FULL LENGTH ARTICLE
Low temperature processed CO2 laser-assisted RF-sputtered GaN thin film for
wide bandgap semiconductors
Seoung-Hyoun Kima, Chang-Hyeon Job, Min-Sung Baeb, Masaya Ichimurac and Jung-Hyuk Koha
aSchool of Electrical and Electronics Engineering, Chung-Ang University, Seoul, Republic of Korea; bGraduate School of Intelligent Energy
and Industry, Chung-Ang University, Seoul, Republc of Korea; cDepartment of Electrical and Mechanical Engineering, Nagoya Institute of
Technology, Nagoya, Japan
ABSTRACT
Owing to its wide bandgap (3.4 eV) and high electron mobility, GaN has attracted significant
attention for applications in solar cells, power transistors, and high-electron-mobility transis-
tors. Crystallized GaN thin film can be hardly prepared in thin film form by employing physical
vapor deposition processes, such as reactive RF sputtering and pulsed laser deposition,
because a high driving energy is required to deposit a thin film due to its high binding energy.
Herein, GaN thin films were prepared by CO2 laser-assisted RF sputtering at a relatively low
temperature of 200°C. The CO2 laser with a 10,600 nm wavelength shows excellent conversion
efficiency from optical energy to thermal energy. At the optimized laser energy density of
0.98 W/mm2, GaN thin film can have a (0002) orientation with a bandgap energy of 3.26 eV. The
crystalline, surface morphological, and optical properties of the fabricated GaN thin films were
evaluated using X-ray diffraction, FE-SEM, X-ray photoelectron (XPS), and photoluminescence
(PL) spectroscopy, and UV-vis spectrometry. The energy bandgap of the fabricated GaN thin
film was measured using the Tauc plot and confirmed via PL. The film composition thus
obtained was analyzed using XPS.
ARTICLE HISTORY
Received 1 July 2022
Accepted 20 November 2022
KEYWORDS
CO2 laser; RF-magnetron
sputtering; thin films;
crystallization; GaN
1. Introduction
Wide energy bandgap semiconductors, such as 4 H-SiC
(3.23 eV), β-Ga2O3 (4.8–4.9 eV), GaAs (1.43 eV), and GaN
(3.4 eV), have been extensively investigated. In particular,
gallium nitride (GaN) has attracted attention for power
device applications because of its wide energy bandgap
(3.4 eV), high thermal conductivity (1.3 W/(cm·K) at 300 K),
high lateral breakdown voltage (10 kV), and high electron
mobility (1000 cm2/(V·s at 300 K)) [1–3]. They have there-
fore been used in various applications such as LED, high-
power transistors, and high-frequency devices [4–7]. Wide
energy bandgap semiconductors are especially promis-
ing for power device applications that can withstand high
voltages and currents even at high temperatures. Such
devices should exhibit low leakage currents at high elec-
tric fields, low thermal currents at high temperatures, and
low switching currents at high frequencies. A high current
or fast switching can sometimes induce significant heat-
ing problems during operation; therefore, power devices
should not be influenced by the surrounding thermal
atmosphere.
For GaN materials, single crystals or epitaxial thin films
are difficult to prepare. Therefore, heteroepitaxial wafers
are typically prepared using hydride vapor phase epitaxy
(HVPE), metal–organic chemical vapor deposition
(MOCVD), or molecular beam epitaxy (MBE) processes
on GaAs heterogeneous substrates. To deposit a GaN
epitaxial thin film on a single-crystal substrate, HVPE and
MOCVD are typically employed. However, owing to the
toxicity of CVD precursors, physical vapor deposition
(PVD) processes are preferred for growing GaN thin films
[8–10]. In Table 1, the different processes for preparing
GaN thin films are summarized. As presented in the table,
an extremely high substrate temperature surpassing
500°C is typically required to grow GaN thin films using
CVD, while even higher temperatures exceeding 800°C
are required for PVD. These conditions suggest the diffi-
culty of growing GaN thin films because of their high
melting temperature and high energy bandgap. To
date, many PVD processes, including sputtering, MBE,
and pulsed laser deposition, have been used to grow
GaN thin films [11–13]. Among these processes, radio
frequency (RF) magnetron sputtering is a representative
PVD process [14–18]. Owing to its high melting tempera-
ture of 1600°C, GaN requires high energy to form a thin
film. Therefore, high processing energy with high vacuum
pressure are key requirements in the processing chamber
system. Owing to its reliability and controllability, the
substrate heating method is preferred to provide suffi-
cient energy for the thin film process during PVD.
However, high thermal energy cannot be transferred to
the thin films in a vacuum chamber system with a direct
substrate heating process because high vacuum condi-
tions cannot be sustained at the high temperatures
required in the processing chamber. In addition, re-
evaporation occasionally occurs because of the high
CONTACT Jung-Hyuk Koh jhkoh@cau.ac.kr Chung-Ang University, 84 Heokseok-Dong, 84 Heokseok-Dong, Seoul, Republic of Korea
JOURNAL OF ASIAN CERAMIC SOCIETIES
2023, VOL. 11, NO. 1, 68–79
https://doi.org/10.1080/21870764.2022.2151102
© 2022 The Author(s). Published by Informa UK Limited, trading as Taylor & Francis Group on behalf of The Korean Ceramic Society and The Ceramic Society of Japan.
This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0/), which permits
unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
http://www.tandfonline.com
https://crossmark.crossref.org/dialog/?doi=10.1080/21870764.2022.2151102&domain=pdf&date_stamp=2023-03-02
substrate temperature in the chamber. Therefore, high-
quality thin films cannot be grown using a standard mag-
netron sputtering process at elevated temperatures.
High quality of GaN thin films is very important for the
power devices applications. Especially, single crystalline
thin film is attractive for deviceapplications due to their
low defects. Therefore, the main purpose of this experi-
ment is to obtain a high-quality polycrystalline thin film
for power devices with characteristics similar to that of
a single-crystal thin film. To obtain a high-quality GaN thin
film, a CO2 laser (wavelength 10,600 nm, beam diameter
3.8 mm) was used in the RF sputtering process. In addi-
tion, the Ar-dependent plasma conditions were varied to
optimize the gas processing conditions. The crystallinity
of the GaN thin films was controlled by varying the pro-
cessing conditions. The crystalline structure and surface
were analyzed using X-ray diffraction (XRD) patterns and
scanning electron microscopy (SEM) images. The Tauc
plot constructed using the transmittance values and
photoluminescence (PL) spectra was analyzed and com-
pared to extract the energy bandgap values.
2. Experimental
A CO2 laser-assisted RF sputtering process was used to
deposit GaN thin films on sapphire substrates. A pre-
sputtering process was performed to clean the target
and sapphire (c-plane) substrate. To supply sufficient
energy during thin-film growth for GaN wide bandgap
materials, a CO2 laser (wavelength of 10,600 nm, beam
diameter of 3.8 mm) was used to irradiate the substrate
during RF sputtering. Irradiated optical energy can pro-
mote thin-film growth with sputtered adatoms in the
substrate. A schematic of the CO2 laser-assisted RF sput-
tering system used in this study is shown in Figure 1.
A ZnSe single-crystal viewport was employed to transfer
photon energy from the laser to the vacuum chamber in
the sputtering system. The substrate temperature and
working pressure during sputtering were 200°C and 15
mTorr, respectively. The processing energy, Ar partial
pressure, and laser energy density during the CO2 laser
assisted RF sputtering process ranged between 100 and
200 W, 20% and 80%, and 0 and 1.16 W/mm2, respec-
tively. The crystal structure of the prepared GaN thin film
was determined through XRD analysis, and New D8-
Advance (Bruker-AXS) using CuKα radiation was ana-
lyzed under 40 kV and 40 mA conditions. The composi-
tion of the prepared thin film was determined through
X-ray photoelectron spectroscopy (XPS) and analyzed
using the AlKα line of K-alpha+ (Thermo Fisher
Scientific). The transmittance was measured using a UV
spectrometer Lambda 35 (Perkin Elmer), and a Tauc plot
was used to extract the light energy bandgap through
the transmittance value. The extracted energy bandgap
was compared with the simulated energy bandgap
measured by PL spectroscopy. Photoluminescence
spectra were measured using a HeAg 30 Deep UV laser
source at room temperature.
Table 1. Deposition methods, substrates, and corresponding substrate temperatures.
Type Deposition method Substrate
Substrate
Temperature
(°C) Phase
Chemical vapor deposition Metalorganic chemical vapor deposition c-plane sapphire 500 Polycrystalline[8]
1000 Single crystal[20]
Hydride vapor phase epitaxy c-plane sapphire 600 Polycrystalline[9,10]
1000- Single crystal[19]
Physical vapor deposition Pulsed laser deposition c-plane sapphire 700 Polycrystalline[11,12]
Molecular beam epitaxy c-plane sapphire 600 Polycrystalline[13]
750 Single crystal[20]
RF magnetron sputtering Liquid Ga target Quartz, c-plane sapphire 860 Polycrystalline[17,18]
GaAs target Quartz 850 Polycrystalline[15,16]
GaN target Glass 200–300 Amorphous[14]
Figure 1. Schematic of the CO2 laser-assisted RF sputtering system.
JOURNAL OF ASIAN CERAMIC SOCIETIES 69
3. Results and discussion
The X-ray diffraction patterns of the RF-sputtered GaN
thin films fabricated by varying the Ar partial pressure are
shown in Figure 2. The RF sputtering process conditions
were as follows: a substrate temperature of 200°C, RF
power of 200 W, and working pressure of 15 mTorr. The
Ar partial pressure was varied from 20% to 80% in 20%
increments. The optimized partial pressure was consid-
ered and discussed to improve crystalline properties. As
the Ar partial pressure increased to 60%, the (1010) peak
of GaN was observed. The observed (1010) diffraction
peaks of the RF-sputtered GaN thin films were attributed
to the nonpolar planes of wurtzite GaN, which suggested
the successful fabrication of the wurtzite GaN film. Black
GaN films with poor crystallinity can be produced under
low processing energy conditions during sputtering,
which may result in the destruction of the atomic struc-
ture [14]. However, the GaN thin films fabricated in this
study were not black in color. The intensity of the (1010)
diffraction peak related to the nonpolar plane showed
the peak when the ratio of reactive gas N2 and inert gas
Ar was properly mixed. The Ar-to-N2 gas ratio depends on
the plasma density; thus, the Ar partial pressure in the
plasma can affect the crystallinity of GaN thin films
because the plasma quality is affected by the discharge
current with Ar ions . This is consistent with previous
reports stating that plasma density and discharge current
increase with increasing Ar partial pressure [21]. In
Figure 2, the GaN(1010) orientation diffraction peak (C.
P.S) values were (a) 689, (b) 1030, (C) 722, (d) 709, and (e)
sapphire substrate 688. Therefore, we confirmed that
optimizing the Ar partial pressure during RF sputtering
is an important step in the GaN thin-film process. The
maximum intensity of the (1010) diffraction peak near 32°
is observed at an Ar partial pressure of 60%.
Figure 3 shows the X-ray diffraction patterns of the RF-
sputtered GaN thin films fabricated under different RF
power conditions. The generated power in the RF
Figure 2. X-ray diffraction patterns of the RF-sputtered GaN thin films deposited on sapphire substrates at the temperature of
200°C, RF power of 200 W, and working pressure of 15 mTorr, with different Ar partial pressure conditions (a) – (d) and without
thin-film fabrication process (e).
70 S.-H. KIM ET AL.
sputtering process was varied from 100 W to 200 W.
Owing to the limitations of the RF power source, the
generated output power was restricted to 200 W. The
processing temperature, working pressure, and Ar partial
pressure were 200°C, 15 mTorr, and 60% of Ar/(N2+ Ar),
respectively. The intensity of the (1010) reflection peak
increased with the increase in the applied RF power, indi-
cating that a high energy is necessary to effectively grow
GaN thin films through RF sputtering. A high RF power can
help introduce high-quality plasma with high kinetic
energy into the chamber during sputtering.
Consequently, the high kinetic energy in the plasma can
be transferred to the GaN thin films during fabrication.
Figure 4 displays X-ray diffraction patterns of the CO2-
laser-assisted RF-sputtered GaN thin films deposited on
a sapphire substrate at a low temperature of 200°C. The
laser energy density was varied from 0.44 W/mm2 to
1.16 W/mm2 in 0.18 W/mm2 increments. The CO2 laser
with a wavelength of 10,600 nm employed to assist the
RF-sputtering process has a photon energy to 0.12 eV.
The intensity of the (0002) reflection of GaN significantly
increased as the laser energy density increased from 0.8
W/mm2 to 0.98 W/mm2. At a laser energy density of
0.98 W/mm2, the (0002) peak of GaN was the dominant
single film peak. The surface energy of the (0002) plane
was higher than those of the other planes of wurtzite
GaN, [22] indicating that the required nucleation energy
of the c-plane of the GaN thin films was the highest
among those of the other planes. By employing the
CO2 laser for RF sputtering, the fabricated GaN thin
films were able to acquire sufficient nucleation and
growth energies during the CO2 laser-assisted RF sputter-
ing because the CO2 laser could supply sufficient forma-
tion energy density at the CO2 laser energy density of
0.98 W/mm2. In comparing the fabrication CO2 laser
energy densities, the peak intensities of (1010) and
(1011) were found to be lower under the energydensity conditions of 0.62 and 0.8 W/mm2 com-
pared with that at 0.98 W/mm2. This finding indi-
cates that a CO2 laser energy density of 0.98 W/
Figure 3. X-ray diffraction patterns of the RF-sputtered GaN thin films deposited on sapphire substrates at the temperature of
200°C, working pressure of 15 mTorr, with different RF power conditions (a) – (c) and without thin-film fabrication process (d).
JOURNAL OF ASIAN CERAMIC SOCIETIES 71
mm2 can supply sufficient energy for the nucleation
and growth of reflections of the (0002) plane
of GaN.
The peak intensity of the (1010) plane of GaN showed
similar values up to a laser energy density of 0.8 W/mm2.
However, as the laser energy surpassed 0.98 W/mm2, the
(1010) peak of GaN suddenly disappeared, and the (0002)
peak of GaN was formed. In addition, the XRD profiles of
the sapphire substrate (non-laser) (f) and CO2-laser-
assisted RF-sputtered GaN thin film fabricated at a laser
energy density of 1.16 W/mm2 (a) were similar to those of
an undeposited sapphire substrate. At a laser energy
density of 1.16 W/mm2, the high laser energy density re-
evaporated the GaN thin films on sapphire substrates. To
estimate the surface energy of the (0002) plane of the
GaN thin film, the Gibbs free energy per unit volume of
the GaN thin films can be calculated using the following
equation (1)
ΔG� ¼
16πγvf
3 ΔGvð Þ
2
( )
2 � 3cosθþ cos3θ
4
� �
; (1)
where γvf is the surface energy of the nucleus–sub-
strate and ΔGv is the Gibbs free energy per unit
volume of the solid phase. Further, θ is the contact
angle at the thin film–substrate interface, which is
Figure 4. X-ray diffraction patterns of the CO2-laser-assisted RF-sputtered GaN thin films deposited on a sapphire substrate by
varying the energy density of the CO2 laser. Process conditions: Ar partial pressure 60%, RF power 200 W, working pressure 15
mTorr, and substrate temperature 200°C (a) – (e). GaN thin film without CO2 laser assistance (f) and without thin-film fabrication
process (g).
72 S.-H. KIM ET AL.
equal to 180° for unattached thin films [23]. Owing
to the wurtzite structure of GaN, γvf depends on the
direction of the plane. The surface energies of GaN
semiconductors with wurtzite structures are sum-
marized in Table 2. The surface energies of the
(1010), (1011), and (0002) planes of the fabricated
GaN thin films are 1.40, 1.76, and 2.64 J/m2 respec-
tively [22]. The GaN (0002) surface energy was
about 2.64 J/m2, which means that the growth of
the (0002) orientation reached the highest surface
energy. As shown in Figure 4, the GaN (0002) dif-
fraction peak is the highest at a laser energy density
of 0.98 W/mm2.
Figure 5 shows the (0002), (1010), and (1011) plane
peak ratios according to the laser energy density calcu-
lated by Equation (2) [24].
Peak ratio 0002ð Þ ¼
Peak intensity 0002ð Þ½ �
Peak intensity uvtwð Þ½ �
; (2)
The peak ratio of the (1010) plane with the lowest surface
energy was calculated to be 84% at a laser energy density
of 0.44 W/mm2. At a laser energy density of 0.62 W/mm2,
the peak ratio of the (1010) planes increased to 47%, and
the peak ratio of the (0002) planes with the highest sur-
face energy increased to 31.5%. At a laser energy density
of 0.80 W/mm2, the peak ratio of (0002) planes increased
to 77.7%, and the peak ratio of (1010) and (1011) planes
with relatively low surface energy decreased. At a laser
energy density of 0.98 W/mm2, the peak ratio of (0002)
plane is 95.2%, indicating that most of the grains grow in
(0002) orientation. As a result, this figure showed that
higher peaks of (0002), (1011), and (1010) were observed
at laser energy density of 0.98, 0.62, 0.44 W/mm2, respec-
tively. It means that the required energies for (0002),
Table 2. Surface energy of the (0001), (1120), (1011), and (1010) planes of GaN
wurtzite.
GaN plane (0001) (1120) (1011) (1010)
Surface energy (J/m2)[22] 2.64 1.53 1.76 1.40
Figure 5. X-ray diffraction pattern peak ratios in (0002), (1010)
and (1011) orientations of CO2 laser-assisted RF sputtered GaN
thin films fabricated at different laser energy densities.
Figure 6. Transmittance and Tauc plot of the CO2 laser-assisted RF-sputtered GaN thin films fabricated at different laser energy
densities. The insert shows the simulated bandgaps of the GaN thin films from the transmittance values.
JOURNAL OF ASIAN CERAMIC SOCIETIES 73
(1011), and (1010) planes were well coincide with esti-
mated surface energy in Table 2.
The optical transmission spectra of the CO2-laser-
assisted RF-sputtered GaN thin films fabricated at different
laser energy densities in the wavelength range of 200–
800 nm are shown in Figure 6. By increasing the CO2 laser
energy density, the transmittance decreased from 90% to
80% within the wavelengths range near 500 nm. In addi-
tion, the wavelength edge of the transmittance increased
from 267 nm to 345 nm with the increase in the CO2 laser
energy density. Therefore, the estimated energy bandgap
of CO2 laser-assisted RF-sputtered GaN thin films shifted to
lower values at approximately 3.32 eV as the CO2 laser
energy increased. The black line in Figure 6 corresponds to
the CO2-laser-assisted RF-sputtered GaN thin film fabri-
cated at a laser energy density of 0.98 W/mm2. For the
laser energy density of 1.16 W/mm2, the transmittance
value was not obtained. Apparently, the thin films evapo-
rated during deposition, indicating that the increasing
laser energy density aided the crystal growth of wurtzite
GaN. The simulated data of the energy band gap from the
Tauc plots of the CO2-laser-assisted RF-sputtered GaN thin
films are presented in the insets of Figure 6. The transmit-
tance of the GaN thin films was measured using a UV-vis
spectrometer, and the (ahν)2 vs. hν curve was subse-
quently plotted: [25]
ahvð Þ
2
¼ A hv � Eg
� �
; ahνð Þ
2
¼ A hν � Eg
� �
; (3)
where a is the absorption coefficient, Eg is the optical
bandgap of the GaN thin film, hν is photon energy, and
A is a constant.
Figure 7. Bandgaps of the CO2 laser-assisted RF-sputtered GaN
thin films fabricated at different laser energy densities.
Figure 8. Scanning electron microscopy (SEM) images of the CO2 laser-assisted RF-sputtered GaN thin films fabricated at different
laser energy densities.
74 S.-H. KIM ET AL.
The relationship between the laser energy density and
bandgap of the CO2-laser-assisted RF-sputtered GaN thin
films is illustrated in Figure 7. The energy bandgap
decreased with increasing laser energy density. When
the laser energy density approached 0.98 W/mm2, the
energy bandgap of the CO2 laser-assisted RF-sputtered
GaN thin films was 3.32 eV, which was similar to the
reported bandgap of GaN thin films. When the laser
energy density exceeded 1.14 W/mm2, delamination
and re-evaporation of the GaN thin film occurred owing
to the excessively high energy density of the CO2 laser.
Therefore, the optimized photon energy of 0.98 W/mm2
can enhance the crystalline properties of the GaN thin
film along the c-plane. Hence, CO2-laser-assisted RF sput-
tering is an effective method for growing GaN thin films.
Figure 9. Scanning electron microscopy (SEM) surface images (a)-(e), cross-sectional images (f) of CO2 laser-assisted RF sputtered
GaN thin films fabricated at a laser energy density of 0.98 W/mm2.
JOURNAL OF ASIAN CERAMIC SOCIETIES 75
Figure 8 shows the SEM surface images of the CO2
laser-assisted RF-sputtered GaN thin films fabricated at
different laser energy densities ranging from 0 W/mm2 to
1.16 W/mm2. In the SEM images of GaN thin films without
laser (f) and with CO2 laser assistance with small energy
density of 0.44 W/mm2 (e), a partially grown grain struc-
ture was observed. As the laser energy density was
increased beyond 0.44 W/mm2, highly dense grains
with a uniform size were formed. When the CO2 laser
energy density approached 0.8 and 0.98 W/mm2, the
grain size further increased. GaN thin films(b) deposited
at a CO2 laser energy density of 0.98 W/mm2 were well
crystallized in their thin film form. Therefore, CO2 laser-
assisted RF-sputtered GaN thin films fabricated at a laser
energy density between 0.8 and 0.98 W/mm2 exhibited
relatively large grains and a uniform structure. Moreover,
we determined that the grain size increased with increas-
ing laser energy density. Finally, the partially damaged
surface of the CO2 laser-assisted RF-sputtered GaN thin
films fabricated at a high incident laser energy density of
1.14 W/mm2 (Figure 8(a)) suggested that high laser
energy densities can damage the thin film quality of the
fabricated GaN [26].
In Figure 9(a-e), the average grain size of the central
region of the GaN thin film was 259 nm, and the average
grain size of the edge region was 246–254 nm. The aver-
age grain size of the whole thin film was 252 nm, indicat-
ing that the film quality in the central region and the edge
region was almost uniform. In Figure 9(f), the deposited
GaN thin film is growing in the C-axis direction, and the
Figure 10. High-resolution scanning electron microscopy (SEM) images of the CO2 laser-assisted RF sputtered GaN thin films
fabricated at different laser energy densities.
76 S.-H. KIM ET AL.
thickness of the thin film has grown around 1 μm. It
means that crystalline size of vertically grown grains
(c-axis direction) were much larger than horizontally
grown grains. In the experiments of X-ray photoelectron
(XPS) and photoluminescence (PL) spectroscopy, and UV-
vis spectrometry, a 1 μm-thick thin film was used.
Figure 10 shows high-resolution SEM surface images
of CO2 laser-assisted RF sputtered GaN thin films fabri-
cated at different laser energy densities. In the GaN thin
film (f) fabricated without laser assistance, small and non-
uniformly grown crystal grains were observed. The GaN
thin film fabricated with the assistance of a CO2 laser
formed high-density particles at a laser energy density
of 0.44 W/mm2. As a result of measuring the grain size of
the GaN thin film fabricated with the assistance of a CO2
laser, (e): 41 nm, (d): 68 nm, (c): 122 nm, (b): 247 nm.
Figure 10(a) shows the surface damaged by the high laser
energy density. It shows that grain size increases with
increasing laser energy density in the range 0–0.98 W/
mm2. The optimal laser energy for obtaining a large grain
size and high-density GaN thin film is 0.98 W/mm2.
Figure 11 displays the PL spectra of the CO2 laser
assisted RF-sputtered GaN thin films with different laser
energy densities. In the PL measurement, a He-Ag source
with UV laser system of 224 nm wavelength was
employed as the excitation source, and a charge coupled
device detector was used to record the PL data from the
excited electron emission. In general, the PL peak of GaN
is located at approximately 360–380 nm [29,30]. By vary-
ing the CO2 laser energy density from 0.62 W/mm2 to
0.98 W/mm2, the PL peak position shifted from 325 nm to
380 nm, which corresponded to 3.81 and 3.26 eV,
respectively. These PL data show similar energy bandgap
behavior in Figure 6 and 7. When high laser energy
densities of approximately 0.98 W/mm2 were applied in
the thin film fabrication process, GaN thin film exhibited
appropriate PL spectra at 3.26 eV. This PL spectrum value
corresponds to the reported energy band gap of GaN
thin films [27,28]. When a low energy density of approxi-
mately 0.44 W/mm2 or higher energy density exceeding
1.16 W/mm2 was applied, thin films showed no PL spec-
tra peaks within the range of 325–380 nm. An appropri-
ate energy density of the CO2 laser can promote the
formation of the wurtzite GaN structure with energy
band gap of 3.3–3.4 eV. Without CO2 laser assistance,
the GaN structure was not properly formed, as evidenced
by the absence of PL data near the 360–380 nm range.
Figure 12 shows the XPS spectra of the Ga 3d core level
of the CO2 laser-assisted RF-sputtered GaN thin films at
different laser energy densities from 0.44 W/mm2 to
1.16 W/mm2 and films RF-sputtered without CO2 laser
assistance. Without CO2 laser assistance, the Ga 3d core
level showed a faint peak intensity, meaning that the GaN
thin film was hardly formed during RF sputtering. However,
by introducing CO2 laser irradiation during RF sputtering,
the Ga 3d core level showed increased peak intensity. The
envelope, Ga 3d core level peak comprised three peaks
originating from Ga-N, Ga-metal, and Ga-O bonds, which
corresponded to 19.9, 19.0, and 20.7 eV, respectively [27].
As shown in the Figure 12(b-e), by increasing the laser
energy density from 0.44 W/mm2 to 0.98 W/mm2, the
number of Ga-N bonds increased, while those of Ga-
metal and Ga-O were virtually unchanged. This finding
Figure 11. Photoluminescence (PL) wavelength of the CO2 laser-assisted RF-sputtered GaN thin films fabricated at different laser
energy densities.
JOURNAL OF ASIAN CERAMIC SOCIETIES 77
means that near the laser energy density of 0.98 W/mm2,
the GaN thin film grew properly. However, as the laser
energy density was increased to 1.16 W/mm2
(Figure 12(a)), the peak intensity of Ga-N bonds decreased.
As previously discussed, the GaN structure can be
destroyed by high laser energy densities. As shown in the
Figure 12, the envelope peak center shifted to low energy
level with increasing laser energy density due to the
increased number of G-N bonds at the energy density of
0.98 W/mm2. At the assisted CO2 laser energy density of
approximately 0.98 W/mm2, the Ga 3d core level showed
the highest envelope intensity and Ga-N binding energy.
This finding means that at the laser energy density of
0.98 W/mm2, GaN thin film has the highest number of
Ga-N bonds and a well-grown crystalline structure.
4. Conclusion
For the first time, CO2 laser-assisted RF-sputtered
GaN thin films were prepared by varying the laser
energy density at a relatively low substrate tem-
perature of approximately 200°C. To assist in the
growth of crystallized GaN thin films on sapphire
substrates, a CO2 laser was employed during the RF
sputtering process. By employing CO2 laser with
energy density of 0.98 W/mm2 to assist RF sputter-
ing at a low substrate temperature of 200°C, (0002)
oriented, well-grown crystalline-structured GaN thin
films were obtained. Both the measurement meth-
ods of Tauc plot and PL spectra proved that GaN
thin films processed with the CO2 laser and RF
sputtering system yielded a well-grown (0002)
orientation with a wide energy bandgap of
Figure 12. X-ray photoelectron spectroscopy (XPS) spectra of the Ga 3d core level of the CO2 laser-assisted RF-sputtered GaN thin
films deposited on a sapphire substrate by varying the energy density of the CO2 laser. Process conditions: Ar partial pressure 60%,
RF power 200 W, working pressure 15 mTorr, substrate temperature 200°C.
78 S.-H. KIM ET AL.
3.26 eV when the CO2 laser was irradiated at an
energy density of 0.98 W/mm2 during the RF sput-
tering process.
Disclosure statement
No potential conflict of interest was reported by the
author(s).
Funding
This research was supported by the MOTIE (Ministry of Trade,
Industry, and Energy) in Korea, under the Fostering Global
Talents for Innovative Growth Program(P0017308) super-
vised by the Korea Institute for Advancement of
Technology (KIAT) and Human Resources Development
(No.20214000000280) of the Korea Institute of Energy
Technology Evaluation and Planning(KETEP) grant funded
by the Korea government Ministry of Trade, Industry and
Energy.
References
[1] Sichel EK, Pankove JI. Thermal conductivity of GaN,
25-360K. J Phys Chem Solids. 1977;38:330.
[2] Kim M, Seo J, Singietti U, et al. Recent advances in
free-standing single crystalline wide band-gap
semiconductors and their applications: gaN, SiC,
ZnO, β -Ga2O3, and diamond. J Mater Chem C.
2017;5:8338.
[3] Chow T. High-voltage SiC and GaN power devices.
Microelectron Eng. 2006;83:112–122.
[4] Shchekin O,Epler J, Trottier T, et al. High performance
thin-film flip-chip InGaN–GaN light-emitting diodes.
J Appl Phys Lett. 2006;89:071109.
[5] Uemoto Y, Hikita M, Ueno H, et al., Gate Injection
Transistor (GIT)—A normally-off AlGaN/GaN power
transistor using conductivity modulation. IEEE Trans
Electron Devices. 2007;54:12.
[6] Jogai B. Influence of surface states on the
two-dimensional electron gas in AlGaN/GaN hetero-
junction field-effect transistors. J Appl Phys.
2003;93:3.
[7] Osipov K, Ina Ostermay I, Bodduluri M, et al., Local
2DEG density control in heterostructures of piezoelec-
tric materials and its application in GaN HEMT fabrica-
tion technology. IEEE Trans Electron Devices. 2018, 65,
8.
[8] Dissanayake A, Lin JY, Jiang HX, et al. Low tem-
perature epitaxial growth and photoluminescence
characterization of GaN. J Appl Phys Lett.
1994;65:2317.
[9] Richter E, Gramlich S, Klein A, et al. Direct growth of
GaN on (0001) sapphire. J Phys Stat Sol.
2001;188:439.
[10] Lee JW, Paek HS, BYoo J, et al. Low temperature buffer
growth to improve hydride vapor phase epitaxy of
GaN. J Mater Sci Eng. 1999;59:12.
[11] Huang TF, Marshall A, Spruytte S, et al. Optical and
structural properties of epitaxial GaN films grown
by pulsed laser deposition. J Cryst Growth.
1999;200:362.
[12] Kawwam M, Lebbou K. The influence of deposition
parameters on the structural quality of PLD-grown
GaN/sapphire thin films. J Appl Surf Sci.
2014;292:906.
[13] Li W, Li A. Post growth thermal annealing of GaN
grown by RF plasma MBE. J Cryst Growth.
2001;227:415.
[14] Maruyama T, Miyake H. Gallium nitride thin films
deposited by radio-frequency magnetron sputtering.
J Vac Sci Technol A. 2006;24:1096.
[15] Yadav BS, Singh S, Ganguli T, et al. Highly oriented GaN
films grown on ZnO buffer layer over quartz substrates
by reactive sputtering of GaAs target. Thin Solid Films.
2008;517:488–493.
[16] Nisha Preschilla A, Major S. Nanocrystalline gallium
nitride thin films. Appl Phys Lett. 2000;77:1861.
[17] Kikuma T, Tominaga K, Furutani K, et al. GaN films
deposited by planar magnetron sputtering. Vacuum.
2002;66:233–237.
[18] Shinoda H, Mutsukura N. Structural properties of GaN
and related alloys grown by radio frequency magne-
tron sputter epitaxy. Thin Solid Films.
2008;516:2837–2842.
[19] Naniwae K, Itoh S, Amano H, et al. Growth of single
crystal GaN substrate using hydride vapor phase
epitaxy. J Cryst Growth. 1990;99:1–4.
[20] Pearton SJ, Ren F, Zhang AP, et al. Fabrication and
performance of GaN electronic devices. Mater Sci Eng
R Rep. 2000;30:3–6.
[21] Borah SM, Bailung H, Pal AR, et al. Study on the influ-
ence of nitrogen on titanium nitride in a dc post
magnetron sputtering plasma system. J Phys D: App
Phys. 2008;41:195205.9.
[22] Hong YJ, Yoo J, Doh YJ, et al. Controlled epitaxial
growth modes of ZnO nanostructures using different
substrate crystal planes. J Mater Chem.
2009;19:941–947.
[23] Cao G Nanostructures & nanomaterials: synthesis,
properties & applications. Imperial college press,
2004. 93p.
[24] Jin SD, Koh J-H. Effects of calcination temperature on
the piezoelectric properties of lead-free Ag doped (Na,
K) NbO3–LiTaO3 piezoelectric ceramics. J Alloys
Compd. 2013;555:390–394.
[25] Lin K, Kuo DH. Characterization of quaternary AlInGaN
films obtained by incorporating Al into InGaN film with
the RF reactive magnetron sputtering technology.
J Mater Sci: Mater Electron. 2017;28:43–51.
[26] Yoo JH, Menor MG, Adams JJ, et al. Laser damage
mechanisms in conductive widegap semiconductor
films. Opt Express. 2016;24:16.
[27] Kumar M, Pasha SK, Krishna TC, et al. Facile synth-
esis and photoluminescence spectroscopy of
3D-triangular GaN nano prism islands. J Dalton
Trans. 2014;43:11855.
[28] Kim D, Song KM, Jung U, et al. Effects of different
InGaN/GaN electron emission layers/interlayers on
performance of a UV-A LED. Appl Sci. 2020.10.1514.
[29] Wu S, Wang L, Yi X, et al. Influence of lateral
growth on the optical properties of GaN nanowires
grown by hydride vapor phase epitaxy. J Appl Phys.
2017;20:122.
[30] Jiao W, Kong W, Li J, et al. Characterization of MBE-grown
InAlN/GaN heterostructure valence band offsets with
varying In composition. J AIP Adv. 2015;6:3.
JOURNAL OF ASIAN CERAMIC SOCIETIES 79
	Abstract
	1. Introduction
	2. Experimental
	3. Results and discussion
	4. Conclusion
	Disclosure statement
	Funding
	References
