Configuração DSLC

Page 1 of 1
GOVERNOR PART NUMBER 9905-708 SERIAL NUMBER 15382094

FIELD SERVICE NUMBER SC0036-10 DATE 18/5/2010

CUSTOMER Siner (Usina Baldin) ENGINEER César R. Oliveira

SYNCHRONIZER – MENU 1

Sync Gain 0,02
Sync Stability 1,57 Seconds
Slip Frequency Ref 0,05 Hertz
Slip Window 0,10 Hertz
Max Phase Window 08 Degrees
Voltage Matching Enabled
Voltage Window 1,0 Degrees
Deadbus Closure Disabled
Breaker Delay 0,08 Seconds
CB Close Hold Time 1,0 Seconds
Close Attempts 5
Reclose Delay 10 Seconds
Sync Reclose Alarm Disabled
Sync Timeout 0 Seconds
Sync Timeout Alarm Disabled
Auto Re-Synchronizer Disabled

LOAD CONTROL – MENU 2

Load Control Gain 0,6205
Load Stability 1,00 Seconds
Load Derivative 0,00 Seconds
Load Control Mode Proportional
Load Control Filter 1,0 Hertz
Loadshare Gain 0,72
Frequency Trimmer Disabled
Rated Load 15,00 MW
Base Load 0,70 MW
Unload Trip 0,35 MW
Load Droop 5,0 Percent
Load Time 10 Seconds
Unload Time 7 Seconds
Raise Load Rate 0,50 % / Second
Lower Load Rate 0,50 % / Second
4mA Remote Load 0,0 MW
20mA Remote Load 15,00 MW
High Limit PU 15,00 MW
High Limit DO 14,00 MW
High Limit Alarm Disabled
Low Limit PU 0,0 MW
Low Limit DO 0,20 MW
Low Limit Alarm Disabled
Load Limit Swiches Disabled
Load Switch PU 20,00 MW
Load Switch DO 18,00 MW
Reverse Power Trip Disabled
Instant Reverese Pwr -10 % Load
Rev Pwr Time Delay 10,0 Seconds
Reverse Power Level -1,0 % Load


PROCESS CONTROL – MENU 3

Process Control Gain 0,1000
Process Stability 1,00 Seconds
Process Derivative 0,00 Seconds
Process Deadband 0,10 mA
Process Droop 0,0 Percent
Process Filter 1,0 Hertz
Process Reference 12,0 mA
Raise Reference Rate 0,10 mA/Second
Lower Reference Rate 0,10 mA/Second
High Limit PU 15,0 mA
High Limit DO 15,0 mA
High Limit Alarm Disabled
Low Limit PU 10,0 mA
Low Limit DO 10,0 mA
Low Limit Alarm Disabled
Process Switches Disabled

VAR/PF CONTROL – MENU 4

VAR/PF Control Mode PF Control
VAR/PF Gain 1,00
VAR/PF Stabiliy 2,50 Seconds
Rated KVARS 10,00 MVAR
KVAR Reference 1,00 MVAR
 Generate
PF Reference 0,92 Lagging
PF Deadband 0,015
Voltage Reference 13800 Volts
Voltage Trim Disabled
Voltage Regulation 1,0 Percent
Voltage Low Limit 12420 Volts
Voltage Low Alarm Disabled
Voltage High Limit 15180 Volts
Voltage High Alarm Disabled
Voltage Switches Disabled
Voltage Range Alarm Disabled
Voltage Ramp Time 100 Seconds

CONFIGURATION – MENU 5

PT Winding Ratio 120,0 : 1
CT Rating 1000 : 5
PT Voltage Input 120 Vac
Voltage Display V-L-to-L
System Frequency 60 Hz
Process Control Action Indirect
Network Address 2
