CHAPTER 4 119

conformation, there is only one Me-Me gauche
interaction.


4.39. Both compounds share the same molecular
formula (C6H14). That is, they are constitutional isomers,
and the unbranched isomer is expected to have the larger
heat of combustion:



4.40.
(a) The name indicates that the parent is a five-carbon
chain and there are three substituents (two methyl groups
at C2, and one methyl group at C4):



(b) The name indicates that the parent is a seven-
membered ring and there are four substituents (all methyl
groups), as shown:


(c) The name indicates a bicyclic parent with two ethyl
groups at C2 and two ethyl groups at C4, as shown:



4.41. We begin by drawing a Newman projection of 2,2-
dimethylpropane:


Notice that the front carbon has three identical groups
(all H’s), and the back carbon atom also has three
identical groups (all methyl groups). As such, we expect
all staggered conformations to be degenerate, and we
expect all eclipsed conformations to be degenerate as
well. Therefore, the energy diagram will more closely
resemble the shape of the energy diagram for the
conformational analysis of ethane.



4.42. Two of the staggered conformations are
degenerate. The remaining staggered conformation is
lower in energy than the other two, as shown:



4.43. For each of the following cases, we draw the
second chair conformation using a numbering system to
ensure the substituents are placed correctly. The
numbering system does NOT need to adhere to IUPAC
rules, as it is just a tool that we are using to draw both
chair conformations correctly. Notice that a ring flip
causes all equatorial groups to become axial groups, and
vice versa.
(a)



(b)
Cl
ClOH
OH
CH3
CH3
1
2
3
4
5 6
3
4 5
6
1
2

(c)


4.44.
(a) The second compound is expected to have a higher
heat of combustion because it has more carbon atoms.
(b) The first compound is expected to have a higher heat
of combustion because it cannot adopt a chair
conformation in which both methyl groups occupy
equatorial positions.
