FERRAMENTAS PARA SYSADMIN
WJ SECURITY
O QUE IREMOS APRENDER
• Configuraçao do Servidor Linux.
• Instalaçao do AJENTI.
• Instalaçao do Netdata.
• Instalaçao do Monitorix.
• Instalaçao do Terminator.
• Instalaçao do Cockpit.
• Elasticsearch | kibana
• Zabbix
TOPOLOGIA
• Servidores interligados.
• Notebook SysAdmin.
• Servidor de Log's.
• Servidor de Monitoramento.
INSTALAÇÃO DO DEBIAN
SERVIDOR
• Link para Download do Debian 9.5
https://cdimage.debian.org/cdimage/arc
hive/9.5.0/amd64/iso-cd/debian-9.5.0-
amd64-netinst.iso
AJENTI
• Site > http://ajenti.org/
• Ajenti basicamente seria um painel de controle, bonito, responsivo e fácil de utilização.
• Fácil acesso via navegador Web.
• Instalações >
apt-get update
apt-get install curl
http://docs.ajenti.org/en/latest/man/install.html
https : // raw . githubusercontent . com / ajenti / ajenti / master / scripts / install . sh | sudo bash - s -
ip:8000
http://ajenti.org/
http://docs.ajenti.org/en/latest/man/install.html
NETDATA
• Site > https://my-netdata.io/
• Comandos para instalação:
# apt install zlib1g-dev uuid-dev libmnl-dev pkg-config curl gcc make autoconf autoconf-
archive autogen automake python python-yaml python-mysqldb nodejs lm-sensors python-
psycopg2 netcat git –y
# cd /opt/
# git clone https://github.com/firehol/netdata.git --depth=1 ./netdata
# cd /opt/netdata
# ./netdata-installer.sh
#ip:19999
https://my-netdata.io/
https://www.youtube.com/redirect?q=https%3A%2F%2Fgithub.com%2Ffirehol%2Fnetdata.git&redir_token=oKdSF6LnqIojX-ehGTHhI0O5SxF8MTU1NjU3NTIzNUAxNTU2NDg4ODM1&stzid=Ugw_9R4cxTVY9SaExn14AaABAg&event=comments
https://www.youtube.com/redirect?q=http%3A%2F%2Fnetdata-installer.sh%2F&redir_token=oKdSF6LnqIojX-ehGTHhI0O5SxF8MTU1NjU3NTIzNUAxNTU2NDg4ODM1&stzid=Ugw_9R4cxTVY9SaExn14AaABAg&event=comments
MONITORIX
• Site > https://www.monitorix.org
• Instalação:
# apt-get update
# apt-get install gdebi
# wget https://www.monitorix.org/monitorix_3.11.0-
izzy1_all.deb
# gdebi monitorix_3.9.0-izzy1_all.deb
# monitorix -c /etc/monitorix/monitorix.conf
# ip:8080/monitorix
https://www.monitorix.org/
TERMINATOR
• Comandos:
# apt-get update
# add-apt-repositório ppa: gnome-terminator
# apt-get install terminator
Atalhos:
. F11: Alternar tela cheia
. Ctrl + Shift + O: Divide os terminais horizontalmente
. Ctrl + Shift + E: Terminais divididos verticalmente
. Ctrl + Shift + W: Fecha o painel atual
. Ctrl + Shift + T: Abre nova aba
. Shift + Ctrl + s: Ocultar / mostrar a barra de rolagem
. Ctrl + Shift + f: Pesquisar por uma palavra-chave
. Ctrl + Shift + w: Fecha o terminal atual
. Ctrl + Shift + R: Redefinir Terminal
. Ctrl + Shift + q: fecha o terminador
COCKPIT
• Site > https://cockpit-project.org/
• Comandos:
# echo 'deb
http://deb.debian.org/debian
stretch-backports main' | sudo tee
/etc/apt/sources.list.d/backports.li
st
# apt-get install cockpit
# ip:9090
https://cockpit-project.org/
http://deb.debian.org/debian
AIDE
• Comandos:
# apt-get update
# apt-get install aide
# /etc/aide/aide.conf > ConfFiles = p+u+g+i+n+s+b+m+a+sha1+md5
/etc/ajenti ConfFiles
!/etc/aide
# aide --config-check
# cd /var/lib/aide
# aide -c /etc/aide/aide.conf --init
# aide -c /etc/aide/aide.conf --check
WEBMIN
• Site > http://webmin.com/
• Comandos:
#
wget http://prdownloads.sourcefor
ge.net/webadmin/webmin_1.900_a
ll.deb
# apt-get –f install
http://webmin.com/
http://prdownloads.sourceforge.net/webadmin/webmin_1.900_all.deb
MEMÓRIA LINUX
• Comandos:
# watch -n 1 free –m
# free –m
# echo 3 > /proc/sys/vm/drop_caches
# sync && sysctl vm.drop_caches=3
# /etc/crontab
# 0 * * * * root sync && sysctl vm.drop_caches=3
# service cron restart
ZABBIX
MONITORING
• Site > https://www.zabbix.com
• Comandos:
Instale o repositório do Zabbix
# wget https://repo.zabbix.com/zabbix/4.2/debian/pool/main/z/zabbix-
release/zabbix-release_4.2-1+stretch_all.deb
# dpkg -i zabbix-release_4.2-1+stretch_all.deb
# apt update
Instalando server Zabbix, agente, frontend:
# apt -y install zabbix-server-mysql zabbix-frontend-php zabbix-agent
https://www.zabbix.com/
https://repo.zabbix.com/zabbix/4.2/debian/pool/main/z/zabbix-release/zabbix-release_4.2-1+stretch_all.deb
ZABBIX MONITORING
• Criando banco de dados:
# mysql -uroot –p
# mysql> create database zabbix character set utf8 collate utf8_bin;
# mysql> grant all privileges on zabbix.* to zabbix@localhost identified by
'password';
# mysql> quit;
• Importar esquema e dados iniciais
# zcat /usr/share/doc/zabbix-server-mysql*/create.sql.gz | mysql -uzabbix -p
zabbix
ZABBIX MONITORING
• Configure o banco de dados para o servidor Zabbix
# /etc/zabbix/zabbix_server.conf
DBPassword=password
• Configure o PHP para frontend do Zabbix
# /etc/zabbix/apache.conf
php_value date.timezone Europe/Riga
• Inicie os processos do servidor e agente do Zabbix
# systemctl restart zabbix-server zabbix-agent apache2
# systemctl enable zabbix-server zabbix-agent apache2
Acesse > http: // server_ip_or_name / zabbix
INSTALANDO GRAFANA
• Site > https://grafana.com/
• Comandos:
# wget https://dl.grafana.com/oss/release/grafana_6.1.6_amd64.deb
# dpkg -i grafana_6.1.6_amd64.deb
• Dependências
# apt-get install -y adduser libfontconfig
• Configurando Inicialização
# update-rc.d -f grafana-server defaults
https://grafana.com/
https://dl.grafana.com/oss/release/grafana_6.1.6_amd64.deb
INSTALANDO GRAFANA
• Iniciando Grafana
# service grafana-server start
• Listando Plugins
# grafana-cli plugins list-remote
# grafana-cli plugins install alexanderzobnin-zabbix-app
• Reiniciando Grafana
# /etc/init.d/grafana-server restart
• Acessando a interface web do Grafana
http://IP_DO_SERVIDOR:3000/login
ELASTICSEARCH
| KIBANA
SITE > HTTPS://WWW.ELASTIC.CO/PT/
https://www.elastic.co/pt/
ELASTICSEARCH | KIBANA
• Comandos:
# wget https://artifacts.elastic.co/downloads/elasticsearch/elasticsearch-7.0.0-
amd64.deb
# wget https://artifacts.elastic.co/downloads/kibana/kibana-7.0.0-amd64.deb
# https://artifacts.elastic.co/downloads/beats/filebeat/filebeat-7.0.0-amd64.deb
# apt-cache search openjdk (JAVA)
# apt-get install openjdk-8-jre
# Instalar versão java mais atualizado
https://artifacts.elastic.co/downloads/elasticsearch/elasticsearch-7.0.0-amd64.deb
https://artifacts.elastic.co/downloads/kibana/kibana-7.0.0-amd64.deb
https://artifacts.elastic.co/downloads/beats/filebeat/filebeat-7.0.0-amd64.deb
GO ACCESS
• Site > https://goaccess.io
• Comandos:
# wget https://tar.goaccess.io/goaccess-1.3.tar.gz
# tar -xzvf goaccess-1.3.tar.gz
# cd goaccess-1.3/
# ./configure --enable-utf8 --enable-geoip=legacy
# make
# make install
• Gerando Log HTML
# goaccess /var/log/apache2/access.log --log-format=COMBINED
https://goaccess.io
https://tar.goaccess.io/goaccess-1.3.tar.gz
AGRADECIMENTOS
• Muito obrigado por ter chegado até aqui, fico muito feliz com seu progresso!!!
• Desejo a todos que este curso tenha trago sabedoria e que ajuda com novas conquista!!
Abraços
Weverton Batista
SysAdmin | DevOps
