Blood Supply of Human
Gingiva Following
Periodontal Surgery
A Fluorescein Angiographic Study
by
WERNER MORMANN, D.M.D.*
SEBASTIAN G . CIANCIO, D.D .s.†
T H E VASCULAR supply of gingival tissues during and
subsequent to periodontal surgery is critical to the
healing of the tissue. Most studies of the blood supply
of gingiva have been done in animals or on human
cadavers, and have shown that the blood supply to the
free and attached gingiva is derived mainly from the
supraperiosteal vessels 1 2 while the periodontal liga­
ment is supplied by vessels perforating the alveolar
bone proper. 3 K i n d l o v a 4 , 5 described anastomoses be­
tween vessels of the gingiva and periodontal ligament,
though the capillaries were arranged differently in each
of these two networks. In the normal periodontium of
different laboratory animals, connections between gin­
gival and periodontal ligament vessels were seldom
observed. 6
The independence of the gingival and periodontal
ligament blood supplies also has been demonstrated
functionally. Occlusion of vessels in the periodontal
ligament does not effect the blood supply of the
gingiva 7 and occlusion of arterioles supplying the gin­
giva does not appear to alter the blood supply of the
periodontal ligament. 8 However, in the latter study,
the initial revascularization of the gingiva was derived
from vessels of the periodontal ligament, thus demon­
strating a potential for extensive collateral circulation
to the gingiva from the periodontal ligament. Garfun-
kel and Sciaky 9 have made a similar observation in
describing the vasculature of the gingiva and periodon­
tal ligament. Kennedy 1 0 also showed that when specific
needs arise a compensatory blood supply can be pro­
vided easily.
The distribution pattern of the vessels in human
jaws was studied by Hayashi 1 1 using carmine gelatin.
He found a richer blood supply in the upper jaw, with
more vascularization on the lingual periosteal aspects
of both upper and lower jaws than the buccal, though
the anterior teeth were an exception to this rule.
Cohen 1 2 injected the same dye into the common carotid
artery to study the vascular architecture of the cat
mandible and demonstrated that the blood supply to
the periodontal ligament emanates from three different
sources; namely, alveolar bone, gingiva and apical
arteries.
Techniques to study gingival capillary architecture
and function have been reviewed by Clemmesen 1 3 and
Gehrke et a l . 1 4 Recently, a fluorescence vital micros­
copy method was used for repeated in vivo examination
of vascular patterns in the buccal gingiva of cats and
dogs . 1 5 , 1 6
The use of fluorescein angiography to observe the
blood circulation in healthy and inflamed gingiva in
man was described by Mormann and Lu tz . 1 7 The
method allowed successful evaluation of functional
conditions in the gingival capillary bed. Sodium fluo­
rescein was selected to study the circulation in view of
its widespread use in medicine. 1 8 The 5th edition of
Goodman and Gilman's text 1 9 states that its diagnostic
usefulness lies in its fluorescent properties and that
untoward effects are minimal. When they do occur,
they are limited to nausea and vomiting. Our experi­
ence with this agent resulted in only one patient
experiencing mild nausea.
The purpose of the present study was to use fluores­
cein angiography in humans in order to observe altera­
tions in gingival circulation following various modifica­
tions of mucogingival flap design.
The rationale for this approach was to confirm, in
humans, previous animal findings concerning pathways
of gingival circulation as well as to provide additional
information relative to current concepts of periodontal
flap design.
MATERIALS AND METHODS
Injection Technique
A l l patients received an intravenous injection of 2
ml of 20% sodium fluorescein at 24 hours after the
surgical procedure. Employing a rapid injection ante-
cubital venipuncture technique an adequate fluorescein
concentration occurred during the first passage of the
dye through the gingival vasculature. After 15 to 20
seconds, the Na-fluorescein entered the gingival capil­
lary system. A n initial photographic sequence of 15
exposures showed that the intracapillary phase of the
fluorescein labeling occurred 15 seconds after the
beginning of the injection. The fluorescein was then
allowed to permeate through the vessel walls and to
diffuse evenly into the gingival tissue. Additional pho­
tographs were taken 1, 3, 5 and 10 minutes after
injection, to document postangiographic plasma fluid
diffusion.
Photographic Technique
The principles of fluorescein angiography of the
gingiva have been described p rev ious ly . 1 7 , 2 0 - 2 3 In this
study a new photographic system was used (Fig. 1).
* Department of Cariology and Periodontology, Dental Institute,
University of Zurich, Zurich, Switzerland.
† Department of Periodontology, School of Dentistry, State Uni­
versity of New York at Buffalo, 3435 Main St., Buffalo, N Y .
681
Highlight
Highlight
682 Mormann, Ciancio
J. Periodontol.
November, 1977
The system consisted of a Zeiss operating microscope
with a newly constructed integral coaxial electron
strobe light (720 W sec), an integral halogen pilot
light (100 W) and a monitoring Zeiss power and
electronic timer unit. Optimal harmonizing of the Zeiss
emulsion (485 nm) and absorption (520 nm) filters
provided fluorescein angiographs of high contrast. K o ­
dak Ektachrome High Speed film was used and proc­
essed at 800 A S A .
Eight subjects with an age range of 20 to 50 (4 male
and 4 female) were included in this study. A l l surgical
procedures described were performed under local infil-
FIGURE 1. Z = Zeiss operating microscope, and 0 2
separate optical systems, and M 2 motor driven cameras, F
= focusing knob, H = height dial, HP = head positioner,
WB = removable individual wax bite, LR = lip retractor, CS
= chin support, ST = standardizing device.
FIGURE 2. Schematic drawing of gingival blood supply and
experimental dissection by a horizontal incision running in the
facial attached gingiva extending to bone in Subject A and
dissection of the gingivo-periodontal anastomosis incision in
Subject B.
FIGURE 3. Subject A. Angiograph 24 hours after full thickness horizontal incision running in attached gingiva of the lower
anterior region indicated by thick vertical black arrows. Long white arrows show central anemia, short arrows show zones of
partial blood supply by collateral circulation, clear zones: normal blood supply.
683 Blood Supply of Human Gingiva
Volume 48
Number 11
tration anesthesia (Xylocaine with 1:80,000 epineph­
rine). Silk sutures (5.0) were placed wherever a flap
was raised. A l l flaps were covered with a periodontal
dressing which was removed at the time of photogra­
phy.
In subject A a horizontal incision extending to bone
was made at the mucogingival junction in the area of
the mandibular incisors. The purpose of this procedure
was to determine the effect of dissecting the supraper-
iosteal gingival vessels at the mucogingival junction on
gingival blood circulation coronal to the incision as
shown in the schematic drawing (Fig. 2).
In subject B an internal bevel incision extending to
bone was made as shown in F ig . 2. This surgical
procedure was carried out at two sites: The facial
aspect of the mandibular right central incisor and the
facial papilla between the mandibular left central and
lateral incisors (Fig. 5). The purpose of this procedure
was to determine the effect of dissecting the anasto­
mosis between the gingival and the periodontal vessels
at the gingival margin.
In subject C the incisions for a full thickness flap
were made extending to bone in the mandibular right
anterior region but the flap was not raised. Between
the mandibular left incisors the same incisions were
made and a labial full thickness replacedflap was
raised (Fig. 7). The purpose of this experimental
procedure was to evaluate the effect on circulation of
raising a flap.
In subject D two labial full thickness replaced flaps
FIGURE 4. Subject A. Clinical aspect 48 hours after horizontal incision. Three areas of superficial necrosis coronal to horizontal
incision (arrows).
FIGURE 5. Subject B. Clinical view immediately after internally beveled incisions (IBI), BL = blood.
684 Mörmann, Ciancio
J. Periodontal.
November, 1977
were raised. Between the mandibular right incisors the
vertical incisions extended to the mucogingival junc­
tion. Between the mandibular left incisors the vertical
incisions were twice as long, extending beyond the
mucogingival junction (Fig. 10). The purpose of this
design was to determine the effect of the length of the
incision and the ratio of length to width on gingival
flap blood supply in replaced full thickness flaps.
In subject E two labial laterally positioned flap
procedures were performed to cover areas of recession
over the mandibular right and left lateral incisors.
Both flaps were prepared with an experimental flap
design so that they were partial thickness in their
coronal half and full thickness in their apical position
(Fig. 13). Both flaps had approximately the same
length but the base of the right flap (NF) was narrower
than that of the left (BF) in terms of the relationship
of flap base to length. This design allowed an evalua­
tion of the role of the width of the base/flap length.
In subject F a laterally positioned flap was placed
over an area of recession on the labial aspect of the
maxillary left cuspid (Fig. 16). The coronal half of the
flap was partial thickness and the apical half was full
thickness. The flap was designed so that its base was
less than ½ of its length. Flap mobilization was easy
because of its length. The purpose of this design was
to determine the effect on blood supply of overextend-
ing the length of a flap.
FIGURE 6. Subject B. Angiograph 24 hours after internally bevelled incisions (IBI).
FIGURE 7. Subject C. Clinical view 24 hours after surgery; vertical incisions as for a full thickness flap (I) and actual raised full
thickness flap ( F F ) .
Highlight
685 Blood Supply of Human Gingiva Volume 48
Number 11
FIGURE 8. Subject C. Angiograph 24 hours after surgery showing disturbance of capillary blood supply (arrows) at incision sites
(I) and in the area of the raised full thickness flap ( F F ) .
FIGURE 9. Subject C, angiograph 96 hours after surgery showing still more areas of repair at raised and retracted full thickness
flap ( F F , arrows).
In subject G the same flap as that described for
subjects E and F was positioned over an area of
recession on the buccal of the maxillary right first
premolar (Fig. 19). This flap differed from that for
subject E in that its base lay in a zone of attached
gingiva which had been widened by a free graft of
palatal mucosa 3 months ago. Therefore this flap had
less mobility than the others described. Consequently,
in being laterally positioned the flap was bent with
traction force needed to fix it to the recipient site.
Tension was exerted by the sutures as they held the
flap in place. With this design the combined effect of
tension and flexion on the flap's blood circulation
could be evaluated.
RESULTS
Subject A
The horizontal incision in subject A was evaluated
24 hours after it was made (Fig. 3). A t this time a
disturbance in gingival blood supply was present coro­
nal to the incision. This suggests that the blood flow to
the gingiva was mainly in an apical to coronal direction.
When the blood vessels were dissected horizontally, a
collateral circulation was not initially established in the
gingival areas coronal to the horizontal incision as
shown in the 24-hour angiograph (Fig. 3). Clinically
the horizontal incision resulted in local superficial
gingival necrosis in the same region of angiographic
686 Mörmann, Ciancio
J. Periodontal.
November, 1977
circulation disturbance 48 hours after it was made
(Fig-4) .
Subject B
The internal bevel incisions in subject B are angio-
graphically shown 24 hours later (Fig. 6). A t 24 hours
no changes were seen in gingival circulation. This
suggests that the blood supply to the gingival tissues
was adequate even when the blood vessels from the
papillary and periosteal area were severed.
Subject C
The incisions and flap in subject C are shown angio-
graphically (Fig. 8) at 24 hours after surgery. Both
areas showed a disturbance in circulation (Fig. 8);
however, examination of the angiographs shows that
circulation was reduced by about 50% at the site
where the full thickness flap was both raised and
retracted. A t 96 hours both wounds appeared clinically
similar. However, the vascular pattern of the area
along the incision lines of the raised flap was still
poorer than that of the "nonelevated flap" (Fig. 9).
Subject D
In subject D the flap with the longer vertical incisions
showed a poorer revascularization at 24, 48 and 96
hours (Figs. 10, 11, 12). The poorer revascularization
of the longer flap (LF) resulted in a triangular, cleft­
like tissue loss at its marginal edges of approximately 2
mm as indicated by the vertical dotted lines in Figs.
10, 11 and 12. A s can be seen from the photographs,
the short flap (SF) showed less circulation disturbance
FIGURE 10. Subject D, angiograph 24 hours after surgery . Short full thickness replaced flap (SF). Long full thickness replaced
flap ( L F ) . Distances A , B, C , D from cemento-enamel junction to respective flap margins. Arrows indicate clinical flap outline
and area of subsequent necrosis.
FIGURE 11. Subject D, angiograph 96 hours after surgery. Increased tissue loss at long flap (LF) as indicated by C and D ' .
687 Blood Supply of Human Gingiva
Volume 48
Number 11
FIGURE 12. Subject D, angiograph 96 hours after surgery. Increased tissue loss at long flap ( L F ) as indicated by C " and D " .
FIGURE 13. Subject E, clinical aspect immediately following surgery, narrow based partial split thickness flap ( N F ) and broad
based partial split thickness flap ( B F ) .
and a better healing of the gingival margin than the
long flap ( L F ) .
Subject E
In subject E at 24 hours (Figs. 13, 14) the flap on
the right with the narrow base (NF) showed a reduced
circulation of approximately 50%. The flap with the
wide base (BF) showed less disturbance. A t 7 days
(Fig. 15), the vascular pattern in both flaps was the
same. After 7 days (Fig. 15) a cleft-like tissue loss
(TL) was discernible at the gingival margin of the
narrow based flap. Healing of the gingival margin at
the wide based flap showed an acceptable gingival
margin with minimal clef ting.
Subject F
In subject F minimal tension and flexion was neces­
sary to position and fix the overlong flap laterally.
Nevertheless, a small ischemic mark (N) was produced
by the suture (Fig. 17). A l so , the vascular pattern in
the flap was good at 24 hours (Fig. 17) and 7 days
(Fig. 18), new circulation in the donor site (DS).
Subject G
In subject G the flap was bent into position and
tension was exerted by the suture to hold the flap in
place. A t 24 hours no vascularization was present in
the flap (Fig. 19). A t 5 days the flap had sloughed
away from the root surface (Fig. 20).
688 Mörmann, Ciancio
J. Periodontal.
November, 1977
FIGURE 14. Subject E, angiograph 24 hours after surgery. Fifty percent circulation only in narrow based flap ( N F ) , clinical
outline of flap indicated by arrows. Eighty percent circulation in broad based flap ( F B ) .
FIGURE 15. Subject E, angiograph 7 days after surgery. More tissue loss ( T L ) at the narrow flap ( N F ) than at the broad flap
( B F ) . New vascularization in the donor site (DS) .
DISCUSSION
The effect of various types of surgical procedures on
the gingival capillaryblood circulation was evaluated
by means of fluorescein angiography. The circulation
changes observed suggested that flaps receive their
major blood supply from their apical aspects. The full
thickness incision in clinically healthy gingiva revealed
that, functionally, the blood supply was mainly directed
caudocranially from the vestibule to the gingival mar­
gin. This is consistent with the morphological findings
in animals by K i n d l o v a 4 , 5 and the histologic findings in
mongrel dogs of Novaes et a l . 2 4
In a fluorescein angiographic study on the gingival
blood circulation with experimental full thickness inci­
sions in humans, vascular disturbances were observed.
They resulted in superficial necrosis in those areas
coronal to the incisions. 2 3 These findings indicate that
main gingival vessels may have been severed in these
regions. Ryan , 2 5 in another human study, reported
that the blood supply of skin is not homogenous. Our
angiographic observations suggest that the same is true
for human gingiva.
In this study, the internal bevelled incision (subject
B) severed the anastomosis between gingival and peri­
odontal vasculature and between gingival and interden­
tal vasculature. Angiographically, the separations from
689 Blood Supply of Human Gingiva
Volume 48
Number 11
either vasculatures showed no effect on circulation of
the free and alveolar gingiva. This finding verifies the
results of circulation measurements in man, which
have shown that gingival and periodontal vessels are
independent of each other. 2 6 - 2 8
The flaps raised in patient D suggest that the greater
the ratio of flap length to base, the greater is the
amount of vascular disturbance. These findings corrob­
orate previous animal studies of pedicle flaps on the
backs of rabbits, 2 9 which indicated that the intrinsic
circulation of the flap is maintained up to the point
where the ratio of the length to width of the simple
parallel pedicle flap is 2:1. Regarding the design of the
flap, these findings suggest that the broader the flap
base, the better is its circulation pattern. This was also
stated by Patterson 3 0 who described a series of experi­
ments in the flank of the pig in which pedicle flaps
were raised. He found that randomly placed pedicle
grafts had a constant 34% reduction in survival length
when compared with control flaps designed to include
a major artery. Kon et a l . , 3 1 using a carbon black
perfusion technique in dogs, found histologically that
the main vessels had been maintained within broad
full thickness flaps during raising and retracting the
flap. In subject C , raising and retracting a full thickness
flap affected an approximate 50% disturbance of the
superficial capillary circulation.
In subjects E to G these principles were tested in
FIGURE 16. Subject F, clinical aspect immediately following surgery. Overextension in length of experimental flap design. Easy
mobilization of flap and minimal tension placed on flap by suturing.
FIGURE 17. Subject F, angiograph 24 hours after surgery. Good flap circulation. Small necrosis area (N) caused by sutures.
Tissue loss at flap end ( T L ) . Donor site ( D S ) .
690 Mörmann, Ciancio J. Periodontol.
November, 1977
FIGURE 18. Subject F, angiograph 7 days after surgery. Some tissue loss at flap end ( T L ) . Good circulation in maintained part of
flap end. Slightly advanced re- and neo vascularization of donor site (DS) .
FIGURE 19. Subject G, angiograph 24 hours after surgery. No circulation in flap area.
lateral sliding flap procedures. These operations were
similar to those described by a number of other inves­
tigators 3 2 - 3 9 and were modified slightly to test the
effects of various modalities on their circulation. The
results in these subjects suggest that sliding flaps should
be sufficiently extended into the alveolar mucosa to
provide adequate mobilization. Myer et a l . 4 0 found, in
the dog, that pedicle grafts under tension which dem­
onstrated complete vascular filling retained their vital­
ity for 3 or 4 days after surgery. However, Gl ickman 4 1
stated that excess tension and bending impair the
circulation when the flap is moved. Regarding the
failure of the flap in subject G , tension was certainly
involved, and persisting changes in the vasculature
caused by the previous operation may have played a
role also in that mobility was decreased. R y a n 2 5 re­
ported that skin graft sites can develop areas of dimin­
ished resistance to further surgery.
A full thickness or partial thickness preparation may
be used in lateral sliding f l aps . 3 5 , 3 6 In the donor site a
loss of bone (0.5 mm) and recession (1.5 mm) is
reported with full thickness f l aps . 3 3 , 4 1 Therefore, at
the donor site a partial thickness flap is preferable
because it offers the advantage of more rapid healing
and reduces the risk of postsurgical recession, particu­
larly if the bone is thin or a dehiscence or fenestration
is suspected. However, if the gingiva is thin, partial
thickness may not be sufficient for flap survival . 3 3 , 3 8 A
691 Blood Supply of Human Gingiva Volume 48
Number 11
FIGURE 20. Subject G, angiograph 5 days after surgery. The flap sloughed away from the root surface.
study on pig skin showed that thick pedicle flaps
separated from their wound beds had a 55.7% survival
rate whereas thin flaps separated from their wound
bed had a 26.5% survival rate. 4 2 This study also
showed that the survival of thin flaps is dependent on
the vascular quality of the recipient site. These findings
are in agreement with histologic impressions reported
by Staffileno et a l . 4 3 and may explain the excellent
healing they reported for split thickness flaps reposi­
tioned to their original position. Compared to these
sites, a thin flap cannot provide nutrition for the
grafted tissue if its own blood supply is inadequate.
Therefore, partial thickness flaps or parts of flaps
which are designed to cover an avascular area should
not be prepared too thin. The success of the very long
partial thickness flap in this study in subject F can be
explained by its full thickness preparation in its apical
part which may have preserved a major gingival vessel
inside the flap and by the relative thickness of the
partial thickness dissection.
CONCLUSIONS
This study demonstrates changes in the gingival
vascular supply of humans following various periodon­
tal surgical procedures. A special system was used to
photograph circulatory changes following an i.v. injec­
tion of sodium fluorescein to visualize blood supply.
The results of this study suggest that the following
concepts are important in the design of periodontal
flaps.
1. Flaps should be broad enough at their base to
include major gingival vessels.
2. A flap's length to width ratio should not exceed 2:1.
3. Minimal tension should be produced by suturing
techniques and the tissue should be managed gently
during the surgical procedure.
4. Partial thickness flap preparations to cover avas­
cular areas should not be too thin so that more blood
vessels are included in them.
5. The apical portion of periodontal flaps should be
full thickness when possible.
ACKNOWLEDGMENTS
The authors wish to acknowledge the support of the Zeiss
Company, Zurich, Switzerland, the technical advice of Dr.
Walter H . Lang, Director, Medical Optical Department,
Zeiss Company, Oberkochen, West Germany, and the clini­
cal assistance of Dr. Andre Bachmann.
REFERENCES
1. Folke, L . E . , and Stallard, R. E . : Periodontal microcir­
culation as revealed by plastic microspheres. J Periodont Res
2: 53,1967.
2. Keller, G . H . , and Cohen, D. W.: India ink perfusions
of the vascular plexus of oral tissues. Oral Surg 8: 539, 1955.
3. Castelli, W. C , and Dempster, W. T.: The periodontal
vasculature and its response to experimental pressure. J Am
Dent Assoc 70: 890, 1965.
4. Kindlova, M. : The blood supply of the marginal perio­
dontium in macacus Rhesus, Arch Oral Biol 10: 869, 1965.
5. Kindlova, M . : Gefassversorgung des Marginalparodon-
tium bei Zahnen eines bleibenden Typus. Stoma (Heidelb)
19: 84,1966.
6. Carranza, F. A . , Jr., Itoiz, M . E . , Cabrini, R. L . , and
Dotto, C. A . : A study of periodontal vascularization in
different laboratory animals. J Periodont Res 1: 120, 1966.
7. Goldman, H . M . : Gingival vascular supply in induced
occlusal traumatism. Oral Surg 9: 936, 1956.
8. Kennedy, J.: Experimental ischemia in monkeys. II.
Vascular response. J Dent Res 48: 888, 1969.
9. Garfunkel, A . , and Sciaky, I.: Vascularization of the
periodontal tissues in the adult laboratory rat. J Dent Res
50: 880,1971.
10. Kennedy, J.: Effects of inflammation of collateral
circulation of the gingiva. J Periodont Res 9: 147, 1974.
11. Hayashi, S.: Untersuchungen über die arterielle Blut-
versorgung des Periodontiums. Dtsch Mschr Zahnheilkd 50:
145,1932.
692 Mörmann, Ciando
J. Periodontal.
November, 1977
12. Cohen, L . : Methods of investigating the vascular
architecture of the mandible. J Dent Res 38: 920, 1959.
13. Clemmesen, Th.: The early circulation in split skin
grafts. Acta Chir Scand 127: 1, 1964.
14. Gehrke, V . , Lange, D. , and Altenhof, H . : Histo-
chemische Untersuchung zur Gefässarchitektonik der men­
schlichen Gingiva. Dtsch zahnärztl Z 26: 586, 1971.
15. Hock, J.: Gingival vasculature around erupting teeth.
J Clin Periodontol 2: 44, 1975.
16. Wayland, H . , and Hock, J.: Application of fluorescein
vital microscopy to the vasculature around eruption teeth.
Microvasc Res 7: 201, 1974.
17. Mörmann, W., and Lutz, F.: Fluoreszenzangiographie
der Gingiva. Acta Parodontol Schweiz Monatsschr Zahn-
heilkd 84: 798, 1974.
18. Wessing, A . : Fluoreszenzangiographie der Retina.
Stuttgart, Georg Thieme Verlag, 1968.
19. Goodman, L . S., and Gilman, A. : The Pharmacolog­
ical Basis of Therapeutics, ed 5, p 394. New York, Macmil-
land Publishers Co., Inc., 1975.
20. Mörmann, W., Bernimoulin, J.-P., and Schmid, M .
O.: Fluorescein angiography of free gingival autografts. J
Clin Periodontol 2: 177. 1975.
21. Mörmann. W., and Bernimoulin, J.-P.: Possibilités
offenes par Tangiographie fluorescéinique en parodontolo-
gie. Actual Odontostomatol (Paris) 109: 105. 1975.
22. Mörmann, W., Schmid, M . O. , and Bernimoulin. J.-
P.: Fluoreszenzangiographische Untersuchung der Blutzirk­
ulation im MukosaSpaltlappen bei der Vestibulumplastik
nach Edlan und Méjchar. Dtsch zahnärztl Z 30: 171. 1975.
23. Mörmann, W.. and Meier, Ch.: Die Förderung der
Revaskularisation von Gingivadefektwunden durch eine
Haftsalbe. 1977, in prep.
24. Novaes, A . B., Kon, S., Ruben, M . P.. and Goldman.
H . M . : Visualization of microvascularization of the healing
periodontal wound. V. Periosteum retention technique of
mucogingival surgery. J Periodontol 41: 685, 1970.
25. Ryan, T. J.: Pathophysiology of skin capillaries. Int J
Dermatol 14: 708, 1975.
26. Hofmann, M . : Zur Oszillographie des Gingivapulses.
Dtsch zahnärztl Z 19: 765, 1964.
27. Körber, K. H . : Untersuchungen zur Physiologie des
parodontalen Gefässystems. Dtsch zahnärztl Z 18: 1092,
1963.
28. Körber, K. H . : Periodontal pulsation. J Periodontol
41:382, 1970.
29. Ohmori, S., and Kurata, K.: Experimental studies on
the blood supply to various types of skingrafts in rabbits
using isotope P 3 2 . Plast Reconstr Surg 25: 547, 1960.
30. Patterson, T.: The survival of skin flaps in the pig. Br
J Plast Surg 21: 113, 1968.
31. Kon, S., Novaes, A . B., Ruben, M . P., and Goldman,
H . M . : Visualization of the healing periodontal wound. IV.
Mucogingival surgery: Full thickness flap. J Periodontol 40:
441,1969.
32. Albano, E . A . , Caffesse, R. G . , and Carranza, F.
A . , Jr.: A biometric analysis of laterally displaced pedicle
flaps. Rev Asoc Odont Argent 57: 351, 1969.
33. Bhaskar, S. N . , Cutright, D. E . , Beasley, J. D . ,
Perez, B., and Hunsuck, E . E . : Healing under four types of
mucogingival flaps. Programs and abstracts, J Am Dent
Assoc 48th General Meeting, 1970. p. 100.
34. Ebert, J. R., and Ratcliff, P. A . : An analysis of the
vascular supply of pedicle grafts. Periodontal Abstr 19: 57,
1971.
35. Grupe, H . E . : Modified technique for the sliding flap
operation. J Periodontol 37: 491, 1966.
36. Grupe, H . E . , and Warren, R.: Repair of gingival
defects by a sliding flap operation. J Periodontol 27: 92,
1956.
37. Sullivan, H . C Dinner, D. . and Carman, D.: Clinical
evaluation of the laterally positioned flap. I.A.D.R Abstr
No. 466, p 169, 1971.
38. Tisot. R. J . , and Sullivan. H . C : Evaluation of the
survival of partial thickness and full thickness flaps. I .A.D.R
Abstr No 470. p 170. 1971.
39. Wilderman, M . , and Wentz, F.: Repair of a dentogin-
gival defect with a pedicle flap. J Periodontol 36: 218, 1965.
40. Myers, B. . Combs. B.. and Cohen. G. : Wound ten­
sion and wound sloughs. Am J Surg 27: 303, 1961.
41. Glickman, J.: Clinical Periodontology. ed 4, p 753.
Philadelphia and London, Saunders, 1972.
42. Clodius, L . . and Smahel, J.: Thin and thick pedicle
flap. Acta Chirplast 14: 30. 1972.
43. Satffileno, H . , Levy, S., and Gargiulo, A . : Histologic
study of cellular mobilization and repair following a perios­
teal retention operation via split thickness mucogingival flap
surgery. J Periodontol 37: 117, 1966.
Announcement
T H E SIR WILFRED FISH R E S E A R C H PRIZE
The 'Sir Wilfred Fish Research Prize' was instituted in 1970 by The
British Society of Periodontology with the object of promoting
periodontal research by young workers. The prize of £100 will be
awarded annually where appropriate.
The research work should have an application to periodontology
and must be unpublished. Individuals may compete either on their
own behalf or on behalf of a research group. Eligibility is limited to
those under the age of 40.
A short list will be drawn up from the manuscripts submitted to the
Panel of Judges. Entrants who reach the short list will be expected to
present their work, at their own expense, in the form of a paper of
fifteen minutes duration, followed by a 10-minute discussion period,
during the Society's International Meeting to be held at the Europa
Hotel, London, England on 3rd and 4th of April, 1978. The final
selection will be made on the content and presentation of the work.
The closing date for receipt of manuscripts (three copies) which
must be submitted to the Honorary Secretary, is 31st January 1978.
Honorary Secretary:
H . D. G L E N W R I G H T
The Dental School,
St. Chad's Queensway,
Birmingham, B4 6NN,
England.
