1
JOUAV® CW-007™ mapping solution
CHENGDU JOUAV DAPENG TECH. CO., LTD
COMMITTED TO BECOME THE WORLD'S LEADING
INDUSTRIAL UNMANNED SYSTEMS AND SERVICE PROVIDER
April, 2020
2
Disclaimer
JOUAV® series vertical take-off and landing fixed-wing UAV products are sensitive items and are
prohibited from any illegal use. JOUAV shall not be liable for the consequences caused by illegal use,
we shall not bear the responsibility of third parties arising from the use of this product, we will not
provide any technical support and committed to. The user's direct or indirect use of JOUAV® series of
vertical take-off and landing fixed-wing UAV products will be deemed to have unconditionally accepted
all the contents covered by this statement. If the user has any terms of this statement If there is any
objection, please stop using it immediately.
CHENGDU JOUAV DAPENG TECH CO.,LTD
3A-8F, Jingrong Innovation Hub,No.200,5th TianFu St., Hi-tech District,
Chengdu City, Sichuan Province, China 610041
028 8171 7278
Visit www.jouav.com for more information
The data on the following pages are actual values, all from JOUAV® internal laboratory. Actual use may differ slightly due to
individual product differences, software versions, use conditions and environmental factors. Please refer to actual use. Due to the
real-time changes in product batches and production and supply factors, in order to provide as accurate product information,
specifications, and product characteristics as possible, JOUAV® may adjust and revise the text descriptions, picture effects, and
other content on the following pages in real time to match the actual product. The performance, specifications, index, parts and
other information are matched.
© 2020-CHENGDU JOUAV DAPENG TECH CO., LTD All rights reserved.
All product and brand names may be trademarks or registered trademarks of the respective manufacturers. TM and ® marks may
be omitted in this document.
3
Contents
April, 2020..............................................................................................................................1
Disclaimer..............................................................................................................................2
1. Overview............................................................................................................................1
2. CW-007 UAV aerial survey system............................................................................. 2
2.1 Platform.......................................................................................................................2
2.2 Test Report..................................................................................................................2
2.3 Technical data.............................................................................................................3
2.4 Main Features............................................................................................................ 4
2.5 POS system................................................................................................................7
2.6 Airborne sensor..........................................................................................................8
2.6.1 CA102™ aerial camera.........................................................................................................8
2.6.2 Multispectral camera...........................................................................................................10
2.7 GCS202 ground control station.............................................................................13
2.8 CWCommander™ ground station software........................................................ 14
2.9 JoPPS™ post-differential GNSS Data processing software.............................15
2.10 Post processing software.....................................................................................16
2.10.1 DOM Software....................................................................................................................16
2.10.2 Mapping software.............................................................................................................. 16
2.11 JOUAV cloud location service............................................................................. 18
3. Work flow........................................................................................................................ 19
4. Training, After-sales service...................................................................................... 20
4.1 UAV academy...........................................................................................................20
4.1.1 Provide UAV pilot training for customers.........................................................................21
4.1.2 Our advantage......................................................................................................................21
4.2 After-sales service and technical support............................................................22
5. Introduction of JOUAV.................................................................................................24
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
1
1. Overview
Traditional surveying and mapping method is to obtain data through ground and
manual observation, the accuracy of acquired data is limited by many objective
conditions. In recent decades, due to the development of space technology and
computer information technology, traditional surveying and mapping has moved towards
digital surveying and mapping. UAV technology has played an important role in this
process.
UAV has the characteristics of flexible, efficient, rapid, accurate, low operation cost,
short production cycle, etc. It can replace workers in remote (difficult to reach) and
high-risk areas, and can perform missions in complex ground and weather conditions. It
has unique advantages in digital city construction, disaster emergency treatment, major
project construction, land supervision and other fields, and has become the preferred
remote sensing platform for emergency support and small-scale mapping.
Due to the characteristics of UAV remote sensing platform and its data acquisition,
there are still many problems to be solved in engineering application, such as reducing
ground control points, improving the degree of operation automation, obtaining results
with high efficiency and improving the level of accuracy.
CW-007 is a portable electric vertical take-off and landing fixed-wing UAV system.
With tool-free disassembly, electrical integration, high altitude and other performance
characteristics. It is including RTK/PPK and aerial camera, can not only remove or greatly
reduce ground control points, improve the level of automation and precision, realize the
goal of surveying and mapping, but also shortening construction period and cost
reduction, improved work efficiency. According to customer's request, can provide the
diversity of data acquisition, a high precision, high efficiency, diversity, stable and reliable
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
2
aerial equipment.
2. CW-007 UAV aerial survey system
2.1 Platform
CW-007 is a small unmanned aerial vehicle, which mainly used in aerial survey,
agriculture, surveillance and other fields. With simple operation that can be carried
and operated by single person, full autonomous flight, vertical take-off and land, and
total weight less than 7kg, modular design, no need any tools for assembly and
disassembly, the electrical plug and the mechanical connection are completed
synchronously, brand new power management module that the whole machine is
powered by only one battery, which simplifiesthe user's operation process and
improves the efficiency of power supply.
2.2 Test Report
JOUAV®CW-007 portable electric unmanned aerial system has obtained the
Test report of Ministry of Industry and Information Technology, Test report of novelty
search, and Evaluation report for scientific and technological achievements.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
3
1) Serial number of Test report of Ministry of Industry and Information Technology:
C1809WT8888-03571
2) Serial number of Test report of novelty search: 20185100901859
3) Serial number of Evaluation report for scientific and technological achievements: Sichuan
ministry of industry and information technology (evaluation) [2018] No. 057
2.3 Technical data
Hardware
Fuselage 1.3m
Wingspan 2.2m
Max. Takeoff weight 6.8kg
Electro-motor Brushless motor, low noise
Radio link 30km
DGPS RTK/PPK
Package size 1200×500×400mm
Payload
Mission payload 800g
Flight
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
4
Flight endurance 60min
Cruise speed 65km/h
Wind Resistance Level 6（10.8-13.8 m/s）
Water Proof Rainfall capacity≤10mm/24h
Take-off and landing VTOL
Max. Flight ceiling 6000m
Max. Takeoff altitude 4500m
Positioning accuracy of vertical 3cm
Positioning accuracy of horizontal 1cm+1ppm
Software
GCS Software CWCommander
2.4 Main Features
1) Light weight: The total weight of the flight platform and mission equipment
is less than 7Kg, which is light and flexible.
2) Easy transportation: Integrated backpack design, the total weight of the
backpack is less than 14Kg, easy to carry by single person on foot.
3) Intelligent battery: BMS system with independent intellectual property
rights. Battery capacity accurate to 5%, charge and discharge safety protection.
CAN interface communicates with flight control and charger. One key switch
power display mode, discharge mode, heating mode.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
5
4) Unique design of waist push power: Level flying power in the waist, and
the use of disc battery, high torque, high efficiency, good heat dissipation.
5) Modular design: It takes within 2 minutes for assembly and disassembly
without any tools.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
6
6) Highly integrated camera: Highly integrated 42-megapixel full-frame
camera, which lighter and smaller than the other camera on the market.
7) Fusion winglet: More optimized aerodynamic layout, reduce resistance.
8) Excellent plateau performance: the highest take-off altitude is 4500m, and
the cruising altitude can reach 6000m.
9) VTOL: Greatly reduce the dependence on the field, catapult frame,
parachute, etc.
10) Fully Auto: No remote controller, one-button take-off and land, safe and
simple, landing accuracy within 10cm.
11) RTK/PPK: Both with RTK and PPK function, RTK is mainly used for
precisely and autonomously vertical land by the accuracy of centimeter-level,
while PPK is mainly used to output high-precision POS data, ensuring
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
7
reduction of more than 80% ground control points.
12) High efficiency: Single flight can finish 4 km2 of 1:500 scale, 8 km2 of
1:1000 scale, 12 km2 of 1:2000 scale.
13) Excellent flight attitude: Strict wind tunnel experiment design, and total
energy adaptive algorithm are adopted for flight control, which ensure stable
attitude and facilitate generation of DLG results.
14) Exposure synchronization: The exposure synchronization module
ensures that the exposure delay is within 10ms.
15) Dual GPS: Ensuring that if the main differential GPS is abnormal, it can
smoothly switch to the backup GPS to ensure flight safety during the flight
mission.
16) Dual compass: Ensure that if there is any abnormality in the built-in
magnetic compass during flight, it can smoothly switch to the backup external
magnetic compass to ensure flight safety.
2.5 POS system
PPK/RTK GNSS module is an industrial-grade high precision differential GNSS
module developed by JOUAV. Real-time kinematic (RTK) can be realized, PPK can
also be carried out after the flight mission is completed. In both cases, centimeter-
level positioning accuracy can be obtained. Especially suitable for high-precision
aerial photography aerial survey operations, which can reduce more than 80% of the
field ground control point and greatly improve the efficiency of aerial photography
aerial survey operations and data accuracy.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
8
GNSS technical parameters
Tracking channel
Number of channels: 120, GPS L1, L2, L2C,
GLONASSL1/L2, GalileoE1
Accuracy of positioning H:10mm+1.0ppm×baseline；V:15mm+1.0ppm×baseline
Processor and memory configuration
Processor Industrial grade processor
Internal Flash capacity 1G Byte
Update rate 5Hz/10Hz/20Hz
Storage format Binary
Performance
Memory capacity 960M
Data storage time 28H
Data reading rate 128KB/s
Photo trigger High level trigger greater than 150ns
2.6 Airborne sensor
2.6.1CA102™ aerial camera
CA102™ aerial photography camera uses a 35mm full-frame ExmorR
CMOS™ backlight image sensor with a 5.6/35 lens, which is highly integrated
with JOUAV® series UAV. The four-angle shock absorption scheme with the best
shock absorption coefficient guarantees the highest accuracy and the best
results.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
9
2.6.1.1 Solid, lightweight, reliable design
After considering the aerodynamic data, body strength, flight speed,
takeoff weight, vibration frequency of the motor, and the space size of the
cabin, the design of the damping adopts the four-angle damping scheme with
the best damping coefficient to ensure a high-quality picture of the camera. In
addition, the most suitable camera installation structure is provided for the
camera.
2.6.1.2 Technical data
Image sensor
Sensor type Exmor R CMOS
Sensor size 35.9×24.0mm (Full frame)
Resolution 7952×5304
Pixels 42.4MP
Camera system
Size 126.9mm×95.7mm×60.3mm
Installation Built-in fixed type
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
10
Lens f5.6/35mm
Exposure system
Exposure interval ≤0.6s
Exposure mode Equal time/distance exposure
Power supply
Power supply mode Airborne unified power supply
Storage
Image storage format RAW，JPEG
Memory interface TF
Memory capacity 128GB
2.6.1.3 Sample aerial photograph
JOUAV ® series of surveying and mapping UAV system, which has the
original data are collected fast, high precision, simple operating system and
other advantages, complete the high accuracy and efficiency of the
photography data collection, through data post-processing, production for
construction planning of the DOM, DEM, DSM, DLG, etc.
2.6.2Multispectral camera
RedEdge-MX™ is a state-of-the-art, lightweight, UAV-mounted multispectral
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
11
imaging device with five separate imagers, each equipped with a special filter,
that allows each imager to receive spectrum in a precise wavelength range.
2.6.2.1 Provide you with more rich and accurate ground informationThe system can automatically precisely control the sensor according to
the requirements of the route parameters, so as to efficiently and accurately
obtain the image data of the region of interest. It has been widely used in the
fields of geology and mineral resources, ecological environment, inland water
body, agriculture, forestry, grassland, Marine, military and so on.
2.6.2.2 Technical data
RedEdge-MX Sensor
Spectrum band Blue, Green, Red, Red edge, Near infrared
Focal length 5.4 mm
View 47.2°HFOV
Sensor size 4.8 mm×3.6 mm
Sensor resolution 1280×960
Weight 170g (including DLS and cable)
Dimensions 9.4cm×6.3 cm×4.6cm
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
12
External power supply
4.2V DC-15.6V DC, 4W nominal value, 8W peak
value
RGB color output Global shutter, aligned with all bands
Spatial resolution 8cm per pixel at 120m AGL (per band)
Imaging speed
Capture 1 per second(all frequencies) , 12 bits
RAW
Connector
Serial, 10/100/1000 Ethernet, mobile Wi-Fi,
external triggers, GPS, SDHC
Trigger option
Timer mode, Overlapping mode, External trigger
mode (PWM, GPIO, serial and Ethernet options),
manual capture mode
Digital camera
Model SONY®RX0
Pixel 15.3 MP
Lens Equivalent 24mm F4 ZEISS® lens
2.6.2.3 Multispectral sample
With cutting-edge technology for irradiance and solar angle
measurements, RedEdge-MX can provide more accurate and reliable data,
greatly improving the accuracy of radiation measurements and significantly
reducing post-processing time.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
13
2.7 GCS202 ground control station
GCS202 Technical Specifications
Input voltage 8～26V DC
Power ＜5W
Dimensions 238.15×117.8×61.5mm
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
14
Weight 557g
Storage environment -55～+85°C
Operating temperature -40～+70°C
Tracking channel GPS:L1 C/A L2 C/A、P；GLONASS:L1 C/A L2 C/A、P
Accuracy of positioning 1cm+1ppm
Storage capacity 8G Byte NAND Flash
Update rate 5Hz
Data storage time ≥200h
Data reading rate 128KB/s
Time 8h
2.8 CWCommander™ ground station software
CWCommander™ software is a ground station support command and control
software for JOUAV® series vertical take-off and landing fixed wing UAV. It can
realize the installation and configuration of flight control and navigation system,
online parameter adjustment, flight mission planning and real-time adjustment, flight
monitoring, data distribution, document playback and other functions.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
15
1) Flight mission management：New, Edit, Delete, Query and other streamline
operation flight for flight mission.
2) Simple route planning: with the automatic generation and calculation
function of CWCommander, customer only need to design and cover the task
area on the map, and the system will automatically calculate the flight waypoint
optimization according to relevant parameters. For complex terrain, polygonal
region can be set, and the software will automatically adjust the datum level
according to the elevation (* offline elevation data file is required for this
function).
3) Intelligent flight process control: If pre-flight inspection is completed and the
whole system meets the take-off condition, the take-off button will automatically
display and send the take-off instruction to the right slide take-off button. After
sliding the take-off button, route safety check will be carried out in the system to
ensure safety.
4) Quick response: UAV can be adjusted quickly during flight, including
hovering standby, change flight altitude with one key, etc.
2.9 JoPPS™ post-differential GNSS Data processing software
Adopt JoPPS™ post-differential GNSS processing software independently
developed by JOUAV to complete differential GNSS data calculation and provide
high-precision GNSS data solution results.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
16
2.10 Post processing software
2.10.1 DOM Software
2.10.1.1 Pix4Dmapper
Pix4Dmapper is a photogrammetric software developed by Pix4D
company, which can obtain point cloud, digital surface model (DSM), digital
elevation model (DEM), orthographic image (DOM) and other results from
images.
2.10.2 Mapping software
2.10.2.1 EPS3D Survey 3D mapping system
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
17
EPS3D Survey 3D mapping system is a product developed based on
EPS geographic information workstation. It provides based on orthogonal
projection (DOM), real 3D model (osgb, dae will work, obj, dsm, etc.), slanted
image (JPG), point cloud data (Ground laser scanning, Airborne laser
scanning LiDAR, measuring vehicle, UAV, etc.) of the 2D or 3D acquisition
editing tools, support for large data browsing and collecting and editing data
base integration, provide property, geographical conditions and other
professional application solutions.
Main function:
1) Source data mapping based on orthograph DOM and real scene surface
model.
2) Real 3D model and source data measurement based on slanted image.
3) Based on various ground laser scanning, airborne LiDAR, measurement
vehicle, UAV and other point cloud and panoramic photo data measurement.
2.10.2.2 Mapmatrix multiple geographic data integrated processing
system
MapMatrix is a widely used digital photogrammetry product, which uses
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
18
vertical photographic aerial images to produce standard basic mapping
products such as digital orthography DOM, DLG, DEM, DSM, etc.
Main function:
1) Stereoscopic mapping, stereoscopic display, stereoscopic collection and
editing
2) DEM processing, including browsing, clipping, format conversion, 2D and
3D editing.
3) Match each pixel, generating high-precision DSM.
2.11 JOUAV cloud location service
JOUAV cloud global location service is a one-to-one cloud service platform
based on cloud computing for global location data intelligent matching, access,
storage, calculation and invocation.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
19
1) No need Base station: No need to set up a base station, not restricted by mobile
communication or network communication in the operating area
2) Cloud computing: Cloud computing technology based on PPK and network RTK
fusion, and integrated expert support.
3) High precision: The operating accuracy is not limited by the range of action of
RTK, and is not limited by the distance between the aircraft and the guidance
station.
4) Large area: Not restricted by the size and shape of the test area, not restricted by
the communication range between the aircraft and the guidance station.
3. Work flow
The basic process of aerial survey and data production for CW-007 is as follows:
5) Aerial survey program design and flight mission planning.
6) Site survey.
7) Aerial survey flight. Depending on the task, it can carry multi-spectral camera.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
20
8) Photo control measurement.
9) Data post processing, according to the project requirements to produce the
required data results.
As shown below:
Verticalphotographic data were processed by Pix4Dmapper, and oblique
photographic data were processed by ContextCapture software. Completed aerial
triangulation, obtained DSM, DEM, DOM, 3D model and other results, and used
MapMatrix stereoscopic mapping or EPS naked eye mapping to produce DLG results.
4. Training, After-sales service
4.1 UAV academy
In order to meet the needs of JOUAV® UAV product test flight, delivery,
customer training, civil UAV pilot training, etc., we mobilize more than 100
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
21
professional technical and management personnel in Beichuan.
4.1.1Provide UAV pilot training for customers
After continuous upgrading, the institute has formed the perfect theoretical
teaching, laws and regulations, payload use, practice flight training topics such as
system solutions, pilot's license training for trainees, and JOUAV® UAV using
training, as well as oblique photography, real-time monitoring, LiDAR system
training courses.
4.1.2 Our advantage
JOUAV® strictly abides by various UAV laws and regulations, and
establishes a dedicated airspace management department to regulate the
application and use of the company's airspace. JOUAV® UAV system has a
complete operation and maintenance course to help customers learn how to use
the UAV correctly and how to maintain it to keep it in the best working condition.
National-level (Beichuan) Aviation Flight Camp in Beichuan County, Mianyang City, Sichuan Province
Training of product delivery Training of civilian UAV pilots
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
22
“Your needs are the core of our
business, and the practicality of training
services and solutions makes us closer
to users.”
4.2 After-sales service and technical support
We are committed to ensuring that every customer can get timely and
professional technical support. Our technical support range includes not only UAV,
FC products, software, payloads and accessories, but also various internal services.
Technical Support
Service
JOUAV® engineers can provide customers with remote
product installation guidance, software updates, and
UAV flight technical support services, they can also
arrive at the scene to provide customers with services
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
23
such as operation debugging, maintenance and repair,
fault clearance, and technical upgrades.
Free repair /
replacement service
within warranty
For products that fail during the product warranty period,
we will provide you with free repair services for some
parts that meet the free repair conditions, and for parts
that meet the replacement conditions, we will replace a
brand new product with complete functions.
Accessories sales
services
To provide accessories for mainstream products,
through the selection of fast and professional logistics
transportation, to ensure that the accessories are
accurate, intact and quickly delivered to customers.
After-sales repair
service
For products returned to the factory for repair, we
provide a complete after-sales repair service chain to
ensure that the products returned to the factory are
repaired quickly and without errors and delivered to
customers.
You may also have other legal rights, depending on the applicable law in your country or
jurisdiction. Depending on the written agreement you signed with JOUAV, you may also have other
rights. Nothing in this warranty statement affects statutory rights that cannot be waived or restricted by
contract, including the rights granted to consumers by laws or regulations that regulate the sale of
consumer products. For after-sales service policy, please refer to <JOUAVAfter-sales Service Terms>.
This after-sales service policy only applies to mainland China, other countries and regions are
subject to local after-sales service policies and laws and regulations.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
24
5. Introduction of JOUAV
JOUAV, established in 2010, is a high-tech enterprise, president unit of Chengdu UAV
Industry Association, and an outstanding private enterprise in Sichuan Province. The
company focuses on the research, development, production, sales and service of
industrial drone-related products. It is committed to providing customers with intelligent,
standardized, and tool-based industrial drone systems. It is a leading industrial scale with
the most market competitiveness in China.
In order to meet the growing market demand, JOUAV® is building a manufacturing base in Tianfu
new district, Chengdu. JOUAV will carry out research on the core and key technologies of UAV in
the base and build an industrial base of UAV with international advanced level.
Technology is leading the change
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
25
10 Year 2000+set 1000+Customers
R&D, Design and
Manufacturing experience
Quantity of all kinds of UAV
and flight control system
JOUAV®Total number of
customers served
CHENGDU JOUAV DAPENG TECH CO., LTD 丨Wholly-owned subsidiary
Founded in 2015
Relying on the technical accumulation of the parent company in the field of UAV
flight control and navigation for many years, it makes full use of its own advantages of
deep customization and integration of flight control, and focuses on the R&D and sales of
vertical take-off and landing fixed wing UAV products of JOUAV® series. The company
launched and mass-produced VTOL fixed-wing industrial UAV in 2015. Currently, it
occupies more than 50% of the market share in the VTOL fixed-wing industrial UAV field
*.
* Data source: According to Frost & Sullivan's "Industrial UAV Industry Research Report" report, in
2019 the company ranked second in China's industrial UAV market share, including more than 50% of
the vertical take-off and landing fixed-wing industrial UAV market share.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
26
Manufacturing Base B9, Shuangliu County, Chengdu
JOUAV adheres to the business philosophy of "technical innovation, aviation quality,
and service first", adheres to the core value of "customer-centric and striver-oriented",
implements the overall strategy of focusing on advantages and steadily expanding,
focusing on vertical take-off and landing fixed wings The development of UAV systems
and supporting products, and under the catalysis of 5G, artificial intelligence and other
new technologies, continue to define and expand the application scenarios of industrial
drones, deepen the market of industrial drones, continuously expand the market scale,
and consolidate Industry leading position.
5.1 Main business
Since its establishment, the company has focused on the development,
production, sales and service of industrial UAV-related products. It is committed to
providing customers with intelligent, standardized and tool-oriented industrial drone
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
27
systems. JOUAV takes VTOL fixed-wing UAV systems as its core products, and
currently has seven series of verticals, namely CW-007, CW-10, CW-15, CW-20,
CW-25, CW-30 and CW-100, the maximum take-off weight covers 6.8 ~ 105 kg, flight
time covers 1 ~ 8 hours, products are widely used in surveying and mapping and
geographic information, patrol inspection, security monitoring,emergency and other
fields, the main customers in the reporting period Including the National Basic
Geographic Information Center, surveying and mapping institutes of various
provinces and cities, CHCNAV, SOUTH, State Grid, China Southern Power Grid,
China Earthquake Administration, China Flight Test Research Institute and other
well-known enterprises and institutions and research institutes.
5.2 Aircraft platform design and manufacturing
JOUAV is one of the few industrial UAV companies that can systematically use
the professional aircraft design system, and has mastered the design methods of a
variety of layout aircraft including tail sitter type, tilting type, composite layout type,
distributed power type, etc. The overall design, aerodynamic layout optimization,
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
28
power matching and optimization, flight mechanics and operational stability control,
composite materials and other fields have deep talents and technical accumulation.
In 2015, the company took the lead in releasing and mass-producing vertical take-off
and landing fixed-wing industrial UAV in China, and included the new category of
"vertical take-off and landing fixed-wing UAV" into the category of industrial UAV. The
company's vertical take-off and landing fixed-wing UAV product adopts a fixed-wing
combined with four-rotor composite wing layout form, which combines high energy
efficiency and long flight time of the fixed-wing UAV, as well as multi-rotor UAV
vertical take-off and landing and can hover the advantages of the technology further
expand the application field of the industrial drone industry, and together with
multi-rotor UAV become the main layout form of industrial drones today.
5.3 Development of Flight Control Navigation System
The company has independent design and development capabilities for flight
control and navigation systems, ground command systems, and integrated avionics
systems. It has mastered cutting-edge control technologies such as total energy flight
control, neural network-based adaptive control, L1 model reference adaptive control,
and related products. It has the characteristics of high intelligence, high adaptability
and high reliability, and realizes the automatic adaptation of various aircraft types
such as fixed wing, helicopter, multi-rotor and flapping wing with a software and
hardware architecture. Almost no need to adjust the parameters to meet the full
autonomous flight control. The flight control and ground command system
independently developed by the company is applied to the flight test verification
platform of many major national aviation projects, including the multi-purpose light
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
29
amphibious aircraft Seagull 300 reduction ratio verification machine free flight stall /
spin test, and free flight test of scale reduction verification machine for large military
transport aircraft Y-20, full-flight test flight of next-generation civil passenger plane
reduction ratio verification machine "Sparrow B", civil flight C919 reduction ratio
verification machine free flight stall test, etc.
5.4 Integrated design and integration
The company has mastered the integrated design and optimization technology
covering flight control and avionics, mission load and aircraft. The company's UAV
system adopts software and hardware common / shared architecture design,
standard electromechanical interface design, multi-data fusion and application,
multi-system collaborative comprehensive optimization design and other methods to
achieve structural weight, loading space, aerodynamic force, transmission
bandwidth, energy, etc. The efficient use of resources, while ensuring the maximum
effectiveness of the system, improves the integrity, compatibility, and scalability of the
system, and embodies advantages in cost control, independent technology control,
and diversified applications. The company currently has the ability to provide
industrial drone products and services to customers in diverse applications and in
multiple fields.
CHENGDU JOUAV DAPENG TECH CO., LTD
3A-8F, Jingrong Innovation Hub, No.200,5thTianFu St., Hi-tech District, Chengdu, Sichuan
Province, China 610041
30
5.5 Rooted in the local, facing the world
The company bases in the Sichuan headquarters, has a perfect market network
and service system, and provides professional and comprehensive product support
to customers in various regions at home and abroad. The company has established
five industry application divisions to meet the diverse needs of global customers. The
marketing center has realized a regional layout, and established seven marketing
areas divided into northern, central, eastern, southern, western, Xinjiang, and
overseas to provide comprehensive services to global customers.
Company headquarters 3A-8F, Jingronghui, Chengdu High-tech Zone
In the future, our goals will remain unchanged:
Let UAV be used in various industries as a basic tool.
	April, 2020
	Disclaimer
	1.Overview
	2.CW-007 UAV aerial survey system
	2.1Platform
	2.2Test Report
	2.3Technical data
	2.4Main Features
	2.5POS system
	2.6Airborne sensor
	2.6.1CA102™ aerial camera
	2.6.1.1Solid, lightweight, reliable design
	2.6.1.2Technical data
	2.6.1.3Sample aerial photograph
	2.6.2Multispectral camera
	2.6.2.1Provide you with more rich and accurate ground inf
	2.6.2.2Technical data
	2.6.2.3Multispectral sample
	2.7GCS202 ground control station
	2.8CWCommander™ ground station software
	2.9JoPPS™ post-differential GNSS Data processing soft
	2.10Post processing software
	2.10.1DOM Software
	2.10.1.1Pix4Dmapper
	2.10.2Mapping software
	2.10.2.1EPS3D Survey 3D mapping system
	2.10.2.2Mapmatrix multiple geographic data integrated proc
	2.11JOUAV cloud location service
	3.Work flow
	4.Training, After-sales service
	4.1UAV academy
	4.1.1Provide UAV pilot training for customers
	4.1.2我
	4.1.2 Our advantage
	4.2After-sales service and technical support
	5.Introduction of JOUAV
	5.1Main business
	5.2Aircraft platform design and manufacturing
	5.3Development of Flight Control Navigation System
	5.4Integrated design and integration
	5.5Rooted in the local, facing the world
