ETP48400-C9A4 24kW Embedded Power (Claro, Peru) User Manual Issue 01 Date 2018-02-01 HUAWEI TECHNOLOGIES CO., LTD. Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. i Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied. The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: support@huawei.com http://www.huawei.com/ mailto:support@huawei.com ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual About This Document Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. ii About This Document Purpose This document describes the DC power system in terms of product overview, components, installation, commissioning, and maintenance. This document also describes operations for the site monitoring unit (SMU) and rectifiers. The figures provided in this document are for reference only. Intended Audience This document is intended for: Sales engineers Technical support engineers Maintenance engineers Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. Indicates a potentially hazardous situation which, if not avoided, could result in equipment damage, data loss, performance deterioration, or unanticipated results. NOTICE is used to address practices not related to personal injury. Calls attention to important information, best practices and tips. NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual About This Document Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. iii Change History Changes between document issues are cumulative. The latest document issue contains all the changes made in earlier issues. Issue 01 (2018-02-01) This issue is the first official release. The SMU software version is V500R002C00. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual Contents Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. iv Contents About This Document .................................................................................................................... ii 1 Safety Precautions ......................................................................................................................... 1 1.1 General Safety .............................................................................................................................................................. 1 1.2 Electrical Safety ............................................................................................................................................................ 2 1.3 Battery Safety ............................................................................................................................................................... 3 1.4 Cable Layout ................................................................................................................................................................. 4 1.5 Mechanical Safety ........................................................................................................................................................ 5 2 Overview ......................................................................................................................................... 7 2.1 Introduction .................................................................................................................................................................. 7 2.2 System Features ............................................................................................................................................................ 7 3 Components ................................................................................................................................... 8 3.1 Exterior ......................................................................................................................................................................... 8 3.2 Rectifier ........................................................................................................................................................................ 9 3.3 SMU02C ..................................................................................................................................................................... 11 3.4 User Interface Module UIM02C ................................................................................................................................. 14 4 Installation.................................................................................................................................... 18 4.1 Installation Preparations ............................................................................................................................................. 18 4.1.1 Preparing Cables ...................................................................................................................................................... 18 4.1.2 Tools ........................................................................................................................................................................ 19 4.1.3 Installation Dimensions ........................................................................................................................................... 20 4.1.4 Requirements for Cable Routing ............................................................................................................................. 20 4.2 Installing a Subrack .................................................................................................................................................... 21 4.3 Installing a Ground Cable ........................................................................................................................................... 21 4.4 Installing a Rectifier ...................................................................................................................................................only. ----End Follow-up Procedure You can query the power system operating status, active alarms, and the names of user-defined dry contact inputs, and configure dry contact outputs on the NMS that is connected over SNMP. 7.7 Connecting the Battery Supply Prerequisites To avoid damage to batteries, switch on the battery circuit breakers only after correctly setting the battery parameters. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 52 Procedure Step 1 Switch on the battery circuit breakers. Step 2 Set all the circuit breakers based on site requirements. Step 3 Observe the power system for 15 minutes. During this period of time, if no alarm (except for the door status alarm) is generated on the LCD of the SMU, the voltages and currents for batteries and loads are normal. By default, the battery switch is in the AUTO position when the power system is delivered. When power-on commissioning is required but AC input is unavailable, open the panel and flip the battery switch to MANUAL. After the SMU is started, flip the battery switch back to AUTO. Figure 7-10 Battery switch ----End 7.8 Subsequent Operations Procedure Step 1 Reinstall the removed cover or panel if any. Step 2 Check whether the paint on the subrack exterior is intact. If any paint has flaked, repaint the area to avoid corrosion. Step 3 Ensure that the site is clean before you leave the site. ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 53 8 Maintenance 8.1 Routine Maintenance Perform routine maintenance periodically based on site requirements. The recommended interval is six months. If any faults are detected, rectify them promptly. 8.1.1 Cabinet Table 8-1 Cabinet maintenance checklist No. Check Item If... Then... 1 Check whether the cabinet paint is flaking or there are scratches on the cabinet surface. The cabinet is scratched. Repaint the cabinet. 2 Check whether the cabinet is rusted or corroded. The environment quality of the equipment room is poor. Evaluate the risk and improve the environment of the equipment room. 3 Check whether the cabinet door lock is damaged. The door lock is rusty or has been tampered with. Replace the door lock. 4 Check whether the front and rear of rectifiers are blocked or dusty. The front or rear of rectifiers is blocked or dusty. Remove the blockage or clean up the dust. 5 Whether there are traces of animals such as insects, mice, and snakes inside the cabinet Animals entered the cabinet. 1. Clear the traces and take precautions during clearance to prevent secretions of animals from entering monitoring boards or energized components. 2. Seal the cable holes to prevent animals from entering the cabinet again. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 54 8.1.2 AC and DC Power Distribution Table 8-2 AC and DC power distribution maintenance No. Maintenance Item If... Then... 1 Check for AC input undervoltage. AC input power cables have a large voltage drop. AC input power cables are in poor contact. The mains voltage is too low. 1. Replace AC input power cables with shorter or thicker cables. 2. Connect AC input power cables securely. 3. Provide the voltage data to the power supplier. 2 Check for AC input overvoltage. The mains voltage is too high. Provide the voltage data to the power supplier. 3 Check whether the AC input voltage is open-phase. AC input power cables are in poor contact, short-circuited, or damaged. The mains supply has failed. 1. Check and rectify the cables. 2. Provide the open-phase data to the power supplier. 4 Check whether a DC output circuit breaker is OFF and a fuse is blown. Load overcurrent occurs. Load short-circuit occurs. Rectify any overcurrent or short circuit. Turn on the circuit breaker or replace the fuse. 5 Check for DC busbar overvoltage. A rectifier is abnormal. Replace the abnormal rectifier. 6 Check for DC busbar undervoltage. The AC power supply has failed. The system is overloaded. A rectifier is abnormal. 1. Resume the AC power supply. 2. Check the load status and rectify faults if any. 3. Replace the abnormal rectifier. 7 Check whether the temperature of a DC busbar working at room temperature exceeds 95°C. The DC busbar is loose or in poor contact. The system is overloaded. 1. Check and secure cabinet busbar connections. 2. Check the load status and rectify faults if any. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 55 8.1.3 Rectifier Table 8-3 Rectifier maintenance checklist No. Check Item If... Then... 1 Check the green indicator status (normal: steady on). Off: There is no AC input. The rectifier is faulty. 1. Check the rectifier AC input. 2. Replace the rectifier. 2 Check the yellow indicator status (normal: off). Steady on: The rectifier has generated an alarm due to ambient overtemperature. The rectifier has shut down as a protective measure because the ambient temperature exceeds the upper or lower threshold. AC input over/undervoltage protection has been triggered. The rectifier is in hibernation. 1. Check the ambient temperature status, and clean the cabinet air channel. 2. Rectify faults in the indoor temperature control system. 3. Check the AC input voltage. 4. If the rectifier is in hibernation, no action is required. Blinking: The rectifier communication has failed. The rectifier is faulty. 1. Check that the rectifier communications cable is securely connected. 2. Replace the rectifier. 3 Check the red indicator status (normal: off). Steady on: The rectifier is latched off due to output overvoltage. The rectifier is faulty. 1. Check that the cabinet is not connected to an external DC power source that has a higher voltage. 2. Check that the rectifier output voltage is normal. 3. Replace the rectifier. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 56 8.1.4 SMU Table 8-4 SMU maintenance checklist No. Check Item If... Then... 1 Check the green indicator status. Off: There is no DC input. The SMU is faulty. 1. Check that the DC input power cable is securely connected. 2. Check that the communications cable is securely connected. 3. Replace the SMU. 2 Check the red indicator status. Steady on: A critical or major alarm has been generated. The SMU is faulty. 1. Check components related to the alarm. 2. Replace the SMU. 3 Check the LCD screen status. The LCD flat cable is loose. The SMU is faulty. 1. Check that the LCD flat cable is securely connected. 2. Replace the SMU. 4 Check whether the SMU can communicate with the NMS. The communications cable is loose. Networking parameters are not correctly set. 1. Check that the communications cable is securely connected. 2. Check that networking parameter settingsare correct. 8.1.5 Parameters on the SMU Table 8-5 SMU parameter maintenance No. Check Item If... Then... 1 Check whether the displayed battery capacity and number of battery strings are the same as the actual data. Parameters are set incorrectly. The number of batteries is changed, or batteries are replaced. Set battery parameters again. 2 Check Charge Current Limit Coefficient. The value is typically 0.15C10 and adjustable. N/A Change the value as required. Otherwise, retain 0.15C10. 3 Check whether the displayed battery temperature is the same The battery temperature sensor is faulty. 1. Replace the battery temperature sensor. 2. Replace the SMU. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 57 No. Check Item If... Then... as the actual temperature. The SMU is faulty. 4 Check whether the displayed total load current is the same as the actual current measured by a clamp meter. The current monitoring cable is loose. The SMU is faulty. 1. Check that the current monitoring cable is securely connected. 2. Replace the SMU. 5 Check whether the displayed battery charge current is the same as the actual current measured by a clamp meter. The current monitoring cable is loose. The SMU is faulty. 1. Check that the current monitoring cable is securely connected. 2. Replace the SMU. 6 Check whether the difference between the displayed DC output voltage and the measured DC busbar voltage is less than 0.5 V DC. The cabinet busbar and cables are loose or in poor contact. The SMU is faulty. 1. Check and secure the cabinet busbar and cable connections. 2. Replace the SMU. 8.1.6 Cables Table 8-6 Cable maintenance checklist No. Check Item If... Then... 1 Check whether signal cables and power cables are separately bound. Signal cables and power cables are bound together. Bind signal cables and power cables separately. 2 Check whether cables are at least 20 mm away from DC negative busbars, fuses, and shunts. Cables are installed close to DC negative busbars, fuses, and shunts. Install cables at least 20 mm away from DC negative busbars, fuses, and shunts. 3 Check whether all cables are bound neatly. Cables are not properly bound. Bind cables neatly. 4 Check whether the cabinet ground bar is securely connected to the site or equipment room ground point. The cabinet ground bar is not securely connected to the site or equipment room ground point. Connect the cabinet ground bar to the site or equipment room ground point. 5 Check whether ground cables are rusty. Cables have corroded after being used for a long time. Replace rusty cables. 6 Check whether the DC RTN+ busbar is grounded. The DC RTN+ busbar is not properly grounded. Connect the ground cable to the DC RTN+ busbar properly. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 58 No. Check Item If... Then... 7 Check whether cables are at danger of overheating or deteriorating. Cables are too thin. Cables are not properly routed. Replace the cables with cables of the required thickness. Route the cables properly. 8 Check whether cables are misshapen by metal parts. Cables are not properly installed. Replace the cables and route them properly. 9 Check whether cables pass behind the air exhaust vents of rectifiers. Cables pass behind the air exhaust vents of rectifiers. Reroute the cables to prevent cable overheating. 10 Check whether power cables use standard terminals. Cables do not use standard terminals. Replace with standard terminals. 11 Check whether cable insulation is damaged. Cable insulation is damaged. Reinsulate the cables with insulation tape. 8.2 Identifying Component Faults 8.2.1 Identifying Circuit Breaker Faults The following indicate that the circuit breaker is faulty: The circuit breaker cannot be switched to ON/OFF after the short circuit fault for its end circuit is rectified. When the circuit breaker is switched to ON and its input voltage is normal, the voltage between the two ends of the circuit breaker exceeds 1 V. The input voltage is normal, but the resistance between both ends of the circuit breaker is less than 1 kΩ when the circuit breaker is OFF. 8.2.2 Identifying Rectifier Faults A rectifier is damaged if any of the following conditions is not met: When the rectifier does not communicate with the SMU and the AC input voltage is around 220 V, the green indicator on the rectifier is steady on, the yellow indicator is blinking, the red indicator is off, and the rectifier output is normal. The SMU can perform equalized charging, float charging, and current limiting control for the rectifier when the communication cable to the rectifier is correctly connected and communication is established between the rectifier and the SMU. 8.2.3 Identifying SMU Faults The following indicate that the SMU is faulty: ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 59 The DC output is normal but the green indicator on the SMU is off. The SMU breaks down or cannot be started. Its LCD has abnormal display or buttons cannot be operated. With alarm reporting enabled, the SMU does not report alarms when the power system is faulty. The SMU reports an alarm when the power system is not faulty. The SMU fails to communicate with the connected lower-level devices even though the communications cables are correctly connected. Communication between the SMU and all rectifiers fails even though the rectifiers and the communications cables are normal. The SMU cannot monitor AC or DC power distribution when communications cables are intact and AC and DC power distribution is normal. Parameters cannot be set or running information cannot be viewed on the SMU. 8.2.4 Identifying AC SPD Faults Check the color of the AC SPD indication window. Green indicates that the AC SPD is normal. Red indicates the AC SPD is faulty. 8.3 Replacing Components Performing maintenance or replacing components may interrupt power to the loads if battery reserve is insufficient. Ensure that the switches for primary loads are in the ON position and do not turn off the battery switch and the AC input switch at the same time. Obtain prior written consent from the customer if load disconnection is required. Do not perform maintenance on rainy days. Otherwise, rain water can enter the system and damage devices and components. 8.3.1 Replacing a Circuit Breaker Prerequisites Before replacing an AC circuit breaker, switch off the upstream input circuit breaker. The cabinet door key, insulation tape, and required tools are available. The new circuit breaker is intact and has the same specifications as the circuit breaker to be replaced. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 60 Procedure Step 1 Switch off the circuit breaker that is to be replaced. Step 2 Record the positions where the output cable and signal cable terminals connect to the circuit breaker. Step 3 Loosen the screw that secures the upper port of the circuit breaker using a Phillips screwdriver,and remove the output power cable and signal cable terminals. Wrap the cable and terminals using insulation tape. Step 4 Loosen the screw that secures the lower port of the circuit breaker using a Phillips screwdriver, and open the buckle at the base of the circuit breaker using an insulated flat-head screwdriver. Step 5 Remove the circuit breaker from the guide rail. Figure 8-1 shows how to remove the circuit breaker. Figure 8-1 Removing the circuit breaker Step 6 Switch off the new circuit breaker. Press the buckle at the circuit breaker base using an insulated flat-head screwdriver and install the new circuit breaker. Then remove the screwdriver so that the buckle secures the circuit breaker to the guide rail. Step 7 Tighten the screw that secures the lower port of the circuit breaker. Step 8 Remove the insulation tape from the output power cable and signal cable terminals. Then connect the output power cable and signal cable terminals to the upper port of the circuit breaker and tighten the screw. Step 9 Switch on the circuit breaker. Figure 8-2 shows how to install the new circuit breaker. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 61 Figure 8-2 Installing the new circuit breaker ----End Follow-up Procedure Check that the load fuse blown alarm has disappeared. 8.3.2 Replacing a Rectifier Prerequisites Protective gloves and the cabinet door key are available. The new rectifier is intact. To prevent burns, exercise caution when removing a rectifier because the rectifier may be hot as a result of continuous operation. Procedure Step 1 Wear protective gloves. Step 2 Push the locking latch on the right side of the panel towards the left. Step 3 Gently draw the handle outwards, and then remove the rectifier from the subrack, as shown in Figure 8-3. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 62 Figure 8-3 Removing a rectifier Step 4 Push the locking latch on the new rectifier towards the left, and pull out the handle. Step 5 Place the new rectifier at the entry of the correct slot. Step 6 Gently slide the rectifier into the slot along the guide rails until it is engaged. Close the handle, and push the locking latch towards the right to lock the handle, as shown in Figure 8-4. Figure 8-4 Installing a rectifier Step 7 Remove the protective gloves. ----End Follow-up Procedure Pack the removed component and send it to the local Huawei warehouse. 8.3.3 Replacing an SMU02C Prerequisites You have obtained the cabinet door key. The new SMU02C is intact. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 63 Procedure Step 1 Connect the ground cable for the ESD wrist strap, and put on the ESD wrist strap and ESD gloves. Step 2 Disconnect the communications cable from the SMU02C panel. Step 3 Push the locking latch leftwards. Step 4 Pull the handle outwards and remove the SMU02C, as shown in Figure 8-5. Figure 8-5 Removing the SMU02C Step 5 Take off the SD card from the side of the SMU02C. If no SD is installed, go to Step 7. Step 6 Insert the SD card into the new SMU02C. Step 7 Place the new SMU02C in the slot, push the locking latch leftwards, and pull out the handle. Step 8 Gently push the SMU02C along guide rails until it is engaged. Close the handle, and push the locking latch rightwards. Figure 8-6 Installing the SMU02C Step 9 Reset SMU02C parameters. Step 10 Reconnect the communications cable to the SMU02C panel. ----End Follow-up Procedure Pack the removed component and have it sent to the local Huawei warehouse. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 64 8.3.4 Replacing a UIM02C Board Prerequisites An ESD wrist strap, ESD gloves, ESD box or bag, cabinet door key, and required tools are available. The new UIM02C board is intact. Procedure Step 1 Connect the ground cable to the ESD wrist strap, and put on the ESD wrist strap and ESD gloves. Step 2 Record the position of signal cables connected to the UIM02C panel, and then disconnect the signal cables. Step 3 Unscrew and take out the UIM02C. Figure 8-7 Taking out the UIM02C Step 4 Record the positions where the UIM02C board connects to all the cables, and then disconnect the cables. Step 5 Remove the UIM02C board. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 65 Figure 8-8 Removing the UIM02C board Step 6 Take out and install the new UIM02C board. Step 7 Connect all the cables on the UIM02C board to the new UIM02C based on the recorded information. Step 8 Push the UIM02C in place and tighten the screws. Step 9 Reconnect signal cables to the new UIM02C panel based on the recorded information. Step 10 Disconnect the ground cable from the ESD wrist strap, and remove the ESD wrist strap and ESD gloves. ----End Follow-up Procedure Pack the removed component and have it sent to the local Huawei warehouse. 8.3.5 Replacing an AC SPD Module Prerequisites An ESD wrist strap, ESD gloves, ESD box or bag, and cabinet door key are available. The new AC SPD module is intact and has the same specifications as the AC SPD module to be replaced. Do not replace an AC SPD module during a thunderstorm. Procedure Step 1 Connect the ground cable of the ESD wrist strap, and wear the ESD wrist strap and ESD gloves. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 8 Maintenance Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 66 Step 2 Press the top and bottom of the faulty AC SPD module and pull it out, as shown in Figure 8-9. Step 3 Install the new AC SPD module, as shown in Figure 8-9. Figure 8-9 Replacing an AC SPD module Step 4 Disconnect the ground cable of the ESD wrist strap, and remove the ESD wrist strap and ESD gloves. ----End Follow-up Procedure Check that the alarm for the AC SPD is cleared. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual A Preparing Terminals Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 67 A Preparing Terminals This section describes how to prepare cord end terminals and OT terminals. Cut a cable of a proper length and install an OT terminal or a cord end terminal. Figure A-1 and Figure A-2 show the procedures for preparing a cord end terminal and an OT terminal respectively. Figure A-1 Preparing a cord end terminal (1) Cable (2) Cord end terminal (3) Crimping tool Figure A-2 Preparing an OT terminal (1) Cable (2) OT terminal (3) Heat shrink tubing (4) Hydraulic pliers (5) Heat gun ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual B Technical Specifications Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 68 B Technical Specifications Table B-1 Environment conditions Item Specifications Operating temperature –40°C to +65°C Transport temperature –40°C to +70°C Storage temperature –40°C to +70°C Operating humidity 5%–95% RH (non-condensing) Storagehumidity 5%–95% RH (non-condensing) Altitude 0 m to 4000 m (When the altitude ranges from 2000 m to 4000 m, the operating temperature decreases by 1°C for each additional 200 m.) Other requirements There should be no conductive dust, corrosive gas, or explosion hazard. Dust, corrosive substances, pests, molds, and other indicators should be controlled in accordance with Class 4.1 requirements in ETSI EN 300 019-1-4 (V2.2.1). Table B-2 Electrical specifications Item Specifications AC input Input system 220/380 V AC three-phase four-wire (default), compatible with 127/220 V AC three-live wire Input frequency 45–66 Hz (rated frequency: 50 Hz or 60 Hz) Power factor (PF) ≥ 0.99 (rated input, with 100% loads) DC output Output voltage range –42 V DC to –58 V DC ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual B Technical Specifications Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 69 Item Specifications Default output voltage –53.5 V DC Maximum output power 24000 W (supports N+1 backup; maximum total output current does not exceed 400 A; and long-term operating current output does not exceed 350 A). Regulated voltage precision ≤ ±1% (The output voltage is within 53.5 V DC ±0.1 under 50% loads.) Peak-to-peak noise voltage ≤ 200 mV (rated input voltage and 0%–100% load) Psophometrically weighted noise ≤ 2 mV (300–3400 Hz; input power ≤ 264 V AC) Current sharing imbalance ≤ ±5% (50%–100% load) AC input protection AC input overvoltage protection threshold ≥ 300 V AC AC input overvoltage recovery threshold 290 V AC–300 V AC AC input undervoltage protection threshold ≤ 80 V AC AC input undervoltage recovery threshold 80 V AC–90 V AC DC output protection DC output overvoltage protection threshold –58.5 V DC to –60.5 V DC If overvoltage occurs inside a rectifier, the rectifier locks out. If the external voltage is greater than -63 V DC for more than 500 ms, the rectifier locks out. AC surge protection Nominal lightning strike discharge current: 30 kA (8/20 µs); maximum lightning strike discharge current: 60 kA (8/20 µs) DC surge protection Differential mode: 10 kA (8/20 µs); common mode: 20 kA (8/20 µs) Safety IEC/EN60950-1 and GB4943, TLC and CE certifications MTBF 200,000 hours (at 25°C) ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual B Technical Specifications Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 70 Table B-3 EMC specifications Item Specifications Electromagnetic interference (EMI) Conducted emission (CE) AC port: EN 55022 class B DC port: EN 55022 class A 1 Radiated emission (RE) EN 55022 class B Harmonic current IEC 61000-3-12 Voltage fluctuation and flick IEC 61000-3-3 EMS Electrostatic discharge (ESD) IEC 61000-4-2 Shell port: contact discharge of 6 kV and air discharge of 8 kV; signal port: contact discharge of 2 kV Electrical fast transient (EFT) IEC 61000-4-4 AC and DC power ports: 2 kV Radiated susceptibility (RS) IEC 61000-4-3 10 V/m field strength Conducted susceptibility (CS) IEC 61000-4-6 Power port: 10 V; signal port: 3 V Surge immunity IEC 61000-4-5 AC and DC power ports: 2 kV (8/20 µs) in differential mode, 4 kV (8/20 µs) in common mode Voltage dips immunity (DIP) IEC 61000-4-11 Note 1: This is a class A product. In a living environment, this product may cause radio interference; therefore, the user may be required to take appropriate measures. Table B-4 Subrack specifications Item Specifications Cabinet dimensions (H x W x D) 397 mm x 482 mm x 330 mm Weight ≤ 30 kg (excluding rectifiers) Protection level IP20 Installation mode Installed in a 19-inch rack ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual B Technical Specifications Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 71 Item Specifications Cabling AC cables go in from the bottom, and DC cables go out from the top. Maintenance mode Maintained from the front Heat dissipation mode Natural heat dissipation ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual C Associations Between Alarms and Dry Contacts on the UIM Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 72 C Associations Between Alarms and Dry Contacts on the UIM Table C-1 Associations between alarms and dry contacts Port Type Silk Screen Associated Alarm Dry contact input (closed: alarm; open: normal) DIN1 Dry contact input 1 DIN2 Dry contact input 2 DIN3 Dry contact input 3 DIN4 Dry contact input 4 DIN5 Dry contact input 5 DIN6 Dry contact input 6 Dry contact output The default setting (closed: alarm; open: normal) can be modified. ALM1 AC Failure/Long AC failure (disabled by default) ALM2 Bus Bar Overvoltage/Bus Bar Undervoltage/Bus Bar Ultra Overvoltage (disabled by default)/Bus Bar Ultra Undervoltage (disabled by default) ALM3 Rectifier Fault Redundant (disabled by default)/Rectifier Fault Non-redundant (disabled by default)/Multi-Rectifier Fault/All Rectifiers Fail to Communicate/Rectifier Fault/Rectifier Protection/Communication Failure ALM4 AC Surge Protector Fault/DC Surge Protector Fault ALM5 Load Fuse Break/Battery Fuse Break ALM6 Battery High Temperature/Battery Very High Temperature (disabled by default)/Battery Low Temperature/Battery Very Low Temperature (disabled by default)/Ambient High Temperature/Ambient Very High Temperature (disabled by default)/Ambient Low Temperature ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual C Associations Between Alarms and Dry Contacts on the UIM Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 73 Port Type Silk Screen Associated Alarm ALM7 Reserved ALM8 Reserved ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual D Acronyms and Abbreviations Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 74 D Acronyms and Abbreviations A ACDB alternating current distribution box B BBU baseband unit BLVD battery low voltage disconnection E EFT electrical fast transient EMC electromagnetic compatibility ESD electrostatic discharge H HTTPS Hypertext Transfer Protocol Secure I IP Internet Protocol L LCD liquid crystal display LLVD load low voltage disconnection M MTBF mean time between failures ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual D Acronyms and Abbreviations Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 75 P PDU power distribution unit R RS radiated susceptibility S SMU site monitoring unit SNMP Simple Network Management Protocol SPD surge protection device T THD total harmonic distortion U UIM user interface module About This Document Contents 1 Safety Precautions 1.1 General Safety 1.2 Electrical Safety 1.3 Battery Safety 1.4 Cable Layout 1.5 Mechanical Safety 2 Overview 2.1 Introduction 2.2 System Features 3 Components 3.1 Exterior 3.2 Rectifier 3.3 SMU02C 3.4 User Interface Module UIM02C 4 Installation 4.1 Installation Preparations 4.1.1 Preparing Cables 4.1.2 Tools 4.1.3 Installation Dimensions 4.1.4 Requirements for Cable Routing 4.2 Installing a Subrack 4.3 Installing a Ground Cable 4.4 Installing a Rectifier 5 Installing Cables 5.1 (Optional) Installing DryContact Signal Cables 5.2 (Optional) Installing a Communications Cable Between the SMU and Huawei BBU 5.3 Installing Communications Cables 5.3.1 WebUI Management 5.3.2 Using the U2000-SPM for Management 5.3.3 NetEco Management 5.3.4 Third-Party NMS Management (over SNMP) 5.3.5 Using Dry Contacts for Management 5.4 Installing DC Output Power Cables 5.5 Installing AC Output Power Cables 5.5.1 Installing 220 V AC Single-Phase Output Power Cables 5.5.2 Installing 110 V AC Dual-Live Wire Output Power Cables 5.6 Installing AC Input Power Cables 5.6.1 Installing 220/380 V AC Three-Phase Four-Wire Input Power Cables 5.6.2 Installing 127/220 V AC Three-Live Wire Input Power Cables 5.7 Installing Battery Cables 6 Verifying the Installation 6.1 Checking Hardware Installation 6.2 Checking Electrical Connections 6.3 Checking Cable Installation 7 Commissioning 7.1 Connecting the AC Power Supply 7.2 Setting the Display Language 7.3 Setting the Date and Time 7.4 Setup Wizard Init 7.5 Setting Battery Parameters 7.6 Setting Communications Parameters 7.6.1 (Optional) Setting Parameters Before Using WebUI 7.6.2 Setting Parameters Before Using U2000-SPM 7.6.3 (Optional) Setting Parameters Before Using NetEco 7.6.4 (Optional) Setting Parameters Before Using SNMP 7.7 Connecting the Battery Supply 7.8 Subsequent Operations 8 Maintenance 8.1 Routine Maintenance 8.1.1 Cabinet 8.1.2 AC and DC Power Distribution 8.1.3 Rectifier 8.1.4 SMU 8.1.5 Parameters on the SMU 8.1.6 Cables 8.2 Identifying Component Faults 8.2.1 Identifying Circuit Breaker Faults 8.2.2 Identifying Rectifier Faults 8.2.3 Identifying SMU Faults 8.2.4 Identifying AC SPD Faults 8.3 Replacing Components 8.3.1 Replacing a Circuit Breaker 8.3.2 Replacing a Rectifier 8.3.3 Replacing an SMU02C 8.3.4 Replacing a UIM02C Board 8.3.5 Replacing an AC SPD Module A Preparing Terminals B Technical Specifications C Associations Between Alarms and Dry Contacts on the UIM D Acronyms and Abbreviations22 5 Installing Cables ......................................................................................................................... 24 5.1 (Optional) Installing Dry Contact Signal Cables ........................................................................................................ 24 5.2 (Optional) Installing a Communications Cable Between the SMU and Huawei BBU ............................................... 25 5.3 Installing Communications Cables ............................................................................................................................. 26 5.3.1 WebUI Management ................................................................................................................................................ 26 5.3.2 Using the U2000-SPM for Management ................................................................................................................. 26 5.3.3 NetEco Management................................................................................................................................................ 26 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual Contents Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. v 5.3.4 Third-Party NMS Management (over SNMP) ......................................................................................................... 27 5.3.5 Using Dry Contacts for Management ...................................................................................................................... 28 5.4 Installing DC Output Power Cables ............................................................................................................................ 30 5.5 Installing AC Output Power Cables ............................................................................................................................ 31 5.5.1 Installing 220 V AC Single-Phase Output Power Cables ......................................................................................... 31 5.5.2 Installing 110 V AC Dual-Live Wire Output Power Cables .................................................................................... 31 5.6 Installing AC Input Power Cables............................................................................................................................... 32 5.6.1 Installing 220/380 V AC Three-Phase Four-Wire Input Power Cables .................................................................... 32 5.6.2 Installing 127/220 V AC Three-Live Wire Input Power Cables .............................................................................. 33 5.7 Installing Battery Cables ............................................................................................................................................. 35 6 Verifying the Installation .......................................................................................................... 37 6.1 Checking Hardware Installation ................................................................................................................................. 37 6.2 Checking Electrical Connections ................................................................................................................................ 37 6.3 Checking Cable Installation ........................................................................................................................................ 37 7 Commissioning............................................................................................................................ 38 7.1 Connecting the AC Power Supply .............................................................................................................................. 38 7.2 Setting the Display Language ..................................................................................................................................... 39 7.3 Setting the Date and Time ........................................................................................................................................... 39 7.4 Setup Wizard Init ........................................................................................................................................................ 39 7.5 Setting Battery Parameters .......................................................................................................................................... 40 7.6 Setting Communications Parameters .......................................................................................................................... 41 7.6.1 (Optional) Setting Parameters Before Using WebUI ............................................................................................... 41 7.6.2 Setting Parameters Before Using U2000-SPM ........................................................................................................ 48 7.6.3 (Optional) Setting Parameters Before Using NetEco ............................................................................................... 48 7.6.4 (Optional) Setting Parameters Before Using SNMP ................................................................................................ 50 7.7 Connecting the Battery Supply ................................................................................................................................... 51 7.8 Subsequent Operations ............................................................................................................................................... 52 8 Maintenance ................................................................................................................................. 53 8.1 Routine Maintenance .................................................................................................................................................. 53 8.1.1 Cabinet ..................................................................................................................................................................... 53 8.1.2 AC and DC Power Distribution ............................................................................................................................... 54 8.1.3 Rectifier ................................................................................................................................................................... 55 8.1.4 SMU......................................................................................................................................................................... 56 8.1.5 Parameters on the SMU ........................................................................................................................................... 56 8.1.6 Cables ...................................................................................................................................................................... 57 8.2 Identifying Component Faults .................................................................................................................................... 58 8.2.1 Identifying Circuit Breaker Faults ........................................................................................................................... 58 8.2.2 Identifying Rectifier Faults ...................................................................................................................................... 58 8.2.3 Identifying SMU Faults ........................................................................................................................................... 58 8.2.4 Identifying AC SPD Faults ...................................................................................................................................... 59 8.3 Replacing Components ...............................................................................................................................................59 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual Contents Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. vi 8.3.1 Replacing a Circuit Breaker ..................................................................................................................................... 59 8.3.2 Replacing a Rectifier ............................................................................................................................................... 61 8.3.3 Replacing an SMU02C ............................................................................................................................................ 62 8.3.4 Replacing a UIM02C Board .................................................................................................................................... 64 8.3.5 Replacing an AC SPD Module ................................................................................................................................ 65 A Preparing Terminals .................................................................................................................. 67 B Technical Specifications ........................................................................................................... 68 C Associations Between Alarms and Dry Contacts on the UIM ........................................... 72 D Acronyms and Abbreviations.................................................................................................. 74 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 1 1 Safety Precautions 1.1 General Safety Ensure that the product is used in an environment that meets the product design specifications such as the grid power, input voltage, temperature, and humidity. Using the product in an incompatible environment may cause malfunctions, damage components, or invalidate the warranty. Follow the precautions and special safety instructions provided by Huawei when operating this product. Personnel who plan to install or maintain Huawei equipment must receive thorough product training, understand all necessary safety precautions, and be able to correctly perform all operations. Huawei will not be liable for any consequences that are caused by the violation of general safety regulations and equipment usage safety standards. The upstream power distribution box for the cabinet should be equipped with a protection switch that has the same specifications as or higher specifications than the input switch of the cabinet. Comply with local laws and regulations. The safety instructions in this document are only supplemental to local laws and regulations. Do not operate the product or handle cables during thunderstorms. Do not expose the equipment to flammable or explosive gas or smoke. Keep batteries away from strong infrared radiation, organic solvents, and corrosive gas. Do not use water to clean the product's internal or external electrical components. To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telecommunication network voltage (TNV) circuits. Do not place any irrelevant objects on batteries. Before using the product, remove any conductors such as jewelry or watches. Use insulated tools for all operations that involve electrical connections. Bolts should be tightened with a torque wrench and marked using red or blue color. Installation personnel mark tightened bolts in blue. Quality inspection personnel confirm if the bolts are tightened and then mark them in red. Follow specified procedures during installation and maintenance. Do not attempt to alter the product or deviate from the recommended installation procedures without prior consent from the manufacturer. Disconnect the AC power supply before maintaining AC power distribution. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 2 Measure contact point voltage with a multimeter before handling a conductor surface or terminal. Ensure that the contact point has no voltage or the voltage is within the specified range. When installing or removing power cables, ensure that the corresponding circuits are disconnected to prevent electric arcs or sparks. If AC input power cables need to be routed from the top, bend the cables in a U shape outside the cabinet and then route them into the cabinet. Performing maintenance or replacing components may interrupt power to the loads if batteries are not connected or the battery reserve is insufficient. Ensure that the switches for primary loads are in the ON position and do not turn off the battery switch and the AC input switch at the same time. Cables stored at subzero temperatures must be stored at room temperature for at least 24 hours before they are laid out. Perform routine maintenance as described in this manual; replace faulty components at the earliest. After maintenance is completed, lock cabinet doors and seal cable holes to prevent rodents from entering the cabinet. 1.2 Electrical Safety Grounding When installing a device, install the ground cable first. When uninstalling a device, remove the ground cable last. Before operating a device, ensure that the device is properly grounded. Ensure that the ground cable is installed securely (the ground resistance should be less than 0.1 ohm). Inappropriate grounding may cause device damage and personal injury. AC and DC Power The power system is powered by high-voltage power sources. Direct or indirect contact (through damp objects) with high-voltage power sources may result in serious injury or death. Non-standard and improper operations may result in fire or electric shocks. Before making electrical connections, turn off the protection switch on the upstream device to cut the power supply. Before connecting the AC power supply, ensure that electrical connections are complete. Before connecting cables to loads or battery cables, check cable and terminal polarities to prevent reverse connections. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 3 ESD To prevent electrostatic-sensitive components from being damaged by static from human bodies, wear a grounded electrostatic discharge (ESD) wrist strap or ESD gloves when touching circuit boards. When holding a board, hold its edge without touching any components, especially chips. Package boards with ESD packaging materials before storing or transporting them. Liquid Prevention Do not place the product in areas prone to water leakage, such as near air conditioner vents, ventilation vents, or feeder windows of the equipment room. Ensure that there is no condensation inside the product or equipment room. Ensure that no liquid enters the product. Otherwise, short circuits will occur and may result in serious injury or death. If any liquid is detected inside the product, immediately disconnect the power supply and contact the administrator. 1.3 Battery Safety Before installing, operating, or maintaining the batteries, read the battery manufacturer's safety instructions. Observe the safety precautions provided in this section, which are supplemental to the safety instructions provided by the battery manufacturer. Basic Requirements Avoid skin contact with battery electrolyte. Before handling batteries, wear goggles, rubbergloves, and protective clothing. When handling a battery, ensure that its electrodes always point upward. Do not tilt or overturn batteries. Before installing or maintaining batteries, switch off the battery circuit breaker or remove the battery fuse. Install batteries in a dry, clean, and ventilated environment that is free from sources of ignition. Do not expose batteries to sunlight or water. Ensure that the load-bearing capacity of the floor in the installation area is sufficient. Install additional supports if required. Secure battery cables to the torque specified in the battery documentation. Loose connections will result in excessive voltage drop or cause batteries to burn out in the case of excessive current. Ensure that battery cables do not come in contact with water. Battery Short Circuit ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 4 High short circuit currents or electric shocks can cause equipment damage, personal injury, or death. To prevent short circuit or electric shock, disconnect the batteries before performing any operation or maintenance. Flammable Gas Do not use unsealed lead-acid batteries. Lead-acid batteries emit flammable gas. Therefore, place and secure lead-acid batteries horizontally to prevent fire or corrosion. Store lead-acid batteries in a place with good ventilation, and take fire safety precautions. Battery Leakage High temperatures may result in battery distortion, damage, and electrolyte overflow. If the battery temperature is higher than 60°C, battery electrolyte may overflow. If the electrolyte overflows, wear goggles, rubber gloves, and protective clothing and absorb the leaking electrolyte using sodium bicarbonate (NaHCO3) or sodium carbonate (Na2CO3). Do not transport or move batteries if there is an electrolyte leakage. Battery Overdischarge After connecting the batteries, remove the battery fuse or turn the battery circuit breaker OFF and then power on the power system. This prevents battery overdischarge. After the power system is on, replace the battery fuse or turn the battery circuit breaker ON. 1.4 Cable Layout When routing cables, ensure that a sufficient distance exists between the cables and the DC busbar, shunt, and fuse. This prevents damage to the insulation layer of the cables. Route and bind signal cables and power cables separately. Ensure that cables meet the VW-1 testing requirements. Do not route cables behind the air exhaust vents of rectifiers in the cabinet. Ensure that all cables are securely bound. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 5 1.5 Mechanical Safety Hoisting Devices Do not walk under hoisted objects. Only trained and qualified personnel should perform hoisting operations. Check that all hoisting tools are available and in good condition. Before hoisting objects, ensure that hoisting tools are firmly fixed onto a load-bearing object or wall. Ensure that the angle formed by each hoisting cable is less than 90 degrees. If metal hoisting cables are used, place protective pads between the cables and the cabinet to prevent scratches to the cabinet surface. Figure 1-1 Hoisting heavy objects Drilling Holes Do not drill holes into a cabinet without permission. Incorrect drilling operations may affect the electromagnetic shielding of the cabinet and damage cables inside. Metal shavings from drilling may short-circuit boards inside the cabinet. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 1 Safety Precautions Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 6 Before drilling holes into a cabinet, wear goggles and protective gloves. Remove cables from inside the cabinet. After drilling, clean up any metal shavings that have accumulated inside or outside the cabinet. Moving Heavy Objects Only trained personnel are allowed to move heavy objects. Wear protective gloves and shoes before moving heavy objects. Be cautious to prevent injury when moving heavy objects. At least two people are required to move heavy objects. When you transport cabinets, ensure that there is no excessive tilt and no sudden jolt. The maximum allowed tilt angle when loading and unloading a cabinet is 15 degrees. Secure the cabinet to a pallet truck before you transport it. When you move a cabinet, ensure that it does not bump into other objects or fall down. Figure 1-2 Transportation gradient ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 2 Overview Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 7 2 Overview 2.1 Introduction ETP48400-C9A4 is an embedded telecom power system that supplies power to –48 V DC communications equipment with a maximum current of 400 A. 2.2 System Features Rectifier voltage input range of 85 V AC to 300 V AC. Comprehensive battery management. Network application over a fast Ethernet (FE) port and an RS485/RS232 port. Communication with Huawei NetEco or third-party network management systems (NMSs) over protocols such as the Simple Network Management Protocol (SNMP) and Hypertext Transfer Protocol Secure (HTTPS) to enable remote management and unattended working. Remote software upgrade. Liquid crystal display (LCD) for display and operations. Web user interface (WebUI) for display and operations. Display in multiple optional languages, such as English, Chinese, Italian, French, Spanish, Portuguese, Russian, German, Turkish and Japanese. Hot swapping of rectifiers and the SMU. Rectifier power factor up to 0.99. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 8 3 Components 3.1 Exterior Figure 3-1 ETP48400-C9A4 view (1) RTN+ busbar (2) LLVD circuit breakers (3) SMU02C (4) Space for rectifiers (5) Ground screw (6) AC input circuit breakers and terminal (7) AC SPD (8) Multi-purpose maintenance socket and protection circuit breaker (9) AC output circuit breaker (10) AC transfer terminals (11) UIM02C (12) Battery switch (behind the cover) ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 9 (13) Battery circuit breakers (14) BLVD circuit breakers Table 3-1 Power distribution specifications Item Power Distribution Specifications Input system 220/380 V AC three-phase four-wire (default), compatible with 127/220 V AC three-live wire AC power distribution AC input: one 3-pole 125 A circuit breaker AC output: one multi-purpose maintenance socket, one 2-pole 16 A protection circuit breaker, one 2-pole 16 A AC output circuit breaker DC power distribution BLVD: two 1-pole 63 A circuit breakers, one 1-pole 32 A circuit breaker, five 1-pole 16 A circuit breakers LLVD: four 1-pole 100 A circuit breakers, two 1-pole 20 A circuit breakers Battery route four 1-pole 125 A circuit breakers 3.2 Rectifier Rectifiers convert AC input into stable DC output. Figure 3-2 Rectifier (1) Run indicator (2) Alarm indicator (3) Fault indicator (4) Locking latch (5) Handle ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) HuaweiProprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 10 Table 3-2 Rectifier indicator description Indicator Color Status Description Run indicator Green Steady on The rectifier has an AC power input. Off The rectifier has no AC power input. The rectifier is faulty. Blinking at 0.5 Hz The rectifier is being queried. Blinking at 4 Hz The rectifier is loading an application program. Alarm indicator Yellow Off No alarm has been generated. Steady on The rectifier has generated an alarm due to ambient overtemperature. The rectifier has generated an alarm for shutdown due to ambient overtemperature or undertemperature. The rectifier is protecting itself against AC input overvoltage or undervoltage. The rectifier is hibernating. Blinking at 0.5 Hz The communication between the rectifier and the SMU has been interrupted. Fault indicator Red Off The rectifier is running properly. Steady on The rectifier has been locked out due to output overvoltage. The rectifier has no output due to an internal fault. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 11 3.3 SMU02C Panel Figure 3-3 SMU02C panel (1) SD card slot (2) Run indicator (3) Minor alarm indicator (4) Major alarm indicator (5) Buttons (6) USB port (protected by a security mechanism) (7) RS485/RS232 port (8) Fast Ethernet (FE) port (9) CAN communications port (10) LCD Indicators Table 3-3 Indicator description Name Color Status Description Run indicator Green Off The SMU is faulty or has no DC input. Blinking slowly (0.5 Hz) The SMU is running properly and communicating with the host properly. Blinking fast (4 Hz) The SMU is running properly but fails to communicate with the host properly. Minor alarm indicator Yellow Off No minor or warning alarm is generated. Steady on A minor or warning alarm is generated. Major alarm indicator Red Off No critical or major alarm is generated. Steady on A critical or major alarm is generated. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 12 Buttons Table 3-4 Button description Button Name Description Up Press Up and Down to scroll through the menus or to change the value of a parameter. Down Cancel Returns to the previous menu without saving the settings. Enter Enters the main menu from the standby screen. Enters a submenu from the main menu. Saves menu settings on a submenu. NOTE The LCD screen becomes dark if no button is pressed within 30 seconds. You need to log in again if no button is pressed within 1 minute. To increase or decrease a parameter value quickly, hold down or . To restart the SMU, hold down and for 10 seconds. To increase (or decrease) the LCD backlight, hold down and (or ) for 2 seconds. SD Card Slot SD card is used for storing the camera capture images, maximum support 32G capacity. USB Port You can insert a USB flash drive into the USB port to upgrade software, set up a site rapidly, and export configuration files and operating logs. You can operate the SMU over a mobile phone application after connecting a WiFi module to the USB port. Communications Ports Table 3-5 SMU02C communication port description Communications Port Communications Parameter Communications Protocol FE 10/100M autonegotiation HTTPS, NetEco protocol, SNMP and TCP-Modbus Protocol RS485/RS232 Baud rate: 1200bit/s, 2400bit/s, 4800bit/s, Master/slave protocol, YDN ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 13 Communications Port Communications Parameter Communications Protocol 9600bit/s, 14400bit/s, 19200bit/s, 115200bit/s protocol, and Modbus protocol CAN Baud rate: 125 kbit/s CAN protocol NOTE All these ports are protected by a security mechanism. Figure 3-4 Communication port pins Table 3-6 Pin definitions for the FE port Pin Signal Description 1 TX+ Transmits data over FE. 2 TX- 3 RX+ Receives data over FE. 6 RX- 4, 5, 7, 8 NA - Table 3-7 Pin definitions for the RS485/RS232 port Pin Signal Description 1 TX+ Transmits data over RS485. 2 TX- 4 RX+ Receives data over RS485. 5 RX- 3 RX232 Receives data over RS232. 7 TX232 Transmits data over RS232. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 14 Pin Signal Description 6 PGND Connects to the ground. 8 NA – Table 3-8 Description for the CAN port pins Pin Signal Description 1 RX+ Receives data over RS485. 2 RX- 3 NA – 4 TX+ Sends data over RS485. 5 TX- 6 GND Grounded. 7 CANH CAN high level signal. 8 CANL CAN low level signal. 3.4 User Interface Module UIM02C Panel The user interface module (UIM02C) supports eight dry contact outputs, six dry contact inputs, and seven sensor ports (including one ambient temperature and humidity input, one water sensor input, two ambient temperature inputs, one door status sensor input, one smoke sensor input, and one battery temperature input). Figure 3-5 UIM02C panel ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 15 Ports Table 3-9 UIM02C port description Port Type Silk Screen Description Sensor ports TEM-HUM Ambient temperature and humidity sensor WATER Water sensor TEMP1 Ambient temperature sensor 1 TEMP2 Ambient temperature sensor 2 GATE Door status sensor SMOKE Smoke sensor BTEMP Battery temperature sensor Dry contact input ports DIN1 NOTE For the associations between dry contact inputs and alarms, see the appendix. DIN2 DIN3 DIN4 DIN5 DIN6 Dry contact output ports ALM1 NOTE For the associations between dry contact outputs and alarms, see the appendix. ALM2 ALM3 ALM4 ALM5 ALM6 ALM7 ALM8 Communications ports COM RS485 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 16 Communication Port Table 3-10 COM communication port description Communication Port Communications Parameter Communications Protocol Function COM Baud rate: 9600 bits/s, 19200 bits/s or 115200 bit/s M/S and Modbus protocol Connects to lower-level devices such as the battery inspection unit, DC air conditioner NOTE The COM port supports the security mechanism. Figure 3-6 Pins in the COM port Table 3-11 Pin definitions for the COM port Pin Signal Description 1 RX+ Receives data over RS485. 2 RX- 4 TX+ Sends data over RS485. 5 TX- 6 PGND Connects to the ground. 3, 7, 8 None - Pins Figure 3-7 shows the pin numbers of the sensor ports. Table 3-12 defines the pins. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 3 Components Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 17 Figure 3-7 UIM02C pin numbers Table 3-12 UIM02C pin numbers Silk screen No. Pin Definitions TEM-HUM 1 12 V 2 ENV_TEMP 3 12 V 4 ENV_HUM WATER 1 12 V 2 WATER 3 GND 4 - TEMP1 1 GND 2 TEMP1 TEMP2 1 GND 2 TEMP2 GATE 1 GATE+ 2 GATE- SMOKE1 SMOKE 2 12 V BTEMP 1 GND 2 BTEMP ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 18 4 Installation 4.1 Installation Preparations 4.1.1 Preparing Cables All cables must comply with local laws, regulations, and standards as well as customer requirements. The cross-sectional area of a power cable depends on the current that will flow through the cable and the voltage drop allowed for the cable. Table 4-1 Preparing cables Cable Type Maximum Operating Current (A) Minimum Cross-Sectional Area (mm2) Maximum Cross-Sectional Area (mm2) Subrack ground cable NA 16 35 AC input power cable (three-phase four-wire) Live wire 54 10 35 Neutral wire 54 10 35 AC output power cable (single-phase) Live wire 16 1.5 16 Neutral wire 16 1.5 16 AC input power cable (three-live wire) Live wire 94 16 35 AC output power cable (dual-live wire) Live wire 16 1.5 16 DC output power cable 16 1.5 16 20 1.5 16 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 19 Cable Type Maximum Operating Current (A) Minimum Cross-Sectional Area (mm2) Maximum Cross-Sectional Area (mm2) 32 2.5 16 63 10 16 100 16 35 Battery cable 125 25 35 NOTE: 1. The size data in the table is the cable sizes applicable when the ambient temperature is 30°C (in air) and only cables in a single loop are involved. 2. When the ambient temperature is not 30°C or cables in multiple loops are routed together, use cables with larger cross-sectional areas if the cabling distance is long. 3. The battery cables should be able to resist a temperature of 90°C at least. Double-insulated flame-retardant copper cables are recommended. 4.1.2 Tools Use tools with insulated handles. The following table is for reference only. Table 4-2 Installation tools and instruments ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 20 4.1.3 Installation Dimensions After the subrack is installed, reserve 2 U cabling space on the top and 1 U cabling space at the bottom.Figure 4-1 shows the installation space requirements. Figure 4-1 Installation space requirements (50 mm): indicates that the distance between the installation plane of power subrack mounting ear and the front of the subrack is about 50 mm. 4.1.4 Requirements for Cable Routing Ensure that cables are more than 20 mm away from heat sources to prevent damage (melting, aging, or breakage) to the cable insulation layer. Ensure that the bending radius of each cable is at least five times the diameter of the cable. Bind cables of the same type together. When routing cables of different types, ensure that they are at least 30 mm away from each other. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 21 Route and bind cables so that they appear neat and tidy and their cable sheaths are intact. Route and bind ground cables and signal cables separately. Route and bind AC power cables, DC power cables, signal cables, and communications cables separately. When routing power cables, ensure that there is no coiling or twisting. Do not join or weld power cables. If necessary, use a longer cable. 4.2 Installing a Subrack Figure 4-2 Installing a subrack 4.3 Installing a Ground Cable Ensure that the ground cable is installed securely. Inappropriate grounding may cause personal injury and device damage. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 22 Figure 4-3 Installing a ground cable (1) Ground bar 4.4 Installing a Rectifier Prerequisites The rectifier is intact after being unpacked. The filler panel has been removed from the rectifier slot. If the rectifier is damaged, contact your local Huawei office. The rectifier slot presents a risk of electric shock. Do not touch the slot with your hands. High temperature is generated around the air exhaust vent when the rectifier is running. Do not touch the vent with your hands or cover the vent with cables or other objects. Procedure Step 1 Push the locking latch towards the left. Step 2 Draw the handle downwards. Step 3 Gently push the rectifier into its slot along the guide rails. Step 4 Push the handle upwards. Step 5 Push the locking latch towards the right to secure the handle. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 4 Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 23 Figure 4-4 Installing a rectifier ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 24 5 Installing Cables Ensure that the upstream AC input circuit breaker is OFF, and attach labels such as "No operations allowed". Switch off all circuit breakers before installing cables. 5.1 (Optional) Installing Dry Contact Signal Cables Procedure Step 1 Press the contact plate using a flat-head screwdriver to flip the metal spring inside each dry contact. Step 2 Connect the signal cables to the corresponding dry contacts. Step 3 Remove the flat-head screwdriver and check that the signal cables are connected securely. Figure 5-1 Installing a dry contact signal cable (1) Contact plate (2) Dry contact port ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 25 5.2 (Optional) Installing a Communications Cable Between the SMU and Huawei BBU If Huawei BBU is deployed, connect a communications cable between the SMU and Huawei BBU. The U2000-SPM and NetEco network management systems (NMSs) are supported. Step 1 Connect one end of a network cable to the RS485/RS232 port on the SMU. Step 2 Connect the other end of the cable to the MON1 port on Huawei BBU, as shown in Figure 5-2. Figure 5-2 Connecting a communications cable (1) RS485/RS232 port on the SMU (2) MON1 port on Huawei BBU ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 26 5.3 Installing Communications Cables 5.3.1 WebUI Management Procedure Step 1 Connect the FE port on the site monitoring unit (SMU) by using a network cable, as shown in Figure 5-3. Figure 5-3 Connecting a communications cable (for WebUI management) (1) User WebUI terminal (2) FE port on the SMU ----End 5.3.2 Using the U2000-SPM for Management For the cable connection to the NMS, see 5.2 (Optional) Installing a Communications Cable Between the SMU and Huawei BBU. 5.3.3 NetEco Management Networking Mode 1: FE Port Step 1 Connect the FE port on the SMU by using a network cable, as shown in Figure 5-4. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietaryand Confidential Copyright © Huawei Technologies Co., Ltd. 27 Figure 5-4 Connecting a communications cable (over the FE port) (1) NetEco terminal (2) FE port on the SMU ----End Networking Mode 2: RS485 Port 5.2 (Optional) Installing a Communications Cable Between the SMU and Huawei BBU shows the NetEco cable connection. 5.3.4 Third-Party NMS Management (over SNMP) Procedure Step 1 Connect the FE port on the SMU by using a network cable, as shown in Figure 5-5. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 28 Figure 5-5 Connecting a communications cable (for third-party NMS management) (1) SNMP-based NMS terminal (2) FE port on the SMU ----End 5.3.5 Using Dry Contacts for Management Procedure Step 1 Alarm signals are uploaded over dry contacts. Connect the dry contact signal cables to the EXT-ALM ports on Huawei BBU, as shown in Figure 5-6. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 29 Figure 5-6 Connecting the UIM02C to Huawei BBU (1) Huawei BBU (2) EXT-ALM1 port (3) EXT-ALM0 port ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 30 5.4 Installing DC Output Power Cables Procedure Step 1 Route DC output power cables through the protective board on the top of the subrack. Step 2 Secure the negative DC output power cable to the corresponding DC output circuit breakers based on the actual load capacity. Step 3 Secure the positive DC output power cable to the corresponding screw on the RTN+ busbar. Figure 5-7 Installing DC output power cables (1) Secondary load (2) Primary load ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 31 5.5 Installing AC Output Power Cables 5.5.1 Installing 220 V AC Single-Phase Output Power Cables Procedure Step 1 Route 220 V AC single-phase output power cables through the protective board from the bottom of the subrack. Step 2 Secure the AC output power cables to the corresponding AC output circuit breaker. Figure 5-8 Installing 220 V AC single-phase output power cables (1) AC load ----End 5.5.2 Installing 110 V AC Dual-Live Wire Output Power Cables Procedure Step 1 Route 110 V AC dual-live wire output power cables through the protective board from the bottom of the subrack. Step 2 Secure the AC output power cables to the corresponding AC output circuit breaker. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 32 Figure 5-9 Installing 110 V AC dual-live wire output power cables (1) AC load ----End 5.6 Installing AC Input Power Cables 5.6.1 Installing 220/380 V AC Three-Phase Four-Wire Input Power Cables Procedure Step 1 Route 220/380 V AC three-phase four-wire input power cables through the protective board from the bottom of the subrack. Step 2 Secure the AC input power cables to the corresponding AC input circuit breakers and terminal. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 33 Figure 5-10 Installing 220/380 V AC three-phase four-wire input power cables (1) Alternating current distribution box (ACDB) ----End 5.6.2 Installing 127/220 V AC Three-Live Wire Input Power Cables Procedure Step 1 Remove the three short-circuit plates from the AC transfer terminals and install them at the positions shown in the following figure. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 34 Figure 5-11 Modifying the AC input mode Step 2 Route 127/220 V AC three-live wire input power cables through the protective board form the bottom of the subrack. Step 3 Secure the AC input power cables to the corresponding AC input circuit breaker. Figure 5-12 Installing 127/220 V AC three-live wire input power cables (1) ACDB ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 35 5.7 Installing Battery Cables Prerequisites Avoid smoking and causing sparks near batteries. Ensure that the battery circuit breakers are OFF before installing batteries. Comply with regulations and warnings of the battery manufacturer. Use tools with insulated handles to avoid burning batteries or causing personal injury. During battery operations, wear goggles, rubber gloves, and protective clothes. Remove conductive articles such as watches and jewelry. If battery acid gets in the eyes, rinse with cold water for more than 15 minutes and seek medical advice immediately. If battery acid contacts skin or clothing, wash with soap and water immediately. Do not use metal to simultaneously touch two or more battery terminals or simultaneously touch a battery terminal and a grounded object (such as the battery compartment). Otherwise, a transient short circuit will occur, which can produce sparks or cause an explosion. During battery installation, never short-circuit or reversely connect positive and negative battery terminals. Connect the negative battery cable before the positive battery cable. Secure battery cables to the torque specified in the battery documentation. Loose connections will result in excessive voltage drop or cause batteries to burn out in the case of excessive current. Procedure Step 1 Route battery cables through the protective panel on the top of the subrack. Step 2 Secure the negative cables of battery strings to battery circuit breakers. Step 3 Secure the positive cables of battery strings to the RTN+ busbar. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 5 Installing Cables Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 36 Figure 5-13 Installing battery cables (1) Battery string ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 6 Verifying the Installation Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 37 6 Verifying the Installation 6.1 Checking Hardware Installation Check that all screws, especially those used for electrical connections, are secured. Check that flat washers and spring washers are installed properly. Check that rectifiers are completely inserted into their respective slots and properly locked. 6.2 Checking Electrical Connections Check that all circuit breakers are OFF or all fuses are disconnected. Check that flat washers and spring washers are securely installed for all OT terminals and that all the OT terminals are intact and properly connected. Check that batteries are correctly installed and that battery cables are correctly connected, and not short circuits exist. Check that input and output power cables and ground cables are correctly connected, and not short circuitsexist. 6.3 Checking Cable Installation Check that all cables are securely connected. Check that all cables are arranged neatly and bound properly to their nearest cable ties, and are not twisted or overly bent. Check that cable labels are properly and securely attached in the same direction. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 38 7 Commissioning Performing commissioning procedure provided in this chapter may result in power failure or alarms. Inform the alarm center before commencing the procedure and after completing the procedure. Commissioning should be performed by trained personnel according to the commissioning instructions provided in this chapter. Commissioning is performed with the power on. Before you perform commissioning, remove any conductors such as jewelry or watches, stand on dry insulating material, and use insulated tools. During commissioning, do not establish contact between electrical points that have different electric currents. Check that the status of a unit or component meets requirements before turning on its switch. If you are maintaining or servicing equipment and do not want others to perform any operation, attach the label "Currently being serviced. Do not switch on." to the equipment. During commissioning, shut down the power system immediately if any fault is detected. Rectify the fault, start the power system, and proceed with the commissioning. 7.1 Connecting the AC Power Supply Procedure Step 1 Measure the input voltage on the AC input circuit breaker. The value should range from 85 V AC to 300 V AC. Step 2 Switch on the AC input circuit breaker and measure the output voltage of the AC input circuit breaker. The value should range from 85 V AC to 300 V AC. Step 3 Check that the run indicators on the rectifiers are steady on. Step 4 Measure the voltage between the –48 V busbar and the RTN+ busbar. The value should range from –42 V DC to –58 V DC. ----End ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 39 7.2 Setting the Display Language After powering on the SMU, press or on the LCD to select a display language. Then press to enter the standby screen. If an undesired language is selected, reinstall and restart the SMU and then select the desired language. 7.3 Setting the Date and Time The LCD backlight turns off if no button is pressed within 30 seconds. Re-login is required if no button is pressed within 1 minute. The preset password for login is 000001. Set the date and time as required. Table 7-1 Setting the date and time Main Menu Second-Level Menu Third-Level Menu Default Value Settings Setting Wizard Date and Time NOTE The date and time vary with time zones. Set the time zone, date, and time based on the local situation. Time Zone UTC +08:00 Beijing Set to the local time zone. Date and Time - Set to the local date and time. NTP Enable No Yes/No NOTE Set the parameter to Yes if you need to synchronize the SMU time and the site network server time. 7.4 Setup Wizard Init After the Setup Wizard Init screen is displayed, set the following parameters. Table 7-2 Setting parameters Item Setting Time Zone Set to the local time zone. Date and Time Set to the local date and time. Battery Vendor Set the parameters based on site requirements. NOTE In the lithium battery scenario, retain the default values. Battery Model ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 40 Item Setting The SMU may restart Yes 7.5 Setting Battery Parameters Table 7-3 Setting battery parameters Main Menu Second- Level Menu Third- Level Menu Fourth-Level Menu Default Value Setting Parameters Settings Acid Battery Basic Parameters Battery1 Connected Yes Yes/No NOTE If N battery strings are connected, set Battery 1 Connected to Battery N Connected to Yes, and set the other parameters to No. Battery2 Connected Yes Battery3 Connected Yes Battery4 Connected Yes Single-String Cap. 150 Ah Single-String Cap. of the batteries in a battery string. NOTE The batteries connected to one circuit breaker or fuse are called a battery string. Other Parameters Installation Time - Set this parameter to the current date. If battery routes 1 and 2 are respectively connected to a battery string (each battery string consists of four 12 V, 150 Ah batteries in series), set Battery1 Connected and Battery2 Connected to Yes and others to No, and set Single-String Cap. to 150 Ah. If battery route 1 is connected to two battery strings in parallel (each battery string consists of four 12 V, 150 Ah batteries in series), set Battery1 Connected to Yes and others to No, and set Single-String Cap. to 300 Ah. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 41 7.6 Setting Communications Parameters 7.6.1 (Optional) Setting Parameters Before Using WebUI Operating Environment Operating system: Windows XP or later Browser: Internet Explorer 8.0 or later, FireFox 13 or later, or Chrome 20 Internet Explorer is used as an example to illustrate all WebUI operations mentioned in this document. Setting a LAN If the SMU is connected to a LAN and a proxy server has been selected, cancel the proxy server settings. If the SMU is connected to the Internet but your computer is connected to a LAN, do not cancel the proxy server settings. Otherwise, you cannot access the SMU. To cancel proxy server settings, perform the following steps: Step 1 Open Internet Explorer. Step 2 Choose Tools > Internet Options. Step 3 Click the Connections tab and click LAN settings. Step 4 Clear Use a proxy server for your LAN, as shown in Figure 7-1. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 42 Figure 7-1 Canceling proxy server settings 1 Figure 7-2 Canceling proxy server settings 2 Step 5 Click OK. ----End Setting Internet Explorer Security ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 43 Set Internet Explorer security before you perform the following operations: Export historical logs, historical data, statistics, and battery test records. Upload system configuration files. Download system configuration files. Upgrade software. To set Internet Explorer security, perform the following steps: Step 1 Open Internet Explorer. Step 2 Choose Tools > Internet Options. Step 3 Click the Security tab. Step 4 Click Internet and click Custom level, as shown in Figure 7-3. After you specify Internet security settings, click Local intranet and click Custom level. Figure 7-3 Internet Explorer security Step 5 Specify the security settings. Enable the following: Initialize and script ActiveX controls not marked as safe for scripting Allow previously unused ActiveX controls to run without prompt Include local directory path when uploading files to a server Automatic prompting for file downloadsETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 44 Figure 7-4 Internet Explorer security setting 1 Figure 7-5 Internet Explorer security setting 2 ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 45 Figure 7-6 Internet Explorer security setting 3 Figure 7-7 Internet Explorer security setting 4 Step 6 Click OK. Step 7 Click the Advanced tab, and select all of Use TLS 1.0, Use TLS 1.1, and Use TLS 1.2. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 46 Figure 7-8 Internet Explorer security setting 5 Step 8 Click OK. ----End Setting SMU Parameters Step 1 Apply to the site or equipment room network administrator for a fixed IP address. Step 2 Set the IP address, subnet mask, and gateway on the SMU's LCD. Table 7-4 IP parameters Main Menu Second-Level Menu Third-Level Menu Default Value Settings Setting Wizard Network Parameters IP Address 192.168.0.10 Set this parameter according to the address provided by the network administrator. Subnet Mask 255.255.255.0 Set this parameter according to the subnet mask provided by the network ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 47 Main Menu Second-Level Menu Third-Level Menu Default Value Settings administrator. Default Gateway 192.168.0.1 Set this parameter according to the gateway address provided by the network administrator. NOTE If the WiFi module is installed, do not set the default gateway to 192.168.8.1. ----End Login Page Enter https://local IP address for the SMU (for example, https://192.168.0.10) in the address box of Internet Explorer and press Enter. The login page is displayed, as shown in Figure 7-9. Figure 7-9 Login page The preset user name is admin, and the preset password is Changeme. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 48 7.6.2 Setting Parameters Before Using U2000-SPM Context If a Huawei BBU is deployed, set the Northbound and M/S Protocol parameters. Procedure Step 1 Set the port mode, communications protocol type, baud rate, and communications address on the SMU's LCD. Table 7-5 Communications parameters Main Menu Second-Level Menu Third-Level Menu Fourth-Level Menu Fifth-Level Menu Default Value Settings Parameters Settings Comm. Parameters Serial Port Northbound Port Mode Manual Manual Protocol Type NOTE Protocol Type is displayed only when Port Mode is set to Manual. M/S Protocol M/S Protocol M/S Protocol Baud Rate - 9600 9600 Comm. Address - 3 3 ----End 7.6.3 (Optional) Setting Parameters Before Using NetEco Networking Mode 1: FE Port Step 1 Apply to the site or equipment room network administrator for a fixed IP address. Step 2 Set the IP address, subnet mask, and gateway on the SMU's LCD. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 49 Table 7-6 IP parameters Main Menu Second-Level Menu Third-Level Menu Default Value Settings Setting Wizard Network Parameters IP Address 192.168.0.10 Set this parameter according to the IP address assigned by the network administrator. Subnet Mask 255.255.255.0 Set this parameter according to the subnet mask provided by the network administrator. Default Gateway 192.168.0.1 Set this parameter according to the gateway address provided by the network administrator. Step 3 Set the IP Addresses and Ports for the active and standby servers of the NetEco on the SMU's LCD. Table 7-7 NetEco parameters Main Menu Second-Level Menu Third-Level Menu Fourth-Level Menu Default Value Settings Parameters Settings Comm. Parameters Network Parameters NetEco Primary IP 192.168.0.10 Set an IP address for the active NetEco server. NetEco Backup IP 192.168.0.10 Set an IP address for the standby NetEco server. NetEco Port Number 31220 31220 NOTE Please contact Huawei technical support if you need change the port number. ----End Networking Mode 2: RS485 Port Step 1 Set Port Mode to Manual, Protocol Type to M/S Protocol, Baud Rate to 9600, and Comm. Address to 3. ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 50 Table 7-8 Communications parameters Main Menu Second-Level Menu Third-Level Menu Fourth-Level Menu Fifth-Level Menu Default Value Settings Parameters Settings Comm. Parameters Serial Port Northbound Port Mode Automatic Manual Protocol Type NOTE This parameter is displayed only when Port Mode is set to Manual. M/S Protocol M/S Protocol M/S Protocol Baud Rate - 9600 9600 Comm. Address - 3 3 ----End 7.6.4 (Optional) Setting Parameters Before Using SNMP Prerequisites You can set SNMP parameters remotely or locally on the WebUI. Before setting SNMP parameters, obtain the information listed in Table 7-9 from the NMS. Table 7-9 Information obtained from the NMS Information Description SNMP version SNMP version and port number used by the SMU and NMS. The SNMP versions include SNMPv1, SNMPv2c, and SNMPv3. SNMP Port Number Read Community Name If you use SNMPv1 or SNMPv2c, enter the read community name and write community name that comply with the NMS. Otherwise, the SMU will not connect to the NMS. The read community name must be different from the write community name. Write Community Name User Name To enhance the security, you need a user name and password for authentication if you use SNMPv3. After the authentication succeeds, the SMU can communicate with the NMS. MD5/SHA Password Trap Target Address IP address and port number reported in the alarm trap. Trap Port ETP48400-C9A4 Embedded Power (STC, Saudi) User Manual 7 Commissioning Issue 01 (2018-02-01) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. 51 Information Description Trap community NOTE If the SMU software version is V500R001C00 or later, you need to obtain the trap community name. If you use SNMPv1 or SNMPv2c, community name used for reporting alarm trap packets. Procedure Step 1 Log in to the WebUI. For details, see 7.6.1 (Optional) Setting Parameters Before Using WebUI. Step 2 Access the System Settings page and set SNMP. If the SNMP version is SNMPv1 or SNMPv2c, after you set SNMP Version in SNMP, set SNMP Version, Read Community Name, and Write Community Name. If the SNMP version is SNMPv3, set SNMP Version in SNMP, click Add in SNMPv3, and set User Name, MD5/SHA Password, and DES/AES Password. Then click Confirm and Submit. Step 3 In SNMP Trap, click Add and set relevant parameters such as Trap Target Address and Trap Port. Step 4 In Mib files, click Export to export the Mib file and then import it into the NMS. If there is only one NMS, perform Step 4 once
