606 CHAPTER 17

To see the value of this approach, consider the
following structure and determine how many
signals are expected in the 1H NMR and 13C NMR
spectra of this compound:

H
H3C CH3
H
H3C
H H
CH3


By redrawing the structure with circles to represent
aromatic rings (rather than alternating single and
double bonds), it becomes easier to see that there
are only two unique kinds of protons in this
structure (highlighted below):



This compound will have only two signals in its 1H
NMR spectrum.
Similarly, the compound will have only four
signals in its 13C NMR spectrum:



Throughout the solutions presented in this chapter,
we will often represent aromatic rings with circles
(particularly when symmetry is relevant to the
discussion).


Useful reagents
The following is a list of reagents encountered in this chapter, as well as their specific function in the context of this
chapter:
Reagents Description
Na2Cr2O7, H2SO4, H2O
Sodium dichromate and sulfuric acid give chromic acid, which is a strong oxidizing
agent that can be used to oxidize a benzylic position, provided that the benzylic
position has at least one benzylic proton. The alkyl group (connected to the aromatic
ring) is converted into a carboxylic acid group.
1) KMnO4, H2O, heat
2) H3O+
Potassium permanganate. A strong oxidizing agent that can be used to oxidize a
benzylic position, provided that the benzylic position has at least one benzylic
proton. The alkyl group (connected to the aromatic ring) is converted into a
carboxylic acid group.
NBS, heat
N-Bromosuccinimide. A reagent that is used for radical bromination at the benzylic
position.
H2O
Water is a weak nucleophile that can be used in an SN1 reaction with a benzylic
halide.
NaOH
Hydroxide is a strong nucleophile that can be used in an SN2 reaction with a primary
benzylic halide.
conc. H2SO4
A strong acid that can be used to achieve acid-catalyzed dehydration to give an
alkene.
NaOEt
Sodium ethoxide is a strong base that can be used to convert secondary or tertiary
halides into alkenes (via an E2 process)
3H2, 100 atm, 150 ºC Conditions for complete hydrogenation of benzene to give cyclohexane.
Na, CH3OH, NH3
Reagents for a Birch reduction, which reduces a benzene ring to give a 1,4-
cyclohexadiene ring.
