A comprehensive literature review on laser powder bed fusion of
Inconel superalloys
Guilherme Maziero Volpato a,b,*, Ulrich Tetzlaff b, Márcio Celso Fredel a
a Federal University of Santa Catarina, Department of Mechanical Engineering, Campus Universitário Reitor João David Ferreira Lima, 88040900, Florianópolis, Brazil
b Technical University of Applied Sciences Ingolstadt, Faculty of Mechanical Engineering, Esplanade 10, 85049 Ingolstadt, Germany
A R T I C L E I N F O
Keywords:
Inconel 718
Inconel 625
Laser powder bed fusion
Selective laser melting
Additive manufacturing
A B S T R A C T
Inconel superalloys are one of the main classes of materials with good potential for production using the additive
manufacturing process of laser powder bed fusion (PBF-LB), which has a broad range of applications in the
transportation and energy sectors. Thus, they have received considerable attention in the scientific literature,
with researchers aiming to better understand their capabilities and limitations in recent decades. This review is
based on around 340 publications spanning the past 14 years and highlights the most significant findings in the
field along with the current challenges and research goals resulting from them. A contextualization is followed by
a succinct microstructural review, which introduces the topics analyzed. The effects of the processing parame-
ters, heat treatment and machining on the materials and their composites are evaluated and the performance of
materials is compared in terms of their mechanical, corrosion and tribological behavior. Publications are mapped
according to their research focus in order to reveal the current research trends in the literature.
1. Introduction
Additive manufacturing (AM), popularly known as “3D printing”,
encompasses a set of advanced manufacturing techniques that are able
to produce tridimensional components from virtual models generated by
computer-aided design (CAD) software. This technology, developed
from rapid prototyping methods in the 1980 s [1], is based on the
layer-by-layer deposition of material according to the geometry defined
by a model, allowing extensive freedom in the design [2,3]. This capa-
bility is especially desirable in fields of engineering associated with a
high degree of responsibility, such as aerospace, automotive and
biomedical applications [4].
Several AM techniques have been focused on the production of metal
components. Among these, laser powder bed fusion (PBF-LB) is associ-
ated with the small-batch production of highly valuable components
with precisely controlled geometries [3]. It consists in a cyclical process,
in which a laser source melts specific regions of a metallic powder bed
and a coater adds a new powder layer on top of it, which becomes
molten in the following step. Each layer corresponds to a slice of the CAD
model, in which the regions to be molten constitute subsequent
cross-sections of the final component geometry.
The process, also known as selective laser melting (SLM), laser
powder bed fusion (L-PBF), laser beam melting (LBM) or direct metal
laser sintering (DMLS) [5], is a valuable tool for the manufacturing of
parts that involve the use of materials whose properties present re-
strictions for classical manufacturing techniques, such as considerable
Abbreviations: AM, Additive manufacturing; AMS, Aerospace Material Specifications; ASTM, ASTM International; CAD, Computer-aided design; CT, Computed
tomography; DED, Directed energy deposition; DMLS, Direct metal laser sintering; EBSD, Electron backscatter diffraction; EDS, Energy-dispersive X-ray spectroscopy;
FCC, Face-centered cubic crystal; HIP, Hot isostatic pressing; HT, Heat treatment; IN625, Inconel alloy 625; IN718, Inconel alloy 718; IN738LC, Inconel alloy 738LC;
Laves, Hexagonal intermetallic phase with (Ni,Fe,Cr)2(Nb,Mo,Ti) stoichiometry; LBM, Laser beam melting; LED, Linear energy density; LM, Light microscopy; L-PBF,
Laser powder bed fusion; PBF-EB, Powder bed fusion using an electron beam; PBF-LB, Powder bed fusion using a laser beam; SEM, Scanning electron microscopy;
SLM, Selective laser melting; S-N, Stress-life curve; Sv, Maximum valley depth; TEM, Transmission electron microscopy; TMF, Thermomechanical fatigue; TTT, Time-
temperature-transformation curve; VED, Volumetric energy density; XRD, X-ray diffraction; γ, Ni-rich matrix of Inconel superalloys; γ’, Cubic intermetallic phase
with Ni3(Al,Ti) stoichiometry; γ’’, Tetragonal intermetallic phase with Ni3Nb stoichiometry; δ, Orthorhombic intermetallic phase with Ni3Nb stoichiometry; σ,
Tetragonal intermetallic phase with CrFe stoichiometry.
* Correspondence to: Ceramic & Composite Materials Research Laboratories, Department of Mechanical Engineering, Federal University of Santa Catarina, Flo-
rianópolis, Brazil.
E-mail address: guilhermemvolpato@gmail.com (G.M. Volpato).
Contents lists available at ScienceDirect
Additive Manufacturing
journal homepage: www.elsevier.com/locate/addma
https://doi.org/10.1016/j.addma.2022.102871
Received 9 March 2022; Received in revised form 25 April 2022; Accepted 2 May 2022
mailto:guilhermemvolpato@gmail.com
www.sciencedirect.com/science/journal/22148604
https://www.elsevier.com/locate/addma
https://doi.org/10.1016/j.addma.2022.102871
https://doi.org/10.1016/j.addma.2022.102871
https://doi.org/10.1016/j.addma.2022.102871
http://crossmark.crossref.org/dialog/?doi=10.1016/j.addma.2022.102871&domain=pdf
Additive Manufacturing 55 (2022) 102871
2
work hardening, high hardness and low thermal conductivity [6]. One
such case is that of nickel-based superalloys used to produce turbine
blades, which are conventionally manufactured by either powder met-
allurgy or by a combination of casting and forging [7].
Nickel-based superalloys are materials that display excellent high-
temperature behavior achieved through high strength allied to high
fatigue, creep and corrosion resistance in temperatures up to around
1000 ◦C [7]. One family of such materials, known by the Inconel
trademark, has been at the center of an extensive research effort to
enable the cost-effective production of superalloy components, with a
high level of control and reproducibility, by PBF-LB in recent decades.
Within the Inconel family, constituted of polycrystalline austenitic
nickel-chromium superalloys, three materials are mainly studied ac-
cording to the PBF-LB literature. Their nominal chemical compositions
are shown in Table 1:
1. Inconel 718 (IN718), a γ’’ precipitation-hardened Ni-Cr wrought
superalloy that, due to its outstanding high temperature properties,
is currently the most widely used superalloy for aerospace applica-
tions worldwide both in market volume [8] and weight fraction of
the components [9];
2. Inconel 625 (IN625), a Ni-Cr-Mo solid-solution-hardened wrought
superalloy used in environments associated with severe corrosion
and high temperatures, such as in marine and aerospace engineering,
chemical processing and nuclear reactors; and
3. Inconel 738LC (IN738LC), a γ’ precipitation-hardened Ni-Cr cast
superalloy with low carbon content and high volume fraction of
strengthening precipitates.
Along with these materials, other superalloys have been studied
together with PBF-LB production techniques to a lesser extent, such as
Hastelloy X [10–17], CM247LC [18–22], Nimonic 263 [23], CMSX486
[24], MAR-M247 [25] and K418 [26]. Within the Inconel family,
Inconel 939 has recently been the focus of precursor studies [27–29].
Fig. 1 presents the annual number of scientific publications focused
on the production of the three selected alloys through PBF-LB (articles
and conference papers). The data was collected in the Web of Science
platform (Clarivate Plc, United States), selecting the maximum data
range up to Decemberto heat-affected zones, due to the fine
equiaxed grain geometry of the former [75,230]. Lastly, post processing
methods have been developed to both increase [203,251,302,316–318]
and decrease [303] the superficial hardness of specimens, which tends to
reduce with increasing subsurface depth [91,319].
An overview of the publications that focus on the measurement of
hardness is found in Appendix C, Fig. 2 C.
7.3. Fatigue
The layer-wise deposition of PBF-LB produces Inconel components
with an anisotropic microstructure, subsurface defects and surface ir-
regularities. These manufacturing artifacts, in turn, seem to affect the
performance of the components under fatigue conditions. Authors have
reported not only shorter fatigue lives [189,265] and higher crack
growth rates [189,320] for as-built conditions compared to conven-
tional manufacturing processes but also the inexistence of fatigue limits
for IN718 obtained through additive manufacturing [321]. This inferior
performance, which seems to be more significant under high strain
amplitudes [285] and temperatures [42], has been the subject of
improvement attempts in various studies in the reviewed literature, and
conditions comparable to conventional manufacturing routes have been
achieved [234,276,322–325].
Several researchers have observed that samples built under different
build orientations present different fatigue lives [134,170,286,287,322,
326–331] and crack growth rates [169,268,271,332–335] under as-built
conditions. There are, however, at least three factors which can influ-
ence this behavior: the direction of microstructural texturing [326,327,
331], orientation-dependent surface defects [134,167,169,268,287,328,
332,336,337] and the positioning of fatigue notches [134,322,327–329,
332,335], all of which can be altered in different orientations. Given that
machined specimens seem to not present significant differences in terms
of fatigue life [322,336,337] and crack growth rates [320] regardless of
microstructural texturing, surface irregularities appear to dominate the
effect of build orientation on fatigue. This conclusion is supported by the
report of changes in the threshold region of the Paris curve when
comparing different build orientations [169,333]. Crack growth, how-
ever, seems to be independent of both build orientation [169,333,335]
and microstructural isotropy [324,325] in the Paris regime.
Microstructural features, on the other hand, have been reported to be
less critical than the incidence of subsurface defects, such as pores,
regarding a reduction in the fatigue life [337]. PBF-LB porosity, apart
from being detrimental in terms of fatigue resistance in general [87,271,
321,338], tends to cause embrittlement [339] and increase crack growth
rates [268,339], so that the morphology of the pores seems to have a
greater impact than the pore depth in relation to the surface of the
component [340]. Although these effects are more pronounced the
greater the size of critical individual pores [245,275,338,339,341],
sub-critical porosity has also been reported to induce fatigue failure due
to pore-pore and pore-surface interactions [341], the latter being espe-
cially relevant given the preferential presence of porosity [177,212,245,
273], precipitates [283] and residual tensile stress [284] near PBF-LB
free-surfaces due to hatch configurations.
In order to reduce the incidence of these defects and overall anisot-
ropy, heat treatments and HIP have been commonly employed [169,
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
14
245,331]. In one study, HIP was found to increase the high cycle fatigue
life in comparison with precipitation hardening alone [204], while other
researchers have noted that the formation of high temperature twins
[191,285] and the δ intermetallic phase [39,206] in the treatment may
be the cause [39,42,265] of the observed reduction in the life of com-
ponents when subjected to fatigue after HIP [206,245,285,342]. None-
theless, another study focusing on the high cycle fatigue of homogenized
specimens showed that fatigue life was improved by the pre-treatment
despite substantial twinning [164].
However, it does not seem possible to control the incidence of surface
defects applying heat treatments or HIP. Reportedly, these are more
critical than subsurface defects in terms of fatigue resistance [245,321,
337,343] and they have also been inversely correlated to fatigue life
when considering surface roughness parameters such as maximum val-
ley depth (Sv) [76]. Although the negative impact of these defects on the
fatigue properties [49,134,245,275,336,343] can be hindered by sur-
face finishing [87,169,234] and/or machining [173,204,234,245,322],
the design of notches for fatigue testing is particularly affected by the
characteristic surface irregularities of PBF-LB specimens [322,328,330,
344]. Thus, notches that are printed with overhanging surfaces [134,
327–330,335,345–347] not only present unmolten particles on their
surface and the stepping effect [87,166,168,266], but nucleate cracks in
an abnormal fashion when compared to wrought and cast specimens,
which tend to grow transgranularly [170,190,324,325,334] and unaf-
fected by precipitate phases [190]. The poor quality of the overhanging
surface induces crack nucleation out of the notch root for intermediate
notch radii [330,346] (Fig. 8) especially under high cycle conditions
[347], which strongly affects crack growth measurements.
Thus, researchers have identified a competition behavior between
crack initiation mechanisms for PBF-LB IN718 [134], which leads to two
separate S-N curves according to the site of crack initiation within the
microstructure. Cracks originated from superficial defects, where the
nucleation sites seem to follow a preferential pattern [336] and depend
on build orientation [134], tend to induce a shorter fatigue life than
cracks nucleated in the interior of components, and thus the fatigue life
can be considerably increased by preventing the former mechanism in
favor of the latter [134,321,343].
An overview of the publications that focus on fatigue behavior is
found in Appendix C, Fig. 3 C.
7.4. Creep
As a result of the rapid solidification regime generated by PBF-LB
processing, components produced by the technique present a signifi-
cant grain refinement under as-built conditions, which directly degrades
their creep resistance [238]. This is especially important in view of the
fact that grain boundary sliding was identified as a dominant process for
creep damage in these materials [272] and failure by intergranular
cracking has been reported for all three reviewed superalloys [49,266,
272,348,349] especially under critical conditions of low strain rates
[272,350]. This is further aggravated by the intense segregation within
additive manufactured microstructures [351], which induces the for-
mation of brittle intermetallic phases such as Laves and δ in grain
boundaries.
Laves is regarded as undesirable for creep resistance due to the
nucleation of intergranular defects and high brittleness [8,49,348,350,
352], but it has been reported that δ can act as a crack barrier [40,49],
avoid grain boundary sliding by pinning, and impede microvoid coa-
lescence [53] despite its absence having been reported to increase creep
resistance [8,41,43,222,352] and induce grain growth [352]. Thus, heat
treatments are employed to promote, among other things, the solubili-
zation of these phases, which increases the volume fraction and di-
mensions of γ’ and γ’’ aging precipitates as well as the creep resistance
[8,40,41,49,51,222,352]. The expected grain growth tends to be hin-
dered [49] and inhomogeneous[41].
The effect on the creep behavior of the addition of an HIP step in heat
treatments, on the other hand, seems to be dependent on the presence of
an intermediate homogenization step. Although some authors have
found that HIP increases the creep life when employed before solution
and aging [41], it has been reported that creep life is reduced if the
technique precedes homogenization at 1100 ◦C together with the stan-
dard treatment [222]. One possible explanation for this is the fact that
the hindering of grain boundary sliding produced by carbide growth
[58,185,187,213] and precipitation [188] under a single precipitation
hardening pre-treatment may be prevented by the dissolution [174] of
the same carbides applying joint treatments, thus reducing creep life.
A further mechanism to consider for the enhancement of creep
resistance is the high anisotropy of PBF-LB specimens, which seems to be
significant even after heat treatments [55,183,349]. Longer creep life,
Fig. 8. – Abnormal crack initiation on notches with poor surface quality due to PBF-LB defects
(reproduced from [330]).
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
15
higher ductility and lower strain rates have been identified when load is
applied in a direction parallel to the build direction [8,53,103,160,238,
260,349], and this has been assigned to a coarser [349] and more
elongated [103,349] microstructure. When a notch is present, however,
the influence of the anisotropy seems to be the opposite and thus the
same direction has been assigned to minimum creep life [159]. This may
be associated with a report that, while creep specimens fail with crack
growth between AM layers when built parallel to the build direction
(Fig. 9a), failure occurs between melt pools when samples are built
orthogonally to it (Fig. 9c) [53]. Also, some studies also have shown that
energy density [71], laser focus height [103], oxidation [43], surface
integrity [40] and ceramic reinforcements [353] have an influence on
the high temperature degradation phenomenon. Changing the scan
strategy can affect the creep behavior [103], but the use of multiple laser
beams reportedly does to not have detrimental effects on it [160].
An overview of the publications that focus on creep behavior is found
in Appendix C, Fig. 4 C.
8. Corrosion behavior
Due to the development of passivation layers at the surface, Inconel
alloys often present high resistances against corrosion and oxidation.
When processed by PBF-LB, however, these materials undergo micro-
structural and superficial changes that alter their corrosion behavior.
Thus, lower corrosion rates have been reported for both as-build and
heat-treated samples in comparison to their wrought counterparts
[354].
The microstructural anisotropy of as-built PBF-LB specimens can
induce corrosion anisotropy in IN718 and IN625 [161,163,355], so that
lower corrosion resistance has been identified for surfaces normal to the
build direction [355]. Because both porosity [355] and the precipitation
of secondary phases such as carbides [216,356], δ [48,215,356] and
Laves [44,357] have been reported to locally increase the corrosion
susceptibility of these materials due to sensitization, this anisotropy has
been related to the presence of these features on the specimen surface.
Nonetheless, it has also been argued that these phases can act as
nucleation sites for oxide passivation layers [358].
The corrosion behavior of PBF-LB Inconel components is also
affected by its dendrite and grain geometry as well as the roughness.
Considering that Cr2O3 and Al2O3 passivation layers have been reported
to preferentially nucleate and stabilize at exposed grain boundaries
[186,359] (Fig. 10), the grain refinement and consequent higher grain
Fig. 9. – Schematic intergranular creep crack path mechanisms for IN718 in different build orientations
(reproduced from [53]).
Fig. 10. – Schematic cross-section of an oxidized surface of PBF-LB IN718
(reproduced from [360]).
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
16
boundary density of these materials tends to induce the formation of
more nucleation sites and, consequently, higher corrosion resistances at
both temperature and under higher temperature conditions [124,163,
356]. Accordingly, the high degree of roughness of as-built PBF-LB
specimens (Fig. 10) contributes to an under-estimation of the surface
area in corrosion kinetics measurements [360], an effect that, together
with corrosion susceptibility itself [361], can be controlled by
electro-chemical polishing [216,253,303].
Some authors have reported that additional mechanisms can be
applied to increase the corrosion resistance of PBF-LB Inconel
superalloys. Surface peening [318,357], alloying with Re [162] and the
addition of TiC [355] or Y2O3 nanoparticles [291] seem to be effective
approaches to reducing the corrosion kinetics, but solution heat treat-
ments have been related with diminished oxidation resistance [362].
Nonetheless, the homogenization of the microstructure by the solution
of segregates after heat treatment has been shown to be beneficial for the
overall corrosion resistance [44,215,357], which is further increased by
the generation of γ’ and γ’’ precipitates and stress release after
controlled aging [216,363].
9. Composites
Composites of PBF-LB can be produced by adding reinforcements to
the powder bed either as distinct particles or by coating the Inconel
powder with it. In the reviewed literature, the use of reinforcements
such as TiC [73,123,125–127,188,242,299,318,355,358,364], WC [71,
84,94,107,122,139,297,365], TiB2 [90], BN [308], Al2O3 [353], gra-
phene [174,300] and carbon nanotubes [38] have been reported.
The addition of reinforcements generally increases the strength [38,
127,174,188,293,297,299,308,364] and hardness [84,122,123,125,
293,297,308] of a sample while decreasing its elongation [38,188,293,
297,299,300] and suppressing grain growth [38,90,94,125,174,188,
299,364]. The latter effect seems to be connected with a notable inhi-
bition of crack development [364]. In addition, this approach appears to
enhance the wear resistance [84,94,122,123,125,308]. The elastic
modulus can be reduced by the addition of TiC [299], while the presence
of graphene [300], TiB2 [90] and in-situ Al2O3 [353] has been found to
increase it. In one study, the latter also reduced creep rates while
increasing creep life, an effect that was attributed to the control of
dislocation glide by the reinforcements [353]. These effects, however,
seem to be influenced by the reinforcement fraction and size, the addi-
tion of WC in fractions superior to 15 wt% causing a steep reduction in
strength [297]. The refinement of particles and its deagglomeration can
be achieved by the use of high energy densities [123,125].
The behavior of composites has also been shown to be dependent on
heat treatment. With the addition of carbon nanotubes there was an
Fig. 11. – Influence of interfacial diffusion layers on the fragmentation of WC particle reinforcements by laser-induced stresses
(reproduced from [139]).
Fig. 12. – Relative efficiency of post-processing methods for the control of
roughness. UIT - ultrasonic impact treatment, USP - ultrasonic shot peening, SP
- shot peening, BF - barrel finishing
(reproduced from [316]).
G.M. Volpato et al.Additive Manufacturing 55 (2022) 102871
17
increase in strength after precipitation hardening [38], but with the
addition of TiC [188] or graphene [174] the strength decreased after
heat treatment. This has been attributed to the suppression of γ’ and γ’’
precipitation by the carbon-rich reinforcements, where a diffusion shell
develops by interdiffusion under high-temperature processing [84,90,
107,122,139,174,188,297,365], depleting the matrix of the elements
necessary for the precipitation of aging phases due to the nucleation of
carbides [38,139,174,188] (Fig. 11a). On the other hand, the interfacial
diffusion shell can act as a crack barrier [84,122], protecting against
particle fragmentation due to laser incidence [139] (Fig. 11b), since
cracks in the reinforcements result not only from matrix contraction but
also interfacial porosity [94].
10. Tribological behavior
The contact behavior of Inconel components produced by PBF-LB is
highly influenced by the defects inherent to the additive manufacturing
process, which affect both the microstructure, topography and the sur-
face quality of as-built materials. These defects, which can be measured
using surface characterization techniques such as profilometry [87,134,
166,167,241,316], focus variation microscopy [204,360], interferom-
etry [345,360] and confocal microscopy [61], can be both controlled
and counterbalanced by careful control of the processing conditions or
by adequate post-processing.
In this regard, studies have shown that the control of parameters,
such as scan speed [84], remelting [107], and linear [122,124,125] and
volumetric [123] energy densities, can improve wear resistance while
decreasing the coefficient of friction (COF) of dry-sliding contact until
conditions are similar to those of conventionally cast materials [366].
This is especially critical regarding contour parameters, which are a key
factor in the definition of the surface topography and roughness of
produced materials [76,80,87]. Moreover, not only high energy den-
sities can change the wear mechanism from adhesive to abrasive wear
[125], since some studies have shown that build orientations of 0◦ [158]
and 45◦ [165] are optimum for wear resistance, although other have
indicated no build direction dependance [366]. The temperature of the
tribological contact has also been described as a factor with an influence
on the wear behavior of these materials and both the wear loss and COF
increase together with temperature while the mechanism of wear
changes from abrasion to oxidation and/or delamination [367].
Besides the control of build parameters, improvement in wear
resistance could also be achieved by applying appropriate heat treat-
ments, like the higher resistance to erosion induced by the in-situ su-
perficial precipitation of aging phases [302]. Although such phases are
generally related to an improvement in the overall wear resistance, due
to an increase in hardness and strength [217], γ’’ was reported to act as a
third body abrasive together with δ under dry sliding, while Laves tends
to be detached from a brittle aged surface [95]. Additionally, the wear
rate of heat-treated specimens has been reported to present a consid-
erable spatial dependence, and regions near support structures exhibited
higher wear resistance than those distant from them [310].
An increase of bulk hardness and, consequently, wear resistance
could also be achieved by the addition of hard and homogeneously
distributed [94] particle reinforcements, such as WC [84,94,107,122]
and TiC [123,125] in the powder bed, which also seem to induce a
change from severe abrasive contact to moderate adhesive wear [84]. In
addition, an overall reduction in friction intensity has been achieved
through the addition of intrinsically lubricating reinforcements such as
hexagonal BN [308].
However, to avoid altering the optimal manufacturing conditions
while simultaneously improving wear behavior, post-processes have
been devised as an alternative to the aforementioned techniques. The
plasma nitriding of PBF-LB IN718 has been reported to improve resis-
tance to both wear and oxidation of tested specimens, but it increased
the already high degree of roughness due to the superficial growth of
CrN [307]. Studies have shown that this roughness, a consequence of the
layer-wise melting of powder, can be controlled by methods such as
barrel finishing, shot peening, ultrasonic shot peening, ultrasonic impact
[316] and ultrasonic cavitation [368]. Turning the surface has been
reported to result in higher hardness and lower wear rates than vibratory
and lapping finishing [369]. Fig. 12 shows the relative efficiency of some
of these methods.
11. Current challenges
Materials of the Inconel family present a wide range of heat-
resistance applications in the energy and transport industries. Their
manufacturing through laser powder bed fusion has been an important
field of research in the recent decades, given the potential of this AM
technique for the production of tailored and optimized components.
Nonetheless, the manufacturing of Inconel components using AM tech-
nology is still limited by key factors that hinder its use in industrial series
production. This review of 337 publications published in the last 14
years enabled the developments in the field related to processing con-
ditions and material properties to be summarized. In this context, the
following topics were identified as current challenges according to the
literature, which currently hinder a broader adoption of the technology:
1. Parameter restrictiveness – the production of Inconel superalloys by
PBF-LB is heavily dependent on the correct choice of manufacturing
parameters. The results of parametrization studies are, however,
mostly empirical, and thus commercially standard parameters are
restricted not only to a given alloy, but to a set of processing con-
ditions that vary according to the employed machine system and the
production environment. Although the design of composite param-
eters, such as energy density, has been aimed at the standardization
of manufacturing parameters, their validity as a predicting gauge is a
subject of debate;
2. Powder reuse – in order to lower the costs associated with PBF-LB,
there is considerable interest in reusing the Inconel powder that
was not consolidated in the production of previous components. This
option, however, brings about uncertainty regarding changes in the
chemical and rheological characteristics of the powder, and thus the
properties of the built component might be compromised. Some
authors have observed no changes in the properties after powder
recycling, but there is evidence of the powder quality being reduced
due to various phenomena during laser incidence;
3. Microstructural changes – although the microstructure and the
associated phases of Inconel superalloys are well described in the
literature, the solidification and precipitation behavior of these al-
loys after the production by PBF-LB is changed, and intense anisot-
ropy, grain refinement, microsegregation and out-of-equilibrium
solidification have been verified. Thus, certain phases tend to appear
under conditions in which they are not expected according to con-
ventional transformation kinetics, which results in different micro-
structures and properties of the AM materials when compared to
wrought and cast alloys;
4. Heat treatment unpredictability – since the performance of Inconel
alloys is highly dependent on precipitation hardening, these mate-
rials undergo a series of heat treatments to promote the nucleation
and growth of the reinforcing phases. However, in view of the
intense segregation of these materials after manufacturing by PBF-
LB, these heat treatments also precipitate undesirable phases
together with the aging reinforcements. There is thus a conflict
G.M. Volpato et al.Additive Manufacturing 55 (2022) 102871
18
between precipitation hardening optimization and segregation con-
trol in these alloys when produced by the AM technique, and lower γ’
and γ’’ volume fractions might be desirable in order to avoid the
growth of undesirable phases in its microstructure;
5. Competition of optimization – although there are conditions under
which certain properties of PBF-LB Inconel are optimized, they are
often not optimal regarding other relevant properties. This can be
verified when considering HIP and sample orientation, which leads
to a competition between the optimization of monotonic and dy-
namic strength. HIP is mostly beneficial for fatigue strength due to
the closing of metallurgical porosity, but the grain growth and
dissolution of precipitates induced by the technique tend to reduce
the monotonic strength. Similarly, while tensile strength seems to be
optimum in samples built either parallel to or at a 45◦ degree in
relation to the build plate, creep resistance is optimized in samples
built perpendicularly to the build plate (90◦);
6. δ-Ni3Nb – there is no consensus on the desirability of the δ phase to
enhance creep resistance. The intermetallic phase is usually consid-
ered undesirable for tensile strength, but authors do not agree on
whether its presence in the microstructure of PBF-LB Inconel is
mostly beneficial or detrimental in terms of creep properties. Some
argue that its presence at grain boundaries may inhibit grain
boundary sliding while inducing local strengthening by the entrap-
ment of dislocations, but others emphasize the undesirability of the
phase due to its brittleness, its behavior as a stress concentrator and
the local entrapment of elements necessary for the precipitation of
aging reinforcements;
7. Novel physical phenomena – the manufacturing conditions to which
Inconel alloys are submitted when produced using PBF-LB give rise
to physical phenomena that are not present in conventional
manufacturing methods. These phenomena alter the operation
behavior of PBF-LB superalloys when in comparison to conventional
materials, being present not only with regard to mechanical response
but also when considering conditions that involve non-mechanical
damage. Some particular mechanical phenomena that can be
attributed to PBF-LB processing include specific types of anisotropy,
high-temperature embrittlement, fatigue dependence on PBF-LB
surface artifacts and microstructural texture, and the dependence
of creep on phases derived from PBF-LB microsegregation. These are
accompanied by reports of novel material behavior when samples
are submitted to post-processing techniques such as heat treatment
and machining, whose final quality hinges upon microstructural
artifacts. Operation in corrosive and tribological environments also
have been linked with new phenomena, which include the nucle-
ation of passivation layers according to PBF-LB surface features and
the dependence of wear resistance on PBF-LB defects and micro-
structure. Thus, in order to properly predict material behavior, it is
imperative that these physical phenomena are taken into account
when designing superalloy components to be produced using PBF-
LB;
8. Restricted literature – despite the growing literature on the subject,
the PBF-LB processing of Inconel superalloys is strongly focused on
IN718 and, to a lesser extent, IN625. In this study, publications
dealing with IN738LC were also reviewed, although they are rela-
tively small in number. Additionally, the application of the tech-
nology to IN939 appears to be in the initial stages of development.
Thus, considering the number of alloys within this family, the liter-
ature is still restricted;
9. Scalability of results – it was verified that, despite the extensive
research that has been conducted in this field, there is still uncer-
tainty regarding how well the promising results of studies can be
scaled to produce industrial and commercial components. This is
emphasized by reports that the mechanical properties are dependent
on sample size and geometry even at laboratory scale.
12. Concluding remarks
This comprehensive overview of past and ongoing research in the
field of Inconel superalloys produced by PBF-LB highlights the great
potential that the AM technique offers for the production of complex
components with optimized and tailored properties. Nonetheless, due to
the novelty of the field and the complex relations that control the
properties and the performance of Inconel components, it is clear that
various aspects of research still require further investigation.
Many studies have been focused on the tensile and hardness prop-
erties of these alloys, but comparatively few describe their behavior
under conditions closer to those of potential applications. The limited
literature concerning creep, fatigue, thermomechanical fatigue (TMF)
and creep-fatigue interactions indicates the need for more research on
these topics, since Inconel superalloys often fail as a result of these
phenomena.
Despite several initiatives aimed at the standardization of the
manufacturing of Inconel alloys by PBF-LB, it was noted that authors
still employ not only various nomenclatures, mathematical notations
and methods, but they also arrive at conclusions that are difficult to
integrate in a broader reference frame. A widespread standardization of
the approach to research in this field is therefore required and authors
need to promote methods that facilitate correlations between studies
and research projects carried out in different contexts.
CRediT authorship contribution statement
Fredel Márcio Celso: Writing – review & editing, Supervision, Re-
sources, Project administration, Funding acquisition, Conceptualization.
Tetzlaff Ulrich: Writing – review & editing, Conceptualization, Funding
acquisition, Project administration, Resources, Supervision. Volpato
Guilherme Maziero: Writing – original draft, Investigation, Data
curation, Conceptualization.
Declaration of Competing Interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Acknowledgments
The authors are grateful for the financial support provided by the
German Academic Exchange Service (DAAD - Germany), by means of
the project enGlobe of the Bavarian Center for Applied Research and
Technology with Latin America (AWARE), on behalf of which this
research was conducted. Mr. Volpato is grateful for the Masters’ schol-
arship granted by the Brazilian Coordination for the Improvement of
Higher Education Personnel (CAPES - Brazil), and support from the
Mechanical Engineering Postgraduate Program of the Federal University
of Santa Catarina (POSMEC/UFSC). The helpful English revision by Dr.
Wiese is gratefully acknowledged.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
19
Appendix A. Map of reviewed publications
Fig. 1A. Map of reviewed publications. Each number refers to the associated publication number in the References section, while each color corresponds to a su-
peralloy: blue for IN718, red for IN625 and green for IN738LC. The size of each method node (in gray) is parametrized by the number of publications that either
employ or focus on the method itself.
Appendix B. Parameter tables
Table 1B, 2B and 3B show a selection of printing parameters employed to build bulk specimens of Inconel alloys 718, 625 and 738LC in the
reviewed literature, respectively. Only studies that explicitly report the values of bulk laser power, scan speed, hatch distance and layer thickness are
included, so that publications that either indicatecommercial parameter sets or fail to mention one or more of the aforementioned parameters are not
referenced. Parameter studies, which change one or more parameters, are indicated with the word “variable” in the parameter subject to change.
The tables are organized in ascending order of layer thickness, followed by laser power.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
20
Table 1B –
Parameters employed in the reviewed literature to build bulk IN718 specimens.
Laser
power
[W]
Scan
speed
[mm/s]
Hatch
distance
[μm]
Layer
thickness
[μm]
Reference number
95 800 50 20 [207]
170 417 70 20 [264]
195 1200 90 20 [67,133,186,277,289]
200 900 70 20 [48]
280 450 30 20 [43]
285 2500 50 20 [97]
Variable Variable 100 20 [135]
90 800 80 25 [308,309]
180 850 150 25 [297]
121 400 60 30 [125]
175 620 120 30 [39,193]
180 600 90 30 [280]
180 600 105 30 [117,159,208,305,312,
322,336]
180 600 150 30 [106]
190 1200 70 30 [269]
195 1100 80 30 [36,181]
200 900 120 30 [284]
200 7000 60 30 [174]
200 900 90 30 [281]
200 7000 100 30 [242,299,300]
200 900 120 30 [58,314]
280 1200 70 30 [50,51]
300 1300 120 30 [194]
400 900 120 30 [68,196]
200 Variable Variable 30 [200]
Variable Variable 100 30 [131]
Variable 875 Variable 30 [156]
180 600 105 35 [180,211,212]
Variable Variable 25 35 [130]
100 560 60 40 [140]
110 450 50 40 [84]
200 1300 90 40 [140]
225 680 90 40 [140]
230 760 110 40 [201,302]
230 760 110 40 [220]
260 1000 110 40 [42]
280 950 110 40 [367]
285 1000 110 40 [52]
285 960 80 40 [34,37,55,110,113,147,
177,189,205,206,245,
257,287,307,320,321,
334,340,349,352,356]
285 1000 110 40 [218,350]
285 970 150 40 [165,354,366]
300 1500 55 40 [292]
300 1200 70 40 [248]
300 1200 85 40 [203]
350 1000 100 40 [146]
350 700 110 40 [202]
350 800 120 40 [60,195,215]
350 1000 200 40 [187,214]
400 7000 20 40 [45,59]
400 7000 80 40 [41]
Variable Variable 70 40 [119]
Variable Variable 80 40 [105]
Variable Variable 110 40 [168]
Variable Variable Variable 40 [66,98,100]
350 Variable 105 45 [301]
100 85.7 160 50 [89]
125 100 50 50 [93,94]
130 400 50 50 [359]
160 800 160 50 [54]
200 1000 80 50 [154]
200 200 180 50 [324,325]
220 800 100 50 [353]
240 800 50 50 [355]
250 700 120 50 [49,175,261]
250 760 120 50 [327,328]
250 805 120 50 [345]
275 805 120 50 [198,219]
300 800 50 50 [107,298]
Table 2B
– Parameters employed in the reviewed literature to build bulk IN625
specimens.
Laser
power [W]
Scan speed
[mm/s]
Hatch
distance
[μm]
Layer
thickness
[μm]
Reference
number
160 500 60 20 [229]
185 900 70 20 [69]
195 1200 90 20 [224,225,228,
362]
195 800 100 20 [46,56,116,235,
246,258]
274 1000 80 20 [263]
Variable Variable Variable 20 [101,102,114,
128,136,138]
Variable Variable 90 20 [313]
175 600 140 30 [155]
200 400 80 30 [317,358]
280 950 110 30 [158]
200 Variable 80 30 [126,127,129]
285 960 110 40 [268,339]
300 1000 100 40 [169]
1000 200 180 40 [96]
50 1300 120 50 [99]
80 25 100 50 [92]
80 100 100 50 [90]
80 1500 100 50 [227]
200 600 80 50 [318]
360 400 125 50 [38]
Variable Variable Variable 50 [153]
200 600 140 60 [252]
253 500 100 60 [282]
Variable 600 140 60 [288]
Variable Variable Variable 100 [65]
Table 1B – (continued )
Laser
power
[W]
Scan
speed
[mm/s]
Hatch
distance
[μm]
Layer
thickness
[μm]
Reference number
300 800 130 50 [188]
400 500 160 50 [162,271]
700 1500 150 50 [85]
6000 480 5000 50 [154]
300 Variable 50 50 [71]
Variable Variable 50 50 [73]
Variable Variable 110 50 [82]
Variable Variable Variable 50 [79,365]
200 875 90 60 [217,241,369]
212.5 850 90 60 [53,160]
Variable Variable Variable 70 [172]
200 200 70 75 [95]
370 700 140 80 [104]
2000 500 800 100 [154]
370 700 130 Variable [338]
60 Variable Variable Variable [86]
Table 3B –
Parameters employed in the reviewed literature to build bulk IN738LC
specimens.
Laser power
[W]
Scan speed
[mm/s]
Hatch
distance [μm]
Layer
thickness [μm]
Reference
number
135 1150 60 20 [237]
270 950 90 30 [291]
300 1000 90 30 [364]
200 Variable Variable 30 [83]
Variable Variable 90 30 [70]
Variable Variable Variable 30 [61]
Variable Variable Variable 40 [64,74]
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
21
Appendix C. Maps of publications focused on mechanical behavior
The figures of this appendix show the research focuses of publications classified in the “Tensile”, “Hardness”, “Fatigue” and “Creep” groups ac-
cording to Section 2, in order to better map the research efforts in regard to mechanical properties in the reviewed literature. A description of how to
interpret each map is to be found in Appendix A.
Fig. 1 C, which shows the publications associated with the “Tensile” group, divides publications according to the following categories:
1. Heat treatment (HT): studies that measured the tensile behavior of samples that underwent different heat treatments;
2. Anisotropy: studies that described the anisotropic tensile response of the samples produced;
3. Elastic constants: studies that measured the anisotropic elastic constants of samples produced;
4. Fracture toughness: studies that measured the fracture toughness of samples produced;
5. Compression: studies that evaluated the monotonic mechanical behavior of samples under compressive stresses;
6. Shear: studies that evaluated the monotonic mechanical behavior of samples under shear stresses;
7. Impact: studies that evaluated the impact resistance of samples produced;
8. High temperature: studies that evaluated monotonic mechanical behavior under high-temperature conditions;
9. Parameters: studies where the influence of build parameters on the monotonic mechanical behavior of samples was considered;
10. Alloying: studies that evaluated the monotonic mechanical behavior of materials submitted to alloying;
11. Composites: studies that evaluated the monotonic mechanical behavior of composite materials.
Fig. 1 C. Map of the publications associated with the “Tensile” group.
Fig. 2 C, which is associated with the “Hardness” group, categorizes publications according to the following categories:
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
22
1. Nanohardness: studies where the nanohardness of the materials was measured;
2. Heat treatment (HT): studies that measured the hardness of samples that underwent different heat treatments;
3. Distribution: studies that evaluated the spatial distribution of hardness within the microstructure or geometry of samples;
4. Parameters: studies where the influence of build parameters on the hardness of samples was considered;
5. Surface: studies that measured the surface hardness of samples;
6. Composites: studies that evaluated the hardness of composite materials.
Fig. 2 C. Map of the publications associated with the “Hardness” group.
Fig. 3 C, a map of the publications of the “Fatigue” group, divides them into the following research focuses:
1. Low cycle fatigue (LCF): studies that conducted fatigue tests in the low cycle fatigue regime;
2. High cycle fatigue (HCF): studies that conducted fatigue tests in the high cycle fatigue regime;
3. Very high cycle fatigue (VHCF): studies that conducted fatigue testsin the very high cycle fatigue regime;
4. Isothermal fatigue (IF): studies that conducted fatigue tests under a constant temperature higher than that of room temperature;
5. Thermomechanical fatigue (TMF): studies in which fatigue tests were conducted with simultaneous changes in temperature and mechanical
strain;
6. Creep-fatigue interaction (CFI): studies that evaluated the simultaneous contribution of fatigue and creep damages;
7. Surface: studies that evaluated the influence of surface defects and quality on fatigue behavior;
8. Fatigue crack propagation (FCP): studies that analyzed the fatigue crack initiation and growth of samples upon cyclic loading;
9. Orientation: studies that evaluated the influence of build orientation on fatigue properties and behavior of samples;
10. Defects: studies that evaluated the influence of internal defects, such as pores or inclusions, on the fatigue properties of samples;
11. Microstructure: studies where the microstructure of samples was analyzed in order to account for fatigue results.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
23
Fig. 3 C. Map of the publications associated with the “Fatigue” group.
Finally, Fig. 4 C, associated with the “Creep” group, divides publications according to the following categories:
1. Heat treatment (HT): studies that evaluated the creep behavior of samples submitted to different heat treatments;
2. Anisotropy: studies that described anisotropic creep response of the samples produced;
3. Delta + : studies that, when evaluating the influence of the δ-Ni3Nb intermetallic phase on the creep behavior of samples, regard it as generally
beneficial for creep properties;
4. Delta -: studies that, when evaluating the influence of the δ-Ni3Nb intermetallic phase on the creep behavior of samples, regard it as generally
detrimental for creep properties;
5. Delta optimization: studies that, when evaluating the influence of the δ-Ni3Nb intermetallic phase on the creep behavior of samples, propose that a
given incidence and/or distribution of the phase is desirable to optimize creep properties;
6. Parameters: studies where the influence of build parameters on the creep behavior of samples was considered;
7. Microstructure: studies where the microstructure of samples was analyzed in order to account for creep results.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
24
Fig. 4 C. Map of the publications associated with the “Creep” group.
References
[1] J. Kruth, P. Mercelis, L. Froyer, M. Rombouts, Binding mechanisms in selective
laser sintering and selective laser melting, Rapid Prototyp. J. 11 (2005) 44–59,
https://doi.org/10.1108/13552540510573365.
[2] L.E. Murr, S.M. Gaytan, D.A. Ramirez, E. Martinez, J. Hernandez, K.N. Amato, P.
W. Shindo, F.R. Medina, R.B. Wicker, Metal fabrication by additive
manufacturing using laser and electron beam melting technologies, J. Mater. Sci.
Technol. 28 (2012) 1–14, https://doi.org/10.1016/S1005-0302(12)60016-4.
[3] W.E. Frazier, Metal additive manufacturing: a review, J. Mater. Eng. Perform. 23
(2014) 1917–1928, https://doi.org/10.1007/s11665-014-0958-z.
[4] K.V. Wong, A. Hernandez, A review of additive manufacturing, ISRN Mech. Eng.
2012 (2012) 1–10, https://doi.org/10.5402/2012/208760.
[5] L. Hitzler, M. Merkel, W. Hall, A. Öchsner, A review of metal fabricated with
laser- and powder-bed based additive manufacturing techniques: process,
nomenclature, materials, achievable properties, and its utilization in the medical
sector, Adv. Eng. Mater. 20 (2018) 1–28, https://doi.org/10.1002/
adem.201700658.
[6] Z. Tian, C. Zhang, D. Wang, W. Liu, X. Fang, D. Wellmann, Y. Zhao, Y. Tian,
A review on laser powder bed fusion of inconel 625 nickel-based alloy, Appl. Sci.
10 (2020), https://doi.org/10.3390/app10010081.
[7] R.C. Reed, The Superalloys, Cambridge University Press, Cambridge, 2006,
https://doi.org/10.1017/CBO9780511541285.
[8] M. Pröbstle, S. Neumeier, J. Hopfenmüller, L.P. Freund, T. Niendorf, D. Schwarze,
M. Göken, Superior creep strength of a nickel-based superalloy produced by
selective laser melting, Mater. Sci. Eng. A 674 (2016) 299–307, https://doi.org/
10.1016/j.msea.2016.07.061.
[9] H. Qi, M. Azer, A. Ritter, Studies of standard heat treatment effects on
microstructure and mechanical properties of laser net shape manufactured
INCONEL 718, Metall. Mater. Trans. A 40 (2009) 2410–2422, https://doi.org/
10.1007/s11661-009-9949-3.
[10] F. Wang, Mechanical property study on rapid additive layer manufacture
Hastelloy® X alloy by selective laser melting technology, Int. J. Adv. Manuf.
Technol. 58 (2012) 545–551, https://doi.org/10.1007/s00170-011-3423-2.
[11] H. Brodin, O. Andersson, S. Johansson, Mechanical Behaviour and Microstructure
Correlation in a Selective Laser Melted Superalloy, in: Turbine Tech. Conf. Expo.,
2013: pp. 1–7.
[12] N.J. Harrison, I. Todd, K. Mumtaz, Reduction of micro-cracking in nickel
superalloys processed by selective laser melting: a fundamental alloy design
approach, Acta Mater. 94 (2015) 59–68, https://doi.org/10.1016/j.
actamat.2015.04.035.
[13] D. Tomus, Y. Tian, P.A. Rometsch, M. Heilmaier, X. Wu, Influence of post heat
treatments on anisotropy of mechanical behaviour and microstructure of
Hastelloy-X parts produced by selective laser melting, Mater. Sci. Eng. A 667
(2016) 42–53, https://doi.org/10.1016/j.msea.2016.04.086.
[14] D. Tomus, P.A. Rometsch, M. Heilmaier, X. Wu, Effect of minor alloying elements
on crack-formation characteristics of Hastelloy-X manufactured by selective laser
melting, Addit. Manuf. 16 (2017) 65–72, https://doi.org/10.1016/j.
addma.2017.05.006.
[15] G. Marchese, G. Basile, E. Bassini, A. Aversa, M. Lombardi, D. Ugues, P. Fino,
S. Biamino, Study of the microstructure and cracking mechanisms of hastelloy X
G.M. Volpato et al.
https://doi.org/10.1108/13552540510573365
https://doi.org/10.1016/S1005-0302(12)60016-4
https://doi.org/10.1007/s11665-014-0958-z
https://doi.org/10.5402/2012/208760
https://doi.org/10.1002/adem.201700658
https://doi.org/10.1002/adem.201700658
https://doi.org/10.3390/app10010081
https://doi.org/10.1017/CBO9780511541285
https://doi.org/10.1016/j.msea.2016.07.061
https://doi.org/10.1016/j.msea.2016.07.061
https://doi.org/10.1007/s11661-009-9949-3
https://doi.org/10.1007/s11661-009-9949-3
https://doi.org/10.1007/s00170-011-3423-2
https://doi.org/10.1016/j.actamat.2015.04.035
https://doi.org/10.1016/j.actamat.2015.04.035
https://doi.org/10.1016/j.msea.2016.04.086
https://doi.org/10.1016/j.addma.2017.05.006
https://doi.org/10.1016/j.addma.2017.05.006
Additive Manufacturing 55 (2022) 102871
25
produced by laser powder bed fusion, Materials 11 (2018), https://doi.org/
10.3390/ma11010106.
[16] Q. Han, R. Mertens, M.L. Montero-Sistiaga, S. Yang, R. Setchi, K. Vanmeensel,
B. Van Hooreweder, S.L. Evans, H. Fan, Laser powder bed fusion of Hastelloy X:
effects of hot isostatic pressing and the hot cracking mechanism, Mater. Sci. Eng.
A 732 (2018) 228–239, https://doi.org/10.1016/j.msea.2018.07.008.
[17] Y.H. Zhou, Z.H. Zhang, Y.P. Wang, G. Liu, S.Y. Zhou, Y.L. Li, J. Shen, M. Yan,
Selective laser melting of typical metallic materials: an effective process
prediction model developed by energy absorption and consumptionanalysis,
Addit. Manuf. 25 (2019) 204–217, https://doi.org/10.1016/j.
addma.2018.10.046.
[18] L.N. Carter, C. Martin, P.J. Withers, M.M. Attallah, The influence of the laser scan
strategy on grain structure and cracking behaviour in SLM powder-bed fabricated
nickel superalloy, J. Alloy. Compd. 615 (2014) 338–347, https://doi.org/
10.1016/j.jallcom.2014.06.172.
[19] V.D. Divya, R. Muñoz-Moreno, O.M.D.M. Messé, J.S. Barnard, S. Baker, T. Illston,
H.J. Stone, Microstructure of selective laser melted CM247LC nickel-based
superalloy and its evolution through heat treatment, Mater. Charact. 114 (2016)
62–74, https://doi.org/10.1016/j.matchar.2016.02.004.
[20] R. Muñoz-Moreno, V.D. Divya, S.L. Driver, O.M.D.M. Messé, T. Illston, S. Baker,
M.A. Carpenter, H.J. Stone, Effect of heat treatment on the microstructure,
texture and elastic anisotropy of the nickel-based superalloy CM247LC processed
by selective laser melting, Mater. Sci. Eng. A 674 (2016) 529–539, https://doi.
org/10.1016/j.msea.2016.06.075.
[21] S. Catchpole-Smith, N. Aboulkhair, L. Parry, C. Tuck, I.A. Ashcroft, A. Clare,
Fractal scan strategies for selective laser melting of ‘unweldable’ nickel
superalloys, Addit. Manuf. 15 (2017) 113–122, https://doi.org/10.1016/j.
addma.2017.02.002.
[22] X. Wang, L.N. Carter, B. Pang, M.M. Attallah, M.H. Loretto, Microstructure and
yield strength of SLM-fabricated CM247LC Ni-superalloy, Acta Mater. 128 (2017)
87–95, https://doi.org/10.1016/j.actamat.2017.02.007.
[23] T. Vilaro, C. Colin, J.D. Bartout, L. Nazé, M. Sennour, Microstructural and
mechanical approaches of the selective laser melting process applied to a nickel-
base superalloy, Mater. Sci. Eng. A 534 (2012) 446–451, https://doi.org/
10.1016/j.msea.2011.11.092.
[24] L.N. Carter, K. Essa, M.M. Attallah, Optimisation of selective laser melting for a
high temperature Ni-superalloy, Rapid Prototyp. J. 21 (2015) 423–432, https://
doi.org/10.1108/RPJ-06-2013-0063.
[25] A. Basak, S. Das, Microstructure of nickel-base superalloy MAR-M247 additively
manufactured through scanning laser epitaxy (SLE), J. Alloy. Compd. 705 (2017)
806–816, https://doi.org/10.1016/j.jallcom.2017.02.013.
[26] Z. Chen, Y. Xiang, Z. Wei, P. Wei, B. Lu, L. Zhang, J. Du, Thermal dynamic
behavior during selective laser melting of K418 superalloy: numerical simulation
and experimental verification, 0, Appl. Phys. A Mater. Sci. Process. 124 (2018),
https://doi.org/10.1007/s00339-018-1737-8.
[27] P. Kanagarajah, F. Brenne, T. Niendorf, H.J. Maier, Inconel 939 processed by
selective laser melting: effect of microstructure and temperature on the
mechanical properties under static and cyclic loading, Mater. Sci. Eng. A 588
(2013) 188–195, https://doi.org/10.1016/j.msea.2013.09.025.
[28] G. Marchese, S. Parizia, A. Saboori, D. Manfredi, M. Lombardi, P. Fino, D. Ugues,
S. Biamino, The influence of the process parameters on the densification and
microstructure development of laser powder bed fused inconel 939, Metals 10
(2020) 1–19, https://doi.org/10.3390/met10070882.
[29] S. Banoth, C.-W. Li, Y. Hiratsuka, K. Kakehi, The effect of recrystallization on
creep properties of alloy IN939 fabricated by selective laser melting process,
Metals 10 (2020) 1016, https://doi.org/10.3390/met10081016.
[30] X. Wang, X. Gong, K. Chou, Review on powder-bed laser additive manufacturing
of inconel 718 parts, in: ASME 2015 Int. Manuf. Sci. Eng. Conf. MSEC 2015, 2015.
https://doi.org/10.1115/MSEC20159322.
[31] M.C. Karia, M.A. Popat, K.B. Sangani, Selective laser melting of Inconel super
alloy-a review, in: AIP Conf. Proc., 2017. https://doi.org/10.1063/1.4990166.
[32] E. Hosseini, V.A. Popovich, A review of mechanical properties of additively
manufactured Inconel 718, Addit. Manuf. 30 (2019), 100877, https://doi.org/
10.1016/j.addma.2019.100877.
[33] S. Sanchez, P. Smith, Z. Xu, G. Gaspard, C.J. Hyde, W.W. Wits, I.A. Ashcroft,
H. Chen, A.T. Clare, Powder Bed Fusion of nickel-based superalloys: a review, Int.
J. Mach. Tools Manuf. 165 (2021), https://doi.org/10.1016/j.
ijmachtools.2021.103729.
[34] G.H. Cao, T.Y. Sun, C.H. Wang, X. Li, M. Liu, Z.X. Zhang, P.F. Hu, A.M. Russell,
R. Schneider, D. Gerthsen, Z.J. Zhou, C.P. Li, G.F. Chen, Investigations of γ′ γ′′ and
δ precipitates in heat-treated Inconel 718 alloy fabricated by selective laser
melting, Mater. Charact. 136 (2018) 398–406, https://doi.org/10.1016/j.
matchar.2018.01.006.
[35] A. Kreitcberg, V. Brailovski, S. Turenne, Elevated temperature mechanical
behavior of IN625 alloy processed by laser powder-bed fusion, Mater. Sci. Eng. A
700 (2017) 540–553, https://doi.org/10.1016/j.msea.2017.06.045.
[36] Y. Zhao, K. Guan, Z. Yang, Z. Hu, Z. Qian, H. Wang, Z. Ma, The effect of
subsequent heat treatment on the evolution behavior of second phase particles
and mechanical properties of the Inconel 718 superalloy manufactured by
selective laser melting, Mater. Sci. Eng. A 794 (2020), 139931, https://doi.org/
10.1016/j.msea.2020.139931.
[37] P. Tao, H. Li, B. Huang, Q. Hu, S. Gong, Q. Xu, The crystal growth, intercellular
spacing and microsegregation of selective laser melted Inconel 718 superalloy,
Vacuum 159 (2019) 382–390, https://doi.org/10.1016/j.vacuum.2018.10.074.
[38] P. Wang, B. Zhang, C.C. Tan, S. Raghavan, Y.-F. Lim, C.-N. Sun, J. Wei, D. Chi,
Microstructural characteristics and mechanical properties of carbon nanotube
reinforced Inconel 625 parts fabricated by selective laser melting, Mater. Des. 112
(2016) 290–299, https://doi.org/10.1016/j.matdes.2016.09.080.
[39] M.E. Aydinöz, F. Brenne, M. Schaper, C. Schaak, W. Tillmann, J. Nellesen,
T. Niendorf, On the microstructural and mechanical properties of post-treated
additively manufactured Inconel 718 superalloy under quasi-static and cyclic
loading, Mater. Sci. Eng. A 669 (2016) 246–258, https://doi.org/10.1016/j.
msea.2016.05.089.
[40] Z. Xu, C.J. Hyde, C. Tuck, A.T. Clare, Creep behaviour of inconel 718 processed
by laser powder bed fusion, J. Mater. Process. Technol. 256 (2018) 13–24,
https://doi.org/10.1016/j.jmatprotec.2018.01.040.
[41] Y.L. Kuo, T. Nagahari, K. Kakehi, The effect of post-processes on the
microstructure and creep properties of Alloy718 built up by selective laser
melting, Materials (2018), https://doi.org/10.3390/ma11060996.
[42] Z. Song, W. Gao, D. Wang, Z. Wu, M. Yan, L. Huang, X. Zhang, Very-high-cycle
fatigue behavior of inconel 718 alloy fabricated by selective laser melting at
elevated temperature, Materials 14 (2021) 1–16, https://doi.org/10.3390/
ma14041001.
[43] T. Nagahari, T. Nagoya, K. Kakehi, N. Sato, S. Nakano, Microstructure and creep
properties of ni-base superalloy IN718 built up by selective laser melting in a
vacuum environment, Metals 10 (2020), https://doi.org/10.3390/met10030362.
[44] Q. Zhang, H. Li, Y. Yang, Effects of solution heat treatment on laves phase and
corrosion behaviors in selective laser melted Inconel 718 alloy, IOP Conf. Ser.
Mater. Sci. Eng. (2019), https://doi.org/10.1088/1757-899X/677/2/022081.
[45] Y.L. Kuo, S. Horikawa, K. Kakehi, The effect of interdendritic δ phase on the
mechanical properties of Alloy 718 built up by additive manufacturing, Mater.
Des. 116 (2017) 411–418, https://doi.org/10.1016/j.matdes.2016.12.026.
[46] M.R. Stoudt, E.A. Lass, D.S. Ng, M.E. Williams, F. Zhang, C.E. Campbell,
G. Lindwall, L.E. Levine, The influence of annealing temperature and time on the
formation of δ-phase in additively-manufactured Inconel 625, Metall. Mater.
Trans. A Phys. Metall. Mater. Sci. 49 (2018) 3028–3037, https://doi.org/
10.1007/s11661-018-4643-y.
[47] K.-Y. Feng, P. Liu, H.-X. Li, S.-Y. Sun, S.-B. Xu, J.-N. Li, Microstructure and phase
transformation on the surface of Inconel 718 alloys fabricated by SLM under
1050◦C solid solution + double ageing, Vacuum 145 (2017) 112–115, https://
doi.org/10.1016/j.vacuum.2017.08.044.
[48] J. Li, Z. Zhao, P. Bai, H. Qu, B. Liu, L. Li, L. Wu, R. Guan,H. Liu, Z. Guo,
Microstructural evolution and mechanical properties of IN718 alloy fabricated by
selective laser melting following different heat treatments, J. Alloy. Compd. 772
(2019) 861–870, https://doi.org/10.1016/j.jallcom.2018.09.200.
[49] V.A. Popovich, E.V. Borisov, V. Heurtebise, T. Riemslag, A.A. Popovich, V.S.
Sufiiarov, Creep thermomechanical Fatigue Funct. graded inconel 718 Prod.
Addit. Manuf. 2018 doi: 10.1007/978-3-319-72526-0_9.
[50] Y. Gao, D. Zhang, M. Cao, R. Chen, Z. Feng, R. Poprawe, J.H. Schleifenbaum,
S. Ziegler, Effect of δ phase on high temperature mechanical performances of
Inconel 718 fabricated with SLM process, Mater. Sci. Eng. A 767 (2019), 138327,
https://doi.org/10.1016/j.msea.2019.138327.
[51] M. Cao, D. Zhang, Y. Gao, R. Chen, G. Huang, Z. Feng, R. Poprawe, J.
H. Schleifenbaum, S. Ziegler, The effect of homogenization temperature on the
microstructure and high temperature mechanical performance of SLM-fabricated
IN718 alloy, Mater. Sci. Eng. A 801 (2021), 140427, https://doi.org/10.1016/j.
msea.2020.140427.
[52] E.M. Fayed, M. Saadati, D. Shahriari, V. Brailovski, M. Jahazi, M. Medraj, Effect
of homogenization and solution treatments time on the elevated-temperature
mechanical behavior of Inconel 718 fabricated by laser powder bed fusion, Sci.
Rep. 11 (2021) 1–17, https://doi.org/10.1038/s41598-021-81618-5.
[53] S. Sanchez, G. Gaspard, C.J. Hyde, I.A. Ashcroft, G.A. Ravi, A.T. Clare, The creep
behaviour of nickel alloy 718 manufactured by laser powder bed fusion, Mater.
Des. 204 (2021), 109647, https://doi.org/10.1016/j.matdes.2021.109647.
[54] T.G. Gallmeyer, S. Moorthy, B.B. Kappes, M.J. Mills, B. Amin-Ahmadi, A.
P. Stebner, Knowledge of process-structure-property relationships to engineer
better heat treatments for laser powder bed fusion additive manufactured Inconel
718, Addit. Manuf. 31 (2020), https://doi.org/10.1016/j.addma.2019.100977.
[55] L.Y. Wang, Y.C. Wang, Z.J. Zhou, H.Y. Wan, C.P. Li, G.F. Chen, G.P. Zhang, Small
punch creep performance of heterogeneous microstructure dominated Inconel
718 fabricated by selective laser melting, Mater. Des. 195 (2020), https://doi.
org/10.1016/j.matdes.2020.109042.
[56] E.A. Lass, M.R. Stoudt, M.E. Williams, M.B. Katz, L.E. Levine, T.Q. Phan, T.
H. Gnaeupel-Herold, D.S. Ng, Formation of the NiNb δ-phase in stress-relieved
inconel 625 produced via laser powder-bed fusion additive manufacturing,
Metall. Mater. Trans. A Phys. Metall. Mater. Sci. 48 (2017) 5547–5558, https://
doi.org/10.1007/s11661-017-4304-6.
[57] W.M. Tucho, V. Hansen, Characterization of SLM-fabricated Inconel 718 after
solid solution and precipitation hardening heat treatments, J. Mater. Sci. 54
(2019) 823–839, https://doi.org/10.1007/s10853-018-2851-x.
[58] L. Zhou, A. Mehta, B. McWilliams, K. Cho, Y. Sohn, Microstructure, precipitates
and mechanical properties of powder bed fused inconel 718 before and after heat
treatment, J. Mater. Sci. Technol. 35 (2019) 1153–1164, https://doi.org/
10.1016/j.jmst.2018.12.006.
[59] Y.L. Kuo, K. Kakehi, Influence of powder surface contamination in the Ni-based
superalloy alloy718 fabricated by selective laser melting and hot isostatic
pressing, Metals (2017), https://doi.org/10.3390/met7090367.
[60] W. Huang, Z. Wang, Isothermal solid-state transformations of Inconel 718 alloy
fabricated by selective laser melting, Adv. Eng. Mater. 23 (2021) 1–11, https://
doi.org/10.1002/adem.202000982.
[61] C. Guo, S. Li, S. Shi, X. Li, X. Hu, Q. Zhu, R.M. Ward, Effect of processing
parameters on surface roughness, porosity and cracking of as-built IN738LC parts
G.M. Volpato et al.
https://doi.org/10.3390/ma11010106
https://doi.org/10.3390/ma11010106
https://doi.org/10.1016/j.msea.2018.07.008
https://doi.org/10.1016/j.addma.2018.10.046
https://doi.org/10.1016/j.addma.2018.10.046
https://doi.org/10.1016/j.jallcom.2014.06.172
https://doi.org/10.1016/j.jallcom.2014.06.172
https://doi.org/10.1016/j.matchar.2016.02.004
https://doi.org/10.1016/j.msea.2016.06.075
https://doi.org/10.1016/j.msea.2016.06.075
https://doi.org/10.1016/j.addma.2017.02.002
https://doi.org/10.1016/j.addma.2017.02.002
https://doi.org/10.1016/j.actamat.2017.02.007
https://doi.org/10.1016/j.msea.2011.11.092
https://doi.org/10.1016/j.msea.2011.11.092
https://doi.org/10.1108/RPJ-06-2013-0063
https://doi.org/10.1108/RPJ-06-2013-0063
https://doi.org/10.1016/j.jallcom.2017.02.013
https://doi.org/10.1007/s00339-018-1737-8
https://doi.org/10.1016/j.msea.2013.09.025
https://doi.org/10.3390/met10070882
https://doi.org/10.3390/met10081016
https://doi.org/10.1016/j.addma.2019.100877
https://doi.org/10.1016/j.addma.2019.100877
https://doi.org/10.1016/j.ijmachtools.2021.103729
https://doi.org/10.1016/j.ijmachtools.2021.103729
https://doi.org/10.1016/j.matchar.2018.01.006
https://doi.org/10.1016/j.matchar.2018.01.006
https://doi.org/10.1016/j.msea.2017.06.045
https://doi.org/10.1016/j.msea.2020.139931
https://doi.org/10.1016/j.msea.2020.139931
https://doi.org/10.1016/j.vacuum.2018.10.074
https://doi.org/10.1016/j.matdes.2016.09.080
https://doi.org/10.1016/j.msea.2016.05.089
https://doi.org/10.1016/j.msea.2016.05.089
https://doi.org/10.1016/j.jmatprotec.2018.01.040
https://doi.org/10.3390/ma11060996
https://doi.org/10.3390/ma14041001
https://doi.org/10.3390/ma14041001
https://doi.org/10.3390/met10030362
https://doi.org/10.1088/1757-899X/677/2/022081
https://doi.org/10.1016/j.matdes.2016.12.026
https://doi.org/10.1007/s11661-018-4643-y
https://doi.org/10.1007/s11661-018-4643-y
https://doi.org/10.1016/j.vacuum.2017.08.044
https://doi.org/10.1016/j.vacuum.2017.08.044
https://doi.org/10.1016/j.jallcom.2018.09.200
https://doi.org/10.1016/j.msea.2019.138327
https://doi.org/10.1016/j.msea.2020.140427
https://doi.org/10.1016/j.msea.2020.140427
https://doi.org/10.1038/s41598-021-81618-5
https://doi.org/10.1016/j.matdes.2021.109647
https://doi.org/10.1016/j.addma.2019.100977
https://doi.org/10.1016/j.matdes.2020.109042
https://doi.org/10.1016/j.matdes.2020.109042
https://doi.org/10.1007/s11661-017-4304-6
https://doi.org/10.1007/s11661-017-4304-6
https://doi.org/10.1007/s10853-018-2851-x
https://doi.org/10.1016/j.jmst.2018.12.006
https://doi.org/10.1016/j.jmst.2018.12.006
https://doi.org/10.3390/met7090367
https://doi.org/10.1002/adem.202000982
https://doi.org/10.1002/adem.202000982
Additive Manufacturing 55 (2022) 102871
26
fabricated by laser powder bed fusion, J. Mater. Process. Technol. 285 (2020),
116788, https://doi.org/10.1016/j.jmatprotec.2020.116788.
[62] L. Scime, J. Beuth, Melt pool geometry and morphology variability for the Inconel
718 alloy in a laser powder bed fusion additive manufacturing process, Addit.
Manuf. 29 (2019), https://doi.org/10.1016/j.addma.2019.100830.
[63] P. Kumar, J. Farah, J. Akram, C. Teng, J. Ginn, M. Misra, Influence of laser
processing parameters on porosity in Inconel 718 during additive manufacturing,
Int. J. Adv. Manuf. Technol. 103 (2019) 1497–1507, https://doi.org/10.1007/
s00170-019-03655-9.
[64] N. Perevoshchikova, J. Rigaud, Y. Sha, M. Heilmaier, B. Finnin, E. Labelle, X. Wu,
Optimisation of selective laser melting parameters for the Ni-based superalloy IN-
738 LC using Doehlert’s design, Rapid Prototyp. J. 23 (2017) 881–892, https://
doi.org/10.1108/RPJ-04-2016-0063.
[65] S.K. Nayak, S.K. Mishra, A.N. Jinoop, C.P. Paul, K.S. Bindra, Experimental studies
on laser additive manufacturing of Inconel-625 structures using powder bed
fusion at 100 µm layer thickness, J. Mater. Eng. Perform. 29 (2020) 7636–7647,
https://doi.org/10.1007/s11665-020-05215-9.
[66] M. Balbaa, S. Mekhiel, M. Elbestawi, J. McIsaac, On selective laser melting of
Inconel 718: densification, surface roughness, and residual stresses, Mater. Des.
193 (2020), 108818,https://doi.org/10.1016/j.matdes.2020.108818.
[67] M. Calandri, S. Yin, B. Aldwell, F. Calignano, R. Lupoi, D. Ugues, Texture and
microstructural features at different length scales in Inconel 718 produced by
selective laser melting, Materials 12 (2019), https://doi.org/10.3390/
ma12081293.
[68] M. Ni, C. Chen, X. Wang, P. Wang, R. Li, X. Zhang, K. Zhou, Anisotropic tensile
behavior of in situ precipitation strengthened Inconel 718 fabricated by additive
manufacturing, Mater. Sci. Eng. A 701 (2017) 344–351, https://doi.org/10.1016/
j.msea.2017.06.098.
[69] G. Marchese, X. Garmendia Colera, F. Calignano, M. Lorusso, S. Biamino,
P. Minetola, D. Manfredi, Characterization and comparison of Inconel 625
processed by selective laser melting and laser metal deposition, Adv. Eng. Mater.
19 (2017), https://doi.org/10.1002/adem.201600635.
[70] H. Wang, X. Zhang, G.B. Wang, J. Shen, G.Q. Zhang, Y.P. Li, M. Yan, Selective
laser melting of the hard-to-weld IN738LC superalloy: efforts to mitigate defects
and the resultant microstructural and mechanical properties, J. Alloy. Compd.
807 (2019), https://doi.org/10.1016/j.jallcom.2019.151662.
[71] H. Zhang, D. Gu, C. Ma, M. Guo, J. Yang, H. Zhang, H. Chen, C. Li, K. Svynarenko,
K. Kosiba, Understanding tensile and creep properties of WC reinforced nickel-
based composites fabricated by selective laser melting, Mater. Sci. Eng. A 802
(2021), 140431, https://doi.org/10.1016/j.msea.2020.140431.
[72] M. Sadowski, L. Ladani, W. Brindley, J. Romano, Optimizing quality of additively
manufactured Inconel 718 using powder bed laser melting process, Addit. Manuf.
11 (2016) 60–70, https://doi.org/10.1016/j.addma.2016.03.006.
[73] Q. Shi, D. Gu, M. Xia, S. Cao, T. Rong, Effects of laser processing parameters on
thermal behavior and melting/solidification mechanism during selective laser
melting of TiC/Inconel 718 composites, Opt. Laser Technol. 84 (2016) 9–22,
https://doi.org/10.1016/j.optlastec.2016.04.009.
[74] D. Grange, J.D. Bartout, B. Macquaire, C. Colin, Processing a non-weldable nickel-
base superalloy by selective laser melting: role of the shape and size of the melt
pools on solidification cracking, Materialia 12 (2020), 100686, https://doi.org/
10.1016/j.mtla.2020.100686.
[75] C. Li, Y.B. Guo, J.B. Zhao, Interfacial phenomena and characteristics between the
deposited material and substrate in selective laser melting Inconel 625, J. Mater.
Process. Technol. 243 (2017) 269–281, https://doi.org/10.1016/j.
jmatprotec.2016.12.033.
[76] J. Gockel, L. Sheridan, B. Koerper, B. Whip, The influence of additive
manufacturing processing parameters on surface roughness and fatigue life, Int. J.
Fatigue 124 (2019) 380–388, https://doi.org/10.1016/j.ijfatigue.2019.03.025.
[77] Y. Li, M. Založnik, J. Zollinger, L. Dembinski, A. Mathieu, Effects of the powder,
laser parameters and surface conditions on the molten pool formation in the
selective laser melting of IN718, J. Mater. Process. Technol. 289 (2021), https://
doi.org/10.1016/j.jmatprotec.2020.116930.
[78] D. Grange, A. Queva, G. Guillemot, M. Bellet, J.D. Bartout, C. Colin, Effect of
processing parameters during the laser beam melting of Inconel 738: comparison
between simulated and experimental melt pool shape, J. Mater. Process. Technol.
289 (2021), 116897, https://doi.org/10.1016/j.jmatprotec.2020.116897.
[79] H. Yang, L. Meng, S. Luo, Z. Wang, Microstructural evolution and mechanical
performances of selective laser melting Inconel 718 from low to high laser power,
J. Alloy. Compd. 828 (2020), https://doi.org/10.1016/j.jallcom.2020.154473.
[80] B. Whip, L. Sheridan, J. Gockel, The effect of primary processing parameters on
surface roughness in laser powder bed additive manufacturing, Int. J. Adv.
Manuf. Technol. 103 (2019) 4411–4422, https://doi.org/10.1007/s00170-019-
03716-z.
[81] J.H. Yi, J.W. Kang, T.J. Wang, X. Wang, Y.Y. Hu, T. Feng, Y.L. Feng, P.Y. Wu,
Effect of laser energy density on the microstructure, mechanical properties, and
deformation of Inconel 718 samples fabricated by selective laser melting, J. Alloy.
Compd. 786 (2019) 481–488, https://doi.org/10.1016/j.jallcom.2019.01.377.
[82] S. Bagherifard, G. Roscioli, M.V. Zuccoli, M. Hadi, G. D’Elia, A.G. Demir,
B. Previtali, J. Kondás, M. Guagliano, Cold spray deposition of freestanding
inconel samples and comparative analysis with selective laser melting, J. Therm.
Spray. Technol. 26 (2017) 1517–1526, https://doi.org/10.1007/s11666-017-
0572-3.
[83] M. Cloots, P.J. Uggowitzer, K. Wegener, Investigations on the microstructure and
crack formation of IN738LC samples processed by selective laser melting using
Gaussian and doughnut profiles, Mater. Des. 89 (2016) 770–784, https://doi.org/
10.1016/j.matdes.2015.10.027.
[84] T. Rong, D. Gu, Q. Shi, S. Cao, M. Xia, Effects of tailored gradient interface on
wear properties of WC/Inconel 718 composites using selective laser melting, Surf.
Coat. Technol. 307 (2016) 418–427, https://doi.org/10.1016/j.
surfcoat.2016.09.011.
[85] Y. Tachibana, T.-T. Ikeshoji, K. Nakamura, M. Yonehara, H. Kyogoku, Selective
laser melting of inconel 718 under high power and high scanning speed
conditions, 2018. https://doi.org/10.4028/www.scientific.net/MSF.941.1574.
[86] T. Mukherjee, H.L. Wei, A. De, T. DebRoy, Heat and fluid flow in additive
manufacturing – Part II: powder bed fusion of stainless steel, and titanium, nickel
and aluminum base alloys, Comput. Mater. Sci. 150 (2018) 369–380, https://doi.
org/10.1016/j.commatsci.2018.04.027.
[87] I. Koutiri, E. Pessard, P. Peyre, O. Amlou, T. De Terris, Influence of SLM process
parameters on the surface finish, porosity rate and fatigue behavior of as-built
Inconel 625 parts, J. Mater. Process. Technol. 255 (2018) 536–546, https://doi.
org/10.1016/j.jmatprotec.2017.12.043.
[88] H. Yang, J. Yang, W. Huang, Z. Wang, X. Zeng, The printability, microstructure,
crystallographic features and microhardness of selective laser melted Inconel 718
thin wall, Mater. Des. 156 (2018) 407–418, https://doi.org/10.1016/j.
matdes.2018.07.007.
[89] E. Chlebus, K. Gruber, B. Kuźnicka, J. Kurzac, T. Kurzynowski, Effect of heat
treatment on the microstructure and mechanical properties of Inconel 718
processed by selective laser melting, Mater. Sci. Eng. A 639 (2015) 647–655,
https://doi.org/10.1016/j.msea.2015.05.035.
[90] B. Zhang, G. Bi, S. Nai, C.N. Sun, J. Wei, Microhardness and microstructure
evolution of TiB2 reinforced Inconel 625/TiB2 composite produced by selective
laser melting, Opt. Laser Technol. 80 (2016) 186–195, https://doi.org/10.1016/j.
optlastec.2016.01.010.
[91] D. Brown, C. Li, Z.Y. Liu, X.Y. Fang, Y.B. Guo, Surface integrity of Inconel 718 by
hybrid selective laser melting and milling, Virtual Phys. Prototyp. 13 (2018)
26–31, https://doi.org/10.1080/17452759.2017.1392681.
[92] X.Y. Fang, H.Q. Li, M. Wang, C. Li, Y.B. Guo, Characterization of texture and grain
boundary character distributions of selective laser melted Inconel 625 alloy,
Mater. Charact. 143 (2018) 182–190, https://doi.org/10.1016/j.
matchar.2018.02.008.
[93] D. Gu, Q. Shi, K. Lin, L. Xi, Microstructure and performance evolution and
underlying thermal mechanisms of Ni-based parts fabricated by selective laser
melting, Addit. Manuf. 22 (2018) 265–278, https://doi.org/10.1016/j.
addma.2018.05.019.
[94] Q. Shi, D. Gu, K. Lin, W. Chen, M. Xia, D. Dai, The role of reinforcing particle size
in tailoring interfacial microstructure and wear performance of selective laser
melting WC/Inconel 718 Composites, J. Manuf. Sci. Eng. Trans. (2018), https://
doi.org/10.1115/1.4040544.
[95] Z. Zhao, H. Qu, P. Bai, J. Li, L. Wu, P. Huo, Friction and wear behaviour of Inconel
718 alloy fabricated by selective laser melting after heat treatments, Philos. Mag.
Lett. 98 (2018) 547–555, https://doi.org/10.1080/09500839.2019.1597991.
[96] X. Hu, Z. Xue, G. Zhao, J. Yun, D. Shi, X. Yang, Laser welding of a selectivelaser
melted Ni-base superalloy: microstructure and high temperature mechanical
property, Mater. Sci. Eng. A 745 (2019) 335–345, https://doi.org/10.1016/j.
msea.2018.12.081.
[97] Q.B. Nguyen, D.N. Luu, S.M.L. Nai, Z. Zhu, Z. Chen, J. Wei, The role of powder
layer thickness on the quality of SLM printed parts, Arch. Civ. Mech. Eng. 18
(2018) 948–955, https://doi.org/10.1016/j.acme.2018.01.015.
[98] B.B. Ravichander, A. Amerinatanzi, N. Shayesteh Moghaddam, Study on the effect
of powder-bed fusion process parameters on the quality of as-built IN718 parts
using response surface methodology, Metals 10 (2020) 1180, https://doi.org/
10.3390/met10091180.
[99] I. Yadroitsev, L. Thivillon, P. Bertrand, I. Smurov, Strategy of manufacturing
components with designed internal structure by selective laser melting of metallic
powder, Appl. Surf. Sci. 254 (2007) 980–983, https://doi.org/10.1016/j.
apsusc.2007.08.046.
[100] G.V. de Leon Nope, L.I. Perez-Andrade, J. Corona-Castuera, D.G. Espinosa-
Arbelaez, J. Muñoz-Saldaña, J.M. Alvarado-Orozco, Study of volumetric energy
density limitations on the IN718 mesostructure and microstructure in laser
powder bed fusion process, J. Manuf. Process. 64 (2021) 1261–1272, https://doi.
org/10.1016/j.jmapro.2021.02.043.
[101] L.E. Criales, Y.M. Arısoy, B. Lane, S. Moylan, A. Donmez, T. Özel, Predictive
modeling and optimization of multi-track processing for laser powder bed fusion
of nickel alloy 625, Addit. Manuf. 13 (2017) 14–36, https://doi.org/10.1016/j.
addma.2016.11.004.
[102] L.E. Criales, Y.M. Arısoy, B. Lane, S. Moylan, A. Donmez, T. Özel, Laser powder
bed fusion of nickel alloy 625: experimental investigations of effects of process
parameters on melt pool size and shape with spatter analysis, Int. J. Mach. Tools
Manuf. 121 (2017) 22–36, https://doi.org/10.1016/j.ijmachtools.2017.03.004.
[103] T.D. McLouth, D.B. Witkin, G.E. Bean, S.D. Sitzman, P.M. Adams, J.R. Lohser, J.-
M. Yang, R.J. Zaldivar, Variations in ambient and elevated temperature
mechanical behavior of IN718 manufactured by selective laser melting via
process parameter control, Mater. Sci. Eng. A 780 (2020), https://doi.org/
10.1016/j.msea.2020.139184.
[104] D.J. Newell, R.P. O’Hara, G.R. Cobb, A.N. Palazotto, M.M. Kirka, L.W. Burggraf, J.
A. Hess, Mitigation of scan strategy effects and material anisotropy through
supersolvus annealing in LPBF IN718, Mater. Sci. Eng. A 764 (2019), 138230,
https://doi.org/10.1016/j.msea.2019.138230.
[105] O. Gokcekaya, T. Ishimoto, S. Hibino, J. Yasutomi, T. Narushima, T. Nakano,
Unique crystallographic texture formation in Inconel 718 by laser powder bed
fusion and its effect on mechanical anisotropy, Acta Mater. 212 (2021), 116876,
https://doi.org/10.1016/j.actamat.2021.116876.
G.M. Volpato et al.
https://doi.org/10.1016/j.jmatprotec.2020.116788
https://doi.org/10.1016/j.addma.2019.100830
https://doi.org/10.1007/s00170-019-03655-9
https://doi.org/10.1007/s00170-019-03655-9
https://doi.org/10.1108/RPJ-04-2016-0063
https://doi.org/10.1108/RPJ-04-2016-0063
https://doi.org/10.1007/s11665-020-05215-9
https://doi.org/10.1016/j.matdes.2020.108818
https://doi.org/10.3390/ma12081293
https://doi.org/10.3390/ma12081293
https://doi.org/10.1016/j.msea.2017.06.098
https://doi.org/10.1016/j.msea.2017.06.098
https://doi.org/10.1002/adem.201600635
https://doi.org/10.1016/j.jallcom.2019.151662
https://doi.org/10.1016/j.msea.2020.140431
https://doi.org/10.1016/j.addma.2016.03.006
https://doi.org/10.1016/j.optlastec.2016.04.009
https://doi.org/10.1016/j.mtla.2020.100686
https://doi.org/10.1016/j.mtla.2020.100686
https://doi.org/10.1016/j.jmatprotec.2016.12.033
https://doi.org/10.1016/j.jmatprotec.2016.12.033
https://doi.org/10.1016/j.ijfatigue.2019.03.025
https://doi.org/10.1016/j.jmatprotec.2020.116930
https://doi.org/10.1016/j.jmatprotec.2020.116930
https://doi.org/10.1016/j.jmatprotec.2020.116897
https://doi.org/10.1016/j.jallcom.2020.154473
https://doi.org/10.1007/s00170-019-03716-z
https://doi.org/10.1007/s00170-019-03716-z
https://doi.org/10.1016/j.jallcom.2019.01.377
https://doi.org/10.1007/s11666-017-0572-3
https://doi.org/10.1007/s11666-017-0572-3
https://doi.org/10.1016/j.matdes.2015.10.027
https://doi.org/10.1016/j.matdes.2015.10.027
https://doi.org/10.1016/j.surfcoat.2016.09.011
https://doi.org/10.1016/j.surfcoat.2016.09.011
https://doi.org/10.1016/j.commatsci.2018.04.027
https://doi.org/10.1016/j.commatsci.2018.04.027
https://doi.org/10.1016/j.jmatprotec.2017.12.043
https://doi.org/10.1016/j.jmatprotec.2017.12.043
https://doi.org/10.1016/j.matdes.2018.07.007
https://doi.org/10.1016/j.matdes.2018.07.007
https://doi.org/10.1016/j.msea.2015.05.035
https://doi.org/10.1016/j.optlastec.2016.01.010
https://doi.org/10.1016/j.optlastec.2016.01.010
https://doi.org/10.1080/17452759.2017.1392681
https://doi.org/10.1016/j.matchar.2018.02.008
https://doi.org/10.1016/j.matchar.2018.02.008
https://doi.org/10.1016/j.addma.2018.05.019
https://doi.org/10.1016/j.addma.2018.05.019
https://doi.org/10.1115/1.4040544
https://doi.org/10.1115/1.4040544
https://doi.org/10.1080/09500839.2019.1597991
https://doi.org/10.1016/j.msea.2018.12.081
https://doi.org/10.1016/j.msea.2018.12.081
https://doi.org/10.1016/j.acme.2018.01.015
https://doi.org/10.3390/met10091180
https://doi.org/10.3390/met10091180
https://doi.org/10.1016/j.apsusc.2007.08.046
https://doi.org/10.1016/j.apsusc.2007.08.046
https://doi.org/10.1016/j.jmapro.2021.02.043
https://doi.org/10.1016/j.jmapro.2021.02.043
https://doi.org/10.1016/j.addma.2016.11.004
https://doi.org/10.1016/j.addma.2016.11.004
https://doi.org/10.1016/j.ijmachtools.2017.03.004
https://doi.org/10.1016/j.msea.2020.139184
https://doi.org/10.1016/j.msea.2020.139184
https://doi.org/10.1016/j.msea.2019.138230
https://doi.org/10.1016/j.actamat.2021.116876
Additive Manufacturing 55 (2022) 102871
27
[106] Y. Lu, S. Wu, Y. Gan, T. Huang, C. Yang, L. Junjie, J. Lin, Study on the
microstructure, mechanical property and residual stress of SLM Inconel-718 alloy
manufactured by differing island scanning strategy, Opt. Laser Technol. 75 (2015)
197–206, https://doi.org/10.1016/j.optlastec.2015.07.009.
[107] H. Zhang, D. Gu, C. Ma, M. Guo, R. Wang, J. Yang, Q. Ge, Microstructure and
tribological property of selective laser melted Ni-based composites using different
scanning strategies, Vacuum 177 (2020), https://doi.org/10.1016/j.
vacuum.2020.109439.
[108] N. Nadammal, S. Cabeza, T. Mishurova, T. Thiede, A. Kromm, C. Seyfert,
L. Farahbod, C. Haberland, J.A. Schneider, P.D. Portella, G. Bruno, Effect of hatch
length on the development of microstructure, texture and residual stresses in
selective laser melted superalloy Inconel 718, Mater. Des. 134 (2017) 139–150,
https://doi.org/10.1016/j.matdes.2017.08.049.
[109] N. Nadammal, T. Mishurova, T. Fritsch, I. Serrano-Munoz, A. Kromm,
C. Haberland, P.D. Portella, G. Bruno, Critical role of scan strategies on the
development of microstructure, texture, and residual stresses during laser powder
bed fusion additive manufacturing, Addit. Manuf. 38 (2021), 101792, https://doi.
org/10.1016/j.addma.2020.101792.
[110] X. Liang, W. Dong, Q. Chen, A.C. To, On incorporating scanning strategy effects
into the modified inherent strain modeling framework for laser powder bed
fusion, Addit. Manuf. 37 (2021), 101648, https://doi.org/10.1016/j.
addma.2020.101648.
[111] I. Serrano-Munoz, T. Fritsch, T. Mishurova, A. Trofimov, D. Apel, A. Ulbricht,
A. Kromm, R. Hesse, A. Evans, G. Bruno, On the interplay of microstructure and
residual stress in LPBF IN718, J. Mater. Sci. 56 (2021) 5845–5867, https://doi.
org/10.1007/s10853-020-05553-y.
[112] H.Y. Wan, Z.J. Zhou, C.P. Li, G.F. Chen, G.P. Zhang, Effect of scanning strategy on
grain structure and crystallographicof 2021.
It can be seen from Fig. 1 that, although IN625 was the first Inconel
superalloy to be produced using PBF-LB (2007), IN718 has gained
incrementally more attention as the manufacturing technique was
developed over the years, quickly overcoming it in terms of research
volume. This trend continues up to the date of the publication of the
present literature review, although IN738LC has also been the focus of
studies since 2011.
These publications focus mostly on the manufacturability through
PBF-LB and on the behavior of Inconel superalloys under conditions that
aim at simulating aspects of the application environment. Thus, they
analyze not only static mechanical response but also high-temperature
conditions, dynamic loading and environmental damage.
Nonetheless, despite the appreciable number of studies that have
been published in the field, there are still technological challenges and
knowledge gaps that prevent the widespread use of the technology in the
industrial production of Inconel alloys. The amount of data gathered
under conditions near to operation is insufficient to predict the behavior
of these materials with reliability, since it is not clear how much of the
knowledge gathered from conventional manufacturing technologies can
be applied in the case of PBF-LB. For instance, as it will be shown in the
following pages, prior research has identified not only microstructural
artifacts but also several phenomena that make the behavior of PBF-LB
superalloys very different from that of conventionally produced mate-
rials in the same application. In addition, since the extent of these
phenomena is restricted to precise manufacturing conditions, the
generalization and scalability of results are particularly difficult, thus
leading to the need for further research with broader scope as well as for
synthetic overviews.
In this context, the aim of this review was to gather, classify and
analyze the results of publications in the field of Inconel superalloys
processed by laser powder bed fusion, in order to provide a compre-
hensive overview of the experimental findings and developments within
the theme from 2007 up to December of 2021. Only studies where pri-
marily an experimental approach was taken were included, and thus
simulation results were only considered when experimentally applied.
No studies focused solely on the development of machinery and
manufacturing processes were considered, due to the lack of focus on the
behavior of the materials considered herein.
This paper builds on former reviews which addressed associated
themes. These include a 2015 publication by Wang et al. that focused on
the PBF-LB processing of Inconel 718 [30], a 2017 article by Karia et al.
on the PBF-LB processing of Inconel superalloys [31], a 2019 paper by
Tian et al. who reviewed PBF-LB applied to Inconel 625 [6], a 2019
publication by Hosseini and Popovich which provided an overview of
the mechanical behavior of AM Inconel 718 [32] and a 2021 article by
Sanchez et al. focused on the PBF processing of nickel-based superalloys
[33]. A total of 337 publications were reviewed in this study, 251 of
which are focused on IN718 (74.5%), 69 on IN625 (20.5%) and 17 on
IN738LC (5%).
Table 1 –
Nominal compositions of Inconel superalloys currently applied in PBF-LB [7].
Composition (w%)
Cr Mo Ti Nb W Co Al C Ni
IN718 19.0 3.0 0.9 5.1 – – 0.5 0.04 Balance
IN625 21.5 9.0 0.2 3.6 – – 0.2 0.05 Balance
IN738LC 16.0 1.75 3.4 0.9 2.6 8.5 3.4 0.11 Balance
Fig. 1. – Number of annual publications focusing on the production of alloys
718, 625 and 738LC using PBF-LB.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
3
2. Outline of topics
Due to the fact that the set of all reviewed publications presents a
wide multifaceted nature, a number of categories were established to
better classify them for analysis. After a general distinction based on
alloy type (between IN718, IN625 and IN738LC), the publications were
separated into several intersecting groups, which were defined as
research subjects approached by each experimentation route, as follows:
1. Parameters: studies that either achieved the optimization of one
or more PBF-LB manufacturing parameters considering criteria
such as build density, defect incidence and build rate, or deter-
mined their effects on material and surface properties;
2. Heat treatment (HT): studies that submitted as-built superalloys
to one or more heat treatments in order to analyze the perfor-
mance and microstructural changes of the materials;
o Hot isostatic pressing (HIP): studies that employed hot isostatic
pressing with aims similar to those of the HT studies;
3. Machining: studies that evaluated machining processes applied to
the materials, analyzing the effects and properties associated
with either the tool or the part;
4. Tensile: studies that employed tensile testing to evaluate the
quasi-static mechanical behavior;
5. Hardness: studies where the macro-, micro- or nanohardness of
the materials were measured;
6. Fatigue: studies conducted to evaluate either low or high cycle
fatigue of the materials, as well as the crack growth behavior;
7. Creep: studies carried out to access the tensile and/or compres-
sive creep behavior of the materials;
8. Corrosion: studies in which the corrosion, oxidation and passiv-
ation mechanisms associated with the materials were
investigated;
9. Composites: studies reporting the production and/or analysis of
metal matrix composites reinforced with various particles and/or
fibers;
10. Tribology: studies where the topography and/or the wear/fric-
tion behavior of the materials were addressed;
11. Simulation: studies where simulation methods were employed to
further analyze data acquired experimentally; and
12. Microstructure: studies that evaluated microstructural features
and changes related to the materials.
Table 2 –
Number of studies by research subject and method.
Group Subgroup IN718 IN625 IN738LC
Microstructure TEM 59 14 5
SEM 196 49 15
EDS 81 23 9
LM 146 31 12
EBSD 100 24 12
XRD 73 20 5
CT 26 5 5
Parameters 85 25 8
HT 104 20 6
HIP 29 7 5
Machining 18 7 0
Tensile 95 28 9
Hardness 73 17 2
Fatigue 44 14 0
Creep 28 3 3
Corrosion 19 8 1
Composites 22 6 1
Tribology 23 4 0
Simulation 31 8 4
Total 251 69 17
Fig. 2. – Connectivity between experimental methods in the reviewed literature related to the production of Inconel by PBF-LB. The numbers correspond to the
number of studies encompassing the subjects at both ends of the associated edge.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
4
Because a significant number of the studies involved microstructural
analysis performed by different methods, this group was further divided,
according to the characterization techniques employed, into the
following subgroups:
1. TEM: transmission electron microscopy and its associated
techniques;
2. SEM: scanning electron microscopy and its associated techniques;
Table 3 –
Phases present in PBF-LB Inconel superalloys.
Table 4 –
Undesirable phases present in PBF-LB Inconel superalloys.
G.M. Volpato et al.
Additive Manufacturingtexture of Inconel 718 processed by selective
laser melting, J. Mater. Sci. Technol. 34 (2018) 1799–1804, https://doi.org/
10.1016/j.jmst.2018.02.002.
[113] H.Y. Wan, Z.J. Zhou, C.P. Li, G.F. Chen, G.P. Zhang, Effect of scanning strategy on
mechanical properties of selective laser melted Inconel 718, Mater. Sci. Eng. A.
753 (2019) 42–48, https://doi.org/10.1016/j.msea.2019.03.007.
[114] Y.M. Arısoy, L.E. Criales, T. Özel, B. Lane, S. Moylan, A. Donmez, Influence of
scan strategy and process parameters on microstructure and its optimization in
additively manufactured nickel alloy 625 via laser powder bed fusion, Int. J. Adv.
Manuf. Technol. 90 (2017) 1393–1417, https://doi.org/10.1007/s00170-016-
9429-z.
[115] F. Geiger, K. Kunze, T. Etter, Tailoring the texture of IN738LC processed by
selective laser melting (SLM) by specific scanning strategies, Mater. Sci. Eng. A
661 (2016) 240–246, https://doi.org/10.1016/j.msea.2016.03.036.
[116] J. Fei, G. Liu, K. Patel, T. Özel, Effects of machining parameters on finishing
additively manufactured nickel-based alloy inconel 625, J. Manuf. Mater. Process.
4 (2020), https://doi.org/10.3390/jmmp4020032.
[117] X. Wang, K. Chou, Effects of thermal cycles on the microstructure evolution of
Inconel 718 during selective laser melting process, Addit. Manuf. 18 (2017) 1–14,
https://doi.org/10.1016/j.addma.2017.08.016.
[118] A. Khabouchi, P. Ventura, N. Leymarie, A. Hazotte, L. Germain, Crystallographic
texture and velocities of ultrasonic waves in a Ni-based superalloy manufactured
by laser powder bed fusion, Mater. Charact. 169 (2020), 110607, https://doi.org/
10.1016/j.matchar.2020.110607.
[119] H. Wang, L. Wang, R. Cui, B. Wang, L. Luo, Y. Su, Differences in microstructure
and nano-hardness of selective laser melted Inconel 718 single tracks under
various melting modes of molten pool, J. Mater. Res. Technol. 9 (2020)
10401–10410, https://doi.org/10.1016/j.jmrt.2020.07.029.
[120] V.S. Sufiiarov, A.A. Popovich, E.V. Borisov, I.A. Polozov, D.V. Masaylo, A.
V. Orlov, The effect of layer thickness at selective laser melting, Procedia Eng. 174
(2017) 126–134, https://doi.org/10.1016/j.proeng.2017.01.179.
[121] J. Ye, S.A. Khairallah, A.M. Rubenchik, M.F. Crumb, G. Guss, J. Belak, M.
J. Matthews, Energy coupling mechanisms and scaling behavior associated with
laser powder bed fusion additive manufacturing, Adv. Eng. Mater. 21 (2019),
https://doi.org/10.1002/adem.201900185.
[122] T. Rong, D. Gu, Formation of novel graded interface and its function on
mechanical properties of WC reinforced Inconel 718 composites processed by
selective laser melting, J. Alloy. Compd. 680 (2016) 333–342, https://doi.org/
10.1016/j.jallcom.2016.04.107.
[123] Q. Jia, D. Gu, Selective laser melting additive manufacturing of TiC/Inconel 718
bulk-form nanocomposites: densification, microstructure, and performance,
J. Mater. Res. 29 (2014) 1960–1969, https://doi.org/10.1557/jmr.2014.130.
[124] Q. Jia, D. Gu, Selective laser melting additive manufacturing of Inconel 718
superalloy parts: Densification, microstructure and properties, J. Alloy. Compd.
585 (2014) 713–721, https://doi.org/10.1016/j.jallcom.2013.09.171.
[125] D. Gu, H. Zhang, D. Dai, M. Xia, C. Hong, R. Poprawe, Laser additive
manufacturing of nano-TiC reinforced Ni-based nanocomposites with tailored
microstructure and performance, Compos. Part B Eng. 163 (2019) 585–597,
https://doi.org/10.1016/j.compositesb.2018.12.146.
[126] L. Chen, Y. Sun, L. Li, Y. Ren, X. Ren, In situ TiC/Inconel 625 nanocomposites
fabricated by selective laser melting: Densification behavior, microstructure
evolution, and wear properties, Appl. Surf. Sci. 518 (2020), 145981, https://doi.
org/10.1016/j.apsusc.2020.145981.
[127] L. Chen, Y. Sun, L. Li, X. Ren, Microstructure evolution, mechanical properties,
and strengthening mechanism of TiC reinforced Inconel 625 nanocomposites
fabricated by selective laser melting, Mater. Sci. Eng. A 792 (2020), 139655,
https://doi.org/10.1016/j.msea.2020.139655.
[128] H.R. Javidrad, S. Salemi, Determination of elastic constants of additive
manufactured Inconel 625 specimens using an ultrasonic technique, Int. J. Adv.
Manuf. Technol. 107 (2020) 4597–4607, https://doi.org/10.1007/s00170-020-
05321-x.
[129] Y. Sun, L. Chen, L. Li, X. Ren, High-temperature oxidation behavior and
mechanism of Inconel 625 super-alloy fabricated by selective laser melting, Opt.
Laser Technol. 132 (2020), 106509, https://doi.org/10.1016/j.
optlastec.2020.106509.
[130] X. Liu, K. Wang, P. Hu, X. He, B. Yan, X. Zhao, Formability, microstructure and
properties of inconel 718 superalloy fabricated by selective laser melting additive
manufacture technology, Materials 14 (2021) 1–18, https://doi.org/10.3390/
ma14040991.
[131] D.S. Watring, J.T. Benzing, N. Hrabe, A.D. Spear, Effects of laser-energy density
and build orientation on the structure–property relationships in as-built Inconel
718 manufactured by laser powder bed fusion, Addit. Manuf. 36 (2020), 101425,
https://doi.org/10.1016/j.addma.2020.101425.
[132] A.M. Mancisidor, F. Garciandia, M.S. Sebastian, P. Álvarez, J. Díaz, I. Unanue,
Reduction of the residual porosity in parts manufactured by selective laser
melting using skywriting and high focus offset strategies, Phys. Procedia 83
(2016) 864–873, https://doi.org/10.1016/j.phpro.2016.08.090.
[133] F. Caiazzo, V. Alfieri, G. Casalino, On the relevance of volumetric energy density
in the investigation of inconel 718 laser powder bed fusion, Materials 13 (2020),
https://doi.org/10.3390/ma13030538.
[134] D.S. Watring, K.C. Carter, D. Crouse, B. Raeymaekers, A.D. Spear, Mechanisms
driving high-cycle fatigue life of as-built Inconel 718 processed by laser powder
bed fusion, Mater. Sci. Eng. A 761 (2019), 137993, https://doi.org/10.1016/j.
msea.2019.06.003.
[135] X. Wang, J. Kang, T. Wang, P. Wu, T. Feng, L. Zheng, Effect of layer-wise varying
parameters on the microstructure and soundness of selective laser melted
INCONEL 718 alloy, Materials 12 (2019), https://doi.org/10.3390/ma12132165.
[136] H.R. Javidrad, S. Salemi, Effect of the volume energy density and heat treatment
on the defect, microstructure, and hardness of L-PBF Inconel 625, Metall. Mater.
Trans. A Phys. Metall. Mater. Sci. 51 (2020) 5880–5891, https://doi.org/
10.1007/s11661-020-05992-x.
[137] S. Traore, M. Schneider, I. Koutiri, F. Coste, R. Fabbro, C. Charpentier,
P. Lefebvre, P. Peyre, Influence of gas atmosphere (Ar or He) on the laser powder
bed fusion of a Ni-based alloy, J. Mater. Process. Technol. 288 (2021), 116851,
https://doi.org/10.1016/j.jmatprotec.2020.116851.
[138] T. Özel, A. Altay, A. Donmez, R. Leach, Surface topography investigations on
nickel alloy 625 fabricated via laser powder bed fusion, Int. J. Adv. Manuf.
Technol. 94 (2018) 4451–4458, https://doi.org/10.1007/s00170-017-1187-z.
[139] M. Xia, D. Gu, C. Ma, H. Zhang, D. Dai, H. Chen, C. Li, Z. Zhou, G. Chen,
I. Kelbassa, Fragmentation and refinement behavior and underlying
thermodynamic mechanism of WC reinforcement during selective laser melting of
Ni-based composites, J. Alloy. Compd. 777 (2019) 693–702, https://doi.org/
10.1016/j.jallcom.2018.11.056.
[140] A.N.D. Gasper, B. Szost, X. Wang, D. Johns, S. Sharma, A.T. Clare, I.A. Ashcroft,
Spatter and oxide formation in laser powder bed fusion of Inconel 718, Addit.
Manuf. 24 (2018) 446–456, https://doi.org/10.1016/j.addma.2018.09.032.
[141] C. Pauzon, A. Raza, E. Hryha, P. Forêt, Oxygen balance during laser powder bed
fusion of Alloy 718, Mater. Des. 201 (2021), https://doi.org/10.1016/j.
matdes.2021.109511.
[142] K. Gruber, I. Smolina, M. Kasprowicz, T. Kurzynowski, Evaluation of Inconel 718
metallic powder to optimize the reuse of powder and to improve the performance
and sustainability of the laser powder bed fusion (Lpbf) process, Materials (2021),
https://doi.org/10.3390/ma14061538.
[143] G.E. Bean, T.D. McLouth,D.B. Witkin, S.D. Sitzman, P.M. Adams, R.J. Zaldivar,
Build Orientation Effects On Texture And Mechanical Properties Of Selective
Laser Melting Inconel 718, J. Mater. Eng. Perform. 28 (2019) 1942–1949, https://
doi.org/10.1007/s11665-019-03980-w.
[144] G. Bean, D.B. Witkin, T.D. McLouth, R.J. Zaldivar, The effect of laser focus and
process parameters on microstructure and mechanical properties of SLM Inconel
718, in: H. Helvajian, A. Piqué, B. Gu (Eds.), Laser 3D Manuf. V, SPIE, 2018, p. 37,
https://doi.org/10.1117/12.2299615.
[145] T. Mishurova, S. Cabeza, T. Thiede, N. Nadammal, A. Kromm, M. Klaus,
C. Genzel, C. Haberland, G. Bruno, The influence of the support structure on
residual stress and distortion in SLM Inconel 718 parts, Metall. Mater. Trans. A
Phys. Metall. Mater. Sci. 49 (2018) 3038–3046, https://doi.org/10.1007/s11661-
018-4653-9.
[146] Y. Cheng, Z. Xiao, H. Zhu, X. Zeng, G. Wang, Influence of substrate characteristics
on residual stress of SLMed Inconel 718, Rapid Prototyp. J. 25 (2019) 792–799,
https://doi.org/10.1108/RPJ-09-2018-0238.
[147] H. Song, T. McGaughy, A. Sadek, W. Zhang, Effect of structural support on
microstructure of nickel base superalloy fabricated by laser-powder bed fusion
additive manufacturing, Addit. Manuf. 26 (2019) 30–40, https://doi.org/
10.1016/j.addma.2018.12.017.
[148] R. Engeli, T. Etter, S. Hövel, K. Wegener, Processability of different IN738LC
powder batches by selective laser melting, J. Mater. Process. Technol. 229 (2016)
484–491, https://doi.org/10.1016/j.jmatprotec.2015.09.046.
[149] L. Cordova, T. Bor, M. de Smit, M. Campos, T. Tinga, Measuring the spreadability
of pre-treated and moisturized powders for laser powder bed fusion, Addit.
Manuf. 32 (2020), https://doi.org/10.1016/j.addma.2020.101082.
[150] B. Kappes, S. Moorthy, D. Drake, H. Geerlings, A. Stebner, Machine learning to
optimize additive manufacturing parameters for laser powder bed fusion of
Inconel 718, 2018. https://doi.org/10.1007/978–3-319–89480-5_39.
[151] L.C. Ardila, F. Garciandia, J.B. González-Díaz, P. Álvarez, A. Echeverria, M.
M. Petite, R. Deffley, J. Ochoa, Effect of IN718 recycled powder reuse on
G.M. Volpato et al.
https://doi.org/10.1016/j.optlastec.2015.07.009
https://doi.org/10.1016/j.vacuum.2020.109439
https://doi.org/10.1016/j.vacuum.2020.109439
https://doi.org/10.1016/j.matdes.2017.08.049
https://doi.org/10.1016/j.addma.2020.101792
https://doi.org/10.1016/j.addma.2020.101792
https://doi.org/10.1016/j.addma.2020.101648
https://doi.org/10.1016/j.addma.2020.101648
https://doi.org/10.1007/s10853-020-05553-y
https://doi.org/10.1007/s10853-020-05553-y
https://doi.org/10.1016/j.jmst.2018.02.002
https://doi.org/10.1016/j.jmst.2018.02.002
https://doi.org/10.1016/j.msea.2019.03.007
https://doi.org/10.1007/s00170-016-9429-z
https://doi.org/10.1007/s00170-016-9429-z
https://doi.org/10.1016/j.msea.2016.03.036
https://doi.org/10.3390/jmmp4020032
https://doi.org/10.1016/j.addma.2017.08.016
https://doi.org/10.1016/j.matchar.2020.110607
https://doi.org/10.1016/j.matchar.2020.110607
https://doi.org/10.1016/j.jmrt.2020.07.029
https://doi.org/10.1016/j.proeng.2017.01.179
https://doi.org/10.1002/adem.201900185
https://doi.org/10.1016/j.jallcom.2016.04.107
https://doi.org/10.1016/j.jallcom.2016.04.107
https://doi.org/10.1557/jmr.2014.130
https://doi.org/10.1016/j.jallcom.2013.09.171
https://doi.org/10.1016/j.compositesb.2018.12.146
https://doi.org/10.1016/j.apsusc.2020.145981
https://doi.org/10.1016/j.apsusc.2020.145981
https://doi.org/10.1016/j.msea.2020.139655
https://doi.org/10.1007/s00170-020-05321-x
https://doi.org/10.1007/s00170-020-05321-x
https://doi.org/10.1016/j.optlastec.2020.106509
https://doi.org/10.1016/j.optlastec.2020.106509
https://doi.org/10.3390/ma14040991
https://doi.org/10.3390/ma14040991
https://doi.org/10.1016/j.addma.2020.101425
https://doi.org/10.1016/j.phpro.2016.08.090
https://doi.org/10.3390/ma13030538
https://doi.org/10.1016/j.msea.2019.06.003
https://doi.org/10.1016/j.msea.2019.06.003
https://doi.org/10.3390/ma12132165
https://doi.org/10.1007/s11661-020-05992-x
https://doi.org/10.1007/s11661-020-05992-x
https://doi.org/10.1016/j.jmatprotec.2020.116851
https://doi.org/10.1007/s00170-017-1187-z
https://doi.org/10.1016/j.jallcom.2018.11.056
https://doi.org/10.1016/j.jallcom.2018.11.056
https://doi.org/10.1016/j.addma.2018.09.032
https://doi.org/10.1016/j.matdes.2021.109511
https://doi.org/10.1016/j.matdes.2021.109511
https://doi.org/10.3390/ma14061538
https://doi.org/10.1007/s11665-019-03980-w
https://doi.org/10.1007/s11665-019-03980-w
https://doi.org/10.1117/12.2299615
https://doi.org/10.1007/s11661-018-4653-9
https://doi.org/10.1007/s11661-018-4653-9
https://doi.org/10.1108/RPJ-09-2018-0238
https://doi.org/10.1016/j.addma.2018.12.017
https://doi.org/10.1016/j.addma.2018.12.017
https://doi.org/10.1016/j.jmatprotec.2015.09.046
https://doi.org/10.1016/j.addma.2020.101082
Additive Manufacturing 55 (2022) 102871
28
properties of parts manufactured by means of selective laser melting, Phys.
Procedia 56 (2014) 99–107, https://doi.org/10.1016/j.phpro.2014.08.152.
[152] H. Yang, G. Jing, P. Gao, Z. Wang, X. Li, Effects of circular beam oscillation
technique on formability and solidification behaviour of selective laser melted
Inconel 718: from single tracks to cuboid samples, J. Mater. Sci. Technol. 51
(2020) 137–150, https://doi.org/10.1016/j.jmst.2019.09.044.
[153] M.C. Sow, T. De Terris, O. Castelnau, Z. Hamouche, F. Coste, R. Fabbro, P. Peyre,
Influence of beam diameter on laser powder bed fusion (L-PBF) process, Addit.
Manuf. 36 (2020), 101532, https://doi.org/10.1016/j.addma.2020.101532.
[154] Y. Wang, J. Shi, Developing very strong texture in a nickel-based superalloy by
selective laser melting with an ultra-high power and flat-top laser beam, Mater.
Charact. 165 (2020), 110372, https://doi.org/10.1016/j.matchar.2020.110372.
[155] J.A. Gonzalez, J. Mireles, S.W. Stafford, M.A. Perez, C.A. Terrazas, R.B. Wicker,
Characterization of Inconel 625 fabricated using powder-bed-based additive
manufacturing technologies, J. Mater. Process. Technol. 264 (2019) 200–210,
https://doi.org/10.1016/j.jmatprotec.2018.08.031.
[156] C. Galera-Rueda, E. Nieto-Valeiras, M. Gardon, M.T. Pérez-Prado, J. LLorca, Effect
of ZrH2 particles on the microstructure and mechanical properties of IN718
manufactured by selective laser melting, Mater. Sci. Eng. A 813 (2021), https://
doi.org/10.1016/j.msea.2021.141123.
[157] N. Kouraytem, J. Varga, B. Amin-Ahmadi, H. Mirmohammad, R.A. Chanut, A.
D. Spear, O.T. Kingstedt, A recrystallization heat-treatment to reduce deformation
anisotropy of additively manufactured Inconel 718, Mater. Des. 198 (2021),
https://doi.org/10.1016/j.matdes.2020.109228.
[158] X. Yan, S. Gao, C. Chang, J. Huang, K. Khanlari, D. Dong, W. Ma, N. Fenineche,
H. Liao, M. Liu, Effect of building directions on the surface roughness,
microstructure, and tribological properties of selective laser melted Inconel 625,
J. Mater. Process. Technol. 288 (2021), 116878, https://doi.org/10.1016/j.
jmatprotec.2020.116878.
[159] D.B. Witkin, R.W. Hayes, T.D. McLouth, G.E. Bean, Anomalous notch rupture
behavior of nickel-based superalloy Inconel 718 due to fabrication by additive
manufacturing, Metall. Mater. Trans. A Phys. Metall. Mater. Sci. 50 (2019)
3458–3465, https://doi.org/10.1007/s11661-019-05298-7.
[160] S. Sanchez, C.J. Hyde, I.A. Ashcroft, R.G.A.A.T. Clare, Multi-laser scan strategies
for enhancing creep performance in LPBF, Addit. Manuf. 41 (2021), https://doi.
org/10.1016/j.addma.2021.101948.
[161] N. Mohammadian, S. Turenne, V. Brailovski, Surface finish control of additively-
manufactured Inconel 625 components using combined chemical-abrasive flow
polishing,J. Mater. Process. Technol. 252 (2018) 728–738, https://doi.org/
10.1016/j.jmatprotec.2017.10.020.
[162] K. Majchrowicz, Z. Pakieła, J. Kamiński, M. Płocińska, T. Kurzynowski,
E. Chlebus, The effect of rhenium addition on microstructure and corrosion
resistance of Inconel 718 processed by selective laser melting, Metall. Mater.
Trans. A Phys. Metall. Mater. Sci. 49 (2018) 6479–6489, https://doi.org/
10.1007/s11661-018-4926-3.
[163] D. Du, A. Dong, D. Shu, G. Zhu, B. Sun, X. Li, E. Lavernia, Influence of build
orientation on microstructure, mechanical and corrosion behavior of Inconel 718
processed by selective laser melting, Mater. Sci. Eng. A 760 (2019) 469–480,
https://doi.org/10.1016/j.msea.2019.05.013.
[164] V.P. Sabelkin, G.R. Cobb, T.E. Shelton, M.N. Hartsfield, D.J. Newell, R.P. O’Hara,
R.A. Kemnitz, Mitigation of anisotropic fatigue in nickel alloy 718 manufactured
via selective laser melting, Mater. Des. 182 (2019), https://doi.org/10.1016/j.
matdes.2019.108095.
[165] V. Anandakrishnan, S. Sathish, D. Muthukannan, V.D. illibabu,
N. Balamuralikrishnan, Dry sliding wear behavior of Inconel 718 additively
manufactured by DMLS technique, Ind. Lubr. Tribol. 72 (2020) 491–496, https://
doi.org/10.1108/ILT-08-2019-0322.
[166] E. Yasa, O. Poyraz, E.U. Solakoglu, G. Akbulut, S. Oren, A study on the stair
stepping effect in direct metal laser sintering of a nickel-based superalloy,
Procedia CIRP 45 (2016) 175–178, https://doi.org/10.1016/j.
procir.2016.02.068.
[167] E.E. Covarrubias, M. Eshraghi, Effect of build angle on surface properties of nickel
superalloys processed by selective laser melting, JOM 70 (2018) 336–342,
https://doi.org/10.1007/s11837-017-2706-y.
[168] Z. Wu, S.P. Narra, A. Rollett, Exploring the fabrication limits of thin-wall
structures in a laser powder bed fusion process, Int. J. Adv. Manuf. Technol. 110
(2020) 191–207, https://doi.org/10.1007/s00170-020-05827-4.
[169] J.R. Poulin, V. Brailovski, P. Terriault, Long fatigue crack propagation behavior of
Inconel 625 processed by laser powder bed fusion: influence of build orientation
and post-processing conditions, Int. J. Fatigue 116 (2018) 634–647, https://doi.
org/10.1016/j.ijfatigue.2018.07.008.
[170] C.J. Hassila, P. Harlin, U. Wiklund, Rolling contact fatigue crack propagation
relative to anisotropies in additive manufactured Inconel 625, Wear 426–427
(2019) 1837–1845, https://doi.org/10.1016/j.wear.2019.01.085.
[171] D. Deng, R.L. Peng, H. Brodin, J. Moverare, Microstructure and mechanical
properties of Inconel 718 produced by selective laser melting: sample orientation
dependence and effects of post heat treatments, Mater. Sci. Eng. A 713 (2018)
294–306, https://doi.org/10.1016/j.msea.2017.12.043.
[172] K. Moussaoui, W. Rubio, M. Mousseigne, T. Sultan, F. Rezai, Effects of selective
laser melting additive manufacturing parameters of Inconel 718 on porosity,
microstructure and mechanical properties, Mater. Sci. Eng. A 735 (2018)
182–190, https://doi.org/10.1016/j.msea.2018.08.037.
[173] S. Periane, A. Duchosal, S. Vaudreuil, H. Chibane, A. Morandeau, J. Cormier,
R. Leroy, Machining influence on the fatigue resistance of Inconel 718 fabricated
by Selective Laser Melting (SLM), Procedia Struct. Integr. (2019) 415–422,
https://doi.org/10.1016/j.prostr.2019.12.045.
[174] Y. Wang, J. Shi, Microstructure and tensile properties of slm graphene reinforced
inconel 718 alloy after post heat treatment, in: ASME 2018 13th Int. Manuf. Sci.
Eng. Conf. MSEC 2018, 2018: pp. 1–7. https://doi.org/10.1115/
MSEC2018–6694.
[175] V.A. Popovich, E.V. Borisov, A.A. Popovich, V.S. Sufiiarov, D.V. Masaylo,
L. Alzina, Impact of heat treatment on mechanical behaviour of Inconel 718
processed with tailored microstructure by selective laser melting, Mater. Des. 131
(2017) 12–22, https://doi.org/10.1016/j.matdes.2017.05.065.
[176] X. Li, J.J. Shi, C.H. Wang, G.H. Cao, A.M. Russell, Z.J. Zhou, C.P. Li, G.F. Chen,
Effect of heat treatment on microstructure evolution of Inconel 718 alloy
fabricated by selective laser melting, J. Alloy. Compd. 764 (2018) 639–649,
https://doi.org/10.1016/j.jallcom.2018.06.112.
[177] B.B. Babamiri, J. Indeck, G. Demeneghi, J. Cuadra, K. Hazeli, Quantification of
porosity and microstructure and their effect on quasi-static and dynamic behavior
of additively manufactured Inconel 718, Addit. Manuf. 34 (2020), https://doi.
org/10.1016/j.addma.2020.101380.
[178] D. Zhang, W. Niu, X. Cao, Z. Liu, Effect of standard heat treatment on the
microstructure and mechanical properties of selective laser melting manufactured
Inconel 718 superalloy, Mater. Sci. Eng. A 644 (2015) 32–40, https://doi.org/
10.1016/j.msea.2015.06.021.
[179] J. Strößner, M. Terock, U. Glatzel, Mechanical and microstructural investigation
of nickel-based superalloy IN718 manufactured by selective laser melting (SLM),
Adv. Eng. Mater. 17 (2015) 1099–1105, https://doi.org/10.1002/
adem.201500158.
[180] J. Schneider, B. Lund, M. Fullen, Effect of heat treatment variations on the
mechanical properties of Inconel 718 selective laser melted specimens, Addit.
Manuf. 21 (2018) 248–254, https://doi.org/10.1016/j.addma.2018.03.005.
[181] Y. Zhao, Z. Ma, L. Yu, J. Dong, Y. Liu, The simultaneous improvements of strength
and ductility in additive manufactured Ni-based superalloy via controlling
cellular subgrain microstructure, J. Mater. Sci. Technol. 68 (2021) 184–190,
https://doi.org/10.1016/j.jmst.2020.07.011.
[182] S.Y. Park, K.S. Kim, M.C. Kim, M.E. Kassner, K.A. Lee, Effect of post-heat
treatment on the tensile and cryogenic impact toughness properties of Inconel
718 manufactured by selective laser melting, Adv. Eng. Mater. 23 (2021) 1–10,
https://doi.org/10.1002/adem.202001005.
[183] H. Hyer, R. Newell, D. Matejczyk, S. Hsie, M. Anthony, L. Zhou, C. Kammerer,
Y. Sohn, Microstructural development in as built and heat treated IN625
component additively manufactured by laser powder bed fusion, J. Phase Equilib.
Diffus. 42 (2021) 14–27, https://doi.org/10.1007/s11669-020-00855-9.
[184] S. Raghavan, B. Zhang, P. Wang, C.-N. Sun, M.L.S. Nai, T. Li, J. Wei, Effect of
different heat treatments on the microstructure and mechanical properties in
selective laser melted INCONEL 718 alloy, Mater. Manuf. Process. 32 (2017)
1588–1595, https://doi.org/10.1080/10426914.2016.1257805.
[185] W.M. Tucho, P. Cuvillier, A. Sjolyst-Kverneland, V. Hansen, Microstructure and
hardness studies of Inconel 718 manufactured by selective laser melting before
and after solution heat treatment, Mater. Sci. Eng. A 689 (2017) 220–232,
https://doi.org/10.1016/j.msea.2017.02.062.
[186] M. Calandri, D. Manfredi, F. Calignano, E.P. Ambrosio, S. Biamino, R. Lupoi,
D. Ugues, Solution treatment study of Inconel 718 produced by SLM additive
technique in view of the oxidation resistance, Adv. Eng. Mater. 20 (2018),
https://doi.org/10.1002/adem.201800351.
[187] Y. Cao, P. Bai, F. Liu, X. Hou, Investigation on the precipitates of IN718 alloy
fabricated by selective laser melting, Metals 9 (2019) 1–10, https://doi.org/
10.3390/met9101128.
[188] X. Yao, S.K. Moon, B.Y. Lee, G. Bi, Effects of heat treatment on microstructures
and tensile properties of IN718/TiC nanocomposite fabricated by selective laser
melting, Int. J. Precis. Eng. Manuf. 18 (2017) 1693–1701, https://doi.org/
10.1007/s12541-017-0197-y.
[189] C. Pei, D. Shi, H. Yuan, H. Li, Assessment of mechanical properties and fatigue
performance of a selective laser melted nickel-base superalloy Inconel 718, Mater.
Sci. Eng. A 759 (2019) 278–287, https://doi.org/10.1016/j.msea.2019.05.007.
[190] A.R. Balachandramurthi, J. Moverare, N. Dixit, D. Deng, R. Pederson,
Microstructural influence on fatigue crack propagation during high cycle fatigue
testing of additively manufactured Alloy 718, Mater. Charact. 149 (2019) 82–94,
https://doi.org/10.1016/j.matchar.2019.01.018.
[191] D.H. Smith, J. Bicknell, L. Jorgensen, B.M. Patterson,N.L. Cordes, I. Tsukrov,
M. Knezevic, Microstructure and mechanical behavior of direct metal laser
sintered Inconel alloy 718, Mater. Charact. 113 (2016) 1–9, https://doi.org/
10.1016/j.matchar.2016.01.003.
[192] G.E. Bean, D.B. Witkin, T.D. McLouth, R.J. Zaldivar, Process gas influence on
microstructure and mechanical behavior of Inconel 718 fabricated via selective
laser melting, Prog. Addit. Manuf. (2020), https://doi.org/10.1007/s40964-020-
00133-7.
[193] W. Tillmann, C. Schaak, J. Nellesen, M. Schaper, M.E. Aydinöz, K.-P. Hoyer, Hot
isostatic pressing of IN718 components manufactured by selective laser melting,
Addit. Manuf. 13 (2017) 93–102, https://doi.org/10.1016/j.addma.2016.11.006.
[194] K. Gruber, R. Dziedzic, B. Kuźnicka, B. Madejski, M. Malicki, Impact of high
temperature stress relieving on final properties of Inconel 718 processed by laser
powder bed fusion, Mater. Sci. Eng. A 813 (2021), https://doi.org/10.1016/j.
msea.2021.141111.
[195] W. Huang, J. Yang, H. Yang, G. Jing, Z. Wang, X. Zeng, Heat treatment of Inconel
718 produced by selective laser melting: microstructure and mechanical
properties, Mater. Sci. Eng. A 750 (2019) 98–107, https://doi.org/10.1016/j.
msea.2019.02.046.
[196] M. Ni, S. Liu, C. Chen, R. Li, X. Zhang, K. Zhou, Effect of heat treatment on the
microstructural evolution of a precipitation-hardened superalloy produced by
G.M. Volpato et al.
https://doi.org/10.1016/j.phpro.2014.08.152
https://doi.org/10.1016/j.jmst.2019.09.044
https://doi.org/10.1016/j.addma.2020.101532
https://doi.org/10.1016/j.matchar.2020.110372
https://doi.org/10.1016/j.jmatprotec.2018.08.031
https://doi.org/10.1016/j.msea.2021.141123
https://doi.org/10.1016/j.msea.2021.141123
https://doi.org/10.1016/j.matdes.2020.109228
https://doi.org/10.1016/j.jmatprotec.2020.116878
https://doi.org/10.1016/j.jmatprotec.2020.116878
https://doi.org/10.1007/s11661-019-05298-7
https://doi.org/10.1016/j.addma.2021.101948
https://doi.org/10.1016/j.addma.2021.101948
https://doi.org/10.1016/j.jmatprotec.2017.10.020
https://doi.org/10.1016/j.jmatprotec.2017.10.020
https://doi.org/10.1007/s11661-018-4926-3
https://doi.org/10.1007/s11661-018-4926-3
https://doi.org/10.1016/j.msea.2019.05.013
https://doi.org/10.1016/j.matdes.2019.108095
https://doi.org/10.1016/j.matdes.2019.108095
https://doi.org/10.1108/ILT-08-2019-0322
https://doi.org/10.1108/ILT-08-2019-0322
https://doi.org/10.1016/j.procir.2016.02.068
https://doi.org/10.1016/j.procir.2016.02.068
https://doi.org/10.1007/s11837-017-2706-y
https://doi.org/10.1007/s00170-020-05827-4
https://doi.org/10.1016/j.ijfatigue.2018.07.008
https://doi.org/10.1016/j.ijfatigue.2018.07.008
https://doi.org/10.1016/j.wear.2019.01.085
https://doi.org/10.1016/j.msea.2017.12.043
https://doi.org/10.1016/j.msea.2018.08.037
https://doi.org/10.1016/j.prostr.2019.12.045
https://doi.org/10.1016/j.matdes.2017.05.065
https://doi.org/10.1016/j.jallcom.2018.06.112
https://doi.org/10.1016/j.addma.2020.101380
https://doi.org/10.1016/j.addma.2020.101380
https://doi.org/10.1016/j.msea.2015.06.021
https://doi.org/10.1016/j.msea.2015.06.021
https://doi.org/10.1002/adem.201500158
https://doi.org/10.1002/adem.201500158
https://doi.org/10.1016/j.addma.2018.03.005
https://doi.org/10.1016/j.jmst.2020.07.011
https://doi.org/10.1002/adem.202001005
https://doi.org/10.1007/s11669-020-00855-9
https://doi.org/10.1080/10426914.2016.1257805
https://doi.org/10.1016/j.msea.2017.02.062
https://doi.org/10.1002/adem.201800351
https://doi.org/10.3390/met9101128
https://doi.org/10.3390/met9101128
https://doi.org/10.1007/s12541-017-0197-y
https://doi.org/10.1007/s12541-017-0197-y
https://doi.org/10.1016/j.msea.2019.05.007
https://doi.org/10.1016/j.matchar.2019.01.018
https://doi.org/10.1016/j.matchar.2016.01.003
https://doi.org/10.1016/j.matchar.2016.01.003
https://doi.org/10.1007/s40964-020-00133-7
https://doi.org/10.1007/s40964-020-00133-7
https://doi.org/10.1016/j.addma.2016.11.006
https://doi.org/10.1016/j.msea.2021.141111
https://doi.org/10.1016/j.msea.2021.141111
https://doi.org/10.1016/j.msea.2019.02.046
https://doi.org/10.1016/j.msea.2019.02.046
Additive Manufacturing 55 (2022) 102871
29
selective laser melting, Mater. Sci. Eng. A 748 (2019) 275–285, https://doi.org/
10.1016/j.msea.2019.01.109.
[197] S. Holland, X. Wang, X.Y. Fang, Y.B. Guo, F. Yan, L. Li, Grain boundary network
evolution in Inconel 718 from selective laser melting to heat treatment, Mater.
Sci. Eng. A. 725 (2018) 406–418, https://doi.org/10.1016/j.msea.2018.04.045.
[198] E.W. Hovig, A.S. Azar, F. Grytten, K. Sørby, E. Andreassen, Determination of
anisotropic mechanical properties for materials processed by laser powder bed
fusion, Adv. Mater. Sci. Eng. (2018) (2018), https://doi.org/10.1155/2018/
7650303.
[199] J. Shi, Y. Wang, Y. Wang, S. Lu, Effect of solid solution temperature on material
properties and microstructure of inconel 718/tic composites by selective laser
melting, Int. Mech. Eng. Congr. Expo 2015 (2015) 1–8.
[200] S.J. Foster, K. Carver, R.B. Dinwiddie, F. List, K.A. Unocic, A. Chaudhary, S.
S. Babu, Process-defect-structure-property correlations during laser powder bed
fusion of alloy 718: role of in situ and ex situ characterizations, Metall. Mater.
Trans. A Phys. Metall. Mater. Sci. 49 (2018) 5775–5798, https://doi.org/
10.1007/s11661-018-4870-2.
[201] J.-R. Zhao, F.-Y. Hung, T.-S. Lui, Microstructure and tensile fracture behavior of
three-stage heat treated inconel 718 alloy produced via laser powder bed fusion
process, J. Mater. Res. Technol. (2019), https://doi.org/10.1016/j.
jmrt.2020.01.030.
[202] P. Liu, J. Hu, S. Sun, K. Feng, Y. Zhang, M. Cao, Microstructural evolution and
phase transformation of Inconel 718 alloys fabricated by selective laser melting
under different heat treatment, J. Manuf. Process. 39 (2019) 226–232, https://
doi.org/10.1016/j.jmapro.2019.02.029.
[203] Z. Liu, X. Li, X. Wang, C. Tian, L. Wang, Comparative investigation on grindability
of Inconel 718 made by selective laser melting (SLM) and casting, Int. J. Adv.
Manuf. Technol. 100 (2019) 3155–3166, https://doi.org/10.1007/s00170-018-
2850-8.
[204] A.R. Balachandramurthi, J. Moverare, N. Dixit, R. Pederson, Influence of defects
and as-built surface roughness on fatigue properties of additively manufactured
Alloy 718, Mater. Sci. Eng. A 735 (2018) 463–474, https://doi.org/10.1016/j.
msea.2018.08.072.
[205] Y. Zhao, K. Li, M. Gargani, W. Xiong, A comparative analysis of Inconel 718 made
by additive manufacturing and suction casting: microstructure evolution in
homogenization, Addit. Manuf. 36 (2020), 101404, https://doi.org/10.1016/j.
addma.2020.101404.
[206] D.T. Ardi, L. Guowei, N. Maharjan, B. Mutiargo, S.H. Leng, R. Srinivasan, Effects
of post-processing route on fatigue performance of laser powder bed fusion
Inconel 718, Addit. Manuf. 36 (2020), 101442, https://doi.org/10.1016/j.
addma.2020.101442.
[207] R. Barros, F.J.G. Silva, R.M. Gouveia, A. Saboori, G. Marchese, S. Biamino,
A. Salmi, E. Atzeni, Stress analysis before and after heat treatment, Metals 9
(2019) 1290. 〈https://www.mdpi.com/2075-4701/9/12/1290〉.
[208] T.D. McLouth, G.E. Bean, D.B. Witkin, S.D. Sitzman, P.M. Adams, D.N. Patel,
W. Park, J.-M. Yang, R.J. Zaldivar, The effect of laser focus shift on
microstructural variation of Inconel 718 produced by selective laser melting,
Mater. Des. 149 (2018) 205–213, https://doi.org/10.1016/j.
matdes.2018.04.019.
[209] W. Tillmann, C. Schaak, J. Nellesen, M. Schaper, M.E. Aydinöz, T. Niendorf,
Functional encapsulation of laser melted Inconel 718 by Arc-PVD and HVOF for
post compacting by hot isostatic pressing, Powder Met. 58 (2015) 259–264,
https://doi.org/10.1179/0032589915Z.000000000250.
[210] G.E. Bean, D.B. Witkin, T.D.McLouth, D.N. Patel, R.J. Zaldivar, Effect of laser
focus shift on surface quality and density of Inconel 718 parts produced via
selective laser melting, Addit. Manuf. 22 (2018) 207–215, https://doi.org/
10.1016/j.addma.2018.04.024.
[211] R. Laquai, B.R. Müller, J.A. Schneider, A. Kupsch, G. Bruno, Using SXRR to Probe
the Nature of Discontinuities in SLM Additive Manufactured Inconel 718
Specimens, Metall. Mater. Trans. A Phys. Metall. Mater. Sci. 51 (2020)
4146–4157, https://doi.org/10.1007/s11661-020-05847-5.
[212] J. Schröder, T. Mishurova, T. Fritsch, I. Serrano-Munoz, A. Evans, M. Sprengel,
M. Klaus, C. Genzel, J. Schneider, G. Bruno, On the influence of heat treatment on
microstructure and mechanical behavior of laser powder bed fused Inconel 718,
Mater. Sci. Eng. A 805 (2021), https://doi.org/10.1016/j.msea.2020.140555.
[213] A. Mostafa, I.P. Rubio, V. Brailovski, M. Jahazi, M. Medraj, Structure, texture and
phases in 3D printed IN718 alloy subjected to homogenization and HIP
treatments, Metals 7 (2017), https://doi.org/10.3390/met7060196.
[214] Y. Cao, P. Bai, F. Liu, X. Hou, Y. Guo, Effect of the solution temperature on the
precipitates and grain evolution of IN718 fabricated by laser additive
manufacturing, Materials 13 (2020), https://doi.org/10.3390/ma13020340.
[215] S. Luo, W. Huang, H. Yang, J. Yang, Z. Wang, X. Zeng, Microstructural evolution
and corrosion behaviors of Inconel 718 alloy produced by selective laser melting
following different heat treatments, Addit. Manuf. 30 (2019), https://doi.org/
10.1016/j.addma.2019.100875.
[216] B. Zhang, M. Xiu, Y.T. Tan, J. Wei, P. Wang, Pitting corrosion of SLM Inconel 718
sample under surface and heat treatments, Appl. Surf. Sci. 490 (2019) 556–567,
https://doi.org/10.1016/j.apsusc.2019.06.043.
[217] Y. Karabulut, E. Tascioglu, Y. Kaynak, Heat treatment temperature-induced
microstructure, microhardness and wear resistance of Inconel 718 produced by
selective laser melting additive manufacturing, Optics 227 (2021), 163907,
https://doi.org/10.1016/j.ijleo.2019.163907.
[218] E.M. Fayed, D. Shahriari, M. Saadati, V. Brailovski, M. Jahazi, M. Medraj,
Influence of homogenization and solution treatments time on the microstructure
and hardness of Inconel 718 fabricated by laser powder bed fusion process,
Materials 13 (2020), https://doi.org/10.3390/ma13112574.
[219] A.A. Popovich, V.S. Sufiiarov, I.A. Polozov, E.V. Borisov, Microstructure and
mechanical properties of Inconel 718 produced by SLM and subsequent heat
treatment, 2015. https://doi.org/10.4028/www.scientific.net/
KEM.651–653.665.
[220] Y. Zhao, Q. Guo, Z. Ma, L. Yu, Comparative study on the microstructure evolution
of selective laser melted and wrought IN718 superalloy during subsequent heat
treatment process and its effect on mechanical properties, Mater. Sci. Eng. A 791
(2020), 139735, https://doi.org/10.1016/j.msea.2020.139735.
[221] N. Kouraytem, R.A. Chanut, D.S. Watring, T. Loveless, J. Varga, A.D. Spear, O.
T. Kingstedt, Dynamic-loading behavior and anisotropic deformation of pre- and
post-heat-treated IN718 fabricated by laser powder bed fusion, Addit. Manuf. 33
(2020), https://doi.org/10.1016/j.addma.2020.101083.
[222] Z. Xu, J.W. Murray, C.J. Hyde, A.T. Clare, Effect of post processing on the creep
performance of laser powder bed fused Inconel 718, Addit. Manuf. 24 (2018)
486–497, https://doi.org/10.1016/j.addma.2018.10.027.
[223] X. Li, J.J. Shi, G.H. Cao, A.M. Russell, Z.J. Zhou, C.P. Li, G.F. Chen, Improved
plasticity of Inconel 718 superalloy fabricated by selective laser melting through a
novel heat treatment process, Mater. Des. 180 (2019), https://doi.org/10.1016/j.
matdes.2019.107915.
[224] G. Marchese, M. Lorusso, S. Parizia, E. Bassini, J.W. Lee, F. Calignano,
D. Manfredi, M. Terner, H.U. Hong, D. Ugues, M. Lombardi, S. Biamino, Influence
of heat treatments on microstructure evolution and mechanical properties of
Inconel 625 processed by laser powder bed fusion, Mater. Sci. Eng. A 729 (2018)
64–75, https://doi.org/10.1016/j.msea.2018.05.044.
[225] G. Marchese, S. Parizia, M. Rashidi, A. Saboori, D. Manfredi, D. Ugues,
M. Lombardi, E. Hryha, S. Biamino, The role of texturing and microstructure
evolution on the tensile behavior of heat-treated Inconel 625 produced via laser
powder bed fusion, Mater. Sci. Eng. A 769 (2020), https://doi.org/10.1016/j.
msea.2019.138500.
[226] A. Kreitcberg, V. Brailovski, S. Turenne, Effect of heat treatment and hot isostatic
pressing on the microstructure and mechanical properties of Inconel 625 alloy
processed by laser powder bed fusion, Mater. Sci. Eng. A 689 (2017) 1–10,
https://doi.org/10.1016/j.msea.2017.02.038.
[227] C. Li, R. White, X.Y. Fang, M. Weaver, Y.B. Guo, Microstructure evolution
characteristics of Inconel 625 alloy from selective laser melting to heat treatment,
Mater. Sci. Eng. A 705 (2017) 20–31, https://doi.org/10.1016/j.
msea.2017.08.058.
[228] G. Marchese, E. Bassini, S. Parizia, D. Manfredi, D. Ugues, M. Lombardi, P. Fino,
S. Biamino, Role of the chemical homogenization on the microstructural and
mechanical evolution of prolonged heat-treated laser powder bed fused Inconel
625, Mater. Sci. Eng. A 796 (2020), 140007, https://doi.org/10.1016/j.
msea.2020.140007.
[229] S. Li, Q. Wei, Y. Shi, C.K. Chua, Z. Zhu, D. Zhang, Microstructure characteristics of
Inconel 625 superalloy manufactured by selective laser melting, J. Mater. Sci.
Technol. 31 (2015) 946–952, https://doi.org/10.1016/j.jmst.2014.09.020.
[230] T. Jokisch, A. Marko, S. Gook, Ö. Üstündag, A. Gumenyuk, M. Rethmeier, Laser
welding of SLM-manufactured tubes, Materials (2019) 1–15.
[231] K. Gola, B. Dubiel, I. Kalemba-Rec, Microstructural changes in Inconel 625 alloy
fabricated by laser-based powder bed fusion process and subjected to high-
temperature annealing, J. Mater. Eng. Perform. 29 (2020) 1528–1534, https://
doi.org/10.1007/s11665-020-04605-3.
[232] D.B. Witkin, T.V. Albright, D.N. Patel, Empirical approach to understanding the
fatigue behavior of metals made using additive manufacturing, Metall. Mater.
Trans. A Phys. Metall. Mater. Sci. 47 (2016) 3823–3836, https://doi.org/
10.1007/s11661-016-3501-z.
[233] K.S. Kim, T.H. Kang, M.E. Kassner, K.T. Son, K.A. Lee, High-temperature tensile
and high cycle fatigue properties of inconel 625 alloy manufactured by laser
powder bed fusion, Addit. Manuf. 35 (2020), 101377, https://doi.org/10.1016/j.
addma.2020.101377.
[234] D.B. Witkin, P. Adams, T. Albright, Microstructural evolution and mechanical
behavior of nickel-based superalloy 625 made by selective laser melting, Proc.
SPIE - Int. Soc. Opt. Eng. (2015), https://doi.org/10.1117/12.2083699.
[235] E.A. Lass, M.R. Stoudt, M.B. Katz, M.E. Williams, Precipitation and dissolution of
δ and γ′′ during heat treatment of a laser powder-bed fusion produced Ni-based
superalloy, Scr. Mater. 154 (2018) 83–86, https://doi.org/10.1016/j.
scriptamat.2018.05.025.
[236] F. Zhang, L.E. Levine, A.J. Allen, M.R. Stoudt, G. Lindwall, E.A. Lass, M.
E. Williams, Y. Idell, C.E. Campbell, Effect of heat treatment on the
microstructural evolution of a nickel-based superalloy additive-manufactured by
laser powder bed fusion, Acta Mater. 152 (2018) 200–214, https://doi.org/
10.1016/j.actamat.2018.03.017.
[237] J. Xu, H. Gruber, R. Boyd, S. Jiang, R.L. Peng, J.J. Moverare, On the strengthening
and embrittlement mechanisms of an additively manufactured nickel-base
superalloy, Materialia 10 (2020), 100657, https://doi.org/10.1016/j.
mtla.2020.100657.
[238] K. Kunze, T. Etter, J. Grässlin, V. Shklover, Texture, anisotropy in microstructure
and mechanical properties of IN738LC alloy processed by selective laser melting
(SLM), Mater. Sci. Eng. A 620 (2015) 213–222, https://doi.org/10.1016/j.
msea.2014.10.003.
[239] O.M.D.M. Messé, R. Muñoz-Moreno, T. Illston, S. Baker, H.J. Stone, Metastable
carbides and their impact on recrystallisation in IN738LCprocessed by selective
laser melting, Addit. Manuf. 22 (2018) 394–404, https://doi.org/10.1016/j.
addma.2018.05.030.
[240] E.A. Jägle, Z. Sheng, L. Wu, L. Lu, J. Risse, A. Weisheit, D. Raabe, Precipitation
reactions in age-hardenable alloys during laser additive manufacturing, JOM 68
(2016) 943–949, https://doi.org/10.1007/s11837-015-1764-2.
G.M. Volpato et al.
https://doi.org/10.1016/j.msea.2019.01.109
https://doi.org/10.1016/j.msea.2019.01.109
https://doi.org/10.1016/j.msea.2018.04.045
https://doi.org/10.1155/2018/7650303
https://doi.org/10.1155/2018/7650303
http://refhub.elsevier.com/S2214-8604(22)00270-6/sbref192
http://refhub.elsevier.com/S2214-8604(22)00270-6/sbref192
http://refhub.elsevier.com/S2214-8604(22)00270-6/sbref192
https://doi.org/10.1007/s11661-018-4870-2
https://doi.org/10.1007/s11661-018-4870-2
https://doi.org/10.1016/j.jmrt.2020.01.030
https://doi.org/10.1016/j.jmrt.2020.01.030
https://doi.org/10.1016/j.jmapro.2019.02.029
https://doi.org/10.1016/j.jmapro.2019.02.029
https://doi.org/10.1007/s00170-018-2850-8
https://doi.org/10.1007/s00170-018-2850-8
https://doi.org/10.1016/j.msea.2018.08.072
https://doi.org/10.1016/j.msea.2018.08.072
https://doi.org/10.1016/j.addma.2020.101404
https://doi.org/10.1016/j.addma.2020.101404
https://doi.org/10.1016/j.addma.2020.101442
https://doi.org/10.1016/j.addma.2020.101442
https://www.mdpi.com/2075-4701/9/12/1290
https://doi.org/10.1016/j.matdes.2018.04.019
https://doi.org/10.1016/j.matdes.2018.04.019
https://doi.org/10.1179/0032589915Z.000000000250
https://doi.org/10.1016/j.addma.2018.04.024
https://doi.org/10.1016/j.addma.2018.04.024
https://doi.org/10.1007/s11661-020-05847-5
https://doi.org/10.1016/j.msea.2020.140555
https://doi.org/10.3390/met7060196
https://doi.org/10.3390/ma13020340
https://doi.org/10.1016/j.addma.2019.100875
https://doi.org/10.1016/j.addma.2019.100875
https://doi.org/10.1016/j.apsusc.2019.06.043
https://doi.org/10.1016/j.ijleo.2019.163907
https://doi.org/10.3390/ma13112574
https://doi.org/10.1016/j.msea.2020.139735
https://doi.org/10.1016/j.addma.2020.101083
https://doi.org/10.1016/j.addma.2018.10.027
https://doi.org/10.1016/j.matdes.2019.107915
https://doi.org/10.1016/j.matdes.2019.107915
https://doi.org/10.1016/j.msea.2018.05.044
https://doi.org/10.1016/j.msea.2019.138500
https://doi.org/10.1016/j.msea.2019.138500
https://doi.org/10.1016/j.msea.2017.02.038
https://doi.org/10.1016/j.msea.2017.08.058
https://doi.org/10.1016/j.msea.2017.08.058
https://doi.org/10.1016/j.msea.2020.140007
https://doi.org/10.1016/j.msea.2020.140007
https://doi.org/10.1016/j.jmst.2014.09.020
http://refhub.elsevier.com/S2214-8604(22)00270-6/sbref222
http://refhub.elsevier.com/S2214-8604(22)00270-6/sbref222
https://doi.org/10.1007/s11665-020-04605-3
https://doi.org/10.1007/s11665-020-04605-3
https://doi.org/10.1007/s11661-016-3501-z
https://doi.org/10.1007/s11661-016-3501-z
https://doi.org/10.1016/j.addma.2020.101377
https://doi.org/10.1016/j.addma.2020.101377
https://doi.org/10.1117/12.2083699
https://doi.org/10.1016/j.scriptamat.2018.05.025
https://doi.org/10.1016/j.scriptamat.2018.05.025
https://doi.org/10.1016/j.actamat.2018.03.017
https://doi.org/10.1016/j.actamat.2018.03.017
https://doi.org/10.1016/j.mtla.2020.100657
https://doi.org/10.1016/j.mtla.2020.100657
https://doi.org/10.1016/j.msea.2014.10.003
https://doi.org/10.1016/j.msea.2014.10.003
https://doi.org/10.1016/j.addma.2018.05.030
https://doi.org/10.1016/j.addma.2018.05.030
https://doi.org/10.1007/s11837-015-1764-2
Additive Manufacturing 55 (2022) 102871
30
[241] Y. Kaynak, E. Tascioglu, Finish machining-induced surface roughness,
microhardness and XRD analysis of selective laser melted Inconel 718 alloy,
Procedia CIRP 71 (2018) 500–504, https://doi.org/10.1016/j.
procir.2018.05.013.
[242] X. Liu, N. Lou, S. Patole, D. Rutman, Y. Wang, J. Shi, Experimental investigation
of micro-machinability of nano-tic reinforced inconel fabricated by direct metal
laser melting , : ASME Int. Mech. Eng. Congr. Expo. Proc., 2015 doi: 10.1115/
IMECE2015-51218.
[243] J. Robl, J. Sedlák, Z. Pokorný, P. Ňuksa, I. Barényi, J. Majerík, Analysis of
advanced additive technology in direct metal laser sintering and precision casting
method, Bull. Pol. Acad. Sci. Tech. Sci. 68 (2020) 109–118, https://doi.org/
10.24425/bpasts.2020.131842.
[244] Y. Li, Z. Zhang, Y. Guan, Thermodynamics analysis and rapid solidification of
laser polished Inconel 718 by selective laser melting, Appl. Surf. Sci. 511 (2020),
145423, https://doi.org/10.1016/j.apsusc.2020.145423.
[245] C. Yu, Z. Huang, Z. Zhang, J. Shen, J. Wang, Z. Xu, Influence of post-processing on
very high cycle fatigue resistance of Inconel 718 obtained with laser powder bed
fusion, Int. J. Fatigue 153 (2021), 106510, https://doi.org/10.1016/j.
ijfatigue.2021.106510.
[246] K. Patel, J. Fei, G. Liu, T. Özel, Milling investigations and yield strength
calculations for nickel alloy Inconel 625 manufactured with laser powder bed
fusion process, Prod. Eng. 13 (2019) 693–702, https://doi.org/10.1007/s11740-
019-00922-2.
[247] D.M. Kim, E. Park, N. Kim, H.W. Park, Experimental investigation on tool wear
during the milling processes for the post-processing of selective laser melted
inconel 718 alloys, in: ASME 2018 13th Int. Manuf. Sci. Eng. Conf. MSEC 2018,
2018. https://doi.org/10.1115/MSEC2018–6561.
[248] C. Tian, X. Li, Z. Liu, G. Zhi, G. Guo, L. Wang, Y. Rong, Study on grindability of
inconel 718 superalloy fabricated by selective laser melting (SLM), J. Mech. Eng.
64 (2018) 319–328, https://doi.org/10.5545/sv-jme.2017.4864.
[249] M.A. Sadiq, N.M. Hoang, N. Valencia, S. Obeidat, W.N.P. Hung, Experimental
study of micromilling selective laser melted Inconel 718 superalloy, Procedia
Manuf. (2018) 983–992, https://doi.org/10.1016/j.promfg.2018.07.129.
[250] H. Ji, M.K. Gupta, Q. Song, W. Cai, T. Zheng, Y. Zhao, Z. Liu, D.Y. Pimenov,
Microstructure and machinability evaluation in micro milling of selective laser
melted Inconel 718 alloy, J. Mater. Res. Technol. 14 (2021) 348–362, https://doi.
org/10.1016/j.jmrt.2021.06.081.
[251] J. Guo, K.H. Au, C.N. Sun, M.H. Goh, C.W. Kum, K. Liu, J. Wei, H. Suzuki,
R. Kang, Novel rotating-vibrating magnetic abrasive polishing method for double-
layered internal surface finishing, J. Mater. Process. Technol. 264 (2019)
422–437, https://doi.org/10.1016/j.jmatprotec.2018.09.024.
[252] U. Ali, H. Fayazfar, F. Ahmed, E. Toyserkani, Internal surface roughness
enhancement of parts made by laser powder-bed fusion additive manufacturing,
Vacuum 177 (2020), https://doi.org/10.1016/j.vacuum.2020.109314.
[253] V. Urlea, V. Brailovski, Electropolishing and electropolishing-related allowances
for IN625 alloy components fabricated by laser powder-bed fusion, Int. J. Adv.
Manuf. Technol. 92 (2017) 4487–4499, https://doi.org/10.1007/s00170-017-
0546-0.
[254] A.P. Nagalingam, S.H. Yeo, Surface finishing of additively manufactured Inconel
625 complex internal channels: a case study using a multi-jet hydrodynamic
approach, Addit. Manuf. 36 (2020), 101428, https://doi.org/10.1016/j.
addma.2020.101428.
[255] E. De Meter, K.H. Chow, E. Marsh, Methodology of using PAAW and the
underlying support network of an L-PBF part to facilitate machining, Procedia
Manuf. 34 (2019) 463–474, https://doi.org/10.1016/j.promfg.2019.06.199.
[256] V. Tripathi, A. Armstrong, X. Gong, G. Manogharan, T. Simpson, E. De Meter,
Milling of Inconel 718 block supports fabricated using laser powder bed fusion,
J. Manuf. Process. 34 (2018) 740–749, https://doi.org/10.1016/j.
jmapro.2018.03.046.
[257] C.S. Lefky, T.G. Gallmeyer, S. Moorthy, A. Stebner, O.J. Hildreth, Microstructure
and corrosion properties of sensitized laser powder bed fusion printed Inconel 718
to dissolvesupport structures in a self-terminating manner, Addit. Manuf. 27
(2019) 526–532, https://doi.org/10.1016/j.addma.2019.03.020.
[258] C.U. Brown, G. Jacob, M. Stoudt, S. Moylan, J. Slotwinski, A. Donmez,
Interlaboratory study for nickel alloy 625 made by laser powder bed fusion to
quantify mechanical property variability, J. Mater. Eng. Perform. 25 (2016)
3390–3397, https://doi.org/10.1007/s11665-016-2169-2.
[259] H. Hack, R. Link, E. Knudsen, B. Baker, S. Olig, Mechanical properties of additive
manufactured nickel alloy 625, Addit. Manuf. 14 (2017) 105–115, https://doi.
org/10.1016/j.addma.2017.02.004.
[260] L. Rickenbacher, T. Etter, S. Hövel, K. Wegener, High temperature material
properties of IN738LC processed by selective laser melting (SLM), Technol. Rapid
Prototyp. J. 19 (2013) 282–290, https://doi.org/10.1108/13552541311323281.
[261] V.A. Popovich, E.V. Borisov, A.A. Popovich, V.S. Sufiiarov, D.V. Masaylo,
L. Alzina, Functionally graded Inconel 718 processed by additive manufacturing:
crystallographic texture, anisotropy of microstructure and mechanical properties,
Mater. Des. 114 (2017) 441–449, https://doi.org/10.1016/j.
matdes.2016.10.075.
[262] X.-A. Hu, G.-L. Zhao, F.-C. Liu, W.-X. Liu, Microstructure and mechanical behavior
of Inconel 625 alloy processed by selective laser melting at high temperature up
to 1000 ◦C, Rare Met. (2019), https://doi.org/10.1007/s12598-019-01321-3.
[263] J. Nguejio, F. Szmytka, S. Hallais, A. Tanguy, S. Nardone, M. Godino Martinez,
Comparison of microstructure features and mechanical properties for additive
manufactured and wrought nickel alloys 625, Mater. Sci. Eng. A 764 (2019),
138214, https://doi.org/10.1016/j.msea.2019.138214.
[264] Z. Wang, K. Guan, M. Gao, X. Li, X. Chen, X. Zeng, The microstructure and
mechanical properties of deposited-IN718 by selective laser melting, J. Alloy.
Compd. 513 (2012) 518–523, https://doi.org/10.1016/j.jallcom.2011.10.107.
[265] C. Pei, W. Zeng, H. Yuan, A damage evolution model based on micro-structural
characteristics for an additive manufactured superalloy under monotonic and
cyclic loading conditions, Int. J. Fatigue 131 (2020), https://doi.org/10.1016/j.
ijfatigue.2019.105279.
[266] X.-A. Hu, G.-L. Zhao, Y. Jiang, X.-F. Ma, F.-C. Liu, J. Huang, C.-L. Dong,
Experimental investigation on the LCF behavior affected by manufacturing
defects and creep damage of one selective laser melting nickel-based superalloy at
815 ◦C, Acta Metall. Sin. 33 (2020) 514–527, https://doi.org/10.1007/s40195-
019-00986-0.
[267] T. Trosch, J. Strößner, R. Völkl, U. Glatzel, Microstructure and mechanical
properties of selective laser melted Inconel 718 compared to forging and casting,
Mater. Lett. 164 (2016) 428–431, https://doi.org/10.1016/j.matlet.2015.10.136.
[268] J.-R. Poulin, A. Kreitcberg, P. Terriault, V. Brailovski, Long fatigue crack
propagation behavior of laser powder bed-fused inconel 625 with intentionally-
seeded porosity, Int. J. Fatigue 127 (2019) 144–156, https://doi.org/10.1016/j.
ijfatigue.2019.06.008.
[269] D. Zhang, Z. Feng, C. Wang, W. Wang, Z. Liu, W. Niu, Comparison of
microstructures and mechanical properties of Inconel 718 alloy processed by
selective laser melting and casting, Mater. Sci. Eng. A 724 (2018) 357–367,
https://doi.org/10.1016/j.msea.2018.03.073.
[270] H. Wong, K. Dawson, G.A. Ravi, L. Howlett, R.O. Jones, C.J. Sutcliffe, Multi-laser
powder bed fusion benchmarking—initial trials with Inconel 625, Int. J. Adv.
Manuf. Technol. 105 (2019) 2891–2906, https://doi.org/10.1007/s00170-019-
04417-3.
[271] T. Brynk, Z. Pakiela, K. Ludwichowska, B. Romelczyk, R.M. Molak, M. Plocinska,
J. Kurzac, T. Kurzynowski, E. Chlebus, Fatigue crack growth rate and tensile
strength of Re modified Inconel 718 produced by means of selective laser melting,
Mater. Sci. Eng. A 698 (2017) 289–301, https://doi.org/10.1016/j.
msea.2017.05.052.
[272] J. Xu, H. Gruber, D. Deng, R.L. Peng, J.J. Moverare, Short-term creep behavior of
an additive manufactured non-weldable Nickel-base superalloy evaluated by slow
strain rate testing, Acta Mater. 179 (2019) 142–157, https://doi.org/10.1016/j.
actamat.2019.08.034.
[273] M.D. Sangid, T.A. Book, D. Naragani, J. Rotella, P. Ravi, A. Finch, P. Kenesei, J.
S. Park, H. Sharma, J. Almer, X. Xiao, Role of heat treatment and build orientation
in the microstructure sensitive deformation characteristics of IN718 produced via
SLM additive manufacturing, Addit. Manuf. 22 (2018) 479–496, https://doi.org/
10.1016/j.addma.2018.04.032.
[274] B. Diepold, M.S. Palm, A. Wimmer, T. Sebald, H.W. Höppel, S. Neumeier,
M. Göken, Rotating scan strategy induced anisotropic microstructural and
mechanical behavior of selective laser melted materials and their reduction by
heat treatments, Adv. Eng. Mater. (2021), https://doi.org/10.1002/
adem.202100622.
[275] A. Yadollahi, M.J. Mahtabi, A. Khalili, H.R. Doude, J.C. Newman, Fatigue life
prediction of additively manufactured material: Effects of surface roughness,
defect size, and shape, Fatigue Fract. Eng. Mater. Struct. 41 (2018) 1602–1614,
https://doi.org/10.1111/ffe.12799.
[276] O. Scott-Emuakpor, J. Schwartz, T. George, C. Holycross, C. Cross, J. Slater,
Bending fatigue life characterisation of direct metal laser sintering nickel alloy
718, Fatigue Fract. Eng. Mater. Struct. 38 (2015) 1105–1117, https://doi.org/
10.1111/ffe.12286.
[277] F. Caiazzo, V. Alfieri, G. Corrado, P. Argenio, Laser powder-bed fusion of Inconel
718 to manufacture turbine blades, Int. J. Adv. Manuf. Technol. 93 (2017)
4023–4031, https://doi.org/10.1007/s00170-017-0839-3.
[278] M. Cloots, K. Kunze, P.J. Uggowitzer, K. Wegener, Microstructural characteristics
of the nickel-based alloy IN738LC and the cobalt-based alloy Mar-M509 produced
by selective laser melting, Mater. Sci. Eng. A 658 (2016) 68–76, https://doi.org/
10.1016/j.msea.2016.01.058.
[279] A. Rezaei, A. Rezaeian, A. Kermanpur, M. Badrossamay, E. Foroozmehr,
M. Marashi, A. Foroozmehr, J. Han, Microstructural and mechanical anisotropy of
selective laser melted IN718 superalloy at room and high temperatures using
small punch test, Mater. Charact. 162 (2020), https://doi.org/10.1016/j.
matchar.2020.110200.
[280] Q. Teng, S. Li, Q. Wei, Y. Shi, Investigation on the influence of heat treatment on
Inconel 718 fabricated by selective laser melting: Microstructure and high
temperature tensile property, J. Manuf. Process. 61 (2021) 35–45, https://doi.
org/10.1016/j.jmapro.2020.11.002.
[281] S. Zhang, X. Lin, L. Wang, X. Yu, Y. Hu, H. Yang, L. Lei, W. Huang, Strengthening
mechanisms in selective laser-melted Inconel718 superalloy, Mater. Sci. Eng. A
812 (2021), 141145, https://doi.org/10.1016/j.msea.2021.141145.
[282] S. Qin, T.C. Novak, M.K. Vailhe, Z.K. Liu, A.M. Beese, Plasticity and fracture
behavior of Inconel 625 manufactured by laser powder bed fusion: comparison
between as-built and stress relieved conditions, Mater. Sci. Eng. A 806 (2021),
140808, https://doi.org/10.1016/j.msea.2021.140808.
[283] B. Madejski, M. Malicki, S. Czarnewicz, K. Gruber, Microstructural and
mechanical properties of selective laser melted Inconel 718 for different specimen
sizes, Fatigue Aircr. Struct. 2020 (2020) 15–26, https://doi.org/10.2478/fas-
2020-0002.
[284] P. Pant, S. Proper, V. Luzin, S. Sjöström, K. Simonsson, J. Moverare, S. Hosseini,
V. Pacheco, R.L. Peng, Mapping of residual stresses in as-built Inconel 718
fabricated by laser powder bed fusion: a neutron diffraction study of build
orientation influence on residual stresses, Addit. Manuf. 36 (2020), 101501,
https://doi.org/10.1016/j.addma.2020.101501.
G.M. Volpato et al.
https://doi.org/10.1016/j.procir.2018.05.013
https://doi.org/10.1016/j.procir.2018.05.013https://doi.org/10.24425/bpasts.2020.131842
https://doi.org/10.24425/bpasts.2020.131842
https://doi.org/10.1016/j.apsusc.2020.145423
https://doi.org/10.1016/j.ijfatigue.2021.106510
https://doi.org/10.1016/j.ijfatigue.2021.106510
https://doi.org/10.1007/s11740-019-00922-2
https://doi.org/10.1007/s11740-019-00922-2
https://doi.org/10.5545/sv-jme.2017.4864
https://doi.org/10.1016/j.promfg.2018.07.129
https://doi.org/10.1016/j.jmrt.2021.06.081
https://doi.org/10.1016/j.jmrt.2021.06.081
https://doi.org/10.1016/j.jmatprotec.2018.09.024
https://doi.org/10.1016/j.vacuum.2020.109314
https://doi.org/10.1007/s00170-017-0546-0
https://doi.org/10.1007/s00170-017-0546-0
https://doi.org/10.1016/j.addma.2020.101428
https://doi.org/10.1016/j.addma.2020.101428
https://doi.org/10.1016/j.promfg.2019.06.199
https://doi.org/10.1016/j.jmapro.2018.03.046
https://doi.org/10.1016/j.jmapro.2018.03.046
https://doi.org/10.1016/j.addma.2019.03.020
https://doi.org/10.1007/s11665-016-2169-2
https://doi.org/10.1016/j.addma.2017.02.004
https://doi.org/10.1016/j.addma.2017.02.004
https://doi.org/10.1108/13552541311323281
https://doi.org/10.1016/j.matdes.2016.10.075
https://doi.org/10.1016/j.matdes.2016.10.075
https://doi.org/10.1007/s12598-019-01321-3
https://doi.org/10.1016/j.msea.2019.138214
https://doi.org/10.1016/j.jallcom.2011.10.107
https://doi.org/10.1016/j.ijfatigue.2019.105279
https://doi.org/10.1016/j.ijfatigue.2019.105279
https://doi.org/10.1007/s40195-019-00986-0
https://doi.org/10.1007/s40195-019-00986-0
https://doi.org/10.1016/j.matlet.2015.10.136
https://doi.org/10.1016/j.ijfatigue.2019.06.008
https://doi.org/10.1016/j.ijfatigue.2019.06.008
https://doi.org/10.1016/j.msea.2018.03.073
https://doi.org/10.1007/s00170-019-04417-3
https://doi.org/10.1007/s00170-019-04417-3
https://doi.org/10.1016/j.msea.2017.05.052
https://doi.org/10.1016/j.msea.2017.05.052
https://doi.org/10.1016/j.actamat.2019.08.034
https://doi.org/10.1016/j.actamat.2019.08.034
https://doi.org/10.1016/j.addma.2018.04.032
https://doi.org/10.1016/j.addma.2018.04.032
https://doi.org/10.1002/adem.202100622
https://doi.org/10.1002/adem.202100622
https://doi.org/10.1111/ffe.12799
https://doi.org/10.1111/ffe.12286
https://doi.org/10.1111/ffe.12286
https://doi.org/10.1007/s00170-017-0839-3
https://doi.org/10.1016/j.msea.2016.01.058
https://doi.org/10.1016/j.msea.2016.01.058
https://doi.org/10.1016/j.matchar.2020.110200
https://doi.org/10.1016/j.matchar.2020.110200
https://doi.org/10.1016/j.jmapro.2020.11.002
https://doi.org/10.1016/j.jmapro.2020.11.002
https://doi.org/10.1016/j.msea.2021.141145
https://doi.org/10.1016/j.msea.2021.140808
https://doi.org/10.2478/fas-2020-0002
https://doi.org/10.2478/fas-2020-0002
https://doi.org/10.1016/j.addma.2020.101501
Additive Manufacturing 55 (2022) 102871
31
[285] S. Gribbin, J. Bicknell, L. Jorgensen, I. Tsukrov, M. Knezevic, Low cycle fatigue
behavior of direct metal laser sintered Inconel alloy 718, Int. J. Fatigue 93 (2016)
156–167, https://doi.org/10.1016/j.ijfatigue.2016.08.019.
[286] V.P. Sabelkin, G.R. Cobb, B.M. Doane, R.A. Kemnitz, R.P. O’Hara, Torsional
behavior of additively manufactured nickel alloy 718 under monotonic loading
and low cycle fatigue, Mater. Today Commun. 24 (2020), 101256, https://doi.
org/10.1016/j.mtcomm.2020.101256.
[287] S.F. Siddiqui, A.P. Gordon, Cyclic shear response of additively manufactured
Inconel 718, Rapid Prototyp. J. 26 (2020) 1237–1248, https://doi.org/10.1108/
RPJ-09-2018-0243.
[288] M. Salarian, H. Asgari, M. Vlasea, Pore space characteristics and corresponding
effect on tensile properties of Inconel 625 fabricated via laser powder bed fusion,
Mater. Sci. Eng. A 769 (2020), 138525, https://doi.org/10.1016/j.
msea.2019.138525.
[289] M. Valdez, C. Kozuch, E.J. Faierson, I. Jasiuk, Induced porosity in super alloy 718
through the laser additive manufacturing process: Microstructure and mechanical
properties, J. Alloy. Compd. 725 (2017) 757–764, https://doi.org/10.1016/j.
jallcom.2017.07.198.
[290] B. Zhang, P. Wang, Y. Chew, Y. Wen, M. Zhang, P. Wang, G. Bi, J. Wei,
Mechanical properties and microstructure evolution of selective laser melting
Inconel 718 along building direction and sectional dimension, Mater. Sci. Eng. A
794 (2020), 139941, https://doi.org/10.1016/j.msea.2020.139941.
[291] C. Guo, Z. Yu, C. Liu, X. Li, Q. Zhu, R. Mark Ward, Effects of Y2O3 nanoparticles
on the high-temperature oxidation behavior of IN738LC manufactured by laser
powder bed fusion, Corros. Sci. 171 (2020), 108715, https://doi.org/10.1016/j.
corsci.2020.108715.
[292] Q.B. Nguyen, M.L.S. Nai, Z. Zhu, C.-N. Sun, J. Wei, W. Zhou, Characteristics of
inconel powders for powder-bed additive manufacturing, Engineering 3 (2017)
695–700, https://doi.org/10.1016/J.ENG.2017.05.012.
[293] M. Xia, D. Gu, C. Ma, H. Chen, H. Zhang, Microstructure evolution, mechanical
response and underlying thermodynamic mechanism of multi-phase
strengthening WC/Inconel 718 composites using selective laser melting, J. Alloy.
Compd. 747 (2018) 684–695, https://doi.org/10.1016/j.jallcom.2018.03.049.
[294] T. Kurzynowski, K. Gruber, E. Chlebus, The use of selective laser melting as a
method of new materials development, 2019. https://doi.org/10.1007/978–3-
030–04975-1_47.
[295] Z.H. Zhang, Y.H. Zhou, S.Y. Zhou, L. Zhang, M. Yan, Mechanically blended Al:
simple but effective approach to improving mechanical property and thermal
stability of selective laser-melted Inconel 718, Metall. Mater. Trans. A Phys.
Metall. Mater. Sci. 50 (2019) 3922–3936, https://doi.org/10.1007/s11661-019-
05299-6.
[296] R. Sitek, R. Molak, J. Zdunek, P. Bazarnik, P. Wísniewski, K. Kubiak, J. Mizera,
Influence of an aluminizing process on the microstructure and tensile strength of
the nickel superalloy IN 718 produced by the Selective laser melting, Vacuum 186
(2021), https://doi.org/10.1016/j.vacuum.2020.110041.
[297] Q.B. Nguyen, Z. Zhu, B.W. Chua, W. Zhou, J. Wei, S.M.L. Nai, Development of
WC-Inconel composites using selective laser melting, Arch. Civ. Mech. Eng. 18
(2018) 1410–1420, https://doi.org/10.1016/j.acme.2018.05.001.
[298] H. Zhang, D. Gu, C. Ma, M. Guo, J. Yang, R. Wang, Effect of post heat treatment
on microstructure and mechanical properties of Ni-based composites by selective
laser melting, Mater. Sci. Eng. A 765 (2019), https://doi.org/10.1016/j.
msea.2019.138294.
[299] Y. Wang, X. Wang, J. Shi, Y. Wang, In situ AFM characterization of deformation
behavior of nano TiC reinforced Inconel 718 superalloy prepared by selective
laser melting, ASME Int. Mech. Eng. Congr. Expo. Proc. 2B-2015, 2015, pp. 1–8
doi: 10.1115/IMECE2015-52426.
[300] Y. Wang, J. Shi, S. Lu, Y. Wang, Selective laser melting of graphene-reinforced
Inconel 718 superalloy: evaluation of microstructure and tensile performance,
J. Manuf. Sci. Eng. Trans (2017), https://doi.org/10.1115/1.4034712.
[301] A. El Hassanin, F. Scherillo, U. Prisco, R. Sansone, A. Astarita, Selective laser
melting of Cu-inconel 718 powder mixtures, J. Manuf. Process. 59 (2020)
679–689, https://doi.org/10.1016/j.jmapro.2020.10.039.
[302] J.-R. Zhao, F.-Y. Hung, T.-S. Lui, Erosion resistance and particle erosion-induced
tensile embrittlement of 3D-selective laser melting Inconel 718 superalloy, Metals
10 (2019) 21, https://doi.org/10.3390/met10010021.
[303] Z. Baicheng, L. Xiaohua, B. Jiaming, G. Junfeng, W. Pan, S. Chen-nan, N. Muiling,
Q. Guojun, W. Jun, Study of selective laser melting (SLM) Inconel 718 part
surface improvement by electrochemical polishing, Mater. Des. 116 (2017)
531–537, https://doi.org/10.1016/j.matdes.2016.11.103.
[304] G. Marchese, E. Bassini, M. Calandri, E.P. Ambrosio, F. Calignano, M. Lorusso,
D. Manfredi, M. Pavese, S. Biamino, P. Fino, Microstructural investigation of as-
fabricated and heat-treated Inconel 625 and Inconel 718 fabricated by direct
metal laser sintering: contribution of Politecnico di Torino and Istituto Italiano di
Tecnologia (IIT) di Torino, Met. Powder Rep. 71(2016) 273–278, https://doi.
org/10.1016/j.mprp.2016.06.002.
[305] X. Wang, T. Keya, K. Chou, Build height effect on the Inconel 718 parts fabricated
by selective laser melting, Procedia Manuf. 5 (2016) 1006–1017, https://doi.org/
10.1016/j.promfg.2016.08.089.
[306] K.S. Mukhtarova, R.V. Shakhov, V.V. Smirnov, S.K. Mukhtarov, Microstructure
and microhardness studies of Inconel 718, manufactured by selective laser
melting and subjected to severe plastic deformation and annealing, IOP Conf. Ser.
Mater. Sci. Eng. (2019), https://doi.org/10.1088/1757-899X/672/1/012049.
[307] G.C. Mondragón-Rodríguez, N. Torres-Padilla, N. Camacho, D.G. Espinosa-
Arbeláez, G.V. de León-Nope, J.M. González-Carmona, J.M. Alvarado-Orozco,
Surface modification and tribological behavior of plasma nitrided Inconel 718
manufactured via direct melting laser sintering method, Surf. Coat. Technol. 387
(2020), https://doi.org/10.1016/j.surfcoat.2020.125526.
[308] S.H. Kim, G.-H. Shin, B.-K. Kim, K.T. Kim, D.-Y. Yang, C. Aranas, J.-P. Choi, J.-
H. Yu, Thermo-mechanical improvement of Inconel 718 using ex situ boron
nitride-reinforced composites processed by laser powder bed fusion, Sci. Rep. 7
(2017), https://doi.org/10.1038/s41598-017-14713-1.
[309] J.P. Choi, G.H. Shin, S. Yang, D.Y. Yang, J.S. Lee, M. Brochu, J.H. Yu,
Densification and microstructural investigation of Inconel 718 parts fabricated by
selective laser melting, Powder Technol. 310 (2017) 60–66, https://doi.org/
10.1016/j.powtec.2017.01.030.
[310] S. Holland, X. Wang, J. Chen, W. Cai, F. Yan, L. Li, Multiscale characterization of
microstructures and mechanical properties of Inconel 718 fabricated by selective
laser melting, J. Alloy. Compd. 784 (2019) 182–194, https://doi.org/10.1016/j.
jallcom.2018.12.380.
[311] S. Feng, J.H. Gong, H. Li, H. Wang, Microstructural investigation of Inconel718
manufactured by SLM, IOP Conf. Ser. Mater. Sci. Eng. 452 (2018), https://doi.
org/10.1088/1757-899X/452/2/022088.
[312] X. Wang, K. Chou, The effects of stress relieving heat treatment on the
microstructure and residual stress of Inconel 718 fabricated by laser metal
powder bed fusion additive manufacturing process, J. Manuf. Process. 48 (2019)
154–163, https://doi.org/10.1016/j.jmapro.2019.10.027.
[313] C. Pleass, S. Jothi, Influence of powder characteristics and additive manufacturing
process parameters on the microstructure and mechanical behaviour of Inconel
625 fabricated by selective laser melting, Addit. Manuf. 24 (2018) 419–431,
https://doi.org/10.1016/j.addma.2018.09.023.
[314] S.M. Zaharia, L.A. Chicoș, C. Lancea, M.A. Pop, Effects of homogenization heat
treatment on mechanical properties of inconel 718 sandwich structures
manufactured by selective laser melting, Metals 10 (2020) 13–16, https://doi.
org/10.3390/met10050645.
[315] L. Huang, Y. Cao, G. Li, Y. Wang, Microstructure characteristics and mechanical
behaviour of a selective laser melted Inconel 718 alloy, J. Mater. Res. Technol. 9
(2020) 2440–2454, https://doi.org/10.1016/j.jmrt.2019.12.075.
[316] D.A. Lesyk, S. Martinez, B.N. Mordyuk, V.V. Dzhemelinskyi, G.I. Lamikiz,
Prokopenko, Post-processing of the Inconel 718 alloy parts fabricated by selective
laser melting: effects of mechanical surface treatments on surface topography,
porosity, hardness and residual stress, Surf. Coat. Technol. 381 (2020), 125136,
https://doi.org/10.1016/j.surfcoat.2019.125136.
[317] L. Chen, Y. Sun, L. Li, X. Ren, Microstructural evolution and mechanical
properties of selective laser melted a nickel-based superalloy after post treatment,
Mater. Sci. Eng. A 792 (2020), 139649, https://doi.org/10.1016/j.
msea.2020.139649.
[318] L. Chen, Y. Sun, L. Li, X. Ren, Improvement of high temperature oxidation
resistance of additively manufactured TiC/Inconel 625 nanocomposites by laser
shock peening treatment, Addit. Manuf. 34 (2020), 101276, https://doi.org/
10.1016/j.addma.2020.101276.
[319] P. Liu, S. Sun, M. Cao, J. Gong, J. Hu, Microstructural evolution and phase
transformation on the X-Y surface of Inconel 718 Ni-based alloys fabricated by
selective laser melting under different heat treatment, High Temp. Mater. Process
38 (2019) 229–236, https://doi.org/10.1515/htmp-2017-0182.
[320] S. Kim, H. Choi, J. Lee, S. Kim, Room and elevated temperature fatigue crack
propagation behavior of Inconel 718 alloy fabricated by laser powder bed fusion,
Int. J. Fatigue 140 (2020), 105802, https://doi.org/10.1016/j.
ijfatigue.2020.105802.
[321] K. Yang, Q. Huang, Q. Wang, Q. Chen, Competing crack initiation behaviors of a
laser additively manufactured nickel-based superalloy in high and very high cycle
fatigue regimes, Int. J. Fatigue 136 (2020), 105580, https://doi.org/10.1016/j.
ijfatigue.2020.105580.
[322] D.B. Witkin, D.N. Patel, G.E. Bean, Notched fatigue testing of Inconel 718
prepared by selective laser melting, Fatigue Fract. Eng. Mater. Struct. 42 (2019)
166–177, https://doi.org/10.1111/ffe.12880.
[323] D.B. Witkin, D.N. Patel, H. Helvajian, L. Steffeney, A. Diaz, Surface treatment of
powder-bed fusion additive manufactured metals for improved fatigue life,
J. Mater. Eng. Perform. 28 (2019) 681–692, https://doi.org/10.1007/s11665-
018-3732-9.
[324] R. Konečná, L. Kunz, G. Nicoletto, A. Bača, Long fatigue crack growth in Inconel
718 produced by selective laser melting, Int. J. Fatigue 92 (2016) 499–506,
https://doi.org/10.1016/j.ijfatigue.2016.03.012.
[325] R. Konecná, L. Kunz, G. Nicoletto, A. Baca, Fatigue crack growth behavior of
Inconel 718 produced by selective laser melting, Frat. Ed. Integrità Strutt. 10
(2015) 31–40, https://doi.org/10.3221/IGF-ESIS.35.04.
[326] G. Nicoletto, A novel test method for the fatigue characterization of metal powder
bed fused alloys, Procedia Struct. Integr. (2017) 67–74, https://doi.org/10.1016/
j.prostr.2017.11.062.
[327] G. Nicoletto, Smooth and notch fatigue behavior of selectively laser melted
Inconel 718 with as-built surfaces, Int. J. Fatigue 128 (2019), https://doi.org/
10.1016/j.ijfatigue.2019.105211.
[328] R. Konečná, G. Nicoletto, E. Riva, Notch fatigue behavior of Inconel 718 produced
by selective laser melting, Procedia Struct. Integr. 17 (2019) 138–145, https://
doi.org/10.1016/j.prostr.2019.08.019.
[329] R. Konečná, G. Nicoletto, L. Kunz, A. Bača, Microstructure and directional fatigue
behavior of Inconel 718 produced by selective laser melting, Procedia Struct.
Integr. 2 (2016) 2381–2388, https://doi.org/10.1016/j.prostr.2016.06.298.
[330] K. Solberg, F. Berto, Notch-defect interaction in additively manufactured Inconel
718, Int. J. Fatigue 122 (2019) 35–45, https://doi.org/10.1016/j.
ijfatigue.2018.12.021.
G.M. Volpato et al.
https://doi.org/10.1016/j.ijfatigue.2016.08.019
https://doi.org/10.1016/j.mtcomm.2020.101256
https://doi.org/10.1016/j.mtcomm.2020.101256
https://doi.org/10.1108/RPJ-09-2018-0243
https://doi.org/10.1108/RPJ-09-2018-0243
https://doi.org/10.1016/j.msea.2019.138525
https://doi.org/10.1016/j.msea.2019.138525
https://doi.org/10.1016/j.jallcom.2017.07.198
https://doi.org/10.1016/j.jallcom.2017.07.198
https://doi.org/10.1016/j.msea.2020.139941
https://doi.org/10.1016/j.corsci.2020.108715
https://doi.org/10.1016/j.corsci.2020.108715
https://doi.org/10.1016/J.ENG.2017.05.012
https://doi.org/10.1016/j.jallcom.2018.03.049
https://doi.org/10.1007/s11661-019-05299-6
https://doi.org/10.1007/s11661-019-05299-6
https://doi.org/10.1016/j.vacuum.2020.110041
https://doi.org/10.1016/j.acme.2018.05.001
https://doi.org/10.1016/j.msea.2019.138294
https://doi.org/10.1016/j.msea.2019.138294
https://doi.org/10.1115/1.4034712
https://doi.org/10.1016/j.jmapro.2020.10.039
https://doi.org/10.3390/met10010021
https://doi.org/10.1016/j.matdes.2016.11.103https://doi.org/10.1016/j.mprp.2016.06.002
https://doi.org/10.1016/j.mprp.2016.06.002
https://doi.org/10.1016/j.promfg.2016.08.089
https://doi.org/10.1016/j.promfg.2016.08.089
https://doi.org/10.1088/1757-899X/672/1/012049
https://doi.org/10.1016/j.surfcoat.2020.125526
https://doi.org/10.1038/s41598-017-14713-1
https://doi.org/10.1016/j.powtec.2017.01.030
https://doi.org/10.1016/j.powtec.2017.01.030
https://doi.org/10.1016/j.jallcom.2018.12.380
https://doi.org/10.1016/j.jallcom.2018.12.380
https://doi.org/10.1088/1757-899X/452/2/022088
https://doi.org/10.1088/1757-899X/452/2/022088
https://doi.org/10.1016/j.jmapro.2019.10.027
https://doi.org/10.1016/j.addma.2018.09.023
https://doi.org/10.3390/met10050645
https://doi.org/10.3390/met10050645
https://doi.org/10.1016/j.jmrt.2019.12.075
https://doi.org/10.1016/j.surfcoat.2019.125136
https://doi.org/10.1016/j.msea.2020.139649
https://doi.org/10.1016/j.msea.2020.139649
https://doi.org/10.1016/j.addma.2020.101276
https://doi.org/10.1016/j.addma.2020.101276
https://doi.org/10.1515/htmp-2017-0182
https://doi.org/10.1016/j.ijfatigue.2020.105802
https://doi.org/10.1016/j.ijfatigue.2020.105802
https://doi.org/10.1016/j.ijfatigue.2020.105580
https://doi.org/10.1016/j.ijfatigue.2020.105580
https://doi.org/10.1111/ffe.12880
https://doi.org/10.1007/s11665-018-3732-9
https://doi.org/10.1007/s11665-018-3732-9
https://doi.org/10.1016/j.ijfatigue.2016.03.012
https://doi.org/10.3221/IGF-ESIS.35.04
https://doi.org/10.1016/j.prostr.2017.11.062
https://doi.org/10.1016/j.prostr.2017.11.062
https://doi.org/10.1016/j.ijfatigue.2019.105211
https://doi.org/10.1016/j.ijfatigue.2019.105211
https://doi.org/10.1016/j.prostr.2019.08.019
https://doi.org/10.1016/j.prostr.2019.08.019
https://doi.org/10.1016/j.prostr.2016.06.298
https://doi.org/10.1016/j.ijfatigue.2018.12.021
https://doi.org/10.1016/j.ijfatigue.2018.12.021
Additive Manufacturing 55 (2022) 102871
32
[331] Z. Zhou, X. Hua, C. Li, G. Chen, The effect of texture on the low cycle fatigue
property of Inconel 718 by selective laser melting MATEC Web Conf., 2018 doi:
10.1051/matecconf/201816502007.
[332] Z.Y. Xue, Experiment and simulation of fatigue crack growth of SLM nickel base
superalloy with different stress ratios and building directions, IOP Conf. Ser.
Mater. Sci. Eng. (2019), https://doi.org/10.1088/1757-899X/490/3/032036.
[333] X. Hu, Z. Xue, T.T. Ren, Y. Jiang, C.L. Dong, F. Liu, On the fatigue crack growth
behaviour of selective laser melting fabricated Inconel 625: Effects of build
orientation and stress ratio, Fatigue Fract. Eng. Mater. Struct. 43 (2020) 771–787,
https://doi.org/10.1111/ffe.13181.
[334] X.F. Ma, H.L. Zhai, L. Zuo, W.J. Zhang, S.S. Rui, Q.N. Han, J.S. Jiang, C.P. Li, G.
F. Chen, G.A. Qian, S.J. Zhao, Fatigue short crack propagation behavior of
selective laser melted Inconel 718 alloy by in-situ SEM study: Influence of
orientation and temperature, Int. J. Fatigue 139 (2020), https://doi.org/10.1016/
j.ijfatigue.2020.105739.
[335] D. Ren, Z. Xue, Y. Jiang, X. Hu, Y. Zhang, Influence of single tensile overload on
fatigue crack propagation behavior of the selective laser melting inconel 625
superalloy, Eng. Fract. Mech. 239 (2020), 107305, https://doi.org/10.1016/j.
engfracmech.2020.107305.
[336] D.B. Witkin, D. Patel, T.V. Albright, G.E. Bean, T. McLouth, Influence of surface
conditions and specimen orientation on high cycle fatigue properties of Inconel
718 prepared by laser powder bed fusion, Int. J. Fatigue 132 (2020), https://doi.
org/10.1016/j.ijfatigue.2019.105392.
[337] Y. Yamashita, T. Murakami, R. Mihara, M. Okada, Y. Murakami, Defect analysis
and fatigue design basis for Ni-based superalloy 718 manufactured by selective
laser melting, Int. J. Fatigue 117 (2018) 485–495, https://doi.org/10.1016/j.
ijfatigue.2018.08.002.
[338] L. Sheridan, J.E. Gockel, O.E. Scott-Emuakpor, Stress-defect-life interactions of
fatigued additively manufactured alloy 718, Int. J. Fatigue 143 (2021), 106033,
https://doi.org/10.1016/j.ijfatigue.2020.106033.
[339] J.-R. Poulin, A. Kreitcberg, P. Terriault, V. Brailovski, Fatigue strength prediction
of laser powder bed fusion processed Inconel 625 specimens with intentionally-
seeded porosity: feasibility study, Int. J. Fatigue 132 (2020), https://doi.org/
10.1016/j.ijfatigue.2019.105394.
[340] H.Y. Wan, Y.W. Luo, B. Zhang, Z.M. Song, L.Y. Wang, Z.J. Zhou, C.P. Li, G.
F. Chen, G.P. Zhang, Effects of surface roughness and build thickness on fatigue
properties of selective laser melted Inconel 718 at 650 ◦C, Int. J. Fatigue 137
(2020), https://doi.org/10.1016/j.ijfatigue.2020.105654.
[341] V. Prithivirajan, M.D. Sangid, The role of defects and critical pore size analysis in
the fatigue response of additively manufactured IN718 via crystal plasticity,
Mater. Des. 150 (2018) 139–153, https://doi.org/10.1016/j.
matdes.2018.04.022.
[342] F.S. Golinveaux, K.B. Rivera, J.I. Rome, Z.T. Kier, C.N. Sagrillo, V.K. Goyal, C.S.
Lynch, Fracture fatigue properties of inconel 718 manufactured with selective
laser melting AIAA Scitech 2019 Forum 2019 doi: 10.2514/6.2019-1967.
[343] V. Prithivirajan, P. Ravi, D. Naragani, M.D. Sangid, Direct comparison of
microstructure-sensitive fatigue crack initiation via crystal plasticity simulations
and in situ high-energy X-ray experiments, Mater. Des. 197 (2021), 109216,
https://doi.org/10.1016/j.matdes.2020.109216.
[344] K. Solberg, J. Torgersen, F. Berto, Fatigue behaviour of additively manufactured
Inconel 718 produced by selective laser melting, Procedia Struct. Integr. (2018)
1762–1767, https://doi.org/10.1016/j.prostr.2018.12.371.
[345] E.W. Hovig, A.S. Azar, M.F. Sunding, E. Andreassen, K. Sørby, High cycle fatigue
life estimation of materials processed by laser powder bed fusion, Fatigue Fract.
Eng. Mater. Struct. 42 (2019) 1454–1466, https://doi.org/10.1111/ffe.12982.
[346] K. Solberg, F. Berto, A diagram for capturing and predicting failure locations in
notch geometries produced by additive manufacturing, Int. J. Fatigue 134 (2020),
105428, https://doi.org/10.1016/j.ijfatigue.2019.105428.
[347] K. Solberg, F. Berto, The effect of defects and notches in quasi-static and fatigue
loading of Inconel 718 specimens produced by selective laser melting, Int. J.
Fatigue 137 (2020), 105637, https://doi.org/10.1016/j.ijfatigue.2020.105637.
[348] L.Y. Wang, Z.J. Zhou, C.P. Li, G.F. Chen, G.P. Zhang, Comparative investigation of
small punch creep resistance of Inconel 718 fabricated by selective laser melting,
Mater. Sci. Eng. A 745 (2019) 31–38, https://doi.org/10.1016/j.
msea.2018.12.083.
[349] J.J. Shi, S.A. Zhou, H.H. Chen, G.H. Cao, A.M. Russell, Z.J. Zhou, X.B. Qi, C.P. Li,
G.F. Chen, Microstructure and creep anisotropy of Inconel 718 alloy processed by
selective laser melting, Mater. Sci. Eng. A 805 (2021), https://doi.org/10.1016/j.
msea.2020.140583.
[350] A. Mostafa, D. Shahriari, I.P. Rubio, V. Brailovski, M. Jahazi, M. Medraj, Hot
compression behavior and microstructure of selectively laser-melted IN718 alloy,
Int. J. Adv. Manuf. Technol. 96 (2018) 371–385, https://doi.org/10.1007/
s00170-017-1522-4.
[351] C. Qiu, H. Chen, Q. Liu, S. Yue, H. Wang, On the solidification behaviour and
cracking origin of a nickel-based superalloy during selective laser melting, Mater.
Charact. 148 (2019) 330–344, https://doi.org/10.1016/j.matchar.2018.12.032.
[352] J.J. Shi, X. Li, Z.X. Zhang, G.H. Cao, A.M. Russell, Z.J. Zhou, C.P. Li, G.F. Chen,
Study on the microstructure and creep behavior of Inconel 718 superalloy
fabricated by selective laser melting, Mater. Sci. Eng. A 765 (2019), https://doi.
org/10.1016/j.msea.2019.138282.
[353] I.T. Ho, T.H. Hsu, Y.J. Chang, C.W. Li, K.C. Chang, S. Tin, K. Kakehi, A.C. Yeh,
Effects of CoAl2O4 inoculants on microstructure and mechanical properties of
IN718 processed by selective laser melting, Addit. Manuf. 35 (2020), 101328,
https://doi.org/10.1016/j.addma.2020.101328.
[354] B. Anush Raj, J.T. Winowlin55 (2022) 102871
5
3. EDS: energy-dispersive X-ray spectroscopy and its associated
techniques;
4. LM: light microscopy and its associated techniques;
5. EBSD: electron back-scattered diffraction and its associated
techniques;
6. XRD: X-ray diffraction and its associated techniques; and
7. CT: computed tomography and its associated techniques.
After these categories had been established, the publications iden-
tified for inclusion in the study were allocated to the appropriate group/
subgroup. Most studies could be placed in two or more of these cate-
gories and were thus placed in more than one group. The results of the
literature classification are shown in Table 2, which shows the number
of studies associated with each research subject category and organizes
them by superalloy type.
It could be noted from the reviewed literature that some subjects
were more thoroughly investigated than others. A greater number of
authors have focused on the topics of heat-treatment, quasi-static me-
chanical behavior, hardness and parameter optimization. A considerable
number of publications report microstructural analysis, mostly
employing SEM and LM. In contrast, the topics of machining, corrosion
and creep behavior are less frequently investigated.
The connectivity between the categories, i.e., how many studies
focus on two of these categories simultaneously, is shown in Fig. 2, with
the exception of the “Microstructure” and “Simulation” groups. Every
group is represented with a circle whose diameter is proportional to the
number of studies which were focused on that subject. These circles are
connected with lines and their width is proportional to the number of
studies that have both groups as subjects simultaneously.
Following the observations gained from Table 2, Fig. 2 indicates that
the topics of heat-treatment, quasi-static mechanical behavior, hardness
and parameter optimization are not only the most represented subjects
in the reviewed literature but also the most inter-connected, and the
interaction between heat treatment and quasi-static mechanical
behavior is the most common. On the other hand, a few gaps could be
noted, for instance, no reviewed studies were focused on the interactions
between corrosion and fatigue, composites and fatigue, corrosion and
HIP, composites and HIP or creep and tribology.
A full overview of the studies analyzed in this review can be seen in
the graph of Appendix A, in which each individual publication is map-
ped to show its associated research subject categories. Each number in
the Appendix refers to the associated publication number in the Refer-
ences section, while each color corresponds to a superalloy: blue for
IN718, red for IN625 and green for IN738LC. The size of each method
node (in gray) is parametrized by the number of publications that either
employ or focus on the method itself.
3. Microstructure
The microstructure of Inconel superalloys can be described as a face
centered cubic (FCC) γ matrix reinforced by several strengthening pre-
cipitates, solid solution elements and carbides. This kind of micro-
structure is associated with Inconel regardless of the manufacturing
technique employed. Some phases provide the alloys with their char-
acteristic properties and strength (Table 3) while others are undesirable
and avoided due to performance deterioration (Table 4).
Among the microstructural strengthening mechanisms, the precipi-
tation of metastable γ’ and γ’’ phases coherent with the γ matrix brings
the most substantial strengthening to some of these superalloys [34]. A
high volume fraction of these phases is associated with high yield and
ultimate tensile stress at high temperatures, as well as high hardness and
creep rupture strength [7]. The precipitation of γ’ is increased by the
addition of Ti and Al, but the presence of Nb increases the development
of γ’’. This effect is predominant in two of the three Inconel alloys
commonly considered in studies on PBF-LB. Thus, while IN718 presents
nano-scale precipitation of γ’’ as its main strengthening mechanism due
to the high Nb content of the alloy, IN738LC has a microstructure with a
high volume fraction of γ’ when compared to most other superalloys due
to its high Ti contents.
A second strengthening mechanism is the solid-solution due to the
presence of atoms with slight atomic radius mismatch with Ni in the γ
matrix. These atoms induce a distortion of the crystal lattice together
with the development of internal stresses associated with alloy
strengthening. Because this expansion is dependent on the degree of
atomic radius mismatch, larger solid-solution atoms such as W and Mo
increase the extent of this mechanism. Thus, it is predominant within the
microstructure of IN625, a Mo-rich superalloy.
A third strengthening mechanism is the formation of carbides, which
are found in various shapes and compositions within the microstructure
of Inconel superalloys. Relevant to the three alloys commonly studied
with PBF-LB are the MC, M23C6 and M6C carbides, in which M stands for
atoms such as Ti, Cr and Mo. These carbides have been associated with
the inhibition of grain growth and grain boundary sliding [35] while not
presenting deleterious levels of stress accumulation due to crystallo-
graphic coherency with the γ matrix [36], being thus desirable up to a
certain amount for the mechanical performance of polycrystalline
superalloys.
On the other hand, the microstructure of PBF-LB Inconel alloys might
also include a number of phases which are undesirable, since their
presence deteriorates the mechanical behavior of the material due to
topologically close-packed crystal structures. These include the Laves
and δ phases, which are often described in the PBF-LB literature. Further
detrimental phases that are common in conventional Inconel materials
were not described in the reviewed literature. This is the case of the
tetragonal σ CrFe phase, despite its significance with regard to the
general microstructure of Inconel.
The Laves phase corresponds to irregularly shaped, bulky and brittle
structures usually in the grain boundaries and interdendritic areas of
IN718 [37] and IN625 [38], being developed from Ti and Nb segrega-
tion upon solidification [39]. It provides preferential sites for the
nucleation of microvoids and cracks [36,40–42] at the same rate that
depletes the matrix from elements needed for γ’’ precipitation [41,43]
and locally reduces γ corrosion resistance [44], thus being mechanically
detrimental for the superalloy.
The δ phase is an acicular phase that has been shown to segregate in
Nb-rich interdendritic regions [34,45–47]. Although studies suggest that
moderate amounts of this phase can improve high temperature me-
chanical behavior through the inhibition of grain growth, microvoid
coalescence and grain boundary sliding due to pinning [40,48–53], it is
argued that these effects can be better achieved by nano-sized pre-
cipitates and the PBF-LB dislocation cell structure itself [54,55]. More-
over, because this phase has also been associated with a reduction in
fracture toughness, high-temperature ductility, fatigue life and corro-
sion resistance in intergranular zones [36,42,45,46,50,55–60], it is also
regarded as undesirable in terms of material performance.
4. Manufacturing parameters
Additive manufacturing technologies are highly dependent on
careful control of the manufacturing parameters, which influence both
the quality and performance of the components. For this reason, a
considerable fraction of the PBF-LB literature is focused on analyzing the
influence of various parameters, either independently or in relation to
each other, with a view to their optimization. These so-called “para-
metric studies” are based on the arrangement of various PBF-LB build
conditions with different parameter sets, each of which is subsequently
evaluated based on an aspect of interest.Jappes, M. Adam Khan, V. Dillibabu, N.C. Brintha,
Direct metal laser sintered (DMLS) process to develop Inconel 718 alloy for
turbine engine components, Optics 202 (2020), 163735, https://doi.org/
10.1016/j.ijleo.2019.163735.
[355] H. Zhang, D. Gu, L. Xi, H. Zhang, M. Xia, C. Ma, Anisotropic corrosion resistance
of TiC reinforced Ni-based composites fabricated by selective laser melting,
J. Mater. Sci. Technol. 35 (2019) 1128–1136, https://doi.org/10.1016/j.
jmst.2018.12.020.
[356] Y.W. Luo, B. Zhang, Z.M. Song, C.P. Li, G.F. Chen, G.P. Zhang, A comparative
investigation of long-term oxidation behavior of selective laser melting-fabricated
Inconel 718 at 650 ◦c, J. Mater. Res. 35 (2020) 2036–2045, https://doi.org/
10.1557/jmr.2020.98.
[357] O.V. Mythreyi, A. Raja, B.K. Nagesha, R. Jayaganthan, Corrosion study of
selective laser melted in718 alloy upon post heat treatment and shot peening,
Metals (2020) 1–19, https://doi.org/10.3390/met10121562.
[358] L. Chen, Y. Sun, L. Li, X. Ren, Effect of heat treatment on the microstructure and
high temperature oxidation behavior of TiC/Inconel 625 nanocomposites
fabricated by selective laser melting, Corros. Sci. 169 (2020), 108606, https://
doi.org/10.1016/j.corsci.2020.108606.
[359] Q. Jia, D. Gu, Selective laser melting additive manufactured Inconel 718
superalloy parts: high-temperature oxidation property and its mechanisms, Opt.
Laser Technol. 62 (2014) 161–171, https://doi.org/10.1016/j.
optlastec.2014.03.008.
[360] T. Sanviemvongsak, D. Monceau, B. Macquaire, High temperature oxidation of IN
718 manufactured by laser beam melting and electron beam melting: effect of
surface topography, Corros. Sci. 141 (2018) 127–145, https://doi.org/10.1016/j.
corsci.2018.07.005.
[361] H. Zhang, D. Gu, C. Ma, M. Xia, M. Guo, Surface wettability and
superhydrophobic characteristics of Ni-based nanocomposites fabricated by
selective laser melting, Appl. Surf. Sci. 476 (2019) 151–160, https://doi.org/
10.1016/j.apsusc.2019.01.060.
[362] S. Parizia, G. Marchese, M. Rashidi, M. Lorusso, E. Hryha, D. Manfredi,
S. Biamino, Effect of heat treatment on microstructure and oxidation properties of
Inconel 625 processed by LPBF, J. Alloy. Compd. 846 (2020), 156418, https://
doi.org/10.1016/j.jallcom.2020.156418.
[363] X. Liu, R. Zhang, S. Feng, H. Li, Y. Wang, J. Gong, H. Sun, Effect of aging
treatment on corrosion resistance of Inconel 718 fabricated by selective laser
melting, IOP Conf. Ser. Mater. Sci. Eng. 772 (2020), https://doi.org/10.1088/
1757-899X/772/1/012075.
[364] W. Zhou, G. Zhu, R. Wang, C. Yang, Y. Tian, L. Zhang, A. Dong, D. Wang, D. Shu,
B. Sun, Inhibition of cracking by grain boundary modification in a non-weldable
nickel-based superalloy processed by laser powder bed fusion, Mater. Sci. Eng. A
791 (2020), 139745, https://doi.org/10.1016/j.msea.2020.139745.
[365] I.T. Ho, Y.T. Chen, A.C. Yeh, C.P. Chen, K.K. Jen, Microstructure evolution
induced by inoculants during the selective laser melting of IN718, Addit. Manuf.
21 (2018) 465–471, https://doi.org/10.1016/j.addma.2018.02.018.
[366] R. Krishnan, M. Naik, D.G. Thakur, V. Dillibabu, Experimental investigation on
wear behavior of additively manufactured components of IN718 by DMLS
process, J. Fail. Anal. Prev. 20 (2020) 1697–1703, https://doi.org/10.1007/
s11668-020-00978-8.
[367] C.S.S., M. Arivarasu, T.R. Prabhu, High temperature dry sliding wear behaviour of
laser powder bed fused Inconel 718, Addit. Manuf. 34 (2020), 101279, https://
doi.org/10.1016/j.addma.2020.101279.
[368] K.L. Tan, S.H. Yeo, Surface modification of additive manufactured components by
ultrasonic cavitation abrasive finishing, Wear 378–379 (2017) 90–95, https://doi.
org/10.1016/j.wear.2017.02.030.
[369] Y. Kaynak, E. Tascioglu, Post-processing effects on the surface characteristics of
Inconel 718 alloy fabricated by selective laser melting additive manufacturing,
Prog. Addit. Manuf. 5 (2020) 221–234, https://doi.org/10.1007/s40964-019-
00099-1.
G.M. Volpato et al.
https://doi.org/10.1088/1757-899X/490/3/032036
https://doi.org/10.1111/ffe.13181
https://doi.org/10.1016/j.ijfatigue.2020.105739
https://doi.org/10.1016/j.ijfatigue.2020.105739
https://doi.org/10.1016/j.engfracmech.2020.107305
https://doi.org/10.1016/j.engfracmech.2020.107305
https://doi.org/10.1016/j.ijfatigue.2019.105392
https://doi.org/10.1016/j.ijfatigue.2019.105392
https://doi.org/10.1016/j.ijfatigue.2018.08.002
https://doi.org/10.1016/j.ijfatigue.2018.08.002
https://doi.org/10.1016/j.ijfatigue.2020.106033
https://doi.org/10.1016/j.ijfatigue.2019.105394
https://doi.org/10.1016/j.ijfatigue.2019.105394
https://doi.org/10.1016/j.ijfatigue.2020.105654
https://doi.org/10.1016/j.matdes.2018.04.022
https://doi.org/10.1016/j.matdes.2018.04.022
https://doi.org/10.1016/j.matdes.2020.109216
https://doi.org/10.1016/j.prostr.2018.12.371
https://doi.org/10.1111/ffe.12982
https://doi.org/10.1016/j.ijfatigue.2019.105428
https://doi.org/10.1016/j.ijfatigue.2020.105637
https://doi.org/10.1016/j.msea.2018.12.083
https://doi.org/10.1016/j.msea.2018.12.083
https://doi.org/10.1016/j.msea.2020.140583
https://doi.org/10.1016/j.msea.2020.140583
https://doi.org/10.1007/s00170-017-1522-4
https://doi.org/10.1007/s00170-017-1522-4
https://doi.org/10.1016/j.matchar.2018.12.032
https://doi.org/10.1016/j.msea.2019.138282
https://doi.org/10.1016/j.msea.2019.138282
https://doi.org/10.1016/j.addma.2020.101328
https://doi.org/10.1016/j.ijleo.2019.163735
https://doi.org/10.1016/j.ijleo.2019.163735
https://doi.org/10.1016/j.jmst.2018.12.020
https://doi.org/10.1016/j.jmst.2018.12.020
https://doi.org/10.1557/jmr.2020.98
https://doi.org/10.1557/jmr.2020.98
https://doi.org/10.3390/met10121562
https://doi.org/10.1016/j.corsci.2020.108606
https://doi.org/10.1016/j.corsci.2020.108606
https://doi.org/10.1016/j.optlastec.2014.03.008
https://doi.org/10.1016/j.optlastec.2014.03.008
https://doi.org/10.1016/j.corsci.2018.07.005
https://doi.org/10.1016/j.corsci.2018.07.005
https://doi.org/10.1016/j.apsusc.2019.01.060
https://doi.org/10.1016/j.apsusc.2019.01.060
https://doi.org/10.1016/j.jallcom.2020.156418
https://doi.org/10.1016/j.jallcom.2020.156418
https://doi.org/10.1088/1757-899X/772/1/012075
https://doi.org/10.1088/1757-899X/772/1/012075
https://doi.org/10.1016/j.msea.2020.139745
https://doi.org/10.1016/j.addma.2018.02.018
https://doi.org/10.1007/s11668-020-00978-8
https://doi.org/10.1007/s11668-020-00978-8
https://doi.org/10.1016/j.addma.2020.101279
https://doi.org/10.1016/j.addma.2020.101279
https://doi.org/10.1016/j.wear.2017.02.030
https://doi.org/10.1016/j.wear.2017.02.030
https://doi.org/10.1007/s40964-019-00099-1
https://doi.org/10.1007/s40964-019-00099-1
	A comprehensive literature review on laser powder bed fusion of Inconel superalloys
	1 Introduction
	2 Outline of topics
	3 Microstructure
	4 Manufacturing parameters
	4.1 Laser power
	4.2 Scan speed
	4.3 Hatch parameters
	4.4 Layer thickness
	4.5 Linear and volumetric energy densities
	4.6 Additional parameters
	5 Heat treatments
	5.1 IN718
	5.2 IN625
	5.3 IN738LC
	6 Machining
	7 Mechanical behavior
	7.1 Tensile strength
	7.2 Hardness
	7.3 Fatigue
	7.4 Creep
	8 Corrosion behavior
	9 Composites
	10 Tribological behavior
	11 Current challenges
	12 Concluding remarks
	CRediT authorship contribution statement
	Declaration of Competing Interest
	Acknowledgments
	Appendix A Map of reviewed publications
	Appendix B Parameter tables
	Appendix C Maps of publications focused on mechanical behavior
	ReferencesThe main build parameters evaluated in PBF-LB studies on Inconel
superalloys are the laser power, scan speed, hatch distance and layer
thickness. These are all machine-specific parameters, which makes them
easy to change from sample to sample. They will be described in more
detail below.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
6
However, because the number of combinations of such parameters
can be considerably large and the parameters themselves are highly
sensitive to each other, such studies tend to be lengthy and complex.
Therefore, several methods have been developed to speed up these
analytical processes, such as the evaluation of combined parameters
(mathematical parameters aimed at evaluating various build parameters
simultaneously) or the use of statistical design of experiment (DoE)
methodologies.
Various other parameters have also been evaluated in the literature,
either individually, together with the main parameters or in relation to
each other. These include the build gas, support structures, powder
variables, laser beam geometry and path, and build orientation, which
are detailed in Section 4.6.
A concise exposition of the parameters employed to build bulk
Inconel samples using PBF-LB is shown in Appendix B, which brings a
series of tables with the employed values of laser power, scan speed,
hatch distance and layer thickness.
4.1. Laser power
The laser power is the main parameter that controls the transference
of energy from the PBF-LB system to the process powder, aimed at its
melting in a controlled and homogeneous fashion to produce dense bulk
components.
Increasing laser power is often associated with easier melting of the
precursor powders and therefore a better densification of as-built com-
ponents [61–64]. However, studies have shown that an indiscriminate
increase in this parameter leads to the formation of porosity in the final
pieces due to the development of keyhole pores and strong convective
flows in the molten material [62,65]. Therefore, maximum material
density is expected by determining an optimum intermediate value of
bulk laser power, which avoids these disadvantages [62,66–71]. This
optimization is also an important method of reducing the overall cost of
the production process, which is considerably increased by the use of
high laser power [63].
It has been evidenced that a high laser power also increases the di-
mensions of the melt pool generated by heating [62,66,72–78], which,
in turn, has been associated [74] with microstructural coarsening [79],
reduced surface roughness [76,80] and a higher incidence of micro-
cracking [64,74]. Since microhardness within the melt pool has been
shown to be independent of the laser power [75], the latter can be
attributed to increased temperature gradients after laser melting, which
induce residual stress in the solidified material [73,81]. This also con-
trols the degree to which layers of deposited material undergo remelting
when subsequent layers are added, which is more pronounced in the
case of deeper melt pools [72,73].
4.2. Scan speed
The scan speed describes how fast the laser beam travels through the
surface of the powder bed, thus being a critical factor for the definition
of the build rate of PBF-LB components. Moreover, it controls the time
during which each part of the powder bed is submitted to the laser
power, having an influence on the energy available for its melting.
Although high scan speeds contribute to high build rates [63], this
condition can also lead to lack of fusion porosity [63–65,82–84] and
defects such as balling [66,72,85] in as-built materials. These effects, in
turn, have been described to be a consequence of the high shear stresses
within the melt pool under such conditions [69]. On the other hand, a
low scan speed can increase the amount of energy per unit of time in the
melt pool, thus increasing its dimensions [66,73,75,77,78,83,86–88]
and inducing both the keyhole phenomenon [61,66,72,77] and spat-
tering due to turbulent melting [87]. Nonetheless, in various studies
focused on building samples with considerably low [89–96] or high [64,
85,97] scan speeds, these effects were ameliorated by adjusting other
parameters.
It has been verified that both extremes of this parameter increase
roughness in relation to optimum values [61,66]. Some authors argue
that this effect is more pronounced with high scan speeds [66,76],
whereas others have found the opposite scenario [87]. Nonetheless,
Fig. 3. – Hatch parameters: (a) hatch distance, (b) layer strategies and (c) layer rotation.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
7
although scan speed has been described as more significant than laser
power in terms of roughness control [66], it has also been reported that
this parameter has a negligible influence on the same property [75]. In
addition, some authors have found that the scan speed has a major
impact not only in controlling the dimensions of components but also
the volume fraction of aging precipitates [98].
High crack density upon solidification has been attributed to low
scan speeds [61,64,83], as this condition increases the maximum tem-
perature within the powder bed [73] and, consequently, the residual
stresses in the solidified melt pool [61,86].
4.3. Hatch parameters
Hatch parameters define the path taken by the laser beam within a
layer, as well as how this path changes from layer to layer. The three
main aspects of this parameters, which are schematically represented in
Fig. 3, are as follows:
1. Hatch distance - the space between adjacent paths of the laser beam,
which can account for the degree of beam overlap;
2. Layer strategy - the geometry that the laser paths take within a same
layer; and
3. Layer rotation - the rotation of the layer strategy after each new
layer.
The hatch distance defines the space between two passes of the laser
beam (Fig. 3a) and thus controls the way in which the surface of the
powder bed is heated. A large distance can lead to a lack of contact
between molten regions of the powder bed, whereas low distances can
result in excess energy input. Therefore, an optimal distance needs to be
identified to ensure the final quality of the build. Optimum hatch dis-
tances associated with minimum porosity have been established for
IN718 [67], IN625 [99] and IN738LC [61]. Optimum values for mini-
mum roughness have also been determined for IN738LC [61]. Some
authors have shown that increasing the hatch distance leads to greater
porosity in as-built specimens [38,61,69,74,86,99], although it has also
been associated with reduced crack incidence [61,64,74], cooling rates
of the powder bed, asymmetry of the melt pools [86] and hardness [69].
Thus, this parameter has been considered a dominant factor for the
definition of both the above-mentioned factors [98] and the porosity
[100]. In one study on the IN738LC melt pool, asymmetry was analyzed
by verifying a micro-humping phenomenon in pools when the hatch
distance was too small [61].
The layer strategy has a strong influence on the final microstructure
and surface topography of the components, and the most common ge-
ometries are shown in Fig. 3b. They can be designed considering either
unidirectional or bidirectional scanning, the latter being reported to
induce bimodality in melt pool sizes as well as a loss of melt pool cross-
section symmetry due to the dynamic distribution of the powder bed
heating[101,102]. It has been shown that the continuous strategy tends
to develop higher texture, anisotropy [103] and geometry-induced re-
sidual stresses [104] than the alternatives, which induce better me-
chanical properties and creep resistance in specific sample orientations
[53,103]. One study has shown that this strategy can be used to tailor
the crystallographic texture from polycrystalline up to single-crystal-like
microstructures [105]. The island strategy (also called “chessboard” by
some authors) is associated with the highest isotropy and the lowest
residual stresses of all such geometries [104], and the size of the islands
seems to be proportional to the relative density of the component [106].
This may be related to a reported superior wear behavior in comparison
to other strategies [107]. Strip geometries can provide intermediate
isotropy results and have been shown to lead to less texture when a
longer hatch length is applied [108]. In addition, different strategies on
how the contour region of samples is exposed to the laser radiation have
also been reported to have major effects on the surface quality of pro-
duced components, which is connected to performance under fatigue
and tribology applications [76,80,87].
Layer rotation (Fig. 3c) can be applied to any of the layer strategies,
leading to different results. If no rotation is applied, the component is
expected to have more heterogeneity, residual stress and shrinkage, as
the laser beam is always focused on the same region of the powder bed
[109–111]. This produces a bimodal grain structure [67,112], which
was also verified when 90◦ rotation was employed [67]. However, 90◦
rotation seems to reduce the tensile and fatigue strengths when
compared to non-rotated samples [113], which may be associated with
the reduced residual stress [111] and microstructural columnarization
[112] observed under this condition. A rotation of 67◦ is often applied in
order to change the path of the laser beam for every new layer, thus
avoiding grain growth [114] and bimodality [67] while also diminishing
the degree of texture [109,115] and facilitating machining [116].
Nonetheless, a preferential alignment to the build direction is
expected in as-built samples due to the orientation of the thermal
gradient during build-up [67,105,115,117–119], despite the careful
control of parameters being able to tailor the preferential texture after
processing [105].
Fig. 4. – Schematic representation of the effects of increasing and decreasing linear and volumetric energy densities as reported in the reviewed literature. The
properties are arranged moving toward their maximization.
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
8
4.4. Layer thickness
The powder layer thickness defines the height of each subsequent
powder layer to be turned molten by the laser beam, thus controlling the
build rate and, consequently, the total manufacturing time of individual
components. Thus, because this total time is one of the main constraints
of additive manufacturing technologies for industrial applications,
increasing the layer thickness could be an effective way to speed up the
build process and increase the cost efficiency. However, it has been
shown for IN718 that higher layer thickness is associated with detri-
mental changes to the properties of the final component, such as reduced
dimensional accuracy [120] and lower mechanical properties due to
lower yield strength [97,120], ultimate tensile strength [97,120],
Young’s modulus [97], Vickers microhardness [86,97] and impact
toughness [120]. Additionally, it has been shown that an increase in
layer thickness induces lower cooling rates within the powder bed as
well as a larger dendritic arm spacing in the final microstructure [86],
despite the parameter having marginal importance for the absorptivity
of the laser power [121].
4.5. Linear and volumetric energy densities
The linear and volumetric energy densities (LED and VED, respec-
tively) are combined parameters, developed for the joint evaluation of
the effects of the aforementioned individual parameters. They are
defined, respectively, by Eqs. 1 and 2, which are represented by various
notations in the literature:
LED =
Laser power
Scan speed
[
J
mm
]
(1)
VED =
Laser power
Scan speed × Hatch distance × Layer thickness
[
J
mm3
]
(2)
In parametric studies, the control of the LED and the VED has led to
similar effects on the as-built specimens, despite the difference between
the two parameters. A summary of these effects can be found in Fig. 4.
Because these parameters describe the amount of energy required to
melt the powder bed, it is commonly acknowledged that applying high
values leads to better overall densification of the material [85,122–130],
which results in greater mechanical stability and, consequently, higher
stiffness and hardness [71,123–126,128,130,131]. Nevertheless, this
effect has been shown to occur only in specific processing windows, and
both density [61,64,65,67,68,71,132,133] and hardness [67,71,122,
133] eventually decrease once the energy density employed becomes
too high.
The fact that density and hardness are optimized at intermediate
values of LED and VED is also verified considering various other prop-
erties of the as-built specimens, such as yield stress [61,81], ultimate
tensile stress [81], elongation [61,81] and fatigue life [134]. This could
be associated with the development of porosity at both extremes of
energy density, that is, low values induce irregular lack-of-fusion
porosity due to insufficient melting of the powder bed [63,67,68,131,
132,134–136] while excessively high values lead to smaller round pores,
attributed to turbulence of the melt pool, gas entrapment and keyhole
formation [61,63,67,132,136].
Other phenomena have been verified to behave proportionally to
these parameters. Due to larger energy input, higher energy density
values result in hotter, wider and deeper melt pools [63,72,74,78,125,
135,137], which tend to present a higher degree of overlapping [138].
The pool dimensions seem to grow linearly with the energy density [63,
78]. This also influences the microstructure of as-built specimens, which
tend to present equiaxed grains when low energy density values are
applied and columnar microstructures when higher values are used
[126,127,130,131,135]. The diameter of the columnar dendrites has
been reported to be inversely proportional to VED [130].
Oxidation resistance [124,129], susceptibility to creep [71] and
crack density [61,74,134] have also been reported to increase with
higher energy density. In the case of crack density, this may be related to
the reportedly higher residual stresses [81] and segregation [130] under
this condition. When considering porosity-nucleated cracking, however,
the tendency seems to be the opposite [136].
In addition, the dimensions of reinforcement particles within the
microstructure are refined, their interfacial roughness decreases and
their volume fraction reduces with higher energy density, which also
leads to higher diffusion and reactivity between the matrix and the
reinforcement particles within composites [122,125]. Increasing the
energy density further can induce the fragmentation of reinforcement
particles [139]. Both the Poisson’s ratio [128] and superficial roughness
[65,87,133] of the samples appear to be minimized on applying higher
LED and VED values, the latter up to a threshold [61,133]. Accordingly,
both the wear rate and the coefficient of friction seem to be reduced
[122,124–126,130], although there is evidence of optimum values for
their minimization [122].
Despite the widespread use of theseparameters as representative
factors in parametric studies, the degree of their validity is subject of
controversy. Some authors report the statistical significance of com-
bined parameters as factors of influence for the measured properties
[133] while others argue that they cannot be used to describe the
experimental settings [87,100]. This inadequacy is clear in specific
studies, in which different parameter combinations achieve as-built
microstructures with different characteristics in terms of melt pool ge-
ometry, hardness, fracture mechanism and thermomechanical fatigue
life while still having the same VED [49,119].
4.6. Additional parameters
In addition to the main PBF-LB build parameters and their combi-
nations, the effects of other factors have been studied and the results
reported in the literature. These include, but are not limited to, the build
gas, support structures, powder variables, laser beam geometry and
path, and build orientation.
Due to the superficial oxidation induced by the melting of the
powder bed, inert gases are a common processing atmosphere in PBF-LB
systems [140–142]. In a comparative study with N2, Ar has been shown
to induce grain refinement and larger melt pools in IN718 as-built
samples, leading to a higher overall strength and ductility [143]
despite greater roughness [144]. The use of He as a shielding gas for
IN625 reduced the spattering intensity in comparison to Ar [137].
However, specimens built under vacuum conditions presented a greater
γ’ stability, as well as a diminished incidence of the δ phase and larger,
more anisotropic, grains compared with the use of Ar, which resulted in
greater creep resistance [43].
Support structures have been found to reduce the overall residual
stress of components [145], this effect being more pronounced under
conditions where the substrates present either low thermal conductivity,
pre-heating or pre-compression [146]. Additionally, although the effects
of these structures on the local microstructure and hardness are not
strong, they have been shown to become more pronounced as the
structures become taller and narrower [147].
The reuse of the powder is of great interest with regard to the eco-
nomic viability of PBF-LB processing, due to the high percentage of
waste and high cost associated with these types of consumables. This is
especially true for gas-atomized powders, which have been shown to
produce denser specimens than water-atomized powders [148]. This
effect can be attributed to the greater regularity in the morphology of
gas-atomized powders, especially under high humidity conditions
[149]. However, the potential for the reuse of powders is related to
changes in its particle diameter and composition by oxidation [140],
particularly in the accumulation of fines after sieving, which seems to
affect both the flowability of the powder bed [150] and the primary
dendrite arm spacing of as-built specimens [141]. These effects are
mostly associated with powder that undergoes spattering during the
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
9
PBF-LB processing, other types tending to be resistant to the additive
manufacturing process [142]. Nevertheless, the extent of the impact of
such changes on the final components is still a subject of research, as
authors have reported no changes in the mechanical behavior of speci-
mens subjected to cycles of reuse (up to 14 times) [151].
Besides the main PBF-LB parameters, the geometry and path of the
laser beam have been considered as promising parameters for the opti-
mization of the density and microstructure in the processing of Inconel.
This can be verified by the development of skywriting [132] and circular
oscillating beam scans [152], both of which tend to reduce
micro-porosity. The latter has also been associated with a reduction in
the microsegregation and the enhancement of texture. Higher anisot-
ropy has also been achieved by using a defocused laser beam, which
seems to produce larger grains and, consequently, improved creep
resistance [103]. In addition, the beam profile can be altered so as to
depart from a Gaussian geometry and achieve lower local maximum
temperatures, thus reducing keyhole formation, increasing process sta-
bility, reducing spattering, increasing build rates and influencing crack
density [83,153]. If applied with very high power, non-Gaussian beam
profiles have also been reported to considerably increase grain size and
crystallographic texture [154].
Various effects of the build orientation on the behavior of PBF-LB
Inconel components have been studied in the reviewed literature,
which usually affects the directional dependence of certain properties of
these superalloys. It has been reported that lower strength, hardness and
stiffness are to be expected in directions normal to the additive manu-
factured layers [68,104,155–157], which may be related to reports of a
significant effect of orientation on the number of pores [150] and grain
size in as-built [131,158] and heat-treated [53] components. A similar
dependence has been verified for creep life [53,159,160], corrosion
resistance [161–163], heat treatment efficiency [164] and wear resis-
tance [158,165]. In addition, the overhanging surfaces produced by
certain build orientations have been shown to present substantial
roughness, which is attributed to a lack of support from the powder bed
during the building process and to the sticking of spattered powder [87,
134,158,161,166–168]. This, in turn, is especially critical in view of
fatigue properties [134], as it has been shown that the defects present at
overhanging surfaces can induce severe changes in fatigue life and crack
growth behavior [134,169] as well as in contact fatigue [170].
5. Heat treatments
Inconel superalloys are heat treated to increase the mechanical
properties at both high temperatures and under room-temperature
conditions. This is normally achieved by a precipitation hardening
heat treatment, which is based on a solution annealing step followed by
an aging sequence. While the high-temperature solution treatment aims
to produce a homogeneous, stress-relieved, isotropic microstructure free
of precipitates, aging takes this microstructure as a basis for the
precipitation of hard γ’ and γ’’ phases within the coarsened grains,
which provides an alloy with high mechanical and thermal performance.
When produced by PBF-LB, however, the initial microstructure of
these alloys is radically different from both wrought and cast compo-
nents, thus needing tailored thermal post-processing to ensure the
satisfactory performance of the components.
5.1. IN718
The conventional heat treatments applied to IN718 are dependent on
the manufacturing route of each component. As an example, while
wrought IN718 components are usually submitted to the AMS 5662 heat
treatment (solution annealing at 980 ◦C for 1 h followed by double aging
at 720 ◦C for 8 h and 620 ◦C for 8 h), the sequence is preceded by a
homogenization step (1080 ◦C for 1 h) for casting specimens, in accor-
dance to AMS 5383 [171]. This change is aimed at reducing the segre-
gation in the irregular microstructure of cast materials.
Accordingly, the recently published standard ASTM F3301 describes
a heat treatment aimed at PBF-LB IN718 that adds stress release
(1065 ◦C for 1.5 h) and HIP (1120 ◦C for 4 h) steps before the applica-
tion of the standard AMS 5662, to address artifacts produced during the
additive manufacturing process. A similar approach to PBF-LB IN718 is
described in the reviewed literature, where various methods are applied
to adjust the as-built microstructure to industry standards.
Because the microstructure ofPBF-LB IN718 presents severe
anisotropy, residual stress and segregation together with a fair number
of defects, various authors have employed high-temperature steps
before the precipitation hardening heat treatment in order to mitigate
these aspects by recrystallization. These include homogenization treat-
ments and also the use of HIP or a high-temperature solution.
In addition to the various typical recrystallization effects that have
been reported for all three methodologies (Table 5), further results show
that although the pre-treatments tend to reduce the mechanical strength
and increase ductility, better mechanical properties are achieved after
the full heat treatment in comparison with precipitation hardening alone
[50,89,144,172–175]. One reason for this improvement may be the
reported increase in the volume fractions of γ’ [176] and γ’’ [8] after
treatments preceded by homogenization and high temperature solution,
respectively, which has been related to the dissolution of segregates rich
in elements for the precipitation of these phases [174,177]. Nonetheless,
other studies revealed no significant changes in the static mechanical
properties when adding homogenization [42,178–180] or HIP [180]
before the precipitation hardening treatment.
HIP is usually employed to reduce the metallurgical porosity of PBF-
LB specimens [41,144,172,177,193,208–210], so that lack-of-fusion
defects tend not to be as affected by the technique [211]. The temper-
ature of the treatment (usually higher than 1050 ◦C [193]) has been
reported to have a greater effect than the pressure on the final densifi-
cation [193]. This may be associated with the precipitation of δ [39,212]
due to the high-temperature dissolution of γ’’ [213] or Laves [43,49,
159] phases followed by slow cooling, which could influence the re-
ported effects of the treatment on mechanical properties such as fatigue
and creep resistance. Nonetheless, when succeeded by a solution heat
treatment, HIP has also been reported to induce the dissolution of δ
[190].
By changing the homogenization and solution temperature, re-
searchers have found that 1080 ◦C provides optimum mechanical
strength [51,52,195,196], 1065 ◦C presents optimum solutioning effi-
ciency without a significant loss in mechanical properties [186] and the
standard temperature of 980 ◦C provides maximum hardness [48].
Moreover, high treatment temperatures have been reported to induce a
higher incidence of twinning and higher grain boundary angles [51,214]
as well as improved tribological behavior [95] and corrosion resistance
[215], although higher pitting has also been described [216]. Higher
aging temperatures have been observed to reduce hardness through the
coarsening of aging precipitates and the transformation of γ’’ into δ
Table 5 –
Reported effects of precipitation hardening pre-treatments applied to IN718.
Homogenization HIP High-temperature
solution
Reduced
segregation
[42,55,176,179,
181]
[175,182,183] [8,41,50,57,174,
184–188]
Grain growth [164,179,181,189] [182,
190–194]
[41,186,187,
194–196]
Reduced
anisotropy
[164,189,197] [182] [188]
Reduced strength – [39,189,191,
198]
[174,184,186,196,
199]
Reduced
hardness
[200–203] [194,204] [48,187,195]
Increased
elongation
[178,200,201] [39,198] [184,196]
Stress relief [171,200,205] [206] [36,185,207]
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
10
[60], which reduce the wear resistance [217].
Increasing the solution time induced recrystallization effects similar
to those in Table 5 [104,185], such as grain [104,186,218] and phase
[57] growth together with a reduction in the anisotropy [104], strength
[104,215] and hardness [57,104,218]. The amount of δ has been
described as directly proportional to solution time [52,218]. By
increasing the duration of the aging treatment, on the other hand, the
coarsening of γ’’ [67] has been reported together with the precipitation
of δ [60,67,219], which induced a reduction in bulk hardness [195].
However, on decreasing the same parameter, authors have succeeded in
increasing the ductility [220].
Some studies focused on the use of a single aging step instead of the
standard double aging have been reported [40,54,67,184,221–223].
Although authors argue that this change does not improve the me-
chanical behavior of the precipitation hardened alloys when compared
to those subjected to the traditional double aging procedure [184], two
studies on novel heat treatments based on long single aging steps indi-
cated that, in relation to the standard, they greatly improve the elon-
gation to failure results while retaining [223] or improving [54] the
strength to levels beyond that of wrought specimens.
5.2. IN625
As with IN718, the grain morphology of IN625 can be altered by
Fig. 5. – Schematic microstructures for PBF-LB Inconel 625 under as-build, direct aged, solutioned and solutioned + aged conditions
(reproduced from [224]).
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
11
solution annealing heat treatments, which can be followed by an aging
sequence for precipitation hardening. Fig. 5 provides a scheme repre-
senting the microstructures of PBF-LB IN625 samples as-built and after
various heat treatments, which correspond to the majority of results
reported in the reviewed literature for standard conditions [224]. Apart
from these cases, however, studies have been mostly focused on the
themes of annealing parameters, effects of HIP and the precipitation of
the deleterious δ phase.
Regarding the solution annealing treatment, most studies were
focused on analyzing the effect of temperature on the structure and
properties of the PBF-LB superalloy. It has been reported that higher
solution temperatures tend to reduce the anisotropy [225–227],
strength, stiffness [225] and residual stresses [92,227] of treated spec-
imens, which may be related to grain growth [225–227], twinning and
the dissolution of hard precipitates [227] under such conditions. The
Laves phase has been reported to dissolve at temperatures higher than
1040 ◦C [38] while δ preferentially precipitates at temperatures be-
tween 800 ◦C and 900 ◦C [228] and dissolves at temperatures higher
than 1000 ◦C [229], the latter being associated with a decrease in
hardness [230]. This has also been verified in a study focused on the
effect of annealing time on the behavior of the material, where a cor-
relation between the treatment time, dissolution of intercellular pre-
cipitates and decrease in dislocation density was described [231].
HIP has been commonly employed for the densification of PBF-LB
IN625 specimens [155,232,233], although its use is restricted to
metallurgical pores with no connection to the material surface [232].
This treatment has been shown to improve fatigue life [233,234], but it
greatly reduces the mechanical strength when compared to full
heat-treated specimens [35,226,234], which can be considered as a
consequence of the dissolution of hard phases and partial recrystalliza-
tion [35].
In a number of studies reported in the reviewed literature it was
found that an industry-recommended stress-relief heat treatment for
IN625 (870 ◦C for 1 h) promotes the formation of a significant amount
of the incoherent δ phase in IN625 PBF-LB specimens [46,56,235,236],
which is expected only after much longer times for wrought alloys at this
temperature [46]. It has been further shown that the TTT curve for the
precipitationof this phase is indeed moved to lower times in PBF-LB
processing [46] (Fig. 6), which evidences the easier precipitation of δ
under these conditions. This phase can be dissolved by subsequent ho-
mogenization at 1150 ◦C for 1 h [236].
5.3. IN738LC
The standard heat treatment for IN738LC is a combination of solu-
tion annealing at 1120 ◦C for 2 h followed by a single aging step at
850 ◦C for 24 h [237]. This treatment can be preceded by HIP, the in-
fluence of which is highly dependent on the applied temperature. Some
studies have shown that HIP at 1000 ◦C [237], 1120 ◦C [64] and
1180 ◦C [238] was not able to change the grain morphology or affect the
mechanical properties, but a higher temperature of 1210 ◦C produced a
different grain configuration due to widespread recrystallization, which
coarsened the γ’ precipitates and reduced the dislocation density and
overall stiffness [237]. This can also be achieved by adding extra
stress-relief [239] or recrystallization [115] steps prior to applying the
standard heat treatment, which have been reported to reduce the
anisotropy and texture of as-built materials. Both results can be associ-
ated with the γ’ solvus temperature for IN738LC, reported as approxi-
mately 1150 ◦C [237].
Another approach to altering the mechanical behavior is the inclu-
sion of an extra aging step after the solution step of the standard heat
treatment. This addition, when allied with HIP, was able to produce
better mechanical properties than those achieved solely by applying the
standard heat treatment [70]. Nonetheless, authors suggest that PBF-LB
in-situ precipitation may be a viable route for the production of IN738LC
Fig. 6. – Displacement of TTT curve for precipitation of δ phase in PBF-LB
Inconel 625
(reproduced from [46]).
Fig. 7. – Directional dependence of machining in Inconel alloys produced by PBF-LB
(reproduced from [248]).
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
12
without heat-treatments, given the intense segregation of the additive
process [240].
6. Machining
Inconel components manufactured by PBF-LB are usually submitted
to machining, which increases the dimensional precision and reduces
the surface roughness [91,241–243] and the fraction of superficial de-
fects [244] of samples. This post-processing technique is especially
important for satisfactory fatigue behavior [204,234,245].
However, the machinability of these components is strongly affected
by the microstructure of the materials. Because as-built PBF-LB speci-
mens present substantial texture and anisotropy, the machining condi-
tions and results are dependent on the direction of the material removal
in relation to PBF-LB coordinates [116,203,246–249]. In this regard,
better surface quality is expected when machining with the cutting
speed along the scanning direction instead of the build direction [248]
(Fig. 7). The final quality is further affected by the defects present in
PBF-LB components [203,249], which, on the other hand, ease the
removal of material, reduce residual stress in the part and reduce tool
wear when compared to wrought materials [203,247,249,250]. Thus,
although defects can be reduced by applying HIP, this technique hinders
the machinability [249], which is also verified after the addition of
ceramic reinforcements in the microstructure [242].
In addition, dry machining has been reported to produce better
roughness and fatigue life results than emulsion [173], and better creep
resistance was reported for samples machined by electro discharge
machining than by conventional computerized numerical control sys-
tems [40]. Methodologies have been proposed for both roughening
[251] and polishing [161,252–254] of PBF-LB Inconel internal surfaces,
as well as for the machining [255,256] and dissolution [257] of support
structures.
7. Mechanical behavior
7.1. Tensile strength
The quasi-static mechanical behavior of PBF-LB Inconel superalloys
differs from conventionally manufactured materials due to differences in
the microstructure, anisotropy and defects caused by the additive
manufacturing processing. This leads to a high variability in the material
properties [258,259], especially in the case of precipitation-hardened
alloys [259]. It has been reported that although as-built PBF-LB sam-
ples present superior strength in comparison to cast materials [64,70,
178,243,260,261], lower stiffness, strength and ductility are expected in
comparison to standard wrought superalloys [35,82,96,103,178,189,
226,232,262–266]. The ductility of additive manufacturing samples is
further affected by the fact that PBF-LB Inconel superalloys present a
strong embrittlement under high-temperature conditions, which has
been attributed to intense segregation induced by the laser processing
[35,103,201,262,266,267].
Nonetheless, the application of appropriate heat treatments can in-
crease the mechanical properties of additive-manufactured superalloys
by ameliorating detrimental microstructural artifacts such as undesir-
able precipitation and anisotropy. With this approach, strength com-
parable [45,50,175,178,179,184,189,191,264] or superior [42,51,59,
65,89,104,181,182,259,268,269] to wrought materials has been ach-
ieved for heat-treated PBF-LB Inconel superalloys. Fracture and impact
toughness of heat-treated PBF-LB IN625 have been shown to be similar
or superior to conventionally produced materials [259], despite IN718
presenting impact toughness inferior to the wrought superalloy [182].
These heat treatments not only induce stress relief, recrystallization and
precipitation of aging reinforcements [35,38,39,64,70,174,180,184,
188,191,195,199,224,226,234,263,270,271], but they have also been
associated with changes in the mechanisms of deformation responsible
for the mechanical behavior of these materials at both high temperatures
and under room-temperature conditions [237,272].
However, due to the crystallographic texture of materials produced
by additive manufacturing, their mechanical behavior tends to be
anisotropic. Although heat treatments such as HIP and pre-aging heating
cycles contribute to the isotropy of heat-treated samples [169,171,182,
225,234,273], and separate homogenization and solution steps seem to
present no benefit in relation to a single heating [44,178,180,269],
direction-dependent mechanical responses, even after heat treatments,
are well documented in the reviewed literature [274].
This directional dependence of the mechanical behavior of PBF-LB
materials is usually analyzed, for geometries produced under various
build directions, parallel to the PBF-LB cartesian coordinates. Thus,
several authors have reported that when stress is applied orthogonally to
the build plate (parallel to the build direction), all three reviewed PBF-
LB Inconel superalloys tend to present minimum relative values of
stiffness [54,89,191,221,238,260,275,276], yield [45,54,68,89,99,120,
155–157,159,171,172,179,189,191,196,221,234,260,273,276–281]
and ultimate tensile strength [35,45,54,68,89,120,155,156,159,171,
172,179,191,196,225,226,234,260,267,273,276,277,279–282]
together with maximum relative ductility [45,68,89,120,156,159,171,
191,196,198,225,260,273,280–283]. IN718 presented maximum re-
sidual stress [284] and minimum deformation anisotropy [157] when
printed under these conditions. This behavior has also been identified
after heat treatment and under high temperature conditions [45,89,159,
260], although the degree to which the mechanical strength is lost has
been reported to be independent of sample orientation [277] and the
machining of heat-treated samples seems to strongly reduce overall
mechanical anisotropy [273].
On the other hand,the relative maximum of directional mechanical
strength has been commonly identified under conditions in which the
materials are stressed at a 45◦ angle in relation to the build plate. This
direction has been reported to present either comparable [54,89,143,
159,283] or superior [35,89,104,191,226,267,271,277,285] properties
compared with those associated with loads applied parallel to the build
plate (orthogonal to the build direction). The authors of a study carried
out to compare the mechanical properties of samples under incremental
build angles arrived at the same conclusions [163]. Similar tendencies
can be verified through the observations that mechanical properties are
enhanced when specimens are loaded in directions not parallel to the
PBF-LB scan vectors [65,89,278] and that the shear properties are
likewise dependent on the build direction [286,287].
This anisotropic mechanical behavior has been associated with the
incidence, distribution and geometry of microstructural elements such
as intergranular precipitates and defects within the columnar micro-
structure of materials produced by AM [45,163,268,288,289], and thus
it has been argued that it is the most significant factor related to stiffness
[198,261] and ductility [198]. A similar tendency can be verified from
the finding that the strength of PBF-LB IN718 tends to decrease along the
build direction, which was attributed to changes in both the precipitate
density and the grain size with build height [290]. The mechanical
properties resulting from these microstructural elements can be
controlled by the appropriate choice of processing parameters [81,89,
99,113,120,143,192,261,288,291–293]. The processing conditions can
also affect the mechanical behavior of the components, as revealed by
studies on the use of multiple laser beams [270], powder recycling [292]
and varying the specimen size [283,290].
Another mechanism employed to alter the mechanical behavior of
PBF-LB Inconel superalloys is the use of the additive manufacturing
system to change the chemical composition and microstructure of the
base superalloy, either through the production of composites or by
alloying. These methods tend to increase the overall entropy of the
system, creating barriers to the dislocation motion and thus restrictively
increasing the strength while reducing the ductility. This has been
verified not only through the alloying of IN718 with Re [294] and Al
[295,296], but from the in-situ production of various composites [38,
174,188,199,297–300]. In contrast, alloying with Cu tends to increase
G.M. Volpato et al.
Additive Manufacturing 55 (2022) 102871
13
the porosity and reduce the strength [301]. A similar effect can be
observed from the influence of post-processes on the incidence of
work-hardening of the material, and thus the superficial erosion pro-
moted by techniques such as sandblasting is expected to reduce the
ductility [302] while stress-relief techniques tend to increase it [303].
An overview of the publications that focus on monotonic tensile
behavior is found in Appendix C, Fig. 1 C.
7.2. Hardness
With regard to conventional Inconel components, high hardness can
be achieved by the precipitation of coherent phases after heat treatment,
solid solution hardening, grain refinement and, in some cases, work
hardening. Although these effects can also be observed in materials
produced by PBF-LB, the high solidification rates achieved via the
manufacturing route produce considerable microstructural refinement
[93,106,122,186,195,229,261,293,304,305]. Thus, due to the
Hall-Petch effect allied to intense segregation, as-built components tend
to be harder than those produced not only by conventional methods
[220,263,306,307], but directly by other AM techniques such as
directed energy deposition (DED) [69] and powder bed fusion by elec-
tron beam (PBF-EB) [227].
Because this refined microstructure is already present in as-built
materials, the hardness of Inconel components produced by PBF-LB
can be tailored both during the primary manufacturing process and
during post-processing steps. The introduction of composite re-
inforcements to the powder bed is a reliable alternative to increase
hardness [90,122–125,293,297,308], but several authors have reported
that an efficient choice of processing parameters can lead to optimum
hardness of as-built components [65,91,122,124,125,133,136,261,293,
309]. On the other hand, other researchers have found that the behavior
of this property is independent of specific parameters [106,172,227].
Regardless of these scenarios, the hardness of the as-built refined
microstructure can be further increased by precipitation hardening heat
treatments [49,172,173,201,261,271,310], where the basic steps of
solution and aging tend to decrease [185,202,224,302] and increase
[57,58,67,171,195,202,237,302,311] the hardness, respectively. These
treatments tend to increase the grain size and dissolve hard phases such
as δ [49,202,203,227,229] and carbides [122,293] in the solution step,
but they also lead to a microstructure with greater isotropy [104,179,
310] and, through the dissolution of hard intermetallic phases, more
elements for the precipitation of aging phases [67,88,312], thus
increasing the hardness. Therefore, although brittle phases such as δ and
Laves present high hardness when considered individually, their disso-
lution increases the volume fraction of aging precipitates within a
heat-treated microstructure. This can be verified through a comparison
of the results obtained employing HIP since, although the dissolution of
δ lead to lower hardness [175], precipitation-hardened samples have
increased hardness when the heat treatment is preceded by HIP [172,
175]. Conversely, as-built samples submitted to annealing but no aging
show an increase in hardness [229,263] due to δ precipitation [229].
These heat treatments have, therefore, a considerable influence on the
hardness behavior of Inconel samples produced by PBF-LB. After heat
treatment, samples produced by PBF-EB are able to achieve comparable
hardness to those produced by PBF-LB [204], which, in turn, are not as
hard as those produced by DED [263].
Furthermore, heat treatments also homogenize the spatial distribu-
tion of hardness in PBF-LB samples [82,104,179,264], which seems to be
to some degree dependent on location after the building process. The
hardness of individual sections has often been described to be uniformly
distributed regardless of position [147,200,264,309,310] but sections
cut parallel to the build plane (i.e., the surface of the powder bed) have
been reported to be less hard than sections cut orthogonally to it [104,
179,312,313]. Nonetheless, studies show that when vertically
sectioning tall samples, there is a heterogeneous hardness distribution
due to differential precipitation of aging and intermetallic phases, which
was not present in samples built horizontally [185,314] and may be
correlated to similar results regarding mechanical strength [290]. This
indicates a possible dependence of the distribution of section hardness
on the build direction [248], which may or may not be significant [171].
Regarding surface hardness, in one study it was observed that the top
surface of as-built components seems to present the highest degree of
hardness and the bottom surface the lowest [315]. This is in agreement
with a report of low hardness at the interface between the component
and the build substrate [75] and thus the lack of support structures has
also been associated with higher overall hardness [147]. The maximum
top hardness can also be linked to the higher hardness reported in
molten regions in comparison
