 08 Feedback: Your suggestions
 10 Q&A: Things you wanted to know
Regulars
Contents
 95 Arduino-based two-wheel self-balancing Segway
 100 Multifunction rechargeable digital clock
 109 AC lamp blinker using timer 555
 112 Add-on USB power circuit for UPS
 113 Simple multi-sensor fire alarm
115 Door-ajar alert with countdown timer
116 Understanding spectrogram of speech
 signals using MATLAB program
Do-It-Yourself
58 IMAGING: Image processing using MATLAB:
Image deblurring and Hough Transform
(Part 4 of 4)
INDUSTRY
79 MARKET SURVEY: Can India become an
electronics design hub?
90 PROJECT REPORT: Solar rooftop PV plant
installation
IEW SUPPLEMENT
139 IEW Supplement 2018
Next
Issue
• Techn
ologies
 for tak
ing
Interne
t to rem
ote are
as
• Autom
ation
• Role o
f senso
rs in th
e
Interne
t of Thi
ngs (IoT
)
NEWS
12 Tech News
83 Industry News
86 New Products
Green Technology
68 Wind power: The global impact
SMART WORLD
Please send payments only in favour of EFY Enterprises Pvt Ltd
January 2018
Vol. 06 | no. 09
ISSn-2454-4426
Editor : ramesh Chopra
Editorial : Editorial Secretary
CorrESPondEnCE Phone: 011-26810601; E-mail: editsec@efy.in
 (technical queries: efylab@efy.in)
SubSCriPtionS & : Phone: 011-26810601 or 02 or 03
miSSing iSSuES E-mail: support@efy.in
baCk iSSuES, : kits‘n’Spares, new delhi
bookS, Cds, Phone: 011-26371661, 26371662
PCbs etc. E-mail: info@kitsnspares.com
nEwSStand : Ph: 011-40596600
diStribution E-mail: efycirc@efy.in
advErtiSEmEntS
nEw dElhi : Ph: 011-26810601 or 02 or 03
(hEad offiCE) E-mail: efyenq@efy.in
mumbai : Ph: 022-24950047, 24928520
 E-mail: efymum@efy.in
bEngaluru : Ph: 080-25260394, 25260023
 E-mail: efyblr@efy.in
PunE : Ph: 08800295610, 09870682995
 E-mail: efypune@efy.in
gujarat: : Ph: 079-61344948
 E-mail: efyahd@efy.in
jaPan : tandem inc., Ph: 81-3-3541-4166
 E-mail: japan@efy.in
SingaPorE : Publicitas Singapore Pte ltd
 Ph: +65-6836 2272
 E-mail: singapore@efy.in
taiwan : j.k. media, Ph: 886-2-87726780 ext. 10
 E-mail: taiwan@efy.in
unitEd StatES : E & tech media
 Ph: +1 860 536 6677
 E-mail: usa@efy.in
Printed, published and owned by ramesh Chopra. Printed at international
Print-o-Pack ltd, C-4 to C-11, hosiery Complex, Phase-ii Extension, noida-201305,
gautam budh nagar, uttar Pradesh, on the first day of each month and published
from d-87/1, okhla industrial area, Phase-1, new delhi 110020. Copyright 2018.
all rights reserved throughout the world. reproduction of any material from
this magazine in any manner without the written permission of the publisher is
prohibited. although every effort is made to ensure accuracy, no responsibility
whatsoever is taken for any loss due to publishing errors. articles that cannot
be used are returned to the authors if accompanied by a self-addressed and
sufficiently stamped envelope. but no responsibility is taken for any loss or delay in
returning the material. EfY will not be responsible for any wrong claims made by
an advertiser. disputes, if any, will be settled in a new delhi court only.
Period Newstand Price You Pay Digital Overseas
Year (`) (`) (`) Digital Print
three 3600 2520 910 — —
two 2400 1800 648 uS$ 15 —
one 1200 960 345 uS$ 5 uS$ 120
SUBSCRIPTION RATES
EFY+DVD: Tools for coders and fun stuff for gamers ..... 82
LASI 7: For designing versatile integrated circuits .............I
Simulating your Intel processor with GNUSim8085 .........IV
OSMC: A friendly media centre for your Raspberry Pi ........VII
eFy Plus DVD
incluDes 28-paGe
special supplement:
8 January 2018 | ElEctronics For you www.EFymag.com
Your suggestions
Feedback
Electronics Projects
From electronicsforu.com
I am interested in ‘1kW Sinewave Inverter’
DIY article published on your website
https://electronicsforu.com/electronics-
projects/1kw-sine-wave-inverter-circuit.
Can I use the same circuit for 12V but with a
different Ah-rated battery?
Amit
The author Dr R.V. Dhekale replies: Yes,
you can use 12V, 24V or 48V batteries to
get a higher power output. You have to be
careful while providing 12V taping for the
circuit. Also, you have to change the inverter
transformer specifications accordingly.
In the above inverter circuit, how can I
change the output frequency of the inverter
to 240V, 60Hz (instead of 50Hz) for use in
Québec, Canada?
Sylvain B.
The author Dr R.V. Dhekale replies: The
frequency can be changed from 50Hz to
60Hz by using the preset provided.
The ‘Arduino Based GSM Home Security
System’ published on your website
https://electronicsforu.com/electronics-
projects/arduino-gsm-home-security-system
is a nice and easy-to-design DIY project.
Where can I find its source code?
Also, I could not convert the PCB in PDF to
Gerber file. Please help.
John Lagos
The author Joy Mukherji replies: The source
code is available on EFY website: http://
efymag.com/admin/issuepdf/Arduino%20
based%20GSM%20home%20security%20
system.rar. This link is also provided at the
end of the article. You can construct the
circuit on a general-purpose PCB.
good wiSheS from
A reguLAr reAder
Thank you very much for remembering
me even after my subscription expired! I
am an amateur electronics hobbyist with
interest in electronics since I was 16 years
old. Now I am 62. Throughout these years,
I have been a reader of EFY. Sometimes
I read EFY in libraries, sometimes I pur-
chase it from magazine stalls or subscribe
to it. I used to assemble DIY projects.
Nowadays DIY projects are based on high-
end technology. I have all the good wishes
for my alma mater in electronics.
Purnachandra Rath
Through e-mail
digitAL trAnSmitterS pLeASe
I am a subscriber to EFY and work for
Prasar Bharati. In our country where ana-
logue radio and terrestrial TV transmissions
still exist, a suitable option is required to
convert the same to digital. I request EFY to
publish a series of articles on viable options
and encourage manufacturers to convince
the government to introduce digital trans-
mission systems. I am sure your contribu-
tion will work as a catalyst.
R.S. Evani
Through e-mail
Audio AmpLifier
This is regarding ‘30W Audio Power
Amplifier using NE5534 and Darlington
Transistors’ DIY project published in
November 2017 issue. NE5534 IC avail-
able in the local market is made in China,
which may blow up any time. Similarly,
almost all ICs used in audio amplifier
circuits published by EFY, which are
available in the local market, are made
in China. These ICs are incapable of sus-
taining 35-40V or higher voltages. What
should be the maximum safe operating
voltages for these circuits?
Also, where can I get original ICs like
TDA2030 and LM1875 used in the circuits
publishedby EFY?
Anirvan Kule
Kolkata
The author Petre Petrov replies:
Many ICs are produced in Asia (China,
Taiwan, Malaysia, etc). Most of these
ICs correspond well to the information
published in datasheets.
Consequently, in all cases, you
should refer datasheets and application
notes published by the manufacturers. If
you find that a component or equipment
is not as per the published technical
parameters, you can contact its manu-
facturer and ask for compensations
according to the local law!
TDA2030, LM1875 and NE5534/A are
very popular and low-priced ICs, and these
behave well according to datasheets. I did
not find significant differences between
these ICs from different manufacturers.
fAn Speed reguLAtor
The ‘Fan Speed Regulator Using PIC16F73’
DIY project published in August 2017 issue
is quite useful. Regarding this project, I
have certain doubts:
1. What is the delay time between
transistors T1 and T2?
2. Is there power loss during this time?
3. Do we need to remove the start
capacitor?
4. Can the circuit be modified for:
(i) Fast over-current detection to cut
off T1 and T2 in case of cross conduction?
(ii) Use of IGBT for higher power?
Joey Dimaculangan
Through e-mail
The author Prof. K. Padmanabhan replies:
The time between the conduction of the
two transistors can be seen in the oscillo-
gram itself (shown in the article). At about
2ms, it is sufficient to prevent shorting.
When there is no current flow, there will
be no power loss. The starting capacitor of
the fan motor need not be removed.
As regards modification, fast over-
current detection will make the circuit
complicated. It is not required for a
simple fan drive. Higher-power applica-
tion is not possible without more complex
drive circuitry. To make the circuit simple,
optoisolator H11D1 is used.
4×4×4 Led CuBe
I want to assemble the ‘4x4x4-LED Cube
Using AT89c2051’ DIY project published
in October 2017 issue. I have seen similar
projects using shift registers, but this
one is much simpler. What changes are
required in the circuit to make it an 8x8x8
LED matrix?
Christo George
Through e-mail
The author Pamarthi Kanakaraja replies:
An 8x8x8 LED cube is somewhat com-
plex. A similar project using 512 LEDs is
available on the following web link:
http://www.instructables.com/id/
Led-Cube-8x8x8
10 January 2018 | ElEctronics For you www.EFymag.com
Q A&
Things You WanTed To KnoW!
Answers compiled by Sani Theo, technical editor. Letters
and questions for publication may be addressed to Editor,
Electronics For You, D-87/1, Okhla Industrial Area, Phase
1, New Delhi 110020 (e-mail: editsec@efy.in) and should
include name and address of the sender.
Ques. Why is battery
charging from the Usb
port of a pc or laptop
sloW?
suresh D.
ans. This is one of the common
questions asked by most mobile users.
Depending on the usage and battery
capacity of your mobile phone, you
need to charge its battery at least
once a day or sometimes more often.
Most mobile charger cables have USB
type-A connector on one end. You just
need a wall adaptor with USB port
or computer USB port to charge the
mobile battery. But there is a differ-
ence in charging speed between wall
adaptor and computer.
The charging speed depends on
various factors, including the power
rating of the charging source. The
power can be determined by multi-
plying the voltage and the current
supplied by the charger.
Normally, the USB port of your
PC gives 5V and up to 500mA (0.5A),
which means delivers about 2.5-watt
power. But if your PC has USB3.0 port,
normally rated at 900mA current,
you can get higher power. Some wall
chargers are rated at 5V and 1000mA
(1A), so their power output would be
5x1=5 watts. Some wall chargers have
even higher current rating. Thus battery
charging from the USB port of a PC or
laptop is comparatively slow.
Q2. hoW Do mobile phones
proDUce electromagnetic
raDiation?
Kone prasanna narayan
a2. Electromagnetic radiation refers
to the waves of electromagnetic field
radiating through space. This radiation
includes radio waves, microwaves, ultra-
violet, infrared, X-rays and gamma rays.
A mobile phone has both transmit-
ter and receiver sections. When the
mobile phone is turned on, it emits
radio waves that consist of radio fre-
quency (RF) energy—a form of electro-
magnetic radiation moving at the speed
of light. It works by transmitting radio
wave signals to (and receiving these
from) nearby base stations. (Base sta-
tion is an essential part because it links
the individual mobile phone with the
rest of the network.)
When talking on a mobile phone,
your voice is captured through its
microphone and a radio signal is gener-
ated from the mobile’s circuitry. The
radio signal is transmitted through its
antenna, which radiates through space.
This transmitted radio wave is picked up
by the antenna at the base station. Then
the mobile phone and base station start
communicating back and forth through
radio waves transmitted from their
respective antennae.
Every antenna, either on a mobile
phone or tower, radiates electromag-
netic waves. Radio waves are the strong-
est near the mobile phone antenna but
get weaker and weaker as you move
away from the phone. Similarly, radio
waves are the strongest at the base
station antenna.
The radiated power
level near a tower
is high but reduces
as you move away
from it.
Typ ica l ly, a
base station may
have several anten-
nae mounted on a
tower. The tower
or mast itself does
not radiate any
energy; it is radi-
ated from antennae
mounted on it.
The maximum
power near the
tower is shown in
the figure on this page. The tower
should be tall enough, as shown in the
figure, to avoid high power radiation to
nearby areas. The cellular or mobile net-
work in a city may have a large number
of base stations. The more the number
of antennae, the more is the radiation
power intensity in the nearby area.
a base station (Courtesy: http://www.steelintheair.com.au)
12 January 2018 | ElEctronics For you www.EFymag.com
World’s largest battery built in Australia
Technology UpdaTes
Tech News
Fully self-driving cars are here
renewable energy company Neoen, and the South Austral-
ian government was signed, the battery was linked to the
grid. The 100-megawatt/129MWh battery will store power
generated by a wind farm in South
Australia, releasing it during times
of increased demand. It is said to
be three times more powerful than
any current competitor.
The battery has the storage
capacity to support around 30,000
homes for over an hour. But, offi-
cials are hoping to further stabilise
the system and ease power load
during peak demand. The goal is
to improve upon the grid to avoid
such instances as the statewide
blackout that left 1.7 million people
without power in September 2016.
However, the battery may not
remain the largest in the world for
long. Currently, Hyundai Electric &
Energy Systems is building a bat-
tery in South Korea to be activated
in early 2018 that is 50 per cent
larger than Tesla’s.
Fully self-driving vehicles from
Waymo —the autonomous vehicle
division of Alphabet— are test-driving
on public roads in Arizona, without
anyone in the driver’s seat. Till date,
driverless vehicles have operated on
public roads with a test driver at the
wheel.
 “This is the most advanced vehi-
cle we have developed to date,” said
Waymo’s CEO, John Krafcik. “Every-
thing in it is designed and built for full
autonomy. A combination of powerful
sensors gives our vehicles a 360-degree
view of the world. The lasers can see
objects in three dimensions, up to 300
metres away. We also have short-range
lasers that stay focused close-up to the
side of the vehicle. Our radars can see
Tesla chief executive Elon Musk has delivered on his promise
of building the world’s biggest lithium-ion battery in 100 days.
Only 63 days after the contract betweenTesla, the French
Tesla has built the world’s biggest battery in Australia
Waymo’s fully self-driving vehicles are test-driving on public roads in Arizona, without anyone in the
driver’s seat
Tech News
14 January 2018 | ElEctronics For you www.EFymag.com
Las Vegas casino using microwaves
to keep guns out
The Westgate Las Vegas Resort and Casino is testing a discreet
weapon-sensing device called the Patscan cognitive micro-
wave radar. Marketed by Canadian security outfit PatriotOne,
the Patscan CMR combines short-range radar with machine
learning algorithms to scan individual guests for guns, knives
and bombs in real time—without forcing them to line up and
walk through metal detectors. And unlike the giant, whole-
body scanners you see in places like airports, Patscan units
are small enough to hide inside existing infrastructure like
walls and doorways.
Smart motorways that beam live
traffic news to cars
Fibre-optic cables running along Britain’s busiest motorways
will be able to beam live traffic updates into high-tech cars
under new proposals by Highways England. Messages will
be transmitted onto dashboards in a move to improve the
efficiency of how major routes operate while also improving
road safety. The connected vehicles will also be programmed to
spot potholes and transmit the information to road operators.
The development is the latest step in upgrading Britain’s
major roads into smart motorways. The way messages are
displayed is another step away from using traditional road
signs. Highways England hopes that improving Wi-Fi and 5G
connectivity across the UK motorways will help it to prepare
for driverless cars.
Fibre-optic cables are the latest step in upgrading Britain’s major roads into
smart motorways (Credit: Dave Thompson/PA)
PatriotOne’s Patscan cognitive microwave radar is small enough to hide
inside existing infrastructure like walls and doorways
Thumbs down: The average Internet user spends 135 minutes per day on
social media
Facebook admits that social media
is bad for us
With people spending more time on social media, many have
started wondering whether that is good for us. According to
Statista, on an average, people spent 135 minutes a day on
social media in 2017.
underneath and around vehicles, tracking moving objects usu-
ally hidden from the human eye.”
The company plans to bring its cars on the road as a ride-
hailing service, in which riders can hail one of the company’s
autonomous minivans via an app like Uber or Lyft. “People
will get to use our fleet of on-demand vehicles, to do anything
from commute to work, get home from a night out, or run
errands,” Krafcik said.
While other autonomous vehicle companies are still work-
ing with safety drivers, Waymo has abandoned their training
wheels in order to rise ahead of the competition.
A system like PatriotOne’s could be the ideal security
solution for a destination like Las Vegas, where resorts find
themselves struggling to ensure the safety of their guests, while
also stoking an ambiance of freedom.
Each radar unit in Patscan consists of a service box and two
antennae. The first antenna emits 1000 pulses of electromag-
netic radiation per second, at frequencies between 500MHz
and 5GHz. The second antenna monitors for electromagnetic
patterns inside that two-metre range. When you hit an object
with electromagnetic radiation, it resonates according to its
shape and material composition.
“We call it an object’s radar signature,” says electrical
engineer Natalia Nikolova, director of McMaster University’s
Electromagnetic Vision Research Laboratory. PatriotOne main-
tains a growing database of known radar signatures, which
Patscan’s onboard computer uses to distinguish weapons from
benign objects and notify security personnel.
Tech News
16 January 2018 | ElEctronics For you www.EFymag.com
Temperature-regulating coffee mug
Beautifully designed to be used in your home or at your desk,
the Ember ceramic mug keeps your beverages at the perfect
temperature from the first sip to the last drop for as long as
you want. For that, you need to choose the exact temperature
in Ember’s companion app, or pick from a preset.
Spending $80 on a mug could look ridiculous but it’s also
wonderful, for every beverage has an ideal temperature for
consumption. For coffee, science says it’s 136 degrees. (Ember
defaults to 135, which is pretty close to it.) Ember keeps your
coffee exactly right for hours.
E-mail tracking is in vogue
According to OMC, 19 per cent of all conversational emails are
now tracked. That’s one in five of the e-mails you get from your
friends. And you probably never noticed.
E-mail tracking service Streak notifies the sender as soon
as his message is opened. It can tell him where, when and on
what kind of device it was read. So with Streak enabled, you
can easily be caught fooling around with messages like “I read
your mail just now.”
The technology is pretty simple. Tracking clients embed
a line of code in the body of an e-mail—usually in a 1x1
pixel image (which is so tiny that it’s invisible), but also in
elements like hyperlinks and custom fonts. When a recipi-
ent opens the e-mail, the tracking client recognises that the
pixel has been downloaded, as well as where and on what
device. Newsletter services, marketers and advertisers have
used the technique for years, to collect data about their open
rates; major tech companies like Facebook and Twitter fol-
lowed suit in their ongoing quest to profile and predict users’
behaviour online.
But lately, a surprising—and growing—number of tracked
emails are being sent not from corporations, but acquaint-
ances.
In fact, a former Facebook executive, Chamath Palihap-
itiya has expressed his regret for being involved in building
the social media platform that he thinks is negatively affect-
ing society: “I think we have created tools that are ripping
apart the social fabric of how society works,” he told an
audience at the Stanford Graduate School of Business. He
joined Facebook in 2007 and became its vice president of
user growth.
“The short-term, dopamine-driven feedback loops we’ve
created are destroying how society works,” Palihapitiya
claimed. He cites issues of misinformation and mistruth that
have resulted through social media. For instance, Palihapitiya
discussed an incident in India where a hoax message about
kidnappings shared via WhatsApp led to the lynching of seven
innocent people.
“That’s what we’re dealing with. And imagine taking
that to the extreme, where bad actors can now manipulate
large swathes of people to do anything you want,” Palihap-
itiya explained. And, with the rising issue this year of fake
news and even manipulated videos, it’s only more difficult
to monitor and catch misinformation on social media.
Ember ceramic mug keeps your coffee exactly right for hours
E-mail tracking service Streak notifies the sender as soon as his message is
opened (Image credit: Getty Images)
Heating and cooling things is easy, but doing so uniformly
poses a challenge. Ember CEO Clay Alexander found the solu-
tion was to create a convection current, like a radiator or a
pot of water. So Ember uses cooling and heating elements up
the sides of the mug—it activates the highest submerged ele-
ment, and cools that spot until the cold liquid begins to fall.
That displaces hotter liquid, moving it up to the top, where
another element on the other side does the same thing. Alex-
ander says even in his early prototypes, he was able to keep the
temperature within one degree from top to bottom. With the
help of design firm Ammunition, Alexander turned his ideas
into a beautiful mug.
18 January 2018 | ElEctronics For you www.EFymag.com
futuristic
Skin plays an important role in mediat-ing our interactions with the world. Specifically, human skin can sense
pressure and temperature, stretch, and heal
itself. Electronic skin is a thin electronicmaterial that mimics human skin in one
or more ways. Recreating the properties of
skin using electronic devices could have
profound implications in various fields like
robotics, prosthetics and medicine. The
artificial skin could one day be used on
robotic hands capable of detecting diseases
or intoxication of humans via touch.
The pursuit of artificial skin has inspired
innovations in materials to imitate skin’s
unique characteristics, including mechani-
cal durability and stretch ability, biodegra-
dability, and the ability to measure a diver-
sity of complex sensations over large areas.
New materials and fabrication strategies
are being developed to make mechanically
compliant and multifunctional skin-like
electronics, and improve brain-machine
interfaces that enable transmission of skin’s
signals into the body.
Scientists and engineers have made
progress toward materials that can detect
pressure, blend with surroundings, meas-
ure body temperature, and do much more.
Here is a summary.
Self-healing electronic skin
Stanford University researchers have devel-
oped an electronic skin capable of healing
itself by combining a self-healing plastic
and nickel, a conductive metal. Unlike
self-healing polymers developed by other
researchers, this skin did not require a high
temperature or UV light to activate.
The individual plastic molecules of
the skin break apart relatively easily, but
the bonds also easily reform. Cut pieces
healed to 75 per cent strength within a few
seconds and fully in less than 30 minutes
when pressed together at room tempera-
ture. Additionally, the process could be
repeated many times—in experiments the
material showed near-perfect healing after
50 breaks. Other self-healing materials alter
their structures in the process and thus can
heal only once.
In addition to being self-healing, the
electronic skin was pressure-sensitive and
very flexible. It was the first material to
exhibit all these properties at the same time.
It was also the first conductive self-healing
polymer. The e-skin could detect both down-
ward pressure and pressure from bending;
thus, in principle, it could detect both the
pressure and angle of a normal human
handshake.
According to the research team, the
material could be useful in prosthetics and
creating self-healing wires for electronic
devices.
Lighting electronic skin
Researchers from the University of California
at Berkeley have created an electronic skin
that lights up when touched. Pressure trig-
gered a reaction in the skin that lit up blue,
green, red and yellow LEDs; as pressure
increased the lights got brighter.
The material was composed of synthetic
rubber and plastic, and was thinner than a
piece of paper. Sandwiched between layers,
organic LEDs were lit by semiconductor-
enriched carbon nanotubes and a conduc-
tive silver ink. The skin was made up of
hundreds of circuits, each of which con-
ElEctronic Skin:
Advancements And Opportunities
Dr S.S. Verma
is a professor
at Department
of Physics, Sant
Longowal Institute
of Engineering and
Technology, Sangrur,
Punjab
Ulsan National Institute’s
electronic skin that can
detect changes in both
temperature and pressure
The various types of
artificial electronic skins
being developed offer
amazing properties and
applications
20 January 2018 | ElEctronics For you www.EFymag.com
futuristic
tained a pressure sensor, a transistor
and a tiny LED. Pressure changed
the resistance of the sensor, thereby
changing the amount of electricity
flowing into the LED.
The team suggested that the
invention could be useful in skin for
prosthetic limbs and robotics. One of
the major problems with these kinds
of light films in the past, though,
was that these only lasted a matter
of hours when exposed to normal air.
Making any piece of ultra-
stretchy electronics often involves
sandwiching materials together to
produce something with the right
properties, whether it’s for a red
light or a method of sensing pres-
sure. In this case, the researchers
added a new protective coating,
called a passivation layer, to various
kinds of e-skin. The coating kept
out oxygen and water vapour well
enough to keep the light working for
several days. Researchers report that
this power LED film also produced
less heat and consumed less power
than previous efforts. The coating
they used can also work on e-skin
that does more than just light up.
Sweating electronic skin
A Northwestern University research
team has developed a first-of-its-kind
soft, flexible microfluidic device that
easily adheres to the skin and meas-
ures the wearer’s sweat to show how
his body is responding to exercise.
A little larger than a quarter
and about the same thickness, the
simple, low-cost device analyses key
biomarkers to help the user decide
quickly if any adjustments, such as
drinking more water or replenishing
electrolytes, need to be made or if
something is medically awry.
Designed for one-time use of
a few hours, the device, placed
directly on the skin of the forearm or
back, even detects the presence of a
biomarker for cystic fibrosis. In the
future, it may be more broadly used
for disease diagnosis.
Sensory electronic skin
Researchers at the Ulsan National
Institute of Science and Technology
have developed an electronic skin
that can detect changes in both tem-
perature and pressure. The skin’s com-
posites are made of a polymer as well
as reduced graphene oxide. Thanks to
that, the artificial skin can detect not
only sensory changes created by water
droplets falling at different pressures
and temperatures but also the tiniest
amount of pressure such as human
hair’s. This makes the skin perfect
for future caregiver robots. Or, when
attached to a human wrist, it can also
be used to monitor pulse pressure by
detecting the changes in skin tempera-
ture that occur when blood vessels
dilate or constrict.
Researchers have created a wear-
able device that is as thin as a tempo-
rary tattoo and can store and transmit
data about the wearer’s movements,
receive diagnostic information and
release drugs into skin. Similar
efforts to develop electronic skin
abound, but the device is the first
that can store information and also
deliver medicine—combining patient
treatment and monitoring. Its crea-
tors say that the technology could
one day aid patients with movement
disorders such as Parkinson’s disease
or epilepsy.
The researchers constructed
the device by layering a package of
stretchable nanomaterials—sensors
that detect temperature and motion,
resistive RAM for data storage,
micro-heaters and drugs—onto a
material that mimics the softness and
flexibility of the skin.
Sensing magnetic fields
There are actually several more
senses than humans’ basic senses
of touch, sight, hearing, taste and
smell. One that humans don’t inher-
ently have is magnetoception—the
ability to perceive magnetic fields.
Found in certain bacteria, migra-
tory birds, fish and invertebrates,
it provides them a better sense of
navigation and orientation.
Researchers at the Leibniz Insti-
tute for Solid State and Materials
Research in Germany describe a new
electronic skin that provides a sense
of magnetic fields. The electronic
skin contains an array of magnetore-
sistive sensor foils that sense both
static and dynamic magnetic fields.
The sensors are made from layers of
cobalt and copper, with polyethylene
terephthalate (PET) film. Informa-
tion about the sensor’s proximity
to a magnetic field is transmitted
wirelessly to an external device that
has LED indicators, giving a visual
representation of the distance.
The skin is only about two micro-
metres thick, which is about one-fifth
as wide as a single human hair. A
square metre of the material weighs
only three grams, which makes
it light enough to rest on a soap
bubble. It is also incredibly elastic,
as it is able to stretchover 270 per
cent in multiple directions over 1000
Electronic skin that lights up when touched
Northwestern University’s flexible device
measures the wearer’s sweat to analyse his key
biomarkers
Leibniz Institute’s skin provides a sense of
magnetic fields
22 January 2018 | ElEctronics For you www.EFymag.com
futuristic
times before wearing
out. Conversely, sensors
are still able to func-
tion properly if the skin
is crumpled up. This
makes them well-suited
for use on the skin.
Multitasking skin
Researchers in Korea
have developed their
own compact electronic
skin that multitasks like
human skin, sensing
pressure, temperature
and sound (which is just
air pressure, really) simultaneously.
The scientists took design cues
from fingertips—home to some
of the most sensitive skins on the
human body. Fingerprint ridges help
amplify vibrations, making sense
of touch extremely fine-grained, so
we can tell crinkly from grainy from
velvety. Plus, the layers of dermis and
epidermis underneath interlock with
each other, providing more points of
contact.
Colour-shifting electronic skin
The ability of animals like chame-
leons, octopus and squid to change
their skin colour for camouflage, tem-
perature control or communication is
well known. While science has been
able to replicate these abilities with
artificial skin, the colour changes are
often only visible to the naked eye
when the material is put under huge
mechanical strain.
Researchers from Tsinghua Uni-
versity have developed a new type of
user-interactive electronic skin that
can change colour. The changes are
perceptible to the humen eye without
much level of strain. The skin could
have applications in robotics, pros-
thetics and wearable technology.
Graphene, with its high transpar-
ency, rapid carrier transport, flex-
ibility and large specific surface area,
shows application potential for flex-
ible electronics, including stretchable
electrodes, super capacitors, sensors
and optical devices. Researchers
employed flexible electronics made
from graphene, in the form of a high-
ly-sensitive resistive strain sensor,
combined with a stretchable organic
electrochromic device. On exploring
the substrate (underlying) effect on
the electromechanical behaviour of
graphene, they found subtle strain—
between zero and 10 per cent—was
enough to cause an obvious colour
change, and the RGB value of the
colour quantified the magnitude of the
applied strain.
Powering the electronic skin
Stanford research team has developed
a stretchable solar cell that could be
used to power the electronic skin.
An accordion-like micro-structure
allowed the cells to stretch up to 30
per cent without damage. The team
also added biological and chemical
sensors to the skin to supplement
pressure sensors.
Another research team has
announced an electronic patch for
monitoring patients’ vital signs.
Described as ‘electric skin,’ the device
was created by embedding sensors
in a thin film and then placing the
film on a polyester backing similar
to those found on temporary tattoos.
A small coil provided power through
induction. In tests, the device stayed
in place for 24 hours without adhe-
sives, relying instead on the Vander
Waals force, and was flexible enough
to move with the skin it was placed on.
Emerging applications
Electronic skins can monitor a per-
son’s heartbeat, brain activity, muscle
contractions and more without the
need for bulky conventional electron-
ics. In addition to patient monitoring,
these could be used to detect speech
by sensing vibrations in the larynx
and emit heat to help
in healing.
Electronic skin
is no thicker than a
human hair and can
be applied as easily
as a temporary tattoo.
It sticks without the
need for any glue, and
can flex and stretch
without breaking.
In essence, e lec -
tronic skin consists
of mechanically flex-
ible sensor networks
that can wrap around
irregular surfaces, and spatially map
and quantify various stimuli.
Long-term vision is to heteroge-
neously integrate a wide range of
sensor networks (pressure, strain,
light, temperature and humidity)
and associated electronics on large-
area plastic substrates using process
schemes that are compatible with
conventional silicon or LCD manu-
facturing lines. The sensor elements
are based on a silicon, oxides, metals,
piezoelectrics and/or organic materi-
als that are processed at less than
35°C. The resulting electronic skin
may find a wide range of applications
in interactive input/control devices,
smart wallpapers, robotics and medi-
cal/health monitoring devices.
Japanese researchers have taken
a step closer to creating electronic
skin by employing flexible electronics
that can be worn as a second skin for
biomedical and other applications.
The aim is to make electronic skin as
much a part of our daily lives as the
clothes we wear.
If this happens, athletes will use
electronic skin to view their heart
rates, sugar levels and work rate. It
could provide doctors with continu-
ous data on patients’ vital signs with-
out the need for repeatedly attaching
and removing medical equipment.
The rest of us might employ the elec-
tronic skin to monitor body health
metrics. Meanwhile, engineers could
put down their tablets when doing
tricky repair work and instead view
maintenance procedures displayed
on their arms. Such is the promise of
ultra-thin, flexible and non-constrain-
ing electronic skin!
Chinese researchers’ electronic skin can change colour like chameleons
24 January 2018 | ElEctronics For you www.EFymag.com
Cloud solutions
In a perfect world, connecting devices, machines and systems to the cloud should be as simple as connecting USB
devices or PCIe expansion cards to a PC.
Make the connection, open the cloud appli-
cation, recognise devices and configure.
You’re now ready to make use of all your
sensor data via a cloud connection, except
that scenario is today nothing more than an
application developer’s dream.
In reality, because sensor data being
gathered at the field level has any number
of characteristics—such as size, structure,
protocol, interface and transmission path—it
has been virtually impossible to realise a
direct cloud connection to all those various
smart sensors with only a few clicks. The
absence of local logic, required to process
heterogeneous data into meaningful infor-
mation, is a roadblock to making sense of
incredibly diverse sensor data.
Yet the appeal of the cloud’s promise to
access Big Data and sophisticated analytics
anytime, anywhere has application devel-
opers inspired to focus on local gateway
technology to find a functional path toward
the plug-and-play vision. Today, more pow-
erful, evolved gateways, which can function
either as dedicated devices or as a virtual
part of a system, play a new role in receiving,
translating, processing and transmitting data
as transparent information to the spectrum
of cloud interfaces. This is enabled by the
new cloud API for IoT gateways. It is essen-
tially a middleware and glue logic solution
to enable simple orchestration of wired and
wireless sensor networks as well as embed-
ded system configurations. The cloud API
provides application-ready software modules
that act as blueprints for original equipment
manufacturers (OEMs) to develop their own
applications, removing complexity and creat-
ing a smart path to connect all types of sensor
networks to any cloud platform.
Amplifying the importance
of gateways
Gateways are complex devices with excellent
transcoding and decision-making capabilities.
Using integrated logic, these collect, analyse
and transcode sensor data and then deter-
mine whether it goes to the field, the cloud
or perhaps another gateway. Their secure
end-to-end encryption further allows them
to structure and move data consistently, for
example, enabling bidirectional communica-
tion with a specificcloud solution.
Enabled with the new cloud API, the IoT
gateway communicates locally with intel-
ligent sensors, now capable of processing
and converting the received sensor data.
Embedded driver modules (EDMs) interface
with hardware and third-party expansion
cards, providing the glue logic that translates
received data into the semantics of the appli-
cation-specific IoT gateway logic. This sensor
engine, with EDM modules incorporated in its
structure, is among the first software compo-
nents to be standardised as a cloud function
module. Its critical value is in moving data
from local sensors to a generic middleware,
independent of protocols.
Data is transmitted into the cloud via pre-
defined interfaces and decision processes, at
the same time normalising data measurements
and checking that received data is meaningful.
By using transparently defined modules and
function blocks, identical logic interfaces can
be used in each application.
From SenSor To Cloud:
A Plug-And-Play Approach Evolving
Zeljko Loncaric is
marketing engineer
at Congatec
Fig. 1: The cloud
API environment
Standardised building
blocks are becoming a
new imperative in cloud
system and application
development
26 January 2018 | ElEctronics For you www.EFymag.com
Cloud solutions
The EDM for the standardised
EAPI interface of computer-on-
modules provides such an example
of standardisation. This enables key
performance information such as
system temperatures and voltages,
CPU utilisation or burglary detec-
tion to be easily transmitted in a
standardised manner to any cloud
by utilising the new Cloud API logic.
The middleware advantage
Historically, there have been no
standardised cloud APIs for IoT
gateways. This created a dead zone
and gap in compatibility for sensor-to-
cloud communication. It’s a challenge
that has also driven an industry-wide
desire to establish smart, efficient
methods for receiving and processing
data locally, and then forwarding it to
the cloud.
To meet this need, cloud APIs must
be not only application-ready but also
standards-based, in order to deliver plug-
and-play integration for the wide range of
wired and wireless sensor connections.
With this advantage, even highly hetero-
geneous protocol configurations can be
integrated with reasonable development
resources, including wireless options
such as Bluetooth LE, ZigBee, LoRa and
other LPWANs, as well as wired protocols
for building and industrial automation.
Cloud communications themselves face
the same plug-and-play challenge, fueled
by individual requirements for propri-
etary servers or third-party offers such as
the Microsoft Azure, Telekom or Amazon
AWS Cloud platforms.
Creating an ecosystem of
standardised building blocks
To round out designs based on this type
of hardware connection and abstrac-
tion, developers also need the flexibility
of a standardised cloud interface. With
standardisation of a cloud API for IoT
gateways, the gateway’s cloud interface
operates independently of the cloud pro-
vider, at least in terms of the design itself.
A new kind of communication
engine developed in response to this
need enables encrypted communica-
tion with servers or different clouds via
smart wireless or wired connections.
It’s a manufacturer-independent, open
standard approach that ensures sensors,
gateways and clouds can be readily
deployed, irrespective of the data type,
computing environment or end-use
application.
For real development value, plug-
and-play convenience must also
extend to the configuration of IoT
gateways. This is illustrated by the
People-System-Things (PST) cloud
framework—a device and data man-
agement system that seamlessly
integrates with the cloud API for IoT
gateways. In addition, PST users can
generate fully-featured web apps
using only the framework’s drag-and-
drop editing tool. No programming is
required, and depending on devices
available to the system, applications
for mobile end users may even be cre-
ated automatically.
Simplifying and accelerating
cloud deployments
In the real world, an IoT appliance is
characterised differently according to
who is asked to define it. For example,
hardware vendors focus primarily on
functions of the embedded system
itself, including the device and its
embedded software. IoT applica-
tion service providers may have
relatively little knowledge of hard-
ware design, and focus their inter-
ests on user interfaces and experi-
ence, website design, databases,
middleware and apps. Lastly,
system integrators or OEMs’ prod-
uct owners focus on configuring,
deploying, maintaining and sup-
porting products that are flexible,
customisable and cost-effective
through standardisation.
To restrain the complexity repre-
sented by all these diverse priorities,
standardised building blocks are
becoming a new imperative in cloud
system and application development.
A strong standards-based ecosystem
is critical to forward progress, with
all major vendors of embedded com-
puter technology, peripherals and
clouds commiting to support these
types of cloud APIs. Each hardware
device demands its dedicated sensor
engine, and each cloud its correspond-
ing cloud engine. The sensor engine
quickly and easily reads, translates
and processes IoT gateway data in
the particular language of the cloud;
users view processed information
on a web application that is created
automatically, with no need to pro-
gram or develop processes for each
sensor. Ultimately, this dramatically
minimises development efforts and
resources required for connecting to
the cloud.
With standardised function blocks,
supply chains can be flexible and OEM
migration strategies remain smart.
Developers pick up tremendous speed
in time-to-market by designing their
IoT application only once, even as
it remains portable to any combina-
tion of sensors, gateways and clouds.
When OEMs’ individual gateways sup-
port a standardised cloud API, only
the cloud engine changes with new
customer clouds. The rest of the solu-
tion can stay as it is, or only needs to
be configured upon customers’ needs.
It’s a new and more practical approach
to cloud connectivity for any sensor
or device in the industrial fields—for
diverse interests across the embedded
value chain.
Fig. 2: Cloud API schematics
Fig. 3: The congatec IoT gateway
embedded
28 January 2018 | ElEctronics For you www.EFymag.com
Globally, there will be over 20 billion connected devices in the next five years, representing $7 trillion dollars
in revenue. This corresponds to roughly
three devices for every person and a value
higher than the year 2016 GDP of all the
countries in the world, except the US and
China. Many of these systems including
implantables, wearables, printed electronics
and the Internet of Things (IoT) will have
ultra-low power and area requirements. So
these applications will rely on ultra-low-
power general-purpose microcontrollers
and microprocessors, making them the
most abundant type of processors produced
and used.
Two types of processors are available at
present: Commercial-off-the-shelf (COTS)
and bespoke. The two have many similar
features, such as a pipeline and cache.
Specifically, COTS processors satisfy
needs of the purchasing organisation with-
out the need to commission custom made,
or bespoke, solutions. Compared to custom
processors, these are cheap, flexible (avoid
binding solution to a single hardware/
software source) and backward-compatible
with legacy products. These provide current
technology solutions and shorten design-to-
production cycles, with their large user base
generally uncovering design defects early.
While COTS processors are likely to be
built for optimal average case performance,
bespoke processors are designed to ease
the certification process. Typical types
of evidence required for certification are
worst-case execution time of instructions,
hardwarereliability and information on
systematic design flaws in the processor.
Bespoke processors are used for applica-
tions with ultra-low area and power con-
straints. Low-power processors are widely
used and are expected to power a large
number of emerging applications. Such
processors tend to be simple, run relatively
simple applications, and do not support
non-determinism, which makes symbolic
simulation-based technique a good fit for
such processors.
Power and area efficiency concerns
Microprocessors and microcontrollers
used in the emerging area- and power-
constrained connected applications are
designed to include a wide variety of
functionalities in order to support a large
number of diverse applications with differ-
ent requirements. On the other hand, the
embedded system is designed for typically a
small number of applications, running over
and again on a general-purpose processor
for the lifetime of the system. Given that a
particular application may only use a small
subset of the functionalities provided by a
general-purpose processor, there may be a
considerable amount of logic in the proces-
sor that is not used by the application.
Cost concerns drive many of the con-
nected applications to use general-purpose
microprocessors and microcontrollers
instead of much more area- and power-effi-
cient ASICs, as, among other benefits, devel-
opment cost of microprocessor IP cores can
be amortised by the IP core licensor over a
large number of chip makers and licensees.
Given the mismatch between the extreme
area and power constraints of emerging
applications and the relative inefficiency
of general-purpose microprocessors and
microcontrollers compared to their ASIC
counterparts, there exists a considerable
opportunity to make microprocessor-based
solutions for these applications much more
area- and power-efficient.
One big source of area inefficiency in a
microprocessor is that a general-purpose
microprocessor is designed to target an
arbitrary application and thus contains
many more gates than what a specific
special processors To Drive
IoTs And Wearables
Considerations when using COTS
COTS components support, maintain and upgrade systems with long life-cycles
of over ten years. When using these components, the following licensing and data
right issues need to be kept in mind:
1. COTS software is usually distributed under licence (typically on a per-user fee basis)
2. COTS documentation is normally copyrighted—distribution as part of another
product usually requires special arrangements and a copy fee
3. Software source code and designs for hardware are usually proprietary and
protected by copyright or patent—even after these are no longer distributed
Part 1 of 2
V.P. Sampath is a
senior member of
IEEE and a member
of Institution of
Engineers India.
Currently working as
technical architect
at AdeptChips,
Bengaluru, he
has published
international papers
on VLSI and networks
30 January 2018 | ElEctronics For you www.EFymag.com
application needs. The unused gates
continue to consume power, resulting
in significant power inefficiency, too.
While adaptive power management
techniques help to reduce power
consumed by unused gates, the
effectiveness of such techniques is
limited due to the coarse granularity
at which these must be applied, as
well as significant implementation
overheads such as domain isolation
and state retention. These techniques
also worsen area inefficiency.
Approaches
One approach to significantly increase
the area and power effi-
ciency of a microproces-
sor for a given applica-
tion is to eliminate all
logic in the microproces-
sor IP core that will not
be used by the applica-
tion. Eliminating logic
that is not used by an
application can produce
a design tailored to the
application—a bespoke
processor—that has sig-
nificantly lower area
and power requirements
than the original micro-
processor IP that targets
an arbitrary application.
Fig. 2: Gates not toggled by two applications—FFT and binSearch—for profiling inputs. Gray gates
are not toggled by either application. Red gates are unique untoggled gates for each application
Fig. 3: Gates not toggled by (a) intFilt and (b) scrambled intFilt for the same input set. Red gates are
uniquely not toggled by that application. Gray gates are not toggled by either application. Red gates
are unique untoggled gates for each application. Even though the applications use the same set of
instructions and control flow, the gates that they exercise are different
(a) FFT (b) binSearch
(a) intFilt (b) Scrambled intFilt
Fig. 1: General-purpose processors are overdesigned for a specific
application (top). The bespoke processor design methodology
allows a microprocessor IP licensor or licencee to target different
applications efficiently without additional software or hardware
development cost (bottom)
Licensee 1
Viterbi
Licensee 1
Viterbi
Licensee 2
tea8
Licensee 2
tea8
Licensee 3
FFT
Licensee 3
FFT
Core
Core
Viterbi
Core
Core
tea8
Core
Core
Licensor
Licensor
Core
Core
FFT
embedded
embedded
32 January 2018 | ElEctronics For you www.EFymag.com
As long as the approach
to create a bespoke proces-
sor is automated, the result-
ing design retains the cost
benefits of a microproces-
sor IP, since no additional
hardware or software needs
to be developed. Also, since
no logic used by the appli-
cation is eliminated, area
and power benefits come at
no performance cost. The
resulting bespoke processor
does not require programmer inter-
vention or hardware support either,
since the software application can
still run, unmodified, on the bespoke
processor.
Static application analysis repre-
sents another approach for determin-
ing unusable logic for an application.
However, application analysis may
not identify the maximum amount
of logic that can be removed, since
unused logic does not correspond
only to software-visible architec-
tural functionalities but also to
fine-grained and software-invisible
micro-architectural functionalities.
For example, consider two differ-
ent applications: FFT and binSearch.
Since these applications use different
subsets of the functionalities provid-
ed by the processor, the parts of the
processor that they do not exercise
are different. However, a closer look
reveals that while some of the differ-
ences correspond to coarse-grained
software-visible functionalities,
other differences are fine-grained,
software-invisible, and cannot be
determined through application
analysis.
The two applications use exactly
the same instructions; however,
die graphs in Figs 2 and 3 show
that the sets of unexercised gates
for the applications are different.
This is due to the fact that even the
sequence of instructions executed by
an application can influence which
logic the application can exercise in
a processor depending on the micro-
architectural details. Such interac-
tions cannot be determined simply
through application analysis.
Given that the fraction of logic
in a processor that is not used by a
given application can be substan-
tial, and many area- and power-
constrained systems only execute
one or few applications for their
entire lifetime, it may be possible to
significantly reduce area and power
in such systems by removing logic
from the processor that cannot be
used by the applications. However,
since different applications can exer-
cise substantially different parts of
a processor, and simply profiling or
statically analysing an application
cannot guarantee which parts of the
processor can and cannot be used by
an application, tailoring a processor
to an application requires a tech-
nique that can identify all the logic
in a processor that is guaranteed to
never be used by the application
and remove unusable logic in a way
that leaves the functionality of the
processor unchanged for the appli-
cation.
In the next section,we describe
a methodology that meets these
requirements. We call general-pur-
pose processors that have been
tailored to an individual application
‘bespoke processors’—reminiscent of
bespoke clothing, in which a generic
clothing item is tailored for an indi-
vidual person.
Tailoring a bespoke processor
to a target application
Bespoke processor design tailors a
general-purpose processor IP to a
target application by removing all
gates from the design that can never
be used by the application. The
bespoke processor, tailored to the
target application, must be function-
ally equivalent to the original proces-
sor when executing the application.
It should retain all the gates from the
original processor design that might
be needed to execute the
application.
Any gate that could be
toggled by the application
and propagate its toggle to a
state element or output port
performs a necessary func-
tion and must be retained to
maintain functional equiva-
lence. Conversely, any gate
that can never be toggled by
the application can safely
be removed, as long as each
fan-out location for the gate is fed
with the gate’s constant output value
for the application.
Removing constant gates for an
application could result in signifi-
cant area and power savings without
any performance degradation. In
addition, gate removal can expose
additional timing slack, which can
be exploited to increase area and
power savings or performance of
a bespoke design. On an average,
bespoke processor design reduces
area and power consumption by
62 per cent and 50 per cent, while
exploiting exposed timing slack
improves average power savings to
65 per cent.
The first step of tailoring a
bespoke processor—input-independ-
ent gate activity analysis—performs
a type of symbolic simulation, where
unknown input values are repre-
sented as X’s, and gate-level activity
of the processor is characterised for
all possible executions of the appli-
cation, for any possible inputs to the
application.
The second phase of bespoke
processor design technique—gate
cutting and stitching—uses gate-level
activity information gathered during
gate activity analysis to prune away
unnecessary gates and reconnect
the cut connections between gates
to maintain functional equivalence
to the original design for the target
application.
Input-independent gate
activity analysis
The set of gates that an application
toggles during execution can vary
depending on application inputs.
This is because inputs can change
the control flow of execution through
Fig. 4: The process for tailoring a bespoke processor to a target application
List of Unused
(Untoggled) Gates
Gate-level
Netlist
Gate Activity
Analysis
Application
Binary
Cutting and
Stitching
Bespoke Processor
Tailored to Application
embedded
34 January 2018 | ElEctronics For you www.EFymag.com
the code as well as data paths exer-
cised by the instructions.
Since exhaustive profiling for
all possible inputs is infeasible, and
limited profiling may not identify
all exercisable gates in a processor,
the analysis technique is based on
symbolic simulation. This technique
is able to characterise the gate-level
activity of a processor executing an
application for all possible inputs
with a single gate-level simulation.
During this simulation, inputs are
represented as unknown logic values
(X’s), which are treated as both 1’s
and 0’s when recording possible tog-
gled gates.
Symbolic simulation has been
applied in circuits for logic and
timing verification, as well as
sequential test generation. More
recently, it has been applied in
determination of application-specific
Vmin. Symbolic simulation has also
been applied for software verifica-
tion. However, no existing technique
seems to have applied symbolic
simulation to create bespoke proces-
sors tailored to an application.
Initially, values of all memory
cells and gates are set to X’s. The
application binary is loaded into
program memory, providing values
that effectively constrain which gates
can be toggled during execution.
During simulation, the simulator sets
all inputs to X’s, which propagate
through the gate-level netlist during
simulation.
After each cycle is simulated, tog-
gled gates are removed from the list
of unexercisable gates. Gates where
an ‘X’ propagated are considered as
toggled, since some input assign-
ment could cause the gates to toggle.
If an ‘X’ propagates to the PC, indi-
cating input-dependent control flow,
the simulator branches the execution
tree and simulates execution for all
possible branch paths, following
depth-first ordering of the control
flow graph.
This naive simulation approach
does not scale well for complex or
infinite control structures which
result in a large number of branch-
es to explore. So a conservative
approximation could be employed
that allows the analysis to scale for
arbitrarily-complex control structures
while conservatively maintaining
correctness in identifying exercisable
gates. The approximation works by
tracking the most conservative gate-
level state that has been observed
for each PC-changing instruction.
The most conservative state is the
one where the most variables are
assumed to be unknown (X).
When a branch is re-encountered
while simulating on a control flow
path, simulation down that path can
be terminated if the symbolic state
being simulated is a sub-state of the
most conservative state previously
observed at the branch, since the
state (or a more conservative ver-
sion) has already been explored. If
the simulated state is not a sub-state
of the most conservative observed
state, the two states are merged to
create a new conservative symbolic
state by replacing differing state vari-
ables with X’s, and simulation con-
tinues from the conservative state.
This conservative approximation
technique allows gate activity analy-
sis to complete in a small number of
passes through the application code,
even for applications with an expo-
nentially-large or infinite number of
execution paths.
The result of input-independent
gate activity analysis for an applica-
tion is a list of all gates that cannot
be toggled in any execution of the
application, along with their constant
values. Since the logic functions per-
formed by these gates
are not necessary for
the correct execu-
tion of the binary for
any input, these may
safely be cut from
the netlist as long as
their constant output
values are preserved.
The following section
describes how unusable gates can be
cut from the processor without affect-
ing its functionality for the target
application.
Cutting and stitching
Once gates that the target application
cannot toggle are identified, these are
cut from the processor netlist for the
bespoke design. After cutting out a
gate, the netlist must be stitched back
together to generate the final netlist
and laid-out design for the bespoke
processor.
Fig. 5 shows the method for cut-
ting and stitching a bespoke proces-
sor. First, each gate on the list of
unusable gates is removed from the
gate-level netlist. After removing a
gate, all fan-out locations that were
connected to its output net are tied
to a static voltage (‘1’ or ‘0’) cor-
responding to the constant output
value of the gate observed during
simulation. Since logical structure
of the netlist has changed, the netlist
is re-synthesised after cutting all
unusable gates to allow additional
optimisations that reduce area and
power.
Gates having constant inputs
after cutting and stitching can be
replaced with simpler gates. Also,
toggled gates left with floating out-
puts after cutting can be removed, as
their outputs can never propagate to
a state element or output port. Since
cutting can reduce the depth of logic
paths, some paths may have extra
timing slack after cutting, allow-
ing faster, higher-power cells to be
replaced with smaller, lower-powerversions of the cells. Finally, the
re-synthesised netlist is placed and
routed to produce the bespoke pro-
cessor layout, as well as a final gate-
level netlist with necessary buffers,
etc to meet timing constraints.
To be continued next month
Fig. 5: Method for cutting and stitching a bespoke processor
List of Unused
Gates
Gate-level
Netlist
Cut Unused
Gates
List of Constant
Gate Values
Set Unconnected
Gate Inputs to
Constant Values
Synthesis Place and Route
Bespoke Gate-
level Netlist
Bespoke
GDSII File
36 January 2018 | ElEctronics For you www.EFymag.com
design
While testing a smartphone, the manufacturer finds a major flaw in the device. Some internal body
parts have overheated and melted during the
stress-test. A root-cause analysis indicates the
designed circuit was not optimised for ther-
mal resilience—a step that should have been
planned and executed at the start of the design
process. There are many such instances where
the solution is simple but gets missed amidst
the complexity of a design process. That is why
designers jot down the list of best practices to
ensure they deliver optimal design with mini-
mal rework and resource. In this article, we
take a look into some of these best practices
and understand their importance.
Common struggles in circuit design
Designers often face issues of rework and
wasted resources. This is mainly due to the
use of smaller tracks for circuit layout, where
all components are not able to fit. Another
reason is the rush to meet timelines.
The design team from PCB Power Market,
a PCB design and manufacturing firm from
India, says, “In a hurry, designers start miss-
ing out some essential components. So they
start using other objects with simple parts
and traces and construct replacements for
components. It works initially. The layout
looks perfect when they view it. But eventu-
ally, they give out.”
Communication with the manufacturer
is also critical. If the capacity of the manu-
facturer is not clear, or if the designer has
not shared all the components and design
schematic with full clarity, the manufactured
end product will be flawed. Along with these
come the technical challenges.
The golden rules
Pre-design and post-design analyses are
equally important to ensure proper circuit
outcome. These involve the following con-
siderations.
Choose the right board spacing. Select-
ing the right spacing can substantially save
cost and rework. According to PCB Power
team, “Wherever possible, use wider tracks
or spacing. If your design permits bigger
tracks via drill size, use them. A via-aspect
ratio of 6:1 ensures that your board can be
The Golden Rules Of
ElEctronic circuit DEsign
Paromik
Chakraborty is a
technical journalist
at EFY
Knowledge of common
pitfalls in designing
electronic circuits, and
how to avoid these, is
important for producing
any product
38 January 2018 | ElEctronics For you www.EFymag.com
design
fabricated anywhere. For most designs,
a little thought and planning will save
cost and improve manufacturability.”
Creating a proper digital represen-
tation of the circuit before taking it to
production is also important. The PCB
Power team continues, “Define all the
components and circuit schematic
properly in the CAD software during
design. In case you have missed out a
component, define the component in
your CAD library in the correct way and
process all the information from there.”
Ensure protection against elec-
trostatic discharge. Electrostatic
discharge (ESD) is caused by sudden
electrical energy, developed by static
electricity or electrostatic induction,
flowing from one charged object to
another. Electronic circuit components
are highly sensitive to ESD. Manufac-
turing floors and design areas should
invest in ESD-protected areas (EPAs)
where high-charge objects are kept out.
Ionisation is a popular process for
ESD-proofing of electronic devices
that cannot be grounded. Use of
ESD protector materials during cir-
cuit design becomes imperative.
Some commonly used ESD protec-
tors include metal-oxide varistors,
transient-voltage-suppression diodes,
polymer-based ESD suppressors and
clamping diodes. ESD protection will
keep electronic devices from getting
damaged by heavy lightning or any
kind of charge transfer.
Save the circuit from EMI. Elec-
tromagnetic compatibility (EMC) is
crucial to ensure the quality of the
circuit being designed. It ensures that
electronic circuits are not troubled by
electromagnetic interference (EMI).
EMI arises due to radio-emission
of other nearby electronic objects. It
impacts electronic circuits by providing
wrong data or making the system stop
altogether. EMI shielding can be done
by using components like ferrite beads
and capacitor filters. Overall, EMC can
be controlled using shielded inductors
to cut down sharp current transients.
There are also EMI shielding materials
that can keep the PCB unaffected.
Create resilience to reverse polar-
ity. There is always the chance that
the two charged ends of an electronic
device get connected to the wrong ter-
minals. One of the most common exam-
ples is attaching a battery in reverse
polarity to an electronic device. If the
circuit is not well-protected against
reverse polarity, hazardous outcomes
might follow, including malfunction
or even frying of the circuit. One pre-
cautionary measure is to connect the
heavy-load-carrying microprocessor
output drivers to a large resistor. Using
a diode bridge is another option that
rectifies the input and ensures correct
polarity in the circuit.
Tend to each component separate-
ly for thermal resilience. Electronic
circuits can lead to disasters if their
components are not tested for heat
resistivity.
The process to ensure thermal
stability at peak temperature differs
for every component. For instance, a
resistor’s capacity is determined by
measuring the de-rating of power at
peak temperature. Capacitance, on
the other hand, can be checked by
evaluating the leakage rate, increase
in equivalent series resistance capac-
ity and de-rating. For diodes and
transistors, current gain and recovery
time under peak temperature can be
essential determinants.
Evaluate the circuit behaviour
with power. It is essential to know
the behaviour of the circuit when
it is connected to a power source.
Measuring the pull-up resistors can
help you know whether the circuit is
behaving properly during power-up.
Pull-up resistance on a logic circuit’s
microcontroller units should be high
on power-up.
You should also know how your
circuit will function if there is a sudden
outage in power while it is processing
some data. Including a power-down
detection circuit is very important to
ensure that the processor is saving the
information properly during a sudden
power cut. Power-off detection circuit
is a network of a diode and a collec-
tion of capacitors, transistors and a
voltage-generating circuit that keeps a
circuit running for some time with its
discharged power during power-cut.
Also take precautionary measures
for current overshoots and undershoots
in the circuit. These are basically spikes
and falls in the current flowing through
a circuit. Very high overshoots may fry
the circuit. On the other hand, excessive
falls can hamper the circuit functioning.
Use of clamping diodes is a good option
to ensure safety of circuit terminals from
such power inconsistencies.
Test points are important. Test
points are small wired loops placed on
a PCB board to allow easy anchoring of
test probes on the circuit. Usually, test
probes are made of phosphor-bronze
alloy with copper conductors or silver-
plate coatings. Ground nets, power nets
and threshold points of circuits should
be mandatorily assigned test points.
Be clear with your manufacturer.
As mentioned before, clarity with the
manufacturer right from the start is
very essential. To avoidcomplications,
learn about the manufacturer’s speci-
fications including minimum trace
width, spacing and number of layers.
You must have complete transparency
while sharing the design details. Men-
tion all the components, the schematic
and the build. In case a custom-build
circuit is desired, but has not been
communicated to the manufacturer,
they would be following the default
build model, which might create great
differences from the expected outcome.
Electronic circuit design is not
easy. Nevertheless, if done well, it can
do wonders—whether you are doing
a small-scale project or a large-scale
business. Thus, keeping the rulebook
open will keep you a step ahead in the
game.
Fig. 1: ESD testing in an EPA
Fig. 2: A diode bridge rectifier circuit
InnovatIon
40 January 2018 | ElEctronics For you www.EFymag.com
tilators, due to lack of which precious lives
are being lost. From there on we decided to
work together to make a cheaper and more
efficient ventilator. Our main aim was to
create something that is cheap, easy to run
and portable,” shared Prof. Vaish.
The technology was developed by A-SET
with medical inputs from AIIMS.
Challenges
Conventional ventilators are very expensive
(costing ` 1-1.5 million each), extremely
big (1-1.5m tall and around 61cm wide and
deep) and complicated, requiring medical
staff to run them. In addition, these need
constant oxygen supply to run, which costs
around ̀ 2000-3500 per day.
A-SET Robotics’ ventilator overcomes
these problems as:
1. It is around a hundred times cheaper
at ̀ 15,000.
2. It has the size of a compact disk, so it
can fit into the user’s pocket.
3. It doesn’t require oxygen supply
and can circulate room air to the
patients.
4. No professional expertise is
required to control it. It can be operated
by just a smartphone via Bluetooth
interface, which makes it extremely
easy to use. Also, in case of any prob-
lem, one may reach out to the provided
helpline numbers, and it can be con-
trolled remotely by the central team.
How it works
A machine learning algorithm under-
stands the patient’s inhale-exhale
pattern and controls air pressure and
flow rate to the patient as per the best
settings:
1. A pressure sensor monitors the
relative pressure of the patient’s air
passage over 1000 times a minute
2. The pressure reading is then sent
to a computing unit, which calculates if
it’s inhale phase or exhale phase
3. In inhale phase, the air is induced
at a controlled pressure and sent at
Ventilators have become synonymous for emergency care. Unfortunately, due to their high cost, not every
hospital and patient in the world can afford
them. The good news is that the world’s
smallest and cheapest ventilator has been
made in India, revolutionising critical care.
This ventilator can be purchased by all levels
of hospitals from primary care hospitals to
tertiary care hospitals. The scope of its com-
mercialisation is quite huge.
The journey
The new ventilator is the result of a joint
effort between Professor Diwakar Vaish,
head, robotics and research, A-SET Training &
Research Institutes, and Dr Deepak Agrawal,
professor-neurosurgery at AIIMS, New Delhi.
“We met during a programme in AIIMS
and there we discussed various challenges
that our healthcare system is facing currently.
Out of all the problems, we centered on ven-
World’s Cheapest And smallest
Ventilator Made In India
Nidhi Arora is
executive editor
at EFY
The new ventilator
developed by
A-SET together
with AIIMS
InnovatIon
42 January 2018 | ElEctronics For you www.EFymag.com
controlled rate to the patient
4. Upon sensing that
the lung is filled to the right
capacity, the air flow is
stopped
5. Thereafter exhale
phase is sensed for the
patient
6. Once exhale phase is
sensed, another air chan-
nel is selected for exhaling
the air from the lungs to the
atmosphere
This is an extremely time-
critical operation as inhale
and exhale happen within a time
span of 1-2 seconds. Even slight delay
in computing can hamper the entire
process. Hence there is hardly any
setting required for the ventilator and
the entire process can be managed by
the ventilator itself without requiring
the services of any health practitioner.
Acceptance and validation
The new ventilator has brought hope
to thousands of those patients who
have complete body paralysis and
Mechanism inside the ventilator
have been hospitalised for many
years. Now, they can afford a ventila-
tor and get back to their homes. This
ventilator can be used in all the situ-
ations where normal ventilators are
used, such as in hospitals, ambulances
and even homes.
Prof. Vaish explained, “Although
the innovation is breakthrough, we
still face some basic functional chal-
lenges. Like, in manufacturing, the
process to obtain certifications is
slow and tedious. We are applying for
major global certifications
and hope to get them in
the near future. We already
have two patents credited
for our product.”
“Technically, mistakes
and innovations go hand-
in-hand. We tried vari-
ous sensors and different
algorithms. At times, the
members of team thought it
was impossible. However, it
is through consistent efforts
and hard work that we won.
We finally succeeded after
over 50 iterations,” Dr Vaish added.
The road ahead
The team wants its product to pen-
etrate as deep as possible. It is looking
for support from the government as
well. It is also open to partnership
with other companies, especially those
in medial domain. The team hopes
that the product reaches to people in
need not just in India but throughout
the world. It wants the sales to cross
50,000 units next year.
IntervIew
43www.efymag.com electronics for you | January 2018
“You Need To Take That
L-Shaped pcb And Figure
Out How To Put MiLLiMetre
Wave Into It”
There is a lot of talk about 5G, its benefits and applications. For
engineers planning to start playing around with 5G, it’s important to
get a bird’s eyeview of the challenges in designing a mobile device
using this technology. Jim Cathey, Larry Paulson and Peter Carson
from Qualcomm explain the basics to EFY’s Dilin Anand
5G
Q. What design changes are
required to make smartphones
millimetre-wave-capable?
A. If you take any smartphone,
it has an L-shaped PCB at one side
and rest of the space is carved out
for a battery. You need to take that
L-shaped PCB (which is already
packed to the brim) and figure out
how to put millimetre wave into it.
You cannot use the existing antenna
setup for LTE here, because the
antenna array and other aspects are
completely different from what is
needed for millimetre wave. Over-
all, there are three items that need
to be balanced: power, coverage
and size.

Q. Could you explain power design
challenges?
A. Power problems are more
of a downlink problem. The gain
in your amplifier decides the
amount of power you transmit
back to the base station. Power-
amplified antenna and the choice
of the antenna element have an
important impact here. Certain
antenna designs cause the radiation
to go forward and narrow instead
of widening and shortening. The
power amplifier drives each one.
So if you have four antennae and
power amplifiers, you can add them
together so that these direct to per-
form beamforming.

Q. What’s the best way to maximise
gain here?
A. You can go for an extremely
low-power amplifier, and add four
4dB amplifiers together to get 16dB
gain. Remember this is going to be a
logarithmic addition for dB here, so
it’s an order of magnitude higher for
each. Once this is done, you can use
polarisation to get an additional 3dB
of antenna gain. The most severe
power efficiency impacts will be at
the downlink due to multi-gigabit
data streams, data processing and
related aspects.

Q. What’s the biggest
benefit of using 802.11ad
instead of 802.11ac?
A. 802.11ad gives much higher
throughputsat the same power
level. The aim here is to balance the
power throughput and not just look
at the power efficiency.

Q. Any final tip that designers need
to keep in mind?
A. You may still end up grabbing
the wrong end of the device and
blocking the module. So you need to
design a way out for this by having
more than one module in these
millimeter-wave devices.
Q. What will be the scenario ten
years from now?
A. In the future, you will have
less low-level decisions to make.
At the same time, you could also
have a lot of data on tap that can be
easily accessed through a potentially
augmented reality interface. Overall,
this means that you will have more
time to dwell on the things of your
choice while everything else can be
automated.
Q. Autonomous vehicles are
starting to look a lot like gadgets.
What’s your take on a realistic
scenario?
A. What will make autonomous
driving actually work is a 100 per
cent autonomous driving system.
If you ban driver-occupied cars
between 6am and 10pm in New
York, London, Tokyo or any other
major city for instance, and then
smart grid the lighting system in
the roads, the whole thing is going
to work in an automated way. It is
going to be an extremely efficient
way.
Jim CAthey
senior viCe president And
president, AsiA pACifiC & indiA,
QuAlComm teChnologies, inC.
lArry pAulson
viCe president And
president, QuAlComm indiA
peter CArson
senior direCtor, mArketing,
QuAlComm teChnologies, inC.
IntervIew
44 January 2018 | ElEctronics For you www.EFymag.com
“The Biggest Challenge Today Is
The Lack Of Hardware”
With expansion of the Internet of Things (IoT), we are looking at an ecosystem
filled with sensors geographically distributed over large areas. This calls for a
wide-area network (WAN) bridged by low-power communication technologies.
Paromik Chakraborty of Electronics For You spoke to Gaurav Sareen, country
director-India, Sigfox, to understand benefits of low-power wide-area network
technologies and how the Indian ecosystem is adapting to these
Low-Power WAN
Gaurav Sareen
country director-
india, SiGfox
Q. How are low-power communica-
tion technologies benefitting wide-
area networks?
A. Till date, cellular communica-
tion was the only WAN technology
available. However, it was meant to
use radio technology and support
high bandwidth—making it extremely
power-hungry. In machine-to-machine
(M2M) communication, where the
sensor-driven data payload is going to
be very small and infrequent, cellular
technologies become an overkill due
to their power inefficiency.
That is where the tables turned
with low-power wide-area network
(LPWAN). LPWAN technologies were
developed bottom-up to be highly
power-efficient. You can have battery-
powered sensors to work for an
upward of ten years without having to
replace their battery.

Q. How do LPWan technologies
achieve improved energy efficiency?
A. The main difference lies in the
design of the transceiver. The trans-
ceiver in cellular devices is always
‘on,’ continuously sending and receiv-
ing data from the nearest station. In
LPWAN, the edge device transmitting
the data is sleeping most of the time.
The transceiver wakes up only at
predefined times or based on real-
time information to transmit its data
and goes back to sleep. That is how it
conserves energy.

Q. cost-wise, how do these compare
to the existing technologies?
A. Communication is a function of
two things—transceiver and connectiv-
ity itself. Let’s take the simple exam-
ple of your mobile service: First, you
pay for the cost of the cellphone that
has the transceiver embedded in the
device, and then you pay for the con-
nectivity to the network provider. New
technologies are trying to address these
cost points and bring them down.
To give you a clear idea, our
transceiver costs just about 1/15th of a
cell phone transceiver’s price. Typi-
cally, a cell phone transceiver costs
$10-$12. Our transceivers cost $1.89.
The cost of cellular networks today
for M2M application is typically about
$60 a year per device (about Rs 300
a month) as against Sigfox network’s
about $3-$4 a year per device.
Going forward, as the cost of trans-
ceivers goes down further to a few
cents, these sensors can be embedded
in a larger variety of applications, and
applications like the IoT and M2M will
start becoming the mainstream.

Q. any example?
A. An example is embedding
transceivers in envelopes or packages
to trace when and where these are
opened. This solves a lot of problems
faced by e-commerce companies.
Earlier, they tried to outsource their
logistics but realised that it was
extremely inefficient because a lot of
products were getting lost, causing
30-40 per cent shipment loss. Now
they have insourced the logistics for
better control and some are starting
to implement the envelope solution.
They are receiving a message about
the location and timestamp when
the package is opened, so the team
can verify whether the package was
received by the intended recipient or
opened somewhere else.

Q. How are LPWans being secured?
A. Today, security is being
designed in every aspect of the con-
nected ecosystem, starting from the
device or hardware level. For that,
we are using Secure Elements (SE),
which is an additional hardware
component that actually encrypts the
data flowing into the hardware and
checks the authenticity of the device.
This ensures that the hardware is not
compromised. Following that, in the
network layer, advanced encryption
schemes (AES) ensure that data in
motion is secure. Finally, we have the
application layer where data is tested
to ensure it is infection-free.

Q. is the indian ecosystem ready for
these?
A. The biggest challenge today is
the lack of hardware. This is inhibiting
the IoT from becoming mainstream.
The second challenge is the lack of
a well-defined policy. Policy-makers
are trying to frame out a structure
considering all use cases where data
privacy regulation needs to be fol-
lowed and where it can be relaxed.
Again, the Bureau of Indian Stand-
ards (BIS) will start certifying IoT
devices—but that will also require a
certification framework. This is taking
time because the technology is in a
nascent stage.
Awareness and education in the
market is another challenge in the
ecosystem.
46 January 2018 | ElEctronics For you www.EFymag.com
test & measurement
High-Speed
MeMory
TesTing
Trends And
Tips
Paromik
Chakraborty is a
technical journalist
at EFY
test & measurement
The high-speed random-access memory (RAM) market is dominated by double-data-rate (DDR) technology with DDR4
ruling the pack. Mobile devices like tablets,
laptops and smartphones use a low-power
version of DDR (LPDDR) to lower their power
consumption.
DDR memory is based on a parallel-line
technology that uses a large number of chan-
nels to carry the data. Operating on such a large
number of data lanes at a high speed presents
its own challenges. This is driving upgradation
of the respective test and measurement (T&M)
devices.
Trends in memory testing
DDR chips are tested at wafer-probe and
memory-module levels. Probing is an impor-
tant aspect of catching the right signals of the
memory by the test equipment. But the process
of probing comes with many difficulties. To
explain simply, when you use probes for DDR,
there is a loss of signal. Such challenges call for
a process called de-embedding.
Sanchit Bhatia, application expert in high-
speed digital applications, Keysight Technolo-
gies, says, “Specialised ball-grid-array probes
are the preferred choice. These are soldered
between the memory and the board. DDR4 has
an average speed of 3.2 gigabits per second. At
such a high speed, there is signal loss when
using these probes. De-embedding is done
to compensate for this signal loss.” After
de-embedding, the signals are tested and
validated by test devicesto ensure proper
functioning of the memory.
On the other hand, memory-module-
level testing is done at an integrated system
level when all the component-level tests are
completed.
Bhatia further explains that DDR testing
can be done in two broad categories. The
first type is parametric testing, which tests
the integrity of DDR signals by analysing
the timing of DDR waveforms and all other
physical-layer parameters. The other category
is functional or protocol testing, which tests
whether the data is flowing as per the rules
set. It evaluates whether all the commands
are in place, addresses are correct and the sig-
nals are following all the protocols properly.
For DDR4 series, Joint Electron Device
Engineering Council (JEDEC), the memory
circuits standards defining body, added a
new test called bit-error rate (BER) test. To
cater to all these evolving test standards and
requirements, high-speed testing equipment
have dramatically improved in capacities
over years.
Upgrades in T&M devices
T&M equipment have seen a number of trans-
formations to scale up to the capabilities of
DDR4 and higher versions and meet JEDEC
standards, be it in terms of speed, size or
channel support. Here are some of the major
trends.
Higher speed, more parallel DUTs. DDR
memory test setups are improving in speed
Before buying any
equipment for high-
speed memory testing,
it is better to go
through the tips and
trends mentioned here
48 January 2018 | ElEctronics For you www.EFymag.com
test & measurement
and capacities in general. Faster bit rates
and capability to test a larger number of
devices in parallel are evident.
As an example, Jin Yokoyama,
functional manager-memory test,
Advantest, explains Advantest’s test
setup evolution. The latest device
in their T5503 series has seen size
reduction and improved cost effi-
ciency with a capacity to test 512
DDR4 DRAM memory devices
simultaneously. Their LPDDR
testing capability has evolved
from 1600 megabits per second
(Mbps) and 12.8 gigabytes per
second (GB/s) for LPDDR3
memories to 3200Mbps and 25.6GB/s
respectively for the newer LPDDR4.
On the other hand, the newest T5582
series can support 1536 devices under
test (DUT) in parallel with maximum
data rate of up to 1.2Gbps.
Higher capacities in high-band-
width oscilloscopes. High-bandwidth
oscilloscopes are used for parametric
tests—evaluating the signal integrity
of the memory. The upgraded oscillo-
scopes support mixed-signal channels,
that is, these have four analogue chan-
nels and 16 digital channels. These
channels help in a range of functions,
like connecting the DDR command
bus to evaluate command triggers or
assessing the complete protocol of the
command.
Another characteristic of DDR
memory signals is that these come as a
combination of ‘read’ and ‘write’ com-
mands. ‘Read’ command comes from
the memory itself, while ‘write’ com-
mand comes from the controller. Read-
write channels of the oscilloscope help
in separating these commands.
Bhatia explains, “With the intro-
duction of DDR4, the oscilloscope
bandwidth has gone up to 13GHz. The
previous highest bandwidth range was
8GHz. The upgrade has resulted in a net
20 per cent increase in equipment price.”
Quad-sampling in logic analysers.
Functional testing of high-speed memo-
ries requires capturing of all possible
channels at the same time. Logic analys-
ers are essential devices for the purpose.
Logic analysers suited for DDR testing
have as many as 136 or more channels
and a speed of 4Gbps or higher.
As a major upgrade, many manu-
facturers are developing logic analysers
with a feature called quad-sampling,
which means these analysers can take
four samples in every clock cycle. The
DDR works on both rising and falling
edges of a signal. Moreover, it has both
read and write signals on each rise and
each fall. For efficient testing, in one
clock cycle, one sample each of Read
rising (Read command on the rising
edge of the signal), Write rising, Read
falling and Write falling is needed.
Without quad-sampling technol-
ogy, the tester will have to split the
clock cycle into four samples by physi-
cal techniques and do the sampling on
four different channels, which is very
cumbersome. Quad-sampling allows
you to procure all four samples on
a single channel, cutting down the
complexity, time and effort required.
Bhatia shares that Keysight’s previ-
ous version of logic analysers used to
have dual-sampling capability, driving
testers to procure the samples on two
separate channels. These have been
upgraded to quad-sample now.
Additionally, the speed of ana-
lysers has gone up to 4Gbps from
2.5Gbps earlier. The protocol testing
setup can be arranged in two levels:
Either for only command and address
debugging, or with data debug capa-
bility along with command and
address debugging.
Software upgrade. There are
specialised software to test DDR
bus for compliance to JEDEC stand-
ards. These DDR compliance testing
software are fully automated and
can complete 50-60 tests in one go.
Another software called DDR debug
tool analyses failures detected by the
DDR compliance testing software. It
helps to narrow down reasons behind
the failure and locate the particular bus
that has failed.
Tips for optimal T&M
Following the upgrade trends in DDR
T&M devices, there will be certain cri-
teria and challenges in designing and
selecting the optimal test setup. Bhatia
shares the important ones.
Preference to devices with
the highest test coverage. DDR
doesn’t have a dedicated compli-
ance program like other technolo-
gies. It has a set of specifications
following which the tests are
done. There is a large list of tests that
can be conducted for DDR memories.
Different vendors provide support for
different number of test automation—
some provide 40 to 50 tests, while
others may give 100. Before selecting a
setup, check the number of tests that
it supports.
Don’t over-invest in higher-band-
width devices. Bhatia opines, “DDR
does not require very high-bandwidth
values such as 20GHz. So test equip-
ment with 13GHz bandwidth will work
fine. DDR memories use FR4, which is
a low-cost semiconductor material. As
these are made to keep the cost afford-
able, excessively high-level bandwidth
is not achievable.”
Data debug is a good choice. Some
protocol testing equipment are incapa-
ble of data debugging. Logic analysers
with data, address and command
debug capability can be customised to
debug any of the selected parameters
as required. So go for a logic analyser
with data debug capability.
Use RC-type probing for best
results. For DDR probing, ensure use
of resistor-capacitor (RC)-type probes.
Many designers choose RCRC (high-
bandwidth) type probes, which do not
give good results because they do not
generate high impedance.
Going forward
DDR5 is still under development, but
is projected to become mainstream in
a short span of time. So T&M equip-
ment manufacturers are already
upgrading for the future. For example,
Advantest is improving its test devices
for a massive 6.4Gbps speed to support
LPDDR5.
Logic analyser for high-speed memory testing (Image source: eet.com)
50 January 2018 | ElEctronics For you www.EFymag.com
telecom
Given all the marketing push and hype around the Internet of Things (IoT), it is difficult to predict how
business models will evolve over the next
few years. For industry practitioners, this
remains one of the major concerns. Usu-
ally, they ponder upon implementing the
IoT and end up asking, “How can the IoT
be used in my industry?”
Looking at the existing solutions is
the most common approach to find an
answer to this question. At one end, there
are business-to-consumer (B2C) solutions,
which are good to have but don’t solve the
real pain. At the other end, we see some
B2B trends around particular industries
where the IoT can play a crucial role. One
such verticalis telecom.
For more than a decade, telecom has
been the poster boy of high-technology
industry. This is because of its fast expan-
sion, highly driven by innovation around
smartphones and the Internet. New
services are being promoted and new
geographies being captured by telcos.
All this adds complexity to managing the
work optimally, combined with the force
of launching new services that add value
to eliminate the competition.
Emergence of the IoT presents some
interesting opportunities for telcos.
Great news is that these opportunities
can propel both the top line and bottom
line, introducing more operational effi-
ciency and additional
revenue streams. Let
us look at some of the
available options.
Enhancing
operational
efficiency
Remote infrastruc-
ture accounts for a
significant portion of
telcos’ operational
cost. The IoT plays a
significant role here
in remote manage-
ment and monitoring.
Let us consider a mobile operator network,
which contains many mobile cell towers
that are spread across a large geographical
area. For managing the remote equipment of
telcos, protocols and standards are in place.
However, there are issues like environmen-
tal protection, physical security and asset
management.
Asset handling and monitoring. A
remote cell tower site incorporates auxiliary
equipment along with major telecommuni-
cation equipment in order to make things
work. One such equipment is the genera-
tor for power backup, which ensures 24/7
network uptime. Energy meters, UPS and
air-conditioning are other major assets.
These come under the passive infrastruc-
ture. Predicting their failure in advance by
monitoring their operational efficiency is an
important part of remote management. The
IoT makes it possible.
Physical security. In remote places,
physical security of costly equipment is
important. This requires an IoT-enabled
intrusion detection system. In addition, a
tracking system for resource consumption
by pilferable consumables such as batteries
and fuels is needed to ensure timely alerts
in order to minimise losses.
Environmental protection. There is
always the threat of environmental damage
to remote sites. The IoT plays a major role
in detecting conditions such as flood, smoke
and bad weather. It also assists in providing
control commands to either shut down the
system to avoid irreparable damages or take
any preventive measures.
Providing last-mile access to
devices
When using the IoT to handle remote telco
sites, it must be noted that the IoT depends
on a reliable communication link. So it is
crucial to consider something which doesn’t
suffer from downsides of the telco’s terres-
trial link failure.
Low-power radio. By playing the role
of a service provider, telcos can tap into the
machine-to-machine (M2M) ecosystem.
M2M communication needs very low band-
How The IoT Is
Revolutionising Telecom
Savaram Ravindra
holds a Masters
degree in
Nanotechnology
from VIT University.
He has worked
as a programmer
analyst at Cognizant
Technology Solutions
Image: Kaa IoT platform
IoT can propel both the
top line and bottom line of
telcos by introducing more
operational efficiency and
additional revenue streams
51www.EFymag.com ElEctronics For you | January 2018
telecom
width in comparison to human-to-human communication
(which needs high-quality source and higher bandwidth).
Traditionally, existing technologies like Wi-Fi and GSM
are used to enable M2M communication. These technolo-
gies, centered around high bandwidth, are overkill for
M2M. They also consume excessive power and are there-
fore energy-inefficient in battery-powered applications.
Therefore, in recent years, new standards were devel-
oped for wide-area, radio-based and low-power technolo-
gies that are optimised for low data rates. Usually known
as low-power WAN (LPWAN), these are highly power
efficient. LoRaWAN and NB-IoT are two such competing
standards.
LoRaWAN is already being used in some parts of
the world. The general use cases of LoRaWAN are in
agriculture, where it is used to establish communication
links with sensors installed on the field. In a similar way,
LoRaWAN can be deployed for public utilities like parking
systems in urban areas. Telcos can tap into LoRaWAN by
providing LoRaWAN services to businesses.
Offering value-added and intelligent services
Merging of virtual and physical worlds. Finding our way
from physical to virtual world and vice-versa is a concept
similar to physical web proposed by Google. But, this
approach of Google works in a personal-area network
(PAN) space.
Proximity sensing (ProSe) is based on standards of a
service on top of 4G LTE cellular service that enables two
devices to detect their proximity and exchange data. Some
of the practical use cases are mentioned below.
Finding people. Suppose you are attending a con-
ference and want to know whether anyone from your
LinkedIn network is present there. If you and your links
have ProSe installed on your smartphones, LinkedIn app
will scan the nearby people quickly and pop up on your
phone’s screen the list of people from your LinkedIn
network.
Finding places. Suppose you are in a new city and you
must locate the nearest train station or bus stand to travel
to another part of the city. If every train, bus and public
transport aggregation point in the city consists of a ProSe
enabled device, these can sync up with the ProSe service
of your smartphone to present you with an interactive
application that helps you find your way to the closest
point. Additionally, if you are able to communicate with
those devices, they can present you with information like
train/bus timings.
To sum up
Analytics, control and monitoring make up the highly
obvious IoT use cases. Many jobs are also being generated
due to innovative applications of the IoT. Many beginners
and experienced professionals are taking IoT training
and certification as it promises a lucrative career. A new
wave of collaborative applications is merging the physical
world into our virtual lives, allowing us to make a transi-
tion from physical to virtual, or virtual to physical world,
seamlessly.
52 January 2018 | ElEctronics For you www.EFymag.com
displays
For decades displays have been simply flat pieces of glass or plastic that dic-tated the design of technology. But
recently, engineers and manufacturers have
been coming up with curved screens, more
and more of which can be found on computer
monitors, televisions and phones. Samsung
Galaxy S7 Edge and LG G Flex are among the
devices featuring bendable display.
With bendable display, manufacturers are
looking to advance technology. In fact, flexible
displays have the potential to become one of
the biggest technological breakthroughs in
the decade, encouraging designers to create
devices we have never seen before.
But what exactly is a flexible display and
why do technology majors around the world
see it as the next big thing? Let’s check out.
Bendable does not mean curved
Although curved screens are impressive, these
are not the same as the ones that are bent.
Traditionally, liquid-crystal displays (LCDs)
are sandwiches with materials that include
backlight, polariser, thin-film transistor, liquid
crystals and filter glass. LCDs are usually flat,
but several companies like Samsung have
managed to produce curved LCDs.
The recently released organic LED ecosys-
tem (OLED) has gained popularity, thanks to
its simplified design, better image quality and
flexibility. OLED displays do not require back-
lighting, so these can be thinned and moulded
into specific shapes such as the curved display
on Samsung Galaxy S7. Flexibility, thinness
and excellent image quality make OLED a
better choice for curved screens, and it is clear
that the OLED will overthrow LCD TVs in the
future. However, OLEDs are currently too
expensive to produce for large screens such as
televisionsand computer monitors, but their
prices will eventually fall.
Although LCDs contain more layers than
OLEDs, these screens may still be bent.
Apple Japan Display is developing a 14cm
(5.5-inch), full HD LCD. The display will use
plastic for the substrate, which has tradition-
ally been made of non-removable glass. This
will enable it to flex and bend.
However, engineers need to come up with
a way to create materials that will not break
down under repeated bending stress, keeping
a consistent image on the screen. This is a
huge challenge.
Durability is a huge plus point
The biggest advantage of flexible displays is
durability. Because the screen can be bent
and manipulated, it can also absorb impact
better than solid glass structures we currently
have. So broken screens can be a thing of the
past. However, it will take some time before
we reach that point. It is assumed today that
bendable screens will use plastic instead of
glass, but the plastic itself can still crack under
extreme stress.
Manufacturers like Corning are currently
working on a flexible glass called Willow,
which is planned to be put into everything
from telephones to televisions to carry devic-
es. Willow is as thin as a piece of paper and
can be bent too. But it will still break if it gets
too much rounded up.
Samsung, LG and Apple join the
move
The three largest mobile manufacturers are
reportedly experimenting with flexible dis-
plays. According to Samsung, the most impor-
tant feature of Galaxy X is that its display can
be folded outside, allowing users to convert
Flexible Displays:
A Revolutionary Breakthrough!
Jawaaz Ahmad
is an electronics
enthusiast
with interest
in VLSI design
and embedded
systems
Flexible AMOLED display (Image
courtesy: www.businesswire.com)
Flexible displays, when
they hit the market,
could provide endless
possibilities in design
and innovation
53www.EFymag.com ElEctronics For you | January 2018
their phones into 12.7cm (7-inch) tablets. LG is also said
to have come out with a smartphone that folds outside to
form a tablet. Patent drawings represent a conceptual LG
phone that has a foldable display which can be used even
after bending. Apple is considering the use of bendable
displays on the iPhone in 2018.
Potential applications
Other technologies could also benefit from flexible
displays. For example, flexible displays could be used
as clothing that changes colour or pattern instantly as
per the environment, making these particularly useful
for soldiers.
Phones can also take a new format, similar to the
Lenovo Cplus prototype, which starts as a thin handset
but folds into a wristband. Samsung experimented with
the introduction of curved displays on its original Galaxy
Gear S smartphone, but moved to a more traditional flat,
rounded Galaxy Gear S3. With curved displays, intel-
ligent observers can theoretically have massive screens
that surround their wrist to display even more informa-
tion at once.
Cars could also use curved screens as more and more
dashboards are going digital. For example, Mercedes
E-Class displays infotainment indicators and infotain-
ment data on a 31cm (12.3-inch) HD display that extends
on the dashboard. Tesla and X models have a huge 43cm
(17-inch) central display, but you can use a curved screen
to make the outline look natural on the car’s dashboard.
The biggest challenges
The concept of bent displays is not new, because gadget
manufacturers appear to be displaying them on large
shows like CES (Consumers Electronics Show in Las
Vegas, USA) and MWC (Mobile World Congress in Barce-
lona, Spain) annually, but no one has brought a flexible
display to the market yet. Why?
Since bending the display is difficult, crafting a device
that uses one effectively is even more difficult. In order
to create a flexible product, manufacturers need to know
how to make each component flexible. Batteries are
particularly difficult to bend because current technology
requires batteries to keep their shape. After being bent,
batteries are short-circuited and, if shorted too far in the
housing, can explode.
Both LG and Samsung have been working on a flexible
battery for many years, but the technology is still not avail-
able. So far, the only way to use a curved display is to make
a device that bends on the hinge. This concept works with
the Lenovo Yoga Book, which is equipped with a touch
screen and a touch pad that doubles as a drawing tablet.
With the hinge, device manufacturers can potentially use
fixed batteries and silicon, but add a fold to them.
We are still waiting for the first device to hit the
market, but when it arrives, we can expect durability and
endless possibilities in design and innovation. Over the
last few years, the patterns of phones and tablets have
been outdated, and flexible displays can make them
exciting again.
displays
54 January 2018 | ElEctronics For you www.EFymag.com
sensors
Be it a silent heart attack detector that detects the protein level of a patient or a posture-correcting chair
that alerts the occupant sitting in a wrong
posture—both recently invented by Indian
teenagers—sensors have a vital role to play
in electronic devices. The fact is that the
application of sensors is ever-expanding
along with the progress in science and
technology.
As per industry reports, sensors are
becoming the biggest and fastest growing
markets, comparable with computers and
communication devices markets. You find
sensors in smartphones, automobiles,
security systems and even everyday objects
like coffee makers! Apart from consumer
electronics, these are also an integral part
of the Internet of Things (IoT), medical,
nuclear, defence, aviation, robotics and
artificial intelligence, agriculture, environ-
ment monitoring and deep-sea applications.
The shift to smarter sensors
Basically, a sensor is an input device
that receives and responds to a signal or
stimulus. Nowadays some sensors come
integrated with many sensing elements
and read-out circuitry in a single silicon
chip, providing high accuracy and mul-
tiple functions. Manufacturers use both
advanced technologies and methods for
signal processing and conversion. Modern
sensors have more features including user-
friendliness, accessibility and flexibility.
So there is a paradigm shift in the sensor
industry with integration of new technolo-
gies to make sensors smarter and intelligent.
Ordinary sensors are still used in many
applications. But innovation and advance-
ment in micro-
electronics is
taking sensor
technology to
a completely
new level. The
functionality of
ordinary sensors
has expanded in
many ways and
these now provide a number of additional
properties. Sensors are becoming more and
more intelligent, providing higher accuracy,
flexibility and easy integration into distrib-
uted systems.
Intelligent sensors use standard bus or
wireless network interfaces to communicate
with one another or with microcontrollers
(MCUs). The network interface makes data
transmission easier while also expanding the
system. Manufacturers can diagnose sensor
faults and guide users to troubleshoot them
remotely through the computer network.
An intelligent sensor may consist of a
chain of analogue and digital blocks, each of
which provides a specific function. Data pro-
cessing and analogue-to-digital conversion
(ADC) functionalities help improve sensor
reliability and measurement accuracy. The
typical structure of an intelligent sensor is
shown in Fig. 1.
Common types of latest sensors
There are a wide variety of sensors depend-
ing on the technology (analogue/digital) and
applications. This article covers some of the
latest sensors including IoT sensors, pollu-
tion sensors, RFID sensors, image sensors,
The Latest In
SenSorS And ApplicAtionS
Sani Theo is
technical editor
at EFY
Fig. 1: Intelligent
sensor structure
(Courtesy: www.
mdpi.com)
Marketsize
According to a BBC Research report, the global
sensor market is chasing double-digit growth. It
expects the global market for sensors to reach
$240.3 billion in 2021, up from about $123.5
billion in 2016. Fingerprint sensors will lead the
market by growing at 15.9 per cent annually.
Another source puts chemical sensors,
process variable sensors, proximity and
positioning sensors among the fastest growing
markets. Automotive industry will once again be
the leading consumer market for sensors.
A TechSci Research report says, “India’s
sensors market is one of the fastest growing
markets in Asia-Pacific. Rising security concerns
and growing trend towards miniaturisation are
shifting the focus of consumers to smart devices,
which make extensive use of various sensors, in
particular, touch and image sensors.” The report
projects India’s sensors market to grow at over
20 per cent annually during 2015-20.
Sensitive
element
Intelligent sensor
MCUADC
Network
interface
Signal
process
circuit
The new wave of sensors,
including those used in
IoTs and wearables, are
soon going to revolutionise
electronics industry
55www.EFymag.com ElEctronics For you | January 2018
sensors
biometric sensors, printed sensors,
and MEMS and NEMS sensors.
IoT sensors. IoT sensors include
temperature sensors, proximity sen-
sors, pressure sensors, RF sensors,
pyroelectric infrared (PIR) sensors,
water-quality sensors, chemical sen-
sors, smoke sensors, gas sensors, liq-
uid-level sensors, automobile sensors
and medical sensors. These sensors
are connected to a computer network
for monitoring and control purposes.
Using sensors and the Internet, IoT
systems have wide applications across
industries with their unique flexibility
in providing enhanced data collection,
automation and operation.
The global market for IoT sen-
sors reached $7.3 billion in 2015. It
is expected to reach $47.8 billion in
2021 from nearly $10.6 billion in 2016,
growing annually at 35 per cent during
2016-21. The Asia-Pacific market for
IoT sensors is expected to grow from
$3 billion in 2016 to $14 billion in 2021
at a CAGR of 36.1 per cent from 2016
through 2021.
Pollution sensors. Air pollution
sensors are used to detect and moni-
tor the presence of air pollution in
the surrounding area. These can be
used for both indoor and outdoor
environments. Although there are
various types of air pollution sensors,
most of these sensors focus on five
parameters: particulate matter, ozone,
carbon monoxide, sulphur dioxide
and nitrous oxide. These sensors are
somewhat costly but are becoming
more affordable for common use.
Sensors capable of detecting
particulate matter with a diameter
between 2.5 and 10μm (PM10) and a
diameter less than 2.5μm (PM2.5) are
available in the market. Fig. 2 shows
a typical PM sensor popular among
hobbyists and experimenters. Fig. 3
shows an easy-to-assemble PM2.5
sensor from Sharp Corporation with a
detection time of ten seconds.
RFID sensors. RFID chips (Fig. 4)
as small as the size of rice grains can
be inserted directly under the skin for
use as ID cards. There is a trend to use
RFID chips in many products includ-
ing contactless banks cards and Oyster
cards. There are also cases where chips
are implanted in pets and cattle for
monitoring.
Wearable sensors. These sensors
include medical sensors, GPS, inertial
measurement unit (IMU) and optical
sensors. With modern techniques and
miniature circuits, wearable sensors
can now be deployed in digital health
monitoring systems. Sensors are also
integrated into various accessories such
as cloths, wrist bands, eyeglasses, head-
phones and smartphones. An IDTechEx
report forecasts optical, IMU and GPS
sensors to dominate the sensors market
in terms of revenue by 2022 (Fig. 5).
Wearable applications and IoTs are
expected to drive double-digit growth
in the global market for sensors. Due
to decrease in manufacturing costs and
low power consumption of sensors,
most traditional wired connections
will be replaced with wireless sensors
and integrated into wireless networks
in the future.
Image sensors. The best example of
this sensor is found in your smartphone
camera. An image sensor detects and
conveys the information that consti-
tutes an image. Digital imaging is fast
replacing analogue imaging. Most digi-
tal cameras use CMOS sensors, which
allow faster speed with lower power
consumption.
An image sensor from Renesas is
shown in Fig. 6.
Biometric sensors. The most
common biometric sensor is your
fingerprint module. R30x fingerprint
module is quite popular among hob-
byists and experimenters. The latest
generation of fingerprint sensors from
Qualcomm consists of sensors for
display, glass and metal, detection of
directional gestures, and underwater
fingerprint match and device wake-up.
These sensors are designed as both an
integrated solution with Qualcomm
Snapdragon mobile platforms, and as
standalone sensors that can be used
with other non-Snapdragon platforms.
Qualcomm fingerprint sensors for glass
and metal are likely to reach the market
in the first half of 2018.
Printed sensors. Sensors printed on
flexible substrates are becoming popu-
Fig. 2: PM2.5/PM10 sensor (Courtesy: http://
aqicn.org)
Fig. 3: PM2.5 sensor (Courtesy: www.digikey.com)
Fig. 4: Grain-size RFID chip (Courtesy: https://voiceofpeopletoday.com)
56 January 2018 | ElEctronics For you www.EFymag.com
sensors
lar. The next generation of printed
sensors will enable applications
ranging from human-machine
interfaces to environmental sens-
ing. The IDTechEx report predicts
the market for fully printed sen-
sors to reach $7.6 billion by 2027.
Printed sensors may have a
very simple structure with only
a few electrodes, while others
are much more complex requir-
ing deposition of multiple layers.
What they have in common is the
capability to be manufactured on
plastic substrates, which offer
advantages in terms of mechani-
cal flexibility, thinness and weight
reduction.
MEMS. Microelectromechani-
cal systems (MEMS) are devices
characterised both by their small
size and the manner in which
these are made. These are made
up of component sizes between
1 and 100 micrometres. The most
notable elements are microsensors
and microactuators.
MEMS devices can vary from
simple structures to extremely
complex electromechanical sys-
tems with multiple moving ele-
ments under the control of inte-
grated microelectronics. In other
words, MEMS sensor is a precision
device in which mechanical part
and micro sensors along with a
signal-conditioning circuit are
fabricated on a small piece of
silicon chip.
Generally, MEMS consist of
mechanical microstructures,
microactuators, microsensors and
microelectronics in one package. Fig.
7 shows the block diagram of a MEMS
device.
Microsensors detect changes in
a system’s environment by measur-
ing thermal, chemical, electrical or
mechanical information. These varia-
bles are processed by microelectronics
and then microactuators act according
to the changes in the environment.
Some common types of MEMS sen-
sors available in the market are:
1. MEMS accelerometers. These
are used to measure static or dynamic
force of acceleration. The major cat-
egories are silicon capacitive, piezo-
resistive and thermal accelerometers.
MEMS accelerometers are used
in smartphones for various controls
including switching between land-
scape and portrait modes, anti-blur
capture and pocket-mode operation.
2. MEMS gyroscopes. These detect
the angular rate of an object. MEMS
gyros are used for vehicle stability
control with a steering-wheel sensor
and rollover detection.
3. MEMS pressure sensors. These
sensors measure three types of pres-
sures: gauge, absolute and differential
pressure. The sensor is integrated with
a diaphragm and a set of resistors on
integrated chips so that pressure is
detected as a change in resistance.These sensors are used in automo-
tive, industrial, medical, defence
and aerospace applications. In
automotive systems these are
widely used in oil pressure sensor,
crash detection, fuel-tank vapour
pressure monitoring, exhaust gas
recirculation, engine management
system, etc.
4. MEMS magnetic field sen-
sors. These sensors detect and
measure magnetic fields, and find
use in position sensing, current
detection, speed detection, vehicle
detection, space exploration, etc.
5. Fluxgate sensors. Fluxgate
sensors are used to measure DC or
low-frequency AC magnetic field.
These find many applications like
space research, geophysics, min-
eral prospecting, automation and
industrial process control. MEMS-
based fluxgate sensors score over
other fluxgate sensors owing to
their less power consumption,
small size and better performance.
NEMS. Nanoelectromechani-
cal systems (NEMS) are a class
of devices like MEMS but on the
nanoscale. These are the next
miniaturisation step after MEMS
devices. Nanoresonators and
nanoaccelerometers are examples
of NEMS. Usually, NEMS rely on
carbon-based materials, includ-
ing diamond, carbon nanotubes
and graphene. One of their most
promising applications is the com-
bination of biology and nanotech-
nology. Nanoresonators would
find application in wireless com-
munication technologies, while
nanomotors might be used in nano-
fluidic pumps for biochips or sensors.
Sensor materials
The exact sensor materials depend on
their type and application. For exam-
ple, digital, analogue, proximity and
image sensors have their own materi-
als, structures, fabrication techniques
and packaging. Here we cover materi-
als and fabrication techniques mainly
for the latest sensors like MEMS com-
monly adopted by most manufacturers.
Materials used in electronics can play
an active or passive role. Some materi-
als play both roles.
Passive materials. These are used
Fig. 5: Wearable chart (Courtesy: www.idtechex.com)
Fig. 6: Image sensor (Courtesy: www.renesas.com)
Fig. 7: Block diagram of a MEMS device
57www.EFymag.com ElEctronics For you | January 2018
sensors
phones, satellite communications and
radar systems. The highly sensitive
GaAs piezoelectric sensors are also
used for biological detection.
InSb. It is useful for magnetic
sensing devices such as Hall Effect
sensors and magnetic resistors. InSb
magnetoresistors are used as position
sensors in automotive applications.
InSb materials are also used for infra-
red imaging.
Plastics. Plastics are widely used
in electronic and electrical compo-
nents and assemblies. Since plastics
are insulators, these are used in a
variety of applications where insula-
tion properties are needed. Polymers
are also used as radiation detectors
and chemical sensors.
Metals. Physical properties and
mechanical processing of metals are
taken into account while designing
sensors. Copper has excellent thermal
and electrical properties, but it is dif-
ficult to machine. Aluminium is used
as an alternative in some cases. Metals
are used in magnetic sensors. Precious
metals like gold, silver, platinum, rho-
dium and palladium are widely used
in sensor devices for automobiles,
RFID tags, mobile phones and PCs.
Ceramics. Ceramics are widely
used in sensor fabrication. These
posses common properties includ-
ing structural strength, light weight,
thermal stability, electrical insulation
and ability to bond with other materi-
als. They do not react with oxygen
and thus do not create oxides. Many
manufacturers use ceramics as sensor
substrates.
Sensor fabrication
Microsensor technology uses the basic
fabrication steps followed in conven-
to provide either mechanical structure
or electrical connection. Some of these
materials like silicon and gallium arse-
nide can also be used as active as well
as passive materials.
Active materials. These materials
are essential to the sensing process in
microelectronics, photosensitive, pie-
zoelectric, magnetoresistive and chem-
oresistive films. Microsensor materials
in the form of thin or thick films play
an active role in the sensing system.
These devices are fabricated using
chemical vapour deposition (CVD) or
low-pressure chemical vapour deposi-
tion (LPCVD) and special techniques
like electrochemical deposition.
Silicon. Elemental silicon is not
found in nature, but occurs in com-
pounds like oxides and silicates. Silicon
is abundant, relatively inexpensive and
exhibits a number of physical proper-
ties that are useful for sensor applica-
tion. It is possible to deposit layers of
materials with the desired properties
on a silicon substrate. Single-crystal-
line silicon is the most widely used
semiconducting material.
Polysilicon. Polycrystalline layers
may be formed by vacuum deposition
onto an oxidised silicon wafer with an
oxide. Polysilicon structures may be
doped with boron or other elements by
ion implantation or other techniques to
reach the required conductivity. The
temperature coefficient of the resist-
ance may be changed over a wide
range, positive or negative—through
selective doping. Polysilicon resistors
have a long-term stability.
Other semiconductors. There
is a wide range of compound semi-
conductors available to prepare het-
erostructures with unique properties.
Gallium-arsenide (GaAs) and indium-
antimonide (InSb) are widely used in
electronic components.
GaAs. Gallium-arsenide is used in
devices such as infrared light-emitting
diodes, laser diodes, microwave mono-
lithic integrated circuits (ICs) and solar
cells. It is also used in optical fibre
temperature sensors. A study shows
that some electronic properties of
gallium-arsenide are superior to those
of silicon. Gallium-arsenide transistors
function at frequencies above 250GHz.
Due to the superior properties of
GaAs, these are widely used in mobile
Some key sensor players
 Analog Devices Inc.
 Custom Sensors and Technologies Inc.
 Delphi Automotive PLC
 Infineon Technologies AG
 Omron Corp.
 Qualcomm Technologies
 Siemens Healthcare Diagnostics
 STMicroelectronics
 Vishay Intertechnology Inc.
 Wilcoxon Research Inc.
(Courtesy: https://globenewswire.com)
tional silicon planar IC technique and
some additional steps. At present, com-
plementary metal-oxide semiconductor
(CMOS) is the most common technol-
ogy used in microsensors. Microsen-
sors are designed and fabricated using
commercial CMOS IC processes with
subsequent bulk-micromachining
technology. The exact steps are different
from sensors to sensors.
Encapsulation. The chip must
be protected from the atmosphere.
Photoresist or silicon nitride materi-
als are often used to cover the sensing
area. LPCVD or CVD process is used
to deposit silicon nitride layer, which
acts as a barrier against water. The
next step is IC encapsulation. That
includes sealing the IC in a plastic resin
or metal case. This process protects the
silicon device from the surrounding
environment, and may not be always
required in some MEMS devices where
the atmosphere is used to transmit the
measured quantity.
Deposition. Some sensors, espe-
cially MEMS devices, are required to
deposit thin and thick film materials
providing the sensing surface with
the required properties. For example,
sensitivity to thermal radiation is given
by coating with nichrome. The film can
be locally etched using lithography and
wet chemical etching processes. Dry
physical etching and laser processing
can also be used.
The scope and future outlook
With micro and nano technologies,
sensors can be made to fit almost
anywhere in consumer devices,
robots, automobiles and even human
bodies. Use of intelligent sensors is
also increasing in counter-terrorism,
cargo tracking, biometrics among
other applications. Latest sensors
are used in automobiles to prevent
impending crash and determine the
type of airbags to be fired, and force
and speed of their deployment. The
use of MEMS inmedical applications,
including implantable devices and
handheld devices for diagnostics and
monitoring systems, is on the rise.
Looking forward, with advancements
in technology, the new wave of sen-
sors including IoTs and wearables is
going to revolutionise the electronics
industry in years to come.
imaging
SCREENING
ULTRASOUND
58 January 2018 | ElEctronics For you www.EFymag.com
Image deblurring removes distortion from a blurry image using knowledge of the point spread function (PSF). Image
deblurring algorithms in Image Processing
Toolbox include Wiener, and regularised
filter deconvolution, blind, Lucy-Richard-
son, as well as conversions between point
spread and optical transfer functions. These
functions help correct blurring caused by
out-of-focus optics, camera or subject move-
ment during image capture, atmospheric
conditions, short exposure time and other
factors.
deconvwnr function deblurs the image
using Wiener filter, while deconvreg function
deblurs with a regularised filter. deconvlucy
function implements an accelerated, damped
Lucy-Richardson algorithm and deconvblind
function implements the blind deconvolu-
tion algorithm, which performs deblurring
without the knowledge of PSF. We discuss
here how to deblur an image using Wiener
and regularised filters.
Deblurring using Wiener filter
Wiener deconvolution can be used effectively
when frequency characteristics of the image
and additive noise are known to some extent.
In the absence of noise, Wiener filter reduces
to an ideal inverse filter.
deconvwnr function deconvolves image
I using Wiener filter algorithm, returning
deblurred image J as follows:
J = deconvwnr(I,PSF,NSR)
where image I can be an N-dimensional array,
PSF the point-spread function with which
image I was convolved, and NSR the noise-
to-signal power ratio of the additive noise.
NSR can be a scalar or a spectral-domain
array of the same size as image I. NSR=0 is
equivalent to creating an ideal inverse filter.
Image I can be of class uint8, uint16,
int16, single or double. Other inputs have
to be of class double. Image J has the same
class as image I.
The following steps are taken to read
‘Image_2.tif’, blur it, add noise to it and then
restore the image using Wiener filter.
1. The syntax to read image (Image_2.
tif) into the MATLAB workspace and display
it is:
>> I=im2double(imread(‘Image_2.tif’));
>>imshow(I)
Fig. 1 shows the image generated by
imshow function.
2. h=fspecial(‘motion’, len, theta)
returns a filter to approximate the linear
motion of a camera by len pixels, with an
angle of theta degrees in a counter-clockwise
direction. The filter becomes a vector for
horizontal and vertical motions. The default
value of len is 9 and that of theta is 0, which
corresponds to a horizontal motion of nine
pixels. B=imfilter(A,h) filters multidimen-
sional array A with multidimensional filter
h. Array A can be logical or non-sparse
numeric array of any class and dimension.
Result B has the same size and class as A.
The syntax is:
>> LEN=21;
>> THETA=11;
>> PSF=fspecial(‘motion’,LEN,THETA);
>> blurred=imfilter(I,PSF,’conv’,’circular’);
>>figure,imshow(blurred)
Fig. 2 shows the image generated by
imshow function.
3. J=imnoise(I,’gaussian’,M,V) adds
Gaussian white noise of mean M and
variance V to image I:
>>noise_mean=0;
>>noise_var=0.002;
>>blurred_noise=imnoise(blurred,’gaussian’,
 noise_mean,noise_var);
>>figure, imshow(blurred_noise)
Fig. 3 shows the image generated by
imshow function.
4. As mentioned above, J=deconvwnr
Image ProcessIng UsIng maTLaB:
Image Deblurring And Hough Transform
Part 4 of 4
Dr Anil Kumar Maini
is former director,
Laser Science and
Technology Centre,
a premier laser and
optoelectronics
R&D laboratory of
DRDO of Ministry
of Defence
Varsha Agrawal is a
senior scientist with
Laser Science and
Technology Centre
(LASTEC), a premier
R&D lab of DRDO
Fig. 1: Image read into the MATLAB
workspace
Fig. 2: Image after filtering with multidimensional
filter
Image pre-processing and
identification of certain
shaped objects in the
image is explained here
imaging
SCREENING
ULTRASOUND
59www.EFymag.com ElEctronics For you | January 2018
(I,PSF,NSR) deconvolves image I using
Wiener filter algorithm, returning
deblurred image J. The following com-
mands generate a deblurred image
using NSR of zero:
>>estimated_nsr=0;
>> wnr2=deconvwnr(blurred_noise,PSF,
 estimated_nsr);
>>figure,imshow(wnr2)
Fig. 4 shows the image generated
by imshow function.
5. The following commands gen-
erate a deblurred image using NSR
calculated from the image:
>>estimated_nsr=noise_var/var(I(:));
>> wnr3=deconvwnr(blurred_noise,PSF,
 estimated_nsr);
>>figure,imshow(wnr3)
Fig. 5 shows the restored image
from the blurred and noisy image
using estimated NSR generated from
the image.
Deblurring with
a regularised filter
A regularised filter can be used effec-
tively when limited information is
known about the additive noise.
J=deconvreg(I, PSF) deconvolves
image I using regularised filter algo-
rithm and returns deblurred image J.
The assumption is that image I was
created by convolving a true image
with a point-spread function and
possibly by adding noise. The algo-
rithm is a constrained optimum in the
sense of least square error between
the estimated and true images under
requirement of preserving image
smoothness.
Image I can be an N-dimensional
array.
Variations of deconvreg function
are given below:
• J = deconvreg(I, PSF, NOISE-
POWER)
where NOISEPOWER is the additive
noise power. The default value is 0.
• J = deconvreg(I, PSF, NOISE-
POWER, LRANGE)
where LRANGE is a vector specifying
range where the search for the optimal
solution is performed.
The algorithm finds an optimal
Lagrange multiplier LAGRA within
LRANGE range. If LRANGE is a scalar,
the algorithm assumes that LAGRA
is given and equal to LRANGE; the
NP value is then ignored. The default
range is between [1e-9 and 1e9].
• J = deconvreg(I, PSF, NOISE-
POWER, LRANGE, REGOP)
where REGOP is the regularisation
operator to constrain deconvolution.
The default regularisation operator is
Laplacian operator, to retain the image
smoothness. REGOP array dimensions
must not exceed image dimensions;
any non-singleton dimensions must
correspond to the non-singleton
dimensions of PSF.
[J, LAGRA] = deconvreg(I, PSF,...)
outputs the value of Lagrange multi-
plier LAGRA in addition to the restored
image J.
In a nutshell, there are optional
arguments supported by deconvreg
function. Using these arguments you
can specify the noise power value, the
range over which deconvreg should
iterate as it converges on the optimal
solution, and the regularisation opera-
tor to constrain the deconvolution.
Image I can be of class uint8, uint16,
int16, single or double. Other inputs
have to be of class double. Image J has
the same class as Image I.
The following example simulates a
blurred image by convolving a Gauss-
ian filter PSF with an image (using
imfilter):
1. Read an image in MATLAB:
>> I=imread(‘image_2.tif’);
>>figure,imshow(I)
Fig. 6 shows the image.
2. Create the PSF, blur the image
and add noise to it:
>> PSF = fspecial(‘gaussian’,11,5);
>> Blurred = imfilter(I,PSF,’conv’);
>> V=0.03;
>>Blurred_Noise=imnoise(Blurred,
 ’gaussian’,0,V);
>>figure,imshow(Blurred_Noise)
Note that additive noise in the
image is simulated by adding Gauss-
ian noise of variance V to the blurred
image (using imnoise). Fig. 7 shows
the blurry and the noisy image.
3. The image is deblurred using
deconvreg function, specifying the
Fig. 3: Image generated after addition of
Gaussian white noise
Fig. 4: Deblurred image using NSR of zero
Fig. 5: Restored image from the blurred and
noisy image using estimated NSR generated
from the image
Fig. 6: Image read in MATLAB
Fig. 7: The blurry and noisy image
imaging
SCREENING
ULTRASOUND60 January 2018 | ElEctronics For you www.EFymag.com
PSF used to create the blur and the
noise power (NP):
>> NP=V*prod(size(I));
>> [reg1 LAGRA] = deconvreg(Blurred_
 Noise,PSF,NP);
>>figure, imshow(reg1)
Fig. 8 shows the restored image.
Hough transform
The Hough transform is designed to
identify lines and curves within an
image. Using the Hough transform,
you can find line segments and end-
points, measure angles, find circles
based on size, and detect and measure
circular objects in an image.
In the following example we take
an image, automatically detect circles
or circular objects in it, and visualise
the detected circles.
1. Read the image and display it.
This example uses an image of circles
of various colours:
>> I=imread(‘Image_3.png’);
>>figure, imshow(I)
Fig. 9 shows the image.
2. Determine radius range for
searching circles. A quick way to find
the appropriate radius range is to use
the interactive tool imdistline, which
gives an estimate of the radii of vari-
ous objects.
h = imdistline creates a Distance
tool on the current axis. The function
returns h—handle to an imdistline
object.
Distance tool is a draggable, resiz-
able line, superimposed on an axis,
which measures the distance between
two endpoints of the line. It displays
the distance in a text label superim-
posed over the line. The tool specifies
the distance in data units determined
by XData and YData properties, which
is pixels by default.
If you wrote the following com-
mand in MATLAB, Fig. 9 would
change to that shown in Fig. 10:
>>d = imdistline
The line can be dragged to get the
size of different circles.
In a nutshell, imdistline command
creates a draggable tool that can be
moved to fit across a circle and the
numbers can be read to get an approxi-
mate estimate of its radius.
To remove the imdistline tool, use
the function:
>>delete(d);
3. Consider the image shown in
Fig. 11. The aim is to find the number
of circles in the figure.
Quite evidently, there are many
circles having different colours with
different contrasts with respect to
the background. Blue and red circles
have strong contrast with respect to
the background, whereas white and
yellow circles have the poorest con-
trast with respect to the background.
4. We calculate the objects that are
brighter and those that are darker than
the background. For this, we need to
convert this RGB image into grayscale
version:
>> RGB=imread(‘Image_4.png’);
>>gray_image=rgb2gray(RGB);
>>figure, imshow(gray_image)
Fig. 12 shows the grayscale image.
5. Function centers=imfindcircles
(A,radius) finds circles in image A
whose radii are approximately equal
to radius. The output, centers, is a
two-column matrix containing (x, y)
coordinates of centers of the circles in
the image.
[centers,radii] = imfindcircles
(A,radiusRange) finds circles with
radii in the range specified by radius-
Range. The additional output argu-
ment, radii, contains the estimated
radii corresponding to the center of
each circle in centers.
By default, imfindcircles finds cir-
cular objects that are brighter than the
background. In our case, let us set the
parameter ‘ObjectPolarity’ to ‘dark’ in
imfindcircles to search for dark circles:
>> [centers,radii]=imfindcircles(RGB,
 [40 60],’ObjectPolarity’,’Dark’)
The result of the above command
is:
centers = 384.2814 204.1827
radii = 50.1646
As you can see, only one circle
is detected. This happens because
imfindcircles is a circle detector, and
similar to most detectors, imfindcircles
has an internal detection threshold that
determines its sensitivity. imfindcircles
has a parameter ‘sensitivity’ that can be
used to control this internal threshold,
and consequently, the sensitivity of the
algorithm. A higher sensitivity value
sets a lower detection threshold and
leads to detection of more circles. This
is similar to the sensitivity control on
motion detectors used in home security
systems.
6. By default, sensitivity, which is
a number between 0 and 1, is set to
0.85. Increase sensitivity to 0.9:
Fig. 8: Restored image
Fig. 9: Image of circles of various colours read
and displayed
Fig. 10: Image shown when interactive tool
imdistline is written in MATLAB
Fig. 11: Image with a number of circles
Fig. 12: RGB image in Fig. 11 converted into
grayscale image
imaging
SCREENING
ULTRASOUND
61www.EFymag.com ElEctronics For you | January 2018
>> [centers,radii]=imfindcircles(RGB,
[40 60],’ObjectPolarity’,’Dark’,
’Sensitivity’,0.9)
You will get:
centers =
384.2002 204.0138
248.6127 201.3416
198.2825 73.5618
442.8091 77.9060
radii =
50.1646
50.2572
50.2951
49.7827
By increasing sensitivity to 0.9,
the function imfindcircles found four
circles. ‘centers’ contains center loca-
tions of circles and ‘radii’ contains the
estimated radii of these circles.
7. Function viscircles can be used
to draw circles on the image. Output
variables ‘centers’ and ‘radii’ from
function imfindcircles can be passed
directly to function viscircles:
>>imshow(RGB)
>> h=viscircles(centers,radii)
Fig. 13 shows the result.
As you can see from Fig. 13, cent-
ers of circles seem to be correctly
positioned and their corresponding
radii seem to match well to the actual
circles. However, quite a few circles
were still missed. Let us increase ‘Sen-
sitivity’ to 0.928:
>> [centers,radii]=imfindcircles(RGB,
 [40 60],’ObjectPolarity’,’Dark’,
 ’Sensitivity’,0.98)
centers =
384.2193 204.4776
248.8446 201.4930
197.7027 73.5149
442.9998 78.3674
 76.7218 76.5162
radii =
 50.1646
 50.2572
 50.2951
 49.7827
 50.4039
Now, we are able to detect five
circles. Hence, by increasing the value
of sensitivity you can detect more
circles. Let us plot these circles on the
image again:
>>delete(h); % Delete previously drawn
circles
>>h = viscircles(centers,radii);
Fig. 14 shows the result.
8. As you can see, function imfind-
circles does not find yellow and
white circles in the image. Yellow
and white circles are lighter than the
background. In fact, these seem to
have very similar intensities as the
background. To confirm this, let us see
the grayscale version of the original
image again. Fig. 15 shows the gray-
scale image.
>>figure, imshow(gray_image)
9. To detect objects brighter than
the background, change ‘ObjectPolar-
ity’ to ‘bright’:
>> [centers,radii]=imfindcircles(RGB,
 [40 60],’ObjectPolarity’,’Bright’,
 ’Sensitivity’,0.98)
centers =
 323.2806 75.9644
122.3421 205.1504
radii =
49.7654
50.1574
10. Draw bright circles in a dif-
ferent colour by changing ‘Colour’
parameter in viscircles:
>>imshow(RGB)
>>hBright=viscircles(centers,radii,
 ’Color’,’b’);
Fig. 16 shows the image.
11. There is another parameter
in function imfindcircles, namely,
EdgeThreshold, which controls how
high the gradient value at a pixel has
to be before it is considered an edge
pixel and included in computation.
A high value (closer to 1) for this
parameter will allow only the strong
edges (higher gradient values) to
be included, whereas a low value
(closer to 0) is more permissive
and includes even the weaker edges
(lower gradient values) in compu-
tation. Therefore, lower the value
of EdgeThreshold parameter, more
are the chances of a circle’s detec-
tion. However, it also increases the
likelihood of detecting false circles.
Hence, there is a trade-off between
the number of true circles that can
be found (detection rate) and the
number of false circles that are found
with them (false alarm rate).
Following commands detect both
the bright and the dark objects and
encircle them:
>>[centersBright,radiiBright,metricBright]
=imfindcircles(RGB,[4060], ‘ObjectPolarity’,
’bright’,’Sensitivity’,0.9,’EdgeThreshold’,
0.2);
>>imshow(RGB);
>> h=viscircles(centers,radii);
>>hBright=viscircles(centersBright,
 radiiBright,’Color’,’b’);
Fig. 17 shows the output image.
Concluded
Fig. 13: Circles drawn usingfunction viscircles
Fig. 14: Replotted circles
Fig. 15: Grayscale version of the image
in Fig. 14
Fig. 16: Bright circles drawn in a different colour
Fig. 17: Both the bright and the dark objects
detected and encircled
tech focus
62 January 2018 | ElEctronics For you www.EFymag.com
Some define a smart city as a city studded with sensors, which collect information to help manage the city’s assets and
resources efficiently. Others say it is the use of
information and communication technology
(ICT) to transform life and working environ-
ments within a region.
But, the Indian government’s Smart Cities
Mission website probably says it best: “There
is no universally accepted definition of a
smart city. It means different things to differ-
ent people. The conceptualisation of smart
city, therefore, varies from city to city and
country to country, depending on the level
of development, willingness to change and
reform, resources and aspirations of the city
residents. A smart city would have a different
connotation in India than, say, Europe. Even
in India, there is no one way of defining a
smart city.”
Largely, a smart city infrastructure aims
to make life easier and safer for citizens. It
provides basic facilities for housing, health-
care, sanitation, food, commutation and
communication; reduces pollution; improves
sustainability and supply of energy; and fos-
ters business and economic welfare in general.
However, what goes into a particular region’s
infrastructure and the priority accorded to
each element is very region-specific. While
a system that helps to accurately display the
arrival time of city buses at each bus stop
might be smart in a city, a good toilet might
be smart in a remote village, and a method of
protecting dwell-
ers from wild ani-
mals might be the
ultimate tool for a
tribal settlement in
the forest! Merely
embedding technol-
ogy across a city’s
functions makes the
city intelligent. The
city becomes smart
only when this tech-
nology meets the
citizens’ demands
and improves their
quality of life.
In the journey
from mere intel-
ligence to real smartness, technology is
just a tool—and at different points of time,
various technological products like sensors,
cameras and drones, mobile devices and
apps, data centres, networks and software
appear and disappear from the scene. It is
therefore difficult to describe one particular
end-to-end solution and say this is the per-
fect smart city infrastructure. Depending on
the local needs, city planners need to pick
and stitch together the tools that would
work for them.
IoT and open data policies
at the core
The Internet of Things (IoT) definitely helps
make a city smart. Innumerable sensors,
mobile devices and video cameras, embed-
ded across the city’s infrastructure and con-
nected over a reliable communications back-
bone, collect data about everything from
traffic to pollution. This data is analysed to
extract useful information, which, in turn,
is used to implement effective city manage-
ment systems, ranging from efficient waste
collection to traffic signal management. This
information enables automation, disaster
prevention and recovery, efficient supply
and consumption of utilities like water and
power, and more.
To be effective, this IoT infrastructure
needs to be supported by an apt open data
policy to enable universal access and use of
the collected data without duplication. Gov-
ernment agencies can also authorise private
How Smart Can Your City Get
Janani
Gopalakrishnan
Vikram is a
technically-qualified
freelance writer,
editor and hands-
on mom based in
Chennai
Let citizens have a say
in the development of
a smart city (Source:
Economist Intelligence
Unit and Phillips
Lighting, 2016)
Key infrastructure elements
of a smart city in India
1. Adequate water supply
2. Assured electricity supply
3. Sanitation, including solid waste management
4. Efficient urban mobility and public transport
5. Affordable housing, especially for the poor
6. Robust IT connectivity and digitalisation
7. Good governance, especially e-governance
and citizen participation
8. Sustainable environment
9. Safety and security of citizens, particularly
women, children and the elderly
10. Health and education
Source: Smart Cities Mission, Government of India
Cities are becoming
smart all over the
world, including India,
by using technology
in various ways
63www.EFymag.com ElEctronics For you | January 2018
explore places and more. It is only fair
then that people are considered one
of the main resources of a city’s smart
infrastructure!
Industry majors like Cisco, IBM,
enterprises to access such databases in
order to get the most out of the data
in a profitable way. For example, a
private company developing a traffic
management system can be allowed
to access data collected by the exist-
ing infrastructure, for a fee, instead
of having to redo the whole thing.
This not only turns the government’s
investment profitable but also makes
the infrastructure more streamlined
without too much duplication.
A Gartner report adds one more
important element to this frame-
work—people. According to Gartner,
people themselves will become nodes
on the Internet, with both static
information and a constantly emit-
ting activity system. Today, there are
multiple apps that use crowd-sourced
information to make better buying
decisions, avoid traffic congestion,
A smart city improves every sphere of life, from environment to education (Source: Deloitte)
Components of a
smart city
1. Connected devices like sensors,
kiosks, cameras, lights, traffic signals,
waste bins and what not
2. A reliable, efficient and secure network
that connects everything together
3. Smart and open data management
systems for collection and analysis of
data from the devices
4. Applications that put this information
to good use
5. Processes that streamline the
collection, analysis and use of data by
different systems
tech focus
tech focus
64 January 2018 | ElEctronics For you www.EFymag.com
Nokia, Philips, Intel, Schneider Elec-
tric, Siemens, Microsoft, Hitachi,
Huawei, Ericsson, Toshiba and Oracle
have dived headlong into the smart
city opportunity. Some companies
specialise in a particular area, while
others provide end-to-end solutions
covering the whole gamut of technolo-
gies and systems. There are also innu-
merable start-ups providing solutions
to specific needs of smart cities.
Trip to some of the smart cities
Apart from some of the districts in
USA and UK, Aarhus, Amsterdam,
Cairo, Lyon, Malaga, Malta, Verona
and the Songdo International Business
District near Seoul are among regions
that have become appreciably smart
in many ways in recent years.
Reducing pollution
through better traf-
fic management. Las
Vegas uses its smart
city infrastructure to
manage traffic, environ-
mental pollution and other
issues. Let’s take the example
of its traffic signals: If your car
is waiting at a signal and there are
no approaching vehicles in sight,
the signal turns green rather than
making your car wait and exhaust
more fumes.
Singapore has been implementing
different solutions for traffic manage-
ment since 2014. One among them is
a GPS-powered solution that empow-
ers citizens with traffic and roadwork
information collected from surveil-
lance cameras installed on roads and
taxis. The system also has features like
traffic news, travel time calculator,
road maps, street directions and park-
ing information. Surveillance cameras
alert authorities and vehicle recovery
services to road incidents.
Understanding the cause of
accidents. On a particular roadway
in Jaipur, there were about 4000
accidents annually. The city authori-
ties installed IoT sensors and video
cameras to discover the reason. They
found that 70 per cent of the accidents
happened because drivers went down
the road the wrong way.The police
used this information to set up sign
boards and take other steps to sig-
nificantly reduce the number of acci-
dents. Sensors in the city also provide
information on pollution, availability
of parking spots, etc.
Supplementing the city’s energy
resources. More than 6000 Vien-
nese citizens have invested in
community-funded solar and wind
power plants in the last five years.
Together, these have produced about
25 million kWh of renewable energy,
powering almost 15,000 households.
Cities across the world are also
using smart grids and meters to save
power and augment user-contrib-
uted power like solar power. Smart
meters help users to study their
consumption patterns
and avail offers like
reduced rates for
consumption
during off-peak hours. While this
helps users to save money, the utility
is able to conserve power.
Conserving another precious
resource—water. Many regions like
Berkeley County and Fountain Valley
in USA have installed smart water
networks to meet water conserva-
tion goals. Beyond just remote meter
readings, these systems comprising a
FlexNet communication system and
residential and commercial meters are
used to study and understand usage
patterns, detect and prevent leakage,
and empower consumers to optimise
their usage.
The water utility in Little Egg
Harbour, a small town in New Jersey,
uses technology in a different way.
Residents of this town leave during
winter and return only when the
weather is warm enough. During
these cold months, however, the water
freezes and pipes tend to break. Using
technology from Sensus, the commu-
nity’s municipal utilities authority can
monitor residents’ homes and quickly
respond to problems. This earns them
their customers’ trust.
Some cities have also started using
solutions like WeatherTRAK to opti-
mise their water usage for landscape
irrigation. This system uses an IoT
machine-to-machine solution and
sensors to assess atmospheric and
geologic factors and supply just the
needed volumes of water instead of
constantly dripping water.
Santander in Spain has deployed
IoT tracking with a smartphone app,
which enables residents to view
real-time data on water quality and
consumption, track trends over
time and receive service alerts.
The IoT tracking system pro-
vides information about
water demand, supply,
pressure, quality and
other environmental
factors, enabling effi-
cient water supply and
conservation and sustain-
able management.
Getting ready for smart waste
collection. The Spanish city of Gra-
nada is in the process of connecting
14,000 waste bins across the city
using sensors. The data collected will
be used to identify the bins that need
to be emptied, and to optimise pick-
up truck routes accordingly. The IoT
City Digital Platform in Denmark also
includes intelligent waste monitoring
using sensors fitted by SmartBin. The
Smart City Framework developed by
the Sunshine Coast Council in Aus-
tralia also includes waste manage-
ment using Enevo’s smart fill sensors.
Making sewers smarter too.
Cincinnati, USA, has a smart sewer
that reduces the overflow of sewage
into water bodies. This is a task that
normally consumes millions of dollars
of the taxpayers’ money! The smart
sewer system responds to peaks and
IoT infrastructure and mobile apps will let you
identify and book parking spots in a smart city
(Source: GetMyParking)
65www.EFymag.com ElEctronics For you | January 2018
troughs in demand from various areas
of the city. It enables the utility to
store sewage flows in huge interceptor
facilities located in various parts of the
sewer system, with smart sensors used
to detect and monitor flow levels and
manage the gates and valves to direct
the flow to locations with sufficient
space. Within a few weeks, the system
developed by Ayyeka helped the city
to avoid 1.4 million gallons of sewer
overflows.
Improving safety through reliable
lighting. Street lighting is important
to ensure safety. At the same time,
the usage has to be optimised to save
power. To balance these require-
ments, many cities are now installing
IoT-connected and energy-efficient
light-emitting diodes (LEDs) for
street lighting. These lights can be
centrally operated and managed using
intelligent software, powered using
alternative energy supplies, or even
made smart enough to detect human
movement and switch off when there
is nobody on the street!
Amsterdam in the Netherlands is
working with Philips to install con-
nected LED lights that can save a city
up to $13 billion a year. Santander is
also rolling out intelligent LED lights
that dim or brighten depending on
the time of day and the presence of
people. These can save around $1.5
million a year.
Smart products used by smart
cities across the world
All over the world, interesting solu-
tions are sprouting to cater to the
needs of smart cities. Let’s look at
some of the promising ones.
To navigate in a smart city, citizens
and visitors need the Internet. But,
what if you cannot afford mobile data
(which is steeper on roaming)? To solve
this problem, a Malaysian company
called Simplify has developed an app
that lets users sell excess bandwidth.
Using this app, you can turn your
Android smartphone into a secure
hotspot, set a price to share it and sell
to others. You can receive payments
immediately through PayPal. This
ability to buy spare data from others
around them has proven to be very
convenient, especially for tourists.
Non-stop communications is one
of the highlights of a smart city. Any
solution that can take connectivity to
remote areas or augment the existing
communication networks in busy
areas is always worth including in
a smart city framework. AT&T has
developed a drone that provides LTE
coverage to customers. It can be used
to provide connectivity when the
existing networks and services are
likely to get overloaded or disrupted.
AT&T’s Cell on Wings (fondly
called Flying COW) is basically a cell
site on a drone, designed to beam LTE
coverage from the sky to customers
on the ground during disasters or big
events. The drone carries a small cell
and antennae and is connected to the
ground by a thin tether. The tether pro-
vides a highly secure data connection
via fibre and supplies power to the
Flying COW, allowing non-stop flying.
Shanghai saw a 30 per cent drop in
crime rates, thanks to its smart secu-
rity solutions. To get there, a smart
Aerial photography can be fruitfully used for surveillance, surveys, mapping, and more (Source: Airpix)
tech focus
tech focus
66 January 2018 | ElEctronics For you www.EFymag.com
city needs proactive surveillance,
not merely security cameras that
let authorities to analyse the scene
after a crime takes place. Deep Glint
is a solution that uses 3D imaging to
monitor large crowds and the way
people on the scene behave. When the
smart cameras spot a fight, unusual
behaviour or doubtable characters,
these instantly alert the concerned
authorities.
ShotSpotter is another such safety
solution. Although gunfire might be
something we see only in movies,
there are some areas where it is an
everyday threat. However, the atmos-
phere in such areas is shrouded
with fear and people hide as soon as
gunshot is heard rather than report it
immediately. Solutions like ShotSpot-
ter or a network of sound sensors
embedded in street lights can be used
to report the incident immediately to
concerned officials.
Bigbelly offers a smart waste collec-
tion and recycling system that has been
used in more than 50 countries across
the globe. It is not merely an IoT-con-
nected bin but also has a built-in solar-
powered waste compacting system that
enables the bin to store up to five times
the amount of waste as a traditional bin
of the same size. When it needs to be
emptied, the bin alerts the appropriate
city department, helping timely waste
clearance and properoptimisation of
pick-up truck schedules.
Another off-beat initiative in waste
management is Zerocycle—a solution
that collects and analyses garbage and
recycling data to determine recycling
rates for all neighbourhoods in a
city. This information can be used to
prepare customised waste reports for
each neighbourhood, which can be
circulated among residents. Although
it sounds like a simple application, it
has been found to be useful in creating
awareness about recycling.
Citymapper is a solution that
helps travellers to move around com-
fortably in a new place. It combines
information about the locality’s public
transport and provides multi-modal
transport options to help users get to
their chosen destination easily.
Searching for an available parking
lot not only kills your precious time
but also causes more pollution as
you keep circling the neighbourhood!
ParkWhiz app helps you find a park-
ing spot in public or private parking
lots. It even lets you reserve a paid slot
using your credit card.
Cities need actionable information
on sources of pollution in order to take
corrective and preventive measures.
EverImpact is a climate monitor-
ing app that discovers the origins of
greenhouse gas emissions in a city.
It measures and monetises the city’s
carbon dioxide emission by mapping
ground-level sensor data with satellite
locations. City officials get a real-time
Oizom’s ambient air quality monitoring system and app help officials and residents stay updated about
pollution levels in their area (Source: Oizom)
map of emissions at street and build-
ing level.
A successful city needs to be inclu-
sive, providing a comfortable environ-
ment for those with disabilities. GPS-
enabled mobile app BlindSquare is a
successful digital service developed
from open data in Helsinki. It helps
visually-impaired people navigate
through the city by describing the
environment, announcing points of
interest and street intersections, guid-
ing them as they go along.
Awesome Indian products
for smart cities
The Indian government’s 100 smart
cities dream has also spurred a lot of
activity in India. The government has
made it clear that this dream can be
achieved only through public-private
synergy. Although there is not much
information about what the first 20
chosen cities are doing with their
funding, we do hear of random smart
developments every day—whether
it is a partnership between ISRO and
Indian Railways to improve safety, a
single dashboard for India’s power
sector, a system that will speed up tray
clearance at the Delhi airport, SMS
notifications about delayed trains,
increase in digital transactions, tools
to speed up Aadhaar verification, or
an upcoming drone policy. The start-
up economy is also buzzing with new
ideas and ventures.
GetMyParking is a Delhi-based
start-up that gathers data from park-
ing lots, helping citizens spot and
reserve parking. IdeaForge provides
solutions for drone-based safety and
surveillance, while Flamencotech
works on technology for smart build-
ings and Oizom Instruments develops
IoT-based environment monitoring
solutions. WeDoSky also works with
drones but it customises the intelli-
gence gained from the aerial images
for varied purposes like security,
irrigation, power lines installation
and prediction of an area’s solar
power potential. Smart Cities Wheel
is another Indian start-up that helps
urban planners to design more
efficient cities using artificial intel-
ligence.
Esyasoft Technologies offers soft-
ware and analytics for smart grids,
67www.EFymag.com ElEctronics For you | January 2018
while Maven Systems specialises in
automated lighting and smart meters.
There are some start-ups with even
bigger ideas. One among them is
Quenext, which aims to consolidate
and analyse data from innumerable
systems ranging from weather to
power, to help utilities optimise their
supply and reduce losses. LoudCell
develops IoT-based sensors, remote
hardware and cloud-based mid-
dleware, which are coupled with
an intuitive dashboard to provide
customers with analytics and intelli-
gence to understand and reduce their
power consumption.
A low-cost smart irrigation con-
troller from FlyBird Farm Innovations
helps farmers to irrigate their crops
precisely, depending on weather, soil
conditions and crop requirements.
One more interesting solution for this
sector comes from TartanSense, which
aims to use unmanned aerial vehicles
and machine learning to bring action-
able intelligence to the agricultural
sector.
Zippr is a Telangana-based com-
pany that creates eight-digit alpha-
numeric codes to replace traditional
door numbers. These unique IDs are
mapped to precise locations overlaid
on a digital map. This fundamentally
transforms how locations are refer-
enced, shared and navigated. Zippr
won the IBM Smart Camp for Smart
City 2016, and is working with the Tel-
angana government to implement this
smart address system in Hyderabad.
Taxi services like Ola and Uber are
playing their part in building smart
cities by providing innovative ride
options, including sharing and shut-
tle services. These bring down the
cost of rides, improve commute facili-
ties and reduce pollution through
car-pooling.
Programmes such as the AIM
Smart City Accelerator provide men-
torship, guidance and planning sup-
port for start-ups and other agencies
working towards the smart city dream!
Opportunity is knocking
at our doors
McKinsey Research projects the smart
city industry to be a $400 billion
market by 2020, with 600 cities world-
wide, which are together expected to
generate 60 per cent of the world’s
GDP by 2025.
A Forbes article by Mohit Kochar
of KPIT Technologies explains how
smart cities are India’s next technol-
ogy opportunity to lead the world. He
states rapid urbanisation, excellent
ecosystem, manpower and tech prow-
ess, the third largest start-up base in
the world and a reputed brand image
in information technology as reasons
why we are well poised to capitalise
this opportunity.
Clearly, there is no dearth of tech-
nologies required for smart cities in
India too. However, we need to focus
on proper planning and infrastructure
development. The investment also
needs to be thoughtful and transpar-
ent. It is estimated that the first 100
smart cities in India will require an
annual investment of ` 350 billion
over the next 20 years! This can simply
not be achieved without private
investments and public-private part-
nerships. There must also be excellent
collaboration between central, state
and local authorities.
Private and government agencies
must also understand that such cities
cannot be built without the participa-
tion of people. This is being reiterated
time and again by experts in the field.
People come in at the very beginning
of the process—because solutions for
a smart city have to be built around
what people need and not merely
what other cities have done! The
residents of a city have to be involved
all through the processes of conceptu-
alisation, planning, development and
implementation.
The smart city infrastructure must
also be easy for people to use. For
example, we need to remember that
connectivity is poor, so implement-
ers have to think about how to work
around it. Literacy levels being low,
you cannot expect everybody to type
in passwords or fill in online forms.
Methods like facial recognition or
biometrics have to be used to author-
ise individuals and validate data. In
such and many other ways, govern-
ment officials have to ensure that
people can transition smoothly to this
connected world—because, whether it
is in 2025 or later, cities are inevitably
going to get smarter!
tech focus
68 January 2018 | ElEctronics For you www.EFymag.com
Green technoloGy
“Of all the forces of nature, I should think
the wind contains the largest amount of
motive power—that is, power to movethings. Take any given space of the earth’s
surface—for instance, Illinois; and all the
power exerted by all the men, and beasts,
and running-water, and steam, over and
upon it, shall not equal the one hundredth
part of what is exerted by the blowing of the
wind over and upon the same space. And
yet it has not, so far in the world’s history,
become proportionally valuable as a motive
power. It is applied extensively, and advan-
tageously, to sail-vessels in navigation. Add
to this a few windmills, and pumps, and
you have about all. ...As yet, the wind is
an untamed, and unharnessed force; and
quite possibly one of the greatest discoveries
hereafter to be made will be the taming and
harnessing of it.”
—Abraham Lincoln
Globally, there is a huge emphasis on encashing the energy generation pos-sibilities of renewable sources, espe-
cially wind. Wind power offers a sustainable
option in the pursuit of renewable energy. In
this article we explore how wind energy is
being utilised in different parts of the world.
A case study from Canada
Wind power promises to be more beneficial
than any other existing source of energy. It
doesn’t produce any undesirable and harm-
ful waste, harnesses the power of nature
(wind), and is one of the best alternatives
to burning of coal/gas or use of nuclear
energy.
The Wolfe Island Wind Project in Canada
aimed at meeting electricity needs of resi-
dents in Kingston, Ontario, through wind
power. As part of the project, 86 turbines
were placed in the wind farm with an invest-
ment of around 410 million dollars to gener-
ate sufficient electricity for 75,000 homes.
The returns for the same were spread over
20-25 years.
Costs and benefits. Turbine generators
for the project cost 1500-2000 dollars per
kilowatt. Using 86 turbines of 2.3MW capac-
ity with a total cost of 410 million dollars, the
project cost a little more than 2000 dollars
per kilowatt.
The wind power cost eight cents to 10.2
cents per kilowatt hour, which was much
higher than the actual electricity price in
Canada (1.2 to 7.8 cents per kilowatt hour,
depending upon the location). On adding
Wind PoWer: The Global Impact
Sanjay Banerjee is a
tech enthusiast and
a senior business
leader at EFY. He is
passionate about
how businesses
can benefit from
technology
Decision Makers’ Connect
Nidhi Arora is
executive editor
at EFY
70 January 2018 | ElEctronics For you www.EFymag.com
Green technoloGy
other costs like admin, marketing and
distribution, it came to a total of 3.2
to 11.8 cents.
The above calculation led to a
conclusion that wind power comes
with a premium price. To overcome
price limitations, the Canadian gov-
ernment provided some subsidies
and incentives like one per cent of
tax benefit per kilowatt hour (kWh)
of electricity produced using wind
power.
Thus it can be concluded that wind
power still has a long way to go before
mass adoption as the turbine cost has
to come down. Not all governments
can afford such a technology.
The case for India
India was among the first few coun-
tries in the world to establish the Min-
istry of New and Renewable Energy
(MNRE). In the last two decades, the
country has witnessed unprecedented
growth in its wind power generation
capacity from about less than 1GW
(gigawatts) to more than 32.72GW
till October 2017. India has the fourth
largest installed wind power genera-
tion capacity in the world.
Of the total installed capacity for
renewable energy generation, wind
power accounts for about 10 per cent.
It is seen that two-thirds of production
happens between May to September
months, coinciding with Monsoons.
One of the major reasons behind the
increase of wind power through the
years has been the benefit of acceler-
ated depreciation for businesses.
The levelised tariff for wind power
reached an all-time low of
` 2.64 per kWh during bid-
ding for various wind power
development projects in
October 2017. Previously,
the bid rate was ` 3.42 per
kWh in August 2017 in an
auction by TANGEDCO
(Tamil Nadu Generation
and Distribution Corpora-
tion).
The MNRE has set a
target of producing about
60,000MW of wind power
by the year 2022. To achieve
this ambitious target, the government
plans to enter into offshore wind
power generation. It plans to set up
the first plant along the Gujarat coast.
To conclude
At the end of 2006, worldwide capac-
Fig. 1: Evolution of the Indian wind sector (Source: Ministry of New and Renewable Energy (2015b))
Fig. 2: Renewable energy capacity additions and share of wind (Source: Central Electricity Authority
Report—Growth of Electricity Sector in India 1947-2013, FY 14 values as per MNRE)
ity of wind-powered generators was
73.9GW. Although it is believed that
wind power presently produces a
little above one per cent of world’s
electricity demand, it contributes
around 20 per cent in Denmark,
about 9 per cent in Spain and roughly
7 per cent in Germany. Around the
world, wind power generation more
than quadrupled between 2000 and
2006. There are many thousands of
wind turbines operating, with a total
capacity of 73,904MW, of which
Europe accounts for 65 per cent
(2006).
The most amazing part of wind
power generation is no greenhouse
gas emission. However, to derive the
maximum benefit, wind power pro-
jects should be undertaken with long-
term planning. To justify the heavy
investment and variable output, these
must be combined with other renew-
able technologies like reservoir-based
hydro and gas plants.
Fun Fact!
Most wind energy comes from turbines
that can be as tall as a 20-story building
and have three 60-metre-long blades.
Smaller turbines erected in a backyard
can produce enough electricity for a single
home or small business.
Why do we need Wind Turbines?
• Wind power helps combat climate
change and reduce reliance on fossil fuels.
71www.efymag.com electronics for you | January 2018
smart world
77 Kolkata Municipality
Benefits From Solar
Streetlights
72 Streetlighting: Should
States Invest In Solar?
71 Aadhaar-Enabled
Biometric Attendance
System
76 Mission 2030: Where Does
India’s EV Ecosystem Stand?
 Government buildings need multiple Aadhaar-enabled
biometric attendance systems at their entry gates
Powered By
Powered By
System Level Solutions
Research | Design | Development | Manufacturing
Aadhaar-Enabled Biometric
AttendAnce system
Aadhaar-enabled UID kit (Image source: http://www.uid-aadhaar.com)
The market for Aadhaar-enabled devices is about ` 2.5 billion. The opportunity to cater to new
as well as replacement systems is tre-
mendous. While we as a nation con-
template opportunities for Aadhaar,
global leaders like Satya Nadella are
quite optimistic and excited about the
possibilities that it will enable.
In his book Hit Refresh, Nadella
mentioned, “Aadhaar now has scaled
to over one billion people, rivalling
the growth of other platform innova-
tions such as Windows, Android or
Facebook.” He praised creation of
the new digital ecosystem IndiaStack.
IndiaStack is a set of application
programming interfaces (APIs) that
allows governments, businesses,
startups and developers to utilise
a unique digital Infrastructure to
solve India’s problems of presence-
less, paperless and cashless services
delivery.
Recently, central government has
mandated all government institutions
to adhere to Aadhaar-enabled bio-
metric attendance system (AEBAS).
The main intent behind the move is to
increase productivity of employees.
The system authenticates attendance
using Aadhaar number created by
Unique Identification Authority of
India (UIDAI).
Business opportunity
Till date, only 10 per cent government
organisations have started marking
attendance on AEBAS. Most govern-
ment organisations look forward to
inviting bid proposals and choose the
best suited option for AEBAS. They are
looking for reliable vendors to provide
a completesolution for enforcement.
Presently, various companies are
offering Aadhaar kits, but there is still
a huge potential for new players to join
the course. Matrix offers Cosec Vega
Faxq, which is designed for Aadhaar-
enabled attendance marking. It is
perhaps the only embedded Linux-
based attendance device available
in the Indian market as of now. The
system user can directly show RFID
card, that is Mifare Smart, and provide
fingerprint.
Benefits of a cloud-based
attendance system
The Indian government has decided
to go for a robust and centralised
attendance management system that
offers easy access, easy scalability
and uniformity in architecture while
costing less.
To avail these benefits, the con-
cerned government organisation
will have to register with the AEBAS
server. Employees’ attendance on
AEBAS server will be linked with
UIDAI server. Attendance will be
taken using the user’s unique Aadhaar
number and biometric credentials.
Authentication process. Compa-
nies like Braintech Services provide
iris and fingerprint scanners as part
of their UID kit. Ravish, managing
director of Braintech Services, shares,
“Being a provider of biometric attend-
ance solutions, we foresee AEBAS to
emerge as the biggest opportunity
in the segment ever. All government
organisations are adopting the system
as they are getting the required infra-
structure as soon as they get clearance
from the concerned nodal officer.”
smart world
72 January 2018 | electronics for you www.efymag.com
Powered By
Security
A substantial amount of energy and
resources is being spent on educating
employees that there is no leakage of
private information in confirming their
identity through Aadhaar. When an
individual authenticates his identity using
the Aadhaar-linked biometric system,
the vendor is not provided with any
information. Only the fingerprint proof is
validated for the entered Aadhaar number
by matching it with the one stored in
the Aadhaar server. It is only one-way
communication.
Daman Singh, managing director
of MindTech Solutions, adds, “Govern-
ment buildings are looking to install
multiple systems at their every entry
gate. Kits are being retailed at 60,000
to 70,000 rupees per unit to organisa-
tions, generating up to 40 per cent
profit for the vendor.”
The investment required
“The business investment isn’t a
major concern, it is about getting
your system approved and registered
with UIDAI for AEBAS usage by the
government body. Once that is taken
care of, one may begin with an initial
investment of approximately three
million rupees. However, the invest-
ment cost varies depending on a lot of
factors like the quality of product, the
inventory to be maintained, whether
the land infrastructure is owned or
rented, etc,” adds Daman. “I person-
ally feel that vendors who have an
experience in dealing with biometric
attendance systems will definitely
have an edge.”
There are various devices that sup-
port AEBAS, and different organisa-
tions are choosing to install different
systems ranging from desktops to
laptops.
Adaptation elements
“Government organisations and
employees need to register them-
selves on attendance.gov.in. This is
an online platform created by central
government whereby we can see real-
time attendance data of government
bodies. Once they have registered,
they just need to install any biometric
device of their choice and provide con-
nectivity either through Wi-Fi, LAN,
PoE (power over ethernet) or mobile
broadband. These devices can then
communicate with the central server,
that is AEBAS. So the process is simple
yet efficient,” shares Het Vaghela of
Matrix.
Road ahead
Government organisations with over
210 million employees offer immense
growth potential. At the same time,
solution providers are optimistic about
use of AEBAS in private organisations
as well. The initiative is drawing
encouragement from various stake-
holders as it is a part of Digital India
initiative.
—Nidhi Arora, executive editor, EFY
Streetlighting:
Should States
Invest In Solar?
 In areas where cabling and
grid power maintenance
might be a challenge,
investing in solar streetlights
is a good option
The call for energy-efficiency has been stronger than ever, and states like Delhi are steer-
ing the drive right from the streets.
AC mains-driven LED streetlights are
great as low-cost power savers. On
the other hand, those who intend to
move away from drawing grid power
altogether, should consider investing
in solar LED streetlights. There are
options to ensure optimal returns from
streetlighting setups, some of which
we explore here.
AC mains-driven LED
streetlights: Quick returns
The initial investment in LED tech-
nology is higher but it guarantees at
least 50 per cent more energy savings
than conventional fluorescent lights
that dominated the market until
recently.
A single LED streetlight setup costs
between ̀ 2000 and ̀ 5000 depending
on a number of factors, including the
LED lumen output, wattage, compo-
nent quality and cabling. Luminaires
of the LED setup generally cost ̀ 30-40
per watt, so power requirements of the
user play a major role in determining
the end product’s cost. For example,
while a 12W system may cost around
` 850, a 40W luminaire can cost up to
` 2500. Additional expenses include
cables for AC mains connection, pole
for installing the luminaire and instal-
lation charges. If the luminaire can be
mounted on a wall, there is no need
for the pole.
In areas with stable power avail-
ability, state governments can expect
a quick return on their investment
in AC mains-driven streetlights.
An executive from Electropower,
a Faridabad-based LED streetlight
Solar LED streetlights
smart world
74 January 2018 | electronics for you www.efymag.com
manufacturer, explains, “An 80W flu-
orescent light with a choke and other
components will consume around
120 watts. This fluorescent light
can be easily replaced with a 40W
LED streetlight producing equal or
brighter light. The replacement cre-
ates an offset energy of 120-40=80W,
that is, each replaced LED streetlight
can save 80W energy per day with no
other running expenses throughout
the life of LED streetlights.”
Dr Kushant Uppal, founder and
CEO, Intelizon Energy, believes that
ROI in AC mains-driven LED street-
lights can be recovered in two years.
Ankit Bajpai, executive director,
EPC, Trisun Sant India, shares the
example of 50W AC LED streetlights
installed by them. These streetlights
cost them ` 2500 per unit with addi-
tional cost of the poles and cables.
They were able to recover the invest-
ment cost in one year through electric-
ity bill savings.
What are the benefits?
LED streetlights save a massive
amount of energy while greatly
reducing carbon emission. For
example, the Indian government’s
Streetlight National Programme
(SLNP) for installing LED streetlights
throughout the country has already
resulted in a total of 1172-tonne
carbon dioxide emission reduction
and 1.4 million kilowatt-hour energy
savings annually.
LED streetlights can run up to
50,000 hours, which ensures a life
expectancy of at least ten years.
Moreover, there are no maintenance
problems. LED drivers, if properly
manufactured with correct quality
control, will run their full life without
glitches. As no batteries or extra acces-
sories are required, operational cost
is nil throughout the LED streetlight’s
lifetime. No ultraviolet emission is
another benefit.
Challenges
Dependence on AC mains power is
the main challenge. Ankit says, “AC
streetlights draw electricity from util-
ity grid. Therefore, while these reduce
electricity consumption, they never
nullify the expense.”
While investing in AC mains-driv-
en LED streetlights, a few things need
to be kept in mind. An AC LED device
designed without a proper heat-sink
can lead to overheating of the light,
causing it to malfunction.Moreover,
LED streetlights emit unidirectionally,
so 360-degree coverage of an area will
require adjustment of the luminaire’s
distance from the ground, proper
beam angle, and installation of reflec-
tors or diffusers.
Solar setup requires expertise in
solar panel positioning; in order to
capture sufficient amount of solar
energy, panels need to be tilted at
a certain angle. Moreover, solar
streetlights require periodic main-
tenance for optimal performance.
This includes panel cleaning, battery
replacement and so on.
Batteries run for an average of 3
to 4 years, requiring replacement.
Moreover, external batteries can get
stolen. So manufacturers are providing
an arrangement to clamp batteries at
a suitable height on the pole. Some of
the latest streetlighting systems have
internal battery systems.
Solar LED streetlights: Keep
the grid at bay
Solar setups greatly reduce the
dependency on grid electricity. Grid-
connected solar streetlights are pre-
ferred over off-grid systems, as com-
plete isolation from grid electricity
may pose problems on foggy days or
days with no sunlight.
According to a spokesperson from
Gautam Solar, a setup comprising a
12W luminaire, a 75W solar panel and
a 40Ah battery costs around ̀ 12,000,
while a 43W LED streetlight with
300W solar panel, set of two 75Ah bat-
teries and extension pole costs around
` 35,000.
Considering the much higher
initial cost and running expenses
on the battery, solar LED streetlight
gives slower ROI, which can take up
to five years of usage. Usually, the
battery needs replacement every 3 to
3.5 years. Separately, it costs between
` 3000 and ` 5000, which adds to the
operational expenses.
The benefits of going solar
The major USP of solar streetlights is
the cut in grid electricity usage. The
electricity thus saved can be distribut-
ed to higher-demand areas. This leads
to carbon footprint reduction also.
The expected lifetime of a solar
setup is 12 years for LED luminaires,
25 years for solar panels and 3-4 years
for batteries. All in all, an LED street-
light coupled with solar panels can be
a great energy and money saver.
Powered By
ac mains-driven led vs solar led streetlights
ac mains-driven led streetlights solar led streetlights
Cost Estimated ` 2000 to ` 5000 and ad-
ditional costs depending on luminaire
wattage, cabling, pole requirement, etc
` 10,000 and above, including additional costs
depending on wattage, panel power, battery,
cabling, pole requirement, etc
ROI 1 to 2 years 2-5 years based on usage
Optimal
applica-
tion
Energy-efficient lighting option with
minimal maintenance at lower cost
with quicker ROI. Suited for areas with
a comparatively better grid electricity
availability
Long-term benefits in terms of financial savings
and environmental safe-keeping by minimising
grid dependency in lieu of a higher investment.
Recommended for remote areas where consistent
electricity availability and grid cabling might be a
challenge
Expert’s view: Are integrated solar panels a good choice?
Streetlights with solar panels embedded on top of the luminaire are the newest options in
the market. Sharing his experience of streetlights with integrated solar panels, Ankit said,
“We installed an integrated panel system, investing ` 6500 a unit. Not being able to tilt the
panel, the product could not capture optimal solar energy. So the purpose of the solar panel
was not served.”
While embedded panel setups come across as a comparatively cheaper and more
compact option, many users like Ankit (from Trisun Sant India) believe that these are not
optimal for solar generation.
smart world
76 January 2018 | electronics for you www.efymag.com
Choice of battery
Currently, two types of batteries are
available for solar streetlighting.
Lead-acid batteries are the conven-
tional options in the market. These
batteries require constant mainte-
nance and cannot be drained out
completely while in use. These allow
a discharge of up to 80 per cent. How-
ever, while lead-acid batteries require
regular manual maintenance, these
tend to have a longer life if maintained
properly.
Lithium-ion and lithium-ferro
phosphate batteries are the latest on
the market. These batteries are much
lighter (one-third that of lead-acid
batteries), allow complete discharge
during use and require almost no
maintenance. However, their life is
limited to nearly 3.5 years. Also, they
cost 20-25 per cent more.
Dr Uppal suggests, “Lead-acid
batteries are heavy and large in size,
requiring them to be installed on
the pole externally. These also need
regular maintenance. So users need
to install them at an accessible height
on the pole, which makes them vul-
nerable to theft. Lithium-ion batteries
have a high energy density and are
maintenance-free.”
What to buy?
Many buyers opt for AC LED street-
lights owing to their lower investment
cost and quicker ROI.
Dr Uppal shares, “Solar-based sys-
tems are ideal for Greenfields projects
and remote locations where cabling
cost savings, power savings and unin-
terrupted power (independent of grid)
can provide a comparatively quicker
ROI within 6 to 24 months, depending
on the location.”
Sambid Mohanty, AGM-Solar,
Havells Lighting, explains benefits of
solar streetlighting with an example:
“If you notice AC-driven LED lightings
across Noida-Greater Noida roads, a
good number of them malfunction,
the reason being poor maintenance
and frequent power cuts. In areas like
these, where cabling and grid power
maintenance might be a challenge,
investing in solar streetlights would
be a better option.”
—Paromik Chakraborty, technical journalist, EFY
Mission 2030:
Where Does
India’s EV
Ecosystem
Stand?
 At present, India doesn’t
have any manufacturer
with the technology or
infrastructure to make
lithium batteries for EVs
India has started its journey towards achieving an all-green vehicle eco-system by 2030. Transport minister
Nitin Gadkari’s bold statement of bull-
dozing in a completely green automo-
tive era confirmed the priority of the
agenda. English dailies quoted Gadkari
as saying, “The government will be
ready with its electric vehicle policy by
December (2017) this year.” Amidst all
the rumble, however, is India prepared
to face the shortcomings in its ecosys-
tem as it inches towards success?
Strengths
India is going strong in many respects
with regards to Mission 2030. Many
initiatives have been taken by the
administration to complement these
strengths. For instance, Energy Effi-
ciency Services Limited (EESL) has
incentivised ` 11.2 billion to Tata
Motors and Mahindra and Mahindra
Limited for production of 10,000 elec-
tric cars. Additionally, EESL is driving
bids for setting up 4000 EV charging
stations in Delhi NCR.
Over time, the increasing number
of EVs and charging stations on the
road would bring down their cost.
Samrath S. Kochar, director, Trontek,
affirms, “With bulk orders, the costs
will come down significantly, making
the vehicles commercially affordable.
This will greatly magnify the adoption
rate within India’s population.”
Take, for instance, Nagpur, which
is the first Indian city to launch 200
EVs in 2017 including four-wheelers,
buses and e-rickshaws. The city saw
installation of over 50 charging sta-
tions, set up by Ola. The government
has fixed Goods & Services Tax (GST)
on automobiles accordingly—setting
only 12 per cent GST on electric vehi-
cles as against 28 per cent taxation on
conventional petrol- and diesel-driven
automobiles.
India’s automobile components
vertical can contribute well to the
mission. Biju Bruno, MD, Greenvi-
sion Technologies, shares, “We have
a strong components and sub-system
manufacturing ecosystem for the
automotive industry, which can adapt
to making the necessary components
for EVs.”
Cummins India, an automobile
engine manufacturer, has already
started R&D on electric vehicle engines.
Major auto-playersSUN Mobility and
Ashok Leyland are pairing up for
electric-driven public transportation
and private vehicle solutions.
Opportunities abound
for energy solution compa-
nies as well. Setting up of
charging infrastructure and
manufacturing of efficient
EV battery solutions, in par-
ticular, assume importance.
Companies like Bharat Heavy
Electricals Limited (BHEL)
and National Thermal Power
Corporation (NTPC) are
working actively, with major
support from the Indian
Space Research Organisation
(ISRO), to bring down the EV vehicles hooked to charging stations
smart world
77www.efymag.com electronics for you | January 2018
cost of batteries. Significant invest-
ments from foreign firms are also
coming in. Finnish energy utility body
Fortum and China’s Zheijang Geely
Holding Group are planning to invest
in developing charging infrastructure
and vehicle solutions in India.
Challenges
Financing is the primary concern.
Kochhar comments, “Cost is the main
challenge for EVs. The upfront cost of
these vehicles is quite high.” For exam-
ple, while a diesel-driven bus costs up
to ` 5 million, the cost of an electric
bus is ` 15 million. Batteries are the
main multipliers of EVs’ upfront cost.
However, battery prices are coming
down, with reports suggesting a dip in
average price from $600 down to $250
in the last five years.
The battery manufacturing sce-
nario needs improvement. Bruno says,
“EVs will depend on lithium batteries
or a similar chemistry that has a high
power-to-weight ratio. At present,
India doesn’t have any manufacturer
with the technology or infrastructure
to make these batteries.”
High taxation on batteries adds
to the problem. “GST on batteries is
28 per cent. It needs to be corrected
immediately. I don’t understand why
the government sees energy stored in
a battery as luxury,” says Bruno. He
adds, “Recycling of lithium batter-
ies is not happening—the elephant
in the room is that no one is talking
about this at the moment. It’s very
important that this piece is figured out
quickly, else we’ll end up overcoming
one problem and landing into another
bigger one.”
There are initiatives by Indian
bodies, however, including ISRO part-
nering with BHEL to produce 50Ah
and 100Ah battery prototypes for two-
wheelers and four-wheelers.
India has its infrastructural chal-
lenges as well. Kochar explains,
“Charging stations need to be set up
at an accelerated pace. The cost of
setting up infrastructure like charging
stations needs attention.”
While we have examples in Nagpur
and some more cities where charging
stations have been set up, the entire
nation has seen a total installation of
barely 100 charging stations. With the
current quality of production, EVs in
India can cover only 120km distance
and achieve 85km/hour maximum
speed with a fully-charged battery.
Keeping that in mind, along with the
scarcity of charging stations, EVs have
not yet caught the Indian consumer’s
eye.
Bruno shares, “Charging infra-
structure will require massive invest-
ment, which only the government
can afford. Private players may not
see ROI here. That is where the bar-
rier lies.” Reports suggest Tata Power
Delhi Distribution Limited is planning
an investment of one billion rupees to
install 1000 charging stations in Delhi
within the coming five years.
EV charging infrastructure calls for
a high availability of electricity. Given
the poor supply-demand ratio of elec-
tricity, this becomes another challenge
for EVs. Investment will be needed to
set up more grids. Smart meters and
power distribution management sys-
tems will play a big role in addressing
these challenges.
The road ahead
For institutions that are setting up
charging stations for captive use,
regulations are being framed to relieve
them of the requirement of any elec-
tricity retailing permission. “The
ecosystem will build over time. We
will see some clear movements and
changes within the next two-three
years,” believes Kochar.
Karnataka’s latest policies to
promote R&D in the EV segment and
Maharashtra’s mass deployment of
EVs and tax relaxation show that the
states in India are already preparing to
embrace the welcome transition.
“EVs have to be subsidised. If
the government wants to save on oil
import bill, savings can happen only
if investments are made in EVs. There
are collateral benefits of less pollution,
cleaner air, better health of the popu-
lation and so on. The government
should not look at this as a subsidy,
but rather as an investment,” says
Bruno.
While many experts believe that
completely green vehicle ecosystem
is achievable by 2030, some say it is a
wishful thinking. Kochar says, “2030
is a good time period to see some mas-
sive changes. Even if not 100 per cent,
I believe we will see the ecosystem
with 50 per cent green vehicles.”
With this project, the government
has pledged to save $60 billion on
petrol and diesel and one gigatonne of
carbon dioxide emission by 2030. Let’s
hope everything goes well to make it
possible.
—Paromik Chakraborty, technical journalist, EFY
Kolkata
Municipality
Benefits
From Solar
Streetlights
 After solar streetlight
installation, Deshapriya Park
in Kolkata was able to reduce
its electricity bill from ` 31,000
a month to ` 1800 a month
Solar energy is the stepping stone towards a green and economical urban ecosystem. Municipali-
ties are turning to solar-powered LED
streetlights as a future-proof lighting
option. Professor (Dr) Santi Pada Gon-
chaudhuri, former managing director
at West Bengal Green Energy Develop-
ment Corporation Limited (WBGED-
CL), and an expert in the renewable
community, drove a solar streetlight
installation project at Deshapriya Park,
a major public park in Kolkata. With
this transition, the Kolkata Municipal
Corporation (KMC) is turning the
tables in terms of electricity cost and
carbon pollution control.
With the previously used AC-
driven sodium vapour streetlights,
the administrators at Deshapriya Park
were experiencing very high electric-
ity bills. Carbon dioxide emission was
also on the rise. The KMC required
a solution that could mitigate such
smart world
78 January 2018 | electronics for you www.efymag.com
If you want to share such case studies with EFY
readers, please contact us at smartworld@efy.in
unhealthy gas genera-
tion and also reduce the
power consumption.
The solution
KMC identified solar-
powered LED streetlights
as the best fit for the
purpose. The previous
sodium vapour lights
consumed 400 watts of
energy each. LED street-
lights, on the other hand,
generate higher bright-
ness level at less than
half the power consump-
tion of sodium vapour
streetlights. Solar panels
coupled with these LED
streetlights further help
to eliminate the compulsion of grid
electricity.
However, majority of solar street-
lighting setups come with batteries and
associated challenges like occasional
requirements for battery replacement
and maintenance, high operational
costs and risk of battery theft. Keeping
all these conditions in mind, Dr Gon-
chaudhuri decided to go with 180W
batteryless grid-connected solar LED
streetlights.
The complete setup
Before installation, the team had
to ensure that the area met certain
criteria for installation. First, since
streetlights would be batteryless, the
locality should have a stable electricity
presence. Metropolitan cities in India
have over 90 per cent availability of
electricity, making the environment
suitable for the product. Second, the
site should have a reliable grid and
proper poles for installation. Finally,
they required permission of State
Electricity Regulatory Commission
for connecting a microinverter to the
grid. The microinverter is required to
transfer the generated solar energy
to the grid. Once these arrangements
were acknowledged, the team went
ahead with the installation.
The total setup included 50 bat-
terylesscarbon-neutral grid-connected
solar LED streetlights with the follow-
ing specifications:
•	 180W LED luminaire
•	 Total 315W (approx. 2x150W)
capacity multicrystalline external
solar PV panels
•	 Pole-top mounting frame for hold-
ing the panels
•	 300W microinverter for connecting
to the grid
•	 Intelligent controller to enable auto-
mated on/off and auto-dimming
•	 9m long steel tubular poles
Dr Gonchaudhuri explains, “The
intelligent controller manages LEDs
during night time using the quantum
of energy pushed during day. In neces-
sity, the controller operates a dimmer
circuit to minimise the consumption
after midnight. However, the same
cannot be felt physically.”
Each streetlight including all
the above-mentioned features cost
` 60,000. The total project cost was
around ̀ 3.2 million.
The returns
The installation completed in January
2015, and since then it has brought
major benefits to the administration.
Massive electricity savings. The
installation of 180W LEDs in place of
400W sodium vapour lamps instantly
reduced the energy consumption
by more than 50 per cent (400-
180=220W savings). Furthermore,
solar energy generated by panels is
utilised throughout the night, cutting
down the grid electricity consumption
as much as possible.
As reported by the Ministry of New
and Renewable Energy (MNRE), 5400
kilowatt-hour solar power was generat-
ed and exported to the grid
in a period of 90 days. The
amount of power imported
from the grid was 5300 kil-
owatt-hour. This indicates
excess energy generation of
100 kilowatt-hour.
Another report illus-
trates that while Deshapri-
ya Park’s electricity bill for
April 2014 was ` 31,000
before solar transition, it
went down to as low as
` 1800 for April 2015 after
solar installation.
Reduced carbon foot-
print. The limited depend-
ence on grid electricity and
transition to LED technol-
ogy greatly reduced carbon
gas emission. According to Dr Gon-
chaudhuri, the setup cut carbon diox-
ide emission by 72 tonnes annually.
No opex and no failure. Battery-
driven solar streetlights call for
frequent maintenance and peri-
odic replacement of batteries, usually
within four years of use. This imposes
a certain amount of operational
expense throughout the product life.
On the other hand, batteryless street-
lights have no such requirements.
Additionally, due to grid connectivity,
these run on days with no sunlight as
well. No disturbances were recorded
in the streetlight functioning. Also,
failure rate was negligible.
Summing up
Based on Calcutta Electric Supply
Corporation (CESC) tariffs, the return
on investment is expected within four
years of use. Carbon-neutral battery-
less streetlights are great options
for urban communities, especially
flyovers, parks and many other public
areas where electricity availability is
consistent. Following the installation,
Kolkata Municipal Corporation has
taken up the target of solarising 28
other parks in the city, which will save
them ̀ 2.5 million for each park annu-
ally. Similar initiatives across all metro-
cities of India can bring a massive
cumulative benefit to the nation.
—Paromik Chakraborty, technical journalist, EFY
the cost and return structure
Month and year of implementation January 2015
Number of streetlights installed 50
Approx. cost of each streetlight
with intelligent control
` 60,000
Estimated total project cost ` 3.2 million
Benefits •	Very low utility electricity usage
•	More than 50% less luminaire energy
consumption (220W less)
•	Annual 72-tonne CO2 reduction
•	No operational cost
Expected ROI Within 4 years
Key figures 90-day energy data:
•	Generated energy exported: 5400kWh
•	Energy imported for consumption: 5300kWh
•	Excess energy generated: 100kWh
Monthly utility bill estimations (CESC):
•	Bill of April 2014 (before installation): ` 30,000
•	Bill of April 2015 (after installation): ` 1800
Data source: Dr S.P. Gonchaudhuri and MNRE
make in india
79www.efymag.com electronics for you | January 2018
Market Survey
Growth of the electronics market has also
translated into an opportunity for the Indian
electronics design industry as the semicon-
ductor design market in India is expected to
grow at around 25 per cent annually from
$9.9 billlion in 2012 to $60 billion in 2020
(Fig. 2). While the Indian electronics system
design and manufactur-
ing (ESDM) industry
as a whole depends on
imports to plug the huge
demand-supply gap,
domestic design services
are still its key strength
with huge potential.
Market potential
The growing customer
base and increased pen-
etration have provided
excellent scope for the
growth of Indian elec-
tronics design houses.
Some of the recent gov-
ernment policies like
Make in India and Digital
India have instilled con-
fidence and aided this
momentum.
Advanced product
development focusing
on miniaturisation, IoT,
automation, LED light-
After decades of sluggish demand, the Indian electronics industry is on a roll—largely due to increased digiti-
sation (making electronics an inseparable
part of almost all types of products) and an
insatiable local demand for electronics goods.
In fact, India is currently one of the largest
growing electronics markets in the world.
With increased affordability, the demand
for electronics products in India—such as
smart TVs, phones and tablets—has skyrock-
eted. It is pegged to grow annually at 41 per
cent between 2017 and 2020, creating a $400
billion market, according to a joint study by
Assocham and NEC Technologies.
Increased digitisation of products like
automobiles and communication equipment
has also boosted the demand for electron-
ics. Advanced technologies like the Internet
of Things (IoT), artificial intelligence and
augmented reality/virtual reality all require
electronic components at the heart of their
hardware systems.
Can India Become An
ElEctronics DEsign Hub?
Sudeshna Das
is director at
ComConnect
Consulting
Quantitative and qualitative information about the
Indian electronic design industry was collected
through secondary research. The findings were
analysed and verified through primary research
by conducting extensive interviews with industry
experts. These senior professionals shared their
insights on:
1. Market size
2. Market potential
3. Market challenges
A trend analysis was done on the basis of their
inputs.
Methodology
make in india
80 January 2018 | electronics for you www.efymag.com
still around 10 per cent)
3. Increased demand due to a
sizeable number of Indian SMEs and
startups focusing on the IoT
According to survey participants,
design services in demand (Fig. 4) are:
1. Embedded software design
2. End-to-end product design
services
3. Electronic design automation
(EDA)
4. Very-large-scale-integration
(VLSI) design
5. Product certification and com-
pliance
Market challenges
In recent years, independent design
houses like Wipro and HCL have
grown in stature and are increasingly
involved in design and development
for global firms. While conditions are
ing, AI and defense applications is
likely to be the biggest growth driver
in the electronics design market. In
addition, there are a few emerging
technologies that could emerge as
key areas of focus in the near future.
These include:
1. Next-generation wireless
2. Artificial intelligence
3. Silicon photonics
India has become the hub for elec-
tronics design with nearly 2000 chips
being designed every year and around
500,000 engineers working in various
aspects of electronic design starting
from chip design and verification to
different stages of product design.
Though still lagging behind chief
competitors in the Far East (China and
Taiwan), the country has significant
potential as it seeks to continually
raise the bar and increase the breadth
and depth of its offering. At least 60
per cent of surveyed respondents (Fig.
3) feel that India has the potential to
becomea design house for the global
electronics industry.
Greater digitisation across seg-
ments has led to the increased pen-
etration of Indian electronic design
houses in such application areas as
LED illumination, communications
and broadband equipment, and auto-
motive electronics. The focus is on
localising the technological changes
while maintaining global competi-
tiveness.
India’s design strength is driven
by:
1. Strong capabilities in embedded
system design
2. Large number of electronics
engineering graduates (even though
the number of employable talent is
Fig. 1: Evolution of the Indian electronics industry (Source: Indian Electronics and Semiconductor Association report)
Fig. 2: Expected market growth of semiconductor design market in India (Source: Ministry of Electronics & IT, IESA, KPMG, Aranca Research)
make in india
81www.efymag.com electronics for you | January 2018
(M-SIPS) and electronic development
fund (EDF) will have a significant
impact in driving this change.
The industry has responded posi-
tively to the government’s support. As
many as 159 new ESDM units were
established in 2015 itself. According
to industry experts, while Make in
India is an initiative in the right direc-
tion, the agenda could also include
‘Make for India’ with focus on Indian
priorities.
Other supportive measures taken
by the Indian government include:
1. 100 per cent FDI allowed in the
electronics hardware manufacturing
sector under automatic route
2. Duty relaxation and schemes
such as EPCG, EHTP and SEZ to
provide tax sops; duty exemption on
equipment required for setting up
semiconductor plants
3. National Policy on Electronics
(2012) and setting up of National Elec-
tronics Mission
indeed favourable for the growth of
the design industry, there are a few
impediments that need to be removed
for the industry to live up to the expec-
tations.
Over the last couple of decades,
the Indian electronic design indus-
try has gradually shifted focus from
manufacturing towards assembly.
Earlier, the entire production and
assembly of products was done in
India. However, now semi-finished
items are imported from China and
only the final assembly is done in
India. For example, mobile phones
and smart TVs are designed in China
and assembled in India. Only a small
percentage of design for local brands
is done in India.
One of the prime reasons behind
this trend is the requirement of
significant investment for R&D in
a sector where margins are already
thin. Pressed for margins, firms prefer
to shop for products that are suitable
for the Indian market and arrange for
imports of semi-knocked-down kits
back to India for assembly.
Other factors impeding the indus-
try growth include:
1. SMEs and startups lack experi-
ence in complex system design and
are completely unaware of outsourc-
ing opportunities in both design and
manufacturing.
2. Design (CAD) tools are expen-
sive, while open source tools are not
of acceptable quality. As engineering
design is capital-intensive, education-
al institutes with relevant CAD and
T&M equipment could offer their labs
on hire, helping startups and SMEs to
develop products at low cost.
3. There is dearth of hardware
accelerators supporting board design
and FPGAs/EPLDs.
4. Governance/policy related
challenges:
(i) Prototype ecosystem is yet to
mature, leading to a lot of time wast-
age in customs and other processes.
(ii) Duty-free components are still
being charged at 28 per cent GST.
5. While there is a steady supply
of graduates in the market, there is
still a significant gap between skill
sets required by the industry and skill
sets acquired by graduates through
higher education institutes. Effective
collaboration programmes between
the industry and institutes can go a
long way in developing more employ-
able candidates for the industry.
Supportive policies
The government of India is deter-
mined to resolve these issues by
developing policies and frameworks
that can catalyse growth in the design
sector. Initiatives like Make in India
and Digital India, and impetus to
existing schemes like the modified
special incentive package scheme
The Indian electronics design industry
consists of:
1. Independent design houses offering
design services for the world market
more under the services business model
(driven by IoT, automation, analytics, etc)
and designing India-specific products
(especially with the IoT and automation
driving efficiencies for manufacturing,
healthcare and hospitality segments)
2. Captive design houses of global
electronics firms
In addition to that, there are EDA tool
providers and original design manufacturers
catering to the market.
Types of electronics
design companies
 Krishnakumar M., delivery head, Communication BU, Tata Elxsi
 Rajeev Ramachandra, founder and director, Mistral Solutions
 Ramendra S. Baoni, founder and chairman, Bisquare
 S.A. Srinivasa Moorthy, director-design engineering and former CEO of AP State
Electronics and IT Agency
 Vijay Anand, director-sales, EmbDes Technologies
Major contributors to this report
Fig. 4: Design services in demand
Embedded software design
End to end product design services
Electronic design automation (EDA)
Very-large-scale-integration (VLSI) design
Product certification and compliance
0
20
40
60
80
100
100%
80%
40%
60%
20%Fig. 3: India’s potential to become the design
house for the global electronics industry
Yes
60%
May be
40%
No - 0%
efy dvd
82 January 2018 | ElEctronics For you www.EFymag.com
Tools For Coders
And Fun sTuFF For Gamers
The following software, besides other, can be found in the DVD
accompanying EFY Plus edition of this magazine
FreeBASIC
FreeBASIC is a cross-platform com-
piler of the popular starter program-
ming language BASIC. It is supported
on operating systems like Windows,
Linux, FreeBSD and protected-mode
MS-DOS. It is also compatible with
XBOX platform, though the platform
support is no more available.
The newest version of the self-
hosting compiler supports ‘C’ runtime
library fully and C++ libraries partially.
It supports header files for additional
third-party libraries like Windows
API, Allegro, TK+, OpenGL and SDL.
Therefore codes compiled in FreeBASIC
environment can be reused in many
other programming ecosystems. The
interface is user-friendly due to the
C-style preprocessor with features
like conditional compiling, multiline
macros and file inclusion.
Small Device C Compiler
Small Device C Compiler (SDCC) is
a popular compiler for programming
microcontrollers. The latest version of
the Standard C computing language
compiler is retargetable and can be
utilised for a group of devices includ-
ing Intel MCS51 series machines,
Freescale HC08 microprocessors,
Maxim DS80C390 device line, Zilog
Z80 microchips and STMicroelectron-
ics STM8 device. The software runs
on Linux, Windows as well as MacOS.
SDCC comes with a set of coding
standard optimisations, which include
dead code elimination, loop optimisa-
tion, copy propagation, ‘switch’ state-
ment jump tables and more. It supports
major data types including char, short,
int, long, float, boolean and long long
for a variety of MCU targets. It also sup-
ports inline assembler codes in func-
tions and automated regression tests.
JDK 9
Major components of Java Develop-
ment Kit (JDK) Standard Edition are
the Java Runtime Environment (JRE),
a code interpreter, a compiler (javac),
an archiver (jar) and a document file
generator (javadoc). One significant
change in JDK 9 is the introduction of
a modular system that brings diverse
configuration options of the JDK and
the JRE. The modular system brings
an optional ‘Link time’ parameter,
which exists between compile-time and
runtime. Customisations to runtime
image can be made with the help of
module usage in the link time.
JDK also includes jmod tool,
which has a similarfunction to JAR
but also incorporates native code files.
Users can enjoy simple string-schemes
for easier identification of different
releases, namely, $MAJOR, $MINOR,
$SECURITY and $PATCH. Updates to
JDK tools have also been introduced,
including support for Read-Eval-Print
Loop (REPL) functionality through
jshell tool, support for multiple class
files to exist in a single JAR, and com-
patibility of older platform codes on
javac.
Free Pascal
This popular compiler for Pascal and
Object Pascal languages has included
further updates. The 16-, 32- and
64-bit compiler can support system
architectures including Intel x86,
ARM, AMD64, SPARC, PowerPC64,
Aarch64, MIPS and JVM. It can run
on Linux, Windows, FreeBSD, MacOS,
Haiku, Nintendo, Android, AROS and
AIX, enabling a ‘write once, compile
anywhere’ system.
Version 3.0.4 updated some units
of Free Pascal. For example, T-List
Autogrowth threshold of SysUtils is
expanded for better memory man-
agement, Inifiles invalid name/value
pair reading and many changes in the
go32 unit. Free Pascal supports addi-
tional Pascal family dialects including
TurboPascal and Delphi.
Open Watcom
Open Watcom is an efficient integrated
development environment (IDE) for C
and C++ programs. It also supports
Fortran programming languages. An
open source IDE licenced by Sybase, it
is compatible with DOS, Windows and
Linux. Open Watcom packs a variety
of tools, including graphical tools for
various functions, linker, debugger
and Vi editor.
The latest version of Open Watcom
has many improvements and bug fixes.
For instance, it features improved
handling of data type like boolean
and floats by the compiler. The IDE
now supports OLE 2.0 and Linker
supports RDOS and ZDOS. Vi Editor
now supports non-ASCII characters in
the 0x80x-0xFF range. The V2.0 Beta
introduces an integrated text-editor,
a two-phase build system and more
fixes.
Terasology
If you are a fan of Minecraft and want
to play something for free, Terasology
might be the one for you. This open
source ‘sandbox’ game for Windows
has mechanics similar to Minecraft
where digital blocks can be used to
innovate buildings, structures and
infrastructure. Additional features
include assigning digital creatures
to activities. Players can create dif-
ferent tools and weapons and use
them, create torches to illuminate
dark areas, eat for improving life force
and so on. The game is licenced by
Apache 2.0.
www.efymag.com electronics for you Plus | January 2018
efy dvd
i
Lasi 7: For Designing
VersatiLe integrated CirCuits
One of the most popular freeware for layout and design, Lasi is amaz-
ingly versatile as it can be used
with various electronic com-
ponents like ICs, MEMS, PC
boards and project documen-
tation drawings. In its latest
version, Lasi 7, tooltips have
been turned off for better user
experience on Windows and
some more updates.
Lasi is a conventionally
preferred module since the
times of Win32, and its various
updated versions have been
quite popular across Windows
Vista, XP and now Windows
7. Lasi can also be accessed on
Linux operating systems using
Wine translator. There are,
however, some user limitations
in the Linux version.
What makes Lasi such a
favourite is the fact that draw-
ings are composed on hierar-
chical individual cells called
Transportable Layout Cells
(TLCs), which are flexible
for transfer between different
drawings and are in basic XML
format.
Along with the main editor
for drawing, Lasi comprises a
lot of other utilities including
DRC programmable bitmap,
and a compiler that helps to
extract Spice circuit files from
schematic and layout format.
Drawings made in Lasi can
also be archived as GDS as the
drawing pattern for Lasi and
GDS is similar. Later, in case
Lasi is unavailable, drawings
can also be transferred to
Fig. 1: Design layout using TLCs in Lasi (Image source: http://www.vlsitechnology.org)
Fig. 2: Complete circuit diagram (Image source: http://www.freebyte.com)
January 2018 | electronics for you Plus www.efymag.comii
efy dvd
Fig. 3: Lasi tools and utilities (Image source: https://i.ytimg.com)
CAD, since CAD systems sup-
port GDS.
New features of Lasi 7
For better and enhanced
user experience, changes
have been made to the main
editor and a few utility tools.
Tools not required have been
turned off as these often
cause unnecessary redraws on
some versions of Windows.
To include the recently made
changes, add-on tools have
been recompiled.
Users can now hide or un-
hide ‘tooltips’ section, depend-
ing upon usability, using the
Cnfg command and also by
checking and unchecking the
tooltips button.
A lot of minor changes
have also been made in the
help feature for files and web
pages.
efy dvd
January 2018 | ElEctronics For you Plus www.EFymag.comiV
Simulating Your intel ProceSSor
With gnuSim8085
For engineers looking to program their processors as per specific applications, a good number
of open source simulation tools are
available. GNUSim8085 is one such
software. This cross-platform software
enables users to digitally simulate, as-
semble and debug the Intel 8085 8-bit
microprocessor—a power-efficient
component for applications like secu-
rity controls and automatic controls.
The Intel 8085 processor is com-
paratively difficult to code directly
due to the lack of an integrated editor
or compiler and limited debugging
capacity. GNUSim8085 simulator tool
eases these difficulties by digitally
designing and debugging the code to
learn the processor’s behaviour before
encoding the actual hardware.
Features of GNUSim8085
Digital representation of Intel 8085 by
the software gives you a clear depic-
tion of registers, ports and memory.
The simulation has input and output
mechanism identical to the actual
hardware’s. The biggest advantage of
this software is the introduction of an
assembler and an editor for the 8085
processor. The editor comes with
syntax highlighting. The software can
display the processor’s registers and
flags. Along with these, the user can
also view input/output (I/O) ports,
memory and stack contents. The
hexadecimal-to-decimal converter
adds a major advantage.
The GNUSim8085 software sup-
ports different languages and is print-
capable. It is compatible with Linux
and Windows operating systems.
Using the software
The software launches a workspace
with sample codes that can be
worked on. A toolbar on the top
contains various options including
File, Reset, Assembler, Debug and
Help. Users can open a new project
from File→New. The user interface
(UI) is very comprehensive and
user-friendly.
The left panel contains a compact
overview of the Intel processor’s
registers and flags. The hexadecimal-
to-decimal converter is located in this
panel as well. The value to be con-
verted needs to be inserted manually.
Below the converter, two spinboxes
are available. One is for the I/O port
value and the other for the memory
port value. Entering the port number
in the numeric box displays the port
content in the adjacent text box. The
default entry format is decimal. You
can enter hex formats as well by add-
ing an ‘h’ before the number. Users
can update port values from these
spinboxes.
The right panel comes with
multiple tabs that list values of the
processor’s different entities. The
first tab is ‘Data,’ which enlists the
defined data variables. The following
tab is ‘Stack,’ which displays address-
es and values of entire stacks in the
program. Stack values are updated
when you initialise a stack pointer
and execute a stack function like
Push or Call. Two other tabs include
I/O port and memory port, which
enlist values and contents of I/O
ports and memory ports, respectively.
An additional tab opens a virtual key-
pad, which allows users to digitally
insert values.
At the lower end of the right
panel is a message box that displays
messagesrelated to program compi-
lation and execution. In case of any
error, the message box displays an
error message mentioning the loca-
tion and reason of error. Successful
program execution displays a success
message.
Assembler. Assembler is an op-
tion in the other top toolbox that
opens various functionalities of the
tool’s assembly unit. Its main func-
tion is to convert the code written
in mnemonics to 8085-compatible
Fig. 1: The GNUSim8085 interface
www.EFymag.com ElEctronics For you Plus | January 2018 V
machine code. Major elements of As-
sembler include Mnemonics, which
are instruction strings of operations;
Labels, which are targeted named
points in the code for Call com-
mands; Comments, which are not
part of the code but are remarks
for the coder’s convenience; and
Pseudo-opcodes.
There are three sub-menus in the
Assembler menu. The first is Assem-
ble, which loads the program code
to the memory address. The second
is Execute, which compiles and
runs the loaded program. The third
option is Show Listing, where users
can view the executed program code
along with the relevant memory ad-
dress opcode, mnemonics and com-
ments. The main importance of this
option lies in preparing the program
for moving into the actual hardware
by either saving as a file and printing
or viewing the complete listing.
Debug and reset. The simulator
toolbar has two other menus. One is
Debug. It consists of sub-menus Step
In, Step Over and Step Out. These
make code debugging easy by analys-
ing the register and memory content
in each step. Debug menu also comes
with a code breakpoint feature.
Reset menu can help users to
erase old data from the simulator and
reset values of registers, ports, flags
and memory. Reset can be done
individually for each component or
for all at once.
Updates in v1.3.7
The latest version of GNUSim8085
has a strong debugger unit. The
program automatically stops run-
ning in case of infinite-loop errors or
any program execution fault. Stack
tracing is quite efficient in this ver-
sion. For instance, users are notified
in case more Pop commands are
executed than Push.
Moreover, the latest version saw
fixing of some major bugs in the
previous releases. One among them
is the unavailability of Project Save
prompt when switching to a new
project. Frequent crashing of the
software when clicking Help→About
has also been solved. Another major
bug solved was the flag setting error
of DAA.
Finally, the biggest advantage of
the software is enabling developers
to insert the program through the
Intel 8085 mnemonics and avoid
hand assembly. Through this, devel-
opers can save a great deal of time
in debugging and ensure an error-
free programming of the hardware
module.
Fig. 2: The Assembler listing of GNUSim
efy dvd
www.efymag.com electronics for you Plus | January 2018
efy dvd
Vii
OSMC: A Friendly Media Centre
For Your Raspberry Pi
A reliable open source media player comes handy when working
on media files. A media centre
software called Open Source
Media Center (OSMC) can help
you get support from an expan-
sive range of systems, including
Windows, iOS, Linux as well as
other devices like Raspberry Pi.
OSMC is a Debian Jessie-driven
Linux distribution that runs Kodi
application on devices, including
Apple TV and Vero in addition to
Raspberry Pi.
Setting up version 2017.01-1
OSMC is compatible with Rasp-
berry Pi 1, 2 and 3. However,
version 2 or higher is desired for
optimal performance. To set up
OSMC on your Raspberry Pi, first
download the OSMC application
on your computer. The installa-
tion will require a confirmation
of the language and the device
where the distro is intended to
be used. Confirm the latest ver-
sion of the software and click to
continue.
In the next step, you will be
prompted to select the storage
type. It can be a USB stick, NFC
device or even internal stor-
age. Usually, Raspberry Pi users
choose to use SD cards.
Select the storage appropri-
ately and move on to the next
step. Here, you will be asked
to confirm whether you will be
using a wireless network (Wi-Fi),
wired network (Ethernet cable)
or would like to configure manu-
ally. Select the suitable network
and continue. OSMC will start
downloading on the SD card or
selected storage and install after
the download.
Now, plug in the storage to
your Raspberry Pi device. OSMC
will start to install in your Pi
system. After the installation
completes, select your language
and time zone. Set up your
device name and accept the
licence agreement. Once all the
steps are successfully followed,
OSMC will configure in your
laptop with Kodi appearing in
the front end. You can perform
all the functions of Kodi on your
Raspberry Pi.
The open source goodness
The OSMC interface is very
compact with an attractive me-
tallic appearance. The left panel
consists of explorable options
where you can play various me-
dia files like videos, movies, TV
shows, music and pictures. All
the media is categorised in fold-
ers, making the user interface
(UI) comprehensive and easy
to find. OSMC supports a large
range of codecs, allowing most
of the video formats and resolu-
tions to run smoothly.
A menu called ‘My OSMC’
in the left panel enables you to
configure your setup including
Raspberry Pi configuration. You
can mark your most visited files
as Favourites and access them
quickly from the menu. Settings
menu allows you to make OSMC
setup changes, including date,
time, language and so on.
OSMC keeps the system
updated. It is responsible for
Fig. 1: OSMC installation wizard (Source: seo-michael.co.uk)
Fig. 2: Storage selection prompt
Fig. 3: Prompt for choice of connection to the web
January 2018 | electronics for you Plus www.efymag.comViii
Fig. 4: The OSMC UI
Fig. 5: Options in My OSMC
up over 40,000 packages to the us-
ers, creating large possibilities for
customisations. This makes OSMC
a highly customisable open source
platform. It is recommended to run
the ‘sudo apt-get update’ command
while incorporating any of the
packages.
Why OSMC is recommended
OSMC is an easy-to-use, quick-to-
install and smooth media platform.
Options available with Kodi in the
package make it a favourite among
the audiophile and movie-buff com-
munity. Moreover, the flexibility of
applications and services is highly
advantageous. And the best of all, it
is free!
managing system resources and
hardware, including remotes,
keyboards and Wi-Fi adaptors. The
biggest attraction of OSMC is that
it enables all the add-ons support
of Kodi to run on the device. Kodi
supports a huge list of add-ons
including media channels like
9GAG.TV, ABC Family, Apple
iTunes Podcasts, Comic Vine, CNET
Podcast, ESPN, IGN.com, Netflix,
MTV and more. Even application
software can be run through Kodi.
Kodi’s add-on inclusion expands
into the OSMC environment, mak-
ing the system highly scalable.
Moreover, OSMC allows users to
configure VPN services.
The Debian repository opens
efy dvd
83www.efymag.com electronics for you | January 2018
By 2020, AI to create more jobs
than it eliminates
Make in india
Industry News
On The Move
Ajay appointed secretary, MoD
Dr Ajay Kumar, additional
secretary in Ministry of
Electronics and Information
Technology, has been
elevated to secretary in
ministry of Defence. Kumar
is a 1985-batch IAS officer of
Kerala cadre.
Apple’s India chief quits
Apple’s chief of operations for
India Sanjay Kaul has decided
to step down from his role at
the company, according to a
report from Reuters. He has
been replaced with a long-time
executive, Michel Coulomb.
Artificial intelligence (AI) will create
2.3 million jobs in 2020, while
eliminating 1.8 million—according to
Gartner. The number of jobs affected
by AI will vary by industry; through
2019, healthcare, public sector and
education will see continuously
growing job demand whilemanufac-
turing will be hit the hardest. Starting
in 2020, AI-related job creation will
cross into positive territory, reaching
two million net-new jobs in 2025.
AI will improve the productivity
of many jobs, eliminating millions
of middle- and low-level positions,
while also creating millions of more
new positions at highly skilled, man-
agement and even the entry level and
low-skilled levels.
The Gartner report suggests that IT
leaders should not focus only on the
projected net increase of jobs. With
each investment in AI-enabled technol-
ogies, they must take into consideration
what jobs will be lost, what jobs will be
created, and how it will transform the
way workers collaborate with others,
make decisions and getting work done.
As regards AI’s impact on the work-
place, the report predicts that by 2022,
one in five workers engaged in mostly
non-routine tasks will rely on AI.
Semiconductor equipment to break sales record
Rooftop PV presents a $23 billion opportunity in India
Worldwide sales of new semicon-
ductor manufacturing equipment
will increase 35.6 per cent to
$55.9 billion in 2017, exceeding its
previous high of $47.7 billion in
2000—according to SEMI, global
industry association representing
the electronics manufacturing
supply chain. Year 2018 will break
another record with 7.5 per cent
growth resulting in sales of $60.1
billion.
SEMI predicts a 37.5 per cent
increase in 2017, to $45.0 billion, for
wafer processing equipment. The other
front-end segment, which consists of
fab facilities equipment, wafer manu-
facturing and mask/reticle equipment,
is expected to increase 45.8 per cent to
$2.6 billion. The assembly and packag-
India will need to invest $23 billion
over the next five years to meet its
40GW rooftop photovoltaics target
for year 2022, according to a new
report by Bloomberg New Energy
Finance (BNEF).
The Indian government has set
its sights on having 175GW of non-
hydro renewables capacity by 2022.
At present, this figure stands at just
60GW. The majority of the capacity in
the 2022 target—a total of 135GW—is
utility-scale (wind farms and solar
parks, in particular) and does not
include large hydro projects. The report
estimates that India will need to invest
$83 billion to build this capacity. The
good news is that, because of falling
capital costs per MW, that figure is $19
billion less than in BNEF’s previous
estimates.
Some of the most interesting
activity will be in small-scale solar.
Shantanu Jaiswal, head of India
research at Bloomberg New Energy
Finance, said: “Rooftop solar in India
will grow inevitably with or without
the support of power distribution
utilities.”
The cost of electricity from roof-
top PV has halved in the last five
years due to fierce competition in
the market and a drop in equipment
prices. In contrast, average retail
electricity rates have increased by 22
per cent in the same period. This has
made rooftop PV cheaper than com-
mercial and industrial grid tariffs in all
major states of India.
ing equipment are projected to grow
by 25.8 per cent to $3.8 billion in 2017,
while semiconductor test equipment
are forecast to increase by 22 per cent
to $4.5 billion.
In 2017, South Korea will be the
largest equipment market for the
first time. After maintaining the top
spot for five years, Taiwan will rank
second, followed by China.
Industry news
84 January 2018 | electronics for you www.efymag.com
Calendar of Forthcoming Electronics
Fairs/Exhibitions/Seminars/Events
Name, Date and Venue Topics Contact address for details
CES 2018
January 9-12, 2018
Las Vegas, Nevada, USA
World’s gathering place for those who thrive on
the business of consumer technologies and where
next-generation innovations are introduced to the
marketplace
Consumer Technology Association
Website: www.ces.tech
NEPCON Japan
January 17-19, 2018
Tokyo Big Sight, Japan
Asia’s leading exhibition for electronics design,
R&D and manufacturing technology
Reed Exhibitions Japan Ltd
Website: http://www.nepconjapan.jp/en/
9th Source India
January 24, 2018
Hotel Green Park, Chennai
International buyer-seller meet and conference
redefining Indian electronics supply chain
Website: www.elcina.com
Indiasoft
January 24-25, 2018
Bengaluru
Exhibition and conference by Electronics and
Computer Software Export Promotion Council
(ESC) to showcase products and capabilities of
Indian tier-II and tier-III software companies
Website: www.indiasoft.org
Electronics West
February 6-8, 2018
Anaheim Convention Center,
California, USA
North America’s largest annual design and
manufacturing event
Electronics West
Website: http://electronicswest.
designnews.com/
India Electronics Week
February 7-9, 2018
KTPO Convention Center,
Bengaluru
With its 4 co-located shows—IoTshow.in, LEDasia.
in, EFY Expo and EFY Conferences—India
Electronics Week acts as a one-stop-shop for
technology enthusiasts
EFY Enterprises Pvt Ltd
E-mail: iew@efy.in
Website: www.indiaelectronicsweek.com
IESA Vision Summit 2018
February 27-28, 2018
Leela Palace, Bengaluru
Summit on electronics system design and
manufacturing
Website: www.iesaonline.org
Embedded World 2018
February 27-March 1, 2018
Exhibition Centre, Nuremberg,
Germany
Trade fair for IT security for electronic systems NürnbergMesse
Website: www.embedded-world.de/en
2nd IoT India Expo
March 7-9, 2018
Pragati Maidan, New Delhi
Hands-on workshops on the Internet of Things (IoT) Website: www.iotindiaexpo.com/
konecthingz-workshop.aspx
26th Convergence India 2018
March 7-9, 2018
Pragati Maidan, New Delhi
International exhibition and conference on digital
convergence
Website: www.convergenceindia.org
ELECRAMA
March 10-14, 2018
India Expo Mart, Greater Noida,
Uttar Pradesh
Flagship showcase of the Indian electrical industry
ecosystem and the largest congregation of power
sector ecosystem in the geography; brings together the
complete spectrum of solutions that powers the planet
IEEMA
Website: http://elecrama.com,
http://ieema.org
electronica China
March 14-16, 2018
Shanghai New International Expo
Center, China
International trade fair for electronic components,
systems and applications
Website: https://electronica-china.com
AMPER 2018
March 20-23, 2018
BRNO, The Czech Republic
International trade fair of electrotechnics,
electronics, automation, communication, lighting
and security technologies
Website: www.terinvest.com
HKTDC Hong Kong
Electronics Fair
April 13-16, 2018
October 13-16, 2018
Hong Kong Convention and
Exhibition Center
Electronics expo Website: www.hktdc.com/
hkelectronicsfairae
KPCA Show 2018
April 24-26, 2018
Kintex, Korea
International electronic circuits show Website: http://www.kpcashow.com
CE China 2018
May 3-5, 2018
Shenzhen Convention & Exhibition
Center, China
International trade show for consumer electronics Website: www.cechina-ifa.com/en
4th Smart Cities India 2018 Expo
May 23-25, 2018
Pragati Maidan, New Delhi
Exhibition on smarter solutions for a better
tomorrow
Website: www.exhibitionsindia.com
3rd India-Taiwan Electronics
Summit
June 1, 2018
Taipei
Summit on electronics system design and
manufacturing
Website: www.elcina.com
JPCA Show 2018
June 6-8, 2018
Tokyo, Japan
48th international electronic circuits exhibition Website: http://www.jpca.net/
show2018/en/exhibition/index.html
ConnecTechAsia
June 26-28, 2018
Singapore
Exhibition and summit on key technologies such as
IoT, cloud/big data, cyber-security, TVEverywhere,
ProAudioTech, SatComm, 5G and more!
Website: www.ConnecTechAsia.com
SES 2018
July 5-6, 2018
Bengaluru
9th strategic electronics (defence and aerospace)
summit
Website: http://ses-india.in/register.asp
Customs duty raised on some
finished electronic items
The Indian government has raised
customs duty on various electronic
products including mobile phones,
microwave ovens and cameras to boost
local manufacturing and createjobs.
The increase in customs duty will give
local manufacturers a cost advantage
over imports. However, it will not
impact imports from countries such
as Thailand and Malaysia, with which
India has free trade agreements.
Customs duty has been increased
by up to ten per cent, as per a notifi-
cation issued by the Central Board of
Excise and Customs. While it has been
increased by five per cent on items
such as mobile phones, video recording
devices, electricity meters and digital
cameras, it has been raised by ten per
cent on items like microwave ovens,
lamps and lighting fixtures.
Currently, these items attract a flat
ten per cent basic customs duty (BCD)
in addition to integrated GST. It is the
BCD that gives a tariff edge to local
manufacturing as a cut in GST rate will
equally benefit both imports and local
production.
Foreign Trade Policy
helping industry
According to ELCINA, the Foreign
Trade Policy after mid-term review
is geared towards promoting exports
very aggressively (with a target of
$900 billion by 2020) and supports
manufacturing with a focus on MSME
and labour-intensive sectors. It has
increased the Merchandise Export
from India Scheme (MEIS) benefit for
majority of the sectors and allocated
` 3690 million incentive for electronics
and telecom.
Under the policy, supplies of
goods and services to SEZs will
attract no GST. Import of second-
hand goods for repair, refurbishing,
re-conditioning or re-engineering has
been made free. GST has also been
abolished for transfer and sale of
these scrips. Also, there is an across-
the-board increase of 2 per cent in
existing MEIS for exports by MSMEs/
labour-incentive industries. Round-
the-clock customs clearance facility
has been extended at 19 sea ports and
17 air cargo complexes.
Continued on next page...
Industry news
85www.efymag.com electronics for you | January 2018
Snippets
User forum on 3D printing concludes successfully
Stratasys, an applied additive technology solutions provider, recently concluded its
first user conference on 3D printing technology. This conference provided a platform
to advocate printing technology where key industry players and end-users exchanged
insights on the latest 3D printing trends, applications and best practices to succeed in
today’s globally competitive manufacturing ecosystem.
SignEasy launches Aadhaar-based electronic signatures
SignEasy, an e-signature software provider for professionals and SMBs, has launched its
Aadhaar-compliant eSign solution with a fully integrated fill-and-sign document workflow.
With over 140,000 customers across 180 countries, SignEasy aims to help businesses
across India eliminate their dependence on paper-based processes while supporting the
Indian government’s vision for Digital India.
Thales acquires Gemalto
Aerospace and defence company Thales is buying chipmaker Gemalto in a deal worth 4.8
billion euros ($5.6 billion). The agreement came just two days after Gemalto had rejected
an earlier bid by rival Atos to strengthen in the emerging field of digital security as well
as the Internet of Things (IoT).
ELCINA’s pre-budget
recommendations
ELCINA president Pankaj Gulati has
urged the Indian government to use
goods and services tax (GST) as a tool
to benefit the manufacturers bound by
IT Agreement. Gulati has also sought
imposition of duty on those technol-
ogy and telecom products which fall
outside the purview of the Information
Technology Agreement (ITA-1) signed
by India in 1996-97. According to him,
such a move would boost domestic IT
and telecom equipment manufactur-
ing in the country.
MediaTek announces
smartphone design training
Med i aTek ha s l aunched i t s
second Smartphone Design Train-
ing Program in collaboration with
India’s Ministry of Electronics and
Information Technology (MeitY).
The programme prepares design
engineers and talented individuals
in the mobile industry with tools,
insights and expertise necessary for a
successful India smartphone industry.
Progamme details are available on
http://i.mediatek.com/makeinindia-
sdtp2018.
In yet another development, Medi-
aTek has partnered with Google to
improve the performance of entry-level
smartphones. Its MT6739, MT6737
and MT6580 system-on-chips (SoCs),
among others, now have board sup-
port packages available to run Google’s
Android Oreo (Go edition). The part-
nership between the two companies
aims to ensure a quality Android smart-
phone experience that is both secure
and affordable for devices with 512MB
to 1GB of memory.
Renesas announces winners
of embedded design contest
Renesas has announced the winners of
its GR PEACH Embedded Design Contest
2017 in ASEAN. The contest encour-
aged students, hobbyists and profes-
sional engineers to build innovative
IoT designs using the Gadget Renesas
(GR) board.
Renesas invited the top ten contest-
ants (six contestants from Vietnam,
three from Singapore and one from
Thailand) for a live project demonstra-
tion and announced the winners during
the grand finale held in Ho Chi Minh
City, Vietnam. An autonomous robot
for indoor surveillance and monitor-
ing, created by Trong Nghia Nguyen
from HCMC University of Technology
Vietnam, won the first prize.
Vignan University sets up
CoE using Keysight products
Vignan University, Andhra Pradesh,
has established an RF and wireless
Centre of Excellence using Keysight
Technologies’ state-of-the-art equip-
ment for system-level design and
measurement of wireless technologies.
In yet another development, Key-
sight Technologies has made most of
its products and solutions available on
the Indian government’s eMarket place
(GeM) (https://gem.gov.in/). GeM
was created to enhance transparency,
efficiency and speed in public procure-
ment. It provides e-bidding, reverse
e-auction and demand aggregation
facilities to help government users get
the best value for their investment.
Continued from previous page...
Automation Expo 2018
Aug. 29-Sept. 1, 2018
Bombay Convention & Exhibition
Center, Goregaon East, Mumbai
13th international exhibition & conference on
automation
IED Communications Ltd
Website: www.automationindiaexpo.com
IFA Berlin
Aug. 31-Sept. 5, 2018
Berlin Exhibition Center
(Expo Center City), Germany
International trade show for consumer electronics
and home appliances
Website: http://b2b.ifa-berlin.com
SEMICON Taiwan, 2018
Taipei, Taiwan
September 12-14, 2018
Premier event in Taiwan for microelectronics
manufacturing
Website: www.semicontaiwan.org/en
TAITRONICS
Oct. 9-12, 2018
Taipei Nangang Exhibition Center
International electronics show Website: https://www.taitronics.tw
Open Source India
October 11-13, 2018
Bengaluru
Platform for the open source community to share
what’s new and exciting in open source languages,
tools and techniques
Website: https://opensourceindia.in/
osidays
GITEX
October 14-18, 2018
Dubai World Trade Centre
Showcase of the world’s most advanced
technologies
Website: https://www.gitex.com/
electronica Munich
Nov. 13-16, 2018
Munich, Germany
International trade fair for electronic components,
systems and applications
Website: www.electronica.de
Since this information is subject to change, all those interested are advised
to ascertain the details from the organisers before making any commitment.
Calendar of Forthcoming Electronics
Fairs/Exhibitions/Seminars/Events
Name, Date and Venue Topics Contact address for details
86 January 2018 | ElEctronics For you www.EFymag.com
Components
TVS diode arrays
Littelfuse, Inc. has introduced 16 series
of automotive-qualified TVS diode
arrays (SPA diodes)
that are Produc-
tion Part Approval
Process (PPAP)
capable. These offer automakers and
high-end industrial manufacturers
single-origin flow from wafer creation
through testing of the devices used in
their products. The AEC-Q101 quali-
fied devices offer a durable approach
for current and emerginginterfaces
in the automotive ecosystem for data
lines, charging lines, control lines and
drivetrain, as well as for communica-
tion ports, including antennae, against
damage due to electrostatic discharges,
electrical fast transients and other over-
voltage transients.
Littelfuse, Inc.
www.littelfuse.com
CAN transceivers
Maxim’s new 2.75kV and 5kV family of
isolated controller area network (CAN)
transceivers help designers to ensure
robust communication and improve
uptime for industrial systems. The high-
speed transceivers integrate up to 5kV
integrated galvanic isolation with fault
protection and ±15kV human body
model (HBM) ESD to increase uptime
in harsh and noisy environments. These
operate up to the maximum high-speed
CAN data rate of 1Mbps and feature
±54V fault protection on receiver inputs.
Maxim Integrated Products
www.maximintegrated.com
Camera solution for cars
Renesas Electronics and HELLA Aglaia
have announced their open and scal-
able front camera solution for advanced
driver-assistance systems (ADAS) and
automated driving. The new front
camera solution combines R-Car V3M,
Renesas’ high-performance, low-power
image-recognition system-on-chip
(SoC) for New Car Assessment Program
(NCAP, Note 1), and HELLA Aglaia´s
field-proven camera software designed
to meet level 2 (partial
automation) and level
3 (conditional auto-
mation) of SAE Inter-
national’s new J3016 standard (Note 2).
Designed for scalability, the solution
enables system designers to build a wide
range of front cameras, from cameras
supporting NCAP to cameras supporting
up to level 3 applications.
Renesas Electronics Singapore
www.renesas.com
Biosensor
MediaTek Sensio MT6381 is a 6-in-1
smartphone biosensor module
that makes it easy to track
heart rate, blood pressure,
peripheral oxygen saturation
levels and more. Available
as an embedded module in
smartphones, it allows consumers to
quickly check and monitor physical well-
ness on a device they use the most—their
smartphone.
MediaTek Sensio MT6381 is a com-
prehensive solution consisting of optical,
electrical and processing components.
Its customisable, compact design means
device manufacturers have the flex-
ibility to embed it directly into all types
of smartphones, versus using multiple
sensors. With MediaTek Sensio, manu-
facturers are able to develop proprietary
applications or leverage third-party appli-
cations and developer add-ons.
MediaTek
www.mediatek.com
3D printing filaments
Rever Industries offers 3D printing
filaments in materials rang-
ing from PLA, ABS, PETG,
Wood, Glow-in-the-dark
HIPS and TPU, and in a wide
range of colours of your
choice. These filaments have
diameter tolerance as good as ±0.03mm
and consistent colour shades.
Rever Industries
www.reverindustries.com
Security controllers
Infineon Technologies has introduced
a one-stop offering for fast and easy
production of payment cards and smart
wearables. Launched under the brand
SECORA Pay, the new contact and dual-
interface EMV security controllers come
with the latest EMV applets. Coming in
various versions, these allow a flexible
approach to regional market require-
ments, thus significantly easing the
adoption of EMV-compliant payment
cards and emerging form factors such
as smart wearables.
Infineon Technologies
www.infineon.com
test & measurement
Multifunction meters
MECO has introduced an all-new Power-
Guard (PG08T) with built-in timer and
relay function for load power
on/off, tariff and money func-
tion to know spending/saving
on electricity, three-pin socket
and plug suitable for Indian
sockets (external adaptor not
required), bigger LCD with backlight
and large digits, and beautiful design in
bright white colour.
This meter can measure power
(W), power factor (PF), carbon emis-
sion (CO2 in kg), total used time (min),
Make in india
New Products
New Products
87www.EFymag.com ElEctronics For you | January 2018
money (CU), tariff (CU/kWh), timer
(DHH:MM), frequency (Hz), energy
(kWh), TRMS current (mA) and TRMS
voltage (V). It can be used in monitor-
ing domestic appliances such as refrig-
erators, washing machines, microwave
ovens and LED lights.
Meco Instruments
www.mecoinst.com
RCD tester
Kyoritsu’s 5410 RCD tester measures
trip time and trip-out current at differ-
ent ranges. Its constant-current-source
circuitry ensures that a fluctuating
mains voltage does not affect the read-
ing accuracy. The device tests rated
residual non-operating current
in x½ range, measuring
RCD trip time in x1 and
x5 ranges. Its key features
are auto ramp test, constant
voltage measurement in standby mode
at each range, remote test, and 0- and
180-degree phase-angle switch (which
permits quick tests and consistent read-
ings). Testing time is 200 to 2000ms.
Kyoritsu KEW India Instruments
www.kew-ltd.co.in
Digital multimeter
Kusam-Meco has introduced a 3½-digit,
1999-count digital multimeter with
terminal blocking system.
KM-6030 features precise
design, convenient oper-
ation, high performance
and multifunction. It has
a large LCD (28mm).To
avoid improper connection
operation, the current terminal sockets
are blocked by a mechanical protection
device when the range switches in V, Ω
or Hz function. It is equipped with PTC
and vice versa element at the input ter-
minal, which provides efficient protec-
tion for many functions.
The multimeter not only measures
AC/DC voltage, AC/DC current, resist-
ance, capacitance, frequency and temper-
ature but is also capable of transistor hFE
test, diode test and data hold function.
Kusam Electrical Industries Ltd
www.kusam-meco.co.in
tools & equipment
Software reference design
NI has announced MAC layer sup-
port for its LabVIEW Communica-
tions 802.11 Application
Framework, allowing
wireless research-
ers to go beyond the
PHY layer to address
complex network-level problems that
must be solved to make the 5G vision a
reality. Wireless researchers can pair the
802.11 Application Framework with NI
software-defined radio hardware to rap-
idly conduct network-level, real-time,
over-the-air prototyping experiments
for a wide range of Wi-Fi and 5G MAC/
PHY research.
New Products
88 January 2018 | ElEctronics For you www.EFymag.com
The framework supports up to 80MHz
of real-time bandwidth and full bidirec-
tional communications and includes MAC
layer features including CSMA/CA, RTS,
CTS, NAV and retransmission.
NI
www.ni.com
8051 development kit
ARTech Electronics has launched A-123, an
advanced microcontroller kit for 8051
developers. A-123 includes
all peripherals on a single
board. It uses IC ZIP socket
to allow easy replacement
of microcontrollers. Its sepa-
rate 5V and 12V power sup-
plies can drive different peripherals.
The experimental board includes
almost all major embedded attributes
like serial communication, interrupt
base, and multiple seven-segment dis-
plays. It also includes DC and stepper
motor along with relays.
ARTech Electronics
www.artechlabs.in

Automated X-ray inspection system
Omron claims to have introduced the
world’s fastest inline automated X-ray
inspection system, VT-X750. The new
system increases automated inspection
speed based on 3D-computed tomogra-
phy (3D-CT). The expanding inspection
logic enables full, in-line inspection
coverage. Unique 3D-CT reconstruc-
tion algorithms provide solder-shape
recognition and defect detection. Dense
and dual-sided board design can present
challenges for X-ray inspection. How-
ever, Omron’s 3D-CT technology can
overcome such design restraints.
Omron Europe B.V.
inspection.omron.eu
IoT modem
Unisem Electronics’ new GSM/GPRS
modem is based on the wireless, low-
power SIM800C module (quad-band
GSM/GPRS solution), enabling rapid IoT
application development.
The modem can be powered by a
standard 12V supply or a single-cell
Lithium-ion battery. It has TTL inputs/
outputs, UART and USB connections
on theboard, allowing users to connect
with the MCU or PC to transfer data/send
AT commands and update firmware for
the module, respectively. There is also
an option to switch between RS232 and
UART (TTL) using jumper settings. The
modem is easy to scale and customise.
Unisem Electronics
www.unisemholdings.com
MCU platform
Enabling developers to quickly and
securely connect Internet of Things (IoT)
endpoints to the cloud, Texas Instru-
ments has integrated new
Amazon FreeRTOS into
SimpleLink microcontroller
(MCU) platform. The integrated
hardware and software solution enables
developers to quickly establish a con-
nection to IoT service out-of-the-box and
immediately begin system development.
TI’s SimpleLink Wi-Fi CC3220SF
wireless MCU LaunchPad development
kit, which supports Amazon FreeRTOS,
offers embedded security features such as
secure storage, cloning protection, secure
bootloader and networking security.

Texas Instruments
www.ti.com
misCellaneous
Dome network camera
VIVOTEK has launched a multi-adjustable
sensor dome camera, MA8391-ETV. Featur-
ing four independent 3-megapixel CMOS
sensors, MA8391-ETV allows users to simul-
taneously view four different
areas while occupying only
a single IP address. This not
only reduces the installation
time and total number of cam-
eras needed but also management effort and
maintenance costs. Due to its unique and
small design, the camera is perfect for sur-
veillance of large areas, such as parking lots
and shopping malls, as well as spaces like
hallways intersections and building corners.
VIVOTEK
www.vivotek.com
Biometric attendance system
To meet government organisations’
requirements for employee time tracking,
Matrix has introduced a fingerprint and
RFID card based, Aadhaar-enabled time-
attendance terminal. Cosec Vega Faxq is
claimed to be the first embedded Linux-
based, Aadhaar-enabled biometric device
registered on AEBAS server. The device
offers unique advantages in terms of con-
nectivity, technology, usage environment
and ease of use. It supports fingerprint as
well as Mifare smart card as credentials.
Matrix Security Solutions
www.matrixaccesscontrol.com
Floodlights
NTL Lemnis has launched
Pharox Flare Plus flood-
lights in 40W, 80W, 120W
and 160W. These professional-range flood-
lights are claimed to meet optimal lighting
requirements while being energy-efficient.
The 40W and 80W versions are general
lights suitable for high lighting, area light-
ing and indoor lighting in areas such as
airports and atriums. The 120W and 160W
versions are more tuned for crane lighting
and light towers, and therefore find indus-
trial and outdoor lighting applications.
These floodlights cost ̀ 5200 for 40W,
` 10,400 for 80W, ` 15,600 for 120W and
` 20,800 for 160W.
NTL Lemnis
www.pharoxglobal.com
Solar inverter
Luminous’ Regalia wall-mounted inverter
battery system directly powers your home
and charges batteries using the regular
mains along with the option to convert solar
energy into electricity to create
an effective power backup for at
least ten hours. The system uses
Wi-Fi connection and a mobile
app to configure with users’
smartphone and update them on
the amount of electricity being consumed by
their electrical appliances and the status of
their inverter battery. It also enables them to
control their electrical appliances with the
help of its smartphone application.
Luminous
www.luminouseshop.com
make in india
90 January 2018 | ElEctronics For you www.EFymag.com
solar installation. According to BNEF, rooftop
solar in India will grow inevitably with or
without the support of power distribution
utilities. India will need to invest $23 billion
over the next five years to meet its 40GW
rooftop photovoltaics target by year 2022.
The cost of electricity from rooftop
PV has halved in the last five years due to
fierce competition in the market and drop
in equipment prices. In contrast, average
retail electricity rates have increased by 22
per cent during the same period. This has
made rooftop PV cheaper than commercial
and industrial grid tariffs in all major states
of India.
However, BNEF expects residential sector
PV growth to pick up rapidly post-2021. At
the moment, its attractiveness is being held
back by the requirement of high upfront
capital expenditure, shortage of financing
options, and the fact that grid electricity is
cheaper for residential consumers with low
consumption.
BNEF experts also indicate that net
metering is a far more important enabler for
residential small-scale solar than business-
scale projects.
Homeowners usually draw less power
during the hours when their PV panels
are producing, making self-consumption
much harder. Solar projects also have a big
and untapped potential to power irrigation
pumps and reduce the use of back-up diesel
The Indian government has set its sights on having 175GW of non-hydro renewable capacity (made up of 60GW
onshore wind, 60GW utility-scale solar, 10GW
bio energy, 5GW small hydro and 40GW
rooftop solar) by 2022. At present, this figure
stands at just 60GW.
India is accelerating development of
renewable energy projects to provide cheap,
reliable and clean power to its 1.3 billion
people. The country’s per-capita on-grid elec-
tricity consumption increased by 22 per cent
over the four years ending March 2017 due to
increased industrial activity, higher uptake of
electrical appliances by residential electricity
users and addition of new consumers to the
grid—according to a report by Bloomberg
New Energy Finance (BNEF).
Majority of the capacity in the 2022
target—a total of 135GW—is utility-scale
(wind farms and solar parks, in particular).
The BNEF report estimates that India will
need to invest $83 billion to build this capac-
ity. The good news is
that, because of falling
capital costs per MW,
that figure is $19 bil-
lion less than BNEF’s
previous estimates.
But some of the
most interesting activi-
ty will be in small-scale
solar, that is, rooftop
Solar rooftop
PV Plant Installation
Project Report
Research Team, ComConnect Consulting
Fig. 1: Annual rooftop
PV installations in
India; India’s financial
year is from April
to March (Source:
Bloomberg New
Energy Finance,
industry surveys,
Ministry of New and
Renewable Energy)
FY2013 2014 2015 2016 2017
CAG
R: 1
17%
MW
715
227
165
7832
make in india
A guide to
starting rooftop
solar installation
business in India
make in india
92 January 2018 | ElEctronics For you www.EFymag.com
generators. Huge growth of
rooftop solar presents busi-
ness opportunities in rooftop
solar system installation.
This project report pro-
vides a brief overview of solar
rooftop PV plant installation
service. Thus it acts as a guide
on how to start a business in
this area.
Components required
Components of a rooftop
solar system are the same
anywhere in the world. That
said, however, some compo-
nents make more sense for
some regions than others.
For regions such as India
and Africa that are keen to
use rooftop solar as a source
of backup power during grid
power outages, batteries
could be required at least in
select cases. For developed
countries such as USA and
the European Union where
grid outages are rare, batteries are
usually not required as backup, with
grid supplying the deficit power.
Similarly, some regions of the
world require use of trackers for
rooftop solar as their rooftop areas
are smaller than required to meet
their power needs. For some other
regions, trackers might not make a
good business case.
Key components of a rooftop solar
plant include:
Solar photovoltaic modules
(panels). There are two kinds of
modules, viz, thin-film and crystal-
line. Rooftop solar plants predomi-
nantly use crystalline panels because
these are more efficient and there-
fore better suited to rooftop instal-
lations where spaceis a constraint.
Panel efficiency and capacity rating
are two important parameters of
solar panels.
Inverters. Inverter determines the
quality of AC power you get, and also
the kind of loads that can be powered
with solar. Different inverters support
different levels of starting current
requirements, which affects the kind
of machinery that can be run on solar
power. Inverters are also the only
major component of the solar plant
that are replaced during the lifetime
of the plant.
Mounting structures. Solar
panels are mounted on iron fixtures
so that these can withstand wind
and panel weight. The panels are
mounted to face south in the north-
ern hemisphere and north in the
southern hemisphere for maximum
power tracking. Panels are tilted at
an angle equal to the latitude of that
location.
Proper design of mounting struc-
tures is crucial for the power plant
performance as the power output
from the PV plant cannot be max-
imised if the mountings buckle and
panels are not optimally oriented
towards the sun. In addition, improp-
erly mounted panels present a ragged
appearance that is not pleasing to the
eye. Mounting structures should also
allow sufficient air circulation to cool
the PV panels as rooftop PV plant
output falls with temperatures rising
above 25°C.
Solar trackers. Tracking is a
mechanism for panel mounting that
allows panels to follow the sun as
it moves across the sky. Single-axis
trackers follow the sun as it moves
from east to west during the day,
while dual-axis trackers also
follow the sun on its north-
south journey over the course
of a year.
Trackers can increase the
power output of a PV plant
but add significantly to both
the initial cost of the plant and
maintenance expenditure. So
trackers should be used on a
case-to-case basis after per-
forming a cost-benefit analysis
over the lifetime of the rooftop
plant.
Batteries. A battery pack
can add 25-30 per cent to
the initial cost of a rooftop
PV solar system for one-day
autonomy (storing an entire
day’s output). Inverters with
integrated charge control-
lers are preferred so that the
inverter can direct grid power
or solar power, based on the
availability and demand, to
charge batteries. This extends
the battery life compared with
standalone charge controllers that
allow parallel charging between grid
and solar power at different power
levels, damaging the battery. If batter-
ies are required, it is vital to perform
a lifetime cost-benefit analysis to
understand the impact on the cost of
rooftop solar power.
Other miscellaneous items required
include:
1. Power-conditioning unit
2. Array junction box (AJB)/DC
distribution box array junction box/
DC distribution box
3. Common AC distribution box
4. Common AC distribution panel
board
5. Cables; DC cables carry current
from panels to inverters, while AC
cables carry current from inverters
to loads
6. Wire
7. Lightning protection
8. Earthing protection
9. Jet pump
Basics of rooftop solar PV
Solar PV panels (also known as solar
PV modules) work by converting sun-
light into electricity. These do not use
the heat from the sun, and can, in fact,
output reduced power in hot climates.
Fig. 2: Block diagram for a grid-connected rooftop PV plant
Import
meter
Export
meter
AC
DC
Domestic
loadElectric grid
Charge
controllerRooftop PV
Battery
Inverter
Fig. 3: Process flow for a grid-connected rooftop PV plant
Sun to Solar Panel
As sunlight hits a
solar cell, energy
is absorbed by the
cell’s silicon, which
is a semiconductor
material. Electrons
are forced to flow in
one direction, creating
direct current.
Solar Panel to
Inverter
Direct current (DC)
is sent from the
panels to an inverter,
which converts it to
alternating current
(AC). AC is used
by lights and other
appliances.
Inverter to Meter
The AC power
is sent from the
inverter to an
electrical panel that
distributes electricity
to the home or
institution.
Meter to Grid
When more power is
generated than used,
it flows into grid and
meter turns in reverse.
When power use is
greater, it flows from
grid and meter moves.
The bill is based on net
difference.
make in india
93www.EFymag.com ElEctronics For you | January 2018
economics of battery technology.
Types of mount. Mounting sys-
tems for rooftop installations are avail-
able for both inclined and flat roofs.
A variety of mounting systems are
available, the most common being
railed, rail-less and shared rail. All
these systems require some type of
penetration or anchoring onto the roof,
whether attached to rafters or directly
to the decking. The standard residential
systems use rails attached to the roof
to support rows of solar panels. Each
panel, usually positioned vertically/
The electricity generated by PV
panels is direct current (DC), which
needs to be converted into alternat-
ing current (AC) using an inverter.
Panels are mounted on the roof-
top using special mounting struc-
tures. If solar power is required when
sunlight is not enough for the panels
to generate electricity (such as at
night), battery backup is required.
Types of solar PV systems. Grid-
tied systems are a combination of
solar PV and grid. As these systems
depend on the grid-supplied refer-
ence voltage for their operation,
grid-tied systems do not work when
the grid is down.
Grid-interactive systems work
in conjunction with either battery
backup or diesel generator to support
loads even during power failure.
Off-grid systems operate inde-
pendent of the grid. These systems
sync with diesel generators and/or
batteries. Battery-based systems were
uncommon in the past due to their
high costs. However, the situation is
changing now, given the improved
Various components of rooftop solar
installations come with varying periods
of warranty:
PV panels. Industry-standard warranty
is 10 years on the product and 25 years
on performance.
Other systems. Inverters, mounting
structures, cables, junction boxes, etc
typically come with a 1-5-year product
warranty, which is extendible subject to
conditions.
Warranty portrait-style, attaches to two rails with clamps. The rails secure to the roof by
a type of bolt or screw, with flashing
installed around/over the hole for a
watertight seal.
Business economics
Solar business models include:
1. Service-based operation. Types
of services being solar rooftop power
plant installation and maintenance
2. Operational model. Just-in-time
sourcing of components and products
as per the project requirement
3. Financial model. A low-cost
model where investment is done for
mainly fixed and variable cost heads.
Raw material or tools are purchased
after order confirmation by the cus-
tomer, utilising the advance from the
customer.
Fixed-cost items include:
1. Company registration
2. Solar installation training
3. Certification
4. Miscellaneous fixed assets
(laptop, smartphone, etc as per
requirement)
make in india
94 January 2018 | ElEctronics For you www.EFymag.com
Table V
Final CosT oF a
RooFTop pV sysTem
aFTeR subsidies
item
Cost of a 100kW rooftop solar
plant
` 6,000,000
Subsidy at 30 per cent ` 18,000,000
Net cost after subsidy ` 4,200,000
Accelerated depreciation at 40
per cent
` 2,680,000
Tax rate 35 per cent
Tax saved through depreciation ` 588,000
net cost after accelerated
depreciation and subsidy
` 3,612,000
Table iV
CosT CalCulaTion aFTeR
inCome Tax subsidy
item
Cost of a 100kW rooftop solar
plant
` 6,000,000
Amount deducted from income ` 6,000,000
Tax amount saved at 30 per cent
income tax
` 18,000,000
net capital cost to the installer ` 4,200,000
Table iii
CosT CalCulaTion
aFTeR CapiTal subsidy
item
Cost of a 100kW rooftop solar
plant
` 6,000,000
Subsidy at 30 per cent of
actual cost
` 18,000,000
net cost after subsidy benefit ` 4,200,000
Table ii
an illusTRaTion oF
Tax saVings FRom
aCCeleRaTed
depReCiaTionbeneFiT
item
Cost of a 100kW rooftop solar
plant (A)
` 6,000,000
Accelerated depreciation at 40
per cent
` 2,400,000
Corporate tax rate 35 per cent
Tax saved through deprecia-
tion (B)
` 840,000
net cost of rooftop solar
plant (a-b)
` 5,160,000
Table i
CosT oF diFFeRenT
RooFTop poweR planT
ComponenTs
Component Cost per watt (`)
Solar modules 32-35
Inverters 6-12
Cables 1-2
Structures 1.7-5
Peripherals 2
Supervision, design and
installation
4
Variable-cost heads include:
1. Human resource
2. Marketing
3. Office space
Detailed business economics,
including estimated value against
the above-mentioned cost heads
and other probable cost heads, along
with breakeven point (BEP) calcula-
tion can be worked out based on the
scale of operation desired. However,
an overview of solar rooftop power
plant installation cost and relevant
subsidies and incentives is given
below.
Solar rooftop power plant instal-
lation cost. Rooftop solar power
plant installation costs roughly `
55-60 per watt depending on the
quality of components selected. Costs
of different rooftop power plant com-
ponents are listed in Table I. The table
does not include battery backup as its
cost depends on the extent of backup
opted for. Not only do batteries add
to the initial cost, recurring mainte-
nance and replacement expenditure,
the energy loss on charging and draw-
ing from the battery also add to the
electricity cost.
Subsidies and incentives avail-
able for rooftop solar PV plants.
Several incentives are available for
rooftop solar PV plants. Broadly,
these can be categorised as acceler-
ated depreciation, capital subsidy
and income tax credits.
Accelerated depreciation of 80 per
cent was available until March 2017
under the Income Tax Act for rooftop
solar PV systems, which was halved
to 40 per cent from April 1, 2017
onwards. It can provide significant
savings to a solar plant developer
who is a taxable assesse and has
sufficient profits against which the
depreciation can be charged. Table
II gives an illustration of tax sav-
ings from accelerated depreciation
benefit.
Capital subsidy is provided in
many countries for the investment
made in rooftop solar power plants.
Table II shows calculation for an
assumed capital subsidy of 30 per
cent.
Investment tax credits has a
similar concept as capital subsidies.
Here, instead of a direct subsidy on
the capital cost, the income tax is
deducted by the amount of incen-
tive. The subsidy calculation is
illustrated in Table III for an assumed
income tax of 30 per cent.
Table IV shows the final cost of a
rooftop PV system factoring in subsi-
dies but without batteries. This is an
estimate for commercial properties,
hence includes accelerated depre-
ciation. A similar estimation can be
done for residential properties by
including investment tax credits as
the incentive in place of accelerated
depreciation.
1. http://jercuts.gov.in/writereaddata/UploadFile/DPRLT_1632.pdf
2. http://npti.in/Download/MBAInternshipProject/Renewable/38_Naveen%20Kumar/PDF%20of%20
Report.pdf
3. http://www.teda.in/uploads/sanction/9383195852.pdf
4. https://www.google.co.in/search?ei=qHsSWsXABcL7vATwyrTQCA&q=rooftop+solar+power+
plant+project+report&oq=rooftop+solar+pv+system+project+for+home+and+office&gs_
l=psy-ab.1.3.0i71k1l4.0.0.0.12931.0.0.0.0.0.0.0.0..0.0....0...1..64.psy-ab..0.0.0....0.ecFHTnYkDjY
5. Bloomberg New Energy Finance (BNEF) press releases
6. https://www.bijlibachao.com/solar/india-solar-photovoltaic-pv-panels-selection-guide-
understanding-system-quality.html
References
Do-it-yourself
95www.efymag.com electronics for you | January 2018
Arduino-Based Two-Wheel
Self-Balancing Segway
Somnath Bera
Preeti
Bhakta &
Sani theo
Segbot, Segway and inverted pendulum—two-wheel self-balancing robots are known by
many names. Here we build a two-
wheel self-balancing robot (segway)
using an MPU-6050 chip. The inertia-
measuring MPU-6050 chip has six
motion sensors—three gyros and three
accelerometers—all integrated into
one breakout board.
Here, we only need angular posi-
tion or gyro of the wheel’s axis. Gyro
readings drift over time, requiring
recalibration quite often. Therefore,
to get correct angular position, gyro
readings are corrected with the help
of a neighbouring accelerometer. Once
the angular position is achieved, trac-
tion motors push the cart towards the
direction of falling. The greater the
angle of shift, the greater the speed
with which the traction motor pushes
the cart. As the angle of shift wrt verti-
cal position reduces to zero, the speed
reduces. Thus, the top of the cart
moves like a pendulum, maintaining
the balance. The author’s prototype is
shown in Fig. 1.
Circuit and working
Circuit of the two-wheel self-balancing
robot is shown in Fig. 2. It is built
around an Arduino Uno (Board1),
dual full-bridge driver L298N (IC1),
5V regulator 7805 (IC2),
MPU-6050, two DC motors
and a few other components.
Motors. We have used
two 12V, 300rpm, geared
and brushed DC motors and
two 100mm wheels. Initially,
brushed motors work fine
but over time, with use, these
tend to develop instability
and inability to balance the
robot. The best option is to
use brushless DC motors, which have
great torque-to-rpm characteristics.
However, these have a direction rever-
sal problem.
Another option is to use stepper
motors, but their lesser rpm hinders
balance. However, there are reports
of people successfully using stepper
motors with Segway bots.
L298N. Motor driver L298N is
available either in a multiwatt15 or
powerSO20 package. It is a high-cur-
rent, dual full-bridge driver for induc-
tive loads including relays, solenoids,
DC and stepping motors. Two enable
inputs (pins 6 and 11) are provided
to enable or disable the device inde-
pendently of the input signals. One
bridge is driven by IN1, IN2 and EN
A, and the other by IN3, IN4 and EN
B pins of IC1.
Software
We have used Jeff Rowberg I2Cdev
libraries for MPU-6050. Arduino Uno
board is programmed with the main
program two_wheel.ino. The main
software has three variables: kp, kd and
ki. Default values work well but can be
changed to provide more
stability to the robot. To
change the values, you
need mpu_calibration.
ino code as explained in
Calibration section.
Compilation. There
was a minor glitch while
compiling the sketch
on Arduino IDE 1.1 as
MPU-6050 libraries were
not getting installed.
So we installed Ardui-
no 1.5.7 and imported
libraries from the main
menu by indicating the
correct location of librar-
ies with Sketch→Import
Library→Add Library
options. After all the
libraries get added to
Fig. 1: Author’s prototype
Fig. 2: Circuit diagram of two-wheel self-balancing robot
CON2
M1
CON3
M2
BATT.1
12V
1
2
3IC2
7805
D5
LED1
POWER
C3
0.1uC2
R1
1K
C1
D3D1 D2 D4
D8D7D6
CON1
MPU−6050
S1
ON/OFF
FOR
FOR
POWER USB
DRIVER
A
T
M
E
G
A
328
AREF
GND
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RST
3.3V
5V
GND
GND
Vin
A0
A1
A2
A3
A4
A5
INPUT
TX
RX
A
R
D
U
IN
O
D
IG
IT
A
L
A
N
A
LO
G
IOREF
BOARD1
FOR
5 IN1
9
Vss
8
GND
7
IN2
10
IN3
12 IN4
6
EN A
11
EN B
4
VS
2
OUT1
3
OUT2
14
OUT4
13
OUT3
1
CS A
15
CS B
IC1
L298N
GND
5V
GND
SDA
SCL
D1−D8 = 1N4007 C1−C2 = 100u, 25V
DC MOTORS
M1,M2 = 12V GEARED
Do-it-yourself
96 January 2018 | electronics for you www.efymag.com
Fig. 3: Actual-size PCB layout of two-wheel self-balancing robot
Arduino IDE, compile the sketch and
upload it to the board.
Construction and testing
An actual-size PCB layout of the two-
wheel self-balancing robot is shown
in Fig. 3 and its components layout
in Fig. 4. Use a suitable metallic chas-
sis for the robot. Mount the Arduino
board on the chassis of the robot.
Then place the PCB on top of the
Arduino board.
First, burn the mpu_calibration.
ino code into Arduino, attach the
MPU-6050 and upload the sketch to
the Arduino board. Thenopen the
serial monitor and select baud rate as
115200. After initialisation of the DMP
(digital motion processing)—on-board
processor of the MPU-6050—press ‘a’
followed by Enter key. You will get a
screen as shown in Fig. 5. Note that
your offset values will be different.
Note down the offset values. Then
open the main two_wheel.ino code
and enter the test offset values. Com-
pile and upload the main code to the
Do-it-yourself
98 January 2018 | electronics for you www.efymag.com
The source code of
this project is
included in this month’s
EFY DVD and is also
available for free download
at source.efymag.com
efy Note
Somnath Bera is additional
general manager at NTPC Ltd.
He is an avid user of open
source software
that the robot is working well, put the
battery inside the chassis.
Calibration. As mentioned earlier,
gyro readings drift over time. To coun-
ter the problem, first you need to find
out the gyro offset for each different
set of gyros.
For MPU-6050 type gyros, here’s
the simplest way: First load mpu_cali-
bration.ino to your Arduino, attach
MPU-6050 on a horizontal surface,
stabilise it for some time, switch off all
the ceiling and table fans during cali-
bration, and get offset readings on the
serial monitor as mentioned earlier.
Insert these values in the offset fields
of the main program. Compile and
upload it to your Arduino processor
and then try to run the robot again. If
the robot is not working well, repeat
the calibration process until you get a
satisfactory result.
Note. The video clip of the author’s
project is available on YouTube link:
https://youtu.be/OQSRoFr_v4Q
Fig. 5: Offset values on serial monitor during calibration
Arduino. Connect the motors, battery
and switch on the circuit. Place MPU-
6050 along the wheel axis of motors to
ensure minimal error of calculation.
First, run the robot with a light-
weight 12V battery. The best way is
to first use a 12V AC/DC adaptor for
the power supply. Once you are sure
Fig. 4: Components layout for the PCB
Parts List
Semiconductors:
Board1 - Arduino Uno board
IC1 - L298N motor driver
IC2 - 7805, 5V regulator
MPU-6050 - Motion sensor (GY-521)
D1-D8 - 1N4007 rectifier diode
LED1 - 5mm LED
Resistors (all 1/4-watt, ±5% carbon):
R1 - 1-kilo-ohm
Capacitors:
C1, C2 - 100µF, 25V electrolytic
C3 - 0.1µF ceramic disk
Miscellaneous:
S1 - On/off toggle switch
BATT.1 - 12V rechargeable battery
M1, M2 - 12V, 300rpm geared DC
 motors
CON1 - 8-pin female connector for
 MPU-6050
CON2, CON3 - 2-pin terminal connector for
 motors
CON4 - 2-pin terminal connector for
 power supply
CON5 - 6-pin female connector
 - 6-pin male connector for shield
 - 2x8-pin male connector for
 shield
 - 10-pin male connector for
 shield
 - 2-pin terminal connector for
 battery
 - Jumper wires
 - 100mm dia. wheels
 - Robot metallic chassis
 - Heat-sink for IC1 and IC2
Do-it-yourself
100 January 2018 | ElEctronics For you www.EFymag.com
Presented here is a digi-tal clock that also func-tions as a rechargeable
light lantern and a mobile
charger. The clock has all
the basic functions like date-
time display, alarm and room
temperature display. It is
powered by a lead-acid bat-
tery, which can be recharged
through solar power or mains
power supply. So the clock
never runs out of power.
The clock is provided
with a female USB socket,
which can be used to charge
most of your mobile phones
and gadgets. Its dedicated
battery charging and load
cut-off circuitry takes care
of the battery through exact
charging topology and pre-
vents it from getting over-
charged or under-charged.
Block diagrams
The functional unit of the
clock is divided into power unit and
main clock unit. Block diagram of the
power unit is shown in Fig. 1.
The power unit provides con-
tinuous power to the clock and other
circuits. Its lead-acid battery can be
charged through solar power or AC
mains power. The battery manage-
ment circuit is designed to accept
power from two sources at the same
time but gives priority to the mains
power. So if the solar power is low or
unavailable, users can plug the bat-
tery into the AC mains wall supply to
charge it.
A solar photovoltaic panel is used
to directly convert solar light and heat
energy into electricity. To harness AC
mains power for the circuit, a step-
down transformer is used. It converts
high-voltage AC into low-voltage
AC. This AC voltage is rectified and
current-limited load switch is
used to derive 5V rail, which
is current-limited to 500mA
for USB charging applica-
tions in order to prevent USB
application from immediately
discharging the clock battery.
Block diagram of the main
clock unit is shown in Fig. 2.
The microcontroller in the
circuit keeps track of all the
sensors and switches con-
nected to it, makes decisions
and calculations, and finally
updates the display section. In
this section, the non-current-
limited 5V rail from the power
section is converted into
3.3V rail via a 3.3V LDO volt-
age regulator (UCC383) that
powers the microcontroller
and other peripherals.
To sense the room temper-
ature, a temperature sensor
is used. Its output is an ana-
logue signal proportional to
the temperature. This signal
is fed to one of the analogue-to-digital
converter channels of the microcon-
troller. The user inputs are sensed
by three momentary push-to-on
switches, which are used to set/check
various parameters of the clock like
alarm, date, etc.
Time keeping is done by a sepa-
rate real-time clock (RTC) chip that
is interfaced to the microcontroller
via I2C bus. The RTC is also powered
by a backup battery, which keeps the
time running even if the AC mains
power fails.
The display section comprises four
7-segment displays, which are multi-
plexed to efficiently use the limited
pins available on the microcontroller.
The two centre LEDs between the two
pairs of 7-segment displays are driven
by the RTC clock. An RGB LED is used
to display AM/PM and date. Finally, a
Multifunction
RechaRgeable Digital clock
Abhishek kumAr
S.C. DwiveDi &
Sani Theo
converted into DC, and then further
smoothened by using capacitors as
low-pass filters. After this, the power
becomes acceptable for the battery
management circuit.
The lead-acid battery is directly
connected to the battery management
circuit, which takes care of battery
charging with charging voltage and
current maintained to acceptable
limits. This ensures longer battery life,
capacity and optimal usage.
Next, a comparator circuit is used.
It checks the battery voltage against
its internal reference voltage and shuts
off the load, thus preventing the bat-
tery from further discharging. A linear
low-dropout (LDO) voltage regulator
is used to derive regulated 5V from
the battery rail. This 5V rail is non-
current-limited and powers most of
the circuitry ahead, including LEDs. A
Fig. 1: Block diagram of power unit
Fig. 2: Block diagram of main unit
(Date/Alarm on-off)(Temp/View alarm)
MinusPlusSet
RGB LED
3V
backup
battery
BQ32000
Real time clock
I2C bus
Center LED drive
Multiplexed 7-segment display
ATMega8
microcontroller
LM35
Temperature
sensor
Buzzer
5V
input
3.3V
LDO
5V regulated output
(500mA current limited)
USB
charging
port
500mA
current
limiter
Low voltage
detector
circuit
6V, 4.5 AH
lead acid
battery
230V
AC
10-12 volt
7 watt solar
panel
5V, 3A low
dropout
linear
regulator
Lead acid
battery
management
circuit
LED lightening and
other circuitry
230V to 12V
step down
transformer
Do-it-yourself
102 January 2018 | ElEctronics For you www.EFymag.com
buzzer is used to acknowledge press-
ing of the user button and provide
alarm indication.
Circuit description
The clock circuit consists of power
unit, LED and USB charging unit, main
controller clock unit and 7-segment
display unit.
Power unit. Circuit diagram of
the powerunit is shown in Fig. 3.
Here 230V AC mains is first converted
into 12V AC using a step-down trans-
former. This 12V AC is converted
into around 17V DC using diodes D1
though D4 in bridge configuration.
This DC is further smoothened using
a 1000µF electrolytic capacitor (C1)
that acts as a first-order low-pass
filter. Ceramic capacitor C2 is used for
further stability of the 7812 regulator
(IC1).
The linear regulator IC1 is used
to derive regulated 12V DC, which
is fed to the relay coil and also to the
normally-open contacts of relay RL1.
A 10-12V, 7-watt solar panel (SP1) is
used to harness solar power. The elec-
tric power from the solar panel is fed
to the normally-closed (NC) contacts
of relay RL1 with a bypass diode (D7)
in series.
Diode D7 creates a voltage drop
in the solar panel’s output, so it is
recommended to use a diode that
has the least forward dropout volt-
age, such as Schottky diode 1N5822.
Diode D5, connected in parallel to the
relay, prevents back emf of the relay
coil from harming rest of the circuitry.
Now, as the solar panel’s output is fed
to NC contacts of the relay, when AC
mains power is not available, the relay
de-energises and thus solar power
directly feeds the charging circuitry.
When AC mains power is avail-
able, the relay energises and thus the
mains-derived 12V DC passes through
the relay, cutting off the solar power.
This way, during low solar power or
night times, the user can charge the
clock using AC mains power.
The common terminal of the relay
is connected to the charging circuitry,
which comprises BQ24450 (IC2). IC
BQ24450 contains all the necessary
circuitry to optimally control charging
of valve-regulated lead-acid batteries.
It controls the charging current as well Fig. 3: Circuit diagram of power unit
D
1
1N
40
07
B
A
T
T
.1
6V
,4
.5
A
h
C
O
N
1
C
2
10
0n
C
O
N
2
F
O
R
12
V
 A
C
F
R
O
M
 X
1
12
V
 D
C
F
R
O
M
 S
P
1
D
3
1N
40
07
D
2
1N
40
07
D
4
1N
40
07
C
1
10
00
u
25
V
F
O
R
X
1
=
 2
30
V
 A
C
 P
R
IM
A
R
Y

T
O
 1
2V
,1
A
 S
E
C
O
N
D
A
R
Y
T
R
A
N
S
F
O
R
M
E
R
1
2
3
IC
1
78
12
D
5
1N
40
07
 R
E
LA
Y
7
P
G
O
O
D
15
D
R
V
E
16 D
R
V
C 13V
F
B
14C
O
M
P
12
C
E
10
S
T
A
T
1
6G
N
D
1
IS
N
S
8
B
S
T
O
P
4
IF
B
2
IS
N
S
M
3
IS
N
S
P
5
IN
11
P
R
E
−
C
H
G
9
S
T
A
T
2
IC
2
B
Q
24
45
0
R
1
0.
47
E
R
26
22
0E LE
D
1
C
H
A
R
G
IN
G
R
10
47
0E
R
11
10
0E
R
12
47
E
R
13
22
E
D
6
1N
54
22
R
14
47
K
R
15
22
K
R
16
4.
7K
R
17
2K
R
25
47
0K
R
24
4.
7K
R
23
47
K
R
18
10
K
R
19
4.
7K
R
20
2K
R
21
22
0E
R
22
10
0E
1W
C
3
10
0n
V
IN
1
V
O
U
T
5
A
D
J
4
G
N
D
3
C
T
2
IC
4
U
C
C
38
3
V
+
8
O
U
T
4
G
N
D
3
−
IN
2
+
IN
1
Y
S
T
P
6
H
5
Y
S
T
N
H
R
E
F
7
IC
3
LM
P
73
00
S
1
M
A
IN
 L
O
A
D
 S
W
IT
C
H
R
2
1M R
3
47
0K
R
4
47
K
R
5
22
K
R
6
1M
R
9
1M
R
7
67
K
R
8
1M
R
27
15
0K
R
28
50
K
C
6
10
0n
C
5
22
0u
16
V
C
4
22
0u
25
V
G
N
D
C
O
N
3
F
O
R
5.
2V
 T
O
C
O
N
4
F
O
R
C
O
N
7
C
O
N
5
F
O
R
5.
2V
 T
O
C
O
N
6
5.
2V
 T
O
C
O
N
9
S
P
1
=
 1
0
−
 1
2V
7W
 S
O
LA
R

P
A
N
E
L
T
1 B
D
24
0
N
O
N
C
R
L1
12
V
,1
C
O
D
7
1N
58
22
Do-it-yourself
103www.EFymag.com ElEctronics For you | January 2018
as the charging voltage to safely and
efficiently charge the battery, thus
maximising battery capacity and life.
Here, IC BQ24450 is configured
as a simple constant-voltage float
charge controller for the 6V, 4.5Ah
battery. It is so flexible that it can be
programmed in various configurations
to suit different charging currents
and voltages for batteries of differ-
ent capacities. Only an external pass
transistor and very few external pas-
sive components are required along
with the IC to implement a charger for
sealed lead-acid batteries.
Here, a BD240 pnp transistor (T1)
is used to drive the battery charging
power. Before proceeding to battery
charger programming, please refer to
the datasheet of BQ24450. Note that
charging rate can be 0.05C to 0.3C.
We will use charging rate (Imax-chg)
= 0.13C = 600mA (approx).
In programming, there are parame-
ters to implement a dual-level charger
for the given battery chemistry. The
first step is to decide the value of
current in the voltage divider resis-
tor string in float mode. It should be
substantially higher than the input
bias current in CE and VFB pins and
the leakage current in STAT1 pin of
BQ24450, but low enough so that
the voltage on PGOOD pin does not
introduce errors. A value of 50µA is
suitable. Readers interested in calcu-
lations may go through the calcula-
tions_charging.doc file included in the
EFY DVD of this month.
LED1 in the BQ24450 circuitry
displays the battery charging status.
Schottky diode D6 prevents the back
current leakage from the battery.
Thereafter the circuit feeds the lead-
acid battery. Next, the battery rail goes
to the low-voltage detection circuit
and IC UCC383 (IC4) in series with a
mains mechanical load switch (S1).
The low-voltage-battery detection
circuit is built around comparator
LMP7300 (IC3), which has an internal
reference of 2.048 volts. The voltage at
which the battery should disconnect
from the load is around 1.75V per
cell, which means 5.25V for three-cell
batteries.
The comparator has open-collector
output, which goes low when the bat-
tery voltage drops below 5.25V. The
comparator output goes to CT pin of
IC4 in the next stage. Thus whenever
the battery voltage goes below 5.25
volts, the comparator output goes
low. This, in turn, switches IC4 off,
shutting down all the loads connected
to the battery and thus preventing the
battery from discharging further.
The potential divider network
comprising resistors R2 through R6
establishes 2.048V at the non-inverting
terminal of comparator IC3 when the
battery rail reaches 5.25V. It is com-
pared with the voltage at the inverting
terminal of the comparator, which is
directly connected to the reference
output of LMP7300. Further, a com-
bined negative and positive hysteresis
of about 300mV in total is programmed
to LMP7300 through R7 and R8, so
that the comparator output does not
fluctuate when the battery voltage
reaches the exact crossing point of the
comparator’s reference potential.
The UCC383 LDO is capable of
driving loads up to 3A with a maxi-
mum dropout of 0.45 volts, which
is excellent for this application. VIN
pin accepts the battery rail, which
nominally varies in the range of 6 to
7.5 volts while charging and 5.25 to 6
Fig. 4: Power LEDs and USB charging circuit
OUT
1IN5
GND
2
FLT 3EN/EN
4
IC5
TPS2051C
CON8
5V
C7
100u
R29
2E,1W
R30
2E,1W
S2
ON/OFF
S3
ON/OFFLED2 LED3 LED4
LED5 LED6 LED7
CON6
FOR
CON7
FOR
GND GND
FOR
16V
5V
GND
5.2V FROM
LED CIRCUIT
CON3
5.2V FROM
CON4
 USB CIRCUIT LED AND USB CIRCUIT
LED2−LED7 = 1W LED
Do-it-yourself
104 January 2018 | ElEctronics For you www.EFymag.com
volts during normal usage.
Through resistors R27 and R28,
the output voltage of IC4 is set to 5V.
Capacitors C4 through C6 are used
for stability of IC4. The 5V rail thus
obtained is used to power the rest of
the circuit.
LEDs and USB charging. Circuit
connections for power LEDs and the
USB charging socket are shown in
Fig. 4.
Here two pairs of 3x1-watt power
LEDs are used for lighting application.
A 2-ohm, 1W current-limiting resistor
is used to limit current in each pair
of LED channels in series with on/
off switches S2 and S3. These LED
channels receive power directly from
the non-current-limited 5V rail (from
the power unit). TPS2051C, which is a
500mA current-limited load switch, is
used to drive a 500mA-limited 5V rail
to power/charge the USB application.
We have used a current-limited
load switch to prevent the USB appli-
cation from fast draining the clock bat-
tery. However,it is optional. Capacitor
C7 is used for stability of the current
limiter.
For USB charging applications,
a female USB-A type jack is used. It
receives power from the 500mA, 5V
current-limited channel of the power
unit.
Main controller clock circuit.
Circuit of the microcontroller-based
main clock circuit is shown in Fig. 5.
Apart from general time display, it also
enables alarm function and indication
of date, month, year and temperature.
The circuit is built around
ATmega8 (IC8) microcontroller. IC8 is
used to update the display, sense user
inputs and take decisions. ATmega8
has 8kB of in-system programmable
Flash with read-while-write capa-
bilities, 512 bytes of EEPROM, 1kB
of SRAM, 23 general-purpose input/
output (I/O) lines, 32 general-purpose
working registers, three flexible
timers/counters with compare modes,
internal and external interrupts, a
serial programmable USART, a byte-
oriented two-wire serial interface, a
6-channel analogue-to-digital con-
verter (ADC) with 10-bit accuracy, a
programmable watchdog timer with
internal oscillator, an SPI serial port
and five software-selectable power-
saving modes, which are sufficient
enough for this application.
A separate in-circuit serial program-
ming port (CON12) is available for pro-
gramming the microcontroller. Time
keeping is done by RTC chip BQ32000
(IC7), which provides an automatic
backup supply using a 3V battery.
IC BQ32000 has a programmable
calibration adjustment from –63ppm to
+126ppm, so that it can also be used
with low-quality crystals. It includes
automatic leap-year compensation as
well. The RTC chip is connected to the
microcontroller via the I2C bus. This
project uses a 3V CR2032 lithium cell
Fig. 5: Main microcontroller clock circuit
CON9
FOR
5.2V FROM
GND
CON5
R31
10K
OSCO
2
OSC11
SCL 6
5SDA
IRQ 7
V3 BACK
GND
4
V 8CC
IC7
BQ32000
IN1
EN5
OUT
2
GND
3
NR/FB
4
IC6
TPS73733
2 PD0/RXD
3 PD1/TXD
4 PD2
6 PD4
8 GND
10 PB7/XTAL2
1 PC6/RESET
5 PD3
7 Vcc
11 PD5
9 PB6/XTAL1
12 PD6
13 PD7
14 PB0
27PC4/SDA
26PC3
25PC2
23PC0
21AVREF
19PB5/SCK
28PC5/SCL
24PC1
22AGND
18PB4/MISO
20AVcc
17PB3/MOSI
16PB2
15PB1
IC8
ATMEGA8
XTAL1
32.768KHz
T2
BC547
T3
BC547
T4
BC547
T5
BC547
BATT.2 3V
C9
10n
C10
10n
C12
10u
10V
10V
C11
10uC8
10u
10V
C13
100n
R32
R33
R34
R35
R36
R38
R37
S4
SET
S5
PLUS
S6
MINUS
R43
10K
1
V
cc
2
V
O
3
G
N
D
IC9
LM35
CON10 CON11
CON12
ICSP
g
f
e
d
c
b
a
RGB1
R47−R49=56E
R49
R48
R47
PZ1
R32−R38 = 120E
R44 R45 R46
R39
1K
R40
1K
R41
1K
R42
1K
1
1
2
2
3
3
4
4
5
6
FOR
C14
1u,10V
PZ1 = PIEZO
BUZZER
TO
CON15
R44−R46 = 4.7K
TO
CON14
CON13
FOR SECONDS
TO
CON16
1
2
Do-it-yourself
105www.EFymag.com ElEctronics For you | January 2018
for the backup supply.
For the internal oscillator func-
tioning, a 32.768kHz crystal is used
at OSC0 and OSC1 pins of IC7. IRQ
pin on the RTC chip is connected to
ATmega8 on port pin PD2 and is also
responsible for seconds indication
through the two LEDs (LED7 and
LED8) that are located between the
two 7-segment display pairs. Anodes
of the two coloured LEDs (in paral-
lel) are connected to IRQ pin, while
the cathode is connected to ground
on CON13. Three momentary push-
to-on switches (S4 through S6) are
connected to pins PD3, PC1 and PC2
of IC8, respectively.
Analogue temperature sensor
LM35 (IC9) is used for room tem-
perature sensing. The analogue signal
output of IC LM35 is proportional to
the temperature by the relationship
10mV/degree Celsius. It is interfaced
to the ADC of the microcontroller. The
sensor is connected to the ADC chan-
nel 3 (PC3) on ATmega8.
For display, four multiplexed
common-cathode 7-segment displays
(DIS1 through DIS4) are connected
via CON10. Their individual cathode
pins are connected to CON11, and
driven by transistors T2 through T5.
The RGB1 LED is connected to PB3,
PB4 and PB5 pins of IC8. The active-
low RESET pin on ATmega8 is pulled
up by a 10-kilo-ohm resistor (R31) and
also tied to a 10µF electrolytic capaci-
tor (C12) to prevent the controller
from regenerative resetting during
supply transients. AVREF pin, refer-
ence in/out pin for the ADC, is tied
to a 100nF ceramic capacitor (C13)
for stability, while AVCC (pin 20) and
AGND (pin 22) are power supply pins
for the ADC circuitry on the microcon-
troller. VCC (7) and GND (8) are power
pins for the rest of the circuitry on the
microcontroller.
You need not connect any crystal
to the microcontroller as its internal
1MHz R-C oscillator is used here. So it
is important to set correct fuse bits on
ATmega8 to configure it for the 1MHz
internal R-C oscillator.
TPS73733 LDO IC (IC6) is used to
power the clock circuit. It gets input
from non-current-limited 5.2V rail
of the power section. TPS73733 is a
3.3V, 1A regulator with a maximum
input voltage of 5.5 volts. EN pin is
used to enable the LDO, however here
we have tied it directly to IN pin for
continuous operation. Capacitors C8
through C11 are used for stability of
the LDO. An external capacitor (C9)
connected to NR/FB pin on the LDO
bypasses noise generated by the inter-
nal bandgap, reducing LDO output
noise to very low levels.
7-segment display unit. Circuit
of the multiplexed 7-segment display
unit is shown in Fig. 6.
It comprises four 7-segment dis-
plays arranged in pairs of two: one
pair (DIS1 and DIS2) on the left side to
display variables like hours and date,
and the other pair (DIS3 and DIS4) on
the right side to display variables like
minutes and month. CON14 through
CON16 in the display unit are con-
nected to display driving ports CON10,
CON11 and CON13, respectively, in
the main clock section (Fig. 5).
Software
The code for the ATmega8 microcon-
troller is written in BASIC language
using BASCOM-AVR compiler. After
initiating the code, allocate default
values to the EEPROM from location
one to four. The EEPROM is basically
used to hold the user-settable alarm
values. Starting from the first location,
it holds alarm hours, then alarm min-
utes, then alarm PM and finally the
alarm flag (which indicates whether
alarm is on or not).
You need to declare subroutines
to clear 7-segment displays, read RTC
chip, display value setting, etc. After
this, configure the ADC to run in
single-mode with auto prescaler and
internal 2.56V reference. Configure
the directions of input-output ports
and initialise them. Then configure
I2C pins and initialise them.
Next, initialise timer0 for multi-
plexing the 7-segment display, timer1
Fig. 6: 7-segment display unit
CON16
FROM
CON15
FROM
CON10
CON11
CON13
a7
f9
g10
e1
d2
c4
dp5
COM
3
b6
DIS1
a7
f9
g10
e1
d2
c4
dp5
COM
3
b6
DIS2
a7
f9
g10
e1
d2
c4
dp5
COM
3
b6
DIS3
a7
f9
g10
e1
d2
c4
dp5
COM
3
b6
DIS4
g
f
e
d
c
b
a
CON14
FROM
LED9
SECONDS
LED8
DIS1−DIS4 = COMMON CATHODE
7−SEGMENT DISPLAY
LTS543
1
1
2
2
3
4
R50
47E
Do-it-yourself
106 January 2018 | ElEctronics For you www.EFymag.com
Fig. 8: Actual-size PCB layout of power unit
Fig. 9: Components layout for the PCB in Fig. 8
Fig. 7: Fuse bits
Parts List
Semiconductors:
IC1 - 7812, 12V voltage regulator
IC2 - BQ24450 charge controller
IC3 - LMP7300 comparator
IC4 - UCC383 regulator
IC5 - TPS2051C power switch
IC6 - TPS73733 regulator
IC7 - BQ32000 RTC
IC8 - ATmega8 microcontroller
IC9 - LM35 temperature sensor
D1-D5 - 1N4007 rectifier diode
D6 - 1N5422 Schottky diode
D7 - 1N5822 Schottky diode
LED1, LED8,
LED9 - 5mm LED
LED2-LED7 - 1-watt white LED
RGB1 - RGB LED (4-pin)
T1 - BD240 pnp transistor
T2-T5 - BC547 npn transistor
Resistors (all 1/4-watt, ±5% carbon, unless stated
otherwise):
R1 - 0.47-ohm, 1-watt
R2, R6, R8, R9 - 1-mega-ohm
R3, R25 - 470-kilo-ohm
R4, R14, R23 - 47-kilo-ohm
R5, R15 - 22-kilo-ohm
R7 - 67-kilo-ohm
R10 - 470-ohm
R11, R22 - 100-ohm
R12, R50 - 47-ohm
R13 - 22-ohm
R16, R19, R24,
R44-R46 - 4.7-kilo-ohm
R17, R20 - 2-kilo-ohm
R18, R31, R43- 10-kilo-ohm
R21, R26 - 220-ohm
R27 - 150-kilo-ohm
R28 - 50-kilo-ohm
R29, R30 - 2-ohm, 1-watt
R32-R38 - 120-ohm
R39-R42 - 1-kilo-ohm
R47-R49 - 56-ohm
Capacitors:
C1 - 1000µF, 25V electrolytic
C2, C3, C6, C13 - 100nF ceramic disk
C9, C10 - 10nF ceramic disk
C4 - 220µF, 25V electrolytic
C5 - 220µF, 16V electrolytic
C7 - 100µF, 16V electrolytic
C8, C11, C12 - 10µF, 10V electrolytic
C14 - 1µF, 10V electrolytic
Miscellaneous:
CON1, CON2 - 2-pin terminal connector
CON3-CON7,
CON9, CON13,
CON16 - 2-pin connector male and female
CON8 - USB A-type connector
CON10, CON14 - 7-pin connector male and female
CON11, CON15 - 4-pin connector male and female
CON12 - 6-pin connector male and female
PZ1 - Piezobuzzer
RL1 - 12V, 1CO PCB-mounted relay
SP1 - 10-12V, 7W solar panel
S1-S3 - On/off switch
S4-S6 - Push-to-on tactile switch
BATT.1 - 6V, 4.5Ah rechargeable battery
BATT.2 - 3V cell (CR2032)
XTAL1 - 32.768kHz crystal
X1 - 230V AC primary to 12V, 1A
 secondary transformer
DIS1-DIS4 - LTS543 common cathode
 7-segment display
 - USB-to-micro USB cable for
 mobile charging
 - 230V AC mains power supply
Do-it-yourself
107www.EFymag.com ElEctronics For you | January 2018
for handling the alarm duration and
timer2 for blinking the segments
while the clock is in ‘Settings’ mode.
After this, declare and initialise cer-
tain variables for ADC calculations,
time seeking, etc. Then initialise I2C
pins, read EEPROM contents for alarm
values and initiate an infinite super-
loop where the RTC chip registers are
read and displays are updated continu-
ously. Also in the same loop, the user
inputs are acknowledged and associ-
ated events like setting alarm on/off
and displaying date-time are initiated.
Also, the current time is compared
against the alarm variables and alarm
is initiated when the time is matched.
Note that while burning the hex file
solarclock.hex to the microcontroller,
the EEPROM file solarclock.eep must
also be programmed. At EFY
Lab, PROGISP programmer
was used to program solar-
clock.hex and solarclock.
eep. Fuse bits should be
D9=high and E1=low as
shown in Fig. 7.
The clock
Charging. As mentioned
earlier, the clock can be
charged from solar power
as well as AC mains power.
Install a 10-12V, 7W solar
panel on the rooftop such
that it receives sufficient
sunlight throughout the
day. Route connections
from the solar panel (SP1)
carefully to the clock’s
charging terminals, keeping
in mind the correct polarity.
Solar power is more
than enough to provide
continuous power to the
clock forever, and the clock
Fig. 10: An actual-size, single-side PCB of LED and
USB circuit
Fig. 11: Components layout for the PCB in Fig. 10
Fig. 12: Actual-size PCB layout of main clock controller circuit Fig. 13: Components layout for the PCB in Fig. 12
can work for more than 60 hours on a
single charge. But when solar power
is not available on cloudy days or at
night, users can charge the clock using
230V AC mains power. The solar panel
rail is automatically cut off while
charging through AC mains power.
This way the clock never runs out of
power. Switch S1 can be used to cut off
all the load from the battery.
The two 3x1-watt LED modules
can be individually switched on as
required. Using the USB jack, you
can charge all possible USB applica-
tions. Thus the project also functions
as a solar-powered USB charger. The
charging status is indicated by LED1 in
the power unit, where a glowing LED
means the battery is charging. The
power unit circuit can automatically
shut off the load when the battery
voltage reaches the state of discharge.
Settings. The clock automatically
turns on when the mains load switch
(S1) is closed. The user-interface of
the clock is designed such that only
three buttons (S4 through S6) are
required to set the various parameters
like current time, hours and date-time,
and to display the current date-time,
set alarm and room temperature.
The Plus button can be used to
increment the values in ‘Settings’
mode. Pressing it once during normal
time display mode, first displays the
room temperature and then the set
Do-it-yourself
108 January 2018 | ElEctronics For you www.EFymag.com
The source code of
this project and
calculations_charging.doc
file are included in this
month’s EFY DVD and
are also available for
free download at
source.efymag.com
efy Note
Fig. 14: Actual-size PCB layout of 7-segment display unit (Fig. 6)
Fig. 15: Components layout for the PCB in Fig. 14
assembling the circuit on the PCB,
connect CON1 to the secondary of
transformer X1, and CON2 to 10-12V,
7W solar panel. Extend CON3 through
CON5 to other sections using proper
connectors. Enclose the PCB in a suit-
able cabinet.
An actual-size PCB layout of the
power LED and USB charging circuit
(in Fig. 4) is shown in Fig. 10 and its
components layout in Fig. 11. After
assembling the circuit on the PCB,
connect CON6 to CON3 in Fig. 3, and
CON7 to CON4 in Fig. 3. Use CON8
for mobile charging through the
USB cable. Affix all the LEDs (LED2
through LED7) on the top or front side
of the cabinet.
An actual-size PCB layout for the
main clock controller circuit (in Fig. 5)
is shown in Fig. 12 and its components
layout in Fig. 13. After assembling the
circuit on the PCB, connect CON9 to
5.2V from CON5 in Fig. 3. Connect the
RGB1 LED and switches S1 through S6
on the front side of the cabinet.
An actual-size PCB layout of the
7-segment display unit (Fig. 6) is
shown in Fig. 14 and its components
layout in Fig. 15. After assembling the
circuit on the PCB, connect CON14 to
CON10, CON16 to CON13, and CON15
to CON11 from Fig. 5. Affix LED8 and
LED9 on the PCB for seconds indica-
tion.
Abhishek Kumar is B.Tech in
electronics and instrumentation.
His interests include embedded
systems, software programming
and instrumentation
bring it to ‘Settings’
menu. In ‘Settings’
menu, use Plus
and Minus keys to
increment and dec-
rement the current
values, respectively.
The correspond-
ing pair of 7-seg-
ment displays starts
blinking. Pressing
Set button again
brings the clock
into the next param-
eter setting mode
and so on until the
normal time is dis-
played. On pressing
Set button once, the
following seven set-
tings are displayed:
1. Set current
hours
2. Set current
minutes: After set-
t ing the current
hours and minutes,
SET is displayed on
the display
3. Set month
4. Set date
5. Set year. After setting month,
date and year SET is displayed on the
display
6. Set alarm hours
7. Set alarm minutes. After setting
alarm hours and minutes SET is dis-
played on the display
To switch off the running alarm,
press any of the three buttons once.
Green colour on the RGB1 LED indi-
cates AM, blue indicates PM and red
indicates that date is displayed.
Construction and testing
An actual-size PCB layout of the power
unit (in Fig. 3) is shown in Fig. 8 and
its components layout in Fig. 9. After
alarm values. Thereafter, it reverts to
normal time display with an acknowl-
edgement beep.
Similarly, the Minus button can be
used to decrement the values in ‘Set-
tings’ mode. Pressing it once during
normal time display mode first displays
the current date on the left and the cur-
rent month on the right, and then the
current year. Thereafter, it reverts to
normal time display with an acknowl-
edgement beep.
To switch on/off the alarm, simply
press and hold the Minus button for
more than one second. If the display
indicates AL-0, the alarm is turned off.
AL-1 indicates the alarm is turned on.
To set the various parameters of
the clock, press SET button once to
Do-it-yourself
109www.efymag.com electronics for you | January 2018
AC LAmp BLinker
Using Timer NE555
Petre tzv Petrov
S.C.

Dwiv
eDi
There are at least two popular applications of blinking a string of 110V/230V AC incandescent
lamps. The first is audio-visual warn-ing at construction sites or where
repairing is going on. The second is
to express joy and excitement during
holidays like New Year’s Day.
Here we use a very simple and
low-cost timer NE555 to switch on
and off two output loads alternately
for audio and visual indications. You
can achieve this by using a bipolar-
transistor-based NE555 or CMOS-
based LMC555.
This circuit can be made to blink
Parts List
Semiconductors:
IC1 - 7809, 9V regulator
IC2 - NE555 timer
IC3, IC4 - MOC3043 optoisolator
D1, D2 - 1N4007 rectifier diode
BR1 - 1A bridge rectifier
Triac1, Triac2 - BTA06 triac
LED1-LED6 - 5mm LED
Resistors (all 1/4-watt, ±5% carbon, unless stated
otherwise):
R1 - 100-ohm, 1-watt
R2 - 1-kilo-ohm
R3, R5 - 10-kilo-ohm
R4 - 33-kilo-ohm
R6-R8 - 330-ohm
R9, R10, R12,
R15 - 220-ohm
R11, R13, R16 - 100-kilo-ohm
R14, R17 - 100-ohm, 0.5-watt
VR1 - 100-kilo-ohm potmeter
Capacitors:
C1, C8-C11 - 0.1µF, 400V polyester
C2, C5 - 0.1µF ceramic disk
C3 - 470µF, 25V electrolytic
C4, C6 - 100µF, 16V electrolytic
C7 - 0.01µF ceramic disk
Miscellaneous:
CON1-CON3 - 2-pin terminal connector
F1 - 0.1A fuse with holder
F2, F3 - 1A fuse with holder
PZ1, PZ2 - Piezo-buzzer
S1-S4 - On/off switch
Load1, Load2 - 230V AC, 60W bulb/lamp
X1 - 230V AC primary to
 12V, 250mA secondary
 transformer
 - 230V AC mains power supply
 - Heat-sinks for triacs
 - Mains power cord
G
N
D
G
N
D
1
T
R
I
2
O
/P
3
R
E
S
E
T
4
C
V
5
T
H
6
D
IS
7
V
cc
8
IC
2
N
E
55
5
R
6
33
0E
LE
D
2
C
7
0.
01
u
X
1
X
1
=
 2
30
V
 A
C
 P
R
IM
A
R
Y
 T
O

L N
B
R
1
1A
C
3
47
0u
25
V
C
2
0.
1u
1
2
3
IC
1
78
09
C
5
0.
1u
D
1
1N
40
07
12
V
,2
50
m
A
 S
E
C
O
N
D
A
R
Y
T
R
A
N
S
F
O
R
M
E
R
23
0V
 A
C
50
H
z
R
2
1K
LE
D
1
C
4
10
0u
16
V
D
2
1N
40
07
R
3
10
K
F
1
0.
1A
S
1
O
N
/O
F
F
C
1
0.
1u
R
1
10
0E
1W4
00
V
R
4
33
K
V
R
1
10
0K
C
6
10
0u
16
V
R
5
10
K
S
2
S
3 S
4
P
Z
1
P
Z
2
R
7
33
0E
R
8
33
0EA
1
K
2
N
C
3
M
T
4
N
C
5
M
T
6
IC
3
M
O
C
30
43
LE
D
3
A
1
K
2
N
C
3
M
T
4
N
C
5
M
T
6
IC
4
M
O
C
30
43
LE
D
4
R
9
22
0E
R
10
22
0E
F
2
1A
C
O
N
1
23
0V
 A
C
C
O
N
2
LO
A
D
1
M
T
2
M
T
1
G
T
R
IA
C
1
B
T
A
06
C
8
0.
1u
40
0V
R
11
10
0K
C
9
0.
1u
40
0V
R
14
10
0E
R
13
10
0K
LE
D
6
LE
D
5
F
O
R
F
O
R
R
12
22
0E
R
15
22
0E
M
T
2
M
T
1
G
T
R
IA
C
2
B
T
A
06
C
10
0.
1u
R
16
10
0K
C
11
0.
1u
R
17
10
0E
40
0V
40
0V
0.
5W
C
O
N
3
LO
A
D
2
F
O
R
F
3
1A
0.
5W
P
Z
1,
 P
Z
2
=
 P
IE
Z
O
−
B
U
Z
Z
E
R

LO
A
D
1,
 L
O
A
D
2
=
 2
30
V
 A
C
, 6
0W
 B
U
LB
12
V
 A
C
L N
Fi
g.
 1
: C
irc
ui
t d
ia
gr
am
 o
f A
C
 la
m
p
bl
in
ke
r u
si
ng
 ti
m
er
 N
E5
55
AC lamps a t a
low frequency, or
switch on and off
electrical loads con-
nected to the mains
at a low speed. In
order to reduce
the RF emissions,
switching is done
only at zero cross-
ings of the mains
AC voltage.
The sw i t ch -
ing frequency is
selected according
to the resistor and
capacitor compo-
nents connected
to NE555. It can
be varied using
100-kilo-ohm pot-
meter VR1.
Circuit and
working
Circuit diagram of
the AC lamp blinker
is shown in Fig. 1.
It is built around
a step-down trans-
former (X1), 9V
voltage regulator
7809 (IC1), timer
NE555 (IC2), two
MOC3043 optoi-
solators (IC3 and
IC4), two BTA06
triacs (Triac1 and
Triac2), two 1N4007
diodes (D1 and D2),
six LEDs (LED1
through LED6), two
piezo-buzzers (PZ1,
PZ2), two 230V AC,
60W bulbs (Load1
and Load2), and a
few other compo-
nents.
Do-it-yourself
110 January 2018 | electronics for you www.efymag.com
Fig. 2: Actual-size PCB layout of AC lamp blinker
Fig. 3: Components layout for the PCB
Do-it-yourself
111www.efymag.com electronics for you | January 2018
Power supply. The circuit works
off a 9V regulated power supply
derived from transformer X1, bridge
rectifier BR1 and regulator 7809. Alter-
natively, you can use a 6V-15V DC or
6V rechargeable battery after slight
modification in the circuit.
The resistors in series with all LEDs
should have appropriate values depend-
ing on the power supply voltage and
the type of LEDs. Piezo-buzzers PZ1
and PZ2 should be used with internal
oscillator and should be operational at
the selected power supply.
Oscillation frequency of timer
NE555 is set with R3, R4, potmeter
VR1 and capacitor C6. Frequency F is
obtained at output pin 3 of IC2 as per
the following relationship:
F=1.44/[{R3+2×(R4+VR1)}×C6]
The output of timer NE555 drives
piezo-buzzers (PZ1 and PZ2), which
can be switched on and off using
switches S3 and S4, respectively. It also
drives two LEDs (LED3 and LED4) and
MOC3043 optoisolators (IC3 and IC4)
with zero-crossing detectors.
When the output of timer IC2 is
low, piezo-buzzer PZ1, LED3, IC3,
Triac1 and Load1 are activated. In that
case, Load2 is switched off. When
the output of timer IC2 is high, piezo-
buzzer PZ2, LED4, IC4, Triac2 and
Load2 are activated. In that case, Load1
is switched off.
That is, Load1 and Load2 are
activated alternately and the time of
their activation is controlled by timer
NE555. Timer NE555 is isolated from
the AC mains using optoisolators so
that you can change the frequency of
the loads and blinking ratio without the
danger of AC mains.
The circuit does not have criti-
cal components and is operational
immediately after proper assembly.
However, precaution should be taken
as the circuit drives loads directly con-
nected to the AC mains. That makes it
obligatory to use optocouplers or optoi-
solators like MOC3041, MOC3042 or
MOC3043. You may also use optocou-
plers rated for 600V, like MOC3061-M,
MOC3062-M or MOC3063-M.
You may use triacs compatible with
the required loads and the selected
optocouplers. When working with 230V
or 240V AC mains, you need to use
at least 400V rated triacs, and prefer-
ably 600V rated triacs like BT139-600,
BTA06-600, TIC226M and MAC223A8.
Resistor and capacitor circuits
around triacs reduce the noise and pro-
tect the triacs. These are obligatory and
should be selected according to the local
conditions of the mains and the selected
components including the loads.
Carefully select the values of resis-
tors and capacitors connected directly
to the mains. These should support the
maximum possible voltages observed
in the local AC mains voltage.
Construction and testing
An actual-size PCB layout of AC lamp
blinker using timer NE555 is shown in
Fig. 2 and its components layout in Fig.
3. After assembling the circuit on the
PCB, enclose it in a suitable box. Place
transformer X1 inside the box and con-
nect its primary and secondary (12V
AC) wires shown in the PCB. Connect
230V AC mains power supply across
L (live) and N (neutral) terminals. Fix
fuses, switches and potmeter VR1 on
the front side of the box. Connect Load1
and Load2 across CON2 and CON3,
respectively. Fix piezo-buzzers PZ1 and
PZ2 on the back side of box. Also fix the
LEDs at any appropriate location outside
the box for visual indications.
Depending on the loads, use heat-
sinks with thermal resistance equal to
or below 30ºC/W for Triac1 and Triac2.
Note. The circuit should be used
only with appropriate fuses. It is pref-
erable to first test the circuit through
an isolation transformer connected to
the AC mains and with light loads like
a 230V, 15W bulb. Also, it is preferable
to first test at lower AC voltage like
50-100Vrms. Check for short-circuits or
other anomalies before initial testing of
the circuit with AC mains.
Caution. As there is risk of electri-
cal shock (the extreme left and right of
the PCB shown by the dotted lines),
this circuit should be tried only by
qualified personnel familiar with the
operations of triacs and AC mains.
Petre Tzv Petrov was a researcher
and assistant professor in
Technical University of Sofia,
Bulgaria andexpert-lecturer in
OFPPT(Casablance), Kingdom of
Morocco. Now he is working as
an electronics engineer in the
private sector in Bulgaria
Do-it-yourself
112 January 2018 | ElEctronics For you www.EFymag.com
Add-On Usb POwer CirCUit
For Ups
A. SAmiuddhin
S.C.

Dwiv
eDi
Most computer UPS have only 230V output and no USB output. Presented here is a
circuit that gives 5V USB output using
the 12V, 7Ah UPS battery fitted inside
a UPS. With this circuit you can power
USB gadgets directly from a UPS with-
out turning on the PC. This circuit can
also be used to power development
boards like Arduino and Raspberry Pi.
Circuit and working
As shown in Fig. 1, the circuit is
built around switch-mode regulator
LM2576-5V (IC1). The LM2576 series
offers a high-efficiency replacement
for popular three-terminal linear
regulators. It substantially reduces the
size of the heat-sink; in some cases,
no heat-sink is required. It provides
all the active functions of a step-down
(buck) switching regulator, capable of
driving up to 3A load with excellent
line and load regulation. The 5V ver-
sion of LM2576 (LM2576-5V) is used
in this circuit.
The 12V battery is connected to
CON1. IC1, along with inductor L1
and diode D1, steps down and con-
verts the 12V input into 5V output.
Capacitor C2 reduces ripples in the
output. Feedback pin 4 of IC1 is
directly connected to the output at C2.
IC1 can be turned on/off by an
external control signal or else it can
be turned on permanently by ground-
ing pin 5 of IC1 through switch S1.
When S1 is in position A, IC1 can be
controlled by connecting an external
control signal at CON3. When S1 is in
position B, IC1 is switched on perma-
nently. LED1 indicates whether IC1 is
on or off. This circuit can be used to
power gadgets digitally.
Construction and testing
An actual-size PCB layout for the
add-on USB power circuit for a UPS
is shown in Fig. 2 and its components
Fig. 1: Circuit diagram of add-on USB power circuit for UPS
Fig. 2: Actual-size PCB layout of add-on USB
power circuit for UPS
Fig. 3: Components layout for the PCB
A. Samiuddhin takes
keen interest in LED
lighting, power electronics,
microcontrollers and
Arduino programming
Parts List
Semiconductors:
IC1 - LM2576-5V voltage regulator
D1 - 1N5822 Schottky diode
LED1 - 5mm LED
Resistors (all 1/4-watt, ±5% carbon):
R1 - 220-ohm
Capacitors:
C1 - 100µF, 25V electrolytic
C2 - 1000µF, 16V electrolytic
Miscellaneous:
CON1 - 2-pin terminal connector
CON2 - USB A-type connector
CON3 - 2-pin connector
L1 - 100µH inductor
S1 - SPDT switch
 - 12V, 7Ah UPS battery
 - USB cable
 - Heat-sink for IC1
R1
220E
CON1
12V
FOR
5
0N /OFF
2
OUTPUT
1
Vin
4FB
3
GND
IC1
LM2576−5V
C1
100u
D1
1N5822
L1
100u
LED1
POWER
CON2
FOR USBS1
CONTROL
CON3
ON/OFF
FOR
SIGNAL
25V
A
B
Vcc
D−
D+
GNDC2
1000u
16V
layout in Fig. 3. Assemble the circuit
on the PCB and place it at a suitable
location inside the UPS.
Use suitable heat-sink for IC1.
Inductor L1 must have a minimum
current rating of 1A. Capacitor C2
should have low equivalent series
resistance (ESR) for better perfor-
mance. Any voltage from 7-40V can
be used for the circuit.
If the external control signal is
open-collector type, a suitable pull-up
resistor must be used on pin 5 of IC1.
Do not leave this pin float. To maintain
stability, capacitor C1 leads must be
kept short and placed near IC1.
Do-it-yourself
113www.efymag.com electronics for you | January 2018
Simple Multi-Sensor
Fire AlArm
Fayaz Hassan
S.C.

Dwiv
eDi
The circuit presented here raises an alarm on detecting flames and high temperatures. It can
be used in two ways: A single sensor
board with an alarm board, or three
sensor boards with an alarm board.
The three separate sensor boards are
to be installed at three different places,
with the alarm unit installed at an
appropriate location.
Circuit and working
Circuit diagram of the fire alarm is
shown in Fig. 1. It is built around a
transformer (X1), 6V voltage regulator
7806 (IC1), temperature sensor LM35
(IC2), flame sensor IR LED (IRLED1),
op-amp LM358 (IC3), transistors
BC547 and BC557 (T1 and T2), a 6V
single-changeover relay and a few
other components.
The circuit senses ambient tem-
perature using LM35 and checks the
presence of flame with an IR
sensor. Yellow- or red-coloured
flames emit IR radiation, which
is sensed by the IR sensor
(IRLED1).
In case yellow/red flame,
high temperature or both are
detected, dual comparator
LM358 triggers npn transistor
T1. Transistor T1 conducts and
its collector goes low to drive
pnp transistor T2 into conduc-
tion. This, in turn, energises
relay RL1 to activate the load
(buzzer, lights and other equip-
ment) connected at CON9.
One big advantage of this
circuit is that in case the sensor
board loses connection from
the alarm board due to fire or
explosion, transistor T2 gets
activated due to logic low at its
base and thus still energises the
relay. So, place the alarm board
at an appropriate remote loca-
tion for monitoring.
Normally, when there is
no fire, LED3 and LED4 on the
sensor board are ‘off.’ LED4
glows when the temperature
crosses the set temperature
range, while LED3 glows when
the IR sensor detects IR radia-
tion from flame. LED5 glows
during normal operation and
goes off when it receives a
signal from the sensor board.
The output of the sensor
board at connector CON5 is
marked as ‘A.’
Three similar sensor boards
at different locations can be
used by connecting their
respective outputs to CON6
through CON8 of the alarm
board. This arrangement is
useful for monitoring multiple
rooms, corridors, hotel rooms
and staircases where alarm
R
2
2.
2K
G
N
D
S
1
P
O
W
E
R
LE
D
2
P
O
W
E
R
O
U
T
1
1
IN
1−
2
IN
1+
3
G
N
D
4
IN
2+
5
IN
2−
6
O
U
T
2
7
V
cc
8
IC
3
LM
35
8
1
Vcc
2
VO
3
GND
IC
2
LM
35 VR
1
10
0K
N
O
N
C
R
L1
6V
, 1
C
O

R
3
1K
R
4
1K
V
R
2
10
K
LE
D
4
LE
D
3
T
2
B
C
55
7
R
9
2.
2K
LE
D
6
A
LA
R
M
S
2
A
LA
R
M
IR
LE
D
1
R
5
47
K
T
P
1
T
P
2
T
P
3
C
3
0.
1u
C
4
0.
1u
R
8
2.
2K
R
7
2.
2K LE
D
5
C
O
N
9
F
O
R

C
5
10
0u
16
V
N
O
N
C
C
O
M
B
R
1
1A
X
1
X
1
=
 2
30
V
 A
C
 P
R
IM
A
R
Y
 T
O
 9
V
,2
50
m
A
1
2
3
IC
1
78
06
C
1
10
00
u
25
V
C
2
10
0u
16
V
NL 23
0V
 A
C
50
H
z
IN
P
U
T
S
E
C
O
N
D
A
R
Y
 T
R
A
N
S
F
O
R
M
E
R
LO
A
D
D
1
1N
40
07
T
P
4
T
P
5
R
E
LA
Y
C
O
N
5
F
O
R
 A
C
O
N
6
F
R
O
M
 A
C
O
N
1
F
O
R
 6
V
R
1
2.
2K
LE
D
1
P
O
W
E
R
C
O
N
4
F
O
R
 6
V
R
10
2.
2K
R
6
2.
2K T
1
B
C
54
7
C
O
N
7
F
O
R
M
 A
C
O
N
8
F
O
R
M
 A
C
O
N
2
F
O
R
 6
V
C
O
N
3
F
O
R
 6
V
G
N
D
G
N
D
P
O
W
E
R
 S
U
P
P
LY
S
E
N
S
O
R
 B
O
A
R
D
 C
IR
C
U
IT
A
LA
R
M
 B
O
A
R
D
 C
IR
C
U
IT
T
P
0
T
E
M
P
E
R
A
T
U
R
E
S
E
N
S
O
R
S
E
N
S
O
R
F
LA
M
E
O
P
−
A
M
P
 D
E
T
E
C
T
O
R
S
IG
N
A
L
IN
V
E
R
T
E
R
R
E
LA
Y
F
O
R
 B
U
Z
Z
E
R
/L
IG
H
T
1 2 3
1 2 3 1 2 3 1 2 3
9V
 A
C
Fi
g.
 1
: C
irc
ui
t d
ia
gr
am
 o
f fi
re
 a
la
rm
Parts List
Semiconductors:
IC1 - 7806, 6V regulator
IC2 - LM35 temperature sensor
IC3 - LM358 op-amp
IRLED1 - IR LED flame sensor
T1 - BC547 npn transistor
T2 - BC557pnp transistor
LED1-LED6 - 5mm LED
D1 - 1N4007 rectifier diode
BR1 - Bridge rectifier
Resistors (all 1/4-watt, ±5% carbon):
R1, R2, R6-R10 - 2.2-kilo-ohm
R3, R4 - 1-kilo-ohm
R5 - 47-kilo-ohm
VR1 - 100-kilo-ohm potmeter
VR2 - 10-kilo-ohm potmeter
Capacitors:
C1 - 1000µF, 25V electrolytic
C2, C5 - 100µF, 16V electrolytic
C3, C4 - 0.1µF ceramic disk
Miscellaneous:
CON1-CON4 - 2-pin connector
CON5-CON9 - 3-pin connector
S1, S2 - On/off switch
RL1 - 6V, 1CO relay
X1 - 230V AC primary to 9V,
 250mA secondary
 transformer
 - 230V AC/50Hz or 6V battery
Do-it-yourself
114January 2018 | electronics for you www.efymag.com
Table I
TesT poInTs
Test point Details
TP0 GND
TP1 6V
TP2 Up to 5V depending on IR radiation
TP3 450mV-550mV. Set using VR2
TP4 5V
TP5 6V
Table II
leD sTaTus
LEDs Status
LED1 ‘On’ if 6V is available across CON1,CON2 and CON3
LED2 ‘On’ if 6V is available in the sensor board
LED3 ‘On’ if flame is detected
LED4 ‘On’ if temperature is detected
LED5 ‘On’ if neither temperature nor flame is detected
LED6 ‘On’ if 6V is available in the alarm board
Fig. 2: Actual-size PCB layout of fire alarm
Fig. 3: Components layout for the PCB
board can be placed at a safe and
open area.
Initial setup
Once the sensor board (middle portion
in Fig. 1) is ready and connected to
6V DC supply via switch S1, set VR2
to get around 450mV at TP3. (450mV
means 45°C as set temperature, since
LM35 outputs 10mV per 1°C tempera-
ture.) Now, using a hair dryer or some
other small heat source, blow hot air
on LM35. Once the temperature of
LM35 crosses 45°C, LED4 glows. Stop
the heat source. At pin 2 of IC3, you
can set 450mV to 550mV for trigger
temperature of 45°C to 55°C or any
other temperature according to your
requirement.
Next, light a candle and keep it
about one metre away from IR LED1
between power supply,
sensor board and alarm
board.
The circuit works off
230V AC, 50Hz. Alterna-
tively, you can use a 6V
battery. In this case, do not
assemble power supply
PCB and connect 6V bat-
tery directly at CON4.
After assembling the
circuit, verify voltages as
shown in Table I. Also refer Table II for
the status of each LED in the circuit.
Fix LEDs on the front panel and label
their functions.
When you are using a single sensor
board, connect CON1 to CON4 for
power supply and CON5 to CON6 for
signal sensing. In this case, CON2,
CON3, CON7 and CON8 are unused.
For the arrangement using three
sensor boards, you can assemble the
sensor boards separately using the
same sensor circuit and power supply
taken from CON1, CON2 and CON3
respectively.
sensor (flame sensor). Set VR1 such
that LED3 goes off and glows again if
the candle is moved little closer to the
IR sensor.
Connect power supplies to sensor
boards and the alarm board. Switch on
S1 and S2. Test the relay operation by
increasing the temperature and also
by bringing the candle flame nearer
to the IR sensor.
Construction and testing
An actual-size PCB layout of the fire
alarm including power supply, sensor
board and alarm board is shown in
Fig. 2 and its components layout in
Fig. 3. Cut the PCB along the dotted
lines. Assemble the power supply,
sensor board and alarm board sepa-
rately. Enclose these in a suitable box.
Connect the respective connectors
Fayaz Hassan is a manager
at Visakhapatnam Steel Plant,
Andhra Pradesh. He has keen
interest in microcontroller projects,
mechatronics and robotics
Do-it-yourself
115www.efymag.com electronics for you | January 2018
Door-AjAr Alert
With Countdown Timer
T.K. Hareendran
Pre
eti
Bha
kta
&
San
i the
o
Ever accidentally left your room door ajar for a long period of time and found your valuables
missing? Here is an intelligent solu-
tion for you. The idea is fairly simple
as it mainly requires a TM1637 4-digit
display and a Digispark USB develop-
ment board.
TM1637 is a popular clock display
module with a TM1637 driver chip
from Titan Micro Electronics. This
4-digit, 7-segment LED display module
can be controlled using just a two-wire
serial interface.
Digispark USB board, based on
Atmel Attiny85 microcontroller, is
similar to Arduino hardware platform.
However, it is smaller with limited pins,
and a bit less powerful than Arduino.
A normally-closed (NC) reed
switch is used as the door sensor.
When the door is closed, as per
mechanical arrangement, switch con-
tacts open to disable the alert system.
When the door is opened, switch con-
tacts close to enable the alert system.
So a piezobuzzer starts beeping after
some time. The alert system wired
around Digispark Attiny85 module
and clock display module shows live
status of the countdown timer.
Arduino-compatible code (door_
ajar.ino) is used for this project.
The code displays the countdown
timer and initiates an alarm after a
set time of about 60 seconds. Here,
DigitalTube library created by Frankie
Chu (https://github.com/reeedstudio/
libraries/tree/master/DigitalTube) is
used to control the 4-digit display.
So, first download the library,
extract contents of the zip file to
arduino/libraries folder, and restart
the Arduino IDE. Now you can see
DigitalTube listed under Sketch/
Include Library options in Arduino
IDE. Next, copy door_ajar.ino code
into the Arduino IDE (Arduino IDE
1.6.6+) to compile and program
Digispark.
To program Digispark, first you
need to install relevant drivers from the
Arduino IDE by selecting Tools/Board/
Boards Manager/Digistump AVR
Boards options. For details go through
the tutorials at http://digistump.com/
wiki/digispark.
After successful installation of the
drivers, Digispark will feature in the
Board list of Arduino IDE. Select the cor-
rect board as per the Digis-
tump model you have. We
selected Digispark(Default-
16.5MHz) option. Click
Sketch/Upload options
from Arduino IDE. You will
be prompted to connect
Digispark board to the USB
port of your PC. As soon
as the board is plugged in,
the code will be uploaded.
Now, plug-out the board
and make connections as
per the circuit diagram.
After construction, enclose the
electronics (including the door sensor)
in a small box made of rigid plastic
and mount it on the door frame.
Attach an appropriate-size magnet
on the door such that when the door
is closed, the magnet comes closest
to the sensor (reed switch S1) and
its contacts open. Use an appropriate
9V alkaline battery pack to power the
system.
Fig. 1: Digispark board
Fig. 2: Circuit of door-ajar alert system
Fig. 3: Author’s prototype during testing
T.K. Hareendran is
founder and promoter of
TechNode Protolabz
The source code of
this project is
included in this month’s
EFY DVD and is also
available for free download
at source.efymag.com
efy Note
Do-it-yourself
116 January 2018 | ElEctronics For you www.EFymag.com
Understanding Spectrogram of
Speech SignalS Using Matlab Program
Dr A.r. JAyAn
Pre
eti
Bha
kta
&
San
i the
o
This article explains speech signal analysis and processing with MATLAB to get its frequen-
cy-domain representation.
In real life, we come across many
signals that are variations of the form
ƒ(t), where ‘t’ is independent variable
‘time’ in most cases. Temperature,
pressure, pulse rate, etc can be plotted
along the time axis to see variations
across time.
In signal processing, signals can be
classified broadly into deterministic
signals and stochastic signals. Deter-
ministic signals can be expressed in
the form of a mathematical equation
and there is no randomness associated
with them. The value of the signal at
any point of time can be obtained by
evaluating the mathematical equation.
An example is a pure sine wave:
ƒ(t)=A sin 2πƒt
where ‘A’ is signal amplitude, ‘ƒ’ is
signal frequency and ‘t’ is time.
Many of the information-bearing
signals may not be predictable in
advance. There is a certain amount
of randomness in the signal with
respect to time. Such signals cannot be
expressed in the form of simple math-
ematical equations. For example, in
the noise signal inside a running auto-
mobile, we may hear many sounds,
including the engine sound, sound
of horns from other vehicles and pas-
sengers talking, in a combined form
with no predictability. Such signals are
examples of stochastic signals.
In the speech signal produced
when you utter steady sounds like ‘a,’
‘i’ or ‘u,’ the waveform is a near-peri-
odic repetition of some well-defined
patterns. When you produce sounds
like ‘s’ and ‘sh,’ the waveform is noise-
like. Theperiodicity in the speech
signal is due to the vibration of vocal
folds at a particular frequency, known
as pitch or fundamental frequency of
the speaker. Steady sounds (a, i or u)
are examples of vowels and noise-like
sounds (s and sh) are examples of
consonants. Human speech signal
is a chain of vowels and consonants
grouped in different forms.
Most of the signals in real life
are available continuously and may
assume any amplitude value. These
signals are called analogue signals
and they are not in a form suitable for
storing or processing using a digital
computer. In digital signal processing,
we process the signal as an array of
numbers. We do sampling along the
time axis to discretise the independent
variable ‘t.’ In other words, we look at
the signal at a number of time instanc-
es separated by a fixed interval ‘T’
(called sampling period=1/ƒs, where
‘ƒs’ is called sampling frequency).
Signal values observed at these time
instances are further discretised in the
amplitude domain to make these suit-
able for storage in the form of binary
digits. This process is called quantisa-
tion. After sampling and quantisation
(called digitisation) of an analogue
signal, the signal assumes the form:
ƒ(n)=qn
where ‘qn’ is an approximation to
the signal amplitude at time instant
t=nT. The signals so produced are
called digital signals. These can be
stored in memory and used for pro-
cessing by mathematical operations
with the help of digital computers.
A pure sine-wave after digitisation
can be represented as an array in the
form:
ƒ(n)=A sin 2πƒnT=A sin 2πƒn/ƒs
where ‘A’ is the signal amplitude, ‘ƒ’ is
the signal frequency, ‘ƒs’ is the sam-
Fig. 1: Waveform of vowel sound ‘aa’
Fig. 2: Waveform of vowel-consonant sound ‘as’
Fig. 3: Waveform of 500 samples of vowel
sound ‘aa’
Fig. 4: Waveform of 500 samples of consonant
sound ‘s’
Do-it-yourself
117www.EFymag.com ElEctronics For you | January 2018
pling frequency and ‘n’ is an integer
called time index. Sample value ƒ(n) is
an approximation of the signal ampli-
tude at time instant t=nT.
Understanding the speech signal
Record vowel sound ‘aa’ using the
computer’s microphone and save it as
a wav file. Select sampling frequency
as 10kHz. You may use audio process-
ing software like Praat, Audacity,
Goldwave or Wavesurfer to record the
signal in wav format at the required
sampling frequency.
The waveform of the signal, which
is a plot of the amplitude of the speech
signal for each sample instant, looks
like Fig. 1. The horizontal axis is time
units in samples and the vertical axis
is amplitude of the corresponding
samples. If you record sound ‘as’ in
which consonant sound ‘s’ follows the
vowel sound ‘a,’ and plot the signal,
the waveform may look like Fig. 2.
On close examination of Fig. 1,
you can see some repeating pattern in
it. A zoomed version of Fig. 1 show-
ing samples in the range 1000 to 1500
is given in Fig. 3. If you plot samples
from 6000 to 6500 in Fig. 2, you get
Fig. 4. Obviously, the waveform in
Fig. 4 has no periodicity and it appears
noise-like. In the waveform of vowel-
consonant sound ‘as,’ you can see that
the speech signal properties transform
gradually from a nearly periodic signal
(samples 2000 to 5000) to a noise-like
signal (samples 5000 to 10000).
Frequency-domain analysis of the
speech signal
Waveform is a representation of the
speech signal. It is a visualisation
of the signal in time domain. This
representation is almost silent on the
frequency contents and the frequency
distribution of energy in the speech
signal. To get a frequency-domain rep-
resentation, you need to take Fourier
transform of the speech signal. Since
speech signal has time-varying prop-
erties, the transformation from time-
domain to frequency-domain also
needs to be done in a time-dependent
manner. In other words, you need to
take small frames at different points
along the time axis, take Fourier trans-
form of the short-duration frames,
and then proceed along the time axis
towards the end of the utterance. The
process is called short-time Fourier
transform (STFT). Steps involved in
STFT computation are:
1. Select a short-duration frame of
the speech signal by windowing
2. Compute Fourier transform of
the selected duration
3. Shift the window along the time
axis to select the neighbouring frame
4. Repeat step 2 until you reach the
end of the speech signal
To select a short-duration frame of
speech, normally a window function
with gradually rising and falling prop-
erty is used. Commonly used window
functions in speech processing are
Hamming and Hanning windows. A
Hamming window with ‘N’ points is
mathematically represented by:
hm(n)=0.54–0.46cos , 0≤n<NN
2πn
and a Hanning window with ‘N’ points
is mathematically represented by:
hn(n)=0.5(1–cos ), 0≤n<NN
2πn
A window function has non-zero
Fig. 5: Hamming (solid) and Hanning (dotted)
windows of 400 samples
Fig. 6: Narrowband spectrogram of vowel-consonant sound ‘as’
Fig. 7: Wideband spectrogram of vowel-consonant sound ‘as’
Do-it-yourself
118 January 2018 | ElEctronics For you www.EFymag.com
If the sampling frequency of the wav
file is not 10kHz, the file needs to be
resampled to 10kHz for proper work-
ing of the program.
Frame shift parameter is set as 100
samples (10ms). MAG variable has the
absolute value of Fourier transform
of frames stored column wise. The
magnitude of Fourier transform is also
called spectrum of that frame of the
signal. As the speech signal has time-
varying properties, the spectrum also
goes on varying with time as we move
along the samples in the wav file.
Magnitude spectrum computed for
individual frames can be represented
in many forms. We have been follow-
ing three parameters: Frame number
(indicator of the time axis), DFT bin
number (indicator of the frequency
axis) and magnitude of DFT computed
(indicator of the spectral energy).
These three parameters can be rep-
resented conveniently in a 2D format
using spectrogram. Spectrogram can
be considered as an image representing
time and frequency parameters (along
X and Y axes) and magnitude values as
the intensity of pixels in the X-Y plane.
Stronger magnitudes get represented
by dark spots and silences (low- or
zero-amplitude signals) get represented
by white spots in the image.
For a real valued signal, you need to
take only the first half of the magnitude
spectrum, since the spectrum has a
symmetric shape with respect to nfft/2.
You will see that the range of values in
the computed magnitude spectrum is
very high as you move from frames with
valid speech signal to frames involving
silences or pauses. It is better to limit the
dynamic range to a fixed value before
plotting. The magnitude spectrum is
converted into the log scale and its
dynamic range is limited to 50dB in the
main program (spectrogram_efy.m) that
computes and plots the spectrogram of
a speech signal.
Parameters Nwt and Nst decide the
Fig. 8: Narrowband spectrogram of sentence “You will mark as please..”
to the same folder where the main
program is stored):
frames = speech2frames( speech, Nw, Ns,
‘cols’, hanning, false );
Generally, frame-duration param-
eter Nwt and frame-shift parameter
Nst are selected such that consecutive
frames have sufficient overlap. The
condition Nst<Nwt ensures an overlap-
ping window placement. In speech-
processing applications, overlapping
is generally kept above 50 per cent by
proper selection of Nst and Nwt. The
framing operation returns a number of
short-duration frames selected using
the window function with the specified
frame length and frame shift param-
eters. Each frame is stored as a column
vector in the returned array. Once fram-
ing is performed, DFT operation is used
to transform each frame to frequency
domain using the command:
MAG = abs( fft(frames,nfft,1) );
Parameter ‘nfft’ specifies the
numberof points in the DFT opera-
tion. It is kept as a power of 2 and
must be greater than the frame length
in samples. Assuming the wav file has
sampling frequency fs of 10kHz, we
have used 1024 points as ‘nfft’ for a
frame length of 400 samples (40ms).
values over a selected set of points
and zero values outside this interval.
When you multiply a signal with a
window function, you get a set of ‘N’
selected samples from the location
where you place the window and zero-
valued samples at all other points.
Fig. 5 shows Hamming and Hanning
windows of 400 points each.
You need to finalise the following
parameters before computing short-
time Fourier transform of the speech
signal:
1. Type of window function to be
used for framing the speech signal
2. Frame length Nwt in milliseconds
3. Frame shift Nst in milliseconds
4. DFT length
For a sampling frequency of ƒs, you
have to use:
Nw=Nwt ƒs/1000
Ns=Nst ƒs/1000
to convert the frame length and frame
shift (Nwt, Nst) in milliseconds into the
corresponding number in samples
(Nwt, Nst). Here fs is the sampling fre-
quency of the speech signal expressed
in Hertz. Once these parameters
are finalised, framing operation is
performed using the MATLAB user-
defined function (needs to be copied
The latest from the Open Source world is here.
OpenSourceForU.com
Join the community at facebook.com/opensourceforu
Follow us on Twitter @OpenSourceForU
THE COMPLETE M AGAZINE ON OPEN SOURCE
Do-it-yourself
119www.EFymag.com ElEctronics For you | January 2018
The source code of
this project is
included in this month’s
EFY DVD and is also
available for free download
at source.efymag.com
efy Note
resolving power of the spectrogram
along time and frequency axes. Spec-
trograms obtained with Nwt values
greater than 20ms are called narrow-
band spectrograms. Generally, these
have a good frequency resolution.
Frequency tracks appear as horizontal
lines varying in intensity.
When you lower the frame-dura-
tion parameter, you need to lower the
frame-shift parameter also to avoid
missing frames. A reduced value of
frame duration results in a lower
frequency resolution but a good time
resolution. The spectrogram obtained
with good time resolution and poor
frequency resolution is called a
wideband spectrogram. Narrowband
spectrograms are useful for accurate
frequency analysis of speech signals.
Wideband spectrograms are useful
for accurate localisation of transient
region onsets in the speech signal.
Narrowband and wideband spec-
trograms for vowel-consonant sound
‘as’ are shown in Figs 6 and 7, respec-
tively. Spectrograms (narrowband
and wideband) for the sentence “You
will mark as please” are shown in
Figs 8 and 9, respectively. Readers are
advised to experiment with different
speech utterances and different values
for Nwt, Nst, and nfft and to observe
variations in spectrograms.
Dr A.R. Jayan is associate
professor in ECE Department
at RIT Kottayam, Kerala
Fig. 9: Wideband spectrogram of sentence “You will mark as please..”
123www.efymag.com electronics for you | January 2018
125www.efymag.com electronics for you | January 2018
127www.efymag.com electronics for you | January 2018
129www.efymag.com electronics for you | January 2018
131www.efymag.com electronics for you | January 2018
133www.efymag.com electronics for you | January 2018
135www.efymag.com electronics for you | January 2018
142 January 2018 | electronics for you www.efymag.com
1. Technologies like IoT, AI and embedded
systems have no future.
Frankly, I have NO interest in new technologies like In-
ternet of Things (IoT), artificial intelligence, etc. I don’t
think these will ever take off, or become critical enough
to affect my organisation or my career.
2. I see no point in attending tech events.
What’s the point in investing energy and resources to
attend such events? I would rather wait and watch—let
others take the lead. Why take the initiative to understand
new technologies, their impact and business models?
3. My boss does not like me.
My boss is not fond of me and doesn’t really want me
to grow professionally. And when she came to know
that IEW 2018 is an event that can help me advance
my career, she cancelled my application to attend it.
Thankfully, she is attending the event! Look forward to a
holiday at work.
4. I hate innovators!
Oh my! Indian start-ups are planning to give LIVE
demonstrations at IEW 2018? I find that hard to believe.
Worse, if my boss sees these, he will expect me to create
innovative stuff too. I better find a way to keep him from
attending.
5. I am way too BUSY.
I am just too busy with my ongoing projects. They just
don’t seem to be getting over. Once I catch up, I’ll invest
Register
for IEW 2018
Hope we have managed to convince you NOT to attend IoTshow.in at IEW 2018! Frankly, we too
have NO clue why 10,000-plus techies attended IEW in March 2017. Perhaps there’s something
about the event that we’ve not figured out yet. But, if we haven’t been able to dissuade you from
attending IEW 2018, then you may register at http://register.efy.in.
Co-located events at IEW 2018
some time in enhancing my knowledge and skills, and
figure out how to meet my deadlines.
6. I only like attending vendor events.
Can you imagine an event where most of the speak-
ers are not vendors? Where most talks will not be
by people trying to sell their products? How boring!
I can’t imagine why anyone would want to attend
such an event. I love sales talks, and I am sure eve-
rybody else does too. So IEW is a big ‘no-no’ for me.
7. I don’t think I need hands-on knowledge.
I don’t see any value in the tech workshops being
organised at IEW. Why would anyone want hands-on
knowledge? Isn’t browsing the Net and watching You-
Tube videos a better alternative?
8. I love my office!
Why do people leave the comfort of their offices and
weave through that terrible traffic to attend a technical
event? They must be crazy. What’s the big deal in lis-
tening to experts or networking with peers? I’d rather
enjoy the coffee and the cool comfort of my office, and
learn everything by browsing the Net!
9. I prefer foreign events.
While IEW’s IoTshow.in was voted the ‘World’s No.1
IoT event’ on Postscapes.com, I don’t see much
value in attending such an event in India—and
that, too, one that’s being put together by an Indian
organiser. Naah! I would rather attend such an event
in Europe.
IOTSHOW.IN
IoTshow.in will be
India’s first major
exposition for all
the stake-holders of
Internet of Things
ecosystem to come
together.
EFY EXPO
The EFY Expo is
a unique elec-
tronics event that
focuses on the
entire ecosystem
of electronics in
India.
LEDASIA.IN
LEDasia.in is
India’s first event
to focus on the
electronics that
powers LED
Lighting.
TEST & MEASURE-
MENT INDIA
Test & Measurement
India (T&M India) is
Asia’s leading exposi-
tion of test & measure-
ment products and
services.
EFY CONFERENCE
EFY Conferences (EFYCON)
started as a tiny 900-foot fall
community conference in
2012, going by the name of
Electronics Rocks. The 2017
edition had over 10,000+ reg-
istrants and 150+ speakers.
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
144 January 2018 | electronics for you www.efymag.com
Smart is in. Be it the water-tap or your car, your tel-
ephone or your city—everything is getting smarter.
But, what about your products? Is there a need to make
them ‘smart’? Or, are they smart enough? Can they be-
come smarter? How can you and your team make them
smarter? Can anyone help you make them smarter? Is it
easy to make them in India? You can find answers to all
these questions at India Electronics Week (IEW).
Since electronics and IT are key enablers of Smarter
Products, IEW brings together five co-located events.
These include expositions, conferences and workshops
for business decision makers, as well as technical deci-
sion makersand influencers. Come and discover the
‘Smart’ world.
Discover the ‘Smart World’ at IEW 2018
Explore the eco-system that enables Smart Products at IEW
Smart
Manufacturing
Innovative
Design
Latest Components &
Embedded Systems
Hi-tech Testing
Equipment
M2M-friendly
Networks
IoT-ready IT
Infrastructure
Industry Ready
Academia
AI & ML Delivery
Infrastructure
Conferences & Workshops at IEW 2018
Title Type Primary
Audience
Take-away Date Hall Questions That Will Be
Answered Here
Topics ENTRY
Profit From
IOT: IOT
Solution
Developers
Business
Confer-
ence
Sr Business
Decision
Makers of
Organisa-
tions Devel-
oping IOT
Solutions
Be able to
build a bet-
ter business
around IOT
Solutions
7th Feb, 2018
(Wednesday)
Aryabhatta •	 What are the opportunities emerging
globally and in India? What are the
challenges?
•	 What are the new business models
emerging in the IOT landscape?
•	 What are the new technologies that are
enabling innovative IOT solutions?
•	 What are the typical business challenges
and how have those been overcome?
Single Day Pass
(Any 1 Day) OR
Business Pass
(All 3 Days) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Profit
From IOT:
Developers
of IOT Solu-
tions for
Industrial
Customers
Business
Confer-
ence
Sr Business
Decision
Makers of
Organisa-
tions Devel-
oping IIOT
Solutions
Be able
to finalise
Strategies
and action
plan to grow
business
faster
8th Feb,
2018
(Thursday)
Aryabhatta •	 What are the opportunities emerging
globally and in India? What are the
challenges?
•	 What are the new business models
emerging in the IIOT landscape?
•	 What are the new technologies that are
enabling innovative IIOT solutions?
•	 What are the typical business challenges
and how have those been overcome?
Single Day Pass
(Any 1 Day) OR
Business Pass
(All 3 Days) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Profit
From IOT:
Industrial &
Manufactur-
ing Sector
Business
Confer-
ence
Sr Business
Decision
Makers from
Industrial &
Manufactur-
ing Sector
(End Cus-
tomers)
How IoT
can help
reduce costs,
improve
efficiency
and increase
revenues in
Industrial &
Manufactur-
ing sector
9th Feb, 2018
(Friday)
Aryabhatta •	 How’s IIOT benefiting industrial/manu-
facturing sector across the globe and
in India?
•	 What are the opportunities and business
benefits presented by IIOT?
•	 What are the new technologies that are
enabling innovative IIOT solutions?
•	 What are the typical business challenges
and how have those been overcome?
Single Day Pass
(Any 1 Day) OR
Business Pass
(All 3 Days) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
146 January 2018 | electronics for you www.efymag.com
Conferences & Workshops at IEW 2018
Title Type Primary
Audience
Take-away Date Hall Questions That Will Be
Answered Here
Topics ENTRY
Profit From
IOT: System
Integrators
of IOT Solu-
tions
Business
Confer-
ence
Sr Business
Decision
Makers
from System
Integration
Organisa-
tions
Be able
to finalise
Strategies
and action
plan to grow
business
faster
8th Feb, 2018
(Thursday)
Bhaba •	 What are the opportunities emerging
globally and in India? What are the
challenges?
•	 What are the new business models
emerging for SIs in the IIOT landscape?
How’s the game changing?
•	 Who are the key IIOT players seeking
system integrators ?
•	 What are the typical business chal-
lenges and how have those been
overcome?
•	 How’s the IIOT tech stack evolving to
make it easier for SIs to deploy solu-
tions?
Single Day Pass
(Any 1 Day) OR
Business Pass
(All 3 Days) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Profit From
IOT: Retail
Sector
Business
Confer-
ence
Sr Business
Decision
Makers
from Retail
Sector (End
Customers)
How IoT
can help
reduce costs,
improve
efficiency
and increase
revenues for
Retail Sector
9th Feb, 2018
(Friday)
Bhaba •	 How’s IOT benefiting retail sector across
the globe and in India?
•	 What are the opportunities and business
benefits presented by IOT for retail?
•	 What are the new technologies that are
enabling innovative IOT solutions for
retail?
•	 What are the typical business chal-
lenges and how have those been
overcome?
Single Day Pass
(Any 1 Day) OR
Business Pass
(All 3 Days) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
ACQUIRE Tech
Track
(IOT)
Developers
working
on the AC-
QUISITION
(typically
hardware)
side of IOT
Solutions
Be able to
develop
ACQUIRE
solutions-
-better,
faster and
cheaper
7th Feb, 2018
(Wednesday)
Sarabhai •	 What are the key tech trends defin-
ing IOT devices and their Acquisition
capabilities?
•	 What are the latest technologies,
platforms and hardware available to
develop solutions faster, better and
cheaper?
•	 What are the engineering challenges
in developing solutions that ACQUIRE,
and how have they been overcome suc-
cessfully?
Sensors,
Development
Boards, Com-
munication
Chips, Proces-
sors, EDA,
Interfaces,
Standards,
Security, etc.
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
ANALYSE Tech
Track
(IOT)
Developers
working on
the ANA-
LYTICAL
side of IOT
Solutions
Be able to
develop AN-
ALYTICAL
solutions-
-better,
faster and
cheaper
8th Feb, 2018
(Thursday)
Sarabhai •	 What are the key tech trends defining
IOT devices and their ANALYTICAL
capabilities?
•	 What are the latest technologies and
platforms available to develop solutions
faster, better and cheaper?
•	 What are the engineering challenges
in developing solutions that ANALYSE,
and how have they been overcome suc-
cessfully?
•	 What are the latest solutions for devel-
opers being offered by leading vendors?
Any innovative solutions
Analytical
Tools, Analyt-
ics As A Ser-
vice, Cloud,
Artificial
Intelligence,
Deep Learn-
ing, Machine
Learning, etc
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
INTEGRATE Tech
Track
(IOT)
Techies
working on
INTEGRAT-
ING a com-
plete IOT
solution
Be able to
INTEGRATE
solutions-
-better,
faster and
cheaper
9th Feb, 2018
(Friday)
Sarabhai •	 What are the key tech trends defining
IOT devices and their ANALYTICAL
capabilities?
•	 What are the latest technologies and
platforms available to develop solutions
faster, better and cheaper?
•	 What are the engineering challenges in
developing solutions that INTEGRATE,
and how have they been overcome suc-
cessfully?
•	 What are the latest solutions for devel-
opers being offered by leading vendors?
Any innovative solutions
Analytical
Tools, Analyt-
ics As A Ser-
vice, Cloud,
Artificial
Intelligence,
Deep Learn-
ing, Machine
Learning, etc
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Harnessing
the Strength
of the
BlockChain
Tech
Track
Tech deci-
sion makers
and creators
of tech solu-
tions
Discover
Blockchain,
its applica-
tions, and
how to im-
plement it
7th Feb, 2018
(Wednesday)
Kalaam •	 What’s blockchain and why is it a great
enabler?
•	 What types of applications can benefit
from Blockchain? Which one’s can’t?
•	 Success Stories of applications that have
benefited from Blockchain, and learn-
ings from their experience
•	 What are the tools, platforms and
technologies available to implement
Blockchain?
•	 How to start the ball rolling?
Blockchain,
Bitcoin, IOT,
IIOT, Security,
Retail-IOT, etc
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
148 January 2018 | electronics for you www.efymag.com
Conferences & Workshops at IEW 2018
Title Type Primary
Audience
Take-away Date Hall Questions That Will Be
Answered Here
Topics ENTRY
RISC Tech
Track
(IOT)
Tech deci-
sion makers
and creators
of tech solu-
tions
Be able to
make your
solutions
MORESECURE
8th Feb, 2018
(Thursday)
Kalaam •	 What are the latest threats and chal-
lenges to the security of IOT solutions
across the globe? How are these being
tackled successfully?
•	 What are the latest tools and best prac-
tices to make IOT solutions secure?
•	 What are the upcoming threats, and
how badly can they affect?
Cybersecu-
rity, Threat,
Artificial
Intelligence,
Blockchain,
etc
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Great Indian
Jugaad
Tech
Track
(DIYers)
DIYers Discover
the coolest
DIY tools,
projects &
practices
9th Feb, 2018
(Friday)
Kalaam •	 What’re the type of projects gaining
popularity within the DIY community?
•	 What’re the coolest components, tools &
equipment in the market?
•	 What’re the latest practices being
adopted by the Gurus?
•	 Why and How the DIY phenomenon is
changing the industry and entrepreneur-
ship?
DIY, Develop-
ment Boards,
Rapid Proto
Equipment,
Test Equip-
ment, Plat-
forms, etc
Single Day Pass
(Any 1 Day) OR
PRO Pass (All
3 Days + 70%
discount on
Workshops)
Who should attend IEW 2018 & What should they attend
Profile of Business
organisations vs
Profile of Audience
End Cus-
tomer
(Business)
Product
OEM
System
Integrator
Design
House
Manufac-
turing Unit
Sr Business
Decision Makers
Plan A Plan B Plan C Plan D Plan E
Sr Tech Decision
Makers
Plan F Plan G Plan H Plan I Plan J
R&D / Solution
Developers
Plan R Plan R Plan R Plan R
Testing/QC Dept Plan T Plan T Plan T Plan T Plan T
Plan A
Biz Decision
Maker of Cus-
tomer (indus-
trial or Retail)
Plan B
Biz Decision
Maker of
Product OEM
Plan C
Biz Deci-
sion Maker
of System
Integrator
Plan D
Biz Decision
Maker of
Design House
Plan E
Biz Decision
Maker of
Mfg Unit
PIOT: Industrial PIOT:
Solutions
PIOT: SI
Channel
ELCINA- CEO
Summit
ELCINA-
CEO Summit
PIOT: Retail ELCINA CEO
Summit
Expo PIOT: Solutions Expo
Buyer Seller
Meet
Buyer Seller
Meet
 Expo
Expo Expo
Plan F
Tech Decn
Maker of Cus-
tomer (indus-
trial or Retail)
Plan G
Tech Decn
Maker of
Product
OEM
Plan H
Tech Decn
Maker of
System
Integrator
Plan I
Tech Decn
Maker of Design
House
Plan J
Tech Decn
Maker of
Mfg Unit
PIOT: Industrial PIOT:
Solutions
PIOT:
Integrator
PIOT: Solutions PIOT:
Industrial
PIOT: Retail PIOT:
Industrial
PIOT: Indus-
trial
PIOT: Integrator Expo
RISC PIOT: Retail PIOT: Retail PIOT: Industrial
Blockchain Acquire Acquire PIOT: Retail
Expo Analyse Analyse Acquire
 Integrate Integrate Analyse
 RISC RISC Integrate
Blockchain Blockchain RISC
Expo Expo Blockchain
Expo
Plan R
R&D / Solution
Developers of Cus-
tomer (industrial
or Retail)
Plan R
R&D / Solution
Developers of
Product OEMs
Plan R
R&D / Solu-
tion Develop-
ers of System
Integrators
Plan R
R&D / Solution
Developers of
Design House
Acquire Acquire Acquire Acquire
Analyse Analyse Analyse Analyse
Integrate Integrate Integrate Integrate
RISC RISC RISC RISC
Blockchain Blockchain Blockchain Blockchain
Great Indian Jugaad Great Indian
Jugaad
Great Indian
Jugaad
Great Indian Ju-
gaad
Expo Expo Expo Expo
Plan T–Test & QC Dept Plan T–Test & QC Dept Plan T–Test & QC Dept Plan T–Test & QC Dept Plan T–Test & QC Dept
T&M Demos T&M Demos T&M Demos T&M Demos T&M Demos
Expo: T&M India Expo: T&M India Expo: T&M India Expo: T&M India Expo: T&M India
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
150 January 2018 | electronics for you www.efymag.com
Expo
(February 7-9, 2018)
Single Day
(February 7-9, 2018)
Business
(February 7-9, 2018)
Pro
(February 7-9, 2018)
Exhibition Access Yes Yes Yes Yes
Access to Keynote Talks Yes Yes Yes Yes
7 FEB
Acquire Track No
Yes
Based on which
day(s) you select
Yes
Blockchain Track No Yes
Profit from IoT Solutions No Yes Yes
Elcina CEO Summit No Yes Yes
8 FEB
Analyse Track No
Yes
Based on which
day(s) you select
Yes
Real-World IoT Security Conference No Yes
Profit from IoT Products No Yes Yes
Profit from IoT System Integrators No Yes Yes
9 FEB
Integrate Track No
Yes
Based on which
day(s) you select
Yes
Great Indian Jugaad No Yes
Profit from IoT Customers No Yes Yes
To be Announced No Yes
Profit from IoT Retail Sector No No Yes Yes
70% Discount on all Workshops
(Reservations First-come, first-served)
No No Yes
Buffet Lunch on All 3-Days No No Yes Yes
Access to Conference Videos No No Yes Yes
Certificate of Attendance No No Yes Yes
Digital Subscription to EFY and EB Magazines No No Yes Yes
PRICE FREE ` 2,999 ` 5,999 ` 8,999
Types of passes available at IEW 2018
Buyer -Seller Meet at IEW 2018
This event provides a unique platform for exhibitors to
meet large buyers of electronic products, components,
manufacturing equipment, LED lighting components
and IoT hardware etc. In 2017, more than 100 meet-
ings took place between buyers and sellers, over a
period of three days. In 2018, we are expecting much
more successful meetings.
Buyers for IEW 2018
•	 Accord Software & Systems Pvt Ltd
•	 Amara Raja Electronics Ltd
•	 Center for Development of Telematics
•	 Intelux Electronics Pvt Ltd
•	 Bharat Electronics Limited (BEL)
•	 Hella India Automotive Private Limited
•	 RP Sanjiv Goenka Group
•	 Renault Nissan Business Centre
•	 Magnitech Engineers
•	 Minda Corporation
•	 Pricol Ltd.
•	 Luminous Power Technologies
•	 Lenovo India
(This list is subject to change as it is prepared on the basis
of information available till 20 Dec, 2017)
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
152 January 2018 | electronics for you www.efymag.com
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
Q. What all can I attend for FREE?
A. The EXPO and the Keynote sessions at EFY Confer-
ences. Plus, there might be some sponsored work-
shops and meetups by our sponsors, which will be
announced on our website from time to time. All free
activities are on a first-come-first-serve basis.
Q. What are the types of passes?
A. There are four types of passes. EXPO Pass is free. The
other three passes are paid and include: Single Day Pass,
Business Pass, and PRO Pass. For more details, refer to:
https://www.indiaelectronicsweek.com/types-of-passes/
Q. Can Students attend?
A. Students can attend the Expo on the 3rd day—as
the first two days are for Industry visitors, and the last
day is Students’ Day. Students can attend any of the
paid events on any of the 3 days though.
Q. What about Group Discounts?
A. Group discounts are available if you go for more
than 3 passes. To get a quote, you can share your
details here (https://www.indiaelectronicsweek.com/
group-discount-form/) OR contact us at +91-98111
55335.
Q. What are the timing of the Expo?
A. Timings for Expo are 10 am to 6 pm.
Q. What are the timings of the Conferences?
A. The timings for the conferences and workshops at
India Electronics Week are different from the timings
of the Expo. These will begin at 8.30 am and go on
till 5 pm.
Q. What time will the registration start?
A. Registration will start at 8.30 am.
Q. Are there food facilities at IEW?
A. Yes. There will be a full-fledged food court at IEW,
where you can purchase healthy and affordable food &
drinks.
Q. Which (paid) passes include lunch?
A. Business and Pro passes include Lunch at the Net-
working Zone.
Q. Is there a special discount for Defence
Personnel?
A. In order to thank our armed forces for the incredible
work they do, we have a special discount for them. They
get all passes at 50% discount.
Q. Who’s qualified to get this discount?
A. Anyone who’s working for any of our armed forces or
inland security organisations including army, navy, air
force, border security, home guard, and police. The same
extends to those who are active or retired. Plus, anyone
working in strategic electronics PSU organisations such as
ISRO, DRDO, Bharat Electronics, ECIL, etc.
Q. How to get this discount?
A. While buying a pass use the promocode DEFPASS and
upload an image of your identityproof. That’s it. If we
find that proof submitted is invalid, then we may cancel
the registration.
Q. Is there a special discount for Academicians?
A. Yes! They are the true builders of our nation, and to
Frequently Asked Questions
154 January 2018 | electronics for you www.efymag.com
thank them—we have a 50% discount for them too.
Again, active or retired academicians can avail this
discount.
Q. Who’s qualified to get this discount?
A. Anyone who teaches as a profession. Profes-
sors, teachers, lecturers, trainers—from schools,
colleges, training institutes—all of them can avail
this benefit. And, the institution can be private or
government owned. As long as you teach, we want
to thank you.
Q. How to get this discount?
A. Academicians can use the promocode ACAPASS
and upload an image of their identity proof. That’s
it. If we find that proof submitted is invalid, then
we may cancel the registration.
Q. Where can we get the details about the
conferences and workshops?
A. We are updating details of all conferences and
workshops on this page: https://www.indiaelec-
tronicsweek.com/conferences-workshops/. As more
conferences, workshops and meetups get finalised,
we will keep updating this page.
Q. Does the pass fee include GST
A. Yes, GST is included in it—so the amounts indi-
cated are NET, and nothing extra needs to be paid
over and above the stated amounts.
Q. If I need a GST invoice – will that be
provided?
A. Yes, the same will be provided. Shoot us an
email (with your GST number) at rsvp@efy.in, and
our team will provide you with a GST-input-credit-
friendly invoice within 3 working days.
Q. When will I get the attendance
certificates?
A. We typically mail the attendance certificates by
courier to those with designated paid passes, within
1 week, after the event. But, if you want, you can
collect the same on the last day too—as long as you
are amongst those who had registered and paid up
before 1st Feb, 2018. If you paid later, we will have
to mail you—as we won’t be able to print and get
them at the event, on time.
Q. Can the payment be made post the event?
A. No, all payments have to be done before the
event. For further details, contact us at +91-98111
55335 or rsvp@efy.in.
Q. What modes of payments do you accept?
A. We accept all modes of payments—Digital (credit
card, debit card, NEFT, PayTM, etc) and Analogue
(Cheque, DD, etc). The former have to be made in
the favour of EFY Enterprises Pvt Ltd, and mailed to
IEW 2018, D-87/1, Okhla Industrial Area, Phase-1,
New Delhi—110020. To make online payment, you
can use our online registration system or login to
your account and upgrade through it.
Q. I have already registered as a Visitor. Now
I want to upgrade my pass—how do I do that?
A. Simply login to your account at http://login.
indiaelectronicsweek.com and upgrade your pass.
Else, speak to our team at +91-98111 55335, and
they will help you.
Q. How will I know which exhibitors should
I visit?
A. We will be issuing a Show Guide (printed) to all
visitors at IEW. This show guide will also be avail-
able on our website. It will enable you to see list
of all exhibitors and search them product category-
wise.
Q. Why should I print my pre-printable
badges? What’s the benefit?
A. If you print those badges at your office or home,
and come with them to the venue—you will NOT
have to stand in any queue. You can simply pick an
empty lanyard (string with plastic sleeve), fold your
printed badge, and wlak straight in?
Q. If I walk straight in, where will I get my
delegate kit and lunch coupons (if I have
paid for that level of pass)?
A. At the expo floor, we will have May I Help You
Desk, where you can collect the same—at any time.
Q. How many events are there at India
Electronics Week?
A. Overall, five branded events are happening under
IEW: EFY Expo, IoTshow.in, LEDasia.in, T&M Expo,
and EFY Conferences. Under these—many conferenc-
es, seminars, workshops and meetups are happening
across the three days.
Q. Are there any age restrictions with
respect to visitors?
A. Yes, entry is for those aged 16 and above only.
And, entry for students is on the third day only,
which is February 9, 2018.
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
156 January 2018 | electronics for you www.efymag.com
The speakers’ Wall of Fame
Looking back at the success of IEW 2017
Buyers’ Feedback
“This is the fifth time I have participated in EFY Expo. Since the last
five years we have been able to find a lot of good suppliers in India.
Currently, we are working with about 25 global and Indian suppliers
that we got through EFY, from product/service categories like metal
sheets, connectors, ESD and cleanrooms. I wish to continue partici-
pating in this event”
Shanaka Perera, purchase manager, Variosystems Pvt Ltd
“This is a very good platform for buyers and sellers. It is more fo-
cused than the meetings we have in our office or at other places.”
Manoj Dhawan, assistant general manager, Luminous Power
Technologies
“With ‘Make In India,’ such platforms where buyers can meet sellers
have become essential for both. It is difficult to bring people having
the same understanding together and to approach intangible ben-
efits. I feel this type of forums should come up in bigger ways, both
implementation and application wise.”
Gururaj. V. Hiremath, senior deputy general manager
(CSC/IED-CMS), Bharat Electronics Ltd
“One-on-one meetings are very important, especially at the start of a
financial year. I had a good response while talking to suppliers here.
This forum is really good for such activities. I am quite satisfied; I
met the right sellers and at the right time.”
Narayan Kumar J., managing director - technical, Sanjay Technologies
Exhibitors’ Feedback
“We have been participating in EFY events for last six
to seven years. This event has been very good for us,
and we eagerly look forward to come back next year.”
Chris Palin, EMEIA manager, HumiSeal
“Thanks EFY for organising this wonderful exhibition!
We came across some serious visitors. We wish to
push our legs into the industrial segment, and have
got some contacts from the industry segment.”
Manish Joshi, Scientech
“IEW is a good platform for having quality conversa-
tions with customers. This time there was a lot of
IoT talk. Quality of conversation was very good this
time!”
Amit Agnihotri, marketing manager, RS Component
“The show has been great this time! We came across
a lot of manufacturers, suppliers, customers and IoT
startups. The conferences were very informative.
Overall, it was a very good networking event.”
Ranga Prasad M.A., director, Semikart
“As far as the event is concerned, we saw quality this
time, which is very important to us.”
Sanjay Malla, chief executive officer, Toradex
A panel discussion a
t IoTshow.in confere
nce
Inaugural session at the CEO Summit
Robot handin
g out kits to c
onference del
egates
Images say It
Better than Words
IE
W
 P
rE
-s
ho
W
 r
EP
or
t
158 January 2018 | ElEctronics For you www.EFymag.com
exhibitors
The India Electronics Week 2017 brings together a gamut of exhibitors from
electronics, LED and Internet of Things (IoT) sectors. They showcase the
latest innovations across various product categories. Presented in this section
is a curtain raiser of some of the exhibitors, with many more to follow
3C TAEYANG Co. LTd.
3C TAEYANG is specialized as a Cable Assembly provider for IT, Displays,
Medical, Electronic devices and Automotive electronic systems. With our
manufacturing technology, we are able to provide not only the reasonable
price but also competitive data interconnect solutions, and distribute a Mobile
Hotspot (Wi-Fi Router, “MIFI” device) available for All 2G(GSM)/3G/4G(LTE)
Worldwide.
3C TAEYANG product range: Mobile Hotspot (Wi-Fi Router, “MIFI” device),
Micro Coaxial Cable Assembly (Automobile, Ultrasound system, IT devices),
RF Cable Assembly & Connectors, Customized CableAssembly High-Mix, Low-
Volume
We proudly introduce Saison Components as our exclusive & authorized
representative for Indian market which has a prominent presence in industries
such as Renewable, Telecom, Power, Automotive, Consumer, Defence etc.
Contact details: www.tae-yang.co.kr
AbhishEk ENTErprisEs
Established in 2003, Abhishek Enterprises specializes in Li ion and Li polymer
battery pack. Msme registered with udyog aadhar under Make in India. ISO
9001:2015 certified, with welding capacity of 6,00,000 cell per month.
We provide customised solutions to our clients in the field of Solar Street
light, POS terminals, IoT solutions, GPRS device, Medical devices, Metering,
etc.
We also offer our services for contract manufacturing of power bank, battery
pack with PCM, pre-cut Ni strip and wires (single side and two side stripping),
branding of cells as per client requirement.
Contact details: www.amcell.co.in, +91-22-26182711
ANdErs ELECTroNiCs pLC
AndersDX specialises in the design, development and supply of world-class
display and embedded technologies to our global B2B customers.
Working with customers at the design stage of their project, AndersDX uses its
expertise in display, embedded computing and touch control technology to help its
customers differentiate their products through exceptional user interface design.
Optimising every aspect of the display design from touchscreen, cover lens,
backlight and motherboard it ensures the product is truly for the application
and can create a solution that will make a difference.
AndersDX has over 65 years of experience exceeding the expectations of blue
chip customers across a wide range of sectors, unparalleled technological
expertise, and an ingrained “people first” service orientation.
Contact details: www.andersdx.com
ANriTsU iNdiA priVATE LiMiTEd
Anritsu Corporation headquartered in Japan is a global provider of innovative
communications test and measurement solutions for more than 120 years,
providing solutions for existing and next-generation wired and wireless
communication systems and operators. Our products include wireless,
optical, microwave/RF and digital instruments as well as operations support
systems for R&D, manufacturing, installation and maintenance. We also
provide precision microwave/RF components, optical devices and high-speed
electrical devices for communication products and systems.
Anritsu India Private Limited, a 100% owned subsidiary of Anritsu Corporation
has its head Office in Bangalore and branch offices in Noida and Hyderabad.
Anritsu India which has ISO9001:2008 & NABL certified quality management
system brings together the functions of sales, marketing, engineering, service
and technical support for better and broader support.
The India calibration & service centre in Bangalore is well equipped and
capable of servicing the range our products for better support to local Indian
customers. The customers in India include the Mobile R&D/Manufacturing
companies, Defence/Aerospace companies, Mobile/Fixed line operators/NEMs
and Education Institutes is supported by Anritsu team of > 60 members in India.
Contact details: www.anritsu.com
ArihANT iMpEX
Arihant Inpex deals in all kinds of Transformer laminations such as Imported
E&I, Strip laminations for distribution & Power transformers, Torroidal Cores
& Motor Stampings.
Materials available in all grades of CRNO & CRGO in special components/
sizes. Raw material can also be offered in sheets, coils or slitted sizes with
high quality & reasonable price.
Contact details: www.golecha.net, 044-26692052
AXELTA sYsTEMs pVT. LiMiTEd
Axelta Systems has emerged as a leading IoT entity delivering utmost value
and effective competency to business through a host of innovative, cost
effective and IoT powered solutions catering to comprehensive needs of an
organization.
The company’s success is marked with exclusivity as it has also gained
prominence as the global leader in IoT Education. Based in Hyderabad, Axelta
was incorporated in 2013 with the mission of empowering business with
significant enhancement in processes through effective IoT. The company is
the brain child of two Ex IITians, Piyush Jain & Manish Agarwal, who bring
with them a profound expertise rooted in combined experience of fifty years
in global IT industry.
Contact details: www.axelta.com
160 January 2018 | ElEctronics For you www.EFymag.com
E CoNTroL dEViCEs
E Control Devices, established in 2012, is an ISO 9001:2015 organization
having core expertise in Electronic component distribution.
We are a team of professionals having both business and technical expertise with
a very structured operations and supply chain knowledge to shorten delivery
time and meet customer wide requirements. We cater almost all the segments
like Consumer Electronics, Automotive, Industrial, Defense, IoT, Lighting, Solar etc.
We source and stock broad range of electrical & electronic components
like Relays, Connectors, Switches, Sensors, RF/Microwave Components,
ICS, Mosfets, Analog devices, Bridges, Displays, Transducers, Sensors,
Optocouplers, Fiber optic devices, Industrial automation, Instrumentation,
IGBT, Thyristors, Rectifiers, Control systems, PLC & CNC parts, Drives, Servo
motors, RF components ,DMD chips, Process control equipment, Military
components, Zigbee, WI-FI, Bluetooth components and Modules.
We also specialize in hard to find Components.
Contact details: www.econtroldevices.com, 0129-4003088
CLoUdThAT TEChNoLoGiEs
Incorporated in March 2012, CloudThat Technologies provides training and
consulting services in Cloud, Big Data & IoT technologies for mid-market &
enterprise clients around the world. With expertise in major cloud platforms
including Amazon Web Services and Microsoft Azure we are the single
technology source for organizations looking to utilize the flexibility and power
Cloud Computing & IoT provides.
We are focused on empowering IT professionals and organizations with
leveraging Cloud, Big Data & IoT. Co-founded by Bhavesh Goswami, an ex-
Amazonian who was part of the AWS product development team and
Himanshu Mody, who brings in 17 years of experience in IT Training and
Consulting business allows us to deliver high quality training and consulting
services with best practices.
We have trained more than 7,000 IT professionals and conducted corporate
trainings for some of the fortune 500 companies which includes Accenture,
Infosys, Fidelity, HCL, Intuit, GE, TCS, HP, SAP, Oracle, Western Union, Philips,
Flipkart, L&T and Samsung etc.
We have presence in Bengaluru, Mumbai, USA & UK.
CloudThat is an AWS Consulting Partner, Microsoft Silver Learning Partner,
Microsoft Silver Cloud Platform Partner, Red Hat Certified Training Partner,
MongoDB Ready Partner and part of Kryterion Testing Network.
Contact details: www.cloudthat.in
CirCuit SyStem india Ltd. (PCB POWer
marKet)
With over 20 years of excellence, PCB Power has become one of India’s
leading PCB designers and manufacturers. Our focus on high-quality and
economically viable systems combined with unmatched consistency has
made us the firm of choice throughout India.
Our customers rely on us for their requirements in research & development,
aerospace & defence, automotive, railways, medical, educational,
telecommunication, industrial electronics and other critical areas of development.
With this value we are proud to launch the PCB Power Market. Be it design,
customization or a component, the PCB Power Market has solutions for all
like customized designs, PCB layouts, power stencils, soldering solutions,
PCB fabrication, PCB assembly, heatsinks & mounting kits, thyristors &
triacs, varistors , switches, capacitors, rectifiers, to thousands of small and
large components that are required to build your state-of-the-art PCB. With
everything under a single roof, the PCB Power Market is the first of its kind in
India – one stop for infinite solutions.
We believe in providing solutionsthat meet the customers requirements.
Cutting-edge High Frequency-RF metal clad PCBs, RT Duroid and Higher Layer
count with lean manufacturing and SPC, are among our ground-breaking
solutions, manufactured in our UL certified facility.
Contact details: www.pcbpower.com
CYrrUp
Our product “Vehicle Black Box” is for vehicles which works in similar fashion
as in flight black box, with additional features to know the vehicle status,
monitor its health, fuel levels, while providing safety and security of vehicle
and its occupants.
It helps us to analyze the driver, how he is driving. With our data analytics
reports, you can draw conclusions on his driving skills and your vehicles
health. It also notifies instantly if your driver is taking sharp turns, jumping
signals or ignoring signboards. Also, if driver is drunk beyond permissible level
it will not allow him to drive. Panic buttons and push-to-call options comes
handy in case of accidents to get instant help from our 24*7 call-center for
ambulance or police help.
It has 2 cameras which track live footage of roads taken and inside the vehicle.
These footage helps in insurance claims, false accuses or illegal blames. Our
one of its kind visual analytics based solution, detects driver drowsiness while
the vehicle is on the move. Additionally, we are developing an auto alert
system meant for drivers, targeting heavy vehicles when moving vehicle in
reverse. This is all-in-one system for complete vehicle management applicable
for personal vehicles, fleet management or transportation management.
Contact details: www.cyrrup.com
digi-Key eLeCtrOniCS
Digi-Key Electronics, a global Internet-based distributor of electronic
components, is an authorized distributor located in Thief River Falls,
Minnesota, USA. By visiting our website engineers have access to more than
6 million components from 650+ trusted suppliers, with over 1.3 million
products in stock and available for immediate shipment.
The company offers a vast selection of online resources including a range of
EDA and design tools, reference design library, on-demand multimedia library,
a comprehensive article library, and community forums, among others. Digi-
Key also offers numerous Supply Chain solutions such as bonded inventory
and just-in-time shipping, as well as a newly updated BOM manager.
Digi-Key prides itself on its ability to provide the best possible service to
customers.
Contact details: www.digikey.in
bridGEThiNGs ioT
BridgeThings IoT is a startup that builds solutions ranging from a simple
AC-DC dual output SMPS (Brand: BT100, for powering IoT sensors
to niche wireless lighting solutions that save up to 60% more power
than a typical LED light. With patented technology that reduces power
consumption of LED lighting based on different sensors, we believe in
taking the LED lighting revolution to its next level. In addition to reducing power,
our lighting solutions helps our customers by cutting down the replacement cost
& time by upto 70%.
With strong competency in simple & mesh wireless networks, Bridge Things
IoT has built a plug & play wireless hardware platform to enable students and
the DIY community to prototype their ideas in no time. We believe in building
solutions that brings efficiency in terms of cost & time.
Contact details: www.bridgethings.com
162 January 2018 | ElEctronics For you www.EFymag.com
FErro sTAr
Ferro Star was established with the aim of making quality ferrite components
(Ferrite Cores & Phenolic Bobbins) for the Electronic Industry. Our motto
is customers satisfaction through innovation & cost consciousness. Based
on its wealth of experience and technical know how we are competent to
design, develop & provide customized ferrite components as per customer’s
requirements at very competitive prices.
The company is marketing the products of Tongxiang Huayuan Electronic
Co.LTD. in India. Presently the Company is dealing in Ferrite Cores i.e. EE/EC/
EDR/EPC/ EFD /PQ/ RM/ET/RING CORES/DRUM CORES/RODS etc. Ferro Star
also deals in Iron Dust cores of various sizes.
GATik GrEENErGY pVT. LTd.
Gatik Greenergy provides wireless home automation products and solutions.
Our products help in turning a home into a smarter and energy efficient one.
With a combination of products from own stable and international brands,
we enable one-touch operations, wireless and remote management of every
aspect of a living space and make it smart.
Gatik Greenergy automation solutions can be used for surveillance, security,
lighting, home appliances, energy management, home theatre and
entertainment. The products can be retro fitted into any building thereby
making it smarter at lowest possible investment. Greenergy’s smart-home
solutions come with built-in remote management capabilities via mobile app.
Part of Bangalore based multi-million dollar Gatik Group, which has interests
in broadband, IT, technology, services and infrastructure, we are one of the
few companies with own R & D wing and indigenously developed products.
Contact details: www.greengatik.com
GT MAGNETiCs pVT LTd
GT Magnetics Pvt. Ltd is one of the leading manufacturers of wound
magnetics, that has a wide range of coils and ferrite transformers. The
company is ISO 9001:2008 certified. Its manufacturing unit was established
in 1997 and since then, it has established a reputation for reliable quality and
on time execution of orders.
Its major products include wound components for the lighting industry, LED
driver transformers, solar lighting products, CFL driver transformers, wound
components (for audio-video and automotive applications), inverter and UPS
systems (for the telecom and charger industries), filter and choke coils and
customised ferrite transformers and coils.
Apart from complying with customers requirements, our prime focus is to
adhere to industry-defined quality standards for ferrite transformers, coils,
SMPS, line filters, etc.
All its products and processes are in compliance with set standards and
norms, as drafted by quality monitoring institutes. Equipped with a good
infrastructure and a team of technical experts, the company’s facility is spread
across 139.35sqm of built area with 2322.57sqm of open space. The different
types of machinery installed at its unit include a CNC automatic winding
machine, an automatic core tapping machine, high-voltage breakdown
testers, temperature-controlled ovens, etc.
Contact details: www.gtmagnetic.com, +91 11 45527299
ELEMENT14 iNdiA pVT. LTd.
Element14 is a leading distributor of electronic components, single board
computers and development kits, tools, test and measurement, software and
design services. We have out-performed the industry norms on parameters
like availability of products, shipping speed and customer responsiveness. At a
given time, we have more than 6,50,000 products like electronic components,
Interconnect and e-mech products, electrical, tools and test and measurement
from more than 3500 leading suppliers like Analog Devices, NXP, Molex, TE
Connectivity, Microchip, Texas Instruments, Vishay, Fluke, Tektronix, Keysight
etc that are in stock and ready to be shipped from our global warehouses.
We also offer the first and only community www.element14.com for design
engineers and electronics enthusiasts.
area of Operations
Segments: Electronic components distribution
Products and Services: Semiconductors and ICs, Single Board Computers and
Development kits, Interconnect and Passives, Electro Mechanical Products,
Tools, Test and Measurement, Design Services, Softwares
Key focus areas: IOT, Prototyping
Parent Company Listing: NYSE
Contact details: www.in.element14.com, 1800 3000 3888
EMbdEs TEChNoLoGiEs pVT LTd
EmbDes Technologies, an engineering solution provider, founded in the year
2012 with offices in Bangalore and Chennai. EmbDes’s focuses on providing
solutions from the concept. The solution includes proof of concept, pilot
production and mass productionbased on customer needs.
Our expertise: Firmware and Linux Device Drivers, Application Development -
Android and iOS, FPGA - IP Core Development, Hardware Design, PCB Design,
Thermal Analysis and Enclosure Design, Proto typing (PCB and 3D Printing),
Mass production (PCB), Injection molding, Sheet metal works
Contact details: www.embdestech.co.in
EMs TEChNoLoGiEs
EMS Technologies is an exclusive distributor for Lackwerke Peters, Germany
and in India for the past 10 years.
Peters have manufacturing experience of more than 55 years in conformal
coating, casting compounds and casting resins, and have presence in 65
countries.
In addition to this EMS Technologies has successfully diversified in the
following related areas:
1. Supply & Manufacturing of ESD- Antistatic products
2. We are manufacturing customized Packing materials (Bubble bag, Metal
bag, VCI bag etc.)
3. We are specialized in Antistatic PET Tray for PCB’s in electronic industry.
EMS Technologies has consolidated its role as a provider of complete
“Conformal Coatings, Conformal Coating Job works & solutions, ESD-Antistatic
products” and foraying into ancillary services related electronics.
Contact details: www.ems-technologies.com
164 January 2018 | ElEctronics For you www.EFymag.com
HK WentWOrtH (india) Pvt Ltd
Electrolube has roots stretching back to 1941, when Henry Kingsbury formed
Kingsbury Components to manufacture volume controls. It was here that
Henry formulated a specialist oil that enhanced the electrical performance
and lifetime of the contact surface in addition to reducing friction of moving
parts.
This breakthrough prompted a range of contact lubricants, forming the basis
of Electrolube. The company now offers thermal management materials,
conformal coatings, encapsulation resins, cleaning solutions and maintenance
products for the electronics industry.
With an expanding presence in 55 countries, Electrolube has a reputation
for excellence. All our products range are manufactured at our factories in
UK, China and India to ISO 9001, ISO 14001, IATF 16949 and OHSA 18001
certification.
Unlike companies with standardised solutions that fail to meet the technical
specifications required for your product, Electrolube’s technical experts create
customised solutions and support you from design through implementation
and beyond.
Contact details: www.hkw.co.uk
hUMisEAL
Humiseal provides the wide selection of products to meet its customers tough
environmental and chemical protection requirements for electronic circuits
and systems. It manufactures over 60 electronics coatings, thinners, strippers
and masking materials and can also offer custom formulations to meet
unusual specifications. HumiSeal® products are qualified to MIL-I-46058C,
UL746E and IPC-CC-830 standards. We offer production facilities certified to
TS-16949. The standard demanded by the automotive industry.
The product portfolio is further enhanced by a range of complimentary
materials that include Thermal management, Display adhesives, Damming &
Potting materials, Conductive adhesives and Sealants.
Our approach to research and development is multi-faceted. The largest part
is market-driven, listening to what our customers want and delivering against
their expectations. At the same time, we are continually looking to the future
and working to develop innovative new products. We have always been
proactive regarding environmental issues and corporate responsibility. When
it comes to protecting your electronics, it makes sense to trust HumiSeal.
Contact details: www.humiseal.com
iGNiTAriUM TEChNoLoGY soLUTioNs
priVATE LiMiTEd
Ignitarium Technology Solutions is a silicon and embedded system solution
provider that has offered cutting-edge engineering solutions in IC design,
System design, Embedded software, Mobility software & Application
development, ever since its inception in 2012.
Headquartered in Bangalore, with business entities in Kochi, San Jose,
USA, Ignitarium embraces the significance of fire, by igniting, purifying,
and refining ideas to produce technology-driven thought leadership, IP,
solutions and services. We are core team of technologists, who have a
collective industry experience of over 100 years, with expertise in IC design
and implementation, FPGA design, Embedded system engineering and
Software development.
Ignitarium’s design service centre focuses on executing projects in VLSI and
software domains. Design services include Semiconductor logic design and
architecture, Design verification, FPGA prototyping, Embedded and Mobility
software.
The key technology focus areas include computer vision, machine learning,
deep learning, IOT and device mobility.
Contact details: www.ignitarium.com
hApsTroNiCs TEChNoLoGY pVT LTd
HAPSTRONICS Technology Pvt. Ltd, with headquarters in Bangalore provides
superior Sales & Support in Electronic Design Automation and Printed Circuit
Board industry, serving Hardware and Software markets.
HAPSTRONICS is authorized channel partner for – Pulsonix, Easy Pc, PCB
Libraries, PCB Investigator tools. Industry-proven PCB design suites which
provides a feature-rich, fully scalable solution that can be expanded and
upgraded as PCB challenges and the level of design sophistication grows.
In order to meet the customer needs of our clients, HAPSTRONICS maintains
a wide range of PCB design applications, exceptional functional and technical
expertise coupled with extensive industry knowledge.
HAPSTRONICS goal is to exceed the expectations of every client by offering
outstanding customer service, increase flexibility and greater value in PCB
design environment. Our principals are distinguished by the functional and
technical expertise combined with hands-on experience, thereby ensuring
that our clients receive the most effective and professional support from us.
Contact details: www.hapstronics.com
hArihi ohM ELECTroNiCs
HARIHI OHM ELECTRONICS is authorised distributor in India for M/s. DIGI
INTERNATIONAL, USA (www.digi.com) for Zigbee/Xbee, WiFi, Cellular, IoT
Gateways & Embedded SBCs and also distributor in India for M/s.AMPEDRF
TECH INC., USA for Bluetooth Modules (www.ampedrftech.com) and we
support all kind of Antennas for wireless.
Contact details: www.harihiohm.in, 040 2796 1299
hiMEsh rEddiVAri TEChNoLoGiEs
Module143.com is an e-commerce website under Himesh Reddivari
Technologies Pvt. Ltd. A leading electronics and IoT company focussed on
sales and service of electronic components for students and makers, which
are used in their IoT, Embedded and Robotic projects. The company also
conducts workshops on different platforms like Arduino, RaspberryPi, IoT, AI
embedded systems, Robotics etc.
Contact details: www.Module143.com
166 January 2018 | ElEctronics For you www.EFymag.com
JTk TEChNoLoGY iNdiA priVATE LiMiTEd
We design & manufacture various kinds of inductors, electronic transformers,
chokes, filters, inverters, and wire harness that are applied in lighting, green
energy and home appliance industry.
JTK has established comprehensive quality control system. We are certified
with ISO9001 and ISO14001, and are also certified in UL system, CQC and CESI
certifications. which ensures our high standard quality product.
With outstanding management, we have sustained and supported many
international electronic companies such as GE, Schneider, Samsung, Haier,
GOODWE,DELTA and still expanding its customer group.
Contact details: No. 62, 4th Floor, Mahalakshmi Metal & Rolling Mills
3rd Cross, 1st Main, 2nd Stage, Yeshwanthpur Industrial suburb. Bangalore,
PIN:- 560022 (KA, INDIA), www.jtkindia.com
kArNATAkA bioTEChNoLoGY ANd
iNForMATioN TEChNoLoGY sErViCEs
(KBitS)
It is the nodal agency of the Department of IT and BT, Government
of Karnataka and a single point contact for investors in IT, BT, ESDM, AVGC and
Startup sectors. It coordinates the conduct of the department’s flagship
annual events like Bangalore IT.biz, Bangalore India
