MH1
MH3
D9105
L9901
NR9901
C9113FB8605
S
G
99
01
S
G
99
02
C9105 C
8612
C
8616
C
99
04
C9908
C9901
R9130
Q9102
C9331
C9332
L9301
R9907
FB9908
C9101
FB9301
C
N
91
02
C
N
91
01
C9801
FB9302
Q9101
C9906
F
B
99
01
F
B
99
02
R
99
08
C9907
C9910
C9902
C9903
RV9901
CN9901
M
H
5
F9902
R
99
09
D
86
02
MH2
CN8601
M
H
7
Circuit Diagrams and PWB Layouts EN 45TPM15.6L LA 10.
2015-July-10 back to
div table
10-1-4 Power layout bottom
19770_503 eps
201 -06
715G6550
SSB Layout Bottom
MH11
MH14
MH19
R
91
45
R8647
R9342R9348
R
93
47
R9109
R
91
10
R
91
11
R
91
14
R9121
R9122
R
91
23
R9124
R9126
R9131
R
91
41
R9125
C
93
36
C8605
C
86
10
C
91
06
C
91
10
C
91
12
C
91
17
C9119
C
91
24
C9127
C9128
R
86
52
R
86
53
R
86
54
R
86
55
R9112
R9102R9103
R9104 R9105
R9106 R9107
R9108
R
91
13
R
91
15
R
91
16
R
91
17
R9118
R9119
R9120
R9138
R9139
R8612
JR9104
JR9101
C9129
C
86
21
C8602
C
86
07
C
91
25
R8611
C8606
C
86
23
C
91
40
C
93
30 C
93
33
C
93
34
C9335
R8616
R
93
44
R
86
15
R9127
R9128R9142
R
93
58
R
93
61
C9108
C
91
07
C
86
17
R
99
03
R
99
04
C9306
C
93
07
C9308
R
93
02
R9304
R9307
Q
93
06
C
93
23
JR
91
05
R9345
JR9107
JR
91
02
JR9108
R
86
02
Z
D
93
01
JR9103
R
91
46
Q
93
05
Q
91
06
C
91
04
R
91
48
R
91
49
R
91
50
R9140
R9129
R
86
04
R8608
R9143
R9144
JR9109
R8603
C
86
03
U
91
03
U
99
01
R
86
56
C
86
04
C
86
09
C
86
11
R8605
R
86
06
Q
86
03
Q
86
02
R
86
17
R
86
09
U8601
U9101
U9301
R
99
01
R
99
02
R
99
05
R
99
06
MH4
S
G
1
S
G
2
Q
86
01
D
86
03
D
91
04
Z
D
91
04
D
91
06
D
91
09
D
86
04
Z
D
86
01
Z
D
86
02
Z
D
91
01
EN 46TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10.2 A 715G6863 PSU
10-2-1 Power
19760_500 eps
A01 A01
201 -06 213
715G9863
POWER
POWER
LED1
LED4
LED2
FB
LED_a
FB
B+
LED3
OUT
OUT
LED_a
!
!
!
VLED+
!
VLED+
!
VLED+
!
!
!
!
+12V
+16V_AL
+12V_Audio
+12V_AL
+16V_AL
+12V1
+12V1
+16V1
+16V1+12V1
DIM
+16V_AL
Vcc2
ON/OFF
+12V_AL
+12V_Audio
Scan_BL_EN
+12V
PS_ON
DIM
+12V
ON/OFF
Vcc2
ON/OFF
!
A
A
Hot Cold
Hot Cold
C8607
10NF 50V
C8607
10NF 50V
C8604
100N 50V
C8604
100N 50V
D9107
SR515
D9107
SR515
R9 4 33ohm 4W + -5%
+
C8615
220uF 50V
+
C8615
220uF 50V
R8607
33K +-1% 1/4W
R8607
33K +-1% 1/4W
R9121R9121
10K OHM +-5% 1/8W
t
NR9902
5R
t
NR9902
5R
1
2
ZD8102
BZT52-B22
ZD8102
BZT52-B22
1
2
R9110
82K OHM 1%
R9110
82K OHM 1%
R9904
NC 750K + 5% 4W
Q8603
2N7002K
Q8603
2N7002K
C8605
NC/100PF 500V
C8605
NC/100PF 500V
CN9101
CONN
CN9101
CONN
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
C8609
NC/1NF 630V
C8609
NC/1NF 630V
D9105
FR107
D9105
FR107
C9109
1NF 50V
C9109
1NF 50V
FB9908
BEAD
FB9908
BEAD
1
2
C9107
1NF 500V
C9107
1NF 500V
R9120
22K 1/8W 1%
R9120
22K 1/8W 1%
R9137
1K OHM +-5% 1/8W
R9137
1K OHM +-5% 1/8W
ZD9102
GDZJ22B
ZD9102
GDZJ22B
1
2
R9131
0 OHM +-5% 1/8W
R9131
0 OHM +-5% 1/8W
FB9901
BEAD
FB9901
BEAD
1 2
C9901
0.47uF 305V
C9901
0.47uF 305V
C8611
100N 50V
C8611
100N 50V
R9116
30 OHM 1/4W
R8604
0.2oHM 1% 1/4W
- +
BD9901
GBL408-C
- +
BD9901
GBL408-C
2
1
3
4
Q9102
2N3904
Q9102
2N3904
R9135
3M3 1%
R9135
3M3 1%
ZD8101
BZT52-B16G
ZD8101
BZT52-B16G
1
2
R9138
470 OHM 1/4W
R9138
470 OHM 1/4W
C9102
2.2NF
C9102
2.2NF
D8602
1N4148W
D8602
1N4148W
C9904
100PF 250V
C9904
100PF 250V
L8601
NC/47UH
L8601
NC/47UH
IC8601
PF7708AS
IC8601
PF7708AS LE
D
1
V
C
C
2
C
S
/O
V
P
3
O
U
T
4
G
N
D
5
D
IM
6
G
M
7
FB
8
R9112
33R 1% 1/8W
R9112
33R 1% 1/8W
R9136
470R 5%
R9136
470R 5%
R8612
NC/22K 1%
R8612
NC/22K 1%
D9102
SR510-22
D9102
SR510-22
1 2
R9905R9905
NC 750K +-5% 4W
Q9101
TK5A65D
Q9101
TK5A65D CN8601
NC/CONN
CN8601
NC/CONN
1
2
3
4
5
6
7
8
+
C9118
470UF 25V
+
C9118
470UF 25V
R9 7 33ohm 4W + 5%
R9907
1.5M 1/2W
R9907
1.5M 1/2W
C9114
1NF 500V
C9114
1NF 500V
R9901R9901
NC 750K + 5% 4W
R9108
82K OHM 1%
R9108
82K OHM 1%
R9106
330K +-1% 1/4W
+C8601
220UF 35V
+C8601
220UF 35V
FB9906
127R
FB9906
127R
1 2
+C9115
330UF 35V
+C9115
330UF 35V
Q8602
DTA144WN3/S
Q8602
DTA144WN3/S
C9121
100N 50V
C9121
100N 50V
R9134
330K +-1% 1/4W
+C9801
47UF 450V
+C9801
47UF 450V
D8601
SR506
D8601
SR506
R9906
NC 750K + 5% 4W
R9119
30 OHM 1/4W
+ C9111
220uF 25V
+ C9111
220uF 25V
RV9901
680V
RV9901
680V
R9124
390K 1/8W 1%
R9124
390K 1/8W 1%
C8613
NC/100N 50V
C8613
NC/100N 50V
t
NR9901
5R
t
NR9901
5R
1
2
R9103
100K 1/8W 1%
R9103
100K 1/8W 1%
FB9903
BEAD
FB9903
BEAD
1 2
C9119
2N2 50V
C9119
2N2 50V
R8616
330K 1/8W 5%
R8616
330K 1/8W 5%
C9120
100P 50V
C9120
100P 50V
R8610
0.2oHM 1% 1/4W
R8610
0.2oHM 1% 1/4W
R9127
NC/100K 1/8W 1%
R9127
NC/100K 1/8W 1%
JR901
0R05 1/4W
JR901
0R05 1/4W
D9106
1N4007
D9106
1N4007
C8612
100N 50V
C8612
100N 50V
R9129
30 OHM 1/4W
FB9905
BEAD
FB9905
BEAD
1 2 T9101
POWER X'FMR
T9101
POWER X'FMR
1
2
4
5
6
7
11
10
8
C9902 NC/470NF 305VC9902 NC/470NF 305V
C9104
100N 50V
C9104
100N 50V
+C9117
470UF 25V
+C9117
470UF 25V
+ C9802
47UF 450V
+ C9802
47UF 450V
C9108
100N 50V
C9108
100N 50V
R9105
4R7 1/4W 5%
R9105
4R7 1/4W 5%
R9125
680R 1/8W 1%
R9125
680R 1/8W 1%
R9109
82K OHM 1%
R9109
82K OHM 1%
L9101
3UH
L9101
3UH
CN9901
SOCKET
CN9901
SOCKET
12
R9132
NC/0 OHM +-5% 1/8W
R9132
NC/0 OHM +-5% 1/8W
R
8614
1R
 1%
R
8614
1R
 1%
CN8603
NC/CONN
CN8603
NC/CONN1
2
C9903
100PF 250V
C9903
100PF 250V
R9101
0.36R
R9101
0.36R
C9112
220N 50V
C9112
220N 50V
+
C8608
10UF 50V
+
C8608
10UF 50V
R8601
47OHM 1/8W
R8601
47OHM 1/8W
IC9101
PF6003AG
IC9101
PF6003AG
GND1
FB2
BNO3 CS 4VCC 5OUT 6
R9104
330K +-1% 1/4W
IC9102
EL817M(X)
IC9102
EL817M(X)
1
2
4
3
C9906
NC/100PF 250V
C9906
NC/100PF 250V
CN8602
NC/CONN
CN8602
NC/CONN1
2
3
4
5
R8605
33K +-1% 1/4W
R8605
33K +-1% 1/4W
D9110
SR510-22
D9110
SR510-22
1 2
R8603R8603
10K OHM -5% 1/8W
R9130
30 OHM 1/4W
D9103
1N4148W
D9103
1N4148W
L9902
23mH
L9902
23mH
1
2
4
3
L8602
47UH
L8602
47UH
R9122
12K 5% 1/4W
R9122
12K 5% 1/4W
R9111
10ohm +/-1% 1/8W
+ C9106
4.7UF 50V
+ C9106
4.7UF 50V
R
8609
1.2R
 1%
R
8609
1.2R
 1%
CN8604
CONN
CN8604
CONN
1
2
3
4
5
6
7
8
D9109
SR515
D9109
SR515
ZD9101
BZT52-B15
ZD9101
BZT52-B15
1
2
R
8611
1.2R
 1%
R
8611
1.2R
 1%
R8608
5.6K 1/4W
R8608
5.6K 1/4W
C9105
220P 50V
C9105
220P 50V
R8613
100KOHM -5% 1/8W
C9905
1NF 250V
R9128
1K5 -1% 1/8W
R9128
1K5 -1% 1/8W
FB9907
BEAD
FB9907
BEAD
1
2
R9 42 33ohm 4W + -5%
D9104
1N4148W
D9104
1N4148W
R9107
82K OHM 1%
R9107
82K OHM 1%
R9903R9903
NC 750K +-5% 4W
C8603
470NF 50V
C8603
470NF 50V
R9126
5K1 1/8W 1%
R9126
5K1 1/8W 1%
R8602
10ohm +/-1% 1/8W
R8602
10ohm +/-1% 1/8W
C9113
1NF 500V
C9113
1NF 500V
R
8606
1.2R
 1%
R
8606
1.2R
 1%
R9902
NC 750K +-5% 4W
+ C9103
4.7UF 50V
+ C9103
4.7UF 50V
R9123
10K OHM +-5% 1/8W
C8610
100N 50V
C8610
100N 50V
R9114
 3.3M 1%
R9114
 3.3M 1%
D8604
1N4148W
D8604
1N4148W
R9 8 33ohm 4W + 5%
C8606
10N 50V
C8606
10N 50V
Q8601
AO4486
Q8601
AO4486
S
1
S
2
S
3
G
4
D
8
D
7
D
6
D
5 +C8602
NC/100UF 50V
+C8602
NC/100UF 50V
C9907
NC/100PF 250V
C9907
NC/100PF 250V
JR902
0R05 1/4W
JR902
0R05 1/4W
R9115
470OHM +-5% 1/8W
R9115
470OHM +-5% 1/8W
D8605
1N4148W
D8605
1N4148W
F9901
FUSE 2.5A
F9901
ZD9103
BZT52-B20
ZD9103
BZT52-B20
1
2
GND3
GND
GND3
GND
1
L9901
NC
L9901
NC
1
2
4
3
D9101
SR510-22
1 2
R9 39 33ohm 4W + 5%
R8615
1K OHM +-5% 1/8W
R8615
1K OHM +-5% 1/8W
IC9103
AS431AN-E1
IC9103
AS431AN-E1
R9 40 33ohm 4W + -5%
C8614
100N 50V
C8614
100N 50V
CN8605
NC/CONN
CN8605
NC/CONN1
2
3
4
5
C9100
NC/100PF
C9100
NC/100PF
D9108
NC/SR204
D9108
NC/SR204
1 2
HS9101
HEAT SINK
HS9101
HEAT SINK
1
2
3
4
0 OHM +-5% 1/8W
R9113R9102
3M3 1%
R9102
3M3 1%
Circuit Diagrams and PWB Layouts EN 47TPM15.6L LA 10.
2015-July-10 back to
div table
10-2-2 power layout top
19760_501 eps
201 -06 05
715G6863
LAYOUT TOP
D9102
D
91
07IC9102
D
91
09D9108
R
91
36
SU2
SU1
SU3
CN8603
D9110
D9106
C9802
B
D
99
01
J907C8602
C9801
C8608
C
9106
C9111
C
9103
D9101
F
99
01
J905
J90
J909
J9
J906
J90
J9
02
J9
C8615
J908
J9
0
J9 2
J9
3
J903
R
91
01
T9101
D8601
S
6
S7
S
3
S
S5 S8 S9
S
10
S11
S12
S13
S15
C9102
C
9117
C
9118
C
99
01
C9905
C9903
C
99
04
CN8601
C
N
86
02
D
91
05
FB9901
HS9101
L9101
MH5
MH1
MH4
Q9102
C
8601
C
9115
FB9905
MH3MH2
FB9906
C9902
L8601
Z
D
91
02
L8602
Q9101
RV9901
CN9101
C
99
06
C
99
07
FB9907
FB9908
G
N
D
3
L9901
L9902
N
R
99
01
N
R
99
02
C
91
00
F
B
99
03
CN9901
R
99
07
CN8605
CN8604
EN 48TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-2-3 Power layout bottom
19760_502 eps
201 -06 05
715G6863
LAYOUT BOTTOM
C
91
04
C
91
05
C
91
12
C9113
C
91
14
C
91
19
C
91
20
R9116
R
91
17
R
91
18
R9119
R
91
20
R9130
R
91
32
R
91
34
R9135
C9121
R9137
R
91
38
R9111
R9131
C
86
04
SM6
SM7
R
91
15
Q8601
IC8601
R
91
39
R
91
40
R
91
41
R
91
42
C
86
03
Q
86
03
IC
91
03
C
86
11
C
86
10C
86
12
C
86
07
C
86
06
C
91
07
C9108
C
91
09
C
86
09
D
91
03
R
86
09
R
86
05
R
86
07
R
86
03
R
86
04
R8613
R
86
12
R
86
06
R
86
10R
86
08
R
86
14
R
86
15
R
86
16
R
91
02
R9104
R
91
06
R9107
R9109
R
91
03
R9110
R
91
27
R
91
28
R9129
R
99
01
R
99
02
R
99
03
R
99
04
R
99
05 R
99
06
JR901
JR902
R
86
11
S
M
5
C8613
R
86
02
R9108
C
86
14
C
86
05
R
86
01
R9105
R9121
R
91
22
R
91
23
R
91
24
R
91
25
R
91
26
D
86
02
R
91
12
R
91
14
R9113
D
86
05
S
2
S
1
D
91
04
Z
D
91
01
IC910
D
86
04
Z
D
91
03
Z
D
81
01
Z
D
81
02
Q
86
02
Circuit Diagrams and PWB Layouts EN 49TPM15.6L LA 10.
2015-July-10 back to
div table
10.3 A 715G6934 PSU
10-3-1 POWER
19760_503 eps
PowerA01 A01
201 -03 05
715G6934
POWER
C9172
220N 50V
R9107
10K 1/4W
HS9152
NC/HEAT SINK
3
4
1
2
F
9902
5A
 250V
1
2
3
4
Q9181
NC/AOD4185
R9125
1K OHM
+
C9802
NC/68UF 450V
DIM
ON/OFF
FB_1
D9152
SR341
2
PS_ON
CN9901
SOCKET
2
R
9184
6.8K
O
H
M
 +-1%
R
9108
10 O
H
M
 1/4W
!
C9104
2.2NF
R9176
10K 1%
C9158
1uF
+12V'
!
+12V'
R9174
3K9 1/8W 1%
C
9159
N
C
/100N
 50V
C9902
470nF 275V
R9164
33ohm 1/4W +/-5%
R9187
NC/10K OHM +-5%
HS9101
HEAT SINK
1234
+22V
R9129
330K 1%
+12V1
!
!
!
R9906
510K 1/4W
D9104
SS1060FL
!
+12V_AUDIO
!
C9920
470PF 250V
Q9183
2N7002K
R9126
1K OHM
PS_ON
R9128
1K 1/8W
D9105
NC/1N4148W
C9106
NC/4N7 50V
U9103
AS431AN-E1
R
9186
100K
O
H
M
 +-5%
 1/8W
R9101
0.22OHM +-5%
R
9185
10K
 O
H
M

-5%
 1/8W
+
C9154
470UF 25V
FB9901
BEAD
2
ZD
9101
N
C
/B
Z
T
52-B
30
1
2
CN9101
CONN
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
!
! !
C9103
NC
+5V
+5V
U9101
PF6003AHS
BNO
1
FB
2
CS
3
GND
4
OUT
5VCC
6NC
7VCC
8
!
FB9903
BEAD
1
2
R9907
NC/390K
- +
BD9901
KBJ608G-FUC
2
3
4
FB9905
BEAD
1 2
C9907
NC/47pF
HS9151
HEAT SINK
1
2
3
4
U9901
NC/CAP004DG-TL
NC
1
D1
2
D1
3
NC
4
NC
5D2
6D2
7NC
8
T9101
POWER X'FMR
1
2
4
5
6
7
8
10
11
L9901
18MH
1
2
4
3
SG9901
NC/DSPL-501N-A21F
C9155
220N 50V
R9104
22OHM 1/8W
L9902
18MH 1
2
4
3
+12V
C9171
22NF 50V
HS9901
NC/HEAT SINK
12
C9157
100N 50V
ZD9301
NC/BZT52-B5V1
12
AC-1
!
SG9902
NC/DSPL-501N-A21F
AC-1
!
t
NR9901
2.5R
1
2
t NR9902
2.5R12
C9110
1NF 50V
R9124
150 OHM 1/4W
R9183
NC/100KOHM
C9105
2.2NF
+
C9151
470UF 25V
R9106
47OHM 1/8W
U9102
EL817M(X)
1
23
4
C9111
100N 50
R9112
3.3M 1/4W
R9111
2M2 5% 1/2W
R
9103
10 O
H
M
 1/4W
R9113
3.3M 1/4W
R
9
1
7
3
6
8
0
R
 1
/8
W
 1
%
R9114
3.3M 1/4W
HOT COLD
D9102
SS1060FL
R9102
47K 1/4W
R9163
33ohm 1/4W +/-5%
R9162
33ohm 1/4W +/-5%
R9161
33ohm 1/4W +/-5%
!
+
C9801
82UF 450V
R9105
75K
FB_1
!
R9171
2K OHM
+12V1
+
C9152
470UF 25V
L9101
3UH
! R9121
150 OHM 1/4W
R9122
150 OHM 1/4W
R9123
150 OHM 1/4W
+12V1
GND1
GND
1
C9912
100PF 250V
D9103
FR107G-A0
C9911
100PF 250V
C9921
470PF 250V
+
C9153
470UF 25V
!
HS-GND
FB9904
BEAD
1 2
!
RV9901
680V
R
9127
470 O
H
M
 1/4W
!
C
9125
100N
 50V
+
C9107
22UF 50V
Q9121
BTN5551A3
R9305
NC/220R 1%
R9306
NC/2K 1/8W 1%
C9308
NC/2N2 50V
R
9302
N
C
/30 O
H
M
 1/4W
C
9304
N
C
/100N
 50V
+
C
9306
N
C
/470U
F
 25V
+
C
9302
N
C
/470U
F
 25V
U9301
NC/AOZ3015AI
PGND
1
VIN
2
AGND
3
VCC
4
FB
5COMP
6LX
7EN
8
R9303
NC/30 OHM 1/4W
C
9182
N
C
/100N
 50V

R
9304
N
C
/10.5K
 O
H
M
 1%
C9309
NC/2N2 50V
R9301
NC/20K 1/4W
C
9307
N
C
/220N
 50V
L9301
NC/47uH
C
9303
N
C
/220N
 50V
FB9301
NC/BEAD
1
2
C9914
220PF 250V
C9913
220PF 250V
C9162
1N5 50V
+
C9112
4.7UF 50V
C9161
1N5 50V
D9121
FMXA-2202S
1
2
3
+
C9121
220uF 50V
+
C9122
220uF 50V
!
+22V
CN9902
NC
L
1
N
2
C9901
470nF 275V
Q9102
NC/LMBT3906LT1G
R
9181
N
C
/100K
O
H
M

D9151
FMEN-220A
1
2
3
+
C
9160
N
C
/4.7U
F
 50V
C9156
100N 50V
Z
D
9171
B
Z
T
52-B
15
1
2
HS9121
NC/HEAT SINK
1
2
3
4
R9182
NC/100KOHM
C9301
NC/220N 50V
D9101
FR107G-A0
ZD9121
BZT52-B271
2
HS-GND
!
Q
9101
T
K
8A
65D
Q9182
NC/2N7002K
HS9122
HEAT SINK
1
2
3
4
FB9902
127R
1 2
F
9901
N
C
/5A
 250V
R9109
470 OHM 1/4W
!!
!
+12V
PS_ON
C9109
2N2 50V
R9175
0 OHM +-5% 1/8W
GND3
GND
1
GND2
GND
1
!
GND5
NC
1
R9905
510K 1/4W
GND4
NC
1
R
9172
1K
5 +-1%
 1/8W
R9904
510K 1/4W
R9903
510K 1/4W
C9108
220P 50V
R9902
510K 1/4W
R9901
510K 1/4W
R
9
1
1
0
1
0
0
K
 1
/8
W
 1
%
R9908
NC/390K
C
9305
N
C
/100N
 50V
C9123
1NF 500V
C9124
1NF 500V
EN 50TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-3-2 LED DRIVER
19760_504 eps
LED DRIVERA02 A02
201 -06 05
715G6934LED DRIVER
R8601
0.05R
+
C8603
220uF 50V
R8623
300K 1/8W 5%
R8605
10ohm +/-1% 1/8W
L8602
NC
R8615
1R2 1%
R8612
33K 1/8W 1%
C8605
100N 50V
R8613
1R2 1%
C8612
47N 50V
L8601
33uH
81
4
6
R8606
33K 1/8W 1%
R8617
1R2 1%
C8611
22pF 50V
R8603
100K
C
8610
1N
F
 50V
+
C8604
220uF 50V
D8603
SS1060FL
C
8609
220P
 50V
R8619
10 OHM
C8607
1uF
C8608
220N 50V
R8604
NC
R8616
1R2 1%
R8608
10K 1/8W
R8607
5.1R 1/8W
+
C8601
220uF 50V
FB8601
BEAD
1 2
R8614
1R2 1%
C8606
1uF
R
8609
10R
 1/8W
 5%
+22V
ON/OFF
OUT
DIM
OUT
VLED+
VLED-
R8618
1R2 1%
ZD8602
NC/BZT52-B221
2
FB8602
NC/BEAD
1 2
R8622
10K 1/8W 1%
C8615
100N 50V
Q8602
LMBT3906LT1G
R8620
2K2 1/8W
C8617
100N 50V
+
C
8614
N
C
/22U
F
 50V
D8605
NC/1N4148
R8621
1K 1/8W 1%
+12V
R8602
NC/0R05 1/4W
CN8601
CONN
1
2
3
4
5
6
7
8
9
10
11
12
ON/OFF
VCC
C8613
100pF 50V
VCC
C8616
2.2UF 25V
Q8603
LMBT3904LT1G
VLED+
VLED-
VLED+
VLED-
VLED-
VLED-
D8604
SS1060FL
D8602
NC/SR506
D8601
SR506
R8610
4K3 1/8W 1%
R8611
33K 1/8W 1%
Q8601
CYS9240
U8601
PF7708AS
LED
1
VCC
2
CS/OVP
3
OUT
4
GND
5DIM
6GM
7FB
8
ZD8601
NC/BZT52-B221
2
Circuit Diagrams and PWB Layouts EN 51TPM15.6L LA 10.
2015-July-10 back to
div table
10-3-3 Power layout top
19760_505 eps
201 -06 06
715G6934
LAYOUT TOP
C9107
C9103D9101 D
91
03
F9901
U9102
J905
J901
J9
22
J9
18
J9
17
J9
09
J9
11
J9
23
J9
06
H1
H2
J9
04
C8614
J9
16
J9
15
J9
02
J9
14
J9
08
J9
21
J924
J9
10
J9
12
J9
13
J9
03
J9
19
J9
20
R8
60
1
R9
10
5
R9101
R9125
R9126
J9
25
T9101
D
86
01
D
86
02
D
86
05
J926
H3
H4
H5
H6
TP
2
TP
3
TP
4
TP
5
TP6
TP
7
TP
9
TP
8
D
R1
MH2
MH1
MH7
MH8
MH6
MH5
M
H
4
MH3
C8
60
3
C8604
C9
90
7
C9
10
4
C9105
C9112
C9151
C9152
C9153
C9154
C9160
C9121
C9122
C8601
C9302
C9306C9912
C9911
C9913
C9914
C9921
C9
92
0CN9902
D9151
D9121
FB
93
01
FB
86
01
GND1
GND2
GND3
HS9101
HS9151
HS9121
L8601
L8602
L9101
L9301
L9901
L9902
Q9121
R9
90
7
SG9901
SG
99
02
H
S9
90
1
FB
99
04
FB
99
02
HS9122
G
N
D
4
G
N
D
5
R9
11
1
HS9152RV9901
R9
90
8
CN8601
C9801
C9802
FB
86
02
CN
91
01
NR9902
NR9901
FB9903FB9905
Q9101
BD9901
FB
99
01
CN9901
F9902C9901
C9902
EN 52TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-3-4 Power layout bottom
19760_506 eps
201 -06 06
715G6934
LAYOUT BOTTOM
SG
3
C8611
C8
61
0
C8
61
2
C8608
C8
60
7
C8
60
6
C9106
C9
10
8
C9
10
9
C9
11
0
C9
11
1
C9155
C9161
C9
16
2
C9172
C9171
C9
18
2
C9
12
3
C9
12
4
C9125
C9303
C9304
C9305
C9
30
8
C9309
C8
60
9
C9
30
7
R8
60
9
R8
60
5
R8607
R8603
R8604
R8
61
3
R8612
R8
60
6
R8610
R8608
R8
61
4
R8
61
5
R8
61
6
R8
61
7
R9
10
2
R9104
R9
10
6
R9107
R9
10
9
R9103
R9
11
0
R9
17
2
R9174
R9
16
1
R9
16
2
R9
16
3
R9
16
4
R9
17
3
R9
17
1
R9175
R9
17
6
R9
18
1
R9
18
2
R9
18
3
R9184
R9
18
6
R9127
R9128
R9
12
9
R9301
R9
30
2
R9
30
3
R9
30
4
R9
30
5
R9
30
6
R9
90
1
R9
90
2
R9
90
3
R9
90
4
R9
90
5
R9
90
6
U
91
01
U
86
01
U
93
01
R9185
U
99
01
JR
90
1
JR
90
2
SM2
SM3
SM4
R8
61
1 SM5
C9
30
1
C8613
R8602
R8
61
8
R8
61
9
JR
90
3
R9108
JR904
C9156
C9
15
7
C8
61
5
C8
61
6
C8617
R8
62
0
R8621
R8
62
2
R8623
C8605
C9158
C9
15
9
R9
18
7
R9121
R9122
R9123
R9124
R9
11
2
R9
11
4
R9113
Q
91
82
Q
91
83
U
91
03
SG
4
D
86
03
D
91
02
D
91
05
D
91
52
Q
86
01
Q
91
81
ZD
91
71
D
91
04
ZD
93
01
ZD
91
01
D
86
04
ZD
91
21
ZD
86
01
ZD
86
02
Q
91
02
Q
86
02
Q
86
03
Circuit Diagrams and PWB Layouts EN 53TPM15.6L LA 10.
2015-July-10 back to
div table
10.4 A 715G6338 PSU
10-4-1 POWER
19610_500 eps
AC inputA01 A01
2013-10 18
715G6338AC input

T5AH/250V
R
9902
3.9M
O
H
M
 +-5%
 1/2W
C9903
100PF 250V
C9904
100PF 250V
1
2
HS9902
HEAT SINK
!
SG9901
NC
SG9902
NC
R
V
9901
680V
1
2
CN9901
SOCKET
COLDHOT
R9901
NC
R9903
NC
!
!
!
1
2
3
4
HS9901
HEAT SINK
C
9902
100N
F
 305V
!
!
12
43
L9902
12mH
C
9901
100N
F
 305V
1 2
3 4
F9901
FUSE
!
1 2t
NR9901
2.5R
!
C9907
470pF 250V
C9908
NC
!
12
43
L9901
12mH
!
!
!
12 t
NR9902
2.5R
!
!
B
Vsin
A
A
B
!
!
2
1
3
4
- +
BD9901
TS10K80-02
N
C
1
D
1
2
D
1
3
N
C
4
N
C
5
D
2
6
D
2
7
N
C
8
IC9901
NC
C9906
470pF 250V
C9905
470pF 250V
EN 54TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-4-2 LED DRIVER
19610_501 eps
LED DriverA02 A02
2013-10 18
715G6338
LED Driver
VLED+
VLED+
R
81
07
510 O
H
M
 +-1%
 1/8W
R
8121
 100K
O
H
M

-1%
 1/8W
C
8107
1N
 50V
R
8124
100K
 1/4W
S1
+
C
810282uF
 100V
G1 G2
+ C
8103
82uF
 100V
G1
R8148
0R051/8W
R8116
0R1 5% 2W
2
L8101
33uH
R8155
200K 1/8W
+36V/+24V
C
8105
220nF
50V
SENSE2
R8111
150K 1/4W +/-1%
C
8109
1U
F
 50V
C8108
100N 50V
R8106
10K 1/8W 1%
R8102
33 OHM
R
8108
330K
 1%
 1/8W
OVP_L
R8112
150K 1/4W +/-1%
C
8110
100N
 50V
R
8113
 10K
O
H
M
 +-1%
 1/8W
VLED_1
VLED_2
D8102
SS1060FL
R8135
10ohm +/-1% 1/8W
C
8114
10N
 50V
R
8101
2.2 O
H
M
 1/8W
C
8104
220nF
50V
R
8103
0K
 1%
 1/8W
R
81
49
20
K
R
8145
0R
68 1W
 5%
R8104
0R1 5% 2W
R8105
1K 1/8W 1%
R
8144
0R
68 1W
 5%
1 2
FB8103
BEAD
OVP_L
R8143
10K 1/8W 1%
R
81
42
10
0K
O
H
M
 +
-5
%
 1
/8
W
2D/3D
R8138
100K 1/8W 1%
C
81
44
10
0N
 5
0V
R8136
20K OHM
Q8147
P5002CMG
1
GND806
GND
1
GND807
GND
DIM
1
GND801
GND1
2
3
4
HS8101
HEAT SINK
R
8147
0R
68 1W
 5%
R
8146
0R
68 1W
 5%
1
GND804
GND
1
GND802
GND
C8131
1N 50V
1
GND805
GND
R8115
1M 1/8W 5%
C8106
100N 50V
R
8156
0R
68 1W
 5%
Q8143
MTBA5N10J3
Q8145
P5002CMG
R
8157
0R
68 1W
 5%
R
8109
 100K
O
H
M
 +-1%
 1/8W
R
8110
240K
 1%
 1/8W
Q8149
MTBA5N10J3R8164
200K OHM
G2 SENSE2
12 FB8101
127R
VLED_1
1
2
3
4
5
6
7
8
9
10
11
12
CN8101
CONN
VLED_1
1 2
FB8102
BEAD
R
8160
4.7R
 1%
R
8161
4.7R
 1%
R8139
10ohm 1%
C8143
100P 50V
+
C8101
330UF 50V
VLED+
VIN
1
OVP
2
EN
3
RT
4
COMP
5
PARL
6
SENSE1
7
Gate1
8
FB1
9
SENSE2
10
Gate2
11
FB2
12
SENSE3
13Gate3
14FB3
15SENSE4
16Gate4
17FB4
18STATUS
19LOSC
20DIM
21CS
22GND
23DRV
24
IC8101
LD7890GS
12
ZD8101
BZT52-B9V1_R1_00001
1
2
3 D8101
MBRF10100CT
C8132
100N 50V
+36V/+24V
C8133
1N 50V
R8134
10K 1/4W
R8133
10K OHM +-5% 1/8W
R8137
20K OHM
ON/OFF
Q8101
P3710BTF
Q8102
PMBT3906
Q8103
2N7002K
1
GND803
GND
+12V
R
8140
100K
 1/8W
 1%
R
8120
240K
 1%
 1/8W
R
8123
240K
 1%
 1/8W
S1
Circuit Diagrams and PWB Layouts EN 55TPM15.6L LA 10.
2015-July-10 back to
div table
10-4-3 LLC 36V
19610_502 eps
LLC 36VA03 A03
2013-10 18A
715G6338
LLC 36V
COLDHOT
1
2
ZD9103
BZT52-B43
C9113
1uF
+ C9121
330UF 50V
+ C9122
NC
C9107
470pF 50V
L9102
1.1uH
R9113
91KOHM +-1% 1/8W
C9106
47pF
C9105
22nF
R9104
22K 1/8W 1%
R9137
0 OHM +-5% 1/8W
C9109
4N7 50V
R9107
2.2R
C
9108
1uF
D9105
UF1010G
C9104
1uF
C9102
100N 50V
R9125
1K 1/8W 1%
C9103
470NF 50V
C9125
100N 50V
R9128
 2.4KOHM +-1% 1/8W
R9106
4R7 +-5% 1/8W
C9111
33N 50V
IC9103
AS431AN-E1
1
2
4
3
IC9102
PS2561DL1-1
R9126
4K7 1/8W 1%
+36V/+24V
R9123
 100KOHM +-1% 1/8W
VCC_ON
R9120
2K4 +/-1% 1/8W
1 2
FB9101
BEAD
R9119
11K 1%
R9108
1K 1/8W 1%
C9101
10NF
R9121
12
K
 5
%
 1
/4
W
R9105
0.1R
B+
VCC
1
VREF
3G
4OV/UV
5FB
6DT/BF
7IS
8NC
9S1
10S2
11
HB
13VCCH
14
D
16
IC9101
LCS700LG-TL
R9101
1MOHM +-1% 1/4W
R9124
 2.4KOHM +-1% 1/8W
R9114
 22KOHM +-1% 1/8W
R9102
1MOHM +-5% 1/2W
R9103
1MOHM +-5% 1/2W
R9127
43R 1%
C9127
1uF
C9128
1uF
1
2
3
D9104
FMEN-2308
C9117
2.2nF 50V
!
!
D9106
SS1060FL
C9126
2.2nF 50V
+36V/+24V
R
9110
8.2K
 1/4W
C9116
47nF 50V
R9109
120R 1%
R
9111
 150K
O
H
M
 +-1%
 1/8W
R9112
12K 1/8W
C9110
2.2UF 25V
R
9115
3K
 1/8W
 +/-1%
+ C
9123
N
C
1
2
HS9101
HEAT SINK
+36V/+24V
R9140
1K 1/8W 1%
OVP
+36V/+24V
Q9104
PMBS3904
C9133
100N 50V
Q9103
PMBS3906
R9139
100 OHM 1%
R9136
1K 1/8W 1%
R9138
1K 1/8W 1%
D9110
SS1060FL
D9108
SS1060FL
1
2
5
6
7
8
9
10
11
12
10
9
T9101
210uH
ON/OFF
R9122
12
K
 5
%
 1
/4
W
R9133
12
K
 5
%
 1
/4
W
R9132
12
K
 5
%
 1
/4
W
2D/3D
DIM
+12V
D9107
SS1060FL
R9129
 2.4KOHM +-1% 1/8W
+
C9120
10UF 50V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CN9101 CONN
1
2
3
4
HS9109
HEAT SINK
EN 56TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-4-4 Main Power 12V
19610_503 eps
Main Power 12VA04 A04
2013-10 18A
715G6338
Main Power 12V

1
2
3
4
HS9302
HEAT SINK
1
2
ZD9303
NC/P6KE160AA0
1
2
3
4
HS9301
HEAT SINK
Q9332
PMBT3906
HOT COLD
C9309
2N2 500V
D9301
SS1060FL
R9321
51 OHM 1/4W
R9331
10K OHM +-5% 1/8W
IC9342
AS431AN-E1
D9302
FR107
Q9301
TK13A65U C9306
NC
Q9341
2N7002K
12
ZD9302
BZT52-B30
C9302
1NF
R9334
10K OHM
C9331
100N 50V
L9301
3UH
1
2
4
3
IC
93
41
P
S
25
61
D
L1
-1
D9303
FR107
12
ZD9301
BZT52-B30
C9310
2N2 500V
R9306
0.1R
+
C
9311
470U
F
 25V
R9342
100K 1/8W 1%
!
R9307
100K 1/4W
1
2
3
4
5
6
7
9
10
T9301
POWER X'FMR/380GL32P133H00
+
C9320
47UF 50V
R9348
1K 1/8W 1%
1
2
ZD9340
BZT52-B16
R9333
10K 1/8W 1%
R9318
51 OHM 1/4W
R9345
6.2K OHM +-1% 1/8W
R9303
6.8K 1/4W
+ C9314
330UF25V
R9337
2Kohm 1/4W +/-5%
R9302
6.8K 1/4W
R9346
2Kohm 1/4W +/ 5%
R9311
10 OHM
R9344
3.9K 1% 1/8W
R9315
470 OHM 1/4W
R9336
2Kohm 1/4W +/-5%
R9316
2.2 OHM 1/4W
R9314
0.27R
R9308
100K 1/4W
R9347
 2.2KOHM +-1% 1/8W
+C9332
10UF 50V
R
93
38
10
0K
 1
/8
W
 1
%
R9312
51 OHM 1/4W
R9335
10K OHM +-5% 1/8W
R9332
330K 1% 1/8W
1
2
4
3
IC
9331
P
S
2561D
L1-
C9304
1N 50V
R9341
10K OHM +-5% 1/8W
Q9331
2N7002K
R9301
6.8K 1/4W
C9301
10NF
C9315
100N 50V+
C
9312
470U
F
 25V
R9309
100K 1/4W
R9310
100K 1/4W
C9341
220N 50V
1
2
Z
D
93
30
B
Z
T
52
-B
15
Q9333
BTC4672M3
C9305
470P 50V
D9331
SS1060FL
PS_ON
C9308
100N 50V
R9320
51 OHM 1/4W
2D/3D
+
C
9313
470U
F
 25V
R9313
10KOHM
+
C
9317
470U
F
 25V
+
C
9318
470U
F
 25V
DV5
VCC
DV5
+12"V
+12"V
VCC
ON/OFF
PS_ON
COLDHOT
B+
DIM
HOT COLD
HOT COLD OVP
R9324
NC
R9325
NC
CT
1
COMP
2
CS
3
GND
4
OUT
5VCC
6
HV
8
IC9301
LD7752B
R
9305
N
C
/100K
O
H
M
 +-5%
 1/8W
VCC_ON
+12V
+12V+12V
+12V
R9326
51 OHM 1/4W
R9327
51 OHM 1/4W
1
2
3
D9305
FME-220B
R9343
 9.53KOHM +-1% 1/8W
1 2
FB9301
BEAD
1
2
3
D9306
FME-220B
R9322
51 OHM 1/4W
R9323
51 OHM 1/4W
+
C9307
10UF 50V
D9304
FR107
+
C
9321
N
C
/ 470U
F
 25V
C9303
47nF 50V
R9319
51 OHM 1/4W
C9328
470pF 250V
!
C9316
1NF 250V
!
!
!
+12V_audio
+12V_audio
2
4
6
8
10
12
14
1
3
5
7
9
11
13
CN9301
CONN
C9319
100N 50V
Circuit Diagrams and PWB Layouts EN 57TPM15.6L LA 10.
2015-July-10 back to
div table
10-4-5 PFC
19610_504 eps
PFCA05 A05
2013-10 18A
715G6338
PFC
C9808
100PF
Vsin !
R9815
2.2R
R
9809
10K
 1/8W
B+
C9803
100N 50V
+ C
9812
68uF
 450V
D9801
IN5408G-04
D9805
IN5408G-04
1 2
L9802
BEAD
C9815
2.2NF
IN
V
1
C
O
M
P
2
R
A
M
P
3
C
S
4
Z
C
D
5
G
N
D
6
O
U
T
7
V
C
C
8
IC9801
LD7591T
C9813
1UF 450V
!
Q9801
TK16A60W
VCC_ON
HOT COLD
D9802
MUR460-28
1 2
L9803
NC
C9814
470pF 250V
R9807
10 OHM 1/8W
R9808
75 OHM 1/8W
C9807
1N 50V
1
2
3
4
HS9801
HEAT SINK
R9813
10K 1/8W
R9810
470 OHM 1/4W
R9805
20K 1/4W
R9811
0.1R
C9801
1UF 450V
D9806 NC/FMNS-1106S
31
45
L9801
240UH
R9814
NCC9809
100P 50V
1 2
FB9802
BEAD
R9812
27K 1/8W 1%
C9806
470NF 50V
R9806
 3.3KOHM +-1% 1/8W
+ C
9810
68uF
 450V
+ C
9811
68uF
 450V
C9802
47P 50V
C9805
100N 50V
R9802
1MOHM +-1% 1/4W
R9803
1MOHM +-1% 1/4W
R9801
1MOHM +-1% 1/4W
R9804
19K1 +-1% 1/8W
D9803
SS1060FL
1
2
FB9803
BEAD
EN 58TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-4-6 Power layout top
19760_505 eps
201 -06 06
715G6934
LAYOUT TOP
C9107
C9103D9101 D
91
03
F9901
U9102
J905
J901
J9
22
J9
18
J9
17
J9
09
J9
11
J9
23
J9
06
H1
H2
J9
04
C8614
J9
16
J9
15
J9
02
J9
14
J9
08
J9
21
J924
J9
10
J9
12
J9
13
J9
03
J9
19
J9
20
R8
60
1
R9
10
5
R9101
R9125
R9126
J9
25
T9101
D
86
01
D
86
02
D
86
05
J926
H3
H4
H5
H6
TP
2
TP
3
TP
4
TP
5
TP6
TP
7
TP
9
TP
8
D
R1
MH2
MH1
MH7
MH8
MH6
MH5
M
H
4
MH3
C8
60
3
C8604
C9
90
7
C9
10
4
C9105
C9112
C9151
C9152
C9153
C9154
C9160
C9121
C9122
C8601
C9302
C9306C9912
C9911
C9913
C9914
C9921
C9
92
0CN9902
D9151
D9121
FB
93
01
FB
86
01
GND1
GND2
GND3
HS9101
HS9151
HS9121
L8601
L8602
L9101
L9301
L9901
L9902
Q9121
R9
90
7
SG9901
SG
99
02
H
S9
90
1
FB
99
04
FB
99
02
HS9122
G
N
D
4
G
N
D
5
R9
11
1
HS9152RV9901
R9
90
8
CN8601
C9801
C9802
FB
86
02
CN
91
01
NR9902
NR9901
FB9903FB9905
Q9101
BD9901
FB
99
01
CN9901
F9902
C9901
C9902
Circuit Diagrams and PWB Layouts EN 59TPM15.6L LA 10.
2015-July-10 back to
div table
10-4-7 Power layout bottom
19760_506 eps
201 -06 06
715G6934
LAYOUT BOTTOM
SG
3
C8611
C8
61
0
C8
61
2
C8608
C8
60
7
C8
60
6
C9106
C9
10
8
C9
10
9
C9
11
0
C9
11
1
C9155
C9161
C9
16
2
C9172
C9171
C9
18
2
C9
12
3
C9
12
4
C9125
C9303
C9304
C9305
C9
30
8
C9309
C8
60
9
C9
30
7
R8
60
9
R8
60
5
R8607
R8603
R8604
R8
61
3
R8612
R8
60
6
R8610
R8608
R8
61
4
R8
61
5
R8
61
6
R8
61
7
R9
10
2
R9104
R9
10
6
R9107
R9
10
9
R9103
R9
11
0
R9
17
2
R9174
R9
16
1
R9
16
2
R9
16
3
R9
16
4
R9
17
3
R9
17
1
R9175
R9
17
6
R9
18
1
R9
18
2
R9
18
3
R9184
R9
18
6
R9127
R9128
R9
12
9
R9301
R9
30
2
R9
30
3
R9
30
4
R9
30
5
R9
30
6
R9
90
1
R9
90
2
R9
90
3
R9
90
4
R9
90
5
R9
90
6
U
91
01
U
86
01
U
93
01
R9185
U
99
01
JR
90
1
JR
90
2
SM2
SM3
SM4
R8
61
1 SM5
C9
30
1
C8613
R8602
R8
61
8
R8
61
9
JR
90
3
R9108
JR904
C9156
C9
15
7
C8
61
5
C8
61
6
C8617
R8
62
0
R8621
R8
62
2
R8623
C8605
C9158
C9
15
9
R9
18
7
R9121
R9122
R9123
R9124
R9
11
2
R9
11
4
R9113
Q
91
82
Q
91
83
U
91
03
SG
4
D
86
03
D
91
02
D
91
05
D
91
52
Q
86
01
Q
91
81
ZD
91
71
D
91
04
ZD
93
01
ZD
91
01
D
86
04
ZD
91
21
ZD
86
01
ZD
86
02
Q
91
02
Q
86
02
Q
86
03
EN 60TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10.5 B 715G6836 SSB
10-5-1 System Power
19760_507 eps
System PowerB01 B01
201 -07 073
715G6836
System Power
AC_DET
R1
R2
R778
4.7K 1/16W
R787
4.7K 1/16W
3V3SB
INVERTER ON/OFF
H: ON
L: OFF
INVERTER ON/OFF
90mil
Low active
+5V_SWQ701
AO3401A
CN701
CONN
2
4
6
8
10
12
1
3
5
7
9
11
+5VSB
12V_AMP6 12V_AMP
BL_ON/OFF
AC_DET#
CORE POWER 1.2V
AC_Off10
AC_Off
FB703 120R
1 2 +12V
R719
0R051/8W
AVDD1V2
FB702
120R
1 2
3V3SB
FB706
120R
1 2
AC_DET
R788
4.7K 1/16W
Q705
MMBT3904
AC_DET# AC_DET
R714
10K +-1% 1/16W
C714
NC/100N 16V
+
C748
100UF 16V
R717
10K +-1% 1/16W
PS_ON
L702
2.2uH
C712
2.2UF
BL_DIMMING
C710
4.7UF 10% 10V
VCCK17
C730
10UF 6.3V 20%
+5VSB
L701
2.2uH
R723
NC 100R 1/16W 5%
GND4,5,6,7,8,9,10,11,12,13,14,15,16,17,18
OPWRSB
VCCK
DVDD3V34,5,6,8,9,10,11,13,15,16,17,18
+5V_SW
DVDD3V3
R725
NC 10K +-1% 1/16W
+12V
BL_ON/OFF
+12V
BL_ON/OFF14
+5VSB
BL_DIMMING
R722
NC 0R05 1/16W
3V3SB
BL_DIMMING
R710
51K 1/16W 5%
+5V_SW9,10,11,12,15
AVDD1V2
DVDD3V3
R709
22K 1%
+12V10
+5V_SW
R779
1K 1/16W 5%
+5VSB
R713
2.2K 1%
+5VSB7,9,16
VCCK
+12V
R724
NC 10K +-1% 1/16W
R786
1K 1/16W 5%
3V3SB4,8,10,13,14
DVDD3V3
Q703
LMBT3904LT1G
AVDD1V28,13,15
+5VSB
Q702
NC SM4310PSKC
S
1
S
2
S
3
G
4
D
8
D
7
D
6
D
5
OPWRSB4
INVERTER_ON_OFF
BL_ON/OFF
Q707
MMBT3904
BL_DIMMING14
3V3SB
BL_DIMMING
BRIGHT ADJUST
Max 3.3V
Min: 0V
U703
M5723B-33F61U
EN1
1
IN1
8
A
G
N
D
2
LX
10
A
G
N
D
4
EN2
5
FB1
3
OUT2
7
IN2
6
P
G
N
D
9
tG
N
D
11
R780
4.7K 1/16W
C706
1UF 10V
C708
NC/4.7UF 10% 10V
R706
100K 1%
Q704
LMBT3906LT1G
R749
36K 1%
R754
1K 1/16W 1%
C745
1UF 10% 16V
C747
22UF 10V
+
C707
100UF 16V
L703
4.7uH
ZD701
PDZ5.1B
1 2
C731
100NF 16V
A
C
_O
ff
R746 0R05 1/16W
U705
G5695T11U
VIN
1
GND
2
EN
3
VFB
4
LX
5
R751 40.2K 1/16W 1%
VCCK
R747 100K 1%
R748
13K 1/10W
R752 0R051/8W
C746
22UF 10V
R
75
0
20
K
 O
H
M
 1
/1
6W
 1
%
C721
2.2UF
C742 100pF 50V
R753
10K +-1% 1/16W
U706
SY8104ADC
LX
5
FB
1
EN
2
GND
3
IN
4
BS
6
C722
10UF 6.3V 20%
C743
0.1uF 50V
C
74
4
10
N
 5
0V
R729
82K 1%
BRIGHT_ADJ
Pre_12V
R730
18Kohm 1/16W +/-1%
Pre-12V_AMP
R728
0R05 1/16W
R718
10K +-1% 1/16W
DVDD3V3+5V_SW
Pre_12V
Pre-12V_AMP
Control Interface
LO = > POWER_ON
Main power On/Off control
HI = > POWER_OFF
L = > DC_OFF
+
C719
100UF 16V
H = > POWER_ON
BRIGHT_ADJ
PS_ON /STANDBY
INVERTER_ON_OFF
R704
100R 1/16W 5%
C726
NC/22uF 10V
C725
NC/10UF 10V
C705
100NF 16V
AC_DET10
R785
100R 1/10W 5%
12V_AMP
OPWRSB
PS_ON
R739
4.7K 1/16W
3V3SB
R705
1K 1/16W 1%
Q708
BC847C
R738
4.7K 1/16W
FB701 120R
1 2
STANDBY
INVERTER_ON_OFF BRIGHT_ADJ
C713
1UF 10% 16V
H = > AC_ON
L = > AC_OFF_DET
Circuit Diagrams and PWB Layouts EN 61TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-2 Peripheral
19760_508 eps
PeripheralB02 B02
201 -07 07
715G6836
Peripheral
C462
100NF 16V
ORESET#
3V3SB
R477
16K 1%
Flash_WP#
R479
22K 1%
PACLE
OPCTRL0
OPWRSB
U0TX
U0RX
FB409 120R
1 2
OSDA1 11,18
OSCL1 11,18
OSCL1
OSDA1
OSCL1
OSDA1
X401
24MHz
1
2
4
3
TXC
3V3SB
UART Port 0
XTALO
HS401
HEAT SINK
1
2
OPCTRL1
OPCTRL0
LED_PWR_GREEN
LED_POWER_RED R473
0R05 1/16W
R474
0R05 1/16W
PARB#
R170 100R 1/16W 5%
POOE#
R171 100R /16W 5%
OPCTRL1
POCE1#
ZD109
AZ5123-01H
1
2
ZD110
AZ5123-01H
1
2
OSDA0
OSCL0
POWE#
10mil
NAND Flash
ICE mode + 24M + serial boot
BGA Strapping OPCTRL0OPWRSBPACLEOPCTRL1
ICE mode + 27M + serial boot
ICE moce + 24M + ROM to Nand boot
X
X
X
X
ICE moce + 27M + ROM to Nand boot
1
0
1
0 0
0
0
0 1
1
0
0
AVDD10_LDO
PACLE
U401B
MT5561LVNT
PDD0
G2
PDD1
G4
PDD2
K3
PDD3
G3
PDD4
H3
PDD5
J6
PDD6
G1
PDD7
J3
PARB#
K4
POOE#
J1
POCE1#
J2
POCE0#
J4
PACLE
K1
PAALE
K2
POWE#
J5
OSDA1
F5OSCL1
F4
OSCL0
R5
OSDA0
P5
ORESETB
W10
OPWRSB
T2
OIRI
T3
U0RX
U2
U0TX
U1
XTALO
W20XTALI
V19
AVDD10_LDO
Y10
AVDD33_REG_STB
T17
FSRC_WR
A20
TP409
I2C & UART Interface
HI = >WP
LO = >WRITE
SYSTEM EEPROM
PDD2
PDD1
PDD3
PDD0
PDD5
PDD4PDD6
PDD7
AVDD33_REG_STB
U406
M24128-BRMN6TP
E0
1
E1
2
E2
3
VSS
4
SDA
5 SCL
6 WC
7 VCC
8
PAALE
TP401
FSRC_WR
STRAPPING
OSCL0
OSDA0
U0RX
U0TX
SYS_EEPROM_WP
U405
TC58NVG0S3ETAI0
CLE
16
I/O0
29
R/B1
7
VSS
13 VDD
12
VDD
37
VSS
36
ALE
17
I/O1
30I/O2
31I/O3
32
I/O4
41I/O5
42I/O6
43I/O7
44
NC
1
NC
2
NC
3
NC
4
NC
5
NC
6
NC
10
NC
11
NC
14
NC
15
NC
20
NC
21
NC
22
NC
23
NC
24
NC
25NC
26NC
27NC
28
NC
33NC
34NC
35
NC
38NC
39NC
40
NC
45NC
46NC
47NC
48
RE
8
CE1
9
WE
18
WP
19
GPIO Interface
5/28
XTALI
R423
10K +-1% 1/16W
R418 10K +-1% 1/16W
R173 100R 1/16W 5%
R419 NC/10K 1/16W 5%
R172 100R 1/16W 5%
R414 10K +-1% 1/16W
C402
4.7UF 10% 10V
C405
100NF 16V
R425
0R05 1/16W
R411
4.7K 1/16W
R415 10K +-1% 1/16W
R407
4.7K 1/16W
C404
100NF 16V
R412
4.7K 1/16W
R421
4.7K 1/16W
R420 10K +-1% 1/16W
R417 NC/10K 1/16W 5%
R422
10K +-1% 1/16W
Heat Sink
R416 NC/10K 1/16W 5%
CN402
CONN
1
2
3
3V3SB
DVDD3V3
DVDD3V3
LED_POWER_RED 10,14
LED_PWR_GREEN 10,14
DVDD3V3
3V3SB
LED_POWER_RED
LED_PWR_GREEN
OPWRSB 3
SYS_EEPROM_WP 14
3V3SB
GND3,5,6,7,8,9,10,11,12,13,14,15,16,17,18
3V3SB3,8,10,13,14
OSCL0 6
OSDA0 6
DVDD3V33,5,6,8,9,10,11,13,15,16,17,18
OIRI 10
U0TX 16
U0RX 16
C406
15PF 50V
XTALO
C403
100NF 16V
R
4
0
3
4
.7
K
 1
/1
6
W
C401
100NF 16V
R
4
0
4
4
.7
K
 1
/1
6
W
R
4
0
2
4
.7
K
 1
/1
6
W
R
4
0
5
4
.7
K
 1
/1
6
W
C407
15PF 50V
R
4
0
1
4
.7
K
 1
/1
6
W
DVDD3V3
DVDD3V3
DVDD3V3
U0TX
U0RX
ORESET#
XTALI
POCE1#
POOE#
PAALE
PACLE
PDD2
PDD0
PARB#
POWE#
OPWRSB
PDD6
PDD3
PDD5
PDD7
PDD4
PDD1
OIRI
SYS_EEPROM_WP
OPWRSB
RESET Circuit
AVDD33_REG_STB
POCE0#
OIRI
OSDA0
OSCL0
EN 62TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-3 Audio A-in/I2S/HP
19760_509 eps
Audio A-in/I2S/HPB03 B03
201 -07 073
715G6836Audio A-in/I2S/HP
C
60
2
N
C
 2
2N
F
25
V
FB611
NC 30R
12
C
60
1
N
C
 2
2N
F
25
V
OUTR
OUTL
OUTL 6
OUTR 6
+
C650
NC 100UF 16V
+
C651
NC 100UF 16V
OUTL
C608
1UF 25V
R627
NC 22K 1/16W
R628
NC 22K 1/16W
OUTR
OUTL
I2C & UART Interface
U0TX
AL0O
U0RX
OSCL0
OSDA0
ARC_SPDIF
ARC_SPDIF 16
Audio Input Interface
I2S Interface
FB610 120R
1 2
C663
10N 50V
R637
4.7K 1/16W
FB608 120R
1 2
FB609 120R
1 2
C662
10N 50V
HP_DET#
C664
NC/100N 16V
DVDD3V3
CN602
PHONE JACK
1
7
6
2
3
4
5
C687
22PF 50V
R603 22R 1/16W 5%
R604 22R 1/16W 5%
C605
NC/33P 50V
R602 22R 1/16W 5%
C606
NC/33P 50V
C603
NC/33P 50V
C604
NC/33P 50V
R60122R 1/16W 5%
CVBS_L_IN
CVBS_R_IN
C688
22UF
YPBPR_L_IN 8
YPBPR_R_IN 8
AOLRCK 6
AOSDATA0 6
AOMCLK 6
AOBCK 6
U0TX 4,16
OSDA0 4,6
OSCL0 4,6
U0RX 4,16
GND3,4,6,7,8,9,10,11,12,13,14,15,16,17,18
PreAmp output for Headphone
H = > HP Detect
HP Detect
HPOUT LT
HPOUT RT
L = > Normal
MCLK
C660
6.8NF 50V
C661
6.8NF 50V
SPDIF_OUT
SPDIF_OUT 9
R625
10 OHM 1/10W
CVBS_L_IN 8
CVBS_R_IN 8
CVBS_R_IN
CVBS_L_IN
R626
10 OHM 1/10W
AL0O
AR0O
HPR_IN
HPL_IN
HPR_IN 6
HPL_IN 6
A
B
CN605
NC CONN
2
1
4
3
AR0O
U401C
MT5561LVNT
AIN_L0
U20
AIN_L1
V20
AIN_L2
T20
AIN_L3
T19
AIN_R0
R20
AIN_R1
R17
AIN_R2
R19
AIN_R3
R18
AL0_ADAC
R16AR0_ADAC
P16
AL1_ADAC
T18AR1_ADAC
U19
ASPDIFI
F16 ASPDIFO
R4
AOMCLK
R2
AOBCK
R1
AOLRCK
P3
AOSDATA0
R3
AOSDATA1
T4
VMID_AADC
T16
AVDD33_ADAC
M16
AVDD33_AADC
M14
AVDD33_CAP
L15
15mil
HP_DET# 10
HP_DET#
FB405 120R
1 2SPDIF_OUT
TP408
TP
DVDD3V3DVDD3V33,4,6,8,9,10,11,13,15,16,17,18
FB406 120R
1 2
R678
0R05 1/16W
DVDD3V3
TP404
TP
ARC_SPDIF
C684
10UF 6.3V 20%
VGA_IN_R
VGA_IN_L
VGA_IN_L VGA_IN_R 7
VGA_IN_L 7
VGA_IN_R
AVDD33_AADC
HPOUT_RT
HPOUT_LT
YPBPR_L_IN
YPBPR_R_IN
AOLRCK
AOMCLK
AOBCK
AOSDATA0
AVDD33_ADAC
AOBCK
AOMCLK
AOSDATA0
AOLRCK
BCK
LRCK
SDATA0
AVDD33_CAP C607
100NF 16V
YPBPR_R_IN
OUTR
YPBPR_L_IN
VMID_AADC
FB612
NC 30R
12
C645
330pF 50V
C646
47pF 50V
R615 27K 1/16W 5%
R622
10K +-1% 1/16W
C643
47pF 50V
AR0O
AL0O
OUTL
OUTR
R623 10K +-1% 1/16W
R620 27K 1/16W 5%
HPR_IN
C647
2.2UF
R617
10K +-1% 1/16W
PreAmp output for Line out
C648
330pF 50V
R618 10K +-1% 1/16W
C644
2.2UF
HPL_IN
Circuit Diagrams and PWB Layouts EN 63TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-4 Speaker Amp
19760_510 eps
Speaker AmpB04 B04
201 -07 073
715G6836Speaker Amp
FB605 120R 3A
1 2
R607
18R 1/10W 5%
C626
470NF 16V
FB604 120R 3A
1 2
R608
18R 1/10W 5%
C627
330pF 50V
FB606 120R 3A
1 2
C629
1UF 16V
C619
470NF 16V
L602
10uH
R631
33R 1/16W 5%
R632
33R 1/16W 5%
C632
330pF 50V
AOBCK
C631
470NF 16V
OUTB
AOSDATA0
OSDA0
L603
10uH
HPL_ N
C618
330pF 50V
FB607 120R 3A
1 2
L+
C622
330pF 50V
L601
10uH
R605
18R 1/10W 5%
R606
18R 1/10W 5%
CN601
CONN
1
2
3
4
5
6
C621
470NF 16V
L604
10uH
OSCL0
AMP_RESETN
OUTC
HPR_ N
TP063
TP065
AOMCLK
ADR
AOLRCK
OUTA
HP_AC_MUTE
OUTA
OUTD
AMP_PDN
OUTC
5/28
+
C609
100uF 25V
C614
10UF 6 3V 20%
C630 1UF 25V
C616
100nF 50V
R609
10K +-1% 1/16W
C638
4.7nF 50V
C623 33nF50V
C636
1UF 25V
R614
18.2K OHM +-1% 1/16W
R610
470R 1/16W 5%
C624 33nF50V
U601
TAS5729MD
GND
1
OUTA
2
BSTA
3
PVDD
4
PWM1
5
PWM2
6
HPIL
7
HPOL
8
HPOR
9
HPIR
10
HPVSS
11
CN
12
AVDD_REG2
37
SSTIMER
38
HP_SD
39
GVDD_REG
40
PVDD
41
BSTD
42
OUTD
43
GND
44
OUTC
45
BSTC
46
BSTB
47
OUTB
48
GND
36
GND
35
TEST
33
DVDD
34
RESET
32
NC
31
SCL
30
SDA
29
SDIN1
28
SCLK
27
LRCLK
26
PDN
25
CP
13
HPVDD
14
GND
15
FLTM
16
FTLP
17
AVDD_REG1
18
AVDD
19
ADR
20
MCLK
21
ROSC
22
GND
23
DVDD_REG
24
E
-P
ad
49
C637
47nF 16V
C615
10UF 6 3V 20%
C610
10UF 6.3V 20%
FB603
120R
1 2
C633 2.2nF 50V
R613
10K +-1% 1/16W
C628 33nF50V
R611
1K 1/16W 1%
C642
4.7UF 10% 10V
C612
100NF 16V
C613
100NF 16V
C625 33nF50V
OUTL
OUTR
C639
4.7nF 50V
C617
100nF 50V
C634 1UF 25V
R612
470R 1/16W 5%
C611
100NF 16V
R616
10K +-1% 1/16W
C635 100NF 16V
C641
47nF 16V
DVDD3V3 AMP3V3PVDD12V_AMP
DVDD3V3
AMP3V3 AMP3V3
AMP3V3
AMP3V3
PVDD
R-
AMP3V3
AMP3V3
PVDD
OSCL0 4
OSDA0 4
12V_AMP
GND3,4,5,7,8,9,10,11,12,13,14,15,16,17,18
HP_AC_MUTE 9
DVDD3V33,4,5,8,9,10,11,13,15,16,17,18
12V_AMP3
AOLRCK 5
AOBCK 5
AOMCLK 5
AOSDATA0 5
HPL_ N 5
HPR_ N 5
AMP Mute
L+
GPIO & I2C Control
HS601
NC/HEAT S NK
1
2
R+
AOBCK
AOMCLK
AMP_MUTE
AOSDATA0
AMP_MUTE 14
AOLRCK
R-
L-L-
R+
Heat Sink
I2S Interface
+
C690
100uF 25V
HPL_IN
HPR_IN
FB602
120R
1 2
Q602
NC MMBT3904
C691
100NF 16VR633
NC 10K 1/16W 5%
PVDD
AMP_PDNAMP_MUTE
R635
NC 22R 1/16W 5%
C640
2.2UF
R634
NC 10K 1/16W 5%
DVDD3V3
AMP_MUTE
AMP_PDN
OSDA0
OSCL0
HP_AC_MUTE
OUTR
OUTL OUTR 5
OUTL 5
OUTB
OUTD
C620
1UF 16V
EN 64TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-5 VGA
19 1 eps
130114
 B05 B05
201 -12 1
715G

































































19760_511 eps
VGAB05 B05
201 -07 073
715G6836VGA
R1208
NC 0R05 1/16W
R1209
NC 0R05 1/16W
C1203
NC 10N 50V
R1211
NC 0R05 1/16W
TP1101 TP1102 TP1103
VGA_RIN
TP1104 C1206
NC 1 5nF 50V
TP1105
C1204
NC 10N 50V
TP1106
C1210
NC 10N 50V
TP1107
TP1108
VGACOM
C1207
NC 10PF 50V
C1208
NC 10PF 50V
C1209
NC 10PF 50V
TP1109
VGA_R
CN606
NC PHONE JACK
1
2
3
4
VGA_G
TP1111
TP1110
VGA_SOG
R1210
NC 0R05 1 16W
VGA_SDA_12
VGA_VSYNC
VGA_HSYNC
VGA_SCL_ 5
ZD1101
NC/AZ5123-01H
1
2
R1207
NC 0R05 1 16W
VGA_SDA_12
ZD1102
NC/AZ5123-01H
1
2
ZD1103
NC/AZ5123-01H
1
2
ZD1104
NC/AZ5123-01H
1
2
R1220
NC 4.7K 1/16W
R1219
NC 4.7K 1/16W
+5VSB
088G353GFF1ACL
R1201
NC 75R 1/16W 1%
R1212
NC 100R 1/16W 1%
VGA IN (V/T)
ZD1123
NC/AZ5123-01H
1
2
R1202
NC 75R 6W %
ZD116
NC BZT52-B5V6S
2
ZD1105
NC/AZ5123-01H
2
C1205
NC 10N 50V
VGA_TX
ZD115
NC BZT52-B5V6S
2
R1216 NC/33R
R1215 NC/33R
VGA_RX
ZD1106
NC/AZ5123-01H
1
2
R1205
NC 100R 1/16W 1%
R1203
NC 75R 1/16W 1%
R1217
NC 100R 1/16W 5%
R1214 NC 33R
VGA_TX R1213 NC33R
VGA_RX
VGA_SDA
VGA_SCL
GND3,4,5,6,8,9,10,11,12,13,14,15,16,17,18
+5V_SW3,9,10,11,12,15
AVDD1V23,8,13,15 AVDD1V2
+5VSB3,9,16
3V3SB3,4,8,10,13,14
12V_AMP
VCCK
R1227 NC 30K OHM
12V_AMP3,6
+5V_SW
R1228 NC 30K OHM
C1201 NC 2.2uF 10V
3V3SB
+5VSB
+12V
ZD1107
NC AZ5123-01H
1
2
C1202 NC 2.2uF 10V
DVDD3V33,4,5,6,8,9,10,11,13,15,16,17,18
+12V3,10
VCCK3,17
DVDD3V3
TP1116
VGA_ N_L
NC 470pF 50V
C1212
NC 470pF 50V
C1211 ZD1111
N
C
 V
P
O
R
T
06
03
10
0K
V
05
1
2
ZD1108
NC/AZ5123-01H
1
2
ZD1110
N
C
 V
P
O
R
T
06
03
10
0K
V
05
1
2
TP1117
R1218
NC 100R 1/16W 5%
R1206
NC 100R 1/16W 1%
R1204
NC 100R 1/16W 1%
VGA_SCL_15
VGA_ N_R
VGA_IN_L 5
VGA_IN_R 5VGA_ N_R
VGA_ N_L
VGA_VS
VGA_SDA
VGACOM
SOG0
VGA_SCL
VGA_BIN
VGA_HS
VGA_R N
VGA_GIN
VGA_SCL8
VGA_SDA8
VGA_VS8
VGA_HS8
VGA_BIN8
SOG08
VGA_GIN8
VGACOM8
VGA_R N8
VGA_VSYNC
VGA_HSVGA_HSYNC
VGA_VS
CN101
NC D-SUB 15P
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
17
1618
19
VGA_BIN
SOG0
VGA_GIN
Circuit Diagrams and PWB Layouts EN 65TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-6 Video YPbPr/CVBS
19760_512 eps
Video YPbPr/CVBSB06 B06
201 -07 073
715G6836Video YPbPr/CVBS
AV_AudioRIN
PR1_DET
AVDD33_RGB_STB
Y1P
SOY1
COM1
PB1P
PR1P
AVDD33_VIDEO_STB
R1001
0R05 1/10W
R1002
100R 1/16W 5%
C1003 2.2UF
SOY1
YPbPr Audio Input
C1004 2.2UF
YPBPR_L_IN
YPBPR_R_IN
ZD105
NC/AZ5123-01H
1
2
IF Interface
ADCINP_DEMOD
ADCINN_DEMOD
R1003
75R 1/16W 1%
C1001
47pF 50V
ADCINP_DEMOD
Analog 1.2V Power
DVDD3V33,4,5,6,9,10,11,13,15,16,17,18 DVDD3V3
AV_CVBS_IN
FB102 120R
1 2
ZD107
AZ5123-01H
2
ZD108
AZ5123-01H
2
ZD106
AZ5123-01H
1
2
AV_AudioLIN
C
11
8
N
C
 1
N
 5
0V
AV_R_In
CVBS0P
CVBS_L_IN
CVBS_R_IN
CVBS_L_IN
CVBS_R_IN
C
11
7
N
C
 1
N
 5
0V
R107
NC 75R 1/16W 1%
AV_L_In
R113
NC 75R 1/16W 1%
CVBS_R_IN 5
CVBS_L_IN 5
TP407TP
VGA_RIN
ADCINN_DEMOD
VGA_GIN
SOG0
C1214
330PF 50V
PR_DET
C1215
330PF 50V
VGA_BIN
DVDD3V3
C105
1UF 10V
CVBS0P
VGA_HS
VGA_VS
VGA_SDA
VGA_SCL
C103
1UF 10V
C101
NC/100N 16V
C102
100NF 16V
R1005
NC/0R05 1/16W
C104
100NF 16V
R1302 NC 33R 1/16W 5%
R114
NC 75R 1/16W 1%
CVBS Audio Input
AVDD1V2
3V3SB3V3SB
Control Interface
3V3SB
AVDD1V2
PR1_DET10
AVDD1V23,13,15
3V3SB3,4,10,13,14
GND3,4,5,6,7,9,10,11,12,13,14,15,16,17,18
YPBPR_R_IN 5
YPBPR_L_IN 5
ADCINN_DEMOD 11
R1301 NC 33R 1/16W 5%
IFAGC_Scaler 11
ADCINP_DEMOD 11
VGACOM
CVBS_COM
ZD101
NC/AZ5123-01H
2
ZD102
NC/AZ5123-01H
2
ZD103
NC/AZ5123-01H
1
2
ZD104
NC/AZ5123-01H
1
2
YPbPr Video/Audio Input
U401D
MT5561LVNT
VGA_SCL
V5
VGA_SDA
V4
VSYNC
V10
HSYNC
U10
BP
V11
SOG
U11
GP
W12
COM
Y12
RP
V12
SOY1
U12
Y1
V13
COM1
U13
PB1
W14
PR1
Y14
SOY0
V14
Y0
U14
COM0
V15
PB0
U15
PR0
W16
VDAC_OUT
W17
CVBS1
Y17CVBS0
V18
ADCINP_DEMOD
W18 ADCINN_DEMOD
Y19
AVDD33_RGB_STB
V17
AVDD33_VIDEO_STB
U17
AVDD12_DEMOD
Y20
AVSS33_CLN
N14
CVBS_COM
Y16
AVSS33_RGB
T12
AVSS33_VIDEO
T14
IF_AGC
J15 RF_AGC
L16
20mil
A
B
C
CN102
JACK
2
1
4
3
6
5
7
AVDD12_DEMOD
E
A
B
C
D
CN116
NC/RCA JACK
1
2
3
4
5
6
7
8
9
10
11
12
13 Side CVBS Video/Audio input
VGA_SCL
SOG0
VGA_RIN
R122
NC 100R 1/16W 5%
VGA_SDA
VGA_VS
VGA_GIN
VGA_BIN
VGACOM
VGA_HS
R102
NC 10R 1/16W 1%
Control Interface
IFAGC_Scaler
R106
NC 0R05 1/10W
YPBPR_R_IN
R117
NC 100R 1/16W 5%
PB1P
PR_DET
VGA_SDA 7
VGA_SCL 7
R109
NC 100R 1/16W 5%
VGA_VS 7
VGA_HS 7
C113
NC 10PF 50V
VGA_BIN 7
R110
NC 0R05 1/10W
SOG0 7
PR1P
VGA_GIN 7
Y1P
C106
NC 1.5nF 50V
VGACOM 7
R108
NC 0R05 1/10W
R118
NC 30K OHM
VGA_RIN 7
COM1
R112
NC 100R 1/16W 5%
C114
NC 10N 50V
Y_IN_1
PB_IN_1 C109
NC 10PF 50V
R105
NC 100R 1/16W 5%
C108
NC 10N 50V
R115
NC 0R05 1/10W
PR_IN_1
C115
NC 2.2uF
YPbPr1R_IN
YPbPr1L_IN
R119
NC 30K OHM
C110
NC 10N 50V
C116
NC 2.2uF
YPBPR_L_IN
C112
NC 10PF 50V
C111
NC 10N 50V
TP405 TP AVDD33_VIDEO_STB AVDD33_RGB_STB
H = > Pr Plug-in (YPbPr)
L = > Pr Plug-out (AV)
AVDD12_DEMOD
AVSS33_CLN
IFAGC_Scaler
AVSS33_RGB
AVSS33_VIDEO
PR1_DET
R120
NC/0R05 1/16W
10mil
C1002
47nF 16V
Merged Analog 3.3V Power
R121
NC 47K 1/16W 5%
R1004
30K OHM
R1006
30K OHM
EN 66TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-7 SPDIF/Mute contorl
19760_514 eps
SPDIF/ Mute contorlB07 B07
201 -07 073
715G6836SPDIF/ Mute contorl
R679
5.1K 1%
R657
10K +-1% 1/16W
R658
4.7K 1/16W R659
2.2K 1%
R668
470R 1/16W 5%
C678
10UF 6.3V 20%
D601
BAV70
3
1
2
Q603
LMBT3904LT1G
D602
BAS316
R660
4.7K 1/16W
HP_AC_MUTE
R664
1K 1/16W 1%
C680
100NF 16V
C679
NC/10UF 6.3V 20%
Q601
LMBT3904LT1G
R669
10K +-1% 1/16W
DVDD3V3
DVDD3V3
+5V_SW
DVDD3V33,4,5,6,8,10,11,13,15,16,17,18
+5VSB
DVDD3V3
+5V_SW3,10,11,12,15
HP_AC_MUTE6
HP_MUTE10
+5VSB3,7,16
GND3,4,5,6,7,8,10,11,12,13,14,15,16,17,18
+5VSB
+5V_SW
C677
NC 100N 16V
R656
NC 33R 1/16W 5%
CN603
NC CONNNECTOR
GND
1 VCC
2 VIN
3
+5V_SW
SPDIF_OUT5
15mil
SPDIF_OUT
R624
100R 1/16W 5%
C685
100NF 16V
R654
180R 1/16W 5%
CN604 RCA JACK
1
2
C686
33P 50V
ZD602
AZ5123-01H
1
2
HP_MUTE
A_MUTE
HP_MUTE
AC OFF
DC OFF
Audio Mute for SCART
HP_MUTE
H: MUTE
L: UN-MUTE
10mil
SPDIF OUT
SPDIF_OUT
Mute Control
GPIO Control Mute
A_MUTE
+
C681
22uF 16V
HP_AC_MUTE
Circuit Diagrams and PWB Layouts EN 67TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-8 LVDS_Keypad_IR
19760_515 eps
LVDS_Keypad_IRB08 B08
201 -07 073
715G6836LVDS_Keypad_IR
TX_AOCKP
TX_AO2N
TX_AOCKP
TX_AO3N
TX_AO0N
TX_AO1N
TX_AE1N
TX_AE3N
TX_AE0N
TX_AE2N
+C409
100UF 35V
KEY_On_board 14
KEY_On_board
HP_DET#
KEY_MENU_L_R_SOURCE
LVDS_PWR_EN
panel_power
+ C480
NC 100UF 25V
AC_DET
IR_PWR
TX_AO0P
TX_AO2P
TX_AE1P
TX_AOCKN
TX_AOCKN
TX_AO3P
TX_AO1P
TX_AE3P
TX_AE2P
TX_AE0P
PR1_DET
DEMOD_RST
HP_MUTE
ARC_on/off
R409
4.7K 1/8W
Panel_Select
R434 100R 1/16W 5%
IRR435 100R 1/16W 5%
FB403
30R
1
2
Joy_Key
C
414
100N
F
 16V
3V3SB
R430
6.8K 1/16W
LED_PWR_GREEN
C
418
100N
F
 16V
R4050
NC 1.2K 1/16W
C
415
N
C
 100N
 16V
R4054
NC/10K
R438 100R 1/16W 1%KEY_MENU_L_R_SOURCE
C
416
N
C
 100N
 16V
C
417
N
C
/100N
 16V
C
419
100N
F
 16V
KEY_UP_DN_DCSW
R433 100R 1/16W 5%
OIRI
3V3SB
LED_POWER_RED
R437 100R 1/16W 1%
CN401
NC CONN
2
4
6
8
10
1
3
5
7
9
Q421
NC BC847C
LED_POWER_RED
DVDD3V33,4,5,6,8,9,11,13,15,16,17,18 DVDD3V3
GPIO Interface
IR/KEY BOARD
PR1_DET
HP_MUTE
DEMOD_RST
3V3SB
C477
10UF 16V
KEY_UP_DN_DCSW
FB408 NC/220R
1 2
R490
NC 100R 1/16W 1%
R491
NC 100R 1/16W 5%
CN408
CONN
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29 SW_CTL 11
16Vto12V
SW_CTL
R492
NC 4.7K 1/16W
KEY_On_board
SW_CTL
3V3SB
U401G
MT5561LVNT
AE3P
C8
AE3N
D8
AE2P
C7
AE2N
D7
AE1P
A6
AE1N
B6
AE0P
C6
AE0N
D6
AO3P
C5
AO3N
D5
AOCKP
A4
AOCKN
B4
AO2P
C4
AO2N
D4
AO1P
C3
AO1N
D3
AO0P
A2
AO0N
B2
TCON0
E4
TCON1
F2
TCON2
C2
TCON3
E3
TCON4
C1
TCON5
D1
TCON6
F3
TCON7
D2
TCON8
F1
C
76
N
C
/1
0N
 5
0V
U403
NC/SY8104ADC
LX
5
FB
1
EN
2
GND
3
IN
4
BS
6
C479
NC/22UF 10V
R488 0R051/8W
R484
NC/10K 1/10W 1%
C478
NC/22UF 10V
A
C
_O
ff
Q422
NC/BC847C
3V3SB
LED_PWR_Blue
L402
NC/4.7uH
R4052
NC 1.2K 1/16W
R485
NC/36K 1%
R487 NC/40.2K 1/16W 1%
R
86
N
C
/2
0K
 O
H
M
 1
/1
6W
 1
%
LED-BLED-R
R483 NC/191K OHM 1% 1/16W
R4055
NC/10K
Q409
NC AO3401
R482 NC/0R05 1/16WC474 NC/100pF 50V
C475
NC/0.1uF 50V
Q405
NC AO3401A
HP_DET#
HP_DET# 5
C411
470NF 16V
LED-B
KEY_UP_DN_DCSW
LED_PWR_GREEN
OIRI
SW401
NC SW
1 2
3 4
LED_POWER_RED
R431
6.8K 1/16W
Q403
NC/2N7002K
R440
NC/470R 1/10W 1%
C412
100NF 16V
C410
100NF 16V
R436
47K 1/16W 5%
R441
4.7K 1/16W
Q401
SM4310PSKC
S
1
S
2
S
3
G
4
D
8
D
7
D
6
D
5
R444
NC/1K 1/16W 1%
R427
NC/1K 1/16W
R432
47K 1/16W 5%
C413
NC/100N 16V
FB404 220R
1 2
FB402 NC/220R
1 2
R439
2.2K 1%
Q402
LMBT3904LT1G
R428
NC 0R05 1/16W
FB401
120R
1 2
LVDSVDD
+12V
Panel_VCC
+5V_SW
DVDD3V3
LVDSVDD
Panel_VCC 3V3SB
+5V_SW
+12V
LVDS_PWR_EN9 10
8
7
Side ConnectorsRear Connectors
6
SPDIF
 OUT
1 2 3 4
10000_022_090121 eps
090121
10000_017_090121.eps
090428
19 1
18 2
Technical Specs, Diversity, and Connections 6 TPM15.6L LA2.
2015-July-10 back to
div.table
7- HDMI 1: Digital Video - In, Digital Audio with ARC - In/Out
Figure 2-8 HDMI (type A) connector
1 - D2+ Data channel �
2 - Shield Gnd �
3 - D2- Data channel �
4 - D1+ Data channel �
5 - Shield Gnd �
6 - D1- Data channel �
7 - D0+ Data channel �
8 - Shield Gnd �
9 - D0- Data channel �
10 - CLK+ Data channel �
11 - Shield Gnd �
12 - CLK- Data channel �
13 - Easylink/CEC Control channel ��
14 - ARC Audio Return Channel �
15 - DDC_SCL DDC clock �
16 - DDC_SDA DDC data ��
17 - Ground Gnd �
18 - +5V �
19 - HPD Hot Plug Detect �
20 - Ground Gnd �
8 - Cinch: Digital Audio - Out
BK - Coaxial 0.4 - 0.6VPP / 75 W ��
9- EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
Figure 2-9 HDMI (type A) connector
1 - Audio R 0.5 VRMS / 1 k �
2 - Audio R 0.5 VRMS / 10 k �
3 - Audio L 0.5 VRMS / 1 k �
4 - Ground Audio Gnd �
5 - Ground Blue Gnd �
6 - Audio L 0.5 VRMS / 10 k �
7 - Video Blue/C-out 0.7 VPP / 75  ��
8 - Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 �
9 - Ground Green Gnd �
10 - n.c.
11 - Video Green 0.7 VPP / 75  �
12 - n.c.
13 - Ground Red Gnd �
14 - Ground P50 Gnd �
15 - Video Red/C 0.7 VPP / 75  �
16 - Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75  �
17 - Ground Video Gnd �
18 - Ground FBL Gnd �
19 - Video CVBS 1 VPP / 75  �
20 - Video CVBS/Y 1 VPP / 75  �
21 - Shield Gnd �
10 - Audio - In: Left / Right, VGA
Bu - Audio L/R in 0.5 VRMS / 10 kW ��
2.5 Chassis Overview
Refer to 9. Block Diagrams for PWB/CBA locations.
10000_017_090121.eps
090428
19 1
18 2
21
20
1
2
Precautions, Notes, and Abbreviation List 7TPM15.6L LA 3.
2015-July-10back to
div.table
3. Precautions, Notes, and Abbreviation List
Index of this chapter:
3.1 Safety Instructions
3.2 Warnings
3.3 Notes
3.4 Abbreviation List
3.1 Safety Instructions
Safety regulations require the following during a repair:
• Connect the set to the Mains/AC Power via an isolation
transformer (> 800 VA).
• Replace safety components, indicated by the symbol �,
only by components identical to the original ones. Any
other component substitution (other than original type) may
increase risk of fire or electrical shock hazard.

Safety regulations require that after a repair, the set must be
returned in its original condition. Pay in particular attention to
the following points:
• Route the wire trees correctly and fix them with the
mounted cable clamps.
• Check the insulation of the Mains/AC Power lead for
external damage.
• Check the strain relief of the Mains/AC Power cord for
proper function.
• Check the electrical DC resistance between the Mains/AC
Power plug and the secondary side (only for sets that have
a Mains/AC Power isolated power supply):
1. Unplug the Mains/AC Power cord and connect a wire
between the two pins of the Mains/AC Power plug.
2. Set the Mains/AC Power switch to the “on” position
(keep the Mains/AC Power cord unplugged!).
3. Measure the resistance value between the pins of the
Mains/AC Power plug and the metal shielding of the
tuner or the aerial connection on the set. The reading
should be between 4.5 M and 12 M.
4. Switch “off” the set, and remove the wire between the
two pins of the Mains/AC Power plug.
• Check the cabinet for defects, to prevent touching of any
inner parts by the customer.
3.2 Warnings
• All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD 	). Careless handling
during repair can reduce life drastically. Make sure that,
during repair, you are connected with the same potential as
the mass of the set by a wristband with resistance. Keep
components and tools also at this same potential.
• Be careful during measurements in the high voltage
section.
• Never replace modules or other components while the unit
is switched “on”.
• When you align the set, use plastic rather than metal tools.
This will prevent any short circuits and the danger of a
circuit becoming unstable.
3.3 Notes
3.3.1 General
• Measure the voltages and waveforms with regard to the
chassis (= tuner) ground (�), or hot ground (
), depending
on the tested area of circuitry. The voltages and waveforms
shown in the diagrams are indicative. Measure them in the
Service Default Mode with a colour bar signal and stereo
sound (L: 3 kHz, R: 1 kHz unless stated otherwise) and
picture carrier at 475.25 MHz for PAL, or 61.25 MHz for
NTSC (channel 3).
• Where necessary, measure the waveforms and voltages
with (�) and without (�) aerial signal. Measure the
voltages in the power supply section both in normal
operation (
) and in stand-by (�). These values are
indicated by means of the appropriate symbols.
3.3.2 Schematic Notes
• All resistor values are in ohms, and the value multiplier is
often used to indicate the decimal point location (e.g. 2K2
indicates 2.2 k).
• Resistor values with no multiplier may be indicated with
either an “E” or an “R” (e.g. 220E or 220R indicates 220 ).
• All capacitor values are given in micro-farads (   10-6),
nano-farads (n   10-9), or pico-farads (p   10-12).
• Capacitor values may also use the value multiplier as the
decimal point indication (e.g. 2p2 indicates 2.2 pF).
• An “asterisk” (*) indicates component usage varies. Refer
to the diversity tables for the correct values.
• The correct component values are listed on the Philips
Spare Parts Web Portal.
3.3.3 Spare Parts
For the latest spare part overview, consult your Philips Spare
Part web portal.
3.3.4 BGA (Ball Grid Array) ICs
Introduction
For more information on how to handle BGA devices, visit this
URL: http://www.atyourservice-magazine.com. Select
“Magazine”, then go to “Repair downloads”. Here you will find
Information on how to deal with BGA-ICs.
BGA Temperature Profiles
For BGA-ICs, you must use the correct temperature-profile.
Where applicable and available, this profile is added to the IC
Data Sheet information section in this manual.
3.3.5 Lead-free Soldering
Due to lead-free technology some rules have to be respected
by the workshop during a repair:
• Use only lead-free soldering tin. If lead-free solder paste is
required, please contact the manufacturer of your soldering
equipment. In general, use of solder paste within
workshops should be avoided because paste is not easy to
store and to handle.
• Use only adequate solder tools applicable for lead-free
soldering tin. The solder tool must be able:
– To reach a solder-tip temperature of at least 400°C.
– To stabilize the adjusted temperature at the solder-tip.
– To exchange solder-tips for different applications.
• Adjust your solder tool so that a temperature of around
360°C - 380°C is reached and stabilized at the solder joint.
Heating time of the solder-joint should not exceed ~ 4 sec.
Avoid temperatures above 400°C, otherwise wear-out of
tips will increase drastically and flux-fluid will be destroyed.
To avoid wear-out of tips, switch “off” unused equipment or
reduce heat.
• Mix of lead-free soldering tin/parts with leaded soldering
tin/parts is possible but PHILIPS recommends strongly to
avoid mixed regimes. If this cannot be avoided, carefully
clear the solder-joint from old tin and re-solder with new tin.
3.3.6 Alternative BOM identification
It should be noted that on the European Service website,
“Alternative BOM” is referred to as “Design variant”.
The third digit in the serial number (example:
AG2B0335000001) indicates the number of the alternative
B.O.M. (Bill Of Materials) that has been used for producing the
specific TV set. In general, it is possible that the same TV
model on the market is produced with e.g. two different types
of displays, coming from two different suppliers. This will then
http://www.atyourservice-magazine.com14
+5V_SW3,9,11,12,15
GND3,4,5,6,7,8,9,11,12,13,14,15,16,17,18
3V3SB3,4,8,13,14
+12V3
KEY_MENU_L_R_SOURCE 14
KEY_UP_DN_DCSW 14
OIRI 4
LED_POWER_RED 4,14
LED_PWR_GREEN 4,14
DEMOD_RST 18
HP_Mute 9
PR1_DET 8
AC_DET 3
AC_DET
ARC_on/off 16
ARC_on/off
TX_AOCKN
TX_AOCKP
LED-R
LVDS POWER Control
H = > LVDS POWER ON
L = > LVDS POWER OFF
LVDS_PWR_EN
TX_AO2P
TX_AO1P
TX_AO2N
TX_AO1N
TX_AO0N
TX_AO3N
TX_AO0P
TX_AO3P
TX_AE1P
TX_AE0P
TX_AE1N
TX_AE0N
TX_AE2N
TX_AE2P
TX_AE3P
TX_AE3N
+12V
16Vto12V
Q408
NC AO3401
CN406
CONN
1
2
3
4
5
6
7
8
9
H = > Power ON
L = > Power ON
LED_PWR_GREENLED_POWER_RED
H = > Standby
L = > Standby
LED-R
LED-B
Joy_Key
IR
IR_PWR
AC_Off 3
AC_Off
EN 68TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-9 TUNER
19760_516 eps
TUNERB09 B09
201 -07 073
715G6836TUNER
R162 100R 1/16W 5%
R165 100R 1/16W 5%
R129 NC/0R05 1/16W
R159
2.2K 1%
IFAGC
R160
2.2K 1%
C146 NC/10N 50V
C127
100NF 16V
R124
1K 1/16W 1%
LNA_INN
C126
7pF 50V
C129 4.7NF 50V
C122
2.2nF 50V
+1V8TUNER
OSCL1
T_SCL
C167
100NF 16V
OSDA1
C166
10N 50V
IFOUT1P
RESET
XTALP
C164
15PF 50V
+1V8TUNER
XTALN
C124
7pF 50V
C165
15PF 50V
XTALN
XTALP
C128
1UF 10V
T_SDA
C131
1UF 10V
C135
100NF 16V
U104
MxL661-AG-R
VDD_3p3
1
LNA_INP
2
LNA_INN
3
VDD_1p8
4
AGC_2/GPO_3
5
AGC_1
6
IF
_O
U
T
P
_2
/G
P
O
_1
7
IF
_O
U
T
N
_2
/G
P
O
_2
8
IF
_O
U
T
P
_1
9
IF
_O
U
T
N
_1
10
V
D
D
_3
p3
11
V
D
D
_1
p8
12
VDD_1p2
13GND_DIG
1VDD_IO
15SCL
16SDA
17CLK_OUT
18
X
TA
L_
N
19
X
TA
L_
P
20
G
N
D
_X
TA
L
21
V
D
D
_1
p8
22
R
E
S
E
T
_N
23
A
S
24
E
-P
A
D
25
R123
510K 1%
C125
100NF 16V
+1V8TUNER
C130 4.7NF 50V
TUNER3.3V
C123
100NF 16V
U102
NC/PE 2750
G
N
D
1
1
R
F
1
2
G
N
D
2
3
GND3
4
RFC
5
GND4
6
G
N
D
5
7
R
F
2
8
G
N
D
6
9
C2
10
C1
11
VDD
12
PADDLE
13
TUNER3.3V
X102
16MHZ
1
2
4
3
TUNER3.3V
LNA_INP
IFOUT1N
FB103 1000OHM1 2
TUNER3.3V
OSDA1
OSCL1
L107
27nH
LNA_INN
C120
1nF 50V
L101
NC 2.2nH
L103
27nH
LNA_INP
C169
5P6 50V
D101
BAV99
3
1 2
C132
1nF 50V
C121
1nF 50V
TUNER3.3V
R130 NC/1MOHM 1/16W +/-5%TUNER3.3V
C147 NC/100N 16V
FB109 1000R
1 2
R168 NC 0R05 1/16W
MxL661
R169
NC 0R05 1/16W
Notch_On2
TUNER3.3V
U113
AZ1117CH-3.3TRG1
A
D
J(
G
N
D
)
1
VOUT
2
VIN
3
4
4
SW_CTL
+5V_SW
C
14
1
10
U
F
 6
.3
V
 2
0%
R133
560R 1/16W 1%
C134
1nF 50V
C190
1UF 10% 16V
Control Interface
IF Interface
R156
330R 1/16W 1%
FB108 1000R
1 2Notch_On1
C133
10UF 6.3V 20%
TUNER_SCL
TUNER_SDA
IFAGC_Toshiba_demo
FCN101
RF CONN
1
12
23
34
4
ANT
5
SW_CTL10
SW_CTL
R149
1K 1/16W 1%C143
10N 50V
IFAGC_Toshiba_demo
T_SCL
T_SDA TUNER_SDA
TUNER_SCL
R116
0R05 1/10W
ADCINP_DEMOD 8
ADCINN_DEMOD 8
TUNER3.3V
FAT_IN-
FAT_IN+
R127
1K 1/16W 1%
D102
BAS316 D_IFP 18
D_IFN 18
D_IFP
D_IFN
C139
10N 50V
C140
0N 50V
C159
NC/1nF 50V
L105
NC 2.2nH D104
NC/BAV99
3
1 2
R449 0R05 1/16W
C168
NC/1nF 50V
L106
8.2NH
R450 0R05 1/16W
C192
4.7PF 50V
DVDD3V3DVDD3V33,4,5,6,8,9,10,13,15,16,17,18
D_IFN
+5V_SW
OSCL1 4,18
GND3,4,5,6,7,8,9,10,12,13,14,15,16,17,18
IFAGC_Scaler 8
OSDA1 4,18
+5V_SW3,9,10,12,15
TUNER_SCL18
IFAGC_Toshiba_demo18
D_IFP
TUNER_SDA18
C136
1nF 50V
C197
100NF 16V
IFAGC_Scaler
R1029
51R 1/16W 5%
L102 82nH
R1030
51R 1/16W 5%
C137
1nF 50V
IFAGC
C158
1nF 50V
IFAGC_Scaler
D103
BAS316
C160
1nF 50V
L104
C148
1UF 10% 16V
R153
10K +-1% 1/16W
R101
0R05 1/16W
C162
NC/47pF 50V
R104
0R05 1/16W
C152
1UF 10% 16V
R164
NC 150R 1/16W 1%
R151
10K +-1% 1/16W
R150
0R05 1/16W
C153
NC/22pF 50V
Notch_On1
C
14
2
10
0N
F
 1
6V
Notch_On2
R157
100R 1/16W 5%
R128
2.2K 1%
FB104
220R
1 2
C154
22PF 50V
R167
0R05 1/16W
R152
0R05 1/16W
C145
22N 25V
R155
100R 1/16W 5%
R1089 NC/0R05 1/16W
C155
22PF 50V
C144
47nF 16V
R161
0R05 1/16W
C151
NC/47pF 50V
R1090 NC/0R05 1/16W
C157
NC/22pF 50V
FCN102
NC/RF CONN
1
12
23
34
4
ANT
5
C161
NC/47pF 50V
C156
1UF 10% 16V
C149
1UF 10% 16V
C150
NC/47pF 50V
C191
22PF 50V
C163
22PF 50V
DVDD3V3
TUNER3.3V
IFOUT1P
IFOUT1N FAT_IN-
FAT_IN+
R1112
0R05 1/16W
R1111
0R05 1/16W
Circuit Diagrams and PWB Layouts EN 69TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-10 DDR3
19760_517 eps
DDR3B10 B10
201 -07 073
715G6836DDR3
R480
0R05 1/16W
C435
1UF 10V
C426
22UF 6.3V
R456
33K 1/16W 1%
U411
G5695T11U
VIN
1
GND
2
EN
3
VFB
4
LX
5
R460
22K 1%
DRAM# Bypass Cap
C441
1UF 10V
C427
100NF 16V
C428
2.2UF
DDRV
C430
10UF 6.3V 20%
L401
2.2uH
C196
NC/4.7UF 10% 10V
RVREF
Main Chip Ref Voltage.
C436
100NF 16V
U401A
MT5561LVNT
DDRV
N1
DDRV
N2
DDRV
N3
DDRV
N4
DDRV
N5
DDRV
N6
DDRVREF
P1
ZQ
P2
TN_MEMPLL
H8
TP_MEMPLL
J8
RVREF
R410
100K 1%
ZQ
R2
DRAM POWER DDRV
R1
+5V_SW
R461
1K 1/16W 1%
C433
100NF 16V
C429
NC/100N 16V
C438
100NF 16V
C440
4.7UF 10% 10V
R455
1K 1/16W 1%
R457
240R 1%
C434
100NF 16V
C432
100NF 16V
C425
NC/100N 16V
C437
100NF 16V
C439
NC/10UF 6.3V 20%
DDRV
DDRV
DDRV
+5V_SW3,9,10,11,15
GND3,4,5,6,7,8,9,10,11,13,14,15,16,17,18
+5V_SW
EN 70TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-11 HDMI/MHL
19760_518 eps
HDMI/MHLB11 B11
201 -07 073
715G6836HDMI/MHL
RX_0_C
HPWR0
RX_0_0
C
505
N
C
/100N
 16V
R
5
1
0
1
0
K

-1
%
 1
/1
6
W
RX_0_1B
RX_0_C
CEC_A0
RX_0_0B
RX_0_1
Q506
BC847C
HDMI_SCL2_IN
RX_2_1
RX_2_C
R508
47K 1/16W 5%
R513
100K1/16W
RX_2_CB
C
511
100N
 16V
HPWR2
R
5
0
4
1
0
K
 1
/1
6
W
 5
%
RX_2_0
Q504
BC847C
R507 22R 1/16W 5%
RX_2_1B
R509
910R 1/16W
3V3SB
RX_0_2B
R506 22R 1/16W 5%
RX_2_0B
HDMI_2M_HPD
C
510
N
C
/100N
 16V
OPWR2_5V
OPWR2_5V
R512
75 OHM 1/16W
C
509
N
C
/100N
 16V
R
5
0
5
1
0
K
 1
/1
6
W
 5
%
RX_2_2
HDMI_SCL2/RX
CEC_A2
HDMI_SDA2_IN HDMI_SDA2/TX
RX_2_2B
R501
100R 1/16W 5%
FB501
120R
1 2
I2C & UART Interface
Control Interface
DVDD3V33,4,5,6,8,9,10,11,15,16,17,18 DVDD3V3
FB503
120R
1 2CEC_A0
HDMI_SCL0
HDMI_SDA0
HDMI_0M_HPD R503
0R05 1/10W
C503
100NF 16V
C501
100NF 16V
REAR HDMI 1
C502
100NF 16V
AVDD1V2AVDD1V2DVDD3V3
R519 100R 1/16W 5%
+5V_SW
+5VSB
R520 100R 1/16W 5%
3V3SB
GND3,4,5,6,7,8,9,10,11,12,14,15,16,17,18
+5VSB3,7,9,16
+5V_SW3,9,10,11,12,15
UART_SEL 16
3V3SB3,4,8,10,14
ESD protcetion
R525
10K +-1% 1/16W
R514
10K 1/16W 5%
R561
75 OHM 1/16W
REAR HDMI 2
(with ARC)
RX_0_1B
RX_0_2
RX_0_1RX_0_1
RX_0_2B
RX_0_1B
RX_0_2
U502
AOZ8804DI
CH1
1
CH2
2
VN
3
CH3
4
CH4
5
NC
6NC
7VN
8NC
9NC
10
RX_0_2B
CN502
HDMI CONN
SHELL1
20
SHELL2
21
D2+
1
D2 Shield
2
D2-
3
D1+
4
D1 Shield
5
D1-
6
D0+
7
D0 Shield
8
D0-
9
CK+
10
CK Shield
11
CK-
12
CE Remote
13
NC
14
DDC CLK
15
DDC DATA
16
GND
17
+5V
18
HP DET
19
SHELL4
23 SHELL3
22
SHELL5
24
Z
D
514
NC/AZ5123-01H
1
2
Z
D
516
NC/AZ5123-01H
1
2
Z
D
515
NC/AZ5123-01H
1
2
Z
D
517
NC/AZ5123-01H
1
2
U401E
MT5561LVNT
HDMI_0_RX_CB
W7
HDMI_0_RX_C
Y7
HDMI_0_RX_0B
V7
HDMI_0_RX_0
V8
HDMI_0_RX_1B
U9
HDMI_0_RX_1
V9
HDMI_0_RX_2B
W9
HDMI_0_RX_2
Y9
HDMI_0_SCL
U7
HDMI_0_SDA
V6
HDMI_0_HPD
W5
AVDD33_HDMI
R10
AVDD12_HDMI_0
Y5
HDMI_1_RX_CB
P20
HDMI_1_RX_C
P19
HDMI_1_RX_0B
P18
HDMI_1_RX_0
P17
HDMI_1_RX_1B
N18
HDMI_1_RX_1
N17
HDMI_1_RX_2B
M20
HDMI_1_RX_2
M19
HDMI_2_RX_CB
M18
HDMI_2_RX_C
M17
HDMI_2_RX_0B
L18
HDMI_2_RX_0
K18
HDMI_2_RX_1B
K20
HDMI_2_RX_1
K19
HDMI_2_RX_2B
J20
HDMI_2_RX_2
J19
HDMI_CEC
K16
HDMI_2_SCL
J17
HDMI_2_SDA
J14
MHL_SENCE
K15HDMI_2_HPD_CBUS
J16
HDMI_1_SCL
J18
HDMI_1_SDA
K14
HDMI_1_HPD
L17
AVDD12_HDMI_1
H20
HDMI_0M_HPD
AVDD1V23,8,15 AVDD1V2
RX_0_C
RX_0_0B
RX_0_1B
RX_0_CB
RX_0_0
RX_0_2
Z
D
506
NC/AZ5123-01H
1
2
Z
D
507
NC/AZ5123-01H
1
2
Z
D
505
NC/AZ5123-01H
1
2
Z
D
504
NC/AZ5123-01H
1
2
Analog Power Merged Analog Power
UART_SEL
HDMI_2M_HPD
AVDD12_HDMI_0
AVDD33_HDMI
AVDD12_HDMI_1
HDMI_SCL2 16
HDMI_SCL2/RX 16
HDMI_SDA2 16
HDMI_SDA2/TX
HDMI_SDA2/TX 16
UART_SEL
HDMI_SCL2/RX
HDMI_SCL2
HDMI_SDA2
HDMI_SCL2
HDMI_SDA2RX_2_1
RX_2_1B
RX_2_CB
RX_2_2
RX_2_0B
RX_2_2B
RX_2_C
RX_2_0
AVDD33_HDMI AVDD12_HDMI_1AVDD12_HDMI_0
ZD501
AZ5123-01H
1 2
ZD518
AZ5123-01H
1 2
CN501
HDMI CONN
SHELL1
20
SHELL2
21
D2+
1
D2 Shield
2
D2-
3
D1+
4
D1 Shield
5
D1-
6
D0+
7
D0 Shield
8
D0-
9
CK+
10
CK Shield
11
CK-
12
CE Remote
13
NC
14
DDC CLK
15
DDC DATA
16
GND
17
+5V
18
HP DET
19
SHELL4
23 SHELL3
22
SHELL5
24
HDMI_CEC
CEC
CEC
ESD protcetion
HDMI CEC
CEC_A2
RX_2_0
RX_2_2BRX_2_0B RX_2_2B
RX_2_CB
RX_2_C
RX_2_0
U506
AOZ8804DI
CH1
CH2
2
VN
3
CH3
4
CH4
5
NC
6NC
7VN
8NC
9NC
10
U507
AOZ8804DI
CH1
1
CH2
2
VN
3
CH3
4
CH4
5
NC
6NC
7VN
8NC
9NC
10RX_2_CB
RX_2_C
RX_2_0B
RX_2_1B
RX_2_1
RX_2_2RX_2_2
RX_2_1B
RX_2_1
R502
100K 1%
RX_0_2B
C
504
100N
F
 16V
RX_0_1
U501
AOZ8804DI
CH1
CH2
2
VN
3
CH3
4
CH4
5
NC
6NC
7VN
8NC
9NC
10
RX_0_0B
RX_0_0
OPWR0_5V
C
506
N
C
/100N
 16V
HDMI_SCL0
HDMI_SDA0HDMI_SDA0_IN
OPWR0_5V
RX_0_CB
R560 47K 1/16W 5%
RX_0_C
RX_0_0B
Q503
BC847C
RX_0_CB
HDMI_SCL0_IN
R
5
1
1
1
0
K

-1
%
 1
/1
6
W
RX_0_2
RX_0_CB
R524
910R 1/16W
RX_0_0
Q502
BC847C
3V3SB
Circuit Diagrams and PWB Layouts EN 71TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-12 GPIO
19760_519 eps
GPIOB12 B12
201 -07 073
715G6836GPIO
USB_PWR_OCP0
KEY_On_board
KEY_On_board 10
LED_POWER_RED
BL_ON/OFF
LVDS_PWR_EN
LED_PWR_GREEN
LED_POWER_RED
R499
10K +-1% 1/16W
USB_OC 15
USB_OC
3V3SB3,4,8,10,13 3V3SB
USB_OC
3V3SB
WiFi_PWR_EN
R448
NC 10K +-1% 1/16W
U401I
MT5561LVNT
GPIO0
B1
GPIO1
E5
OPWM0
E6OPWM1
G5OPWM2
G6
OPCTRL1
V2
OPCTRL2
V3
OPCTRL3
V1
OPCTRL4
U4
ADIN7
R8 ADIN6
T6 ADIN5
U5 ADIN4
T8 ADIN3
U6 ADIN2
U8 ADIN1
P8 ADIN0
T7
GPIO2
G17
GPIO3
H5
GPIO4
H4
GPIO5
F17
OPCTRL0
U3
USB_PWR_EN0
LED_PWR_GREEN LVDS_PWR_EN
BL_ON/OFF
BL_DIMMING
USB_PWR_EN0
SYS_EEPROM_WP
KEY_UP_DN_DCSW
KEY_MENU_L_R_SOURCE
USB_PWR_OCP0
GND3,4,5,6,7,8,9,10,11,12,13,15,16,17,18
AMP_MUTE
AMP_MUTE 6
AMP_MUTE
BL_DIMMING
WiFi_PWR_EN
WiFi_PWR_EN 15
KEY_MENU_L_R_SOURCE
KEY_UP_DN_DCSW
R481
10K +-1% 1/16W
SYS_EEPROM_WP
KEY_On_board
LVDS_PWR_EN 10
USB_PWR_EN0 15
SYS_EEPROM_WP 4
BL_ON/OFF 3
LED_PWR_GREEN 4,10
BL_DIMMING 3
LED_POWER_RED 4,10
USB_PWR_OCP0 15
KEY_UP_DN_DCSW 10
KEY_MENU_L_R_SOURCE 10
EN 72TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-13 USB/WiFi
19760_520 eps
USB/ WiFiB13 B13
201 -07 073
715G6836USB/ WiFi
USB_DP_P1
USB_DM_P1
OC
2.5 = > NORMAL
HI = > POWER ON
LO = > POWER OFF
USB_DP_P0
USB_DM_P0
HI = > NORMAL
LO => OC
USB_OC 14
USB_OC
DEMOD_TSSYNC
DEMOD_TSVAL
DEMOD_TSDATA0
DEMOD_TSCLK
USB_DM_P1
DEMOD_TSDATA018
DEMOD_TSCLK18
DEMOD_TSVAL18
DEMOD_TSSYNC18 DEMOD_TSSYNC
DEMOD_TSVAL
DEMOD_TSCLK
DEMOD_TSDATA0
AVDD12_ETH
USB_DP_P1
USB_OC
C171
NC/100N 16V
C172
NC/100N 16V
REXT
AVDD33_ETH
DVDD3V3AVDD1V2
U401H
MT5561LVNT
CI_CD1#
E18
CI_D3
E17
CI_MDO3
E16
CI_MDO4
E20
CI_D4
E19
CI_D5
D20
CI_MDO5
D19
CI_A1
C9
CI_MDO6
C20
CI_D6
D18
CI_D7
B20
CI_MDO7
C19
CI_CE1#
B19
CI_A10
A19
CI_IORD#
A18
CI_OE#
C18
CI_A11
B18
CI_IOWR#
D17
CI_MISTRT
D16
CI_A9
C17CI_A8
C16
CI_MDI0
A16
CI_MDI1
C15
CI_A13
B16
CI_A14
A15
CI_MDI2
C14
CI_MDI3
C13
CI_WE#
B15
CI_IREQ#
F11
CI_MDI4
A13
CI_MDI5
E12
CI_MIVAL
B13 CI_MCLKI
D14
CI_MDI6
F12
CI_MDI7
E13
CI_A12
E9
CI_A7
D12
CI_MCLKO
A12
CI_RESET
C12
CI_A6
B12CI_A5
E10
CI_WAIT#
C11
CI_A4
D10CI_A3
A10
CI_REG#
B10
CI_MOVAL
C10
CI_A2
F10
CI_MOSTRT
D11
CI_MDO0
E11
CI_A0
D9
CI_MDO1
E7
CI_MDO2
E8
CI_PWR_EN
F18
CI_D0
B8
CI_D1
D13
CI_D2
F9
CI_CD2#
F7
U401F
MT5561LVNT
USB_DM0
H19
USB_DP0
H18
USB_DM1
G19
USB_DP1
F19
RXVN
W2
RXVP
W3
TXVN
Y1
TXVP
Y2
AVDD33_ETH
R9AVDD12_ETH
Y4
REXT_ETH
W4
AVDD1V23,8,13 AVDD1V2
TP410
TP411
TP412
TP413
WiFi_PWR_EN 14
WiFi_PWR_EN
R1114
10K +-1% 1/16W
USB_PWR_OCP0
C170
1UF 10% 16V
USB_DP_P0
USB_PWR_EN0 USB_PWR_OCP0
USB_DM_P0
USB_PR
+5V_SW
WiFi_PWR_EN
DVDD3V3
Q706
NC AO3401A
WiFi
R1115 NC 10K 1/16W 5%
R1027
24K 1%
+5V_SW
DVDD3V3
USB_PWR_OCP0 14
+5V_SW3,9,10,11,12
GND3,4,5,6,7,8,9,10,11,12,13,14,16,17,18
DVDD3V33,4,5,6,8,9,10,11,13,16,17,18
USB_PWR_EN0 14
Control Interface
AVDD33_ETH
AVDD12_ETH USB_PWR_EN0
1
2
3
4
CN103
USB CONN
1
2
3
4
6
5R1025
NC 0R05 1/16W
R452 NC 5R6 1/16W 5%
R1026
NC 4.7K 1/16W
C
173
10U
F
 10V
C
175
N
C
/10P
 50V
R451 NC 5R6 1/16W 5%
t
TH101
PTCR
1 2
R1024
NC 10K 1/16W 5%
U404
NC/G5250M1T1U
OUT
1
GND
2
OC
3
EN
4
IN
5
R1032
10K +-1% 1/16W
C
176
N
C
/10P
 50V
C
174
100N
F
 16V
+5V_SW
DVDD3V3
Z
D
119
NC/AZ5123-01H
1
2
Z
D
118
NC/AZ5123-01H
1
2
CN403
NC CONN 1
2
3
4
5
6
Circuit Diagrams and PWB Layouts EN 73TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-14 FACTORY DEBUG PORT
19760_521 eps
FACTORY DEBUG PORTB14 B14
201 -07 073
715G6836FACTORY DEBUG PORT
U414
74HC4052PW
1Y0
12
2Y0
1
1Y1
14
2Y1
5
1Y2
15
2Y2
2
1Y3
11
2Y3
4
S0
10
S1
9
VEE
7
GND
8
/E
6
1Z
13
2Z
3
VCC
16
S1
C408
100NF 16V
U0TX
+5VSB
U0RX
+5VSB
D401
BAS316
ARC_on/of f
HDMI_SCL2/RXUART_SEL
R406
10K +-1% 1/16W
10mil
UART_SEL
ARC_on/of f
S0
L :ON-state
HDMI functionH
S1
NC/ARC
H
H
CHANNEL
L
S0
ARC on/off enable control
H :OFF-state
Debug mode
HDMI
pin14
+12V
ARC_SPDIF
R467
40.2K 1/16W 1%
U0TX
U0RX
R466
60.4K 1%
R464
10K +-1% 1/16W
+5VSB
HDMI_SCL2
HDMI_SDA2
Q404
LMBT3904LT1G
ARC_SPDIF
UART_SEL
HDMI_SDA2/TX
HDMI_SCL2/RX
HDMI_SDA2HDMI_SDA2/TX
HDMI_SCL2/RX HDMI_SCL2R493
NC 0R05 1/16W
R494
NC 0R05 1/16W
U410
74CBTLV1G125GW
OE
1
A
2
GND
3
B
4
Vcc
5
R468
10K +-1% 1/16W
R470
180R 1/10W 1%
C444
1UF 25V
R471
82R 1/10W 1%
C443
100NF 16V
DVDD3V3
DVDD3V3
+5VSB
DVDD3V3
+5V_SW
UART_SEL 13
HDMI_SDA2 13
HDMI_SDA2/TX 13
+5VSB3,7,9
HDMI_SCL2 13
GND3,4,5,6,7,8,9,10,11,12,13,14,15,17,18
U0RX 4
U0TX 4
+5V_SW3,9,10,11,12,15
DVDD3V33,4,5,6,8,9,10,11,13,15,17,18
ARC_on/of f 10
ARC_SPDIF 5
HDMI_SCL2/RX 13
HDMI_SDA2
HDMI_SCL2
HDMI_SDA2/TX
EN 74TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-15 VCCK & DVSS
19760_522 eps
VCCK & DVSSB15 B15
201 -07 073
715G6836VCCK & DVSS
C456
10UF 6.3V 20%
C451
10UF 6.3V 20%
C447
10N 50V
C459
100NF 16V
C448
10N 50V
C458
100NF 16V
C460
100NF 16V
C450
10UF 6.3V 20%
C454
4.7UF 10% 10V
C457
100NF 16V
VCCK
VCCK
VCC3IO
VCCK
DVDD3V3
VCC3IO
DVDD3V3
VCCK
GND3,4,5,6,7,8,9,10,11,12,13,14,15,16,18
DVDD3V33,4,5,6,8,9,10,11,13,15,16,18
VCCK3
+ C449
100UF 16V
Core Power
3.3V IO Power
C446
1UF 10V
C452
1UF 10V
C453
1UF 10V
U401J
MT5561LVNT
VCCK
K6VCCK
K5VCCK
J9VCCK
L1VCCK
L2VCCK
L3VCCK
L4VCCK
L5VCCK
L6
DVSS
H9
DVSS
H10
DVSS
H12
DVSS
A1
DVSS
J10
DVSS
J11
DVSS
J12
DVSS
K9
DVSS
K10
DVSS
K11
VCC3IO
P9
VCC3IO
N10
VCC3IO
P10
DVSS
R13 DVSS
M9 DVSS
L12 DVSS
M11 DVSS
M13 DVSS
M12
VCCK
K7
VCCK
K8
VCCK
L7
VCCK
L8
VCCK
M7
VCCK
M8
DVSS
K12
DVSS
A8
DVSS
F6
DVSS
F20
DVSS
G7
DVSS
G18
DVSS
H13
DVSS
H11
DVSS
J13
DVSS
L9
DVSS
L11
DVSS
L13
DVSS
M1
DVSS
M2
DVSS
L10
DVSS
M3
DVSS
R6
DVSS
M4
DVSS
M5
DVSS
M6
DVSS
N8
DVSS
N13
DVSS
N11
DVSS
N12
DVSS
N15
DVSS
T13
DVSS
N16
DVSS
P7
DVSS
P11
DVSS
P12
DVSS
P14
DVSS
R11
DVSS
R12
DVSS
R14
DVSS
T5
DVSS
W19
DVSS
Y3
DVSS
G8 DVSS
H16
DVSS
J7
DVSS
M10
DVSS
N7
DVSS
N9
DVSS
T15 DVSS
U16 DVSS
V16
DVSS
H14
C461
10UF 6.3V 20%
C463
10UF 6.3V 20%
Circuit Diagrams and PWB Layouts EN 75TPM15.6L LA 10.
2015-July-10 back to
div table
10-5-16 DEMOD_Toshiba TC90537
19760_523 eps
DEMOD_Toshiba TC90537B16 B16
201 -07 073
715G6836DEMOD_Toshiba TC90537
X101
16MHZ
1
2
4
3R135
10K 1/10W
SBYTE_ORR OSDA1
R142
NC 10K 1/16W 5%
OSCL1
XT_O
XT_I
XT_O
XT_I
D_IFP
D_IFN
TP101
R141
10K +-1% 1/16W
DEMOD_RST
TP110 TP109
OSDA1
FAGC_Toshiba_demo
OSCL1
R148
10K +-1% 1/16W
TP108
R
15
4
2.
2K
 1
%
U103
G9141T11U
IN
1
GND
2
SHDN
3
SET
4
OUT
5
TP107
TP106
TP105
C195
10UF 6 3V 20%
TP104
DVDD3V3
TP102
C194
1UF 10V
TP103SLADRS1
+1V2
PBVAL_ORR
SRDT_ORR
TUNER_SCL
TUNER_SDAFAGC_Toshiba_demo
SLADRS0
A
G
C
C
N
T
I
SLADRS1
R146
4.7K 1/16W
DVDD3V3
R147
4.7K 1/16W
DEMOD_RST10
DEMOD_TSCLK15
DEMOD_TSDATA015
TUNER_SDA11
DVDD3V33,4,5,6,8,9,10,11,13,15,16,17
DEMOD_TSVAL15
IFAGC_Toshiba_demo11
GND3,4,5,6,7,8,9,10,11,12,13,14,15,16,17
DEMOD_TSSYNC15
D_IFP11
D_IFN11
OSDA1 4,11
TUNER_SCL11
OSCL1 4,11
DEMOD_TSCLK
TUNER_SDA
DEMOD_TSDATA0
GPIO Interface
DEMOD_TSVAL
DEMOD_TSSYNC
C188
100NF 16V
C185
10UF 6.3V 20%
C183
100NF 16V
C186
100NF 16V
C187
100NF 16V
C193
10N 50V
C177
100NF 16V
C189
100NF 16V
C199
100NF 16V
RP101
33 OHM +-5% 1/16W
1
2
3
4
8
7
6
5
C180
100NF 16V
R137
1.2K OHM 1/16W 1%
C184
100NF 16V
FB106
120R
12
R143
00R 6W 5%
FB1009
120R
12
C178
27PF
R136
1M 1/10W 5%
C119
100NF 16V
R125
10K +-1% 1/16W
R145
100R 1/16W 5%R140
0R05 OHM
C182
100NF 16V
FB105
120R
12
R126
NC/ 10K+-5%1/16W
R134
10K +-1% 1/16W
R144
00R 6W 5%
R138
20K OHM 1/16W 1%
C181
10UF 6.3V 20%
C138
100NF 16V
R111
NC/ 10K+-5%1/16W
FB107
120R
12
C179
27PF
R139
NC 0R05 OHM
FB1008
120R
12
DVDD3V3
+1V2
+1V2
DVDD3V3
DVDD3V3
SRCK_ORR
DVDD3V3
DVDD3V3
FB407 10R
1 2
DVDD3V3
DEMOD_TSSYNC 15
DEMOD_TSCLK 15
DEMOD_TSVAL 15
DEMOD_TSDATA0 15
FB1010
120R
12
SLADRS0
U101
TC90537FG
V
S
S
47
V
D
D
S
14
GPIO1
4
GPIO2
5
S
B
Y
T
E
16
A
G
C
C
N
T
1
18
X
O
23
SLADRS1
29
PLLVSS
26
S
Y
R
S
T
N
42
V
P
G
M
41
VDDC
32
ADCVSS
34
VREFH
36
S
T
S
F
LG
1
43
S
C
L
45
VSS
31
ADCVDD
33
T
N
S
C
L
20
T
N
S
D
A
21
A
N
N
 Q
40
A
N
N
 I
38
A
N
P
 I
37
S
T
S
F
LG
0
44
S
D
A
46
R
S
E
O
R
F
15
X
I
24
VREFL
35
A
N
P
 Q
39
S
LA
D
R
S
0
17
CKI
28
VDDC
1
V
S
S
13
SRCK
12
PBVAL
11
SRDT
10
SLOCK
9
RLOCK
8
RERR
7
SLPEN
6
V
D
D
S
48
VSS
2
GPIO0
3
A
G
C
C
N
T
R
19
X
C
K
O
22
PLLVDD
25
VDDC
27
TSMD
30
DEMOD_RST
C1074
NC 10PF 50V
D_IFN
D_IFP
TUNER_SCL
EN 76TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10-5-17 SSB layout top
19760_524 eps
715G6836LAYOUT TOP
X401
D602
D401
C1
41
C148
C149
C1
52
C1
56
C1
90
C1
96
C4
39
C4
02
C4
11
C428
C430C4
40
C444
C450
C451
C454
C456
C461
C4
63
C6
10
C614
C6
15
C6
16C6
17
C619
C6
21
C623 C624C6
25
C626
C6
28
C630
C631
C634
C636
C6
38
C6
39
C6
40
C642 C6
44
C6
47
C678
C679
C6
84
C195
C708
C710
C712
C713
C7
21
C7
22
C730
C1
73
C6
20
C629
C725
C726
FB
61
1
FB403
FB405
FB501
FB
50
3
FB
60
3
FB604
FB
60
5
FB606
FB607
FB
60
8
FB
60
9
FB
61
0
FB
70
6
FB
10
4
FB401
FB402
FB404
FB408
FB
60
2
FB701
FB702
FB703
R1
16
R440
R466
R4
70
R471
R605R606R607R608
R6
25
R6
26
R719
TH101
C4
26
C1201
C170
C6
08
C115C116 R106 R1
08
R110R115 R1
00
1
R1
40
C1
00
3
C1
00
4
FB
61
2
C133
C169 FB103
D102
D1 3
X1
02
R135
C181 C185
FB
10
08
FB1009
FB105
FB106 FB107
R1
36
FB1010
C475
C7
43
C478
C479
C746
C747
C4
49
C4
09
C7
07
C1202
C4
77
C745
R4
84
R748
R4
88
R752
ZD
70
1
C7
48
C4
80
R4
09
X1
01
D
11
5
D
11
6
C688
C7
19
R785
R503
C6
50 C6
51
C7
23
R1
74
R1
75
R176
IC
T2
R1
R2
SCREW1
IC
T1
SCREW2
R3R5
R6
U
70
5
CN103
CN
60
3
CN
60
4
U
41
0
U501 U502
U
50
6
U
50
7
U
40
4
U601
U113
H
S6
01
U
10
3
L601
L6
02L6
03
L6
04
U405
GND2
GND3GND4
U401
SE
N
1
SE
N
3
SE
N
4
ME3 ME4
SE
N
2
HS401
L703
L702
CN
70
1
U703
ME1 ME2
L7
01
C1
01
C102
C1
04
C1
05
C1
06
C1
08
C109
C1
10
C1
11
C1
12
C1
13
C1
14
C1
17
C1
18
10
02
C186
C1
79
C1
00
1
C1
03
C6
77
C1
42
C143
C144
C1
45
C150C151
C153
C154 C155
C157
C1
61
C1
62
C163
C6
01
C193
C1
71
C1
74
C1
75
C1
76
C1
72
C119
C1
88
C189
C191
C194
C401C403
C404
C405
C406C407
C408
C410
C412
C4
13
C4
14
C4
15
C4
16
C4
17
C4
18
C4
19
C4
25
C4
27
C4
29
C4
32
C4
33
C4
34
C4
35
C4
36
C4
37
C4
38
C4
41
C4
43
C4
46
C4
47
C4
48
C4
52
C4
53
C4
57
C4
58
C459
C460
C4
62
C5
01
C502
C503
C5
04
C5
05
C5
06
C1
77
C6
85
C6
86
C604
C605
C606 C6
07
C6
11
C612
C6
13
C6
18
C6
22
C6
27
C632
C633
C635
C6
37
C6
41
C6
43
C645
C6
46
C6
48
C6
60
C6
61 C6
62
C6
63
C664
C6
80
C603
C6
87
C706
C7
14
C7
31
C184
C6
02
FB102
B4
09
L4
01
U411
CN501
CN602
CN102
C1
07
4
C705
CN605
U
41
4
CN
50
2
SW401
C138
FCN101
FCN102
C120
C121
C122C1
23
C1
24
C125
C1
26
C127
C128
C129
C130
C1
31
C1
32
C1
34
C135
C136C137
C1
39
C140
C146
C147
C1
58
C1
59
C160
C1
64
C1
65
C1
66
C167
C1
68
C1
92
C1
97
L101
L102
L103L104
L105
L1
06
L107
D101
D
10
4
U101
C1
78
C180 C182 C183
C187
C199
RP
10
1
U406
SE
N
6
CN101
C1207
C1
21
0
C1211 C1212
L402
U102
U
70
6
C1
03
C
20
4
C1
05
C1
2
6
C1208C1209
C4
74C4
76
C742
C744
ZD1110ZD1111
U403
CN
60
6
CN116
R1
00
2
R1
01
R102
R1
04
R1
05
R107
R1
09
R121
R1
12
R1
13
R1
14
R122
R1
17
R1
18
R1
19
R1
00
3
R1114
R4
81
R149
R1
50
R151
R1
52
R1
53
R1
55
R156
R1
57
R1
59
R1
60
R1
61
R162
R164
R165
R1
67
R141
R4
01
R4
02
R4
03R404
R4
05
R4
06
R407
R4
80
R4
11
R4
12
R414
R4
15
R4
16
R4
17
R4
18
R4
19
R4
20
R421
R4
22
R4
23
R425
R4
27
R4
28
R4
30
R4
31
R4
32
R4
33
R4
34
R435
R4
36
R4
37
R4
38
R439
R4
41
R5
08
R4
44
R4
48
R449R450
R4
51
R4
52
R4
55
R4
57
R460
R4
61
R4
64
R467
R468
R1202
R4
73
R474
R1227
R4
77
R4
79
R4
85
R501
R5
02
R506
R5
07
R5
10
R5
11
R514
R504
R505
R5
19
R5
20
R5
24
R525
R4
05
4
R513
R4
05
0
R4
05
5
R4
05
2
R634
R635
R512
R5
60
R5
61
R601
R602
R603
R604
R6
09
R6
10
R611 R6
12R6
13
R6
14
R615
R6
16
R6
17
R618
R620
R6
22
R623
R6
24
R637
R654 R6
56
R6
57
R658
R659R6
60
R6
64
R6
68
R6
69
R679
R678
R704
R1
48
R1
54
R705
R7
06
R738
R7
09
R710
R739
R713
R714
R7
17
R7
18
R722
R723
R724
R725
R7
28
R729R730
R1201
R138
R1024
R1025
R1
02
6
R1027
R1
02
9
R1
03
0
R1032
R145
R144
R1
08
9
R1
09
0
R1
11
1
R1
11
2
R456
R483
R4
86
R1004
R1
00
5
R1006
R1
11
5
R120
R147
R126
R123
R124
R127
R128
R129
R130
R1
33
R1
25
R146R1
11
R134
R1
39
R142R143
R1
37
R1
68
R1
69
R1
21
9
R1203
R1
20
7
R1
20
8
R1
20
9
R1
21
0
R1
21
1
R1
21
3
R1214
R1
21
5
R1
21
6
R1
21
7
R1
21
8
R1
22
0
R1228R1301
R1302
R4
10
R4
82
R4
87
R4
99
R7
46
R7
47
R749
R750
R751
R753
R754
CN409
C609
R1
2
4
R
20
R1
20
6
R1
21
2
C690
FB108FB109
R1
70
R1
71
R4
90
R491
R4
92
Q401
Q702
CN
40
1
C1
21
4
C1
21
5R631
R632
R778
R779
R780
R7
86
R787R788
CN402
Q40
Q
70
1
Q
70
6
Q
42
1
D601
Q
40
2
Q
40
4
Q422
Q601
Q
60
Q
70
3
Q
70
4
Q
50
3
Q
50
2
Q
70
8
Q705
Q
70
Q403
ZD101ZD102ZD103ZD104 ZD
10
5
ZD
10
6
ZD
10
7
ZD
10
8
ZD109 ZD110
ZD
11
8
ZD
11
9
ZD
11
01
ZD1102ZD1103
ZD
11
04
ZD
11
05
ZD
11
06
ZD
11
07
ZD
11
08
ZD
11
23
ZD501
ZD
50
4
ZD
50
5
ZD
50
6
ZD
50
7
ZD
51
8
ZD602
C6
91
ZD
51
4
ZD515
ZD
51
6
ZD
51
7
C5
09C510
C511
R5
09
R6
33 Q504
Q506Q
60
2
Q
40
8
Q409
R1
72
R1
73
CN
40
6
R4
93
R494
FB406
FB
40
7
R6
27
R6
28
CN
60
1
R4
CN403
C6
81
C198
U
10
4
CN408
CN504
Circuit Diagrams and PWB Layouts EN 77TPM15.6L LA 10.
10-5-18 SSB layout bottom
TP101
TP102
TP103
TP104
TP105
TP106TP107
TP108
TP109 TP110
TP401
TP
40
4
TP405
TP
40
7
TP
11
01
TP
11
02
TP
11
03
TP
11
04
TP
11
05TP
11
06
TP
11
07
TP
11
08
TP
11
09
TP
11
10
TP
11
11
TP
11
16
TP
11
17
TP408
TP
40
9
TP
41
0
TP
41
1
TP
41
2
TP
41
3
TP
06
3
TP
06
5
EN 78TPM15.6L LA 10.Circuit Diagrams and PWB Layouts
2015-July-10 back to
div table
10.6 J 715G61767 IR/LED Panel
10-6-1 IR
19641_500.eps
IR/LED panelJ J
2013-0 -29C
715G6167
IR/LED panel
Q001
BC847C
POWER
R002
1K 1/16W 5%
R001
470R 1/16W 5%
Z
D
00
2
V
P
O
R
T
06
03
10
0K
V
05
1
2
---->
Z
D
00
3
V
P
O
R
T
06
03
10
0K
V
05
1
2
C
00
4
N
C
/1
00
N
 5
0V
S
W
001
TA
C
T
 S
W
 F
W
R
D
 H
1.5M
M
Key1
R
00
5
0R
05
1/
8W
---->
Precautions, Notes, and Abbreviation List 8 TPM15.6L LA3.
2015-July-10 back to
div.table
result in sets which have the same CTN (Commercial Type
Number; e.g. 28PW9515/12) but which have a different B.O.M.
number.
By looking at the third digit of the serial number, one can
identify which B.O.M. is used for the TV set he is working with.
If the third digit of the serial number contains the number “1”
(example: AG1B033500001), then the TV set has been
manufactured according to B.O.M. number 1. If the third digit is
a “2” (example: AG2B0335000001), then the set has been
produced according to B.O.M. no. 2. This is important for
ordering the correct spare parts!
For the third digit, the numbers 1...9 and the characters A...Z
can be used, so in total: 9 plus 26= 35 different B.O.M.s can be
indicated by the third digit of the serial number.
Identification: The bottom line of a type plate gives a 14-digit
serial number. Digits 1 and 2 refer to the production centre (e.g.
SN is Lysomice, RJ is Kobierzyce), digit 3 refers to the B.O.M.
code, digit 4 refers to the Service version change code, digits 5
and 6 refer to the production year, and digits 7 and 8 refer to
production week (in example below it is 2010 week 10 / 2010
week 17). The 6 last digits contain the serial number.
Figure 3-1 Serial number (example)
3.3.7 Board Level Repair (BLR) or Component Level Repair
(CLR)
If a board is defective, consult your repair procedure to decide
if the board has to be exchanged or if it should be repaired on
component level.
If your repair procedure says the board should be exchanged
completely, do not solder on the defective board. Otherwise, it
cannot be returned to the O.E.M. supplier for back charging!
3.3.8 Practical Service Precautions
• It makes sense to avoid exposure to electrical shock.
While some sources are expected to have a possible
dangerous impact, others of quite high potential are of
limited current and are sometimes held in less regard.
• Always respect voltages. While some may not be
dangerous in themselves, they can cause unexpected
reactions that are best avoided. Before reaching into a
powered TV set, it is best to test the high voltage insulation.
It is easy to do, and is a good service precaution.
3.4 Abbreviation List
0/6/12 SCART switch control signal on A/V
board. 0 = loop through (AUX to TV),
6 = play 16 : 9 format, 12 = play 4 : 3
format
AARA Automatic Aspect Ratio Adaptation:
algorithm that adapts aspect ratio to
remove horizontal black bars; keeps
the original aspect ratio
ACI Automatic Channel Installation:
algorithm that installs TV channels
directly from a cable network by
means of a predefined TXT page
ADC Analogue to Digital Converter
AFC Automatic Frequency Control: control
signal used to tune to the correct
frequency
AGC Automatic Gain Control: algorithm that
controls the video input of the feature
box
AM Amplitude Modulation
AP Asia Pacific
AR Aspect Ratio: 4 by 3 or 16 by 9
ASF Auto Screen Fit: algorithm that adapts
aspect ratio to remove horizontal black
bars without discarding video
information
ATSC Advanced Television Systems
Committee, the digital TV standard in
the USA
ATV See Auto TV
Auto TV A hardware and software control
system that measures picture content,
and adapts image parameters in a
dynamic way
AV External Audio Video
AVC Audio Video Controller
AVIP Audio Video Input Processor
B/G Monochrome TV system. Sound
carrier distance is 5.5 MHz
BDS Business Display Solutions (iTV)
BLR Board-Level Repair
BTSC Broadcast Television Standard
Committee. Multiplex FM stereo sound
system, originating from the USA and
used e.g. in LATAM and AP-NTSC
countries
B-TXT Blue TeleteXT
C Centre channel (audio)
CEC Consumer Electronics Control bus:
remote control bus on HDMI
connections
CL Constant Level: audio output to
connect with an external amplifier
CLR Component Level Repair
ComPair Computer aided rePair
CP Connected Planet / Copy Protection
CSM Customer Service Mode
CTI Color Transient Improvement:
manipulates steepness of chroma
transients
CVBS Composite Video Blanking and
Synchronization
DAC Digital to Analogue Converter
DBE Dynamic Bass Enhancement: extra
low frequency amplification
DCM Data Communication Module. Also
referred to as System Card or
Smartcard (for iTV).
DDC See “E-DDC”
D/K Monochrome TV system. Sound
carrier distance is 6.5 MHz
DFI Dynamic Frame Insertion
DFU Directions For Use: owner's manual
DMR Digital Media Reader: card reader
DMSD Digital Multi Standard Decoding
DNM Digital Natural Motion
10000_053_110228.eps
110228
Precautions, Notes, and Abbreviation List 9TPM15.6L LA 3.
2015-July-10back to
div.table
DNR Digital Noise Reduction: noise
reduction feature of the set
DRAM Dynamic RAM
DRM Digital Rights Management
DSP Digital Signal Processing
DST Dealer Service Tool: special remote
control designed for service
technicians
DTCP Digital Transmission Content
Protection; A protocol for protecting
digital audio/video content that is
traversing a high speed serial bus,
such as IEEE-1394
DVB-C Digital Video Broadcast - Cable
DVB-T Digital Video Broadcast - Terrestrial
DVD Digital Versatile Disc
DVI(-d) Digital Visual Interface (d= digital only)
E-DDC Enhanced Display Data Channel
(VESA standard for communication
channel and display). Using E-DDC,
the video source can read the EDID
information form the display.
EDID Extended Display Identification Data
(VESA standard)
EEPROM Electrically Erasable and
Programmable Read Only Memory
EMI Electro Magnetic Interference
EPG Electronic Program Guide
EPLD Erasable Programmable Logic Device
EU Europe
EXT EXTernal (source), entering the set by
SCART or by cinches (jacks)
FDS Full Dual Screen (same as FDW)
FDW Full Dual Window (same as FDS)
FLASH FLASH memory
FM Field Memory or Frequency
Modulation
FPGA Field-Programmable Gate Array
FTV Flat TeleVision
Gb/s Giga bits per second
G-TXT Green TeleteXT
H H_sync to the module
HD High Definition
HDD Hard Disk Drive
HDCP High-bandwidth Digital Content
Protection: A “key” encoded into the
HDMI/DVI signal that prevents video
data piracy. If a source is HDCP coded
and connected via HDMI/DVI without
the proper HDCP decoding, the
picture is put into a “snow vision” mode
or changed to a low resolution. For
normal content distribution the source
and the display device must be
enabled for HDCP “software key”
decoding.
HDMI High Definition Multimedia Interface
HP HeadPhone
I Monochrome TV system. Sound
carrier distance is 6.0 MHz
I2C Inter IC bus
I2D Inter IC Data bus
I2S Inter IC Sound bus
IF Intermediate Frequency
IR Infra Red
IRQ Interrupt Request
ITU-656 The ITU Radio communication Sector
(ITU-R) is a standards body
subcommittee of the International
Telecommunication Union relating to
radio communication. ITU-656 (a.k.a.
SDI), is a digitized video format used
for broadcast grade video.
Uncompressed digital component or
digital composite signals can be used.
The SDI signal is self-synchronizing,
uses 8 bit or 10 bit data words, and has
a maximum data rate of 270 Mbit/s,
with a minimum bandwidth of 135
MHz.
iTV Institutional TeleVision; TV sets for
hotels, hospitals etc.
LS Last Status; The settings last chosen
by the customer and read and stored
in RAM or in the NVM. They are called
at start-up of the set to configure it
according to the customer's
preferences
LATAM Latin America
LCD Liquid Crystal Display
LED Light Emitting Diode
L/L' Monochrome TV system. Sound
carrier distance is 6.5 MHz. L' is Band
I, L is all bands except for Band I
LPL LG.Philips LCD (supplier)
LS Loudspeaker
LVDS Low Voltage Differential Signalling
Mbps Mega bits per second
M/N Monochrome TV system. Sound
carrier distance is 4.5 MHz
MHEG Part of a set of international standards
related to the presentation of
multimedia information, standardised
by the Multimedia and Hypermedia
Experts Group. It is commonly used as
a language to descrbe interactive
television services
MIPS Microprocessor without Interlocked
Pipeline-Stages; A RISC-based
microprocessor
MOP Matrix Output Processor
MOSFET Metal Oxide Silicon Field Effect
Transistor, switching device
MPEG Motion Pictures Experts Group
MPIF Multi Platform InterFace
MUTE MUTE Line
MTV Mainstream TV: TV-mode with
Consumer TV features enabled (iTV)
NC Not Connected
NICAM Near Instantaneous Compounded
Audio Multiplexing. This is a digital
sound system, mainly used in Europe.
NTC Negative Temperature Coefficient,
non-linear resistor
NTSC National Television Standard
Committee. Color system mainly used
in North America and Japan. Color
carrier NTSC M/N= 3.579545 MHz,
NTSC 4.43= 4.433619 MHz (this is a
VCR norm, it is not transmitted off-air)
NVM Non-Volatile Memory: IC containing
TV related data such as alignments
O/C Open Circuit
OSD On Screen Display
OAD Over the Air Download. Method of
software upgrade via RF transmission.
Upgrade software is broadcasted in
TS with TV channels.
OTC On screen display Teletext and
Control; also called Artistic (SAA5800)
P50 Project 50: communication protocol
between TV and peripherals
PAL Phase Alternating Line. Color system
mainly used in West Europe (colour
carrier = 4.433619 MHz) and South
America (colour carrier
PAL M = 3.575612 MHz and
PAL N = 3.582056 MHz)
PCB Printed Circuit Board (same as “PWB”)
PCM Pulse Code Modulation
Precautions, Notes, and Abbreviation List 10 TPM15.6L LA3.
2015-July-10 back to
div.table
PDP Plasma Display Panel
PFC Power Factor Corrector (or
Pre-conditioner)
PIP Picture In Picture
PLL Phase Locked Loop. Used for e.g.
FST tuning systems. The customer
can give directly the desired frequency
POD Point Of Deployment: a removable
CAM module, implementing the CA
system for a host (e.g. a TV-set)
POR Power On Reset, signal to reset the uP
PSDL Power Supply for Direct view LED
backlight with 2D-dimming
PSL Power Supply with integrated LED
drivers
PSLS Power Supply with integrated LED
drivers with added Scanning
functionality
PTC Positive Temperature Coefficient,
non-linear resistor
PWB Printed Wiring Board (same as “PCB”)
PWM Pulse Width Modulation
QRC Quasi Resonant Converter
QTNR Quality Temporal Noise Reduction
QVCP Quality Video Composition Processor
RAM Random Access Memory
RGB Red, Green, and Blue. The primary
color signals for TV. By mixing levels
of R, G, and B, all colors (Y/C) are
reproduced.
RC Remote Control
RC5 / RC6 Signal protocol from the remote
control receiver
RESET RESET signal
ROM Read Only Memory
RSDS Reduced Swing Differential Signalling
data interface
R-TXT Red TeleteXT
SAM Service Alignment Mode
S/C Short Circuit
SCART Syndicat des Constructeurs
d'Appareils Radiorécepteurs et
Téléviseurs
SCL Serial Clock I2C
SCL-F CLock Signal on Fast I2C bus
SD Standard Definition
SDA Serial Data I2C
SDA-F DAta Signal on Fast I2C bus
SDI Serial Digital Interface, see “ITU-656”
SDRAM Synchronous DRAM
SECAM SEequence Couleur Avec Mémoire.
Colour system mainly used in France
and East Europe. Colour
carriers = 4.406250 MHz and
4.250000 MHz
SIF Sound Intermediate Frequency
SMPS Switched Mode Power Supply
SoC System on Chip
SOG Sync On Green
SOPS Self Oscillating Power Supply
SPI Serial Peripheral Interface bus; a
4-wire synchronous serial data link
standard
S/PDIF Sony Philips Digital InterFace
SRAM Static RAM
SRP Service Reference Protocol
SSB Small Signal Board
SSC Spread Spectrum Clocking, used to
reduce the effects of EMI
STB Set Top Box
STBY STand-BY
SVGA 800 × 600 (4:3)
SVHS Super Video Home System
SW Software
SWAN Spatial temporal Weighted Averaging
Noise reduction
SXGA 1280 × 1024
TFT Thin Film Transistor
THD Total Harmonic Distortion
TMDS Transmission Minimized Differential
Signalling
TS Transport Stream
TXT TeleteXT
TXT-DW Dual Window with TeleteXT
UI User Interface
uP Microprocessor
UXGA 1600 × 1200 (4:3)
V V-sync to the module
VESA Video Electronics Standards
Association
VGA 640 × 480 (4:3)
VL Variable Level out: processed audio
output toward external amplifier
VSB Vestigial Side Band; modulation
method
WYSIWYR What You See Is What You Record:
record selection that follows main
picture and sound
WXGA 1280 × 768 (15:9)
XTAL Quartz crystal
XGA 1024 × 768 (4:3)
Y Luminance signal
Y/C Luminance (Y) and Chrominance (C)
signal
YPbPr Component video. Luminance and
scaled color difference signals (B-Y
and R-Y)
YUV Component video
Mechanical Instructions 11TPM15.6L LA 4.
2015-July-10back to
div.table
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assembly/Panel Removal (for 5000 series)
4.4 Assembly/Panel Removal (for 4100 series)
4.5 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing (24" PHG4100 series)
19771_100.eps
C
N
60
1
C
N
70
1 CN408
C
N
86
04
CN9101
MAIN POWER SUPPLY
(1054)A
SSB
(1053)B
ECN408
ECN701
E
C
N
40
1
ECN601
E
C
N
40
1
E
C
N
601
E
C
N
401
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)IR LED BOARD
(1056)J
K
E
Y
B
O
A
R
D
 C
O
N
T
R
O
L
1057)
E
C
N
40
1
Mechanical Instructions 12 TPM15.6L LA4.
2015-July-10 back to
div.table
Figure 4-2 Cable dressing (32" PFG5000 series)
Figure 4-3 Cable dressing (32"PHG5000 series)
19770_100 eps
C
N
60
1
C
N
70
1 CN408CN8602
C
N
9101
C
N
40
1













MAIN POWER SUPPLY
(1054)A
SSB
(1053)B
ECN408
ECN701
E
C
N
60
1
ECN601
ECN401
E
C
N
401
E
C
N
408
E
C
N
601
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
IR/LED BOARD
(1056)J
KEYBOARD CONTROL
1057) E 0
19770_101.eps
C
N
60
1
C
N
70
1
CN408CN8604
C
N
9101
C
N
40
1













MAIN POWER SUPPLY
(1054)A
SSB
(1053)B
ECN408
ECN701
E
C
N
60
1
ECN601
ECN401
E
C
N
40
8
E
C
N
401
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
R/LED BOARD
(1056)J
K
E
Y
B
O
A
R
D
 C
O
N
T
R
O
L
1057)
E
Mechanical Instructions 13TPM15.6L LA 4.
2015-July-10back to
div.table
Figure 4-4 Cable dressing (40" 5000 series)
Figure 4-5 Cable dressing (48" 5000 series)
19770_102 eps
C
N
60
1
C
N
70
1
CN408
CN8601
C
N
9101
C
N
40
3













MAIN POWER SUPPLY
(1054)A SSB
(1053)B
ECN408
ECN701
E
C
N
60
1
E
C
N
60
1
ECN403
E
C
N
40
8
E
C
N
403LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)IR LED BOARD
(1056)J
KEYBOARD CONTROL
1057) E 0
19770_103 eps
C
N
60
1
C
N
70
1
C
N
40
3
CN408
CN8101 CN9301
MAIN POWER SUPPLY
(1054)A
SSB
(1053)B
ECN408
ECN701
ECN601ECN601
ECN403
E
C
N
40
8
E
C
N
403
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)IR LED BOARD
(1056)J
KEYBOARD CONTROL
(1057) E
Mechanical Instructions 14 TPM15.6L LA4.
2015-July-10 back to
div.table
4.2 Service Positions
For easy servicing of a TV set, the set should be put face down
on a soft flat surface, foam buffers or other specific workshop
tools. Ensure that a stable situation is created to perform
measurements and alignments. When using foam bars take
care that these always support the cabinet and never only the
display. Caution: Failure to follow these guidelines can
seriously damage the display!
Ensure that ESD safe measures are taken.
4.3 Assembly/Panel Removal (for 5000 series)
Instructions below apply to the 32PFG5000/77, but will be
similar for other 5000 series models.
4.3.1 Stand
Refer to Figure 4-6 for details.
1. Remove the fixation screws [1] that secure the stand
bracket. Refer to Figure 4-6 for details.
2. Take the stand bracket out from the set.
Figure 4-6 Stand removal
4.3.2 Rear Cover
Refer to Figure 4-6 and Figure 4-7 for details.
Warning: Disconnect the mains power cord before removing
the rear cover.
1. Remove the fixation screws [2], [3] and [5] that secure the
rear cover. Refer to Figure 4-6 and Figure 4-7 fordetails.
2. At the indicated areas [4] the cover is secured by clips. Be
very careful with releasing those.
3. Gently lift the rear cover from the TV. Make sure that wires
and cables are not damaged while lifting the rear cover
from the set.
19770_104.eps
1
1 1
11
M4 × 16
5
5 5
Q3 × 8
Mechanical Instructions 15TPM15.6L LA 4.
2015-July-10back to
div.table
Figure 4-7 Rear cover removal
4.3.3 Keyboard Control Unit
Refer to Figure 4-8 for details.
1. Release the connector [2] from the keyboard control panel.
Caution: be careful, as these are very fragile connectors!
2. Remove all the fixation screws from the keyboard control
panel [1].
When defective, replace the whole unit.
19770_105 eps
2
2
2
222
22
2
2
2
2
3
M3× 8
2
 M3× 6
3
4
Mechanical Instructions 16 TPM15.6L LA4.
2015-July-10 back to
div.table
Figure 4-8 Keyboard Control unit removal
4.3.4 Small Signal Board (SSB)
Refer to Figure 4-9 for details.
Caution: it is mandatory to remount all different screws at their
original position during re-assembly. Failure to do so may result
in damaging the SSB.
1. Release the clips from the LVDS connector that connect
with the SSB [1].
Caution: be careful, as these are very fragile connectors!
2. Unplug all other connectors [2] .
3. Remove all the fixation screws from the SSB [3].
4. The SSB can now be shifted from side connector cover,
then lifted and taken out of the I/O bracket. Refer to
Figure 4-9 for details.
Figure 4-9 SSB removal
4.3.5 Power Supply Unit (PSU)
Caution: it is mandatory to remount all different screws at their
original position during re-assembly. Failure to do so may result
in damaging the PSU.
1. Gently unplug all connectors from the PSU.
2. Remove all fixation screws from the PSU.
3. The PSU can be taken out of the set now.
19770_106.eps
1
1
2
19770_107.eps
1
3 3
2
3 3
Mechanical Instructions 17TPM15.6L LA 4.
2015-July-10back to
div.table
4.3.6 Speakers
1. Gently release the tapes that secure the speaker cables.
2. Unplug the speaker connector from the SSB.
3. Take the speakers out.
When defective, replace the both units.
4.3.7 IR/LED Board
1. Remove the stand bracket as described earlier.
2. Gently release the clips that hold the board and take it out
from the bezel.
3. Unplug both the connectors from the IR/LED board.
When defective, replace the whole unit.
4.3.8 LCD Panel
1. Remove the SSB as described earlier.
2. Remove the PSU as described earlier.
3. Remove the keyboard control panel as described earlier.
4. Remove the stand bracket as described earlier.
5. Remove the IR/LED as descr bed earlier.
6. Remove the fixations screws that fix the metal clamps to
the front bezel. Take out those clamps.
7. Remove all other metal parts not belonging to the panel.
8. Lift the LCD Panel from the bezel.
When defective, replace the whole unit.
4.4 Assembly/Panel Removal (for 4100 series)
Instructions below apply to the 24PHG4100/77.
4.4.1 Stand and Rear cover
Refer to Figure 4-10 for details.
Warning: Disconnect the mains power cord before removing
the rear cover.
1. Remove the fixation screws [1] that secure the stand
bracket. Refer to Figure 4-10 for details.
2. Remove the fixation screws [2] that secure the rear cover.
3. At the indicated areas [3] the cover is secured by clips. Be
very careful with releasing those.
4. Gently lift the rear cover from the TV. Make sure that wires
and cables are not damaged while lifting the rear cover
from the set.
Figure 4-10 Stand & Rear cover removal
4.4.2 Speakers & Keyboard Control Unit
Refer to Figure 4-11 for details.
1. Gently release the tapes that secure speakers and
keyboard cables.
2. Release the connector [3] from the keyboard control panel.
3. Remove fixation screws[1] and [2] that secure speskers
and keyboard.
4. Gently take the speakers and keyboard out.Refer to
Figure 4-11 for details.
When defective, replace the whole unit.
19771_101 eps
1
Q4 × 12
2
 M3 × 8
1
2
1
3 3
Mechanical Instructions 18 TPM15.6L LA4.
2015-July-10 back to
div.table
Figure 4-11 Speakers & Keyboard control unit removal
4.4.3 Small Signal Board (SSB)
Refer to Figure 4-12 for details.
Caution: it is mandatory to remount all different screws at their
original position during re-assembly. Failure to do so may result
in damaging the SSB.
1. Release the clips from the LVDS connector that connect
with the SSB [1].
Caution: be careful, as these are very fragile connectors!
2. Unplug all other connectors [2] .
3. Remove all the fixation screws from the SSB [3].
4. The SSB can now be shifted from side connector cover,
then lifted and taken out of the I/O bracket. Refer to
Figure 4-12 for details.
Figure 4-12 SSB removal
4.4.4 Power Supply Unit (PSU)
Caution: it is mandatory to remount all different screws at their
original position during re-assembly. Failure to do so may result
in damaging the PSU.
1. Gently unplug all connectors from the PSU.
2. Remove all fixation screws from the PSU.
3. The PSU can be taken out of the set now.
19771_101.eps
1
Q4 × 6
Q3 × 62
1 111 2
2
3
19770_107.eps
1
3 3
2
3 3
Mechanical Instructions 19TPM15.6L LA 4.
2015-July-10back to
div.table
4.4.5 IR/LED Board
1. Remove the stand bracket as described earlier.
2. Gently release the clips that hold the board and take it out
from the bezel.
3. Unplug both the connectors from the IR/LED board.
When defective, replace the whole unit.
4.4.6 LCD Panel
1. Remove the SSB as described earlier.
2. Remove the PSU as described earlier.
3. Remove the keyboard control panel as described earlier.
4. Remove the stand bracket as described earlier.
5. Remove the IR/LED as descr bed earlier.
6. Remove the fixations screws that fix the metal clamps to
the front bezel. Take out those clamps.
7. Remove all other metal parts not belonging to the panel.
8. Lift the LCD Panel from the bezel.
When defective, replace the whole unit.
4.5 Set Re-assembly
To re-assemble the whole set, execute all processes in reverse
order.
Notes:
• While re-assembling, make sure that all cables are placed
and connected in their original position. See Figure 4-1 to
Figure 4-5.
• Pay special attention not to damage the EMC foams on the
SSB shields. Ensure that EMC foams are mounted
correctly.
Service Modes, Error Codes, and Fault Finding 20 TPM15.6L LA5.
2015-July-10 back to
div.table
5. Service Modes, Error Codes, and Fault Finding
Index of this chapter:
5.1 Test Points
5.2 Service Modes
5.3 Stepwise Start-up
5.4 Service Tools
5.5 Software Upgrading
5.6 Error Codes
5.7 The Blinking LED Procedure
5.8 Fault Finding and Repair Tips
5.1 Test Points
As most signals are digital, it will be difficult to measure
waveforms with a standard oscilloscope. However, several key
ICs are capable of generating test patterns, which can be
controlled via ComPair. In this way it is possible to determine
which part is defective.

Perform measurements under the following conditions:
• Service Default Mode.
• Video: Colour bar signal.
• Audio: 3 kHz left, 1 kHz right.
5.2 Service Modes
The Service Mode feature is split into five parts:
• Service Alignment Mode (SAM).
• Factory Mode.
• Customer Service Mode (CSM).
• Computer Aided Repair Mode (ComPair).
SAM and the Factory mode offer features, which can be used
by the Service engineer to repair/align a TV set. Some features
are:
• Make alignments (e.g. White Tone), reset the error buffer
(SAM and Factory Mode).
• Display information (“SAM” indication in upper right corner
of screen, error buffer, software version, operating hours,
options and option codes, sub menus).
The CSM is a Service Mode that can be enabled by the
consumer. The CSM displays diagnosis information, which the
customer can forward to the dealer or call centre. In CSM
mode, “CSM”, is displayed in the top right corner of the screen.
The information provided in CSM and the purpose of CSM is to:
• Increase the home repair hit rate.
• Decrease the numberof nuisance calls.
• Solved customers’ problem without home visit.
ComPair Mode is used for communication between a computer
and a TV on I2C /UART level and can be used by a Service
engineer to quickly diagnose the TV set by reading out error
codes, read and write in NVMs, communicate with ICs and the
micro processor (PWM, registers, etc.), and by making use of
a fault finding database. It will also be possible to up and
download the software of the TV set via I2C with help of
ComPair. To do this, ComPair has to be connected to the TV
set via the ComPair connector, which will be accessible
through the rear of the set (without removing the rear cover).
Note: For the new model range, a new remote control (RC) is
used with some renamed buttons. This has an impact on the
activation of the Service modes. For instance the old “MENU”
button is now called “HOME” (or is indicated by a “house” icon).
5.2.1 General
Next items are applicable to all Service Modes or are general.
Life Timer
During the life time cycle of the TV set, a timer is kept (called
“Op. Hour”). It counts the normal operation hours (not the
Stand-by hours). The actual value of the timer is displayed in
SAM in a decimal value. Every two soft-resets increase the
hour by + 1. Stand-by hours are not counted.
Software Identification, Version, and Cluster
The software ID, version, and cluster will be shown in the main
menu display of SAM and CSM.
The screen will show: “AAAAAAB-XXX.YYY.MMM.TTT”,
where:
• AAAAAA is the chassis name: TPM144L.
• B is the region indication: E = Europe, A = AP/China, U =
NAFTA, L = LATAM.
• XXX is the main version number: this is updated with a
major change of specification (incompatible with the
previous software version). Numbering will go from 0- 255.
• YYY is the sub version number: this is updated with a minor
change of specification (incompat ble with the previous
versions). Numbering will go from 0- 255.
• MMM is the number of the mandatory (upgrade) release in
association with the area of the mandatory (upgrade)
release. Numbering will go from 0 - 255.
• TTT bit 7 to 1 is the area of the mandatory (upgrade)
release where 0 - none, 1 - Netflix, rest reserved.
• TTT bit 0 : 0 = development release, 1 = production
release.
Display Option Code Selection
When after an SSB or display exchange, the display option
code is not set properly, it will result in a TV with “no display”.
Therefore, it is required to set this display option code after
such a repair.
To do so, press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in back to div.table 6-3. When the value
is accepted and stored in NVM, the set will switch to Stand-by,
to indicate that the process has been completed.
During this algorithm, the NVM-content must be filtered,
because several items in the NVM are TV-related and not SSB
related (e.g. Model and Prod. S/N). Therefore, “Model”
and “Prod. S/N” data is changed into “See Type Plate”. In case
a call centre or consumer reads “See Type Plate” in CSM
mode.
5.2.2 Service Alignment Mode (SAM)
Purpose
• To modify the NVM.
• To display/clear the error code buffer.
• To perform alignments.
Specifications
• Operation hours counter (maximum five digits displayed).
• Software version, error codes, and option settings display.
• Error buffer clearing.
• Option settings.
• Software alignments (White Tone).
• NVM Editor.
• Set screen mode to full screen (all content is visible).
How to Activate SAM
To activate SAM, use one of the following methods:
• Press the following key sequence on the remote control
transmitter: “062596”, directly followed by the “INFO/OK”
button. Do not allow the display to time out between entries
while keying the sequence.
• Or via ComPair.
After entering SAM, the following items are displayed,
with “SAM” in the upper right corner of the screen to indicate
that the television is in Service Alignment Mode.
Service Modes, Error Codes, and Fault Finding 21TPM15.6L LA 5.
2015-July-10back to
div.table
Table 5-1 SAM mode overview
How to Navigate
• In the SAM menu, select menu items with the UP/DOWN
keys on the remote control transmitter. The selected item
will be indicated. When not all menu items fit on the screen,
use the UP/DOWN keys to display the next/previous menu
items.
• With the “LEFT/RIGHT” keys, it is possible to:
– (De) activate the selected menu item.
– (De) activate the selected sub menu.
– Change the value of the selected menu item.
• When you press the MENU button once while in top level
SAM, the set will switch to the normal user menu (with the
SAM mode still active in the background).
How to Store SAM Settings
To store the settings changed in SAM mode (except the
RGB Align settings), leave the top level SAM menu by using
the POWER button on the remote control transmitter or the
television set. The mentioned exceptions must be stored
separately via the STORE button.
How to Exit SAM
Use one of the following methods:
• Switch the set to STANDBY by pressing the mains button
on the remote control transmitter or the television set.
• Via a standard RC-transmitter, key in “00” sequence.
Note: When the TV is switched “off” by a power interrupt while
in SAM, the TV will show up in “normal operation mode” as
soon as the power is supplied again. The error buffer will not be
cleared.
5.2.3 Contents of the Factory mode:
Purpose
• To perform extended alignments.
Specifications
• Displaying and or changing Panel ID information.
• Displaying and or changing Tuner ID information.
• Error buffer clearing.
• Various software alignment settings.
• Testpattern displaying.
• Public Broadcasting Service password Reset.
• etc.
How to Activate the Factory mode
To activate the Factory mode, use the following method:
• Press the following key sequence on the remote control
transmitter: from the “menu/home” press “1999”, directly
followed by the “Back/Return” button. Do not allow the
display to time out between entries while keying the
sequence.
After entering the Factory mode, the following items are
displayed,
Main Menu Sub-menu 1 Sub-menu 2 Description
System Information Op Hour e.g. 00057 This represents the life timer. The timer counts normal operation hours, but does
not count Stand-by hours.
Main SW ID e.g. “TPM144L_002.004 000.00 1” See paragraph Software Identification Version and Cluster for the software name
definition.
ERR e.g. “000 000 000 000 000” Shows all errors detected since the last time the buffer was erased. Five errors
possible.
OP1 e.g. “001 224 032 000 038 137 220
015”
Used to read-out the option bytes. See paragraph 6.4 Option Settings in the
Alignments section for a detailed description. Ten codes are possible.
OP2 e.g. “159 255 127 045 011 017 000
000”
Clear Codes Press [OK] to clean the Error Codes
immediately
Erases the contents of the error buffer. Select this menu item and press the MENU
RIGHT key on the remote control. The content of the error buffer is cleared.
Options OP#1-OP#8 e.g. “032” Option code
Alignments Warm R Gain To align the White Tone. See
paragraph 6.3 Software Alignments in the Alignments section for a detailed
description
G Gain
B Gain
Normal R Gain
G Gain
B Gain
Cool R Gain
G Gain
B Gain
Store Store the RGB value
NVM editor NVM editor NVM-editor will function as in the past: Address and Value
field is a decimal value via digit entry
Service Date Edit and display the applicable service data by using the displayed key pad.
Upload to USB Channel List To upload several settings from the TV to an USB stick
NVM Copy
Readable info
EDID Copy
Download from USB Channel List To download several settings from the USB stick to the TV
NVM Copy
EDID Copy
Initialize NVM Press [OK] to Initialize NVM
immediately
To initialize a (corrupted) NVM. Be careful, this will erase all settings.Service Modes, Error Codes, and Fault Finding 22 TPM15.6L LA5.
2015-July-10 back to
div.table
Table 5-2 Factory mode overview
Item Item value
Default value
Description24" 32" 40" 48"
0 F/W VERSION Press OK Displays the software versions of the supplier, Flash PQ, Smart Picture, BL Dimming,
Source Meter, the Picture Quality checksum, the Dimming library, the Source meter
library, the Flash AQ, the MTK, MCU and OAD software versions.
1 PANEL_ID see back to div.table 6-3 Displays and changes the Panel D with the left and right cursor; be careful changing
this, it can result in not correct displaying the screen!
2 ERR Code: xxx xxx xxx xxx xxx 000 000 000 000 000 Values showing the last 5 errors during the last 50 hours of operation, according to
table 5-4 Error code table
3 CLEAR ERROR BUFFER Press OK Selecting this clear all current error codes.
4 NVM ADDRESS 0 NVM address 0 to 8191, Use Item 6 to change and 7 to store the data to the correct
NVM address
5 NVM VALUE 0 Displays the value at the NVM address of item 5
6 NVM STORE Press OK Use this option to save the data of item 6 to NVM address of item 5
7 NVM COPY TV to USB Press OK Use this to store the NVM data to the REPAIR folder of a FAT formatted USB memory
stick. The TV will write two files in the REPAIR folder of the memory stick. It will create
this folder if it does not exist. The items are “Channel list”, “Personal settings”, “Option
codes”, “Display-related alignments” and “History list”. In case the download to the
USB stick was not successful “Failure” will appear. In this case, check if the USB stick
is connected properly. Now the settings are stored onto the USB stick and can be used
to download onto another TV or other SSB. Uploading is of course only possible if the
software is running and if a picture is available. This method is created to be able to
save the customer’s TV settings and to store them into another SSB.
8 NVM READ USB to TV Press OK Use this to store the NVM data from the USB memory stick to the TV. The TV will save
the two files which were created in item 8 to the NVM of the set. Use these options
when replacing a SSB. When “USB to TV Success” is displayed remove the power and
restart the TV
9 CLR_TEMP_R 128 128 128 128 Red colour temperature setting
10 CLR_TEMP_G 120 125 128 128 Green colour temperature setting
11 CLR_TEMP_B 111 102 128 128 Blue colour temperature setting
12 AUTO_COLOR Press OK PC: any pattern that has black and white, YPbPr: SMPTE bar (colour bar), any timing.
13 ADC_GAIN_R 0 Red ADC gain
14 ADC_GAIN_G 128 128 128 128 Green ADC gain
15 ADC_GAIN_B 128 128 128 128 Blue ADC gain
16 ADC_OFFSET_R 255 255 255 255 Red ADC offset
17 ADC_OFFSET_G 255 255 255 255 Green ADC offset
18 ADC_OFFSET_B 255 255 255 255 Blue ADC offset
19 VIRGING_MODE off Use this to return the set to virgin mode. Depends whether the set has been used
already.
20 E_Fuse on E-fuse mode
21 ORT_MODE off ORT mode
22 AGEING MODE off Use this for aging a new LCD panel
23 RESET_PBS_PWD Press OK Use this to reset the Child Lock
24 V DEO_PWM_MEDIUM 0 VIDEO PWM Medium value
25 V DEO_PWM_M NIIMUN 0 VIDEO PWM Minimum value
26 V DEO_PWM_MAX MUN 0 VIDEO PWM Maximum value
27 PWM_RATIO_BEST_PICTURE 0 PWM ratio best picture
28 PWM_RATIO_STD_TOP 0 PWM ratio standard top
29 PWM_RATIO_STD_BOTTOM 0 PWM ratio standard bottom
30 PWM_RATIO_BEST_POWER 0 PWM ratio best power
31 VIDEO_STD_TH_HIGH 0 VIDEO standard threshold high
32 VIDEO_STD_TH_LOW 0 VIDEO standard threshold low
33 YPBPR_PHASE InValid Not available for this chassis
34 AUD_GAIN_L NE N 0 0 1 1 Line-in audio gain
35 AUD_GAIN_HDMI 0 0 0 0 HDMI audio gain
36 AUD_GAIN_ATV 0 0 0 0 Analogue TV audio gain
37 AUD_GAIN_DTV 0 0 0 0 Digital TV audio gain
38 AUD_GAIN_USB 0 0 0 0 USB audio gain
39 ESTICKER NVM1 0 0 0 0 ESTICKER value
40 ESTICKER NVM2 0 0 0 0 ESTICKER value
41 ESTICKER NVM3 0 0 0 0 ESTICKER value
42 ESTICKER NVM4 0 0 0 0 ESTICKER value
43 ESTICKER NVM5 0 0 0 0 ESTICKER value
44 ESTICKER NVM6 0 0 0 0 ESTICKER value
45 ESTICKER NVM7 0 0 0 0 ESTICKER value
46 ESTICKER NVM8 0 0 0 0 ESTICKER value
47 ESTICKER NVM9 0 0 0 0 ESTICKER value
48 ESTICKER NVM10 0 0 0 0 ESTICKER value
49 ESTICKER NVM11 0 0 0 0 ESTICKER value
50 ESTICKER NVM12 0 0 0 0 ESTICKER value
51 ESTICKER NVM13 0 0 0 0 ESTICKER value
52 ESTICKER NVM14 0 0 0 0 ESTICKER value
53 ESTICKER NVM15 0 0 0 0 ESTICKER value
54 ESTICKER NVM16 0 0 0 0 ESTICKER value
55 ESTICKER NVM17 0 0 0 0 ESTICKER value
56 ESTICKER NVM18 0 0 0 0 ESTICKER value
Service Modes, Error Codes, and Fault Finding 23TPM15.6L LA 5.
2015-July-10back to
div.table
How to Exit the Factory mode
Use one of the following methods:
• Select EXIT_FACTORY from the menu and press the “OK”
button.
Note: When the TV is switched “off” by a power interrupt, or
normal switch to “stand-by” while in the factory mode, the TV
will show up in “normal operation mode” as soon as the power
is supplied again. The error buffer will not be cleared.
5.2.4 Customer Service Mode (CSM)
Purpose
The Customer Service Mode shows error codes and
information on the TVs operation settings.The call centre can
instruct the customer (by telephone) to enter CSM in order to
identify the status of the set.This helps the call centre to
diagnose problems and failures in the TV set before making a
service call.
The CSM is a read-only mode; therefore, modifications are not
possible in this mode.
Specifications
• Ignore “Service unfriendly modes”.
• Line number for every
line (to make CSM language independent).
• Set the screen mode to full
screen (all contents on screen is visible).
• After leaving the Customer Service Mode, the original
settings are restored.
• Possibility to use “CH+” or “CH-” for channel surfing, or
enter the specific channel number on the RC.
How to Activate CSM
To activate CSM, press the following key sequence on a
standard remote control transmitter: “123654” (do not allow the
display to time out between entries while keying the sequence).
After entering the Customer Service Mode, the following items
are displayed.

Note: Activation of the CSM is only possible if there is no (user)
menu on the screen!
Contents of CSM
• 1.1 Set Type This information is very helpful for a
helpdesk/workshop as reference for further diagnosis. In
this way, it is not necessary for the customer to look at the
rear of the TV-set. Note that if an NVM is replaced or is
initialized after corruption, this set type has to be re-written
to NVM.
• 1.2 Production code Displays the production
code (the serial number) of the TV. Note that if an NVM is
replaced or is initialized after corruption, this production
code has to be re-written to NVM.
• 1.3 Installation date Indicates the date of the first
installation of the TV. This date is acquired via time
extraction.
• 1.4 a Option Code 1 Gives the option codes of option
group 1 as set in SAM.
• 1.4b Option Code 2 Gives the option codes of option
group 2 as set in SAM.
• 1.5 SSB Gives an identification of the SSB as stored in
NVM. Note that if an NVM is replaced or is initialized after
corruption, this identification number has to be re-written to
NVM. This identification number is the 12NC number of the
SSB.
• 1.6 Display 12NC NVM read/write.
• 1.7 PSU 12NC NVM read/write.
• 2.1 Current Main SW Displays the built-in main software
version. In case of field problems related to software,
software can be upgraded. As this software is consumer
upgradeable, it will also be published on the internet.
• 2.2 Standby SW Displays the built-in stand-by processor
software version. Upgrading this software will be poss ble
via USB.
• 2.3 Panel Code Displays the Display Code number.
• 2.4 Bootloader ID ID of Bootloader.
• 2.5 NVM version Detects and displays NVM version.
• 2.6 Flash ID ID of flash model.
• 2.7 e-UM version eDFU (help) version.
• 2.8 Channel Table Structure Version version of channel
table structure.
• 2.9 Error Codes Detectsand displays errors.
• 3.1 Signal Quality Analog/digital signal strength.
• 3.2 Child lock Not active / active. This is a combined item
for locks. If any lock (channel lock, parental lock) is active,it
is indicated as “active”.
• 3.3 HDCP keys Indicates the validity of the HDMI keys (or
HDCP keys). In case these keys are not valid and the
customer wants to make use of the HDMI functionality, the
SSB has to be replaced.
57 ESTICKER NVM19 0 0 0 0 ESTICKER value
58 ESTICKER NVM20 0 0 0 0 ESTICKER value
59 ESTICKER RESET Press OK ESTICKER reset
60 DIM_L B RESET Press OK Reset the Dimming
61 SRC_METER-RESET Press OK Reset the Source meter
62 AMBLIGHT RESET Press OK AMBLIGHT RESET
63 ACFG RESET Press OK REST ACFG
64 AQ_INDEX 7 5 5 6 Audio Quality index
65 AUDIO TEST MODE off Used for audio testing during production
66 AUDIO CHANNEL TYPE 2.0 Defines the installed speaker system
67 TEST PATTERN Press OK With the “left” and “right” keys of the remote control various test patterns can be chosen
68 EDID UPDATE Press OK Used to enter a new ED D codes into the NVM
69 TCON_GAMMA_UPDATE Invalid TCON gamma update
70 DUMP PQ FROM TV Press OK Saves the picture quality data to a file “pq bin” to the root of a FAT formatted USB
memory stick
71 LOAD PQ to TV Press OK Loads the picture quality data from a file “pq bin” in to the TV
72 DUMP AQ FROM TV Press OK Saves the audio quality data to a file “AQ.bin” to the root of a FAT formatted USB
memory stick
73 LOAD AQ to TV Press OK Loads the audio quality data from a file “AQ.bin” in to the TV
74 PANEL FLIP OFF OFF OFF OFF Flip panel
75 CVI_SOURCE OFF OFF OFF OFF Enable/Disable CVI source
76 VGA_SOURCE OFF OFF OFF OFF Enable/Disable VGA source
77 HDMI2 OFF Enable/Disable HDMI2 source
78 HDMI SIDE ON Enable/Disable HDMI S DEsource
79 RESET_OPTION_CODE Press OK Reset Option Code
80 EXIF_FACTORY Press OK Exits the Factory mode
Item Item value
Default value
Description24" 32" 40" 48"
Service Modes, Error Codes, and Fault Finding 24 TPM15.6L LA5.
2015-July-10 back to
div.table
How to Navigate
By means of the “CURSOR-DOWN/UP” knob (or the scroll
wheel) on the RC-transmitter, can be navigated through the
menus.
How to Exit CSM
To exit CSM, use one of the following methods.
• Press the MENU/HOME button on the remote control
transmitter.
• Press the POWER button on the remote control
transmitter.
• Press the POWER button on the television set.
5.3 Stepwise Start-up
Figure 5-1 Stepwise Start-up
19080_206_110323 eps
120224
Power OffStandby
Soft ModePower On
Semi-
Standby
Standby
Switch
Off(Mains
Power Plug)
Standby Soft Mode
Command Received,
previously in Standby
Soft Mode (Power tact
switch)
TV Wakeup
commands
Received
(TV Wakeup
keys)
Digital
background
tasks started
Digital
background
tasks completed
Swith On,
previously in
Standby/Semi-
Standby (Mains
Power Plug)
Standby
Soft Mode
Command
Received
(Power tact
switch)
Switch Off (Mains
Power Plug)
Switch Off
(Mains Power
Plug)
Swith On,
previously in
Standby Soft Mode
(Mains Power Plug)
Standby
commands
Received (RC
Standby key)
Standby Soft Mode
Command Received,
previously in Standby
Soft Mode (Power
tact switch)
TV Wakeup
commands
Received
(TV Wakeup
keys)
Switch On, previously
in Power On Mode
(Power tact switch)
Standby Soft Mode
Command Received,
(Power tact switch)
Switch Off (Mains
Power Plug) Switch On,previously in
TV Operation Mode
(Mains Power Plug)
Service Modes, Error Codes, and Fault Finding 25TPM15.6L LA 5.
2015-July-10back to
div.table
5.4 Service Tools
5.4.1 ComPair
Introduction
ComPair (Computer Aided Repair) is a Service tool for Philips
Consumer Electronics products. and offers the following:
1. ComPair helps to quickly get an understanding on how to
repair the chassis in a short and effective way.
2. ComPair allows very detailed diagnostics and is therefore
capable of accurately indicating problem areas. No
knowledge on I2C or UART commands is necessary,
because ComPair takes care of this.
3. ComPair speeds up the repair time since it can
automatically communicate with the chassis (when the
micro processor is working) and all repair information is
directly available.
4. ComPair features TV software up poss bilities.
Specifications
ComPair consists of a Windows based fault finding program
and an interface box between PC and the (defective) product.
The ComPair II interface box is connected to the PC via an
USB cable. For the TV chassis, the ComPair interface box and
the TV communicate via a bi-directional cable via the service
connector(s).
The ComPair fault finding program is able to determine the
problem of the defective television, by a combination of
automatic diagnostics and an interactive question/answer
procedure.
How to Connect
This is described in the chassis fault finding database in
ComPair.
Figure 5-2 ComPair II interface connection
Caution: It is compulsory to connect the TV to the PC as
shown in the picture above (with the ComPair interface in
between), as the ComPair interface acts as a level shifter. If
one connects the TV directly to the PC (via UART), ICs can be
blown!
How to Order
ComPair II order codes:
• ComPair II interface: 3122 785 91020.
• Software is available via the Philips Service web portal.
• ComPair UART interface cable for TPM10.1x xx.
(using DB9 to 2mm pitch JST connector): 3122 785 90630.
Note: When you encounter problems, contact your local
support desk.
5.5 Software Upgrading
5.5.1 Description
It is possible for the user to upgrade the main software via the
USB port. This allows replacement of a software image in a
stand alone set. A description on how to upgrade the main
software can be found in the DFU or on the Philips website.
5.5.2 Introduction
Philips continuously tries to improve its products, and it’s
recommend that the TV software is updated when updates are
available. Software update files can be obtained from the
dealer or can be downloaded from the following websites:
http://www.philips.com/support
Preparing a portable memory for software upgrade
The following requirements have to be met:
1. A personal computer connected to the internet.
2. An archive utility that supports the ZIP-format (e.g. WinZip
for Windows or Stufflt for Mac OS).
3. A FAT formatted USB memory stick (preferably empty).
Note:
1. Only FAT/DOS-formatted memory sticks are supported.
2. Only use software update files that can be found on the
http://www.philips.com/support web site.
5.5.3 Check the current TV software version
Before starting the software upgrade procedure, it is advised to
check that what the current TV software:
1. Press the “1 2 3 6 5 4” button on the remote control to enter
the CSM mode.
2. Use the up/down cursor keys to select “Current Main
Software”.
If the current software version of the TV is the same as the
latest update file found on http://www.philips.com/support, it is
not necessary to update the TV software.
5.5.4 Download the latest software
1. Open the internet page http://www.philips.com/support.
2. Find information and software related to the TV.
3. Select the latest software update file and download it to the
PC.
4. Insert the USB memory stick into one of the USB ports of
the PC.
5. Decompress the downloaded ZIP file and copy it to the root
directory of the USB flash drive.
5.5.5 Update the TV software
1. Turn the TV on and wait for it to boot completely.
2. Insert the USB memory stick that contains the software
update files in one of the TV’s USB ports.
3. The TV will detect the USB memory stick automatically.
Then a window jumps out as Figure 5-3.
Note: If the USB flash drive is not detected after power up,
disconnect it and re-insert it.
4. Select [Update] and press OK. See Figure 5-3.
5. To proceed, In next menu select [Start] and press OK to
start software updates. See Figure 5-4.
6. Upgrading will now begins and the status of the updating
progress will be displayed.
7. When the TVsoftware is updated. Remove your USB flash
drive, then select [Restart] and press OK to restart the
TV.See Figure 5-5.
10000_036_090121 eps
091118
 TO
UART SERV CE
CONNECTOR
 TO
UART SERVICE
CONNECTOR
 TO
I2C SERVICE
CONNECTOR
 TO TV
PC
HDMI
I2C only
Optional power
5V DC
ComPair II Developed by Ph lips Brugge
RC outRC in
Optional
Switch
Power ModeLink/
Activity I2C
ComPair II
Multi
function
RS232 /UART
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
http://www.philips.com/support
Service Modes, Error Codes, and Fault Finding 26 TPM15.6L LA5.
2015-July-10 back to
div.table
Figure 5-3 Update the TV software [1/3]
Figure 5-4 Update the TV software [2/3]
Figure 5-5 Update the TV software [3/3]
Note:
• Do not remove the USB flash drive during the software
update.
• If a power failure occurs during the update, do not remove
the USB flash drive from the TV. The TV will continue the
software update as soon as the power comes up again.
• If an error occurs during the update retry the procedure or
contact the dealer.
• We do not recommend downgrading to an older version.
• Once the upgrade is finished, use the PC to remove the TV
software from the USB portable memory.
5.5.6 Content and Usage of the One-Zip Software File
Below you find a content explanation of the One-Zip file, and
instructions on how and when to use it. Only files that are
relevant for Service are mentioned here.
• EDID_clustername.zip: Contains the EDID content of the
different EDID NVMs. See ComPair for further instructions.
• FUS_clustername_version.zip: Contains the file
downloaded which is needed to upgrade the TV main
software and the software download application.
• NVM_clustername_version.zip: Default NVM content.
Must be programmed via ComPair.
5.5.7 How to Copy NVM Data to/from USB
When copying data to and from a USB memory stick, the folder
“repair” is used. When inserting an empty USB memory stick,
and downloading data to the stick, the TV will create this folder.
When sending data from a USB memory stick to a TV, the
intended data must be available in the “repair” folder.
Note that when copying EDID data to the TV, all necessary
EDID files must be in this folder.
Service mode overview for your reference.
Table 5-3 Service mode overview
5.6 Error Codes
5.6.1 Introduction
Error codes are required to indicate failures in the TV set. In
principle a unique error code is available for every:
• Activated (SW) protection.
• Failing I2C device.
• General I2C error.
The last five errors, stored in the NVM, are shown in the
Service menu’s. This is called the error buffer.
The error code buffer contains all errors detected since the last
time the buffer was erased. The buffer is written from left to
right. When an error occurs that is not yet in the error code
buffer, it is displayed at the left side and all other errors shift one
position to the right.
An error will be added to the buffer if this error differs from any
error in the buffer. The last found error is displayed on the left.
An error with a designated error code never leads to a
deadlock situation. It must always be diagnosable (e.g. error
buffer via OSD or blinking LED or via ComPair).
In case a failure identified by an error code automatically
results in other error codes (cause and effect), only the error
code of the MAIN failure is displayed.
5.6.2 How to Read the Error Buffer
You can read the error buffer in three ways:
• On screen via the SAM/CSM (if you have a picture).
Example:
– ERROR: 000 000 000 000 000: No errors detected
– ERROR: 013 000 000 000 000: Error code 13 is the
last and only detected error
19080_207_110324 eps
110324
19080_208_110324 eps
110324
19080_209_110324 eps
110324
Service Modes Description
SAM Service alignment mode
Factory Mode Used for extended alignments
CSM 3-page compact CSM pages. There will be CSM dump to
USB-stick upon entering CSM-mode
USB SW upgradeable SW-upgrading of flash memories MT5561LVNT can be
done via USB. The main SW can be upgraded via the ZIP
file downloaded.
NVM-Editor in SAM NVM-editor will function as in the past: Address and Value
field is a decimal value via digit entry
Service Data New Service data in SAM for CTN, Prod. no., 12NC
programming with virtual keyboard
USB copy/paste in
SAM
Channel list, NVM data, Readable info, EDID
UART logging There will be printout available in UART. No specifications
of the printout, per MTK provision/definition.
Blind SAM RC sequence “062598” + “Menu” +
“Panel code”
Clear Buffer RC sequence “062599” + “OK” or via SAM
Service Modes, Error Codes, and Fault Finding 27TPM15.6L LA 5.
2015-July-10back to
div.table
– ERROR: 034 013 000 000 000: Error code 13 was
detected first and error code 34 is the last detected
(newest) error
• Via the blinking LED procedure (when you have no
picture). See paragraph 5.7 The Blinking LED Procedure.
• Via ComPair.
5.6.3 Error codes
In this chassis only “layer 2” error codes are available and point
to problems on the SSB. They are triggered by LED blinking
when CSM is activated. Only the following layer 2 errors are
defined:
Table 5-4 Error code table
5.6.4 How to Clear the Error Buffer
The error code buffer is cleared in the following cases:
• By using the CLEAR command in the SAM menu
• By using the CLEAR command in the Factory mode:
• By using the following key sequence on the remote control
transmitter: “062599” directly followed by the OK button.
• If the contents of the error buffer have not changed for 50
hours, the error buffer resets automatically.

Note: If you exit SAM by disconnecting the mains from the
television set, the error buffer is not reset.
5.7 The Blinking LED Procedure
5.7.1 Introduction
The software is capable of identifying different kinds of errors.
Because it is poss ble that more than one error can occur over
time, an error buffer is available, which is capable of storing the
last five errors that occurred. This is useful if the OSD is not
working properly.
Errors can also be displayed by the blinking LED procedure.
The method is to repeatedly let the front LED pulse with as
many pulses as the error code number, followed by a period of
1.5 seconds in which the LED is “off”. Then this sequence is
repeated.
Example (1): error code 4 will result in four times the sequence
LED “on” for 0.25 seconds / LED “off” for 0.25 seconds. After
this sequence, the LED will be “off” for 1.5 seconds. Any RC
command terminates the sequence. Error code LED blinking is
in red color.
5.8 Fault Finding and Repair Tips
Note:
• It is assumed that the components are mounted correctly
with correct values and no bad solder joints.
• Before any fault finding actions, check if the correct options
are set.
5.8.1 NVM Editor
In some cases, it can be convenient if one directly can change
the NVM contents. This can be done with the “NVM Editor” in
SAM mode. With this option, single bytes can be changed.
Caution:
• Do not change these, without understanding the function of
each setting, because incorrect NVM settings may
seriously hamper the correct functioning of the TV set!
• Always write down the existing NVM settings, before
changing the settings. This will enable you to return to the
original settings, if the new settings turn out to be incorrect.
5.8.2 Load Default NVM Values
It is possible to upload the default values to the NVM with
ComPair in case the SW is changed, the NVM is replaced with
a new (empty) one, or when the NVM content is corrupted.
After replacing an EEPROM (or with a defective/no EEPROM),
default settings should be used to enable the set to start-up and
allow the Service Default Mode
