PROBLEM 12.44
A 130-lb wrecking ball B is attached to a 45-ft-long steel cable
AB and swings in the vertical arc shown. Determine the tension
in the cable (a) at the top C of the swing, (b) at the bottom D of
the swing, where the speed of B is 13.2 ft/s.

SOLUTION
(a) At C, the top of the swing, 0;Bv = thus

2
0B
n
AB
v
a
L
= =
 0: cos 20 0n BA BF T WΣ = − ° =
 or (130 lb) cos 20BAT = × °
 or 122.2 lbBAT = 
(b)
2( )
:Σ = − = B D
n n BA B B
AB
v
F ma T W m
L
 or
2
2
130 lb (13.2 ft/s)
(130 lb)
45 ft32.2 ft/s
BAT
   = +         

 or 145.6 lbBAT = 
