CHAPTER 17 625

ppm, each with an integration of 2. This is the
characteristic pattern of a disubstituted aromatic ring, in
which the two substituents are different from each other:



The singlet at 3.9 ppm (with an integration of 3)
represents a methyl group. The chemical shift is
downfield from the expected benchmark value of 0.9
ppm for a methyl group, indicating that it is likely next to
an oxygen atom:


The singlet at 2.6 ppm (with an integration of 3)
represents an isolated methyl group. The chemical shift
of this signal suggests that the methyl group is
neighboring a carbonyl group:



The carbonyl group accounts for one degree of
unsaturation, and together with the aromatic ring, this
would account for all five degrees of unsaturation. The
presence of a carbonyl group is also confirmed by the
signal at 196.6 ppm in the 13C NMR spectrum.
We have uncovered three pieces, which can only be
connected in one way, as shown:


This structure is consistent with the 13C NMR data: four
signals for the sp2 hybridized carbon atoms of the
aromatic ring, and two signals for the sp3 hybridized
carbon atoms (one of which is above 50 ppm because it
is next to an oxygen atom).
Also notice that the carbonyl group is conjugated to the
aromatic ring, which explains why the signal for the
C=O bond in the IR spectrum appears at 1676 cm-1,
rather than 1720 cm-1.

17.53.
(a) If we functionalize the benzylic position (via
bromination), the product can be obtained in just one
more step, via a Williamson ether synthesis, as shown:



(b) This transformation requires that we move the
position of the OH group. This was a strategy that was
covered in Chapter 11. Specifically, we saw that the
location of an OH group can be moved via elimination
followed by addition. The first step is to convert the
alcohol into an alkene via acid-catalyzed dehydration
(E1). Then, hydroboration-oxidation will convert the
alkene into the desired alcohol, via an anti-Markovnikov
addition of H and OH across the  bond:


(c) The carbon skeleton is getting larger, so we must
form a CC bond. In addition, we must install a triple
bond. Both of these goals can be achieved via
bromination at the benzylic position, followed by an SN2
reaction in which an acetylide ion is used as the
nucleophile, as shown:




17.54. The molecular formula (C11H14O2) indicates five
degrees of unsaturation (see Section 14.16), which is
highly suggestive of an aromatic ring, as well as either
one double bond or one ring.
In the 1H NMR spectrum, the signals near 7 ppm are
likely a result of aromatic protons. Notice that the
combined integration of these two signals is 4H. This,
together with the distinctive splitting pattern (a pair of
doublets), suggests a 1,4-disubstituted aromatic ring, in
which the two substituents are different:
