siemens.com/sitrain

SITRAIN
Digital Industry Academy
IK-TIAPN
Industrial Communications
PROFINET with Industrial Ethernet in TIA Portal
IK-TIAPN
Industrial Communications
PROFINET with Industrial Ethernet in TIA Portal







SITRAIN
Training for Industry


Industrial
Communication
PROFINET with Industrial
Ethernet in TIA Portal

Course IK-TIAPN
1 Communication with SIMATIC
2 Basics of Industrial Ethernet
3 Basics of PROFINET
4 Network Components
5 PROFINET Configuration
6 Topology Editor
7 Diagnostics
8 Web Services for PROFINET
9 Ring Redundancy MRP
10 Shared Device
Name:


Course from: to:


Instructor:


Location:



This document was produced for training purposes.
SIEMENS assumes no responsibility for its contents.
The reproduction, transmission or use of this document or its
contents is not permitted without express written authority.
Offenders will be liable to damages.

Copyright © Siemens AG 2018. All rights, including rights
created by patent grant or registration of a utility model or
design, are reserved.



SITRAIN course offer on the internet:www.siemens.com/sitrain

Version: V15.01.00 (for TIA Portal V15.1)

11 I-Device
12
PROFINET IRT & Isochronous
Mode & Oversampling

13 Gateways
14
Communication Possibilities in
TIA Portal

15 S7 Communication
16 Open User Communication – OUC
17 OPC UA
18
Appendix:
Diagnostics and Commissioning
Tools

19 Training and Support
20

Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-1

Contents 1





1. Communication in the SIMATIC World ................................................................. 1-2
1.1. Communication in a Factory ................................................................................................. 1-3
1.2. Subnets in SIMATIC ............................................................................................................. 1-4
1.3. Industrial Ethernet ................................................................................................................. 1-6
1.4. Industrial Wireless Communication....................................................................................... 1-7
1.4.1. IWLAN – Industrial Wireless LAN ......................................................................................... 1-8
1.4.2. IWLAN and WirelessHART ................................................................................................... 1-9
1.4.3. Teleservice (Remote Diagnostics and Remote Maintenance) with SIMATIC
Teleservice .......................................................................................................................... 1-10
1.5. PROFINET IO ..................................................................................................................... 1-11
1.6. IT Standards & Security ...................................................................................................... 1-12
1.7. Actuator - Sensor Interface ................................................................................................. 1-13
1.8. IO-Link ................................................................................................................................. 1-14
1.9. Gateways ............................................................................................................................ 1-15
1.10. Additional Information ......................................................................................................... 1-16
1.10.1. PROFIBUS .......................................................................................................................... 1-17
1.10.2. EIB, European Installation Bus (KNX) in Building Automation ........................................... 1-18


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-2 Training Document, V15.01.00
1. Communication in the SIMATIC World


SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... get an idea of communication in automation
... be familiar with the different communication media
... get an introduction to communication in the factory
... know what the four large subnets in SIMATIC are
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-3
1.1. Communication in a Factory

Management Level / Operations Level
Higher-level tasks that concern the overall operation are handled at the management level
(management functions). These tasks include the storage of process values as well as
processing functions for optimization and analysis and their output in report form. The data
required for this is collected and processed for the whole site. Other sites can also be accessed
from the management level. The number of devices can exceed 1000.
Control Level / Cell Level
All automation and optimization tasks are handled autonomously at the cell level. Programmable
controllers, PCs and devices for operator control and monitoring are connected to one another at
the cell level.
Field Level
The field level is the link between the systems and the programmable controllers. The field
devices measure, signal and forward the commands of the cell level to the systems. Small
amounts of data are transmitted in most cases. Hierarchical communication is typical, that is,
several field devices communicate with one master.
Actuator-Sensor Level
At this level, a master communicates with the actuators and sensors connected to its subnet. Fast
response times for a few data bits are characteristic for this level.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 3 Siemens AG © 2016
Communication in a Factory
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-4 Training Document, V15.01.00
1.2. Subnets in SIMATIC

Industrial Ethernet (IEEE 802.3)
Industrial Ethernet, the international standard for area networking is currently the number one
network in the LAN environment with a share of over 90%. Industrial Ethernet enables powerful
communication networks to be set up over wide areas. On the basis of global wireless standards,
e.g. IEEE 802.11a/b/g/n, GSM, GPRS or UMTS (3G), reliable wireless networks can be set up in
the industrial environment.
PROFINET (IEC 61158/61784)
PROFINET, the international standard uses Industrial Ethernet and enables real-time
communication down to the field level. With the full utilization of existing IT standards, PROFINET
enables high-performance motion control applications, efficient cross-manufacturer engineering
and high machine and plant availability on Industrial Ethernet. Due to its flexibility, PROFINET
offers new options for system design, such as the use of any topology and fail-safe networks,
even via wireless connections.
PROFIBUS (IEC 61158/61784)
PROFIBUS, the international standard for the field level is the global market leader among
fieldbus systems. It is the only fieldbus to allow communication both in manufacturing applications
and in process-oriented applications.
AS-Interface (IEC62026/EN 50295)
AS-Interface is the international standard which, as an economical alternative to the cable
harness, links sensors and actuators by means of a two-wire cable.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 4 Siemens AG © 2016
Subnets in SIMATIC
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document,V15.01.00 1-5
IO-Link
IO-Link is the standard for intelligently connecting sensors, RFID systems and actuators from the
field level to the control level.
Gateways
Gateways are realized using controllers or links. Configuration and diagnostics can be performed
from any point in the system.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-6 Training Document, V15.01.00
1.3. Industrial Ethernet

Industrial Ethernet
Industrial Ethernet is based on the IEEE 802.3 and IEEE 802.11 standards and enables
connection of your automation system to your office networks.
Industrial Ethernet provides information technology (IT) services with which you can access
production data from the office environment and work with the data.
Due to the uniform standard and the standardization of Industrial Ethernet, a smooth transition to
the office environment is possible. This coupling occurs with the help of network components
such as switches, routers or similar.
Compared to the “normal” Ethernet, Industrial Ethernet is subjected to higher requirements.
Industrial Ethernet components therefore also usually have a higher protection class or similar
functionalities, for example.

SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 5 Siemens AG © 2016
Industrial Ethernet
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-7
1.4. Industrial Wireless Communication

Industrial Wireless Communication
Within the scope of industrial communication, wireless communication opens up new prospects –
from partial modernization of a plant to optimization of complex logistics or production processes.
With Industrial Wireless Telecontrol, Industrial Wireless LAN and WirelessHART as a basis,
Siemens offers solutions for reliable automation with Industrial Wireless Communication.
Wireless solutions are increasingly becoming a matter of course in machines and plants. For
stringent data communication requirements, Industrial Wireless LAN (IWLAN) relies on
innovations such as deterministic radio and the PROFINET Industrial Ethernet standard. Through
the use of PROFIsafe via IWLAN, PROFINET opens up completely new prospects – from
efficient engineering and real-time solutions to safety-related tasks. Furthermore, an IWLAN
infrastructure can also be used for additional applications such as video monitoring.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 6 Siemens AG © 2016
Industrial Wireless Communication
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-8 Training Document, V15.01.00
1.4.1. IWLAN – Industrial Wireless LAN

Industrial Wireless LAN
Wireless solutions are increasingly becoming a matter of course in machines and plants. For
stringent data communication requirements, Industrial Wireless LAN (IWLAN) relies on
innovations such as deterministic radio and the PROFINET Industrial Ethernet standard. Through
the use of PROFIsafe via IWLAN, PROFINET opens up completely new prospects – from
efficient engineering and real-time solutions to safety-related tasks. Furthermore, an IWLAN
infrastructure can also be used for additional applications such as video monitoring.
In summary, extensions of the IEEE 802.11 standard are made available with Industrial Wireless
LAN which address the requirements of industrial customers, in particular, with regard to
deterministic and redundancy (iFeatures). This gives customers a single radio network for
process-critical data (e.g. I/O communication, safety-related communication) and for non-critical
communication (e.g. service and diagnostics).

SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 7 Siemens AG © 2016
IWLAN – Industrial Wireless LAN
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-9
1.4.2. IWLAN and WirelessHART

WirelessHART
WirelessHART is an open industry standard, developed for the particular requirements of wireless
communication at the field level in the process industry. It meets all specific requirements for
reliability, security, cost-effectiveness and user-friendly operation. WirelessHART opens up new
communication options that were previously impracticable or impossible due to the operating
environment or for economic reasons.
SCALANCE W
SCALANCE W provides IWLAN access points, client modules and an IWLAN controller for setup
of the wireless infrastructure and connection of terminals in the industrial environment. The
products provide the unique combination of reliability, robustness and security. SCALANCE W
IWLAN components and the resulting possible PROFINET communication provides a wireless
solution for applications down to the field level.
The reliability of the radio channel is extended in a dust-free and water-tight design (IP65) of the
robust enclosure meeting the stringent requirements for mechanical stability for which SIMATIC is
known. Modern security mechanisms for user identification (authentication) and data encryption
provide protection against unauthorized access and can be integrated in existing security policies
without any problems.
The RCoax cables provide a wear-free and reliable radio link, especially for conveyor systems,
robots and rail-guided vehicles of any type.

SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 8 Siemens AG © 2016
IWLAN and WirelessHART
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-10 Training Document, V15.01.00
1.4.3. Teleservice (Remote Diagnostics and Remote Maintenance) with SIMATIC
Teleservice

Teleservice
Remote diagnostics and remote maintenance of production plants have become indispensable in
modern automation technology. They are more efficient and more cost-effective than on-site visits
by a service employee. This allows malfunctions to be detected and corrected much faster.
Downtimes of machines are reduced and their availability is increased.
Machines and plants are increasingly operated in places that are far away from the place of
manufacture. Plant manufacturers must nevertheless be able to guarantee services in case of
malfunctions. During the warranty period, in particular, this can result in high costs. Teleservice
helps to reduce this risk significantly. The possible applications for Teleservice are manifold.
Plants can be diagnosed, values set and data transmitted from anywhere in the world via
telephone lines.
Teleservice also enables the sending of text messages per SMS or e-mail by SIMATIC
controllers, thereby contributing significantly to savings in travel and personnel cost due to fewer
service visits. In the case of remote Teleservice connections, a distinction is made between
remote maintenance and remote connection.
Remote Maintenance
Remote maintenance permits access to a CPU with STEP 7 or an HMI device via WinCC. For
remote maintenance, a technician dials into a remote system by telephone. STEP 7 can be used
to read status information or to correct the user program remotely.
Remote Connection
Remote connection refers to a connection for data transmission. Remote connections are used to
transmit data over the telephone network. Teleservice supports the program-controlled
establishment of a connection between the PG or PC and automation system. Process data
exchange between several automation systems can also be coordinated.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 9 Siemens AG © 2016
Teleservice (Remote Diagnostics
and Remote Maintenance) with SIMATIC Teleservice
Industrial Communication, PROFINET with Industrial Ethernet inthe TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-11
1.5. PROFINET IO

PROFINET IO
PROFINET enables the integration of distributed field devices (IO-Devices such as
signal modules) directly in Industrial Ethernet. With the tried-and-tested configuration with STEP
7, these field devices are assigned to a central controller (the so-called IO-Controller). Existing
modules or devices can continue to be used with PROFINET-capable interfaces or links, which
safeguards the existing investments of PROFIBUS and AS-Interface users. A configuration with
standard and fail-safe modules in one station is also possible. An IO-Supervisor is used for HMI
and diagnostics purposes by means of hierarchical diagnostic screens (Overview and Detailed
diagnostic). User data is transferred via real-time communication. Configuration and diagnostic
data is transferred using TCP/IP or IT standards. The easy tried-and-tested engineering approach
for PROFIBUS has been adopted for PROFINET. From the viewpoint of programming with STEP
7, it does not matter if an I/O device is being accessed via PROFIBUS or PROFINET.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 10 Siemens AG © 2016
PROFINET IO
IO-Device
PN/PN-Coupler
PROFINET IO 3
PROFINET IO 2
I-Device
PROFINET IO 1
IO-Controller IO-Controller
I-Device
IO-Controller
I-Device
IO-Device IO-Device I-Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-12 Training Document, V15.01.00
1.6. IT Standards & Security

IT Standards & Security
With Industrial Ethernet as its basis, PROFINET not only offers scalable real-time communication,
but also standard TCP/IP communication according to IEEE 802.3 – with no compromises. This is
the basis for integrated horizontal and vertical networking, whether wired or wireless. Accordingly,
pioneering functions and established IT standards for network management, network diagnostics,
web services, security and the connection of higher-level Gigabit networks are supported by
PROFINET without any restrictions.
Network Management
Vis-à-vis fieldbuses, Ethernet in conjunction with TCP/IP and UDP/IP offers additional options for
network management. The aspects of network infrastructure, IP management, network
diagnostics and time synchronization are components of the integrated network management. It
simplifies the administration and management of Ethernet – through the use of standard protocols
from the IT world.
Industrial Security
As Ethernet networks have found their way down to the field level, this has enabled an integrated
networking of all automation levels – as well as the direct connection to office networks and the
Internet. However, this also means that production networks are exposed to the same risks as
office networks – incorrect internal accesses and external attacks. Even a brief failure or minor
malfunction can bring production to a standstill and cause massive damage. The automation
technology therefore needs a security concept that reliably protects the production networks and
automation components and is perfectly tailored to the particular requirements. Protection
concepts are:
• Access protection to automation cells (cell protection concept)
• Protection against espionage and manipulation
• Secure remote accesses via unsecure networks
These security objectives can be achieved through the use of PROFINET security components
such as SCALANCE S.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 11 Siemens AG © 2016
IT Standards & Security
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-13
1.7. Actuator - Sensor Interface

Actuator - Sensor Interface
AS-Interface is an open, international standard based on EN 50295 and IEC 62026-2 for process
and field communication. Worldwide, leading manufacturers of actuators and sensors support
AS-Interface. The AS-Interface is a single master system. For automation systems from Siemens,
there are communication processors (CPs) and gateways (Links) which act as master to control
the process and field communication, as well as sensors and actuators which are addressed as
AS-Interface slaves.
SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 12 Siemens AG © 2016
Actuator - Sensor Interface, ASI-Bus
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-14 Training Document, V15.01.00
1.8. IO-Link

IO-LINK
IO-Link is the smart concept for the standardized linking of switching devices and sensors to the
control level by means of an economical point-to-point connection.
The new IO-Link communication standard below the fieldbus level enables central error
diagnostics and localization down to the actuator/sensor level and facilitates both commissioning
and maintenance by allowing parameter data to be modified dynamically, direct from the
application.
The increasing intelligence of field devices and their integration in the overall automation enables
data access down to the lowest field level. The result: higher system availability and reduced
engineering effort.
As an open interface, IO-Link can be integrated into all common fieldbus and automation
systems. Consistent interoperability ensures maximum protection of investment. This also applies
in the context of existing machine concepts for continued use of sensors that have no IO-Link
interface.

SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 13 Siemens AG © 2016
IO-Link
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-15
1.9. Gateways

Gateways
Gateways from one bus system to another are realized using links, controllers (PLCs) or PCs. In
the case of PLCs or PCs, integrated interfaces and communication processors (CPs) can be
used for this. Links forward the data autonomously from one network to the other.
Links
Some of the most common links are listed below:
• IE/PB Link and IE/PB Link PN IO for the transition from Industrial Ethernet to
PROFIBUS (also for fail-safe communication)
• IE/AS-i LINK PN IO for the transition from Industrial Ethernet to AS-Interface
• IWLAN/PB Link PN IO for the transition from IWLAN to PROFIBUS
• PN/PN Coupler for the coupling of two PROFINET networks
• PB DP/PB DP and PB DP/PB PA for coupling DP/DP and DP/PA networks
• DP/AS-i LINK Advanced and DP/AS-Interface Link 20E for the transition
from PROFIBUS to AS-Interface
• DP/EIB Link for the transition from PROFIBUS to KNX/EIB


SITRAIN
IK-TIAPN / Communication in the SIMATIC World Page 14 Siemens AG © 2016
Gateways
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-16 Training Document, V15.01.00
1.10. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 50 Siemens AG © 2016
Additional Information
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Communication in the SIMATIC World
Training Document, V15.01.00 1-17
1.10.1. PROFIBUS

PROFIBUS
PROFIBUS is a bus system for process and field communication in cell networks with a small
number of nodes, with field devices and for data communication compliant with IEC 61 158 /
EN 50170. It is open for the connection of components of other manufacturers that conform to the
standards:
• PROFIBUS DP: for fast, cyclic data exchange with field devices
• PROFIBUS PA: for applications in process automation and in the intrinsically-safearea
• Data communication: PROFIBUS FDL and for data communication between
 programmable controllers of different manufacturers
PROFIBUS Medium
The simple and cost-effective two-wire RS 485 transmission technology is exceptionally suitable
for networks with a linear/tree structure and high data transmission rates. The total size of the
network is smaller than with an optical network, but can also reach distances up to 1 km (at 12
Mbit/s) or up to 10 km (at 187.5 Kbit/s) through segmentation and signal regeneration with up to 9
repeaters. Instead of standard repeaters, it is also possible to use diagnostic repeaters, which not
only handle the signal regeneration but also the online monitoring of the connected bus segment.
A segment can have up to 32 nodes (master/slaves) and the entire network up to 126 nodes. The
start and end of each segment must be fitted with an active cable termination that is either
already integrated in the device (e.g. repeater) or is available as an active RS 485 terminating
element.
Note
On the Service & Support pages it is possible to download the “SIMATIC PROFIBUS PROFIBUS
with STEP 7 V13” manual. This can be found in the Publication number: 59193579.

SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Communication with SIMATIC
PROFIBUS
Entry ID: 59193579
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Communication in the SIMATIC World
1-18 Training Document, V15.01.00
1.10.2. EIB, European Installation Bus (KNX) in Building Automation

EIB / KNX
The EIB (European Installation Bus) is now commonly used especially in Europe for building
management systems. It is supported by many representatives of the electrical and building
services automation sector who have come together under the auspices of the European
Installation Bus Association (EIBA). A defined standard interface allows products from different
vendors to be used in a common installation.
One of the objectives of the EIB technology is to control all operational functions and processes in
a building by means of a common bus cable. A twisted pair bus cable is looped through the
building for the control. In addition to transmitting the control message frames, this bus cable also
transmits the 24 V supply for the bus nodes. EIB is a distributed, event-driven serial bus system
based on CSMA/CA. It is used to acquire, control, monitor and signal all operational functions in a
building or large facility.

SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Communication with SIMATIC
EIB, European Installation Bus (KNX) in
Building Automation
EIB-buttons
DP/EIB Link
Powerline
Bus coupler
Powerline
Coupler
Powerline 230 V
DriveWind sensor
EIB-binary-
input-modules
KNX
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-1

Contents 2





2. Basics of Industrial Ethernet ................................................................................. 2-3
2.1. In the Beginning there was Ether .......................................................................................... 2-4
2.2. The Historical Development of Industrial Ethernet ............................................................... 2-6
2.3. Horizontal Levels of Industrial Automation ........................................................................... 2-8
2.4. Why Ethernet in the Industrial Environment ......................................................................... 2-9
2.5. Advantages of Ethernet in the Industrial Environment........................................................ 2-10
2.6. Comparison Industrial Ethernet → Office Ethernet ......................................................... 2-11
2.7. Industrial Ethernet Components ......................................................................................... 2-12
2.8. ISO / OSI 7 – Layer Model .................................................................................................. 2-13
2.8.1. Layer 1: Physical Layer ....................................................................................................... 2-15
2.8.2. Layer 2: Data Link Layer ..................................................................................................... 2-16
2.9. Ethernet in the OSI Model ................................................................................................... 2-18
2.9.1. Ethernet Specification of the Physical Layer ...................................................................... 2-19
2.9.2. The Ethernet Telegram in the Data Link Layer ................................................................... 2-20
2.10. MAC Address ...................................................................................................................... 2-22
2.11. IP Address V4 / Internet Protocol Address Version 4 ......................................................... 2-23
2.12. Subnet Mask ....................................................................................................................... 2-24
2.13. Network Address ................................................................................................................. 2-25
2.13.1. Additional Network Address ................................................................................................ 2-26
2.14. Addresses of a Network ...................................................................................................... 2-27
2.15. Subnetting / Supernetting ................................................................................................... 2-28
2.16. Calculation of IP Ranges - Classic...................................................................................... 2-29
2.17. Calculation of IP Ranges - Alternative ................................................................................ 2-30
2.18. Alternative Calculation of Device Addresses ...................................................................... 2-31
2.19. PING / Packet Internet Groper ............................................................................................ 2-32
2.20. Task Description: IP Addresses and Subnet Masks .......................................................... 2-33
2.20.1. Exercise 1: Calculating with IP Addresses ......................................................................... 2-34
2.20.2. Exercise 2: Subnetting ........................................................................................................ 2-35
2.21. Access Procedure for Industrial Ethernet: CSMA/CD......................................................... 2-36
2.22. Duplex Mode ....................................................................................................................... 2-37
2.23. Types of Telegrams in Ethernet .......................................................................................... 2-38
2.24. Ethernet HUB ...................................................................................................................... 2-39
2.25. Shared LAN  → Switched LAN ........................................................................................ 2-40
2.26. Ethernet SWITCH ............................................................................................................... 2-41
2.27. Ethernet SWITCH Basics .................................................................................................... 2-42
2.27.1. Ethernet SWITCH Basics 1 ................................................................................................. 2-42
2.27.2. Ethernet SWITCH Basics 2 ................................................................................................. 2-43
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of IndustrialEthernet
2-2 Training Document, V15.01.00
2.27.3. Ethernet SWITCH Basics 3 ................................................................................................. 2-44
2.28. Switching Methods .............................................................................................................. 2-45
2.28.1. Store and Forward .............................................................................................................. 2-45
2.28.2. Cut Through ........................................................................................................................ 2-46
2.28.3. Fragment Free .................................................................................................................... 2-47
2.29. Switching Telegram Forwarding ......................................................................................... 2-48
2.29.1. Prioritization through the PCP ............................................................................................. 2-48
2.29.2. Processing Telegrams through Queues ............................................................................. 2-49
2.30. Task Description: Setting the Field PG IP Address and Resetting Devices to Factory Settings2-50
2.30.1. Exercise 3: Selecting the Field PG Ethernet Card ............................................................. 2-51
2.30.2. Exercise 4: Opening the Adapter Settings .......................................................................... 2-52
2.30.3. Exercise 5: Assigning the Field PG a Static IP Address ..................................................... 2-53
2.30.4. Exercise 6: Networking the Devices ................................................................................... 2-54
2.30.5. Exercise 7: Resetting the Devices to Factory Settings ....................................................... 2-55
2.31. Additional Information ......................................................................................................... 2-57
2.31.1. ISO / OSI 7 – Layer Model .................................................................................................. 2-58
2.31.1.1. Layer 1: Physical Layer ....................................................................................................... 2-60
2.31.1.2. Layer 2: Data Link Layer ..................................................................................................... 2-61
2.31.1.3. Layer 3: Network Layer ....................................................................................................... 2-63
2.31.1.4. Layer 4: Transport Layer ..................................................................................................... 2-64
2.31.1.5. Layer 5: Session Layer ....................................................................................................... 2-65
2.31.1.6. Layer 6: Presentation Layer ................................................................................................ 2-66
2.31.1.7. Layer 7: Application Layer .................................................................................................. 2-67
2.31.2. TRACERT / Trace Route .................................................................................................... 2-68
2.31.3. IP Address V6 ..................................................................................................................... 2-69
2.31.4. Special IP Area Ranges / IP Addresses ............................................................................. 2-70


Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-3
2. Basics of Industrial Ethernet


SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... be familiar with the history of Ethernet
... understand the difference between Ethernet and Industrial Ethernet
... basically understand Industrial Ethernet
... understand the structure of IP addresses and subnet masks
… be able to calculate with IP addresses and subnet masks
… understand the difference between Shared LAN and Switched LAN
and be able to explain it
… know the function of a Switch and how it works
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-4 Training Document, V15.01.00
2.1. In the Beginning there was Ether

Ethernet
Digital communication is an integral part of today’s world. The basis on which this digital
communication is even possible is, however, often forgotten: The Ethernet.
The “birth” of Ethernet is depicted in the picture. The most important facts with regard to Ethernet
are the following:
• The first mention of Ethernet was in 1973 in a memo from Robert Metcalfe.
• It was developed between 1973 and 1974. It was modeled on the former ALOHAnet.
• In 1975, Xerox PARC filed the patent for the Ethernet. As the developers involved, the
patent lists: Robert Metcalfe, Chuck Thacker, Butter Lampson and David Boggs.
• Starting in 1980, the Ethernet was further developed as Ethernet-Version 1 by the IEEE in
Working Group 802.
• The standardization of this bus system occurs in 1983 through IEEE 802.3.
• In 1985, SIEMENS launched the SINEC H1 bus system on the market - the Ethernet for
the industrial application and the predecessor of today’s SIMATIC NET Industrial Ethernet.
• International recognition was achieved in 1989 as the ISO/IEC/IEEE 8802-3
Standard for Ethernet was published.







SITRAIN
IK-TIAPN / Grundlagen Industrial Ethernet Seite 3 Siemens AG © 2016
Am Anfang war der Ether
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-5
Transmission Techniques
Starting in 1981, IEEE pursued three different techniques:
• CSMA/CD (802.3)
Carrier Sense Multiple Access / Collision Detection
• Token Bus (802.4)
• Token Ring (802.5)
While the Token Bus procedure was supported by General Motors and the Token Ring procedure
by IBM, the ECMA (European Computer Manufactures Association) supported the CSMA/CD
procedure.
In March 1982 their members agreed to support the procedure which was followed by the
recognition of the CSMA/CD 802.3 Standard in December 1982. This Standard was then
published in 1985.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-6 Training Document, V15.01.00
2.2. The Historical Development of Industrial Ethernet

SIEMENS Industrial Ethernet
After extensive investigations and the supplementing of the standard by an integrated shielding
and grounding concept, the suitability of Ethernet for industrial use was demonstrated.
In this industrial design, the bus system has captured the industry since 1985 as SINEC H1, the
predecessor of today’s SIMATIC NET Industrial Ethernet. The sceptics of the time, who deemed
a non-deterministic access procedure such as the CSMA/CD used for Ethernet as inappropriate
for industrial use, have been proven wrong by thousands of plants.
Since then, Industrial Ethernet has been consistently further developed. To increase the system
availability, the first redundant networks came into being at the end of the eighties through the
development of a dual Ethernet bus system.
With the advent of fiber optic cables, the shift of Ethernet as a bus system to a star-shaped
network began at the end of the eighties. Terminals were no longer connected by a commonly
used bus, rather, point-to-point via an active network component, the star coupler or hub. Greater
distances between devices became possible. Potential equilization or lightning protection
measures became redundant. This was the birth of the SINEC H1FO communicationsystem.
Particularly in the terminal connection area, “Twisted Pair” established itself in the mid 1990s as
the new transmission medium with which a higher connection density at lower connection costs
was achieved.
At the same time, the passive cabling technology for the transmission of data and voice were
standardized in the European standard EN 50173 “Generic cabling systems, 1995” and in the
international equivalent ISO/IEC 11801. Company networks were divided into primary area
(network between buildings), secondary area (building backbone) and tertiary area (network on
the floor). The tree-like network topology used primarily in the office area today emerged.
The first SIMATIC NET Industrial Ethernet Switches were introduced to the market at the end of
the 1990s. The OSM (Optical Switch Module) and ESM (Electrical Switch Module) were
specifically designed for use in the plant and terminal network of a process control system. They
were the first representatives of a new product group, the Control Level Switches.

Many properties of the Industrial Ethernet OLMs which were replaced almost completely by the
new switches in today’s plants, can be found once again in the Control Level Switches:
Optimized for use in compact control cabinets, DIN rail mounting, 0°C - 60°C ambient
temperature, 24V DC supply.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 4 Siemens AG © 2016
The Historical Development of Industrial Ethernet
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-7
Added to this was a considerably simplified network planning with an extensive structure (up to
50 switches can be cascaded), the increase of the transmission speed to 100 Mbit/s, a higher
number of ports per network component, a long distance variant for single distance lengths up to
26km with single-mode fiber optic cables as well as the remote diagnostics via the
SNMPStandard.
The systematic further development of FieldLevel Switches by SIMATIC NET brought the new
device generation with the product lines SCALANCE X-100 (unmanaged switches) and
SCALANCE X-200 (managed switches) onto the market in mid 2004. With a multitude of
electrical and optical connections as well as devices with high IP65 degree of protection and for
isochrones real-time, a suitable device variant is available here for every application.
PROFINET, the open standard for automation, goes one step further: real-time and IT
communication can be operated together on the same network. PROFINET is based on Industrial
Ethernet and enables the device interfacing from the field level up into the process management
level. In addition to the direct connection of distributed field devices, the intelligent terminals, to
Industrial Ethernet, isochronous Motion Control applications can also be realized.




 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-8 Training Document, V15.01.00
2.3. Horizontal Levels of Industrial Automation

Process Management Level / Data Management Level
The process management level, also called the data management level, is used to manage, to
archive and to visualize data as well as data sets from the control and field levels.
Control Level
The control level is responsible for the control and regulating of the plant and the process. Here,
the data from the field level comes together and is analyzed intrinsic to the plant section.
Field Level / Production Level
The task of the field level is to measure, position and switch the individual plant sections. Here,
the sensor and actuator data is read-in and processed.
Vertical Integration
Through the use of Industrial Ethernet, standard mechanisms of communication and information
technology such as OPC/XML along with standard protocols such as UDP/TCP/IP and HTTP can
be used in automation. This makes a transparent access directly to the data of the automation
systems in the control level and production level by the process management level of the
company possible.
The vertical integration of the individual horizontal levels is thereby extremely simplified!
Note
In a comprehensive integration, the company level is also integrated via the management level. It
can then communicate with the management level via the office Ethernet and exchange data.



SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Basics of Industrial Ethernet
Horizontal Levels of Industrial Automation
Process Management
Level
Control Level
Field Level
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-9
2.4. Why Ethernet in the Industrial Environment

Communication in the Industrial Environment
The demands on communication in the industrial environment are very different from those of
conventional office communication. This applies to almost all aspects of communication, such as,
active and passive network components, connected terminals, network concepts / network
topologies, availability, data volumes, ambient conditions, only to mention a few.
Likewise, there are network protocols specially optimized for industrial communication, even
though back then TCP/IP, a classic protocol in office communication, had entered into the
production and process control.
Industrial Ethernet – Designed for Industry
The basic idea of Industrial Ethernet is to use the existing standard (Ethernet network standard
IEE 802.3) and to supplement it by the necessary and useful details for industrial communication.
This results in products for the specific circumstances in the production and process control
environment.
Note
Unlike Ethernet, Industrial Ethernet is not a standard! That is why when different manufacturers
talk about Industrial Ethernet they may have different understandings of the specifications.

SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 6 Siemens AG © 2016
Why Ethernet in the Industrial Environment
◼ Ethernet is the leader in office networks
◼ PROFINET is the innovation of PROFIBUS
on the basis of Ethernet
◼ The Ethernet technology provides very high
innovative strength, such as, switching
technology, wireless communication, Gigabit,
Security,..
◼ Ethernet offers a variety of transmission media
(copper, fiber-optic, wireless communication)
as well as flexible network structures (star, ring
and line topologies)
◼ A large number of suppliers / manufacturers,
also for the industrial market
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-10 Training Document, V15.01.00
2.5. Advantages of Ethernet in the Industrial Environment

Advantages of Industrial Ethernet over other Fieldbuses
• Plant data and IT data can be transmitted almost simultaneously via one common
medium.
• A large address area with an almost unlimited number of devices (subscribers) is
available.
• Through a cascading of switches, large network expansions and a mixture of different
network structures can easily be realized.
• Larger amounts of data can be transmitted quickly and efficiently because of the
transmission rate of 100 Mbit/s.
• Future-proof due to Gigabit Ethernet.
• Equal bus access for all network participants is possible.
• Different transmission media (cable, wireless, fiber optic,…) can be combined.
• Simple integration of Internet technologies and protocols.
• The development of Industrial Ethernet profits from developments in the “office Ethernet”
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 7 Siemens AG © 2016
Advantages of Ethernet in the Industrial
Environment
Uniform network structure
◼ Fewer interfaces
◼ Plant-wide processing
◼ Easy to use
The advantages of Internet technologycan be used in production.
◼ Web services
◼ Remote access / maintenance
◼ Software updates
Further development of current systems
◼ Increasing performance
◼ Larger data volumes
◼ System integration down to the field level
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-11
2.6. Comparison Industrial Ethernet → Office Ethernet

Industrial Ethernet
The same Ethernet Standard is used both in industry and in the office. The requirements
concerning the network products used, however, differ considerably!
In everyday industrial use, networks must work reliably under extreme conditions, such as,
electromagnetic interference, high operating temperatures and mechanical stresses.
Network Products
In order to meet the high demands of industry, there are special Industrial Ethernet network
products. Many suppliers offer both passive as well as active network components which meet
the particular requirements of an industrial environment.

SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 8 Siemens AG © 2016
Comparison Industrial Ethernet → Office Ethernet
Industrial Ethernet Office Ethernet
Installation ▪System-dependent cabling and cable
bushing
▪Field assembly connectors up to IP67
▪Redundant cabling, frequently ring
structures
▪Fixed base installations in the building
▪Variable device connection to standard
work areas
▪Predominantly star-shaped cabling
Data ▪Small data packets
▪Very high network availability
▪Mainly cyclic transmission
▪Real-time performance necessary
▪Large data packets
▪Medium network availability
▪Mainly acyclic transmission
▪No real-time performance necessary
Environment ▪Expanded temperature range
▪Dust, moisture and vibration possible
▪Danger due to mechanical damage or
chemical load
▪High EMC load
▪Normal temperature range
▪Little dust, moisture and vibration
▪Very little mechanical or chemical load
▪Low EMC load
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-12 Training Document, V15.01.00
2.7. Industrial Ethernet Components

Industrial Ethernet Components
In the industrial environment, both the active as well as the passive components must withstand
much harsher ambient conditions than in the office world. This becomes perceptible in many
ways!
Industrial Ethernet components, active as well as passive, have a higher protection class, a more
rugged design, and, have integrated diagnostic LEDs, just to mention a few examples.
Note
The use of office Ethernet network products in the industrial environment is not recommended!

SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Basics of Industrial Ethernet
Industrial Ethernet Components
Easy exchange
Easy diagnostics (LEDs)
Easy exchange
Set – / Reset – button
Redundant power supply
Increased degree of
protection
Signal contact
Rugged design
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-13
2.8. ISO / OSI 7 – Layer Model

Open Systems Interconnection (OSI) – Model
The OSI – 7 Layer Model is a reference model for manufacturer-independent communication
systems, that is, a design basis for communication protocols and computer networks.
OSI stands for Open Systems Interconnection and was designed and standardized by ISO as the
basis for communication standards. The OSI layer model or OSI reference model is based on the
DoD layer model on which the Internet is based. In comparison to the DoD layer model, the OSI
layer model is more finely subdivided.
DoD layer model (Department of Defense):


The OSI model serves as a tool for describing the principle function of a network. It is divided into
seven sub-areas which are also referred to a layers. Each layer, with the exception of the
uppermost layers, makes its function available to the layers above it. The most important layers
for Ethernet are Layer 1 and Layer 2.

SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Basics of Industrial Ethernet
ISO / OSI 7 – Layer Model
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
Anwendungs-
orientiert
Transport-
orientiert
Transport-
orientiert
Transport-
orientiert
transport-oriented
Anwendungs-
orientiert
application-
oriented
7. Application Layer
6. Presentation Layer
5. Session Layer
4. Transport Layer
3. Network Layer
2. Data Link Layer
1. Physical Layer
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-14 Training Document, V15.01.00
For each layer, functions and protocols are defined which must fulfill specific tasks for the
communication between two systems. For communication between two systems, the
communication or the data flow passes through all 7 layers of the OSI layer model twice - once at
the Sender and once at the Recipient. Depending on how many ‘stops’ the communication route
has, the communication also passes through the layer model several times.
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-15
2.8.1. Layer 1: Physical Layer

Physical Layer
In the physical layer, the electrical, optical and mechanical connection to the transmission
medium used is defined. It is responsible for the proper transmission of individual bits through the
physical channel. This is essentially a matter of the coding of signals, the defining of the
transmission medium and the transmission devices.
Each medium has its own section.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 11 Siemens AG © 2016
Layer 1: Physical Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
1. Physical Layer:
Measures and procedures for transmitting bit sequences
▪ Devices and network components are assigned to the
Physical Layer
▪ Defines the optical, electrical and mechanical connection
to the transmission medium
▪ Manages the coding of the individual bits or the bit
sequences
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-16 Training Document, V15.01.00
2.8.2. Layer 2: Data Link Layer

Data Link Layer
In the data link layer, the transmission and the grouping of the individual bits in the transferable
unit as well as the access procedure to the network is defined. It provides a reliable connection
between terminal and transmission medium and ensures an error-free transmission.
For this, the bit data flow is divided into (data) blocks, also called frames, and checksums are
added. With this checksum, flawed blocks can be detected by the recipient and subsequently be
rejected or even be corrected.
According to IEEE, the Data Link Layer is divided into two sublayers - the Logical Link Control
and the Media Access Control. Due to the Media Access Control, the data link layer is sometimes
also called the MAC Layer.
Media Access Control
The Media Access Control layer is the lower of the two layers in the data link layer. It controls the
access to the transmission medium. It defines which protocol is to be used. There are two
different types of access, a controlled access and a competing access.
Controlled access:
• Token Ring
• Token Bus
• CSMA/CR
Competing access:
• ALOHA
• CSMA/CD
• CSMA/CA


SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 12 Siemens AG © 2016
Layer 2: Data Link Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
2. Data Link Layer:
Logical connections to data packets and elementary error
detectionmechanisms
▪ Consists of two sublayers, the Logical Link Control layer
as well as the Media Access Control layer
▪ Divides the bit data flow into blocks or frames and adds a
checksum
▪ Ensures a reliable and error-free transmission on the
transmission medium
Logical Link Control
Media Access Control
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-17
Logical Link Control
The Logical Link Control layer is the upper of the two layers in the data link layer. It adds several
identifiers to the data packet which are structured as follows:
• DSAP (Destination Service Access Point) of 8 bytes
• SSAP (Source Service Access Point) of 8 bytes
• Control of 8 or 16 bytes
Note
A renewed request of rejected blocks is not regulated or provided in the data link layer!
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-18 Training Document, V15.01.00
2.9. Ethernet in the OSI Model

Ethernet in the OSI – Layer Model
Referring to the OSI model, the Ethernet Standard describes Layer 1 as well as Layer 2. To be
more exact, the Ethernet Standard describes Layer 1 and Layer 2a since the Data Link layer is
divided into two sublayers of which only the Media Access Control layer belongs to the Ethernet
Standard.
The Ethernet Standard therefore summarizes both mechanisms and media of the Physical Layer
as well as the access to these in the Media Access Control in the Data Link Layer.
SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Basics of Industrial Ethernet
Ethernet in the OSI Model
Layers
Logical Link Control
Network
Transport
Application
Presentation
Session
2b
3
4
5
6
7
Ethernet based on
Layer 1 + Layer 2a
Physical
2a
1
Media Access Control
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-19
2.9.1. Ethernet Specification of the Physical Layer

Definition of the Medium
In the Physical Layer level, the different transmission media and the resulting data (en)coding are
described in Ethernet. Each medium has its own section in the Standard.
Notation of the Sections of the IEEE 802.3 for the Physical Layer
The notation of the sections can be divided into three parts:
• The transmission rate
• The transmission procedure
• The medium used
100BASE-TX, for example, means that you are working with a transmission rate of 100 Mbit/s
(100) with the baseband transmission (BASE) and a Twisted Pair Medium (TX).
These notations are not always 100% consistent but the transmission rate is always
recognizable.
SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
Basics of Industrial Ethernet
Ethernet Specification of the Physical Layer
100Base-TX
Transmission rate
Transmission procedure
Transmission medium
Typische
Standards
Teilbereich Übertragungsrate Medium
▪10Base5 ▪10 Mbit/s ▪Coaxial cable
▪10Base-T ▪10 Mbit/s ▪Twisted Pair cable (TP)
▪100Base-TX ▪100 Mbit/s ▪Twisted Pair cable (TP)
▪100Base-SX ▪100 Mbit/s ▪Fiber optics (short wave)
▪1000Base-T ▪1000 Mbit/s ▪Twisted Pair cable (TP)
▪1000Base-LX ▪1000 Mbit/s ▪Fiber optics (long wave)
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-20 Training Document, V15.01.00
2.9.2. The Ethernet Telegram in the Data Link Layer

Definition of the Access Procedure
The functional description of the Physical Layer is not enough to be able to targetedly transmit
data. Only with the definitions on the MAC level of the Data Link Layer does it become possible to
transmit data and the targeted sending of data within a network. The Ethernet Standard describes
the access procedure with collision detection and how to proceed after a collision occurs on the
MAC-Layer level.
Definition of the Frame Format and the Addressing
Beyond that, the Frame Format, that is the telegram structure of an Ethernet telegram, and the
addressing scheme are described. This is necessary to guarantee uniform data processing.
The Ethernet Telegram
The Ethernet telegram is standardized according to IEEE802.3 and is therefore subject to a fixed
structure:
• Preamble:
The preamble consists of a 7 byte long alternating bit sequence: “101010…1010”, also
called a 10s-series. This is followed by the 1 byte long SFD - the Start Frame Delimiter,
with the bit sequence: “10101011”.
In the past, these 8 bytes were used for the bit synchronization of the different network
devices. With today’s network components and the contemporary network topologies,
this synchronization process is actually no longer necessary and is now only found in the
specification for compatibility reasons.
• Destination Address / Destination – MAC – Address:
The MAC address of the network station which is to receive the data is stored in the 6
bytes of the Destination Address.
• Source Address / Source – MAC – Address:
The MAC address of the network station, which has sent the data to the destination
address is found in the 6 bytes of the Source Address.

SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
Basics of Industrial Ethernet
The Ethernet Telegram in the Data Link Layer
Not part of the
Ethernet telegram
Ethernet Telegram according to IEEE802.3 (64 bytes to 1518 bytes)
with VLAN Tag maximum 1522 bytes
Preamble SFD Destination
Address
Source
Address
VLAN
Tag
Type Data FCS
7 Bytes 1 Byte 6 Bytes 6 Bytes 4 Bytes 2 Bytes 46 Bytes – 1500
Bytes
4 Bytes
Layer 2 describes the access to Layer 1 as well as the telegram structure
VLAN Tag is optional
TPID TCI
2 Bytes 2 Bytes
8100 PCP CFI VID
PROFINET uses PCP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-21
• VLAN Tag:
In the Tagged-MAC-Frame according to IEEE 802.1Q there follows an additional 4 bytes
as VLAN-Tag. The first 2 bytes contain the “Tag Protocol Identifier”, short TPID. This
normally contains the constant 0x8100 (=802.1qTagType) which identifies a Tagged-
MAC-Frame as such. The following 2 bytes contain the “Tag Control Information”, also
called TCI. It contains the “Priority Code Point”, PCP, the bit for “Canonical Format
Indicator”, CFI, as well as the “VLAN Identifier”, VID. The VLAN-Tag is also used in
PROFINET with the help of the PCP to prioritize the RT packets.
• Type / Type Field (EtherType):
The Type Field describes which type of packets are transported with this telegram. This
can be, for example, the Internet Protocol (IP). The identifier would then be 0x8000
(IPv4).
In earlier versions, the length of the packet was found here instead of the Type.
• Data / User data:
The user data of the telegram is found here. It can have a maximum length of 1500
bytes. If the user data is less than 46 bytes, a so-called PAD Field (also called “Padding
Bytes”) is inserted in order to achieve the minimum size of an Ethernet Frame of 64
bytes.
The minimum size of 64 bytes for an Ethernet Frame is important in order to be able to
reliably detect the collision of Ethernet packets!
• Frame Check Sequence (FCS) / Test mark:
The Frame Check Sequence (FCS) is a 4 byte long sequence which is calculated from
the previous contents of the packet. It uses the Destination Address, the Source Address,
the Type and the Data to calculate its 4 bytes. It is used by the recipient to verify the
validity of the telegram. If the telegram is changed through errors on the line, it can be
detected with the FCS.
Note
There are circumstances in which the Ethernet Frame can be larger than the maximum byte size
of 1518 bytes. With the use of VLANs, for example, this is the case. A check must be made here
to see whether all network components can even process such an oversizedEthernet Frame
since it will otherwise be rejected!

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-22 Training Document, V15.01.00
2.10. MAC Address

MAC Address
The MAC address is the address of the physical interface of an Ethernet device. It is six bytes
long, is as a rule presented in hexadecimal format and must be unique in the network. Originally,
the address had to be unique worldwide and permanently burnt onto the device. Nowadays,
many devices have adjustable addresses.
The address is divided into an Organizationally Unique Identifier (OUI) which stands for the
manufacturer of the device and a device address given by the manufacturer. Due to their many
products, most manufacturers now have several OUIs.

SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Basics of Industrial Ethernet
MAC Address
MAC address of a
SCALANCE XC208
00-1B-1B FE-B4-BC
Manufacturer ID Device address
Each manufacturer has
an ID
Each device has a
unique address
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-23
2.11. IP Address V4 / Internet Protocol Address Version 4

IP Address V4
The IP address in Version 4 is 32 bits wide and uniquely identifies an IP device, also called IP
node, in a network. This address is not, like the MAC address in Ethernet, permanently assigned
to a device but can be freely configured.
To make things easier, when we talk about an IP address after this, it is always assumed that this
is of the type Version 4. If it should be of the type Version 6, it will say so explicitly!
The IP address is represented in four blocks with 8 bits each which are separated by a dot. Even
if this address is calculated in binary format, it is noted in decimal notation for reasons of
readability.
Each block can assume a value of 0 to 255.
Localhost
There is a special IP address, the so-called “Localhost” address. Your own computer can always
be addressed with this address regardless of which IP address the network card currently has.
The localhost address is composed as follows: 127.0.0.1


SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Basics of Industrial Ethernet
IP Address V4 /
Internet Protocol Address Version 4
1100_0000 1010_1000 0000_0000 0000_0010
192 168 0 2
192.168.0.2
Decimal format
Standard format
An IP address is represented as 4 blocks à 8 bits, separated by a dot
127.0.0.1
Localhost address
Binary format
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-24 Training Document, V15.01.00
2.12. Subnet Mask

Subnet Mask
The subnet mask is, like the IP address, a 32 bit wide number. Together with the IP address, it
defines the size of a network. By means of the subnet mask, an end device can check whether a
communication partner is located in the same network or in another network.
The subnet mask read in binary format consists of an uninterrupted sequence of ones. The
subnet mask is noted either like an IP address in four blocks of 8 bits each or as a number of
leading ones.
The latter representation is always added to an IP address with a “/”. The IP address
192.168.0.100 with subnet mask 255.255.255.0 can therefore also be written as
192.168.0.100/24.
Note
The familiar concept of network classes is outdated and was revised. It was replaced in 1993 with
the Classless Inter-Domain Routing (CIDR).
In the picture, the network classes in alternative representation are only displayed since these are
required for the simplified calculation of IP ranges.
A subnet mask which only consists of ones, that is 32 ones, is not allowed.


SITRAIN © Siemens AG 2018
Page 18
IK-TIAPN
Basics of Industrial Ethernet
Subnet Mask
1111_1111 1111_1111 1111_1111 0000_0000
255 255 255 0
/24
Binary format
Decimal format
Alternative
representation
A subnet mask in binary format always consists of an uninterrupted sequence of ones!
Invalid subnet mask
1111_1111 1111_1111 1111_1111 0000_0100
255 255 255 4
/8 /16 /24 /32
Network classes
(outdated)
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-25
2.13. Network Address

ANDing Addresses
In order to place an IP device correctly in a network, an associated subnet mask must always be
configured in addition to an IP address. The IP address and the required subnet mask together
form the network address.
In order to determine the network address of an IP address and so also to check whether two IP
addresses are located in the same network, the IP address is “ANDed” binary and bit-by-bit with
the subnet mask.
This means that each bit of the IP address is linked with the relevant bit of the subnet mask with a
logical “AND”. 1 & 1 becomes 1, 0 & 1 as well as 1 & 0 to 0.
Network Address
The result of the operation described above is the address of the network in which the IP address
is located, in other words, the network address.
With the help of this network address, the user can find out whether two IP addresses (two
devices) are located in the same network and can therefore exchange data without a router. This
is the case when both IP addresses have the same network address. If the network addresses
are not the same, data can only be exchanged between the devices with the help of a router.


SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Basics of Industrial Ethernet
Network Address
255 255 255 0
192 168 0 100
&
=
192 168 0 0
1100_0000 1010_1000 0000_0000 0110_0100
1111_1111 1111_1111 1111_1111 0000_0000
&
=
1100_0000 1010_1000 0000_0000 0000_0000
ANDing the
addresses
ANDing the
addresses
IP address and subnet mask in binary notation
Network address
decimal
Network address
binary
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-26 Training Document, V15.01.00
2.13.1. Additional Network Address

Network Mask
The subnet mask can also be seen as the network mask. This means that the subnet mask also
determines the maximum number of devices which can be located in a network.
In a network with the subnet mask 255.255.255.0, there can be 254 valid devices. In a network
with the subnet mask 255.255.254.0, there can be 510 valid devices.

SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Basics of Industrial Ethernet
Additional Network Address
255 255 252 0
192 168 3 100
&
=
192 168 0 0
192 168 9 100
255 255 252 0
&
=
192 168 8 0
ANDing the
addresses
ANDing the
addresses
Same network
address as before
Different network
address
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-27
2.14. Addresses of a Network

Network
Each network has special network addresses. These are the network address as well as the
broadcast address. These two special addresses cannot be used as device addresses in this
network!
Network Mask
The network mask defines the size and thus the maximum number of devices of a network. The
maximum number of devices is always two less than the maximum number of addresses in a
network. Each network always has at least two valid device addresses!
Network Address
The network address is always the first address in a network. Through this address, it can be
checked whether two devices are located in the same network. As a result, the network address
cannot be used as a device address!
Broadcast Address
The broadcast address is always the highest address in a network, but just like the network
address, it cannot be used as a device address! All devices of a network can be addressed viathe broadcast address.
SITRAIN © Siemens AG 2018
Page 21
IK-TIAPN
Basics of Industrial Ethernet
Addresses of a Network
255 255 255 0192 168 0 100
IP address Subnet mask
Network address192 168 0 0
192 168 0 1-254
256 – 2 valid device
addresses
192 168 0 255 Broadcast address
255 255 252 0192 168 9 100
IP address Subnet mask
Network address192 168 8 0
192 168 8 1
192 168 11 255 Broadcast address
192 16811 254
4 x 256 – 2 = 1022
valid device addresses
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-28 Training Document, V15.01.00
2.15. Subnetting / Supernetting

Subnetting
Subnetting is when you divide a network into two or more smaller ones. The smaller a network is
the more stable it runs. Depending on how many devices take part in a network, the subnet mask
must be adjusted.
An expansion of the subnet mask by a One (1) means a halving of the network. Two subnets are
formed. Each additional One halves the networks in turn.
Supernetting
If you remove a One from the subnet mask, this is supernetting. The networks are then twice as
large as before.


SITRAIN © Siemens AG 2018
Page 22
IK-TIAPN
Basics of Industrial Ethernet
Subnetting / Supernetting
255 255 255 192
Subnet mask
Network address
64 – 2 valid device addresses
Broadcast address
172 100 5
0
1-62
63
172 100 5
64
65-126
127
172 100 5
128
129-190
191
172 100 5
192
193-254
255
Network address
64 – 2 valid device addresses
Broadcast address
Network address
64 – 2 valid device addresses
Broadcast address
Network address
64 – 2 valid device addresses
Broadcast address
172 100 5 200
IP address
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-29
2.16. Calculation of IP Ranges - Classic

IP Ranges
Since there is only a limited space for IP addresses in the IP address space and thus also for
devices in a network, the existing address space must be optimally utilized. This is done with the
help of subnetting and IP ranges.
Before you insert devices in a network you should decide what is the maximum number of
devices which should be possible in the same subnet and which IP range must be reserved for
the devices.
Classic Calculation
So that the calculation of how many devices are possible in an IP range can be done quickly,
easily and efficiently, the method above can be used.
The octet of the subnet mask which is not completely filled with 1s is looked at. Thinking
decimally, this is the octet which is smaller than 255. This octet is taken and its numerical value is
subtracted from the maximum number of network addresses 256. The result of this calculation is
the bandwidth of the individual IP ranges which can be found in a network mask with this subnet
mask. The counting of the IP ranges always starts with the first network address which is found at
Address 0. If, for example, a bandwidth of 4 resulted from the calculation, the IP ranges would
start at the addresses 0,4,8,12,16,20,24, etc.
The number of devices is then calculated by multiplying the maximum number of devices in a
network times the bandwidth and then subtracting two devices which are occupied by the network
address and the broadcast address. Thus, in the example above, 4x256 -2 results in a maximum
of 1022 devices per IP range.

SITRAIN © Siemens AG 2018
Page 23
IK-TIAPN
Basics of Industrial Ethernet
Calculation of IP Ranges - Classic
255 255 252 0
192 168 9 100 IP address
Subnet mask
256
192 168 0 0 First IP range
252-
= 4
Max. number of network addresses
Subnet mask
Bandwidth of the IP ranges
192 168 3 255
192 168 4 0 Second IP range
192 1687 255
4x256–2 = 1022 devices
4x256–2 = 1022 devices
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-30 Training Document, V15.01.00
2.17. Calculation of IP Ranges - Alternative

Alternative Calculation of the Bandwidth
If the subnet mask is not stated in the classic representation as four octets (e.g. 255.255.255.0)
but in the alternative presentation (e.g. /20), an easy calculation of the devices in a mask can also
be done here.
You take the subnet mask and subtract it from the next higher “network class”. In the example
above this is 24 minus 20. The result, in this case 4, is then the exponent. To find the number of
bandwidths in the respective range, you calculate 2 to the power of 4. That is, 24 results in a
bandwidth of 16 for the individual IP ranges.
The calculation of the maximum number of devices is identical to the classic calculation but it can
also be more easily realized using the following method.


SITRAIN © Siemens AG 2018
Page 24
IK-TIAPN
Basics of Industrial Ethernet
Calculation of IP Ranges - Alternative
/20192 168 116 100 IP address
24
192 168 0 0 First IP range
20-
= 4
Maximum number of Ones
Subnet mask
Number of Zeros in the octet
192 168 15 255
192 16816 0 Second IP range
192 168 31 255
16x256–2 = 4094 devices
16x256–2 = 4094 devices
= 16 2^4 = 16 Bandwidth of the IP ranges
/8 /16 /24 /32 Network classes
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-31
2.18. Alternative Calculation of Device Addresses

Alternative Calculation of the Device Addresses
A further possibility to find out how many device addresses / devices are now possible in an IP
range is just as easy and efficient using the alternative representation of the subnet mask.
You take the subnet mask and subtract it from the maximum number of Ones which would be
theoretically possible in a subnet mask. In the example above this is 32 minus 20. The result, in
this case 12, is then the exponent. To find the number of device addresses in every IP range, you
calculate 2 to the power of 12. That is, 212 results in a maximum number of 4096 device
addresses for the individual IP ranges. From this, two addresses, the network address and the
broadcast address, still have to be deducted. This results in a maximum device number of 4094.


SITRAIN © Siemens AG 2018
Page 25
IK-TIAPN
Basics of Industrial Ethernet
Alternative Calculation of Device Addresses
/20192 168 116 100 IP address
32
20-
= 12
Maximum number of Ones
Subnet mask
Number of Zeros in the mask
= 4094 2^12 = 4096 – 2 = 4094 devices
/32 max. number of Ones
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-32 Training Document, V15.01.00
2.19. PING / Packet Internet Groper

Ping / Packet Internet Groper
Simply called “Ping”, this tool is probably the most widely used and most familiar tool for testing
whether a network connection to another network device exists.
A Ping can be executed via the search field in the Windows Start menu as well as in the
command line. It is recommended, however, that you use the command line for a Ping since the
popup window automatically closes after the Ping command is executed via the search field in the
Windows Start menu. The command line can be opened by entering “cmd” in the Windows Start
menu.
Another way to open the command line is to start the execution window using the shortcut
“Windows-key + R” and then entering the command “cmd”.
On a Windows operating system, a Ping is executed four times one after the other by default. In
order to execute a continuous ping, the Ping command can have a “-t” added to it. This
continuous Ping as well as all other commands can be aborted in the command line by using the
key combination “CTRL + C”!
Function
After entering the Ping command, the network device sends an ICMP-Packet (Internet Control
Message Protocol) of the type ICMP Echo Request to the destinationaddress. As soon as this
station has received the Packet, it sends an ICMP-Packet of the type ICMP Echo Reply back.
The throughput time of a packet can be determined when the sender halves the time that has
elapsed until the answer is received from the destination address
Note
By entering “ping” or “ping /?” in the command line, you can get an overview of all possible
combinations that are possible with the Ping command.


SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 26 Siemens AG © 2016
PING / Packet Internet Groper
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-33
2.20. Task Description:
IP Addresses and Subnet Masks

Task Description
In the following exercises, you are to calculate network addresses, broadcast addresses, device
addresses and subnet masks. You are also to check whether various device addresses are valid
addresses or not.
Do not use any other tools such as a calculator, cell phone ☺, or similar for this.
SITRAIN © Siemens AG 2018
Page 27
IK-TIAPN
Basics of Industrial Ethernet
Task Description:
IP Addresses & Subnet Masks
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-34 Training Document, V15.01.00
2.20.1. Exercise 1: Calculating with IP Addresses

Task
Each partial task has a different purpose. You are to calculate either the network addresses, the
broadcast addresses, whether the device addresses are valid addresses, or, the number of
maximum possible devices.
Task 1
Calculate the network address of the respective IP address.
Network address for IP address 1: _______________________________________
Network address for IP address 2: _______________________________________
Task 2
Calculate the broadcast address of the network in which the respective IP address is located.
Broadcast address for IP address 3: _______________________________________
Broadcast address for IP address 4: _______________________________________
Task 3
Are the following IP addresses valid device addresses?
IP address 5: _______________________________________
IP address 6: _______________________________________
Task 4
Calculate how many device addresses fit in the respective networks.
Number of device addresses in Network 1: _______________________________________
Number of device addresses in Network 2: _______________________________________

SITRAIN © Siemens AG 2018
Page 28
IK-TIAPN
Basics of Industrial Ethernet
Exercise 1: Calculating with IP Addresses
IP address 1: 192.168.113.16
Subnet mask: 255.255.248.0
IP address 2: 172.16.100.34/30
Task 1: Network addresses
IP address 3: 192.168.8.255
Subnet mask: 255.255.240.0
IP address 4: 10.0.50.1
Subnet mask: 255.255.255.252
Task 2: Broadcast addresses
IP address 1: 192.168.1.0
Subnet mask: 255.255.254.0
IP address 2:192.168.100.3/30
Task 3: Device addresses
Network 1: 192.168.0.0/29
Network 2: 10.0.0.0/22
Task 4: Number of devices
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-35
2.20.2. Exercise 2: Subnetting

Task
You are to become familiar with subnet masks and solve the task asked below.
Task 5
Select the subnet masks in such a way that the subnets are, on the one hand, as small as
possible, and on the other hand, all devices plus two buffer addresses fit in the subnets.
Network mask & subnet mask for Subnet 1: _______________________________________
Network mask & subnet mask for Subnet 2: _______________________________________
Network mask & subnet mask for Subnet 3: _______________________________________
Network mask & subnet mask for Subnet 4: _______________________________________
Note
Calculate the subnet mask plus the network address as the solution!
Example: 192.168.200.64/28.

SITRAIN © Siemens AG 2018
Page 29
IK-TIAPN
Basics of Industrial Ethernet
Exercise 2: Subnetting
You are to connect an automation network to an IT structure. For this, the Administrator of the IT
network has reserved an IP address area for the automation:
192.168.100.0/23
You are to divide the automation network into suitable subnets based on its communication
relationships. Select the subnet masks and the network addresses in such a way that the subnets
which you form are as small as possible but always have two IP addresses / device addresses as a
buffer for expansions.
Task 5: Subnetting
12 devices 30 devices 230 devices 40 devices
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-36 Training Document, V15.01.00
2.21. Access Procedure for Industrial Ethernet: CSMA/CD

Collision Afflicted Shared Medium
Historically, Ethernet is a protocol that works with a shared medium. This means that only one
device at a time can send data on a line. If several devices simultaneously send information on
the line, there is an overlapping and the information is lost. This is called a collision. An area in
which collisions could occur is called collision domain. In traditional Ethernet, the entire network is
a collision domain.
Access Procedure: CSMA/CD (Carrier Sense Multiple Access / Collision Detection)
CSMA/CD is an access procedure that was developed to detect collisions on the line and, in this
case, to resend the data. It can be subdivided into the following:
• Carrier Sense (CS):
Before data is sent, a check is made as to whether another device is already sending
data.
• Multiple Access (MA):
In spite of a previous check, it can happen that two or more devices simultaneously
transfer data. A collision can occur.
• Collision Detection (CD):
During sending, the devices check whether a collision has occurred on the line. If a
collision is detected, the data is resent after a random waiting time which is determined
according to the back-off algorithm.
Note
A collision is not a faulty behavior in the traditional Ethernet, but a consciously tolerated feature of
the medium. The more devices exchange data in a network or the larger the collision domains,
the more likely a collision is. This also means that with an increasing number of collisions, the
data throughput rate sinks.
In modern networks, collisions are no longer possible because of full duplex data transmission
and the switches used. Today, CSMA/CD is therefore no longer used or required. .
SITRAIN © Siemens AG 2018
Page 30
IK-TIAPN
Basics of Industrial Ethernet
Access Procedure
for Industrial Ethernet: CSMA/CD
No telegram traffic on the network Station A listens to the network and sends
Station D listens to the network and sends Collision on the network
Station A
Station B
Station C
Station D
Station A
Station B
Station C
Station D
Station A
Station B
Station C
Station D
Station A
Station B
Station C
Station D
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-37
2.22. Duplex Mode

Half Duplex Mode
In communications engineering, half duplex mode is when communication is only possible
alternately in one direction. Traditional Ethernet always worked in half duplex mode, since only
one channel was available via the coaxial cable through which simultaneous data traffic was only
possible in one direction. CSMA/CD ensured that collisions did not occur here.
Full Duplex Mode
The restriction that it is only possible to simultaneously send in one direction does not exist for
modern Ethernet techniques. If twisted pair cables or fiber optic cables are used, you can usually
work in full duplex mode. Here, it is possible to simultaneously send in both directions. Collisions
do not occur and CSMA/CD is not used here.Since information is sent in both directions, the data
throughput also increases. With full duplex, Fast Ethernet achieves 200 Mbit/s and Gigabit
Ethernet 2Gbit/s.

SITRAIN © Siemens AG 2018
Page 31
IK-TIAPN
Basics of Industrial Ethernet
Duplex Mode
Half duplex mode
Simultaneous communication only
possible in one direction
Full duplex mode
Simultaneous communication in both
directions possible
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-38 Training Document, V15.01.00
2.23. Types of Telegrams in Ethernet

Distinction between the Recipients
In general, Ethernet distinguishes between three types of telegram on the basis of the number of
recipients - Unicasts, Multicasts and Broadcasts.
Unicast
A unicast is a telegram that has exactly one recipient. The MAC address of this recipient is
specified as the destination MAC address in the Ethernet telegram. Bidirectional communication
usually occurs via Unicasts.
Multicast
A multicast has several recipients. A telegram to several recipients is recognizable by the first bit
of the MAC address (least significant bit). If this bit is “1”, the telegram is a multicast or broadcast.
Intelligent network components are required for the correct forwarding of a multicast. If these are
not able to filter multicasts, a multicast is handled like a broadcast.
Broadcast
A broadcast is a telegram to all Ethernet devices (subscribers). A broadcast always has the
address “FF-FF-FF-FF-FF-FF” as the destination MAC address.
Note
In addition to the three already mentioned types of telegram, there is also the “Anycast” telegram
type. However, in the world of automation it is rarely used.
Anycast
An anycast is really a unicast which is sent to all devices that have this anycast address.
However, only the device which is accessible via the shortest route for the packet is addressed.
This, in turn, is determined by the so-called routing protocol.
SITRAIN © Siemens AG 2018
Page 32
IK-TIAPN
Basics of Industrial Ethernet
Types of Telegrams in Ethernet
Unicast
Multicast
Broadcast
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-39
2.24. Ethernet HUB

Ethernet HUB
In Ethernet, a star distributor which has several connections is referred to as a hub. As a rule,
HUBs have the following basic functions:
• Reproduction of the physical interfaces
• Improvement of the network quality compared to a pure coaxial segment through the
restoration of signal amplitudes, the signal timing or the isolation of a faulty segment
Expansion of the Collision Domain
When a HUB is used, the network segment remains a shared medium and collisions continue to
occur. The more HUBs are used, the larger the collision domain becomes and the lower the net
throughput becomes.
Principle of Telegram Forwarding
With regard to telegram forwarding, a HUB has no intelligence. This means that all telegrams are
always forwarded to all interfaces; regardless of which telegram type it is. A unicast is forwarded
to all devices just like a broadcast. If the S7-1500 sends a telegram which is addressed to the S7-
300, the HUB nevertheless forwards it to all devices.

SITRAIN © Siemens AG 2018
Page 33
IK-TIAPN
Basics of Industrial Ethernet
Ethernet Hub
HUB
All connected devices share
the bandwidth
Only one device (at a
time) can communicate
Whatever arrives at a port,
is output to all others
Symbol: HUB
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-40 Training Document, V15.01.00
2.25. Shared LAN  → Switched LAN

Shared LAN
In a Shared LAN, all connected devices share the bandwidth of the network. The network is
therefore collision-afflicted and telegrams can be lost. A frame which is sent by a device goes
through all segments. Therefore, there can only always be one telegram in a Shared LAN.
The use of HUBs, repeaters and OLMs require compliance with configuration rules and in each
case reduce the maximum extension of the network.
Switched LAN
In a Switched LAN, every connected device finds itself in its own collision domain. As a result, it
can handle the entire bandwidth of the network. It is virtually impossible for collisions to occur in a
Switched LAN! A frame which is sent by a device only goes through the segments which lie on
the path to its receiver. Therefore, there can be several telegrams in a Switched LAN
simultaneously.
SITRAIN © Siemens AG 2018
Page 34
IK-TIAPN
Basics of Industrial Ethernet
Shared LAN → Switched LAN
Data traffic
Shared LAN
all devices in a collision domain
Switched LAN
all devices in their own collision domain
Separation of the collision domains
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-41
2.26. Ethernet SWITCH

Ethernet SWITCH
In network technology, an Ethernet Switch refers to a device which physically and logically
connects the network nodes with one another. Switches are now the standard components for
connecting Ethernet devices to one another.
Reduction of the Collision Domain
A switch decouples its physical interfaces, also called ports, from one another. In half duplex
mode, each port has its own collision domain(s). Modern switches and devices usually can
handle full duplex mode which leads to a collision-free network.
Principle of Telegram Forwarding
Switches have certain intelligence and only forward telegrams to the desired addressees insofar
as they are known. The rest of the network devices are not aware of the data exchange. There is
no physical connection between each end device. For a unicast, the Source MAC Address and
the Destination MAC Address is used to decide to which ports which telegram is forwarded. A
switch is thus a device which works on the Data Link Layer of the OSI model. Multicasts and
broadcasts are forwarded to several or all devices. Ideally, every final device receives only the
data intended for it.
SITRAIN © Siemens AG 2018
Page 35
IK-TIAPN
Basics of Industrial Ethernet
Whatever arrives at a port,
is specifically forwarded
All devices can
communicate simultaneously
All connected devices have
the same bandwidth
Ethernet Switch
Switch
Symbol:
SWITCH
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-42 Training Document, V15.01.00
2.27. Ethernet SWITCH Basics
2.27.1. Ethernet SWITCH Basics 1

Forwarding Database
Based on the Destination MAC Address of an Ethernet telegram, a switch decides to which of its
ports it specifically forwards which unicast telegrams. For this, it internally creates a database in
which is stored which MAC address is accessible at which port. This database is called Filtering
Database or also Forwarding Database (FDB).
Forwarding Database for Cascading
In the example, only one device each and with that only one MAC address was connected to
each port of the switch. Thus, only one MAC address is assigned to each port. If, however, further
network components such as switches or even HUBs are connected to a port, then more than
one MAC address can be accessible on one port.
The address of the connected switch is not listed since switches usually operate transparently in
the network. Only Managed Switches actively generate telegrams and so are entered in the FDBs
of the other switches. Here, they behave like final devices. It can therefore very well be that a port
is assigned several MAC addresses!
Unicast Learning
The database is filled with the Source MAC Addresses of the telegrams received. With each
forwarding of packets, these entries are compared with the DestinationMAC Address of the
current telegram and only forwarded to the appropriate ports. This ensures that unicast telegrams
are only forwarded to the appropriate ports.
SITRAIN © Siemens AG 2018
Page 36
IK-TIAPN
Basics of Industrial Ethernet
Ethernet SWITCH Basics 1
Forwarding Database (FDB)
MAC Address Port Switch
▪MAC Address of A ▪P1
▪MAC Address of B ▪P2
▪MAC Address of C ▪P3
▪MAC Address of D ▪P4
MAC A MAC B
MAC C MAC D
P 1 P 2
P 3 P 4
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-43
2.27.2. Ethernet SWITCH Basics 2

Checking the Source MAC Address
When the first telegram of device C reaches the switch, a check is made as to whether the
Source MAC Address of this packet is already listed in the FDB of the switch. In other words, a
check is made to see whether the switch already “knows” the device. If this is the case, the Aging
Timer for the relevant entry is reset.
If the MAC address (like here) is not listed, a new entry is created. This contains the MAC
address of device C and the port P1.
Checking the Destination MAC Address
Next, a check is made as to whether the address of the recipient (in other words, the Destination
MAC Address of the Ethernet telegram) is listed in the FDB. Since this is not the case, the
telegram is forwarded to all ports (except that of the receiver). This ensures that the telegram
reaches the appropriate end device.
Deleting FDB Entries
There are two ways of deleting addresses from the FDB. On the one hand, the associated MAC
addresses are deleted for a Link Down of a port; on the other hand, old entries are sorted out
based on an Aging Time.
Link Down
A Link Down refers to the pulling of a cable or the interruption of an existing connection through a
cable break or similar.
An active link is immediately established when a cable is inserted between two Ethernet devices
(subscribers) (Lighting up of the usually green LED on the network port).
SITRAIN © Siemens AG 2018
Page 37
IK-TIAPN
Basics of Industrial Ethernet
Forwarding Database (FDB)
MAC-Adresse Port Switch
Ethernet SWITCH Basics 2
Forwarding Database (FDB)
MAC Address Port Switch
▪MAC Address of C ▪P3
Receipt of a telegram
from C
Is the address of C
in the FDB?
Yes
Reset the Aging Timer
Is the address of B
in the FDB?
Device C sends a telegram to device B
Forward the packet to the
port entered in the list
Wait for the next
telegram
Enter address C and
port 3 in the FDB
No
Forward packet to all
ports
NoYes
Aging Time approx.
30 sec – 40 sec
Not at the receiving port!
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-44 Training Document, V15.01.00
2.27.3. Ethernet SWITCH Basics 3

Checking the Source MAC Address
When the first telegram of device B reaches the switch, a check is made as to whether the
Source MAC Address of this packet is already listed in the FDB of the switch. In other words, a
check is made to see whether the switch already “knows” the device. If this is the case, the Aging
Timer for the relevant entry is reset.
If the MAC address (like here) is not listed, a new entry is created. This contains the MAC
address of device B and the port P2.
The only way for a SWITCH to learn which network devices are connected to which of its ports is
therefore via incoming Ethernet telegrams!
Aging Time
Every time a MAC address is entered in the database, a timer is started. If it expires, the entry is
considered obsolete and is deleted. This so-called Aging Time is often 30 sec to 40 sec in the
industrial environment and can be configured for Managed Switches. The Aging Time is stored in
the Forwarding Database for every entry. For each packet that reaches the switch, the timer for
the relevant Source MAC Address is reset. This procedure ensures that the FDB is always kept
as current as possible.
If entries didn’t have an expiry date, changes in the network would, under certain circumstances,
not be detected. For cascading networks, it is entirely possible that the failure of a network
participant or the replugging of the device in another port does not necessarily cause the link
down of every port involved, in whose FDB this device is entered.

SITRAIN © Siemens AG 2018
Page 38
IK-TIAPN
Basics of Industrial Ethernet
Ethernet SWITCH Basics 3
Forwarding Database (FDB)
MAC-Adresse Port Switch
▪MAC Adresse von C ▪P3
▪MAC Address of B ▪P2
Aging Time approx.
30 sec – 40 sec
Receipt of a telegram
from B
Is the address of B
in the FDB?
Yes
Reset the Aging Timer
Is the address of C
in the FDB?
Device B sends a telegram to device C
Forward the packet to the
port entered in the list
Wait for the next
telegram
Enter address B and
port 2 in the FDB
No
Forward packet to all
ports
NoYes
A SWITCH only learns its port
allocation through incoming telegrams!
Forwarding Database (FDB)
MAC Address Port Switch
▪MAC Address of C ▪P3
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-45
2.28. Switching Methods
2.28.1. Store and Forward

Store and Forward
With this switching method, each Ethernet telegram is completely read in before it is forwarded. If
the telegram length is in the valid range of the Ethernet Standard, the checksum is calculated and
compared to the FCS stored in the telegram. If the values are divergent, the data is rejected and
not forwarded. If they match, the switch passes through the various phases of the packet
forwarding. With this method, no invalid, too short or too long Ethernet frames are forwarded in
the network. This is the most commonly used switching procedure.

SITRAIN © Siemens AG 2018
Page 39
IK-TIAPN
Basics of Industrial Ethernet
Switching Methods - Store and Forward
Source port
Frame
Switch
Frame is detected at the source port
Address tableStore Switch
Fabric
Destination port
Source port
Switch
Entire frame is read in
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
FCS is checked and the destination port is
determined based on the destination
address
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
Frame sent to the destination address or
rejected
Address tableStore Switch
Fabric
Destination port
Frame
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-46 Training Document, V15.01.00
2.28.2. Cut Through

Cut Through
With Cut Through, the telegram is already forwarded as soon as the Destination MAC Address
has been read in. However, the FCS is also calculated and compared. The problem is, however,
that the forwarding cannot be reversed. As a result, the sending is simply aborted for an invalid
FCS. This behavior ensures that, under certain circumstances, invalid, too short or even too long
packets are forwarded which have to be filtered by downstream network components or by the
end node. You achieve, however, very short latencies. Cut Through is used for very time-critical
applications such as PROFINET IRT.
SITRAIN © Siemens AG 2018
Page 40
IK-TIAPN
Basics of Industrial Ethernet
Switching Methods – Cut Through
Source port
Frame
Switch
Frame is detected at the source port
Address tableStore Switch
Fabric
Destination port
Source port
Switch
Destination address is read in
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
FCS is, however, still checked! If
something doesn’t fit, sending is aborted!
Address tableStore Switch
Fabric
Destination port
Frame is sent to destination address
Industrial Communication, PROFINETwith Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-47
2.28.3. Fragment Free

Fragment Free Switching
This method is a special form of Cut Through. Once again, the entire telegram is not read in.
However, at least 64 bytes are always read in before forwarding begins. In this way, you can
realize very time-critical applications and ensure that at least telegrams which are too short are
not forwarded. Fragment Free is a very special procedure and is not used very often.
Note
Fragments which are under 64 bytes are usually the debris of a collision that no longer make up a
useful frame!
SITRAIN © Siemens AG 2018
Page 41
IK-TIAPN
Basics of Industrial Ethernet
Switching Methods – Fragment Free
Source port
Frame
Switch
Frame is detected at the source port
Address tableStore Switch
Fabric
Destination port
Source port
Switch
Minimum length of 64 bytes is checked
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
Address tableStore Switch
Fabric
Destination port
Frame
Source port
Switch
Frame is sent to destination address
Address tableStore Switch
Fabric
Destination port
Frame
The destination port is determined based
on the destination address
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-48 Training Document, V15.01.00
2.29. Switching Telegram Forwarding
2.29.1. Prioritization through the PCP

Prioritization with the Help of the Priority Code Point (PCP)
In the PCP (Priority Code Point) of the VLAN tag, a number is stored with which the type of traffic
can be classified. It is used to give priority to certain telegrams over others.
This is relevant when a switch is working to capacity and it cannot forward the telegrams quickly
enough. Data must be buffered or, in the worst case, rejected. If a telegram then has a higher
priority than the other telegrams, it is forwarded before the others. In this way, it can be ensured
that this telegram is not rejected!
Prioritization Levels
The different priority levels are specified in the IEEE 802.1Q-2005 as follows:

PCP Priority Classification
1 0 (lowest) Background
0 1 Best Effort
2 2 Excellent Effort
3 3 Critical Applications
4 4 Video
5 5 Voice
6 6 Internetwork Control
7 7 (highest) Network Control
PROFINET uses the PCP Priority 6!
SITRAIN © Siemens AG 2018
Page 42
IK-TIAPN
Basics of Industrial Ethernet
Switch – Prioritization of Telegrams (PCP)
Telegram with
higher PCP
Theoretical simultaneous arrival of two telegrams with different priorities
Telegrams with higher PCP are forwarded
with priority
PCP
Telegram 1 6
Telegram 2 0
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-49
2.29.2. Processing Telegrams through Queues

Queues in the Switch
The prioritization is realized through so-called queues in the Switching ASIC of the switch. The
prioritization of telegrams is only relevant when a switch becomes overloaded or several
telegrams arrive simultaneously. Depending on the performance class, switches have differing
numbers of queues (two to eight).
Siemens switches have two ways of processing these queues:
• Strict Priority Queuing
• Weighted Round Robin Priority Queuing
Strict Priority Queuing
The queues are emptied in a fixed order. In the example above, first Queue four, then Queue
number three, etc. As long as telegrams are buffered in Queue four, no telegram from the other
Queues is forwarded. If there are telegrams in Queue three, no telegrams from Number two or
Number one are forwarded.
Weighted Round Robin Priority Queuing
All queues from the highest to the lowest priority are passed through. If there are telegrams in a
queue, they are forwarded. A maximum of X telegrams at a time are sent from a queue, whereby
X depends on the priority. This procedure ensures that no telegrams remain in low priority queues
if a high priority device (for example, in case of a failure) generates too much load.
PCP to Queue Mapping
The decision which telegram is buffered in which queue is decided by the PCP value of the VLAN
tag. An internal table is stored in each switch. This table defines which PCP value is assigned to
which queue. Ex works, the mapping is configured according to IEEE 802.1Q. For modern
switches, this mapping can, however, also often be adjusted to your own requirements.
In the picture, the mapping is presented according to IEEE 802.1Q-2003.

SITRAIN © Siemens AG 2018
Page 43
IK-TIAPN
Basics of Industrial Ethernet
Switch – Mechanismus der Priorisierung (Queuing)
The PCP value decides in which queue
which telegram is put
Queue
1 (low priority)
2
3
4 (high priority)
PCP
0
1
2
3
4
5
6
7
Depending on the switch, 2-8 queues are
possible
PROFINET uses the PCP Priority 6
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-50 Training Document, V15.01.00
2.30. Task Description: Setting the Field PG IP Address and Resetting
Devices to Factory Settings

Task Description
You are to give the Field PG a fixed IP address for all subsequent exercises. This must be
defined in the network card settings. For this, you are to select one of the two network cards and
give it a static IP address. Then, you are to reset all devices to factory settings. To do this, you
must first connect each of the devices to one another.
SITRAIN © Siemens AG 2018
Page 44
IK-TIAPN
Basics of Industrial Ethernet
Task Description: Setting the Field PG IP Address
and Resetting Devices to Factory Settings
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-51
2.30.1. Exercise 3:
Selecting the Field PG Ethernet Card

Task
You are to select the virtual interface from the VM-ware which is bridged to the
 of the Field PG.
What to Do
1. Configure the interface as shown in the picture.
Note
The identification of the network card of the M5 Field PG is easier “to remember” with the
following. If you stand in front of the device, that is, can look on the display, the left interface is the
 and the right interface is the
.
This is easier to remember if you regard (memorize) the interface with “L” in the name as the left
interface and the interface with “LM” as the left-middle, that is the right interface.

SITRAIN © Siemens AG 2018
Page 45
IK-TIAPN
Basics of Industrial Ethernet
Exercise 3: Selecting the Field PG Network Card
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-52 Training Document, V15.01.00
2.30.2. Exercise 4: Opening the Adapter Settings

Task
In the Control Panel, you are to open the adapter settings.
What to Do
1. Open the Start menu.
2. Switch to the Control Panel.
3. Open the Network and Sharing Center.
4. Go into the menu item “Change adapter settings”.
SITRAIN © Siemens AG 2018
Page 46
IK-TIAPN
Basics of Industrial Ethernet
Exercise 4: Opening the Adapter Settings
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-53
2.30.3. Exercise 5: Assigning the Field PG a Static IP Address

Task
For the network card you selected in Exercise 3, you are now to assign a static IP address.
What to Do
1. With a double-click, open the Status of the network card (LAN-Connection Status) you
 selected.
2. Switch to the Properties of the network card.
3. Highlight the element “Internet Protocol Version 4 (TCP/IPv4)”.
4. Open the Properties of this element.
5. Using the Ping function of your computer,check whether the IP address 192.168.222.250 is
already assigned. If yes, ask the Instructor to come to you before you continue!
6. Use the IP address 192.168.222.250 for this interface. Use the Subnet mask 255.255.255.0.
7. Confirm your changes.


SITRAIN © Siemens AG 2018
Page 47
IK-TIAPN
Basics of Industrial Ethernet
Exercise 5:
Assigning the Field PG a Static IP Address
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-54 Training Document, V15.01.00
2.30.4. Exercise 6: Networking the Devices

Task
You are to network the devices with one another. You are to proceed as shown in the picture.
What to Do
1. Network the S7-1510SP-1PN CPU with Port P1 of the SCALANCE XC208.
2. Then, network the network card selected by you with Port P2 of the SCALANCE XC208.
3. Finally, connect Port P2 of your S7-1500 case with Port P3 of the SCALANCE XC208.



SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 48 Siemens AG © 2016
Exercise 6: Networking the Devices
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-55
2.30.5. Exercise 7: Resetting the Devices to Factory Settings

Task
You are to reset all devices, which you networked with one another in the previous exercise, to
their factory settings. For this, you are to use the TIA Portal.
What to Do
1. Start the TIA Portal.
2. Expand the menu item “Online access”.
3. Expand your selected interface. If the wiring is correct, the interface should be identified with
the following symbol:
4. Update the accessible devices.
5. One after the other reset all accessible devices to their factory settings. Should there be a
choice whether the IP address is to be retained or deleted, delete it. So that the factory
settings can be re-established for the HMI device via the Online access, the Runtime must be
exited for this!
6. Finally, update the accessible devices. There should no longer be an IP address for any
device!
Note
To fulfill this task, you do not have to create a project yet, nor do you have to open an existing
project!
Furthermore, your computer must be in the same subnet as the devices which you want to reset
to their factory settings.




SITRAIN © Siemens AG 2018
Page 49
IK-TIAPN
Basics of Industrial Ethernet
Exercise 7:
Resetting the Devices to Factory Settings
HMI Runtime must be
exited
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-56 Training Document, V15.01.00
For a PLC with Memory Card, the card must first be formatted before you reset to factory
settings! Otherwise, a reset to factory settings is not possible!


Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-57
2.31. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 50 Siemens AG © 2016
Additional Information
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-58 Training Document, V15.01.00
2.31.1. ISO / OSI 7 – Layer Model

Open Systems Interconnection (OSI) – Model
The OSI – 7 Layer Model is a reference model for manufacturer-independent communication
systems, that is, a design basis for communication protocols and computer networks.
OSI stands for Open Systems Interconnection and was designed and standardized by ISO as the
basis for communication standards. The OSI layer model or OSI reference model is based on the
DoD layer model on which the Internet is based. In comparison to the DoD layer model, the OSI
layer model is more finely subdivided.
DoD layer model (Department of Defense):



The OSI model serves as a tool for describing the principle function of a network. It is divided into
seven sub-areas which are also referred to a layers. Each layer, with the exception of the
uppermost layers, makes its function available to the layers above it. The most important layers
for Ethernet are Layer 1 and Layer 2.

SITRAIN © Siemens AG 2018
Page 51
IK-TIAPN
Basics of Industrial Ethernet
ISO / OSI 7 – Layer Model
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
Anwendungs-
orientiert
Transport-
orientiert
Transport-
orientiert
Transport-
orientiert
transport-
oriented
Anwendungs-
orientiert
application-
oriented
7. Application Layer
6. Presentation Layer
5. Session Layer
4. Transport Layer
3. Network Layer
2. Data Link Layer
1. Physical Layer
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-59
For each layer, functions and protocols are defined which must fulfill specific tasks for the
communication between two systems. For communication between two systems, the
communication or the data flow passes through all 7 layers of the OSI layer model twice - once at
the Sender and once at the Recipient. Depending on how many ‘stops’ the communication route
has, the communication also passes through the layer model several times.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-60 Training Document, V15.01.00
2.31.1.1. Layer 1: Physical Layer

Physical Layer
In the physical layer, the electrical, optical and mechanical connection to the transmission
medium used is defined. It is responsible for the proper transmission of individual bits through the
physical channel. This is essentially a matter of the coding of signals, the defining of the
transmission medium and the transmission devices.
Each medium has its own section.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 52 Siemens AG © 2016
Layer 1: Physical Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
1. Physical Layer:
Measures and procedures for transmitting bit sequences
▪ Devices and network components are assigned to the
Physical Layer
▪ Defines the optical, electrical and mechanical connection
to the transmission medium
▪ Manages the coding of the individual bits or the bit
sequences
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-61
2.31.1.2. Layer 2: Data Link Layer

Data Link Layer
In the data link layer, the transmission and the grouping of the individual bits in the transferable
unit as well as the access procedure to the network is defined. It provides a reliable connection
between terminal and transmission medium and ensures an error-free transmission.
For this, the bit data flow is divided into (data) blocks, also called frames, and checksums are
added. With this checksum, flawed blocks can be detected by the recipient and subsequently be
rejected or even be corrected.
According to IEEE, the Data Link Layer is divided into two sublayers - the Logical Link Control
and the Media Access Control. Due to the Media Access Control, the data link layer is sometimes
also called the MAC Layer.
Media Access Control
The Media Access Control layer is the lower of the two layers in the data link layer. It controls the
access to the transmission medium. It defines which protocol is to be used. There are two
different types of access, a controlled access and a competing access.
Controlled access:
• Token Ring
• Token Bus
• CSMA/CR
Competing access:
• ALOHA
• CSMA/CD
• CSMA/CA


SITRAIN
IK-TIAPN / Basics ofIndustrial Ethernet Page 53 Siemens AG © 2016
Layer 2: Data Link Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
Logical Link Control
Media Access Control
2. Data Link Layer:
Logical connections to data packets and elementary error
detection mechanisms
▪ Consists of two sublayers, the Logical Link Control layer
as well as the Media Access Control layer
▪ Divides the bit data flow into blocks or frames and adds a
checksum
▪ Ensures a reliable and error-free transmission on the
transmission medium
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-62 Training Document, V15.01.00
Logical Link Control
The Logical Link Control layer is the upper of the two layers in the data link layer. It adds several
identifiers to the data packet which are structured as follows:
• DSAP (Destination Service Access Point) of 8 bytes
• SSAP (Source Service Access Point) of 8 bytes
• Control of 8 or 16 bytes
Note
A renewed request of rejected blocks is not regulated or provided in the data link layer!
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-63
2.31.1.3. Layer 3: Network Layer

Network Layer
The task of the Network Layer is the transmission of data packets between the sender and the
recipient. This includes the routing of the packets, the logical addressing of terminals and the flow
control.
Included in the Network Layer is, for example, the Internet Protocol or also the NSAP addresses.
Note
If communication between the sender and the recipient cannot take place directly, but only via
intermediate ‘stops’, the forwarding of packets occurs in the Network Layer.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 54 Siemens AG © 2016
3. Network Layer:
Routing and data flow control
▪ It is responsible for the transmission of data packets
between the sender and the recipient
▪ The Internet Protocol, for example, belongs to the Network
Layer
Layer 3: Network Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-64 Training Document, V15.01.00
2.31.1.4. Layer 4: Transport Layer

Transport Layer
The Transport Layer ensures data transmission beyond network boundaries, which is managed in
the LAN by the Data Link Layer. It is intended to have a logical connection to a remote
communication partner which is checked by acknowledgement telegrams. Connection-less
services are also supported.
Note
The Transport Layer offers Layers 5 to 7 a uniform access to the data. As a result, they do not
have to take the properties of the communication network into consideration.

SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 55 Siemens AG © 2016
4. Transport Layer:
Logical end-to-end connections
▪ It is the link between the transport-oriented layers and the
application-oriented layers
▪ Ensures data transmission beyond network boundaries
Layer 4: Transport Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-65
2.31.1.5. Layer 5: Session Layer

Session Layer
The task of the Session Layer is the organization of the communication between the recipient and
the sender. It provides services for an organized and synchronized data exchange. If, for
example, during communication a connection is lost, the session can be continued at so-called
check points and doesn’t have to start at the beginning.
The RPC Protocol (Remote Procedure Call) is included in this layer.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 56 Siemens AG © 2016
5. Session Layer:
Process-to-process connections
▪ Provides the process communication between two
systems
▪ Provides services for a synchronized and organized data
exchange (Check Points)
Layer 5: Session Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-66 Training Document, V15.01.00
2.31.1.6. Layer 6: Presentation Layer

Presentation Layer
The Presentation Layer makes data exchange between different systems possible. This is
achieved by converting system-dependent presentations of data into an independent form.
Furthermore, data compression as well as data encryption belongs to the Presentation Layer.
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 57 Siemens AG © 2016
6. Presentation Layer:
Output of data in standard formats
▪ Converts the data into different codecs and formats
▪ Makes data exchange between different systems possible
through independent standard formats
Layer 6: Presentation Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-67
2.31.1.7. Layer 7: Application Layer

Application Layer
The Application Layer establishes the connection to the lower layers and provides functions for
the applications. The data input and the data output also takes place in this layer.
It includes the user-specific services of the various communication applications!
SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 58 Siemens AG © 2016
7. Application Layer:
Services, applications and network management
▪ Establishes the connection to the lower layers
▪ Manages the data input and the data output
Layer 7: Application Layer
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-68 Training Document, V15.01.00
2.31.2. TRACERT / Trace Route

TRACERT / Trace Route
In addition to the Ping command to determine whether a connection exists to a network
component, the TRACERT command can be executed to receive further information.
With the “tracert” command, the path of data packets in an IP network can be tracked and made
visible.
Note
Just as with the Ping command, you can get a listing of all possible combinations with the
“tracert” command by entering “tracert” or “tracert /?”.



SITRAIN
IK-TIAPN / Basics of Industrial Ethernet Page 59 Siemens AG © 2016
TRACERT / Trace Route
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of Industrial Ethernet
Training Document, V15.01.00 2-69
2.31.3. IP Address V6

IP Address V6
An IPv6 address consists of 128 bits and thus allows an address amount of 2128 or also written as
340,282,366,900,000,000,000,000,000,000,000,000,000 IPv6 addresses. In comparison, IPv4
allows 4.3 billion addresses. That is, 6x1023 addresses per m2 of the earth’s surface including
areas of water can be assigned!
An IPv6 address is subdivided into 8 times 16 bits. These 16 bits are represented as a
hexadecimal number per each 4 bits. The presentation of an IPv6 address is therefore
hexadecimal. The 8 blocks of 4 hexadecimal numbers each are separated by a colon “:”. In order
to ensure a simplified notation, leading zeros in a block can be omitted and a string of zeros can
be replaced by two colons “::”. However, the last simplification can only be used once in an IPv6
address!
The first 64 bits of an IPv6 addressare referred to as the Network Prefix and the last 64 bits as
the Interface Identifier.
The notation of the hexadecimal characters should also be noted for an IPv6 address. By
definition, these must be written in lower case and must not be written in upper case!
Note
There is an Internet Stream Protocol which has identified its own packets with an IPv5 identifier.
However, this was never publically used and was only used for experiments. In order to avoid
confusion and possible complications, it was however therefore determined to call the new
address type IPv6 and not IPv5.






SITRAIN © Siemens AG 2018
Page 60
IK-TIAPN
Basics of Industrial Ethernet
IPv6
2001:0db8:85a3:08d3:1319:8a2e:0370:7344192.168.0.2
IPv4
An IPv6 address is represented in 8 blocks à 4 hex, separated by a colon
IPv6
Decimal format Hexadecimal format
2001:0db8:85a3:08d3
Network Prefix (64 bits)
1319:8a2e:0370:7344
Interface Identifier (64 bits)
2001:0db8:0000:0000:0000:8a2e:0070:7344 IPv6 address
2001:db8:0:0:0:8a2e:70:7344 Leading zeros can be omitted
2001:0db8::8a2e:0070:7344 Several zeros can be omitted
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of Industrial Ethernet
2-70 Training Document, V15.01.00
2.31.4. Special IP Area Ranges / IP Addresses

Special IP Area Ranges / IP Addresses
It was established and incorporated in the devices that special IP addresses and also IP area
ranges are used for specified tasks. These tasks are incorporated in the hardware of the devices
and can only be used for these, that is, should only be used for these.
The picture shows a brief overview.

SITRAIN © Siemens AG 2018
Page 61
IK-TIAPN
Basics of Industrial Ethernet
Special IP Area Ranges / IP Addresses
Address area Meaning
0.0.0.0/8 Hosts on the local network. Only as source address.
10.0.0.0/8 Private addresses. Not in use on the public Internet
127.0.0.0/8 Loopback addresses. Typically only 127.0.0.1 is used.
169.254.0.0/16 “Link-Local-Address”, can only be used on a Link.
172.16.0.0/12 Private addresses. Not in use in the public network.
192.168.0.0/16 Private addresses. Not in use in the public network.
224.0.0.0/4 IPv4 Multicast addresses, only as destination address.
240.0.0.0/4 Reserved addresses with the exception of 255.255.255.255.
255.255.255.255/32 Broadcast address. Can only be used in the local network.
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-1

Contents 3





3. Basics of PROFINET .............................................................................................. 3-2
3.1. PROFINET ............................................................................................................................ 3-3
3.2. PROFINET vs. PROFIBUS ................................................................................................... 3-4
3.3. PROFINET Communication Model ....................................................................................... 3-5
3.4. Real-time Communication in PROFINET ............................................................................. 3-6
3.5. Network Components in PROFINET .................................................................................... 3-7
3.6. I/O Communication via PROFINET IO ................................................................................. 3-8
3.7. PROFINET Device Addressing ........................................................................................... 3-10
3.8. PRONETA ........................................................................................................................... 3-11
3.8.1. Task Description: PRONETA – IP Addresses & Device Names of the Network Components
& Line Test .......................................................................................................................... 3-12
3.8.1.1. Exercise 1: Assigning IP Addresses to the Devices using the PRONETA Tool ................. 3-13
3.8.1.2. Exercise 2: Initializing the Network Components with the PROFINET Device Name using
PRONETA ........................................................................................................................... 3-14
3.9. Additional Information ......................................................................................................... 3-15
3.9.1. PI - PROFIBUS and PROFINET International .................................................................... 3-16
3.9.2. Primary Setup Tool – PST .................................................................................................. 3-17


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-2 Training Document, V15.01.00
3. Basics of PROFINET


SITRAIN
IK-TIAPN / Basics of PROFINET Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... know what is meant by the term “PROFINET”
... understand the basic functioning of PROFINET
… be familiar with the Primary Setup Tool
… be familiar with the PRONETA tool
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-3
3.1. PROFINET

PROFINET
PROFINET combines the advantages of two worlds. It provides the properties of PROFIBUS
needed for industrial use and combines them with the properties of Ethernet. This results in a
flexible, efficient and high-performance system: PROFINET. The following pages explain how
PROFINET works and why.
Advantages of Ethernet in Automation
• With the future demands placed on performance and data quantities, the fieldbus is
reaching its limit
• Ethernet offers a powerful and future-proof communication platform through continued
technical development
• Vertical integration offers previously unused productivity potential through the connection
of the office and automation worlds
• In the office world, Ethernet is the unequivocal standard regarding installation technology
and protocols Token Bus (802.4)
Features of PROFINET
• Internationally standardized: IEC 61158, IEC 61784
• Integrated communication via fieldbus and Ethernet
• Integration of existing fieldbus systems (PROFIBUS, ASI)
• Use of the TCP/IP protocol
• Communication in real-time
• Isochronous drive control for Motion Control applications via IRT
SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Basics of PROFINET
PROFINET
PROFINET is Ethernet
▪ Ethernet is the established standard in the IT world for the
fast exchange of data (IEEE 802.3)
▪ PROFINET is always full duplex → simultaneous
communication in two directions
▪ PROFINET is always
“switched Ethernet”
▪ Distribution of network load
can be influenced using
topology
▪ PROFINET uses the
standardized structure of
Ethernet telegrams
For comparison: PROFIBUS
▪ One line to which all
nodes (devices) are
connected
▪ Performance directly
dependent on the number
of nodes (devices)
Controller
Slaves
Devices
100 MBit/s full duplex
Master
100 MBit/s
100 MBit/s
PROFINET completely uses all possibilities offered by Ethernet
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-4 Training Document, V15.01.00
3.2. PROFINET vs. PROFIBUS

PROFINET vs. PROFIBUS
The picture shows the most important characteristics and differences between the two bus
systems.





SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Basics of PROFINET
PROFIBUS vs. PROFINET
Property PROFIBUS PROFINET
Bit transfer EIA-485 100 Base-TX, 100 Base-FX
Cable 2-wire 4-wire
Max. length 1200m / segment
Unlimited / network; up to 100 m / copper
cable
Transmission rate
9.6 kBit/s – 12 Mbit/s
Half duplex
100 Mbit/s Full duplex
Topology Line, Tree,Ring Line, Star, Ring, Tree, Wireless
Data transmission Common medium Switched network
User data/Frame 246 bytes 1440 bytes
Devices Up to 32 / segment
Unlimited / network;
up to 256 IO-Devices per IO-Controller
Addresses DP address: 1…125 Device name (unlimited number)
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-5
3.3. PROFINET Communication Model

IT Standards
The WEB integration of PROFINET was primarily designed with commissioning and diagnostics
in mind. Standard protocols (e.g. http) are used to access a PROFINET device from the Internet
or Intranet. The data is transmitted in standard formats, such as, HTML or XML and can be
presented with standard browsers, such as, Firefox or Internet Explorer.
Due to the world-wide accessibility, it is possible for the application producer to easily support the
user in commissioning, device diagnostics etc. The access to the data takes place via web
servers which are integrated in the modules.
Real-time Channel (RT channel)
In order to be able to satisfy the real-time requirements of automation, an optimized
real-time communication channel, the real-time channel (RT channel), was specified in
PROFINET. It builds on Ethernet (Layer 2).
The data packets are addressed on the basis of the MAC addresses of the devices involved
instead of on an IP address. This type of solution minimizes the processing times in the
communication stack considerably and leads to an increase in performance with regards to the
update rate of automation data. Removing several protocol layers reduces the (telegram) frame
length.

SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Basics of PROFINET
PROFINET Communication Model
Prioritization of the RT frames by means of VLAN tagging according to IEEE 802.1q
Ethernet
TCP/UDP
R
e
a
lt
im
e
PROFINET applications
1
IT applications
• HTTP
• SNMP
• DHCP …
2
Open TCP/IP channel
• Device
parameterization
• Reading diagnostic
data
• Negotiating the
communication channel
for user data
1
2
Standard data Realtime data
IP
RT Real-time channel
• High performance
transmission
• Cyclic data
• Event-controlled
messages
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-6 Training Document, V15.01.00
3.4. Real-time Communication in PROFINET

Optimized Data Transmission through Prioritization
In addition to the minimized communication stack in the programmable controllers, transmission
of data over the network is also optimized in PROFINET. Measurements have shown that in
switched networks, for an extremely high network load, transmission times of up to 20 ms can
occur between two stations on Ethernet. A network load of this size cannot be ruled out when
using standard network components, for example, when simultaneously uploading quality data
from the devices. In order to be able to achieve the best result here too, the packets are
prioritized in PROFINET according to IEEE 802.1q (VLAN).
The network components control the data flow between the devices on the basis of these
priorities. Priority 6 (Network Control) is used as the standard priority for real-time data. This
causes a priority handling over other applications, such as, Internet telephony with Priority 5.
The prioritization of PROFINET telegrams with the help of the VLAN tag only causes the
PROFINET telegrams to be preferentially sent. Due to the PCP, however, the sending of a lower
priority telegram is not interrupted!
If, for example, video data with the same priority as the PROFINET data occurs, a difference can
be detected in the RT transmission: → longer jitter times.
Solution: use IRT functionality by means of IRT switches.
Network components and controllers available on the market can be used for real-time
communication. Of course, only on the premise that the switches used can evaluate the priority of
the PROFINET telegram.
IRT Channel
Isochronous Real - Time (IRT) as a further development with the following properties:
• Isochronous data transmission
• Cycle times <1ms with jitter accuracy <1µs
• Typical area of application is Motion Control

SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Basics of PROFINET
Real-time Communication in PROFINET
Real-time data and standard
data on one cable
Separate channels for IO-
data and TCP/IP data
Prioritization of IO-data
according to IEEE 802.1q
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-7
3.5. Network Components in PROFINET

Devices for PROFINET IO
The general names of the most important devices in PROFINET are presented in the picture. The
following contains a brief explanation of the terms:
• IO-Controller:
Device through which the connected IO-Devices are addressed. This means that the IO-
Controller exchanges the input and output signals with the connected field devices. It
corresponds to Class-1-Master in PROFIBUS.
• IO-Device:
A distributed-arranged field device which is assigned to an IO-Controller, for example,
distributed IO, valve block, frequency inverter, switches with integrated PROFINET IO
functionality. In PROFIBUS, an IO-Device corresponds to the Slave.
• IO-Supervisor:
PG/PC/HMI device for commissioning and / or for diagnosis. In PROFIBUS, it
corresponds to a Class-2-Master.
• I-Device:
Intelligent IO-Device. A PLC is not configured as an IO-Controller, but as an I-Device and
provides a higher-level controller with I/O data in a transfer area.
• HMI:
Device for operator control and monitoring.
SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Basics of PROFINET
Network Components in PROFINET
PROFINET IO-System
IO-Controller
I-Device
IO-Device HMI
PROFINET / Industrial Ethernet
S7-1500
S7-300 ET200 MP
PG/PC
IO-Supervisor
TP
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-8 Training Document, V15.01.00
3.6. I/O Communication via PROFINET IO

PROFINET Communication
PROFINET communication takes place via Industrial Ethernet. The following types of
transmission are supported:
• Acyclic transmission of engineering and diagnostic data and alarms
• Cyclic transmission of user data
PROFINET IO communication occurs in real-time.
I/O Communication
The reading or writing of inputs/outputs of distributed IO through PROFINET IO occurs via so-
called I/O communication. The picture shows the various network components between which
communication can take place in PROFINET:
• IO-Controller - IO-Controller communication via PN/PN coupler
• IO-Controller - IO-Device communication
• IO-Controller - I-Device communication
IO-Controller – IO-Controller Communication via PN/PN Coupler
A fixed number of data is cyclically transmitted between the user programs in CPUs of IO-
Controllers. A PN/PN coupler is required as additional hardware.
The IO-Controllers mutually access configured address areas, so-called Transfer areas, which
can be located within or outside of the process image of the CPUs. If parts of the process image
are used as Transfer areas, these must not be used for real I/O modules.
The data transmission occurs with Load and Transfer operations via the process image (tables)
or via direct access.
IO-Controller – IO-Device Communication
The IO-Controller cyclically sends data to the IO-Devices of its PROFINET IO-System and
receives data from them.
SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Basics of PROFINET
IO-Device
PN/PN-Coupler
PROFINET IO 3
PROFINET IO 2
I-Device
PROFINET IO 1
IO-Controller
I/O Communication via PROFINET IO
IO-Controller
I-Device
IO-Controller
I-Device
IO-Device IO-Device I-Device
IO-Controller –
I-Device
communication
IO-Controller –
IO-Device
communication
IO-Controller– IO-Controller communication via PN/PN coupler
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-9
IO-Controller – I-Device Communication
A fixed number of data is cyclically transmitted between the user programs in CPUs of IO-
Controllers and I-Devices.
The IO-Controller does not access I/O modules of the I-Device but configured address areas, so-
called Transfer areas, which can be located within or outside of the process image of the CPU of
the I-Device. If parts of the process image are used as Transfer areas, these must not be used for
real I/O modules.
The data transmission occurs with Load and Transfer operations via the process image (tables)
or via direct access.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-10 Training Document, V15.01.00
3.7. PROFINET Device Addressing

PROFINET IO-System
So that the IO-Devices are accessible for the IO-Controller, they must be supplied with unique
address parameters. Each IO-Device has three address parameters for the complete address:
• MAC Address:
Each PROFINET device already has a burnt-in, world-wide unique MAC address when it
is delivered. As a rule, this cannot be changed. It is required for the real-time
communication.
• Device Name:
Before an IO-Device can be addressed by an IO-Controller, it must have a device name.
For PROFINET, this approach was selected because names are easier to manage than
complex IP addresses.
• IP Address:
In addition to the device name and the MAC address, an IO-Device also requires an IP
address so that, for example, acyclic Read/Write services can be executed.
SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Basics of PROFINET
PROFINET Device Addressing
MAC address
IP address
MAC address
Device name
IP address
IO-Device
IO-Controller
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-11
3.8. PRONETA

PRONETA
SIEMENS PRONETA is a free PC-based software tool which simplifies the commissioning of
PROFINET systems by being able to take over the following tasks:
• Topology Overview (Network Analysis):
PRONETA automatically scans the PROFINET and all connected components and then
displays a topologic overview. This overview can be exported in the form of a device list.
It is possible to “initialize” the components and do other simple configuration tasks as well
as comparing the real configuration with a reference plant.
• IO Test:
PRONETA allows for an IO-Test for quickly testing the wiring of a plant and the module
expansion of components. By reading or writing the inputs and outputs, PRONETA
ensures that the distributed I/Os are correctly wired with their sensors and
actuators.PRONETA can create test profile templates and store test protocols in order to
document the test results.
All of these tasks can be carried out even before a CPU is integrated in the network.
Moreover, since neither other engineering tools nor hardware are required, PRONETA makes
the fast and easy testing of the plant configuration possible at an early point in time.
PRONETA is an official product of Industrial Communication under PROFINET and so can
also be found on the SIEMENS pages:
http://w3.siemens.com/mcms/automation/de/industrielle-
kommunikation/profinet/produktportfolio/proneta/Seiten/proneta.aspx

Note
You will find further information, documentation as well as the download for the PRONETA Tool
on the Service & Support pages under the Entry ID number: 67460624.

SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Basics of PROFINET
PRONETA
Entry ID: 67460624
http://w3.siemens.com/mcms/automation/de/industrielle-kommunikation/profinet/produktportfolio/proneta/Seiten/proneta.aspx
http://w3.siemens.com/mcms/automation/de/industrielle-kommunikation/profinet/produktportfolio/proneta/Seiten/proneta.aspx
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-12 Training Document, V15.01.00
3.8.1. Task Description: PRONETA –
IP Addresses & Device Names of the Network Components & Line Test

Task Description
Before you can read out the networking configuration, make the renewed assignment of the IP
addresses and the device names as well as do the line test with the help of the PRONETA tool,
all devices must once again be reset to factory settings. Afterwards, do the steps above for the
devices.
SITRAIN
IK-TIAPN / Basics of PROFINET Page 17 Siemens AG © 2016
Task Description: PRONETA – IP Addresses &
Device Names of the Network Components
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-13
3.8.1.1. Exercise 1: Assigning IP Addresses to the Devices using the PRONETA Tool

Task
With the help of the PRONETA tool, you are once again to assign an IP address to all network
devices. Again, the devices are to be given the following IP addresses:
• S7-1513-1PN: 192.168.222.1
• ET200SP: 192.168.222.2
• TP700 Comfort: 192.168.222.3
• SCALANCE X208: 192.168.222.4
• S7-1510SP-1PN : 192.168.222.5
All devices are to be assigned the subnet mask 255.255.255.0.
What to Do
1. Start the PRONETA tool.
2. Switch to the “Network analysis” view
3. In any order you like, assign all network components the IP addresses as well as the subnet
mask defined in the task.
Note
Even the PRONETA tool allows you to identify a device through a flash test:

SITRAIN
IK-TIAPN / Grundlagen PROFINET Seite 19 Siemens AG © 2016
Übung 4: Vergabe der Teilnehmer
IP-Adressen über das Tool PRONETA
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-14 Training Document, V15.01.00
3.8.1.2. Exercise 2: Initializing the Network Components with the PROFINET Device Name using
PRONETA

Task
With the help of the PRONETA tool, you are to assign a PROFINET device name to all network
devices. You are free to use with the following information or choose your own:
• S7-1513-1PN: s7-1513-plc
• ET200SP: et200-io-device
• TP700 Comfort: tp700-comfort-panel
• SCALANCE XC208: scalance-xc208-switch
• S7-1510SP-1PN : s7-1510sp-plc
What to Do
1. Initialize all network devices with the help of the PRONETA tool.


SITRAIN
IK-TIAPN / Basics of PROFINET Page 20 Siemens AG © 2016
Exercise 5: Initializing the Network Components
with the PROFINET Device Name using PRONETA
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-15
3.9. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Basics of PROFINET Page 15 Siemens AG © 2016
Additional Information
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Basics of PROFINET
3-16 Training Document, V15.01.00
3.9.1. PI - PROFIBUS and PROFINET International

PROFIBUS & PROFINET International
27 Regional PI Associations (RPAs) are members in this international umbrella organization. One
of them is the PROFIBUS Nutzerorganisation e.V. (PNO). The goal of the PNO as well as the
other Regional PI Associations is to promote the technology’s advancement as well as the
international propagation of the open and standardized technologies PROFIBUS and PROFINET.
On the PI Homepage, you can get information and can download free-of-charge a variety of
documents such as directives, profiles, presentations, brochures, software etc.


SITRAIN
IK-TIAPN / Basics of PROFINET Page 16 Siemens AG © 2016
PI - PROFIBUS and PROFINET International
Industrial Communication,PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Basics of PROFINET
Training Document, V15.01.00 3-17
3.9.2. Primary Setup Tool – PST

PST – Primary Setup Tool
The Primary Setup Tool, short PST, is a software provided by Siemens free of charge. With the
help of the PST, network components, Ethernet CPs, controllers, IO-Devices can be carried out
for SIMATIC NET. As well, address assignments such as the assignment of IP addresses or the
initialization with a PROFINET device name can be carried out for network transitions.
The PST does not require any other software packages or licenses for this functionality. The only
requirement is that these SIMATIC NET devices have a preset ETHERNET (MAC) address and
are accessible online in the network.
If the SIMATIC NET module should have an integrated Web Based Management, this can be
called directly in the PST via the button: “Start the browser for configuring INC modules ”.
Note
You will find further information on the various versions of the Primary Setup Tool on the Service
& Support pages under the Entry ID number: 19440762. Furthermore, you can also download the
various versions of the Primary Setup Tool from this Entry ID number.


SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Basics of PROFINET
Primary Setup Tool – PST
Browse
IP address
Download
Mac address
Device name
Entry ID: 19440762
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-1

Contents 4





4. Network Components ............................................................................................ 4-2
4.1. System Configurations over the Course of Time .................................................................. 4-3
4.2. Basic Structures of the Network Topology ............................................................................ 4-4
4.3. Conceptual Design Information ............................................................................................. 4-6
4.4. Network Components ........................................................................................................... 4-7
4.5. Cable Categories for Twisted-Pair Cables ............................................................................ 4-8
4.6. FastConnect ........................................................................................................................ 4-10
4.7. Task Description: Cabling with FastConnect ...................................................................... 4-11
4.7.1. Exercise 1: Stripping with the Help of the Stripping Tool .................................................... 4-12
4.7.2. Exercise 2: Assembling the IE Cable .................................................................................. 4-13
4.8. Optical Cabling and Connecting Methods .......................................................................... 4-14
4.9. Active Industrial Ethernet Components .............................................................................. 4-15
4.10. Industrial Wireless LAN Components ................................................................................. 4-16
4.11. Communication Processors (CPs) for IE ............................................................................ 4-18
4.12. TIA Selection Tool ............................................................................................................... 4-19
4.13. Task Description: Reading-out the Firmware of the Devices & Configuration of the System in
the TIA Selection Tool ......................................................................................................... 4-20
4.13.1. Exercise 3: Reading-out the Firmware of the Devices (TIA Portal) .................................... 4-21
4.13.2. Exercise 4: Configuration of the System in the TIA Selection Tool .................................... 4-22
4.14. Additional Information ......................................................................................................... 4-23
4.14.1. Versions of IE FC RJ45 Plugs ............................................................................................ 4-24
4.14.2. Industrial Ethernet FC Modular Outlet RJ45 ....................................................................... 4-25


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-2 Training Document, V15.01.00
4. Network Components


SITRAIN
IK-TIAPN / Network Components Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... have a basic overview of the plant configurations
... know the various network topologies
... be familiar with network components
... know and understand the difference between active and passive
network components
... understand the FastConnect concept
... know the TIA Selection Tool and be able to use it to configure his
network configuration
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-3
4.1. System Configurations over the Course of Time

System Configurations
The demands on industrial systems in automation have kept evolving and increasing over the
years. As a result, technology and the technical possibilities have also been further developing.
In the beginning, without fieldbuses, system components were wired centrally to the controllers
and managed. With the establishment of fieldbus systems, came the first shift into industrial
automation. This saved cabling effort, installation time and cost. However, this also had a more
complex wiring of the system as a consequence. PROFIBUS, in particular, asserted itself here.
Since the Internet and thus also Ethernet components have become more and more common
and accepted in everyday life, the next step into industry was only a question of time. This was
then taken with Industrial Ethernet and PROFINET. Everyday Ethernet components were made
compatible for industrial use and so found their way into automation.
Distributed networks with switches and routers, the connection to the office world as well as
Industrial Security or even IWLAN are today a part of everyday life and are an integral part of
automation.
SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Network Components
System Configurations over the Course of Time
Central Not Central Distributed
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-4 Training Document, V15.01.00
4.2. Basic Structures of the Network Topology

Network Topologies
Network topologies are oriented toward the requirements of the devices to be networked. The
most common topologies include Line, Star and Ring structures. In reality, most systems consist
of mixed structures. These can be implemented with both electrical cables and with optical cables
(fiber optic cables).
Line
The line is the simplest network structure. It is characterized by the "backbone" of the network to
which the individual devices are connected either directly or via individual branches whereby
each branch only contains one device.
The advantage of the line topology is the easy construction which only requires limited hardware
investment. It is suitable, for example, for the large-scale networking of rigidly coupled machines
like in a production line.
Disadvantages of the line topology are that the resources are not fully utilized and that there is a
lack of redundancy: a break in the line at one location cannot be bridged.
A further limitation for networks with line structure is the physical arrangement of the network
devices. Depending on their position, the backbone must potentially be laid the long way around
which in turn can lead to problematic telegram runtimes. Line structuresare typically designed
with devices with two integrated network interfaces.
Ring
If the two ends of a line are connected by means of an additional connection, a ring structure is
created. The switches interconnected into a ring do not have to be exclusively connected with
fiber optic or electrical cables. A mixed electro-optical ring is also allowed.



SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Network Components
Basic Structures of the Network Topology
Line TreeStar
Ring
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-5
A ring topology without a special redundancy mechanism is not possible! This would lead to the
complete failure of the network. The special redundancy mechanism ensures that the ring
structure normally remains a logical line and consequently no telegrams go around in circles.
When a ring section fails, the mechanism makes it possible for an alternate route to be quickly
available in the ring: instead of via the direct, now interrupted route, the message goes via the
long, intact network section and reaches its recipient "indirectly". The network does not
disintegrate into two segments.
Star
The star topology differs from the line in that a switch acts as the "center" of a network from which
the cables branch to the individual end devices. The connection between the individual devices
thus no longer occurs directly but indirectly via the switch.
The immediate effect of this topology is that the messages no longer have to take “detours” via
other devices but are purposefully sent from the switch to the recipient. This means that the
network performance increases significantly since all devices of the star can communicate
simultaneously. In addition to the network performance, the reliability also increases. Should a
cable to a device fail, all other network components remain unaffected by it.
Tree
If several star topologies are connected with one another, this is called a tree topology. Typically,
these star structures are then aligned hierarchically.
Larger networks have this structure, especially when several topologies are combined with one
another. In most cases, a higher-level network element, either a coupler element or another
topology, forms the root. From there, a trunk with many branches is formed.
Intermeshed Topology
Intermeshed networks are when network components are linked multiple times. The network is
fully intermeshed when each component is connected with every other component. This topology
is usually used in an office but it is also used in industry for special cases such as energy
transportation. However, this topology cannot be implemented without a special protocol.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-6 Training Document, V15.01.00
4.3. Conceptual Design Information

Conceptual Design Information
When planning and wiring network components certain framework conditions have to be taken
into account. These are not ‘must’ obligations but are useful information on how to increase the
performance and the availability of the devices:
• Devices that have a high communication load should not be put at the end of line
structures.
• If line structures are planned, the increased failure risk must be taken into account and
must be considered in the plans.
• Due to their high data traffic, CPUs should always be connected to central switches.
• Use firewalls when integrating networks into higher-level networks or when connecting to
the Internet. Topic: Security
• Avoid bottlenecks when designing the network
• Configure networks in as structured a manner as possible



SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Network Components
Conceptual Design Information
Communication
bottleneck
Structure networks logically!
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-7
4.4. Network Components

Network Components
Industrial Ethernet networks can contain two types of network components. These network
components are divided into active and passive components.
Passive Components
Network components which do not have an active influence on the signal are classified as
passive components. Normally, all connection technology components such as plugs,
connectors, cables, etc. fall into this category.
A listing of all passive components can be found in the Industry Online Support pages under the
Entry ID: 84922825.
Active Components
Network components which actively influence the signal in the network are classified in the
category of active components. This can be a signal processing or even the rejection of a
telegram. Examples of active components are switches, access points, repeaters, media
converters or even Link modules.

SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Network Components
Network Components
Passive Components Active Components
Forward a signal without actively
influencing it
Influence the signal
ID: 84922825
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-8 Training Document, V15.01.00
4.5. Cable Categories for Twisted-Pair Cables

Categories for Twisted-Pair Cables
According to EIA/TIA-568, ISO/IEC-11801, EN50173 and EN 50288-x-x, TP cables are divided
into different categories or levels. They specify the electrical minimum requirements for the cable
and essentially specify the maximum permissible transmission frequency. Currently the
Categories 1 to 7 are defined. The permissible transmission frequency increases with the cable
category. A Twisted-Pair cable of a certain category complies with the requirements of the
respective category and with those categories below that.
Category 1 (CAT1)
Category 1 cables are designed for voice transmission in telephony and for data transmission at a
low transmission frequency of less than 1MHz. Nowadays, such cable is no longer used.
Category 2 (CAT2)
CAT2 cables are designed for transmission frequencies of up to 4MHz. Such cable types were
frequently used for house cabling such as for ISDN.
Category 3 (CAT3)
A CAT3 cable is designed for a transmission frequency of up to 10MHz and so permits a
transmission speed of up to 10Mbit/s and a maximum cable length of 100m. Nowadays, such
cable types really no longer find a use in the LAN area.
Category 4 (CAT4)
Cables of the CAT4 cable type are designed for transmission frequencies of up to 20MHz and
transmission speeds of up to 16Mbit/s. These were frequently used in Token Ring networks.
Category 5 (CAT5)
Transmission frequencies up to 100MHz are specified in Category 5. Here, transmission speeds
of up to 100Mbit/s are possible.
SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Network Components
Cable Categories for Twisted-Pair Cables
The Category (CAT) specifies for which
transmission speed and which maximum length
a cable designed
Category Transmission speed
CAT1 ---
CAT2 ---
CAT3 10MBit/s
CAT4 16MBit/s
CAT5 100MBit/s
CAT5e 1GBit/s
CAT6 1GBit/s
CAT6a 10GBit/s
CAT6e 10GBit/s
CAT7 10GBit/s
CAT8 40GBit/s
Still in the
development stage
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-9
Category 5e (CAT5e)
As far as the quality of the cable is concerned, there is no difference between Category 5 and
Category 5e. So that a cable fulfills the conditions for Category 5e, more rigorous acceptance
measurements are however necessary. These measurements are defined through the
ANSO/TIA/EIA-TSB-67 standard. If these criteria are fulfilled, a CAT5e cable is also authorized
for the operation of 1000BASE-T, that is, 1GBit/s.
Category 6 (CAT6)
Cables of the CAT6cable type are designed for transmission frequencies of up to 250MHz and
transmission speeds of 1GBit/s. Category 6 is extended by the two sub-categories 6a and 6e.
Category 6a (CAT6a)
The “a” for Category 6a cable types stands for “augmented”, that is, improved. Such cables are
specified for transmission frequencies of up to 625MHz and thus permit transmission speeds of
up to 10GBit/s and cable lengths of up to 100m.
Category 6e (CAT6e)
Cables of the CAT6e cable type permit frequencies of a maximum of 500MHz and a maximum
length of 55m for a transmission speed of 10GBit/s.
Category 7 (CAT7)
For Category 7 cables, transmission frequencies of up to 600MHz are permitted and a
transmission speed of up to 10GBit/s. Since, however, the requirements for shielding are very
high in Category 7, this not only has an impact on the cable itself but also on the connector
technology and the assembly of these. Category 7 connectors must fulfill either the IEC 60603-7-
7 standard or the IEC 61076-3-104 standard.
Category 8 (CAT8)
In Category 8, a transmission rate of 40GBit/s and a maximum frequency of 2000MHz is planned.
However, this specification is currently still in the planning stages.
Note
The specific cabling of industrial plants is defined in the IEC 61918 standard and the structured
cabling of industrial buildings is defined in the ISO/IEC 24702 standard.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-10 Training Document, V15.01.00
4.6. FastConnect

FastConnect
FastConnect is a cabling system consisting of cables, plugs and tools for PROFIBUS and
Industrial Ethernet/PROFINET networks, available for copper and glass fiber optic cables for on-
site assembly.
FastConnect can be assembled quickly and easily on-site. As a result, the RJ45 cabling
technology, as an existing standard, is also available as an industry-suitable design.
IE FC RJ45 Plugs
The IE FC RJ45 plugs are compact and rugged connectors. They have a rugged, industry-
suitable metallic enclosure which protects the data communication against interference. The
plugs conform to the EN 50173 (RJ45) and ISO/ IEC 11801 standards.
IE FC TP Cable
The FastConnect (FC) Twisted Pair (TP) cables are shielded, radial symmetrically designed
cables with 100 Ohms surge impedance.
The combination of twisting the wires, foil shield and braided shield make the FC cables
particularly suitable for installation in an electromagnetic industrial environment. The design also
guarantees great stability of the electrical and mechanical data in the installed state.
With the IE FC Stripping Tool, it is possible to remove the correct length of outer sheath and
shield of the FC TP cables in one go.
Stripping Tool
With the Industrial Ethernet FastConnect (IE FC) Stripping Tool, the correct length of outer sheath
and shield can be removed from Industrial Ethernet FastConnect cables. The IE FC cable
prepared this way is connected to the plug or the outlet via cutting/clamping contacts. For the IE
FC Stripping Tool there are two knife cassettes with different knife clearances. The IE FC
Stripping Tool is delivered with a yellow knife cassette.
Note
The IE FC Stripping Tool may be used only for stripping SIMATIC NET Industrial Ethernet
FastConnect cables. If the tool is used in any other manner, it can lead to accidents or the
destruction of tool and cable.
SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Network Components
FastConnect
Stripping tool for IE
FC cables
Special IE FC cable
IE FC RJ45 plug
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-11
4.7. Task Description: Cabling with FastConnect

Task Description
You are to do a theoretical check of the Ethernet cabling of the training devices. In this context,
you are to remove the insulation from an Ethernet cable and then assemble an RJ45 plug.
SITRAIN
IK-TIAPN / Network Components Page 10 Siemens AG © 2016
Task Description:
Cabling with FastConnect
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-12 Training Document, V15.01.00
4.7.1. Exercise 1: Stripping with the Help of the Stripping Tool

Task
You are to remove the insulation from a Siemens Industrial Ethernet FastConnect cable.
What to Do
1. Prepare the cable in such a way that you have a clean cut edge.
2. Use the Stripping Tool to measure the required length for removing the insulation.
3. Carry out the cable stripping as shown in the picture.
4. Untwist the stripped cable.
Note
So that the insulation is cleanly removed from the cable, the knife cassette of the Stripping Tool
must be adjusted. Use the Allen key provided for this.


SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Network Components
Exercise 1:
Stripping with the Help of the Stripping Tool
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-13
4.7.2. Exercise 2: Assembling the IE Cable

Task
You are to assemble a FastConnect RJ45 plug using the cable you stripped in Exercise 1.
What to Do
1. Prepare the RJ45 plug assembly by imitating the color coding of the plug on the cable.
2. Open the IE FC RJ45 plug. If necessary, use a suitable screwdriver.
3. Carry out the assembly steps as shown in the picture.
4. Close the IE FC RJ45 plug and test its functioning.



SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Network Components
Exercise 2: Assembling the IE Cable
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-14 Training Document, V15.01.00
4.8. Optical Cabling and Connecting Methods

Fiber Optic Cable
For fiber optic cables, data transmission occurs through the modulation of electromagnetic waves
in the range of visible and invisible light.
High quality plastic and glass fiber optic is used.
For Industrial Ethernet, there are different fiber optic cable types which offer tailored solutions for
the various operating and ambient conditions for the connection of network components to one
another.
The following fiber optic cables are offered for Industrial Ethernet:
• Glass fiber optic cable
• PCF fiber optic cable
• POF fiber optic cable
Glass fiber optic cables are used for long distances. For short distances, plastic optical fiber such
as Polymer Optic Fiber (POF) or plastic-coated glass fiber optic such as Polymer Cladded Fiber
(PCF) are recommended.
Some advantages of using fiber optic cables vis-à-vis electrical cables are:
• Galvanic isolation of devices and segments
• No potential equalization necessary
• No shield currents
• No influencing of the transmission paths through external electromagnetic interferences
• No interfering transmissions along the transmission route
• …

SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Network Components
Optical Cabling and Connecting Methods
Cables
▪ Plastic fiber optic cable (POF*/PCF*)
▪ Glass fiber optic cable according to IEC 60793, 60794
IP 20 plug-in connector
▪ SC RJ push/ pull plug for POF, PCF, Glass
fiber optic cable
▪ SC push pull/ST plug for glass fiber optic cable
IP 65/67 plug-in connector
▪ Connector face compatible with IP20 version
▪ Push/ pull plug with integrated SC RJ plug
* POF = Polymer Optic Fiber
* PCF = Polymer Cladded Fiber
Fiber optic cable transmission technology according to IEC 8802-3
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-15
4.9. Active Industrial Ethernet Components

Active Industrial Ethernet Components
Active Industrial Ethernet components are network components which have an active influence
on the signal or the telegram.This includes stand-alone devices such as switches, media
converters, link modules or even communication modules (CM) and communication processors
(CP).
Siemens Tools such as the TIA Selection Tool or the SIMATIC NET Selection Tool provide
support for the selection of suitable components for the specific application.

SITRAIN
IK-TIAPN / Network Components Page 14 Siemens AG © 2016
Active Industrial Ethernet Components
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-16 Training Document, V15.01.00
4.10. Industrial Wireless LAN Components

Industrial WLAN Components
The SCALANCE W products can be subjected to fluctuations in the extended temperature range
without coming into contact with dust and water. Rugged enclosures and mechanical protection
against jolts and vibration enable the use in a harsh industrial environment. Even the accessories
such as antennas, power supplies and cabling are part of this concept and are manufactured to
industry standards. Energy and data are transmitted with Power-over-Ethernet via a cable and so
save investment and maintenance costs. The removable media C-PLUG (Configuration Plug)
stores project engineering and configuration data which enables a quick device exchange and
without specially trained personnel. This minimizes downtimes and saves training costs.
To protect against unauthorized access, the products provide modern standard mechanisms for
user identification (Authentication) and data encryption and can simultaneously be integrated in
existing safety concepts without a problem.
With the international IEEE 802.11n standard, wireless communication via IWLAN is even more
robust. The greatest advantage results from the use of multipath scattering (Multiple Input,
Multiple Output (MIMO)). This allows the devices to use several antennas in parallel. In this way,
a higher data rate is achieved and at the same time the susceptibility to interference in
environments with many reflexions is reduced.
Access Points
The access points are the central base stations for infrastructure networks. They coordinate and
control the wireless communication within a wireless (radio) cell. If two or more access points are
located in one wireless network, that is, the same wireless network name (SSID), the client
module can switch between the wireless cells which are formed by the individual access points
(roaming). The wireless connection is thereby maintained. This method is used when the required
wireless coverage is greater than the range of an access point. All access points can also be
configured in such a way that their functionality is limited to that of a client.

SITRAIN
IK-TIAPN / Network Components Page 15 Siemens AG © 2016
Industrial Wireless LAN Components
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-17
Client Modules
The client modules of the SCALANCE W product line are used as a gateway from wireless to
wired network segments (bridge function). Usually they communicate with an access point
(infrastructure network).
iFeatures
With the help of a Key Plug, additional functionalities can be activated for special SCALANCE
switches. For the 780s and 740s series, these additional functionalities include the so-called
iFeatures such as iREF, iPCF, etc.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-18 Training Document, V15.01.00
4.11. Communication Processors (CPs) for IE

Communication Processors (CPs) / Communication Modules (CMs)
Communication processors and communication modules expand the controller by a further
interface. The maximum number of CPs and CMs which can be connected to a controller
depends on their performance class.
A CM or CP allows further networks to be connected to the controller. These, however, do not
have to be connected to the networks of the internal interface of the PLC, but rather a stand-
alone operation of these networks can take place.
CPs and CMs furthermore relieve the internal PLC processor of communication tasks and add
further possible connections. Unlike CMs, CPs additionally expand the functionalities of the
controller (Security, ISO, FTP,…).
Both components are connected to the controller via the internal backplane bus.
The exact properties of the respective CMs and CPs can be obtained from their device manuals
which can be found on the Service and Support pages.

SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Network Components
Communication Processors (CPs) for IE
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-19
4.12. TIA Selection Tool

TIA Selection Tool
Both the active as well as the passive components must withstand harsher ambient conditions in
the industrial environment than in the office world. This is noticeable in many ways!
With the TIA Selection Tool you can select, configure and order devices for Totally Integrated
Automation. It is the successor to the SIMATIC Selection Tool and combines already familiar
configurators for automation in one tool. You can start it directly in the Siemens Industry Mall or
download it as a file.
The TIA Selection Tool provides you with wizards for selecting the desired devices and networks.
As well, there are configurators for selecting modules and accessories as well as for checking the
correct functioning. The TIA Selection Tool generates a complete order list from your product
selection or product configuration. You can export this directly into the Industry Mall or the CA 01
shopping cart.
With the TIA Selection Tool, you can select and configure the SIMATIC S7, SIMATIC ET 200,
SIMATIC HMI Panels, SIMATIC IPC, SIMATIC HMI Software and Industrial Communication
components. Beyond that, you can create PROFIBUS and PROFINET networks, configure their
topology as well as select associated cables and connectors.
Further information on the TIA Selection Tool can be found via the following link:
http://w3.siemens.com/mcms/topics/de/simatic/tia-selection-tool/Seiten/tab.aspx
The TIA Selection Tool can be started directly online via the following link:
https://www.siemens.com/tia-selection-tool/start
SIMATIC NET Selection Tool
The SIMATIC NET Selection Tool is a slimmed down version of the TIA Selection Tool which only
deals with industrial communication and only has Industrial Ethernet components for selection.
More information on the SIMATIC NET Selection Tool can be found on the Service and Support
pages under the following Entry ID: 39134641
The SIMATIC NET Selection Tool can also be started directly online via the following link:
http://www.siemens.de/snst
SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Network Components
TIA Selection Tool
http://w3.siemens.com/mcms/topics/de/simatic/tia-selection-tool/Seiten/tab.aspx
https://www.siemens.com/tia-selection-tool/start
http://www.siemens.de/snst
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-20 Training Document, V15.01.00
4.13. Task Description: Reading-out the Firmware of the Devices &
Configuration of the System in the TIA Selection Tool

Task Description
Since all network components have an IP address which is located in the same subnet as our
Field-PG, the firmware of all devices can be read out. This is required afterwards in order to
configure the system in the TIA Selection Tool.
SITRAIN © Siemens AG 2018
Page 18
IK-TIAPN
Network Components
Task Description: Reading-out the Firmware of the Devices &
Configuration of the System in the TIA Selection Tool
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document,V15.01.00 4-21
4.13.1. Exercise 3: Reading-out the Firmware of the Devices (TIA Portal)

Task
With the help of the TIA Portal, you are to read-out the firmware of all accessible devices. This is
best done via the ‘Online access’ and from there via the accessible devices.
What to Do
1. Display all connected devices via the function “Update accessible devices” in the ‘Online
access’ tab.
2. The firmware of the network components can be obtained via Online & diagnostics and there
in the menu item “General” which is located under Diagnostics (see picture).
3. Determine the firmware of the S7-1513-1PN:__________________________
4. Determine the firmware of the ET200SP:_____________________________
5. Determine the firmware of the SCALANCEX208:_______________________
6. Determine the firmware of the S7-1510SP-1PN:________________________
Note
For this task, you still don’t need a project!
The firmware of a module can only be read out if the module has an IP address and this IP
address has the same network address as the device through which the firmware is to be read
out with the help of the TIA Portal.
Example:
S7-1513-1PN: IP address: 192.168.222.1 // Subnet mask: 255.255.255.0
 Network address: 192.168.222.0
Field PG: IP address: 192.168.222.250 // Subnet mask: 255.255.255.0
 Network address: 192.168.222.0
Reading out the firmware via the TIA Portal would be possible in this case!
SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Network Components
Exercise 3: Reading-out the
Firmware of the Devices (TIA Portal)
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-22 Training Document, V15.01.00
4.13.2. Exercise 4: Configuration of the System in the TIA Selection Tool

Task
You are to create the hardware configuration of your system in the TIA Selection Tool. You are
then to network the devices in the Network view and assign the ET200SP to the correct IO-
Controller.
What to Do
1. Open the TIA Selection Tool.
2. Create the setpoint configuration of the system so that it matches your actual configuration.
3. Supplement your programming device.
4. Network the devices according to your wiring.
5. Assign the ET200SP IO-Device to the correct IO-Controller.
6. Save the TIA Selection Tool project.
7. Export your configuration.
SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Network Components
Exercise 4: Configuration of the System
in the TIA Selection Tool
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-23
4.14. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Netzkomponenten Seite 21 Siemens AG © 2016
Wenn Sie noch mehr wissen wollen
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Network Components
4-24 Training Document, V15.01.00
4.14.1. Versions of IE FC RJ45 Plugs

IE FC RJ45 Plugs
The IE FC RJ45 plugs are compact and rugged connectors. They have a rugged, industry-
suitable metallic enclosure which protects the data communication against interference. The
plugs conform to the EN 50173 (RJ45) and ISO/ IEC 11801 standards. They are available in two
pin versions. Once as the IE FC RJ45 plug in 2x2 version for Fast Ethernet cables with 4 wires
and then the IE FC RJ45 plug in 4x2 version for Gigabit Ethernet cables with 8 wires.
IE FC RJ45 Plug 2x2
The IE FC RJ45 plug 2x2 is, for its part, available in three versions. These differ in the cable
outlet of the plug:
• With 180° (straight) cable outlet:
Due to the design, the IE FC RJ45 Plug 180 can be used both on devices with single
sockets as well as on devices with multiple sockets (blocks). The plug is suitable for
connecting IE FC TP cables to SIMATIC NET modules and SCALANCE devices.
• With 90° (angled) cable outlet:
The plug is suitable for connecting IE FC TP cables to ET200 or PN/PN couplers.
• With 145° (angled) cable outlet:
The plug is suitable for connecting IE FC TP cables to SIMOTION and SINAMICS
modules.
IE FC RJ45 Plug 4x2
The IE FC RJ45 plug 4x2 is only available in one version:
• With 180° (straight) cable outlet:
Through the plug, point-to-point connections (10 / 100 / 1000 Mbit/s) for Industrial
Ethernet can be implemented between two terminals/ network components of up to 90 m
without patch technology.
SITRAIN © Siemens AG 2018
Page 22
IK-TIAPN
Network Components
Versions of IE FC RJ45 Plugs
IE FC RJ45 Plug 4x2
IE FC RJ45 Plug 145°
IE FC RJ45 Plug 4x2
IE FC RJ45 Plug 180° IE FC RJ45 Plug 90°
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Network Components
Training Document, V15.01.00 4-25
4.14.2. Industrial Ethernet FC Modular Outlet RJ45

Industrial Ethernet FastConnect Modular Outlet RJ45
The Industrial Ethernet FC Modular Outlet RJ45 serves the transition from the rugged Industrial
Ethernet FC TP cables used in the industrial environment to pre-assembled TP Cord cables by
means of an RJ45 socket. In combination with FC TP cables and pre-assembled TP Cords, the
Industrial Ethernet FC Modular Outlet RJ45 ensures time-saving installations. A color coding
prevents errors during wire insertion. The Industrial Ethernet FC Modular Outlet RJ45
corresponds to Category 5 of the ISO/IEC 11801 and EN 50173 international cabling standards.
Modular Outlet Basic Module
The Industrial Ethernet FC RJ45 Modular Outlet basic module is available with three
interchangeable inserts:
• Insert 2 FE:
Basic module with interchangeable insert for two Fast Ethernet connections for
connecting two 10/100 Mbit/s terminals/network components.
• Insert 1 GE:
Basic module with interchangeable insert for one Gigabit Ethernet connection for
connecting one 10/100/1000 Mbit/s terminal/network component.
• Outlet Power Insert:
Basic module with interchangeable insert for one power supply and one 10/100 Mbit/s
terminal/network component.

SITRAIN © Siemens AG 2018
Page 23
IK-TIAPN
Network Components
IE FC Modular Outlet RJ45
Insert 1x Gigabit EthernetInsert 2x Fast Ethernet Outlet Power Insert
IE FC Modular Outlet RJ45
Outlet open and
wired
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-1

Contents 5





5. PROFINET Configuration ....................................................................................... 5-2
5.1. Manual Commissioning of a PN IO-System ......................................................................... 5-3
5.2. Manual Commissioning Sequence ....................................................................................... 5-5
5.3. Name Assignment using the TIA Portal with Project ............................................................ 5-6
5.3.1. Definition of the PROFINET Device Name in the Project ..................................................... 5-6
5.3.2. Assigning the PROFINET Device Name via the Project ...................................................... 5-7
5.3.3. Writing the PROFINET Device Name onto the MMC ........................................................... 5-8
5.4. Name Assignment using the TIA Portal without Project ....................................................... 5-9
5.5. Download the PROFINET-IO Configuration to the IO-Controller ....................................... 5-11
5.6. Device Exchange without Programming Device ................................................................. 5-12
5.7. Task Description: Commissioning the S7-1500 Case ........................................................ 5-13
5.7.1. Exercise 1: Creating a Project ............................................................................................5-14
5.7.2. Exercise 2: Configuring and Parameterizing the S7-1500 .................................................. 5-15
5.7.3. Exercise 3: Creating a TP700 Comfort ............................................................................... 5-16
5.7.4. Exercise 4: Configuring and Parameterizing the ET200SP ................................................ 5-17
5.7.5. Exercise 5: Networking & Grouping the Devices ................................................................ 5-18
5.7.6. Exercise 6: Inserting a Tag Table from the Library ............................................................. 5-19
5.8. Additional Information ......................................................................................................... 5-21
5.8.1. Device Number of an IO-Device ......................................................................................... 5-22


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-2 Training Document, V15.01.00
5. PROFINET Configuration


SITRAIN
IK-TIAPN / PROFINET Configuration Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... be able to configure PROFINET-IO networks in the TIA Portal
... be able to assign parameters to an IO-Device
... understand the storing of PROFINET device names
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-3
5.1. Manual Commissioning of a PN IO-System

Manual Name Assignment for a PROFINET IO-System
So that the individual devices are accessible during system startup of the IO-Controller, they are
given device names. This is done during the manual commissioning of the PN IO-System by the
IO-Supervisor.
If the commissioning is done manually, it must however be kept in mind that the device names
which are downloaded into the IO-Controller via the hardware configuration must match those
which the IO-Supervisor assigns to the individual IO-Devices. That is, the device names which
were assigned offline for the individual IO-Devices must match the online device names. This is
comparable with the setting of the PROFIBUS address. If errors are made here, the IO-Device
cannot be reached by the IO-Controller.
The PROFINET name of a device must comply with the PROFINET name convention!

PROFINET Name Convention
The following lists the rules for the converted name. The hardware configuration checks whether
the name conventions are complied with and, if necessary, corrects them. If the converted name
is not to differ from the name of the module, then the name of the module must satisfy these
rules:
• The name is limited to a total of 128 characters (letters "a" to "z", numbers "0" to "9",
hyphen or dot)
• The name consists of one or more labels, which are to be separated by a dot ".".
• A label within the device name, that is, a character string between two dots, may be a
maximum of 63 characters.
• No special characters such as vowel mutations, brackets, underscore, forward slash,
blank etc. The hyphen is the only special character allowed.
• No capital letters may be used in the device name.
• The device name must not begin with the characters "-" or "." and it must not end with
these characters.
SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
PROFINET Configuration
Manual Commissioning of a PN IO-System
Load configuration
onto IO-Controller
Namen zuweisen über
TIA-Portal, C-Plug oder MMC
Namen zuweisen über
TIA-Portal, C-Plug oder MMC
Namen zuweisen über
TIA-Portal, C-Plug oder MMC
Assign name via
TIA Portal, C-Plug or MMC
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-4 Training Document, V15.01.00
• The device name must not begin with numbers.
• The device name must not begin with the character string "port-xyz-" (x, y, z = 0...9).
• The device name must not have the format n.n.n.n (n = 0...999)
Device names are assigned to the PROFINET IO devices in the commissioning phase.


Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-5
5.2. Manual Commissioning Sequence

Manual Commissioning Sequence of a PROFINET IO-System
The manual commissioning of a PROFINET IO-System can be divided into the following steps:
• Delivered condition / Factory settings:
The device is commissioned for the first time or it is reset to its factory settings. The
device has no IP address and no device name. It can only be addressed via its MAC
address.
• Device name assignment:
If the commissioning is done manually, the IO-Device can be assigned a device name in
two ways. The device name can always be written in the IO-Device by the IO-Supervisor.
For this, various software packages can be used (TIA Portal, PST-Tool, etc…). If the IO-
Device supports an MMC, the device name can also be written directly onto the card
using the PG or using a PC with a connected USB prommer.
• Downloading the PROFINET-IO configuration into the IO-Controller:
After all devices have been assigned a device name either directly via the relevant tools
or using the MMC card, the PN-IO configuration is downloaded into the IO-Controller.
• IP addresses assignment:
After the PN-IO configuration is downloaded into the IO-Controller, the controller
searches for the PROFINET device names in the network during startup. As soon as one
of these names has been found, the IO-Controller assigns the IP address stored in the
configuration for this name. The IO-Controller and not the IO-Supervisor assigns the IP
address to the IO-Device.
Note
If the IO-Supervisor writes the device name directly in the IO-Device and there is an MMC or a C-
Plug in the device at the time, the device name is stored on this medium and so permits a device
exchange without programming device.

SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
PROFINET Configuration
Manual Commissioning Sequence
Delivered condition / Factory settings
Device only has a MAC address
IO-Supervisor writes the device name in the IO-
DEVICE or on the MMC of the IO-Device
IO-Supervisor downloads the PROFINET-IO
configuration into the IO-Controller
IO-Controller recognizes the
IO-Device via the name and writes the IP address
in this IO-Device during system startup
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-6 Training Document, V15.01.00
5.3. Name Assignment using the TIA Portal with Project
5.3.1. Definition of the PROFINET Device Name in the Project

Name Assignment using the TIA Portal with Project
The TIA Portal makes it possible to assign names to IO-Devices with or without a project.
Definition of the PROFINET Device Name in the Project
The user can define the PROFINET device name with the help of a project either in the Device
view or in the Topology view in the Properties of the IO-Device.
The PROFINET device name of a PROFINET device is either automatically generated or
assigned manually by the user. If the option: “Generate PROFINET device name automatically” is
activated, the PROFINET device name is derived from the general name of the device. If this is
not the case, a name can be assigned here which differs from the general name.
Activating or deactivating this function has no influence on the control and the compliance with
the PROFINET name convention, however. This is always executed by the TIA Portal and the
name assigned by the user is automatically corrected by the system in case of an error.
Whether the name complies with the convention or not can be checked in the field: “Converted
name”. If the converted name complies with the PROFINET device name, the PROFINET device
name is defined accordingto the PROFINET name convention. This is a benefit for the user
because he can immediately carry out the control of the name convention while defining the
device name!
Note
The PROFINET device name must not have any capital letters. These are automatically
converted into lowercase letters by the TIA Portal. Attention should be paid to this when assigning
the device name.

SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
PROFINET Configuration
Name Assignment using the TIA Portal with Project:
Definition of the PROFINET Device Name
Possible in Network view
and Topology view
PROFINET device name is standard-compliant PROFINET device name is not standard-compliant
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-7
5.3.2. Assigning the PROFINET Device Name via the Project

Assigning the PROFINET Device Name via the Project
The assignment of the name defined in the hardware configuration of the IO-Controller for the
respective IO-Device can either be done in the Device view or in the Topology view. A right-click
on the IO-Device calls the dialog “Assign device name”.
In the dialog that now opens, the name stored in the hardware configuration can be assigned to
the selected IO-Device. This PROFINET device name can no longer be changed in this step! The
advantage of this method is that the PROFINET device name which the IO-Controller searches
for during its startup always matches the device name which is loaded on the IO-Device!
Note
A right-click on the PROFINET IO-System also calls the dialog “Assign device name”. The
difference here to the execution on the IO-Device is that now the PROFINET device name which
is to be assigned can be selected via a selection window. That is, all available PROFINET-IO
Device names are displayed for selection which now can be assigned successively.
For the assignment of several IO-Devices, this is in particular a considerable reduction in
workload!

If an MMC or a C-Plug is inserted in the IO-Device while the PROFINET device name is being
written to the device, the device name is written onto the MMC / C-Plug and is lost on the device
when the MMC / C-Plug is pulled!
SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
PROFINET Configuration
Name Assignment using the TIA Portal with Project:
Assigning the Device Name
Writes the name directly in
the IO-Device
Possible in Network view
and Topology view
Name cannot be changed
Found IO-Device of the
same type
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-8 Training Document, V15.01.00
5.3.3. Writing the PROFINET Device Name onto the MMC

Writing the PROFINET Device Name onto the MMC
If a Micro Memory Card is inserted in the PG or the USB prommer, the PROFINET device name
can also be written directly onto the MMC and then inserted into the IO-Device. The IO-Device
then adopts the PROFINET device name during its startup.
This function can be executed both in the Device view and the Topology view by right-clicking on
the IO-Device.
Note
The function “Write IO-Device name to Micro Memory Card” is only displayed if the IO-Device
supports this function!

SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
PROFINET Configuration
Name Assignment using the TIA Portal with Project:
Writing the Device Name onto the MMC
MMC must be
inserted in the PG/PC
Possible in Network
view and Topology view
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-9
5.4. Name Assignment using the TIA Portal without Project

Name Assignment using the TIA Portal without Project
With the help of the TIA Portal, every IO-Device can be assigned a PROFINET device name. For
this, no additional software and also no project is required.
The user can search for all accessible devices using the ‘Online access’. Then, the IO-Device to
be initialized is selected and the function: “Online & diagnostics” is called. Here, in the “Functions”
tab and the “Assign name” menu item, the IO-Device can be assigned a PROFINET device
name. However, it must be noted here that the user must enter the name himself. If this name
later does not match the name that is loaded into the IO-Controller, the IO-Controller will not be
able to find this IO-Device.

Note
The IO-Device does not require an IP address to execute the “Assign name” function! However, it
must be noted that to identify the IO-Device with the help of the TIA Portal, the following
requirements must be fulfilled:
• The IO-Device must be assigned an IP address.
• The IP address of the IO-Device must be located in the same subnet as the PG or the
PC on which the TIA Portal is installed.

SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
PROFINET Configuration
Name Assignment using the TIA Portal without Project:
Defining and Assigning the Device Name
Select the desired IO-Device
via the interface
Manually assign device name
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-10 Training Document, V15.01.00
If these requirements are fulfilled, the IO-Device is presented in the “General” tab as follows:

If these are not fulfilled, this presentation is as shown:

With the help of the TIA Portal, a temporary IP address can be assigned to every IO-Device!


Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-11
5.5. Download the PROFINET-IO Configuration to the IO-Controller

Downloading the PROFINET-IO Configuration
After all IO-Devices have been assigned a PROFINET device name, the PROFINET-IO
configuration must finally still be downloaded to the IO-Controller. This is executed by
downloading the hardware configuration into the IO-Controller. In the HW-Config, all device
names of the IO-Devices are stored which are assigned to this IO-Controller. Then during its
startup phase, the IO-Controller searches for the PROFINET device names. It assigns the
PROFINET-IO configuration which is stored in the hardware configuration to the corresponding
IO-Device names.
Configuration Time for an IO-Device
In the hardware configuration of the IO-Controller, you can define in the menu item: “Startup” the
maximum time the IO-Controller is to try to configure (parameterize) the IO-Device. The default
setting for this option is 60 seconds. The IO-Controller will try for 60 seconds to configure
(parameterize) each IO-Device.
Note
If, after downloading the hardware configuration using the TIA Portal, the option: “Start all” is
selected, the IO-Device cannot be configured by the IO-Controller. The TIA Portal cannot be
addressed for the set configuration time!

SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
PROFINET Configuration
Downloading the PROFINET-IO
Configuration to the IO-Controller
PROFINET-IO configuration is
downloaded via the HW-Config
Maximum configuration time for
each IO-Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-12 Training Document, V15.01.00
5.6. Device Exchange without Programming Device

Device Exchange without Programming Unit
As previously mentioned, there are PROFINET-IO Devices which support an MMC or a C-Plug.
These make the function: “Device replacement without programming device” possible in the
PROFINET-IO System.
Since, for an IO-Device with an MMC or a C-Plug, the PROFINET device name is not written in
the internal memory of this IO-Device, the MMC or the C-Plug can simply be removed from the
defective device and inserted in the exchange IO-Device when a device fails. The new IO-Device
is automatically initialized with the PROFINETdevice name of the defective device and the
PROFINET-IO System continues running without an error.
Premise for this of course is that the new IO-Device has the same configuration as the defective
IO-Device.
Note
The removable media, that is, the MMC or the C-Plug, must be purchased separately!


SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
PROFINET Configuration
Device Exchange without Programming Device
Removable media MMC Removable media C-Plug
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-13
5.7. Task Description: Commissioning the S7-1500 Case

Task Description
You are to commission the 1500 case. You are to create the hardware configuration of the
different devices and parameterize the individual modules. Then you are to network them and
load the individual devices with the information from the project.
SITRAIN
IK-TIAPN / PROFINET Configuration Page 11 Siemens AG © 2016
Task Description:
Creating a Project + Commissioning the 1500 Case
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-14 Training Document, V15.01.00
5.7.1. Exercise 1: Creating a Project

Task
You are to create a new TIA Portal project in which you will solve most of the following tasks. You
can decide what name you wish to give your project and also where you want to store it!
What to Do
1. Open the TIA Portal.
2. In either the Project view or in the Portal view, create a new project. The name assignment is
you choice. You can define the storage location anywhere on D-drive.

SITRAIN
IK-TIAPN / PROFINET Configuration Page 12 Siemens AG © 2016
Exercise 1: Creating a Project
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-15
5.7.2. Exercise 2: Configuring and Parameterizing the S7-1500

Task
You are to configure and parameterize the S7-1500. The digital input and output modules are to
be given the addresses from 0-3 and the analog input module is to be given the range from 44-
59.
The S7-1500 gets the IP address 192.168.222.13 with the subnet mask 255.255.255.0. The
device name is: “1513-io-controller”.
What to Do
1. Add an unspecified S7-1500 to your project.
2. Detect the configuration of the connected S7-1500.
3. Adjust the I/O addresses of the modules according to the picture and the task.
4. Assign the IP address 192.168.222.13 with the subnet mask 255.255.255.0.
5. The CPU gets the name: 1513-io-controller.
6. Save your project.


SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
PROFINET Configuration
Exercise 2:
Configuring and Parameterizing the S7-1500
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-16 Training Document, V15.01.00
5.7.3. Exercise 3: Creating a TP700 Comfort

Task
You are to create a new Comfort Panel TP700 Comfort. This Panel does not have to have any
content but must simply exist in the project. The Panel gets the IP address 192.168.222.70 with
the subnet mask 255.255.255.0. The device name for the Panel is “touch-me”.
What to Do
1. Insert a new TP700 Comfort in your project.
2. Set the interface of the Panel to the IP address 192.168.222.70 with the subnet mask
255.255.255.0.
3. Name the Panel “touch-me”.
4. Save your project.
5. Download the Panel with your changes.



SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
PROFINET Configuration
Exercise 3: Creating a TP700 Comfort
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-17
5.7.4. Exercise 4: Configuring and Parameterizing the ET200SP

Task
In your project, you are to generate an ET200SP and configure as well as parameterize it. The
digital inputs and outputs are to be in the address range of 4-5, the analog I/Os get the range 6-
13. The ET200SP is assigned the IP address 192.168.222.200 with the subnet mask
255.255.255.0. The PROFINET device name for the IO-Device is “et200sp-io-device”. After the
configuration and parameterization, assign this name to the Online-Device. The initial generation
of the ET 200SP occurs via the Hardware detection. Subsequently, the configuration and
parameterization still has to be completed.
What to Do
1. Generate a new ET 200SP. For this, use the menu command: "Hardware detection / IO
devices" in the "Online" menu in the menu bar of TIA Portal.
2. If necessary, carry out changes in the parameterization of the ET 200SP that still have to be
made according to the task.
3. Assign the IP address 192.168.222.200 with the subnet mask 255.255.255.0 for the IO-
Device.
4. Offline in the Hardware Configuration rename the ET 200SP "et200sp-io-device".
5. Go into the Properties of the “AI 4xU/I 2-wire ST” module and adjust the potential group to
“Enable new potential group (light BaseUnit)”.
6. Save your project.
7. Assign the Online-Device the device name just configured.
Note
The modules can only be parameterized after the devices have been networked. Therefore, work
through the following exercise and then return to this exercise!

SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
PROFINET Configuration
Exercise 4:
Configuring and Parameterizing the ET200SP
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-18 Training Document, V15.01.00
5.7.5. Exercise 5: Networking & Grouping the Devices

Task
You are to network all devices in the Network view and check the settings such as IP address
and device name. With the networking, a PROFINET IO-System between the ET200SP and the
S7-1500 is to result.
Finally, you are still to group the devices in the TIA Portal Project tree. For this, you are to create
a group with the name: "1513Case".
What to Do
1. Switch to the “Network view” in your project.
2. Network the individual devices one below the other.
3. Check the IO-System between S7-1500 and ET200SP. The ET200SP must be assigned to
the S7-1500 as an IO-Device.
4. Then parameterize the I/O addresses of the ET200SP according to the task from the previous
exercise.
5. Check the IP addresses of the individual modules as well as their device names.
6. Also check whether the option: “Generate PROFINET device name automatically” is activated
for each PROFINET interface:

7. In your Project tree, create a new group with the name "1513Case". Then, assign the S7-
1500, the ET 200SP as well as the TP700 to this group.
8. Save your project.
SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
PROFINET Configuration
Exercise 5: Networking & grouping the Devices
Name: 1513-io-controller
IP: 192.168.222.13
Name: touch-me
IP: 192.168.222.70
Name: et200sp-io-device
IP: 192.168.222.200
Subnet mask: 255.255.255.0
Network address: 192.168.222.0
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-19
5.7.6. Exercise 6: Inserting a Tag Table from the Library

Task
You are to insert the prefabricated tag table from the “IK-TIAPN” library into your project. The
library can either be opened immediately or it must first still be retrieved. In this case, retrieve the
library in the same folder as the archive file is located.
You will find the library under the following path on your computer:
C:\Archives\TIA_Portal\IK-TIAPN

What to Do
1. Open or retrieve (unzip) the library.
2. Open the Chapter5 (folder) of the IK-TIAPN library and, using drag & drop, drag the
“1513CaseVariables” into your project under “PLC tags”.
3. Save your project.
4. Load the controller.
5. All modules should now have the status OK, that is, show agreen light. If this is not the case,
check your configuration of the modules.




Note
 Since you are working with a fail-safe CPU here, you must set the “Full access incl. fail-safe
(no protection)”.


SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
PROFINET Configuration
Exercise 6:
Inserting a Tag Table from the Library
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-20 Training Document, V15.01.00


Note
 If the offline configured access node of the PLC is not located in the subnet of the physical
device, TIA Portal will automatically query whether you are assigning an IP address in the
address range 192.168.x.241 to 192.168.x.250 of the network card.

Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – PROFINET Configuration
Training Document, V15.01.00 5-21
5.8. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / PROFINET Projektierung Seite 18 Siemens AG © 2016
Wenn Sie noch mehr wissen wollen
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – PROFINET Configuration
5-22 Training Document, V15.01.00
5.8.1. Device Number of an IO-Device

Device Number of an IO-Device
The device number of an IO-Device is automatically assigned by the TIA Portal when an IO-
Device is created. The device number must be unique in the PROFINET I/O-System, but it can
still be manually adjusted later on. The device number of the IO-Controller is always ‘0’ and
cannot be manually changed.
Various instructions require the device number and not the device name or the geographic
address of a module in order to be able to address it.
SITRAIN
IK-TIAPN / PROFINET Configuration Page 19 Siemens AG © 2016
Device Number of an IO-Device
wird bei einigen
Anweisungen benötigt
Is required for some
instructions
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-1

Contents 6





6. Topology Editor ...................................................................................................... 6-2
6.1. Automatic Commissioning of a PN IO-System ..................................................................... 6-3
6.2. Automatic Commissioning Sequence ................................................................................... 6-4
6.3. The LLDP (Link Layer Discovery Protocol) ........................................................................... 6-5
6.4. Basics of LLDP...................................................................................................................... 6-6
6.5. Topology Detection with the Help of the LLDP ..................................................................... 6-7
6.5.1. Structure of a PROFINET IO System ................................................................................... 6-7
6.5.2. Downloading the Configuration to the IO-Controller ............................................................. 6-8
6.5.3. Name Information is Distributed via LLDP ............................................................................ 6-9
6.5.4. IO-Controller assigns further Device Names ...................................................................... 6-10
6.6. Adjusting the Topology View to the Network View ............................................................. 6-11
6.7. Creating the Setpoint Topology .......................................................................................... 6-12
6.8. Downloading the Setpoint Topology into the IO-Controller ................................................ 6-14
6.9. Task Description: Creating the Setpoint Topology ............................................................. 6-15
6.9.1. Exercise 1: Creating the Setpoint Topology of the 1500 Case ........................................... 6-16
6.10. Detecting the Actual Topology of a PN IO-System ............................................................. 6-17
6.11. Offline/Online Comparison of the Topology ........................................................................ 6-18
6.12. Device Replacement without Exchangeable Medium......................................................... 6-20
6.13. Overwriting the PROFINET Device Name .......................................................................... 6-21
6.14. Task Description: Detecting the Remaining Topology of the System and Testing the
Automatic Commissioning .................................................................................................. 6-22
6.14.1. Exercise 2: Configuration & Parameterization of the Missing Devices (Scalance + ET 200SP
PLC) .................................................................................................................................... 6-23
6.14.2. Exercise 3: Detecting the Actual Topology ......................................................................... 6-25
6.14.3. Exercise 4: Activating a Device Replacement without Exchangeable Medium .................. 6-26
6.14.4. Exercise 5: Permit Overwriting the Device Names ............................................................. 6-28
6.15. Additional Information ......................................................................................................... 6-29
6.15.1. Device Replacement without Topological Configuration .................................................... 6-30


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-2 Training Document, V15.01.00
6. Topology Editor


SITRAIN
IK-TIAPN / Topology Editor Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... understand the automatic commissioning of a PROFINET I/O-
System based on a Setpoint (Preset) Topology and be able to apply
it
... be familiar with the device exchange without removable media
... be familiar with the function “Overwriting the PROFINET device
name”
... be able to carry out a comparison of the online to the offline
topology
... understand for what the LLDP is required
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-3
6.1. Automatic Commissioning of a PN IO-System

Automatic Commissioning of a PROFINET IO-System
The function “Automatic commissioning of a PROFINET IO-System” is based on the LLDP (Link
Layer Discovery Protocol).
This function is beneficial especially for the commissioning of multiple machines of the same type with
the same configuration and setpoint (preset) topology: The expenditure of time and the possible
causes of errors during commissioning are minimized.
With this function, the IP address and device name assignment of the PROFINET IO-Devices occurs
automatically through the respective PROFINET IO-Controller, without a removable media (e.g. Micro
Memory Card) with stored device name or a programming device (PG) being necessary.
So that the automatic commissioning of a PROFINET IO System can be executed by the IO-
Controller, the following requirements must be fulfilled:
• The IO-Controller and the IO-Devices must support the PROFINET functionality “…device
replacement without exchangeable medium/PG”.
• The devices must be reset to the delivered condition (factory settings) (normally!).
• The topology of the PROFINET IO System with the IO-Devices concerned must be
configured.
• The configured setpoint topology must match the actual topology.
Note
The topology of the PROFINET IO System is configured offline. With this setpoint topology, the
PROFINET IO-Controller is made familiar with the ‘neighborhood’ relationships of all PROFINET IO-
Devices foundin the PROFINET IO- System.
On the Service & Support pages, you will find further information on the function “Device exchange
without exchangeable medium” under the Entry ID number: 36752540 and you will be able to check
which devices support this functionality.
SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Topology Editor
Automatic Commissioning of a PN IO-System
Download topology
to the IO-Controller
IO-Controller assigns
names to IO-Devices
Create the topology of
the PN IO-System
ID: 36752540
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-4 Training Document, V15.01.00
6.2. Automatic Commissioning Sequence

Automatic Commissioning Sequence
The automatic commissioning of a PROFINET IO system can be divided into individual steps:
• Creation of the setpoint topology:
The setpoint topology must be created by the IO-Supervisor. So that the automatic
commissioning of the PROFINET IO system can occur later on without errors, it must
match the actual topology.
• Loading the IO-Controller:
After the setpoint topology is created, it must be downloaded into the IO-Controller. With
the help of the setpoint topology, the controller can carry out a comparison to the actual
topology and execute the automatic commissioning.
• IO-Controller writes the PROFINET device names in the IO-Devices:
During startup, after the configuration is loaded, the IO-Controller then writes the defined
device names in the IO-Devices with the help of the setpoint topology.
• IO-Controller assigns the IP addresses to the IO-Devices:
After the names are assigned, the assignment of the IP addresses for the individual IO-
Devices is done as a last step.


SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Topology Editor
Automatic Commissioning Sequence
IO-Supervisor creates the topology in the software / the
TIA Portal
IO-Supervisor downloads the PN-IO configuration
including the topology to the IO-Controller
During startup, the IO-Controller writes the
PROFINET device names in the IO-Devices on the basis of
the loaded topology
Through the name, the IO-Controller detects the
IO-Device and, during system startup, writes the IP
address in this IO-Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-5
6.3. The LLDP (Link Layer Discovery Protocol)

Link Layer Discovery Protocol
The LLDP (Link Layer Discovery Protocol) is a manufacturer-independent Layer 2 protocol. This
protocol is defined according to the IEEE-802.1AB standard and enables neighboring devices to
exchange information with one another.
In a PROFINET IO system, all devices are connected with each other via their Ethernet ports and
through them enter into a ‘neighborhood’ relationship. That is, through these ports, each device
cyclically sends LLDP packets with its own information to its neighbors and receives their
information.
Note
The LLDP is a “one-way protocol”. The sending and the receiving of information takes place
independent of one another. A device which sends its information to the neighboring components
does not expect an answer or a receipt confirmation from its neighboring components.


SITRAIN
IK-TIAPN / Topology Editor Page 5 Siemens AG © 2016
The LLDP (Link Layer Discovery Protocol)
Link Layer Discovery Protocol:
▪ Manufacturer-independent Layer 2 protocol
▪ Enables neighboring devices to exchange information with
one another
▪ LLDP is a “one-way protocol”! Sending and receiving
takes place independent of one another
Layers
Data Link
Network
Transport
Physical
7
6
5
4
3
2
1
Application
Presentation
Session
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-6 Training Document, V15.01.00
6.4. Basics of LLDP

Basics of the Link Layer Discovery Protocol
LLDP packets are sent to the target address 01:80:2C:00:00:0E with the Ethernet type ID
0x88CC. Packets which are sent to this address only reach the port of the direct neighboring
device and are not forwarded. The information received in this way is stored by the neighboring
component in the neighbor table (LLDP MIB (Management Information Base)).
Each connection point in the topology is identified by an alias. The alias consists of the device
identifier (MAC address or device name) and the port identifier (port number). Through the MAC
address, the alias is unique in the network. In this way, the Network Management Station (e.g.
TIA Portal) can detect the topology uniquely.


SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Topology Editor
Basics of LLDP
P1 P1
P2
P3
P4
P5
P6
P7
P8
TIA-Portal
I am “s7-1500”
I am “x208”
PartnerID.PortID
Port1 PartnerMAC.PartnerPort
PartnerID.PortID
Port1 PartnerMAC.PartnerPort
PartnerID.PortID
Port1 s7-1500.P1
Assigns name
Assigns name
s7-1500
Port1 PartnerMAC.PartnerPort
s7-1500
Port1 x208.P1
x208
Port1 s7-1500.P1
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-7
6.5. Topology Detection with the Help of the LLDP
6.5.1. Structure of a PROFINET IO System

Topology Detection with the Help of the LLDP
The LLDP makes it possible for the network components to be able to fill their LLDP-MIB, that is,
their neighbor tables with information. Through the sent LLDP telegrams, all devices connected in
the PROFINET get the information about which device is located at which of its ports.
Structure of a PROFINET IO System
The devices are physically linked to one another. Since the IO-Devices do not yet have a name,
each IO-Device sends its neighbor its own MAC address and the port number for each
‘neighborhood’ relationship. This information is stored in the neighbor table of each IO-Device.
Note
The part “PartnerMAC” presented in the picture would be replaced by the actual MAC address of
the respective partner in a real system!
The LLDP-MIBs presented in the picture are updated in the devices approximately every 2
minutes. For that reason, a topology error message may occur somewhat time-delayed when a
cable is switched.


SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Topology Editor
Topology Detection with the Help of the LLDP:
Structure of a PROFINET IO System
Device Name
Port PartnerMAC.PartnerPort
LLDP-MIB
Neighbor tableIO-Controller
P1 P1
P2
P3
P4
P5
P6
P7
P8
---
Port1 PartnerMAC.P1
Port3 PartnerMAC.P1
Port5 PartnerMAC.P1
Port8 PartnerMAC.P1
P1
P1
P2
P1
P1
---
Port1 PartnerMAC.P3
---
Port1 PartnerMAC.P5
Port2 PartnerMAC.P1
---
Port1 PartnerMAC.P8
---
Port1 PartnerMAC.P2
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-8 Training Document, V15.01.00
6.5.2. Downloading the Configuration to the IO-Controller

Downloading the Configuration into the IO-Controller
The first step of automatic commissioning is the downloading of the configuration and thus also
the setpoint topology into the IO-Controller. After this process is completed, the IO-Controller has
been given a PROFINET device name.
This name is now shared with all connected components (in the picture, only the SCALANCE
Switch x208) by LLDP. For their part, these components enter the new information in their
neighbor tables.
Based on the setpoint topology, the IO-Controller can now determine with this new information
which devices are connected to the CPU / the IO-Controller with which port. The IO-Controller
then assigns these devices the names stored in the configuration. In the picture, the IO-Controller
detects that the device which is connected to the CPU with its Port 1 is to be given the name
x208 according to the setpoint topology. For that reason, this device is assigned this name by the
IO-Controller.SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Topology Editor
x208
Port1 S7-1500.P1
Port3 et200sp-cpu.P1
Port5 et200sp-switch.P1
Port8 et200s.P1
Topology Detection with the Help of the LLDP:
Downloading the Configuration to the IO-Controller
IO-Controller
is loaded
---
Port1 PartnerMAC.P1
Port3 PartnerMAC.P1
Port5 PartnerMAC.P1
Port8 PartnerMAC.P1
PROFINET IO-Controller topology information
x208
Port1 S7-1500.P1
Port3 et200sp-cpu.P1
Port5 et200sp-switch.P1
Port8 et200s.P1
et200sp-cpu
Port1 x208.P3
et200sp-switch
Port1 x208.P5
Port2 et200sp-sp.P1
et200s
Port1 x208.P8
et200sp-sp
Port1 et200sp-switch.P2
---
Port1 s7-1500.P1
Port3 PartnerMAC.P1
Port5 PartnerMAC.P1
Port8 PartnerMAC.P1
x208
Port1 s7-1500.P1
Port3 PartnerMAC.P1
Port5 PartnerMAC.P1
Port8 PartnerMAC.P1
Switch gets port
information
IO-Controller
assigns name
---
Port1 s7-1500.P1
x208
Port1 s7-1500.P1
P1 P1
P2
P3
P4
P5
P6
P7
P8
P1 P1
P2
P3
P4
P5
P6
P7
P8
P1 P1
P2
P3
P4
P5
P6
P7
P8
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-9
6.5.3. Name Information is Distributed via LLDP

Name Information is Distributed via LLDP
The SCALANCE switch has now been given new information, namely its PROFINET device
name. The switch forwards this new information to its neighboring devices via the LLDP (in the
picture, the et200sp-cpu, the et200sp-switch and the et200s). For their part, the neighboring
devices then enter the new information in their neighbor tables.
SITRAIN
IK-TIAPN / Topology Editor Page 9 Siemens AG © 2016
Topology Detection with the Help of the LLDP:
Name Information is Distributed via LLDP
P1
P2
P3
P4
P5
P6
P7
P8
P1
P1
P2
P1
---
Port1 x208.P3
---
Port1 x208.P5
Port2 PartnerMAC.P1
---
Port1 x208.P8
x208
Port1 s7-1500.P1
Port3 PartnerMAC.P1
Port5 PartnerMAC.P1
Port8 PartnerMAC.P1
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-10 Training Document, V15.01.00
6.5.4. IO-Controller assigns further Device Names

IO-Controller Assigns the Remaining Device Names
With this information and the topology information which is stored in the Controller, the Controller
identifies the IO-Devices and assigns them their names. As soon as the Devices have been given
a name, they share it with their partners.
In this way, the entire PROFINET IO-System is commissioned.
Summary
The topology of the PROFINET IO-System is configured offline. With this setpoint topology, the
‘neighborhood’ relationships of all PROFINET IO-Devices located in the PROFINET IO-System
are made known to the PROFINET IO-Controller.
From the relationships specified through the setpoint topology and the relationships detected via
the LLDP real PROFINET-Devices, the IO-Controller can identify the IO-Devices without a name
and assign them the configured name and the IP address.
SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Topology Editor
Topology Detection with the Help of the LLDP:
IO-Controller assigns further Device Names
The procedure of exchanging LLDP information and assigning PROFINET device names is repeated
until all devices from the setpoint topology have been given a device name!
P1 P1
P2
P3
P4
P5
P6
P7
P8
IO-Controller
x208
Port1 s7-1500.P1
Port3 et200sp-cpu.P1
Port5 et200sp-switch.P1
Port8 et200s.P1
P1
P1
P2
P1
P1
et200sp-cpu
Port1 x208.P3
et200sp-switch
Port1 x208.P5
Port2 PartnerMAC.P1
et200s
Port1 x208.P8
---
Port1 et200sp-switch.P2
Et200sp-sp is then
initialized
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-11
6.6. Adjusting the Topology View to the Network View

Adjusting the Topology View to the Network View
The function "Apply positions from the Network view" allows you to also adopt the positions of the
devices adjusted in the Network view in the Topology view without further effort. That is, a
synchronization of the Topology view is made. Here, the Network view serves as a template for
the Topology view.
An alignment of the Network view on the basis of the Topology view is not possible!

Note
Since - on the basis of the Network view - the Topology view can only derive the configuration of
the devices and not the wiring of the devices, only the position is adopted!

SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Topology Editor
Adjusting the Topology View to the Network View
Apply positions from the
Network view
Network view serves as
template for
synchronization
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-12 Training Document, V15.01.00
6.7. Creating the Setpoint Topology

Creating the Setpoint Topology
When an IO-Device is assigned to the IO-Controller in the Network view it is still not established
how the ports are interconnected with one another. This assignment occurs in the Topology view
or also in the Topology editor.
An interconnection in the Network view does not generate an interconnection in the Topology
view and vice-versa. Creating a device in one of the two views, however, also generates the
device in the other view.
The networking of the ports in the Topology view can either be generated graphically through
drag & drop or through a table. For the tabular Topology overview and the tabular networking, the
overview must be dragged into the editing window using the arrow keys or drag & drop.


Creating a topology is not absolutely necessary! The realtime functionality of a PROFINET
network can be used on its own. When IRT and the automatic commissioning of a PROFINET IO-
Systems is used, the creation and downloading of a setpoint (preset) topology into the IO-
Controller is, however, absolutely necessary!
In addition to the use of IRT and the automatic commissioning, the creation of a topology also
offers the following advantages:
• By using an Offline/Online comparison, it is possible to carry out a setpoint-actual
comparison for the devices which support this functionality.
• The function “Support device replacement without exchangeable medium” is available.





SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Topology Editor
Creating the Setpoint Topology
Networking through
drag & drop
Topology – graphic
presentation
Autofocus for the
port selection
Topology – tabular
presentation
Networking through
tabular selection
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-13
Note
The interconnection of ports can also be done in the Inspector window instead of graphically or
symbolically in the work area:

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-14 Training Document, V15.01.00
6.8. Downloading the Setpoint Topology into the IO-Controller

Downloading the Setpoint Topology into the IO-Controller
The setpoint topology created in the Topology view is downloaded into the IO-Controller together
with the hardware configuration. After the download, the IO-Controller then compares the loaded
setpoint topology with the real actual topology. IO-Devices without a name are now, if they fulfill
the requirements, initialized by the IO-Controller – they are assigned the name defined in the
setpoint topology for the Device.
Differences between the setpoint and the actual topology are identified by the IO-Controller and
are signaled to the user via an error evaluation.
Note
Differences between the setpoint topology and the actual topology are also displayed by the IO-
Controller via the diagnostic buffer. An incorrectly inserted patch cable or a wire break could also
be identified and signaled in this way!SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Topology Editor
Downloading the Setpoint Topology into the
IO-Controller
PROFINET-IO topology is downloaded
via the HW-Config
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-15
6.9. Task Description: Creating the Setpoint Topology

Task Description
You are to configure a setpoint (preset) topology for the S7-1500 case which corresponds to the
real topology.
Note
To make it easier to create the setpoint topology, you can also use the PRONETA tool.

SITRAIN
IK-TIAPN / Topology Editor Page 13 Siemens AG © 2016
Task Description:
Creating the Setpoint Topology of the 1500 Case
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-16 Training Document, V15.01.00
6.9.1. Exercise 1: Creating the Setpoint Topology of the 1500 Case

Task
In your project, you are to create a setpoint topology which corresponds to the actual topology of
the system. Then you are to load the controller. No errors should occur for any module. If they do,
eliminate them!
What to Do
1. In your project, switch to the “Topology view”.
2. Network the individual devices with one another just as it corresponds to the real structure.
3. Save your project.
4. Load the controller. No errors should occur for any module.
5. Eliminate any possible errors.
6. Once again load and save your project.
Note
In the online view in the Topology editor, you can very easily control which offline wiring does not
fit to the real wiring of the system or which has errors during running operation:

SITRAIN
IK-TIAPN / Topology Editor Page 14 Siemens AG © 2016
Exercise 1: Creating the Setpoint Topology
Devices must be networked
according to their real connection
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-17
6.10. Detecting the Actual Topology of a PN IO-System

Detecting the Actual Topology of a PROFINET IO-System
TIA Portal makes it possible to detect the actual topology of a PROFINET IO-System. For this,
TIA Portal sends a topology query into the IO-System and receives in return all LLDP MIBs.
By reading out these neighbor tables, TIA Portal can deduce the required information for building
the interconnections between the individual devices as well as the port allocations and with that
also the topology.
Correlation IP Addresses and LLDP MIB
So that the LLDP MIBs can be read out of the devices, they must have a valid IP address!
TIA Portal can temporarily assign an IP address to devices that do not have an IP address before
the topology is read out. This option can be found in the TIA Portal ‘Settings’ and there under the
item: “Hardware configuration”:

If this option is activated, the popup window questioning whether the TIA Portal is to assign
temporary IP addresses to the IO-Devices appears before every Offline/Online comparison of the
topology.
SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Topology Editor
Detecting the Actual Topology of a PN IO-System
P1 P1
P2
P3
P4
P5
P6
P7
P8
Topology editor
Port PartnerID.PortID
Port1 PartnerMAC.PartnerPort
Port PartnerID.PortID
Port1 PartnerMAC.PartnerPort
Port PartnerID.PortID
Port1 s7-1500.P1
Port s7-1500
Port1 PartnerMAC.PartnerPort
s7-1500
Port1 x208.P1
x208
Port1 s7-1500.P1
Topology query by the
TIA Portal to all devices
LLDP MIBs are read-out
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-18 Training Document, V15.01.00
6.11. Offline/Online Comparison of the Topology

Offline/Online Comparison of the Topology
With the Offline/Online comparison, the configured topology is compared to the actually existing
topology. Online detected devices are automatically assigned to the offline configured devices, as
far as this is possible.
An online detected device is automatically assigned to an offline existing device when the
following properties of the two devices match:
• PROFINET device name
• Order number
• Number of ports
All devices detected online which are not automatically assigned can then also be assigned
manually to the offline devices if they exist in the project.
Applying the Online Topology Offline
After the devices detected online are assigned to the offline configured devices, their port
interconnections are compared and can then also be applied in the offline project as required.
For this the ports, which are to be applied in the offline project, are selected and in the “Action”
column, the selection is changed from “No action” to “Apply” for these:

The loading of the online interconnection in the offline topology, for those where the selection was
set to “Apply”, is then completed via the button “Synchronize”.
For the standard offline/online comparison, a search method is applied which uses the DCP
protocol.


SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Topology Editor
Offline/Online Comparison of the Topology
offline networking
Synchronize
offline/online comparison online networking
Assignment to the
Offline Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-19
Advanced Offline/Online Comparison
For the standard offline/online comparison, a search method is applied which uses the DCP
protocol.
For the Advanced offline/online comparison, ICMP is additionally used in order to also detect
devices that do not support DCP. PG/PC stations, for example, belong to such devices.

Note
It can take several seconds until the Offline/Online comparison has been completely carried out
and visualized. During this time, no operator inputs are possible.
The progress of the Offline/Online comparison can, however, be seen in the status bar:

A right-click in the Topology overview opens the selection window in which the selection “Apply
all” can be made. All online port interconnections which can be applied are then set from “No
action” to “Apply”.


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-20 Training Document, V15.01.00
6.12. Device Replacement without Exchangeable Medium

Device Replacement without Exchangeable Medium
IO-Devices, which do not have a slot for a removable media (e.g. ET 200SP, ET 200MP) or which
support the PROFINET functionality ‘device exchange without exchangeable medium/PG’, can be
replaced without a removable media - containing a stored device name - having to be inserted or
without the device name having to be assigned with the PG. The replacement IO-Device no
longer receives the device name from the removable media or from the PG but from the IO-
Controller.
To assign the device name, the IO-Controller uses the configured topology and the
‘neighborhood’ relationships detected from the IO-Devices.
In the Online Support pages, under the Entry ID: 36752540, you will find a listing of all IO-
Controllers and all IO-Devices which support the automatic commissioning without topology, that
is, the ‘device exchange without exchangeable medium’.
https://support.industry.siemens.com/cs/de/de/view/36752540
So that the name assignment by the IO-Controller can function smoothly, however, the IO-Device
must first be brought back to its delivered condition, that is, its factory settings since the IO-
Controller can normally not overwrite the PROFINET device name of the IO-Device.
Note
So that the device replacement without exchangeable medium is carried out without a problem,
the connection of the new IO-Device must take place exactly the same as for the replaced IO-
Device. That is, the port interconnection must match since the setpoint topology otherwiseno
longer matches the actual topology and the IO-Controller cannot assign a name to the IO-Device.
SITRAIN © Siemens AG 2018
Page 18
IK-TIAPN
Topology Editor
Device Replacement without Exchangeable Medium
Device does not support a
removable media
Requirement:
delivered condition
Must be activated in the
IO-Controller
IO-Device must support
the function
https://support.industry.siemens.com/cs/de/de/view/36752540
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-21
6.13. Overwriting the PROFINET Device Name

Permitting Overwriting of the PROFINET Device Name
The function: “Permit overwriting of device names of all assigned IO-Devices” makes it possible
to exchange PROFINET IO-Devices without first resetting them to their delivered condition / their
factory settings. Before the IO-Controller overwrites the PROFINET device name, a check is
made as to whether the type of the new IO-Device matches the type of the configured IO-Device.
If this is the case, the configured name is then written in the IO-Device.
This functionality is possible with an S7-1500 CPU as of Firmware Version V1.5 and with an
ET200SP CPU as of Firmware Version V1.6. The effort in replacing an IO-Device is reduced with
this function.
Note
If the option "Permit overwriting of device names of all assigned IO-Devices" is activated,
incorrectly connected devices can be given an incorrect PROFINET device name from the
configuration.
Depending on the connected peripherals, malfunctions can cause danger to life, serious risk of
injury or material damage!
In every case of a device exchange, check whether the correct replacement device is connected
and that the port interconnection meets the configured setpoint topology in order to avoid any
possibility of risk!
SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Topology Editor
Overwriting the PROFINET Device Name
IO-Device exchange
Delivered condition
not required
IO-Controller overwrites
the name
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-22 Training Document, V15.01.00
6.14. Task Description: Detecting the Remaining Topology of the
System and Testing the Automatic Commissioning

Task Description
The topological networking of the remaining system components is not to be entered manually
but is to be detected using TIA Portal. First the missing Devices must naturally be generated,
configured, parameterized as well as networked in the project!
Then, the PROFINET functions for automatic commissioning of a system, such as, the
functionalities “…device replacement without exchangeable medium” or also “…overwriting of
(PROFINET) device names…” are to be activated and tested in the controller.
SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Topology Editor
Aufgabenstellung: Restliche Topologie der Anlage
ermitteln und die automatische IBN testen
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-23
6.14.1. Exercise 2: Configuration
& Parameterization of the Missing Devices (Scalance + ET 200SP PLC)

Task
You are to complete your project by inserting the missing devices in TIA Portal which are already
physically networked (CPU 1510SP-1PN + SCALANCE XC208).
The digital inputs and outputs of the 1510SP-1PN controller get the address 0. The controller is
assigned the IP address 192.168.222.10 with the subnet mask 255.255.255.0. The PROFINET
device name is “1510-io-controller”.
For the SCALANCE XC208, the PROFINET device name “scalancexc208” is set in the hardware
configuration offline. It is assigned the IP address 192.168.222.208 with the subnet mask
255.255.255.0. The S7-1513 takes on the role of its IO-Controller.
Subsequently, you are to integrate the two new Devices into the existing PROFINET IO-System.
What to Do
1. As a new device, add a SIMATIC ET200CPU. Pay attention to the correct MLFB Number and
the correct Firmware Version. You can also use the functionality “Detect the configuration of
the connected device” by using an unspecified CPU:


2. Configure and parameterize the PLC according to the task.
SITRAIN © Siemens AG 2018
Page 21
IK-TIAPN
Topology Editor
Exercise 2: Configuration & Parameterization of the
Missing Devices (Scalance + ET 200SP PLC)
Add (detect)
ET 200SP CPU
Add Scalance XC208
192.168.222.10
255.255.255.0
1510-io-controller
192.168.222.208
255.255.255.0
scalancexc208
1513 is IO-Controller for
the Switch
I/O addresses: 0/0
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-24 Training Document, V15.01.00
3. Insert a new device of the type SCALANCE XC-200 managed. Here as well, pay attention to
the correct MLFB Number and the correct Firmware Version.
4. Parameterize the SCALANCE XC208 according to the task.
5. Network the devices in the Network view in TIA PORTAL.
6. Set up the PROFINET IO-System in such a way that the S7-1513 functions as the IO-
Controller for the Switch and not the S7-1510SP.
7. Create a new group with the name "1510Case" and assign the S7-1510SP as well as the
SCALANCE XC208 to it.
8. Save your project.
9. Download both controllers.
10. The error LED of the S7-1513 should begin to flash. This state is normal and will be fixed in
 the following exercises!
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-25
6.14.2. Exercise 3: Detecting the Actual Topology

Task
You are to detect the actual topology of your components. For this, use the integrated
Offline/Online comparison of the Topology editor in TIA Portal.
What to Do
1. Open the Topology view in your project.
2. Show (Expand) the Topology overview.
3. Start an Offline/Online comparison. It can take a few seconds until it shows the desired data.
The current progress is presented in the lower right corner in TIA Portal.
4. Apply the actual topology in your project and then synchronize the setpoint and the actual
topology. Pay attention to the note!
5. Save your project.
6. Download the S7-1513. The error LED continues to flash. This is a desired state!
7. Download the S7-1510SP. If the error LED also flashes for this one, it is also OK!
Note
It may be that you have to assign the correct Offline-Devices to the Online-Devices before
applying the actual topology in your project. If necessary, do this using this drop-down window:

SITRAIN © Siemens AG 2018
Page 22
IK-TIAPN
Topology Editor
Exercise 3: Detecting the Actual Topology
Carry out Offline/Online
comparison
Apply all and Synchronize
Show / hide
Topology overview
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-26 Training Document, V15.01.00
6.14.3. Exercise 4: Activating a Device Replacement without Exchangeable
Medium

Task
You are to check whether the functionality “Support device replacement without exchangeable
medium” is activated in the S7-1513 as well as in the S7-1510SP. If this is not the case, activate
them. Then you are to test this functionality by resetting the ET 200SP to its factory settings. It
should now automatically be re-initialized by the S7-1513 without you having to do anything! If the
functionality is deactivated, this should not be the case! Test both cases!
What to Do
1. Check whether the functionality is activated in both controllers. If this is not the case, activate
this option and download both controllers!
2. With the help of the Online access, reset the ET 200SP to its factory settings.
3. The ET200SP and all its modules should now flash green.
4. After a short time, the IO-Controller will automatically initialize the IO-Device,the ET 200SP,
and also assign it the IP address. The ET 200SP and its modules should now once again light
up green.
5. Deactivate the functionality in the S7-1513 and download the controller.
6. Once again, reset the ET 200SP to its factory settings.
7. The ET 200SP and its modules should now once again flash green. The flashing will not,
however, stop since the IO-Controller cannot automatically initialize the ET 200SP.
8. Ping the IP address of the ET 200SP. This should not be accessible.
9. Activate the functionality in the S7-1513 and download it.
10. The ET 200SP should now once again light up green.
11. Ping the ET 200SP. It should once again be accessible.
12. Save your project.
SITRAIN © Siemens AG 2018
Page 23
IK-TIAPN
Topology Editor
Exercise 4:
Device Replacement without Exchangeable Medium
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-27
Note
The flashing of the S7-1513 error LED is still a normal state!
The functionality “Support device replacement without exchangeable medium” is activated on the
S7-1500 by default!
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-28 Training Document, V15.01.00
6.14.4. Exercise 5: Permit Overwriting the Device Names

Task
Finally, you are to activate the functionality “Permit overwriting of device names of all assigned IO
devices” on the S7-1513. With this function, the controller can overwrite the SCALANCE XC208
which has an incorrect PROFINET device name and so causes the error on the S7-1513. Then,
you are to change the device names of the IO-Devices for further tests. You are to do this using
the function “Assign name” in the ‘Online access’. When the functionality is activated, the
controller should simply overwrite the names once again.
What to Do
1. Activate the functionality on the S7-1513 and download it.
2. All modules should now light up green and the S7-1513 error LED should no longer flash.
3. As a test, overwrite the names of the ET200SP and the SCALANCE XC208. After a few
cycles, the controller should overwrite them with the names specified in the hardware
configuration.
4. Save your project!
SITRAIN © Siemens AG 2018
Page 24
IK-TIAPN
Topology Editor
Exercise 5: Permit Overwriting the Device Names
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Topology Editor
Training Document, V15.01.00 6-29
6.15. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Topologie-Editor Seite 24 Siemens AG © 2016
Wenn Sie noch mehr wissen wollen
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Topology Editor
6-30 Training Document, V15.01.00
6.15.1. Device Replacement without Topological Configuration

Device Replacement without Topological Configuration
The functionality: “Device replacement without topological configuration” permits a device
exchange without a removable media and without configured setpoint topology in the IO-
Controller.
This function is supported by the following IO-Devices:
• ET 200SP IM 155-6 PN HF with the article number 6ES7155-6AU00-0CN0 as of
Firmware V2.0
• ET 200SP IM 155-6 PN ST with the article number 6ES7155-6AA00-0BN0 and 6ES7155-
6AU00-0BN0 as of Firmware V3.1
For these IO-Devices, the device name is also additionally stored on the bus adapter, if it is of the
type BA 2xRJ45 or 2xFC. Due to the fact that the name can be stored both on the interface
module and on the bus adapter, the following scenarios can result when the interface module is
replaced:

 Interface module empty Interface module with device
name
Bus adapter
empty
No device name exists. Device name from interface
module is used and copied onto
the bus adapter
Bus adapter
with device
name
Device name from bus adapter is used
and copied onto the interface module.
Device name from bus adapter is
used and copied onto the
interface module, if the module
contains another device name.

SITRAIN © Siemens AG 2018
Page 26
IK-TIAPN
Topology Editor
Device Replacement without Topological
Configuration
ET 200SP supports device
replacement without
topological configuration
PROFINET-Gerätenamen
wird auf dem Bus Adapter
abgelegt
PROFINET device name is
stored on the bus adapter
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-1

Contents 7





7. Diagnostics ............................................................................................................. 7-2
7.1. Diagnostic Possibilities ......................................................................................................... 7-3
7.2. Diagnostics via LEDs ............................................................................................................ 7-4
7.2.1. LEDs of the PLC S7-1513 – 1PN.......................................................................................... 7-4
7.2.2. LEDs of the SCALANCE XC208 ........................................................................................... 7-5
7.2.3. LEDs of the ET 200SP .......................................................................................................... 7-6
7.2.4. LEDs of the PLC S7-1510SP – 1PN ..................................................................................... 7-7
7.3. System Diagnostics .............................................................................................................. 7-8
7.4. Diagnostics with the Help of Display Units ........................................................................... 7-9
7.5. Task Description: Commissioning and Diagnosis of the TP700 ......................................... 7-10
7.5.1. Exercise 1: Inserting the TP700 from the Library & Connecting it with the S7-1513 ......... 7-11
7.5.2. Exercise 2: Creating the Diagnostics View on the TP700 Comfort .................................... 7-12
7.6. Detecting the Hardware Identifier of an I/O Module............................................................ 7-13
7.7. Detecting the Hardware Identifier of an IO-Device ............................................................. 7-14
7.7.1. Data Type GEOADDR ........................................................................................................ 7-15
7.8. Activating / Deactivating an IO-Device ............................................................................... 7-16
7.9. Reading-out the Device Name of the IO-Device ................................................................. 7-18
7.10. Task Description: Reading-out the ET 200SP Device Name and Activating / Deactivating the
IO-Device ............................................................................................................................ 7-19
7.10.1. Exercise 3: Reading-out the ET 200SP Hardware Identifier and Outputting it on the HMI 7-20
7.10.2. Exercise 4: Activating / Deactivating the ET 200SP ........................................................... 7-22
7.10.3. Exercise 5: Reading-out the ET 200SP Device Name and Outputting it on the HMI ......... 7-23
7.11. Reading-out the Module LED Status .................................................................................. 7-24
7.12. Reading-out the Device and Module States ....................................................................... 7-25
7.13. Task Description: Reading-out the Module State of the ET 200SP ................................... 7-27
7.13.1. Exercise 6: Reading-out the Module State of the ET 200SP .............................................. 7-28


 Industrial Communication, PROFINET with IndustrialEthernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-2 Training Document, V15.01.00
7. Diagnostics


SITRAIN
IK-TIAPN / Diagnostics Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... have a basic overview of the various diagnostic possibilities in the
TIA Portal
... be familiar with the meaning of the LEDs of the different
components
... be familiar with the system diagnostics
... be able to operate the diagnostics with the help of display units
... be able to program different instructions for diagnostics
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-3
7.1. Diagnostic Possibilities

Diagnostic Possibilities
The automation world of SIMATIC offers you a wide range of diagnostic possibilities. For the
simplest diagnostic possibility – the visual inspection of LEDs on the SIMATIC devices, for
example – you do not have to carry out any other activities or programming. For a system
diagnostics or the visualization of the diagnostics on the display devices, you hardly have to do
anything either.
Further and more in-depth diagnostic possibilities are usually defined in the user program and, for
their part, then require advanced programming knowledge.
On the Service & Support pages, you will find an article on diagnostics with an S7-1500 under the
Entry ID number: 98210758.

SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Diagnostics
Diagnostic Possibilities
Possibilities Use Conditions
LEDs Directly visible diagnostics On-site on the hardware possible
PG / TIA Portal
More detailed diagnostic
information
Engineering software necessary
System diagnostics
Predefined diagnostic
information
Is set in the hardware configuration
Display devices
(CPU-Display / Web
server / HMI)
Same presentation of the
diagnostic information
Connection to the CPU is required
User program
Reaction to events directly
possible in the program
Additional programming effort
ID: 98210758
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-4 Training Document, V15.01.00
7.2. Diagnostics via LEDs
7.2.1. LEDs of the PLC S7-1513 – 1PN

LINK-LEDs of the PLC (X1P1, X1P2)
In order to determine why communication between two partners in the network does not work,
you should first of all always rule out a physical problem! That is, you must check whether a
physical connection, normally via an Ethernet cable, even exists between the devices.
In this case, the LINK-LEDs of the controller lend themselves for this. These signal whether a
LINK, that is a physical connection, is established between the port assigned to the LED and the
communications partner or not. If this LED if off, no LINK connection exists at the moment. This
can be caused either through a wire break in the cable, a general cable break or simply a plug
that is not wired 100 percent.
Communication between Devices
When the devices connected to the PROFINET or Ethernet interface exchange data amongst
themselves, the associated LINK-LED begins to flicker yellow. The faster the flickering, the faster
the transmission frequency is between the partners.
Note
If the LINK-LED appears to take on a continuous light, the transmission frequency is so high (fast)
that the LED only displays a yellow color.
This behavior can frequently be observed with a coupling between a PROFINET IO-Controller
and a PROFINET IO-Device.

SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Diagnostics
Diagnostics via LEDs
LEDs of the PLC 1513 – 1PN
Run/Error/Maint-LEDs
LINK RX/TX-LEDs
Options LINK-LED Meaning
LED off A LINK connection does not exist.
LED lights up green
There is an Ethernet connection to a
communications partner.
LED flashes green The "LED flash test" is being performed.
LED flickers yellow
Data is being exchanged with a communications
partner via the PROFINET interface.
LED lights up yellow
Transmission frequency in the PROFINET is so fast
that the flickering appears as a continuous light.
ID: 59186494
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-5
7.2.2. LEDs of the SCALANCE XC208

Display Mode LEDs of the SCALANCE XC208 (DM1, DM2)
The LEDs (DM1, DM2) indicate which display mode is set. There are 4 display modes (A, B, C
and D). Display mode A is the standard mode. Depending on display mode set, the Power LEDs
(L1, L2) and the Port LEDs show different information.
Power LEDs of the SCALANCE XC208 (L1, L2)
The Power LEDs (L1, L2) of the SCALANCE XC208 indicate in which voltage range the power
supply at the L1 as well as at the L2 connections finds itself or whether the power supply is
generally monitored.
Port LEDs of the SCALANCE XC208 (P1, P2, P3, P4, P5, P6, P7, P8)
The Port LEDs of the SCALANCE XC208 show the same behavior as the LINK LEDs of the S7-
1513-1PN.
Fault LED of the SCALANCE XC208 (F)
The Fault LED of the SCALANCE XC208 indicates whether the SCALANCE XC208 is currently in
an error-free operation (LED is not lit up) or whether an error detected by the device is currently
pending (LED is lit up or flashes red).
The possible errors detected by the SCALANCE XC208 are listed in the picture. Depending on
the model of the SCALANCE family, different errors and also various numbers of errors are
detected by the respective device.
Redundancy Manager LED of the SCALANCE XC208 (RM)
The RM LED of the SCALANCE XC208 indicates whether the SCALANCE XC208 is
parameterized as a redundancy manager or not. Furthermore, with an active redundancy
manager role, it signals whether the ring is interrupted or not.
Standby LED of the SCALANCE XC208 (SB)
The Standby LEDs (SB) of the SCALANCE XC208 is used to display the standby function of the
SCALANCE XC208. Furthermore, it indicates the status (active/passive).
SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Diagnostics
Diagnostics via LEDs
LEDs of the SCALANCE XC208
Fault/RM/Standby/Anzeige-
modus/Power-LEDs
Port-LEDs
Options Fault-LED Meaning
LED flashes red An internal error was detected.
LED lights up red
-Link Down event at one of the monitored
ports
-Loss of one of the two redundant power
supplies
-C-Plug error
-Switch startup (20 seconds)
-Device is in PROFINET operation:
→no connection to the controller
→diagnostic interrupt pending
-Redundancy manager connected through
-Loop Detection
ID: 109476763
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-6 Training Document, V15.01.00
7.2.3. LEDs of the ET 200SP

LINK LEDs of the Bus Adapter (LK1, LK2)
The various light patterns of the LINK LEDs of the bus adapter are shown in the picture. Unlike
the LINK LEDs of the PLC S7-1513 - 1PN and the SCALANCE XC208, these do not flash yellow
when data is exchanged between the connected devices.They only indicate, through a green
continuous light, that a communication between the connection partners exists.
Power LED of the ET 200SP (PWR)
The Power LED of the Interface Module IM155-6PN ST of the ET200 SP indicates, through a
green continuous light, that there is sufficient supply voltage. If the Power LED does not light up,
there is no or too little voltage connected to the ET200 SP.
Run, Error, Maint LEDs of the ET 200SP (RN, ER, MT)
A listing of the various light and flashing patterns of the Run, Error and Maint LEDs can be found
in the manual of the SIMATIC ET200 SP Interface Module IM 155-6 PN ST. This can be found on
the Service and Support page under the Entry-ID: 59768173.
SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Diagnostics
Diagnostics via LEDs
LEDs of the ET 200SP
Power LED
LINK LX-LEDs
Options LINK-LED Meaning
LED off A LINK connection does not exist.
LED lights up green
There is an Ethernet connection to acommunications partner.
LED flashes green The "LED flash test" is being performed.
Run/Error/Maint-LEDs
ID: 59768173
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-7
7.2.4. LEDs of the PLC S7-1510SP – 1PN

LINK LED of the PLC 1510SP – 1PN (LK3)
The various light patterns of the LINK LEDs of the PLC S7-1510SP – 1PN are shown in the
picture. Unlike the LINK LEDs of the PLC S7-1513 - 1PN and the SCALANCE XC208, these do
not flash yellow when data is exchanged between the connected devices. It only indicates,
through a green continuous light, that a communication between the connection partners exists.
The PLC S7-1510SP - 1PN has an integrated PROFINET interface with one port. Additional ports
can, however, be added via an optional bus adapter (BA) (similar to an ET 200SP).
Power, Run, Error, Maint LEDs of the ET 200SP (PWR, R/S, ER, MT)
A listing of the various light and flashing patterns of the Power, Run, Error and Maint LEDs can be
found in the manual of the SIMATIC ET 200SP CPU S7-1510SP - 1PN. This can be found on the
Service and Support page under the Entry -ID: 90157130.
SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Diagnostics
Diagnostics via LEDs
LEDs of the PLC 1510SP – 1PN
Run/Error/Maint-LEDs
LINK LK-LED CPU
Optional BA module
Power LED
LINK LX-LEDs BA
ID: 90157130
Options LINK-LED Meaning
LED off
A LINK connection does not
exist.
LED lights up green
There is an Ethernet
connection to a
communications partner.
LED flashes green
The "LED flash test" is being
performed.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-8 Training Document, V15.01.00
7.3. System Diagnostics

System Diagnostics
The system diagnostics of an S7-1500 is always activated by default and cannot be deactivated
by you. No further handling is necessary in order to use these diagnostic possibilities.
What you can set is whether the different Alarm Categories generate alarms and whether these
are to require an acknowledgement or not.


SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Diagnostics
System Diagnostics
Always active
Possible settings
RSE no longer necessary
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-9
7.4. Diagnostics with the Help of Display Units

Diagnostics with the Help of Display Units
Since a programming device is not always available in a plant in order to look at the diagnostic
buffer of the PLC to see what kind of error is currently pending and since the controller has
normally ‘disappeared’ inside the control cabinet so that the display of the S7-1500 is not
accessible without a problem, the possibility of diagnostics on display units lends itself for this.
For system diagnostics on Siemens HMI devices, there is a prefabricated Control which is simply
dragged into the HMI screen using drag & drop and which then provides the user with the
relevant diagnostic information there.
System Diagnostics View Control
The system diagnostics view makes it possible to present the diagnostic buffer of the connected
CPU on the HMI device.
A further function is the overview of the PROFINET IO-System and the graphic presentation of
failed devices. This diagnosis is even available module-by-module!

SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Diagnostics
Diagnostics with the Help of Display Units
Exchange
diagnostic data
Sends diagnostic
data
HW diagnostics on
the HMI
Diagnostic buffer
PLC on HMI
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-10 Training Document, V15.01.00
7.5. Task Description: Commissioning and Diagnosis of the TP700

Task Description
You are to commission the TP700 Comfort which is located in your S7-1500 case. For this, you
are to use the template which is located in the “IK-TIAPN” library. Then, you are to establish an
HMI connection between the TP700 Comfort and the CPU S7-1513 - 1PN and create the system
diagnostics view on the Panel. Finally, you are to test whether the diagnostics view also supplies
the desired data.
Your old TP700 Comfort must be deleted from the library before you commission the Panel!
SITRAIN
IK-TIAPN / Diagnostics Page 10 Siemens AG © 2016
Task Description:
Commissioning and Diagnosis of the TP700
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-11
7.5.1. Exercise 1:
Inserting the TP700 from the Library & Connecting it with the S7-1513

Task
You are to open the “IK-TIAPN” library and then insert the prefabricated touchpanel TP700
Comfort located in the folder “Chapter7” from the library into your project. Then, you are to
establish an HMI connection between the touchpanel and the CPU 1513 - 1PN.
The library is located on your computer in the following path:
C:\Archives\TIA_Portal\IK-TIAPN
What to Do
1. Delete the TP700 Comfort from your project.
2. Open the “IK-TIAPN” library.
3. Using drag & drop, drag the TP700 Comfort “touch-me” from the folder “Chapter7” and the
subfolder “HMI” into your project.
4. Establish an HMI connection between the TP700 Comfort and the CPU S7-1513 - 1PN.
5. Rewire (re-network) the lost topology between the S7-1513 and the Panel as well as between
the Panel and the SCALANCE XC208.
6. Also drag the new TP700 Comfort back into the folder "1513Case".
7. Save your project.
8. Download the S7-1513.

SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Diagnostics
Exercise 1: Inserting the TP700
from the Library & Connecting it with the S7-1513
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-12 Training Document, V15.01.00
7.5.2. Exercise 2: Creating the Diagnostics View on the TP700 Comfort

Task
You are to create the diagnostics view on the TP700 Comfort and test it.
What to Do
1. Open the already existing “Diagnosis” screen in the touchpanel.
2. Using drag & drop, drag the Control “System diagnostics view” into the screen.
3. Adjust the size and the properties of the Control as required.
4. Compile the touchpanel.
5. Download your configuration into the touchpanel.
6. Test your diagnostics view.
7. Correct, if necessary, your project.
8. Save your changes.




SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Diagnostics
Exercise 2: Creating the Diagnostics View on the
TP700 Comfort
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-13
7.6. Detecting the Hardware Identifier of an I/O Module

IO2MOD
The instruction “IO2MOD” allows you to read out the hardware identifier of a module from an I/O
address of the module. The instruction is located in the Extended Instructions and there in the
folder “Addressing”.
At the input “ADDR”, variables of the type I, Q, PI or PQ can be specified. If the programming
language SCL is used, the type PQ is not permitted. The hardware identifier is returned through
the data type “HW_IO” or “HW_ANY”.
The function “IO2MOD” has an internal error evaluation using the output “RET_VAL”.

SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Diagnostics
Detecting the Hardware Identifier of an I/O Module
Address of module
Hardware identifier
Data type: HW_ANY
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-14 Training Document, V15.01.00
7.7. Detecting the Hardware Identifier of an IO-Device

GEO2LOG
In the Extended Instructions in the folder “Addressing”, you will find the instruction “GEO2LOG”.
This instruction allows you to detect the hardware identifier of an IO-Device during runtime of the
controller.The hardware identifier is detected through the slot information of the IO-Device. This
information is passed to the instruction via the data type “GEOADDR”.
The hardware identifier is returned with the help of the data type “HW_ANY”.
Note
The instruction “GEO2LOG” also has a system-internal error evaluation which is evaluated via the
parameter “RET_VAL”. The meaning of the error code which is output can be found in the block
help in TIA Portal.
SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
Diagnostics
Detecting the Hardware Identifier of an IO-Device
Data type: GEOADDR
Hardware identifier
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-15
7.7.1. Data Type GEOADDR

GEOADDR
The data type “GEOADDR” is a structure which consists of the following components:
• HWTYPE:
The component “HWTYPE” determines which further components of the structure
“GEOADDR” are evaluated.
• AREA:
Specification of the bus system to be evaluated.
• IOSYSTEM:
Identifier for the IO-System. The identifier for PROFINET is always 100!
• STATION:
Specification of the station number, if “AREA” > 0. If “AREA” = 0 then the rack is specified
here.
• SLOT:
Slot number
• SUBSLOT:
Number of the submodule


SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
Diagnostics
Data Type GEOADDR
0:Central module 1: PROFINET IO
2: PROFIBUS DP 3: AS-I
1: IO-System 2: IO-Device/DP-Slave
3: Rack 4: Module 5: Submodule
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-16 Training Document, V15.01.00
7.8. Activating / Deactivating an IO-Device

D_ACT_DP
The function “D_ACT_DP” can be used to specifically activate or deactivate DP-Slaves as well as
PROFINET IO-Devices. As a further functionality, the instruction also offers the possibility of
reading out the current status of the DP-Slave / PROFINET IO-Device, that is, whether the device
is currently activated or deactivated.
Especially for maintenance work or similar work on distributed I/Os, it makes sense to deactivate
the device before beginning the job so that no unnecessary error messages or error reactions can
occur on the CPU and be executed.
The function “D_ACT_DP” can be found in the Extended Instructions in the folder “Distributed
I/O”.
The instruction “D_ACT_DP” is an asynchronous working instruction, that is, the execution can
extend over several CPU cycles / calls. An internal error evaluation and the status display on the
current task can be taken from the parameters “RET_VAL” and “BUSY”.
Note
If you take the hardware identifiers from the previous pages as an example, the block can only
deactivate and activate the IO-Device ET 200SP with the hardware identifier 264.

If the hardware identifier 266 is used, the function “D_ACT_DP” outputs the following error:
SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Diagnostics
Activating / Deactivating an IO-Device
activate/deactiviate
+ status IO-Device
not edge-triggered
Activation Deactivation
Hardware
identifier
Read-out status
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-17



The plain text for the error number: 8093 can then be taken from the Help:
8093:
For the address specified in LADDR, there is no DP-Slave/PROFINET IO-Device which can be
activated or deactivated.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-18 Training Document, V15.01.00
7.9. Reading-out the Device Name of the IO-Device

Get_Name
If the hardware identifier of the PROFINET IO-System and the device number of the PROFINET
IO-Device is known, the PROFINET device name of the IO-Device can be read-out at runtime
with the help of the instruction “Get_Name”.
The device name which is output corresponds to the name of the header module.
The “Get_Name” instruction is an acyclic instruction. It can take longer than one CPU cycle for
the function to read out the name of the PROFINET device. Through the parameters “DONE” and
“BUSY”, you can see the current status of the reading-out of the name. The parameter “ERROR”
is used by the instruction as an error output.
Note
If the PROFINET device name is longer than the area specified at the parameter “DATA”, the
parameter is filled with the maximum possible number of characters and the remaining are
discarded.
The length of the PROFINET device name can also be taken from the output parameter “LEN” of
the instruction “Get_Name”.

SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Diagnostics
Reading-out the Device Name of the IO-Device
Hardware-Kennung
PROFINET IO System
Device number
Hardware identifier
PROFINET IO System
PROFINET
device name
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-19
7.10. Task Description: Reading-out the ET 200SP Device Name
and Activating / Deactivating the IO-Device

Task Description
Having integrated the HMI device for diagnosis in your project in the previous exercise, this is
now to be used to read out the device name of the ET 200SP at runtime and to be able to
activate as well as deactivate the IO-Device at any time. The programming of this new
functionality takes place in the “FB_Diagnosis” function block which is to be created. This function
block is called in OB1 with the instance data block “iDB_FB_Diagnosis”.
The HMI screen for communication with the controller already exists in the library. The screen
elements are linked with the tags/variables of the data block “PROFINET_Diagnosis”.
SITRAIN © Siemens AG 2018
Page 18
IK-TIAPN
Diagnostics
Task Description: Reading-out the ET200SP Device
Name and Activating / Deactivating the IO-Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-20 Training Document, V15.01.00
7.10.1. Exercise 3:
Reading-out the ET 200SP Hardware Identifier and Outputting it on the HMI

Task
You are to integrate the data block “PROFINET_Diagnosis” into your project and use the
variables contained in this block for parameterizing the PLC instructions.
You are to read out the hardware identifier of the ET 200SP and this is subsequently to be output
on the HMI screen “PROFINET-IO”. The reading-out of the hardware identifier is to take place in
the function block “FB_Diagnosis”. This function block is called in the organization block “Main”
and must be created by you.
What to Do
1. Using drag & drop, drag the data block called “PROFINET_Diagnosis” from the IK-TIAPN
library in the folder Chapter7 in the subfolder “SPS” into your project.
2. Create a new function block called “FB_Diagnosis” and call it in your OB1. Name the instance
data block “iDB_FB_Diagnosis”.
3. In your FB, create the instructions necessary for reading out and outputting the hardware
identifier.
4. Download the changes into the controller.
5. Drag the HMI screen “PROFINET-IO” into the folder “Screens” and the tag table
“PROFINET_Diagnosis” into the folder “HMI tags” which are located in the Device “touch-me”.
6. Link the "PROFINET-IO" screen with the "Start" screen just as it is in the "Diagnosis" screen.
7. Load the changes onto your HMI device and test your program.
8. If necessary, make changes so that your program matches the task.



SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Diagnostics
Exercise 3: Reading-out the ET200SP Hardware
Identifier and Outputting it on the HMI
Drag & Drop
Read out the
HW identifier
Output HW
identifier
HMI screen for
output
Input
GEOADDR
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-21
Note
Please note that thedata types “HW_ANY” and “HW_IO” cannot be used on the TP700 Comfort!
If necessary, take another look at the structure of the data type “GEOADDR” in the Online Help of
TIA Portal.
As required, use temporary as well as static variables in the function block!
It may be that the connection between the touchpanel and the controller does not correspond to
the configured connection in the tag table “PROFINET_Diagnosis”. In this case, adjust the
connection and re-synchronize the HMI tags!
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-22 Training Document, V15.01.00
7.10.2. Exercise 4: Activating / Deactivating the ET 200SP

Task
After the hardware identifier is read-out, it is now to be used to activate and deactivate your IO-
Device during runtime. Furthermore, the status of the IO-Device can then also be read out.
This functionality, as well, is output on the TP700 Comfort and controlled by it.
What to Do
1. Program the functionality called for in the task in your FB “FB_Diagnosis”.
2. Download and test your programming.
3. If necessary, make changes so that your program matches the task.
Note
The “REQ” parameter of the function “D_ACT_DP” is not edge-controlled.
As required, use temporary as well as static variables in the function block!
SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Diagnostics
Exercise 4: Activating / Deactivating the ET200SP
Switch on/off
IO-Device
Control
D_ACT_DP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-23
7.10.3. Exercise 5: Reading-out the ET 200SP Device Name and Outputting it on
the HMI

Task
Finally, the PROFINET device name of the ET 200SP is to be read out and presented on the HMI
device.
This functionality is also to be implemented in the FB “FB_Diagnosis”.
What to Do
1. Open the function block “FB_Diagnosis” and program the functionality.
2. Download and test your programming.
3. If necessary, make changes so that your program matches the task.
4. Save your project.
Note
The call of the instruction “Get_Name” is to be made using a multiple instance.
As required, use temporary as well as static variables in the function block!
SITRAIN © Siemens AG 2018
Page 21
IK-TIAPN
Diagnostics
Exercise 5: Reading-out the ET200SP
Device Name and Outputting it on the HMI
Read out the IO-
Device name
Control
Get_Name
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-24 Training Document, V15.01.00
7.11. Reading-out the Module LED Status

LED
In a plant, most controllers are installed in the control cabinet. This means that the simplest way
of quickly doing a system diagnostics, namely looking at the LEDs on the controller or the
component, is not possible.
The instruction “LED”, however, makes it possible to read out the LEDs of a module and so
visualize the LED Status on a display unit or similar. This way, the LED Status of the module can
be analyzed and evaluated through the program.
The instruction “LED” requires the hardware identifier of the module for this and the specific
identification number of the LED on the module. If this does not exist, it is displayed through the
output parameter “RET_VAL”. Through this parameter, the status of the LED, such as, flashing
with 1 Hz or flashing with 2Hz, can also be displayed.

SITRAIN © Siemens AG 2018
Page 22
IK-TIAPN
Diagnostics
Reading-out the Module LED Status
Hardware identifier
LED-Nummer
1 STOP/RUN
2 ERROR
3 MAINT (Maintenance)
4 Redundant
5Link (green)
6 RX/TX (yellow)
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-25
7.12. Reading-out the Device and Module States

DeviceStates
If the state or the status information of all modules within a PROFINET IO-System or within a DP-
Master system has to be queried, the instruction “DeviceStates” can be used. This allows you to
read out different statuses of the connected Devices through the parameter “Mode”. These
statuses are stored in the InOut parameter “STATE”. If the status information of a PROFINET IO-
System is to be read-out, an Array of 1024 bits is used at the parameter “STATE”; for a DP-
Master system, an Array of 128 bits is used. For this Array, the Bit 0, that is, the first bit, always
serves as the group display for both systems. If for at least one Device the bit of the status
display is set to 1, the group display bit also has the Status 1.
For a PROFINET IO-System, the individual bits of the Array correspond to the device numbers of
the individual IO-Devices. For a DP-Master system, the bits then correspond to the PROFIBUS
addresses of the individual DP-Slaves.
ModuleStates
If, instead of the state of a PROFINET IO-System or a DP-Master system, the state of the
individual modules of an IO-Device or a DP-Slave has to be read-out, the function “ModuleStates”
can then be used. With the help of this instruction, different status information of the individual
modules can be queried through the input parameter “MODE”. Just as for the instruction
“DeviceStates”, the statuses of the individual modules are then stored in the InOut parameter
“STATE”. The parameter “STATE” is an Array with 128 bits. Here as well, the first bit serves as
the group display. If a bit in the Array is set to 1 through the instruction “ModuleStates”, the group
display is also automatically set to 1.

SITRAIN © Siemens AG 2018
Page 23
IK-TIAPN
Diagnostics
Reading-out the Device and Module States
Array [0..1023] of BOOL
Array [0..127] of BOOL
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-26 Training Document, V15.01.00
MODE
The value passed via the parameter “MODE” to the instructions “DeviceStates” and
“ModuleStates” causes the same configuration for both instructions. The only difference is that
the setting for the instruction “DeviceStates” refers to the individual Devices/Slaves and for the
instruction “ModuleStates” it refers to the individual modules. The following status information can
be queried via the configuration of the parameter “MODE”:
1. IO-Devices/DP-Slaves – Modules are configured
2. IO-Devices/DP-Slaves – Modules have failed
3. IO-Devices/DP-Slaves – Modules deactivated
4. IO-Devices/DP-Slaves – Modules present
5. IO-Devices/DP-Slaves – Modules for which a problem has occurred:
• Maintenance necessary or recommended
• Not accessible
• Not available
• Error has occurred
• …


Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Diagnostics
Training Document, V15.01.00 7-27
7.13. Task Description: Reading-out the Module State of the
ET 200SP

Task Description
As a final diagnostic function, the state of the modules of the ET 200SP are to be read-out. This
functionality is also implemented in the FB “FB_Diagnosis” with the help of the instruction
“ModuleStates”.
The evaluation of the status information of the individual modules is to take place through the
data block “PROFINET_Diagnosis”.
SITRAIN © Siemens AG 2018
Page 24
IK-TIAPN
Diagnostics
Task Description:
Reading-out the Module State of the ET200SP
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Diagnostics
7-28 Training Document, V15.01.00
7.13.1. Exercise 6: Reading-out the Module State of the ET 200SP

Task
You are to supplement your function block “FB_Diagnosis” by adding the function “ModuleStates”
and you are to evaluate the state of the modules of the ET 200SP in it. Decide for yourself which
mode you must use so that the status information displays which modules of the ET 200SP have
failed and which are currently running without errors.
The evaluationof the status information is carried out directly in the data block
“PROFINET_Diagnosis” via the TIA Portal functionality “Monitor block” .
What to Do
1. Open the function block “FB_Diagnosis” and program the functionality.
2. Download and test your programming.
3. If necessary, make changes so that your program matches the task.
4. Save your project.
Note
As required, use temporary as well as static variables in the function block!

SITRAIN © Siemens AG 2018
Page 25
IK-TIAPN
Diagnostics
Exercise 6:
Reading-out the Module State of the ET200SP
Read-out module
state
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-1

Contents 8





8. Web Services PROFINET ....................................................................................... 8-2
8.1. Diagnostics Anywhere, Anytime ........................................................................................... 8-3
8.2. Activating the Web Server on the CPU ................................................................................. 8-4
8.3. Access with HTTPS .............................................................................................................. 8-5
8.4. Introduction Page & Web Server (Access Level: Minimum) ................................................. 8-6
8.5. Web Server (Access Level: Administrative) .......................................................................... 8-7
8.6. Diagnostics ............................................................................................................................ 8-8
8.7. Diagnostic Buffer ................................................................................................................. 8-10
8.8. Module Information ............................................................................................................. 8-11
8.8.1. Firmware Update via Module Information ........................................................................... 8-12
8.9. Alarms ................................................................................................................................. 8-13
8.10. Communication Part1 ......................................................................................................... 8-14
8.11. Communication Part2 ......................................................................................................... 8-15
8.12. Set Topology ....................................................................................................................... 8-16
8.13. Actual Topology .................................................................................................................. 8-17
8.14. Topology and Module Information ...................................................................................... 8-18
8.15. Reading the Tag Status ...................................................................................................... 8-19
8.16. Writing the Tag Status ........................................................................................................ 8-20
8.17. Reading the Watch Tables .................................................................................................. 8-21
8.18. Writing the Watch Tables .................................................................................................... 8-22
8.19. Online Backup of the PLC ................................................................................................... 8-23
8.20. Customer Pages ................................................................................................................. 8-24
8.21. Filebrowser .......................................................................................................................... 8-26
8.22. DataLogs ............................................................................................................................. 8-28
8.23. Task Description: Activating the Web Server of the S7-1513 and Uploading a Filebrowser
File ...................................................................................................................................... 8-30
8.23.1. Exercise 1: Activating the Web Server on the S7-1513 ...................................................... 8-31
8.23.2. Exercise 2: Uploading a File onto the Filebrowser ............................................................. 8-32
8.23.3. Exercise 3: Checking the File on the Memory Card ........................................................... 8-33
8.24. Web Server CPU S7-1510SP - 1PN ................................................................................... 8-34
8.25. Web Based Management (WBM) SCALANCE XC208....................................................... 8-35
8.26. Cable Test ........................................................................................................................... 8-36
8.27. Task Description: Activating the Web Server of the S7-1510SP + Cable Test via the
SCALANCE XC208 Web Server ......................................................................................... 8-37
8.27.1. Exercise 4: Activating the Web Server of the S7-1510SP .................................................. 8-38
8.27.2. Exercise 5: Executing the Cable Tester Function in the Web Server of the SCALANCE
XC208 ................................................................................................................................. 8-39
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-2 Training Document, V15.01.00
8. Web Server


SITRAIN
IK-TIAPN / Web Services PROFINET Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... be familiar with the possibilities of web diagnostics and be able
to apply them
... understand the web server of the S7-1500
... be able to parameterize the web server of the S7-1500
... be familiar with the Web Based Management of a SCALANCE
Switch
... be able to carry out a cable test via a SCALANCE Switch
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-3
8.1. Diagnostics Anywhere, Anytime

Diagnostics via the Web Server
Available from everywhere and accessible at all times - this is what customers always expect
from the diagnostics of systems. When the system is connected to the Internet via a router and
taking into account the relevant security guidelines, you are one step closer to meeting these
expectations. We are talking about the integrated web server on the S7-1500 and the S7-1200 as
well as on most other SIMATIC products of the newest generation here.
Via the web server, it is possible to operate diagnostics with only the help of a web browser. No
further software or other aids are required. The different possibilities are explained in more exact
detail in the following sections.
Note
On the Service & Support pages, you will find the download for the function manual about the
web server of the S7-1500 under the Entry-ID: 59193560.

SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Web Services PROFINET
Diagnostics Anywhere, Anytime
Worldwide
diagnostics
ID: 59193560
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-4 Training Document, V15.01.00
8.2. Activating the Web Server on the CPU

Activating the Web Server
In the CPU’s delivered condition, the web server is deactivated for security reasons. This can be
activated with a few mouse clicks:
• Select (highlight) the CPU either in the Device view or in the Network view
• In the CPU Properties, select the section Web server
• Activate the web server and set the desired update interval
• Edit the User management• Compile the configuration and reload,
Note
In order to be able to access the web server, the access via the interface through which you want
to reach the PLC web server must however, still be activated!
The User management must be adjusted. By default, there is no administrator and every user of
the web server only has minimum authorization!
When activating the web server, the following pop-up window appears in which TIA Portal
separately points out the need to take appropriate safety measures against manipulation from
outside:

SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Web Services PROFINET
Activating the Web Server on the CPU
Activate
web server
Properties
Controller
Automatic
update
Eigenschaften
Schnittstelle
Zugriff auf
Webserver
aktivieren
Activate web
server access
User
management
Properties
Interface
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-5
8.3. Access with HTTPS

HTTPS – Secure Connection
HTTPS stands for “Hyper Text Transfer Protocol Secure” and is used to transfer data tap-proof in
the World Wide Web. This function can also be used for the SIMATIC web server. If the access to
the web server is only to be possible using a secure connection, the relevant checkmark must be
set for the option “Permit access only with HTTPS”.
For an error-free HTTPS access to the SIMATIC, the following points must be ensured:
• The current time-of-day must be set in the CPU.
• The IP address of the CPU must be stipulated.
• A valid certificate must be installed in the web browser.
Certificate
The certificate for the web server can be downloaded via the Introduction page and then installed
in the web browser used. It is also possible to access the SIMATIC without an installed certificate
if the option: “Continue to this website (not recommended)” is selected in the window that opens.
This is only possible for S7-1500 controllers with FW < 2.0.
You will find further information on this topic and on self-signed certificates in the Entry-ID
103528224.
Note
Even if the checkmark is not set for the option “Permit access only with HTTPS”, you can always
access the SIMATIC using HTTPS!

SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Web Services PROFINET
Access with HTTPS
Access only with
HTTPS
Intro page
web server
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-6 Training Document, V15.01.00
8.4. Introduction Page & Web Server (Access Level: Minimum)

Introduction Page Web Server
Through the IP address of the configured CPU, you can establish a connection to its web server
after it was activated in the hardware configuration. The connection can be established either
through a standard connection with the prefix “http://” or through a secure connection with the
prefix “https://”.
By default, the introduction page appears the first time the web server is accessed. Here there
are links to the Industry Mall, to an Overview of the SIMATIC controllers, to the Service & Support
pages and the possibility of downloading the certifcate for the HTTPS connection.
If the option “Skip Intro” is activated, the introduction page is no longer displayed the next time the
web server is accessed. It is then routed directly to the Start page of the web server.
Start Page Web Server
With minimum authorization, only the Start page on the web server of the CPU can be looked at.
Without any authorization level, you (the user) only see(s) in which operating mode (e.g. RUN or
STOP) the PLC is and which status it currently has.
Note
If, after activating the option “Skip Intro”, you wish to go back to the introduction page, it can be
called by clicking on the link “Intro”.

SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Web Services PROFINET
Introduction Page & Web Server (Access Level:
Minimum)
minimale
Berechtigungen
User log in
Minimum
authorization
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-7
8.5. Web Server (Access Level: Administrative)

Authorizations Web Server
The assignment of individual access authorizations for the web server user must be made in the
Hardware configuration of the controller.
By default, no user is set up and all accesses to the web server only have minimum authorization.
In case not all authorizations are selected, the user is given limited authorization:

In the following sections, as an example, the individual pages of the web server are displayed
with administrative authorization.
Start Page Web Server
If the authorizations “flash LEDs” and “change operating mode” are assigned for the logged in
user, he can let the LEDs of the Devices flash as well as set the operating mode to STOP or RUN
on the Start page of the web server.



SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Web Services PROFINET
Web Server (Access Level: Administrative)
maximale
Berechtigungen
Maximum
authorization
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-8 Training Document, V15.01.00
8.6. Diagnostics

Diagnostics
The "Diagnostics" web page of the web server is divided into five subcategories – "Identification",
"Program protection", "Memory", "Runtime information" as well as "Fail-safe".
Identification
The "Identification" tab contains various general CPU characteristics such as the order number or
the Firmware version which is currently loaded on the CPU.
The information which is found in "Identification" can be entered in the general properties of the
controller.
Program Protection
Here, you will find information about whether the PLC program contains a know-how protection or
a copy protection. As soon as at least one block is present in the PLC that has a know-how
protection, it is indicated here. The "Binding" information field indicates whether a copy protection
is activated through the binding to the serial number of the CPU or the Memory Card for at least
one block of the PLC program.
Memory
Here you will find current values on the memory utilization of the controller. This information is
useful if larger expansions to the program are pending and you are unsure of how much memory
space is currently still available on the CPU and on the memory card.





SITRAIN © Siemens AG 2017
Seite 9
IK-TIAPN
Webdienste PROFINET
Diagnose
Identifikation
Laufzeitinfo
Programmschutz
Fehlersicher
Speicher
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-9
Runtime Information
You will find current information on program load, communication load and cycle time in the
"Runtime information" tab. From this data you can determine whether runtime problems could
possibly exist for the execution of the user program.
Fail-safe
The safety program of an F-CPU consists of one or two F-runtime groups. The F-runtime group’s
signature, cycle times (F-monitoring time) and runtimes of these F-runtime groups can be found
in the "Fail-safe" tab.
Note
The "Diagnostics" page is activated (enabled) through the authorization "query diagnostics":






























 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-10 Training Document, V15.01.00
8.7. Diagnostic Buffer

Diagnostic Buffer
You can look at the diagnostic buffer of the PLC on the web server via the “Diagnostic buffer”
page. For every diagnostic buffer entry, there is a section with the detailed information on the
currently selected entry underneath the list.
A maximum of 50 entries is always displayed which can be selected viaa drop-down menu:

The maximum number of diagnostic buffer entries can be taken from the technical data of the
respective device.
Note
The “Diagnostic Buffer” page is activated (enabled) through the authorization “query diagnostics”:


SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Web Services PROFINET
Diagnostic Buffer
Selection of the entries
to be displayed
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-11
8.8. Module Information

Module Information
The state of the hardware components can be read-out in the web server via the “Module
information” tab. The state of the CPU as well as the connected PROFINET IO-System and its
components are displayed here. Through the “PROFINET IO-System” section, the diagnostics
can be queried right down to the module level.
Note
The “Module information” page is activated (enabled) through the authorization “query
diagnostics”:



SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Web Services PROFINET
Module Information
Opens further
details
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-12 Training Document, V15.01.00
8.8.1. Firmware Update via Module Information

Firmware Update
If the user has the authorization to perform Firmware updates via the web server (see picture),
this can be carried out via the Module information page.
Via the Details view, in the “Firmware” tab, the Firmware downloaded from the Service & Support
pages can be selected and then loaded into the module.
Note
The authorization "perform a firmware update" automatically also activates (enables) the
authorization "change operating mode" as well as the authorization "query diagnostics":

SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Web Services PROFINET
Firmware Update via Module Information
Necessary
authorizations
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-13
8.9. Alarms

Alarms
Via the “Alarms” page of the web server, all alarms can be displayed which are currently pending
in the alarm buffer of the controller. These are displayed in the correct order of their occurrence
with date and time. Alarms in the alarm window cannot be acknowledged via the web browser.
In order to get the complete picture of error analysis, it is always recommended to look at the
“Diagnostic buffer” page in addition to the “Alarms” page.
Note
The “Alarms” page is activated (enabled) through the authorization “query diagnostics”:


SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Web Services PROFINET
Alarms
Alarm buffer
PLC
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-14 Training Document, V15.01.00
8.10. Communication Part1

Communication
On the “Communication” page of the web server, there are four subsections:
• Parameter
• Statistics
• Resources
• Connections
Parameter
Summarized information on the PROFINET and Ethernet interfaces of the associated CPU of the
web server is found in the “Parameter” tab.
Statistics
In order to be able to look at the statistics of the data transmission via the interfaces, you can
switch into the “Statistics” tab. Here, there is an overview of the sent and received data packages
of the CPU interfaces and the total amount of sent and received packages.

SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Web Services PROFINET
Communication Part1
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-15
8.11. Communication Part2

Resources
An overview of all connection resources in use, all connection resources not in use and the
maximum possible connection resources is found in the “Resources” tab.
Connections
In the "State" section, there is an overview of the communication connections being established
and the already established or set up connections.
For each of these connections, the table contains information on the connection State, the Local
ID, the Slot of the Gateway, the Remote address (IP address), the associated Remote address
type, the Type of connection and the connection Type.
Note
The “Communication” page is activated (enabled) through the authorization “query diagnostics”:


SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
Web Services PROFINET
Communication Part2
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-16 Training Document, V15.01.00
8.12. Set Topology

Topology
On the “Topology” web page, you are given information about the topological structure of the
system. Differentiation is made between the Set(point) Topology and the Actual Topology. The
Set Topology is only displayed if a topology was actually configured in the controller in TIA Portal.
The Actual Topology, on the other hand, is always detected and presented in the web server. The
“Topology” web page consists of the following tabs:
• Graphic view
• Table view
• Status overview
You can only switch between the Set and Actual Topology in the Graphic view. The Actual
Topology is always presented in the Table view tab! Only the devices of the PROFINET-IO
System of the CPU are displayed in the “Status overview” tab.
Graphic View
In the “Graphic view” tab, the topology of the system is graphically prepared and presented. You
can switch here between the presentation format Set Topology and Actual Topology and so carry
out a comparison between the project and the system.
Status Overview
In the “Status overview” tab, all devices of the PROFINET IO-System connected to the CPU are
presented. Here, a quick overview of the state of the IO-System can be made without distractions
resulting because of topological connection relationships.
Note
If a Set Topology is not configured in the CPU, all PROFINET-IO devices are simply presented in
the “Graphic view” tab when the Set Topology is selected.
SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
Web Services PROFINET
Set Topology
Sprung zum
Baugruppen-
zustand
Sprung zum
Baugruppen-
zustand
Jump to Module
information
Status of all
Devices of the
IO-System
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-17
8.13. Actual Topology

Actual Topology
The Actual Topology of the system can be displayed in two different formats – graphic and table.
Table View
In the Table view of the Actual Topology, not only the real connections between the devices are
displayed but also the statuses of the individual devices. Differentiation is made between the four
following statuses which can be presented:
• Configured and accessible PROFINET device
• Not configured and accessible PROFINET device
• Configured but not accessible PROFINET device
• Device for which no ‘neighborhood’ relationships
can be detected or the ‘neighborhood’ relationships are not
complete or can only be read-out with errors.
Note
The “Topology” page is activated (enabled) through the authorization “query diagnostics”:


SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Web Services PROFINET
Actual Topology
Zustand
Devices
Zustand
Devices
Zustand
Devices
Zustand
Devices
Zustand
Devices
State of Devices
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-18 Training Document, V15.01.00
8.14. Topology and Module Information

Switch to the Module Information
With a mouse-click on the State symbol of the represented device, you can switch to the
associated Module information. That is, the web server page “Module information” is
automaticallyopened with the correct Device and the error source can be analyzed!

SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Web Services PROFINET
Topology and Module Information
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-19
8.15. Reading the Tag Status

Tag Status
In the web server, the status of the tags defined in the controller can be monitored via the “Tag
status” page. Only a symbolic addressing is permitted. Absolute addresses cannot be monitored
via the “Tag status”. Tags from all tag tables defined in the project can be monitored.
When you exit the “Tag status” page, any tags which have been entered are not stored. That is,
the next time the page is opened, the page will be empty. If you want to keep the configuration of
the tags to be monitored, you either have to create a bookmark in the browser for the configured
tag status or you have to save the address line from the browser. That way you can re-access the
same tag configuration.
Note
The “Tag status” page is activated (enabled) through the authorization “read tag status”:


SITRAIN © Siemens AG 2018
Page 18
IK-TIAPN
Web Services PROFINET
Reading the Tag Status
Value at time of
update
Tag tables of the
controller
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-20 Training Document, V15.01.00
8.16. Writing the Tag Status

Write Tag Status
On the “Tag status” page in the web server of the CPU, the authorization “write tag status”
permits you not only to read out the value of tags but also to change the value of these tags via
the web server.
However, you can still only use tags which have been declared symbolically in the controller.
Note
It is possible to only activate the authorization “write tag status”. However, this doesn’t make
sense since the “Tag status” menu item only appears in the web server when the authorization
“read tag status” has been assigned!

SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Web Services PROFINET
Writing the Tag Status
erlaubt das Wert
ändern im
Variablenstatus
Permits you to
change values in
the tag status
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-21
8.17. Reading the Watch Tables

Watch Tables
On the “Watch tables” page of the web server, you can also use the watch tables created in the
project for the controller for the web server. For this, the tables which are also to be displayed in
the web server must be added in the hardware configuration of the controller under the “Web
server” menu item and there under Watch tables.
Currently, only a read-only access to these tables is possible. That is, these cannot be expanded
via the web server.
In addition, the tags in the table can only be read and not controlled (written) via the Watch tables
in the web server, unlike the Watch tables in the project.
If there are absolute addresses without symbol in the symbol table which is displayed in the web
server, then no current values are displayed for these in the Watch tables in the web server. This
contrasts with Watch tables in the project where absolute addresses without symbol can also be
monitored.
Note
The number of Watch tables which can be monitored in the web server depends on the size of
the SIMATIC Memory Card used. When the existing memory space is exceeded by configured
alarms and tags, Watch tables in the web browser are only partially displayed.
The “Watch tables” page is activated (enabled) through the authorization “read tags”:

SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Web Services PROFINET
Reading the Watch Tables
Without a
symbol, no value
can be
presented
Eigenschaften
Steuerung
Properties
Controller
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-22 Training Document, V15.01.00
8.18. Writing the Watch Tables

Write Tags
If the user is assigned the authorization “write tags”, it is now also possible for him, on the “Watch
tables” page, to change the value of the tags in this table.
Note
So that it is possible to change the values of tags in a Watch table, this must be set in the web
server settings of the controller:

It is possible to only activate the authorization “write tags”. However, this doesn’t make sense
since the “Watch tables” menu item only appears in the web server when the authorization “read
tags” has been assigned!

SITRAIN © Siemens AG 2018
Page 21
IK-TIAPN
Web Services PROFINET
Writing the Watch Tables
erlaubt das Wert
ändern in
Beobachtungstabellen
Permits values to be
changed in Watch
tables
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-23
8.19. Online Backup of the PLC

Online Backup
The web server of the controller enables the user to create or to restore (load) a backup of the
controller without having to start and operate TIA Portal. Requirement for this, of course, is the
appropriate authorization that must be assigned to the user.
Any number of backups of the controller can be created and as a result different configurations
can be kept for one CPU.
Note
An online backup of the controller is only possible in the "STOP" mode. For that reason, in
addition to the right to create or restore an online backup, the user must also be assigned the
right to change the operating mode.

SITRAIN © Siemens AG 2018
Page 22
IK-TIAPN
Web Services PROFINET
Online-Sicherung der PLC
Online-Sicherung nur
in Stopp der CPU
möglich
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-24 Training Document, V15.01.00
8.20. Customer Pages

Customer Pages
In the "Customer pages" area of the web server, HTML pages, which you yourself create, can be
displayed.
On these pages, tags of the controller can be read and written. The pages are generated and
edited with an HTML editor. Then TIA Portal generates data blocks (Web-Control-DB and
Fragment-DBs) from these pages which are loaded into the controller. Using the instruction
“WWW”, the web server of the controller is then synchronized and initialized with the user
program. The first call of the instruction “WWW” generates the link to the customer pages on the
web server of the CPU (see picture). A click on the link then starts the customer pages in a new
browser window.


Note
The “Customer pages” page is activated (enabled) through the authorizations “open user-defined
web pages” as well as “write in user-defined web pages”. With the authorization “write in user-
defined web pages”, the authorization “open user-defined web pages” is also automatically
assigned:


SITRAIN © Siemens AG 2018
Page 23
IK-TIAPN
Web Services PROFINET
Customer Pages
ID: 68011496
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-25
An entry which deals with customer pages on the S7-1500 in more detail can be found on the
Service & Support pages under the Entry-ID: 68011496.
Important
Writing accesses in customer pages can influence the process parameters and with that the
operation of the CPU.
For that reason, it is strongly recommended that a password is always assigned in the User
management for users with write-access in customer pages to protect against manipulations from
outside!
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-26 Training Document, V15.01.00
8.21. Filebrowser

Filebrowser
The “Filebrowser” page is activated (enabled) through the authorization “read files”. Via the web
browser, you can now lookat which additional files are on the SIMATIC Memory Card in the CPU
and open them. This is very helpful, for example, for commissioning or for service calls, since
additional information material such as manuals, system descriptions and similar can be stored
here.
With the authorization “write/delete files”, additional authorizations are activated (enabled). These
include:
• The uploading of files to the SIMATIC Memory Card of the controller
• The deleting of files on the SIMATIC Memory Card
• The renaming of files on the SIMATIC Memory Card
All these authorizations refer to the “Filebrowser” in the web server of the controller! Of course, it
is always possible to write, to delete or to rename files by inserting the SIMATIC Memory Card of
the CPU into a card reader, regardless of the user authorizations in the web server!


SITRAIN © Siemens AG 2018
Page 24
IK-TIAPN
Web Services PROFINET
Filebrowser
Upload/
Delete/Change
permitted
Activate
Filebrowser
Uploaded
manuals
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-27
Note
The authorization “write/delete files” does not yet activate the menu item “Filebrowser” in the web
server:

The File server is only activated with the authorization “read files”.
The program files which are generated when the project is downloaded onto the controller are not
displayed in the File browser for security reasons.
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-28 Training Document, V15.01.00
8.22. DataLogs

DataLogs
The “DataLogs” page on the web server makes it possible to look at the “DataLogs” generated via
the program and to store it on your local computer. Since a local temporary copy is generated on
the computer when the Log file is opened via the web server, you can still save information in this
Log file from the controller side. The format in which the Log files are generated is the CSV
format (comma separated values).
Via the web server, the Log files present on the controller can also be emptied, if the
authorization “write/delete files” was assigned. However, the Log files are not completely deleted
from the SIMATIC Memory Card through this action. Only the contents, that is, the entries of the
Log file are deleted. This action is however not possible if the selected Log file is still open in the
controller!
DataLogs in the Filebrowser
If there are Log files on the SIMATIC Memory Card, they are also displayed on the “Filebrowser”
page in a separate folder.

SITRAIN © Siemens AG 2018
Page 25
IK-TIAPN
Web Services PROFINET
DataLogs
Upload -
Delete - Change
Activate DataLogs
page
ID: 59193101
Empty Logfile
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-29
Note
The “DataLogs” page uses the same authorizations as the “Filebrowser” page:

On the Service & Support pages, you will find a document which covers the structure and use of
the CPU memory of the S7-1500 under the Entry-ID: 59193101. This PDF also contains a
chapter which deals with the topic of data logging and also includes a small programming
example.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-30 Training Document, V15.01.00
8.23. Task Description: Activating the Web Server of the
S7-1513 and Uploading a Filebrowser File

Task Description
You are to activate the web server of the S7-1513. You are then to create a new User and assign
him the necessary rights so that he can use the Filebrowser. You can assign any user name and
password you like. Finally, you are to load a file, such as, your archived project onto the memory
card of the controller via the Filebrowser of the web server.
SITRAIN © Siemens AG 2018
Page 26
IK-TIAPN
Web Services PROFINET
Task Description: Activating the Web Server of the
S7-1513 and Uploading a Filebrowser File
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-31
8.23.1. Exercise 1: Activating the Web Server on the S7-1513

Task
You are to activate the web server on the S7-1513 controller. Then, you are to set up a new User.
Make sure that he has the necessary authorizations so that he can load files onto the File server
of the web browser and, with that, onto the SD card of the controller.
What to Do
1. Activate the web server on the controller.
2. Activate the option: “Permit access only with HTTPS”.
3. Create a new User and assign the required authorizations as stated in the task.
4. Save your project.
5. Download your changes into the controller.
Note
Don’t forget to check whether the access to the web server via the desired interface is also
activated.

SITRAIN © Siemens AG 2018
Page 27
IK-TIAPN
Web Services PROFINET
Exercise 1:
Activating the Web Server on the S7-1513
Activate
web server
Create new user
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-32 Training Document, V15.01.00
8.23.2. Exercise 2: Uploading a File onto the Filebrowser

Task
Via the web server, with the help of the Filebrowser, you are to upload any file from your
computer onto the SD card of the controller.
Recommendation: Archive your project and then upload it into the controller.
What to Do
1. Open your Internet Explorer (a browser of your choice).
2. Open the web server of the controller.
3. Log in to the web server using the previously created User.
4. Open the Filebrowser.
5. Upload any file, via the Filebrowser, onto the SD card of the controller.

SITRAIN © Siemens AG 2018
Page 28
IK-TIAPN
Web Services PROFINET
Exercise 2: Uploading a File onto the Filebrowser
Uploaded file
Upload file to
SD card
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-33
8.23.3. Exercise 3: Checking the File on the Memory Card

Task
You are to check whether the upload of your file really worked. You are to remove the SD card
from the controller and insert it in the SD card reader on your Field-PG (left side). Then, with the
Windows Explorer, you are to check whether your uploaded file is on the SD card. After that, you
are to re-insert the card in the controller and start the controller.
What to Do
1. Remove the SD card from the controller.
2. Insert the SD card in the card reader of your Field-PG (left side).
3. With the help of the Windows Explorer, check whether your file is on the SD card.
4. If it is not on the SD card, repeat the previous exercise!
5. If the file is on the SD card, remove the card from the Field-PG and re-insert it in the controller.
6. Start the PLC.

SITRAIN © Siemens AG 2018
Page 29
IK-TIAPN
Web Services PROFINET
Exercise 3: Checking the File on the Memory Card
File was uploaded
onto the card
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-34 Training Document, V15.01.00
8.24. Web Server CPU S7-1510SP - 1PN

Web Server CPU 1510SP - 1PN
From its handling, the web server of the CPU S7-1510SP - 1PN is not different from the web
server of the CPU S7-1513 - 1PN or from that of another CPU. The basic settings, such as,
activating the web server, setting up the User authorizations, setting the accessibility of the web
server, etc. are exactly identical!
The web servers of the various controllers can differ regarding which authorizations can be
activated (enabled) for the different Users.
Below is a comparison between the possible authorizations for an S7-1513 - 1PN V1.7 (left) and
the S7-1513 - 1PN V1.8 (right):Unlike an S7-1513 - 1PN V1.7, an S7-1513 - 1PN V1.8 also permits the writing of tags and the
writing of tag statuses.

SITRAIN © Siemens AG 2018
Page 30
IK-TIAPN
Web Services PROFINET
Web Server CPU 1510SP-1PN
Administrative
authorizations
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-35
8.25. Web Based Management (WBM) SCALANCE XC208

Web Based Management (WBM) SCALANCE XC208
IE Switches have an integrated HTTP-Server for the Web Based Management. If an IE switch is
addressed via a web browser, it returns HTML pages to the client computer depending on the
user inputs.
The user enters his configuration data into the HTML pages sent by the IE switch. An IE switch
evaluates this information and dynamically generates answer pages. The particular advantage of
this functional principle is that no special software except a web browser is required on the client
side.
Requirements for a WEB
So that the Web Based Management of an Industrial Ethernet switch can be used, at least the
following requirements must be fulfilled:
• An IE switch must have and IP address so that you can use the Web Based
Management.
• In order to be able to use the Web Based Management, an Ethernet connection between
the IE switch and the client computer must exist.
• It is recommended that you use a current browser.
• All pages of the Web Based Management require JavaScript. For that reason, make sure
that JavaScript is activated in the browser settings.
• Since the Web Based Management is HTTP or HTTPS-based, you must enable the
access to Port 80 or 443 when a firewall is installed.
Note
The browser must not be setup in such a way that it is to reload the page from the server every
time the page is accessed. The currentness of the dynamic page contents is ensured through
other mechanisms.
SITRAIN © Siemens AG 2018
Page 31
IK-TIAPN
Web Services PROFINET
Web Based Management (WBM) SCALANCE XC208
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-36 Training Document, V15.01.00
8.26. Cable Test

Cable Test
Via the SCALANCE XC208, you can carry out an error diagnosis of the cables on the individual
electrical Ethernet ports. This option is called "Cable Tester" and is found in the Web Based
Management in the menu "System" and there under the entry "Port Diagnostics". This makes it
possible to localize short-circuits and cable interruptions.
This function is not possible for IRT devices.
In order to be able to carry out the error diagnosis, the Ethernet cable must be plugged into the
SCALANCE XC208. However, there must not be any physical connection (link) to another
network component. That is, the other cable end must not be connected!
Then the port, to which the cable is connected, is selected via the Web Based Management and
the test is performed.
SITRAIN © Siemens AG 2018
Page 32
IK-TIAPN
Web Services PROFINET
Cable Test
Port selection
Cable must not
be connected
Cable error-free
and connected
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-37
8.27. Task Description: Activating the Web Server of the S7-1510SP
+ Cable Test via the SCALANCE XC208 Web Server

Task Description
You are to activate the web server of the S7-1510SP CPU and become familiar with its user
interface. Then you are to switch into the WBM of the SCALANCE XC208 and there carry out a
cable test for all cables connected to the SCALANCE XC208!

SITRAIN © Siemens AG 2018
Page 33
IK-TIAPN
Web Services PROFINET
Task Description: Web Server of the S7-1510SP +
Cable Test via SCALANCE XC208 Web Server
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Web Services
8-38 Training Document, V15.01.00
8.27.1. Exercise 4: Activating the Web Server of the S7-1510SP

Task
You are to activate the web server of the S7-1510SP controller and compare its user interface
and options with the web server of the S7-1513 SPS.
What to Do
1. Switch to the Devices view of the S7-1510SP.
2. Activate the web server of the controller and also make sure that it is accessible via the
connected PROFINET interface.
3. Create a new User with an “administrative” access level.
4. Download the changes into the controller.
5. Start the Internet Explorer and call the web server of the controller via its IP address.
6. Log in to the web server using the newly created User.
7. Test the functionalities of the web server such as “Diagnostic Buffer”, “Module information” as
well as “Topology” and compare these to the web server of the S7-1513 which you already
know.



SITRAIN © Siemens AG 2018
Page 34
IK-TIAPN
Web Services PROFINET
Exercise 4:
Activating the Web Server of the S7-1510SP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Web Services
Training Document, V15.01.00 8-39
8.27.2. Exercise 5: Executing the Cable Tester Function in the Web Server of the
SCALANCE XC208

Task
Via your web browser, you are to call the function ‘Cable Tester’ in the Web Based Management
of the SCALANCE XC208. Then you are to test all cables connected to the SCALANCE XC208
for their length and their functioning.
What to Do
1. Open the Web Based Management of the SCALANCE XC208 in your web browser.
2. Log in to the Web Based Management as Administrator.
3. Switch to the Cable Tester function in the WBM of the SCALANCE XC208.
4. Carry out a wire test/cable test for all cables connected to the switch.
5. After that, you can still become familiar with the other options of the Web Based Management
of the switch.
Note
In their delivered condition, most Siemens IE switches have the default administrator access:
admin / admin. That is, both the User name and the User password for administrative
authorizations on the switch is "admin". It is imperative that this is adjusted to your own needs
when the switch is commissioned in a system! This is the only way to prevent an unauthorized
access to the switch and with that the system!
Newer switches of the SCALANCE family automatically
prompt the user to assign a new password after the first
Administrator login!



SITRAIN © Siemens AG 2018
Page 34
IK-TIAPN
Web Services PROFINET
Exercise 4:
Activating the Web Server of the S7-1510SP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-1

Contents 9





9. Ring Redundancy MRP .......................................................................................... 9-2
9.1. Ring Topology ....................................................................................................................... 9-3
9.2. MRP – Media Redundancy Protocol ..................................................................................... 9-4
9.3. Operation of an MRP Ring .................................................................................................... 9-5
9.4. Controlling the Ring with the MRP Manager ......................................................................... 9-6
9.5. Detecting a Defective Ring Line............................................................................................ 9-7
9.6. Restoring the Defective Ring Line ........................................................................................ 9-8
9.7. MRP Options on the S7-1513 ............................................................................................... 9-9
9.8. Domain Settings .................................................................................................................. 9-10
9.9. Watchdog Time ...................................................................................................................9-11
9.10. Task Description: Introducing a Loop and then Activating MRP ....................................... 9-12
9.10.1. Exercise 1: Introducing a Loop ........................................................................................... 9-13
9.10.2. Exercise 2: Activating MRP with the S7-1513 as MRP Manager ....................................... 9-14
9.10.3. Exercise 3: Running Light for Visualizing the Re-configuration Times ............................... 9-15
9.10.4. Exercise 4: Adjusting the Watchdog Time .......................................................................... 9-16
9.11. Additional Information ......................................................................................................... 9-17
9.11.1. MRP Manager (Auto) .......................................................................................................... 9-18
9.11.2. MRP on the SCALANCE XC208 ......................................................................................... 9-19


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-2 Training Document, V15.01.00
9. Ring Redundancy MRP


SITRAIN
IK-TIAPN / Ring Redundancy MRP Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... understand what a ‘Loop’ is and why it must be avoided without
MRP
... be able to configure and parameterize MRP
... be familiar with and understand the functional principle of MRP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-3
9.1. Ring Topology

Ring Topology without Redundancy Protocol
If devices are connected to one another in the Ethernet, it is important to avoid introducing a ring,
also called a loop, between the devices. If this should accidently happen circling telegrams
suddenly result within the network. This is especially the case when a device sends a broadcast
in the loop which is then forwarded by every additional device. Since the ring / loop is not
terminated, the broadcast now circles in the ring. With several circling telegrams, the load is then
so high that the network collapses and no more communication is possible via the network! This
can happen within seconds of a ring being introduced but it can also take several minutes. A
collapse of communication is, however, unavoidable with a ring without a redundancy protocol!
Furthermore, even when the loop is dissolved, it may be necessary to disconnect network
devices from the network before they can then be registered again on the network.
Redundancy Protocols / Ring Protocols
To prevent the circling of data telegrams, redundancy protocols are used in the ring. These have
different ways of working; however, they all have the same effect: the loop is dissolved and only if
required, that is, with the failure of a cable, is the loop closed once more.
In automation, the protocol MRP (Media Redundancy Protocol) is often used. This protocol is part
of the PROFINET specification.
Note
On the Service & Support pages, you will find an entry under the EntryID: 33696406 which takes
a closer look at the topic of ring redundancy with the Media Redundancy Protocol (MRP).

SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Ring Redundancy MRP
Ring Topology
ID: 33696406
A LOOP is
introduced
Circling
telegrams
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-4 Training Document, V15.01.00
9.2. MRP – Media Redundancy Protocol

The Ring Redundancy Procedure MRP
The Media Redundancy Protocol (MRP) is a standardized redundancy protocol for automation
and is specified in the standard IEC 61158 Type 10 “PROFINET”. Similar to STP or RSTP
((Rapid) Spanning Tree Protocol), the protocol is established on Layer 2 of the OSI-layer model.
The goal of ring redundancy procedures is to increase the availability of the system. This is
achieved by introducing an alternative route for the telegram traffic. So that circling telegrams
cannot be introduced via this alternative route, the route which the telegrams can take must be
managed. In a ring, this task is handled by the “Manager”. In an MRP ring, it is also called MRP
Manager. All other devices in a ring are referred to as “Clients”. The ports at which the individual
devices of the ring are connected to one another are referred to as “ring ports”.
Note
Whether a device can take on the role of “Manager”, “Client” or “both” in a ring can be found in
the device specifications. As soon as a device can take on the role of MRP Manager, it is also
usually possible to define this device as an MRP Client.

SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Ring Redundancy MRP
MRP – Media Redundancy Protocol
As a rule, PLCs
can take on both
roles
Standard: EC 61158 Type 10 "PROFINET"
Devices in an MRP Ring can take on the role of either Manager or Client
As a rule,
distributed I/Os
can only be a client
As a rule, Managed
Switches can take
on both roles
As a rule, Panels
can only be a client
All devices of an MRP ring must support
MRP and MRP must be activated
Response times of <= 200ms for a device
number <= 50 devices
Each Ring must include at least one
MRP Manager
Connection of the devices must only take
place via the ring ports
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-5
9.3. Operation of an MRP Ring

Requirements MRP Ring
Requirements for smooth operation with the Media Redundancy Protocol MRP are:
• The ring in which MRP is used must only consist of devices which support this function.
• "MRP" must be activated for all devices in the ring.
• All devices must be connected to one another via their ring ports.
• There must be at least one redundancy manager (Role "Manager (Auto)").
• If there is one device in the ring that has the role “Manager”, no further devices with the role
“Manager” or “Manager (Auto)” may be in this ring!
• The ring may consist of a maximum of 50 devices. Otherwise, re-configuration time of greater
than or equal to 200ms can result.
• All partner ports within the ring must have the same settings.
Re-configuration Time
The re-configuration time is the time which the manager in an MRP Ring requires to detect a
cable failure and to switch the alternative route for the telegrams active. This time can be up to a
maximum of 200ms.
Conditions
• RT operation is possible when MRP is used.
• The IRT operation is not possible in conjunction with MRP.
• The TCP/IP communication is possible in conjunction with MRP, since lost data packets are
repeatedly sent, if necessary.
• Prioritized startup and the use of MRP is not possible.

SITRAIN © Siemens AG 2018
Page 5
IK-TIAPN
Ring Redundancy MRP
Operation of an MRP Ring
Redundant line
(really exists!)
ET200SP is defined
as Client
Scalance is defined
as Client
TP700 is defined as
Client
MRP Manager
separates the ring
at a port
Controller is defined
as Manager
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-6 Training Document, V15.01.00
9.4. Controlling the Ring with the MRP Manager

The Way the MRP Manager Works
The task of the manager is to monitor the ring topology.
During normal operation of the ring, that is, without ring interruption due to an error, the
redundancy manager separates its two ring ports from one another so that the ring topology
becomes a line from the point of view of communication. As soon as the ring is open because of
the failure of a device or a cable break and the data communication is no longer ensured, the
redundancy manager re-configures the data routes within 200ms. For this, it connects its tworing
ports through and creates a new linear network structure through this replacement route.
SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Ring Redundancy MRP
Controlling the Ring with the MRP Manager
MRP Manager
sendet
Testtelegramm
Testtelegramm
wird an beiden
Ports versendet
During operation, test telegrams
are sent in parallel to both ports
and must be received at both
Test telegram is
sent to both ports
MRP Manager
sends test
telegram
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-7
9.5. Detecting a Defective Ring Line

Detecting a Defective Ring Line
Test telegrams are used to detect a defective ring line.
The redundancy manager monitors the ring for interruptions. For this, it sends test telegrams from
both ring port 1 and ring port 2. The test telegrams pass through the ring in both directions until
they arrive at the respective other ring port of the redundancy manager (see picture). If the ring is
interrupted, either due to the failure of the connection between two devices or even due to the
failure of an entire device, the sent test telegrams of the one ring port no longer reach the other
ring port. Through this procedure, the MRP Manager can detect an interruption of the ring and
then connect through its ring ports.
So that the devices in the ring do not try to send their telegrams to other devices via the defective
line but also take the “new” route, MRP Manager sends ARP delete telegrams to each device.
These delete the Forwarding Database (FDB) of the switches so that the new accessibility of the
existing devices is learned. Subsequently, the devices send the telegrams via the replacement
line.
Note
Unlike PROFIBUS, the electrical failure of a device in PROFINET also causes the failure of the
communication path via this device. Due to the failure of the device, the switch of the device also
fails. Incoming telegrams can then no longer be forwarded!


SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Ring Redundancy MRP
Detecting a Defective Ring Line
Test telegram traffic is
terminated
Cable break between 2
devicesRedundant line is
switched active
MRP Manager detects
that no more test
telegrams are received
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-8 Training Document, V15.01.00
9.6. Restoring the Defective Ring Line

Restoring the Defective Ring Line
As soon as the interruption is eliminated, the original transmission routes are re-established, the
two ring ports in the redundancy manager are separated from one another and the redundancy
clients are informed of the change. The redundancy clients then go back to using the original
routes to the other devices. Just as for the line failure, this is also implemented by sending delete
telegrams from the MRP Manager.
The Manager once again sends ARP delete telegrams and so deletes the FDB of the MRP
clients. Subsequently, they once again learn the “old” telegram route to all devices.

SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Ring Redundancy MRP
Restoring the Defective Ring Line
Test telegram traffic
can circulate once
more
Defective line was
exchanged
Redundant line is
switched to Standby
once again
MRP Manager detects
that test telegrams are
once again arriving
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-9
9.7. MRP Options on the S7-1513

MRP Options
The settings for MRP are made in the PROFINET interface of the device. There, the entry “Media
redundancy” is located, where the MRP functionality of the controller can be parameterized. If the
selected device does not support the ring redundancy procedure MRP, this entry does not exist in
the Advanced options.
The following items are found under the entry “Media redundancy”:
• The MRP Domains to which the Device is currently assigned. This can be changed in the
Network view.
• The Media redundancy role of the device. The drop-down menu for this entry differs
depending on the possible roles for the device.
The device can be both “Manager” and “Client”:

The device can only take on the role of a “Client”:

• The ring ports, via which the device is connected with the MRP Ring, are displayed here. If
the Device has more than two PROFINET ports, the ports presented here must be
connected with the ring!
• If the option “Diagnostic interrupts” is to be activated, the Device signals further diagnostic
interrupts, such as, wiring or port errors, a neighbor of the ring port does not support MRP,
ring interruptions and ring restoration, …. Redundancy managers signal more diagnostic
interrupts than clients.
• You can switch to the settings of the MRP Domains in the Network view via the button
“Domain settings”.

SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Ring Redundancy MRP
MRP Options on the S7-1513
Properties
Interface
MRP Domains
MRP Role
Ring ports CPU
Diagnostics interrupt
Further Domain
settings
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-10 Training Document, V15.01.00
9.8. Domain Settings

MRP Domains
In the Network view, the settings for the MRP domains present in the PROFINET IO-System can
be made.
Here, you get an overview as well as change possibilities for the following settings:
• How many MRP Domains are present in the selected IO-Network and which domains the
Default Domains represent are displayed.
• For each Domain, further information, such as, the number of interfaces within the ring, the
number of managers, etc. is presented:

• The IO-Network, to which the MRP Domain is assigned, is displayed.
• Devices which are members of the selected Domains. Here, the associated Domain of the
individual Devices as well as their role in the MRP Domain can additionally be adjusted and
changed.

SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Ring Redundancy MRP
Domain Settings
MRP-Domäne
Setting for Default
Domains
MRP role of the
devices
Devices in the
ring
MRP Domains
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-11
9.9. Watchdog Time

Watchdog time
In the menu item “Watchdog” in the PROFINET interface of an IO-Device, you will find the item
“Accepted update cycles without IO data”. Since the changeover times, in the MRP operation,
between the defective line and the replacement line can be up to 200ms in the Worst Case, this
number must be adjusted if you wish to have a smooth changeover.
With the default setting of 3 accepted update cycles without IO data, the IO-Device always goes
into fault for an MRP changeover and the outputs are briefly de-energized. With an increased
number of update cycles, the IO-Device does not “notice” the breakdown of the line and the
outputs continue to have power. Of course, during the changeover time, the IO-Controller cannot
control the IO-Device.
Note
If the watchdog time is changed, you always have to check whether a critical IO-Device state can
occur in the selected time frame! If this is the case, a shorter time must be selected!
SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Ring Redundancy MRP
Watchdog Time
Ansprechüber-
wachungszeit
Watchdog time
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-12 Training Document, V15.01.00
9.10. Task Description:
Introducing a Loop and then Activating MRP

Task Description
In order to become more familiar with the MRP and rings in networks, you are first of all to
introduce a ring to your system and then modify the introduced ring into an MRP ring in orderto
achieve the required ring redundancy.
Finally, you are to program a running light on the ET 200SP so that the re-configuration times of
the MRP ring can be visualized.
SITRAIN
IK-TIAPN / Ring Redundancy MRP Page 14 Siemens AG © 2016
Task Description:
Introducing a Loop and then Activating MRP
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-13
9.10.1. Exercise 1: Introducing a Loop

Task
With the help of the SCALANCE XC208, you are to introduce a ring which includes the following
devices:
• S7-1513
• ET 200SP
• TouchPanel
• SCALANCE XC208 Switch
What to Do
1. Take two suitably long PROFINET cables.
2. Connect the Port “P1” of your S7-1500 training case to the Port “P5” of the SCALANCE
switch.
3. Then connect the Port “P2” of your S7-1500 training case to the Port “P3” of the SCALANCE
switch.
4. Monitor how the system goes into fault.
Note
The system must go into fault in any case. If this is not the case, check all PROFINET
connections of the above-mentioned devices. These must all be connected to one another!

SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
Ring Redundancy MRP
Exercise 1: Introducing a Loop
Es entsteht ein
Loop!
A loop is
introduced!
neue LeitungNew line
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-14 Training Document, V15.01.00
9.10.2. Exercise 2: Activating MRP with the S7-1513 as MRP Manager

Task
In your project, you are to activate the MRP functionality for all devices that are part of the ring.
For this, the S7-1500 is to take on the role of “Manager”. All other devices of the ring are given
the role of “Client”.
What to Do
1. Switch to the Topology view.
2. Update the offline topology of your project. For this, use either the Offline/Online comparison
function or enter the connections manually.
3. Switch to the Network view in your project.
4. Define the roles of the devices either individually via the various PROFINET interfaces of the
devices or collectively via the MRP Domain settings of the IO-Network.
5. Download the modified configuration to all necessary devices.
6. Test the MRP functionality.
Note
Before you can once again access the controller, you must dissolve the loop!
The role of the TP700 Comfort cannot be set via the MRP Domain in the Network view. For this,
you must switch to the PROFINET interface Properties of the Panel.
SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
Ring Redundancy MRP
Exercise 2:
Activating MRP with the S7-1513 as MRP Manager
PLC is MRP
Manager
HMI muss separat
auf Client umgestellt
werden
HMI must separately be
changed over to Client
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-15
9.10.3. Exercise 3: Running Light for Visualizing the Re-configuration Times

Task
You are to use the “RunningLight_ET 200SP” block from the IK-TIAPN library in order to generate
a running light on the ET 200SP. This running light improves the visual presentation of the re-
configuration times of the MRP ring.
What to Do
1. Open the “IK-TIAPN” library, if it is closed.
2. Using drag & drop, copy the “Running Light” tag table into your project.
3. Then drag the “RunningLight_ET200SP” block from the “Chapter9” folder into your project.
4. Compile and download your project. Then save it.
5. Once again test the MRP functionality with the help of the running light. The running light is
switched on and switched off via the input “S_Runninglight_On” (%I 0.7).
The re-configuration times which the Manager requires should now be easier to recognize.
Note
The library is stored in the following path: “C:\Archives\TIA_Portal\IK-TIAPN”. There, it is either
archived (zipped) and must first still be retrieved (unzippped) or it is already retrieved and only
has to be opened.

SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Ring Redundancy MRP
Exercise 3: Running Light for Visualizing the
Re-configuration Times
Running light
from the library
Insert in the
project
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-16 Training Document, V15.01.00
9.10.4. Exercise 4: Adjusting the Watchdog Time

Task
You are to change the “Watchdog time” option of the PROFINET interface of all required IO-
Devices in such a way that a smooth changeover is ensured. That is, when a ring line is pulled
and inserted, the breakdown of the running light is no longer to be recognized.
What to Do
1. Switch to the Network view of your project.
2. Change the “Accepted update cycles without IO data” of all required IO-Devices in such a way
that these correspond to the task.
3. Compile and download your project. Then save it.
4. Test whether your changes ensure a smooth changeover.



SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Ring Redundancy MRP
Exercise 4: Adjusting the Watchdog Time
Adjust the update
cycles
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-17
9.11. Additional Information

Note
The following pages contain either additional information or are for reference to complete a topic.

SITRAIN
IK-TIAPN / Ringredundanz MRP Seite 19 Siemens AG © 2016
Wenn Sie noch mehr wissen wollen
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN - Ring Redundancy MRP
9-18 Training Document, V15.01.00
9.11.1. MRP Manager (Auto)

MRP Manager (Auto)
If it is not necessary to have a fixed redundancy manager in the MRP Ring, the function “Manager
(Auto)” can be used. If this role is assigned to several devices of the MRP Ring, then at runtime,
there is a negotiation amongst these devices as to which device takes on the role of redundancy
manager and which one(s) takes on the role of “Client”.
The advantage of this method is that when the negotiated redundancy manager fails during
running operation, one of the other MRP Ring devices that had been given the role of “Client”
during the negotiation can step into the position of the failed redundancy manager and can take
on the role of “Manager (Auto)”. When the failed redundancy manager is restored, the role of
“Manager (Auto)” is then once again negotiated between the devices concerned.
If only one device is assigned the role of “Manager (Auto)” in the MRP Ring, it naturally takes on
the role of redundancy manager.
Note
If a device of the MRP Ring is assigned the role of “Manager”, then no other device may be given
the role “Manager (Auto)” or “Manager”!
SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Ring Redundancy MRP
MRP Manager (Auto)
MRP Manager role is
negotiated at runtime
MRP Manager Rolle wird
zur Laufzeit ausgehandelt
Both devices are set to
Manager (Auto)
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Ring Redundancy MRP
Training Document, V15.01.00 9-19
9.11.2. MRP on the SCALANCE XC208

MRP on the SCALANCE XC208
The SCALANCE XC208 Switch offers the same functionality as an S7-1513. Furthermore, it also
offers a support for other ring redundancy procedures, such as, HRP.


Alternative Redundancy
Unlike the S7-1513, the SCALANCE XC208 can also be parameterized via alternative
mechanisms such as the Web Based Management, WBM, or via the Simple Network
Management Protocol, SNMP. This is also true for the Media Redundancy. This is either
parameterized via the PROFINET IO Settings via the S7 controller or via the WBM. If a
parameterization via the WBM is desired, the option must be activated in the Settings of the
SCALANCE XC208. Then all options are ‘greyed out’ and the parameterizations can bedone via
the Web Based Management.


SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Ring Redundancy MRP
MRP on the SCALANCE XC208
Client or Manager role
possible
Ring ports can be set
Redundanz alternativ
einstellbar (z.B. WBM oder
SNMP)
Redundancy can
alternatively be set (e.g.
WBM or SNMP)
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-1

Contents 10





10. Shared Device ....................................................................................................... 10-2
10.1. Traditional System Expansion ............................................................................................ 10-3
10.2. Alternative System Expansion ............................................................................................ 10-4
10.3. Module-by-Module Shared Device...................................................................................... 10-5
10.3.1. Parameterizing the Module-by-Module Shared Device ...................................................... 10-6
10.4. Submodule-by-Submodule Shared Device ......................................................................... 10-8
10.4.1. Configuring the Submodule-by-Submodule Shared Device ............................................. 10-10
10.5. MSI – Module-internal Shared Input MSO – Module-internal Shared Output ................. 10-11
10.5.1. MSI – Module-internal Shared Input ................................................................................. 10-12
10.5.2. MSO – Module-internal Shared Output ............................................................................ 10-13
10.6. Task Description: ET 200SP as Shared Device ............................................................... 10-14
10.6.1. Exercise 1: Copying the S7-1510SP into a New Project .................................................. 10-15
10.6.2. Exercise 2: Copying the ET 200SP into a New Project .................................................... 10-16
10.6.3. Exercise 3: Parameterizing the ET 200SP as Module-by-Module Shared Device ........... 10-17
10.6.4. Exercise 4: Controlling the Conveyor Model via the S7-1510SP ..................................... 10-18
10.7. Additional Information ....................................................................................................... 10-19
10.7.1. Shared Device in the Same Project .................................................................................. 10-20
10.7.2. Requirements for Using Shared Device in the Same Project ........................................... 10-21


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-2 Training Document, V15.01.00
10. Shared Device


SITRAIN
IK-TIAPN / Shared Device Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... know the difference between a traditional system expansion and an
alternative system expansion
... know the term Shared Device, understand it and be able
to explain it
... be familiar with the different possibilities to configure and
parameterize a Shared Device
... be able to commission a Shared Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-3
10.1. Traditional System Expansion

Traditional System Expansion
In larger or widely distributed systems, numerous IO-Controllers as well as IO-Devices are
frequently used. Often it happens that in time the system or even system parts must be
expanded. For this, further IO-Devices are then used which are connected to new IO-Controllers.
Even for expansions which are located very close together, such as, the installation of new
sensors or actuators for a new IO-Controller, a new IO-Device must be installed in spite of an
existing IO-Device.
The reason for this is that an IO-Device in the traditional sense can always only be assigned to
one IO-Controller. Therefore, the new sensor and actuator data must be coupled to a new IO-
Device which, for its part, is assigned to a new IO-Controller.


SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
Shared Device
Traditional System Expansion
Control of the
robot
System is
expanded
System is
expanded
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-4 Training Document, V15.01.00
10.2. Alternative System Expansion

Alternative System Expansion with Shared Device
For a system expansion which is located very close together, investment costs and time can be
saved with the help of the functionality “Shared Device”.
The “Shared Device” function makes it possible to distribute the modules as well as the
submodules of an IO-Device between several IO-Controllers. The IO-Device is indirectly assigned
to several IO-Controllers. Due to this functional principle, no new IO-Device must be installed for
the system expansion but rather an expansion of the existing IO-Devices with further I/O modules
is sufficient. The new data of the system is then assigned to a new IO-Controller.
Note
The “Shared Device” function also permits the mixing of F- as well as ‘normal’ modules in one
and the same IO-Device. This IO-Device can then be accessed not only from an F-controller but
also from a ‘normal’ controller.

SITRAIN © Siemens AG 2018
Page 4
IK-TIAPN
Shared Device
Alternative System Expansion
ET 200SP is
Shared Device
ET 200SP HF up to
4 Controllers
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-5
10.3. Module-by-Module Shared Device

Module-by-Module Shared Device
The simplest and most widespread form of a Shared Device is the module-by-module Shared
Device. To subdivide an IO-Device module-by-module means that the various IO-Controllers to
which the IO-Device is to be assigned, in each case, have access to one complete module of this
Device. It doesn’t matter what type of module this is as long as this module supports the “Shared
Device” function.
Conditions
So that the “Shared Device” function can be used, some additional points must be taken into
account:
• The software with which the controller is programmed must support this function (Step7 as of
V12 SP1).
• The controller must support this function (S7-1500 as of V1.1 as IO-Controller).
• The IO-Device must support this function (see device manual).
• The IO-Controller(s) which is/are to use the Shared IO-Device must be created in different
TIA Portal projects.
• The Shared Device must be configured exactly the same in each of these projects. The
exception to this is the configuration of the I/O modules.
• The send clock (transmission frequency) of all IO-Controllers which have access to the
Shared Device must be the same.
Note
All advanced functionalities such as “Submodule-by-submodule Shared Device” or module-
internal Shared Input as well as module-internal Shared Output are based on the principle of the
“Shared Device”. That is, these functionalities always require that the IO-Controllers are located
in different projects and that the IO-Device is identically configured as well as parameterized in
the projects (exception: I/O-Module assignment).

SITRAIN © Siemens AG 2018
Page 6
IK-TIAPN
Shared Device
Module-by-Module Shared Device
The IO-Device must support the Shared Device function! Two projects are required!
Up to 4 controllers
share the I/Os of the ET
200SP
In this case, sharing
is done module-by-
module
Copy & PasteThe same
IO-Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-6 Training Document, V15.01.00
10.3.1. Parameterizing the Module-by-Module Shared Device

ParameterizationSo that the “Shared Device” function can be used, it is most important that the IO-Devices, which
are used, support this functionality! If the IO-Device does, the entry “Shared Device” can be found
under “Advanced options” under the PROFINET interface of the Device (see picture). Depending
on the Interface module, up to 4 IO-Controllers are supported here.
After you have parameterized how many IO-Controllers are to have access to the modules of the
IO-Device, this must also be defined for the individual modules themselves. In the Device
overview of the module, there is a column with the title “Access” (see picture). If the access to this
module is not to be done by the local IO-Controller, but by one of the others, the correct setting
must be chosen here. After all modules which are to be accessed by the local IO-Controller have
been given the name of the local IO-Controller, the hardware configuration can be loaded into the
local IO-Controller.
Then, the projects with the other IO-Controllers are opened. The additional IO-Controllers that
want to access the IO-Device as Shared Device must be located in a separate project! After that,
the IO-Device is transferred from the original project into the other projects using Copy & Paste.
Finally, the assignment of the I/O modules to the local IO-Controllers takes place.
Note
An I/O-Module may only be assigned to one IO-Controller!
You have to perform this consistency check yourself. TIA Portal cannot check whether an I/O-
Module has been assigned to several IO-Controllers!

SITRAIN © Siemens AG 2018
Page 7
IK-TIAPN
Shared Device
Parameterizing the
Module-by-Module Shared Device
Selection
IO-Controller
Property Interface
module
Controller in
another project
Name of local
IO-Controller
IO-Controller of
another project
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-7
Alternative Parameterization Methods
The assignment of different IO-Controllers to the individual modules of the IO-Device can also be
done in the Network view in TIA Portal. For this, the IO-Device must be highlighted and after that,
the menu item “Shared Device” can be found in the "General" Properties under the entry “Module
parameters”. The assignment can then be set here!


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-8 Training Document, V15.01.00
10.4. Submodule-by-Submodule Shared Device

Submodule-by-Submodule Shared Device
The functionality of the submodule-by-submodule Shared Device is the further development of
the module-by-module Shared Device. Here, you can not only set whether you would like to
assign individual modules to different IO-Controllers, but you can also decide submodule-by-
submodule which parts of the module are to be assigned to which IO-Controller!
Into how many parts a module can be subdivided depends on the number of I/Os of the module:
• One digital module with 16 inputs / outputs can be subdivided into 2 submodules.

• One digital module with 32 inputs / outputs can be subdivided into 4 submodules.

• One analog module with 8 inputs / outputs can be subdivided into 8 submodules.



SITRAIN © Siemens AG 2018
Page 8
IK-TIAPN
Shared Device
Submodule-by-Submodule Shared Device
Up to 4 controllers
share the I/Os of the
ET 200MP
Sharing is done
submodule-by-
submodule
The IO-Device and the modules must support submodule-by-submodule Shared Device!
Two projects are required!
Copy & PasteThe same
IO-Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-9
• One analog module with 4 inputs / outputs can be subdivided into 4 submodules.

• One analog module with 2 inputs / outputs can be subdivided into 2 submodules.

• One analog module with 4 inputs and 2 outputs can be subdivided into 4 submodules with 1
analog input each and into 2 submodules with 1 analog output each.


That is, digital modules can only be subdivided into submodules with 8 inputs/outputs while
analog modules can only be subdivided into submodules with 1 input/output. A larger, that is,
other division of the submodules is currently not possible!
Note
A module which supports the functionality “module-by-module Shared Device” does not
necessarily have to support the functionality “submodule-by-submodule Shared Device”.

 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-10 Training Document, V15.01.00
10.4.1. Configuring the Submodule-by-Submodule Shared Device

Configuration
After defining the number of IO-Controllers assigned to the Shared Device, the submodules can
be distributed.
In the "Properties" of the I/O-Modules, under "Module parameters", you will find the section for
configuring the inputs or the outputs, in which the possibility then exists to carry out the
“Configuration of submodules”. Depending on the type, a different subdivision into the individual
submodules occurs.
Assignment of the I/O Addresses
The addresses of the individual submodules are assigned according to the same principle which
is also used for the I/O-Modules. The address area is filled starting from the smallest address
upwards without leaving any possible gaps. As can be seen in the picture, this can mean that a
DI 32 module which had the address area from 14..17 before the module distribution, all of a
sudden occupies the addresses 4,14,15 as well as 16 after the subdivision to submodules.
Note
Currently, a module can either be subdivided into the predefined distribution or it is not
subdivided. It is, for example, not possible to subdivide a digital input module with 32 inputs into 2
submodules à 16 inputs. It can either be subdivided into 4 submodules à 8 inputs or not be
subdivided at all!


SITRAIN © Siemens AG 2018
Page 9
IK-TIAPN
Shared Device
Configuring the
Submodule-by-Submodule Shared Device
Splitting the I/O
addresses
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-11
10.5. MSI – Module-internal Shared Input
MSO – Module-internal Shared Output

MSI - MSO
If it is not sufficient that the inputs/outputs of a module are distributed amongst various IO-
Controllers, but all I/Os of a module are required on all Controllers, the functionality “module-
internal Shared Input” as well as “module-internal Shared Output” can be used.
This function permits several IO-Controllers to access the same inputs or outputs.
With this technique, up to 4 IO-Controllers can read-access the data of an input module or an
output module.
Note
The functionality “MSI” as well as “MSO” cannot be used in conjunction with the function
“submodule-by-submodule Shared Device”. If one of these two functions is used in the module,
the respective other function is automatically deactivated and cannot be used!
SITRAIN © Siemens AG 2018
Page 10
IK-TIAPN
Shared Device
MSI – Module-internal Shared Input
MSO – Module-internal Shared Output
The IO-Device and the modules must support MSI or MSO!
Two projects are required!
In MSO,
only 1 Controller can
write outputs
Up to 4 Controllers
can read back
outputs
Up to 4 Controllers
can read inputs
Copy & PasteThe same
IO-Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-12 Training Document, V15.01.00
10.5.1. MSI – Module-internal Shared Input

MSI – Module-internal Shared Input
The functionality “module-internal Shared Input” (MSI) enables an input module to provide its
input data to up to four IO-Controllers. Each Controller can read-access the same channels.
Configuration
When the module supportsthe “MSI” function, a section “Copy of module for Shared Device
(MSI)” can be found in the ‘Module parameters’ in the ‘Properties’ of the module. Here you can
define for how many IO-Controllers the input is to be duplicated. Then, which copy is to be
accessed locally and which copies are available for the other IO-Controllers in other projects is
also defined via the column “Access”.
Note
If the “MSI” function is activated in the module, the functionality “Value status (Quality
Information)” is also automatically activated. This supplies a Quality Byte along with every byte
which specifies the state of this byte.
Due to this automatic setting, the address space which is required for this module, is however,
also doubled! (example picture: 4Byte → 8Byte)



SITRAIN © Siemens AG 2018
Page 11
IK-TIAPN
Shared Device
MSI – Module-internal Shared Input
Value status
expands I/Os
I-Addresses are added
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-13
10.5.2. MSO – Module-internal Shared Output

MSO – Module-internal Shared Output
The function “module-internal Shared Output” (MSO) enables an output module to provide its
output data to up to four IO-Controllers. With this function you must make sure, however, that still
only 1 IO-Controller has the write permission, that is, the write-access rights for this output
module. All other IO-Controllers are only granted a read-only access to this data.
Configuration
Just as for the function “MSI”, the module must support the functionality “MSO”. If this is the case,
then a section “Copy of module for shared device (MSO)” can be found in the ‘Module
parameters’ in the ‘Properties’ of the module. Here you can define for how many IO-Controllers
the output is to be duplicated. However as mentioned, only a copy of the module output state as
input address occurs here! For the IO-Controller which has the write-access to the output data,
the system additionally stores a copy of the output data in the input data. Finally, which copy is to
be accessed locally and which copies are available for the other IO-Controllers in other projects is
also defined via the column “Access”.
Note
If the “MSO” function is activated in the module, the functionality “Value status (Quality
Information)” is also automatically activated. This supplies a Quality Byte along with every byte
which specifies the state of this byte.
Due to this automatic setting, the address space which is required for this module, is however,
also doubled! (example picture: 4Byte → 8Byte)
SITRAIN © Siemens AG 2018
Page 12
IK-TIAPN
Shared Device
MSO – Module-internal Shared Output
Value status
expands I/Os
I-Addresses are added
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-14 Training Document, V15.01.00
10.6. Task Description: ET 200SP as Shared Device

Task Description
The ET 200SP is now to be used as a Shared Device between the S7-1513 and the S7-1510SP.
The digital output card of the ET 200SP is to be assigned to the S7-1510SP and the remaining
modules, including the header module, are to be assigned as IO-Controllers to the S7-1513.
For this functionality, you must generate a new TIA Portal project in which one after the other the
S7-1510SP and then the ET 200SP are copied. Then, in both projects, you are to parameterize
the ET 200SP as Shared Device and assign the input and output cards to the correct IO-
Controller.
Finally, the control of the conveyor model via the S7-1510SP is to be made with a simple jog
operation.


SITRAIN © Siemens AG 2018
Page 13
IK-TIAPN
Shared Device
Task Description: Integrating the S7-1510 and
Defining the ET 200SP as Shared Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-15
10.6.1. Exercise 1: Copying the S7-1510SP into a New Project

Task
You are to create a new TIA Portal project “IK-TIAPN_en_Shared_Device” and copy the
S7-1510SP into this project.
What to Do
1. Open a new TIA Portal Instance.
2. Create a new project. Name it IK-TIAPN_en_Shared_Device.
3. Using drag & drop, copy the S7-1510SP into it.
4. Save your new project.


SITRAIN © Siemens AG 2018
Page 14
IK-TIAPN
Shared Device
Exercise 1:
Copying the S7-1510SP into a New Project
Create new project
Copy & Paste
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-16 Training Document, V15.01.00
10.6.2. Exercise 2: Copying the ET 200SP into a New Project

Task
You are to copy the ET 200SP into your new project.
What to Do
1. Copy the ET 200SP into your new project.
2. Create a folder called "Shared" in the project "IK-TIAPN_en_Shared_Device". After that, drag
the S7-1510 and the copied ET 200SP into this folder.
3. Save it.



SITRAIN © Siemens AG 2018
Page 15
IK-TIAPN
Shared Device
Exercise 2 :
Copying the ET 200SP into a New Project
Copy & Paste
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-17
10.6.3. Exercise 3: Parameterizing the ET 200SP as Module-by-Module Shared
Device

Task
You are to parameterize the ET 200SP in both projects in such a way that it takes on the function
of a module-by-module Shared Device. The "DQ 16x24VDC/0.5A ST_1" module is to be
assigned to the S7-1510SP.
What to Do
1. Open the Device view of the ET 200SP in your original project.
2. Parameterize the ET 200SP as Shared Device (the parameterization in the picture
corresponds to the ET 200SP parameterization which is connected to the S7-1513).
3. Open the Device view of the ET 200SP in the “IK-TIAPN_en_Shared_Device” project.
4. Complete the parameterization of the ET 200SP as Shared Device.
5. Compile your projects and save them.
6. Download your projects into the two controllers and check whether all devices function without
error.
Note
Don’t forget your MRP parameterization in the new “IK-TIAPN_en_Shared_Device” project!
SITRAIN © Siemens AG 2018
Page 16
IK-TIAPN
Shared Device
Exercise 3: Parameterizing the ET 200SP
as Module-by-Module Shared Device
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-18 Training Document, V15.01.00
10.6.4. Exercise 4: Controlling the Conveyor Model via the S7-1510SP

Task
You are to program the control of the conveyor model with the help of the S7-1510SP. A simple
jog operation is to be possible. The input “S_ConveyorLeft_Man” (%I 0.0) is to control the output
“K_Left” (%Q4.6) and the input “S_ConveyorRight_Man” (%I 0.1) the output “K_Right” (%Q4.5).
The jog operation is to be programmed in the OB “Main” of the S7-1510SP. The tag tables for the
tags of the conveyor model and the S7-1510 case can be copied from the library. The new input
tags “S_ConveyorLeft_Man” and “S_ConveyorRight_Man” are located in the tag table
“1510CaseVariables”.
What to Do
1. Copy the tag tables from the library.
2. In OB1, program the required functionality as per the task.
3. Compile and download your project.
4. Test whether the program fulfills the task.
5. Save your project.



SITRAIN © Siemens AG 2018
Page 17
IK-TIAPN
Shared Device
Exercise 4:
Controlling the Conveyor Model via the S7-1510SP
Programming Jog left/right
in the OB Main
Jog left
S_ConveyorLeft_Man
Jog right
S_ConveyorRight_Man
neue Variablentabellen per
Drag & Drop anlegen
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-19
10.7. Additional Information

Note
The following pages contain either additional information or are for reference to completea topic.

SITRAIN
IK-TIAPN / Ringredundanz MRP Seite 19 Siemens AG © 2016
Wenn Sie noch mehr wissen wollen
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – Shared Device
10-20 Training Document, V15.01.00
10.7.1. Shared Device in the Same Project

Using a Shared Device in the Same Project
For easier management of the Shared Device functionality, it is also possible to use this function
in a project in TIA Portal.
This can make the maintenance and service of the IO-Device easier. It should, however, be
transparent, that the two IO-Devices are one and the same IO-Device, that is, that the IO-Device
uses the functionality Shared Device!

Note
Here as well, it is required that the Shared Device Copy must match the original IO-Device
exactly!
Furthermore, the Shared Device and the Shared Device Copy cannot be operated in the same
subnet. TIA Portal would detect a double IP address here and would output an error message!



SITRAIN © Siemens AG 2018
Page 19
IK-TIAPN
Shared Device
Shared Device in the Same Project
The same IO-Device
Copy & Paste
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – Shared Device
Training Document, V15.01.00 10-21
10.7.2. Requirements for Using Shared Device in the Same Project

Requirements
The functionality “Generate PROFINET device name automatically” is a convenience function in
TIA Portal. This derives the PROFINET device name automatically from the Device-Name. In that
way, the assignment of an online IO-Device to an offline IO-Device in a project is considerably
simplified.
So that you can now use the functionality ‘Shared Device’ in the same project, the option
“Generate PROFINET device name automatically” must be deactivated for the Shared Device.
Only by deactivating this function is it possible for the copy of the IO-Device, which is to be used
as a Shared Device, to be assigned the same device name offline.
In TIA-Portal, you can have two identical PROFINET device names but not two identical Device-
Names!

Note
The manually set name of the copied IO-Device must match the name of the IO-Device, which
served as the template, exactly.
Changes to the name of the original IO-Device later on must be added manually!



SITRAIN © Siemens AG 2018
Page 20
IK-TIAPN
Shared Device
Requirements for Using Shared Device in the Same
Project
Two identical Device names
not possible
Deactivate option before
copying
The name of the copied IO-
Device
is adopted
Must have the same IP
address → different
networks
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – I-Device
Training Document, V15.01.00 11-1

Contents 11





11. I-Device – Intelligent IO-Device ........................................................................... 11-2
11.1. Data Exchange between Two IO-Controllers ..................................................................... 11-3
11.2. I-Device ............................................................................................................................... 11-4
11.2.1. I-Device without Subordinate PROFINET IO-System......................................................... 11-5
11.2.2. I-Device with Subordinate PROFINET IO-System .............................................................. 11-6
11.2.3. I-Device as Shared Device ................................................................................................. 11-7
11.3. Communication via Transfer Areas..................................................................................... 11-8
11.4. Parameterizing the I-Device ................................................................................................ 11-9
11.5. Parameterizing the Transfer Area ..................................................................................... 11-10
11.6. Cross-Project I-Device ...................................................................................................... 11-11
11.6.1. Importing the I-Device in a New Project ........................................................................... 11-12
11.7. Task Description: S7-1510SP as I-Device ........................................................................ 11-13
11.7.1. Exercise 1: Parameterizing the S7-1510SP as I-Device .................................................. 11-14
11.7.2. Exercise 2: Integrating the I-Device in the S7-1513 Project ............................................. 11-15
11.7.3. Exercise 3: Controlling the Conveyor Model with the Help of the S7-1513 as well as
the S7-1510SP .................................................................................................................. 11-16


 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – I-Device
11-2 Training Document, V15.01.00
11. I-Device – Intelligent IO-Device


SITRAIN
IK-TIAPN / I-Device Page 2 Siemens AG © 2016
Objectives
At the end of the chapter the participant will ...
... understand the IO-Controller communication with PROFINET
... be familiar with the possible applications of an I-Device
... be able to configure and parameterize an IO-Controller as I-Device
... be able to commission an I-Device
Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
IK-TIAPN – I-Device
Training Document, V15.01.00 11-3
11.1. Data Exchange between Two IO-Controllers

Data Exchange between Two IO-Controllers
If data is to be exchanged between two controllers, the first possible solution that comes to mind
is the CPU-CPU communication using the communication instructions in TIA Portal. These
include, for example, the popular S7 Communication and the Open User Communication (in
short: OUC). It is also possible to use the MODBUS on TCP Communication for the CPU-CPU
communication. Familiar instructions of these communication methods are:
• GET / PUT
• BSEND / BRCV
• TSEND / TRCV
However, in addition to these more familiar communication methods, data exchange between two
controllers can also be accomplished by using a data exchange functionality offered in
PROFINET: the option "I-Device" (Intelligent IO-Device).
Note
Not every controller / IO-Controller supports the functionality I-Device!

SITRAIN © Siemens AG 2018
Page 3
IK-TIAPN
I-Device
Data Exchange between Two IO-Controllers
How can data
exchange be
accomplished?
Data exchange
I/O data of ET is
to be transferred to
HMI
 Industrial Communication, PROFINET with Industrial Ethernet in the TIA Portal
 IK-TIAPN – I-Device
11-4 Training Document, V15.01.00
11.2. I-Device

Device (Intelligent IO-Device)
In a controller, the functionality "I-Device" makes it possible to exchange data between different
IO-Controllers. That way, the controller can, for example, be used as an intelligent pre-processing
unit for partial tasks. In this case, the controller / the IO-Controller with activated I-Device
functionality is connected to a "higher-level" IO-Controller as an IO-Device.
Data exchange using the I-Device functionality has the following advantages:
• Easy interfacing of IO-Controllers
• Real-time communication between IO-Controllers (Real-Time as well as Isochronous Real-
Time)
• Less processing load on the IO-Controller due to distribution of processing power amongst I-
Devices
• Lower communication load due to processing of process data on-site
• Clarity, since partial tasks are processed in separate STEP-7 projects
Ways to Integrate an I-Device
The integration of an I-Device in the PROFINET IO-System can be done in the following ways:
• I-Device without subordinate PROFINET IO-System
• I-Device with subordinate PROFINET IO-System
• I-Device as Shared Device
Note
On the Service & Support pages, under the Entry-ID: 109478798 you will find further
