9
Journal of Oleo Science
Copyright ©2013 by Japan Oil Chemists’ Society
J. Oleo Sci. 62, (1) 9-16 (2013)
The viscosity stability of O/W emulsion containing
α-gel through an ionic-complex system
Makoto Uyama＊ , Kaori Ikuta, Takashi Teshigawara, Kei Watanabe and Reiji Miyahara
Shiseido Research Center (Shin-Yokohama), Shiseido Co. Ltd., 2-2-1 Hayabuchi, Tsuzuki-ku, Yokohama, Kanagawa 224-8558, Japan
1 INTRODUCTION
Various active ingredients, which often are electrolytes,
are used in cosmetic products for moisturizing and whiten-
ing the skin. When these electrolytes are added to an oil in
water（O/W）emulsion system, stability generally deterio-
rates remarkably because of the increasing hydrophobici-
ties of the surfactants in the system, particularly in cases
of nonionic surfactants, and their cloud points decrease. To
reconcile the stabilities of O/W emulsion systems contain-
ing electrolyte-type active ingredients, a system containing
an α-crystalline phase（α-gel）, which consisted of water,
higher alcohols, and the anionic surfactant, sodium N-stea-
royl-N-methyl taurate（SMT, Fig. 1（a））, was developed by
Konno and Watanabe1, 2）.
An α-gel（α-type hydrate crystal）is one of the hydrated
crystalline state of surfactants and lipids that appears as a
highly viscous gel3, 4）. The long-periodic structure of an
α-gel has a repeating bilayer structure, with its packed
（sub-cell）structure of hydrophobic groups forming a hex-
agonal sub-lattice and its hydrophilic groups holding a
large amount of water.
α-Gel is often confused with a lamella liquid crystalline
phase, because both have a repeated bilayer structure.
However, unlike an α-gel, the hydrophobic groups of a
＊Correspondence to: Makoto Uyama, Shiseido Research Center (Shin-Yokohama), Shiseido Co. Ltd., 2-2-1 Hayabuchi, Tsuzuki-ku,
Yokohama, Kanagawa 224-8558, Japan
E-mail: makoto.uyama@to.shiseido.co.jp
Accepted July 14, 2012 (recieved for review May 22, 2012)
Journal of Oleo Science ISSN 1345-8957 print / ISSN 1347-3352 online
http://www.jstage.jst.go.jp/browse/jos/　　http://mc.manusriptcentral.com/jjocs
lamella liquid crystalline phase are in a molten（liquid）state
with no specific sub-lattice structure. The two forms can
be easily distinguished by X-ray scattering measurements.
In the wide-angle X-ray scattering pattern of an α-gel, a
sharp peak is observed at 15 nm－1（Bragg angle of 21°）,
which corresponds to the diffraction of the sub-lattice. In
contrast, no peak is evident for the sub-lattice structure of
lamellar liquid crystalline phases.
Abstract: Although many active ingredients are used in cosmetic products for moisturizing and whitening
the skin, they are often electrolytes, and the stabilities of oil in water (O/W) type emulsion formulae
containing electrolytes are generally difficult to control. To solve this problem, formulae containing an
α-crystalline phase (α-gel) consisting of water, higher alcohols, and anionic surfactants such as sodium
N-stearoyl-N-methyl-taurate (SMT) have been developed. However, in spite of their excellent salt tolerance,
these formulae have poor viscosity stability under non-electrolyte conditions, and the viscosity decreases
over time. To obtain adequate viscosity stability, the required electrolyte concentration is approximately
1wt%, which is somewhat high for cosmetic applications. To replace the salts, distearyl dimethyl ammonium
chloride (DSAC), a cationic surfactant, with an opposite electric charge to SMT, was used in O/W emulsion
formulae, resulting in improved viscosity stability at a lower concentration than that of salts. The
stabilization mechanism with DSAC was found to be different from that of salts.
Key words: α-Crystalline phase, α-gel, Emulsion, Sodium N-stearoyl-N-methyltaurate, Distearyl dimethyl ammonium
chloride, DSC, SAXS, cryo-SEM
Fig. 1　 Chemical structures of SMT (a), DSAC (b), and
C22TAC (c).
M. Uyama, K. Ikuta, T. Teshigawara et al.
J. Oleo Sci. 62, (1) 9-16 (2013)
10
Konno has reported that an O/W emulsion showing ex-
cellent long-term viscosity stability can be obtained with
SMT as an anionic surfactant in the α-gel structure of the
emulsion, even with electrolytes, unlike other anionic sur-
factants1）. However, approximately 1wt％ NaCl was needed
to obtain long-term viscosity stability, because under low-
or non-electrolyte conditions, remarkable viscosity deterio-
ration was observed over time. Although the α-gel system
with SMT showed outstanding salt tolerance, its excellent
viscosity stability could be lost in non- or low-concentration
electrolyte conditions over time. Moreover, the use of 1
wt％ NaCl is marginally intolerable for preparing cosmetic
formulae.
This study investigated materials that can be used with
SMT at lower concentrations to enhance the long-term vis-
cosity stability of O/W emulsions.
In particular, this study focused on the following two
points. First, materials should be cationic, to weaken the
electrostatic repulsion of SMT and neutralize its electric
charge. Second, they should be hydrophobic surfactants,
because unlike water-soluble NaCl, they are integrated into
the α-gel structure of the system at concentrations lower
than that required by NaCl.
Distearyl dimethyl ammonium chloride（DSAC, Fig. 1
（b））5－9）, a cationic surfactant, is a strongly hydrophobic
double-alkyl-chain-type surfactant, which is insoluble in
water. DSAC is thought to be easily incorporated into the
α-gel structure because of its straight alkyl chains, and to
interact electrostatically with SMT in the α-gel. Using cryo-
genic scanning electron microscopy（cryo-SEM）, Yamagu-
chi et al. studied changes in the structure of assembly in
the ternary 1-hexadecanol, octadecyl trimethyl ammonium
chloride, and water system, altering the molar ratio of
1-hexadecanol to octadecyl trimethyl ammonium chloride,
as well as the preparation temperature10, 11）. Nagahara et al.
observed the cationic assembly in the system composed of
behenyl trimethyl ammonium chloride, behenyl alcohol,
and water, with or without amido propyl betaine laurate
also using cryo-SEM12－14）.
This study shows（1）the improvement of the long-term
viscosity stability of an O/W emulsion system containing an
α-gel, and（2）a possible mechanism through an SMT/DSAC
ionic complex.
2 EXPERIMENTAL
2.1 Materials
SMT and behenyl alcohol were purchased from Nikko
Chemicals（Tokyo, Japan）. DSAC, behenyl trimethyl am-
monium chloride（C22TAC, Fig. 1（c））, and stearyl alcohol,
were purchased from Sanyo Chemical Industries（Kyoto,
Japan）, Toho Chemical Industry（Tokyo, Japan）, NOF cor-
poration（Tokyo, Japan）, respectively. Other materials used
in this study were cosmetic grade and used as received.
2.2 Methods
2.2.1 Preparations of O/W emulsions
Formulae of O/W emulsion sample used in this study are
provided in Table 1. O/W emulsion samples were prepared
Table 1　Basic formulae of O/W emulsions (wt%).
Ingredients
NaCl
added*
DSAC
added**
C22TAC
added***
Water phase
　Sodium N-stearoyl-N-methyltaurate (SMT)
　Humectant
　Xanthan gum
　Citrate buffer
　Sodium chloride
　Disodium EDTA
　Preservative
　Water
Oil phase
　Stearyl alcohol
　Behenyl alcohol
　Hydorocarbon Oil
　Silicone Oil
　Distearyl Dimethylammonium chloride (DSAC)
　Behenyl trimethyl ammonium chloride (C22TAC)
0.2
13
0.1
0.1
0 or 1
0.1
proper wt.
up to 100
0.3
1.1
2
3
－
－
0.2
13
0.1
0.1
－
0.1
proper wt.
up to 100
0.3
1.1
2
3
0－0.1
－
0.2
13
0.1
0.1
－
0.1
proper wt.
up to 100
0.3
1.1
2
3
－
0－0.1
*Formula added with NaCl.
**Formula added with distearyl dimethyl ammonium chloride (DSAC).
***Formula added with behenyl trimethyl ammonium chloride (C22TAC).
The viscosity stability of O/W emulsion containing α -gel through an ionic-complex system
J. Oleo Sci. 62, (1) 9-16 (2013)
11
by adding the oil phase heated at 85℃ to the water phase
heated at 80℃ and subsequent emulsification using a ho-
mogenizer（T.K. ROBOMIX®）（PRIMIX, Osaka, Japan）.
Emulsion particle sizes were observed withthe optical mi-
croscope and made below 5 μm. The samples were then
cooled at 40℃ in an ice/water bath.
2.2.2 Viscosity measurements
The prepared sample was stored at room temperature,
and viscosity was measured by a rotary viscosity meter（B-
type, VDA2）（Shibaura systems, Tokyo, Japan）at 1, 15, and
30 days after preparation. For the measurements, rotor No.
3 was used at 12 rpm at 30℃ for 1 min.
2.2.3 Small-angle X-ray scattering（SAXS）measurements
SAXS measurements were performed with a SAXSess
camera（Anton Paar, Graz, Austria）. Cu-Kα（λ : 1.542 Å）ra-
diation was used. The scattering intensity of each sample
was measured at 25℃ for 10 min with a cyclone imaging
plate detection system（Perkin-Elmer, Waltham, MA, USA）
and analyzed by SAXSQuant software（Anton Paar）. Emul-
sion samples for SAXS measurements were ultracentri-
fuged at 65,000 rpm for 7 hours at 25℃, using a himac
CP100wx（Hitachi Koki, Tokyo, Japan）before SAXS mea-
surements.
2.2.4 Differential scanning calorimetry（DSC）
DSC measurements were performed using a DSC Q2000
（TA Instruments, Delaware, USA）, equipped with a refrig-
erated cooling system（RCS 90）（TA Instruments）, over a
temperature range of 25 to 85℃ at a heating rate of 1℃/
min. Tzero pans and Tzero hermetic lids（TA Instruments）
were used, and the sample weight was adjusted to approxi-
mately 10 mg.
2.2.5 Electron microscopy and image analysis
Cryo-SEM can fix and observe the actual state of a col-
loidal material, such as a cream product, while preserving
its α-gel structure.
Under conventional SEM operating conditions, α-gel
structural information would be lost due to possible gel
structure coalescence at ambient temperature. To obtain
the cryo-SEM images of prepared samples, a small amount
of sample was put onto a specimen holder and plunged into
liquid nitrogen. The frozen specimen on the holder was
transferred to a microscope cold stage at －70～－90℃.
Then, the surface of specimen was fractured on the stage
and observed with a scanning electron microscope（Hitachi
S-3000N）（Hitachi High-Technologies, Tokyo, Japan）with
an acceleration potential of 5 kV.
3 RESULTS AND DISCUSSION
3.1 Effect of DSAC on the viscosity of O/W emulsions
Base formulae used in this study are shown in Table 1.
Although the concentrations and the types of humectants
varied to some extent, the variations were confirmed to
have no influence on the viscosity stability of the sample
emulsion in a separate experiment（data not shown）. Simi-
larly, the influence of humectants on the viscosity stability
was also hardly taken into consideration in a previous
report1）. Xanthan gum（0.1 wt％）, a thickening agent, was
also confirmed to have practically no effect on the viscosity
（data not shown）. Citrate buffer（citric acid and sodium
citrate）was used to control the emulsion pH between 5.8
and 6.2.
Cationic surfactants are known to attenuate the electric
charge of SMT. We expected that a small amount of DSAC
would affect the viscosity of O/W emulsion samples more
strongly than salts, because DSAC has two straight alkyl
chains that are easily incorporated in the α-gel, and can ef-
ficiently shield the electric charge of SMT in the α-gel.
Figure 2 shows the viscosity changes upon addition of
DSAC. The viscosities of samples containing 0, 0.02, and
0.05 wt% DSAC decreased from 3560, 3920 and 4080 mPa・
s at 1 day to 2950, 3210, and 3950 mPa・s at 30 days post-
preparation, respectively. Decreases in the viscosities of
samples containing 0, 0.02, and 0.05 wt% DSAC for 30 days
were found to be 610, 710, and 130 mPa・s, respectively.
On the other hand, the viscosities of samples containing
Fig. 2　 Time-course of the viscosity of O/W emulsion
samples containing DSAC or NaCl. Plots repre-
sent viscosity of samples containing (●) 0 wt%
DSAC; (▲), 0.02 wt%; (■), 0.05 wt%; (◆),
0.07 wt%; and (×), 0.10 wt% DSAC. The stars
(＊) represent the viscosity of the sample con-
taining 1.0 wt% NaCl.
M. Uyama, K. Ikuta, T. Teshigawara et al.
J. Oleo Sci. 62, (1) 9-16 (2013)
12
0.07 and 0.1 wt% DSAC increased from 3960 and 2530
mPa・s at 1 day to 4130 and 2900 mPa・s at 30 days post-
preparation, respectively, indicating that DSAC was able
not only to suppress spontaneous viscosity decreases but
also to increase the viscosity of the samples in a dose-de-
pendent manner. The minimum concentration of DSAC for
obtaining the suppression effect was 0.05 wt％, which was
quite lower than those of salts. This result indicated that
the systems containing 0.07 and 0.10 wt% DSAC were in
condensed states, because van der Waals attractions
became more dominant than electrostatic repulsions.
Therefore, the optimal concentration of DSAC in this
system was 0.05 wt％.
On the other hand, the viscosities of sample containing
1.0 wt% NaCl were found to be 4050 mPa・s at 1 day and
3770 mPa・s at 30 days after preparation, and yielding a de-
crease in the sample viscosities of 280 mPa・s, over 30 days.
This result indicated that 0.05 wt% DSAC suppressd the
spontaneous viscosity decrease more than 1.0 wt% NaCl.
3.2 Effect of C22TAC on the viscosity of O/W emulsions
C22TAC has a single straight alkyl chain and is water
soluble（＞50℃）, in contrast to DSAC. Yet, C22TAC is also
a cationic surfactant that was expected to form an ionic
complex with SMT.
Figure 3 shows the results of the viscosity change upon
addition of C22TAC. Spontaneous viscosity decrease was
slightly suppressed only in the sample containing 0.100
wt% C22TAC, indicating that a larger amount of C22TAC
than DSAC was required to suppress the spontaneous de-
crease in viscosity. It may be possible to include C22TAC in
an α-gel that consists of water, higher alcohols, and SMT
but probably a large portion of C22TAC exists as micelles
in the system12, 15）.
3.3 Mechanism for the improvement in the viscosity sta-
bility of O/W emulsions by addition of DSAC
3.3.1 Phase behavior and interlamellar distance
SAXS measurements were performed on O/W emulsion
samples with or without DSAC（Fig. 4）. The samples were
the same samples used in the viscosity measurement ex-
periments in Fig. 2. Samples were ultracentrifuged before
SAXS measurement to condense the α-gel, because the
α-gel concentration was low and resulted in insufficiently
Fig. 4　 SAXS patterns of ultracentrifuged O/W emul-
sion samples containing DSAC having pos-
sible interlamellar distances of structures and a
sample of hydrate crystal of higher alcohol. The
samples were the same samples used in the vis-
cosity measurement experiments (Fig. 2). Pat-
tern (a) shows a sample containing 0 wt%; (b),
0.02 wt%; (c), 0.05 wt%; (d), 0.07 wt%; and (e),
0.10 wt% DSAC. Pattern (f) shows a sample of
the hydrate crystal of the higher alcohol. Down-
ward arrow indicates the peak originating from
the hydrated crystal of the higher alcohol.
Fig. 3　 Time-course of the viscosity of O/W emulsion
samples containing C22TAC. Plots represent
viscosity of samples containing (●) 0 wt%
C22TAC; (▲), 0.045 wt%; (■), 0.063 wt%;
(◆), 0.085 wt%; and (×), 0.100 wt% C22TAC.
The viscosity stability of O/W emulsion containing α -gel through an ionic-complex system
J. Oleo Sci. 62, (1) 9-16 (2013)
13
intense signals. A diffraction pattern derived from a lamel-
lar structure was observed for all samples. Generally, the
addition of electrolytes, such as NaCl, to this sort of emul-
sion system reportedly allows the hydrophilic groups of
surfactants to dehydrate, resulting in the shrinkage of the
interlamellar distance of the lamellar structures1, 16, 17）. Al-
though DSAC is not a salt, shrinkage of the interlamellar
distance was observed in a dose-dependent manner. The
interlamellar distances of samples containing 0, 0.02, 0.05,
0.07, and 0.10 wt% DSAC were 23, 22, 21, 21, and 19 nm,
respectively. Generally, oppositely charged surfactants
form an ion complex, allowing the shrinkage of the interla-
mellar distance18, 19）. However, when DSAC was added to
the system at more than0.10 wt％, a peak different from
that of a lamellar structure was observed（the arrow in Fig.
4（e）, q＝1.07 nm－1）. The peak was speculated to originate
from a hydrate crystal of a higher alcohol（Figs. 4（e） and
（f））. However, a peak shape change was not observed
clearly in the wide-angle upon the addition of DSAC, prob-
ably because the intensity was weak（data not shown）.
3.3.2 DSC Measurements
To confirm the inclusion of DSAC in the α-gel, DSC mea-
surements of the samples were performed20－23）. The DSC
data for the samples used in Fig. 2 are shown in Fig. 5.
Single endothermic peaks were observed in the samples
containing 0－0.05 wt% DSAC. Upon increasing DSAC
from 0.05 to 0.10 wt%, the peaks moved toward lower tem-
peratures, and other peaks appeared in the lower tempera-
ture region（～59℃ and ～61℃）. An endothermic peak
that appeared in this region was probably derived from the
melting of the higher alcohol hydrate crystal that was ex-
cluded from the α-gel, rather than the melting of the DSAC
hydrate crystal, because（1）the possible electrostatic and
hydrophobic interactions between SMT and DSAC were
very strong, impeding the independent precipitation of
DSAC, and（2）the melting point of the hydrate crystal
（Krafft point）of DSAC is known to be 37℃5）.
To prepare an O/W emulsion formula having excellent
viscosity stability and a single α-gel structure, the ratio of
SMT and DSAC was very important, and our findings indi-
cated an optimal ratio of DSAC to SMT of approximately 4
to 1（25 wt％）. This ratio does not change dramatically,
even when converted into a molar ratio, because the mo-
lecular weight of SMT and DSAC are 427.62 and 585.60,
respectively.
3.3.3 Cryo-SEM observations
Figure 6 shows the cryo-SEM photographs of the control
O/W emulsion sample（Fig. 6（A））, a sample containing 1.0
wt％ NaCl（Fig. 6（B））, a sample containing 0.05 wt％
DSAC（Fig. 6（C））, and a sample containing 0.10 wt％
C22TAC（Fig. 6（D））10－14）, 24, 25）. All samples were observed
seven days after preparation. To prevent samples from be-
coming difficult to freeze or easy to melt, humectants were
removed from the basic formula. Konno reported that after
the addition of 0.5 wt％ NaCl to an O/W emulsion sample,
no layer structures were observed1）. In this study, stratified
vesicle structures having 3 or 4 layers around emulsion
particles were observed in the control（Fig. 6（A））.
Fig. 5　 DSC thermograms of O/W emulsion samples
containing DSAC. The samples were the same
samples used in the viscosity measurement ex-
periments (Fig. 2). Line (a) shows the thermo-
gram of the sample containing 0wt%; (b), 0.02
wt%; (c), 0.05 wt%; (d), 0.07 wt%; and (e), 0.10
wt% DSAC.
Fig. 6　�Cryo-SEM photographs of O/W emulsion
samples containing SMT. The magnifications of
photographs were 500, and cryo-SEM observa-
tion was performed at –70 – –90 ℃. Photograph
(A) is the control sample; (B), sample contain-
ing 1.0 wt% NaCl; (C), sample containing 0.05
wt% DSAC; (D), sample containing 0.10 wt%
C22TAC. All samples were observed 7 days af-
ter the preparation. The arrows in photograph (C)
and (D) indicate plate-like structures.
M. Uyama, K. Ikuta, T. Teshigawara et al.
J. Oleo Sci. 62, (1) 9-16 (2013)
14
However, the addition of 1.0 wt％ NaCl gave a slightly
stratified vesicle structure（Fig. 6（B））. The interlamellar
distance was compressed by the addition of NaCl, and the
stratified vesicle structure disappeared in cryo-SEM. On
the other hand, in the system containing DSAC, no strati-
fied vesicle structure was observed completely, but rather,
a plate-like structure was observed（arrows in Fig. 6（C））.
Yamagata et al. studied the effects of temperature on the
development of the internal structure of the cetyltrimeth-
ylammonium chloride/cetyl alcohol/ water system13）. Using
cryo-SEM, they discussed the system’s internal structure
using the terms lamellar structure（plate-like lamellar
structure in this report）and multilamellar vesicles. The
cause of the improvement of the viscosity stability of the
O/W emulsion sample upon addition of DSAC was thought
to be due to this plate-like structure. In the case of
C22TAC, a plate-like structure was also observed, as in the
case of DSAC, but the structure was sparse and caves were
notably large（Fig. 6（D））.
As illustrated in Fig. 7, electrolytes such as NaCl might
be distributed according to the Boltzmann distribution
from the surface of the α-gel to bulk water26－28）, conse-
quently, a high concentration of salt was necessary to sta-
bilize the viscosity of the system. On the other hand, DSAC
might be included in the α-gel, interacting with SMT di-
rectly, and therefore, it was speculated that a smaller
quantity of DSAC than that of salt would improve the vis-
cosity stability. Unlike salt, which attenuated electrostatic
repulsion and reduced the interlamellar distance, DSAC
was able to neutralize the charge of SMT directly in the
α-gel, resulting in a change in the α-gel microstructure.
Figure 8 shows the schematic illustration of a possible
mechanism explaining DSAC effect. After being added to
an emulsion system, distearyl dimethyl ammonium（DSA）
ion was incorporated into the α-gel through the hydropho-
bic interaction of its alkyl chains with SMT, forming an ion
complex with SMT through an electrostatic interaction.
Then, entropy（ΔS）was increased by release of the sodium
ion（the counter cation for SMT）from the surface of the
α-gel to bulk water, resulting in a decrease in the Gibbs
Free Energy（ΔG＝ΔH－TΔS）. Therefore, this process was
speculated to be spontaneous and entropy-driven29－32）. Al-
though there was an entropic decrease upon incorporation
of the DSA ion in the α-gel, a favorable change in Gibbs
energy might be observed due the strong, unfavorable hy-
drophobic interaction of DSA ion with bulk water. In addi-
tion, the entropy of the chloride ion（the counter anion for
DSA ion）increased when the DSA ion formed an ion
complex with SMT. Therefore, being included in the α-gel,
DSAC was speculated to be in a favorable energy balance
state. Hydration and dehydration might also significantly
affect the entropy（ΔS）of the system31）. The incorporation
of DSAC in the α-gel allowed the small sodium counterion
of SMT to be exchanged for a bulky DSA ion, and this re-
placement was thought to allow the microstructure of the
α-gel to assume a plate-like lamellar structure instead of
the curved structure formed in a stratified vesicle. This mi-
crostructure change was speculated to contribute to the
improvement of the viscosity stability and the increase of
the storage modulus value upon addition of DSAC. Because
the friction between stratified vesicles produced viscosity
without DSAC, the inter-vesicle contact areas were small,
and the structure collapsed easily when shear stress was
applied to the system. On the other hand, with DSAC, the
structure became difficult to collapse even under a high
shear stress, because the friction between plate-like struc-
tures was strong due to the large contact areas.
Fig. 7　�Schematic illustration of the micro layer struc-
ture of an α-gel in O/W emulsion samples.
Illustration shows differences in the working
mechanism between NaCl (A) and DSAC (B)
for contributing to the formation of the structure.
Fig. 8　�Schematic illustration of microstructural change
of an α-gel in an O/W emulsion induced by
DSAC.
The viscosity stability of O/W emulsion containing α -gel through an ionic-complex system
J. Oleo Sci. 62, (1) 9-16 (2013)
15
4 Conclusions
In this report, DSAC was used instead of salts to solve
the problem of the viscosity stability of O/W emulsions
containing SMT. A small amount of DSAC improved the
viscosity stability and more effectively than salts. The
mechanism of the stabilization by DSAC was speculated to
differ from that of salts.
References
1） Konno, Y. The Development of O/W Emulsions in the
Presence of Electrolytes, Fragrance Journal. 19,
90-95（2005）.
2） Watanabe,K.; Inoue, H.; Teshigawara, T.; Kimura, T.
α-Gel Prepared in Sodium Methyl Stearoyl Taurate/
Behenyl Alcohol/Water System-Characterization of
Structural Changes with Water Concentration. J. Oleo
Sci. 61, 29-34（2012）.
3） Suzuki, T.; Takei, H. Solution Behavior and the Associ-
ation Structures of Long-chain Monoalkyl Phosphates.
J. Chem. Soc. of Jpn. 5, 633-640（1986）.
4） Yamaguchi, M.; Noda, A. Formation of the Complexes
in the Ternary System Composed of 1-Hexadecanol,
Octadecyltrimethylammonium Chloride and Water. J.
Chem. Soc. of Jpn 9, 1632-1638（1987）.
5） Kunieda, H.; Shinoda, K. Solution Behavior of Dialkyl-
dimethylammonium Chloride in Water. Basic Proper-
ties of Antistatic Fabric Softeners. J. Phys. Chem. 82,
1710-1714（1978）.
6） Laughlin, R. G.; Munyon, R. L.; Fu, Y. C.; Emge, T. J.
Physical Science of the Dioctadecyldimethylammoni-
um Chloride-Water System. 2. Kinetic and Mechanistic
Aspects. J. Phys. Chem. 95, 3852-3856（1991）.
7） Carvalho, L. A.; Carmona-Ribeiro, A. M. Interactions
between Cationic Vesicles and Serum Proteins. Lang-
muir 14, 6077-6081（1998）.
8） Partal, P.; Kowalski, A. J.; Machin, D.; Kiratzis, N.; Ber-
ni, M. G.; Lawrence, C. J. Rheology and Microstructur-
al Transitions in the Lamellar Phase of Cationic Sur-
factant. Langmuir 17, 1331-1337（2001）.
9） Kano, K.; Romero, A.; Djermouni, B.; Ache, H. J.;
Fendler, J. H. Characterization of Surfactant Vesicles
as Membrane Mimetic Agents. 2. Temperature-Depen-
dent Changes of the Turbidity, Viscosity Fluorescence
Polarization of 2-Methylanthracene, and Positron An-
nihilation in Sonicated Dioctadecyldimethylammonium
Chloride. J. Am. Chem. Soc. 101, 4030-4037（1979）.
10） Yamaguchi, M.; Noda, A. Formation of the complexes
in the ternary system composed of 1-hexadecanol, oc-
tadecyltrimethylammonium chloride and water. Nip-
pon Kagakukaishi（9）1632-1638（1987）.
11） Yamaguchi, M.; Noda, A. Structures of the associates
formed in the ternary system composed of 1-hexadec-
anol, octadecyltrimethylammonium chloride and wa-
ter. Nippon Kagakukaishi（1）26-32（1989）.
12） Nagahara, Y.; Nishida, Y.; Isoda, M.; Yamagata, Y.; Ni-
shikawa, N.; Takada, K. Structure and performance of
cationic assembly dispersed in amphoteric surfactants
solution as a shampoo for hair damaged by coloring. J.
Oleo Sci. 56, 289-295（2007）.
13） Yamagata, Y.; Senna, M. Effects of Temperature on the
Development of the Internal Structure of the Cetyltri-
methylammonium Chloride/Cetyl Alcohol/Water Sys-
tem. Langmuir 15, 7461-7463（1999）.
14） Yamagata, Y.; Senna, M. Change in viscoelastic behav-
iors due to phase transition of the assembly compris-
ing cetyltrimethylammonium chloride/cetyl alcohol/
water. Langmuir 15, 4388-4391（1999）.
15） Ishino, S.; Asakawa, T.; Ohta, A.; Miyagishi, S. Fluores-
cence Quenching of Quinoline Derivatives in a Micelle
System. J. Oleo Sci. 52, 535-540（2003）.
16） Kim, J. Y.; Dungan, S. R. α-Lactalbumin-AOT Charge
Interactions Tune Phase Structures in Isooctane/Brine
Mixtures. Langmuir 25, 7918-7926（2009）.
17） Grudzien, R. M.; Pikus, S.; Jaroniec, M. Synthesis and
Properties of Ordered Mesoporous Organosilicas with
Vinyl and Mercaptopropyl Surface Groups: The Effect
of Ligand Concentration on Pore Structure. J. Phys.
Chem. C. 113, 4875-4884（2009）.
18） Starodoubtsev, S. G.; Ryabova, A. A.; Khokhlov, A. R.;
Allegra, G.; Famulari, A.; Meille, S. V. Smectic Arrange-
ment of Bentonite Platelets Incorporated in Gels of
Poly（acrylamide）Induced by Interaction with Cationic
Surfactants. Langmuir 19, 10739-10746（2003）.
19） Mezei, A.; Meszaros, R.; Varga, I.; Gilanyi, T. Effect of
Mixing on the Formation of Complexes of Hyper-
branched Cationic Polyelectrolytes and Anionic Sur-
factants. Langmuir 23, 4237-4247（2007）.
20） Tajima, K.; Imai, Y.; Nakamura, A.; Koshinuma, M.
Three-phase Emulsification of Hexadecane with Dimy-
ristoylphosphatidylglycerol Sodium Salt in Water: An
Interpretation by New Phase Transition in Bilayer As-
sembly. J. Oleo Sci. 50, 475-484（2001）.
21） Yokoyama, S.; Inagaki, A.; Tsuchiya, K.; Sakai, H.; Imu-
ra, T.; Ohkubo, T.; Tsubaki, N.; Abe, M. Stearylamine
Changes the Liposomal Shape from MLVs to LUVs. J.
Oleo Sci. 54, 251-254（2005）.
22） Yamamoto, T.; Satoh, N.; Onda, T.; Tsujii, K. A Novel
Iridescent Gel Phase of Surfactant and Order-Disorder
Phase Separation Phenomena. Langmuir 12, 3143-
3150（1996）.
23） Jansson, J.; Schillen, K.; Olofsson, G.; da Silva, R. C.;
Loh, W. The Interaction between PEO-PPO-PEO Tri-
block Copolymers and Ionic Surfactants in Aqueous
Solution Studied Using Light Scattering and Calorime-
try. J. Phys. Chem. B. 108, 82-92（2004）.
24） Kim, W.-J.; Yang, S.-M. Microstructures and Rheologi-
M. Uyama, K. Ikuta, T. Teshigawara et al.
J. Oleo Sci. 62, (1) 9-16 (2013)
16
cal Responses of Aqueous CTAB Solutions in the Pres-
ence of Benzyl Additives. Langmuir 16, 6084-6093
（2000）.
25） Tan, G.; Xu, P.; John, V. T.; He, J.; McPherson, G. L.;
Agarwal,; V. Bose, A. Cryo-Field Emission Scanning
Electron Microscopy Imaging of a Rigid Surfactant Me-
sophase. Langmuir 24, 10621-10624（2008）.
26） Lou, J.; Shih, C. Y.; Lee, E. Diffusiophoresis of Concen-
trated Suspensions of Spherical Particles with Charge-
regulated Surface: Polarization Effect with Nonlinear
Poisson-Boltzmann Equation. Langmuir 26, 47-55
（2010）.
27） Verschueren, A. R. M.; Notten, P. H. L.; Schlangen, L. J.
M.; Strubbe, F.; Beunis, F.; Neyts, K. Screening and
Separation of Charges in Microscale Devices: Com-
plete Planar Solution of the Poisson-Boltzmann Equa-
tion. J. Phys. Chem. B. 112, 13038-13050（2008）.
28） Lima, E. R. A.; Biscaia, Jr., E. C.; Boström, M.; Tavares,
F. W.; Prausnitz, J. M. Osmotic Second Virial Coeffi-
cients and Phase Diagrams for Aqueous Proteins from
a Much-Improved Poisson-Boltzmann Equation. J.
Phys. Chem. C. 111, 16055-16059（2007）.
29） Ponomarenko, E. A.; Tirrell, D. A.; MacKnight, W. J.
Stoichiometric Complexes of Synthetic Polypeptides
and Oppositely Charged Surfactants in Organic Sol-
vents and in the Solid State. Macromolecules 29,
8751-8758（1996）.
30） Starodoubtsev, S. G.; Ryabova, A. A.; Dembo, A. T.;
Dembo, K. A.; Aliev, I. I.; Wasserman, A. M.; Khokhlov,
A. R. Composite Gels of Poly（acrylamide）with Incor-
porated Bentonite. Interaction with Cationic Surfac-
tants, ESR and SAXS Study. Macromolecules 35,
6362-6369（2002）.
31） Maeyer, L. D.; Trachimow, C. Kaatze, U. Entropy-Driv-
en Micellar Aggregation. J. Phys. Chem. B. 102, 8480-
8491（1998）.
32） Dedinaite, A. Claesson, P.M. Interfacial Properties of
Aggregates Formed by Cationic Polyelectrolyte and
Anionic Surfactant. Langmuir 16, 1951-1959（2000）.
