AC16 Software Engineering

 79
Test # Description Test Data
1 A valid scalene triangle. a = 2, b = 3, c = 4
2 An illegal triangle with a zero length side. a = 0, b = 1, c = 1
3 An illegal triangle with one short side. a = 1, b = 4, c = 2
4 A valid equilateral triangle. a = 1, b = 1, c = 1
5 A valid isosceles triangle. a = 1, b = 2, c = 2

Q.14 Consider a program which computes the square root of an input integer
between 0 and 5000. Determine the equivalence class test cases.
Determine the test cases using boundary value analysis also.

Ans. For a program that computes the square root of an input integer which can
assume values in the range of 0 to 5000, there are three equivalence classes: The set
of negative integers, the set of integers in the range of 0 and 5000, and the integers
larger than 5000. Therefore, the test cases must include representatives for each of the
three equivalence classes and a possible test set can be: {-5,500,6000}.
Boundary value analysis leads to selection of test cases at the boundaries of the
different equivalence classes. For a function that computes the square root of integer
values in the range of 0 and 5000, the test cases must include the following values: {0,
-1,5000,5001}.

Q.15 For the structural chart given in fig.1 calculate the Information Flow index of
 individual modules as well as whole software.


 Ans:
Module Fan-in Fan-out
Information Flow index of
module(Fan-in*Fan-out)
2
main 2 2 16
A 2 2 16
B 2 2 16
C 2 1 4
l 0 1 0
m 1 1 1
n 0 1 0
x 1 1 1
AC16 Software Engineering

 80
y 1 0 0

 Total information flow = IF (main) + IF (A) + IF (B) + IF (C) + IF (I) + IF (m)
 + IF (n) + IF (x) + IF (y)
 = 16 + 16 + 16 + 4 + 0 + 1 + 0 + 1 + 0
 = 54

Q.16 For the flow graph shown in Fig2, compute McCabe’s Cyclomatic Complexity.


Ans:In this flow graph, Number of regions are 5, hence the Cyclomatic complexity is
= 5
OR
No of edges = 10
No of nodes (N) = 7
Hence Cyclomatic complexity + E-N+2 = 10-7+2 = 5

Q 17 Write a program in C to add two numbers and then calculate the values of the
following software science metrics :
(i) n(vocabulary of a program )
(ii) N (program length)
(iii)V(Volume)
(iv) L(program level)

 Ans Void Main()
 { int i,j,sum
 scanf(“%d%d”,i,j);
 sum = i+j;
printf(“%d” ,sum);}

operators occurrences operands occurrences
main() 1
 i 2
