Exercícios + Amplificador de Instrumentação

Prévia do material em texto

Exercícios com Amp. Op.
e
Amplificador de Instrumentação
Eletrônica Analógica 2
Gustavo Brito de Lima
Faculdade de Engenharia Elétrica
Universidade Federal de Uberlândia
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Introdução – Conceitos e características importantes referente a amplificadores operacionais
1
Exercício 1
Para o circuito da figura à esquerda calcule IL. Para o circuito da figura à direita calcule Vo.
1mA
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 2
Considere que se deseja monitorar três sensores (T - Temperatura, V - Vazão e D – Densidade) em um processo industrial. Cada sensor responde segundo seu gráfico específico mostrado abaixo. Os valores apresentados por estes sensores são combinados, segundo a equação 1 abaixo e geram como resultado a variável R, a qual deve ser enviada a um mostrador digital, cujo valor apresentado segue o gráfico do Mostrador Digital. Diante deste cenário, projete um circuito com AO para receber as informações dos sensores, combiná-las segundo a equação 1 e enviá-la ao Mostrador Digital, de tal forma que este mostre o valor da variável R.
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 2
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 3
Nas indústrias, a transmissão de sinais analógicos provenientes de sensores (temperatura, vazão, pressão etc) até o CLP (Controlador Lógico Programável) normalmente é feita através de sinais de corrente embasados em um padrão, definido por 4-20 mA, no qual a intensidade da corrente varia em função da variação da grandeza monitorada pelo sensor.
Este método de transmissão é utilizado como forma de aumentar a imunidade a ruídos do cabo de comunicação, uma vez que o sinal de corrente, nesta faixa de valores, é mais imune a ruídos que o sinal de tensão. Entretanto, o sinal de corrente necessita ser convertido em sinal de tensão, antes de ser aplicado à entrada analógica do CLP, o qual possui uma faixa de tensão de entrada que varia de 0 a 10 volts.
Por conta disso, sabendo-se que o valor de corrente igual a 4 mA deve produzir 0 volts na entrada do CLP e que 20 mA deve produzir 10 volts, projete um circuito, baseado em amplificadores operacionais, para converter e enquadrar o sinal de corrente em sinal de tensão na forma descrita.
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 3
Circuito Eletrônico
C
L
P
4 a 20 mA
0 a 10 V
Sensor
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 4
A figura a seguir ilustra um motor de indução trifásico acionado por um inversor de tensão (“inversor de frequência”), cuja entrada é ligada à rede elétrica com frequência de 60Hz. Pela variação da corrente de referência (IREF) de 4 a 20 mA, a velocidade de rotação do motor é controlada, variando linearmente de 0 a 2000 rpm.
A corrente de referência provém de um circuito analógico com amplificadores operacionais nas configurações “amplificador não inversor” e “conversor de tensão-corrente”. A entrada do amplificador não inversor é ligada a uma fonte de tensão constante e igual a 1V. Diante do exposto, calcule o valor da resistência do potenciômetro Rp que levará o motor à rotação de 1000 rpm. (ENADE 2014).
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 4
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 5
Conforme ilustrado na figura abaixo, considere que se deseja monitorar a intensidade da força muscular em uma atividade física através de um sinal luminoso (LED), o qual aumenta o brilho de acordo com o aumento da intensidade da força muscular. Diante desta realidade, projete um circuito que receba o sinal de tensão de um sensor de força, como mostrado abaixo, e alimente um LED, de tal forma que o brilho deste seja proporcional à intensidade da força muscular. Adote VLED = 2,0 volts e VCC = ±15volts.
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Exercício 5
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Amplificador de Instrumentação
Eletrônica Analógica 2
Gustavo Brito de Lima
Faculdade de Engenharia Elétrica
Universidade Federal de Uberlândia
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Introdução – Conceitos e características importantes referente a amplificadores operacionais
11
Tópicos Abordados nesta aula
Introdução ao Amplificador de Instrumentação
Dedução do ganho
Aplicações
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Amplificador de Instrumentação
O amplificador de instrumentação é utilizado para realizar a subtração de dois sinais (V1 e V2)
O subtrator clássico possui duas desvantagens:
Baixa impedância de entrada;
Baixo CRMM;
Um amplificador de instrumentação utiliza um pré-estágio para mitigar esses problemas.
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
13
Subtrator
Amplificador de Instrumentação
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
14
Não Inversor
Pré-Estágio – Influência de V1
Vx
Vy
Usando o Teorema da Superposição, determina-se Vx1 e Vy1 aterrando a fonte V2. Posteriormente Vx2 e Vy2 aterrando a fonte V1
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Pré-Estágio – Influência de V1
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Pré-Estágio – Resumo de V1
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Não Inversor
Pré-Estágio – Influência de V2
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Pré-Estágio – Influência de V2
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Pré-Estágio – Resumo de V2
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Pré-Estágio
Vx
Vy
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Amplificador de Instrumentação
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Aplicações – Blindagem Eletrogmagnética
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Aplicações – ECG
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Aplicações – Sensoriamento com Ponte de Wheatstone
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Aplicações – Medidor de Corrente
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Próxima Aula
Filtros Ativos
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
Referências desta aula
Complementar
Avançada
Básica
Universidade Federal de Uberlândia
Faculdade de Engenharia Elétrica
Disciplina – Eletrônica Analógica II
