1


SOLIDWORKS Certification
Exam Guide & Practice Test

CSWP: Certified
SOLIDWORKS Professional


2

Contents
About This Guide ................................................................................................................ 3
The CSWP Certification ....................................................................................................... 4
CSWP Exam Details ............................................................................................................. 5
How to Prepare for the Exam ............................................................................................. 8
How to Take This Practice Exam ........................................................................................ 9
Taking the Real Exam ....................................................................................................... 10
Test Questions .................................................................................................................. 18
Answer Key ....................................................................................................................... 27
Hints and Tips ................................................................................................................... 28
Frequently Asked Questions ............................................................................................ 29
Helpful Sites ...................................................................................................................... 32



3

About This Guide
This guide contains information, advice, and practice for becoming a Certified
SOLIDWORKS Professional. Here, you will find:
 An overview of SOLIDWORKS Certifications
 Details about the CSWP Exam
 Advice on preparing for and taking the CSWP Exam
 A Practice CSWP Segment 1 Exam and answer key
 Directions to useful SOLIDWORKS websites


4

The CSWP Certification
SOLIDWORKS Certifications are a benchmark to measure your knowledge and
competency with SOLIDWORKS software. A certification helps you stand out from the
crowd and showcases your expertise to businesses and professionals alike—a valuable
asset in a competitive job market.

A few popular SOLIDWORKS Certifications include:
 CSWA: Certified SOLIDWORKS Associate
 CSWP: Certified SOLIDWORKS Professional
 CSWPA: Certified SOLIDWORKS Professional Advanced:
o Sheet Metal
o Weldments
o Surfacing
o Mold Tools
o Drawing Tools
 CSWE: Certified SOLIDWORKS Expert
 CEPA: Certified Enterprise PDM Administrator

Why take the CSWP Exam?
The CSWP certification sets you apart as a person who has surpassed the basic skills
of SOLIDWORKS and who has developed an advanced understanding of the software.
Achieving certification establishes you as a highly competent professional in the use
of SOLIDWORKS. For hiring managers, it acts as a valuable assessment to attest for an
individual’s competency, thereby reducing the amount of time and energy required to
research prospective candidates.

Passing the CSWP, alongside four of the five CSWPA exams, is a prerequisite for
taking the CSWE Exam to become a Certified SOLIDWORKS Expert.

All candidates receive electronic certificates, business card logos, and personal listing
in the CSWP directory when they pass.

5

CSWP Exam Details
Each of the three segments are purchased as separate exam credits (they may be
purchased as a three-part bundle) and are taken in separate sittings.

Total Exam Length: 3 hours 20 minutes (All segments)
Minimum Passing grade: See details below
Re-test Policy: There is a minimum 14 day waiting period between every attempt
of the same CSWP Segment exam. Also, an exam credit for that CSWP Segment must
be purchased for each exam attempt.

The following is the topic and question breakdown of the CSWP exam:

Segment 1:
70 Minutes – 75 points to pass/105 points maximum
 Creating a part from a drawing
 Using linked dimensions and equations to aid in modeling
 Using equations to relate dimensions
 Updating parameters and dimension sizes
 Mass property analysis
 Modifying geometry on initial part to create a more complex part
 Modifying parameters on the part at different stages while maintaining all
other dimensions and design intent
Segment 2:
50 Minutes – 77 points to pass/104 points maximum
 Creating configurations from other configurations
 Changing configurations
 Creation of configurations using a Design Table
 Mass properties
 Changing and/or rearranging features of an existing SOLIDWORKS part
Segment 3:
80 Minutes - 77 points to pass/109 points maximum
 Creating an assembly
 Adding parts to an assembly
 Doing collision detection when moving a part in an assembly
 Interference detection
6

 Basic and advanced mates
 Rigid and Flexible subassemblies
 Replacing a part with another part in an assembly
 Creating a coordinate system
 Using a coordinate system to perform mass properties analysis

Standard SOLIDWORKS tools that may be covered in the exam include:
 Sketch entities - lines, rectangles, circles, arcs, ellipses, centerlines
 Sketch tools - offset, convert, trim
 Sketch relations
 Boss and cut features - extrudes, revolves, sweeps, lofts
 Fillets and chamfers
 Draft
 Shell
 Hole Wizard
 Linear, circular, and fill patterns
 Linked dimensions
 Equations
 Mirror
 Dimensions
 Feature conditions – start and end
 Multi-body parts
 Rib
 Feature scope
 Mass properties
 Move/Delete face
 Materials
 Restraints
 Inserting components - new and existing
 Standard mates and advanced mates
 Reference geometry – planes, axis, mate references
 In-context features
 Interference detection
 Suppression states
 Move/Rotate component
 Assembly features
7

 Collision detection in an assembly
 External references
 Design tables
 Dimensions and model items
8

How to Prepare for the Exam
Don’t let the exam questions take you by surprise! We recommend that you practice
the skills in the “CSWP Exam Details” section above, and that you ask for help from
experienced SOLIDWORKS users.

No details to the solutions for either this sample exam or the real test will be
shared by the SOLIDWORKS Certification team. Please consult your SOLIDWORKS
reseller, your local user group, or the on-line SOLIDWORKS forums at
forum.solidworks.com to review any topics on the CSWP exam.

A great resource is the SOLIDWORKS website (SOLIDWORKS.com).
 For training courses, go to Home > Support > Training > SOLIDWORKS
Courses.
 To download models to practice on, go to Home > Support > Training >
SOLIDWORKS Training Files
 You’ll find a wealth of access to videos, tutorials, blogs, events, and fellow
users in the SOLIDWORKS Community at Home > Resource Center

You can also log into my.solidworks.com to browse lessons, forums, models, and
much more.

Last but not least, make use of this exam guide to review realistic exam questions,
look over important topics, and familiarize yourself with the exam procedure.

To simulate test conditions, you can take the sample exam in the testing client
software. For instructions, go to the ‘Taking the Real Exam’ section.

The practice exam enclosed within is designed to give you a preview of the CSWP
without disclosing the entirety of the test. Thus, we’ve provided questions that aretypical to the hardest segment – Segment 1 – of the exam.

9

How to Take This Practice Exam
1. You must be running SOLIDWORKS on the computer, both for the practice and
actual test. SOLIDWORKS can only be installed with the Windows operating
system.
2. Excel should be installed on the computer you are running SOLIDWORKS to
ensure that your Design Table functionality works properly for the exam.
3. To simulate real conditions, it is best NOT to print this exam.
In the real test, the VirtualTester client window runs concurrently with
SOLIDWORKS, requiring you to switch between applications. Keep this
document open and consult it while running SOLIDWORKS.
4. After each question, save a version of your model in a different file for later
reference. This may also help you fix errors later on in the test.
5. The multiple choice will help you check that your model is on the right track. If
your answer is not listed in the selections offered, it is likely that there is
something wrong with your model.
6. This guide includes an answer key after the practice exam.
7. Dimensions are circled in some images to indicate new or altered dimensions.
8. This practice exam is also available to take for free on-line in the testing client
software. To take the exam in the client software, follow the instructions in the
next section.

10

Taking the Real Exam
The real exam can be taken on your personal computer at a time of your choosing.
The CSWP Exam is administered through the Tangix TesterPRO Client, an application
that you may download from the SOLIDWORKS VirtualTester website. You will need a
connection to the Internet throughout the exam.

The sample exam in this packet can also be taken in the Tangix TesterPRO Client.

If you will be running the client on a separate computer from the one that is running
SOLIDWORKS, make sure there is a way to transfer files from one computer to the
other. You will be required to download SOLIDWORKS files during the real test to be
able to correctly answer some of the questions.

To learn the testing procedure in VirtualTester, if you have a MySOLIDWORKS
account, please refer to this video:
http://my.SOLIDWORKS.com/mylearning/lessons/489/installing-and-viewing-the-
test-software

Alternatively, you may follow these steps:
1. Visit the SOLIDWORKS VirtualTester Certification Center at
https://SOLIDWORKS.virtualtester.com/.

2. Locate and click the button (right hand side of page) to download the Tangix
TesterPRO Client:



11

3. Open the downloaded folder and run the executable file:


4. Agree to the License Agreement.



12

5. Click the install button.


6. Click the finish button.



13

7. When you run the program, select your language and click Continue.

If you have already taken a SOLIDWORKS Certification Exam, skip to step 9.

8. If this is your first exam, you will need to create an account. Fill in the required
fields and click continue:

Write down your login credentials for future use!
Skip to step 10.


14

9. If you have already taken a SOLIDWORKS Certification Exam, select the option
below, fill in your credentials, and click continue.


10. If you are taking a sample exam online, scroll down and select the exam with a
gift icon.



15

11. To take an exam from a credit, select an exam that has the words ‘Start Exam’
next to it (only exams that you have credits for will show as available):

If you do not have credit for the exam, do one of the following:
 If you have an Event ID or Voucher, type it into the field on this page and
click “Submit.”
 Purchase an exam credit online. This may be found on solidworks.com:
Click Support > Certification > Exam Registration.

12. You may be asked to select a language. Select a language and click “Start
Exam.”

16


13. Confirm the exam you are about to begin:


14. Agree to the Confidentiality Agreement and Candidate Conduct Policy.



17

15. On the Examination Information page, read the information and then click
“Start Examination”, this will begin the timed portion of your exam.



















The practice exam begins on the next page.
18

Test Questions
This section will give you a general idea of Segment 1 of the CSWP Exam.
These images are to be used to answer Questions #1 – 3.
19

1. Stage 1 – Initial Part
Build this part in SOLIDWORKS.

Unit system: MMGS (millimeter, gram, second)
Decimal places: 2
Part origin: Arbitrary
Material: Alloy Steel
Density = 0.0077 g/mm^3
All holes through all unless shown otherwise

Use the following parameters and equations which correspond to the dimensions
labeled in the images:

A = 213 mm
B = 200 mm
C = 170 mm
D = 130 mm
E = 41 mm
F = Hole Wizard Standard: Ansi Metric Counterbore
 Type: Hex Bolt – ANSI B18.2.3.5M
 Size: M8
 Fit: Close
 Through Hole Diameter: 15.00 mm
 Counterbore Diameter: 30.00 mm
 Counterbore Depth: 10.00 mm
 End Condition: Through All
X = A/3
Y = B/3 + 10mm

Hint 1: The dimensions that are to be linked or updated and are variable will be
labeled with letters. Any dimensions that are simple value changes or refer to new
features from one stage to another will be circled in the images.

Hint 2: To save the most time, make use of linked dimensional values and equations.

Measure the mass of the part.
20


What is the mass of the part (grams)?

a) 14139.65
b) 14298.56
c) 15118.41
d) 14207.34


21

2. Update parameters of the initial part.

Unit system: MMGS (millimeter, gram, second)
Decimal places: 2
Part origin: Arbitrary
Material: Alloy Steel
Density = 0.0077 g/mm^3
All holes through all unless shown otherwise

Use the following parameters and equations which correspond to the dimensions
labeled in the images:

A = 225 mm
B = 210 mm
C = 176 mm
D = 137 mm
E = 39 mm
F = Hole Wizard Standard: Ansi Metric Counterbore
 Type: Hex Bolt – ANSI B18.2.3.5M
 Size: M8
 Fit: Close
 Through Hole Diameter: 15.00 mm
 Counterbore Diameter: 30.00 mm
 Counterbore Depth: 10.00 mm
 End Condition: Through All
X = A/3
Y = B/3 + 10mm

Hint 1: The dimensions that are to be linked or updated and are variable will be
labeled with letters. Any dimensions that are simple value changes or refer to new
features from one stage to another will be circled in the images.

Hint 2: To save the most time, make use of linked dimensional values and equations.

What is the mass of the part (grams)?

22

3. Update parameters of the initial part.

Unit system: MMGS (millimeter, gram, second)
Decimal places: 2
Part origin: Arbitrary
Material: Alloy Steel
Density = 0.0077 g/mm^3
All holes through all unless shown otherwise

Use the following parameters and equations which correspond to the dimensions
labeled in the images:

A = 209 mm
B = 218 mm
C = 169 mm
D = 125 mm
E = 41 mm
F = Hole Wizard Standard: Ansi Metric Counterbore
 Type: Hex Bolt – ANSI B18.2.3.5M
 Size: M8
 Fit: Close
 Through Hole Diameter: 15.00 mm
 CounterboreDiameter: 30.00 mm
 Counterbore Depth: 10.00 mm
 End Condition: Through All
X = A/3
Y = B/3 + 10mm

Hint 1: The dimensions that are to be linked or updated and are variable will be
labeled with letters. Any dimensions that are simple value changes or refer to new
features from one stage to another will be circled in the images.

Hint 2: To save the most time, make use of linked dimensional values and equations.

What is the mass of the part (grams)?

23

These images are to be used to answer Questions #4 and 5.
4. Stage 2 – Modify

24

Modify the part using the following dimensions.

Note: The changes from the initial part are concentrated in areas AA, BB and CC
shown in the images.

Unit system: MMGS (millimeter, gram, second)
Decimal places: 2
Part origin: Arbitrary
Material: Alloy Steel
Density = 0.0077 g/mm^3
All holes through all unless shown otherwise

Use the following parameters and equations which correspond to the dimensions
labeled in the images:

A = 221 mm
B = 211 mm
C = 165 mm
D = 121 mm
E = 37 mm
X = A/3
Y = B/3 + 15mm

Note: The equation for Y has changed from the initial part.

Hint 1: The dimensions that are to be linked or updated and are variable will be
labeled with letters. Any dimensions that are simple value changes or refer to new
features from one stage to another will be circled in the images.

Hint 2: To save the most time, make use of linked dimensional values and equations.

Measure the mass of the part.




25

What is the mass of the part (grams)?

a) 13095.40
b) 13206.40
c) 13313.35
d) 13395.79




26

5. Stage 2 – Update Parameters

Unit system: MMGS (millimeter, gram, second)
Decimal places: 2
Part origin: Arbitrary
Material: Alloy Steel
Density = 0.0077 g/mm^3
All holes through all unless shown otherwise

Use the following parameters and equations which correspond to the dimensions
labeled in the images:

A = 229 mm
B = 217 mm
C = 163 mm
D = 119 mm
E = 34 mm
X = A/3
Y = B/3 + 15mm

Hint 1: The dimensions that are to be linked or updated and are variable will be
labeled with letters. Any dimensions that are simple value changes or refer to new
features from one stage to another will be circled in the images.

Hint 2: To save the most time, make use of linked dimensional values and equations.

Measure the mass of the part.

What is the mass of the part (grams)?



END OF TEST
27

Answer Key
1. d) 14207.34
2. 16490.45
3. 15100.47
4. b) 13206.40
5. 14208.00



28

Hints and Tips
DISCLAIMER: IT IS UP TO YOU TO RESEARCH THESE HINTS. BEING A
PROFESSIONAL LEVEL CERTIFIED SOLIDWORKS USER SHOULD ALSO INCLUDE THE
ABILITY TO RESEARCH SOLIDWORKS FUNCTIONALITY. CONSULT HELP, YOUR VAR
AE’S, THE ON-LINE FORUMS OR BLOGS. NO ANSWERS WILL BE SHARED BY THE
CERTIFICATION TEAM!

Hint 1: Use linked (also known as “shared values”) dimensions to manage the
dimensions that are to be the same in each stage. This will ensure that the
dimensions that are to be linked together in value stay linked together.

Hint 2: Change the label of the dimensions in your part to A, B, C, D, etc. to visually
keep track of which dimensions need to be changed.

Hint 3: As an alternative to Hint #2, you can also use the Design Table to manage the
changing parameters.


29

Frequently Asked Questions
Below is a series of common questions regarding SOLIDWORKS Certifications. To
peruse more FAQs, please visit the SOLIDWORKS Certification FAQ page under Home
> Support > Certification > FAQ.
1. What is the Certified SOLIDWORKS Professional (CSWP) exam?
The CSWP exam is a comprehensive, non-proctored online exam that tests an
individual’s ability to design and analyze parametric parts and movable assemblies
using a variety of complex features in SOLIDWORKS, including design validation tools.
A Certified SOLIDWORKS Professional is an individual that has successfully passed
this exam.
2. What resources do I need to take the CSWP?
The CSWA/P test is an on-line test that can be taken on any computer that has
SOLIDWORKS running and a connection to the Internet. You are responsible for
providing your own working copy of SOLIDWORKS. A commercial license of
SOLIDWORKS or the SOLIDWORKS Student Edition will be adequate for the exams.

The test runs in its own client window separate from SOLIDWORKS. You can either
run the exam software on the same computer as your SOLIDWORKS software or in a
separate computer next to the one running SOLIDWORKS. Please note that if you are
taking the test on a separate computer that you have some means to transfer files
from the computer running the testing client to the computer running
SOLIDWORKS. Dual monitors are recommended but not required.

As stated above, an internet connection is required for the CSWA/P exams. At this
point there are no provisions for a stand-alone exam.

3. What is the policy on retaking the CSWA/P?
There is a 30-day waiting period before retaking the CSWA and any Advanced CSWP
exam. There is a 14-day waiting period before retaking any CSWP segment
exam. Also, the user will be required to purchase another exam credit to retake the
test.
30

4. What do I receive when I pass the exam?
You will receive certificates for each exam that you pass. You receive an email that
directs you to our electronic certificate access page. There you can login and
download your electronic certificate(s) and electronic business card logo(s); CSWP’s
also receive discounts to partner products and SOLIDWORKS World events. For more
information refer to www.solidworks.com/cswp.
5. Can the exam be paused?
No. Once started, exams cannot be paused.
6. I took the exam and my Internet connection failed when the test ended. How do I
report my results now?
The tester software will retry to connect for ~2 minutes. If the connection is still not
available, an error message will be displayed and a TXT file will be saved on your
desktop. The name of the file is: Tangix_TesterPro_Error_Date_Time.
Please send this file to support@tangix.com
7. Will my answers be lost if my computer crashes? Will I lose my testing credit/have
to pay again if my computer crashes?
You will have to start the examination over and no refund will be available. Once you
click ‘take exam’ your exam credit will be redeemed and we cannot refund your
payment or voucher. If your computer crashes, your answers are not recoverable.
8. Which commercial version of the software should I use to take the CSWP exams?

For all exams, the minimum version necessary is listed on the information page of
that exam. Please go to http://www.solidworks.com/certification and click on the
individual exam information page links on the left.

9. Will a certificate be mailed out to me once I pass an exam?
SOLIDWORKS no longer mails out certificates to individuals who have passed an
exam. We have made it a simple download that you can print from your computer so
you no longer have to wait to receive it. To print your certificate,
simply visit www.virtualtester.com/solidworks/user.php. On that page, simply click
31

the "Print My Certificate" button and follow the on-screen instructions. Please note
that not all exams have printable certificates.
32

HelpfulSites
SOLIDWORKS Home:
www.SOLIDWORKS.com
SOLIDWORKS Resource Center:
http://www.SOLIDWORKS.com/sw/resources.htm
SOLIDWORKS YouTube Channel:
https://www.youtube.com/user/SOLIDWORKS
MySOLIDWORKS:
my.SOLIDWORKS.com
Training Pages:
http://www.SOLIDWORKS.com/sw/support/software-training-certification.htm
