avaliacao de ruido DOSIMETRIA 2 LEANDRO DE JESUS -LUZIANIA

Prévia do material em texto

Relatório dosimetria de ruído @ SONUS 2 SN: 032000039
 1 de 5
Empresa avaliada: SERRA DA MESA TRANSMISSORA DE ENERGIA S. A. Data: 11/11/2020
Setor: BASE REGIONAL LUZIANIA.
Funcionário avaliado: LEANDRO DE JESUS ANDRADE
Jornada de trabalho [hh:mm]: 08:00
Configuração dos dosímetros
Dosímetro NR15 Curva
de ponderação: A
Ponderação de tempo: Lenta (S)
Nível limiar (TL) [dB]: 80
Critério de referência (CR) [dB]: 85
Duplicação de dose (Q) [dB]: 5
Dosímetro NHO01
Curva de ponderação: A
Ponderação de tempo: Lenta (S)
Nível limiar (TL) [dB]: 80
Critério de referência (CR) [dB]: 85
Duplicação de dose (Q) [dB]: 3
 Dosímetro USER
Curva de ponderação: A
Ponderação de tempo: Lenta (S) Nível
limiar (TL) [dB]: 80
Critério de referência (CR) [dB]: 85
Duplicação de dose (Q) [dB]: 5
Resultado da avaliação
Duração: 06:00:00 Início:
10:10:52
 Tempo em pausa: 00:57:01 Fim:
17:06:53
Dosímetro NR15
Dose [%]: 3,82
Dose diária [%]: 5,09
Lavg [dB]: 63,53 NE
[dB]: 63,52
NEN [dB]: 63,52
TWA [dB]: 61,45
Ocorrências de picos de 115 dB: 0
Dosímetro NHO01
Dose [%]: 4,58 Dose
diária [%]: 6,11
Leq [dB]: 72,90
NE [dB]: 72,90
NEN [dB]: 72,90
TWA [dB]: 71,65
Dosímetro USER
Dose [%]: 3,82
Dose diária [%]: 5,09
Lavg [dB]: 63,53 NE
[dB]: 63,52
NEN [dB]: 63,52
TWA [dB]: 61,45
Registro de calibração
Verificação de campo @ 1kHz
Pré verificação [dB]: 114,00 (11/11/2020 08:45)
Pós verificação [dB]: 114,00 (11/11/2020 17:06:00)
Calibração de laboratório
Dosímetro: CTR8978/2019 02/12/2019
Calibrador de áudio: cr2 criffer 36000019
Gráficos
 Bandas
de oitavas
Relatório dosimetria de ruído @ SONUS 2 SN: 032000039
 2 de 5



Ind

D/H

L [dB]

Ind

D/H

L [dB]

Ind

D/H

L [dB]

Ind

D/H

L [dB]

Ind

D/H

L [dB]

Relatório dosimetria de ruído @ SONUS 2 SN: 032000039
 3 de 5
 001 10:10:52 77,29 056 11:05:52 55,38 111 12:00:52 55,75 166 12:55:52 60,48 221 14:47:53 62,61
 002 10:11:52 77,36 057 11:06:52 56,90 112 12:01:52 60,61 167 12:56:52 52,67 222 14:48:53 56,20
 003 10:12:52 76,84 058 11:07:52 58,31 113 12:02:52 55,12 168 12:57:52 54,12 223 14:49:53 55,74
 004 10:13:52 74,53 059 11:08:52 55,27 114 12:03:52 56,78 169 12:58:52 53,39 224 14:50:53 70,06
 005 10:14:52 74,93 060 11:09:52 56,75 115 12:04:52 55,01 170 12:59:52 53,06 225 14:51:53 57,03
 006 10:15:52 82,91 061 11:10:52 60,57 116 12:05:52 53,31 171 13:00:52 56,72 226 14:52:53 56,67
 007 10:16:52 77,04 062 11:11:52 57,07 117 12:06:52 54,02 172 13:01:52 55,07 227 14:53:53 56,07
 008 10:17:52 80,87 063 11:12:52 60,99 118 12:07:52 54,59 173 13:02:52 56,44 228 14:54:53 58,28
 009 10:18:52 81,34 064 11:13:52 70,00 119 12:08:52 64,61 174 13:03:52 70,59 229 14:55:53 70,37
 010 10:19:52 86,05 065 11:14:52 69,99 120 12:09:52 53,68 175 13:04:52 66,61 230 14:56:53 70,68
 011 10:20:52 87,46 066 11:15:52 68,88 121 12:10:52 55,53 176 13:05:52 57,04 231 14:57:53 72,03
 012 10:21:52 78,07 067 11:16:52 73,51 122 12:11:52 63,54 177 13:06:52 55,00 232 14:58:53 72,76
 013 10:22:52 59,53 068 11:17:52 69,31 123 12:12:52 67,91 178 13:07:52 55,73 233 14:59:53 78,67
 014 10:23:52 62,57 069 11:18:52 67,67 124 12:13:52 74,13 179 13:08:52 55,19 234 15:00:53 70,82
 015 10:24:52 56,39 070 11:19:52 69,61 125 12:14:52 64,59 180 13:09:52 71,71 235 15:01:53 72,83
 016 10:25:52 59,24 071 11:20:52 66,80 126 12:15:52 66,70 181 14:07:53 74,40 236 15:02:53 83,81
 017 10:26:52 55,63 072 11:21:52 67,86 127 12:16:52 66,74 182 14:08:53 62,46 237 15:03:53 85,77
 018 10:27:52 62,58 073 11:22:52 65,56 128 12:17:52 56,44 183 14:09:53 62,56 238 15:04:53 73,59
 019 10:28:52 58,60 074 11:23:52 58,03 129 12:18:52 53,74 184 14:10:53 81,28 239 15:05:53 75,54
 020 10:29:52 41,72 075 11:24:52 63,34 130 12:19:52 54,84 185 14:11:53 87,49 240 15:06:53 67,84
 021 10:30:52 61,52 076 11:25:52 56,89 131 12:20:52 54,22 186 14:12:53 74,17 241 15:07:53 72,55
 022 10:31:52 56,43 077 11:26:52 63,36 132 12:21:52 54,64 187 14:13:53 67,23 242 15:08:53 57,90
 023 10:32:52 59,40 078 11:27:52 66,30 133 12:22:52 54,19 188 14:14:53 78,17 243 15:09:53 52,36
 024 10:33:52 59,33 079 11:28:52 69,34 134 12:23:52 55,55 189 14:15:53 71,67 244 15:10:53 52,22
 025 10:34:52 58,79 080 11:29:52 72,78 135 12:24:52 54,58 190 14:16:53 81,67 245 15:11:53 67,32
 026 10:35:52 57,63 081 11:30:52 72,32 136 12:25:52 52,93 191 14:17:53 85,30 246 15:12:53 75,84
 027 10:36:52 58,10 082 11:31:52 74,88 137 12:26:52 53,19 192 14:18:53 81,23 247 15:13:53 78,36
 028 10:37:52 59,91 083 11:32:52 69,95 138 12:27:52 53,89 193 14:19:53 79,69 248 15:14:53 82,59
 029 10:38:52 58,13 084 11:33:52 73,71 139 12:28:52 53,85 194 14:20:53 83,22 249 15:15:53 77,96
 030 10:39:52 52,97 085 11:34:52 74,49 140 12:29:52 53,85 195 14:21:53 83,57 250 15:16:53 81,47
 031 10:40:52 69,60 086 11:35:52 80,62 141 12:30:52 56,79 196 14:22:53 82,28 251 15:17:53 73,16
 032 10:41:52 75,25 087 11:36:52 75,79 142 12:31:52 53,58 197 14:23:53 78,45 252 15:18:53 64,75
 033 10:42:52 66,12 088 11:37:52 66,92 143 12:32:52 52,64 198 14:24:53 78,31 253 15:19:53 65,57
 034 10:43:52 68,41 089 11:38:52 71,10 144 12:33:52 51,44 199 14:25:53 79,64 254 15:20:53 66,25
 035 10:44:52 81,15 090 11:39:52 71,53 145 12:34:52 53,49 200 14:26:53 66,17 255 15:21:53 69,75
 036 10:45:52 79,22 091 11:40:52 75,75 146 12:35:52 55,13 201 14:27:53 73,66 256 15:22:53 65,94
 037 10:46:52 85,08 092 11:41:52 67,62 147 12:36:52 56,96 202 14:28:53 53,79 257 15:23:53 64,45
 038 10:47:52 68,60 093 11:42:52 68,07 148 12:37:52 53,09 203 14:29:53 55,47 258 15:24:53 65,34
 039 10:48:52 57,91 094 11:43:52 62,30 149 12:38:52 55,31 204 14:30:53 60,75 259 15:25:53 66,97
 040 10:49:52 57,76 095 11:44:52 62,35 150 12:39:52 64,14 205 14:31:53 67,80 260 15:26:53 69,27
 041 10:50:52 77,21 096 11:45:52 68,86 151 12:40:52 54,37 206 14:32:53 61,80 261 15:27:53 70,54
 042 10:51:52 71,61 097 11:46:52 63,51 152 12:41:52 54,13 207 14:33:53 54,52 262 15:28:53 59,23
 043 10:52:52 70,86 098 11:47:52 68,63 153 12:42:52 54,77 208 14:34:53 52,87 263 15:29:53 66,61
 044 10:53:52 71,14 099 11:48:52 81,00 154 12:43:52 56,97 209 14:35:53 57,28 264 15:30:53 73,74
 045 10:54:52 75,13 100 11:49:52 82,34 155 12:44:52 55,31 210 14:36:53 52,56 265 15:31:53 67,78
 046 10:55:52 74,12 101 11:50:52 67,51 156 12:45:52 59,94 211 14:37:53 52,01 266 15:32:53 68,95
 047 10:56:52 73,71 102 11:51:52 66,76 157 12:46:52 54,78 212 14:38:53 53,52 267 15:33:53 73,08
 048 10:57:52 72,05 103 11:52:52 69,63 158 12:47:52 59,35 213 14:39:53 53,26 268 15:34:53 55,14
 049 10:58:52 68,93 104 11:53:52 64,20 159 12:48:52 55,54 214 14:40:53 53,94 269 15:35:53 63,60
 050 10:59:52 73,34 105 11:54:52 61,21 160 12:49:52 55,88 215 14:41:53 55,65 270 15:36:53 53,60
 051 11:00:52 69,47 106 11:55:52 62,30 161 12:50:52 54,24 216 14:42:53 53,05 271 15:37:53 65,78
 052 11:01:52 69,21 107 11:56:52 69,45 162 12:51:52 53,46 217 14:43:53 53,46 272 15:38:53 67,47
 053 11:02:52 71,39 108 11:57:52 64,60 163 12:52:52 51,99 218 14:44:53 55,69 273 15:39:53 58,92
 054 11:03:52 57,65 109 11:58:52 64,17 164 12:53:52 51,43 219 14:45:53 66,84 274 15:40:53 59,82
055 11:04:52 58,37 110 11:59:52 56,00 165 12:54:52 53,00 220 14:46:53 72,05 275 15:41:53
 68,93 Ind D/H L [dB] Ind D/H L [dB] Ind D/H L [dB] Ind
 D/H L [dB] Ind D/H L [dB]
Relatório dosimetria de ruído @ SONUS 2 SN: 032000039
 4 de 5
27615:42:53 79,76 331 16:37:53 73,44

Relatório dosimetria de ruído @ SONUS 2 SN: 032000039
 5 de 5
277 15:43:53 82,33 332 16:38:53 72,13
278 15:44:53 77,21 333 16:39:53 68,68
279 15:45:53 69,04 334 16:40:53 71,65
280 15:46:53 57,41 335 16:41:53 73,31
281 15:47:53 61,17 336 16:42:53 73,09
282 15:48:53 77,91 337 16:43:53 72,99
283 15:49:53 66,07 338 16:44:53 64,77
284 15:50:53 65,24 339 16:45:53 72,68
285 15:51:53 69,57 340 16:46:53 67,00
286 15:52:53 70,07 341 16:47:53 71,90
287 15:53:53 58,15 342 16:48:53 69,74
288 15:54:53 66,80 343 16:49:53 65,89
289 15:55:53 73,18 344 16:50:53 71,37
290 15:56:53 66,45 345 16:51:53 69,19
291 15:57:53 73,27 346 16:52:53 54,38
292 15:58:53 60,15 347 16:53:53 54,63
293 15:59:53 52,96 348 16:54:53 55,39
294 16:00:53 53,36 349 16:55:53 66,52
295 16:01:53 54,01 350 16:56:53 55,98
296 16:02:53 55,21 351 16:57:53 67,89
297 16:03:53 54,01 352 16:58:53 75,45
298 16:04:53 53,07 353 16:59:53 74,07
299 16:05:53 52,73 354 17:00:53 68,69
300 16:06:53 54,31 355 17:01:53 54,06
301 16:07:53 55,27 356 17:02:53 55,42
302 16:08:53 54,61 357 17:03:53 71,25
303 16:09:53 53,54 358 17:04:53 83,54
304 16:10:53 53,88 359 17:05:53 81,01
305 16:11:53 60,06 360 17:06:53 83,11
306 16:12:53 68,58
307 16:13:53 78,70
308 16:14:53 69,75
309 16:15:53 70,47
310 16:16:53 54,28
311 16:17:53 54,34
312 16:18:53 53,74
313 16:19:53 53,34
314 16:20:53 54,87
315 16:21:53 56,14
316 16:22:53 54,98
317 16:23:53 55,33
318 16:24:53 54,02
319 16:25:53 56,76
320 16:26:53 71,75
321 16:27:53 78,97
322 16:28:53 79,11
323 16:29:53 70,63
324 16:30:53 77,57
325 16:31:53 59,28
326 16:32:53 58,32
327 16:33:53 61,42
328 16:34:53 53,31
329 16:35:53 53,29
330 16:36:53 56,17
