Disquete 1
Disquete
Disquete de 90mm (3½ ")
Disquete é um disco de mídia magnética
removível, para armazenamento de dados. O
termo equivalente em inglês é floppy-disk,
significando disco flexível.
Pode ter o tamanho de 3,5 polegadas com
capacidade de armazenamento de 720 KB
(DD=Double Density) até 2,88 MB (ED=Extra
Density), embora o mais comum atualmente seja
1,44 MB (HD=High Density), ou 5,25 polegadas
com armazenamento de 160 KB (Single Side =
Face Simples) até 1,2 MB (HD).
Histórico dos formatos de disquete
Um disquete de 8 polegadas.
Os (as) disquetes tiveram diferentes tamanhos e
formatos desde que foram inventados, em 1971,
com o último formato (3½-polegadas (inch) HD) a
ser definitivamente adotado.
Tipo de disco Ano Capacidade
8-inch 1971 80 kB
8-inch 1973 256 kB
8-inch 1974 800 kB
8-inch dual-sided 1975 1MB
5¼-inch 1976 160 kB
5¼-inch DD 1978 360 kB
5¼-inch QD 1984 1.2 MB
3-inch 1984? 320 kB
Disquete 2
3½-inch 1984 720 kB
3½-inch HD 1987 1.44 MB
3½-inch ED 1991 2.88 MB
Outras características dos disquetes
Disquete de 5"1/ 4
Disquete de formato 5,25 polegadas,
atualmente em desuso.
Tipo Usado em Setores por
trilha
trilhas por
Face
Capacidade Taxa de transferência de
bits
Dupla
Densidade
P.C./XT 8 40 160/320 KB 250 KBit/s
Dupla
Densidade
P.C./XT 9 40 180/360 KB 250 KBit/s
Alta Densidade AT 15 80 1,2 MB 500 KBit/s
A capacidade dos disquetes 5"1/4, nos modelos mais antigos de leitora, é limitado a uma
face. Neste caso, embora a mídia permita, apenas uma das faces é acessada de cada vez.
Nos modelos mais novos, com duas cabeças de leitura/escrita, ambas as faces são
acessadas.
Disquete de 3"1/ 2
Tipo Usado em Setores por
trilha
Trilhas por
Face
Capacidade Taxa de transferência
de bits
Dupla Densidade P.C./XT 9 80 720 KB 250 Kbit/s
Alta Densidade AT 18 80 1,44 MB 500 Kbit/s
Alta Densidade
Extra
AT 36 80 2,88 MB 1 Mbit/s
Disquete 3
Por dentro do disquete
Legenda:
1 - Trava de proteção contra escrita.
2 - Base central. 3 - Cobertura móvel.
4 - Chassi (corpo) plástico. 5 - Disco
de papel. 6 - Disco magnético. 7 -
Setor do disco.
Os disquetes possuem a mesma estrutura de um disco
rígido sendo todos periféricos de entrada e saida, tendo
como diferenças o fato dos disquetes poderem ser
removíveis e o fato dos disquetes serem compostos de
um único disco magnético.
Os disquetes são divididos em pistas. Um conjunto de
pistas concêntricas repartidas em intervalos regulares
definem a superfície magnética do disco. As pistas são
numeradas de 0 a n, sendo n o número total. A pista 0 é a
mais externa.
Cada cilindro é dividido em um número constante de
partes de mesmo tamanho, denominado setor. O nome
destes depende do formato do disquete e são numerados
de 1 até n, sendo n o número de setores por pista.
Cada setor possui o tamanho de 512 bytes. O setor (ou
bloco) é a menor porção do disco que o computador
consegue ler.
O disco magnético geralmente é dividido em duas faces,
denominadas 0 e 1. Alguns leitores mais atuais, visto que
os discos possuem essas duas faces, são equipados com
duas cabeças de leitura/escrita, uma para cada face do
disco.
Para se calcular a capacidade do disquete, pode-se usar a
fórmula: Número de faces × número de pistas × números
de setores/pista × 512 bytes/setor.
Problemas
As unidades de leitura geralmente possuem um botão que, se pressionado ejeta o disquete.
A possibilidade de ejetar o disquete mecanicamente pode acarretar erros de leitura, ou até
mesmo a perda de todos os dados contidos no disquete caso a ejeção seja feita durante um
processo de leitura. Uma exceção a isso é constituído pelas unidades de leitura dos
computadores Macintosh, nos quais a ejeção do disco é comandada pelo sistema
operacional e realizada através de um motor interno.
Um outro problema é referente a sua vida útil. Os disquetes possuem vida útil que varia de
5 a 6 anos (pouco, se for comparado ao CD, que dura 20 anos). Disquetes mais velhos e com
muito uso, começam a desprender fragmentos do disco magnético interno, sendo que
alguns desses fragmentos podem grudar nas cabeças de leitura, dificultando muito a
leitura/escrita de outros disquetes. Para essa situação, é recomendável utilizar um
"disquete" especial para limpeza, em que no lugar do disco magnético fica localizado um
tecido para limpeza.
Disquete 4
Desuso
Disquete
estilizado.
O disquete já foi considerado um dispositivo com grande capacidade de
armazenamento, especialmente devido ao pequeno tamanho dos arquivos.
Atualmente, devido ao tamanho cada vez maior dos arquivos e, devido à
existência de mídias de armazenamento não-voláteis de maior capacidade,
como Zip Disks, cartões de memória (memory sticks, cartões MMC, cartões
SD, ...), Flash Drives USB (muitas vezes em formato de chaveiro), CD-R,
CD-RW, DVD gravável e regravável; além de existir outras maneiras de
guardar arquivos, como armazenamento distribuído em redes locais, e-mail e disco virtual,
o disquete se tornou um utilitário obsoleto. Muitos fabricantes de computadores dão como
certa a "morte" dos disquetes e que os computadores do futuro não terão mais drives de
disquetes. O maior problema em relação aos disquetes é justamente o problema do disquete
velho : o disquete possui uma "vida útil" de 5 anos. Após esse prazo, a sua camada
magnética começa a se danificar e aí pode haver perda de dados. O pior dessa situação é
que a camada magnética começa a realmente se descolar da camada plástica do disquete,
sujando as cabeças de leitura/gravação. Para resolver esse problema, basta limparmos as
cabeças de leitura e gravação da unidade de disquete com um disco de feltro especial. Em
geral esse disco vem junto com um vidrinho contendo álcool isopropílico que é usado na
limpeza.
Meio de Contaminação de Vírus
Os disquetes foram os primeiro transmissores de vírus de computador, no fim dos anos 80,
o Vírus Ping-Pong, Vírus Stoned, Vírus Jerusalem e Vírus Sexta-Feira 13 eram disseminados
através do disquete. Que contaminava o PC quando inserido na máquina, e após contaminar
ele contaminava qualquer outro disquete sem vírus que fosse inserido no driver do PC. Até
o surgimento na Internet, o disquete era o único meio de propagação de vírus que existia.
• "Camisinha"
Na época o único meio de proteger um disquete contra vírus era colocar um selo no lacre
quadrangular superior ou, no caso dos disquetes de 3"½, ativar a trava de proteção contra
escrita, de forma a impedir que o PC gravasse qualquer coisa no disquete, fazendo dele um
meio de leitura de dados somente, protegendo assim, de vírus.
