85
Hector Choy, Long-Range Planning Supervisor, Black Thunder Mine, Gillete, Wyoming, United States
CHAPTER 5
Strip Mine Planning
and Design
Hector Choy
INTRODUCTION
Modern strip mining (which is often referred to as open pit or
open-cast mining) began with the development of the steam
shovel used in the excavation of the Panama Canal. However,
underground mining continued to dominate the extraction
industries until the early 1900s, when strip mining proved
itself to be more economical for near-surface, flat-lying
deposits.
Strip mining is a form of surface mining that uses strip
cuts to mine generally shallow, flat-lying deposits. Strip mines
are typically layered deposits—a classic example is surface
coal mining. This chapter concentrates on considerations in
the mine planning and design process of strip coal mines.
The primer for mining engineers is Surface Mining (Pfleider
1972); see Kennedy (1990) for the updated second edition of
that text, and SME’s Mining Engineering Handbook, 3rd edi-
tion (Darling 2011).
Mine Planning and Design
There are two general approaches to mine planning. The first
is the development of a greenfield or new property. Capital
investments have not been committed; the property may
already have been acquired or is in the process of evaluation.
The prefeasibility study establishes the value of the property
and potential capital commitment. Prefeasibility may require
a general mine plan to establish if mining is practical and may
go as far as suggesting what equipment would be used. The
feasibility study then details the capital commitment and life
of the property and includes a detailed economic evaluation.
To develop economics in terms of cash flow, expected net
present value (NPV), and internal rate of return (IRR), the fea-
sibility study requires a detailed mine plan, equipment selec-
tion, schedules identifying the timing and amount of capital
expenditures, and estimates of projected revenue and costs.
Information on mining economics can be found in Stermole
and Stermole (2019). Table 1 lists items to consider in a mine
plan feasibility study.
An existing property or brownfield expansion consid-
ers an operation where equipment and facilities are already
in place and future development is planned. Mine planning
for existing operations may require a different approach to
address market conditions and the need to expand, scale back,
or maintain a steady-state production level.
In an existing property, where equipment and facilities
are established, the two stages of mine planning are the short-
term mine plan and the long-term or (life-of-mine) plan. These
stages are significant in that mines often assign designated
staff and instigate significant mine planning efforts to best
meet the differing requirements and level of detail for these
two functions. A list of items to consider in the mine planning
process is shown in Table 2.
Short-Term Mine Planning
The short-term mine plan (or operating plan) generally relates
to a period of less than 5 years and is typically broken down
into monthly, quarterly, and annual operating plans. Each
stage reflects a level of detail designed to guide the mining
toward fulfilling annual production and economic budgets
and capital expenditures. A high degree of planning detail is
placed on the first 2 years of short-range planning with col-
laboration from other departments such as production, main-
tenance, electrical, and plant. Each of these departments
provides essential information to the planning process, such
as mining methods, major equipment outages, preventive
maintenance and repairs, substation relocation, and railroad
and power plant outages, and it is the responsibility of the
mining engineer to incorporate relevant information into the
mine plan. During the first 2 years of short-range planning,
sequencing and scheduling is performed on a monthly basis.
For each month of the plan, the first step is to sequence and
schedule the removal of soil material (topsoil), either by plac-
ing this into individual piles where it can be stored for later
use during the reclamation process or laid down directly onto
previously mined areas in the ongoing reclamation process.
The second step is the sequencing and scheduling of the over-
burden removal process through conventional drilling and
blasting, truck and shovel overburden prestrip (if required),
cast blast, dragline bench (pad) construction, and dragline or
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
86 SME Surface Mining Handbook
truck and shovel overburden removal to expose the coal seam
beneath. The final step is the sequencing and scheduling of
coal removal and blending from different pits if available. The
process will include coal blasting, loading and hauling, crush-
ing, and storage to meet the production and quality require-
ments necessary to satisfy power plant contract agreements.
Long-Term Mine Planning
The defined planning periods can vary depending on the
size and life of the reserves, along with the general purpose
and objectives of the operation. The objectives of the long-
term mine plan include identifying and scheduling labor lev-
els, equipment production levels, and capital requirements
Table 1 Salient factors requiring consideration in mine planning and feasibility studies
Information About Deposit General Project Information Development and Extraction Economic Analysis
Geology: overburden
Stratigraphy
Geologic structure
Physical properties (highwall arid
spoil characteristics, degree of
consolidation)
Thickness and variability
Overall depth
Topsoil parameters
Geology: coal
Quality (rank and analysis)
Thickness and variability
Variability of chemical
characteristics
Structure (particularly at contacts)
Physical characteristics
Hydrology: overburden and coal
Permeability
Porosity
Transmissivity
Extent of aquifer(s)
Geometry
Size
Shape
Attitude
Continuity
Geography
Location
Topography
Altitude
Climate surface conditions
(vegetation, stream diversion)
Drainage patterns
Political boundaries
Exploration
Historical (area, property)
Current program
Sampling (types, procedures)
Market
Customers
Product specifications (tonnage,
quality)
Locations
Contract agreements
Spot sale considerations
Preparation requirements
Transportation
Property access
Coal transportation (methods,
distance, cost)
Utilities
Availability
Location
Right-of-way
Costs
Land and mineral rights
Ownership (surface, mineral,
acquisition)
Acreage requirements (on-site,
off-site)
Location of oil and gas wells,
cemeteries, etc.
Water
Potable and preparation
Sources
Quantity
Quality
Costs
Labor
Availability and type (skilled,
unskilled)
Rates and trends
Degree of organization
Labor history
Governmental considerations
Taxation (local, state, federal)
Royalties
Reclamation and operating
requirements
Zoning
Proposed and pending mining
legislation
Compilation of geologic and
geographic data
Surface and coal contours
Isopach development (thickness
of coal arid overburden, stripping
ratio, quality, costs)
Mine size determination
Market constraints
Optimum economics
Reserves
Method(s) of determination
Economic stripping ratio
Mining and barrier losses
Burned, oxidized areas
Mining method selection
Topography
Refer to previous geologic/
geographic factors
Production requirements
Environmental considerations
Pit layout
Extent of available area
Pit dimensions and geometry
Pit orientation
Haulage, power, and drainage
systems
Equipment selection
Sizing, production estimates
Capital and operating cost
estimates
Repeat for each unit operation
Project cost estimation (capital and
operating)
Mine
Mine support equipment
Office, shop, and other facilities
Auxiliary facilities
Labor requirements
Development schedule
Additional exploration
Engineering and feasibility studyPermitting
Environmental approval
Equipment purchase and delivery
Site preparation and construction
Start-up
Short-range and long-range
production plan
Cash flow
Revenue
Capital
Labor
Operating costs
Royalties
Taxes
Evaluation
Risk reward
Net present value
Internal rate of return
Source: Hrebar and Atkinson 1998
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 87
(including major equipment purchases, infrastructure expan-
sion, reserve expansion, acquisition of new reserves, mine
permit acquisition, and end-of-life reclamation). Long-term
mine plans usually cover a period greater than a year beyond
the current active operations, up to and including the point
when the life-of-mine plan starts. Typically, these long-term
mine plans are broken down into levels of detail that include
quarterly plans for up to 5 years, annual plans out to a mini-
mum of 10 years, and general plans out to the life-of-mine
planning horizon. Other applications of long-term planning
are to determine production sensitivity to revenues and costs
(which would affect production rates), capital projects, and
the life of the reserve. Both short- and long-term mine plans
are decision tools to help manage the risk and reward opportu-
nities that confront mine management.
Risk and Reward
The successful implementation of a correctly formulated mine
plan will yield the optimal recovery of the resource, as mea-
sured by optimizing the resulting revenues (reward) and effec-
tively controlling costs (risk). Costs for a new property can
vary substantially because of unknown conditions. It is the
mining engineer’s task to identify and characterize key condi-
tions and factors and to assign costs to them that realistically
represent the risks involved in developing and safely mining
the reserve. It is also the mining engineer’s function to get the
most value from the reserve by using proven methods to mine
and produce the resource in a timely manner. Determining the
time value of money—or the NPV of a project—is the most
common method of measuring the economic balance between
risk (costs) and reward (revenues) for a mine development
project:
i1NPV cash flows
t=
+^ h (EQ 1)
where
 NPV = net present value
 cash flows = net cash flows at time t
 i = discount rate
 t = time of cash flow
A base-case mine plan is typically developed to identify
and quantify the costs and revenues associated with develop-
ing the property. Successive planning scenarios are usually
developed to evaluate the cost/revenue effects of changing
mine plan layout, sequencing, production schedules, equip-
ment, or other parameters to minimize cost impacts and maxi-
mize the resource recovery and revenues to optimize NPV.
This process is a daunting one but is nevertheless a necessary
task, and as multiple plans are developed and evaluated the
what-if scenario begins to gel into a solid base-case plan.
Table 2 Major steps in surface mine development preceding production buildup and full production
Assembly of
Minable Coal
Package
Market
Development
Environmental
and Related
Studies
Preliminary
Design, Machine
Ordering NEPA Process Permits
Design and
Construction
Mining
Preparation
Lease
acquisition
Mapping the
area
Drilling
program
Surface
drilling rights
acquisition
Drilling,
sampling,
logging,
analysis
Mineral
evaluation
(determination
on commercial
quantities
present)
Drilling on
closer centers
(development
drilling)
Sampling,
logging
analysis
Surface
acquisition
Market survey
Potential
customer
identification
Letter of intent
to develop and
supply
Contract
negotiation
Initial
reconnaissance
Scope of work
development
Consultant
selection
Implementation
Environmental
impact report
Environmental
monitoring
Conceptual
mining
development
Economic size
determination
Mining system
design,
layout, and
development
Equipment
selection
Stripping
machine
ordering
Mine plan
development
Identification
of lead agency
for EIS
Draft EIS
EIS review and
comments
EIS hearing
and record
Federal EIA
review
Council on
Environmental
Quality filing
Mining and/
or reclamation
plan approval
State water
well rights
appropriation
permits
State special
use permit,
such as a
reservoir
State mining
permit
State industrial
siting permit
Federal NPDES
permit
U.S. Forest
Service special
land use permit
Preliminary
design and
estimation
Material
ordering and
contracting
Water well
development
Access road
and site
preparation
Railroad
construction
Power supply
installation
Facilities and
coal handling
construction
Warehouse
building and
yards
Coal
preparation
and loading
facilities
construction
Overland
conveyor
construction
Stripping
machine(s)
erection
Loader erection
Support
equipment
readying
Labor
recruitment and
training
Source: Jones 1977
Note: EIA = environmental impact assessment; EIS = environmental impact statement; NEPA = National Environmental Policy Act of 1969;
NPDES = National Pollutant Discharge Elimination System.
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
88 SME Surface Mining Handbook
OUTLINING RESERVES
Project mapping often begins with a general location map that
shows geopolitical boundaries, towns, roads, general topo-
graphic features, the mine location, and any nearby residences
or structures. In addition to the general location map, one
should also be aware of any old abandoned or active under-
ground mines beneath the surface mine property.
Mapping
Planning starts with more detailed mapping of topography,
surface drainage features, surface and mineral ownership,
existing facilities and infrastructure, and potential mine area
and disturbance boundaries. Commercial aerial mapping
flights and unmanned aerial vehicles (UAVs or drones) retro-
fitted with GPS and LiDAR lasers can provide accurate digital
images of the terrain and are now easily obtained and inexpen-
sive. The acquired data can be processed into a digital terrain
model and subsequently into a surface contour of the property
to help identify existing structures, facilities, and other sur-
face features. Ground surveys using GPS equipment provide
additional detail and have, in the short time since its incep-
tion, become the basis for the ongoing process of mapping
and documenting mining and related activities. Infrastructure
includes the location of existing features—roads, rail lines,
pipelines, power lines, communication lines and cell towers,
wells, buildings, and structures on and adjacent to the mining
property—that may be used for or affected by mining activi-
ties. It is important to identify not only features related to the
mining activities, but also features and resources that may
require special environmental considerations, such as streams,
ponds, forest land, fire breaks, wetlands, wildlife habitat, and
other protected or environmentally sensitive areas. Initial geo-
logical maps should include surficial geology (outcrops, sur-
face geologic exposures, structural features) and indications
of strike and dip of structures. Maps prepared by governmen-
tal research organizations such as the U.S. Geological Survey
are a typical starting point for new operations. Conversion of
GPS surveys to a geographic information system format allow
the ongoing collection and integration of ownership, environ-
mental, geologic, mine, and reclamation planning and opera-
tional information.
Because modern mapping is computerized, map infor-
mation is developed and saved as individual layers that can
then be selected and combined to produce a range of special-
ized maps. Although it is important to define and establish a
common mapping datum for compatibility, determining a map
scale is not critical because the scale can be adjusted later to
meet map presentation requirements.After a standard map-
ping datum is established, all mapping should be completed
and input to that datum. The mapping datum and coordinate
system should be compatible with the maximum area expected
to be affected by mining and should accommodate both short-
and long-term planning. Documenting the basis for the map-
ping information (metadata) and preserving original data in a
digital format with appropriate backups is important. Access
and ability to change, alter, or delete information on original
data maps should be carefully restricted, and any such altera-
tions properly and securely logged.
Drill-Hole Coverage
Sufficient drill-hole information is critical for the development
of geologic and mine planning models. For example, if a com-
pany has a history of drilling in the area, such as oil and gas
exploration; other mining companies or government research
agencies have drilled in the area, then all known drilling infor-
mation should be reviewed and evaluated for reliability and
content. Field geologist data and drilling and geophysical
information are then consolidated into a geologic computer
model. In a new operation (or one that is expanding into a
new reserve area), a drilling program will be required to col-
lect enough information to adequately evaluate the property. A
resource is typically defined by the level of confidence in the
occurrence and extent of the minable seams. In open pit min-
ing, the terms measured, indicated, and inferred convey both
the extent of drilling and the level of confidence in the reserve
characterization. In surface strip mines, the deposits tend to
have consistent thickness characteristics; therefore, drill spac-
ing for initial exploration often involves a grid spacing of
0.4 to 0.8 km (Figure 1). Areas that require more extensive
drilling (or seismic studies) are seam boundaries, structural
features, and surface disconformities such as valleys, surface
displacements indicating faulting, and depositional uncon-
formities. The greater the variation in reserve characteris-
tics, the greater is the need for increased drilling density or
supplementary data collection. Data quality can be evaluated
and supplemented using geostatistics techniques, which take
into consideration variances in the coal seam when drill data
are being correlated. In operating mines, geologic structure
and coal quality information from the initial drilling program
can be supplemented by performing infill exploration drill-
ing ahead of the active pit areas. Infill drilling refers to drill-
ing additional exploration holes within the initial exploration
drilling grid spacing. Normally, drill spacing for infill explora-
tion drilling is in the range of 122 to 244 m apart (Figure 2).
Figure 1 Initial exploration drilling spacing: undeveloped
area
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 89
This tighter drill spacing will yield a more refined geological
structure and coal quality model. Some mines prefer to obtain
structural and quality information from drilling and blasting
activities in active operating areas. Once a geological model
is developed, the engineer should use the model to become
familiar with the reserve and identify structure, thickness, and
quality issues that may exist in planned mining areas.
Geology to Mine Planning
Using the drill-hole information and surface structural fea-
tures, the geologist develops a geological model. This model
should include seam identification, structure, thickness, qual-
ity, and characteristics that may affect mining efficiency such
as overburden or interburden thickness and characteristics,
fracturing, variations in thickness, washouts, and water table.
The engineer should be looking for inconsistencies in qual-
ity and thickness to determine the extent of minable seams
and the mining characteristics that would affect equipment
selection and productivity. It is also important to understand
overburden, interburden, and floor characteristics and struc-
tural constraints as indicators of potential stability prob-
lems. Information on highwall angle and spoil angle can be
estimated by material type and stability characteristics from
geotechnical analysis. Thickness, strike or dip, strip ratio, and
quality maps should be developed for all potentially minable
seams. This can either be a fairly straightforward process, or
more complex and time-consuming if seams combine and
split. Transitioning from a geological model to a mining model
requires the understanding of reserve characteristics, potential
structure hazards, equipment capabilities, and strip mining
methods. Geological cross sections, history and knowledge
of the area, research on similar deposits, and knowledge of
mining methods are all resources the engineer can use to opti-
mize mine planning.
The basis for a good mine plan is a good understanding
of the topography and geology of the property. To facilitate
this, there are numerous geologic and mining computer soft-
ware programs that can produce accurate topographical maps
based on aerial and land survey data information that cover
all of the projected mining area along with potential facili-
ties and any significant surface structures. Most topographical
surfaces are normally stored electronically as a grid or trian-
gulated irregular network (TIN) file. In addition, it is neces-
sary to become familiar with seam characteristics, structure,
and the quality information for each minable seam (referred to
as target seams). Contour thickness maps (also known as iso-
pach maps) should be generated for each of the targeted seams
and should include information on overburden, interburden
(waste material between targeted seams), and the undiluted
thickness of the targeted seams. Quality maps (sometimes
called isopleth maps) should also be created for each targeted
seam. Geologic structure maps (also known as contour maps)
need to be developed to identify any structures (e.g., faulting
and offsets) that would affect the mining method or decrease
recovery and increase dilution and waste.
Coal loss due to ribs, barriers, top or bottom of coal seam
dilution, and overblasting can be as high as 10% in eastern
U.S. operations (Secor et al. 1977).
Reserve Evaluation
Modern mine planning starts with a computer model of the
resource. The extent, structure, quantity, and quality of the
resource and the associated burden material should be well
defined. These data allow the engineer to develop a mining
model. The mining model will incorporate and consolidate
data of the resource into a model of minable seams, waste, and
soil materials (sometimes referred to as suitable plant growth
material or topsoil). For this purpose, a reserve is identified as
a resource that is delineated by its economic strip ratio.
Strip Ratio
The economic stripping limit is usually the first factor to
be determined in establishing the mine plan. The economic
stripping ratio (ESR) is defined as the cubic meters of waste
material to be removed to uncover 1 t (metric ton) of product.
For illustration purposes in this chapter, coal will be used as
the resource. Developing maps that show the ratio of over-
burden thickness to a minable coal thickness is a good place
to begin. This ratio can be converted to a strip ratio map by
mapping the thickness of the overburden and interburden
converted to cubic meters and divided by the thickness of the
coal converted to metric tons. This ratio is calculated using
the cumulative thickness of both overburden/interburden and
coal seams down to, and including, the lowest minable seam.
For example, for a 61-m cumulative overburden/interbur-
den thickness with a total coal thickness of 6.1 m, and assum-
ing the average density of bituminous coal at 1.28 t/m3, the
stripping ratio would be calculated as follows:
burden = 61 m × 0.91 m × 0.91 m = 51.0 m3
coal resource= 6.1 m × 0.91 m × 0.91 m × 1.281 t/m3
= 6.47 t
or
Figure 2 Infill exploration drilling spacing
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
90 SME Surface Mining Handbook
stripping ratio = 51.0 m3 ÷ 6.47 t = 7.88:1 (EQ 2)
These calculations can be used to define an economic
limit:
• Cost for overburden/interburden mining is $1.63/m3
• Cost of coal mining is $2.76/t
• Estimated revenue is $13.23/t
The economic stripping ratio is defined as
RESR MCO
MCC= − (EQ 3)
where
 ESR = economic stripping ratio (m3/t)
 R = revenue from coal or ore ($/t)
 MCC = mining cost of coal or ore ($/t)
 MCO = mining cost of overburden/interburden/waste ($/m3)
($13.23/t – $2.76/t) ÷ $1.63 = 6.41 or 6.41:1
The ratio becomes the economic mining limit and is the
first step in establishing the economically minable reserve.
The formula can become more complex as issues of quality
affect the economic value of the coal. It is important for the
engineer to understand the mining economics and contract
restrictions, including coal quality penalties and bonus provi-
sions (such as lower ash and sulfur, and higher BTU content),
may affect revenues. Other adjustments to coal recovery (and
actual minable reserves) would be dilution and in-seam losses,
which tend to downgrade the stripping ratio by increasing the
cubic meters of waste and decreasing the number of metric
tons of resource. Depending on mining conditions and thick-
ness and quality of the seam, losses can amount to several
percent and have a significant impact on the reserve.
RESOURCE CONTROL
Ownership of land and minerals is a key consideration that
should be addressed and determined early in the planning
process because it can affect development time frames, per-
mitting requirements, development cost structure, and project
profitability.
Land and Mineral Ownership
Land ownership typically consists of two components: the
surface estate and the mineral estate. Either or both may be
held by private (fee estate) or public (public estates are gener-
ally managed by federal or state agencies) entities. In some
cases, the surface and mineral estates may be held separately
(severed estate).
The rights to access and utilize the surface and to develop
and produce the mineral resource can be secured through
direct ownership (purchase of the surface and/or mineral
estate), lease agreement, or a combination of these legal vehi-
cles. In the instance of federally managed public estate coal,
a company with a proposed coal lease must submit its request
to acquire the lease with the Bureau of Land Management
(BLM) through a lease by application. The BLM then per-
forms an environmental assessment study and establishes coal
lease market value and sale criteria. Interested companies that
can mine the coal lease economically must submit competitive
bids and the BLM awards the coal lease to the highest bid-
der. The successful bidder must pay a bonus bid for each ton
of coal in the lease. In many cases, the right to develop and
produce the mineral resource (particularly where public estate
minerals are involved) carries with it certain rights of sur-
face access and use. However, there may be instances where
the surface is privately owned and the coal beneath publicly
owned or vice versa. In either case, lease agreements will need
to be developed and agreed upon by both parties.
With the exception of direct ownership, other access and
development rights typically involve structured payments
to secure and exercise these rights. These typically take the
form of advance payments to secure the rights, flat-rate annual
fees for use of the lands, royalty payments based on mineral
production rates, fee payments keyed to specific activities, or
combinations of these payment mechanisms.
Secure, well-defined access and development rights are
an important element of a stable cost structure and are key to
project cost control and profitability. Also, ownership rights
for the project area and an adjacent buffer zone can be impor-
tant in minimizing and successfully addressing potential con-
flicts with adjacent landowners and uses.
Other Resources
In Wyoming (United States) during the 1990s and 2000s, gas
collected from coal seams (i.e., coal-bed methane) became a
significant consideration relative to permitting and the timing
for development of coal reserves where both (independently
recoverable) resources exist. Existing oil and gas (or other
mineral) leases must be a consideration in the extent of and
timing for development and production of reserves because
most of these wells will need to be purchased to mine through
them or the well bypassed altogether.
PERMITTING
Mine permitting is the process of preparing and submitting
relevant project information for review and approval by
jurisdictional government authorities to verify project plan
compliance with applicable laws and regulations. In general,
applicable laws and regulations as they relate to mining are
designed to prevent, control, minimize, or effectively mitigate
potential adverse mining-related impacts on the environment,
wildlife, and human health and welfare.
Mine permitting may involve submittal of individual
permit applications for approval of specific mining-related
activities (mining and reclamation, air emissions, water dis-
charge, wildlife surveys, facility construction, and so on).
Alternately, it may involve environmental analysis and plan
approvals for the project as a whole or a combination of all
these approval mechanisms may be involved. An outline of
typical mine permitting requirements is provided later in this
chapter.
Typically, the process involves a review by national or
state/provincial agencies that have approval authority over
land uses or mining and reclamation plans. It may also involve
review by agencies with authority over specific environmental
resources such as air, water, wildlife, and other specific project
aspects. Normally, some provision is provided in the permit-
ting process for input by affected parties and nongovernmen-
tal organizations.
Environmental Baseline
At the start of the permitting process, it is important to effec-
tively characterize environmental resources and values as they
exist in the project area (this is the baseline) prior to min-
ing disturbance. Generally, baseline characterization involves
field studies by qualified professionals of all resources and
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 91
values that may be affected. The following resource values
are typically characterized:
• Land use
• Cultural, archaeological, and paleontological resources
• Geology
• Meteorology and air quality
• Surface and groundwater hydrology
• Soils
• Vegetation and wetlands
• Fish, wildlife, and related habitat values
• Aesthetics and noise
• Socioeconomic conditions
Baseline characterization then forms the basis for devel-
opment of specific measures to prevent, control, minimize, or
mitigate the potential impacts and for the evaluation of poten-
tial mining-related impacts with consideration of planned con-
trol and mitigation measures.
Mitigation Plans
At the point in a project at which permitting activities are
initiated, mining and reclamation plans are generally well
defined, including the locations, extent, and nature of surface-
disturbing activities. Comparison of the extent and nature
of mining activities with information from environmental
baseline characterization provides the basis for development
of project mitigation plans. In many cases, required mitiga-
tion measures are defined to some extent by specific regula-
tory requirements. A common example is the requirement for
the collection and treatment of runoff from mine disturbance
areas to comply with effluent standards before water is dis-
charged to natural drainages. To address site conditionsand
constraints or enhance postmining land use, the mine operator
may have an opportunity to develop site-specific mitigation
plans or to modify mitigation plans within the limits of regula-
tory constraints.
Impact Analysis and Monitoring
Environmental impact analysis is an integral part of the per-
mitting process, whether it is the evaluation of regulatory
compliance as part of a permit review or of the significance
of potential impacts.
In the context of a permit review, impact analysis focuses
on whether the proposed mining and related activities (and
planned mitigation measures) meet specific regulatory require-
ments and performance standards.
For environmental factors, impact analysis typically
includes the evaluation of direct, indirect, and cumulative
impacts and assesses whether potential impacts meet an objec-
tive, or indeed the subjective measure of significance.
Prepared and evaluated as part of the permitting process,
monitoring plans provide a mechanism for the direct mea-
surement of impacts on specific environmental resources. If
properly designed and administered, monitoring can identify
significant changes in resource conditions. It can be used to
assess the effectiveness of mitigation measures and the accu-
racy of impact assessments and to modify operating and miti-
gation practices.
Timing
It is critical to allow sufficient time in the project schedule
for project permitting. It normally takes between 12 and 18
months to collect adequate information for the environmental
baseline characterization. Depending on project complexity,
permit preparation may require between 6 and 24 months.
Required agency reviews and approval may extend the over-
all permitting schedule by another 6–24 months. Important
factors in minimizing permitting time frames include ensur-
ing adequate and timely baseline characterization, conduct-
ing effective ongoing communication with stakeholders, and
coordinating closely with jurisdictional agencies.
INFRASTRUCTURE
Existing infrastructure (i.e., roads, water wells, oil or gas
wells, pipelines, phone lines or power lines that run through
the property) must be identified and mapped. The landowners
must be contacted and be informed of the intent and potential
impacts of mining.
Existing Infrastructure
Where existing infrastructure may be affected by mining, mit-
igation action may be necessary, either in the form of compen-
sation or relocation/replacement of the structures.
Mine Infrastructure
The necessary infrastructure to support mining and related
operations will need to be planned, developed, and accounted
for in the economic evaluation process. This infrastructure
will include roads and utilities, office and change-house facili-
ties, warehouse and maintenance facilities, material handling,
processing and product transportation facilities, drainage and
sediment control systems, and so forth.
Infrastructure Mapping
Maps showing both existing and planned mine infrastructure
are typically developed as part of the mine planning process.
Features that will be mined around or that are not within the
mining area are not shown on the reserve map. Some struc-
tures require economic analysis to determine whether min-
ing around or compensation, relocation, or replacement is the
better economic approach. These areas may be included in
the reserve, but until the status of the areas is resolved they
should be excluded in the base-case mine plan as non-minable
reserves.
PIT DESIGN
For surface strip mines, the choice of mining method is dic-
tated by the terrain, geology, and depth of the resource. The
terms contour mining and area mining are used to describe
mining methods that are suited to specific geologic and topo-
graphic conditions.
Mining Methods
Where the terrain is variable and multiple seams are present,
contour mining may be the best option. In the Appalachian
mines of the United States, thin seams, undulating topography,
and sometimes steeply dipping seams require equipment that
is highly adaptive and mobile and can move material relatively
long distances. These conditions favor contour mining using
large-tracked dozers, rubber-tired scrapers, truck and shovel
or loader-truck equipment fleets, and occasionally small drag-
lines (23–35 m3). As the ESR increases, contour mining may
be coupled with follow-up to auger, highwall mining or with
conventional underground methods.
Where the terrain is relatively uniform and the seam
or seams are flat lying, area mining is often the preferred
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
92 SME Surface Mining Handbook
approach. Relatively large flat-lying deposits such as the coal
reserves of Wyoming’s Powder River Basin (PRB), phosphate
deposits in Florida (United States) and the Middle East, and
the Canadian tar sands are well suited to area mining meth-
ods using large draglines (46–120 m3), fleets of large-scale
shovel trucks (shovel capacity 46–76 m3; truck capacity
140–230 m3), or even bucket-wheel excavators (BWEs) and
cross-pit conveyor systems. Using large stripping equipment
and moving large quantities of material keeps unit operating
costs to a minimum. The PRB mines initially commenced in
the mid-1970s because of the Organization of the Petroleum
Exporting Countries (OPEC) oil embargo. They started at the
coal seam outcrop and were typically mined at a 1:1 stripping
ratio up until the 1980s; however, by the 1990s the stripping
ratio had increased to more than 2:1 and at present the strip-
ping ratio is more than 3:1. As mining progresses to the west,
the stripping ratio increases as the coal seams dip between 1%
and 2% to the southwest and the overburden gets thicker. This
increase in strip ratio is also reflected where split seams occur.
Coal quality also increases from north to south, which can
have a significant effect on the ESR. Changes in geology must
be taken into consideration in pit design and equipment selec-
tion. Bise (2003) gives several examples of equipment selec-
tion. Bucyrus-Erie Company (1979), Caterpillar Performance
Handbook (Caterpillar, Inc. 2018), and Specifications and
Applications Handbook (Komatsu 2013) are good sources of
information on shovel and truck selection and operation.
Large electric shovels are used in both contour and area
mining. They offer good flexibility, reasonable mobility, and
moderate to high loading capacity, and they can be used for
both stripping overburden and ore loading. However, electric
shovels do require a truck fleet, along with associated support
equipment (dozers, blades, and water trucks) and haulage-
road requirements, which can increase production costs.
Draglines are high-production machines used to strip and
move overburden over short distances. Draglines have limited
mobility and are generally not suited for loading product. It
can take up to a year to construct a dragline, and its cost can
range from $50 to $100 million. Nevertheless, draglines are
dominant in the large surface coal mines in the United States
and in other large flat-lying deposits throughout the world
(Cassidy 1973).
In the lignite mines of Europe and the U.S. Gulf Coast,
large BWEs and conveyor-belt systems are used to excavate
and move large volumes of overburden and product economi-
cally. The BWE is a continuous-excavation machine capable
of removing up to 240,000 m3 of material per day. BWEs are
found mostly in coal mining in Europe, Australia, and India.
A BWE can cost more than $100 million and take 5 years to
construct.
A compilation of equipment application and various
mining scenarios as applied at operating properties can be
found in Chironis (1978) and Kirk (1989). Support equip-
ment including drills, dozers, scrapers, loaders, graders, water
trucks, and—depending on individual mine requirements—a
multitude of other equipment required to complete the min-
ing cycle is a significant capital and operatingcost. Sources
for accounting for this equipment include vendor publications
such as the Caterpillar Performance Handbook, Edition 48
(Caterpillar, Inc. 2018) and vendor websites.
Cast blasting is a technique generally used in combination
with dragline operations to increase overburden production
capacity and reduce costs. Occasionally truck and shovel,
dozers, and scrapers are used in lieu of draglines. Cast blast-
ing utilizes the blast energy and gravity to move a portion of
overburden from the highwall side of the pit into the previous
empty pit and against the previous spoils. The portion of the
overburden that is not casted onto the empty pit is then moved
onto the spoils using the dragline effectively, thereby reduc-
ing overall dragline production and rehandling requirements.
However, the effective design and control of blasting is impor-
tant to maximize overburden movement while preventing loss
of the underlying resource, particularly in multiple-seam pits.
Highwall mining is a method of increasing coal recov-
ery in a pit where the stripping ratio has reached its economic
limit and surface operations are no longer cost-effective. Two
types of highwall mining are commonly used: auger min-
ing, in which a large-diameter auger bores parallel holes into
the exposed coal seam; and conventional mining, in which a
remote-controlled continuous miner, coupled with an exten-
sible conveyor, extends parallel entries into the exposed coal
seam. For highwall mining to be effective, the key criterion is
that the coal and surrounding rock must be competent to be
self-supporting when a portion of the coal seam is removed.
Geotechnical calculations determine the size and allowable
depth of the auger or miner entries. Recoveries above 50%
are possible with augers as large as 2.4 m in diameter, and
conventional methods can result in slightly higher recover-
ies. Experience has shown that highwall mining is not well
adapted to steeply dipping seams.
Pit Geometry
After the boundary of the minable reserves is established, the
geometry and structure of the reserve dictate pit orientation
and configuration. When the pit orientation is laid out, the
mapped dip and strike of the seams and any geological struc-
tures such as faulting or discontinuities should be taken into
consideration. Geotechnical evaluations provide additional
valuable information for determining highwall and spoil slope
angles, slope angles for waste and soil stockpiles, pit-end and
interbench slope angles, and the overall highwall angle for
multiple-seam operations.
For both planning and operations tracking and reporting,
a standard naming convention should be established for desig-
nating and referring to specific mining areas, pits within each
mining area, and cut sequencing within each pit. This nam-
ing convention should designate and explain mining units to
be used in the scheduling process. The width and length of
the pits are typically constrained by the pit geometry, physical
limitations of the equipment (e.g., dragline reach), and the tar-
geted production rate required. Pits are generally broken down
into strips and mining blocks based on both production sched-
uling considerations and the accuracy required for reporting
volumes. Each mining block should contain information such
as area, overburden thickness and volume, coal thickness and
tonnage, and coal quality. Short-term planning often requires
smaller blocks (i.e., 60 × 60 m), depending on drill spac-
ing and quality variations. A smaller mining block provides
increased accuracy relative to production volumes and qual-
ity. Long-term planning does not require the same accuracy,
so larger mining blocks may be acceptable (i.e., 250 × 60 m),
thereby reducing data requirements and the amount of time
required to input and analyze the data for mine scheduling.
Points to consider when developing the design of mine
pits include the following:
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 93
• Orientation of the pit with respect to the strike and dip
of the seam and site topography. Pits with inside curves
result in insufficient spoil room and additional rehandle
and should be avoided. Outside curves create additional
spoil room and provide for spoil-side access to the coal
seam. Similarly, mining up-dip creates more spoil room
and reduces the potential for spoil failure. If the terrain
is relatively flat, straight pits usually give better control
over the pit and tend to result in better productivity.
• Prominent structural features, such as faulting,
along with intersecting drainages and groundwater.
A groundwater dewatering system, such as drilling wells
ahead of the active pits, may be required to reduce the
impact on highwall stability. The water produced from
dewatering wells can later be used for dust suppression
on haul roads and while drilling on blast patterns.
• Length and width of the pit. Generally, a maximum pit
length of 1.6 km (1 mi) is a good rule where ramp access
to the pit floor is sufficient. Most ramps are spoil side, but
there are occasions when highwall ramps and drilling and
blasting ramps are required. Minimum pit width is driven
by the depth of the pit and equipment clearances needed
in the pit bottom. There generally needs to be sufficient
width in the bottom of the pit to operate coal-loading
equipment with truck and drill access. Keeping the pit
width to a minimum is necessary to minimize rehandling.
• Haul access. This consideration of pit design should provide
sufficient room for drilling, blasting, and coal extraction.
Intermediate spoil ramps, usually at least one per pit, are
required to access the pit bottom from either side of the
main haulage ramp. Pit-end ramps are also a consideration,
so that coal extraction, drilling, and blasting are not cut off
by overburden operations. Haulage access design becomes
more complex for multiple-seam operations.
• Highwall and pit-end ramps. These are used when spoil
material is unstable. The disadvantage of highwall ramps
is that the ramp must be re-established after each cut,
and the main haul road requires relocation when mining
advance encroaches on the existing haul road.
Rehandle
Rehandle is defined as material that is moved more than once
to uncover the same amount of resource. A normal amount
of rehandle for a dragline is 10%; however, this depends on
the dragline mining method. Some circumstances require
increased rehandle, such as when pit width and/or overbur-
den depth is greater than the average design for the equipment
being used. In such cases, rehandling material may be more
cost-effective than purchasing additional equipment or using
equipment that is more costly on a unit production basis. When
rehandle costs and volumes for major production equipment
increase beyond normal limits, the availability and effective
productivity of the equipment for stripping is decreased.
Utilizing truck and shovel prestripping on a dragline pit may
decrease rehandle significantly, resulting in additional strip-
ping capacity but increasing total stripping cost. Managing
rehandle becomes a trade-off between production capacity
and lowest-cost utilization of the equipment.
Another source of high-dragline rehandle occurs when
draglines have to mine across a coal ramp. As the dragline
approaches the ramp, it becomes difficult to spoil the overbur-
den material in front of the ramp to its final spoil destination
in a single pass. This material must temporarily be dumped
on the ramp and subsequently rehandled for final spoiling. In
many cases, this inefficiency is reduced by removing some of
the rehandle material with truck and shovel or loader-truck
assistance.
Unnecessary rehandle can occur when stockpiles are
placed too close to the active pit or when production schedul-
ing requires rehandle of stockpiled material. Spoiland high-
wall failures, which can also result in unnecessary rehandle,
may result from poor maintenance of the pit bottom (i.e., large
amounts of standing water), stacking spoils too high, high-
wall/spoil angles that exceed design parameters, or weak floor
structure. An elevated water table, water in the pit, and poor
surface-water drainage can all greatly influence highwall and
spoil stability. Unplanned rehandle is an unnecessary cost that
can have a direct impact on production cost.
Mining Sequence
For a new property, the mine planning process comprises set-
ting a target production, selecting the equipment necessary to
meet that production rate, and running a projected production
schedule to determine the economics of the plan. Production
sensitivities are then run to determine if the plan can be
improved by changing the production level, equipment, pro-
duction sequence, or other preselected parameters. It is not
uncommon, and indeed it is acceptable, to run several itera-
tions to produce an economically optimized mine plan.
For an operating mine, production targets and equipment
fleet may be preset. In such situations, meeting the target pro-
duction rate becomes the focus of planning runs to best fit
adjustments to pit configuration and sequencing to the equip-
ment for a given production rate. In this case, planning options
may include supplementing, replacing, or idling existing
equipment to meet the required production rate. The mining
sequence is considered in the pit design phase.
A typical example of mine sequencing is a dragline oper-
ation initiated with a box cut. In a dragline operation, the box
cut is typically the initial excavation, which creates sufficient
spoil room for the first dragline pit. Figure 3 illustrates three
box-cut scenarios.
A typical mining sequence would involve topsoil removal,
overburden removal, coal removal, backfilling of the resulting
Cut
End Cut
Spoil
A
Seam
A
Overburden
Cut
End Cut with Rehandle
Spoil
Borrow Pit
Spoil
Spoil
A
Seam
A2
A1 Overburden
Cut
Borrow Pit
Spoil
A
Seam
A
Overburden
Source: Skelly and Loy 1975
Figure 3 Box-cut methods
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
94 SME Surface Mining Handbook
pit with overburden spoils, and grading of the spoils to the
final reclamation configuration, followed by reclamation grad-
ing, replacement of soil materials, and revegetation. For most
regulated operations, unless there is a variance in the permit,
soil materials and, in some cases, underlying weathered mate-
rials are stripped and stockpiled for future replacement on
regraded spoil materials. In some cases, these materials can be
directly replaced on existing regraded spoil areas, avoiding the
need for stockpiling and often resulting in better reclamation.
Figures 4A–4G illustrate the steps in a typical dragline
sequence. Figure 4A shows the pit as it would look at the end
of the previous cycle. The coal is extracted and the pit is ready
for the next cut, which is shown by the vertical dashed line.
Figures 4B and 4C illustrate the results of cast blasting on both
the upper and lower seams. Figure 4D shows the upper bench
being graded in preparation for the dragline bench. Figure 4E
illustrates the several phases of stripping that a dragline would
perform; the first is extending the bench to allow the dragline
to walk out far enough to cast the next cut of spoil to build a
spoil-side bench for the dragline to sit on. In Figure 4F, the
dragline is moved to the spoil side, where the bench has been
graded to an elevation that allows the dragline to uncover the
coal seam. Finally, Figure 4G shows the section immediately
before removing the coal, which is the last step in the cycle.
When the coal has been extracted, the cycle is repeated.
The purpose of generating range diagrams (Figure 5) is
to determine the amount of material moved by the production
equipment in each sequential step. These volumes are then
used to determine the productivity of the equipment for that
specific pit geometry. Overburden thickness and changes in
the coal seam geometry can affect the production levels and a
different configuration may be required.
The trade-off with the cast-blasting technique is the loss
of coal and dilution due to fracturing of the coal seam at the
exposed highwall of the pit, sometimes referred to as the wedge
(Figure 6). Other configurations that could be compared to cast
blasting would be a pre-bench truck and shovel or scraper fleet,
depending on the depth of the material above the first seam.
Computer programs that simulate dragline scenarios are
used to generate the equipment volumes needed for scheduling.
By using the volumes and tonnages from the mining blocks and
adjusting the equipment configuration and rate of production
for different geometries and sequencing, a database of schedul-
ing volumes can be generated by pit and equipment type with
rehandle quantities and expected coal production tonnage. Each
scheduled scenario produces operating hours for each piece of
equipment. By using the equipment operating hours and apply-
ing an estimated or historical equipment cost per hour through
an economic model, scenarios are compared to evaluate the
impacts of each on NPV. This process is used in both proposed
and ongoing mine projects to provide justification for equip-
ment purchases and modifications to the mine plan.
Specialized Blasting Techniques
For strip (open-cast) mining, overburden must often be frag-
mented by blasting so it can be efficiently and economically
excavated. For many years, mining engineers have consid-
ered cast blasting (explosives casting) of overburden both to
take advantage of the explosive energy used to fragment the
overburden and to reduce material excavation and handling
costs (Brealey and Atkinson 1968; McDonald et al. 1983).
The low cost and high gas pressures of ANFO explosives
make cast blasting more attractive as a production tool. The
advantages of cast blasting become increasingly significant
for thick overburden with resistant layers requiring high
powder factors (kilograms of explosives per cubic meter of
overburden blasted)—0.65 kg/m3 is typical for some very
strong sandstones, for example, in the United States, South
Africa, and Australia. Applications have shown that in certain
circumstances, cast blasting in deep overburden can be more
economic than conventional stripping. This method, which
is based on reducing the primary overburden removal by the
(A)
(B)
(C)
(D)
(E)
(F)
(G)
Source: Hrebar and Atkinson 1998
Figure 4 Dragline pit sequence cross section
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 95
dragline (Figure 7), has the added advantage of promoting
gravity segregation of the cast material. Large rock fragments
come to rest near the pit floor to form the base of the spoils,
thereby improving spoil drainage and stability. Figure 8 illus-
trates a typical cast blasted profile.
Presplit blasting may be used in conjunction with cast
blasting to dewater permeable overburden and create stable
highwalls. Additionally, in strong ground, a vertical face can be
created in conjunction with cast blasting, rather than the irregu-
lar sloping face produced by conventional blasting (Figure 9).
It is obvious from Figure 9B that the vertical face, with greatly
reduced distance from the front row of blastholes to the toe
of the highwall, will result in far more efficient cast blasting.
However, cast blast patterns using angled blastholes (Figure 10)
tend to produce more casting distance (projectile effect) than
cast pattern using vertical holes (toppling effect). In cast blast-
ing, rows of blastholes parallel to the highwall are detonated
sequentially, initiated from the highwall progressively from
front to back, resulting in maximum overburdencast across
the pit. Experience shows that marginally more overburden is
Figure 5 Dragline range diagram
Cast Pro�le
Coal
Wedge
Cast-to-Final
Coal
Overburden
Figure 6 Potential coal wedge loss
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
96 SME Surface Mining Handbook
cast using this design, but a section of overburden between the
presplit line and the last row of blastholes may remain in place
(Figure 11). Typically, the first three front rows of a cast blast
pattern will move the most volume of material the farthest to
its final resting location (i.e., cast-to-final). The fourth row and
up to the last row tend not to cast and subsequently the mate-
rial is moved by stripping equipment. Cast blast patterns are
usually designed using a square or staggered pattern. Choosing
which pattern to use is site specific and will need to be tested to
determine which will achieve the lowest blasting cost and the
greatest cast-to-final volume movement.
The geometry of the spoil after cast blasting must be con-
trolled to provide a section suitable for dragline operations
while moving as much overburden as possible across the pit.
The best results appear to occur with about a 30° offset using
a staggered V pattern with relatively long, interrow delays.
Figure 12 illustrates a typical section and the desired sec-
tion. The throw depression can be greater than desirable, and
some minor rehandling of the thrown spoil is necessary to
establish a bench for dragline operations. Depending on the
type of overburden (such as mudstone, sandstone, shale, coal
stringers, or a combination), the spacing-to-burden ratio of
the blasting pattern should be determined using site-specific
geologic factors and requires detailed consideration to control
the trajectory of the thrown spoil. For example, a porous sand-
stone layered with several coal stringers will degrade the blast
energy and not cast as well as a solid hard sandstone, which
will yield a more efficient cast. The presence of coal stringers
and weak layers in the overburden allows the blast energy to
escape rather than confine the blasting gas in the borehole and
may result in a violent blast with undesirable flyrock.
A means of evaluating the feasibility and effectiveness of
cast blasting is the use of the linear relationship of cast volume
to depth/width (d/w) ratio. This is a ratio varying from 0.4 to
0.9, where d is the pit depth from the highwall crest to the bot-
tom of the lowermost seam and w is the width of the exposed
pit bottom (toe of highwall to toe of spoils). Generally, the
Interburden
38 m (125 ft)
Lower Coal Seam
Main Coal Seam
Prime Dragline Burden
Truck and Shovel Prestrip
Blast P
ro�le
27.5 m (90 ft)
30 m (98 ft)
11.5 m (38 ft)
 Section Width 305 m (1,000 ft)
Prime D/L Truck and Shovel Total Spoil
 822,045 358,209 463,837
Spoil Handled Once: 760,254 92%
Rehandled Once: 61,791 8%
822,045 100%
Bank Cubic Yards
Dozer Extended Bench
Courtesy of Mincom, Inc., Denver, Colorado
Figure 7 Typical pit section
Saving in Dragline
StrippingProfile After
Blast B
Profile After
Blast A
Dragline Seat
Spoil Heap
Large Fragments in
Base of Spoil Heap
New Profile
Blast B
Blast A
Source: Hrebar and Atkinson 1998
Figure 8 Blast cast profile
(A)
(B)
Source: Hrebar and Atkinson 1998
Figure 9 Blast cast profile: (A) conventional blasting profile,
(B) presplitting profile
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 97
greater the d/w ratio value, the greater the cast-to-final volume
into the empty pit.
A potential negative side effect of large cast blasts is the
unintended development of ground vibration (depending on
the size of the cast pattern), airblasts, and fumes. If the mine
is located in a remote area this may not be a problem; how-
ever, if the mine is located near towns, inhabited dwellings,
industrial facilities, and such, it may pose an issue. One must
adjust several parameters to resolve such issues; for example,
blast smaller cast patterns (which decreases efficiency), adjust
blast-delay timing (longer delays), avoid cast blasting on
cloudy days to reduce airblasts, or use highly water-resistant
bulk product (to reduce fumes).
Single-Seam, Cross-Pit, Chop-Down Operation
A dragline used in the chop-down mode is about 60% efficient
compared with the conventional drag mode. Bucket mainte-
nance costs are also higher (although this is considerably alle-
viated by the better fragmentation achieved in cast blasting).
The depth/width ratio of the pit should exceed 0.4 for cast
blasting to be considered (i.e., this method is best suited to
deeper pits).
Figure 13 shows the method of operation. The dragline
bench height in Figure 13C can be fixed so that the spoil crests
are essentially level, virtually eliminating the need to grade
the spoil peaks during reclamation. This advantage can only
be fully realized, however, if the height of the dragline bench
above the top of the seam does not exceed the optimum dig-
ging depth. Where this height exceeds the optimum digging
depth, the bucket must be cast and dragged prior to the swing
cycle, thereby increasing cycle times. In these circumstances,
it is usually more economic to level the spoil peaks with either
the dragline (rehandle) or conventional mobile equipment.
The single-seam, chop-down method may be used to strip
seam partings in multiple-seam operations. This operation
results in a reduction of dragline productivity of up to 50%,
but if the ratio of parting to lower seam thickness is low, this
approach can be an economical option.
Two-Seam Method
The steps utilizing cast blasting are illustrated in the following
sequence (refer to Figures 4A–C, and as described previously
in the “Mining Sequence” section):
1. The pit section prior to blasting (Figure 4A).
2. Interburden blasted into the void left after extracting the
mineral from the previous strip. Large rocks will form the
base of the spoil heap and are not handled by the dragline
(Figure 4B).
3. Blasted overburden. The throw depression of the inter-
burden blast is filled by overburden spoil (Figure 4C).
This method results in an increase in dragline productivity
above that of conventional dragline stripping, but insufficient
experience is available in comparable conditions to quantify
this increase. However, other marked advantages include:
• Both seams are exposed, allowing simultaneous seam
recovery. The upper seam can be dozed over the side of
Remains
In Situ
Presplit
Line
Last Row
of HolesProfile
Before BlastProfile
After Blast
Source: Hrebar and Atkinson 1998
Figure 11 Blasting with parallel tie-up
Angled
Drill Hole
Empty Pit
Spoils
Coal
Overburden
Figure 10 Example of a cast blast pattern profile with angled drill holes
Highwall
X-delay
Presplit
Line
Dragline Seat
Rehandle
Actual
Profile
Desired
Profile
Throw Depression
40%
60%
Percentage
Blast Over
1
2
4
6
1 2 3 4 5 6
Source: Hrebar and Atkinson 1998
Figure 12 Blasting method
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
98 SME Surface Mining Handbook
the bench (or by other suitable means) onto the lower
seam, thereby concentrating and simplifying mineral
loading operations and improving blending. The volume
of in-pit exposed reserves is increased, allowing greater
flexibility in operation.
• Spoil stability is enhanced by gravity segregation of the
cast blast materials, with larger durable rock forming a
base for the spoils.
• With both seams exposed simultaneously, additional drag-
line moves and dead-heading can be eliminated or reduced.
• Reduced need to handle durable rock materials with the
dragline can result in reduced bucket maintenance costs.
This method can also be used for single-seam, thick-
overburden applications to eliminatechop-down operations
for upper overburden benches. Where weathered material
exists near the surface, the upper bench can be presplit with
more closely spaced holes than for the lower, more competent
overburden. Provided weathering is not too deep, the upper
bench slope can be increased, up to a maximum of 90° (verti-
cal), because presplitting will limit blasting effects and reduce
drainage concerns.
Highwall
a b c
a
d
b c
Edge of Seam
Throw Depression
Blasted Profile
Optimum Bench Height
Presplit
Line
(A)
(B)
(C)
Source: Hrebar and Atkinson 1998
Figure 13 Cross-pit, chop-down with single-seam method of
operation
Stripping Previously Worked Deposits
In some situations, thick coal seams that have been previously
partially extracted by underground methods (e.g., room-and-
pillar mining) can be economically recovered by strip mining.
In these situations, stability and the safe operation of the drag-
line can be in question where conventional dragline stripping
is proposed. Cast blasting provides an alternative stripping
method for suspect areas where the dragline is not located
over the pillared coal, thereby minimizing stability and drag-
line safety concerns.
Equipment Selection
The following criteria are among those that should be con-
sidered when selecting equipment for a new or expanding
operation:
• The life of the project. Certain capital and operating
cost considerations should be evaluated. Smaller equip-
ment (e.g., scrapers) has lower capital costs but much
higher operating costs, depending on the haul distance
and the unit volume moved. In comparison, draglines
have much higher capital costs and much lower unit
operating costs. For example, a scraper may have a capi-
tal purchase cost of $2 million, with a recurring replace-
ment cost every 5 years, a unit capacity of 23 m3, a life of
35,000 hours, and an operating cost of $0.98/m3 varying
with the haulage cycle. A 115-m3 dragline might have a
capital purchase price of $50 million, an operating cost of
$0.20/m3, and a life of 150,000 hours. It typically will last
for the life of the project, which could be 30 years, with a
single major rebuild costing $10 million.
• Depth and thickness of the seam(s) overburden and
coal, with total depth to last minable seam. Typically,
pits up to 150 m in depth can be surface mined.
• Strike and dip of the property. Is the deposit type more
suited to area mining or contour mining?
• Comparison with similar operations. Consider similar
operations, but do not restrict the decision by existing
convention. In the 1980s, there were only truck and shovel
operations in the PRB. The first dragline was introduced
in 1982, and since then draglines have dominated U.S.
surface mines in Wyoming, Montana, Colorado, Texas,
and North Dakota.
• Combinations of mining methods. This may require an
array of equipment types.
• Equipment type and size. For draglines, evaluate the
equipment type and size by generating range diagrams
from cross sections across the length of the reserve.
Figure 7 (or Figure 5) illustrates a typical range diagram
and the volume distribution. Choose typical cross sec-
tions that represent variations in the reserve. For truck
and shovel operations, bench height and passes per cycle
help to determine equipment matching. Three to five
bucket passes by a shovel to fill a truck is considered a
good match. It will be important to select equipment that
can handle changes in pit geometry.
• Dragline capacity. Multiple-seam operations require
handling of intermittent coal and interburden, which
will impact the productivity of a dragline and require
loader-truck equipment to handle the smaller seams.
Dragline capacity must take into account such production
interruptions.
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
 Strip Mine Planning and Design 99
• Haulage scenarios. Evaluate haulage scenarios for truck
and shovel and scraper operations.
• Cast blasting. Look at the possibility of augmenting pro-
duction with cast blasting.
• Used draglines. Evaluate the market for used draglines
that are currently idle. Finding a dragline that can be relo-
cated for half the cost of a new dragline may fit the mine
plan needs.
All options should be evaluated for the highest NPV and
IRR.
Ground Control and Pit Slope Stability
Effective ground control and planning for pit slope stabil-
ity comprise a two-step process. First, geological structures
and groundwater conditions that may affect stability need to
be identified and characterized. The planning process then
focuses on the proper layout and design of the pit geometry
and mine structures to address site-specific structural and
groundwater conditions.
In addition to adequate exploration drilling, sampling,
and logging to characterize geology, lithology, general struc-
ture, water levels, and reserve characteristics, seismic stud-
ies can prove invaluable in delineating structural features and
characteristics. Groundwater studies can also provide supple-
mental information on groundwater occurrence and flows.
Proper pit layout minimizes exposure of structural uncon-
formities in the pit highwall, provides for effective drainage
of both surface water and groundwater, and avoids geometries
that tend to adversely concentrate ground forces (i.e., noses
or notches). Similar considerations are appropriate for mine
structures, including mine spoils, overburden and waste piles,
tailings facilities, water impoundments, and mine buildings.
For pit slopes and spoil piles, as well as engineered
structures such as tailings facilities and water impoundments,
geotechnical analysis by qualified professionals is appropri-
ate. These analyses assess both static and dynamic (seismic)
stability and are often required by applicable regulations. In
the case of engineered structures, foundation testing is often
a component of the geotechnical analysis and specific recom-
mendations for foundation preparation and drainage measures
are incorporated into project construction plans.
MINE SAFETY
As a critical element of modern mining operations, safety
must be a key consideration in planning all aspects of mine
operations: layout and design of pit geometry and mine struc-
tures and facilities, road design, equipment selection, and
operations planning and scheduling.
Applicable regulatory requirements often factor in safety
as well as environmental considerations. However, effective
protection of worker safety and health requires thought and
effort well beyond the scope of regulations. For this reason,
the planning phase should address both engineered safety con-
siderations (i.e., pit design and equipment safety features) and
safety systems (i.e., worker training, safety awareness, equip-
ment inspection and maintenance, and health monitoring).
LAND RECLAMATION
On completion of active mining operations, whether for an
individual mining area or for the mine as a whole, mine dis-
turbance areas should be returned to a stable condition. The
potential for any short- or long-term adverse environmental
effects or hazards to wildlife and human health and safety
should be minimized, and productive postmining land use(s)
should be supported. After completion of the initial phase
of mine planning and prior to mine permitting, a postmin-
ing topography (PMT) of the mine is developed. A rigorous
review of the PMT is performed by regulatory agencies where
several rounds of revisions and amendments are normally car-
ried out prior to approval.
Once the PMT is approved and the mine has progressed
a few years, the reclamation process of the mine can start by
backfilling the voids with overburden using truck and shovel
material and grading mine pit areas using dozers or scrapers
to near the approved PMT surface. The backfilled elevation is
controlled using a GPS survey crew or equipment fitted with
GPS guidance system. The PMT surface shouldblend with the
surrounding terrain to promote effective drainage.
Once the overburden material is graded to near PMT level
(e.g., 0.6 to 0.9 m below final PMT) the overburden must be
sampled and analyzed for pH levels and other natural occur-
ring elements. If the analysis meets acceptable limits imposed
by the regulatory agencies, replacing stockpiled soil materi-
als (topsoil) can begin. If the overburden sample analysis is
not satisfactory, then overburden material must be removed,
replaced, resampled, and reanalyzed. This process is repeated
throughout all backfilled areas.
Topsoil material for reclamation generally comes from
two locations: stockpiles or topsoil removal ahead of the active
pit mining. If there are no areas available to receive topsoil
directly from pit advancement, then it needs to be stockpiled
for later use. Topsoil stockpile slopes are graded with shal-
low sides (i.e., 3:1 slopes) to avoid erosion due to heavy rain
runoff. Berms and ring ditches are also constructed around
the perimeter of the stockpile to contain the topsoil and avoid
contamination with the surrounding overburden. Seeding of a
topsoil stockpile is required to grow vegetation and maintain
its organic composition.
After a graded area is spread with topsoil, the topsoil
depth and location are measured and recorded. (Generally,
topsoil replacement depth is determined in the approved recla-
mation plan.) Once topsoil replacement depth is achieved, the
topsoil is disked and seeded. A seed mixture that is compatible
with native vegetation species is designated in the approved
reclamation plan and normally targets a higher vegetation
yield than what was originally present during premining. Once
seeding is complete, the vegetation in the area must grow and
thrive on its own without further human intervention (i.e.,
no fertilizers or watering). After a few growing seasons, the
process of monitoring vegetation growth and animal popula-
tion begins: this can take several years. The reclamation of the
postmining land conserves and attracts indigenous and nonin-
digenous animals to the area, hence promoting a sustainable
ecosystem.
As part of the planning process, it is sometimes possible
to enhance the natural conditions and land uses that existed
prior to mining or to make land modifications that may facili-
tate higher and better land uses.
Effective land reclamation can minimize the potential for
any short- or long-term liabilities and maintain or increase
the value of mined lands. Land reclamation is important in
promoting a positive perception of the operator and the min-
ing industry as a whole as being environmentally aware
and responsible.
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
100 SME Surface Mining Handbook
RECENT MAJOR CHANGES
Major changes and developments over the last few years in
terms of strip mining can best be summarized as follows:
• Improved mine planning software on a year-to-year basis.
Most mine planning software programs of today are com-
puter-aided design (CAD) driven with three-dimensional
modeling and visualization. In the past, planning was
more of a two-dimensional modeling system consisting
of data input, black-box calculations, and results.
• Better computers to handle the graphics and calculations
needed in mine planning software.
• Refined data acquisition using GPS survey systems,
LiDAR laser scanners, UAV (drone) with laser or pho-
togrammetry data-acquisition system (although this pro-
duces large electronic files).
• Improved cast blast software design using a CAD system
as well as usage of electronic detonators for precise blast
timing as compared to pyrotechnic systems.
• GPS-controlled equipment with onboard electronic
design plan (for draglines, shovels, dozers, drills, etc.),
which reduces surveyor assistance.
Future Changes for the Next Generation
Major changes and developments for the next generation in
terms of strip mining include:
• Major technological advances for mining equipment
(GPS guidance and tracking systems)
• Introduction of fully functional autonomous/remote-
operated equipment (haul trucks, dozers, drills, blades,
etc.)
• Quicker surveyed field-data acquisition using drones
(field to office)
• Equipment/personnel proximity detection systems (colli-
sion avoidance)
• Equipment operator fatigue monitoring systems (eye
detection/safety)
• Improved equipment communication systems to handle
all equipment monitoring and data gathering
• Opposition to strip mining (coal) due to climate change
ACKNOWLEDGMENTS
The majority of this chapter is based on the excellent chapter
by Jerry M. Nettleton and the late Ernest T. Shonts Jr., which
appeared in SME’s Mining Engineering Handbook, 3rd edi-
tion (Darling 2011).
ABOUT THE AUTHOR
Hector Choy began his career in coal mining as a haul truck
operator and working in the drilling and blasting crew for Teck
Corporation at the Bullmoose Mine in British Columbia. Choy
then attended the British Columbia Institute of Technology
and graduated with a Technologist Certificate in Mining, fol-
lowed by a Bachelor of Science (Mining Engineering) with a
minor in Business Finance from Montana College of Mineral
Science and Technology in Butte, Montana. Thereafter he
joined Shell Mining Company and worked for 3 years in
underground coal with duties including feasibility studies,
underground short- and long-range planning, longwall and
continuous miner panel design, ventilation, roof control, and
hoisting. Choy then transitioned to surface coal mining for
Trapper Mine in Craig, Colorado, where his duties included
haul road design and long-range dragline planning before
he moved to Arch Resources at Black Thunder Mine near
Gillette, Wyoming, where for 28 years he has held a number of
significant positions including pit and engineering supervisor,
and later, short- and long-range planning supervisor.
SUGGESTED FURTHER READING
Brealey, S.C., and Atkinson, T. 1968. Opencast mining.
Mining Engineering 123(12):147–163.
Hrebar, M.J., and Atkinson, T. 1998. Strip mine planning and
design. In SME Mining Engineering Handbook, 2nd ed.
Edited by H.L. Hartman. Littleton, CO: SME.
Kennedy, B.A. 1990. Surface Mining, 2nd ed. Littleton, CO:
SME.
Pfleider, E.P. 1972. Surface Mining. New York: SME-AIME.
REFERENCES
Bise, C.J. 2003. Mining Engineering Analysis, 2nd ed.
Littleton, CO: SME.
Brealey, S.C., and Atkinson, T. 1968. Opencast mining.
Mining Engineering 123(12):147–163.
Bucyrus-Erie Company. 1979. Shovel/truck. In Surface Mining
Supervisory Training Program. South Milwaukee, WI:
Bucyrus-Erie Company.
Cassidy, S.M. 1973. Elements of Practical Coal Mining. New
York: SME-AIME.
Caterpillar, Inc. 2018. Caterpillar Performance Handbook,
Edition 48. Peoria, IL: Caterpillar.
Chironis, N.P. 1978. Coal Age Operating Handbook of Coal
Surface Mining and Reclamation, vol. 2. New York:
McGraw-Hill.
Darling, P.G. 2011. Mining Engineering Handbook, 3rd ed.
Littleton, CO: SME.
Hrebar, M.J., and Atkinson, T. 1998. Strip mine planning and
design. In SME Mining Engineering Handbook, 2nd ed.
Edited by H.L. Hartman. Littleton, CO: SME.
Jones, J.R. 1977. The process of developing a western coal
mine. In 1977 Mining Yearbook. Denver: Colorado
Mining Association. pp. 132–138.
Kennedy, B.A. 1990. Surface Mining, 2nd ed. Littleton, CO:
SME.
Kirk, S.J., ed. 1989. Western Surface Coal Mining. Littleton,
CO: SME.
Komatsu. 2013. Specifications and Applications Handbook,
31st ed. Tokyo, Japan: Komatsu.
McDonald, K.L., Smith, W.K., and Crosby, W.A. 1983.
Productivity improvements for dragline operations using
controlled blasting in a single and multiple seam open-
cast operation at Reitspruit, South Africa. CIM Bulletin
76(851).
Pfleider, E.P. 1972. Surface Mining. New York: SME-AIME.
Secor, E.S., Larwood, G.M., Gupta, A.B., et al. 1977. Coal
Recovery from Bituminous Coal Surface Mines in the
EasternUnited States—A Survey. Information Circular
873. Washington, DC: U.S. Bureau of Mines.
Skelly and Loy. 1975. Economic Engineering Analysis of U.S.
Surface Coal Mines and Effective Land Reclamation.
USBM Contract No. SO 24104. Washington, DC: U.S.
Bureau of Mines.
Stermole, F.J., and Stermole, J.M. 2019. Economic Evaluation
and Investment Decision Methods. Golden, CO:
Investment Evaluations Corporation.
Copyright © 2023 Society for Mining, Metallurgy & Exploration Inc. All rights reserved.
