AR822_EN_Col2008_2 SAP Ariba Cloud Integration Gateway Configuration

Text Material Preview

© SAP SE AR822 1
AR822
SAP Ariba Integration:
Cloud Integration Gateway
Collection 2008
© SAP SE AR822 2
HOME
Course Title
LOGO HERE
@ Copyright. All rights reserved.
Outline
SAP Ariba Cloud Integration
Gateway: Overview and Getting
Started
Master Data Integration
Network Integration
Transactional Data Integration
Migration, Multiple ANIDs, and More
© SAP SE AR822 3
HOME
Course Title
LOGO HERE
@ Copyright. All rights reserved.
SAP Ariba Cloud Integration
Gateway: Overview and Getting
Started
Getting Started with CIG
1
Cloud Connector
Integration Add-Ons
Configure SAP Ariba Add-On
4
3
2
CIG Configuration
5
Content Based Routing
Custom Mapping Tool
7
6
© SAP SE AR822 4
LOGO HERE
@ Copyright. All rights reserved.
SAP Ariba Cloud Integration
Gateway Configuration
© SAP SE AR822 5
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 1: Architecture
By the end of this lesson, you will be able to:
• Match SAP Ariba Cloud Integration Gateway features to their associated benefit(s)
This lesson includes the following topics:
i. Quick CIG video
ii. 10 Key Features
© SAP SE AR822 6
LOGO HERE
@ Copyright. All rights reserved.
Architecture
By leveraging the SAP Cloud Platform Integration, the SAP Ariba Cloud Integration Gateway:
üSimplifies integration with guidance-based setup
üReduces the integration deployment time
üProvides an integrated test framework by default to test the scenarios
üAligns with SAP standard software lifecycle In addition, the SAP Ariba Cloud Integration Gateway:
ü Facilitates smoother upgrades.
ü Supports download through the SAP Service Marketplace.
ü Addresses issues with standard SAP Notes and correction instructions.
ü Uses the single sign-on functionality, to allow buyers to access their SAP
Ariba Cloud Integration Gateway account from their Ariba Network
account or Ariba Application realms.
ü Supports management of a single configuration based on your core ERP
capabilities when you connect to the Ariba Network.
ü Supports certificate-based or basic username and password based
authentication for connectivity.
ü Provide innovative tools
© SAP SE AR822 7
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 2: Connecting to CIG via SAP Ariba Applications
By the end of this lesson, you will be able to:
• Identify pre-requisites for connecting and assigning permissions
• Access CIG via various SAP Ariba Applications
This lesson includes the following topics:
i. Connecting CIG to Ariba Network
ii. Connecting CIG to SAP Ariba Sourcing
iii. Connecting CIG to SAP Ariba Procurement
© SAP SE AR822 8
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network
Connecting via
Ariba Network
Pre-Requisites Assign User
Permissions Access CIG
© SAP SE AR822 9
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network
Connecting via
Ariba Network
Pre-Requisites Assign User
Permissions Access CIG
© SAP SE AR822 10
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Pre-Requisites)
ü Buyer Account on Ariba Network
ü Enable your AN Buyer account to access CIG
In order to start testing once all the configurations are done, you
need to:
ü Maintain valid trading Buyer-Supplier relationship on Ariba
Network
ü Have access to SAP Marketplace to download SAP Ariba
Cloud Integration Gateway add-on for SAP ERP or SAP
S/4HANA
ü Download/Install/Configure SAP Ariba CIG AddOn on your
SAP system
ü Configure necessary certificates
© SAP SE AR822 11
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network
Connecting via
Ariba Network
Pre-Requisites Assign User
Permissions Access CIG
© SAP SE AR822 12
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
You will now need to create users (as required) and assign necessary
permissions to access & configure CIG.
Even though AN Buyer account is added to the Feature Availability list, users
still need to have necessary permissions assigned to access CIG.
© SAP SE AR822 13
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 1 of 6
The Administrator of the Buyer
AN account will need to login
with their administrator
credentials.
Click on the Administration
dropdown menu and click on
Users.
© SAP SE AR822 14
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 2 of 6
Under manage Role
section, click on Create
Role.
© SAP SE AR822 15
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 3 of 6
Enter a distinctive Name for the role.
(Optional – Enter a description for the role. Descriptions
can be useful later, if you want to review or revise the
structure of your roles).
Click Save.
© SAP SE AR822 16
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 4 of 6
Each role must have at least one permission:
ü Ariba Cloud Integration Gateway
Configuration: Allows you to create, modify, &
maintain projects on the SAP Ariba Cloud
Integration Gateway.
ü Ariba Cloud Integration Gateway Access:
Allows you to view & search for projects
available on the SAP Ariba Cloud Integration
Gateway.
Click Save.
Buyer administrator can assign predefined permissions to users accessing the CIG.
Creating a role must be done before you create users.
© SAP SE AR822 17
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 5 of 6
Under Manage Users, click Create User.
© SAP SE AR822 18
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Assign User Permissions)
Step 6 of 6
ü Provide required user related information.
ü Assign the newly created role to that user.
ü Click Done.
© SAP SE AR822 19
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network
Connecting via
Ariba Network
Pre-Requisites Assign User
Permissions Access CIG
© SAP SE AR822 20
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 1 of 7
• Login to your Ariba Network Buyer account having
permission to access CIG.
• Click on the Administration dropdown
• Click Configuration.
© SAP SE AR822 21
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 2 of 7
Click on Cloud Integration Gateway Setup option.
© SAP SE AR822 22
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 3 of 7
• After reading & agreeing to Terms of Use &
Privacy Statement, check the box next to Enable
the Ariba Cloud Integration Gateway.
• Click Save.
© SAP SE AR822 23
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 4 of 7
You will be navigated back to the configuration page.
Click Cloud Integration Gateway Setup.
© SAP SE AR822 24
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 5 of 7
You will see Go to the Ariba Cloud Integration
Gateway link enabled.
Click on the link.
Recommendation: send your backend SAP system information before accessing &
configuring your CIG account very first time.
© SAP SE AR822 25
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 6 of 7
Upon enabling CIG from Ariba Network in step 4, you will get
an automated email from notification@sapnetworkmail.com
to set the password of your P User, a unique user ID for your
account in CIG.
This P User information will be needed for following:
1. Sending SAP system information to CIG.
2. Execute Interface Setup programERPOrder_POLineLineDetailItem>>Item>>LineItems>>Item –X/XX à
PO_Items>>Item>>PO_Item
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the mapping where you want to add the function, right-click
on the Mapping Line, click on Choose When and create.
SOURCE
© SAP SE AR822 160
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Choose When
2. On the selection Screen, choose operator as non empty
3. Choose the second field and map it to same target, right-click
(again) on the Mapping Line, click Choose When and create.
© SAP SE AR822 161
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Choose When
4. On the selection Screen, choose Operator as non empty and
Order as 2.
5. Give the sample payload and run Test.
© SAP SE AR822 162
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Text Node to Item Level Extrinsic
Mapping item level long text to ne Extrinsic field.
Ex: In OrderRequest IDOC E1EDPT1>>E1EDPT2 will contain the long
text. This need to be mapped to line level extrinsic.
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the mapping where you want to add the condition, map
E1EDPT2-TDLINE to Extrinsic at ItemDetail level
© SAP SE AR822 163
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Text Node to Item Level Extrinsic
2. Right-click on the Mapping Line and choose Target Variable>>Set
Variable>> Position
3. Select a condition item and choose ItemOut which is used for loop.
© SAP SE AR822 164
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Text Node to Item Level Extrinsic
4. Add source condition. Choose the similar path in the source
condition E1EDP01 with condition type Position Variable and also
the specific TDID to be picked.
5. Add the 2nd source condition to pick the specific TDID, the reason
is there might be different TDIDs (Long Text)..
© SAP SE AR822 165
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Text Node to Item Level Extrinsic
6. Add condition value as Z.
7. Give the sample payload and run Test.
© SAP SE AR822 166
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 4: Limitations
By the end of this lesson, you will be able to:
• Identify custom mapping tool limitations
© SAP SE AR822 167
LOGO HERE
@ Copyright. All rights reserved.
Limitations
• Comments
ØIDOC to cXML - We cannot map the IDOC comments to comments node in cXML.
ØcXML to IDOC/Proxy - For example in IDOC, the comments need to be mapped to
TDLINE and length of TDLINE is 70 characters. In CIG mappings, we cannot split
the comments and create multiple TDLINE
• A standard output which got generated cannot be changed. Customer will have
to do the mapping from source to target again.
• Customer cannot see the standard mapping lines and manual customizations
(Done by Engineering).
• Concatenate function: Max 3 fields only can be concatenated.
• Adding multiple conditions via Choose When is not supported.
© SAP SE AR822 168
LOGO HERE
@ Copyright. All rights reserved.
Content Based Routing
© SAP SE AR822 169
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 1: Overview
By the end of this lesson, you will be able to:
• Navigate the Custom Routing Tool
• Understand the feature and functions of Custom Routing Tool
This lesson includes the following topics:
• Flow Overviews
• Feature and Functions
© SAP SE AR822 170
LOGO HERE
@ Copyright. All rights reserved.
Overview
Buyers can use custom routing to route transaction documents to the specific ERP client system based on the system ID of the ERP system and certain
conditions.
Using this feature the buyer can do the following:
Create & Edit Custom Routing for Document Type
XPath Based Document Routing
© SAP SE AR822 171
LOGO HERE
@ Copyright. All rights reserved.
Overview
Ariba Network
or SAP Ariba Applications Cloud Integration Gateway
Company Code - 1000
Company Code - 2000
System ID 1
System ID 2
SAP S/4 Hana
SAP ECC
© SAP SE AR822 172
LOGO HERE
@ Copyright. All rights reserved.
Overview
To navigate to Mapping Tool in CIG follow the below steps:
1. Login to Cloud Integration Gateway.
2. Go to My Configurations.
3. Navigate to Custom Routing.
© SAP SE AR822 173
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 2: Configuration Steps
By the end of this lesson, you will be able to:
• Configure content based routing
This lesson includes the following topics:
i. Create custom routing
© SAP SE AR822 174
LOGO HERE
@ Copyright. All rights reserved.
Configuration Steps
1. Go to the Custom Routing tab under My Configuration.
2. Click Create Custom Routing.
© SAP SE AR822 175
LOGO HERE
@ Copyright. All rights reserved.
Configuration Steps
3. Select Direction and Document Type, enter values for Name
and Description.
4. From the Action Value drop down, select the System ID for
which you want to do the CBR.
© SAP SE AR822 176
LOGO HERE
@ Copyright. All rights reserved.
Configuration Steps
5. On the conditions section click on the + sign to add Xpath
.
6. Either you can select a Possible XPath from the available
list, or click New XPath
© SAP SE AR822 177
LOGO HERE
@ Copyright. All rights reserved.
Configuration Steps
7. Enter values for Name and Description, select the Data
Type.
8. Select the XPath of the node for which you want to do the
CBR.
© SAP SE AR822 178
LOGO HERE
@ Copyright. All rights reserved.
Configuration Steps
9. Select the Operand from the drop down.
10. Under Operand, select EXISTS
11. Click Save.
© SAP SE AR822 179
LOGO HERE
@ Copyright. All rights reserved.
Outbound
Buying and Invoicing
AN System ID – AN1
AN System ID – AN2
Ariba Network
Cloud Integration Gateway
System ID – S1
System ID – S2
© SAP SE AR822 180
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 3: Operands
By the end of this lesson, you will be able to:
• Describe the operands allowed when defining an XPath
This lesson includes the following topics:
i. Operands allowed for String Data Type
ii. Operands allowed for Numeric Data Type
© SAP SE AR822 181
LOGO HERE
@ Copyright. All rights reserved.
Operands
This function is used for adding different conditions for defining XPath.
Ø For String Data Type.
Ø For Numeric Data Type.
S.No Operand
1 Equals
2 Not equals
3 Not begins with
4 Not null or empty
5 Exists
6 Not exists
7 Contains
8 Not contains
9 Begins with
Operands Allowed for
String Data Type
S.N
o Operand
1 Greater than
2 Less than
3 Greater than or
equal
4 Less than or equal
5 Equals
Operands Allowed for
Numeric Data Type
© SAP SE AR822 182
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 4: Use Cases
By the end of this lesson, you will be able to:
• Configure company code based routing
This lesson includes the following topics:
i. Company code based routing
© SAP SE AR822 183
LOGO HERE
@ Copyright. All rights reserved.
Company Code Based Routing
Ex: Maintain a custom routing condition where company code 1000 and 2000
need to point to one backend system B1 and company code 3000 and 4000
need to point to backend system B2.
Go to the Custom Routing tab under My Configuration and click on Create
Custom Routing.
1. Select Direction and Document Type, enter values for Name and
Description.
2. From the Action Value drop down, select the System ID B1.
© SAP SE AR822 184
LOGO HERE
@ Copyright. All rights reserved.
Company Code Based Routing
3. Click on the New XPath button, enter Name and Description.
4. Enter value of XPath as:
/PurchaseOrderExportRequest/ERPOrder_PurchOrdHeaderDetails
_Item/item/CompanyCode[UniqueName=1000 or
UniqueName=2000]
© SAP SE AR822 185
LOGO HERE
@ Copyright. All rightsreserved.
Company Code Based Routing
5. Select the Operand as EXISTS, click Save
6. From the Action Value drop down, select the System ID B2.
© SAP SE AR822 186
LOGO HERE
@ Copyright. All rights reserved.
Company Code Based Routing
7. Enter value of XPath as
/PurchaseOrderExportRequest/ERPOrder_PurchOrdHeaderDetails_Item/it
em/CompanyCode[UniqueName=3000 or UniqueName=4000]
Click Save
8. Select the Operand as EXISTS, click Save
9. Check the CBR overview screen.
© SAP SE AR822 187
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 5: Sample XPaths
By the end of this lesson, you will be able to:
• Recognize various Xpath Examples
This lesson includes the following topics:
i. XPath examples
© SAP SE AR822 188
LOGO HERE
@ Copyright. All rights reserved.
Sample XPaths
S.No XPath Examples
1 /cXML/Request/InvoiceDetailRequest/InvoiceDetailRequestHeader/*[@role ='billTo' and @addressID = '0001']/Name
2 /cXML/Request/InvoiceDetailRequest/InvoiceDetailRequestHeader/InvoicePartner/Contact[@role='remitTo']/PostalAddress/City
3 /cXML/Request[1]/InvoiceDetailRequest[1]/InvoiceDetailOrder[1]/InvoiceDetailItem[LineNum]/InvoiceDetailItemReference[1]/Description[1]
4 /cXML/Header/To/Credential[@domain='SystemID']/Identity
5 /PurchaseOrderExportRequest/ERPOrder_PurchOrdHeaderDetails_Item[1]/item[1]/CompanyCode[1]/UniqueName[1]
© SAP SE AR822 189
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 6: Limitations
By the end of this lesson, you will be able to:
• Understand the limitations of content based routing
This lesson includes the following topics:
i. Limitations
© SAP SE AR822 190
LOGO HERE
@ Copyright. All rights reserved.
Limitations
Content Based Routing Limitations:
1. Adding more than two conditions for a transaction is not
possible.
2. SAP Ariba Cloud Integration Gateway doesn’t support
custom routing for suppliers.
© SAP SE AR822 191
LOGO HERE
@ Copyright. All rights reserved.
Section Complete
Congratulations!
You have now completed this Section!in SAP system.
3. Cloud Connector configuration.
The auto generation P user ID required to connect to CIG is triggered when you enable CIG.
© SAP SE AR822 26
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via Ariba Network (Access CIG)
Step 7 of 7
While accessing CIG very first time, if you have not sent the
backend system information to CIG via SAP Data Sync report,
you will land on Trading Partner System information page where
you would need to provide required information of your SAP
system. Until you provide the backend system information,
CIG will not allow you to proceed further.
Recommendation: send your backend SAP system information before accessing & configuring your CIG account
very first time.
© SAP SE AR822 27
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing
Connecting via
SAP Ariba Sourcing
Pre-Requisites Access CIG
© SAP SE AR822 28
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Pre-Requisites)
ü SAP Ariba Sourcing Realm connected to an active Buyer Account on
Ariba Network.
ü Enable your Sourcing Realm to access CIG (for Master Data
Integration).
ü Enable your AN Buyer account to access CIG (for transaction
integration).
In order to start testing once all the configurations are done, you need to:
ü Access to SAP Marketplace to download SAP Ariba Cloud Integration
Gateway add-on for SAP ERP or SAP S/4HANA.
ü Configure AddOn on your SAP system.
ü Configure your certificates.
• For SAP Ariba Sourcing Integration, enabling CIG through Ariba Sourcing
Realm is only meant for Sourcing Master Data Integration.
• For Sourcing Transactions Integration such as Quote Request; Award &
Contract, you need to enable CIG from Ariba Network as well.
© SAP SE AR822 29
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing
Connecting via
SAP Ariba Sourcing
Pre-Requisites Access CIG
© SAP SE AR822 30
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 1 of 6
Login to your Ariba Sourcing realm with a user having
“Customer Administrator” permission.
Click the dropdown menu for Manage.
Click Administration.
© SAP SE AR822 31
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 2 of 6
Click the dropdown menu for Integration Manager.
Click Cloud Integration Gateway
© SAP SE AR822 32
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 3 of 6
After reading & agreeing to Terms of Use & Privacy
Statement, check the boxes next to I have read and
agree.… & Enable the Ariba Cloud Integration Gateway
Capability.
Also check the boxes of the tasks / Integration Events
you want to adopt to enable them. Then click Save.
These tasks / events are only meant for integration with
S/4 HANA Cloud version and not applicable for
integration with on-premise SAP system.
1) Export Purchase Contract Request to CIG-S4HANA – This parameter is to enable Ariba
Contract CLID integration with S/4 HANA cloud. This integration is slightly different from our
Add-On integration because it doesn’t go through AN(meaning it is not cXML based
integration). Hence we introduced a new parameter.
2) Export RFX Awards to S4HANA – This parameter is to enable Quote Message from Ariba
Sourcing to S/4 HANA Cloud.
3) Import Purchase Contract Status Update Request from CIG-S/4HANA – This
parameter is to enable Contract Status update from S/4 HANA Cloud to Ariba Contracts
(Response flow for integration of Export Purchase Contract Request to CIG-S4HANA)
4) Import Sourcing Request from S/4HANA – This parameter is to enable Quote Request
flow from S/4HANA cloud to Ariba Sourcing. In S/4 HANA cloud the RFQ created is called
Sourcing Request.
5) SMExternalValidation – Do not have info about this parameter. In SLP, we can have
validations within SLP/SM or in the external system like MDG. This parameter may be
controlling that behaviour. Need to check with the PM for SLP.
6) Send RFQ Confirmation to S4HANA – This is a new flow. Once we send the Quote
Request from S/4 HANA Cloud to Ariba Sourcing, they will send a response back to S/4
HANA. This will be called RFQ confirmation. This is currently under development and Murali
is working on it. This parameter is to enable this flow.
© SAP SE AR822 33
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 4 of 6
The CIG status is now Enabled.
Click the link Visit the cloud integration gateway
© SAP SE AR822 34
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 5 of 6
Upon enabling CIG from Ariba Sourcing Realm in previous step, you will get an
automated email from notification@sapnetworkmail.com to set the password of
your P User, a unique user ID for your account in CIG.
This P User information will be needed for following:
1. Sending SAP system information to CIG.
2. Execute Interface Setup program in SAP system.
3. Cloud Connector configuration.
4. Sending Master Data from your SAP system to Ariba Sourcing.
• Each P User is associated with only one AN Buyer Account.
• The system has built-in intelligence to check AN Buyer ID connected to your Sourcing
Realm to avoid duplicate creation on P User.
• Thus, as an SAP Ariba Sourcing Customer even tough you enable CIG through your
Sourcing Realm for Sourcing Master Data Integration, NO new P User will get created
when you enable CIG again through Ariba Network for Sourcing Transaction Integration.
© SAP SE AR822 35
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Sourcing (Access CIG)
Step 6 of 6
While accessing CIG very first time, if you have not sent the
backend system information to CIG via SAP Data Sync
report, you will land on Trading Partner System information
page where you would need to provide required information
of your SAP system. Until you provide the backend
system information, CIG will not allow you to proceed
further.
Recommendation: send your backend SAP system information before accessing & configuring your CIG account very first time.
© SAP SE AR822 36
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement
Connecting via
SAP Ariba Procurement
Pre-Requisites Access CIG
© SAP SE AR822 37
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Pre-Requisites)
ü SAP Ariba Procurement Realm
ü Enable your Procurement Realm to access CIG
ü Enable your associated AN Buyer account to access CIG (for
transaction integration for Invoice Management Realm & Combo
Realm)
In order to start testing once all the configurations are done, you need to:
ü Access to SAP Marketplace to download SAP Ariba Cloud Integration
Gateway add-on for SAP ERP or SAP S/4HANA.
ü Configure AddOn on your SAP system.
ü Configure your certificates.
© SAP SE AR822 38
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Pre-Requisites)
Please note that for SAP Ariba Procurement Integration, enabling CIG through SAP Ariba Procurement realm is
meant for both Procurement Master Data Integration & Procurement Transaction Integration.
For Procurement Transactions Integration through solutions such as Invoice Management (aka Invoice Pro) &
Combo Realm, you need to enable CIG from Ariba Network as well.
© SAP SE AR822 39
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement
Connecting via
SAP Ariba Procurement
Pre-Requisites Access CIG
© SAP SE AR822 40
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 1 of 6
Login to your SAP Ariba Procurement realm (login
requires user with “Customer Administrator”
permission)
Click the dropdown menu for Manage
Click Core Administration© SAP SE AR822 41
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 2 of 6
Under Integration Manager
Click Cloud Integration Gateway
© SAP SE AR822 42
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 4 of 6
After reading & agreeing to Terms of Use & Privacy
Statement, check the boxes next to I have read and agree.…
& Enable the Ariba Cloud Integration Gateway Capability.
Also check the boxes of the tasks / Integration Events you
want to adopt to enable them. Then click Save.
© SAP SE AR822 43
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 4 of 6
The Status is now Enabled.
Click the link Visit the cloud integration gateway.
© SAP SE AR822 44
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 5 of 6
Upon enabling CIG from SAP Ariba Procurement realm, you will recieve an
automated email from notification@sapnetworkmail.com to set the password of
your P User, a unique user ID for your account in CIG.
This P User information will be needed for following:
1. Sending SAP system information to CIG.
2. Execute Interface Setup program in SAP system.
3. Cloud Connector configuration.
4. Sending Master Data from your SAP system to Ariba Sourcing.
• Each P User is associated with only one AN Buyer Account.
• The system has built-in intelligence to check the AN Buyer ID connected to your
Procurement realm to avoid duplicate creation on P User.
• Thus, as an SAP Ariba Procurement Customer even tough you enable CIG through
your Procurement realm for Procurement Master Data Integration, NO new P User will
get created when you enable CIG again through Ariba Network for Procurement
Transaction Integration.
© SAP SE AR822 45
LOGO HERE
@ Copyright. All rights reserved.
Connecting to CIG via SAP Ariba Procurement (Access CIG)
Step 6 of 6
While accessing CIG very first time, if you have not sent
the backend system information to CIG via SAP Data
Sync report, you will land on Trading Partner System
information page where you would need to provide
required information of your SAP system. Until you
provide the backend system information, CIG will not
allow you to proceed further.
2 text pop-ups
© SAP SE AR822 46
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 3: Adding & Editing ERP information
By the end of this lesson, you will be able to:
• Add or edit ERP system information
This lesson includes the following topics:
i. Step-by-step instruction on how to add or edit ERP system information
© SAP SE AR822 47
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 1 of 6
Click on the User Name appearing at the top/right corner of
the screen.
Click Basic Data
© SAP SE AR822 48
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 2 of 6
The Trading Partner System Information page is now displayed.
Click Add to define a new backend system
© SAP SE AR822 49
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 3 of 6
Add new backend SAP system information
When you want to add ERP system information manually (not
recommended), you need to provide following information:
A. ERP Name (Select from the list of available values)
B. ERP version (Select from the list of available values)
C. System ID – Logical System ID of your ERP.
D. Service Pack
E. Middleware (Select from the list of available values)
F. Middleware Version
G. Time Zone (of your ERP system)
H. AddOnInfo1 – ERP Software Component ARBCI1. Specify the
version of the add-on SP you are using.
I. AddOnInfo2 – ERP Software Component ARBCI2. Specify the
version of the add-on SP you are using.
J. AddOnInfoR – ERP Software Component ARBCIGR. Specify the
version of the add-on SP you are using.
Click Save
© SAP SE AR822 50
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 4 of 6
The new backend system is now visible
Click Finish
© SAP SE AR822 51
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 5 of 6 Click on the pencil icon to edit the information in the
existing entry.
© SAP SE AR822 52
LOGO HERE
@ Copyright. All rights reserved.
Adding & Editing ERP information
Step 6 of 6
Change the required fields (from the list of available values).
Click Save
© SAP SE AR822 53
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 4: Home Page
By the end of this lesson, you will be able to:
• Navigate the CIG Home Page
This lesson includes the following topics:
i. Home Page navigation
© SAP SE AR822 54
LOGO HERE
@ Copyright. All rights reserved.
Home Page
1. Integration Projects
ü Displays all the projects & it’s
statuses.
ü Allows user to view; create; edit or
delete the project.
2. Supplier Reporting
ü Displays all the projects of
connected suppliers & it’s statuses.
ü Provides visibility on the status of
supplier on-boarding.
3. Transaction Tracker
ü Track the transaction documents
that you have sent & received.
ü Download payloads & attachments
4. Under My Projects, you will see a list of
available integration projects
5. Create a New Integration Project
button.
Once ERP system information is added, you will be navigated to Home page of your CIG account.
© SAP SE AR822 55
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 5: Configuring Ariba Cloud Integration Project
By the end of this lesson, you will be able to:
• Configure an SAP Ariba Cloud Integration Project
This lesson includes the following topics:
i. Integration Project Wizard
ii. Step-by-step instructions on how to configure an SAP Ariba Cloud Integration Project
© SAP SE AR822 56
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project
Integration Project Wizard
• The Integration Project Wizard automates complex integration tasks by asking a series of easy-to-
answer questions.
• The answers you provide help Cloud Integration Gateway derive transaction configurations.
• Tip: you can reuse the connection information for future integrations with other Ariba products.
Let’s take a look at the steps!
© SAP SE AR822 57
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project
Click Create a New Integration Project
Does this step look familiar? It should because we completed this step at the end of
the “Home Page” lesson.
Now, let’s take a look at the rest of the steps!
© SAP SE AR822 58
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Basic Information
We are now in the Project Wizard!
Provide following basic information:
• Project Name of your choice. Users are recommended
to enter a meaningful name that helps to identify the
project easily.
• Select Product – Depending upon your solution
adoption, choose the product – Ariba Network; Ariba
Procurement or Ariba Sourcing.
• Click NextYou need to create a separate project for integrating with each SAP Ariba product.
© SAP SE AR822 59
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity (1/5)
Step 1 of 5
To define Connection for a project you can do
either of the following:
Option A: Select from available connections by
clicking on the down arrow sign of the connection
listed in Reusable Connections table. This
option is available only when you are creating
second project.
OR
Option B: Create a fresh connection by clicking
on Add New Connection button.
© SAP SE AR822 60
LOGO HERE
@ Copyright. All rights reserved.
Step 2 of 5 • Select from available connections by clicking on the down arrow sign of
theconnection listed in Reusable Connections table.
Option A: Select from
available connections by
clicking on the down
arrow sign of the
connection listed in
Reusable Connections
table. This option is
available only when you
are creating second
project.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity (2/5)
© SAP SE AR822 61
LOGO HERE
@ Copyright. All rights reserved.
Step 3 of 5
In this example, the Connection Details drop down menu provides the
Edit option. This means the connection is New and you can edit the
connection information because it is not associated with any other
project.
In this example, the Connection Details drop down menu excludes the Edit
option. This means the connection is associated with other project, and can
only be resued but can not be edited.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity (3/5)
© SAP SE AR822 62
LOGO HERE
@ Copyright. All rights reserved.
Step 4 of 5
Option B: Create a fresh connection by clicking on Add new Connection button.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity (4/5)
© SAP SE AR822 63
LOGO HERE
@ Copyright. All rights reserved.
Step 5 of 5
Duplicate connection for a unique combination of SAP System ID + Document Type is prohibited.
To add a new connection, define or select appropriate values:
Transport Type – Choose Addon if you are integrating via Cloud Connector.
If using middleware: choose HTTPS
Environment – Choose the environment of your backend SAP system for
which you are setting up the connection as TEST or PRODUCTION, or
TEST/ PRODUCTION.
Name – When you create a connection manually, the name can be of your
choice. Spaces or Special Characters in the name are not allowed.
System ID – Choose your SAP system’s Logical System ID.
Configuring Ariba Cloud Integration Project: Connection for
Direct Connectivity (1/5)
© SAP SE AR822 64
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity
This section holds information
for connecting from CIG to
your SAP system.
This section holds information
for connecting from your SAP
system to CIG.
Connect to
Backend
Connect Trading
Partner to CIG
There are two Connection Details pages:
© SAP SE AR822 65
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity - Connect to Banckend (1/2)
Step 1 of 2
Connect to Backend section:
Document Type: Choose “Any” to have all the document types covered under a
single connection. Else, you will need to create separate connection for each of the
document type.
Domain Name – Virtual Host name of your SAP system maintained in SAP Cloud Connector
configuration.
Port – Virtual Port number of your SAP system maintained in SAP Cloud Connector
configuration.
Client ID – Your SAP system’s Client ID.
Location ID – Your SAP Cloud Connector’s unique Location ID defined in SAP Cloud
Connector configuration.
Document Type Example: In Ariba Network Integration scenario, customer may want to route inbound invoices (from Ariba Network) to
ERP system through their Tax Management System or Vendor Invoice Management (VIM) System & rest of the incoming documents
directlyto their backend ERP system. Then, customer can create 2 connections - one for inbound Invoice to Tax management System or
VIM & other for rest of the inbound documents to ERP system.
In such case, customer need to ensure that
The Tax Management System or VIM is capable of handling & processing the IDOC or SOAP messages.
Connectivity is built between their Tax Management System or VIM.
© SAP SE AR822 66
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity - Connect to Banckend (2/2)
Step 2 of 2
Connect to Backend section continued:
Authentication – You can choose from the available values – Basic or Certificate
Ø Basic: For this mode of authentication, provide Username & Password of your SAP
system manually.
Ø Currently certificate authentication mode is not supported while connecting to
backend on-premise SAP system via cloud connector (Direct Connect option).
© SAP SE AR822 67
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity - Connect Trading Partner to CIG (1/2)
Step 1 of 2
Connect Trading Partner to CIG section:
Authentication Type – You can choose from the available values – Basic or Certificate.
Ø Basic: For this mode of authentication, Username (P User ID) will be set
automatically. You can not change the value of P User ID.
Ø Certificate: If you select this mode of authentication, you need to add the public key of the
certificate received from trusted CAs. (Certificate that is to be added should be in the BASE64
encoded format.)
© SAP SE AR822 68
LOGO HERE
@ Copyright. All rights reserved.
Step 2 of 2
Duplicate certificates are prohibited.
Configuring Ariba Cloud Integration Project: Connection for Direct Connectivity - Connect Trading Partner to CIG (2/2)
© SAP SE AR822 69
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for
Direct Connectivity
Once all the required information is provided / verified:
Click Save
Click Next
The connection is made available for production as soon as the project in which it has
been configured is deployed to production.
© SAP SE AR822 70
LOGO HERE
@ Copyright. All rights reserved.
If you are connecting via middleware perform the following steps:
1. On the Connection tab either select existing connection from the list of Reusable Connections or
click on Add New Connection.
2. Choose HTTPS as the Transport Type.
3. Choose the Environment of your connection as Test or Production or Test / Production.
4. Enter a Name for your connection in the Name field.
5. Choose the system to which you would like to connect to in the System ID field.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity (1/2)
© SAP SE AR822 71
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity (2/2)
© SAP SE AR822 72
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity
This section holds information
for connecting from CIG to
your middleware.
This section holds information
for connecting from your
middleware to CIG.
Connect CIG to
Trading Partner
Connect Trading
Partner to CIG
There are two Connection Details pages:
© SAP SE AR822 73
LOGO HERE
@ Copyright. All rights reserved.
6. In the Connect CIG To Trading Partner section:
Choose the Document Type for the connections of this integration project. Choose ANY to support
all document types. Choose a specific document type, if you want to restrict the project.
Enter the URL to connect to the middleware. See the information on next 2 pages.
Choose the Authentication Type for the middleware connection:
• Basic: Enter your middleware Username and Password to authenticate.
• Certificate: Download the certificate & save on your middleware system.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity - Connect CIG
to Trading Partner (1/3)
© SAP SE AR822 74
LOGO HERE
@ Copyright. All rights reserved.
A generic URL would be:
https://:/XISOAPAdapter/MessageServlet?channel=::"
Sample URL:
https://samplepi:51101/XISOAPAdapter/MessageServlet?channel=:BS_ACIG:CC_CIG_S
OAP_Sender
Where:
ü samplepi: is the server name
ü 51101: is the port
ü BS_ACIG: is the business system name
ü CC_CIG_SOAP_Sender: is the communication channel name for the SAP Process
Integration configuration scenario
Middleware: SAP Process Integration
Configuring Ariba CloudIntegration Project: Connection for Mediated Connectivity - Connect CIG
to Trading Partner (2/3)
© SAP SE AR822 75
LOGO HERE
@ Copyright. All rights reserved.
https://:/cxf/receiveCIGSOAP
& / Or
https://:/ cxf/receiveCIGSyncDocument
Sample URL: https://arlkgt1-hcioem.avtsbhf.eu1.hana.ondemand.com:443/cxf/receiveCIGSOAP
Where:
ü arlkgt1-hcioem.avtsbhf.eu1.hana.ondemand.com: is the hostname
ü 443: is the port
Middleware: SAP CPI
For Network Integration; Sourcing Integration & Procurement Integration Async Flows:
https://:/cxf/receiveCIGSOAP
For Procurement Integration Sync Flows: https://:/
cxf/receiveCIGSyncDocument
If you are implementing Ariba Procurement Integration & deploying all the integration
flows, then you need to create separate connections – one with synchronous
document type and one with Document Type = Any for rest of the document types.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity - Connect CIG
to Trading Partner (3/3)
© SAP SE AR822 76
LOGO HERE
@ Copyright. All rights reserved.
7. In the Connect Trading Partner to CIG section:
Choose the Authentication Type for the middleware connection:
• Basic: Your P User ID will get populated in Username filed. No password needed.
• Certificate: Add your certificate or reuse an existing one. If you want to reuse a certificate that you
already added, choose it in the Certificate Name section.
TEST URL & PROD URL of CIG will be displayed.
8. Click Save.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity - Connect
Trading Partner to CIG (1/2)
© SAP SE AR822 77
LOGO HERE
@ Copyright. All rights reserved.
About opening ports in SAP PI/PO
When using any On Premise solution – there is only 1 IP (or “data center address”).
However, when CIG is present, there is no static IP. Therefore, we must instead configure the IP Range in SAP PI.
Please contact Ariba Customer Support to get the information on IP ranges for opening ports in SAP PI.
Configuring Ariba Cloud Integration Project: Connection for Mediated Connectivity - Connect
Trading Partner to CIG (2/2)
© SAP SE AR822 78
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Mappings
In the CIG Buy Side Integration, standard mappings are developed in XSLT &
stored in the database.
Thus, you don’t need to perform any activities in this step.
Click Next
© SAP SE AR822 79
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Parameters
Follow these steps to define parameters:
• Within the Parameters tab, select the Document Type from the dropdown menu
• Choose the document type being adopted/add the cross-reference mappings.
• Click Add
In this section you need to define values in the parameter fields which you
want to map.
• The transactions & the related parameters are added by the administrator.
• You can define the values for both test & production environments.
79
© SAP SE AR822 80
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Parameters
Follow these steps to define parameters (continued):
• Click the pencil icon to edit the entry
In this section you need to define values in the parameter fields which you
want to map.
• The transactions & the related parameters are added by the administrator.
• You can define the values for both test & production environments.
• Enter values for the parameters in the TEST Environment and PROD Environment.
• If you want to have different value in PROD Environment, uncheck the box Use same
values. Then click Save.
These fields are part of the message that will be sent/received based on the document –
the field must be mapped to the value – can be a standard value or created.
© SAP SE AR822 81
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Parameters
Follow these steps to define parameters (continued):
• Enter parameter values for another Document Type as
needed or click Next.
In this section you need to define values in the parameter fields which you want to map.
• The transactions & the related parameters are added by the administrator.
• You can define the values for both test & production environments.
© SAP SE AR822 82
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-UOM Mappings
Follow these steps to define UOM Mappings:
• Click Download link to obtain the UOM.csv file.
Once you define parameter values for all required Document Types, you will land on the UOM Template page:
UOM Mapping Requirements
• Ariba Network (required)
• SAP Ariba Sourcing (required)
• SAP Ariba Procurement (excluded)
© SAP SE AR822 83
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-UOM Mappings
Once you define parameters values for all required Document Types, you will land on UOM Template page
Follow these steps to define UOM Mappings (continued):
• Define the corresponding SAP ERP value for each Ariba Network specific UOM, and
save the template.
UOM Mapping Requirements
• Ariba Network (required)
• SAP Ariba Sourcing (required)
• SAP Ariba Procurement (excluded)
© SAP SE AR822 84
LOGO HERE
@ Copyright. All rights reserved.
Follow these steps to define UOM Mappings (continued):
• Select the System ID for which you would like to upload UOM maps;
click on Upload link to add the template & click Next.
.
Configuring Ariba Cloud Integration Project: Cross Reference-UOM Mappings
UOM Mapping Requirements
• Ariba Network (required)
• SAP Ariba Sourcing (required)
• SAP Ariba Procurement (excluded)
© SAP SE AR822 85
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-UOM Mappings
UOM Mapping Requirements
• Ariba Network (required)
• SAP Ariba Sourcing (required)
• SAP Ariba Procurement (excluded)
Example shown:
For integration with SAP Ariba Procurement, UOM Mappings are maintained in the SAP Ariba
Procurement realm. You don’t need to define it in CIG.
© SAP SE AR822 86
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Lookup Values
Once you define UOM Mappings, you will land on Lookup Table page.
Values in Lookup Table are required mainly for Real Time Budget Check; Total Landing Cost & Withholding Tax features of
Ariba Procurement Integration & Quote Request feature of Ariba Sourcing Integration.
Follow these steps to define Lookup Values Mappings:
• In the Document Types/Names column, click on Select to add document
type & from the available list, choose the document type. The associated
template to that document type will get displayed.
© SAP SE AR822 87
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Lookup Values
• Expand the template
node & enter the Ariba
value & Customer value
for the template in the
TEST Environment and
PROD Environment.
• Click Next when values
for all the required
document types are
configured.
© SAP SE AR822 88
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Lookup Values
Additional document
type example:
• Expand the template node & enter
the Ariba value & Customer value
for the template in the TEST
Environment and PROD
Environment.
• Click Next when values for all the
required document types are
configured.
© SAP SE AR822 89
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Lookup Values
Additional document
type example:
• Expand the template node & enter the Ariba value & Customer value for the
template in the TEST Environment and PROD Environment.
• Click Next when valuesfor all the required document types are configured.
© SAP SE AR822 90
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Lookup Values
Refer to the sample values per template given in below table:
Document type Template Name Sample SAP Ariba value Sample customer value
RequisitionRealTimeBudgetExportRequest TaxOnCompanyCode 3000 TRUE
PurchaseOrderExportRequest ProcurementConditionType
Road Freight FRBI
Air Freight FRB2
Handling Charge ZB00
PurchaseOrderChangeExportRequest ProcurementConditionType
Road Freight FRB3
Handling ZB00
PaymentExportRequest WithholdingTaxMap
WHTTAX1 T1
WHTTAX2 T2
WHTTAX3 T3
© SAP SE AR822 91
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Cross Reference-Defining Realm
If you are working on a project for Ariba Sourcing integration or Ariba Procurement integration, then once you define Lookup
Table values, you will land on Realm ID page.
Here you need to select the realm you would like the project to connect to.
This is more important when you have multi-ERP (FPC) environment & creating different projects for each back-end system.
Follow these steps to define Realm ID:
1. Select Realm ID to which you are connecting the specific back-end system ID you have defined while creating connection.
2. Click Next.
© SAP SE AR822 92
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Configuration Confirmation
After you have defined values for all the Cross References, you will land on Configuration Confirmation page.
Here you can review the configuration details & modify any information as & if needed.
1. Click the pencil icon to edit, and modify the details of any configuration if needed.
2. Click Confirm.
© SAP SE AR822 93
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Configuration Confirmation
Once the project is confirmed, the project status will be In Testing.Before you confirm the project, it will hold In Progress status.
© SAP SE AR822 94
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Test
At this stage you need to decide whether to test the configured documents manually or you would want to use TestCentral, the
automated test tool to execute the test scenarios programmatically / in automated way.
1. If you do not want to use TestCentral & perform manual testing, click on Skip Test.
2. If you want to use TestCentral, click on Run Test.
The Execution Start Date can be set in either case.
• This is just a stop gap arrangement. Since the
Self-Test framework is not ready, you will not
find complete functionality of the framework
working.
• It is strongly recommended to execute all of
your UAT scenarios in this phase before you
Go Live.
© SAP SE AR822 95
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Test
At this stage you need to run the mandatory test cases either manually or via TestCentral.
• When you choose Skip Test, system will ask your confirmation which represents your responsibility to execute all the
necessary business test scenarios & achieve desired quality criteria. It is advisable to schedule / set the Execution Start Date
to accommodate the timeframe, you need to complete UAT phase.
• When you choose Run Test, you can schedule the testing activity at a specific date & time. All the test scenarios that you select
will get executed.
© SAP SE AR822 96
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Test
Once the testing is complete, the project status will be Tested.
© SAP SE AR822 97
LOGO HERE
@ Copyright. All rights reserved.
Configuring Ariba Cloud Integration Project: Deployment
Once you complete execution of UAT scenarios, the results will be captured in the background for each scenario defined in
TestCentral as well as a successful execution of those scenarios,
Status will be updated as Completed.
You can see result of individual test scenario in Pass / Fail column & the Go Live button activated.
This means your project is ready to get deployed on production. Click the button to Go Live.
© SAP SE AR822 98
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
Usually, in SAP, a three-system landscape exists which consist of:
• Development Server –DEV
• Test or Quality Assurance Server – TEST / QA
• Production Server - PROD
This configuration is not meant as a system-failure preemptive measure but, as a configuration pipeline management. This pipeline approach is for a landscape where
the configuration in the Development system is moved to the Quality Assurance / Test system and, finally, to the Production system.
The advantages of the pipeline approach are as follows:
ü All systems are synchronized for Production functionalities.
ü Configuration changes are first done in Development, thoroughly tested in Quality Assurance and finally published in Production.
ü The migration path from one server to the next is simple & often, automated.
However, SAP Ariba exclusively features a landscape offering:
• Test Realm –TEST
• Production Realm -PROD
© SAP SE AR822 99
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
The SAP Ariba standard landscape is based on a two-environment platform. All prework, design, configuration, testing and training is done in Test while
Production is solely reserved for live business processes.
The advantages of this landscape are as follows:
• Simplicity of maintenance due to low number of environments.
• Limited synchronization efforts due to low number of environments.
© SAP SE AR822 100
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
If you have 3-tier landscape in SAP environment (SAP Dev; SAP Test & SAP Prod) & want to connect all 3 tiers with SAP Ariba, one of the following 3 options can be considered:
1. Disconnected SAP Dev environment:
SAP Dev >>> Not connected with SAP Ariba
SAP Test >>> SAP Ariba Test
SAP Prod >>> SAP Ariba Prod
• SAP DEV server disconnected from SAP Ariba environment.
• SAP side development work done in SAP Dev & can be tested at component level only (may be using some simulators).
• SAP side development work done in SAP Dev is then transported to SAP Test for further end-to-end configuration & testing.
• Configuration and integration efforts are done in SAP Test.
• SAP Test is paired with SAP Ariba Test.
• Once the solution is ready, it is transported from SAP Test to SAP PROD while SAP Ariba Test is moved to SAP Ariba Prod.
• Master Data from SAP Prod can also be loaded into SAP Ariba Test (as & if necessary).
• Configuration or integration changes, as necessary, are done in SAP Test / SAP Ariba Test and, after testing, validation & approval, moved to SAP Prod / SAP Ariba Production.
• In CIG portal, regular (single) project with 2 separate connections (Environment = TEST & Environment = PROD) is created.
© SAP SE AR822 101
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
2. SAP Dev environment connected with SAP Ariba Test:
SAP Dev >>> SAP Ariba Test
SAP Test >>> SAP Ariba Test
SAP Prod >>> SAP Ariba Prod
• SAP Dev & SAP Test are paired with SAP Ariba Test.
• SAP side development work done in SAP Dev & tested with SAP Ariba Test.
• SAP side development work done in SAP Dev is then transported to SAP Test for further end-to-end configuration & testing.
• Configuration & integration efforts start in SAP Dev.
• Configuration & interfaces are then migrated to SAP Test.
• A limited & specific set of data can be used to connect SAP Dev with SAP Ariba Test to avoid uploading duplicate master data in SAP Ariba Test (from SAP Dev & SAP Test).
• If SAP Dev & SAP Test has overlapping master data, then consider using Content-based Routing in CIG to transmit the documents to appropriate back-endsystem (SAP Dev or SAP test).
• With this approach, you will be able to keep & use 2 projects in CIG. One pointing to SAP Dev & other pointing to SAP Test + SAP Prod.
• Once the solution is ready, SAP Test is moved to SAP PROD while SAP Ariba Test is moved to SAP Ariba Prod.
• Master Data from SAP Prod can also be loaded into SAP Ariba Test (as & if necessary).
• Configuration or integration changes, as necessary are done in SAP Dev / SAP Test / SAP Ariba Test and, after testing, validation & approval, moved to SAP Prod & SAP Ariba Prod.
• In CIG portal:
o Create a (single) project with 1 connection (Environment = TEST / PROD) is created & use for connecting SAP Dev to SAP Ariba Test. Make sure that this project is NOT deployed to PROD.
o Create another (single) project with 2 separate connections (Environment = TEST & Environment = PROD) is created & use for connecting SAP Test to SAP Ariba Test & SAP Prod to SAP Ariba Prod.
© SAP SE AR822 102
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
3. SAP Dev environment connected with SAP Ariba Supplemental realm (additional cost involved):
SAP Dev >>> SAP Ariba Supplemental
SAP Test >>> SAP Ariba Test
SAP Prod >>> SAP Ariba Prod
• SAP DEV server paired with SAP Ariba Supplemental.
• SAP side development work done in SAP Dev & tested with SAP Ariba Supplemental.
• SAP side development work done in SAP Dev is then transported to SAP Test for further end-to-end configuration & testing.
• Configuration & integration done in SAP Ariba Dev is manually migrated / replicated to SAP Ariba Test.
• Configuration & integration efforts start in SAP Dev.
• Configuration & interfaces are then migrated to SAP Test.
• SAP Test is paired with SAP Ariba Test.
• Once the solution is ready, it is transported from SAP Test to SAP PROD while SAP Ariba Test is moved to SAP Ariba Prod.
• Master Data from SAP Prod can also be loaded into SAP Ariba Test (as & if necessary).
• Configuration or integration changes, as necessary are done in SAP Test / SAP Ariba Test and, after testing, validation & approval, moved to SAP Prod / SAP Ariba Production.
• In CIG portal (Note that SAP Ariba Supplemental is an independent site with different ANID & CIG account. Thus, create projects in respective CIG account):
o Create a (single) project with 1 connection (Environment = TEST / PROD) is created & use for connecting SAP Dev to SAP Ariba Supplemental.
• Make sure that this project is NOT deployed to PROD.
o Create another (single) project with 2 separate connections (Environment = TEST & Environment = PROD) is created & use for connecting SAP Test to SAP Ariba Test & SAP Prod to SAP Ariba Prod.
o Custom mappings & / or engineering-driven custom mappings done in CIG account associated with SAP Ariba Supplemental need to be manually redone in CIG account associated with SAP Ariba Test.
© SAP SE AR822 103
LOGO HERE
@ Copyright. All rights reserved.
Managing Multiple Landscapes
Important considerations to be noted:
• A supplemental site is an additional SAP Ariba Test realm completely disconnected from the standard environment where the SAP Ariba solution is being
deployed.
• A Supplemental site requires licenses & subscription services to be purchased for the additional environment.
• Migration from SAP Ariba Dev to SAP Ariba Test is a manual process that must be considered accordingly in the Project Plan as it may take several days to
be completed.
• There is no standard or automated migration between the SAP Ariba Supplemental site & the SAP Ariba Test site. Thus, Supplemental site requires
services, as configuration cannot be done in a self-service mode.
• Supplemental site is created with a different ANID and linked to a different Ariba Network account.
• Such Ariba Network account does not include any supplier enablement services as it only serves the purpose of integration testing.
• Supplemental site behaves as any standard site, supporting CIG & not limiting the number of concurrent users.
• Trying to simulate a Development environment with Supplemental site is theoretically possible but, it would require increasing the subscription services
associated with the project, increasing the cost and the timelines.
• As they lack Ariba Network support, additional cost in the shape of additional hours is required to cover any required configuration or change in the Ariba
Network side.
• Supplemental site is not meant to become the pair of the SAP Dev server. The most common use case for a Supplemental site is “Education and Training”.
© SAP SE AR822 104
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 6: Resetting P User Password
By the end of this lesson, you will be able to:
• Reset P User password of SAP Ariba Cloud Integration Gateway.
© SAP SE AR822 105
LOGO HERE
@ Copyright. All rights reserved.
Resetting P User Password
In the event where you don’t remember your P User
Password or you want to change the P User
Password, you can use one of the following options to
reset your P User Password of your Cloud Integration
Gateway:
1. Through SAP Cloud Identity portal
2. Through CIG portal
© SAP SE AR822 106
LOGO HERE
@ Copyright. All rights reserved.
Resetting P User Password – through SAP Cloud Identity Portal
1. Access https://aribaoperations.accounts.ondemand.com/
2. Provide email ID associated with your CIG & click
Forgot Password
3. Once again provide email ID associated with your
CIG & click Send
© SAP SE AR822 107
LOGO HERE
@ Copyright. All rights reserved.
Resetting P User Password – through SAP Cloud Identity Portal (continued)
4. Open the email from your inbox & press Click here to reset
your password
5. Provide new password and click Save
© SAP SE AR822 108
LOGO HERE
@ Copyright. All rights reserved.
Resetting P User Password – through CIG Portal
1. Access CIG and navigate to My Configurations>>>Authorization.
Click Change Password
2. On the Warning popup, click Accept.
The warning popup is shown basically to remind you that
when you change P User password, you need to make
changes to the corresponding configuration objects where
P User ID & password information is used. For example:
1. SAP Data Sync
2. RFC Destination’s Logon & Security info
3. Interface Setup for Web Services
3. Provide new password & click Submit.
© SAP SE AR822 109
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 7: Configuring Multi-ERP for Network Integration
By the end of this lesson, you will be able to:
• Link one ore more SAP systems (Multiple ERP) to a single Ariba Network Buyer account through the Cloud Integration Gateway (CIG).
This lesson includes the following topics:
Steps to configure multi-ERP in:
i. Ariba Network Buyer Account
ii. CIG
iii. Cloud Connector
iv. SAP NetWeaver PI
v. SAP CPI
Prerequisites:
Raise a Service Request (SR) with Ariba Customer Support to enable your Ariba Network Buyer account for multi-ERP support.
© SAP SE AR822 110
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Ariba Network Buyer account
1. Once Ariba Customer Support confirms the enablement of multi
ERP for your AN Buyer Account, login to your AN Buyer account.
Click on Administration dropdown & then click on Configuration
2. You will see Business Application IDs link enabled. You can see
this link only if your AN Buyer Account is multi ERP enabled. Click
on the link
© SAP SE AR822 111
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Ariba Network Buyer account
3. You will see option to create Business Application IDs.
Click Create
4. Provide details of your Business (SAP) System & other details.
Click Save
© SAP SE AR822 112
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Ariba Network Buyer account
5. You will see the BusinessSystem getting displayed under List
of System IDs. Click Create again to provide details of your
another Business (SAP) System if needed.
6. Provide details of your another Business (SAP) System & click
Save. You will see all your Business Systems listed. Click Save &
then click Done
© SAP SE AR822 113
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Ariba Network Buyer account
7. Once all your Business Systems are created, you can assign it
to your suppliers accordingly. To do so, click on Supplier
Enablement dropdown & then click Active Relationships. You
will see all suppliers connected to your AN Buyer.
8. Select the supplier to which you want to add Business System
ID info & from More Actions dropdown, click Edit.
© SAP SE AR822 114
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Ariba Network Buyer account
9. Go to Unique Supplier ID Configuration section & click Add.
10. Select System ID from the list you created & Vendor ID of the
supplier in that Business System. Click Save.
11. If you have the same supplier in another Business System,
repeat the step#13 and add Vendor ID of the supplier defined in
that Business System.
All the Vendor IDs associated with respective Business
Systems will then be displayed on the UI.
© SAP SE AR822 115
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in CIG
In CIG, you would need to create separate project per ERP / Business System.
Follow the below steps:
1. Send the ERP information of each SAP system to CIG.
2. Ensure that information of each SAP system is available in CIG>>>Basic Data & is accurate.
3. Create separate projects per SAP system & select relevant information in the connection tab while creating projects.
© SAP SE AR822 116
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in Cloud Connector
In Cloud Connector, you would need to define different Internal Systems corresponding to each ERP system.
© SAP SE AR822 117
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in SAP NetWeaver PI
In PI, you would need to add the condition in Receiver Determination.
© SAP SE AR822 118
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in SAP CPI
1. Maintain value mappings for SAP System ID & Virtual Host / Port.
Virtual host & port should be the same as defined in Cloud Connector for
that particular SAP System ID.
2. Maintain value mappings for SAP System ID & SAP Credentials.
These are virtual user credentials for which you will need
to define mappings with actual user credentials in a later
step.
© SAP SE AR822 119
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in SAP CPI
3. Maintain value mappings for SAP System ID & Cloud Connector
Location ID.
4. Maintain mappings for SAP Credentials & SAP Login Info:
a. Under Manage Security, click on Security Material.
© SAP SE AR822 120
LOGO HERE
@ Copyright. All rights reserved.
Configuring Multi-ERP for Network Integration in SAP CPI
5. Maintain mappings for SAP Credentials & SAP Login Info
b. Click on User Credentials.
6. Maintain mappings for SAP Credentials & SAP Login Info
c. Add SAP User ID & Password for the Credentials maintained in Value Mappings in
step#2.
© SAP SE AR822 121
LOGO HERE
@ Copyright. All rights reserved.
Custom Mapping Tool
© SAP SE AR822 122
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 1: Overview
By the end of this lesson, you will be able to:
• Navigate the Custom Routing Tool
• Understand the feature and functions of Custom Mapping Tool
This lesson contains the following use cases:
i. Feature Overview
ii. Execution Flow
iii. Supported Version
© SAP SE AR822 123
LOGO HERE
@ Copyright. All rights reserved.
Mapping Tool Overview
Mapping Tool
The mapping tool provides added self-service in CIG which helps support the hefty demand of custom mappings.
Using this feature the buyer can do the following:
Create & Edit Customization
Compare
Deploy/ Undeploy & Manage versions
Test
© SAP SE AR822 124
LOGO HERE
@ Copyright. All rights reserved.
Mapping Tool Overview
Flow:
ØCIG executes the standard mappings.
ØCustom XLSTs via SRs.
ØCIG executes the mappings done via mapping tool.
Standard Mappings SR Custom Mappings Mapping tool Custom Mappings
© SAP SE AR822 125
LOGO HERE
@ Copyright. All rights reserved.
Mapping Tool Overview
Access Mapping tool:
• Log in to Cloud Integration Gateway.
• Go to My Configurations.
• Navigate to Mappings.
© SAP SE AR822 126
LOGO HERE
@ Copyright. All rights reserved.
Mapping Tool Overview
Supported CIG AddOn Versions:
Ø Starts from ADDONINFO 1 - ARBCI10003
Ø Starts from ADDONINFO 2 - ARBCI20003
Ø Please check the support policy for updated information, SAP Note: 2400737
© SAP SE AR822 127
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 2: Features
By the end of this lesson, you’ll be able to :
• Create & Edit Customizations
• Deploy, Un-deploy, and Manage Versions
• Test a Custom Map
Lesson Topics
• Create Customization
• Edit Customization
• Deploy Customization
• Testing Customization
© SAP SE AR822 128
LOGO HERE
@ Copyright. All rights reserved.
Features: Create & Edit Customization
Create a new custom mapping:
Go to the Mappings tab under My Configuration:
1. Select the Transaction for which you want to do the customization;
Click ADD.
2. On the Document Mapper screen; Select the System ID from the
drop down menu and Click OK.
3. On the Document Mapping screen, Map the Source Node to
Target Node and Click Save Mapping
© SAP SE AR822 129
LOGO HERE
@ Copyright. All rights reserved.
Features: Create & Edit Customization
Edit custom mappings:
Go to the Mappings tab under My Configuration:
1. Select the transaction for which you want to edit the customization.
Click Edit icon
2. On the Document Mapping screen, Edit the Source Node to Target
Node mapping and click Save Mapping
© SAP SE AR822 130
LOGO HERE
@ Copyright. All rights reserved.
Features: Deploy/Un-deploy & Manage Versions
Deploy custom mappings:
Go to the Mappings tab under My Configuration:
1. Select the Transaction you want to manage. Click List Versions
2. On the Mapping Version Details screen, select Version & Deployment mode
and click Close
© SAP SE AR822 131
LOGO HERE
@ Copyright. All rights reserved.
Features: Deploy/Un-deploy & Manage Versions
3. On the My Configurations screen, verify the selected deployment version and
mode is marked correctly.
© SAP SE AR822 132
LOGO HERE
@ Copyright. All rights reserved.
Features: Testing Custom Map
Testing Custom Mappings:
Go to the Mappings tab under My Configuration:
1. Select the Transaction you want to test, click Test Mapping
2. On the Mapping Testing Tool screen, Browse or Copy the input content
© SAP SE AR822 133
LOGO HERE
@ Copyright. All rights reserved.
Features: Testing Custom Map
3. Select SystemID and click Test
4. On the Mapping Testing Tool screen, check the mapping
tool extension transformation
© SAP SE AR822 134
LOGO HERE
@ Copyright. All rights reserved.
About This Lesson
@ Copyright. All rights reserved.
Lesson 3: Node Functions
By the end of this lesson, you’ll be able to :
• Describe, and provide examples of, the node functions
• Identify and execute specific custom mapping use cases
This lesson includes the following topics:
1. Node Functions
2. Use Cases
© SAP SE AR822 135
LOGO HERE
@ Copyright. All rights reserved.
Node Functions
© SAP SE AR822 136
LOGO HERE
@ Copyright. All rights reserved.
Use Cases
• Map extrinsic at header level
• Map extrinsic at item level
• Map a new optional element/ Concatenate/ Sub-string
• Delete a mappedelement
• Format Number
• Normalize
• Format Date
• Map a Child Value form source structure to a Parent field in target structure
• Choose When
• Map text node to item level extrinsic
• Create/ Replace node
© SAP SE AR822 137
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Header Level
EXAMPLE:
Map SAP Purchase Order document type to OrderRequest cXML extrinsic
(Map E1EDK01-BSART to Extrinsic(2) and Add Constant Value to Extrinsic-Name)
Go to the Mappings tab under My Configuration and select the Transaction
1. Select the Extrinsic at Header level, click Duplicate Node
© SAP SE AR822 138
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Header Level
2. On cXML Order Request Screen verify the new Extrinsic field
3. On cXML Order Request Screen, click the Target Node and click Add
Constant Value
© SAP SE AR822 139
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Header Level
4. Enter the Extrinsic name and click Ok
5. On the Document Mapping screen, map the Source Node to Target Node and
click Save Mapping
6. Give the sample payload and run Test
© SAP SE AR822 140
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
EXAMPLE:
Map SAP Material Group to cXML OrderRequest in
OrderRequest>>ItemOut>>ItemDetail>>Extrinsic
Go to the Mappings tab under My Configuration and select the Transaction
1. Select the Extrinsic at Line level, click the Duplicate Node option.
© SAP SE AR822 141
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
2. Map E1EDP01>>MATKL to ItemDetail>>Extrinsic and hard-code the
extrinsic name to MaterialGroup
3. Loop the material group for all the line items, right-click on the
mapping line and choose Target Variable, click Add Position
Variable
© SAP SE AR822 142
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
4. Check for the highlighted text Select an Item on the target structure.
5. Select the structure with multiple occurrence, click the root node of
extrinsic(2) i.e ItemOut from the structure.
© SAP SE AR822 143
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
6. Add source condition to loop the segments, right-click on the
mapping line and choose Add Source Condition
7. Select a condition item as E1EDP01 since E1EDP01 and ItemOut
are in the same level.
© SAP SE AR822 144
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
8. From the pop-up choose Position Variable radio button, click Ok
9. On the Document Mapping screen, click Save Mapping
© SAP SE AR822 145
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map Extrinsic at Item Level
10. Give the sample payload and run Test
© SAP SE AR822 146
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Delete a Mapped Element
If a buyer does not want to send certain nodes to the target system,
then they can suppress the details using this node function.
Ex: Buyer does not want to send the accounting details to the supplier.
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the target segment to suppress, click on the Distribution
Node on cXML Order Request and Delete
2. On cXML Order Request screen, check for the Red Line against
Distribution node
© SAP SE AR822 147
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Delete a Mapped Element
3. On the Document Mapping screen, click Save Mapping
4. Give the sample payload and run Test
© SAP SE AR822 148
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Format Number
This function is used for formatting different numeric values.
Ex: If the amount value is 10.1999, and if we introduce a format
number function with formatting 0.00, then the output would be
10.20.
ERPOrder_PurchOrdLineDetails_Item>>ServiceDetails>>MaxAmo
unt (fx) à POITEMS>>ITEM>>Maxamount
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the mapping where you want to add the function, right-
click on the Mapping Line, click Functions
2. On the selection screen, choose Add Function, click Add
Format Number Function
© SAP SE AR822 149
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Format Number
3. On the pop-up screen, enter the Number Format Pattern in the
box, click OK, click Save Mapping
4. Give the sample payload and run Test
SOURCE TARGET
© SAP SE AR822 150
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Format Date
This function is used for formatting different Date types.
EX: Source has a date format like 2019-01-28 (YYYY-MM-DD) and if we need
to change the date format to 2019-28-01 (YYYY-DD-MM), then add date
format function like [Y0001]-[D01]-[M01].
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the mapping where you want to add the function, right-click on the
Mapping Line, click Functions
2. On the selection screen, choose Add Function, click Add Format Date
Function
© SAP SE AR822 151
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Format Date
3. On the Pop-up screen, enter the Date Format Pattern, click OK, click
Save Mapping
4. Give the sample payload and run Test
© SAP SE AR822 152
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Normalize Function
This function is used for normalizing any field values.
Ex: Removes white spaces from the field value.
Go to the Mappings tab under My Configuration and select the Transaction
1. Select the mapping where you want to add the function, right-click on the
Mapping Line, click Functions
2. On the selection screen, choose Add Function, click Add Normalize
Function, click Save Mapping
© SAP SE AR822 153
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Normalize Function
3. Give the sample payload and run Test
SOURCE TARGET
© SAP SE AR822 154
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map a Child Value from Source Structure to Parent Field in Target Structure
EXAMPLE: Mapping certain filed at line level to a field in header level
based on a condition.
Map E1EDP01>>E1EDP02>>BELNR(QUALF = 002) from source to
OrderRequestHeader>>@parentAgreementID
Go to the Mappings tab under My Configuration and select the
Transaction
1. Select the E1EDP01 from source structure, Map E1EDP02-
>BELNR to OrderRequestHeader-@parentAgreementID.
© SAP SE AR822 155
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map a Child Value from Source Structure to Parent Field in Target Structure
2. Add Source Condition on the mapping line with field QUALF(Qualifier).
3. Select the condition item as QUALF, check for the pop-up
© SAP SE AR822 156
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map a Child Value from Source Structure to Parent Field in Target Structure
4. Enter the qualifier as 002 or the required qualifier, click OK
5. Now, again click the mapping line, choose Select a Condition
Item, then select the first line via mapping (as the reference
remains same across all line items); click Add Source condition
and click E1EDP01
© SAP SE AR822 157
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map a Child Value from Source Structure to Parent Field in Target Structure
6. Check for the condition pop-up, enter from which line item the
value needs to be selected, Enter 1, click OK
7. Give the sample payload and run Test
© SAP SE AR822 158
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Map a Child Value from Source Structure to Parent Field in Target Structure
First line item E1EDP02>>BELNR is 123. This need to be
mapped to parentAgreementID at OrderRequestHeader.
© SAP SE AR822 159
LOGO HERE
@ Copyright. All rights reserved.
Use Cases: Choose When
This node function is similar to if and else structure.
Ex: If ExternalLineNumber exists, map it to target else map
ERPLineItemNumber.
