Q&A: Outside-the-Box Engineering Hands-Free, RPi-Based Monitor |
The JEADI ARM Pt. 3 Automatic Control Pt. 2 | Hybrid Cooling 101 |
Power Analysis Attacks | Vintage Programming Languages |
LoRa Wireless Communication The Future of Embedded FPGAs
COMMUNICATIONS
JUNE 2017
ISSUE 323CIRCU
IT CELLAR | ISSU
E 323 | JU
NE 2017
circuitcellar.com
circuitcellar.com
BUILD AN MCU-BASED
MONITORING SYSTEM
SPECIAL FOCUS
3-D PRINTING
CC Vault



Unlock the power of embedded design.
Order yours today! cc-webshop.com
*CC Vault is a 16-GB USB drive.
A vault of need-to-know information in the fields of embedded
hardware, embedded software, and computer applications

This pocket-sized vault comes fully loaded with every issue of Circuit Cellar
magazine and serves as an unparalleled resource for embedded hardware
and software design tips, schematics, and source code.
From green energy design to ‘Net-enabled devices, maximizing power to
minimizing footprint, CC Vault* contains all the trade secrets you need to
become a better, more educated electronics engineer.
www.cc-webshop.com
The innovations of tomorrow start
with great development tools
Our tools offer:
www.iar.com/ew
• Outstanding optimizations
• Complete safety certification
• Powerful code analysis
• Strong trace technology
• Extensive support services
http://www.iar.com/ew
CIRCUIT CELLAR • JUNE 2017 #3232
Issue 323 June 2017 | ISSN 1528-0608
CIRCUIT CELLAR® (ISSN 1528-0608) is published monthly by:
KCK Media Corp.
111 Founders Plaza, Suite 904
East Hartford, CT 06108
Periodical rates paid at East Hartford, CT, and additional offices.
One-year (12 issues) subscription rate US and possessions
$50, Canada $65, Foreign/ ROW $75. All subscription orders
payable in US funds only via Visa, MasterCard, international
postal money order, or check drawn on US bank.
SUBSCRIPTIONS
Circuit Cellar, P.O. Box 462256, Escondido, CA 92046
E-mail: circuitcellar@pcspublink.com
Phone: 800.269.6301
Internet: circuitcellar.com
Address Changes/Problems: circuitcellar@pcspublink.com
Postmaster: Send address changes to
Circuit Cellar, P.O. Box 462256, Escondido, CA 92046
ADVERTISING
Contact: Paul Lipsey
Phone: 757-525-3677
Fax: 888-980-1303
E-mail: plipsey@circuitcellar.com
Advertising rates and terms available on request.
New Products:
New Products, Circuit Cellar, 111 Founders Plaza, Suite 904
East Hartford, CT 06108, E-mail: newproducts@circuitcellar.com
HEAD OFFICE
KCK Media Corp. 111 Founders Plaza, Suite 904
East Hartford, CT 06108
Phone: 860.289.0800
COPYRIGHT NOTICE
Entire contents copyright © 2017 by KCK Media Corp.
All rights reserved. Circuit Cellar is a registered trademark
of KCK Media Corp. Reproduction of this publication in
whole or in part without written consent from
KCK Media Corp. is prohibited.
DISCLAIMER
KCK Media Corp. makes no warranties and assumes no
responsibility or liability of any kind for errors in these
programs or schematics or for the consequences of any such
errors printed in Circuit Cellar®. Furthermore, because of
possible variation in the quality and condition of materials and
workmanship of reader-assembled projects, KCK Media Corp.
disclaims any responsibility for the safe and proper function
of reader-assembled projects based upon or from plans,
descriptions, or information published in Circuit Cellar®.
The information provided in Circuit Cellar® by KCK Media
Corp. is for educational purposes. KCK Media Corp. makes
no claims or warrants that readers have a right to build
things based upon these ideas under patent or other
relevant intellectual property law in their jurisdiction, or
that readers have a right to construct or operate any of
the devices described herein under the relevant patent or
other intellectual property law of the reader’s jurisdiction.
The reader assumes any risk of infringement liability for
constructing or operating such devices.
© KCK Media Corp. 2017 Printed in the United States
THE TEAM
PRESIDENT
KC Prescott
EDITOR-IN-CHIEF
C. J. Abate
CONTROLLER
Chuck Fellows
ADVERTISING COORDINATOR
Nathaniel Black
GRAPHICS
Grace Chen
ADVERTISING SALES REP.
Paul Lipsey
FOUNDER
Steve Ciarcia
PROJECT EDITORS
Chris Coulston
Ken Davidson
David Tweed
Game Changers: 3-D Printers, Embedded FPGAs, & More
If you’re interested in 3-D printing, you’ve come to the right place. This
issue includes a “special focus” section dedicated to the subject. In an essay
titled “A Dynamic Overview of Key 3-D Printing Features,” Alexandrea Mellen and
Ashley Mellen cover the history of commercialized 3-D printing technology and
also discuss the current state of the industry (p. 38). On page 42, we present
interviews with two 3-D printing
innovators—Nicolas Roux (Founder/
CEO of Zimple) and Jeff Moe (Founder/
CEO of Aleph Objects).
The rest of the issue comprises
articles on a variety of interesting
subjects, from power analysis attacks
to vintage programming languages.
Below are short article previews.
Starting on page 12, Cyrus Moradi
presents a Raspberry Pi-based
autonomous monitoring system. You
can apply Cyrus’s techniques to build a monitoring system for a variety of other
applications.
In the third article in the series titled “JEADI ARM Project,” Abdul Rafay,
Michael Smith, and Jason Long detail the required connections for the boards to
add a JEADI output interface (p. 18). They also cover the project’s software.
Last month, George Novacek introduced the basic principles of automatic
control, including a simple closed-loop control system, common control laws,
and proportional system shortcomings. This time he tackles frequency domain
analysis (p. 52).
Turn to page 56 for Ayse Coskun’s thoughts on high-performance chips and
the potential of hybrid cooling. She posits that that hybrid and heterogeneous
cooling methods can substantially improve power efficiency.
System and data security are serious concerns for hardware engineers
and embedded software developers alike. In “Breaking a Password with Power
Analysis Attacks,” Colin O’Flynn addresses power analysis attacks and how they
can be used to recover passwords (p. 60).
Like many of you, Robert Lacoste has a passion for retro electronics and
technology. This month he offers an interesting overview of several vintage
programming languages (p. 64). You might even want to use one for an upcoming
project!
On page 70, Jeff Bachiochi kicks off a new series on long-range, low-power
wireless communications. He introduces LoRa technology and describes its
advantages over other options.
Geoff Tate (CEO/Cofounder of Flex Logix Technologies) closes this issue with an
essay on the future of embedded FPGAs (p. 80). He argues that you can’t afford
to not take advantage of embedded FPGA technology.
C. J. Abate
Innovative 3-D printing technology
COLUMNISTS
Jeff Bachiochi (From the Bench), Ayse K. Coskun (Green Computing),
Bob Japenga (Embedded in Thin Slices), Robert Lacoste (The Darker Side),
Ed Nisley (Above the Ground Plane), George Novacek (The Consummate
Engineer), and Colin O’Flynn (Embedded Systems Essentials)
mailto:circuitcellar@pcspublink.com
mailto:circuitcellar@pcspublink.com
mailto:plipsey@circuitcellar.com
mailto:newproducts@circuitcellar.com
circuitcellar.com 3
OUR NETWORK
SUPPORTING COMPANIES
NOT A SUPPORTING COMPANY YET?
Contact Paul Lipsey (plipsey@circuitcellar.com, Phone: 757-525-3677, Fax: 888-980-1303)
to reserve space in the next edition of Circuit Cellar.
Accutrace, Inc. C3
All Electronics Corp. 79
CCS, Inc. 79
Elprotronic 47
IAR Systems 1
Imagineering, Inc. 78, C4
Lauterbach GmbH 25
MaxBotix, Inc. 79
Mouser Electronics, Inc. 78
PanaVice Products, Inc. 41
Saelig Company, Inc. 78
Scidyne, Corp. 79
Siglent Technologies America, Inc. 15
Technologic Systems 21, 78
NEWSLETTER
Sign up for the Circuit Cellar Newsletter to receive electrical engineering
tips, embedded systems industry news,and exciting product deals via
e-mail to your inbox on a regular basis. If you’re looking for essential
electrical engineering-related information, we’ve got you covered: embedded
development, programmable logic, wireless communications, robotics, analog
techniques, embedded programming, and more!
 A FREE Weekly Newsletter
mailto:plipsey@circuitcellar.com
www.circuitcellar.com
www.audioxpress.com
www.voicecoilmagazine.com
CIRCUIT CELLAR • JUNE 2017 #3234
CONTENTS JUNE 2017 • ISSUE 323
COMMUNICATIONS
 INDUSTRY & ENTERPRISE
06 : PRODUCT NEWS
11 : CLIENT PROFILE
Newhaven Display International, Inc. (Elgin, IL)
 FEATURES
12 : Hands-Free, RPi-Based Monitoring System
By Cyrus Moradi
How to build and program a handy monitoring system
around a Raspberry Pi
18 : The JEADI ARM Project (Part 3)
Connections and Software
By Abdul Rafay, Michael Smith, and Jason Long
The required connections and software to complete the
JEADI ARM project
26 : FROM THE ARCHIVES
FPGA Embedded Microcontroller Environment
By John Clayton
An in-depth look at a “slightly unusual” approach to
designing with an FPGA
 CC COMMUNITY
32 : QUESTIONS & ANSWERS
Creativity Lives Here
An Interview with Jean Noel Lefebvre
By Wisse Hettinga
A chat with Jean Noel Lefebvre, who launched Ootsidebox
at the YouFactory fab lab in Lyon, France
35 : EDITORS' PICKS
Communications
Several of the Circuit Cellar team’s favorite articles on
communications-related topicsRASPBERRY PI-BASED MONITORING SYSTEM
JEADI ARM PROJECT
Hard coded
test path
Activate
L
F
R
B
End
User commands
ARM
Microprocessor
LEFT
FORW
RIGHT
BACK
Car
interface
L
F
R
B
Virtual
Car
Direction
LEDs
4
JEADI
RC CAR
circuitcellar.com 5
CONTENTS
 3-D PRINTING
38 : A Dynamic Overview of Key 3-D Printing
Features
By Ashley Mellen and Alexandrea Mellen
The six fundamental 3-D printing processes that
dominate the modern market
42 : Advances in 3-D Printing and Related
Technologies
Q&As with Industry Innovators
Nicolas Roux (Founder/CEO of Zimple) and Jeff Moe
(Founder/CEO of Aleph Objects) talk about innovation
and the future of 3-D printing
48 : Resources for Cutting-Edge 3-D Printing and
Related Technologies
 COLUMNS
52 : THE CONSUMMATE ENGINEER
Automatic Control (Part 2)
Frequency Domain Analysis
By George Novacek
A peek under the hood of control theory with a focus on
frequency domain analysis
56 : GREEN COMPUTING
On the Potential of Hybrid Cooling
By Ayse K. Coskun
How hybrid and heterogeneous cooling methods can
substantially improve power efficiency
60 : EMBEDDED SYSTEMS ESSENTIALS
Breaking a Password with Power Analysis Attacks
By Colin O’Flynn
Use a power analysis attack to break a real system
64 : THE DARKER SIDE
Vintage Programming Language
By Robert Lacoste
A few of the many old-school programming languages
that you might find interesting (and perhaps useful) today
70 : FROM THE BENCH
Long-Range, Low-Power Wireless
Communications (Part 1)
Trading Throughput for Distance
By Jeff Bachiochi
LoRa technology and its advantages over other options
 TESTS & CHALLENGES
76 : CROSSWORD
77 : TEST YOUR EQ
 TECH THE FUTURE
80 : The Future of Embedded FPGAs
Changing the Way Chips are Designed
By Geoff Tate
How embedded FPGA technology is revolutionizing
chip design
VINTAGE PROGRAMMING LANGUAGES
@editor_cc
@circuitcellar circuitcellar
EXCITING ADVANCES IN 3-D PRINTING TECHNOLOGY
CIRCUIT CELLAR • JUNE 2017 #3236
IN
D
U
ST
RY
 &
 E
NT
ER
PR
IS
E
PRODUCT NEWS
Radar Module for Makers
OmniPreSense Corp.’s recently unveiled radar module
is capable of detecting objects 5 to 10 m away and giving
electronic systems enhanced information about the world
around them. Intended for the “maker” community, the $169
OPS241-A module is capable of making any Android phone
supporting USB On-the-Go (OTG) into a radar gun.
The 53 mm × 59 mm OSP241-A short-range radar is capable
of reporting motion, speed, and direction of objects detected
in its wide field of view. You can plug it into a Raspberry
Pi’s USB port to enable a variety of useful applications. An
API provides direct control of the OPS241-A and allows for
changes to reported units (e.g., meters/second and miles/
hour), transmitted power, and other settings. Compared to
PIR or ultrasonic sensors, the OPS241-A provides increased
range, a wider coverage area, and immunity to noise and
light, while providing enhanced information about the
detected object.
Potential applications range from security motion
detection to a radar gun. You can plug the OPS241-A directly
into an Android phone or tablet running USB OTG and terminal
program to turn them into a radar gun. When mounted on a
drone, the OPS241-A can detect objects 5 to 10 m away for
collision avoidance.
OmniPreSense Corp. | omnipresense.com
New MEMS Accelerometers for Industrial Condition Monitoring Apps
Analog Devices’s new ADXL1001 and ADXL1002 high-
frequency, low-noise MEMS accelerometers are designed
for industrial condition-monitoring applications. The
accelerometers deliver the high-resolution vibration
measurements needed for the early detection of machine
failure (e.g., bearing faults).
The ADXL1001 and ADXL1002’s benefits, features, and
specs:
• Deliver ultra-low noise density over an extended
bandwidth with high-g range.
• Available in two models with full-scale ranges of ±100
g (ADXL1001) and ±50 g (ADXL1002).
• Typical noise density for the ADXL1002 is 25 μg/√Hz,
with a sensitivity of 40 mV/g, and 30 μg/√Hz for
ADXL1001 with sensitivity 20 mV/g.
• Operate on single voltage supply from 3. to 5.25 V
• Electrostatic self-test
• Over range indicator
• Rated for operation over a –40°C to 125°C temperature
range.
The accelerometers cost $29.61 each in 1,000-unit
quantities.
Analog Devices | www.analog.com
Essential new product announcements and industry-related news are
posted regularly at CircuitCellar.com.
http://www.analog.com
www.omnipresense.com
www.circuitcellar.com
circuitcellar.com 7
IND
U
STRY &
 ENTERPRISE
PRODUCT NEWS
Fifth-Generation Quasi-Resonant Flyback Controller and Integrated Power IC
Infineon Technologies recently announced the fifth
generation of its stand-alone quasi-resonant flyback controller
and integrated power IC CoolSET family. This generation
offers more efficiency, faster startup, and improved overall
performance. The new ICs are especially designed for AC/DC
switch mode power supplies in a wide variety of applications.
The latest 700- and 800-V CoolMOS P7 families are
integrated with a fifth-generation controller in a single
package. The cascode configuration for the high-voltage
MOSFET in combination with the internal current regulator
provides fast startup performance. Light load performance is
optimized through an Active Burst Mode (ABM) with selectable
entry/exit thresholds.
Furthermore, the device incorporates new algorithms that
minimize the switching frequency spread between different
line conditions. It also simplifies EMI filter design. Device
protection includes input over-voltage protection, brown in/
out, pin short to ground, and over-temperature protection
with hysteresis. All protection features are implemented with
auto-restart to minimize any interruption to operation.
The complete fifth generation quasi-resonant controller
and CoolSET product portfolio will be available starting in
May 2017. The controller comes in an SMD package (DSO-8).
The CoolSET comes in both SMD (DSO-12) and through-hole
(DIP-7) packages.
Infineon Technologies | www.infineon.com
New Development Tool for Bluetooth 5
Nordic Semiconductor’s Bluetooth 5 developer solution for
its nRF52840 SoC comprises the Nordic S140 v5.0 multi-role,
concurrent protocol stack that brings Bluetooth 5’s long range
and high throughput modes for immediate use to developers
on the Nordic nRF52840 SoC. The Nordic nRF5 SDK offers
application examples that implement this new long-range,
high-throughput functionality.The existing Nordic nRF52832
SoC is also complemented with a Bluetooth 5 protocol stack.
Bluetooth 5’s high throughput mode offers not only
new use cases for wearables and other applications, but
also significantly improves user experience with Bluetooth
products. Time on air is reduced and thus leads to faster more
robust communication as well as reduced
overall power consumption. In addition, with
2 Mbps, the prospect of audio over Bluetooth
low energy is possible.
The new Preview Development Kit
(nRF52840-PDK) is a versatile, single-board
development tool for Bluetooth 5, Bluetooth
low energy, ANT, 802.15.4m, and 2.4-GHz
proprietary applications using the nRF52840
SoC. The kit is hardware compatible with the
Arduino Uno Revision 3 standard, making
it possible to use third-party-compatible
shields. An NFC antenna can be connected
to enable NFC tag functionality. The kit gives
access to all I/O and interfaces via connectors
and has four LEDs and four buttons which are
user-programmable.
Nordic Semiconductor |
www.nordicsemi.com
http://www.infineon.com
http://www.nordicsemi.com
CIRCUIT CELLAR • JUNE 2017 #3238
IN
D
U
ST
RY
 &
 E
NT
ER
PR
IS
E
PRODUCT NEWS
New Thermal Imaging Solution for Benchtop Electronics Testing
FLIR Systems recently launched the FLIR ETS320 thermal
imaging solution for benchtop electronics testing. Well
suited for testing and analyzing the thermal characteristics
of electronic components and printed circuit boards (PCBs),
the battery-powered FLIR ETS320 comprises a high-
sensitivity thermal camera and an adjustable, hands-free
table stand. With more than 76,000 points of temperature
measurement, the rechargeable FLIR ETS320 enables you
to monitor power consumption, detect hot spots,
and identify potential points of failure during
product development. The highly accurate camera
can visualize small temperature differences so
you can evaluate thermal performance, ensure
environmental compatibility, and troubleshoot
problems.
The FLIR ETS320 ships fully assembled and
ready to connect to a PC running FLIR Tools
software for detailed data analysis, recording,
and reporting. The integrated test stand and
sliding mount design offer flexibility when imaging
electronic components of various sizes.
The FLIR ETS320 costs $2499 and is available
through established FLIR distribution partners.
FLIR Systems | www.flir.com
Handy Four-Channel,
High-Resolution
Oscilloscope
The TiePie engineering recently
introduced a new four-channel, high-
resolution, USB 3.0 oscilloscope.
Featuring TiePie engineering’s
SafeGround technology, the
Handyscope HS6 DIFF is available in
models with sampling rates from 50
MSps up to 1 GSps. SafeGround enables
you to use the oscilloscope inputs both
as single ended and as differential.
When SafeGround is active and you
accidentally create a short circuit,
SafeGround disconnects the ground of
the input channel without damaging
the oscilloscope or PC.
The Handyscope HS6 DIFF’s
features, benefits, and specs:
• 1 GSps sampling and a flexible
resolution of 8 to 16 bit
• Four input channels with up to 250-MHz analog
bandwidth
• Highly accurate 1 ppm time base
• DC accuracy of 0.25 % and 0.1 % typical
• 200-MSps USB streaming data logger
• Up to 256 mega-sample memory per channel
• SureConnect connection test on all channels
• Spectrum analyzer with 32 million bins
TiePie | www.tiepie.com
Essential new product announcements and industry-related news are
posted regularly at CircuitCellar.com.
http://www.flir.com
http://www.tiepie.com
www.circuitcellar.com
circuitcellar.com 9
IND
U
STRY &
 ENTERPRISE
PRODUCT NEWS
vSound Violin Digital Processor
Saelig Company recently introduce the Cambrionix
ThunderSync16, which provides 16 USB2.0 ports and a
Thunderbolt host connection capable of transfer speeds of up
to 20 Gbps to allow large data transfer in the shortest possible
time. For data syncing requirements, the Thunderbolt’s data
transfer speed delivers a greatly increased data transfer
rate between a host Thunderbolt connection and 16 attached
devices than a USB2.0 connection.
The ThunderSync 16’s features, specs, and benefits:
• Speeds up situations needing large data transfer (e.g.,
video file uploading or operating system updates)
when the data is required to be loaded in the fastest
possible time.
• Supports universal, intelligent charging of USB ports
at up to 2.4 A simultaneously.
• It can be daisy-chained via the dual Thunderbolt
ports.
• Allows for the charging of multiple device types
simultaneously (e.g., mobile phones, MP3 players,
e-readers, etc.)
• Preprogrammed Very Intelligent Charging protocol
ensures the correct charging profile is used for the
specific product, maintaining battery performance
and extending battery life
• Operates with the complementary Cambrionix
LiveView app
• Supplied software displays the charging status in
detail.
• An API is also provided for software automation
scripting, essential for software QA and mobile phone
remarketing companies.
The ThunderSync 16 is well suited for industrial, defense,
security, software QA, and wearable camera applications
requiring large-scale charging and data transfer. It is powered
by an internal universal power supply, and is Intel Certified,
CE Marked, UL Listed, and EMC FCC tested
Saelig Company | www.saelig.com
TeraFire Hard Cryptographic
Microprocessor
Microsemi Corp. recently added Athena’s TeraFire
cryptographic microprocessor to its new PolarFire field
programmable gate array (FPGA) “S class” family. The
TeraFire hard core provides Microsemi customers access to
advanced security capabilities with high performance and low
power consumption.
Features, benefits, and specs:
• Supports additional algorithms and key sizes commonly
used in commercial Internet communications
protocols such as TLS, IPSec, MACSec and KeySec.
• The Athena TeraFire EXP-5200B DPA-resistant
cryptographic microprocessor capable of nearly 200
MHz operation.
• Enables high-speed DPA-resistant cryptographic
protocols at speeds well over 100 Mbps
• Integrated true random number generator for
generating keys on-chip and for protecting
cryptographic protocols
• The TeraFire crypto microprocessor is extensible with
additional object code licensed from Athena or with
accelerators attached via the PolarFire FPGA fabric
Microsemi’s PolarFire “S class” FPGAs with Athena’s
TeraFire cryptographic microprocessor will be available in Q2
2017. A soft version of the core is available for Microsemi’s
SmartFusion2 SoC FPGAs.
Microsemi | www.microsemi.com
http://www.saelig.com
http://www.microsemi.com
CIRCUIT CELLAR • JUNE 2017 #32310
IN
D
U
ST
RY
 &
 E
NT
ER
PR
IS
E
PRODUCT NEWS
Radar Module for Makers
Linear Technology recently announced H-grade versions of
the LT8304/-1 monolithic flyback regulators with guaranteed
operation for junction temperatures as high as 150°C.
By sampling the isolated output voltage directly from the
primary-side flyback waveform, it requires no opto-coupler
or third winding for regulation.
The LT8304H/-1’s features, specs, and benefits:
• VIN Range from 3 to 100 V
• Up to 24 W of output power
• LT8304-1 Capable of output voltages up to 1 kV
• Onboard 2-A, 150-V integrated DMOS power switch
• Off-the-shelf power transformers
• No opto-coupler or transformer third winding required
for voltage feedback
• 116-µA Quiescent current
• Boundary mode operation
• Accurate input enable & undervoltage lockout with
hysteresis
• Output diode temperature compensation
• H Grades: –40°C to 150°C operating junction
temperature
Linear Technology | www.linear.com
Expanded Low-Power, Open-Frame AC-DC Power Supply Series
CUI recently added four low-power, open-frame AC-DC
power supply series to its VOF product family. The VOF 6B,
VOF 10B, VOF 15B, and VOF 20B series are 6-, 10-, 15-, and
20-W power additions to CUI’s general-purpose AC-DC power
supplyportfolio that currently ranges from 6 to 300 W. Well
suited for space-constrained, low-power ITE, industrial,
and consumer applications, the new models are housed in
compact, board-mount packages measuring as small as
1.913″ × 0.917″ × 0.638″ (48.6 × 23.3 × 16.2 mm). They
feature industry-standard pinouts, 4-kVAC isolation, and no-
load power consumption less than 100 mW.
The 6-to-20-W modules feature a wide universal input
voltage range of 85 to 264 VAC with single output voltages
of 5, 9, 12, 15, 24, and 48 VDC, depending on the series.
Operating temperatures at full load range from –25° to
50°C, derating to 50% load at 70°C. All of the models carry
UL/cUL and TUV 60950-1 safety certifications and meet EN
55032 Class B and FCC Class B limits for radiated emissions.
Protections for short circuit, over current, and over voltage
come standard. The series also carry a minimum MTBF of
300,000 h at 115 VAC at 25°C ambient, calculated per MIL
HDBK 217F.
Prices for the VOF 6B, VOF 10B, VOF 15B, and VOF 20B
series start at $7.57 per unit in 100-piece quantities.
CUI, Inc. | www.cui.com
Essential new product announcements and industry-related news are
posted regularly at CircuitCellar.com.
http://www.linear.com
http://www.cui.com
www.circuitcellar.com
circuitcellar.com 11
CLIENT PROFILE
IND
U
STRY &
 ENTERPRISE
Newhaven Display
International, Inc.
Elgin, IL, USA
www.newhavendisplay.com
About Newhaven Display
Since 2001, Newhaven Display has been providing the
worldwide marketplace with cost-effective, high-quality dis-
plays, including OLEDs, LCDs, and VFDs. In addition to its vast
standard part offerings, Newhaven Display develops custom
display designs for all industries. It prides itself on first-rate
customer support, design services, and development assis-
tance.
At its Elgin, IL headquarters, Newhaven Display performs
product quality inspections, stock, design, develop, manu-
facture, and assemble our display products. All of its part-
nered production centers are state-of-the-art facilities with
extensive experience in display development. Newhaven Dis-
play works closely with its production centers to ensure its
products meet all requirements of proper design and quality
standards.
Why Should CC Readers Be Interested?
Newhaven Display offers a variety of high-quality TFT dis-
plays. Ranging from 1.8” to 7.0”, these TFTs come ready with
the option of capacitive or resistive touch and are available
as standard, Premium (MVA), or Sunlight Readable displays.
When wider viewing areas
are needed, the Premium
TFTs have up to 75° view
from all sides, whereas the
Sunlight Readable TFTs are
the ideal option for outdoor
applications.
To help with developing
with these TFTs, Newhaven
Display also has plug-and-play BeagleBone and Arduino de-
velopment boards that make prototyping a breeze. Developed
and designed by Newhaven Display’s engineers in Elgin, IL,
these boards are perfect for any level of engineer looking to
get started with TFT development. For high-quality, brilliant
TFT displays and development assistance, turn to Newhaven
Display.
Circuit Cellar prides itself on presenting readers with information
about innovative companies, organizations, products, and servi-
ces relating to embedded technologies. This space is where Circuit
Cellar enables clients to present readers with useful information,
special deals, and more.
http://www.newhavendisplay.com
www.circuitcellar.com/subscription
CIRCUIT CELLAR • JUNE 2017 #32312
FE
AT
U
RE
S
Cyrus developed a Raspberry Pi-based,
autonomous monitoring system. After
presenting the hardware and the code, he covers
the system’s performance and areas for development.
By Cyrus Moradi
Hands-Free, RPi-Based
Monitoring System
Maintaining a home garden can provide you with inexpensive fresh herbs and
vegetables that might not be readily available
in grocery stores. But for some of you,
watering a home garden or providing it with
adequate sunlight may be difficult or hard
to remember. Implementing an automated
monitoring system can help reduce gardening
errors, schedule watering, and improve
resource allocation techniques.
I recently built a Raspberry Pi-based
system for monitoring my garden’s growth
and well-being (see Photo 1). Specifically,
the Raspberry Pi controls both watering
and lighting. I specify the time of day and
frequency at which water should be pumped
to plants based on the soil’s moisture. The
system’s photo sensor informs the Raspberry
Pi to illuminate the plants with high-powered
LEDs when light is required. Naturally, I can
adjust the lighting and moisture sensitivity
settings according to my preferences.
The system’s Raspberry Pi notifies me of
important changes via SMS texting.
HARDWARE OVERVIEW
The system’s hardware comprises two
subsystems: lighting and watering (see
Figure 1 and Figure 2). Each subsystem
has its own sensing mechanism. Three 3-W
LEDs serve as the system’s primary light
source. The white LEDs—which I chose for
their natural-looking white color—possess a
rather strong intensity for their reasonable
price. The wavelength temperature of the
white LEDs ran between 6000 and 6500
K at roughly 500 nm, whereas the sun’s
temperature resides around 6000 K and 483
nm.[1] The LEDs consumed 3 W of power. As
you can likely tell, the LEDs consumed a lot of
power and dissipated even more heat. Adding
a voltage divider with a potentiometer would
remedy the high-power consumption, help
reduce heat dissipated, and allow the user to
control brightness settings on the LEDs.
We wanted the smart garden’s artificial
lighting to closely resemble natural sun light;
this way, our plants. Although our prototype
used a constant LED intensity, the LED’s
intensities can be changed with a voltage
divider and accompanying potentiometer. A
switched mode power supply (SMPS) can help
drastically reduce power consumption by the
relay module while running the relay at the
relay’s “hold voltage”, the lowest possible
voltage that the relay still switches. Another
circuitcellar.com 13
FEATU
RES
option is to throw in a series resistor to reduce
power supplied (and ultimately dissipated) to
the relay board.
Number 8 screws were used in the
prototype as heatsinks, as the LEDs produce
a huge amount of excess heat. An aluminum
heatsink would greatly improve the current
design, avoiding any possibility of a garden
fire. The LEDs were controlled by relay
switches. Our lights were mounted on tall but
skinny metal legs with hot glue. These “legs”
stood above the plant, but with the wiring
safely distant from the water dispenser and
plant pot to avoid any undesirable catastrophe.
The light sensor consists primarily of a
photo resistor. As the light intensity grows,
the photo resistor’s value drops causing the
Raspberry Pi to read a change in state from
FIGURE 1
The integrated hardware for the entire
garden system
PHOTO 1
The first smart garden prototype
CIRCUIT CELLAR • JUNE 2017 #32314
FE
AT
U
RE
S
low to high. (If the GPIO is set up to active high,
pull-down.) As expected, the photo sensor
responded very well to changes in lighting. In
very dim to dark settings, the sensor did not
conduct, whereas in less dim to light settings,
the sensor outputted a high signal. However,
one could easily insert a voltage divider or
low-gain amplifier to either lower or raise
the turn-on threshold. This alters the default
sensitivity with a hardware hack. As before, in
our case, the lower resistor value was chosen
in order to match the input voltage levels of the
Raspberry Pi. This was then calibrated using
different light intensities. Our field testing
found that the light sensor would turn off in a
dark setting (e.g., covering the photo resistor
with my hand or turning the light switch off)
and turned on in less dim to lighter settings
(e.g., when I held my hand roughly a foot over
the sensor in a well-litroom). Knowing the
analog value of the photo sensor is valuable
for gardeners wanting extra sensitivity for
their plants. Although the Raspberry Pi’s
GPIO pins operate only in the digital realm,
it is possible to use an RC charging circuit to
find the timing constant and, thus, a rough
estimate of the analog voltage.
Just as a plant can have too little water,
it can also have too much water. In order
to provide water to the plants we needed
a system by which the Raspberry Pi could
electronically control the water flow. We
originally considered using a plastic solenoid
valve that used stored gravitational potential
energy in order to dispense the water. This
system required over 7’ of head pressure
for the water to clear the valve. We realized
that this was unrealistic for a home garden
and looked for a more suitable option. We
decided to use a CPU water cooling pump to
inject the water into the plant pot. The relay
switch circuit used for lighting also controls
the switching mechanism for the water
dispensing.
Initially, we planned on creating soil
moisture sensors using graphite pencils and
an analog-to-digital converter. However,
we found that it was easier and relatively
inexpensive (not to mention more professional
looking) to buy soil moisture sensors with
built-in Schmitt triggers. The sensors had
two prongs with plastic encasings that we
simply inserted into the soil. These made
the moisture sensor calibration very easy.
The sensor also proved to be reliable in our
prototype. We didn’t attempt any calibration
methods as the sensors clearly distinguished
between dry and damp or wet soil.
One problem users might have is that
the sensors conducted in both moderately
damp or very wet soil equally well. For plants
needing lots of water, this may be a problem.
This issue can be remedied by adding multiple
moisture sensors with the potentiometers on
the accompanying Schmitt triggers calibrated
to trigger at different moisture levels. This
way the user can specify which setting best
matches the desired moisture values of the
plant by simply selecting which GPIO pin to
use. Otherwise, the user can manually alter
the potentiometer setting using a single
sensor.
SOFTWARE OVERVIEW
The Raspberry Pi garden application
ran Raspbian 4.10.1, unchanged, in a Linux
FIGURE 2
Take a look at the Sain Smart four-
channel relay module. I use only two
channels to control the three LED
lighting and water pump. Note the
switches on the right half of the relay
module. Channel/Relay 1 is used to
control the lighting, whereas Channel/
Relay 2 controls the pump.
• Saelig Company, Inc. • www.saelig.com • sales@saelig.com • 1-888-7SAELIG •
(1-888-772-3544)
Oscilloscope
A Powerful New Alternative:
for only
200MHz
 $379!
• 200MHz 2-Ch Super Phosphor Oscilloscope
• 1GSa/s sampling
• 14Mpts memory
• 100,000 wfm/s refresh rate (normal)
• 400,000 wfm/s refresh rate (sequence)
• Serial triggering/decoding included!
• (I2C, SPI, UART, RS232, CAN, LIN)
• Low-noise front end supports 500uV/div to 10V/div scale
• 10 short-cut buttons for easy use
• Auto measurements for 38 parameters
• Math Functions including FFT
• USB Host/USB Device/LAN (VXI-11) interfaces
• Supports SCPI commands, Pass-Fail, Trigger Out
SDS1202X-E
http://www.saelig.com
mailto:sales@saelig.com
CIRCUIT CELLAR • JUNE 2017 #32316
FE
AT
U
RE
S
environment. I used Python 3 and its basic
libraries such as GPIO and OS. I edited the
code using gedit and nano, but any editor
works. Two Python scripts light.py and
moist.py control the lighting and watering
operations while the bash script, garden.sh,
allows the user to run the garden application
easily. The software used the Twilio API and
various modules that I’ll cover below.
We initially wanted to use callbacks to
control the LED lighting and event detection to
toggle the LEDs. However, because our design
did not require any real-time time constraints,
we chose to implement a program that polled
our sensors. Specifically, the light sensor was
polled if the following conditions were met:
the time of day had to be between 8 AM and
7 PM to mimic real-world daylight hours. The
time settings used the “datetime” Python
module that uses Network Time Protocol
(NTP) queries from global NTP servers for
accurate time readings. The time was set
to the current Eastern Standard Time. If
the gardener does not have network access
or desires a clock that runs independent of
the Raspberry Pi’s power state, a stand-
alone, real-time clock module like the Maxim
Integrated DS1307 would be a great time
source. Note that a network connection is
needed to run the Twilio SMS notifications.
Although we only used hour, the user may set
conditions with minute or second for more
precise specifications using the datetime
module. The start and end times along with
light on/off times can be set by parameters
defined in the bash script, garden.sh. The
user simply inserts the parameters belonging
to their respective python script that wish
to change within garden.sh. This saves the
user time from digging into the code and
modifying variables.
The watering system pumps water from
the reservoir into the plant pot for a set period
of time during daylight hours. While we chose
daylight hours during our initial testing, we
recognize that watering during nighttime
hours would reduce evaporation of water.
Regardless, the time conditions show that it
is possible to constrain run time to specific
times of day. The current configuration in the
bash script has a pump run time of 5 seconds.
It is important to be aware of the pump’s
high pump rate (4L/min). A long run time can
cause your garden to become a swamp! Like
lighting, the begin/end time and running time
settings can be altered to best fit the specific
plant’s needs within the bash script.
The Raspberry Pi updates the user on its
current status through SMS texting. Twilio
offers a free and easy-to-use API that allows
the Raspberry Pi to send texts to the user’s
cell phone, notifying whether the lighting was
on or the pump running.
We began by creating a Twilio account,
following a guide by a hacker who used a
Raspberry Pi to send him SMS texts from his
fish.[2] It involves the standard registration
process such as giving your email, etc. After
choosing our favorite area code for your
Raspberry Pi, we received a phone number,
account ID (for the REST API), and AuthToken.
Next, Twilio was installed onto the
Raspberry Pi:
sudo pip install twilio
Now, Twilio can be run on any Python
program on the Raspberry Pi. We imported
the TwilioRestClient library to our programs
light.py and moist.py:
from twilio.rest import TwilioRestClient

circuitcellar.com/ccmaterials
REFERENCES
[1] T. Ahmed, “Wavelength
of the Sun’s Peak Radiation
Output,” in G. Elert, The
Physics Factbook, 2002,
http://hypertextbook.com/
facts/2002/TahirAhmed.
shtml.
[2] L. Orsini, “My Fish Just
Sent Me A Text Message,”
ReadWrite.com, 2014, http://
readwrite.com/2014/04/23/
raspberry-pi-connected-
home-fish-text-message-
twilio/.
RESOURCES
Adafruit Industries, Rapberry
Pi Model 2,” 2014, https://
cdn-shop.adafruit.com/pdfs/
raspberrypi2modelb.pdf.
T. Ahmed, “Wavelength of the
Sun’s Peak Radiation Output,”
in G. Elert, The Physics
Factbook, 2002, http://
hypertextbook.com/facts/2002/TahirAhmed.
shtml.
Lady Ada, “Adding a Real Time Clock to a
Raspberry Pi,” Adafruit Industries, 2016,
https://cdn-learn.adafruit.com/downloads/pdf/
adding-a-real-time-clock-to-raspberry-pi.pdf.
Python Software Foundation, “Datetime—Basic
Date and Time Types,” https://docs.python.
org/2/library/datetime.html.
Stevenvh, “What Are Some Ways to Use
Relays More Efficiently?,” StackExchange.com,
2012, https://electronics.stackexchange.com/
questions/34561/what-are-some-ways-to-use-
relays-more-efficiently.
SOURCES
Raspberry Pi and Raspbian OS
Raspberry Pi Foundation | www.raspberrypi.orgFour-channel 5-V relay module
Sain Smart | http://www.sainsmart.com
DC30A DC5V/DC12V Brushless DC water
pump
Shenzhen Zhongke Century Technology Co. |
www.minibrushlessdcpump.com
SUNKEE Soil hygrometer detection module
Watt Converter | www.wattconverter.com/
detail/B00AYCNEKW
Programmable SMS API
Twilio | www.twilio.com/sms
http://www.raspberrypi.org
http://www.sainsmart.com
http://www.minibrushlessdcpump.com
http://www.wattconverter.com/
http://www.twilio.com/sms
www.circuitcellar.com/ccmaterials
http://hypertextbook.com/facts/2002/TahirAhmed. shtml
http://readwrite.com/2014/04/23/raspberry-pi-connected-home-fish-text-message-twilio
https://cdn-shop.adafruit.com/pdfs/raspberrypi2modelb.pdf
http://hypertextbook.com/facts/2002/TahirAhmed. shtml
https://cdn-learn.adafruit.com/downloads/pdf/adding-a-real-time-clock-to-raspberry-pi.pdf
https://docs.python.org/2/library/datetime.html
https://electronics.stackexchange.com/questions/34561/what-are-some-ways-to-use-relays-more-efficiently
circuitcellar.com 17
FEATU
RES
ABOUT THE AUTHOR
Cyrus Moradi earned a BS in Electrical and Computer Engineering at Cornell
University. He is a software engineer at MITRE Corp. in Bedford, MA.
The Twilio API client is then defined:
client = TwilioRestClient(account =
accountID, token = tokenID)
accountID and tokenID are the account
number and authorization identification
supplied on your Twilio account from earlier.
To send an SMS message to your phone,
I inserted:
client.messages.create(to = user_num,
from_ = RPI_num, body = ‘msg’)
user_num is the gardener’s cellphone
number (including region [+1] and area code).
RPI_num is the Raspberry Pi’s number supplied
by Twilio, and ‘msg’ is the notification method
sent. This means that as long as the Raspberry
Pi has a Twilio account, the user can update
the code with the desired receiving phone’s
number. These arguments are passed in
the shell script, garden.sh. The arguments
passed include: the user’s phone number;
the Raspberry Pi’s number; Twilio account
and token IDs; and separate run times and
begin/end times for the pump and LEDs. In
the future, I plan on adding a message option
for both python scripts, light.py and moist.py.
RESULTS & FUTURE WORK
The current home garden prototype meets
expectations without any issue. I thoroughly
tested the design to confirm that the basic
tasks operations worked (e.g., lighting and
water dispensing). Next, we confirmed that
the sensing hardware functioned normally
followed ensuring that program did not violate
any of the timing conditions. The Twilio SMS
texting program worked well; it delivered
results as expected.
I envision more features in future
iterations. I initially planned to control water
supply through SMS text reception; however,
I learned that port forwarding (using the local
flask server on the Internet) was not permitted
by the Cornell University network. Otherwise,
a user could use the platform ngrok to run the
flask server from his or her network.
A difficulty I encountered was an issue
with our original RT Preempt kernel patch of
Raspbian. An error developed (possibly self-
made by changing a conf. file) that prevented
me from accessing the Internet. Using the
base version of Raspbian 4.10.1, I was able
to achieve normal functionality. Besides these
errors, the project worked well from the
software side. Notification updates from the
Raspberry Pi arrived accurately and timely.
The time of day conditions from the date time
library were correct.
The relay board adequately powered
both the LED lights and the water pump.
The photosensor was able to differentiate
darkness from lit environments, but the
moisture sensor was unable to differentiate
from soil that was heavily saturated and
slightly saturated water. This ended up not
being a huge issue, but the gardener using
this smart garden prototype should be wary
that incorrect water doses can harm a plant.
My first autonomous indoor garden was a
success! While I could not send texts from my
mobile phone to the Raspberry Pi, the other
systems in the project functioned as intended.
The water pump moved a more than sufficient
amount of water to the plant and the soil
sensor was able to determine when the plant
was watered adequately. The photosensor was
able to determine if the plant was receiving
sunlight and the lights were able to illuminate
the plant container. The lights produced too
much waste heat, which caused the heatsink
adhesive to burn off which may be avoided
if thermal adhesive is used. The system was
also able to inform the user when subsystems
were being activated. I found this to be very
resourceful for the user. A user can know how
frequently the plant is actually being watered
as well as the amount of light the plant is
actually receiving as opposed to its intended
amount. Another improvement to the system
could be the hosting of a website on the user’s
local network that indicates water and light
levels through time. Also, the use of an analog-
to-digital converter to get better information
about the current light and moisture levels
would be helpful. Finally, a compact camera
that would be used for updating the user on
plant growth progress through SMS texting or
email would be a useful addition.
I am satisfied with the prototype’s results.
You could grow food year round in your home
with tis sort of system. You can capitalize on
the use of efficient scheduling and resource
allocation techniques, which make it an
affordable and effective method for low-
volume farming. I hope to inspire a new
generation of farmers that don’t have to
break a sweat as long as the AC is running.
Author’s Note: Alex Jaus was my partner
for this project. He graduated from Cornell
University in 2016 and currently works as a
software engineer at Green Hills Software
in Santa Barbara, CA.
CIRCUIT CELLAR • JUNE 2017 #32318
FE
AT
U
RE
S In the final article of this series, Abul,
Michael, and Jason cover the required
connections and configuration for the
boards to add a JEADI output interface
to provide four new output lines to drive
an actual RC car through its remote
controller. They also cover the software-
related aspects of the project.
By Abdul Rafay, Michael Smith, and
Jason Long
The JEADI ARM Project (Part 3)
This series of introductory articles on embedded systems development discusses
the essential details of the JEADI-ARM
project. Our goal was to provide Just Enough
Additional Development Interfaces to extend
the capabilities of low-cost ARM development
boards. As detailed in the first two articles
in this series, we want to have sufficient
additional hardware interfaces to control a
radio-controlled (RC) car through user button
input and to configure outputs to send signals
to activate a remote controller (see Figure 1).
In Part 1, we discussed setting up the
development environment and tested it by
developing the traditional “Hello World”
program on two demonstration boards,
an STMicroelectronics STM32F4 Cortex-4
Discovery and an EiE Cortex-3 Razor. We
developed a coding style that allowed us to
hide how different ARM cores are interfaced
to the on-board buttons and LED peripherals
that the manufacturers had made available on
the different evaluation boards. We provided
code for a virtual car interface where the car
directions LEFT, RIGHT, FORWard, and BACK
were shown using the on-board LEDs in Part
2. The car path could be controlled by a fixed
path stored in an array. We then developed
JEADI input interfaces (red boxes in Photo 1
and Photo 2) to extend the input capabilities
of each board. This allowed us to control the
virtual car through a custom path controlled
by commands from a six-button user interface.
In this article, we’ll discuss the required
connections and configuration for the two
boards to add a JEADI output interface to
provide four new output lines to drive an
actual RCcar through its remote controller.
In the next section, we’ll show how to drive
the actual RC car by modifying the main.c
code from Part 2 and I/O functions for the
OUTPUT_RC output configuration of the two
boards. We’ll finish by discussing the circuit
modifications needed to make the remote
Connections and Software
Hard coded
test path
Activate
L
F
R
B
End
User commands
ARM
Microprocessor
LEFT
FORW
RIGHT
BACK
Car
interface
L
F
R
B
Virtual
Car
Direction
LEDs
4
JEADI
RC CARFIGURE 1
Here’s an overview of the JEADI
project, which provides Just Enough
Additional Development Interfaces
to allow a low-cost ARM board to
manipulate an RC car.
circuitcellar.com 19
FEATU
RES
controller interface with the boards.
If you don’t want to write all the code by
hand, you can refer to the project’s github
download links listed at the end of article
(STM32F4_RC0 and ATSAM3U_RC0 for the STM
and Razor boards, respectively).
JEADI FOR RC—SOFTWARE
We can remove all the new RC car code
from Listing 1 by setting the define OUTPUT_RC
to 0. This gives us back the same functionality
as in Part 2. We first initialize the LED and
button interfaces before driving the virtual
car interface using DriveCar() with directional
commands either derived from a predefined
array in DriveCar_FixedPath() or by button
commands from our new JEADI input interface
in DriveCar_ButtonPath().
Depending on the input configuration
selected, commands are read either from an
array using the ReadFixedPath() or by reading
the user input buttons until an END_COMMAND
or End button press is intercepted. If the
BUTTON_PATH define is 1, the user input pattern
is converted to the virtual car LED interface
bit pattern using the ProcessInputVirtual()
function. The command is echoed to the output
interface using the DriveCar() when the
Activate button is pressed and then released.
Having the echo occurring on the falling edge
of the Activate signal avoids multiple command
being sent with a single press.
Setting the OUTPUT_RC define to 1 brings
in the new code to control the RC car. The
InitRCOutput() function is used for initializing
the output RC interface. For debugging
purposes, the direction commands from
the fixed array or JEADI button interface
are sent to the virtual car LED interface,
DriveCar(), before activating the real car using
DriverCarRC(). We use the ProcessInputRC()
function to take into account that the signals
must be sent to different I/O pins to control the
virtual and real car interfaces.
JEADI FOR RC—FIRMWARE
Using the same approach as we took in
Part 2, we have defined a series of macros to
allow us to use equivalent code to control the
JEADI interface on the Discovery board (see
Listing 2) and the EiE board (see Listing 3).
The use of these processor-dependent macros
means that we can use a common hardware
interface for both boards in Listing 4.
To take account of the different processor
and board layouts, we made the JEADI output
interface from the breakout pins E8, E10, E12,
and E14 on the Discovery board (see Photo 3)
and from pins A9, A10, A15, and A16, which
come out of the extender board pins on the
Razor board (see Photo 4). ProcessInputRC(),
DriveCarRC(), and WriteCommandRC() in
PHOTO 2
Portions of the EiE Razor board with an additional input interface (a) and on-board LEDs (b) and buttons
marked
PHOTO 1
This is the STM32F407 Discovery with additional input interface and on-board LEDs and button marked.
a)
b)
CIRCUIT CELLAR • JUNE 2017 #32320
FE
AT
U
RE
S
LISTING 2
STM32F4 “IO_functions_RCCAR.h” header entries for the RC car project
//Common main.c for the RC car project
#include <stdio.h>
#include “IO_functions_RCCAR.h”
#define FIXED_PATH 1
#define BUTTON_PATH 0
#define OUTPUT_RC 1 // ** NEW CODE
int main(void){
 //Initialize IO Interfaces
 InitLED();
 InitButtons();
#if OUTPUT_RC //** NEW CODE
 InitRCOutput();
#endif
#if FIXED_PATH
 DriveCar_FixedPath();
#elif BUTTON_PATH
 DriveCar_ButtonPath();
#endif
}
void DriveCar_FixedPath(void){
 //Get command
 int command = ReadFixedPath();
 while(command != END_COMMAND){
 if(ReadActivateButton()){
 //Wait for button release
 while(ReadActivateButton() != 0);
 //Drive virtual car
 DriveCar(command);
#if OUTPUT_RC // ** NEW CODE
 //Convert direction for RC interface
 int commandRC
 = ProcessInputRC(command);
 //Drive RC car
 DriveCarRC(commandRC);
#endif
 //Get next command
 command = ReadFixedPath();
 }
 WaitSometime(SAMPLE_DELAY);
 }
}
void DriveCar_ButtonPath(void){
 while(!ReadEndButton()){
 //Convert button press into a command
 int button = ReadDirectionButtons();
 command = ProcessInput(button)
 if(ReadActivateButton()){
 //Wait for button release
 while(ReadActivateButton() != 0);
 //Drive virtual car
 DriveCarVirtual(command);
#if OUTPUT_RC // ** NEW CODE
 //Convert direction for RC interface
 int commandRC
 = ProcessInputRC(command);
 //Drive RC car
 DriveCarRC(commandRC);
#endif
 }
 WaitSometime(SAMPLE_DELAY);
 }
}
LISTING 1
Common main.c code with functionality to drive the car through the RC output interface
#ifndef IO_FUNCTION_RCCAR_H
#define IO_FUNCTIONS_RCCAR_H
#include “IO_functions_BUTTON_PATH.h”
#define RC_PORT E
#define OUTPUT1_PIN 8
#define OUTPUT2_PIN 10
#define OUTPUT3_PIN 12
#define OUTPUT4_PIN 14
#define RC_LEFT (1<<OUTPUT3_PIN)
#define RC_FORW (1<<OUTPUT2_PIN)
#define RC_RIGHT (1<<OUTPUT4_PIN)
#define RC_BACK (1<<OUTPUT1_PIN)
#define RC_COAST 0x0
#define ENABLE_OPENDRAIN(PORT,PIN)\
 ENABLE_OPENDRAIN_FME(PORT,PIN)
#define ENABLE_OPENDRAIN_FME(PORT,PIN)\
 GPIO##PORT->OTYPER |= (1<<PIN)
#endif
LISTING 3
ATSAM3U “IO_functions_RCCAR.h” header entries for the RC car project
#ifndef IO_FUNCTION_RCCAR_H
#define IO_FUNCTIONS_RCCAR_H
#include “IO_functions_BUTTON_PATH.h”
#define RC_PORT A
#define OUTPUT1_PIN 9
#define OUTPUT2_PIN 10
#define OUTPUT3_PIN 16
#define OUTPUT4_PIN 15
#define RC_LEFT (1<<OUTPUT3_PIN)
#define RC_FORW (1<<OUTPUT2_PIN)
#define RC_RIGHT (1<<OUTPUT4_PIN)
#define RC_BACK (1<<OUTPUT1_PIN)
#define RC_COAST 0x0
#define ENABLE_OPENDRAIN(PORT,PIN)\
 ENABLE_OPENDRAIN_FME(PORT,PIN)
#define ENABLE_OPENDRAIN_FME(PORT,PIN)\
 AT91C_BASE_PIO##PORT->PIO_MDER |= (1<<PIN)
#endif
BUILT FOR EXTREMES
Single Board Computer
Qty 100
Low Power Industrial
Single Board Computer with
WiFi and Bluetooth
$159
TS-7680
From the deserts of Africa to the Canadian tundra,
no terrain is too demanding for our boards.
Deployed in �eet management, pipeline monitoring,
and industrial controls, our single board computers
are working in some of the most demanding
places on Earth.
The TS-7680 is designed to provide extreme
performance for applications which demand
high reliability, fast boot-up/startup, and
connectivity at low cost and low power.
Powered by a 454 MHz ARM CPU the TS-7680
offers a great balance between industrial
features and high end capabilities.
BUILT FOR EXTREMES
Single Board Computer
Qty 100
Low Power Industrial
Single Board Computer with
WiFi and Bluetooth
$159
TS-7680
From the deserts of Africa to the Canadian tundra,
no terrain is too demanding for our boards.
Deployed in �eet management, pipeline monitoring,
and industrial controls, our single board computers
are working in some of the most demanding
places on Earth.
The TS-7680 is designed to provide extreme
performance for applications which demand
high reliability, fast boot-up/startup, and
connectivity at low cost and low power.
Powered by a 454 MHz ARM CPU the TS-7680
offers a great balance between industrial
features and high end capabilities.
www.embeddedarm.com
CIRCUIT CELLAR • JUNE2017 #32322
FE
AT
U
RE
S
Listing 4 have a lot in common with ProcessInput(),
DriveCar(), and WriteCommand(), which we developed in Part
2 to control the virtual car. ProcessInputRC() rearranges the
bits in the button command to the required configuration
to drive the Discovery board’s PORT-E and the EiE board’s
PORT-A. Function DriveCarRC() outputs this bit pattern to the
required port using WriteCommandRC() and it inserts a wait
to allow the car to physically respond before turning off the
drive signals. The new initialization routine, InitRCOutput(),
makes use of the ENABLEPORT() and SETPINOUTPUT() macros
from Parts 1 and 2 to perform most of the configuration of
JEADI output interface pins to control the RC car. We’ll explain
the new macro, ENABLE_OPENDRAIN(), in more detail in the
next section.
OUTPUT INTERFACE DETAILS
Let’s look at some details of the hardware-specific include
files for each board (see Listing 3 and Listing 4). Port and pin
definitions are followed by the output bit patterns to drive the
RC interface.
Note that the output pin signals are written in the following
form:
OUTPUTREGISTER(RC_PORT) = ~command;
The use of the inversion operator ~ is required due to active
LISTING 4
Common I/O functions to drive the virtual car interface using a fixed test pattern in
the RC car project
//Common IO_functions.c for the RC car project
#include “IO_functions_RCCAR.h”
void InitRCOutput(void){
 //Enable RC Port pins
 ENABLEPORT(RC_PORT,OUTPUT1_PIN);
 ENABLEPORT(RC_PORT,OUTPUT2_PIN);
 ENABLEPORT(RC_PORT,OUTPUT3_PIN);
 ENABLEPORT(RC_PORT,OUTPUT4_PIN);
 //Set pin mode to output
 SETPINOUTPUT(RC_PORT,OUTPUT1_PIN);
 SETPINOUTPUT(RC_PORT,OUTPUT2_PIN);
 SETPINOUTPUT(RC_PORT,OUTPUT3_PIN);
 SETPINOUTPUT(RC_PORT,OUTPUT4_PIN);
 //Enable open-drain
 ENABLE_OPENDRAIN(RC_PORT,OUTPUT1_PIN);
 ENABLE_OPENDRAIN(RC_PORT,OUTPUT2_PIN);
 ENABLE_OPENDRAIN(RC_PORT,OUTPUT3_PIN);
 ENABLE_OPENDRAIN(RC_PORT,OUTPUT4_PIN);
 //Pull output high (off) to stop
 // Car starting incorrectly on power up
 WriteCommandRC(RC_COAST);
}
unsigned int ProcessInputRC(
 unsigned int command){
 unsigned int controlRC = 0;
 switch(command & (RIGHT | LEFT)){
 case RIGHT:
 controlRC = RC_RIGHT; break;
 case LEFT:
 controlRC = RC_LEFT; break;
 }
 switch(command & (FORW | BACK)){
 case FORW:
 return controlRC | RC_FORW;
 case BACK:
 return controlRC | RC_BACK;
 default:
 return controlRC | RC_COAST;
 }
}
void DriveCarRC(unsigned int command){
 WriteCommandRC(command);
 WaitSometime(DELAY);
 WriteCommandRC(RC_COAST);
}
void WriteCommandRC(unsigned int command){
 OUTPUTREGISTER(RC_PORT) = ~command;
}
PHOTO 3
Here is the STM32F407 Discovery with additional connections for the input (Part 2) and
output interfaces.
circuitcellar.com 23
FEATU
RES
low nature of the output. This means that a
very important part of the InitRCOutput()
initialization function is the line
OUTPUTREGISTER(RC_PORT) = RC_COAST. This
sets the JEADI output interface to RC_COAST to
deactivate the signals to the RC car at start-
up. If this is not done, the car will be sent
commands to simultaneously go FORWard,
BACK, LEFT, and RIGHT, which is probably
not good for the controller or the car! This
also means that the connected controller
must be powered up only after powering up
the evaluation board. The ENABLE_OPENDRAIN
macro writes the STM32F4’s Output Type
Register, GPIOx_OTYPER, and ATSAM3U’s
Multi-driver Enable Register, PIO_MDER, to
enable open drain outputs.
ARM BOARD HARDWARE
CONFIGURATION
In Part 2, we gave guidelines to extend
the input interface for user commands. In
this section, we’ll describe how to extend
the boards’ I/O capabilities by extending the
output interface for the remote controller.
For output pins, we need to know how
the external component will be driven: active
high or active low, in push-pull or open-drain
configuration, etc. As the name suggests,
active-high components require a logic 1 to
be turned on while active-low are activated
on logic 0. For example, as we mentioned in
Part 2, an LED connected with a pull-down
resistor is active-high, while one connected
with a pull-up resistor will be active-low.
Figure 2 shows output pins with transistors
configured for push-pull and open drain
operations. A CMOS push-pull driver has the
ability to both source and sink current as
the PMOS device turns on when the input is
low and the NMOS device turns on when the
input is high. In open-drain mode, only the
NMOS is active and the driver output can only
sink current. Its two states are low and high
impedance (behaves like open circuit). When
the input is high, the NMOS is active and the
output is set to 0 V, When the input is low, the
NMOS is off and the output is high-impedance.
Typically, we use an external pull-up resistor
to limit the current on any open-drain outputs.
OUTPUT INTERFACE
CONFIGURATION
To proceed with JEADI output interface
pin configuration, we need to know how the
external component (in our example, the RC
controller interface button) will be driven:
active high or active low, in push-pull or open-
drain configuration, etc. So, let’s have a look at
our remote controller circuit. We used a New
Bright RC car (see Photo 5). The direction is
controlled by two rocker switches that push
FIGURE 2
Equivalent internal circuit
representations for open-drain and
push-pull output pin configurations
PHOTO 5
New Bright RC car and controller (Source: www.newbright.com)
PHOTO 4
This is the Razor with additional
connections for the input (Part 2) and
output interfaces.
http://www.newbright.com
CIRCUIT CELLAR • JUNE 2017 #32324
FE
AT
U
RE
S
on an internal button. Removing a couple of
screws from the controller allows inspection
of the remote controller circuit (see Photo 6).
Connecting a multimeter at the various solder
connections while the controller internal
buttons are being pushed revealed that these
buttons on the circuit board are connected
to the ground. Thus, we can assume that the
push button is connected to an internal pull-up
resistor in the transmitter IC (see Figure 3) and
configure the ARM JEADI interface to handle
that situation.
In principle, all you need to do is enable
the processor to trigger a signal equivalent
to a button push, and then directly connect
the JEADI output pins configured in open-
drain mode directly to the switch pins of
the transmitter IC. However, doing a direct
connection is potentially hazardous to the
processor. If the user does not configure the
output in open-drain mode correctly, then
accidently pressing a controller button will
short the processor output to ground. This
will cause a high current drain from the ARM
output, potentially burning it out. We have
avoided this problem by adding a protective
PHOTO 6
Additional components added to the
circuit of the remote controller for
interfacing with the microprocessor

circuitcellar.com/ccmaterials
RESOURCES
Atmel Corp., “SAM3U Series: Atmel | SMART ARM-Based
Flash MCU,” 2015, www.atmel.com/images/atmel-6430-32-
bit-cortex-m3-microcontroller-sam3u4-sam3u2-sam3u1_
datasheet.pdf.
EiE, Razor Firmware, http://embeddedinembedded.com/
low-level-firmware/led-basic-operation.
———, Razor Schematics, http://embeddedinembedded.
com/wp-content/uploads/2016/04/2014-08-29-MPGL1-
EHDW-03-Schematics.pdf.
JEADI Project Files, https://github.com/SMILE-Projects/
SMILE_Projects.
STMicroelectronics, “RM0090 Reference Manual,” DocID018909, Rev
13, www.st.com/resource/en/reference_manual/DM00031020.pdf.
———, “UM1472 User Manuel: Discovery Kit with STM32F407VG MCU,”
DocID022256, Rev 6, 2016, www.st.com/resource/en/user_manual/
dm00039084.pdf.

SOURCES
ATSAM3U Microcontroller
Atmel | www.atmel.com
EiE Razor
Embedded in Embedded | http://embeddedinembedded.com
STM32F4 DiscoverySTMicroelectronics | www.st.com
http://www.st.com/resource/en/reference_manual/DM00031020.pdf
http://www.atmel.com
http://embeddedinembedded.com
http://www.st.com
www.circuitcellar.com/ccmaterials
www.atmel.com/images/atmel-6430-32-bit-cortex-m3-microcontroller-sam3u4-sam3u2-sam3u1_ datasheet.pdf
http://embeddedinembedded.com/low-level-firmware/led-basic-operation
http://embeddedinembedded.com/wp-content/uploads/2016/04/2014-08-29-MPGL1-EHDW-03-Schematics.pdf
https://github.com/SMILE-Projects/
SMILE_Projects
www.st.com/resource/en/user_manual/dm00039084.pdf
circuitcellar.com 25
FEATU
RES
FIGURE 3
These are the connections between the microprocessor and the remote controller. The diode protects the
microprocessor I/O if the interface is incorrectly configured.
ABOUT THE AUTHORS
Abdul Rafay (abdul.rafay1@.ucalgary.ca) is a
graduate student in the Department of ECE
at the University of Calgary. He joined aca-
demia in May 2016 after working for four
years in embedded systems and FPGA-based
digital design and verification.
Mike Smith (Mike.Smith@ucalgary.ca) is a
professor of Computer Engineering at the
University of Calgary. Mike’s main interests
are in developing new biomedical engineer-
ing algorithms and moving them onto multi-
core and multiple-processor embedded sys-
tems in a systematic and reliable fashion.
Jason Long (jason.long@engenuics.com)
graduated from the Department of ECE at
the University of Calgary in 2002 and now
runs an embedded systems design and
training company. He has run the Embed-
ded in Embedded (EiE) program for 15 years.
diode between the JEADI interface and the
controller.
The ground connection and four direction
signals are connected to the jumper cable with
connectors on both ends and taken out of a
slit at the rear of the New Bright RC controller
casing. A similar procedure will be needed
for cars from other manufacturers. We leave
it as an exercise for the reader to modify
the project to send pulse-width-modulated
signals to an RC helicopter control module!
CONCLUSION
As we walked through this series of articles
for programming embedded ARM boards
typically found in the academia, we setup the
build environment, demonstrated hardware
interfacing and developed a modular code
structure using macros that allowed us to
hide the architectural specifics of different
evaluation boards while maintaining
portability. We discussed how to extend the
default capabilities of ARM boards by
providing example of microprocessor control
of a radio-controlled car. Starting with a
virtual car interface to validate the algorithm,
we moved on to driving the real RC car
interface, providing the essential code and
steps to add additional input and output
interface along the way. In future, we are
planning another series of articles where we
are going to add a simple operating system to
the boards. This will allow multitasking and
give us more flexible control of the system, to
enable us to develop more complex and more
interesting applications.
Authors' Note: We'd like to thank Warren
Flaman for his assistance with this project.
Warren is a technician with the Department
of ECE at the University of Calgary. He has
been responsible for the design of custom
hardware for most of Dr. Smith’s hands-on
interfacing laboratories.
advertisement_codecoverage_layout2017.indd 1 11.04.2017 08:32:56
mailto:abdul.rafay1@.ucalgary.ca
mailto:Mike.Smith@ucalgary.ca
mailto:jason.long@engenuics.com
www.lauterbach.com/1659
CIRCUIT CELLAR • JUNE 2017 #32326
FE
AT
U
RE
S If you want to set up a simple
custom microcontroller development
environment, this article is for you. As
you’ll see, all you need to get started
with FPGA-based embedded design
is a PC, some HDL coding/synthesis
tools, and an FPGA board.
By John Clayton
Editor's Note:
This article first appeared in
Circuit Cellar 235, 2010.
FPGA Embedded Microcontroller
Environment
Field programmable arrays (FPGAs) have become packed with logic gates, and many
types also include features such as embedded
block RAMs, hardware multipliers, and PLLs.
Some throw in SERDES, memory interfaces,
or Ethernet MAC functions—all the essential
items needed for putting together really fancy
“systems on a chip.” The FPGA offers these
capabilities at an affordable price point, which
adds excitement for the designer and begs
the question: How can you take advantage of
all that capability? Perhaps best of all, with
FPGAs, there is no real penalty for trying
out a design. If it’s faulty, you can easily
modify it. In this sense, the FPGA becomes
like a quick-turnaround personal foundry, a
veritable playground for experimentation and
innovation. In this article, I’ll share some advice
on setting up a simple custom microcontroller
development environment. Along the way, I’ll
also present some ideas for an “easygoing”
approach to design and development.
THE INGREDIENTS
All you need to get started with embedded
design using FPGAs is a PC, some HDL coding/
synthesis tools, and a suitable FPGA board to
download to. Several suppliers have parts that
are suitable for developing a small custom
microcontroller environment. Obviously, the
larger FPGAs will allow instantiating more logic
(Multicore anyone?) and hardwired multipliers
will often aid in the pursuit of higher execution
speeds. The board design I used is also
given out free, and there’s a user’s manual
describing the board. One word of warning
though: There’s no schematic. It’s basically an
FPGA breakout board, with the download cable
built right in.
In this article, I’ll first describe the rationale
behind my slightly unusual approach to FPGA
design. Then I’ll explain how I built up a system
of building blocks that eventually became the
trusted foundation on which I built and refined
an embedded Microchip Technology PIC16F84-
compatible embedded microcontroller. The
complete code for the design is provided in
Verilog, and you can use many of the same
blocks to build your own designs. (The code is
posted on the Circuit Cellar FTP site.) If VHDL is
the preferred language, I’ll leave the translation
as an exercise for you. I use both languages,
and because VHDL is “strongly typed,” I
believe that Verilog is more appropriate for the
“easygoing” experimenter. If translation is to
be performed from one language to the other,
I recommend doing it the old-fashioned way—
by hand. I don’t currently know of any really
good, automated, free tools for the purpose.
DESIGNERS COME FIRST
One principle that I think is self-evident—
but which is quite often sacrificed in industry
for the sake of cost reduction or basic
economy—is this: The designer/developer is a
respectable person, and some effort should be
expended to make life easier for that person.
Now, back in the good old times (Like the late
1970s?), there were these simple monitor
programs that developers used on SBCs.
They were extremely low-level programs
like Motorola’s MIKBUG or the firmware for
Steve Ciarcia’s Z-80 Applications Processor
(ZAP). These monitor programs filled a very
important function by providing the ability to
reset, read, modify, write, and single-step or
begin code execution at a given point. Now,
within an FPGA, you can create state machines
that provide many of these basic functions in
hardware, without making any demands on
the target processor at all. As you may have
guessed, the “monitor hardware” will have a
circuitcellar.com 27
FEATU
RES
super-short learning curve, which is really not
a bad deal. Once it has met its purpose, it can
be cut out of the design completely, if desired.
IP CORES
This article focuses on producing complex
FPGA designs from basic building blocks that
were written from scratch. This presents a
paradox of sorts. How do I effectively share
what I’ve already built up, while at the same
time encourage the sort of deep learning
that comes from building a setof code
modules from scratch? In essence, what I’ve
decided is that most designers want to build
a particular new function, and would rather
not have to “reinvent the wheel” for all the
surrounding support logic needed to exercise
the experimental new module.
Enter the firmware-based design and
debugging environment built around a
homemade IP core called “rs232_syscon” (see
Photo 1). It works through a serial port, with
no software needed, and it allows you to enter
and read back parallel data from registers
and memory, as well as initiate a Reset
command. With user-defined register fields for
“go,” “single_step,” and for setting hardware
breakpoints, there is really no limit to what the
digital or DSP designer can define, debug, and
use with such a system. Although it is tedious
to hand-enter large amounts of data through
the “hyperterm”-driven interface, scripts can
be easily run from the PC that help alleviate the
drudgery. After all, if it’s no fun, why pursue it
as a hobby or otherwise?
SIMULATION OR NOT?
With the rs232_syscon core, and some
ready-made parameterized and configurable
register blocks up the designer’s sleeve, a
“Module Under Test” can be run through its
paces using the actual target FPGA instead
of a simulator. Figure 1 shows the concept I
used. I will not deny that simulations work like
a charm. But I will say that it takes time to put
together a really good simulation test bench. It
takes more time to carefully run and analyze
the simulation both pre- and post-synthesis.
And in the end, there may well be some
sort of real-world gotchas that just weren’t
covered by the simulation. For example, will
a frequency-doubling PLL correctly lock? Very
few simulations will give good satisfaction on
this type of question. Personally, I want to
know about those real-world gotchas as early
as possible, so I’m suggesting you get the code
compiled and the bitstream loaded into the
FPGA and start debugging ASAP.
DEVELOPMENT MODULES
As I previously stated, there are two major
components which work together in this
firmware-based development environment:
the rs232_syscon, which is the “system
controller,” and the register blocks, which
form the boundary between the development
environment and the new logic or IP core
under test.
Describing the rs232_syscon module
is easy because its purpose is to provide
the world’s simplest command line. There
are three commands: read, write, and
initialize. The syntax is parameterized, so it
FPGA
PC
Serial
Tristate bus
reg_8 reg_8 reg_8
Developing module
or function under test
RS232_syscon
FIGURE 1
A “module under test” can be run through its paces using the actual target FPGA instead of a simulator. This
is the concept I used.
PHOTO 1
This is an example of a screenshot
of rs232_syscon in action, set up for
16-bit address with 8-bit data and
quantity fields. If the quantity is
omitted, the previous value is used.
CIRCUIT CELLAR • JUNE 2017 #32328
FE
AT
U
RE
S
scales according to the way the module is
instantiated (see Table 1).
The UART function is designed with
simplicity in mind—a simple TX, RX, and GND
interface, without double buffering or flow
control of any kind. I trust I haven’t offended
anyone by also conveniently leaving out the
parity bit and fixing the UART transfer size at
8 bits. After all, its just for simple debugging.
I am particularly proud of the automatic
data rate generator inside this module because
it synchronizes to whatever data rate it sees
from the host terminal—even nonstandard
speeds. It does this by checking the received
intervals of each character, filtering out and
rejecting the characters that do not match what
it is looking for, which happens to be an “enter”
character (technically, the carriage return,
0x0D). If the relative sizes of the intervals
within the received candidate character match
those of an enter character (which are known a
priori), the module decides that the candidate
character must be an “enter” character, so
it sets its divider to the count derived from
measuring the intervals, and implements the
new baud rate automatically. If the target
system uses a programmable system clock
generator, the user can adjust system clock
frequencies under register control, and the
board’s UART still easily adjusts to the new
baud rates “on the fly.” This is excellent for
the human user, who can see a prompt after
simply pressing Enter a time or two. Now that
I think of it, wouldn’t it be a fun feature to
add an automatic TX/RX swapping function for
those times when the lines end up connected
backwards? It might save some head
scratching. But I digress.
The other part of the support environment
is the register block. For the most “easygoing”
environment, I’ve chosen to embrace the use
of internal tristate gates. Some have preached
against the use of internal tristates, citing
inherent difficulties in formal verification
methods, test coverage, and lack of ability to
completely avoid glitches or bus contention. The
debugging environment described here uses
them for one simple reason: they can make
life easier. With internal tristates, I can run
a single bidirectional data bus out to register
blocks, and they all get an address and respond
to commands quite well. They’re easily scalable
in number. When you think about it, without the
tristate bus, each new block of registers would
require a separate new input on a data read
multiplexer, which can become cumbersome as
it doesn’t change its number of ports quite so
easily as this tristate bus. Most systems need
several registers to control a given function,
so why not group them together? I put them
into sets of eight. If I want another set of eight
registers, I just “plop” down another instance
of the “reg_8pack” module. (I suppose there
could have been a register six-pack, which
sounds nice, but of course, being greedy for
more registers, in the end I yielded to the fact
that eight is a power of two.) The register block
gets three address lines, the data bus, read/
write line and a decoded “register block select”
line. From continual use and tweaking, many
features have been added to the basic register
block. For example, the current register block
is fully parameterized as to data bus width,
individual register widths (1 bit minimum),
default contents of the registers at reset, and
whether each register is R/W or read only.
There is even a provision for setting or clearing
the register bits under control of the logic within
the fabric of the FPGA. This can come in quite
handy when single-stepping a microcontroller
or implementing a hardware breakpoint.
BREAKING THE MOLD
So, now that I’ve established some useful
building blocks for a basic development
environment, what about this fabled
microcontroller design I’ve been dreaming
of? I’ll describe something I figured out while
implementing the “risc16f84” instruction
execution engine. I’m giving it that funny name
this time to highlight the fact it’s not a fully
featured PIC16F84 microcontroller. Its design
has been modified so that it’s missing some
things which are in the standard PIC16F84
RS232_syscon Syntax
All parameters are in hexadecimal.
Command Parameter 1 Parameter 2 Parameter 3 Comments
r aaaa qq Read starting from address aaaa,
quantity qq items
w aaaa dd qq Write starting at address aaaa,
data dd, quantity qq times
I Initialize, issues a reset pulse
TABLE 1
The unit is parameterized, so that
the width of the data bus determines
the width of the dd field. Likewise,
the address bus can be scaled to any
width. Even the quantity field can be
enlarged if desired. Output formatting
for reads is automatic.
ABOUT THE AUTHOR
John Clayton (morianton@gmail.com) holds a BSEE from Brigham Young
University and an MSEE degree from The University of Texas, Austin. After
working for 12 years as a DSP programmer and board designer, he is nowa principal design engineer at Orbital Sciences Corporation in Chandler, AZ.
mailto:morianton@gmail.com
circuitcellar.com 29
FEATU
RES
microcontroller, and it’s got some extra growth
as well. When working to approximate the
performance of an existing processor design,
you can choose which level of compatibility is
preserved.
One, choose a design that is completely bit-
accurate and cycle-accurate in every way. It’s
a lot of work, and less fun in my opinion.
Two, choose a design that’s the same as the
first, but throw out JTAG debugging. After all,
you can load code in different ways.
Three, choose a design similar to the first
two, but also throw out cycle accuracy. You
really just want it to function correctly. After
all, what are a few cycles between friends?
Four, choose a design that’s instruction set-
compatible, but not code-library-compatible.
In other words, eliminate the package-
constrained ports and begin to set up I/O for
the microcontroller the way you really want it.
After all, it’s inside an FPGA now so you needn’t
be limited to ports A, B, and C. Add a few
new ports into the memory map. Obviously,
this choice may require custom SW coding or
modifying existing code libraries somewhat.
Five, you have control of the CPU instruction
superset. Consider adding new instructions.
And six, add tightly coupled hardware
accelerators to take workload off of the
processor. After all, you can completely halt
and restart the processor on a cycle-by-cycle
basis if desired.
This list should inspire some creative ideas
and help you “think outside the box.” As you’ll
see, I chose to work at level four from the
aforementioned list. Also, you can pipeline the
design, or not, to whatever level you choose.
DEBUGGING ENVIRONMENT
Initially, I was stumped when my UART
wasn’t responding properly. So, I borrowed a
logic analyzer and saw what was happening.
As luck would have it, the problem wasn’t
immediately obvious. So, I recompiled the
code, this time adding a “debug port,” which
would show the shift register contents and
finite state machine state. This quickly led to
the “ah-ha” moment, and the problems were
fixed in the code.
Hopefully, with the building block provided
in this article, you will not be constrained to
work at such a low level as this. But I can’t
guarantee it, and you may need a logic
analyzer, or even (gasp) a simulation or two.
Once the design environment is working,
many problems can be attacked by looking at
register contents and reasoning about what the
unit under test/development is actually doing.
I was able to develop several different cores
by using the rs232_syscon core, and these are
all posted at www.opencores.org. Some of the
older projects will have earlier versions of the
support environment which don’t include some
of the features now present.
LCD PANEL
One of the fun dreams I realized with my
completed RISC PIC16F84 core was to hook it
up to an old VGA resolution LCD flat panel from
a laptop. I purchased a broken laptop on the
Internet that would only put up error codes on
the screen. This was what I wanted because
I knew I could use the FPGA to scope out the
signals present at the LCD interface. I made
sure it was an older, parallel direct drive type
of display, not one of the newer high-speed
serial LVDS types—although now that I think of
it, some FPGAs will support LVDS. But there I
go digressing again. My FPGA breakout board
did not contain external RAM. Rather than add
some, I decided to use the internal block RAMs
as a rudimentary display buffer. Because of the
limited amount of memory, I ended up with
“fat” 5 × 5 pixel color blocks in a 128 × 96
array, supporting eight colors.
I was able to write a colored-rectangle
“screen saver” program for the RISC PIC16F84
processor in C and load it via the rs232_syscon
module. Then I began speed-testing the
processor core. I enjoyed watching the screen
updates vary in speed as I adjusted the clock,
all the while keeping an eye on my interrupt-
serviced LED display which would change at a
constant rate because I had a fixed-frequency
interrupt request generator set up.
A fun variation on the full-size LCD panel
project is to grab an old cell phone and use
the FPGA to explore the interface to its little
display. Sometimes cell phone displays can be
purchased with datasheets as well.
PHOTO 2
a—This is the FPGA breakout board.
There is a ribbon cable connection to
the WIZnet board. The USB is only for
power. The interface to rs232_syscon
is via a nine-pin D-shell connector.
b—This view from the back shows
the Xilinx FPGA configuration PROM
and an on-board parallel cable
implementation.
a) b)
http://www.opencores.org
CIRCUIT CELLAR • JUNE 2017 #32330
FE
AT
U
RE
S
WILL ANY BOARD DO?
The FPGA board used for the coding
described in this article was home-made, and
the design files for that board are provided
freely to anyone who wishes to use or modify
it. One day I heard my spouse very clearly
utter the nonsense word “Pondooker” and I
thought it was a cute name for the board,
plus it fit into a neat five-letter, consonants-
only naming scheme: PNDKR. As I mentioned
earlier, PNDKR is really a simple board—more
of an “FPGA breakout board,” than anything
else. Other than RS-232-level translators, the
board just has a bunch of I/O headers. So I
would say that any FPGA board with a suitable
number of available I/O pins can work. One can
even go onto an online auction and purchase
an FPGA board pulled from some product. A
board schematic is not always required. As
long as you can configure the FPGA device,
provide it power, reset and clock, and obtain
access to an appropriate number of I/O pins,
those are the main requirements.
One factor which militates in favor of
finding a commercially produced board
instead of making one is the growing number
of FPGAs that are housed in fine-pitch BGA
packages. These can be difficult to work with
by hand. Unless the BGA balls are brought out
to headers or vias, the FPGA cannot easily be
“probed” on an oscilloscope or logic analyzer.
Nevertheless, one company, SchmartBoard,
provides a 400-pin board that purportedly
allows hand soldering at a 1.0-mm pitch for
those who wish to try their hand.
AUDIO OVER ETHERNET
During the 2007 WIZnet iEthernet
Design Contest, I was tantalized by the
possibility of interfacing an FPGA board with
WIZnet’s WIZ810MJ board for easy Ethernet
connectivity. I found that the embedded RISC
PIC16F84 microcontroller interfaced with the
WIZnet IC quite easily. The connections were
provided by an IDC cable (see Photo 2). You
can review my flexible audio transmission over
Ethernet (FATE) project at www.circuitcellar.
com/Wiznet/winners/001103.html. The design
sets up a simple dedicated wired Ethernet
network. You can then use the network to
coordinate the distribution of high-quality
audio signals throughout a building and the
area around it.
AFFORDABLE FUN
I currently write VHDL code for various
aerospace-related FPGA applications. As
you can imagine, the test requirements
for these applications are rigorous. If you
will pardon the pun, the exclusive use of
hardware testing in lieu of simulation for
aerospace circuit development and debug
“will not fly.” Therefore, I was pleased to
embark on a course of writing test benches
and using simulations to create and debug
new designs. This effort has resulted in
the realization that within a test bench, a
simulation can support a system controller
that generates the same bus cycles as the
hardware-based “rs232_syscon” module—
effectively using text input and output files
to deliver commands to the system under
test—and record the responses from the
system. This approach has the advantage
that a particular set of “syscon” commands
can be used (with very little modification)
during both the simulation and hardware
checkout phases of design and test.I have not gone to the trouble to make the
output identical between the two modules,
but it could be done easily. The input is mostly
identical. The only modification is the addition
of a simulation delay value per command line
for sim_syscon. The VHDL source code for this
module and example I/O text files have been
included with the other (Verilog) source files
posted on the Circuit Cellar FTP site. A recent
translation of rs232_syscon into VHDL is now
available. If anyone translates “sim_syscon”
into Verilog, I’d be pleased to receive a copy.
Also note that in sim_syscon the “w”
command (write) has been renamed as
“f” (fill) so that the write command can be
revamped to handle multiple data items on a
single command line. This should be a useful
modification if you want to use the interface
for loading processor code or large volumes
of data to the target system. The number of
command lines needed can be reduced by
more than an order of magnitude.
While it is difficult for an FPGA to compete
directly with ASICs on fundamental clock
speed, power per MIPS, analog capability, or
low cost in volume of millions of units, I like to
think they get closer than anything else can at
fairly low cost. And besides, I probably won’t
be selling millions of units any time soon. But
I should be having fun along the way?

circuitcellar.com/ccmaterials
PROJECT FILES
To download the code, go to
ftp://ftp.circuitcellar.com/
pub/Circuit_Cellar/2010/235.
RESOURCE
PNDKR User’s manual and files, www.
opencores.org.
SOURCES
PIC16F84 Microcontroller
Microchip Technology, Inc. | www.microchip.
com
XC2S200E Spartan-IIE FPGA
Xilinx, Inc. | www.xilinx.com
http://www.xilinx.com
www.circuitcellar.com/Wiznet/winners/001103.html
www.circuitcellar.com/ccmaterials
ftp://ftp.circuitcellar.com/pub/Circuit_Cellar/2010/235
www.opencores.org
www.microchip.com
such as this book,
designing a microprocessor
 can be easy.
Okay, maybe not easy, but certainly
less complicated. Monte Dalrymple
has taken his years of experience
designing embedded architecture
and microprocessors and compiled
his knowledge into one comprehensive
guide to processor design in the
real world.
cc-webshop.com
Microprocessor Design Using
Verilog HDL will provide you
with information about:
• Verilog HDL Review
• Verilog Coding Style
• Design Work
• Microarchitecture
• Writing in Verilog
• Debugging, Verification,
and Testing
• Post Simulation and more!
Verilog HDL
With the right tools
Monte demonstrates
how Verilog hardware
description language
(HDL) enables you to
depict, simulate, and
synthesize an electronic
design so you
can reduce your workload
and increase productivity.
www.cc-webshop.com
CIRCUIT CELLAR • JUNE 2017 #32332
CO
M
M
U
NI
TY
Creativity Lives Here
An Interview with Jean Noel Lefebvre
Jean Noel Lefebvre is an electronics engineer with a strong interest in how
people interact with the electronic systems.
A true outside-the-box thinker, started his
company, Ootsidebox (www.ootsidebox.fr),
right in the middle of the YouFactory fab lab
in Lyon, France. He knows where creativity
lives and is willing to show it to you. Meet
Jean Noel Lefebvre.
HETTINGA: Why do you have your office in
the middle of the fab lab?
LEFEBVRE: The fab lab here is a wonderful
place where people can come to do some
3-D printing, laser cutting, or to work with
electronics. But perhaps more importantly, it
is a place where you can meet other people,
where you can learn new skills and find new
ideas and inspiration.
HETTINGA: That is important for you—
the interaction between technology and
others?
LEFEBVRE: Yes, that has always been part
of my projects. My first invention was the
Ootside box. It was a touch application and it
allowed you to control a computer or a system
just by pointing or with gestures. We tried
raising enough funds on Indigogo to continue
developing it, but unfortunately, we did not
reach our targets. After that, I decided to
name my company after this project. Through
this project, I also discovered the Arduino
ecosystem and the enormously inspiring
world of makers and fab labs. I always was
interested in electronics, but when you are
very young, you have no idea what you are
doing and all my radios and sound equipment
failed. That is what I learn here—how to help
people, sometimes young people, understand
how electronics works.
HETTINGA: And what do they need to learn?
LEFEBVRE: Good soldering! If you learn
good soldering, you are already halfway to a
successful project. I sometimes do soldering
classes in schools. I bring some easy soldering
projects and some equipment, and it is very
rewarding to see how the kids are able to
Jean Noel Lefebvre (Founder, Ootsidebox)
With the proliferation of affordable 'Net-connected technologies during the last decade, the nontechnical
members of society have come to realize that electrical engineering is an exceedingly creative endeavor.
Outside-the-box innovators like Jean Noel Lefebvre are literally reinventing how we interact with the world
around us.
By Wisse Hettinga
Video: Interview with
Jean Noel Lefebvre
(https://youtu.be/iTD02dvU2x4)
http://www.ootsidebox.fr
https://youtu.be/iTD02dvU2x4
circuitcellar.com 33
CO
M
M
U
NITY
make their first electronic project.
HETTINGA: You are a big fan of Arduino.
LEFEBVRE: Indeed. The Arduino platform
and ecosystem is important because of its
low threshold to the world of electronics.
Arduino is even so important and valuable
that I decided to make a real gold version, the
Golduino. I have it here, and it is still work in
progress, but for people who want to have
something special and valuable, it will be a
great thing to have or to give to others.
HETTINGA: Again, I see you have a special
take on electronics. And again, this refers
to a special interaction between people
and electronics.
LEFEBVRE: I feel that is very important.
The world of technology can make people
alone and isolated with very little room for
emotions. Take the IoT developments as an
example. You can see it as a world of sensors,
actuators, and huge amounts of data. You can
easily get lost. To find a response to that, I
am doing a special project called "Color the
World." It will be a Wi-Fi-connected lamp that
will take the color of everything you hold in
front of it. In the back, there will be a world
map where you can "share" you color with
others and color the world. On Earth Day you
can all decide to color the world green, make
your part of the world yellow if the sun shines,
or blue if the world is "blue."
HETTINGA: And you found a way to keep
playing your old EP records?
LEFEBVRE: Ha, yes. If you are like me, you
will still have your old EP vinyl records, but
no easy way to play them anymore. With
my Floating Disc Player, you will be able to
use the cover of the EP to play your favorite
music again. Inside the EP cover, there is an
RFID tag, and the moment you insert the EP
The Airbar interface provides
infrared touch anywhere
Playing old tunes with the Floating
Disc Player
CIRCUIT CELLAR • JUNE 2017 #32334
CO
M
M
U
NI
TY
in the player, it will recognize the song in
the playlist and start the music. It is a great
player for home parties!
HETTINGA: What more are you working on?
LEFEBVRE: Again, it is interaction, I am
afraid. I am making an interface for the
Airbar. The Airbar is an infrared sensor bar
that originally was developed to turn your
laptop screen into a touch screen. With my
interface, it will be possible to turn everything
like desks, whiteboards, displays, and
windows into interactive areas. You can draw
a piano keyboard on a piece of paper, launch
the application, and you can start playing
by just touching the paper. The resolution
is good enough to recognize your writing on
plain paper, turn that into a digital pattern,and display that in an application.
HETTINGA: This will all be available for
others?
LEFEBVRE: Yes, it will be available on my
website www.ootsidebox.fr. It will be all open
source, so everyone who is interested can
continue developing the product.
HETTINGA: You know where creativity
lives?
LEFEBVRE: Yes, that’s easy. It lives where
open-minded people come together and want
to share their ideas with others. That is why
fab labs, tech shops, and makerspaces are
important—open places where people can
walk in, have a coffee and a chat, and go away
with new ideas.
Color the IoT world
http://www.ootsidebox.fr
circuitcellar.com 35
EDITORS' PICKS
CO
M
M
U
NITY
Short-Range IR Communications System
Progressive Reflective Transmission Solution
By Robert N. Capper, Jr. (Circuit Cellar 179, 2005)
Robert’s PIC-based IR transmission system is perfect for
short-range communication. It’s a reflective system, so you
can place the various components wherever you’d like.
“With IR technology, addressing is implicit. If it’s in the
local space, it’s part of the system. If it’s in the next room,
it doesn’t (for all intents and purposes) exist. The reduced
complexity of transmission (compared to
spread spectrum) can enable battery life
expectancy that you can measure in years.
But where’s the complexity? The penalty is
in the receiver.
My remote wireless IR door switch
system uses non-line-of-sight diffuse
Reflective mode of transmission. It
generally operates without special
consideration for the placement of the
components as long as they can see into
a common reflective space. The system, which also works in
a direct line-of-sight configuration, can achieve distances of
better than 70′. This places constraints on the receiver, which,
for a variety of reasons, must be powered by the AC mains.
So, the trade-off is a simple transmitting device that has a
long battery life but a moderately complex receiver that must
be line powered …
When working on an IR signaling application, you must
address three critical topics: the signal-to-noise ratio, the
signal-to-noise ratio, and the signal-to-noise ratio. If you solve
this problem at the outset, you’ll have done most of the hard
conceptual work. Optical output power is the most important
part of this solution. This is, of course, a solution with an
easy answer and hard limits. Your first objective should be
to get as much free optical power as possible. Well, OK, it
isn’t really free, but picking the most
efficient IR LED for the application will
go a long way toward easing subsequent
demands on the battery. Unfortunately,
I’ve found that choosing the optimum
IR LED isn’t always simple. Datasheets
from different manufactures don’t always
list specifications in ways that make
comparisons easy. But beyond that, even
comparing the devices available from one
manufacturer doesn’t result in expected
performance differences.
A number of issues may contradict simple intuition. Of
course, total power output is a prime consideration, but you
may not be able to read that directly, given the manufacturer’s
specifications. Even knowing this, there’s no direct correlation
between the total output power and performance in this
application.”
These articles and others on topics relating to Communications are available
at www.cc-webshop.com.
Embedded System Communication
A Control Platform for Ethernet-Enabled Systems
By Francis Fernandes, Rajendra Gad, Vinaya Gad, Shane Lobo, Gourish Naik, and Jivan Parab (Circuit Cellar 255, 2011)
Many of today’s industrial and consumer electronic
applications have hefty data transmission needs and
requirements. This means engineers must incorporate
efficient embedded technologies that can communicate
effectively with each other. You can customize this SoC control
platform for any Ethernet-enabled
design on your workbench.
“This article presents a system-
on-chip (SoC) developed using an
Altera Nios II softcore processor, a
general embedded system platform
for Ethernet-enabled appliance
control. The embedded system is
implemented on Altera’s Cyclone-
II FPGA. The designed platform
is flexible and versatile and can
be customized for any Ethernet-
enabled appliance or smart
appliance. The client-side frontend
interface is .NET-based for a rich
and user-friendly design.
The .NET framework is used by the remote client to connect
to the server which uses a Nios II processor. The platform can
also be used to implement TCP/IP control for complex control
systems. The design uses the lightweight Internet protocol
(lwIP) stacks module of Micriμm’s
μC/OS real-time kernel as a design
handshake over the session layer of
the OSI model.
The nearby figure represents the
client-server system configuration
over an Ethernet network. The
client has a .NET frontend interface
for user-friendly purposes and
the server is running socket
programming at the backend using
an lwIP TCP/IP stack over the Nios
II softcore processor on a Cyclone-
II FPGA. LwIP is a lightweight
implementation of the TCP/IP
protocol suite.”
Communications
http://www.cc-webshop.com
CIRCUIT CELLAR • JUNE 2017 #32336
EDITORS' PICKS
CO
M
M
U
NI
TY
Communications
Microprocessor Communications
By Stuart Ball (Circuit Cellar 102–103, 1999)
Communication is tricky when you have several processors
involved. In this two-part series, Stuart looks at ways to get
the messages between processors on a single backplane. He
writes:
“Although most embedded applications can be handled
with a single processor, every now and then, you find a job
requiring a system with two or more processors. Nearly
every multiprocessor design needs a way for the processors
to communicate. In this series, I look at the different methods
for communicating between processors and the various
tradeoffs involved.
To start off, I’ll look at useful approaches when two
processors share the same PC board or backplane. Let’s say
the processor communicates with a higher-level system, like
a PC, and distributes commands to a lower-level processor
that controls a DC motor.
CPU 1 talks to the host system, and CPU 2 controls a DC
motor, under the control of CPU 1. CPU 2 senses the motor
position via a shaft encoder and gets other sensor inputs
as well. In a typical real-world scenario, you might find this
arrangement if CPU 1 needs to execute slow, complex tasks
in response to the host, and CPU 2 has to execute fast, simple
tasks to control the motor speed or position. You may find
CPU 1 controlling multiple processors like CPU 2.
Clearly, CPU 1 must communicate with CPU 2 to get
this job done. This requires commands like turn motor on,
turn motor off, set motor speed to x, and start motor when
sensor y goes active. The nearby figure shows one method of
communicating between processors. The circuit is an 8-bit
register written by CPU 1 and read by CPU 2. The register is
a 74xx374 (xx = LS, HC, ACT, etc.), but this scheme can be
implemented in programmable logic or with any register that
has tristate outputs.
The D inputs to the register connect to the data bus of CPU
1 (or to the lower 8 bits if CPU 1 is a 16- or 32-bit processor).
The clock input (pin 11) connects to a write strobe from CPU
1. The write strobe is the same type you’d use to clock data
into any register or a peripheral IC, and it goes low when CPU
1 writes to the specific address where the communication
register is located.
The register’s Q outputs connect to CPU 2’s data bus.
When CPU 2 wants to read the register, it generates a low-
going read strobe (a decoded address strobe) at the register’s
Output Enable (pin 1) This strobe enables the tristate outputs,
so CPU 2 to read the register data.”
Flexible USB-CAN Bridge
By Craig Beiferman (Circuit Cellar 157, 2003)
When Craig decided that he needed a cost-effective,
efficient way to control several microcontroller circuits from
one computer, he used a PIC microto design a USB-CAN
distributed motion controller. He writes:
“Do you want the capability to control numerous
microcontroller circuits from your computer? With this handy
project, now you ‘CAN.’ In conjunction
with fellow designer Dale Herman, I built
an inexpensive circuit that allows a PC’s
universal serial bus (USB) to interface to
a controller area network (CAN) bus.
When it comes to communication
between multiple microcontrollers, I
cannot think of a nicer interface than the
CAN bus. You may be asking yourself,
why? What’s wrong with RS-232, RS-485,
SPI, or I2C? The simple reason is that
if you really need full processor power,
nothing will slow you down like constant
interrupts for every byte received, not
to mention the fact that the additional
software overhead of packet decoding and
checksum checking, ACK NAK schemes,
and so on eat processor bandwidth. The
CAN link-layer hardware handles many of
these issues in the background.
OK, so what’s the best choice for
communicating with a PC? Unfortunately,
the PC does not come standard with a
CAN bus, and some manufacturers are starting to phase out
parallel and RS-232 ports (particularly on laptops). However,
on the PC side, USB has been growing in popularity, and for
good reason: its simple plug-and-play and high speed make
for a great bus.
At first, I was worried about how long it would take me
to develop drivers for a USB interface. I’m certainly not a
USB expert. That’s when I stumbled
across Future Technology Devices
International’s (FTDI) FT245BM chip,
which is a cost-effective device for
quickly interfacing a microcontroller to
the USB bus with little knowledge of the
USB specification. The FT245BM allows
a transfer speed of up to 1 MBps, and
its 384-byte transmit and 128-byte
receive FIFO buffers allow for high data
throughput. A parallel microcontroller
interface allows for the quick transfer
of data. But what about the drivers? No
problem. To my relief, I found out that
FTDI supplies free Windows drivers
and example schematics. With my fear
subsided, I pressed on looking for an
appropriate microcontroller. I chose the
40-MHz PIC18F258 microcontroller from
Microchip because of its built-in CAN
2.0B controller, which can communicate
at up to 1 Mbps.”
circuitcellar.com 37
EDITORS' PICKS
CO
M
M
U
NITY
Mic Check
A Communication System for Cyclists
By Ed Nisley (Circuit Cellar 133, 2001)
It’s all about communication. Back in 2001 before cell
phones were ubiquitous, Ed designed a way to remain in
contact with fellow bicyclists while on the move. In this article,
he explains how he uses an electret microphone hooked into
his helmet to chat with cycling companions. He writes:
“I thought I should review the most basic input device
in common use: the microphone. In this day and age, this
means an electret microphone. Along the way, I’ll look at
some issues in practical applications. Rest assured, you will
not find the ultimate secret of high-fidelity reproduction
revealed in this article …
The circuit connects an electret mic to my ICOM Z1A
handheld amateur radio. It also incorporates the earbud
audio output and push-to-talk control functions, so the circuit
(see the nearby figure) has a few more bits and pieces than
you might expect. In addition, it must work in an RF-rich
environment because the Z1A transmits 5 W in the 2-m or
70-cm band through a nearby antenna when you’re talking
through the mic!
The specs for the Z1A’s external mic signal assume a
dynamic microphone, which produces a higher
audio output at a lower impedance than an
electret element. Although the mic jack includes
a separate 3.3-VDC supply, you can’t simply wire
up an electret mic and expect to get decent
results. An electret’s audio output is too low and
its impedance is too high. I’ve tried it; it doesn’t
work.
Unfortunately, you can’t simply wire up an op-
amp and get decent results either, because RF on
the mic input overwhelms the few millivolts of
audio. At best, the audio sounds distorted and, at
worst, you don’t hear anything at all.
The circuit (see nearby figure) uses ferrite
beads on the mic and power leads, as well as
the amplified audio output to the Z1A. These
beads, often referred to as ‘black magic,’ act as
a relatively high resistance at RF frequencies and
form an effective filter when used outboard of a
low RF impedance.”
These articles and others on topics relating to Communications are available
at www.cc-webshop.com.
Selecting the Best CAN Controller
By Olaf Pfeiffer (Circuit Cellar 143, 2002)
Selecting the right CAN controller for an application can
be a daunting task. Fortunately, Olaf has some great advice
for minimizing cost and maximizing performance. He writes:
“Traditionally, CAN was used in automotive applications.
Today, CAN is one of the best choices for embedded networking
applications that need to communicate between several
embedded 8-bit and 16-bit microcontrollers. The biggest
current growth sectors are embedded machine control
applications such as home appliances, industrial machines,
and other machinery containing multiple microcontrollers
that need to communicate with each other.
A big advantage of CAN compared to other network
solutions is the price/performance ratio. When it comes to
price, CAN is the most affordable network, next to a regular
serial channel. It costs about $3 to CAN-enable an existing
microcontroller design. When you break it down, replacing an
8-bit or 16-bit microcontroller with one that features a CAN
interface costs about $1. An additional $1 is needed for the
transceiver (line driver for twisted pair) and another $1 for
connectors and additional PCB area.
Replacing a microcontroller with one that features a
CAN interface seems easy, because about 20 different
semiconductor manufacturers produce microcontrollers with
one or multiple on-chip CAN interfaces. However, there are
major dissimilarities in the CAN controllers available that can
make a big difference when it comes to performance. The
difference can be that with one device, the communication
overhead uses all of the available MCU performance, whereas
on another device the same communication task can be
performed with a minimum of MCU execution time.
This article will point out some of the major differences
between CAN controllers available and explain how the
differences can affect your application.”
http://www.cc-webshop.com
SP
EC
IA
L
SE
CT
IO
N
-
 3
-D
 P
RI
NT
IN
G
CIRCUIT CELLAR • JUNE 2017 #32338
A Dynamic Overview of Key 3-D
Printing Features
Commercialized 3-D printing technology has come a long way during the last 30 years. We've
witnessed significant advances in printing speed, printing resolution, material quality, printing
software, and more. With easy access to 3-D printers, it's an exciting time for everyone interested
in rapid prototyping and product modeling.
By Ashley Mellen & Alexandrea Mellen
Three-dimensional (3-D) printing technologies made their
commercialized debut with 3D Systems
stereolithography in 1987. Though the
technology faced technical, chemical,
and financial complications, it launched
years of additive manufacturing
research into multiple industries. This
led to what is expected to be $27 billion
in 3-D printing spending by 2019. As
the industry has developed, so have the
printers. 3-D printing companies have
advanced and diverged significantly to
feature new processes and cutting-edge
hardware and software features.
INDUSTRIAL VS CONSUMER
In the 1980s, 3-D printing research was
more commonly and technically known
as additive manufacturing research.
Additive manufacturing encompassed all
uses of processes designed to create 3-D
parts by layering material. Over the last
30 years, the terminology has matured.
While the same core concept applies, a
distinction has been made to separate
industrial and hobbyist use. Additive
manufacturingis associated with scaled,
industrial applications, and 3-D printing
is associated with rapid prototyping and
consumer use.
TYPES
Six fundamental 3-D printing
processes dominate the modern
market: fused deposition modeling,
stereolithography, material jetting,
binder jetting, selective laser sintering,
and directed energy deposition. Let's
review each one.
Fused deposition modeling, used by
Stratasys, is the most common hobbyist
3-D printing technology. A thermoplastic
is forced through a heated extruder
head, where it becomes molten and is
fed onto the product in a single, two-
dimensional layer. The head moves two-
dimensionally during each build of a
single layer, and it then moves vertically
between layers to make space for the
next layer.
Stereolithography, a process used by
Formlabs, utilizes photo-polymerization.
An ultraviolet laser is focused onto a
vat of photopolymer resin, where it
draws each layer of the part. The resin
Ashley Mellen is an organic chemist employed as a production manager at the Mellen Company, Inc. She
earned her Master’s degree in chemistry at Boston University with a focus on organic polymer chemistry.
Her Master’s thesis was the study of eco-friendly photosensitive resins for 3-D printing under Dr. Mark
Grinstaff. Aside from work for her degree, Ashley has worked with several extrusion, stereolithography, and
binder jetting printers over the past six years.
Alexandrea Mellen is a computer engineer specializing in mobile app development and information security.
She has presented her research at Black Hat, the largest information security conference in the world, and
MIT. Alexandrea has spent a great deal of time mentoring startups in the Boston community as a partner
at the Dorm Room Fund and as a mentor for multiple universities, including Hult Business School. She also
worked as an engineering consultant for startups around Boston before founding her own startup, Terrapin.
She has over five years of experience in 3-D printing working for multiple companies.
circuitcellar.com 39
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
solidifies where the laser is drawn due to its
photosensitive nature, and then the process
is repeated with a new layer until the part is
completed.
Material jetting, also used by Stratasys,
sprays liquid photopolymer in layers, which
are subsequently cured with ultraviolet light.
Each layer is added and cured, then the
process repeats until the part is formed.
Binder jetting, used by ExOne, shoots
liquid binding material across a powder bed
in layers. The powder and binding material
combine, then another layer of powder is
spread across the bed and the process is
repeated until the part is complete.
In selective laser sintering, a high-
powered laser is used to fuse plastic, metal,
ceramic, or glass powders layer by layer to
form an object. 3D Systems sells SLS printers,
among others.
During directed energy deposition,
electron beams are focused on a metal
powder to fuse the metal together in layers
until the part is complete. This is used in large
scale applications such as the repair of fighter
jet wings.
SOFTWARE
3-D printing software differs drastically
based on a familiar debate: the power of
open source. Open-source software can be
incredibly helpful for users who wish to own
and operate different 3-D printers with the
same software, while still having a large
number of features and a reliable product.
Some open-source software, such as Cura,
makes it simple for a beginner to set up a
print on almost any 3-D printer, while also
having over 200 features for experienced
users. The main drawback of this kind of
software is that it requires either an SD card
or a USB connection from the printer to the
computer. As a solution to this problem,
companies like AstroPrint sell a software
and hardware product combination. Their
hardware, AstroBox, connects to a 3-D
printer through the normal cable connection,
but instead of connecting to the computer, it
enables the user to print wirelessly from any
web-enabled device. For tinkerers, a company
called OctoPrint supplies solely the software,
and encourages the user to set up the system
with a Raspberry Pi.
Software also exists that is specific to a
single type of printer, which, though limiting,
enables the software to work seamlessly and
have hardware-reliant features. NVBots has
developed the NVCloud, which can only be
used on an NVBots printer, but is optimized
for the printer and includes hardware-specific
features. For example, the user can queue
multiple print jobs at a time because of the
printers automated part removal hardware.
This software feature would be useless
without the company-specific hardware.
SPEED & RESOLUTION
Printing speed and resolution are uniquely
linked qualities in 3-D printers. Often, an
increase in speed results in a decrease in
resolution, and vice versa. Speed of the print
can be improved by printing thicker layers,
but layer thickness is the main quality that
determines resolution. Frequently, a trade-
off is made depending on the use case of the
printer. For example, if the printers main use
is for first draft prints, the user may value
speed over precise, high resolution parts.
Equally, if the printers main use is for final
drafts with a complicated series of parts, the
user may value precision over speed.
Many printers allow the user to vary the
resolution of the print through the printer
software and hardware. The Taz6 by Lulzbot
has a maximum speed of 7.9" per second,
but can vary resolution from 0.002" to 0.2"
through the Cura software. The Ultimaker 2+
is actually capable of ranging the speed from
1.18" to 11.8" per second, with a resolution
range of 0.002" to 0.023", because of their
unique hardware. Swappable print nozzles
enable the printer to adjust the resolution of
the print so drastically.
Another simpler factor that affect the print
speed is the design of the part. If a part has
a hollow center or thin interior supports, it
will take much less time than a solid print.
Additionally, parts that are shorter and wider
CIRCUIT CELLAR • JUNE 2017 #32340
SP
EC
IA
L
SE
CT
IO
N
-
 3
-D
 P
RI
NT
IN
G
typically print faster than taller and thinner
parts due to a combination of print head
acceleration over time and decreased layers.
TINKERING
One of the simple pleasures of 3-D printing
is how it enables tinkerers. Open-source
hardware and user upgrades create unique,
custom 3-D printers completely characteristic
to the user.
Open-source hardware is a highly unique
feature to the 3-D printing industry, as users
can print backup parts for their machine. For
example, Lulzbot printers are largely made
up of parts that are created through 3-D
printing. Lulzbot provides the printer owner
the files needed to print their own copies of
parts so they can print backup copies in case
of failure.
Equally exciting, some 3-D printers are
designed to be taken apart and upgraded.
Users can buy separate parts to upgrade
their 3-D printer after purchase. For example,
Lulzbot sells interchangeable parts to upgrade
the printer in various ways, such as to add
a dual head for dual extrusion. On a more
delicious note, some companies sell upgrades
that can be used to 3-D print food! 3Drag’s
printer can be converted from a plastic
printer to a chocolate printer with a syringe
needle attachment.
AUTOMATIC BED LEVELING
Automatic bed leveling, while it sounds
trivial, is one of the most consequential
features a 3-D printer can have. In order
for the print to adhere to the bed properly,
it must be level and a particular distance
from the bed. If it is not, the part will not
adhere to the bed properly, and most times,
the print will fail. For SLS printers, it is
important that the bed is level so the laser
can be calibrated properly to polymerize
the appropriate amount of material.For
extrusion printers, it is critical that the
bed be at the appropriate distance, as the
moving print head can jam if the bed is too
close, or fail to stick if the bed is too far
away.
When automatic bed leveling is not
available, the user must level the bed
manually. Depending on the printer, the user
might have to calibrate it by hand, or there
may be some level of assistance provided
by the printer. For example, the Ultimaker
2+ has assisted leveling and comes with
a calibration card. The Zortrax M200 has
assisted leveling with precise instructions on
exactly how many turns are needed to level
the machine. Unfortunately, leveling the bed
manually can be a frustrating and time-
consuming process, even with assistance.
Typically, it involves turning screws at three
or more different locations around the print
bed until the bed is level.
Alternatively, some printers use a
combination of dedicated hardware and
software to automatically level the bed. This
saves the end user time and a good deal
of frustration. The Lulzbot Taz6 uses metal
tabs at the four corners of the build plate to
calibrate the bed. The print nozzle contacts
the metal tabs to complete a circuit, which
is then used to determine the distance
from the nozzle to the bed. This process is
repeated for each corner to determine and
alter the bed height until it is level. The
Prusa i3 MK2 uses a process called Mesh
Bed Leveling. This leveling system uses nine
calibration points combined with custom
software to create a model of the print bed.
It uses this model to adapt to a slanted bed
and any imperfections in the bed itself, since
even a flat print bed is never perfectly flat.
Printing speed and resolution are uniquely linked qualities in 3-D printers.
Often, an increase in speed results in a decrease in resolution, and vice versa.
Speed of the print can be improved by printing thicker layers, but layer thick-
ness is the main quality that determines resolution.
circuitcellar.com 41
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
COST
3-D printers differ significantly in price
point. This variation is often due to the scale
at which they are used: consumer, prosumer,
professional, and subscription.
Consumer printers, such as the Prusa i3
MK2 or Maker Select, are less than $1,000
and are reliable, but do not necessarily have
the quality required for product resale. They
do not typically include product support, but
instead rely solely on community resources.
Prosumer printers such as the Taz6 or
Form2 have a broader price range, from
$1,000 to approximately $5,000. Though they
are less financially accessible than consumer
3-D printers, they are generally more reliable
and produce higher quality prints. They also
often have more features, yet still retain
many of the community resources available
to the consumer printers.
Professional 3-D printers, such as the
uPrint SE Pro, are any printers that cost a
flat rate of more than $5,000. These printers
are usually custom-made for specific types of
additive manufacturing, and have larger print
beds and more reliable printing; though they
are rarely open source.
Subscription-based printers typically
offer services and vary greatly in pricing.
Subscription services include warrantees,
printer support, or even cloud services. For
instance, NVBots offers a yearly subscription
service for access to the printer, customer
service, a library of 3-D models, and a cloud
resource to monitor and print remotely.
ADVANCES TO COME
Commercialized 3-D printing technologies
have come a long way since the 1980s. The
field is constantly improving, and different
companies are releasing new, exciting features
regularly. Whether in a large or a small system,
the technology that goes into 3-D printers is
advancing quickly, enabling the production of
prototypes and models with greater accuracy
and repeatability than ever before.
Innovative Holding Solutions
cc-webshop.com
Circuit Cellar 2016
Digital Archive
With this digital subscription, you have access
to all 12 issues of Circuit Cellar 2016 from any
computer or tablet at anytime. Readers can
explore project ideas, bookmark pages, and
make annotations throughout each issue.
Order yours today
www.cc-webshop.com
www.panavise.com
CIRCUIT CELLAR • JUNE 2017 #32342
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
42
We've recently seen a lot of innovation in the 3-D printing industry. Numerous companies are now manufacturing
affordable desktop 3-D printers. Other companies have begun supplying handy printing-related services
(e.g., online modeling), printing components, and interesting accessories (e.g., air filtration systems for 3-D
printers). It's clear that 3-D printers are poised to become essential tools in every engineering workspace,
university electroncis lab, makerspace, and industrial design facility.
By C. J. Abate
Nicolas Roux
Founder/CEO | Zimple
www.zimple3d.com

C. J.: Tell us about your background and
technical interests.
NICOLAS: I am an embedded system
engineer, with a background in electronics
and mechanics. I fell in love with 3-D printing
four years ago, and then I started to make
some personal projects (RC cars, lights, toys).
My cofounder, Antoine, is a data scientist
student passionate by the internet.
C. J.: How did you get started with 3-D
printing? A school project? A personal
project?
NICOLAS: I started to work with 3-D printers
four years ago, with a Prusa i3. Since my
childhood, I have always loved making things.
I have tried all the construction games! After
my preparatory class, which is a two-year
intensive program preparing you to pass
the competitive examination for engineering
school, I bought my first 3-D printer in order
to restart making things, with my own ideas
and designs. Being able to design, print, and
try something I’ve got in my mind is a huge
pleasure for me. Since I’ve tried it four years
ago, I never stopped to make things!
C. J.: Your company Zimple's focus is "3-D
printing without toxic emissions." What led
you to this mission?
NICOLAS: After using a lot of different 3-D
printers, I found that all of them have some
problems regarding their use. So with Zimple,
we want to share the solutions I found to
counter the problem I’ve been facing with
my 3-D printers. The fumes released by 3-D
printers was the biggest problem for me. It
really smells bad and gives me headache.
After looking into research on the subject, I
realized that this issue was really important
and theses fumes were very harmful. So, tired
of keeping my window open with my printer
nearby, I decided to develop a solution. I
had the idea of this solution: "hoovering"
the particles directly at the nozzle, because
I found it more elegant, less expensive, and
more scalable on my different printers than
building an enclosure.
C. J.: It seems logical that the air around a
working 3-D printer isn't as clean as the air
in an empty room. But is there hard data on
the negative effects of exposure to printer-
related toxins?
NICOLAS: Many studies about the emissions
when processing thermoplastic are available
on the Internet. The results are unambiguous:
Advances in 3-D Printing and
Related Technologies
Q&As with Industry Innovators
http://www.zimple3d.com
circuitcellar.com 43
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
they are very toxic and released in huge
amounts. After talking with many people
around the 3-D printing industry and the
thermoplastic ecosystem, we realized that
this problem is known by every professional.
They are all aware of the fumes released by
the fusion of thermoplastic, and so they use
big and powerful exhausting systems when
melting plastic. Desktop 3-D printing is a
very new technology. It’s the first time that a
real manufacturing machine can be placed in
a living room, on a desktop near an engineer,
or in a schoolroom. And this is the problem:
people tend to forget that 3-D printers are real
manufacturing boxes and not computers. The
technology will reach the point where everyone
will be able to use it as we use photocopiers,
but even photocopiers have a particle filter
inside it. It’s just a question of time before all
3-D printers will have a built-in filter.
C. J.: Tell us how you came to develop
Zimpure, which is a compact air filtering
system. In terms of engineering, what
were the biggest problems associated with
designing the system?
NICOLAS: With Zimpure we wanted to develop
an efficient and compact filtering system. The
two main challenges in terms of engineering
were: First, to find a way to exhaust all the
gases and particles, without using a huge and
loud exhausting fan. Then, to use the filter that
will be able to filter all the nanoparticles and
gases released. Testing these two points isn’t
easy, because you can’t see the particles. Even
if the ABS smell disappeared when we were
turning on Zimpure, we wanted to know how
efficient it was on both issues: nanoparticles
and gases. To do so, we’ve collaborated
with a laboratory (CEA) in the Laboratory of
Climate and Environment Science department
(LSCE). They kindly provide us the measuring
instruments we need to conduct our tests.
After testing our prototype, we improved it to
reach our goal: a 99% particle filtration ratio
and more than 90% for the gases. We are now
proud of, and confident in, our product, and
we rely on it every day in our office and home.
C. J.: Give us an overview of Zimpure. Tell
us more about what it does and its benefits.
NICOLAS: So Zimpure is a very compact (160
× 120 × 124 mm) and silent (around 50 dB, a
bit less than some printers). And it's a really
efficient exhausting and filtering system. (It
filters 99% of the particles and more than
90% of the gases released while printing.) It
is also a very affordable product. We sold it
Zimpure Delta
CIRCUIT CELLAR • JUNE 2017 #32344
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
44
for $108 (€99) on Kickstarter. The final price
is $162.80 (€149). The enclosure or cover we
can buy costs between $273 and $327. That’s
not possible for many of us. That’s why we
choose to make Zimpure more affordable.
C. J.: Compatibility with the many 3-D
printers on the market could be a problem.
How are you dealing with compatibility?
NICOLAS: Our Zimpure is the same for all the
3-D printers. The only change concerns the
suction head, because printers don’t have
exactly the same extruders. That’s why the
users will print themselves their suction head,
depending on their printer. Being able to ask
our customers to print a custom part gives
our project an affordable cost. It also connects
us to our community in a very pleasant way.
We can talk about the emission issues and
compatibility design. We love it! Community is
the strength of 3-D printing. We are designing
and testing suction heads for a lot of 3-D
printers. The final user will be able to download
his own suction head on our website. He will
just have to print it and Zimpure will be ready
to clean! Many 3-D printer users are designers
or engineers, so we think they will probably
adapt or even improve our suction heads for
their specific needs. We will share some CAD
files in order to make them easier to modify.
C. J.: You exceeded your Kickstarter goal in
April 2017. What are your plans now?
NICOLAS: We are currently running our
production—a batch of 500 Zimpures. When
it is, done we will go in different fab labs and
resellers to test new suction heads on other
3-D printers and to present our product. We
will send all the Zimpure units before the end
of June 2017 for sure. Some backers will even
receive it by the end of May.
C. J.: Any new products in the pipeline?
NICOLAS: Zimpure is going to evolve this year,
and two other products are coming.
C. J.: Where do you see the 3-D printing
industry going in the next five to 10 years?
NICOLAS: 3-D printing is going to be more
and more used by everyone in society.
Personal 3-D printers will maybe take longer
to come up, but we think everyone will be able
to access them and more and more products
using the technology will appear. 3-D printing
is a disruptive technology that enables us to
mass produce custom products. It will be
used more and more for production purposes
and not only prototyping.
Jeff Moe
Founder/CEO | Aleph Objects
www.alephobjects.com

C. J.: When did you first become interested
in 3-D printing?
JEFF: I became interested in 3-D printing
when I learned about the RepRap project that
started at the University of Bath, in England,
and quickly spread into a global collaborative
movement. RepRap hardware development
worked similarly to Free Software
development, with individuals around the
world building and modifying 3-D printers
and sharing what they learned.
C. J.: What was your first 3-D printing
project?
JEFF: In 2010, I ordered an open-source
hardware ShaperCube kit from RepRap Source
out of Germany. There was an enormous
number of parts, and it was a challenge to
assemble, but it worked more or less.
C. J.: What about the most recent object you
printed for yourself (not work related)?
http://www.alephobjects.com
circuitcellar.com 45
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
JEFF: Given that I own a 3-D printer
manufacturing company, I don’t print a whole
lot of things that aren’t work related in some
way. But recently, I did design and print a
mount for a webcam at my house.
C. J.: Tell us about Aleph Objects. Why'd you
start the company in 2011?
JEFF: I founded Aleph Objects because I saw
an opportunity for open-source hardware
to be as successful and influential as Free
Software projects such as GNU/Linux and
Wikipedia. The community and momentum
that was building around 3-D printing was
unlike anything that I had seen in hardware
before. Arduino had an active community,
and it enabled the RepRap project to get off
the ground, but RepRap brought open-source
hardware to a much larger audience.
C. J.: Why open source?
JEFF: Free software, Libre Innovation, and open-
source hardware are all about respecting user
freedom. Things you buy should not spy on you,
restrict your use, or impede you from learning
how they work. By respecting the individual’s
right to understand how their 3-D printer
works, we build a collaborative community that
shares these values. In turn, that community
collaborates, sharing improvements and
modifications to their hardware, which helps us
iterate and bring innovations to market faster.
To that end, we share everything, from CAD
files to Bills of Materials to the layout of our
manufacturing floor.
C. J.: Can you tell us a bit about the main
customers for your LulzBot Mini? Are they
mostly home users or perhaps architects
and engineers?
JEFF: The LulzBot Mini was conceived as a
less expensive, easier-to-operate sibling to
the LulzBot TAZ, aimed at new users and
people with smaller budgets. But read the
reviews, and you’ll learn that the LulzBot
Mini is just an all-around great 3-D printer.
It’s fast, versatile, portable, and incredibly
reliable. So, while our target audience of
home users, teachers, and libraries has been
happy with their LulzBot Minis, we also sell
them to engineers, architects, researchers,
and manufacturing startups. In our own
LulzBot 3-D printing cluster that we use to
manufacture parts for our assembly line, over
half of the machines are LulzBot Minis.
C. J.: You announced the LulzBot TAZ
MOARstruder Tool Head at the 2017
Consumer Electronics Show (CES). What has
LulzBot TAZ
CIRCUIT CELLAR • JUNE 2017 #32346
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
been the feedback from users since then?
JEFF: We’ve heard a number of times that
it’s like having a brand new bigger printer.
It enables people to utilizethe TAZ’s whole
build volume without tying up their printer for
days. We are seeing more robust functional
printed components as well. Plus, it’s just fun
to watch that much plastic moving through
the extruder and seeing those big layers
stacking up. You feel closer to the process
because you can really see your part taking
shape.
C. J.: When developing the MOARstruder,
what was your main focus? Enabling higher
printing speed? Higher output? Object
strength?
JEFF: We called it the MOARstruder because
it enables all of those things, but speed was
the primary development driver. The TAZ 6 is
huge, but because full-volume prints can take
so long, it’s not always convenient to utilize
the whole build volume. With the MOARstruder
that equation changes dramatically. The
increased speed is a function of larger and
wider extrusion, which in turn makes the
parts printed with the MOARstruder much
stronger. The strength improvements alone
are reason enough to buy one.
C. J.: Can you tell us about any new products
in the pipeline?
JEFF: Of course. We are nearing a beta
release of Cura 2 LulzBot Edition software.
Cura 2 has a lot of new 3-D printing features,
an improved interface, and better slicing
performance. Aleph Objects is also funding
development of a new elementary/beginner
interface for Blender called “Blender 101,”
which will make the software more suitable
for those just starting in 3-D. On the
hardware front, we are working on a next-
generation 3-D printer, code-named Athena.
Athena is being developed after months of
research into state-of-the-art open-source
3-D printing technology and will feature all-
new electronics, extruders, and hot ends
developed collaboratively with partners
around the globe. We’re always looking at
ways to improve printing with our current
hardware too. Look for future upgrades to
our heated bed design, hot ends, and other
upgrades to LulzBot TAZ and Mini 3-D printers.
We share all of our hardware research and
development projects on a public server that
is updated every half hour here: devel.lulzbot.
com and software development here: code.
alephobjects.com.
C. J.: Where you do see the most opportunity
for the company's growth? The personal or
industrial 3-D printing market?
JEFF: Poor-performing, closed-source
machines that flooded the market seem to
have cooled the hype that formed around “a
3-D printer in every home.” Plus, there are
now Chinese-made printers available for just
a couple hundred dollars and we have no
intention of competing in that pricing tier.
That said, our customer split is still close to
50/50 between personal and professional use.
Cheaper machines can serve to open one’s
eyes to the potential, but don’t perform well
enough to live up to it. So, a LulzBot printer is
often someone’s second or third 3-D printer
purchase, when they’re fed up with the lack of
reliability from lower-quality machines. Our
Athena project is definitely targeted more
at the professional and industrial end of the
market as that is where we anticipate more
growth will happen over the next several
years.
C. J.: Have you seen any new and exciting
applications for 3-D printing? For instance,
are any of your customers doing surprising
things with LulzBot printers?
JEFF: Our customers are constantly surprising
us. From NASA engineers hacking a TAZ to
print high-temperature aerospace plastics
to a company printing rugged dirt bike
motorcycle parts. One customer that has
gotten viral attention recently is Hyperflesh,
circuitcellar.com 47
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
out of Denver, Colorado. They make hyper-
realistic silicone masks of celebrities and
politicians, using a LulzBot TAZ to print the
molds.
C. J.: Where do you see the 3-D printing
industry going in the next five to 10 years?
JEFF: A lot has changed in this industry since
we started up in 2011. Quality and speed
have improved, prices have come down,
material selection has grown exponentially,
and I would expect these trends to continue.
We have also seen a continual shift toward
more open development. The most popular
3-D printers in the world are or are based
on open-source designs, and free slicing
and printing software dominates. Even
traditionally secretive companies are
dabbling in less restrictive development,
like HP allowing third-party material
development for their new machines. With
collaborative development leading the way,
innovation will continue to accelerate.
C. J.: Which industry (e.g., medical,
aerospace, automotive) stands to benefit
the most from advances in 3-D printing and
why?
JEFF: While they all stand to benefit
tremendously, medical applications seem likely
to be the most disruptive. Current generation
LulzBot 3-D printers print with thermoplastics
only, so our exposure is limited to external use
medical applications. Nonetheless, there are
already amazing things being printed with
LulzBot printers in the medical field. Custom
3-D-printed prosthetics can save people
thousands of dollars over traditionally
fabricated prosthetics. 3-D-printed surgical
reference models can lead to improved surgical
outcomes. In the greater 3-D printing field,
exploration of 3-D printing implants, grafts,
drugs, and even organs is compelling.
www.cc-webshop.com
www.elprotronic.com
CIRCUIT CELLAR • JUNE 2017 #32348
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
48
3D Hubs
• Location: Amsterdam, Netherlands
• Web: www.3dhubs.com
• Business: The 3D Hubs platform connects
users with local 3-D printing services.
It checks a user’s digital design and its
matchmaking algorithms optimizes 3-D
print options. To use 3D Hubs, customers
upload a 3-D design, choose a material,
and select a 3-D printing service.
• Services: Rapid Prototyping, Additive
Manufacturing, 3-D Printing for Education
3D Slash
• Location: Paris, France
• Web: www.3dslash.net
• Business: 3D Slash's mission is to make
3-D printing accessible to everyone. It
offers a handy 3-D modeling tool. Users
create their models by "slashing a cube."
• Products: 3D Slash Modeling Tool
Airwolf 3D
• Location: Costa Mesa, CA, USA
• Web: www.airwolf3d.com
• Business: Designs highly accurate, high-
speed desktop 3-D printers for engineers,
hobbyists, and students alike.
• Products: AXIOM Printers and Apex 3D
Printing Software
Axis Prototypes
• Location: Toronto, Canada
• Web: www.axisproto.com
• Business: A 3-D printing service bureau
that creates accurate prototypes directly
from digital files and delivers them
within a few days in North America. It
also distributes the latest in 3-D SLA
printers based on digital light processing
(DLP) technology.
• Products: 3-D Printing and Prototyping
Services
Resources for Cutting-Edge 3-D
Printing & Related Products
BCN3D Technologies Sigma 3-D printer
http://www.3dhubs.com
http://www.3dslash.net
http://www.airwolf3d.com
http://www.axisproto.com
circuitcellar.com 49
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
BCN3D Technologies
• Location: Barcelona, Spain
• Web: www.bcn3dtechnologies.com
• Business: BCN3D manufactures
open-source 3-D printers. Its IDEX
(Independent Dual Extruder) system
works with multi-material, multicolor
prints and support structures.
• Products: BCN3D Sigma 3-D Printer,
BCN3D Ignis Laser Cutting Machine, Kit
BCN3DR Open-Source 3-D Printer, BCN3D
Sigma and Simplify3D Software, Sigma
Progen
BigRep
• Location: Berlin, Germany
• Web: www.bigrep.com
• Business: BigRep aims to revolutionize
3-D printing and manufacturing. Its
BigRep ONE and BigRep Studio enable
large-scale 3-D printing.
• Products: BigRep ONE 3D Printer, BigRep
Studio 3-D Printer, and Polymers for 3-D
Printing Applications
byFlow
• Location: Eindhoven, Netherlands
• Web: www.3dbyflow.com
• Business: Manufactures a foldable,
portable 3-D printer
• Product: Focus Portable 3-D Printer
colorFabb
• Location: Belfeld, Netherlands• Web: www.colorfabb.com
• Business: colorFabb develops high-
quality filaments for FDM 3-D printing.
It offers a wide range of 3-D printing
materials that are well suited for most
FDM 3-D printers.
• Products: PLA/PHA and Co-Polyester-
Based Materials for FFF/FDM 3-D Printing
Fargo 3D Printing
• Location: Fargo, ND, USA
• Web: www.fargo3dprinting.com
• Business: Fargo 3D Printing provides
3-D printer sales, service, support, and
education to businesses, educational
institutions, and individuals.
• Products/Services: 3-D Printing Parts,
3-D Printer Support
Airwolf 3D AXIOM Dual
Direct Drive Printer
http://www.bcn3dtechnologies.com
http://www.bigrep.com
http://www.3dbyflow.com
http://www.colorfabb.com
http://www.fargo3dprinting.com
CIRCUIT CELLAR • JUNE 2017 #32350
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
50
MakerBot Industries, LLC
• Location: Brooklyn, NY, USA
• Web: www.makerbot.com
• Business: MakerBot is a desktop 3-D printer
manufacturer that offers a variety of printers
and connected 3-D printing solutions.
• Products: Makerbot Replicator+,
Makerbot Replicator Mini+, Makerbot
Replicator Z18, 3D printing acces-sories
makexyz
• Location: Phoenix, AX, USA
• Web: www.makexyz.com
• Business: Offers 3-D printing on demand
by connecting 3-D printer owners with
designers.
• Proudcts/Services: 3-D Printers and
Printing Tools, 3-D Scanners, and 3-D
Print Materials
New Matter
• Location: Pasadena, CA, USA
• Web: www.newmatter.com
• Business: Manufactures desktop 3-D
printers and offers an onine marketplace
for 3-D designs.
• Products: MOD-t Desktop 3-D Printer
Pirate 3D
• Location: Palo Alto, CA, USA
• Web: www.pirate3d.com
• Business: Manufactures high-quality
desktop 3-D printers
• Products: Buccaneer+ 3-D Printer
Printrbot, Inc.
• Location: Lincoln, CA, USA
• Web: www.printrbot.com
• Business: Founded in 2011, Printrbot's
stated mission is to "make 3-D printing
more accessible worldwide." Its printers
are well suited for educators, designers,
and makers.
• Products: New Simple Pro printer,
Printrbot Simple Metal printer, Printerbot
Play printer, Printerbot Plus printer
Proto Labs
• Location: Maple Plain, MN, USA
• Web: www.protolabs.com
• Business: Manufactures prototypes and
offers on-demand part manufacturing
with facilities in five countries.
• Products/Services: 3-D Printing, CNC
Machining, Injection Molding
Rize One 3-D printer
http://www.makerbot.com
http://www.makexyz.com
http://www.newmatter.com
http://www.pirate3d.com
http://www.printrbot.com
http://www.protolabs.com
circuitcellar.com 51
SP
EC
IA
L
SE
CT
IO
N
-
3-
D
PR
IN
TI
NG
Rize, Inc.
• Location: Woburn, MA, USA
• Web: www.rize3d.com
• Business: Rize's mission is to "put an
entirely safe, affordable and industrial-
quality 3-D printer, capable of producing
injection molded-quality end-use parts,
in every engineer’s office." Its patented
Augmented Polymer Deposition (APD) 3-D
printing technology enables on-demand
manufacturing.
• Products: Rize One 3-D Printer
Robo 3D
• Location: San Diego, CA, USA
• Web: https://robo3d.com
• Business: Designs and distributes
desktop 3-D printers and 3-D printing
accessories.
• Products: Robo C3 Printer, Robo R2 Smart
Printer, R1 +Plus Printer
Sculpteo
• Location: Villejuif, France
• Web: www.sculpteo.com
• Business: Based in France with a factory
in San Francisco, Sculpteo provides online
3-D printing and laser cutting services
for on-demand production of prototypes,
individual products, and short-run
manufacturing.
• Products: On-demand Online 3-D Printing
and Laser Cutting
Shapeways
• Location: New York, NY
• Web: www.shapeways.com
• Business: Shapeways is a creative
community of makers using 3-D printing,
as well as a marketplace for consumers.
Designers can use Shapeways to
manufacture products in over 58 different
high-quality materials and finishes.
• Products/Services: 3-D Printing Services
and Online Marketplace
Simplify3D
• Location: Cincinnati, OH, USA
• Web: www.simplify3d.com
• Business: Simplify3D provides a 3-D
printing software suite for transforming
digital computer files into 3-D physical
models.
• Products: Simplify3D Software
Ultimaker
• Location: Geldermalsen, Netherlands
• Web: www.ultimaker.com
• Business: Ultimaker is a premium 3-D
printer manufacturer. The printers
are created through open-source
collaboration.
• Products: Ultimaker 3, Ultimaker 2+,
Ultimaker 2 Go, Ultimaker Original+
Voxel8
• Location: Somerville, MA, USA
• Web: www.voxel8.com
• Business: Voxel8 offers multi-material,
digital manufacturing solutions such as:
the co-deposition of conductive metal
and engineering-grade polymer matrix
for 3-D electronics; mixed-gradient
deposition of flexible/rigid morphologies
(e.g., athletic shoes); and the conformal
deposition of customized materials (e.g.,
direct-writing polyurethane patterns on
textiles or antennas on molded parts).
• Services: Product Printing and Design,
Materials Formulation, and Customized
Production Runs
http://www.rize3d.com
https://robo3d.com
http://www.sculpteo.com
http://www.shapeways.com
http://www.simplify3d.com
http://www.ultimaker.com
http://www.voxel8.com
CIRCUIT CELLAR • JUNE 2017 #32352
CO
LU
M
NS
THE CONSUMMATE ENGINEER
Automatic Control (Part 2)
Last time, George covered the basic
principles of automatic control, including
a simple closed-loop control system,
common control laws, and proportional
system shortcomings. This month, he
focuses on frequency domain analysis.
By George Novacek
In Part 1 of this series, we discussed automatic control systems in general. Let’s
step back a little now and take a quick look
under the hood of control theory. The widely
used frequency domain analysis represents
classic control theory, which is intuitive
to those of us who design analog circuits.
The same principles apply to all feedback
electronic circuits: oscillators, amplifiers of
all kinds, phase-locked loops, voltage and
current regulators, and so on. This series,
however, focuses on automatic systems
containing mechanical components.
It begins with Laplace transform:
F(s) = f(t)e dtst
0
−∞∫
The function f(t) is a function of time. s is
the Laplace operator. F(s) is the transformed
function. Typical Laplace transfer functions
are 1/s for integration. s for differentiation.
e—sT is for delay and so forth. Let’s say,
for example, that an input signal into an
integrator vi(t) generates output vo(t). Using
the Laplace transformation, we can write:
V (s) = V (s)
so
i
The Laplace operator s is defined:
s + j≡ s w
This means that s is a complex variable. As
we know, j is the imaginary variable defined
as √–1. In electrical engineering, we prefer j
instead of i common in mathematics because
i often designates immediate current. Omega
w is the sign for circular frequency, which
equals to 2πf. Because control systems’
analyses investigate steady-state sinusoidal
signals, s is zero. Consequently, we can write:
s = j2 fπ
It is obvious that for a DC signal where f is
0, the resulting s is 0. Every circuit designer
knows that the gain of a differentiator or a
high-pass filter at DC is zero. An integrator,
on the other hand, would be approaching
infinity at f > 0 limited by saturation or by
attenuation for a low-pass filter.
The frequency domain analysis of a
system is valid for a range restricted to where
the system is linear and time invariant (i.e.,
the LTI range). For a system to be considered
LTI, three conditions must be satisfied.
Homogeneity: An element is homogenous for
the values of k where an input r(t) produces
output c(t), and then an input k × r(t) produces
output k × c(t). Superposition: If an input r1(t)
Frequency Domain Analysis
circuitcellar.com 53
CO
LU
M
NS
produces output c1(t) and input r2(t) produces
output c2(t), then input r1(t) + r2(t) = c1(t) +
c2(t). Time invariance: If r(t) generates c(t),
then r(t – τ) mustgenerate c(t – t) for all t
> 0.
These severe restrictions can be satisfied
within a limited range only. Therefore, our
design must come to LTI requirements as
much as possible. This is not an unusual
problem in engineering, including electronics.
No components (e.g., resistors, capacitors,
and inductors) are purely resistive or reactive.
They all contain parasitic components of the
other types, but competent engineers know
how to select them so that the effects of those
parasitic characteristics can be ignored within
the operational range. Active components
also have limitations including saturation. We
must build amplifiers and other processing
circuits with sufficient headroom to make
them behave as LTI within the required scope.
With some notable exceptions, well
designed electronics are rarely the LTI limiting
component. Those exceptions are usually
within the plant characteristics where size,
weight and cost limitations may encroach on
some electronic components’ LTI.
I already mentioned transfer functions
of controller elements (i.e., an integrator, a
differentiator, and a delay). Given voltage V
and current I, let’s consider some transfer
functions of electronic components.
Inductance L:
V(s) = Ls I(s)
v(t) = L di(t)
dt
×
×
Capacitance C:
V(s) = 1
C
 I(s)
s
v(t) = v + 1
C
i(t)dt0
×
∫
Resistance R:
V(s) R I(s)
v(t) R i(t)
= ×
= ×
Many transfer functions applying to
mechanical elements (e.g., velocity, mass,
spring, inertia, and pressure) have equivalents
in electronics. While common transfer
functions are available in books on control
systems, others may have to be determined.
The Circuit Cellar readers are mostly electrical
engineers, so they can relate to transfer
functions of the electrical components
FIGURE 1
Bode plot of gain (a) and phase (b) trace with different damping factor a versus the frequency of a second-
order system.
ABOUT THE AUTHOR
George Novacek is a professional engineer
with a degree in Cybernetics and Closed-
Loop Control. Now retired, he was most
recent l y pres ident o f a mu l t inat iona l
manufacturer for embedded control systems
for aerospace applications. George wrote 26
feature articles for Circuit Cellar between
1999 and 2004. Contact him at gnovacek@
nexicom.net with “Circuit Cel lar ”in the
subject line.
a)
b)
CIRCUIT CELLAR • JUNE 2017 #32354
CO
LU
M
NS
mentioned above. Mechanical components,
unfortunately, are seldom as intuitive to us.
In a perfect world the electronic controller
designer should be given the required gains
and limits, while leaving the selection, design
and characterization of the control system
and its components to mechanical engineers.
But that doesn’t always happen.
With the help of the transfer functions the
response of a control system can be calculated.
In the frequency domain analysis we use
sinewave, because it is the only waveform that
does not change its shape in an LTI system.
Using sinewaves does not cause a problem
because, thanks to M. Jean-Baptiste Joseph
Fourier we know that any waveform shape
can be generated by a series of sinewaves.
Therefore, the response of an LTI system
can be characterized by investigating the
gain and the phase of its frequency response
also referred to as the Bode plot. This can
be accomplished by calculations, computer
simulation or measurement and graphically
displayed.
Figure 1 is a Bode plot of a second-order
system with resonant frequency f = 10 Hz
and critical and low damping factors a, often
designated by x. Such a system’s response is
defined as:
f(s)
s 2
2
2 2= + × × × +
w
x w ws
In this instance, w = 2pf. x is the damping
coefficient and s is the Laplace operator. Both
circuitcellar.com/ccmaterials
RESOURCES
G. Ellis, Control System Design
Guide, Elsevier Academic
Press, 2002.
B. C. Kuo, Automatic Control Systems, Prentice
Hall, 2009.
G. Novacek, “Electro-Hydraulic Servo Valves,”
Circuit Cellar 253, 2011.
Wikipedia, Nyquist Stability Criterion,
https://en.wikipedia.org/wiki/
Nyquist_stability_criterion.
FIGURE 2
Combining the forward and the feedback
transfer functions into one OLG G(s)
H(s)
C(s)R(s)
+
−
R(s)
G(s)
C(s)1 + G(s)H(s)
FIGURE 3
OLG Bode plot of a controller
www.circuitcellar.com/ccmaterials.
https://en.wikipedia.org/wiki/
Nyquist_stability_criterion
circuitcellar.com 55
CO
LU
M
NS
the gain and the phase responses are affected
by the damping factor x.
Being from the slide ruler generation I
must admit that I never enjoyed making those
calculations. So quite often we minimized
the number of calculations by generating
asymptotes only. Anything more than a
second-order system response calculation
used to be nearly impossible, but thanks to
computers, the Bode plots can nowadays
be generated very quickly by the multitude
of simulation or mathematical tools such as
PSpice, LTSpice, Matlab, Mathcad, Simulink
and others.
To analyze automatic systems in frequency
or time domain, we start by defining it by a
block diagram. The functional blocks (there
can be many) are gradually combined into a
single block to obtain the transfer function
of the system. Figure 2 shows just two
blocks, the forward and the feedback paths
for simplicity. To check for stability the gain
and the phase are plotted with the feedback
disconnected. This is called an open loop gain
(OLG).
The result will be something like the Bode
plot in Figure 3. This one is the OLG response
of the analog electronic controller shown in
Part 1 with an actuator. I spread the plot
frequency until the phase reached 180° to
illustrate the phase and the gain margins.
The OLG vs. frequency is shown in decibels
(dB) and the phase in degrees. The main point
of interest for us to judge the potential for
unwanted oscillations is where the phase
reaches –180° while the OLG is greater than
0 dB. In our case, the phase at 0 dB OLG is
–89°. This means that the phase margin is
180 – 89 = 91°. Another point of interest is
where the phase reaches -180°. The OLG here
is -29dB, thus the gain margin is 29dB. If the
OLG was greater than 0dB when the phase
reached 180° the system would oscillate after
closing the feedback loop. The large phase
and gain margins of Figure 3 will guarantee
no oscillations, but will not guarantee a
possibility of instability, namely in response
to a step input. Automatic systems are rarely
exposed to a step in the setpoint, but a step
input may be due to an external disturbance.
We shall address that issue when we discuss
the time domain response.
In many electromechanical systems the
plant, due to its inertia, stops responding
above certain, fairly low frequency. This is
not unusual. However, the bandwidth of the
electronic controller should always be at least
ten times the fastest component in the plant.
To complete our excursion into the
frequency domain analysis we must mention
the Nyquist plot also used for assessing the
system stability. Figure 4 shows the plots
related to the frequency, phase and damping
illustrated by Figure 1 and defined by
Equation 8. Nyquist contour is a parametric
plot of the frequency response of a system
transfer function with the feedback closed.
The real and the imaginary parts of the
transfer function are plotted in Cartesian
coordinates with the real part on the x-axis
and the imaginary part on the y-axis, with the
frequency as a parameter.
The system stability is assessed using the
Nyquist Stability Criterion. It is determined by
evaluating the Nyquist contour in relation to
the point at x = –1 and y = 0. Next month
we’ll discuss time domain analysis and digital
systems using z transform.
FIGURE 4
Nyquist contours for the critically (left) and under damped (right) system described by Equation 8
CIRCUIT CELLAR • JUNE 2017 #32356
CO
LU
M
NS
GREEN COMPUTING
High-performance chips have significant heat generation
variations across theirvarious microachitectural and
circuit blocks. This article argues that hybrid and
heterogeneous cooling methods that tackle the “hot
spots” locally and use efficient cooling methods to remove
the background heat offer the potential to substantially
improve power efficiency.
By Ayse K. Coskun
High temperatures on chips have been among the primary limiting factors in
building and running high-performance
processors. This is because high
temperatures adversely affect reliability and
increase leakage power consumption. Rising
temperatures have been getting even more
attention recently in tandem with aggressive
technology scaling, which has resulted in high
power densities (i.e., high power consumption
per area).
As processor manufacturers continue to
pack more functionality into a single chip,
maintaining safe temperatures becomes even
more challenging. In the next generation
processors targeting “exascale computing,”
power densities of 1 to 2 kW/cm2 are
anticipated. For example, IBM’s recent work on
two-phase cooling introduces a new method
to handle such high power densities.[1]
Another thermal challenge with future
high-performance chips is that heat
generation across a processor die is
significantly heterogeneous. While one corner
of a circuit block may reach extremely high
power densities, others may operate at much
more moderate power levels. Consequently,
chips often exhibit very high temperature
peaks that are localized. In fact, one can
find in the literature many thermal maps
(e.g., constructed via infrared cameras)
that demonstrate the heat heterogeneity in
various modern real-world processors.
While heat generation is highly
heterogeneous and it is expected to become
even more visibly heterogeneous in future
processors, cooling subsystems are generally
homogeneous—meaning that the cooling
infrastructure on a chip typically has the
same cooling capability across the chip and it
is built using a single cooling technology. This
homogeneous design of the cooling subsystem
causes cooling inefficiencies (under- or over-
cooling) for chips with spatially heterogeneous
heat profiles.
There are a number of advanced cooling
methods that have been developed in the recent
years following the growing significance of
efficient thermal management. These cooling
methods, including liquid cooling, two-phase
cooling, thermoelectric coolers (TEC), the use
of phase-change materials (PCMs) on chip or
on package, and others, have rather distinct
response times, efficiencies, or granularities.
For example, while TECs are great in reducing
the temperatures of local hot spots rapidly,
using a large number of TECs on chip may
cause prohibitively high cooling power as
TECs are “active” devices that consume
energy to provide cooling. Liquid cooling
achieves efficient heat removal, but typically
the operational settings of pumps (that push
the liquid) can be changed in the order of
hundreds of milliseconds or seconds; thus,
On the Potential of
Hybrid Cooling
circuitcellar.com 57
CO
LU
M
NS
this granularity may hinder effective rapid
thermal management. Generally speaking,
a single cooling solution that is able to
efficiently optimize cooling for any arbitrary
chip does not exist; so, one needs to consider
the tradeoffs in response time, cooling power,
overall efficiency, and others while selecting
the best cooling method for a given system.
Can we combine different cooling methods
together to maximize the energy efficiency
of heat removal? By putting together the
strengths of different cooling methods, it
may be possible to design systems whose
efficiency substantially surpasses that of
the systems designed today. The rest of this
article discusses “hybrid cooling” strategies
that integrate multiple cooling methods on a
given system, often in a heterogeneous way
across the chip (i.e., using different cooling
devices or geometries on different parts of
the chip), so as to address the differences in
heat generation.
ADVANCED COOLING SOLUTIONS
The idea of hybrid cooling can apply to
many cooling methods. For example, one
can consider putting together a conventional
heat sink with a liquid-cooled cold plate. Or
modern data centers that combine in-row
liquid coolers with conventional fans and heat
sinks at the server level could be considered
as early adopters of hybrid cooling. In this
article, I will specifically focus on hybrid
cooling on the chip because removing the
generated heat directly on the chip can
enable dramatically pushing the performance
limits imposed by the critical temperature
thresholds on chips. I will discuss hybrid
and heterogeneous integration of several
advanced cooling methods together, including
TECs, liquid cooling, and PCMs.
A TEC operates based on the Peltier effect
such that when current passes through the
TEC device, heat is absorbed from one side
(cold side) and rejected to the other side (hot
side), creating a thermal gradient across
the two sides. Superlattice-based thin film
TECs are compatible with silicon fabrication
and can be directly integrated on the back
of a silicon chip. Existing on-chip TEC devices
are composed of ultrathin (5 to 10 µm)
thermocouples sandwiched between copper
and they are covered with ceramic insulator
plates at the outmost surfaces. The cooling
ability of a TEC is dependent on the applied
current: typically, the higher the current, the
higher the cooling ability. While TECs can
provide rapid reduction of temperature on
local hot spots, larger TEC sizes can easily
become too costly in terms of the cooling
power (as more current needs to flow).
Liquid cooling can remove heat from
chips more efficiently compared to air
cooling. Liquid-cooled cold plates or applying
liquid cooling at the racks/data center are
already in use in modern data centers or
high-performance computing clusters. An
emerging advanced liquid cooling method
is etching hannels on the backside of a chip
or placing microchannels in between the
stacked dies in a 3D-stacked system. (Refer
to my Circuit Cellar 284 article on “Greener
Cooling.”) Liquid cooling is ideal for removing
the background heat and its efficiency
increases for more uniform heat distributions
on the chip. Otherwise, in case of large local
hot spots, liquid flow rate and/or channel
dimensions need to be adjusted to handle the
worst-case hot spot. Thus, such cases result
in over-cooling of the lower-power areas of
the chip and higher pump power.
TECs and liquid cooling are both “active”
cooling methods, which means they require
external power to cool the chip. A passive
emerging cooling method is using PCMs
on chip. PCMs (such as cerrobend, gallium,
or mixes of PCMs with metal to increase
conductivity) absorb large amounts of heat
FIGURE 1
An example hybrid cooling solution includes placing TECs on the hot spots and then removing the background
heat of the chip using microchannel-based liquid cooling. In this way, one can reduce the total cooling power
required and/or achieve higher performance.
ABOUT THE AUTHOR
Ayse K. Coskun (acoskun@bu.edu) is an associate
professor in the Electrical and Computer
Engineering Department at Boston University
(BU). She received MS and PhD degrees in
Computer Science and Engineering from the
University of California, San Diego. Coskun’s
research interests broadly include energy-
efficient computing and intelligent management
of computing systems, from mobile devices to
data centers. She worked at Sun Microsystems
(now Oracle) in San Diego, CA, prior to her
current position at BU. Coskun was an associate
editor of the IEEE Embedded Systems Letters, and currently serves as an
