1. Depending on the source, the routes in the routing table can usually be divided into which of the
following categories? (Multiple choice)
A. Interface routing
B. Direct routing
C. Static routing
D. Dynamic routing
Answer: BCD
2. To view the debug information of the NAT packet, you should use the ______ command to open
the debug information and output it to the monitor.
A. terminal monitor
Debugging nat
 1 / 19
https://www.dumpsinfo.com/unlimited-access/
https://www.dumpsinfo.com/exam/gb0-192-enu
B. terminal debugging
Debugging nat
C. terminal monitor
Terminal debugging
Debugging nat packet
D. terminal monitor
Terminal debugging
Debug nat
Answer: C
3.The messages exchanged between the DHCP relay and the DHCP server use ______.
A. unicast
B. broadcast
C. multicast
D. anycast
Answer: A
4. The Ethernet port Ethernet1/0 of the customer router MSR-1 is configured as follows:
Interface Ethernet0/0
IP address 192.168.0.1 255.255.255.0
This interface is connected to a Layer 3 switch, and this Layer 3 switch is the default gateway of the
customer's office network segment 192.168.7.0/24~192.168.83.0/24.
Now the customer requires configuring an ACL on MSR-1 to prohibit all users on the office network
from initiating Telnet to the address 192.168.0.1 of MSR-1. Which of the following configurations is
correct?
A. Acl number 3000
Rule 0 deny 0.0.0.0 255.255.255.255 destination 192.168.0.1 0 destination-port eq telnet
Interface Ethernet0/0
IP address 192.168.0.1 255.255.255.0
Firewall packet-filter 3000 inbound
B. Acl number 3000
Rule 0 deny 0.0.0.0 255.255.255.255 destination 192.168.0.1 0 destination-port eq telnet
Interface Ethernet0/0
IP address 192.168.0.1 255.255.255.0
Firewall packet-filter 3000 outbound
C. Acl number 3000
Rule 0 deny 255.255.255.255 0 destination 192.168.0.1 0 destination-port eq telnet
Interface Ethernet0/0
IP address 192.168.0.1 255.255.255.0
Firewall packet-filter 3000 inbound
D. Acl number 3000
Rule 0 deny 255.255.255.255 0 destination 192.168.0.1 0 destination-port eq telnet
Interface Ethernet0/0
IP address 192.168.0.1 255.255.255.0
Firewall packet-filter 3000 outbound
Answer: A
5. There is a route in the routing table of the router with the network segment 10.168.100.0/24, its
Cost is 20, and its Preference is 255. Which of the following statements about this route are correct?
 2 / 19
https://www.dumpsinfo.com/
(Multiple choice)
A. This route must be learned through dynamic routing
B. The priority of this route is the highest value, indicating any route from an untrusted source.
C. Cost 20 means that the hop count of this route is 20
D. This is a valid dynamic route
Answer: AD
6. According to the way the switch processes VLAN data frames, the port types of H3C Ethernet
switches are divided into ______.(Multiple choice)
A. access port
B. trunk port
C. Mirror port
D. hybrid port
E. monitor port
Answer: ABD
7. Which of the following statements about Hybrid ports is correct?
A. The Hybrid port only receives data frames with VLAN tags
B. Hybrid ports can strip certain VLAN tags in the outbound port direction.
C. When the Hybrid port sends data, it must carry the VLAN tag
D. Hybrid ports do not need to be configured with PVID
Answer: B
8.The DHCP client sends a _______ message to the DHCP server to update the IP lease?
A. DHCP Request
B. DHCP Release
C. DHCP Inform
D. DHCP Decline
E. DHCPACK
F. DHCP OFFER
Answer: A
9. Among the following options, which are the characteristics of 802.1x authentication based on MAC
address? (Multiple choice)
A. All access users under the port need to be verified individually.
B. When the first user under the port goes offline, other users will also be denied access to the
network.
C. When a user goes offline, only that user cannot use the network
D. As long as the first user under the port is authenticated successfully, other access users can use
network resources without authentication.
Answer: AC
10. The customer’s network connection looks like:
HostA----GE0/0--MSR-1--S1/0-----WAN-----S1/0--MSR-2--GE0/0----HostB
Both routers come with factory default configuration. Correct IP addresses are configured for the four
interfaces of the router. The IP addresses and gateways of the two hosts, HostA and HostB, are
correctly configured. Assuming that all physical connections are normal, then ______. (Multiple
 3 / 19
https://www.dumpsinfo.com/
choice)
A. Each router needs to be configured with at least 1 static route to achieve intercommunication
between HostA and HostB.
B. Each router needs to be configured with at least 2 static routes to achieve intercommunication
between HostA and HostB.
C. No routing is configured on the router. HostA can ping the IP address of interface S1/0 of MSR-2.
D. No routing is configured on the router. HostA can ping the IP address of interface S1/0 of MSR-1.
Answer: AD
11. Two MSR routers are directly connected through their respective GigabitEthernet0/0 interfaces.
The following configuration is seen on one MSR router:
Interface LoopBack2
IP address 8.8.8.8 255.255.255.255
#
Interface GigabitEthernet0/0
Port link-mode route
IP address 100.1.1.2 255.255.255.0
#
Rip 1
Undo summary
Version 2
Network 100.0.0.0
Network 8.0.0.0
Assuming that the routers at both ends have correctly configured RIP, which of the following analyzes
are correct based on this configuration? (Multiple choice)
A. The peer router will learn the RIP route 8.8.8.8/32
B. The peer router will learn the RIP route of 8.0.0.0/8
C. Turning off aggregation means sending different subnets within the natural network segment as
natural mask routes.
D. Turning off aggregation means that the subnet mask information of the natural network can be
passed through RIP
Answer: AD
12.VLAN division methods include ______.(Multiple choice)
A. Port-based partitioning
B. Division based on MAC address
C. Division based on port attributes
D. Protocol-based partitioning
E. Division based on subnets
Answer: ABDE
13. Which of the following statement is correct? (Multiple choice)
A. The FTP data connection remains open throughout the FTP session.
B. The FTP control connection remains open throughout the FTP session.
C. The FTP data connection is closed after the data transfer is completed.
D. The FTP control connection is closed after the data transfer is completed.
Answer: BC
 4 / 19
https://www.dumpsinfo.com/
14. In the switched network as shown in the figure, all switches have the STP protocol enabled.
Based on the information in the figure, which switch will be selected as the root bridge?
A. SWA
B. SWB
C. SWC
D. SWD
E. Insufficient information to judge
Answer: B
15. The two WAN interfaces S1/0 and S1/1 of router MSR-1 are connected to routers MSR-2 and
MSR-3 respectively. At the same time, the Ethernet port of MSR-1 is connected to MSR-4, and all
four routers run the RIP protocol.
After the network 192.168.0.0 on MSR-1 fails, MSR-1 immediately sends the update message that
the route is unreachable to the other three routers. If the suppression time is not considered, then
______. (Multiple choice)
A. RIP’s fast convergence mechanism is used on MSR-1
B. The RIP triggered update mechanism is used on MSR-1
C. If MSR-1 receives periodic routing update information from neighboring routers before it has time
to send updateinformation about this route, then MSR-1 will update incorrect routing information.
D. This method of sending update messages immediately cannot completely avoid routing loops
when used alone.
Answer: BCD
16. Two MSR routers are connected through Ethernet and serial interfaces respectively, as shown in
the figure. The PPP link layer protocol runs on the serial link, OSPF runs on the two routers, and both
belong to Area 0. At the same time, the three network segments on each router (GE interface network
segment, serial interface segment, LAN segment) are released in Area 0 through the network.
 5 / 19
https://www.dumpsinfo.com/
Currently, the OSPF neighbor status at both ends is stable, then ______. (Multiple choice)
A. If the OSPF Cost value is not modified, the LAN segment from RTA to RTB will prefer the GE link.
B. As long as the OSPF Cost values of the GE interface and serial interface of the two routers are
correctly modified, two equal-value routes to the other party's LAN will be formed on RTA and RTB.
C. On the GE link, RTA and RTB will still elect DR and BDR.
D. All the above statements are correct
Answer: ABCD
17. The two WAN interfaces S1/0 and S1/1 of router MSR-1 are connected to routers MSR-2 and
MSR-3 respectively. At the same time, the Ethernet port of MSR-1 was connected to MSR-4. All four
routers ran the RIP protocol and completed route learning correctly. All loop prevention features of
RIP were enabled on all routers. At this time, it was found that the MSR Network 192.168.0.0 on -2
fails, then ______. (Multiple choice)
A. The Cost of the 192.168.0.0 routing entry on MSR-2 is set to the maximum value.
B. In the routing tables on the four routers, the Cost of the 192.168.0.0 routing entry is set to the
maximum value.
C. MSR-2 will start the suppression time for the 192.168.0.0 routing entry.
D. The suppression time will also be started for the 192.168.0.0 routing entry on MSR-4.
Answer: ABCD
18. In a PPP connection, which of the following statement about NCP is wrong? (Multiple choice)
A. NCP is used to negotiate the authentication method
B. NCP is used to negotiate the format and type of data packets transmitted on the data link.
C. NCP is used to establish, tear down and monitor data links
D. NCP can be configured with different network layer protocols
Answer: AC
19. Among the following statements about Easy IP, which of the following is wrong?
A. Easy IP is a special case of NAPT
B. When configuring Easy IP, you do not need to configure ACL to match the packets that need to be
NAT translated.
C. There is no need to configure a NAT address pool when configuring Easy IP
D. Easy IP is suitable for situations where NAT equipment dials up or dynamically obtains a public IP
address.
Answer: B
20.8.8.8/32 Direct 0 0 127.0.0.1 InLoop0
21.The transport layer protocol that DNS can use is______.
 6 / 19
https://www.dumpsinfo.com/
A. TCP
B. UDP
C. TCP or UDP
D. NCP
Answer: C
22.Which of the following are correct IPv6 addresses? (Multiple choice)
A. 2001:410:0:1::45FF
B. 2001:410:0:1:0:0:0:0:45FF
C. 2001:410:0:1:0:0:0:45FF
D. 2001:410:0:1:45FF
E. 2001:410::1:0:0:0:45FF
Answer: ACE
23. Among the following statements about Easy IP, which is correct? (Multiple choice)
A. Easy IP is a special case of NAPT
B. When configuring Easy IP, you do not need to configure ACL to match the packets that need to be
NAT translated.
C. There is no need to configure a NAT address pool when configuring Easy IP
D. Easy IP is suitable for situations where NAT equipment dials up or dynamically obtains a public IP
address.
Answer: ACD
24. Two routers MSR-1 and MSR-2 are interconnected through the S0/0 interface. The two routers
learn the routes of the LAN segment from each other by running the RIP protocol.
See the following configuration commands on MSR-1:
[MSR-1-Serial0/0] rip authentication-mode md5 rfc2453 H3C
Which of the following interpretation of this command is correct? (Multiple choice)
A. Configure RIP to use MD5 plaintext authentication
B. Configure RIP to use MD5 ciphertext authentication
C. Specify MD5 verification to use the message format specified in RFC2453
D. Specify MD5 authentication to use H3C private extension protocol message format
Answer: BC
25. Host B and Host A cannot access each other.
26. Which of the following statements about frame relay are correct?
A. Configure InverseARP to automatically discover the DLCI address of the peer router.
B. Frame relay DTE equipment can query the permanent virtual circuit status on the interface through
LMI
C. The frame relay network can realize interconnection between multiple nodes and can broadcast a
certain frame to all nodes at one time.
D. Permanent virtual circuits are virtual circuits automatically allocated through protocols, and their
creation/deletion does not require manual operation.
Answer: B
27. To view the comprehensive information of the routing table on the MSR router, such as the total
 7 / 19
https://www.dumpsinfo.com/
number of routes, the number of RIP routes, the number of OSPF routes, the number of activated
routes, etc., which of the following commands can be used? (Multiple choice)
A. <MSR>display ip routing-table statistics
B. [MSR-GigabitEthernet0/0] display ip routing-table statistics
C. [MSR] display ip routing-table
D. [MSR] display ip routing-table accounting
Answer: AB
28. It is required to set a subnet mask to divide the Class B network 172.16.0.0 into as many subnets
as possible. Each subnet is required to accommodate 15 hosts, so the subnet mask should be _____.
Answer: 255.255.255.224
29. Use the ______ command to view NAT entries.
A. display nat table
B. display nat entry
C. display nat
D. display nat session
Answer: D
30. After executing the display command on the switch SWA, the switch output is as follows:
<Switch>display link-aggregation summary
Aggregation Interface Type:
BAGG -- Bridge-Aggregation, RAGG -- Route-Aggregation
Aggregation Mode: S -- Static, D -- Dynamic
Loadsharing Type: Shar -- Loadsharing. NonS -- Non-Loadsharing
Actor System ID:0x8000 ? 000f-e267-6c6a
AGG AGG Partner ID Selected Unselected Individual Share
Interface Mode Ports Ports Ports Type
????????????????????????????
RAGG10 S None 1 0 0 NonS
BAGG20 D 0x8000.00e0-fc-01 2 0 0 Shar
Which can be judged from the above output? (Multiple choice)
A. Aggregation group 10 contains 1 port participating in data forwarding
B. The type of aggregation group 10 is manual aggregation
C. The type of aggregation group 20 is dynamic protocol aggregation
D. There is no valid port in aggregation group 20
Answer: ABCD
31. Which of the following statement about IP addresses is correct? (Multiple choice)
A. The IP address consists of two parts: the network number and the host number.
B. The network number of a Class A IP address has 8 digits, and the actual number of variable digits
is 7 digits.
C. Class D IP addresses are usually used as multicast addresses.
D. Address translation (NAT) technology is usually used to solve the conversion of Class A addresses
to Class C addresses.
Answer: ABC
 8 / 19
https://www.dumpsinfo.com/
32. On MSR routers , configuration files are files saved in ______ format.
A. Batch file
B. Text file
C. Executable file
D. Database files
Answer: B
33. If you want the current configuration to continue to take effect after the system is restarted, you
should use the ______ command to save the current configuration to the configuration file before
restarting the device.
Answer: save
34. Divide a Class C network into subnets. If the subnet mask is 28 bits, then the maximum number of
hosts that each subnet can accommodate is ()
Answer: 14
35.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0
36.168.95.0/19 Direct 0 0 192.168.120.153 S6/0
Which of the following description of the route with the destination address 192.168.96.0/19 is
correct? (Multiple choice)
A. This is a directly connected route with a metricvalue of 0
B. The interface IP address of S6/0 on this router is 192.168.120.153
C. The next hop of the router, that is, the IP address of the peer device is 192.168.120.153
D. This is a manually configured static route with a metric value of 0
Answer: AB
37. Two empty-configured MSR routers MSR-1 and MSR-2 are interconnected through their
respective GE0/0, and their IP addresses are 192.168.1.2/30 and 192.168.1.1/30 respectively.
Then add the following configuration on both routers:
[MSR-ospf-1]area 0
[MSR-ospf-1-area-0.0.0.0]network 192.168.1.1 0.0.0.3
The OSPF Router IDs of the two routers are their respective GE0/0 interface addresses, and there is
no other configuration on the two routers.
So to ensure that MSR-1 becomes the OSPF DR in the next election, which of the following
configurations need to be added? (Multiple choice)
A. Configure on MSR-1: [MSR-1-GigabitEthernet0/0]ospf dr-priority 255
B. Configure on MSR-2: [MSR-2-GigabitEthernet0/0]ospf dr-priority 0
C. Configure on MSR-1: [MSR-1-ospf-1]ospf dr-priority 255
D. Configure on MSR-2: [MSR-1-ospf-1]ospf dr-priority 0
Answer: AB
38. In the network environment as shown in the figure, perform the following NAT configuration on
RTA:
[RTA]acl number 2000
[RTA-acl-basic-2000] rule 0 permit source 10.0.0.0 0.0.0.255
[RTA-acl-basic-2000] nat address-group 1 200.76.28.11 200.76.28.11
 9 / 19
https://www.dumpsinfo.com/
[RTA]interface Ethernet0/1
[RTA-Ethernet0/1] nat outbound 2000 address-group 1
After configuration, both Client_A and Client_B are accessing the Server, so the NAT table of RTA
may be ______ at this time.
A. Protocol GlobalAddr Port InsideAddr Port DestAddr Port
1 200.76.28.11 12289 100.0.0.1 1024 200.76.29.4 1024
VPN: 0, status: NOPAT, TTL: 00:01:00, Left: 00:00:59
1 200.76.28.11 12288 100.0.0.2 512 200.76.29.4 512
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:51
B. Protocol GlobalAddr Port InsideAddr Port DestAddr Port
1 200.76.28.11 12289 100.0.0.1 1024 200.76.29.4 1024
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:59
1 200.76.28.12 12288 100.0.0.2 512 200.76.29.4 512
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:51
C. Protocol GlobalAddr Port InsideAddr Port DestAddr Port
1 200.76.28.12 12289 100.0.0.1 1024 200.76.29.4 1024
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:59
1 200.76.28.11 12288 100.0.0.2 512 200.76.29.4 512
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:51
D. Protocol GlobalAddr Port InsideAddr Port DestAddr Port
1 200.76.28.11 12289 100.0.0.1 1024 200.76.29.4 1024
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:59
1 200.76.28.11 12288 100.0.0.2 512 200.76.29.4 512
VPN: 0, status: 11, TTL: 00:01:00, Left: 00:00:51
Answer: D
39. The two MSR routers are interconnected through their respective WAN interfaces S1/0. At the
same time, RIPv2 is run on the two routers to dynamically complete the remote routing of each other.
Now for security reasons, verification needs to be added to RIP, then which of the following are
correct RIP configurations?
A. [MSR-serial1/0] rip authentication-mode simple 123
B. [MSR]rip authentication-mode simple 123
 10 / 19
https://www.dumpsinfo.com/
C. [MSR-rip-1] rip authentication-mode simple 123
D. [MSR-rip-2] rip authentication-mode simple 123
Answer: A
40. Which of the following statement about the OSI reference model is correct?
A. The data at the transport layer is called a frame (Frame)
B. The data at the network layer is called a segment (Segment)
C. The data at the data link layer is called a packet (Packet)
D. The data in the physical layer is called bit (Bit)
Answer: D
41.IPv6 uses ______ notation to represent addresses.
A. Colon hexadecimal
B. Dotted decimal system
C. colon decimal
D. Dotted hexadecimal
Answer: A
42. Execute display ip routing-table on the router, then the next hop interface displayed in the routing
table may be ______. (Multiple choice)
A. InLoop0
B. Null0
C. Serial 6/0/1
D. Vlan500
Answer: ABC
43. During the establishment of a PPP session, when authentication is set but fails, the PPP link
enters the ______ stage.
A. Establish
B. Network
C. Authentication
D. Dead
E. Terminate
Answer: E
44. The customer's two MSR routers, MSR-1 and MSR-2, are interconnected back-to-back through
their respective S0/0 interfaces. The Frame Relay protocol is started and encapsulated between the
S0/0 interfaces of two MSR routers. MSR-1 is the DCE side of Frame Relay, and MSR-2 is the DTE
side of Frame Relay.
In order to save resources, frame relay sub-interfaces are configured on both routers. The
configurations are as follows:
MSR-1:
Interface Serial0/0.40 p2p
Fr dlci 222
IP address 30.2.2.2 255.255.255.252
MSR-2:
Interface Serial0/0.100 p2p
 11 / 19
https://www.dumpsinfo.com/
Fr dlci 222
IP address 30.2.2.1 255.255.255.252
Then based on this configuration it can be inferred that ______.
A. Unable to ping 30.2.2.1 on MSR-1
B. Can ping 30.2.2.1 on MSR-1
C. The frame relay sub-interfaces of the two routers cannot communicate with each other because
there is no fr map configured.
D. The frame relay sub-interfaces of the two routers cannot communicate with each other because
their sub-interface numbers are inconsistent.
Answer: B
45.Which of the following statements about optical fibers are correct? (Multiple choice)
A. Multimode optical fiber can transmit light of different wavelengths and different angles of incidence
B. The cost of multimode fiber is lower than that of single-mode fiber
C. When using multi-mode optical fiber, the maximum signal transmission distance is longer than that
of single-mode optical fiber.
D. The core of multimode fiber is thinner
Answer: AB
46. On the MSR router, you can use the ______ command to clear NAT session entries.
A. clear nat
B. clear nat session
C. reset nat session
D. reset nat table
Answer: C
47. Customer router MSR-1 configures MP to connect to MSR-2 through interfaces S0/0 and S0/1.
Currently, MP is running normally.
At the same time, the two routers run RIP to complete route learning on the LAN segments of the two
routers. Then the Metric value of the RIP route learned on MSR-1 may be ______. (Multiple choice)
A. 2M
B. 4M
C. 2
D. 1
Answer: CD
48. Which of the following configuration command to enable DHCP service on the router is correct?
A. [Router] dhcp
B. [Router-dhcp-pool-0] dhcp
C. [Router] dhcp enable
D. [Router-dhcp-pool-0] dhcp enable
Answer: C
49. The MSR router sent 5 packets by default during the last ping. If you want to specify the number
of packets to send, you can use the ______ parameter.
A. -n
B. -d
 12 / 19
https://www.dumpsinfo.com/
C. -s
D. -c
Answer: D
50. There is a route in the routing table of the router with the network segment 10.168.100.0/24, its
Cost is 15, and its Preference is 100. Which of the following statements about this route are correct?
(Multiple choice)
A. This route may be a manually configured static route.
B. This route may be a route dynamically discovered through RIP
C. If this is a RIP route, then the route is an invalid route
D. This route must be learned through dynamic routing
Answer: BD
51.NAPT mainly converts ______ information of data packets? (Multiple choice)
A. Data link layer
B. Network layer
C. Transport layer
D. Application layer
Answer: BC
52. On the MSR router, you see the following display in the routing table:
Destination/Mask Proto Pro Cost NextHop Interface
53. The public network address of the G0/0 interface of the customer router MSR-1 is 1.1.1.1/24, the
IP address of the G0/1 interface of MSR-1 is 192.168.0.254/24, and the G0/1 interface is connected
to a switch. The delivery machine is connected to four hosts in the network segment
192.168.0.1/24~192.168.0.4/24. Now the customer requires configuring NAT on MSR-1 so that all
four hosts can access the public network.
Make the following configuration on MSR:
Acl basic 2000
Rule 0 permit source 192.168.0.0 0.0.0.255
Nat address-group 1
Address 1.1.1.1 1.1.1.1
Interface GigabitEthernet0/0
Nat outbound 2000 address-group 1
So which of the following ACL configurations can meet customer needs? (Multiple choice)
A. rule 0 permit source 192.168.0.0 0.0.0.254
B. rule 0 permit source 192.168.0.0 0.0.0.6
C. rule 0 permit source 192.168.0.0 0.0.0.7
D. rule 0 permit source 192.168.0.0 0.0.0.255
Answer: CD
54. Regarding the understanding of methods, which of the following statements is correct? (Multiple
choice)
A. Packet switching is a switching method based on cut-through switching
B. The transmitted information is divided into packets of a certain length and forwarded in units of
packets.
C. Packet switching includes frame-based packet switching and cell-based packet switching
 13 / 19
https://www.dumpsinfo.com/
D. Each packet carries the address identification of the receiver and the sender. The packet can be
forwarded directly without any operation, thus improving efficiency.
Answer: BC
55. A default route A is configured on an MSR router running RIP, and its next hop address is
100.1.1.1; at the same time, the router learns a default route with a next hop address of 100.1.1.1
from a neighbor router through RIP. B.
The router uses default priority and cost values for routing protocols, then ______.
A. There is only route A in the routing table of this router because the Cost of route A is 0.
B. There will only be route B in the routing table of this router because dynamic routing takes
precedence
C. There is only route A in the routing table of this router because route A has a high priority.
D. Both route A and route B will be written into the routing table because they come from different
sources and do not conflict with each other.
Answer: B
56.The well-known port number of the transport layer protocol used by DNS is ______.
A. 50
B. 55
C. 53
D. 51
Answer: C
57. Two empty-configured MSR routers MSR-1 and MSR-2 are interconnected back-to-back through
their respective S1/0 interfaces, and their respective GigabitEthernet0/0 interfaces are connected to
the client hosts HostA and HostB respectively:
HostA----GE0/0--MSR-1--S1/0---------S1/0--MSR-2--GE0/0----HostB and then connect the two routers
The following configurations were made above:
Configuration on MSR-1:
[MSR-1] interface GigabitEthernet 0/0
[MSR-1-GigabitEthernet0/0] ip add 192.168.1.1 24
[MSR-1] interface Serial 1/0
[MSR-1-Serial1/0] ip address 30.3.3.1 30
[MSR-1] rip
[MSR-1-rip-1] network 0.0.0.0
Configuration on MSR-2:
[MSR-2] interface GigabitEthernet 0/0
[MSR-2-GigabitEthernet0/0] ip address 10.10.10.1 24
[MSR-2] interface Serial 1/0
[MSR-2-Serial1/0] ip address 30.3.3.2 30
[MSR-2] rip
[MSR-2-rip-1] network 10.10.10.0
[MSR-2-rip-1] network 30.3.3.1
After the above configuration, the WAN interfaces between the two routers can communicate with
each other, other physical links in the network are good, and both hosts HostA and HostB can ping
the addresses of their respective gateways GigabitEthernet0/0, then which of the following statements
is correct?
A. The command network 0.0.0.0 on MSR-1 is incorrectly configured. A specific network segment
should be configured.
 14 / 19
https://www.dumpsinfo.com/
B. There is no RIP route in the routing table of MSR-2
C. The command network 30.3.3.1 on MSR-2 is incorrectly configured and should be network
30.3.3.2
D. All three of the above are wrong. Both routers can learn RIP routes.
Answer: D
58. In the network environment as shown in the figure, two routers are connected back-to-back
through serial ports. The rate of the interconnection link must be set to 2Mbps. Which of the following
statement below is correct?
A. It is necessary to confirm that the interface type and cable meet the V.24 regulations
B. Use the baudrate 2048000 command to configure the synchronization port of RTA.
C. Use the baudrate 2048000 command to configure the RTB synchronization port.
D. Use the virtual-baudrate 2048000 command to configure the synchronization port of RTB.
E. Use the bandrate2048000 command to configure the synchronization port of RTA, and use the
virtual-baudrate2048000 command to configure the synchronization port of RTB.
Answer: B
59. Data segmentation is done in ______ in the OSI reference model.
A. Physical layer
B. Network layer
C. Transport layer
D. Access layer
Answer: C
60. On the MSR router, type the first few letters of a keyword in the command and press ______ to
complete the command.
A. <Esc> key
B. <Space> key
C. <Enter> key
D. <Tab> key
Answer: D
61. A certain network connection looks like:
HostA----GE0/0--MSR-1--S1/0---------S1/0--MSR-2--GE0/0----HostB
Two of the MSR routers, MSR-1 and MSR-2, are interconnected back-to-back through their
respective S1/0 interfaces, and their respective GE0/0 interfaces are connected to the client hosts
HostA and HostB respectively. By configuring IP addresses and routes, HostA can communicate with
 15 / 19
https://www.dumpsinfo.com/
HostB in the current network. HostA's IP address is 192.168.0.2/24, and the default gateway is
192.168.0.1. The GE0/0 interface address of MSR-1 is 192.168.0.1/24.
The following configuration has been added to MSR-1:
Firewall enable
Firewall default permit
Acl number 3003
Rule 0 deny icmp source 192.168.0.2 0 icmp-type echo-reply
Interface GigabitEthernet0/0
Firewall packet-filter 3003 inbound
So______. (Multiple choice)
A. The IP address of interface GE0/0 of MSR-1 cannot be pinged on HostA.
B. The IP address of interface GE0/0 of MSR-1 can be pinged on HostA.
C. Unable to ping HostA on MSR-1
D. HostA can be pinged on MSR-1
Answer: BC
62.Does the DHCP client send a message to the DHCP server to update the IP lease?
A. DHCP ACK
B. DHCP OFFER
C. DHCP Inform
D. DHCP Decline
E. DHCP Request
F. DHCP Release
Answer: E
63. The WAN main link of a company's MSR router is a synchronous and asynchronous serial port,
which is connected to the operator's network through a V.35 cable; the router also uses an ISDN BRI
interface as a backup link.
So regarding line bandwidth, which of the following statements are correct? (Multiple choice)
A. The bandwidth of the backup line may be 64Kbps
B. The bandwidth of the backup line may be 128Kbps
C. The bandwidth of the backup line may be 144Kbps
D. The bandwidth of the main link may be 1Mbps
Answer: ABD
64. The WAN links of the customer's two routers, MSR-1 and MSR-2, use the PPP protocol, and
MSR-1 is required to serve as the main verifier to verify MSR-2 through PAP. So what configurations
are required on MSR-2?
A. [MSR-2-Serial0/0] ppp pap user user
B. [MSR-2-Serial0/0] ppp pap password simple password
C. [MSR-2] ppp pap local-user user password simple password
D. [MSR-2-Serial0/0] ppp pap local-user user password simple password
Answer: D
65. Which of the following description of VTY features in H3C equipment is correct?
A. Only used for Telnet to the device
B. Each device can support simultaneous access by multiple VTY users
C. Each VTY user corresponds to a physical interface
 16 / 19
https://www.dumpsinfo.com/
D. Passwordless verification is not supported
Answer: B
66. The following prompt information is seen on router MSR-1:
[MSR-1] display firewall-statistics all
Firewall is enable, default filtering method is 'permit'.
Interface: GigabitEthernet0/0
In-bound Policy: acl 3000
Fragments matched normally
From 2008-11-08 2:25:13 to 2008-11-08 2:25:46
0 packets, 0 bytes, 0% permitted,
4 packets, 240 bytes, 37% denied,
7 packets, 847 bytes, 63% permitted default,
0 packets, 0 bytes, 0% denied default,
Totally 7 packets, 847 bytes, 63% permitted,
Totally 4 packets, 240 bytes, 37% denied.
From this it can be inferred that ______. (Multiple choice)
A. It can be seen from the 37% denied in the above information that there is already data matching
the rules in ACL3000.
B. Some data packets do not match the rules in ACL3000, but match the default permit rules.
C. ACL3000 is applied in the inbound direction of GigabitEthernet0/0
D. 0% denied default inthe above information means that the default matching rule of this ACL is
deny
Answer: ABC
67. The IP address of a certain host is 130.25.3.135 and the subnet mask is 255.255.255.192. Then
the network address of the subnet where the host is located is ______.
A. 130.25.0.0
B. 130.25.3.0
C. 130.25.3.128
D. 130.25.3.255
Answer: C
68. Which of the following description of circuit switching and packet switching is correct? (Multiple
choice)
A. The circuit switching delay is small and the transmission is real-time.
B. High utilization of circuit-switched network resources
C. Packet switching delay is large and transmission real-time performance is poor
D. Low utilization of packet switching network resources
Answer: AC
69. Router MSR-1 is interconnected with MSR-2 and MSR-3 respectively. In the routing table of
MSR-1, there is a RIP route learned from MSR-2 to the destination network segment 120.10.12.0/24.
Its Cost is 3; at this time, MSR-1 also receives a RIP route from MSR-3 that is still destined for the
destination network segment 120.10.12.0/24, and its Cost is 15, then ______.
A. The routing table of MSR-1 will not be updated, and the routes for this network segment learned
from MSR-2 will still be retained.
B. The routing table of MSR-1 will be updated to the route with a cost of 15 learned from MSR-3.
 17 / 19
https://www.dumpsinfo.com/
C. The routing table of MSR-1 will be updated because the RIP route with Cost 15 means that there
may be a loop in the network.
D. The routing table of MSR-1 will not be updated because a RIP route with a Cost of 15 means an
unreliable route and RIP will not write it into its own routing table.
Answer: A
70. Two MSR routers are connected as shown in the figure. Currently there is OSPF running between
the two routers.
Now it is necessary to configure an ACL on RTA to prevent the establishment of OSPF neighbor
relationship between RTA and RTB. Which of the following ACLs is feasible to apply in the outbound
direction of RTA's GE0/0 interface? (Multiple choice)
A.Acl number 3000
Rule 0 deny ip destination 224.0.0.5 0
Rule 5 permit ip
B.Acl number 3000
Rule 0 deny ip destination 224.0.0.5 0 eq 89
Rule 5 permit ip
C.Acl number 3000
Rule 0 deny udp destination-port eq 89
Rule 5 permit ip
D.Acl number 3000
Rule 0 deny ospf
Rule 5 permit ip
Answer: AD
71. Which of the following statement about HDLC is correct? (Multiple choice)
A. The HDLC protocol is a bit-oriented transport layer protocol.
B. Any bit stream can be transmitted transparently on the HDLC link.
C. The HDLC protocol adopts a unified frame format, so both data packets and protocol packets are
transmitted in standard format frames on the HDLC link.
D. HDLC can run on synchronous/asynchronous links, so it has a wide range of applications.
Answer: BC
72.A network administrator configured RIP on a router:
Rip 1
Version 2
Network 100.0.0.0
Network 8.0.0.0
However, it is found that the peer's RIP route cannot be learned. The administrator needs to turn on
RIP debugging information on the router. Which of the following configurations can be used to view
 18 / 19
https://www.dumpsinfo.com/
RIP debugging information on the router?
A. <MSR>debugging rip packet
B. [MSR] debugging rip packet
C. <MSR>debugging rip 1 packet
D. <MSR>debugging rip 2
Answer: C
73. After executing the display command on the switch SWA, the switch output is as follows:
<Switch> display arp all
Type: S-Static D-Dynamic A-Authorized
IP Address MAC Address VLAN ID Interface Aging Type
74.The characteristics of MSTP are? (Multiple choice)
A. MSTP is compatible with STP and RSTP.
B. MSTP divides a switching network into multiple domains, forming multiple spanning trees in each
domain, and the spanning trees are independent of each other.
C. MSTP prunes the loop network into a loop-free tree network to avoid the proliferation and infinite
loop of packets in the loop network. It can also provide redundant paths for data forwarding and
implement VLAN data during the data forwarding process. load balancing.
D. None of the above statements are correct.
Answer: ABC
75. Which of the following statement about the STP protocol is correct? (Multiple choice)
A. The BridgeID value is a combination of the bridge's priority and the bridge's MAC address. The
front is the priority, and the back is the MAC address.
B. The default priority value of H3C Ethernet switch is 32768
C. The smaller the priority value, the lower the priority.
D. When the priorities are the same, the smaller the MAC address, the higher the priority.
E. The one with a larger BridgeID value will be selected as the root bridge.
Answer: ABD
76. Which of the following description of PPP PAP verification is correct? (Multiple choice)
A. PAP authentication is a two-way handshake protocol
B. The PAP username is in clear text, but the password is confidential
C. The PAP username is in cipher text and the password is in clear text.
D. The PAP username and password are both in clear text.
Answer: AD
77.When configuring OSPF on a router, what configurations must be performed manually?
A. Configure Router ID
B. Specify the network type of each ospf-enabled interface
C. Create OSPF area
D. Create OSPE process
Answer: C
Powered by TCPDF (www.tcpdf.org)
 19 / 19
https://www.dumpsinfo.com/
http://www.tcpdf.org
