NOME: Abcdeiver Barbosa Condé
1-
















C1 = ( x1 , y1)
C1 = 55/2 , 15/2 = 27,5 cm ; 7,5 cm

C2 = ( x2 , y2)
C2 = 15/2 , 85/2 = 7,5 cm ; 42,5 cm

C3 = ( x3 , y3)
C3 = 85/2 , 15/2 = 42,5 cm ; 77,5 cm




REC 1
R
EC
 2

REC 3
FIGURA Xi (cm) Yi (cm) Ai (cm²) Xi*Ai (cm³) Yi*Ai (cm³)
REC1 27,5 7,5 55 * 15 = 825 (27,5 * 825) = 22687,5 (7,5 * 825) = 6187,5
REC2 7,5 42,5 55 * 15 = 825 (7,5 * 825) = 6187,5 (42,5 * 825) = 35062,5
REC3 42,5 77,5 85 * 15 = 1275 (42,5 * 1.275) = 54187,5 (77,5 * 1.275) = 98812,5
∑ 2925 83062,5 140062,5

Coordenada x = ∑ Xi*Ai / ∑Ai
= 83062,5 / 2925 = 28,4 cm
Coordenada y = ∑ Yi*Ai / ∑Ai
= 140062,5 / 2925 = 47,885 cm
C (27,4 ; 47,885)

2
Ix (b h^3)/12+A.dy^2
F1) Ix1=(55 (15)^3)/12+825.(40,38)^2=1361001,0356 cm^4
F2) Ix2=(15 (55)^3)/12+825.(5,4)^2=232025,75 cm^4
F3) Ix3=(85 (15)^3)/12+1275.(-29,615)^2=1142142,737 cm^4
Ix=Ix1+Ix2+ Ix3
Ix=1361001,0356 + 232025,75 + 1142142,737
Ix= 2735169,522 cm^4
Iy (h b^3)/12+A.dx^2
F1) Iy1=(15 (55)^3)/12+825.(0,9)^2=208637 cm^4
F2) Iy2=(55 (15)^3)/12+825.(20,9)^2=375837 cm^4
F3) Iy3=(15 (85)^3)/12+1275.(-14,1)^2=1021139 cm^4
Iy=Iy1+Iy2+ Iy3
Iy=208637 + 375837+1021139
Iy= 1605613cm^4
