815


PROBLEM 13.189
When the rope is at an angle of 30α = ° the 1-kg sphere A has
a speed 0 0.6 m/s.v = The coefficient of restitution between A
and the 2-kg wedge B is 0.8 and the length of rope 0.9 ml =
The spring constant has a value of 1500 N/m and 20 .θ = °
Determine, (a) the velocities of A and B immediately after the
impact (b) the maximum deflection of the spring assuming A
does not strike B again before this point.

SOLUTION
Masses: 1 kg
2 kg
A
B
m
m
=
=

Analysis of sphere A as it swings down:
Initial state: 030 , (1 cos ) (0.9)(1 cos30 ) 0.12058 mh lα α= ° = − = − ° =

0 0
2 2
0 0
(1)(9.81)(0.12058) 1.1829 N m
1 1
(1)(0.6) 0.180 N m
2 2
AV m gh
T mv
= = = ⋅
= = = ⋅

Just before impact: 1 10, 0, 0h Vα = = =
 2 2 2
1
1 1
(1) 0.5
2 2A A A AT m v v v= = =
Conservation of energy: 0 0 1 1T V T V+ = +

2
2 2 2
0.180 1.1829 0.5 0
2.7257 m /s
A
A
v
v
+ = +
=

 1.6510 m/sA =v
Analysis of the impact: Use conservation of momentum together with the coefficient of restitution. 0.8.e =

Note that the ball rebounds horizontally and that an impulse Tdt is applied by the rope. Also, an impulse
Ndt is applied to B through its supports.
