Answer: a Explanation: At leading pf armature current will be high as the emf will be high for a synchronous motor. 9. The inverted V plots is plotted between a) power factor vs field current for constant shaft load b) field current vs power factor for variable shaft load c) armature current vs field current d) terminal voltage vs power factor View Answer Answer: a Explanation: inverted v-curves are plotted between power factor and field current for constant shaft load. 10. For a power system having induction motor loads, an overexcited synchronous motor is also attached. Then the over all power factor a) improves b) degrades c) becomes upf d) remains same View Answer Answer: a Explanation: An over excited synchronous motor acts as a source of lagging reactive power and so the overall power factor improves. 11. For a power system having induction motor loads, an overexcited synchronous motor is also attached. The induction motor will now operate at a) lagging b) leading c) reduced power factor d) increased power factor View Answer Answer: a Explanation: Adding synchronous motor will improve the pf of the system but then the induction motor will still work at lagging pf only. 12. Synchronous compensators are a) overexcited synchronous motor with no mechanical load b) overexcited synchronous motor with mechanical load c) underexcited synchronous motor with no mechanical load d) normal excited synchronous motor with no mechanical load View Answer Answer: a Explanation: Synchronous compensators are overexcited synchronous motor with no mechanical load. 13. For a synchronous motor, mark the appropriate.
