118 www.skpaudio.com
F U L L R A N G E D S P
P O W E R E D S P E A K E RQWLINE
› System Type Self Powered 15”, two-way, bass-reflex
› Maximum SPL (1m) Normal: 136 dB
› Frequency Range (-10dB) 41 Hz - 19.7 kHz
› Frequency Response (±3 dB) 56,9 Hz - 17.4 kHz
› Input 1: XLR/1/4’’ combo connector with MIC/LINE selector / Input 2: XLR Line input
› Input Impedance 20K Ohms (balanced), 10K Ohms (unbalanced)
› Full Built-in DSP:
- 4 EQ USER selectable presets
- POLE, MONITOR and BRACKET location configuration
- Selectable HPF
- Bass and Treble EQ
- Signal Indicators Frontal LED function configurable, ON/OFF/LIMIT
› Dynamic Control (Input) ADFL - Adaptative Distortion Free Limiter
› Crossover Frequency 2.3 kHz
› Design Highly efficient Class-D amplifier
› Power Rating 1600W (LF 900W HF 700W)
› AC power input 100V - 240V ~ 50/60 Hz
› LF Driver 15 In woofer / 3”VC / 85 Oz / cool efficiency
› HF Driver 1.75 In Compression driver / Ferrofluid
› Coverage Pattern 90° x 50° nominal
› Enclosure FEM optimized, Asymmetrical, 18 mm, birch & poplar
› Suspension / Mounting Dual Angle 35 mm pole socket, 12 x M10 Suspension Points
› Transport 2 side handles
› Finish heavy duty paint finish
› Grille Electrostatic paint, heavy duty grill with acoustical transparent black cloth
› Dimensions (H x W x D) 750mm x 460mm x 550mm
› Weight 24 Kg
QW15 COD. 5110176
S P E C I F I C A T I O N S
B A C K P A N E L
MASTER DIMENSIONS
555 x 555 x 845 mm / 21.8 x 21.8 x 33.2 In
LOGISTICS INFORMATION
GROSS WEIGHT
27.8 Kg / 61.3 Lb
MASTER PIECES
1u
Q10 MK2 - COD. 8000973
3”Voice Coil 1.75”Compression Driver DSPFull Built-in
LARGE
DISPLAY
STEREO XLR
LINK OUT
ENCLOSURE ASYMMETRICAL,
BIRCH/POPLAR PLYWOOD
1600W
15”
P O W E R R A T I N G
W O O F E R
136dBMax SPL
119www.skpaudio.com
S E L F P O W E R E D 1 8 ”
S U B W O O F E R
QW15
QW18S
QWLINE
› System Type Self Powered 18” subwoofer
› Maximum SPL Output 135 dB peak
› Frequency Range (-10dB) 30 Hz - 150 Hz
› Frequency Response (±3 dB) 33 Hz – 121 Hz
› Inputs Two Balanced female XLR/ 1/4” combo connectors
› Input Impedance 20K Ohms (balanced)
› Signal Indicators Frontal LED function configurable, ON/OFF/LIMIT
› Dynamic Control (Input) ADFL - Adaptative Distortion Free Limiter
› System Low Pass DSP selectable
› Loop out Crossover Frequency DSP selectable
QW18S COD. 8000972
S P E C I F I C A T I O N S
› Amplifier Design Class-D amplifier
› Power Rating 1600W
› AC power input 100V - 240V ~ 50/60 Hz
› LF Driver 18 In woofer / 4”VC / cool efficiency
› Enclosure FEM optimized, Rectangular, 18 mm, birch & poplar
› Transport 2 side handles
› Finish heavy duty paint finish
› Grille Electrostatic paint, heavy duty grill with acoustical transparent black cloth
› Dimensions (H x W x D) 510 mm x 650 mm x 650 mm
› Weight 38 Kg
B A C K P A N E L
MASTER DIMENSIONS
620 x 750 x 770 mm / 24.4 x 29.5 x 30.3 In
LOGISTICS INFORMATION
GROSS WEIGHT
44 Kg / 97 Lb
MASTER PIECES
1u
Q10 MK2 - COD. 8000975
4”Voice Coil 2 COMBOXLR/TRS Inputs 135dBMax SPL DSPFull Built-in
LARGE
DISPLAY
STEREO XLR
LINK OUT
ENCLOSURE ASYMMETRICAL,
BIRCH/POPLAR PLYWOOD
18”WOOFER 1600W POWER
RATING
REINFORCED
HANDLES
35 mm.
POLE SOCKET
120 www.skpaudio.com
F U L L R A N G E D S P
B I A M P L I F I E D L O U D S P E A K E R
› 12” Woofer
› 2” Voice Coil
› 1.35” Compression Driver
› 1400 Power Rating
› MAX SPL 130dB
› 45 Hz - 20 kHz Frequency Response
› (W x H x D) 44.5*41.5*68 cm/18*17*27 inch
› Weight (net) 15.9 kg / 35 lb
› Coverage pattern 100x60°
Q12 MK2
S P E C I F I C A T I O N S
4 DSP EQ
PRESETS
ULTRA-DURABLE
POLYPROPYLENE
GABINETS
2-BAND ANALOG
EQUALIZER MASTER DIMENSIONS
MASTER DIMENSIONS
460 x 430 x 660 mm / 18.1 x 16.9 x 26 In
395 x 365 x 565 mm / 15.5 x 14.4 x 22.2 In
LOGISTICS INFORMATION
LOGISTICS INFORMATION
GROSS WEIGHT
GROSS WEIGHT
17.5 Kg / 38.6 Lb
12 Kg / 26.5 Lb
MASTER PIECES
1u
MASTER PIECES
1u
Q12 MK2 - COD. 8000970
Q10 MK2 - COD. 8000971
QMK2 SERIES
› 4 EQ Presets
› 2-Band Analog Equalizer
› 2x Mic/Line inputs XLR/TRS
› Mic/Line Selection Switch
› Aux Input
› XLR Link OUT
› Polypropylene Cabinet
› Ergonomic Handles
› 35 mm. Pole Socket
B A C K P A N E L
› 10” Woofer
› 1.5” Voice Coil
› 1” Compression Driver
› 1300 Power Rating
› MAX SPL 127dB
› 50 Hz - 20 kHz Frequency Response
› (W x H x D) 39*36*56.5 cm / 15*14*22 inch
› Weight (net) 11 kg / 24 lb
› Coverage pattern 110x60°
Q10 MK2
S P E C I F I C A T I O N S
3
CHANNEL
BI-AMP TWS
CONNECTION
121www.skpaudio.com
› 35 Hz - 20 kHz Frequency Response
› 3 Channel
› 2x XLR/TRS Input
› Mic/Line Selection Switch
› 3.5 mm Aux Input
› XLR Link OUT
F U L L R A N G E D S P
B I A M P L I F I E D L O U D S P E A K E R
Q15 MK2
S P E C I F I C A T I O N S
COD. 5110176
LARGE
DISPLAY
ULTRA-DURABLE
POLYPROPYLENE
GABINETS
XLR LINK
OUTPUT MASTER DIMENSIONS
510 x 540 x 780 mm / 20 x 21.2 x 30.7 In
LOGISTICS INFORMATION
GROSS WEIGHT
24.4 Kg / 53.8 Lb
MASTER PIECES
1u
Q15 MK2 - COD. 8000969
3
CHANNEL
BI-AMP TWS
CONNECTION
QMK2 SERIES
3”Voice Coil 1.75”Compression Driver SPL132dBM
AX DSPFull Built-in
› Polypropylene Cabinet
› Ergonomic Handles
› 35 mm Pole Socket
› (W x H x D) 41*46*69 cm / 16.1*18.1*27.1 lb
› Weight (net) 21 Kg. / 46.3 Lb.
› Coverage pattern 90x60°
15”WOOFER 1500W POWER
RATING
B A C K P A N E L
MAX POWER
1200W
MAX SPL
121DB
CLASS
D/AB
35MM
POLE SOCKET
› XLR/TRS LINE/MIC input
› XLR link output
› 250W (LF)+50W (HF) RMS
› Main volume control
› 115V / 230V -60/50 Hz Switchable
› Power amplifier design D/AB
› LED power / signal / clip indicator
› Line / MIC in switchable
› 2 way Bi-amped coaxial Speaker
› SPL MAX 121dB
› Frequency response
 70 Hz - 20 KHz
› Sensitivity 94 dB
› Woofer impedance: 4 ohm
› 10” coaxial speaker
› PLY painted cabinet
› 35mm stand pole hole
› 2 side handle
› Compact cabinet design
› Include DSP
› 5 Selectable presets
(MUSIC / FLAT / LOW CUT / STAGE / VOCAL)
S P E C I F I C A T I O N S
DIGITAL
SIGNAL
PROCESSOR
W I T H
WOOFER
10
D/
AB
SKM10A MKII
SELF POWERED COAXIAL SPEAKER
MAX POWER
1400W
SKM12A MKII
SELF POWERED COAXIAL SPEAKER
MAX SPL
123DB
CLASS
D/AB
35MM
POLE SOCKET
› XLR/TRS LINE/MIC input
› XLR link output
› 300W (LF)+50W (HF) RMS
› Main volume control
› 115V / 230V -60/50 Hz Switchable
› Power amplifier design D/AB
› LED power / signal / clip indicator
› Line / MIC in switchable
› 2 way Bi-amped coaxial Speaker
› SPL MAX 123dB
› Frequency response
 65 Hz - 20 KHz
› Sensitivity 95 dB
› Woofer impedance: 4 ohm
› 12” coaxial speaker
› PLY painted cabinet
› 35mm stand pole hole
› 2 side handle
› Compact cabinet design
› Include DSP
› 5 Selectable presets
(MUSIC / FLAT / LOW CUT / STAGE / VOCAL)
S P E C I F I C A T I O N S
DIGITAL
SIGNAL
PROCESSOR
W I T H
WOOFER
12
D/
AB
MAX POWER
1400W
MAX SPL
124DB
CLASS
D/AB
35MM
POLE SOCKET
› XLR/TRS LINE/MIC input
› XLR link output
› 300W (LF)+50W (HF) RMS
› Main volume control
› 115V / 230V -60/50 Hz Switchable
› Power amplifier design D/AB
› LED power / signal / clip indicator
› Line / MIC in switchable
› 2 way Bi-amped coaxial Speaker
› SPL MAX 124dB
› Frequency response
 55 Hz - 20 KHz
› Sensitivity 96 dB
› Woofer impedance: 4 ohm
› 15” coaxial speaker
› PLY painted cabinet
› 35mm stand pole hole
› 2 side handle
› Compact cabinet design
› Include DSP
› 5 Selectable presets
(MUSIC / FLAT / LOW CUT / STAGE / VOCAL)
S P E C I F I C A T I O N S
DIGITAL
SIGNAL
PROCESSOR
W I T H
WOOFER
15
D/
AB
SKM15A MKII
SELF POWERED COAXIAL SPEAKER
Q1 PRO
PORTABLE ACTIVE LOUDSPEAKER
Q
SERIES
TWS CONNECTION
3 CHANNEL
1
5
2 43
RECHARGEABLE
NEODYMIUM
TWEETER
LITHIUM ION BATTERY
VARIABLE DIRECTIVITYTOUCH SCREEN CONTROL
USE THIS MODE FOR
SMALL MEETINGS,
TRAINING
MONITOR USE FOR
MONITORING
USE FOR ALL TYPE
STREET PERFORMANCE,
BAND SHOW
40°(V)90°(H) 40°(V)
90°(H)
90°(V)40°(H)
600WMAX POWER
POLE
