Management of Severe Botulinum-Induced
Eyelid Ptosis With Pretarsal Botulinum Toxin
and Oxymetazoline Hydrochloride 0.1%
Francesco P. Bernardini, MD; Brent Skippen, MD; Brittony Croasdell, MS;
Jair Mauricio Cerón Bohórquez, MD; Gillian Murray, MD; Karim Sayed, MD;
Lee Walker, MD; Morris E. Hartstein, MD; and for the Complications
in Medical Aesthetics Collaborative (CMAC) Study Group
Abstract
Background: Eyelid ptosis following periocular onabotulinumtoxinA (BoNT-A) treatment is a known complication that can
be frustrating for both patients and practitioners. Iatrogenic blepharoptosis occurs due to local spread of the BoNT-A from
the periocular region into the levator palpebrae superioris muscle. Although injectors should have a thorough understand-
ing of the relevant anatomy in order to prevent it, BoNT-A induced ptosis can occur even in the most experienced hands.
Objectives: The aim of this study was to describe a case series of patients treated effectively with topical oxymetazoline
HCl 0.1% and pretarsal BoNT-A injections in the setting of botox-induced ptosis.
Methods: The study group consisted of 8 patients who had undergone recent cosmetic BoNT-A treatment preceding the
sudden onset of unilateral upper eyelid ptosis.
Results: A diagnosis of severe ptosis (>3 mm) was made in all the cases in this series. Pretarsal BoNT-A injections alone or
in association with topical administration of Upneeq eyedrops (Upneeq, Osmotica Pharmaceuticals, Marietta, GA) signifi-
cantly reversed the ptosis in all treated cases.
Conclusions: This is the first documented case series of patients treated effectively with topical oxymetazoline HCl 0.1%
and pretarsal BoNT-A injections in the setting of botox-induced ptosis. This treatment combination is a safe and effective
option in these cases.
Level of Evidence: 4
Editorial Decision date: March 10, 2023; online publish-ahead-of-print March 21, 2023.
Dr Bernardini is an aesthetic oculoplastic surgeon in private practice in
Genova and Milano, Italy. Dr Skippen is an associate professor, UNSW
Medical School, Wagga Wagga, Australia. Ms Croasdell is the clinical
director of a private practice in Chicago, IL, USA. Dr Cerón Bohórquez
is the clinical director of a private practice in Hamburg-Hafencity,
Germany. Dr Murray is a pharmacist, Institute of Pharmaceutical
Science, Kings College London, London, UK. Dr Sayed is the clinical
director of a private practice in Oslo, Norway. Dr Walker is the clinical
director of a private practice in Liverpool, UK. Dr Hartstein is the
director of ophthalmic plastic surgery, Shamir Medical Center, Zerifin,
Israel.
Corresponding Author:
Dr Brent Skippen, 36 Docker Street, Wagga Wagga 2650, Australia.
E-mail: brentskippen@gmail.com;
Instagram: @cmac
Cosmetic Medicine
Aesthetic Surgery Journal
2023, Vol 00(0) 1–7
© The Author(s) 2023. Published by
Oxford University Press on behalf of The
Aesthetic Society. All rights reserved.
For permissions, please e-mail:
journals.permissions@oup.com
https://doi.org/10.1093/asj/sjad070
www.aestheticsurgeryjournal.com
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
mailto:brentskippen@gmail.com
mailto:@cmac
https://doi.org/10.1093/asj/sjad070
https://www.aestheticsurgeryjournal.com
Blepharoptosis following periocular onabotulinumtoxinA
(BoNT-A) treatment is a known complication that can be
frustrating for both patients and practitioners. Iatrogenic
blepharoptosis occurs due to local spread of the BoNT-A
from the periocular region into the levator palpebrae supe-
rioris muscle. Although injectors should have a thorough
understanding of the relevant anatomy in order to prevent
it, BoNT-A–induced ptosis can occur even in the most ex-
perienced hands. This complication usually occurs 3 to 14
days after BoNT-A injection and may last up to 2 months.
Until recently, practitioners have treated this complication
with apraclonidine eyedrops, which may help to mask min-
imal asymmetries but are insufficient in most cases of more
severe ptosis. Additionally, there may be nonresponders to
apraclonidine therapy, leaving many cases of ptosis to self-
resolve unpredictably several weeks later, when the para-
lytic effect of the toxin has spontaneously subsided.
Recently, a new topical eyedrop, oxymetazoline hydro-
chloride (HCl) 0.1% (Upneeq, Osmotica Pharmaceuticals;
Marietta, GA), has been approved by the FDA to provide
aesthetic improvement to minimal amounts of involutional
upper eyelid ptosis. Upneeq has been suggested by
Nestor et al as potentially beneficial as a theoretical alter-
native to apraclonidine for improving botox-induced pto-
sis.1 In addition, Mustak et al proposed the use of BoNT-A
to treat mild involutional ptosis by selectively weakening
the pretarsal orbicularis.2 To the best of our knowledge,
this is the first case series of consecutive patients affected
by severe blepharoptosis following periocular BoNT-A
treatment, managed with either pretarsal BoNT-A injec-
tions alone or in combination with topical Upneeq.
METHODS
This review adhered to the standards of the Declaration of
Helsinki and was compliant with the Health Insurance
Portability and Accountability Act, as well as adherent to
IRB approval standards. Written informed consent was ob-
tained for each procedure. All the patients were treated be-
tween March 2021 and December 2022 at different facilities
and included patients referred from elsewhere and patients
who originated in the treating facility. Standardized pretreat-
ment and posttreatment clinical photographs were obtained
for each patient. Inclusion criteria included recent cosmetic
BoNT-A treatment preceding the sudden onset of unilateral
upper eyelid ptosis. Exclusion criteria included patients with
brow ptosis without measurable levator ptosis. All patients
included in this study had a unilateral relative ptosis of
3 mm or more and a margin reflex distance 1 (MRD1) of
2 mm or less. Difference in the MRD1 measurements was
the main outcome measure of the study. Medical records
of the included patients were requested from the treating
practitioners and reviewed accordingly.
RESULTS
Eight patients met the study criteria; all were female.
Patient demographics are summarized in Table 1. The
mean age of the patients was 39 years (range, 31-54 years).
Pretreatment history and review of medical records re-
vealed that BoNT-A was used in all 8 cases. Patient data
along with treatment are detailed in Table 1. Clinical photo-
graphs before and after ptosis reversal are also included. A
diagnosis of severe ptosis (>3 mm) was made in all the cas-
es in this series. Final patient satisfaction with the aesthetic
results in our case series was very high, as summarized in
Table 1. The mean upper eyelid elevation achieved was
3.4 mm. Pretarsal BoNT-A injections alone or in association
with topical administration of Upneeq eyedrops signifi-
cantly reversed the ptosis in all treated cases. Mean follow-
up time was 8 months (range, 6-12 months), and there were
no reported complications.
Case Reports
Case 1
A 49-year-old female was initially treated with 50 units of
BoNT-A (Botox, Allergan, Irvine, CA) (14 units to the frontalis
area, 20 units in the glabella region, and 16 units total to the
lateral orbicularis oculi). The 50 units of botulinum toxin
was reconstituted with 1.25 mL of preserved normal saline.
At the routine 14-day posttreatment follow-up, a mild bilat-
eral brow and severe left eyelid ptosis was observed. Her
MRD1 was 0 mm in the left eye and 4 mm in the right eye
(Figure 1A). Immediate medical treatment consisted of 2
drops of oxymetazoline HCl 0.1% (Upneeq) followed by 2
units of BoNT-A, administered at 2 injection points superfi-
cially, at the medial and lateral limbus line into the pretarsal
orbicularis, using a 1:1 reconstitution. Theeyelid ptosis im-
proved by 1 mm 20 minutes after instillation of the drops
and the remaining 3 mm 10 days after BoNT-A injection
(Figure 1B). No adverse events were reported by the pa-
tient, who applied the drops for a 6-week period. The bilat-
eral asymmetric ptosis fully resolved 8 weeks after the
initial botox treatment.
Case 2
A 31-year-old female was treated with abobotulinumtoxinA
(Dysport, Ipsen, Cambridge, MA) at a resident clinic. The in-
jection pattern reported by the injecting physician was as
follows: corrugators: head and tail separately injected,
1 cm superior to the supraorbital rim, with 9 units
of Dysport to each injection site; procerus: 7 units of
Dysport injected with total glabellar dose of 42 units of
Dysport. The patient experienced right upper eyelid ptosis
5 days after injection. Examination revealed an MRD1 of
1 mm in her right eye and 4 mm in her left eye. Treatment
involved injection of 2 units of BoNT-A, administered at 2
2 Aesthetic Surgery Journal
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
injection points at the medial and lateral limbus line into the
pretarsal orbicularis, using a 1:1 reconstitution. The patient
was also prescribed topical Upneeq. The patient reported min-
imal relief from the topical Upneeq; however, the ptosis was
completely resolved 10 days after the pretarsal injections.
Case 3
A 37-year-old female was injected by her neurologist for
treatment of migraines. The patient reported a 3-point in-
jection technique but was unable to provide the medical re-
cords of the treatment. The patient presented to one of the
authors for correction of her right blepharoptosis. Her
MRD1 was 0 mm in her right eye and 4 mm in her left eye
(Figure 2A). The patient was treated in 2 locations on her
pretarsal orbicularis with 2 units of neuromodulator, recon-
stituted 1:1 at each injection point. The patient was also pre-
scribed topical Upneeq. The patient reported minimal relief
(∼1 mm) from the topical Upneeq and complete resolution
of the ptosis about 15 days after the pretarsal injections.
The image shown depicts the patient 5 days after pretarsal
injections and 2 weeks after pretarsal BoNT-A injections
and topical Upneeq (Figure 2B).
Case 4
A 35-year-old female presented 14 days following cosmetic
botox treatment elsewhere. Medical records from the treat-
ing practitioner showed she was originally injected by a
3-point injection technique to the glabella with an addition-
al 2 injection points in the tail end of the brow for a total of
20 units of BoNT-A. The patient complained of “heaviness”
at Day 5 posttreatment and was retreated with 3 units of
BoNT-A in the midpupillary line, underneath the eyebrow.
The patient began to experience blepharoptosis 7 days af-
ter her second injection. A severe ptosis of her right eyelid
was noted. Her MRD1 was 1 mm in her right eye and 5 mm in
her left eye (Supplemental Figure 1A). Medical treatment in-
volved 2 units total of BoNT-A injected into the pretarsal or-
bicularis with one injection point being at the medial limbus
line and the second at the lateral limbus line. Upneeq eye-
drops were prescribed which provided an immediate
Table 1. Treatment Performed: Results of Topical Oxymetazoline Hydrochloride 0.1% (Upneeq, Osmotica Pharmaceuticals;
Marietta, GA) and Pretarsal BoNT-A Injection
Patient
number
Demographic Initial aesthetic
botulinum toxin
treatment
Ptosis Adjunct
procedures
performed
Eyelid elevation
achieved from
Upneeq (mm)
Eyelid elevation
achieved from
BoNT-A injection
(mm)
Total amount of
upper eyelid
elevation (mm)
Patient
satisfaction
1 49-year-old
female
Botox
(Allergan; Irvine, CA)
Unilateral
(left)
Pretarsal
BoNT-A +
Upneeq topical
1 3 4 High
2 31-year-old
female
Dysport (Ipsen;
Cambridge, MA)
Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
0 3 3 High
3 37-year-old
female
Unknown Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
1 3 4 High
4 35-year-old
female
Unknown Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
1 3 4 High
5 54-year-old
female
Unknown Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
0 3 3 High
6 40-year-old
female
Unknown Unilateral
(left)
Pretarsal botox
+ upneeq
topical
0 3 3 High
7 44-year-old
female
Dysport Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
0 3 3 High
8 47-year-old
female
Botox Unilateral
(right)
Pretarsal
BoNT-A +
Upneeq topical
1 2 3 High
BoNT-A, onabotulinumtoxinA.
Bernardini et al 3
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
positive effect of 1 mm. The patient’s results are shown 2
weeks after injections (Supplemental Figure 1B).
Case 5
A 54-year-old female presented with a total right upper
eyelid ptosis 4 days after being injected elsewhere
(Supplemental Figure 2A); the patient was being treated
with Upneeq eyedrops at the time of presentation without
any significant beneficial response. The patient underwent
pretarsal BoNT-A injection using 4 units total in 2 injection
points (2 units medial limbus line and 2 units lateral limbus
line) with 1:1 reconstitution. The patient presented 4 days af-
ter pretarsal BoNT-A treatment with a significant improve-
ment and almost complete resolution of the ptosis; the
topical Upneeq treatment was suspended and the patient
returned 2 weeks after injection with complete resolution
of the ptosis (Supplemental Figure 2B).
Case 6
A 40-year-old female was injected by another practitioner
and presented 15 days following treatment. Medical re-
cords from the treating practitioner did not record the total
dose of BoNT-A administered. A severe ptosis of her left
eyelid was noted. Her MRD1 was 1 mm in her left eye de-
spite topical Upneeq treatment and 4 mm in her right eye
(Supplemental Figure 3A). Treatment consisted of a left up-
per eyelid pretarsal injection of 2 units of BoNT-A in the line
of the medial limbus and 2 units of BoNT-A in line with the
lateral limbus. Clinical photographs were taken before
treatment and 10 days later, and showed complete reversal
of the ptosis (Supplemental Figure 3B).
Case 7
A 44-year-old female was injected by an outside practition-
er and presented 14 days following treatment. Medical re-
cords from the initial treating practitioner noted that a
total of 125 Speywood units of Azzalure (Dysport) were
used in the periocular region. She presented with complete
ptosis of the left eyelid and also felt that she was “over-
frozen” in the forehead, lateral orbicularis oculi and glabella
regions. She was being treated with topical Upneeq, but
without substantial benefit. She was subsequently treated
with a left upper eyelid pretarsal injection of BoNT-A, 2
units in line with the medial limbus and 2 units in line with
the lateral limbus. Clinical photographs were taken before
treatment and 13 days after injection (Supplemental
Figure 4). There was full resolution of the eyelid ptosis fol-
lowing the pretarsal BoNT-A injection. No adverse events
were reported and the patient was satisfied with the
outcome.
Case 8
A 47-year-old female patient was treated with approximately
150 units of Allergan Botox by a neurologist. Exact injection
points were not recorded; however, several injections points
werein the lower 2 cm of the forehead and the lateral corru-
gators were also injected. After 5 days, a significant right up-
per eyelid ptosis had developed, with an MRD1 of 1 mm. Two
weeks after initial treatment the patient presented with an
MRD1 of 1 mm in her right eye and 4 mm in her left eye
(Supplemental Figure 5A). Immediate medical treatment con-
sisted of 2 drops of topical Upneeq followed by injection of 3
units of BoNT-A, administered in 3 injection points superfi-
cially (approximately 3 mm medial to the lateral canthus, ap-
proximately 3 mm lateral to the medial canthus, and at the
lateral limbus line) into the pretarsal orbicularis, using a 1:1 re-
constitution. The eyelid ptosis improved by 1 mm 20 minutes
after instillation of the drops and another 2 mm 2 weeks after
the pretarsal injection (Supplemental Figure 5B). No adverse
events were reported by the patient, who used the drops for
a 3-week period.
DISCUSSION
Blepharoptosis, or eyelid ptosis, is not an uncommon com-
plication of periocular botulinum toxin injection and is de-
fined as drooping of the upper eyelid occurring within 2
weeks after the injection. The presumed mechanism of up-
per eyelid ptosis is considered to be the unintended spread
A B
Figure 1. (A) A 49-year-old female with a margin reflex distance 1 of 0 mm in her left eye and 4 mm in her right eye. (B)
Improvement of ptosis 10 days after pretarsal onabotulinumtoxinA injection and topical Upneeq (Osmotica Pharmaceuticals;
Marietta, GA).
4 Aesthetic Surgery Journal
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
of botulinum toxin to the levator muscle.1 The occurrence of
blepharoptosis following toxin injections can be rather
“dramatic” for the affected patient. It has an obviously
prominent negative impact on the patient’s appearance
and can also affect vision and interfere with daily function.3
Various definitions and severity scales for eyelid ptosis
have been suggested in the literature, but in the post–bot-
ulinum treatment setting any eyelid margin alteration or
asymmetry that was not recorded before the treatment is
considered to be significant. Ptosis is considered severe
when it is 3 mm or more. In terms of mechanism of action,
BoNT-A–induced blepharoptosis is classified as neurogen-
ic because it is due to impairment of transmission of electri-
cal impulses at the neuromuscular junction.1
BoNT-A binds to transport proteins in nerve cells and
blocks the release of acetylcholine from nerve endings;
this neurotransmitter is responsible for muscle contraction.
The degree to which injected toxin may overflow from a tar-
geted region to an unintended region is largely determined
by the active physical distribution of toxin suspension or
spread.3 Patient-dependent factors include younger age,
outdoor work life, sun damage, loss of skin elasticity, and
thicker skin.4 Medically dependent risk factors include pre-
vious facial surgical procedures, neurological conditions
such as multiple sclerosis or myasthenia gravis, and prior
history of Bell’s palsy or other induced eyelid ptosis.4 Risk
of ptosis can also be based on the amount of injected bot-
ulinum toxin (units), injected volume (mL), and product type.
It is a widely held opinion that poor injection technique is
a major factor in patients developing ptosis and includes
various combinations of mistakes associated with depth
of placement and administration of botulinum toxin injec-
tion and dosing.4 In a large study, botulinum toxin–induced
blepharoptosis was estimated to occur in 5.4% of patients
treated by inexperienced injectors andjection external to the corneal limbi (medial and lateral) in
a superficial plane (dermal layer) has minimal chances of af-
fecting the levator while maximizing the paralytic effect on
the pretarsal orbicularis. Figure 3 shows the injection sites
in the pretarsal orbicularis of the ptotic upper lid.
The pretarsal orbicularis is the muscle most intimately
connected with automatic eyelid function, responsible for
baseline eyelid closure and blinking. By weakening the
baseline strength of the pretarsal orbicularis the residual le-
vator/Müller complex force is empowered, with conse-
quent restoration of the correct eyelid aperture. In
botox-induced ptosis, it is difficult to gauge how much im-
pact comes from the levator muscle vs Müller’s muscle;
however, it is possible that recovery comes mainly from un-
opposed Müller’s muscle function since the levator is the
directly affected muscle.
Unfortunately, in this series, the levator function was not
measured before or after the occurrence of ptosis and the
subsequent treatment; however, looking at the severity of
ptosis and the temporary loss of the eyelid crease in the af-
fected muscle, it is likely that the levator muscle function is
significantly impaired if not completely blocked, leaving
only Müller’s muscle to elevate the upper eyelid. The timing
and the amount of response that was achieved from topical
treatment and pretarsal botulinum toxin injections clearly
indicates the respective impact of the reversal treatment
proposed herein. Although the effect after instillation of
topical Upneeq can be immediate, usually starting after
20 seconds with a positive impact of no more than 1 mm
of MRD1 gain, the subsequent response, of 2 to 3 mm of
MRD1 gain occurring after 10 to 14 days can be attributed
to the administration of pretarsal botulinum toxin.
Oxymetazoline HCl Ophthalmic Drops
Oxymetazoline HCl 0.1% is the only FDA-approved medical
treatment for acquired blepharoptosis in adults.1,7
Oxymetazoline (Afrin, Bayer AG; Leverkusen, Germany) nasal
spray was originally approved by the FDA more than 50
years ago for the treatment of nasal congestion.8
Oxymetazoline HCl 0.1% elevates the upper eyelid by activat-
ing both α1- and α2-adrenergic receptors in Müller’s muscle.
Common side effects include punctate keratitis, conjunctival
hyperemia, dry eye, blurry vision, eye irritation, and head-
ache. Tachyphylaxis is a known response to treatment with
α-adrenergic agonists but can take many weeks or longer
to develop, a timeline that exceeds the 14 days used to as-
sess treatment efficacy in this study.8
To our knowledge, this is the first documented series of
patients effectively treated with oxymetazoline HCl 0.1%
and pretarsal BoNT-A injections in the setting of botox-
induced ptosis. This study enhances the knowledge base
of management of varying severities of botox-induced pto-
sis. We believe that topical Upneeq alone can be effective
in addressing mild cases of post-botox ptosis of approxi-
mately 1 to 2 mm only, but for more severe cases of ptosis
of 3 mm or more, ie, all those described in this series, pre-
tarsal botulinum toxin injection is the mainstay of treatment.
In severe cases, topical Upneeq could provide a degree of
instant relief until the more definitive action of pretarsal
BoNT-A injections takes effect.
Study Shortcomings
Levator function was not measured at any time after the oc-
currence of ptosis at the time of the original botulinum in-
jection, or during the secondary treatment. Some
degrees of temporary posttreatment lagophthalmos could
be expected after pretarsal injection and might then lead to
corneal exposure with dry-eye symptoms. However, specif-
ic dry-eye parameters were not evaluated in our series.
Figure 3. Injection sites in the pretarsal orbicularis of the
ptotic upper lid.
6 Aesthetic Surgery Journal
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
Since the patients were referred, we can only speculate on
the mechanism for the development of botox-induced pto-
sis. However, no patients in this series complained of dry-
eye symptoms after pretarsal BoNT-A injection.
This study also did not conduct a comparison between the
utility of topical apraclonidine vs topical Upneeq in the set-
ting of botox-induced ptosis. Topical apraclonidine is still
the most commonly used drug for this condition.
Apraclonidine is an α2-adrenergic agonist and oxymetazo-
line is both an α1- and α2-adrenergic agonist. We are not en-
tirely certain as to whether α1-adrenergic agonist effects
might give better efficacy in this setting. This paper does
not offer insights on the potential mechanism of occurrence
of botox-induced ptosis, relative to the amount (units or mL)
and botox type. Potential comparative studies evaluating the
power of apraclonidine vs Upneeq alone and/or in associa-
tion with pretarsal botulinum toxin could establish the real
added value of topical Upneeq in this setting; it would
have been ideal to have a comparative group of patients
similarly affected by botox-induced ptosis treated with pre-
tarsal injection of saline solution to rule out any placebo ef-
fect and statistically measure the real impact on time of
ptosis reversal between the study group and the placebo.
CONCLUSIONS
If the levator muscle is accidentally weakened or paralyzed
by the unintended diffusion of aesthetic periocular treat-
ment by BoNT-A injection, Müller’s muscle action can be bi-
modally potentiated by the direct effect of topical
oxymetazoline HCl 0.1% on the muscle and indirectly by
weakening the baseline force of the pretarsal orbicularis
muscle with pretarsal BoNT-A injections. It is intuitive that
a degree of paralytic lagophthalmos might be expected
to occur due to pretarsal muscle impairment from
BoNT-A injections, although none occurred in this series
of patients. The lack of reported dry-eye symptoms from
all treated patients in this series supports the benefit of re-
versing severe BoNT-A–induced ptosis as the risk of partial
lagophthalmos is low. However, patients need to be specif-
ically informed about this potential risk. In our experience,
this treatment combination is a safe and effective option
in cases of severe botox-induced eyelid ptosis.
Supplemental Material
This article contains supplemental material located online at
www.aestheticsurgeryjournal.com.
Acknowledgments
All authors listed are part of the Complications in Medical
Aesthetics Collaborative (CMAC) Study Group; Francesco
Bernardini, Jair Mauricio Cerón Bohórquez, Brittony
Croasdell, and Gillian Murray are part of the CMAC
International Expert Board. Brittony Croasdell had the original
idea for this paper.
Disclosures
The authors declared no potential conflicts of interest with re-
spect to the research, authorship, and publication of this
article.
Funding
The authors received no financial support for the research,
authorship, and publication of this article.
REFERENCES
1. Nestor MS, Han H, Gade A, Fischer D, Saban Y, Polselli R.
Botulinum toxin–induced blepharoptosis: anatomy, etiolo-
gy, prevention, and therapeutic options. J Cosmet
Dermatol. 2021;20(10):3133-3146. doi: 10.1111/jocd.14361
2. Mustak H, Rafaelof M, Goldberg RA, Rootman D. Use of
botulinum toxin for the correction of mild ptosis. J Clin
Aesthet Dermatol. 2018;11(4):49-51.
3. Nestor MS, Arnold D, Fischer D. The mechanisms of action
and use of botulinum neurotoxin type A in aesthetics: key
clinical postulates II. J Cosmet Dermatol. 2020;19(11):
2785-2804. doi: 10.1111/jocd.13702
4. King M. Management of ptosis. J Clin Aesthet Dermatol.
2016;9(12):E1-E4.
5. Carruthers JA, Lowe NJ, Menter MA, etal. A multicenter,
double-blind, randomized, placebo-controlled study of
the efficacy and safety of botulinum toxin type A in the
treatment of glabellar lines. J Am Acad Dermatol.
2002;46(6):840-849. doi: 10.1067/mjd.2002.121356
6. Bodnar ZM, Neimkin M, Holds JB. Automated ptosis mea-
surements from facial photographs. JAMA Ophthalmol.
2016;134(2):146-150. doi: 10.1001/jamaophthalmol.2015.
4614
7. Ugradar S, Kim JS, Trost N, et al. Changes to eye white-
ness and eyelid/brow position with topical oxymetazoline
in aesthetic patients. Aesthet Surg J. 2022;42(6):582-589.
doi: 10.1093/asj/sjab400
8. Bradley EA, Bradley DJ. Oxymetaxoline for ptosis.
JAMA Ophthalmol. 2020;138(11):1176-1177. doi: 10.1001/
jamaophthalmol.2020.3833
Bernardini et al 7
D
ow
nloaded from
 https://academ
ic.oup.com
/asj/advance-article/doi/10.1093/asj/sjad070/7082917 by O
hio N
orthern U
niversity user on 19 April 2023
http://academic.oup.com/asj/article-lookup/doi/10.1093/asj/sjad070#supplementary-data
http://www.aestheticsurgeryjournal.com
https://doi.org/10.1111/jocd.14361
https://doi.org/10.1111/jocd.13702
https://doi.org/10.1067/mjd.2002.121356
https://doi.org/10.1001/jamaophthalmol.2015.4614
https://doi.org/10.1001/jamaophthalmol.2015.4614
https://doi.org/10.1093/asj/sjab400
https://doi.org/10.1001/jamaophthalmol.2020.3833
https://doi.org/10.1001/jamaophthalmol.2020.3833
	Management of Severe Botulinum-Induced Eyelid Ptosis With Pretarsal Botulinum Toxin and Oxymetazoline Hydrochloride 0.1%
	METHODS
	RESULTS
	Case Reports
	Case 1
	Case 2
	Case 3
	Case 4
	Case 5
	Case 6
	Case 7
	Case 8
	DISCUSSION
	Two-Stage Management of BoNT-A–Induced Eyelid Ptosis
	Pretarsal Botulinum Toxin Injection
	Oxymetazoline HCl Ophthalmic Drops
	Study Shortcomings
	CONCLUSIONS
	Supplemental Material
	Acknowledgments
	Disclosures
	Funding
	REFERENCES
