World of silicon
opens up at ISSCC
NEWS REPORTS FROM THE INTERNATIONAL SOLID-STATE CIRCUITS CONFERENCE PAGES 8 TO 11
Raspberry Pi captures public imagination
RS AND FARNELL GET FIRST DISTRIBUTION DEALS FOR LOW-COST EDUCATIONAL COMPUTER PAGE 4
Testing power supply efficiency
HOW TO MINIMISE ERRORS WHEN MEASURING POWER SUPPLY EFFICIENCY PAGE 14
7-13 March 2012 | No. 2498 | ElectronicsWeekly.com
ElectronıcsWeekly
FREE
SHIPPING
ON ORDERS
OVER £50!
DIGIKEY.CO.UK
DIGIKEY.CO.UK
*A shipping charge of £12.00 will be billed on all orders of less than £50.00. All orders are shipped via UPS for delivery within 1-3 days (dependent on fi nal
destination). No handling fees. All prices are in British pound sterling and include duties. If excessive weight or unique circumstances require deviation from
this charge, customers will be contacted prior to shipping order. Digi-Key is an authorized distributor for all supplier partners. New product added daily.
© 2012 Digi-Key Corporation, 701 Brooks Ave. South, Thief River Falls, MN 56701, USA
the week at
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 3
icrochip.comicrochip.comwww.miwww.mi
EDITOR’S CHOICE PRODUCT OF THE WEEK
Microcontrollers for all seasons
BLOG WATCH
Maxim’s plan targets FPGAs
Smallest embedded Wi-Fi module
RTX claims to have the smallest
embedded Wi-Fi module based on
an Energy Micro microcontroller.
The RTX4100 development module
will be used to link low-power sen-
sors and actuators to the internet
for machine-to-machine (M2M) ap-
plications. “It can be integrated into
devices to support various wireless
standards including 802.11 b/g/n.
The module features a built-in and
an external antenna,” said Peter Mar-
iager, chief technology officer at RTX.
www.rtx.dk
Low-power MCU has LCD control
Renesas Electronics has announced
the RL78/L12 range of low-power mi-
crocontrollers with an on-chip LCD
controller that reduces current con-
sumption by about 30% compared
to its previous MCUs. Designed for
small LCD panel applications there
are 18 product versions with pin
count ranging from 32 to 64, and on-
chip flash memory capacities ranging
from 8kbyte to 32kbyte.
www.renesas.eu
Motor control tool is free
Toshiba Electronics Europe has
announced a free software tool for
design and test of embedded motion
control applications built around
ARM Cortex-M3 motor control mi-
crocontrollers. Dubbed MotorMind,
it is compatible with Toshiba’s TMP-
M37x microcontrollers, which are
notable for a hardware vector engine
(VE) and programmable motor drive
(PMD) outputs.
www.toshiba-components.com
Debugger gets slimline probe
IAR Systems has introduced a slim-
line in-circuit debug probe which it
has integrated into its C/C++ com-
piler and debugger tool suite. I-jet,
as part of the Embedded Workbench
IDE, supports microcontrollers based
on ARM7, ARM9, ARM11, ARM
Cortex-M, ARM Cortex-R4, and ARM
Cortex-A5/A8/A9 cores.
www.iar.com/ijet
Embedded standards group
An embedded computing standards
group has been founded by firms in-
cluding: Advantech, Congatec, Data
Modul, Kontron and MSC. Called
SGET, it will look at the Computer-
on-Module (COM) specifications
Qseven and a dedicated ARM mod-
ule specification.
www.sget.org
ARM Cortex-M3 gets touchy-feely
Fujitsu has added capacitive touch
functionality to its FM3 family of
ARM Cortex-M3 based microcontrol-
lers. FM3touch uses an ADC-based
capacitive sensing algorithm to reach
a high sensitivity of only a few femto-
Farad, using one pin-per-touch input
channel without the need for external
components.
emea.fujitsu.com/semiconductor
Cognitive computer uses MRAM
Everspin Technologies, the devel-
oper of Spin-Torque magnetic-RAM
(MRAM), has demonstrated its
memory technology being used in a
cognitive computing platform. Cogn-
iMem Technologies is using MRAM
to store and restore the content of
the neurons in a system with 4,096
silicon neurons that mimic how the
human brain processes data.
www.everspin.com
Motor chip gets four add-ons
Freescale has squeezed a microcon-
troller, mosfet gate drive, voltage
regulator and LIN bus physical layer
into a single control chip for brush-
less DC motors. The 16bit mixed-sig-
nal MCUs are called the S12 MagniV
S12ZVM family.
www.freescale.com
Silicon Labs goes M3 for USB
Silicon Labs has introduced a
family of microcontrollers based
around ARM’s 32bit Cortex-M3 core.
Called Precision32, it includes 32
SiM3U1xx and SiM3C1xx products
with footprint-compatible USB and
non-USB options.
www.silabs.com
ECOsineTM Harmonic Filters www.myecosine.com
Schaffner Ltd T +44 (0) 118 977 0070 E uksales@schaffner.com www.schaffner.uk.com
Reduction of THID to <5%
TDD in accordance with IEEE 519
Increase in system reliability
More efficient utilization of electric power
Long-term cost and energy savings
Fast and easy plug-and-play operation
Very compact and light-weight design
Status monitor as standard feature
50Hz and 60Hz versions available
UL-approved, CE-marked, RoHS compliant
news
News: Raspberry Pi with
www.electronicsweekly.com
www.electronicswee y.com
computer on a stick
www.electronicsweekly.com
more onlinemore onlinemore online
News: Raspberry Pi with a News: Raspberry Pi with a
week to goweek to goweek to go
www.electronicsweekly.comwww.electronicsweekly.com
Blog: Element14 CEO speaks: Blog: Element14 CEO speaks:
Computer literacy & Raspberry PiComputer literacy & Raspberry PiComputer literacy & Raspberry Pi
www.electronicsweekl .comwww.electronicsweekly.comwww.electronicsweekly.com
News: In depth: Raspberry Pi, theNews: In depth: Raspberry Pi, theNews: In depth: Raspberry Pi, the
ccomputer on a stickcomputer on a stick
www.electronicsweekly.comwww.electronicsweekly.comwww.electronicsweekly.com
Raspberry Pi has arrived: RS and
Farnell get first distribution deals
ElectronicsWeekly.com4 | EW 7-13 MARCH 2012
R
aspberry Pi, the £25 edu-
cational computer from
Cambridge, will be distrib-
uted globally by RS Com-
ponents and Premier Farnell, and the
Model A has been given a RAM boost
to 256Mbyte.
“RS Components and Premier Far-
nell will be responsible for all distri-
bution of the Model A and Model B
devices,” Raspberry Pi Foundation
executive director Eben Upton told
Electronics Weekly.
“This should help to address peo-
ple’s concerns around our ability to
ramp to serious volume, and around
the economics of the device – these
companies wouldn’t sign up for this
unless there was a strong business
case for them.”
“There will also be an increase in
the RAM size for the model A to
256Mbyte, still within the $25 budg-
et,” he added.
Set up by a group of high-flying
Cambridge techies, the Raspberry Pi
Foundation aims to inspire a genera-
tion of programmers by putting com-
petent, low-cost hardware into the
hands of children and teenagers,
much in the way that Sinclair com-
puters did in the 1980s.
The ARM11-based computer is the
size of a credit card and simply plugs
into a TV or monitor, a keyboard and
a mouse to form a potent Linux com-
puter with powerful graphics. More
Raspberry Pi details here.
There are two versions: Model A
($25) has one USB 2.0 port, and B
($35)has two instead USB 2.0 ports
The appointment of RS and Farnell as distributors proves that the markets intend to take it seriously, writes Steve Bush
and Ethernet. “Raspberry Pi provides
a revolutionary low-cost platform,
which opens up programming to a
whole new audience,” said Glenn
Jarrett, head of marketing at RS.
“We are very honoured to have
been chosen to work with the foun-
dation as a distribution partner at the
launch of this exciting new tool,” he
added.
Both RS and Farnell, which also
trades as Element14, have active
community websites – respectively:
DesignSpark and element14.
“RS was selected as a distribution
partner for Raspberry Pi because, in
the eyes of the foundation, it con-
nects with engineers across the globe
throughout their careers,” said RS.“As such, the company is well
Computer programming – at the right price
positioned to provide Raspberry Pi
adopters with support, advice and
access to additional resources as
they embark on new development
 activities.
“It was particularly impressed
with the DesignSpark community
and resources provided for new de-
velopers working on Open Source
designs.”
Raspberry Pi B boasts two USB 2.0 ports, and Ethernet
news
Start-up pursues flickering
light alternative to Wi-Fi
ElectronicsWeekly.com6 | EW 7-13 MARCH 2012
And another
one bites
the dust
MANNERISMS
Glass coating cuts arcing, raises operation
voltage of ceramic chip capacitors by 1kV
PASSIVES
OPTICS
W
hat do Wilbur and Orville
Wright, and Bob Dennard
have in common? They
invented things which have been
supremely useful for members of
the human race but which have lost
enormous amounts of money, writes
David Manners in his Mannerisms
Blog on ElectronicsWeekly.com.
The airline services industry has
not made a penny piece in profit over
its lifetime, nor has the DRAM
industry.
The announcement of the
bankruptcy of Elpida makes you
wonder: Why do people do it? Why
do they run airlines? Why do they
manufacture DRAM?
Apart from Samsung, the DRAM
industry has lost $14bn in the past
three years.
In the disaster year of 1985, when
all the US DRAM makers except
Texas Instruments and Micron pulled
out of the business, the industry lost
$6bn.
Over the 40 years since DRAM first
appeared on the market the
accumulated losses must be
immense.
Last week Elpida, the last of the
Japanese DRAM makers, has gone
bust owing $5.5bn.
For Japan, DRAM was the product
which propelled them, in 1988, to
over 50% of world semiconductor
market share with six companies in
the top 10.
Governments vied for DRAM fabs
offering grants, loans and tax
holidays just to get these money-
burners to locate in their countries.
In the 1990s, the Scottish wooed
NEC and Hyundai. The Welsh wooed
LG. The Taiwanese authorities have
fought a losing battle trying to prop
up their failing DRAM-makers.
The Japanese have been
subsidising Elpida but have now
learnt their lesson.
“What doesn’t work in global
competition doesn’t work even with
the help of state funds,” says Kaname
Tajima, head of the industrial unit of
Japan’s ruling Democratic Party, “we
must discern Japan’s strength and
learn lessons from the failure.”
Quite so.
Mannerisms
electronicsweekly/com
A
n Edinburgh start-up is
using light instead of radio
for wireless comms, writes
David Manners. Edinburgh
start-up Visible Light Communica-
tions (VLC) is intending to use flick-
ering LEDs instead of 802.11 Wi-Fi
for broadband communications.
Data rates of up to 500Mbit/s have
been achieved for the technology,
called Li-Fi, but the first product
from VLC – a consumer transmitter –
will deliver data rates of 100Mbit/s
using VLC’s SIM-OFDM technology
and optical spatial modulation. It is
due for launch next year.
The technology was invented by
Edinburgh University’s Harald Haas.
“At the heart of this technology is a
new generation of high-brightness
light-emitting diodes,” said Haas.
“Very simply, if the LED is on, you
transmit a digital 1, if it’s off you
transmit a 0.”
High speeds are achieved by
implementing parallel data
transmission using arrays of LEDs,
where each LED transmits a different
N
orfolk-based capacitor maker
Syfer has pushed up the
operation voltage of ceramic
chip capacitors, by over 1kV in
many case sizes, regardless of local
humidity.
“Typical devices include a 2kV
multi-layer ceramic chip capacitor in
a 1206 package [100pF to 3.3nF], 2kV
in 2220 with capacitance range of
220pF to 33nF, 3kV in 1880 [100pF to
3.3nF], and 5kV in 2220 package
with 220pF to 4.7nF capacitance,”
said the firm.
Key to the voltage increase is an
undisclosed process that puts a glass
coating over the capacitor body
without covering the end terminals.
“Arcing is the problem with high
voltage” said Syfer MD Howard
Ingleson. “A standard 1206 X7R chip
capacitor might be rated at 2kV, but
in 90% humidity the arcing voltage is
lower.” Unlike the surface of a PCB
which is smooth, the naturally
irregular surface a ceramic promotes
arcing by absorbing moisture and
pollution. It also picks up tiny spots
of tin from the terminals of adjacent
capacitors during manufacture.
“X7R is quite a rough surface,” said
Ingleson. “If we polished it, it would
do much better.” A thin coating of
glass takes the ceramic surface out of
the equation. “A standard 2,300V
part goes up to 3,520V with the
coating. The higher voltage is very
consistent with changes in
humidity,” said Ingleson. “You can
go up a voltage range with the same
size chip.”
Why doesn’t every one do this? “It
is not easy to coat the ceramic
without coating the electrodes,” he
said. And, why not a polymer
coating? “Glass, won’t come off,” said
Ingleson. “We have seen this with
conformal coating.”
The coating process has been
branded ProtectiCap.
“ProtectiCap and a matte tin layer
over the nickel base termination
minimises the risk of flash-over and
avoids the need for the customer to
apply conformal coating after
soldering,” said Syfer.
The coated X7R capacitors are
aimed at power supplies, lighting
ballasts, inverters, and general high
voltage circuits, with values from
100pF to 33nF, in packages from
1206 to 2220, at voltages from 2 to
5kV.
Syfer
www.syfer.com
data stream. Also mixtures of red,
green and blue LEDs can be used to
alter the light’s frequency, with each
frequency encoding a different data
channel.
Because it uses light rather than
radio signals, VLC could be used in
aircraft, integrated into medical
devices and hospitals where Wi-Fi is
banned, or even underwater, where
Wi-Fi doesn’t work.
The snag with LiFi is, of course,
that it relies on line of sight.
VLC’s SIM-OFDM technology and
optical spatial modulation allows
LED light to modulate at a rate so fast
as to be imperceptible to the human
eye, but which can be picked up by
receivers such as suitably configured
smartphone cameras at speeds of
hundreds of megabits per second,
enabling the light source to transmit
data.
“At the rate we currently adopt
wireless data, we will ultimately run
out of radio spectrum as we cope
with the long-term demand of
wireless data transmissions and the
trillions of bytes of data
communicated every month,” said
VLC chief executive Gordon Povey
(pictured). “Turning a light source, a
simple household LED bulb for
example, into a localised data
communications centre, is a
potentially viable alternative.”
Visible Light Communications
visiblelightcomm.com/
Povey: A viable alternative
More Flexibility
vicorpower.com/rp/flexibility/ew
Vicor gives power system architects the flexibility to choose from modular,
plug-and-play components, ranging from bricks to semiconductor-centric solutions
with seamless integration across all power distribution architectures.
From the wall plug to the point of load.
Don’t let inflexible power products slow you down.
Choose from limitless power options to speed your competitive advantage.
Flexibility. Density. Efficiency.
Trust your product performance to Vicor
news
Flexible organic sensor for
touch-screens and controls
ElectronicsWeekly.com8 | EW 7-13 MARCH 2012
ORGANIC
The IEEE holds the
International
Solid-State Circuits
Conference once a year
in San Francisco.
It is the world
show-case for cunning
on-chip circuit design
and is a partner to
IEDM, the IEEE’s
electron devices
meeting which
highlights innovation
amongst the detailed
nuts and bolts of chip
design.
U
sing organic
transistors, en-
gineers at the
University of
Leuven have deposited
a complete capacitive
touch interface on flex-
ible plastic foil.
“These are to the authors’ best
knowledge the first capacitive sen-
sors on a flexiblefoil,” said the team.
“We see applicability in future flexi-
ble touch-screens as well as control
interfaces for consumers: for scroll-
ing up and down in an e-reader, for
 example.”
Both sensors and circuit were
made on an existing three-metal
layer pentacene transistor process
from Eindhoven-based Polymer Vi-
sion. Like many organic electronic
processes, it yields slow n-FETs, so
the circuits had to be designed with
the much faster p-channel FETs.
Two touch patterns were devel-
oped, an analogue slider whose
 capacitance changes depending on
finger position (Figure 1) and a two-
dimensional touch array (photo).
The slider readout circuit is reset
by clock2 (running at 330Hz) which
causes the capacitors to discharge.
Clock1, which is in anti-phase with
Clock2, then connects the sensor into
the circuit whose output voltage then
climbs at a rate proportional to the
ratio of the fixed capacitor (25pF)
and the sensor capacitor (0-500pF) –
and largely unaffected by process
variations. The voltage at Vout at the
end of Clock2 is available for process-
ing outside the scope of the project.
The same readout circuit is used
for the matrix array of 5x5mm touch
pads, with columns switches ground-
ing one column at a time, and row
switches presenting the capacitance
to the readout circuit. Row and col-
umn scanning signals come from an
organic transistor frequency divider
built with four flip-flops and eight
NAND gates. Refresh rate is 93Hz.
The output from the matrix is a se-
ries of analogue voltages, and meas-
urements indicate that more resolu-
tion (down to 1mm) is available with
the existing circuit by interpolating
between signals from adjacent rows
and columns.
Figure 1: (a) Dimensions of the capacitive sensor, (b) the working
principle of the sensor and (c) schematic view of the architecture of the
sensor read0out circuit
More multimedia. More sensors. More fuel efficiency. In 2012, the key word is “more.” But cars aren’t getting any bigger. And your
job isn’t getting any easier. That’s why we’re giving you more integration than ever before. So you get more space. And consumers
get the cars they demand—including some they’ve only dreamed of.
Featured Technologies
GMSL serializer/deserializer chipset delivers HDCP content over coaxial cables, so you can add new multimedia and safety
systems at a much lower price point
Battery-monitoring ICs feature a patented SMBus daisy-chain interface to improve safety, performance, and reliability in
hybrid and electric vehicles
Multi-output PMICs supply all the power rails you need to integrate functions like voice control, MP3 playback, and
Bluetooth® connectivity into infotainment systems
Fully integrated RF tuners deliver new levels of performance for active antennas, mobile TV, HD radio, and universal GPS
© 2012 Maxim Integrated Products, Inc. All rights reserved. Innovation Delivered, Maxim, and the Maxim logo are trademarks or registered trademarks of Maxim Integrated Products, Inc., in the United States and
other jurisdictions throughout the world. Bluetooth is a registered trademark of Bluetooth SIG. All other company names may be trade names or trademarks of their respective owners.
Learn about these and other automotive solutions.
www.maxim-ic.com/Auto-Ad
Navigate to the Future
Integration speeds you past design challenges on the road ahead
news
Flying resonators raise solar efficiency
ElectronicsWeekly.com10 | EW 7-13 MARCH 2012
A
biopotential acquisition chip
from Imec and its Netherland
partner Holst Centre has been
singled out for praise at the Interna-
tional Solid-State Circuits Confer-
ence in San Francisco.
“There has been a growing interest
in wearable biopotential-monitoring
systems, which have very strict re-
quirements in terms of power dissi-
pation, high signal quality, small area
and robust operation during ambula-
tory use,” said the ISSCC.
This chip has the “first analogue
motion artifact suppression tech-
nique that does not degrade the per-
formance of an analogue front-end”,
it claimed.
The three-channel chip consumes
192μW from a 1.2V supply (160μA)
and is capable of rail-to-rail DC offset
rejection for suppressing motion arti-
facts, while achieving 120dB CMRR
(common-mode rejection), 1GΩ
input impedance, and 1.3μVrms
input- referred noise at 100Hz band-
width.
Made on 0.18μm CMOS, the chip
measures 8x5mm. “The biopotential
acquisition asic improves the quality
of recording in portable biopotential
monitoring systems, particularly in
ECG [electrocardiography], said the
ISSCC.
Including the acquisition chip,
Imec and Holst are presenting 14 pa-
pers at ISSCC 2012. Among these are
descriptions of three successive ap-
proximation ADCs for reconfigurable
radios: A 1.7mW 11bit 250Msample/s
2x interleaved pipelined ADC in
40nm CMOS, a 70dB 10bit
0-80Msample/s current-integrating
ADC with adaptive dynamic ranging,
and a 7-10bit 0-to-4Msample/s ADC
with 6.5-16fJ/conversion-step.
There is also a 60GHz transceiver
chip in 40nm digital low-power
CMOS, “obtaining sufficient error
vector management [EVM -17dB at
7Gbit/s] for modulations as complex
as QAM16 in the four channels spec-
ified by IEEE802.15.3c”, said ISSCC.
 Addressing thin-film transistors
made from unusual semiconductors,
Imec has papers on: a hybrid (organic
+ solution-processed metal-oxide)
bidirectional RFID tag, and a 6bit
10Msample/s current-steering DAC
made with amorphous GaInZn oxide
thin-film transistors, achieving a
spurious free dynamic range of over
30dB up to 300kHz.
Wearable biopotential monitoring chip
MEDICAL
On-die aerial
Thz imaging
SENSORS
Integration cap THz mixer
under ground
plane Ring antenna
I
maging far-infra-red (sub-millime-
tre) radiation between 300GHz and
3THz could mean seeing several
millimetres under the skin or inside
teeth. It can be detected as heat, but at
ISSCC researchers, including a team
from STMicroelectronics, described
imaging it as RF radiation. Key to
this is a 32x32 array of square 80μm
pixels, each dominated by a circular
antenna (BW=0.6-1THz) built from
metallisation, with two internal con-
nections feeding anti-phase RF into a
differential nmos distributed resistive
detector made from a single novel
65nm n-mosfet (pictured). This allows
the fet to work above its ft (=160GHz).
S
olar panels are generally
connected in series strings,
followed by a high-voltage
inverter to make mains
voltage. Shading of a single panel
severely cuts the output of the entire
series string.
Inverse parallel diodes are
generally connected to bypass
shaded panels – an arrangement that
does not allow for partial shading of
some panels. One-inverter-per-panel
(‘microinverters’) is an expensive
way around the whole problem.
At ISSCC, a team from Dartmouth
College New Hampshire and Solar
Semiconductor presented a different
solution which maintains an equal
voltage across all the panels in a
string regardless of shading.
This leads to higher power
extraction, said the team. Instead of a
diode, they connect a series-
connected (series-resonant) inductor
and capacitor across each panel
through a 0.35μm 90V CMOS/
LDMOS chip.
This chip can disconnect the
resonator, and alternatively connect
it across the panel above in the string.
Careful control of timing allows
energy to be transferred (as half-
cycles of sinewave current) from the
lower panel to the upper panel, and
vice versa.
Each chip can handle three
resonators, and multiple chips can be
cascaded to handle long strings (see
Figure 1).
With all the resonators switching
up and down in synchronisation,
energy can be inched arbitrarily up or
down the string.
Vmpp is the voltage at which
maximum power can be extracted
from a panel for a given current.
“Due to the first-order logarithmic
variation of Vmpp with short circuit
current, the strategy recovers mis-
match loss over a widerange of mis-
match levels,” said the team.
Oscillator, gate-drive, timing and
communication are all integrated. Six
off-chip mosfets are needed to
implement the double-pole double-
throw power switch.
Conversion efficiency is above
99% and, as the circuit replaces
diodes that are conventionally
collected together in a junction box
with all the necessary connections, it
can be retrofitted to existing
installations.
www.dartmouth.edu
www.solarsemiconductor.comFigure 1
POWER
news
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 11
Figure 1: Transceiver block design
WIRELESS
K
orean engineers have
implemented a 15μA 5.8GHz
active wake-up radio using
mixed signal processing.
Wake-up radio is a way of cutting
the power consumption of a seldom-
used receiver – in this case an active
car tag for road-tolling.
Inside a wake-up radio there are
two receivers: a simple low-power
one that is just complex enough to
recognise the desired signal, and a
more power-hungry full featured
receiver that demodulates and
decodes data from the signal; as well
as a transmitter if two-way
communication is required.
The simple receiver awaits the
signal and, when it thinks it has
found it, wakes the comprehensive
receiver.
Best power consumption is
achieved when the simple receiver is
just sophisticated enough not false-
trigger the full receiver too often.
To help the system along, the
desired signal can be customised for
wake-up reception.
In the case presented at ISSCC, the
data part of the signal – modulated at
256kbit/s – is preceded by 15-17
cycles of simple 14kHz AM
modulation. The team rejected a
SAW front-end for the wake-up
receiver as being too wideband
(leading to false triggering), and too
lossy to be sensitive enough.
Instead, they used a four transistor
LC-tuned high-gain RF envelope
detector feeding a comparator as a
one-bit ADC (see diagram).
A low-power delay-based band-
pass filter decides if the tell-tail
14kHz signal is present.
Made on 0.13μm CMOS, final
sensitivity in the wake-up radio is
-45dBm (MI=0.85).
The associated full receiver is
similar in architecture, but has an
LNA before the envelope detector,
and an analogue band-pass filter
between that and the one-bit ADC.
256kbit/s decoding is on a separate
chip.
Sensitivity is -61dBm (MI=0.85)
and current consumption is 19mA.
The +5dBm transmitter on the
same chip draws 40mA delivering
data at 512kbit/s.
The design is a team effort between
KAIST and PhyChips.
www.kaist.edu/
www.phychips.com/
Active wake-up
radio allows long
range RF tagging
mouser.com
Find It
Here.
Faster.™
Fastest Part Search.
Best Selection.
Immediate Delivery.
Authorised
Distributor
of semiconductors
and electronic
components for
design engineers.
news
Safe gas analyser a hit with councils
ElectronicsWeekly.com12 | EW 7-13 MARCH 2012
TEST
MANNERISMS
£108m bill for 4G mobile interference goes to operators
B
irmingham design consul-
tancy ByteSnap has put
mobile phone-like user-
friendliness into an intrin-
sically safe industrial gas analyser.
The brief was to bring analysers for
landfill gasses up-to-date by incor-
porating a fast colour user interface
without compromising Zone 0 (maxi-
mum) safety.
Being intrinsically safe puts strict
requirements onto the internal cir-
cuit, while a comprehensive interface
means running an operating system,.
“There are tough power require-
ments, you have got to limit the
amount of power going into each part
of the circuit,” company founder
Dunstan Power told Electronics
Weekly. “Basically, you can put 1W
into each part of the circuit. We did it
for 800mW for the whole device.”
To meet this, the company chose
an ARM9 running Windows CE at
400MHz. Without a powerful smart-
phone processor to fall back on, Byte-
Snap developed its own lightweight
user interface, which it calls SnapUI.
“This is the first time ByteSnap’s user
interface development framework
and Windows CE have been used in
an intrinsically safe device that is ap-
proved for Zone 0 environments,”
said co-founder Graeme Wintle.
A
typically British fudge could
hinder the roll-out of 4G
mobile services, writes David
Manners It’s a bit surprising that it’s
only now that proposals have been
issued for dealing with the inter-
ference between digital terrestrial
broadcasting and 4G mobile phone
transmissions.
Ofcom was pointing out last June
that the frequencies for digital terres-
trial TV broadcasting were ‘adjacent’
SnapUI, aimed at Windows CE,
separates user interface design from
the application code, into an XML
configuration file, which enables the
user interface to be developed on a
desktop in parallel with embedded
system development.
With an operating system and dis-
play, available markets have been
broadened by adding multi-language
support – new translations can be
added to the XML file without re-
coding the application.
Despite the power limit, the ana-
lyser, the 5000 series from Geotechni-
cal Instruments, has a number of
built-in sensors alongside the gas de-
tector.
“With ByteSnap’s help we have de-
veloped a gas analyser that is a gener-
ation ahead of the competition. Not
only can it take readings in under 10
seconds, it combines GPS, Bluetooth,
an accelerometer, compass and a col-
our screen. It even operates in tem-
peratures from -10°C to +50°C,” said
Geotechnical project manager Steve
Earp. “We’ve found ease of use to be
a killer feature, local councils remark
upon how quickly staff get up and
running with it.”
ByteSnap
www.bytesnap.co.uk
to the 800-900MHz band being auc-
tioned for 4G.
What we now have is a classic Brit-
ish fudge. Earlier this week the De-
partment for Culture, Olympics,
Media and Sport (DCMS) accepted
that 4G transmitters are going to af-
fect terrestrial TV broadcast recep-
tion in nearby households. It said all
of these households will be issued
with filters on the basis of their prox-
imity to the transmitters.
The filters will connect to set-top
boxes and this process will be so sim-
ple anyone can do it, says DCMS. Fil-
ters will do the trick for most of the
900,000 households, but for about
10,000 they will not work, so will
have to switch to satellite or cable
TV. If a household cannot switch to
cable or satellite – and the DCMS
thinks there could be 500 such
households – they’ll be given
£10,000 by the government and told
‘you’re on your own’.
The DCMS recommends that
groupings of the cast-out 500 could
pool their money to invest in addi-
tional relay transmitters.
The nationwide cost of providing
the filters will be £108m, funded by
the winners of the 4G spectrum auc-
tion which has been delayed by bick-
ering among potential licensees. It is
currently due later this year.
The departmental secretary of state
Ed Vaizey said: “We expect the de-
ployment of 4G mobile services in
800MHz and 2.6GHz to begin in 2013
in the UK, when the spectrum has
been cleared and is available for 4G
services to be deployed.” Clearing
could be a reference to the need to
use the frequencies currently allocat-
ed for the Olympic Games.
electronicsweekly.com/mannerisms
interview
Taking European
markets head-on
Analog Devices is changing the way it markets its
semiconductors in Europe. Pascal Cerruti tells
Richard Wilson why
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 13
W
e will be more
aggressive in the
way we market
our products,
says Pascal Cerruti, European
marketing communications
director at Analog Devices. The
semiconductor company plans to
change its emphasis from just selling
components to selling platforms,
including reference designs, software
and tools as well as silicon.
“This is a new position for the
company in Europe,” says Cerruti.
The more agressive sales strategy is
the brainchild of ADI’s vice-president
of sales for the EMEA region, Carsten
Suckrow, who joined the chip
company just over a year ago.Europe accounts for about a
quarter of ADI’s sales. There is
belief in the company that it can
increase its share of the European
market by capitalising on its
reputation, especially in analogue
semiconductor technologies.
The company is aiming for double-
digit growth in its European business
over the next three years. “We are re-
asserting the ADI brand, particularly
in the analogue world,” says Cerruti.
“It is all about reaching new
markets.”
The company’s largest market
sectors in Europe are automotive and
communications. Cerrutti says there
is a plan to target new end markets
with specific products and platform
offerings. Focus markets include
industrial process control, metering
systems and instrumentation.“We are
looking for new business and new
customers in these focus areas,” says
Cerruti.
An example of the new strategy
was the company’s promotion of its
iCoupler digital isolator product
family at the end of last year.
Despite the signal isolator market
being highly competitive with
companies such as Texas Instruments
and Avago, ADI believes it has the
products to grow its business by
targeting specific markets across
Europe. “In a way it is a test case for
the new strategy,” says Cerruti.
Rather than just marketing
components the company has
worked with its distributors Arrow
and Silica on evaluation boards. “We
have also designed our own boards
and created circuit designs which are
available on the website,” says
Cerruti.
The company is also reviewing its
sales channels in various European
countries. It is using its distribution
channel to grow business in France
and Italy as well as its traditionally
strong markets of Germany and the
UK.
Cerruti also says the company
would work closely with its
distributors on new product
introductions. “We will launch
products through distribution with
guaranteed product availability and a
strong presence on websites,” says
Cerruti. “There is a real sense of
urgency in this now for us,” adds
Cerruti.
Analog Devices
www.analog.com
The most advanced,
multilingual, multicurrency
mobile site for
design engineers.
Mouser is an authorised distributor of semiconductors
and electronic components with 9 European locations,
over 2 million products online, 2-3 day delivery and
updated products daily.
m.mouser.com
The Newest Products for Your Newest Designs®
Authorised Distributor
Scan here
to learn more
power systems
Testing power supply efficiency
Andrew Skinner outlines some of the critical factors to help minimise errors when measuring power supply efficiency
ElectronicsWeekly.com
I
n the industrial and medical
equipment markets increasing
numbers of manufacturers of
end systems are asking power
supply manufacturers for both the
headline efficiency of products and
for high efficiency levels over the
typical operating load range of their
equipment.
Even when their own equipment
does not fall within the scope of any
standards or directives, there is a real
desire to produce environmentally
responsible products.
It is common to benchmark the
efficiency of products against
existing standards such as 80 Plus,
even if they are not required for the
end application: 80 Plus requires that
the input and output power is
measured to within 0.5% accuracy,
which means results in a ±1%
accuracy on the efficiency
measurement.
Looking at the effects of that on the
80% efficient power supply ±1.5W is
not a significant error. As the
efficiency goes up to 90% or 95%,
the error is around ±1W – a level that
seems quite acceptable when
considering input power. But if you
look at the losses in the power supply
instead, then the story is rather
different.
Taking the 80% efficient power
supply, a loss of 25W is seen, and in a
typical power supply temperature
rises of around 50°C at full load
would be expected. So a ±1%
measurement accuracy could
actually equate to a 13% error
(±6.5°C), which is a perfectly
acceptable level of accuracy.
However, with an efficiency of 90%
the error can be as high as ±25%,
giving a variation in temperature rise
of greater than 10°C, which can halve
the life of the electrolytic capacitors
and have a significant impact on the
end application.
Above 90% efficiency, the impact
of this ±1% measurement accuracy
becomes more critical. If an engineer
were to design in a power supply that
was 96% efficient and then try to use
a unit that is at 94% there could be a
problem with temperatures varying
by over 20°C. At these levels it is
becoming increasingly more
important for design engineers to
verify a power supply’s performance
before specifying it in a design.
The efficiency of an AC-DC power
supply is typically measured using
an AC power analyser – checking the
input voltage, the input current, the
power factor and the power.
The specification for a typical AC
power analyser looks quite good,
with a headline specification that can
be 0.1%, but other factors such as the
size of the measured signals versus
the measurement range, and the
frequency of the signals, can reduce
the final measurement accuracy.
Perhaps more interesting is how
the output power is measured. When
using a digital multimeter, voltages
can be measured very accurately.
Typically, current is often not so
accurate, as it depends on the range:
often a higher accuracy can be
achieved by measuring the voltage
across a calibrated shunt resistor to
measure current.
Digital multimeters use a sampling
technique for measurements but
unfortunately the sampling
frequency and algorithms used are
rarely explained in the product
literature – you could take two or
three multimeters from different
manufacturers and get fairly
significant differences in the
measurement results.
As an example, of the noise that
can be present in the output of a
power supply, Figure 4, shows the
output current (voltage across a
calibrated shunt) for a 10W power
supply.
It is clear that the signal is not DC,
Figure 4: Measuring output current – Spike noise with
frequency content over 10MHz
Figure 5: Block diagram illustrates the set-up used
to measure the efficiency of the CFE400M digital
power supply.

Sales Rentals Service UKAS Calibration
01483 302 700 info@caltest.co.uk www.caltest.co.uk
 Universal (100-240 Vac,1ø, 50/60 Hz), power factor corrected
 input with inrush current limiting
 Single phase, dual range: 0-150 Vac, 0-300 Vac output
 15 to 1,200 Hz full power operation
 5,000 Hz small signal bandwidth
 Front mounted universal socket and rear
 terminal block for versatility and ease
 of operation
NEW from PPS!
Available only at Caltest
The 118-ACX Single Phase High Density
Programmable AC Power Source
Com
pliant to CE,
CSA and UL standards -
Test for overseas m
arkets
power systems
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 15
Figure 2: Efficiency of a 100W power supply from the point of view of
PSU lo es
Figure 2: Efficiency of a 100W power supply from the point of view of Figure 2: Efficiency of a 100W power supply from the point of view of
PSU lossesPSU losses
Figure 3: Accuracy of test equipmentFigure 3: Accuracy of test equipment
input power
Figure 1: Efficiency of a 100W power supply from the point of view of Figure 1: Efficiency of a 100W power supply from the point of view of
input powerinput power
there is a low frequency
characteristic to it and
spike noise that has
frequency content in
excess of 10MHz.
To accurately measure
the efficiency of our
CFE400M digital power
supply, a number of
techniques were used to
improve the
measurement accuracy.
First, external calibrated
current shunts were used
for both input and output
current measurements,
with RC filtering added
to minimise the noise –
so as not to rely on the
unspecified filtering
characteristics of the
measurement equipment.
This enabled the input
power to be measured
with accuracy of about
±0.4%,output current to
just over ±0.1% and the
output voltage to ±0.02%.
This resulted in an
efficiency measurement
that is accurate to within
±0.5%.
Figure 6 shows the
measured efficiency: the
blue line shows the
measured results, but
actually the efficiency
lies between the max and
min lines – between 93
and 94%. Statistical
techniques based on
multiple measurements
on multiple power
supply samples could, of
course, be used to further
improve the accuracy.
The efficiency of the
power supply is at a level
where direct comparison
of unit efficiencies is
difficult due to the
sensitivity to
Figure 6: CFE400M 24V Achievable accuracy with filtered signals
measurement error. So an engineer
may find that the measured
efficiency of this or similarly
specified products may not appear to
be the same as that claimed on the
manufacturer’s datasheet, depending
upon the measurement method used.
Andrew Skinner is chief technology officer at
TDK-Lambda UK
TDK-Lambda UK
www.uk.tdk-lambda.com/cfe
Benchmark
MOSFETs
Part
Number
BVDSS
(V)
RDS(on)
4.5Vgs
(m )
QG
4.5Vgs
(nc)
ID@
25˚C
(A)
Package
IRLS3034-7PPBF 40 1.7 120 240 D2PAK-7
IRLS3034PBF 40 2 108 195 D2PAK
IRLB3034PBF 40 2 108 195 TO-220
IRLP3034PBF 40 2 108 195 TO-247
IRL1404ZSPBF 40 5.9 75 75 D2PAK
IRL1404ZPBF 40 5.9 75 75 TO-220
IRL1104SPBF 40 12 68 104 D2PAK
IRL1104PBF 40 12 68 104 TO-220
IRL3705ZSPBF 55 12 40 75 D2PAK
IRL3705ZPBF 55 12 40 75 TO-220
IRLZ44ZSPBF 55 23 24 51 D2PAK
IRLZ44ZPBF 55 23 24 51 TO-220
IRLZ24NSPBF 55 75 15 18 D2PAK
IRLZ24NPBF 55 75 15 18 TO-220
IRLS3036-7PPBF 60 2.2 110 240 D2PAK-7
IRLS3036PBF 60 2.8 91 195 D2PAK
IRLB3036PBF 60 2.8 91 195 TO-220
IRLS4030-7PPBF 100 4.1 93 190 D2PAK-7
IRLS4030PBF 100 4.5 87 180 D2PAK
IRLB4030PBF 100 4.5 87 180 TO-220
IRL2910SPBF 100 40 140 55 D2PAK
IRL2910PBF 100 40 140 55 TO-220
 THE POWER MANAGEMENT LEADER
Features
Logic
Level
For more information call
+49 (0) 6102 884 311 or visit us at
www.irf.com
Your FIRS
T CHOICE
for Perform
ance
Same Package,
60% More Current
wireless
Military radio gets
4G power gain
RF power optimisation technology developed in
Cambridge for mobile phones has been applied to a
military radio system, writes Steve Bush
ElectronicsWeekly.com16 | EW 7-13 MARCH 2012
C
ambridge Consultants has
adopted novel RF power
technology for a military
radio software-defined
radio (SDR) architecture. Called
ModStar, the architecture relies on
Coolteq from Nujira, also Cambridge-
based, which is a super-fast tracking
switching power-supply technique
that can modulate the supply rail of
an RF power amplifier (PA) to follow
the RF amplitude profile.
The result of Coolteq, which Nujira
sells as modules for base-stations and
chips for phones, is a PA that wastes
less heat because it always operates
with just enough headroom to keep it
linear, and no more.
Software-defined radio copes with
arbitrary modulation schemes at arbi-
trary frequencies
by using broad-
band RF hardware,
fast ADCs and
DACs, and copious
amounts of digital
signal processing.
“In recent years,
defence organisa-
tions around the
world have invest-
ed in a variety of
custom radio sys-
tems, using many different air inter-
faces, to perform specific tasks,” said
Cambridge Consultants (CCL). “A
key challenge for operations today is
ensuring that all of these different air
interfaces can be interoperable in the
field, and that seamless communica-
tions can be conducted on any of the
legacy systems. SDR can provide ex-
actly this capability, delivering sup-
port for multiple air interfaces within
a single, flexible implementation.”
However, SDR radios can be bulky
and less power-efficient than radios
dedicated to particular bands and
modulation. “The ModStar architec-
ture has been designed to enable im-
plementation of SDR modules that
can link multiple communication
platforms in a lightweight device that
would be far more portable for
troops,” claimed CCL. “Portability is
enhanced by Nujira’s efficient enve-
lope tracking technology for power
amplifiers, that can extract double
the power output from a given power
transistor. Equipment and battery
size are minimised by reducing filter-
ing and power consumption require-
ments, allowing smaller form factors
or wider bandwidths to be achieved.”
CCL is making extra use of the fast
PA power supply. “Nujira’s compo-
nent tracks the envelope, and we are
also doing something else with it,”
CCL business development manager
Tim Phipps told Electronics Weekly.
ModStar uses an open loop polar
modulator with non-continuous time
feedback and software pre-distortion.
Non-continuous time feedback com-
pensates for changes in frequency,
temperature and power without the
need for a compli-
cated continuous
time polar loop,
said CCL. The re-
sulting design is an
efficient power
amplifier with
multi-band, multi-
mode operation.
“The polar loop
modulator we have
incorporated into
the ModStar archi-
tecture is an extremely robust tech-
nique that has been used in millions
of mobile phones, that can deliver ex-
ceptional performance with extreme-
ly high reliability for military appli-
cations,” said Phipps.
A proprietary Cartesian-to-polar
conversion ensures continual phase
lock is achieved within the radio and,
according to CCL, zero crossings are
handled with a novel DSP technique.
“The advantage of this architecture is
that the radio design is simplified;
with the most significant design chal-
lenges being moved into the digital
domain, where they can be resolved
with an integrated and scalable solu-
tion. A digital, fractional N synthesis-
er provides a clean reference clock
signal with an inherently low phase
noise,” said the firm.
www.cambridgeconsultants.com
www.nujira.com
Relec Electronics Ltd
Tel: +44 1929 555700 Fax: +44 1929 555701
e-mail: sales@relec.co.uk
www.relec.co.uk
DIN rail ac-dc power supplies
Relec Electronics can supply DIN Rail
power supplies from 10 to 960W in
output power from stock and at extremely
attractive prices. Units are available in single
phase, 3-phase and dc input versions with
output voltages of 5V, 12V, 24V and 48V as
standard. Low profile versions are available
that are only 56mm deep (AMR Series) in
power ratings of 10W, 24W, 36W, 60W and 100W.
DIN rail battery chargers
A range of DIN rail mounted battery
chargers for industrial applications,
available with both ac & dc inputs
for 12V, 24V, 36V & 48V systems.
These provide a low cost solution
where battery back-up is required
and have all of the features to add
external low voltage disconnect relays
and contactors to protect your battery.
DIN rail mounting RFI filters
Relec Electronics offer a range of single
phase and 3-phase EMC filters
designed for DIN rail Mounting.
These EMC filters are designed
specifically for mounting on TS35
DIN rails in industrial control
systems. The FMAB (1-stage) and
FMBB (2-stage - high attenuation) are
suitable for single phase systems, the FMAC
(1-stage) for 3-phase systems and the FMAD series
(1-stage) for 3-phase systems with a neutral conductor.
DIN rail dc-dc power supplies
A range of DIN rail brackets and accessories
for standard dc-dc converters as well as a
range of chassis mounting dc-dc converters
with a DIN rail mounting accessory
bracket. Special mounting brackets
have been developed to accept a
wide range of standard regulated dc-dc
converters with 1 or 2 isolated outputs up to
30W for applications requiring DIN rail mounting
where a bespoke circuit board is not available.
Design solutions for design engineers
www.micrel.com© 2012 Micrel, Inc. All rights reserved.Micrel, Innovation Through Technology and Ripple Blocker are
are trademarks of Micrel, Inc.
Even electronics work better
when they have peace and quiet.
Ideal for use in:
 Medical imaging applications
 Tablet/PC/notebook computers
 Webcams, digital still and video cameras
 Security and surveillancecameras
 Videoconferencing
 Bar code scanners
 Smartphone cameras and RF power
 Global Positioning Systems (GPS)
 Automotive and industrial applications
For more information, contact your local
Micrel sales representative, or visit Micrel at:
www.micrel.com/ad/RippleBlocker/
Realize unmatched PSRR
performance for noise-sensitive
applications.
Ripple Blocker (MIC94300/MIC94310)
attenuates ripple voltage in any power supply
design.
80dB of PSRR at 1kHz
60dB of PSRR at 5MHz
Enable clean system power to increase overall
system performance.
Higher RF transmission signal strength
Increase dynamic signal integrity
Save space and cost when implementing
feature-rich system solutions.
Up to 63% smaller solution than discrete
alternatives
0.8mm x 0.8mm 4 bump, WLCSP
Scan this code to learn more!
Introducing Ripple Blocker™
Power Supply Output Noise Attenuator
power
Search for power efficiency/density
is changing power system design
Steve Oliver explores power circuits design at the system-level to explain the impact of specific
architectural choices on efficiency, physical size and materials cost
ElectronicsWeekly.com18 | EW 7-13 MARCH 2012
Figure 1
T
he basic functions of any
power supply are transforma-
tion (shifting voltage levels),
and regulation. Traditional
power supply architectures co-locate
these functions – and that of isolation
and necessary ancillary functions
such as EMI filtering. The newest
power conversion functional blocks
separate out those basic functions
allowing each to be individually opti-
mised, and performance maximised.
Beyond that, they provide the sys-
tem designer with new degrees of free-
dom; there is greater choice about
where to locate transformation and
regulation – and isolation – in the
power system hierarchy, and much
greater flexibility in managing power
dissipation.
Conversion blocks now operate at
high efficiency but some level of loss
cannot be avoided. By considering the
power architecture as a whole, the de-
signer can not only minimise losses
but, to a significant extent, choose
where they will appear.
Power distribution philosophies
have evolved through several genera-
tions, especially in respect of what
happens on the system cards. In gen-
eral, incoming power, usually AC
mains, is converted to a DC bus, clas-
sically at 48V, that is routed across the
backplane. The line cards (in the tele-
comms system case) transform that
voltage either directly to the power
rails that the card uses or, in newer ar-
chitectures, via two separate steps; a
non-isolated buck/boost regulator fol-
lowed by a fixed-ratio DC-DC convert-
er or current multiplier.
Two steps rather than one might at
first appear to be a retrograde step, but
the cumulative efficiency of the opti-
mised blocks is better than the total of
what went before. A key component
in this mix is the current multiplier or
voltage transformation module; de-
signers can now call on a true “DC
transformer” providing a fixed-ratio
conversion, at well over 93% efficien-
cy, and capable of delivering well over
100A from around 7cm² of PCB area.
When taking the system view, an
important step is recognising that the
48V bus need no longer be regarded as
nominal and variable, but fixed and
indeed, “rock-solid”. Engineers on
past systems had to allow for that
nominal 48V to vary over a wide
range. With a “solid” 48V on the back-
plane, the first converter on the line-
card can be a narrow-input-range
component rather than a wide-range
design. This change alone can reduce
the losses in that function. Wide back-
plane bus voltage was often tolerated
because of having to allow, in high-
availability systems, for switch-over to
an alternate source – batteries or a
local generator.
Taking the system view, adding a
stage of buck/boost regulation to the
stand-by supply, and if necessary im-
proving the regulation performance of
the primary supply’s power entry
module, ensures the provision of the
totally-stable 48V bus. In effect the de-
signer has chosen to re-locate some of
the inescapable losses off the line
card, upstream in the architecture. A
typical analysis can show over 60%
reduction in worst-case intermediate
bus conversion and distribution losses
on the board; and as much as a 3.5%
efficiency improvement under worst-
case input voltage of 36V. That is,
there is a cost to boost the 36V (per-
haps from an under-performing bat-
tery pack) to the stable 48V: but this is
more than offset by the gains in effi-
ciency on the system card when it
draws on a stable input bus. At the
same time, the power density of the
intermediate conversion stage can rise
by as much as 50%.
In the past acceptance of less-than-
perfect DC system buses reflected the
need to design cards and sub-systems
that would be used in the field as up-
grades. Today upgrades have become
rare and the more common scenario is
to replace an entire installation. But
even so, the power available to feed
the cabinet, or room, or building does
not change. It becomes the telecomms
or datacomms specialist’s job to deliv-
er the maximum performance for that
input power: and the task of the
power supply architect to make as
much of the power budget as possible
available to perform the main function
of the backplane. Some tasks become
simpler; the processor that demands
many tens of Amps at under 1V must
have some measure of supply regula-
tion very close to its pins, to handle
massive power transients. Any signifi-
cant length of PCB copper between
the final stage of the power hierarchy
and the CPU cannot be tolerated.
The good news for the power design-
er is that with high-efficiency devices
and the new freedom to relocate loss-
es, thermal design almost ceases to be a
problem. As a proportion of the power
dissipated by the Asic or network proc-
essor, the minimal heat dissipated by
an over-90%-efficient final stage of reg-
ulation can almost be neglected and
becomes a minor part of the thermal
load that mustbe carried away from the
SoC (system-on-chip) device. All of the
power input to a system eventually ap-
pears as heat; the power system archi-
tect now has new methods to ensure
that as much of that energy as possible
has done useful work.
Steve Oliver is marketing and sales vice-
president at Vicor
Vicor
www.vicorpower.com
PCB ASSEMBLY
YOU CAN GET BETTER SERVICE AND PAY LESS TOO!
• Is your PCB assembler too expensive?
• Are they late on delivery?
• Is their quality not good enough?
• Under pressure to get your costs down?
We are PRECISION MANUFACTURING LTD, the expert PCB assembler and box-build speciailist.
We offer a host of low cost solutions using our multiple prototype and high volume production
lines, catering for a huge variety of board sizes, styles and technologies, all based in the UK.
We’ll give you top quality and real cost savings.
Call PML now to find out how you can get a better PCB assembler - and pay less too.
FM569006
www.precision-mfg.co.uk
01604 662736
> Mannerisms:
When Andy Grove
changed Intel’s
mission statement
In September 1999, Andy Grove,
co-founder and the then chairman of
Intel, came to London and announced
that Intel had changed its mission
statement to become the ‘building
block supplier to the Internet econo-
my’ from the old mission statement
which was to be ‘the building block
supplier to the new computer
industry’.
In pursuit of the new mission
statement, Grove said that the
company had invested in 250
companies involved in such diverse
Internet-related activities from
providing optical components
(Bookham Technology) to providing
last minute deals on flights and hotel
rooms (lastminute.com).
Some of Intel’s investments - like
network processor company Softcom
and comms chip supplier Level One -
were for 100 per cent of the compa-
nies, others were for minority stakes.
Collectively, said Grove, the amount
of money spent on theseinvestments
was out-running the amount of money
Intel was investing in its own business.
“The last year we have spent more
money acquiring some seven
companies than we have spent on
capital spending - for the first time
ever : $4 billion on acquisitions, $3
billion on capital spending”, he said.
electronicsweekly.com/mannerisms
> BeagleBoard in the spotlight
Before we launch the March/April 2012 competition, let’s have
another themed roundup of posts... on BeagleBoard matters, the
single-board powered by Texas Instruments and its OMAP3530
system-on-a-chip.
electronicsweekly.com/gadget-master
> Battery capacity label by 31 May
The requirement of the EU Batteries and Accumulators Directive
2006/66/EC that any automotive or portable batteries should
display a capacity label has been extended to 31 May 2012.
electronicsweekly.com/blogs/directivedecoder
> In-car displays to power ahead with 50% growth
Sat-navs and in-console monitors will increase flat panel dispaly
shipments for the automotive segment by nearly 50% to 62 million
units in 2015.
electronicsweekly.com/distributionworld
> JellyBean@Home?
Slashgear considers whether Google’s rumoured software
environments are actually the same thing – Android 5.0.
electronicsweekly.com/blogs/eyes-on-android
the week online
Highlights from
Raspberry Pi with a week to go
A closer look at this capable
cheap educational computer.
electronicsweekly.com/news
What’s in store for ST-
Ericsson?
ST seems finally to have woken up to
the fact that ST-Ericsson is a ticking
timebomb which could wreck it.
electronicsweekly.com/mannerisms
ST top management gets a
bollocking
ST has been the subject of a stinging
note from Arete Research Services.
electronicsweekly.com/mannerisms
SpaceX, Orbital Sciences
prepare for landmarks
The first commercial vehicles
intended to dock with the ISS space
station are making good progress on
their way to launch.
electronicsweekly.com/news
Joining ARM
After leaving ES2, Sir Robin
Saxby got a lot of letters.
electronicsweekly.com/mannerisms
Embedded market goes
ARM crazy
The embedded industry follows the
general trends in electronics for
smaller, less power-hungry and
multicore devices.
electronicsweekly.com/news
4G transmitters will affect TV
reception
In the UK, about 900,000 homes will
be affected.
electronicsweekly.com/news
1
2
3
4
5
6
7
MOST POPULAR BLOG OF THE WEEK
BLOGS
electronicsweekly.com/photo-galleries

Get the latest news via RSS feed
 electronicsweekly.com/rss
PICTURE GALLERIES
Taking a visual angle on stories or
interesting subjects, the galleries
complement Electronics Weekly’s
more traditional text-based articles.
Take a look behind the scenes, and
step through the photos in our
latest galleries.
> 50th anniv. of US orbital space flight
> CES International 2012
> Elektra Awards 2011 - Winners
> Spy-in-the-sky circuit-board glider
test
mi.yokogawa.commi.yokogawa.comwww.tmwww.tm
Test set gets CAN/LIN bus monitor
Electrical safety monitor and vital
signs monitor in handhelds
The Rigel Medi-
cal Med-eKit Lite
(pictured right) is a
handheld vital signs
testing kit, featur-
ing a 288 electrical
safety analyser and
the UNISIM vital
sign simulator.
The instrument
can be used for oper-
ation and test con-
trol of all IEC 62353
and IEC 60601 required electrical
safety tests in manual, semi auto-
matic or fully automatic test modes.
Featuring built-in automated test-
ing, the portable UniSIM is the small-
est simulator capable of undertaking
six tests, enabling medical device en-
gineers to quickly, easily and accu-
rately undertake NIBP, SpO2, ECG,
temperature, IBP and respiration
functionality tests simultaneously
using a single instrument.
www.rigelmedical.com
Test firms combine boundary
scan tester with USB scope
XJTAG and Pico Technology have
collaborated on the development of
a portable boundary scan and oscil-
loscope system.
The system combines XJTAG’s
boundary scan technology with the
digital signal acquisition capabilities
of the Pico Technology oscilloscope.
“As board designs have become
more densely populated, restricted
access to devices such as BGAs
means oscilloscopes continually
have to evolve,” said Simon Payne,
CEO of XJTAG.
“This is the next logical step, com-
bining oscilloscope and boundary
scan technologies,” said Payne. “The
PicoScope software is also well-suit-
ed to this system, as it’s a Windows
program that can run alongside the
XJTAG software on a PC without
modification,” said Alan Tong, man-
aging director, Pico Technology.
Called XJTAG Expert, the system
ElectronicsWeekly.com20 | EW 7-13 MARCH 2012
PRODUCT
FOCUS
has an integrated high speed USB
2.0 to JTAG controller providing a
high speed interface to the
JTAG chain, combined with a
digital oscilloscope, spectrum
analyser, waveform and func-
tion generator and serial pro-
tocol analyser.
It requires two USB ports,
and can supply power to low-
power target systems, which
means that testing can be done
even without a source of
mains power. The unit con-
tains the licence for the
XJTAG system.
www.xjtag.com
www.picotechcom
Signal integrity network analysers
take S-parameter measurements
LeCroy has introduced 8- and 12-port
models of the SPARQ series of signal
integrity network analysers. The
SPARQ makes S-parameter measure-
ments, like a more expensive vector
network analyser.
For example, the 12-port SPARQ is
priced similarly to a 4-port VNA,
claimed the supplier.
All SPARQ models use a built-in
OSLT calibration kit to allow users to
calibrate the analyser and measure
the device under test, without using
calibration standards that are exter-
nal to the instrument.
This means that a user can com-
plete a full 12-port S-parameter meas-
urement in approximately 30 min-
utes with much of that time being
unattended acquisition and calcula-
tion time.
When using a network analyser
with only 4 ports, signal integrity en-
gineers can measure the S-parameters
of only a single differential lane.
“While useful, these measure-
ments only provide a partial under-
standing of circuit behavior, and do
not characterize the crosstalk be-
tween lanes,” said LeCroy.
With the SPARQ-3012E, users can
measure the complete 12-port S-pa-
rameter matrix in both single-ended
and mixed-mode representations.
www.lecroy.com
Carrier aggregation on test
mobile delivers faster data rates
Aeroflex’s TM500 LTE test mobile
supports carrier aggregation, which
ttid.co.uk - for all your instrument needs
As UK distributors for Ametek Programmable
Power we offer DC power supplies and AC
power sources to beyond 300 killowatts.
test
www.anritsu.co. m.com.comwww.anritsuwww.anritsu
Bit error rate analyser gets 28G/32G modules
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 21
PRODUCT
FOCUS
is an important feature of LTE-
 Advanced.
This feature allows multiple carri-
ers comprised of either contiguous or
non-contiguous spectrum to be
added together, allowing wider chan-
nel bandwidths, and faster data rates,
to be achieved.
For LTE-Advanced, 3GPP Release
10 introduced several new features to
augment the existing LTE standard
and to meet or exceed the targets of
the International Telecommunica-
tions Union (ITU) for IMS-Advanced.
These features are aimed at raising
the peak data rate to 1Gbit/s and
 beyond.
Achieving this speed will require a
channel bandwidth that is much
wider than the 20MHz currently
specified for LTE.
This will not be possible with just
a single carrier in the limited spec-
trum bands available to most opera-
tors. Consequently, carrier aggrega-
tion, the ability to combine multiple
carriers scattered around the spec-
trum, will be used to achieve the
wider effective bandwidth that will
be required, typically up to 100MHz.
www.aeroflex.com
TEST & MEASUREMENT
More than ever …
... we need energy, power and our planet. Yokogawa is
the marketleader in innovative test and measurement technologies
focusing on the challenges related to energy conservation, effi ciency
and sustainability Together with our customers we help design, build
and deploy next generation products that increase the quality of life,
productivity and the effi cient use of the world’s resources.
Energy effi ciency in everyday consumer goods, new greener modes of
transport and development of renewable energy sources are some of
the areas where more than ever Yokogawa is changing everyone’s future
for the better. Just take a closer look to the DL850 ScopeCorder
We are working on a sustainable future
For more information on our DL850 ScopeCorder, scan the code
with your smartphone. Or check the website tmi.yokogawa.com.
Or contact Yokogawa Measurement Technologies Ltd on
01928 597200 and ask Andy Barnes for more information.
test
www.agilent.com/find/M81909090gilent.com/find/M81gilent.com/find/M81www.agwww.ag
Waveform generator for 5-7GHz
ElectronicsWeekly.com22 | EW 7-13 MARCH 2012
PRODUCT
FOCUS
136Gbit/s waveform generator
has 16QAM modulation
Southern Photonics has worked with
Micram on the development of a
34GS/s arbitrary waveform generator.
The AWG-34G can be used to gener-
ate high-order complex modulation
formats, such as 16QAM, at speeds of
up to 136Gbit/s.
“Currently available bench-top
AWGs do not have the bandwidth
necessary to meet the needs of future
communications systems develop-
ment,” said John Harvey, CEO of
Southern Photonics. “With Micram’s
fast VEGA signal converter technolo-
gy we are enabling researchers to
generate any high speed multi-level
electronic signal they require, then
convert them into complex modulat-
High performance PSUs
for bench or system
For full information
 visit our web tour at:
aimtti.co.uk/go/ql
The QL Series II is the latest and highest performance linear regulated
power supply series from Aim-TTi, building upon the success of the original
QL series and adding a new 242W triple output model (QL564T).
Very high precision, very low noise, excellent dynamics
Advanced user interface with numeric and rotary control
Multiple voltage/current ranges for increased flexibility
Switchable remote sense provides perfect load regulation
Comprehensive protection including OVP and OCP trips
Extended memories for power supply set-ups steps, up to 110
Compact bench footprint; modular width for rack mounting
Duplicate power and sense terminals at rear (P models)
Auxiliary output now fully variable 1.00V to 6.00V at 3A
with selectable voltage and current metering (T models)
Full voltage set & current readback on auxiliary O/P (-TP models)
Bus programmable via USB, RS232, GPIB and now LAN (P models)
LAN interface is LXI class C compliant
IVI drivers are supplied providing support for common applications such as
LabView, LabWindows, and HP/Agilent VEE.
LXI (Lan eXtensions for Instrumentation) is the LAN
based successor to GPIB, combining the advantages of
Ethernet with the simplicity and familiarity of GPIB.
The TTi laboratory power supply range now includes many models with LXI
support, both Linear and PowerFlex with power from 75W up to 1200W.
Measurably better value
THURLBY THANDAR INSTRUMENTS
Glebe Road, Huntingdon, Cambridgeshire, PE29 7DR
Tel: 01480 412451 e-mail: info@aimtti.com
Web: www.aimtti.co.uk
Trademarks:
LabView/LabWindows - National Instruments;
VEE - Agilent Technologies
THE BEST IN TEST
FOR 25 YEARS
0800 583 4455 www.sjelectronics.co.uk
Electronics Weekly. Quadrant House, The Quadrant, Sutton, Surrey SM2 5AS www.electronicsweekly.com
Editorial 020-8652 8642: Fax: 020-8652 8979 electronics.weekly@rbi.co.uk Publishing director David Wilson,
david.wilson@rbi.co.uk 020 7611 1285 Editor Richard Wilson richard.wilson@rbi.co.uk 020 8652 3650 Components editor
David Manners david.manners@rbi.co.uk 020 8652 3643 Technology editor Steve Bush steve.bush@rbi.co.uk 020 8652 3640
Web editor Alun Williams alun.williams@rbi.co.uk 020 8652 8313 Production editor Sue Proud sue.proud@rbi.co.uk 020 8652
4689 Editorial secretary Alison Noble alison.noble@rbi.co.uk 020 8652 8642 Circulation Customer service advisor 01444
475611 Subscriptions One year UK £102, Europe £133. Rest of the world £165 USA £140 and Canada £152. Please
forward your remittance with subscription order. Electronics Weekly Subscriptions Dept, PO Box 302, Haywards Heath,
West Sussex, RH16 3YY, UK. Tel: 01444 445566 Fax: 01444 445447 | To apply for a free copy of the magazine in print or
digital versions go to: rbisubscribe.com/cc/ewe
Registered at the Post Office as a newspaper. SSN 0013-5224. Electronics Weekly is published by Reed Business Information Limited, Quadrant House, The Quadrant, Sutton, Surrey SM2 5AS ® 2011
Reed Business Information Limited. A member of BPA. Electronics Weekly is a trademark of Reed Business Information Limited.
ADVERTISING: Display Group sales manager Lee De La Rue Browne lee.delaruebrowne@rbi.co.uk 020 8652 3262 Account managers Teo Tansiri teo.tansiri@rbi.co.uk 020 8652
8209: Julie West julie.west@rbi.co.uk 020 8652 3112 Classified Sales executive Paul Roberts 020 8652 8410 paul.roberts@rbi.co.uk
Recruitment recruitment.services@rbi.co.uk 020 8652 3400 Direct copy line Pre-press co-ordinator Dan Long daniel.long@rbi.co.uk 020 8652 3127
products
ElectronicsWeekly.com 7-13 MARCH 2012 EW | 23
ed optical signals using our IQ Trans-
mitter,” said Harvey.
www.southernphotonics.com
Fast serial link analyser can han-
dle many different protocols
Tektronix has introduced a protocol
test platform for high-speed serial
links with data rates up to 10Gbit/s.
According to the supplier, the
TPI4000 protocol analyser will allow
one instrument to be used to perform
multiple test functions and to look
at protocols such as Ethernet, fibre
channel, common public radio in-
terface (CPRI), and serial front panel
data port (FPDP).
The series consists of two models.
The TPI4202 is a portable unit with a
built-in monitor and keyboard and
supports up to eight ports. The
TPI4208 is a 4U rack-mount unit that
supports up to 32 ports. Each can be
configured with options to support
different data rates and protocols.
www.tektronix.com
Power quality analysers measure
energy waste and cost
Fluke has a range of three-phase
power quality analysers which use a
patented algorithm to measure ener-
gy waste and also to quantify its cost.
The 430 series II analyser allows
operators to assess the impact of new
energy-efficient, electronically-
driven systems from lighting to motor
controls to HVAC and calculate the
cost of wasted energy. The analyser
features three new measurement
functions, as well as hardware, soft-
ware and firmware improvements.
New models have up to 32Gbyte
(8Gbyte standard) memory, a swap-
pable SD memory card and USB con-
nectivity for longer power and energy
logging and faster data download.
Both models are compliant with the
stringent international IEC 61000-4-
30 Class-A standard. Each one can
monitor systems with up to 10 power
quality parameters on one screen and
record up to 150 parameters on four
phases simultaneously, meeting the
EN50160 standard, and are safety
rated 600 V CAT IV/1000V CAT III.
www.fluke.com
ollic.comollic.comollic.comwww.atowww.ato
Tool support for Cortex-M0/M3
Sub-1GHz wireless transceiver
has +20dbm output
Silicon Laboratories has a range of
sub-GHz transceivers, the EZRadio-
PRO Si446x transceiver family which
offers a transmit output power of
+20dBm, sensitivity of -126dBm, link
budget of 146dB and RX adjacent
channel selectivity of 58dB.
They also feature an antenna diver-
sity algorithm developed to counter-
act the effects of multipath and fad-
ing, effectively doubling the wireless
range in a multipath/fading environ-
ment. Designed with continuous fre-
quency coverage from 119MHz to
1050MHz, the transceivers support a
number of advanced modulation
techniquesincluding 4GFSK, (G)
FSK, GMSK and OOK, with support
for maximum data rates up to
1Mbit/s (4GFSK).
They achieve a 50nA sleep/
standby current with register reten-
tion. Transmit current specifications
as low as 17mA at +10dBm can be
achieved for coin-cell battery appli-
cations and 85mA at +20dBm for
higher performance applications.
www.silabs.com
24 EW7-13 MARCH 2012 ElectronicsWeekly.com
ARENA TO ADVERTISE CALL 020 8652 8410
www.beta-layout.com
A
ll
re
g
is
te
re
d
b
ra
n
d
s
re
m
a
in
th
e
re
g
is
te
re
d
tr
a
d
e
m
a
rk
s
o
f
th
e
re
sp
e
c
tiv
e
m
a
n
u
fa
c
tu
re
r
!
Free Phone UK: 0800 389 8560
sales@pcb-pool.com
TTT�PMFOFQ@FO@RFQP�@LJ
� RKFNRB�PRFQB�LC�
�OFQFPE�����
J>KRC>@QROFKD�PBOSF@BP
�L�>HBA�
Free Prototype
board, now also
on Aluminium
�K>M
PCB Pool
services
�PH �>SB�
Guaranteed
fast turnaround
service
�BP@RB�
B
Discounted
overrun stock
available online
�>II�RP�LK�
������������
The full range of Spirit’s services are available at
Specialist in
MPCB manufacture
ElectronicsWeekly.com/jobs 7-13 MARCH 2012 EW 25
ULTIMATEDESTINATION
Careers that inspire
OPPORTUNITIES IN PRODUCT DEVELOPMENT
We’re driven by big ideas. Creativity, inspiration and engineering excellence shine through
in every aspect of our new vehicles – raising our standards yet further, and fuelling our
growth in over 170 countries worldwide.
But no matter how exceptional the results we achieve, the drive for perfection never
stops. We’re at the forefront of innovation, with an incredibly diverse and enticing
product mix. And to stay there, we need all kinds of engineers to help us further push
the boundaries in everything from whole vehicle design and infotainment to electrical
engineering and hybrid engines.
Our ceaseless search for great ideas is taking us in some fascinating new directions. If you
want to explore where your thinking could take you, visit www.jaguarlandrovercareers.com
Scan with your QR
reader to visit the
mobile site.
Field Applications Engineers (x3) for Microchip
To help realise our ambitious growth plans for our highly successful semiconductor business, we are expanding our Microchip semiconductor support team. We currently have three vacancies in locations across the UK mainland
for Field Applications Engineers. In these field based roles, you will visit our customers to promote and offer support and guidance in the evaluation, selection and design-in of products from this world class manufacturer.
The successful candidate will demonstrate the ability to:
O Identify and support customers’ new design project needs through in-depth, hands-on technical expertise
 O Liaise with and support our field sales team whilst managing your own design project tracker
 O Identify new customers and develop design-in opportunities, taking ownership of the activity and participating in reviews
 O Work closely with customers’ engineering teams to provide creative and innovative design solutions
 O Align product offers to their appropriate target industrial markets
 O Maintain an active supplier relationship, attend exhibitions & conferences and undertake training sessions
In return we offer:
O Highly attractive salary, car scheme and benefits package
 O Comprehensive training and development programs in the UK, Europe and the United States
 O Exciting prospects for personal growth and career progression in a vibrant and dynamic work environment

Candidates should ideally be qualified to HNC/Degree level in Electronic Engineering, with a proven track record in electronics hardware and software design. You may already be working in a similar role, however we are equally
interested in applications from design engineers currently working ‘at the bench’ who are looking for their next career step in electronics. To apply, please send your CV by email to recruitment@anglia.com or by post to the
address below. However, should you require further information about this position then call Michelene Hircock on 07775 513027.
www.anglia.comSandall Rd, Wisbech, Cambs, PE13 2PS
The UK’s leading independent authorised distributor of electronic components
26 EW7-13 MARCH 2012 ElectronicsWeekly.com
Microchip has a position for a District Sales Manager for the North of England
If you are an experienced Sales Management professional with a history of achievement in the Semiconductor Industry and are looking to join a
market leading and highly successful semiconductor manufacturer, please contact us without delay!
We are also interested in hearing from individuals keen to pursue a pure field sales role.
The Company
Microchip Technology Inc. is a leading provider of microcontroller and analog semiconductors, providing low-risk product development,
lower total system cost and faster time to market for thousands of diverse customer applications worldwide. The company has a turnover of
over $1.4 billion and employs over 7500. For more information, visit the Microchip website at www.microchip.com.
Location
Applicants should ideally reside in the North of England
Job Summaries/Key Attributes
The ideal candidates will:
• Be a highly motivated and results focussed individual.
• Be fully conversant with the UK market for semiconductors.
• Have significant experience of relevant industry selling and/or Marketing experience.
• Ideally have some man management experience (for the DSM position).
Microchip is an equal opportunity employer, and successful candidates for the DSM role can expect:
A competitive salary package, including quarterly Company performance related bonus schemes, a company car or generous car allowance, a new
hire share grant plus an on-going performance related share programme, discounted Microchip share purchase scheme, private medical insurance,
21 days paid holiday per year and a contributory Pension Scheme.
To apply
Please send your CV and letter of application to europe.humanresources@microchip.com
or apply via our website at www.microchip.com/careers
No Agencies
H.R. Microchip Ltd, Microchip House, 720 Wharfedale Road, IQ Winnersh, Wokingham, Berkshire, UK, RG41 5TP
District Sales Manager – North of England
www.microchip.com
The Microchip name and logo are registered trademarks of Microchip Technology Incorporated in the USA and other countries. ©2012 Microchip Technology Inc. All rights reserved. REC141UK/02.12
RECRUITMENT PARTNER OF CHOICE
On the same wavelength
or on a different frequency?
We’re JAM and we’re specialists in recruiting for Electronics and Semiconductor roles. We like to really get to know our candidates so
we can match you to the right job and right company and we’ll keep you informed throughout the process. But don’t just take our word
for it, take a look at what some of our candidates and clients have said about us…
“I’ve worked with JAM over the past year or so on some
challenging briefs. They have strong technical knowledge
and have been able to match our requirements to high
quality candidates. I’d highly recommend them.”
Chris, Embedded Software Engineer, Yorkshire

“Despite job specifications that were very specific, and for
roles that were difficult to fill, JAM succeeded in finding me
strong candidates. I would recommend JAM to any company
looking to recruit electronics professionals.”
Simon, Electronics Design Engineer, South East
“I was very impressed by JAM’s professionalism and by the quality
of search they conducted. The candidates presented were all
very strong and matched our requirements. Communication
between the company and the candidates has been flawless
and professional.”
Timothy, Software Engineer, West Midlands
“Sound knowledge, quick processes and honest communication.
Every time we work together my expectations are exceeded –
I would have no hesitation in recommending them.”
Jennifer, Systems Engineer, North West
0845 050 5522
info@jamrecruitment.co.uk
www.jamrecruitment.co.uk
ElectronicsWeekly.com/jobs 7-13 MARCH 2012 EW 27
technical | commercial| executive | permanent | contract
true technology specialists
0118 988 1150 | enquiry@ic-groupltd.com | www.ic-groupltd.com
European Recruitment Ltd (ERL) are industry leaders in the Wireless, Handsets,
Chipsets and Networks – Software & Hardware Engineering, ICT and Oil & Gas
sectors. Our expertise lies in finding all levels of candidates so the client has a
complete solution to their needs. Our consultants specialises in finding technical
experts from junior level up to senior managers.
Example clients: Intel Mobile, Qualcomm, NVIDIA, Renesas Mobile, Anritsu,
Anite, R&S, CSR, PA Consulting and many more.
For testimonials and a list of our latest vacancies please visit
www.eu-recruit.com
Contact +44 (0) 1273 957 888 or info@eu-recruit.com
Wireless, Software & Hardware
Engineering, ICT, Oil & Gas
ELECTRONICS & SOFTWARE SYSTEMS
RECRUITMENT SPECIALISTS
Defence, Automotive, Aerospace, Marine, Telecoms,
Consumer Electronics & Medical Device markets
electronics@matchtech.com
01489 898883
Knowledge is better than guesswork
For the industry’s best, contact Redline.
www.Redlineplc.com
Tel: 01582 450054
Engineering, Science & Technology Recruitment
UniversityWay, Cranfield Technology Park, MK43 0BT
01234 436 136
post@vrl.co.uk
www.vrl.co.uk
Vector –TheTechnology Specialists.We are all Engineers & Scientists,
so we understand you and your needs and we get it right!
Whether you are job hunting or recruiting staff, talk to the experts!
JAM provides Permanent, Contract and Recruitment Process Outsourcing
solu�ons to some of the UK’s most successful organisa�ons.
Your Recruitment Partner in
Electronics & Semiconductors
We’re passionate about our clients, our services and our people; our
passion for the industry has helped us become the specialist recruitment
company we are today.
To see our latest opportuni�es visit www.jamrecruitment.co.uk or to talk
to one of our specialist consultants please call 0845 050 5522.
Email: recruitment.services@rbi.co.uk UK Tel: +44 (0)20 8652 3400
RECRUITMENT CONSULTANCIES INDEX
ωωω.ρτρσ.χο.υκ
ελεχτρονιχσωεεκλψ≅ρτρσ.χο.υκ
01925 821133
ΡΤΡΣ αρε προυδ το βε α παρτ οφ Εϖολυτιον, ωιννερσ οφ τηε
Βεστ Ινδυστρψ Κνοωλεδγε ατ τηε ρεχεντ ΡεχρυιτΡανκ αωαρδσ.
񡖉 Ελεχτρονιχσ & Εμβεδδεδ Αππλιχατιονσ
񡖉 ΙΤ & Τελεχομμυνιχατιονσ
񡖉 Αεροσπαχε ανδ Δεφενχε
񡖉 Μεδιχαλ, Ωιρελεσσ, Χελλυλαρ & Σχιεντι! χ
񡖉 Αυτομοτιϖε, Χοντρολ ανδ Μονιτορινγ Σψστεμσ
񡖉 Εντερταινμεντ ανδ Μυλτιμεδια Σψστεμσ
ΤΗΕ ΡΕΑΛ−ΤΙΜΕ ΡΕΧΡΥΙΤΜΕΝΤ ΣΠΕΧΙΑΛΙΣΤΣ:
