GE Transportation
GE OHV AC Control System
Events, Historical Counters and
Profiles Information
Document No. GEK-91756, Rev. C
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
ii GE Proprietary and Confidential Information
© 2017 General Electric Company. All rights reserved. The information contained in this publication is the property of
General Electric Company and is disclosed in confidence. This publication is intended for use by GE customers solely
for purposes of operating and performing routine maintenance of purchased or licensed GE products, and it shall
not be reproduced, redistributed, retransmitted, translated, abridged, adapted, condensed, revised or otherwise
modified, in any form, in whole or in part, or used for any other purpose, or disclosed to third parties, without the
express written consent of GE. However, if a GE customer (“Customer”) requires additional copies of this publication
or portions thereof for internal use, GE hereby grants to Customer a limited right to reproduce this publication, in
whole or in part, and Customer agrees to use such authorized copies (“Copies”) solely for its intended purposes. Any
Copies made under this limited reproduction right shall contain this notice and any other legal notices appearing in
this publication. The Customer shall be responsible for complying with U.S. export control laws with respect to distri-
bution of all Copies.
GE and Customer agree that the information contained herein does not purport to cover all details or variations in
GE products or to provide for every possible contingency with installation, operation or maintenance. Should further
information be desired or should particular problems arise that are not covered sufficiently for the user’s purposes,
the matter should be referred to General Electric Company. Any applicable Federal, State or local regulations or
company safety or operating rules must take precedence over any information or instructions given in the Technical
Documentation. GE has no obligation to keep the material up to date after the original publication.
GENERAL ELECTRIC COMPANY EXPLICITLY DISCLAIMS ALL WARRANTIES OF ACCURACY, MERCHANTABILITY OR FIT-
NESS FOR ANY PURPOSE IN CONNECTION WITH THIS PUBLICATION AND USE THEREOF.
If you are not an authorized recipient of this publication, you are hereby notified that any perusal, use, distribution,
copying or disclosure is strictly prohibited. If you have received this publication in error, please immediately return to
GE at the following address: GE Transportation, Technical Publications Department, Building 14, 2901 East Lake Rd.,
Erie, PA 16531.
Revision History
Rev Date By Description
NEW Apr 2013 TLB Initial release of publication.
A June 2013 TLB Updates to format, addition of tables, large text changes, added Invertex Ie and
II information.
B Feb-2015 GEM Revised Table 1., DPSC Event List through Table 7., Mine Historical Statistical
Data Profiles as per Workflow: 126932325.
C Feb-2017 RKS Updated the Section 2.1., DSC/PSC EVENT LIST (000 - 099), 2.2., INVERTER EVENT
LIST (XX00 - XX99), 2.3., ADDITIONAL SYSTEM EVENTS/DSC EVENT LIST (500 -
599), 2.4., DSC/TCI EVENT LIST (600 - 699) and 3., HISTORICAL DATA COUNTERS.
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
TABLE OF CONTENTS
Section Page
1. GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. EVENT LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1. DSC/PSC EVENT LIST (000 - 099) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2. INVERTER EVENT LIST (Xx00 - Xx99) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.3. ADDITIONAL SYSTEM EVENTS/DSC EVENT LIST (500 - 599) . . . . . . . . . . . . . . . . . . . . . . . . . . 119
2.4. DSC/TCI EVENT LIST (600 - 699) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
3. HISTORICAL DATA COUNTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
3.1. MINE HISTORICAL COUNTERS (301 - 399) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
3.2. DSC AND PSC HISTORICAL EVENT COUNTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
3.3. INVERTER 1 HISTORICAL EVENT COUNTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
3.4. INVERTER 2 HISTORICAL EVENT COUNTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
3.5. DSC AND TCI HISTORICAL EVENT COUNTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
4. HISTORICAL PROFILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
4.1. MINE HISTORICAL STATISTICAL DATA PROFILES (401 - 441) . . . . . . . . . . . . . . . . . . . . . . . . . 143
GE Proprietary and Confidential Information iii
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
This page intentionally left blank.
iv GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
1. GENERAL INFORMATION
1.1. INTRODUCTION
This publication details information retained by the GE OHV AC Control System.
This Control System may have an Invertex I, Invertex Ie, or Invertex II computer system. Invertex I and Ie have two
CPU cards: Propulsion System Control (PSC) and Truck Control Interface (TCI). Truck information is communicated
between and stored on the two cards. Later truck models may have the Invertex II computer system. Trucks
equipped with Invertex II have one CPU card: the Drive System Controller (DSC). The DSC CPU card is a consolidation
of the PSC and TCI CPU cards, thus the DSC CPU card will generate the same events as the PSC and TCI CPU cards.
The event lists within this publication apply to all three computer systems.
GE recommends that saved information (Events and Historical Counters and Profiles) be regularly downloaded as
part of a maintenance program to ensure continuity of truck history.
Revisions are Indicated by Margin Bars
GE Proprietary and Confidential Information 1
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
This page intentionally left blank.
2 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2. EVENT LISTS
The Event Lists are separated in to four categories: DSC/PSC Event List (000 - 099), Inverter Events (Xx00 - Xx99),
Additional System Events/DSC Events (500 - 599), and DSC/TCI Event List (600 - 699). These categories are the four
control areas that Events are identified by the Control System and active Events are displayed on the DID panel.
Events are notification that an unusual situation or limits of the Control System have been exceeded. Events may not
affect the truck operation and are informational Events only. Other Events, frequently referred to as Faults, may
restrict or inhibit truck operation.
The categories of the Event Tables are:
1. EVENT # - This column represents the three digit code event.
2. SUBCODE - This column represents the sub-codes for each Event #.
3. EVENT DESCRIPTION - This column describes the parameters monitored for each Event.
4. RESTRICTION- This column describes the control system action resulting from an Event. Restrictions have been
defined for each Event List section.
5. CAUSE OR DEFINITION — A brief description of likely causes of the Event.
6. AUTO RESET — This column defines if the control system will reset a particular Event and continue operating.
7. OPER. RESET — This column display if the Operator is able to reset a restrictive Event and how many times the
Operator can reset the particular Event. Zero (0) represents the operator is not required or unable to reset a par-
ticular Event.
2.1. DSC/PSC EVENT LIST (000 - 099)
2.1.1. RESTRICTIONS
This restriction is associated with the detection of the given event.
Possible restrictions associated with a PSC event are defined as follows:
Table 1. Restrictions
RESTRICTION OR ACTION DEFINITION OF RESTRICTED STATES
NO_PROPEL ”NO PROPEL” (Red) light illuminated in operator Cab. No propulsion effort
allowed, however, retard effort and DC link energization allowed.
NO_POWER ”NO RETARD” (Red) Light illuminated in operator Cab. No Propulsion effort
and No retard effort allowed. DC Link is de-energized.
SPD_LIM /
SYSWARN
”Propel System Caution” (Yellow) light illuminated in operator Cab. Propel,
Retard and DC link energization still allowed. The truck is under a speed limit
restriction of 10/15 MPH (16/24KPH).
SPDLIM_LOW Speed limit set to lower speed point of 5 MPH(8KPH).
INVx_OFF When Active, prohibits the system from enabling Inverter X’s run drive
signal.
GE Proprietary and Confidential Information 3
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Note: For Restriction, wherever ramps are indicated, timing for Short ramp is Zero second, Medium Ramp is 1.2
seconds and Long Ramp is 2.4 second.
2.1.2. DSC/PSC Event List (000 - 099)
The following is the Event List for the DSC/PSC propulsion portion of the Control System.
Table 2. DSC/PSC Event List
ENGSPD_ RP When Active, raises the engine speed to account for a possible stuck RP
contactor/chopper, and closes RP1/CM1
SYSEVENT There are no Restrictions. Event is for informational purposes only.
DELAYED_SHTDWN Indicates a NO_PROPEL/NO_RETARD is imminent. Note, delayed shutdown
restrictions have an Operator Override feature where after the truck comes
to a stop the operator can operate the truck with a 50% torque de-rate and
5 MPH(8KPH) speed limit by holding down the Dump Override / Reset switch.
Unloaded truck can be operated for 5 minutes and loaded truck can be
moved 100M or 3 minutes. RETARD NOT AVAILABLE IN THIS MODE.
LOADBOX_DIS Loadbox is disabled.
NO_RETARD Retard mode is restricted.
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
2 1 Ground Fault
NO_POWER
(long ramp)
Power cable or traction motor
fields current leakage to
ground exceeded limit
NO 1
3 1
Excessive Alterna-
tor Field Transient
NO_POWER
(short ramp)
AC Ripple in alternator DC
excitation power
NO 1
4 1
GF Cutout or Propel
Lockout – GF Cutout
Active
SYSEVENT GF Cutout Switch Active NO 0
4 2
CF Cutout or Propel
Lockout – Prop lock-
out Active
SYSEVENT Propel Lockout Switch is Active NO 0
4 3
CF Cutout or Propel
Lockout – Prop
lockout Error
SYSEVENT Propel Lockout Switch Error NO 0
5 1
Drive System Over-
temp - AFSE
NO_PROPEL
(long_ramp)
The AFSE panel indicates high
temperature (measured)
NO 0
5 2
Drive System Over-
temp – Aux. Inverter
NO_PROPEL
(long_ramp)
Aux Inverter (if equipped) indi-
cates
high temperature
NO 0
Table 1. Restrictions
4 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
5
3
Drive System Over-
temp – Aux. Phase
Control
NO_PROPEL
(long_ramp)
Aux Blower (if equipped)
phase control indicates high
temperature
NO 0
5 4
Drive System Over-
temp - Alternator
NO_PROPEL
(long_ramp)
Alternator indicates over tem-
perature (calculated)
NO 0
5 5
Drive System Over-
temp - Left Stator
NO_PROPEL
(long_ramp)
TM1 (left) stator indicates high
temperature (calculated)
NO 0
5 6
Drive System Over-
temp - Left Rotor
NO_PROPEL
(long_ramp)
TM1 (left) rotor indicates high
temperature (calculated)
NO 0
5 7
Drive System Over-
temp - Right Stator
NO_PROPEL
(long_ramp)
TM2 (right) stator indicates
high temperature (calculated)
NO 0
5 8
Drive System Over-
temp - Right Rotor
NO_PROPEL
(long_ramp)
TM2 (right) rotor indicates
high temperature (calculated)
NO 0
5 9
Drive System Over-
temp – Chopper
Module
NO_PROPEL
(long_ramp)
CM1 or CM2 indicates Chop-
per
Module IGBT high temperature
(calculated)
NO 0
5 10
Drive System Over-
temp – Chopper
Diode
NO_PROPEL
(long_ramp)
CD1 or CD2 indicates Chopper
diode high temperature
(calculated)
NO 0
5 11
Drive System Over-
temp – Left Phase
Module
NO_PROPEL
(long_ramp)
Inverter 1 indicates high
phase module temperature
(calculated)
NO 0
5 12
Drive System Over-
temp - Left Diode
NO_PROPEL
(long_ramp)
Inverter 1 indicates high diode
temperature (calculated)
NO 0
5 13
Drive System Over-
temp – Right Phase
Module
NO_PROPEL
(long_ramp)
Inverter 2 indicates high
phase module temperature
(calculated)
NO 0
5 14
Drive System Over-
temp - Right Diode
NO_PROPEL
(long_ramp)
Inverter 2 indicates high diode
temperature (calculated)
NO 0
5 15
Drive System Over-
temp - Rectifier
Diode
NO_PROPEL
(long_ramp)
A diode within the Rectifier
Diode panel or Rectifier Diode
module indicates high tem-
perature(Calculated)
NO 0
5 28
Drive System Over-
temp – H-Bridge Pri-
mary
NO_PROPEL
(long_ramp)
H-Bridge Primary indicates
high temperature(calculated)
NO 0
5 29
Drive System Over-
temp – H-Bridge
Secondary
NO_PROPEL
(long_ramp)
H-Bridge secondary indicates
high temperature(calculated)
NO 0
5 30
Drive System Over-
temp – Transformer
Primary
NO_PROPEL
(long_ramp)
Transformer Primary RTD indi-
cates high temperature(RTD)
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 5
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
5 31
Drive System Over-
temp – Transformer
Secondary
NO_PROPEL
(long_ramp)
Transformer secondary RTD
indicates high tempera-
ture(RTD)
NO 0
5 32
Drive System Over-
temp – CBI 1(Con-
trol) IGBT
NO_PROPEL
(long_ramp)
Control group cooling blower
inverter 1 IGBT indicates high
temperature (calculated)
NO 0
5 33
Drive System Over-
temp – CBI 1(Con-
trol) Diode
NO_PROPEL
(long_ramp)
Control group cooling blower
inverter 1 Diode indicates high
temperature (calculated)
NO 0
5 34
Drive System Over-
temp – CBI 2 (Wheel)
IGBT
NO_PROPEL
(long_ramp)
Wheel motor cooling blower
inverter2 IGBT indicates high
temperature (calculated)
NO 0
5 35
Drive System Over-
temp – CBI 2 (Wheel)
Diode
NO_PROPEL
(long_ramp)
Wheel motor cooling blower
inverter2 Diode indicates high
temperature (calculated)
NO 0
5 36
Drive System Over-
temp – CBI 3 (Grid 1)
IGBT
NO_PROPEL
(long_ramp)
Grid motor 1 -cooling blower
invereter3 IGBT indicates high
temperature (calculated)
NO 0
5 37
Drive System Over-
temp - CBI 3 (Grid 1)
Diode
NO_PROPEL
(long_ramp)
Grid motor 1 -cooling blower
invereter3 Diode indicates
high temperature (calculated)
NO 0
5 38
Drive System Over-
temp - CBI 4 (Grid 2)
IGBT
NO_PROPEL
(long_ramp)
Grid motor 2 -cooling blower
invereter4 IGBT indicates high
temperature (calculated)
NO 0
5 39
Drive System Over-
temp - CBI 4 (Grid 2)
Diode
NO_PROPEL
(long_ramp)
Grid motor 2 -cooling blower
invereter4 Diode indicates
high temperature (calculated)
NO 0
6 1
Both Inverter Comm
Failed – Inv. Comm
Fault
NO_POWER
(med ramp)
Communications failure
between DSC or PSC and both
Inverter CPU cards
NO 2
7 1
Alternator Field
Grounded
SPD_LIM
Alternator Field circuit
grounded
NO 1
8 1
DC Link Overvolt-
age– Not in Retard
NO_POWER
(short ramp)
Over voltage occurred on the
DC Link while in the PROPEL or
NO MOTION mode.
NO 2
8 2
DC Link Overvolt-
age – In Retard
NO_POWER
(short ramp)
Over voltage condition
occurred on the DC Link while
in the RETARD mode
NO 2
8 3
DC Link Overvolt-
age - Instantaneous
NO_POWER
(short ramp)
Instantaneous over
voltage condition occurred in
the DC Link (regardless of
operating mode)
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
6 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
9 1
Alt Field Overcur-
rent – Normal
NO_POWER
(short ramp)
Alternator field excitation
current excessive for an
extended period
NO 2
9 2
Alt Field Overcur-
rent - Instantaneous
NO_POWER
(short ramp)
Alternator field excitation
current instantaneously
excessive
NO 2
9 3
Alt Field Overcur-
rent – Low eng
speed
NO_POWER
(short ramp)
Alternator field excitation
current excessive for low
engine RPM
NO 2
9 4
Alt Field Overcur-
rent – Instant – Low
Eng Spd
NO_POWER
(short ramp)
Alternator field excitation
current instantaneously
excessive for low engine RPM
NO 2
10 1
H-Bridge Fault –
Failed to turn on
INV3_OFF
DAB (H-bridge) failed to turn
on
NO 2
11 1
Retard Lever Bad –
Voltage too high
SYSEVENT
The feedback from the Retard
Lever (if equipped) is higher
than expected
NO 0
11 2
Retard Lever Bad –
Voltage too low
SYSEVENT
The feedback from the Retard
Lever (if equipped) is lower
than expected
NO 0
12 1
Retard Pedal Bad –
Voltage too High
SYSEVENT
Retard Pedal feedback higher
than expected
NO 0
12 2
Retard Pedal Bad –
Voltage too Low
SYSEVENT
Retard Pedal feedback lower
than expected
NO 0
13 1
Midvolt Failure – Pri-
mary LinkV Too High
NO_POWER
(med ramp)
Mid–Volt Test was disabled
due to Primary DC Link volts
being out of range
YES 2
13 2
Midvolt Failure –
Secondary LinkV
Too High
NO_POWER
(med ramp)
Mid–Volt Test was disabled
due to Secondary DC Link volts
being out of range
YES 2
14 1
Analog Sensor Fault
– Alt Field Amps
SPD_LIM
The Alternator field current is
out of the expected range
NO 0
14 2
Analog Sensor Fault
– Link I - Range
SPD_LIM
The DC Link current is out of
the expected range
NO 0
14 3
Analog Sensor Fault
– GRID I - Range
SPD_LIM
Load box current is out of the
expected range
NO 0
14 4
Analog Sensor Fault
– 3 Phase Alt Volts
SPD_LIM
Alternator three phase output
voltage is out of expected
range
NO 0
14 5
Analog Sensor Fault
– Alt Field Volts
SPD_LIM
Alternator excitation field
voltage is out of expected
range
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 7
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
14 10
Analog Sensor Fault
– PSC Link Volts
SPD_LIM
DC Link voltage is out of
expected range
NO 0
14 11
Analog Sensor Fault
– INV1 Link Volts
SPD_LIM
Voltage to Inverter 1 is out of
expected range
NO 0
14 12
Analog Sensor Fault
– INV2 Link Volts
SPD_LIM
Voltage to Inverter 2 is out of
expected range
NO 0
14 13
Analog Sensor Fault
– Ground Fault
SPD_LIM
The ground connection to the
DSC or PSC Analog I/O card
has been lost
NO 0
14 14
Analog Sensor Fault
– Gain Check
SPD_LIM
The 10 volt DC power to the
DSC or PSC Analog I/O card
has been lost
NO 0
14 15
Analog Sensor Fault
– Ground Fault Cur-
rent
SPD_LIM
The ground fault amps output
from DSC or PSC Analog I/O
card is out of range
NO 0
14 16
Analog Sensor Fault
– ATOC ma
SPD_LIM
Alternator tertiary amps from
DSC or PSC Analog I/O card is
out of
expected range
NO 0
14 21
Analog Sensor Fault
– Blower 1 Amps
SPD_LIM
The grid blower motor 1
current is out of expected
range
NO 0
14 22
Analog Sensor Fault
– Blower 2 Amps
SPD_LIM
The grid blower motor 2 (if
equipped) current is out of
expected range
NO 0
15 2
Analog Sensor Fault
(restrictive) – Link
Amps
NO_POWER
(med ramp)
The DC Link current is out of
expected range
NO 2
16 1
System CPU Fault
(FB147/ FB174 –
Task 1
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 2
System CPU Fault
(FB147/ FB174 ) –
Task2
NO_POWER
(med ramp)
PSC CPU card problem
detected
NO 2
16 3
System CPU Fault
(FB147/ FB174 –
 Task 3
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 4
System CPU Fault
(FB147/ FB174 ) –
Task 4
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 5
System CPU Fault
(FB147/ FB174 ) –
Task 5
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
8 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
16 6
System CPU Fault
(FB147/ FB174 ) –
Task 6
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 7
System CPU Fault
(FB147/ FB174 ) –
Flash CRC
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 9
System CPU Fault
(FB147/ FB174 ) –
Maint Task
NO_POWER
(med ramp)
 PSC CPU card problem
detected
NO 2
16 10
System CPU Fault
(FB147/ FB174 ) –
Excess Timeouts
NO_POWER
(med ramp)
 PSC CPU card software or I/O
communication
NO 2
16 11
System CPU Fault
(FB147/ FB174 ) –
Invalid pointers
NO_POWER
(med ramp)
 PSC CPU card initialization
problem
NO 2
16 12
System CPU Fault
(FB147/ FB174 ) –
BRAM CRC
NO_POWER
(med ramp)
 PSC CPU card BRAM Problem NO 2
17 1
Digital I/O Card
Fault ( FB104)
NO_POWER
(med ramp)
DSC or PSC CPU card has lost
communication with DSC or
TCI Digital I/O card
NO 2
18 1
Analog I/O Card
Fault ( FB143) – No
Response
NO_POWER
(med_ramp)
(2700 only)
DSC or PSC Analog I/O card is
missing or not seated in the
card slot
NO 2
18 2
Analog I/O Card
Fault ( FB143) – Ana-
log Card Timeout
NO_POWER
(med_ramp)
(2700 only)
DSC or PSC CPU card has lost
communication with DSC or
TCI Analog I/O card
NO 2
19 1
Incorrect Hillstart
Sequence – Riding
retard pedal
SYS_EVENT
Acceleration Pedal and
Retard/Brake Pedal are both
activated above 7 mph (11.2
kph)
NO 0
19 2
Incorrect Hillstart
Sequence – Exces-
sive roll back
SYS_EVENT
Excessive rollback when
attempting to Hillstart
NO 0
20 1
High Torque Time-
out – Low Speed
NO_PROPEL
(long_ramp)
One of the Traction Motors
(TM1 or TM2) has time out on a
high torque level
NO 0
21 1
TCI Comm fault – No
periodic data
NO_PROPEL
(med ramp)
No periodic data received
from TCI for 1 second
YES 0
22 1
Persistent TCI Comm
Fault – No periodic
data while stopped
NO_POWER
(short ramp)
Persistent communication loss
with TCI
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 9
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
23 Tertiary Overcurrent
NO_POWER
(short ramp)
The Tertiary single phase AC
alternator output current is
high
NO 2
24 1
GE Config File – File
Not Loaded
NO_POWER
(long_ramp)
DSC or PSC CPU Card does not
detect a valid configuration
file loaded
NO 0
24 3
GE Config File –
Wrong version
loaded
NO_POWER
(long_ramp)
DSC or PSC CPU Card does not
detect a valid configuration
file loaded
NO 0
24 4
GE Config File –
Overspeed settings
incorrect
NO_POWER
(long_ramp)
Overspeed settings incorrect NO 0
24 5
GE Config File –
Panel type does not
match config
NO_POWER
(long_ramp)
Software panel type does not
match actual pane l(config
issue)
NO 0
24 6
GE Config File –
Error in config file
NO_POWER
(long_ramp)
Error in config file NO 0
24 7
GE Config File – DAB
requires 190B1 or
later hw
NO_POWER
(long_ramp)
Dual Active Bridge for second-
ary DC bus needs 190B1or
later hardware
NO 0
 24 8
GE Config File –
FL489 requires
190C1 or later card
NO_POWER
(long_ramp)
FL489 requires 190C1 or later
card
NO 0
24 9
GE Config File – Old
Version
NO_POWER
(long_ramp)
Config File - Old Version NO 0
24 10
GE Config File – Sta-
tex Config not
loaded
NO_POWER
(long_ramp)
Statex config file not loaded NO 0
24 11
GE Config File –
Config requires a
license
NO_POWER
(long_ramp)
Configuration requires a
License
NO 0
24 12
GE Config File –
Mine code not set
NO_POWER
(long_ramp)
Mine code not set (RM&D only) NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
10 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
25 1
Aux Blower System
– Not running
NO_POWER
(med ramp)
2700, 150, or
200
The Aux Blower system not
running
NO 2
25 2
Aux Blower System
– Numerous Shut-
downs
NO_POWER
(med ramp)
2700, 150, or
200
The Aux Blower system has
numerous shutdowns
NO 2
26 1
Filter cap overpres-
sure – Inv 1
NO_POWER
(med ramp)
(930E-1/2 only)
Capacitor in Inverter 1
system over pressure
(930E-1/2 only)
NO 0
26 2
Filter cap overpres-
sure – Inv 2
NO_POWER
(med ramp)
(930E-1/2
only)
Capacitor in Inverter 2
system over pressure
(930E-1/2 only)
NO 0
27 1
Connection Error -
CNFB
NO_POWER
(med ramp)
One or more of the ICP panel
connectors (CNA - CNF) is not
connected or loose
NO 2
27 2
Connection Error –
CNI/CNX (3500 NP/
150 T)
NO_POWER
(med ramp)
One or more of the CNX (CNX1
- CNX5) connectors is not
connected or loose
NO 2
27 3
Connection Error –
Aux Blower Connec-
tor
NO_POWER
(med ramp)
Aux Bower (if equipped)
CNXFB connector is not
connected or loose
NO 2
28 1
Hyd Blower System
Fault – Not Running
SPD_LIM
Hydraulic blower system Not
OK or no speed feedback
NO 1
29
Bad Direction Com-
mand
NO_PROPEL
(mid ramp)
Torque Command polarity
does not match direction
request for an extended time
NO 1
30 GF Contactor SPD_LIM
GF contactor and
feedback do not agree
NO 2
31 1
Battery Boost Circuit
– GFR Failed to Open
SPD_LIM GFR failed to open NO 2
31 2
Battery Boost Circuit
– GFR Failed to
Close, R1 Open, or
AFSE SCR3 failure
SPD_LIM
GFR commanded to close
with AFSE enabled but no DC
Link power
NO 2
31 3
Battery Boost- SCR3
Failed
SPD_LIM AFSE panel or SCR3 shorted NO 2
32 1 RP Contactor – RP 1
SPD_LIM &
ENGSPD_RP
RP1 comand does not match
the RP1 feedback (aux contact
if used or calculated)
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 11
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
32 2 RP Contactor – RP2
SPD_LIM &
ENGSPD_RP
RP2 comand does not match
the RP2 feedback (aux contact
if used or calculated)
NO 2
32 3 RP Contactor – RP3
SPD_LIM &
ENGSPD_RP
RP3 comand does not match
the RP3 feedback (aux contact
if used or calculated)
NO 2
33 1
RP or Chopper HP
Balance – May be
shorted/stuck
SPD_LIM &
ENGSPD_RP
HP Imbalance due to Chopper
Module shorted/ RP contactor
stuck
NO 2
33 2
RP or Chopper HP
Balance – Choppers
stuck on
SPD_LIM &
ENGSPD_RP
HP Imbalance due to Chopper
Module on
without CM2 closure
NO 2
34 1
Retard Power Cir-
cuit – Detected High
Chopper Percent ON
– RP2 may not have
closed
SPD_LIM
Detected High Chopper
Percent ON - CM2/RP2 may be
inoperable
NO 2
34 2
Retard Power Cir-
cuit – Overvoltage
Protection Active
SPD_LIM
Overvoltage Protection Active
- CM2/RP2 may be inoperable
NO 2
34 3
Retard Power Cir-
cuit – Link Discharg-
ing Error – RP2 may
not have closed
SPD_LIM
Link Discharging Error - CM2/
RP2 may be inoperable
NO 2
34 4
Retard Power Cir-
cuit – Choppers
stuck on
SPD_LIM A Chopper Module is stuck on NO 2
35 Engine Speed Input SPD_LIM
The Engine Speed Sensor (ESS)
is out of the expected range
NO 0
36 1
Grid Blower – Blower
1 stall
NO_POWER
(long ramp)
Grid Blower Motor 1 Stall
(excessive current)
NO 2
36 2
Grid Blower – Blower
2 stall
NO_POWER
(long ramp)
Grid Blower Motor 2 (if
equipped) Stall (excessive
current)
NO 2
36 3
Grid Blower – Blower
1 open
NO_POWER
(long ramp)
Grid Motor 1 open circuit or
DC Link and Inverter
Imbalance
NO 2
36 4
Grid Blower – Blower
2 open
NO_POWER
(long ramp)
Grid Motor 2 (if equipped)
open circuit or DC Link and
Inverter imbalance
NO 2
36 5
Grid Blower – Blower
1 & 2 delta too large
NO_POWER
(long ramp)
The current of BM1 and BM2 (if
equipped) unequal
NO 2
36 7
Grid Blower – Blow-
ers off with grid I
NO_POWER
(long ramp)
Grid current without
blower operation
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
12 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
36 8
Grid Blower – AC
Blower speed too
low
NO_POWER
(long ramp)
AC Grid blower speed is too
low
NO 2
37 1
Logic Power Supply
– +5V
SPD_LIM
Positive (+) 5 VDC power
supply fault
NO 0
37 2
Logic Power Supply
– +15V
SPD_LIM
Positive (+) 15 VDC power
supply fault
NO 0
37 3
Logic Power Supply
– -15V
SPD_LIM
Negative (–) 15 VDC power
supply fault
NO 0
37 4
Logic Power Supply
– +24V
SPD_LIM
Positive (+) 24 VDC power
supply fault
NO 0
37 5
Logic Power Supply
– -24V
SPD_LIM
Negative (–) 24 VDC power
supply fault
NO 0
38 1
Logic Power Supply
(instant) – +5V
SPD_LIM
Positive (+) 5 VDC power
supply fault
NO 2
38 2
Logic Power Supply
(instant) - +15V
SPD_LIM
Positive (+) 15 VDC power
supply fault
NO 2
38 3
Logic Power Supply
(instant) - -15V
SPD_LIM
Negative (–) 15 VDC power
supply fault
NO 2
38 4
Logic Power Supply
(instant) - +24V
SPD_LIM
Positive (+) 24 VDC power
supply fault
NO 2
38 5
Logic Power Supply
(instant) - -24V
SPD_LIM
Negative (–) 24 VDC power
supply fault
NO 2
39 1
Grid Blower I Delta
Too Large
SPD_LIM
Delta current between dc grid
blower 1 and blower 2 is too
high
NO 2
40 1
Grid Current w/o
Blowers – Measured
GRIDI
NO_PROPEL
(long_ramp)
Grid current without required
grid blower speed
NO 0
41 1
Shorter Chopper
Suspected – Amps >
than Expected
SPD_LIM ENG-
SPD_RP LDBX-
_DIS
Suspect shorted chopper NO 2
42 1
Direction Requested
in Selfload
NO_PROPEL
(med_ramp)
A truck direction (forward or
reverse) was selected while in
Load Box mode
NO 0
43 1
Propulsion Battery
Voltage Low –
Engine Off
SPD_LIM
Battery power from the truck
batteries is below 20VDC with
Engine OFF
NO 0
43 2
Propulsion Battery
Voltage Low –
Engine On
SPD_LIM
Battery power from the truck
batteries is below 20VDC with
Engine ON
NO 0
44 1
Propulsion Battery
Voltage High
SYSEVENT
Battery power from the truck
batteries is above 35VDC
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 13
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
45 1
Chopper Open Cir-
cuit – Chopper 1
SPD_LIM
Chopper Module 1 (CM1) Open
Circuit
NO 0
45 2
Chopper Open Cir-
cuit – Chopper 2
SPD_LIM
Chopper Module 2 (CM2) Open
Circuit
NO 0
45 3
Chopper Open Cir-
cuit – Chopper 3
SPD_LIM
Chopper Module 3 (CM3) Open
Circuit
NO 0
45 4
Chopper Open Cir-
cuit – Chopper 4
SPD_LIM
Chopper Module 4 (CM4) Open
Circuit
NO 0
46 1 Retard Circuit Short
SPD_LIM ENG-
SPD_RP
A short between DC Link and
Dynamic Retarding resistors,
(speed & RPM reduced)
NO 0
47 1 Engine Stall
NO_POWER
(med ramp)
Restrictive, The engine RPM
has dropped below minimum
allowable RPM
NO 2
48 1
DC Link Charging
Error - Shorted DC
Link at Startup
NO_POWER
(short ramp)
The DC Link voltage remained
below 50
VDC after battery boost
enabled
YES 2
48 2
DC Link Charging
Error –AFSE Com-
mand at full for too
long
NO_POWER
(short ramp)
AFSE Command at Full for too
long
YES 2
49 1
Loss of Comm -
Engine CAN Network
SPDLIM_LOW
LOADBOX_DIS
Loss of communication -
engine CAN network
NO 0
50 1
Loss of Comm - OEM
CAN Network
SYSEVENT
Loss of communication – OEM
CAN network
NO 0
51 1
Tach Left Rear –
Zero While Moving
INV1_OFF
Left rear wheel SS1
indicates zero speed while
other
speed sensors indicate speed
NO 0
51 2
Tach Left Rear –
High While Stopped
INV1_OFF
Left rear wheel SS1
indicates speed while other
speed sensors indicate 0
NO 0
52 1
Tach Right Rear –
Zero While Moving
INV2_OFF
Right rear wheel SS2
indicates zero speed while
other
speed sensors indicate speed
NO 0
52 2
Tach Right Rear –
Zero While Moving
INV2_OFF
Right rear wheel SS2
indicates speed while other
speed sensors indicate 0
NO 0
53 1
Tach Left Front –
Zero While Moving
SYSEVENT
Left front wheel SS3
indicates zero speed while
other
speed sensors indicate speed
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
14 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
53 2
Tach Left Front –
High While Stopped
SYSEVENT
Left front wheel SS3
indicates speed while other
speed sensors indicate 0
NO 0
53 3
Tach Left Front –
Numerous Bad
Pulses While Moving
SYSEVENT
Left front wheel SS3 indicates
a higher rate of speed change
than other sensors
NO 0
54 1
Tach Right Front –
Zero While Moving
SYS_EVENT
Right front wheel SS4
indicates zero speed while
other
speed sensors indicate speed
NO 0
54 2
Tach Right Front –
High While Stopped
SYS_EVENT
Right front wheel SS4
indicates speed while other
speed sensors indicate 0
NO 0
54 3
Tach Right Front –
Numerous Bad
Pulses While Moving
SYS_EVENT
Right front wheel SS4
indicates a higher rate of
speed change than other
sensors
NO 0
55 1 Front Wheel Tachs SYS_EVENT
Front speed sensors
(SS3 & SS4) zero speed while
rear speed sensors (SS1 & SS2)
show speed
NO 0
56 1
Incorrect SW Ver
Loaded –Inv 1
SYSEVENT
Inverter 1 software is
incorrect
NO 0
56 2
Incorrect SW Ver
Loaded –Inv 2
SYSEVENT
Inverter 2 software is
incorrect
NO 0
56 3
Incorrect SW Ver
Loaded –Inv 3
SYSEVENT
 Inverter 3(DAB) software is
incorrect
NO 0
57 1
Inverter 1 SW Type
Incorrect
INV1_OFF
Inverter 1
software type does not match
what is expected
NO 0
58 1
Inverter 2 SW Type
Incorrect
INV2_OFF
Inverter 2
software type does not match
what is expected
NO 0
59
Inverter 3 SW Type
Incorrect
INV3_OFF
Inverter 3 (DAB)
software type does not match
what is expected
NO 0
61 1
Wheel Motor Over-
speed
SYSEVENT
One or more of the wheel
speed sensors indicate truck
speed is above allowable limit
of 46 mph
NO 2
61 2
Speed Control Over-
speed
SYSEVENT
Truck speed is greater than
active overspeed setting
NO 2
62 3
Engine Inducement
Active – Initial Level
Speed limit
75% HP
restriction
Tier4 engine inducement ini-
tial level active 75% HP restric-
tion
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 15
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
62 4
Engine Inducement
Active – Secondary
Level
Speed limit
50% HP reduc-
tion
Tier4 engine inducement sec-
ondary level active 50% HP
restriction
NO 0
62 5
Engine Inducement
Active – Final Level
No propel
Tier4 engine inducement final
level active, No-Propel restric-
tion
NO 0
62 6
Engine Inducement
Active – Induce-
ment Overridden
SYSEVENT
Tier4 engine inducement
overiden
NO 0
63 1
Engine Load Signal
Fault – Below Min
SYSEVENT
Engine analog load signal
below minimum
NO 5
63 2
Engine Load Signal
Fault – Above Max
SYSEVENT
Engine analog load signal
above maximum
NO 5
63 3
Engine Load Signal
Fault – PWM Low
SYSEVENT
Engine PWM load signal
below minimum
NO 5
63 4
Engine Load Signal
Fault – PWM High
SYSEVENT
Engine PWM load signal
above maximum
NO 5
63 5
Engine Load Signal
Fault – PWM Wrong
Period
SYSEVENT
Engine PWM load signal
frequency incorrect
NO 5
63 6
Engine Load Signal
Fault – PWM Wrong
Readings
SYSEVENT
Engine PWM load signal
frequency inconsistent
NO 5
64 1
Excessive High
Torque Operation
SPD_LIM
Truck life impacted by high
torque events causing cumu-
lative damage to drive
system. Possible causes are
excess payload, high rolling
resistance, steep grades or
operating with a single
inverter. Auto resets when
load is dumped or condition
subsides.
Yes 0
65 1
Analog Input Range
Check – AFSE temp
sensor
SPD_LIM
The Alternator Field Static
Exciter (AFSE) temperature is
out of range (actual)
NO 2
65 2
Analog Input Range
Check – Aux Inv
Temp Sensor
SPD_LIM
The Auxiliary Inverter (if
equipped) temperature is out
of range (calculated
NO 2
65 3
Analog Input Range
Check – Aux PC
Temp Sensor
SPD_LIM
The Aux Inverter Phase
Control (if equipped)
temperature is out of range
(calculated)
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
16 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
65 4
Analog Input Range
Check – Alternator
SPD_LIM
Traction Alternator
temperature is out of range
(calculated)
NO 2
65 5
Analog Input Range
Check – Left Stator
SPD_LIM
Left wheel (TM1) stator
temperature is out of range
(calculated)
NO 2
65 6
Analog Input Range
Check – Left Rotor
SPD_LIM
Left wheel (TM1) rotor
temperature is out of range
(calculated)
NO 2
65 7
Analog Input Range
Check – Right Stator
SPD_LIM
Right wheel (TM2) stator
temperature is out of range
(calculated)
NO 2
65 8
Analog Input Range
Check – Right Rotor
SPD_LIM
Right wheel (TM2) rotor
temperature is out of range
(calculated)
NO 2
65 9
Analog Input Range
Check – Chopper
Module
SPD_LIM
Chopper Module (CM1 or CM2)
temperature is out of range
(calculated)
NO 2
65 10
Analog Input Range
Check – Chopper
Diode
SPD_LIM
Chopper diode (CD1 or CD2)
temperature is out of range
(calculated)
NO 2
65 11
Analog Input Range
Check – Left Phase
Module
SPD_LIM
Inverter 1 IGBT temperatures
are out of range (calculated)
NO 2
65 12
Analog Input Range
Check – Left Diode
SPD_LIM
Inverter 1 diode temperatures
are out of range (calculated)
NO 2
65 13
Analog Input Range
Check – Right Phase
Module
SPD_LIM
Inverter 2 IGBT temperatures
are out of range (calculated)
NO 2
65 14
Analog Input Range
Check – Right Diode
SPD_LIM
Inverter 2 diode temperatures
are out of range (calculated)
NO 2
65 15
Analog Input Range
Check – Rectifier
Diode
SPD_LIM
Rectifier Module (RMA, B, C) or
Rectifier Panel (RD)
temperatures are out of range
NO 2
65 28
Analog Input Range
Check – H-Bridge
Primary
SPD_LIM
H-Bridge primary analog input
out of range
NO 2
65 29
Analog Input Range
Check – H-Bridge
Secondary
SPD_LIM
H-Bridge secondary analog
input out of range
NO 2
65 30
Analog Input Range
Check – Trans-
former (Pri)
SPD_LIM
Transformer Primary tempera-
ture is out of range
NO 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 17
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
65 31
Analog Input Range
Check – Trans-
former (Sec)
SPD_LIM
Transformer Secondary tem-
perature is out of range
NO 2
65 32
Analog Input Range
Check – CBI 1 (Con-
trol) IGBT
SPD_LIM
Control group cooling blower
inverter 1 IGBT temperature is
out of range (calculated)
NO 2
65 33
Analog Input Range
Check – CBI 1 (Con-
trol) Diode
SPD_LIM
Control group cooling blower
inverter 1 diode temperature
is out of range(calculated)
NO 2
65 34
Analog Input Range
Check– CBI 2
(Wheel) IGBT
SPD_LIM
Wheel motor cooling blower
inverter2 IGBT temperature is
out of range(calculated)
NO 2
65 35
Analog Input Range
Check – CBI 2
(Wheel) Diode
SPD_LIM
Wheel motor cooling blower
inverter2 diode temperature is
out of range(calculated)
NO 2
65 36
Analog Input Range
Check – CBI 3 (Grid
1) IGBT
SPD_LIM
Grid motor 1 -cooling blower
invereter3 IGBT temperature
(calculated) is out of range
NO 2
65 37
Analog Input Range
Check – CBI 3 (Grid
1) Diode
SPD_LIM
Grid motor 1 -cooling blower
invereter3 diode temperature
is out of range(calculated)
NO 2
65 38
Analog Input Range
Check – CBI 4 (Grid
2) IGBT
SPD_LIM
Grid motor 2 -cooling blower
invereter4 IGBT temperature is
out of range(calculated)
NO 2
65 39
Analog Input Range
Check – CBI 4 (Grid
2) Diode
SPD_LIM
Grid motor 2 -cooling blower
invereter4 diode temperature
is out of range(calculated)
NO 2
66 1
CM1 – Turn ON Fail-
ure
NO_POWER
(med ramp)
Chopper1 turn on failure YES 2
66 2 CM1 – GRIDI sensor
NO_POWER
(med ramp)
Grid current sensor fault YES 2
66 3 CM1 – LINKI sensor
NO_POWER
(med ramp)
Link current sensor fault YES 2
66 4
CM1 – Grid Blower 1
I Sensor
NO_POWER
(med ramp)
Grid blower 1 sensor fault YES 2
66 5
CM1 – Grid Blower 2
I Sensor
NO_POWER
(med ramp)
Grid blower 2 sensor fault YES 2
66 6
CM1 – GRIDI-LINKI
Delta
NO_POWER
(med ramp)
Grid and link current delta
 not ok
YES 2
66 7
CM1 – Turn OFF Fail-
ure
NO_POWER
(med ramp)
Chopper1 turn off failure YES 2
66 8
CM1 – Grid Resis-
tance Bad
NO_POWER
(med ramp)
Grid resistance fault, turned
on but readings are off
YES 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
18 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
66 9
CM1 - GRIDI Sensor
not zero at test start
NO_POWER
(med ramp)
Grid current sensor not
zero at test start
YES 2
66 10
CM1 – LINKI sensor
not zero at test start
NO_POWER
(med ramp)
Link current sensor not zero at
test start
YES 2
67 1
CM2 – Turn ON Fail-
ure
NO_POWER
(med ramp)
Chopper2 turn on failure YES 2
67 2 CM2 – GRIDI sensor
NO_POWER
(med ramp)
Grid current sensor fault YES 2
67 3 CM2 – LINKI sensor
NO_POWER
(med ramp)
Link current sensor fault YES 2
67 4
CM2 – Grid Blower 1
I Sensor
NO_POWER
(med ramp)
Grid blower 1 sensor fault YES 2
67 5
CM2 – Grid Blower 2
I Sensor
NO_POWER
(med ramp)
Grid blower 2 sensor fault YES 2
67 6
CM2 – GRIDI-LINKI
Delta
NO_POWER
(med ramp)
Grid andn link current delta
not ok
YES 2
67 7
CM2 – Turn OFF Fail-
ure
NO_POWER
(med ramp)
Chopper2 turn off failure YES 2
67 8
CM2 – Grid Resis-
tance Bad
NO_POWER
(med ramp)
Grid resistance fault, turned
on but readings are off
YES 2
67 9
CM2 - GRIDI Sensor
not zero at test start
NO_POWER
(med ramp)
Grid current sensor not
zero at test start
YES 2
67 10
CM2 – LINKI sensor
not zero at test start
NO_POWER
(med ramp)
Link current sensor not zero at
test start
YES 2
68 1
CM3 – Turn ON Fail-
ure
NO_POWER
(med ramp)
Chopper3 turn on failure YES 2
68 2 CM3 – GRIDI sensor
NO_POWER
(med ramp)
Grid current sensor fault YES 2
68 3 CM3 – LINKI sensor
NO_POWER
(med ramp)
Link current sensor fault YES 2
68 4
CM3 – Grid Blower 1
I Sensor
NO_POWER
(med ramp)
Grid blower 1 sensor fault YES 2
68 5
CM3 – Grid Blower 2
I Sensor
NO_POWER
(med ramp)
Grid blower 2 sensor fault YES 2
68 6
CM3 – GRIDI-LINKI
Delta
NO_POWER
(med ramp)
Grid andn link current delta
not ok
YES 2
68 7
CM3 – Turn OFF Fail-
ure
NO_POWER
(med ramp)
Chopper3 turn off failure YES 2
68 8
CM3 – Grid Resis-
tance Bad
NO_POWER
(med ramp)
Grid resistance fault, turned
on but readings are off
YES 2
68 9
CM3 - GRIDI Sensor
not zero at test start
NO_POWER
(med ramp)
Grid current sensor not
zero at test start
YES 2
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 19
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
68 10
CM3 – LINKI sensor
not zero at test start
NO_POWER
(med ramp)
Link current sensor not zero at
test start
YES 2
69 1
CM4 – Turn ON Fail-
ure
NO_POWER
(med ramp)
Chopper4 turn on failure YES 2
69 2 CM4 – GRIDI sensor
NO_POWER
(med ramp)
Grid current sensor fault YES 2
69 3 CM4 – LINKI sensor
NO_POWER
(med ramp)
Link current sensor fault YES 2
69 4
CM4 – Grid Blower 1
I Sensor
NO_POWER
(med ramp)
Grid blower 1 sensor fault YES 2
69 5
CM4 – Grid Blower 2
I Sensor
NO_POWER
(med ramp)
Grid blower 2 sensor fault YES 2
69 6
CM4 – GRIDI-LINKI
Delta
NO_POWER
(med ramp)
Grid andn link current delta
not ok
YES 2
69 7
CM4 – Turn OFF Fail-
ure
NO_POWER
(med ramp)
Chopper4 turn off failure YES 2
69 8
CM4 – Grid Resis-
tance Bad
NO_POWER
(med ramp)
Grid resistance fault, turned
on but readings are off
YES 2
69 9
CM4 - GRIDI Sensor
not zero at test start
NO_POWER
(med ramp)
Grid current sensor not
zero at test start
YES 2
69 10
CM4 – LINKI sensor
not zero at test start
NO_POWER
(med ramp)
Link current sensor not zero at
test start
YES 2
70 1
Link Cap Level Get-
ting Low
SYSEVENT
Non-Restrictive, Total
capacitance of DC Link is low
but acceptable for operation
NO 0
70 2
Sec Link Cap Level
Getting Low
SYSEVENT
 Non-Restrictive, Secondary
link capacitance is low but
acceptable for operation
NO 0
71 1
Link Cap LOW – MPH
Restricted
SPD_LIM
Restricted, DC link capaci-
tance is below acceptable lev-
els
NO 0
71 2
Sec Link Cap LOW –
MPH Restricted
SPD_LIM
Restricted, Secondary link
capacitance is below accept-
able levels
NO 0
72 1
Ground Circuit – Cap
Test did not finish
SPD_LIM
Restrictive, Ground fault
detected during DC Link
capacitance test
NO 0
72 2
Sec Ground Circuit –
Cap Test did not fin-
ish
SPD_LIM
Restrictive, secondary Ground
fault detected during DC Link
capacitance test
NO 0
73 1
Analog
Sensor
Offset Fault
–LINKI
SYSEVENT
Current is detected in the DC
Link when current should be
zero
0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
20 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
74 1
INV 1 Comm Failed –
Foreground
INV1_OFF
The TMC1 card is not commu-
nicating with the DSC or PSC
CPU card
NO 0
74 2
INV 1 Comm Failed –
Option Bit
INV1_OFF
DSC or PSC CPU cannot set
Option bits of the TMC1 card
NO 0
75 1
INV 2 Comm Failed –
Foreground
INV2_OFF
The TMC2 card is not commu-
nicating with the DSC or PSC
CPU card
NO 0
75 2
INV 2 Comm Failed –
Option Bit
INV2_OFF
DSC or PSC CPU cannot set
Option bits of the TMC2 card
NO 0
76 1
FB173 Card – Speed
FPGA
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card software did not
properly load at startup
NO 0
76 2
FB173 Card – Speed
while running
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
76 3
FB173 Card – Alt
FPGA
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card software did not
properly load at startup
NO 0
76 4
FB173 Card – uCon-
troller Download
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card software did not
properly load at startup
NO 0
76 5
FB173 Card – Slow
Task Timer
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
76 6
FB173 Card – Med
Task Timer
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
76 7
FB173 Card – Fast
Task Timer
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
76 8
FB173 Card – Failed
Diode Task Timer
NO_POWER
(long ramp)
DSC or PSC CPUdetects the
17FB173 card had a timeout
issue after software download
NO 0
76 9
FB173 Card – A3p
Reading
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card with A3P read-
ing
NO 0
76 10
FB173 Card – Alt
FPGA Timed Out
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
76 11
FB173 Card – uCon-
troller Reset
NO_POWER
(long ramp)
DSC or PSC CPU detects the
17FB173 card had a timeout
issue after software download
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 21
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
77 1
VI Test Failed –
Inverter
NO_POWER
(long ramp)
When switching from REST to
READY mode, Inverter 1 or
Inverter 2 has failed VI test
YES 99
78 1
Inv Background Msg
Fail – INV 1
SYSEVENT
Inverter 1 TMC1 card
communication error with
DSC or PSC CPU card
NO 20
78 2
Inv Background Msg
Fail – INV 2
SYSEVENT
Inverter 2 TMC2 card
communication error with
DSC or PSC CPU card
NO 20
78 3
Inv Background Msg
Fail – INV1 – Could
not set Option word
SYSEVENT
Inverter 1 TMC1 card
communication error with
DSC or PSC CPU card
NO 20
78 4
Inv Background Msg
Fail – INV2 – Could
not set Option word
SYSEVENT
Inverter 2 TMC2 card
communication error with
DSC or PSC CPU card
NO 20
78 5
Inv Background Msg
Fail – INV1 – Could
not set App ID
SYSEVENT
Inverter 1 TMC1 card
communication error with
DSC or PSC CPU card
NO 20
78 6
Inv Background Msg
Fail – INV2 – Could
not set App ID
SYSEVENT
Inverter 2 TMC2 card
communication error with
DSC or PSC CPU card
NO 20
78 7
Inv Background Msg
Fail – INV3
SYSEVENT
Inverter 3 (DAB)card
communication error with
DSC or PSC CPU card
NO 20
78 8
Inv Background Msg
Fail – INV3 – Could
not set Option word
SYSEVENT
Inverter 3 (DAB)card
communication error with
DSC or PSC CPU card
NO 20
78 9
Inv Background Msg
Fail – INV3 – Could
not set App ID
SYSEVENT
Inverter 3 (DAB)card
communication error with
DSC or PSC CPU card
NO 20
79 1
FB173 Card – Speed
FPGA
NO_POWER
(long ramp)
FB173 Card fault– Speed
FPGA
NO 0
79 2
FB173 Card – Speed
While Running
NO_POWER
(long ramp)
FB173 Card fault– Speed While
Running
NO 0
79 3
FB173 Card – Alt
FPGA
NO_POWER
(long ramp)
FB173 Card fault– Alt FPGA NO 0
79 4
FB173 Card – uCon-
troller Download
NO_POWER
(long ramp)
FB173 Card fault– uController
Download
NO 0
79 5
FB173 Card – Slow
Task Timer
NO_POWER
(long ramp)
FB173 Card fault– Slow Task
Timer
NO 0
79 6
FB173 Card – Med
Task Timer
NO_POWER
(long ramp)
FB173 Card fault– Med Task
Timer
NO 0
79 7
FB173 Card – Fast
Task Timer
NO_POWER
(long ramp)
FB173 Card fault– Fast Task
Timer
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
22 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
79 8
FB173 Card – Failed
Diode Task Timer
NO_POWER
(long ramp)
FB173 Card fault– Failed Diode
Task Timer
NO 0
79 9
FB173 Card – A3p
Reading
NO_POWER
(long ramp)
FB173 Card Alternator 3 phase
voltage
does not compare to expected
DC Link voltage
NO 0
79 10
FB173 Card – Alt
FPGA Timed Out
NO_POWER
(long ramp)
FB173 Card fault– Alt FPGA
Timed Out
NO 0
80 1
Cruise Control Lever
Error – Out of Range
or Not Present
SYSEVENT
Cruise control lever output
voltage is out of range or not
present
NO 2
80 2
Cruise Control Lever
Error – Not Return-
ing to Default Pos.
SYSEVENT
Cruise control lever output
voltage is not returning to
default range
NO 2
81 1
Quad Chopper –
Grid I Sensor – High
Value
SPD_LIM Grid current high value NO 2
81 2
Quad Chopper –
Link I Sensor – High
Value
SPD_LIM Link current high value NO 2
81 3
Quad Chopper –
Grid I Sensor – Load-
box
SPD_LIM
Grid current sensor is out of
range
NO 2
81 4
Quad Chopper –
Link I Sensor – Load-
box
SPD_LIM
Link current sensor is out of
range
NO 2
81 5
Quad Chopper –
High Chopper Per-
cent ON – CM2 may
not have turned on
SPD_LIM
Detected high chopper
percent on - CM2 may not
have closed
NO 2
82 1
Grid Protection –
Choppers on Exces-
sively in Propel
SPD_LIM &
ENGSPD_RP
Choppers on excessively in
propel
NO 2
83 1
Too Many Boots not
from Powerup –
Multiple 86 Events
Recorded
SPD_LIM
Mutiple 86 events. Too many
boots not from power up
NO 0
84 1
Control Power
Switch
SYSEVENT
Control Power Switch (CPS)
feedback lost with truck
motion
NO 2
85 1 Aux Cooling Fault SYSEVENT
Axle box air pressure not
sensed
Yes 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 23
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
85 2
Aux Cooling – Aux
RPM FB/CMD input
OOL
SYSEVENT
Auxiliary cooling motor RPM
out of range (if equipped)
NO 0
85 3
Aux Cooling – Aux-
RPM FB/Cmd Mis-
match
SYSEVENT
Auxiliary cooling motor
command does not match
feedback (if equipped)
NO 0
85 4
Aux Cooling –
Abnormal Shutdown
SYSEVENT
Auxiliary cooling motor
commanded to run and did
not (if equipped)
NO 0
86 2
Sys Boot Not From
Pwrup – Slow
Watchdog
SYSEVENT
PSC/DSC CPU card reset due
to slow watchdog timer expir-
ing
Yes -
30 Sec.
N/A
86 3
Sys Boot Not From
Pwrup – Software
Request
SYSEVENT
Card reset due to request from
software
Yes -
30 Sec.
N/A
86 6
Sys Boot Not From
Pwrup – Power
Monitor
SYSEVENT
Card reset due to +5VDC
Power monitoring
Yes -
30 Sec.
N/A
86 7
Sys Boot Not From
Pwrup – Push But-
ton Reset
SYSEVENT
Card reset due to Reset Pin
jumper
Yes -
30 Sec.
N/A
86 8
Sys Boot Not From
Pwrup – Fast
Watchdog
SYSEVENT
Card reset due to fast watch-
dog expiring
Yes -
30 Sec.
N/A
86 9
Sys Boot Not From
Pwrup – 1.2 Vdc
Power Supply
SYSEVENT
Card reset due to 1.2 V Power
Supply out of tolerance
Yes -
30 Sec.
N/A
86 10
Sys Boot Not From
Pwrup – 1.25 Vdc
Power Supply
SYSEVENT
Card reset due to 1.25 V Power
Supply out of tolerance
Yes -
30 Sec.
N/A
86 11
Sys Boot Not From
Pwrup – 2.5 Vdc
Power Supply
SYSEVENT
Card reset due to 2.5 V Power
Supply out of tolerance
Yes -
30 Sec.
N/A
86 12
Sys Boot Not From
Pwrup – 3.3 Vdc
Power Supply
SYSEVENT
Card reset due to 3.3 V Power
Supply out of tolerance
Yes -
30 Sec. N/A
86 17
Sys Boot Not From
Pwrup – Vehicle
Moving at re-boot
SYSEVENT
Vehicle speed greater than 1
mph(1.6KPH) when card was
booted
Yes -
30 Sec.
N/A
87 1 HP Low SYSEVENT
Expected horsepower from
the diesel engine is low
NO 9
88 1
HP Limit – Engine
May Stall
SYSEVENT
The system horsepower
exceeds transient high HP
limit
NO 9
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
24 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
88 2
HP Limit – Engine
May Stall
SYSEVENT
The system horsepower is out
of limits, low engine speed or
engine stall
NO 9
89 2
Eng Spd Cmd – RPM
does not match
command
SYSEVENT
Engine speed does not match
engine command
NO 3
89 3
Eng Spd Cmd –
Engine Cold Idle
Lock Active
SYSEVENT Engine cold idle lock active NO 3
89 4
Eng Spd Cmd – Alt
Spd Sensor Error
SYSEVENT Alternator speed sensor error NO 3
90 1
Cooling Blower Inv
Cutout – Cntrl Blwr
SYSEVENT
Control group cooling blower
inverter cut-out
NO 0
90 2
Cooling Blower Inv
Cutout – Axle Blwr
SYSEVENT
Wheel motor cooling blower
inverter cut-out
NO 0
90 3
Cooling Blower Inv
Cutout – Grid Blwr 1
SYSEVENT Grid blower 1 inverter cut-out NO 0
90 4
Cooling Blower Inv
Cutout – Grid Blwr 2
SYSEVENT Grid blower 2 inverter cut-out NO 0
91 1 Inverter 1 Cutout SYSEVENT
Event code is automatically
generated
when Inverter 1 isCutout
manually
NO 0
92 1 Inverter 2 Cutout SYSEVENT
Event code is automatically
generated
when Inverter 2 is Cutout
manually
NO 0
93 1
Inverter 3 Cutout
(H-Bridge)
SYSVENT
Event code is automatically
generated
when Inverter 3(DAB) is Cut-
out manually
NO 0
94 1 Illegal Limp Mode SYSEVENT
Inverter 1 or Inverter 2 was
cutout with the truck in motion
NO 3
95 Bad BBRAM Battery SYSEVENT
The voltage of the battery on
the DSC or PSC CPU card is low
NO 1
96
Unexpected System
Reset
SYSEVENT
DSC or PSC CPU Card has
detected that it went through
a reset sequence while the
System Mode was either
Ready, Propel,
Retard, or Loadbox
YES 2
97 Thaw Mode Active SYSEVENT
Cold weather Thaw mode is
active
NO 0
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 25
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2.2. INVERTER EVENT LIST (Xx00 - Xx99)
2.2.1. Restrictions
SPD_LIM - Imposes a 10 / 15 MPH (16/24KPH) speed limit on the truck.
SYS_EVENT - No Restriction.
INV_OFF - Inverter is restricted by the PSC from running. This will disable the inverter's run drive. It will also
force the truck into the existing ”limp” mode. The inverter_off restriction shall also impose a Truck Speed
Limit on the truck via the existing SYS_WARN/SPD_LIM restriction.
TRUCK_SPD_LIM_LOW - Speed limit set to lower speed point 5 mph (8 kph).
Default block restriction is for TMC. CBI * and DAB* restrictions are also included separately.
2.2.2. Numbering Scheme and Inverter Number Allocations
The event numbering scheme is listed in Section 2. The Inverter Events lists the last two digits of the event. In order to
get the event number for TMC 1 through TMC 4, change the hundreds digit to the appropriate inverter (2xx for TMC2,
3xx for TMC 3, etc.).
The above event numbering is also applied to CBI events (11xx for CBI1, 12xx for CBI2, etc.) and DAB (Dual Active
Bridge) events(21xx) used in trucks with electrification.
Table 3. Inverter Number and Device Description
98 1 PTU Data Store SYSEVENT
A datastore has been manu-
ally requested
YES 0
99 1
Software – CPU Per-
cent
SYSEVENT CPU Percentage is high NO 0
99 3
Software – Old Ver-
sion of PriOS
SYSEVENT
Primary Operating System is
older than expected
NO 0
INVERTER #
INVERTER EVENT
DEVICE PREFIX
DEVICE DEVICE DESCRIPTION
Inverter 1 1xx Inverter 1 (TMC1) Inverter 1 Traction Motor Control 1
Inverter 2 2xx Inverter 2 (TMC2) Inverter 2 Traction Motor Control 2
Inverter 3 21xx Inverter 3 (DAB) Inverter 3 Dual Active Bridge
EVENT #
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
26 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2.2.3. Inverter Event List (Xx00 - Xx99)
Table 4. Inverter Events
Inverter 4 11xx CBI 1 (Control)
Inverter 4 Cooling Blower Inverter 1 Control
Group Blower
Inverter 5 12xx CBI 2 (Wheel)
Inverter 5 Cooling Blower Inverter 2 Wheel Motor
Blower
Inverter 6 13xx CBI 3 (Grid 1) Inverter 6 Cooling Blower Inverter 3 Grid Blower 1
Inverter 7 14xx CBI 4 (Grid 2) Inverter 7 Cooling Blower Inverter 4 Grid Blower 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
Xx00
INVERTER CPU
CARD:
INV_OFF / Truck Speed
Limit
Inverter xx cpu card
fault
Yes TMC: 3
 DAB: 2
23 Pattern had bad
a, b ,c output
DAB: */
TRUCK_SPD_LIM_LOW
CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
29
Extrapolation
interrupt not
running
30 Vector interrupt
not running
31 tic interrupt not
running
32
NMI
occurred(i960) -
fast WD (PPC)
34 Background not
running
35 PGA could not
be programmed
38 PGA initialization
failed
39 PGA d/p did ont
initialize
GE Proprietary and Confidential Information 27
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
40 Parameter not
Found
41 Parameter
multiply defined
48 CAM ISR is not
running
50 CAM RAM Failed
51 CAM RAM upper
bank failed
52
Card power
monitor reset,
5V low
53
Card power
monitor reset,
3.3V low
54
Card power
monitor reset,
2.5V low
55
Card power
monitor reset,
1.25V low
56
Card power
monitor reset,
1.2V low
57
Watchdog
disabled by
WDIS jumper
58
Incompatible
TMC card type
for this
application
59
Overrun End of
Programmed
CAM
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
28 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Xx01
INV x CPU Card
(NR):
 SYSTEM EVENT
Inverter xx CPU Card
detected specific
Phase Module problem
during VI test
Yes TMC: 3
DAB: 2
1 CBI: 2
Phase A+
command Not
OFF
2
Phase A-
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
3
Phase B+
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
4
Phase B-
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
5
Phase C+
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
6
Phase C-
command NOT
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
7
Phase A+
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
8
Phase A-
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 29
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
9
Phase B+
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
10
Phase B-
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
11
Phase C+
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
12
Phase C-
command NOT
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
13
Chopper 1
Interrupt not
running
SYSTEM EVENT
Inverter xx CPU Card
Chopper interrupt not
running
Yes TMC: 3
DAB: 2
CBI: 2
14
Chopper 2
Interrupt not
running
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
16 Inverter CPU
was reset
SYSTEM EVENT
Inverter xx CPU Card
unexpected reset
Yes TMC: 3
DAB: 2
CBI: 2
17
Phase A2+
command Not
OFF
SYSTEM EVENT
Inverter xx CPU Card
detected specific
Phase Module problem
during VI test
Yes TMC: 3
DAB: 2
CBI: 2
18
Phase A2-
command Not
OFF
SYSTEM EVENT Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
30 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
19
Phase B2+
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
20
Phase B2-
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
21
Phase C2+
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
22
Phase C2-
command Not
OFF
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
23
Phase A2+
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
24
Phase A2-
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
25
Phase B2+
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
26
Phase B2-
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 31
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
27
Phase C2+
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
28
Phase C2-
command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
29 Slow watchdog
reset
SYSTEM EVENT Slow watchdog reset Yes TMC: 3
DAB: 2
CBI: 2
30 Pushbutton
reset
SYSTEM EVENT Pushbutton reset Yes TMC: 3
DAB: 2
CBI: 2
31 Direct command
line reset
SYSTEM EVENT
Direct command line
reset
Yes TMC: 3
DAB: 2
CBI: 2
Xx02 5 INV xx I/O Card:
INV_OFF / Truck Speed
LimitInverter xx CPU Card
internal I/O problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Logic Ground
not OK
8 Could not
access I/O Card
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
32 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
9 A/D Conversion
did not work
INV_OFF / Truck Speed
Limit
A/D conversion did not
work
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
10
Retard on too
long while not
braking
INV_OFF / Truck Speed
Limit
Inverter xx CPU Card
detects Chopper
Module was ON too
long, while not in
Retard Mode
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
11
PTF A - Phase A
Overcurrent
signal too Long
INV_OFF / Truck Speed
Limit
Inverter xx protective
turn off of Phase A,
current excessive for
extended time
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
12
PTF B - Phase B
Overcurrent
signal too Long
INV_OFF / Truck Speed
Limit
Inverter xx protective
turn off of Phase B,
current excessive for
extended time
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
13
PTF C - Phase C
Overcurrent
signal too Long
INV_OFF / Truck Speed
Limit
Inverter xx protective
turn off of Phase C,
current excessive for
extended time
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 33
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
14 Current IC not
zero at start up
INV_OFF / Truck Speed
Limit
Inverter xx CPU Card,
Phase C current
problem detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
15 C Phase Current
Too High
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
16 Protective Turn
off circuit not OK
INV_OFF / Truck Speed
Limit
Inverter xx Protective
Turn off circuit not OK
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
17
Phase A and B
Currents do not
Match
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
imbalance between
Phase Modules A1 and
B 1
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
18
Phase A and C
Currents do not
Match
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
imbalance between
Phase Modules A1 and
C1
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
34 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
19
Phase A2 and B2
currents do not
match
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
imbalance between
Phase Modules A2 and
B2
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
20
Phase A2 and C2
currents do not
match
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
imbalance between
Phase Modules A2 and
C2
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
21
Excessive phase
A null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on A1
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
22
Excessive phase
B null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on B1
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
23
Excessive phase
C null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on C1
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 35
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
24
Excessive phase
A2 null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on A2
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
25
Excessive phase
B2 null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on B2
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
26
Excessive phase
C2 null current
offset
INV_OFF / Truck Speed
Limit
Inverter xx, VI test
determined current
excessive on C2
without devices ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx03 1 INV x I/O Card
(NR)
SYSTEM EVENT Inverter xx CPU Card Yes TMC: 3
Internal I/O Problem
detected
DAB: 2
CBI: 2
Chopper 1
Command Not
Off
2
Chopper 2
Command Not
Off
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
36 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
3
Chopper 1
Command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
4
Chopper 2
Command Not
ON
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
5 Volt Scale A Out
of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
6 Volt Scale B Out
of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
7 Link Volt Scale
Out of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
8 Current Scale A
Out of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
9 Current Scale B
Out of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
10 Input V Scale
Out of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
11
High Frequency
on VCO VTest
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
12
Low Frequency
on VCO VTest
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 37
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: 2
13 High Frequency
on IA Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
14 High Frequency
on IB Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
15
High Frequency
on VCO Link
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
16
High Frequency
on VCO in
channel
SYSTEM EVENT
High frequency on
VCO in channel
Yes TMC: 3
DAB: 2
CBI: 2
17 Current IA Too
Positive
SYSTEM EVENT
Inverter xx I/O Card
indicates Phase A1
current out of range
Yes TMC: 3
DAB: 2
CBI: 2
18 Current IA Too
Negative
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
19 Current IB Too
Positive
SYSTEM EVENT
Inverter xx I/O Card
indicates Phase B1
current out of range
Yes TMC: 3
DAB: 2
CBI: 2
20 Current IB Too
Negative
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
21 Link Voltage too
High
SYSTEM EVENT
Inverter xx I/O Card
indicates DC link volts
too high
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
38 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
22
Input Filter
Voltage Too
High
SYSTEM EVENT
Inputfilter voltage too
high
Yes TMC: 3
DAB: 2
CBI: 2
23
High Frequency
on VCO DB
Chopper
SYSTEM EVENT
Inverter xx CPU Card
Internal I/O Problem
detected
Yes TMC: 3
DAB: 2
CBI: 2
24
DB Chopper
Voltage too H
igh
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
25
High Frequency
on VCO VA
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
26
High Frequency
on VCO VB
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
27
High Frequency
on VCO VC
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
28 VA Voltage too
High
SYSTEM EVENT
Inverter xx I/O Card
indicates
Yes TMC: 3
Phase A volts too high DAB: 2
CBI: 2
29 VB Voltage too
High
SYSTEM EVENT
Inverter xx I/O Card
indicates
Yes TMC: 3
Phase B volts too high DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 39
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
30 Volt Scale C Out
of Range
SYSTEM EVENT Yes TMC: 3
Volt scale c out of
range
DAB: 2
CBI: 2
31 VC Voltage Too
High
SYSTEM EVENT
Inverter xx I/O Card
indicates
Yes TMC: 3
Phase C volts too high DAB: 2
CBI: 2
34
High Frequency
on VCO IC1
Channel
SYSTEM EVENT
Inverter xx CPU Card
Internal I/O Problem
detected
Yes TMC: 3
DAB: 2
CBI: 2
35
Low Frequency
on VCO IC1
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
36 Current IC1 Too
High
SYSTEM EVENT
Inverter xx CPU Card
Phase 1C Current Out
of Range
Yes TMC: 3
DAB: 2
CBI: 2
37 Current IC1 Too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
50 Current Scale C!
out of range
SYSTEM EVENT
Inverter xx CPU Card
Internal I/O Problem
detected
Yes TMC: 3
DAB: 2
CBI: 2
51
High Frequency
on VCO IA2
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
52
Low Frequency
on VCO IA2
Channel
SYSTEM EVENT Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
40 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
53
High Frequency
on VCO IB2
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
54
Low Frequency
on VCO IB2
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
55
High Frequency
on VCO IC2
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
56
Low Frequency
on VCO IC2
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
57 Current IA2 too
high
SYSTEM EVENT
Inverter xx CPU Card
Phase 2A Current Out
of Range
Yes TMC: 3
DAB: 2
CBI: 2
58 Current IA2 too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
59 Current IB2 too
high
SYSTEM EVENT
Inverter xx CPU Card
Phase 2B Current Out
of Range
Yes TMC: 3
DAB: 2
CBI: 2
60 Current IB2 too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
61 Current IC2 too
high
SYSTEM EVENT
Inverter xx CPU Card
Phase 2C Current Out
of Range
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 41
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
62 Current IC2 too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
63 Current Scale A2
out of Range
SYSTEM EVENT
Inverter xx CPU Card
Internal I/O Problem
detected
Yes TMC: 3
DAB: 2
CBI: 2
64 Current Scale B2
Out of Range
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
65 Current Scale C2
Out of Range.
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
66
Ground
calibration scale
out of range
SYSTEM EVENT
Ground calibration
scale out of range
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
Xx04 1 INV x F/O card
INV_OFF / Truck Speed
Limit
Inverter xx Fiber Optic
Card Power Supply
voltage out of range
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Fiber Optic Card
Power Supply
Monitor
2 Fiber Optic Card
Disabled
INV_OFF / Truck Speed
Limit
Inverter xx Fiber Optic
Card
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
42 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
Enable missing DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3
Fiber Optic Card
Enabled and no
Direction
INV_OFF / Truck Speed
Limit
Fiber optic card
enabled
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
and no direction DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4
Fiber optic 2
power supply
monitor
INV_OFF / Truck Speed
Limit
Fiber optic 2 power
supply monitor
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 Fiber optic 1 15v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 1 15v
power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Fiber optic 1 INV
LEM 24v power
low
INV_OFF / Truck Speed
Limit
Fiber optic 1 INV LEM
24v power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 43
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
7 Fiber optic 1 5v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 1 5v power
low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
8
Fiber optic 1
chop LEM 24v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 1 chop LEM
24v power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
9 Fiber optic 2 15v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 2 15v
power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
10
Fiber optic 2 INV
LEM 24v power
low
INV_OFF / Truck Speed
Limit
Fiber optic 2 INV LEM
24v power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
11 Fiber optic 2 5v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 2 5v power
low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
12
Fiber optic 2
chop LEM 24v
power low
INV_OFF / Truck Speed
Limit
Fiber optic 2 chop LEM
24v power low
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
44 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx05 1 INV x P.S. Card
INV_OFF / Truck Speed
Limit
Inverter xx CPU Card
+5VDC out of range
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
+5 Volt not in
Tolerance
2 +15 Volt not in
Tolerance
INV_OFF / Truck Speed
Limit
Inverter xx CPU Card
+15
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
VDC out of range DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 -15 Volt not in
Tolerance
INV_OFF / Truck Speed
Limit
Inverter xx CPU Card -
15
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
VDC out of range DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 45
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
6 +24 Volt not in
Tolerance
INV_OFF / Truck Speed
Limit
Inverter xx FODC1
Card and
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
current transducer
+24V out
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
of range CBI: 2
7 -24 Volt not in
Tolerance
INV_OFF / Truck Speed
Limit
Inverter xx FODC1
Card and
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
Current Transducer -
24V DC
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
out of range CBI: 2
8 +24-2 Volt not in
ToleranceINV_OFF / Truck Speed
Limit
Inverter xx FODC1
Card and
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
current transducer
+24V out
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
of range CBI: 2
9 -24-2 Volt not in
Tolerance
INV_OFF / Truck Speed
Limit
Inverter xx FODC1
Card and current
transducer - 24V out
of range
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
46 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
10 LEM +15v power
low
INV_OFF / Truck Speed
Limit
LEM +15v power low Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
11 LEM -15v power
low
INV_OFF / Truck Speed
Limit
LEM -15v power low Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
12 GD +15v power
low
INV_OFF / Truck Speed
Limit
GD +15v power low Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
13 Current module
+/-15v overload
INV_OFF / Truck Speed
Limit
Current module +/-15v
overload
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
14 Tach circuit
overload
INV_OFF / Truck Speed
Limit
Tach circuit overload Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 47
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
15 2nd INV LEM
+15v power low
INV_OFF / Truck Speed
Limit
2nd INV LEM +15v
power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
16 2nd INV LEM -
15v power low
INV_OFF / Truck Speed
Limit
2nd INV LEM -15v
power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
17 2nd INV GD +15v
power low
INV_OFF / Truck Speed
Limit
2nd INV GD +15v
power low
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
18
2nd INV current
module +/-15v
overload
INV_OFF / Truck Speed
Limit
2nd INV current
module +/-15v
overload
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx06 1 INV x DC Wiring
Fault
INV_OFF / Truck Speed
Limit
Inverters xx, DC Link
connections open
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
 CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
48 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DC Power
Connection
Open
2
Link and Phase
Voltage
Mismatch
INV_OFF / Truck Speed
Limit
Inverters xx DC Link
volts doesn’t match
voltage sensed by
Phase voltage
feedbacks
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3
Link and
chopper voltage
mismatch
INV_OFF / Truck Speed
Limit
Link and Chopper
voltage mismatch
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx07 1 GDPS x Failure
INV_OFF / Truck Speed
Limit
Gate Drive Power
Supply is missing
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Gate Drive
Power Supply
Off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Gate Drive
Power Supply
Off with enable
INV_OFF / Truck Speed
Limit
Gate Drive Power Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
Supply is off when link DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 49
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
charged CBI: 2
3
Multiple Phase
Modules not Off
with Enable
INV_OFF / Truck Speed
Limit
Multiple phase
modules not off when
it should be
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx09 1 INV x Link V
Sensor-
INV_OFF / Truck Speed
Limit
During VI test, Inverter
xx
Yes TMC: 3
Link Voltage
Sensor Failed
DAB: */
TRUCK_SPD_LIM_LOW
DC Link voltage sensor DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
problem detected CBI: 2
Xx11 1 INV x Input Volt
Sensor:
INV_OFF / Truck Speed
Limit
Filter voltage outside
limits
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Filter Voltage
Outside Limits
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
50 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
xx13 1 INV x General
Event
INV_OFF / Truck Speed
Limit
Problem detected with Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
Inverter xx Phase A
current during VI test,
detected high current
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase A+
Current out too
High
2
Phase A-
Current out too
High
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3
Phase B+
Current out too
High
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
current during VI test,
detected high current
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4
Phase B-
Current out too
High
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 51
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
5
Phase C+
Current out too
High
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
current during VI
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
Test, detected high
current
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase C-
Current out too
High
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7
Phase A+
Current out too
Low
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A
current during VI test,
detected low current
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
8
Phase A-
Current out too
Low
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
9
Phase B+
Current out too
Low
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
current during VI
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
52 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
test, detected low
current
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
10
Phase B-
Current out too
Low
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
11
Phase C+
Current out too
Low
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
current during VI
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
Test, detected low
current
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
12
Phase C-
Current out too
Low
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
13 Phase A Current
not Zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A
current during VI test,
current not zero when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSEOR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 53
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
15 Phase B Current
not Zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
current during VI
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
test, current not zero
when expected
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
17
Phase A Voltage
too High while
Phase A- is ON
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A
voltage during VI test,
current not zero when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
 DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
18
Phase A Voltage
too Low while
Phase A+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
19
Phase A Voltage
too High while
Phase B- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
54 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
20
Phase A Voltage
too Low while
Phase B+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
21
Phase A Voltage
too High while
Phase C- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
22
Phase A Voltage
too Low while
Phase C+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
23
Phase B Voltage
too High while
Phase A- is ON
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
voltage during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
24
Phase B Voltage
too Low while
Phase A+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
25
Phase B Voltage
too High while
Phase B- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 55
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
26
Phase B Voltage
too Low while
Phase B+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
27
Phase B Voltage
too High while
Phase B- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
28
Phase B Voltage
too Low while
Phase C+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
29
Phase C Voltage
too High while
Phase A- is ON
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
voltage during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
30
Phase C Voltage
too Low while
Phase A+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
56 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
31
Phase C Voltage
too High while
Phase B- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
32
Phase C Voltage
too Low while
Phase B+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
33
Phase C Voltage
too High while
Phase C- is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
34
Phase C Voltage
too Low while
Phase C+ is ON
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
35
Phase A Fault
Current when
Phase A+ on
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A
overcurrent during VI
test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 57
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
36
Phase A Fault
Current when
Phase A- on
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
37
Phase B Fault
Current when
Phase B+ on
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
overcurrent during VI
test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
38
Phase B Fault
Current when
Phase B- on
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
39
Phase C Fault
Current when
Phase C+ on
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
overcurrent during VI
test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
40
Phase C Fault
Current when
Phase C- on
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
58 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
48
Phase A Voltage
High with all
GTOs Off
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A
voltage during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
49
Phase A Voltage
Low with all
GTOs Off
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
50
Phase B Voltage
High with all
GTOs Off
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B
voltage during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
51
Phase B Voltage
Low with all
GTOs Off
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
52
Phase C Voltage
High with all
GTOs Off
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
voltage during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
53
Phase C Voltage
Low with all
GTOs Off
INV_OFF / Truck Speed
Limit
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 59
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
54 Possible Phase
to DC+ Short
INV_OFF / Truck Speed
Limit
Inverter xx DC Link
positive to Phase short
detected during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
55 Possible Phase
to DC- Short
INV_OFF / Truck Speed
Limit
Inverter xx DC Link
negative to Phase
short detected during
VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
60 Link Volts above
PTL
INV_OFF / Truck Speed
Limit
Inverter xx DC Link
voltage excessive
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
70Phase A
Negative
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase A
negative current
unbalanced, low
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
71
Phase B
Negative
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase B
negative current
unbalanced, low
current detected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
60 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
72
Phase C
Negative
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase C
negative current
unbalanced, low
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
73
Phase A
Negative
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase A
negative current
unbalanced, high
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
74
Phase B
Negative
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase B
negative current
unbalanced, high
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
75
Phase C
Negative
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase C
negative current
unbalanced, high
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
76
Phase A Positive
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase A
positive current
unbalanced, low
current detected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 61
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
77
Phase B Positive
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase B
positive current
unbalanced, low
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
78
Phase C Positive
Current Low
(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase C
positive current
unbalanced, low
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
79
Phase A Positive
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase A
positive current
unbalanced, high
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
80
Phase B Positive
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase B
positive current
unbalanced, high
current detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
81
Phase C Positive
Current
High(Unbalance)
INV_OFF / Truck Speed
Limit
Inverter xx Phase C
positive current
unbalanced, high
current detected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
62 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
82 No Current
While Running
INV_OFF / Truck Speed
Limit
Inverter xx phase
current zero while
running
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
83
Excessive Regen
while in
Motoring
INV_OFF / Truck Speed
Limit
Inverter xx detected
high Link voltage
during propel with
torque feedback
opposite polarity
command
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
84 Phase C Current
out not zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C
current during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
85
Phase A2
Current Out not
zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase A2
current during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
86
Phase B2
Current Out not
zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase B2
current during VI test
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 63
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
87
Phase C2
Current Out not
zero
INV_OFF / Truck Speed
Limit
Problem detected with
Inverter xx Phase C2
current during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
88 Instantaneous
link overvoltage
INV_OFF / Truck Speed
Limit
Instantaneous link
overvoltage
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx14 22 INV x (NR)
General Event
SYSTEM EVENT
Inverter xx CPU card
input channel problem
detected
Yes TMC: 3
DAB: 2
CBI: 2
Low Frequency
on IA Channel
24 Low Frequency
on IB Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
26
Low Frequency
on VCO Link
Filter
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
28 Low Frequency
on VCO In Filter
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
64 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
38 Link Voltage Too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
40
Input Filter
Voltagte Too
Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
46
Low Frequency
on VCO Chopper
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
48 Chopper Voltage
too Low
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
50
Low Frequency
on VCO VA
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
52
Low Frequency
on VCO VB
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
54
Low Frequency
on VCO VC
Channel
SYSTEM EVENT Yes TMC: 3
DAB: 2
CBI: 2
56 VA Voltage too
Low
SYSTEM EVENT
Inverter xx CPU card
VA input channel too
negative
Yes TMC: 3
DAB: 2
CBI: 2
58 VB Voltage too
Low
SYSTEM EVENT
Inverter xx CPU card
VB input channel too
negative
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 65
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
61 VC Voltage too
Low
SYSTEM EVENT
Inverter xx CPU card
VC
Yes TMC: 3
input channel too
negative
DAB: 2
CBI: 2
65
High negative
dV/dt with PTF
while braking
SYSTEM EVENT
High negative dv/dt
with Protective turn off
while braking
Yes TMC: 3
DAB: 2
CBI: 2
66
Out of Sat
Cluster
(REMOVED)
SYSTEM EVENT
Inverter xx CPU card
detected many out of
Saturation faults
Yes TMC: 3
DAB: 2
CBI: 2
67 Ground fault
detected
SYSTEM EVENT Ground fault detected Yes TMC: 3
DAB: 2
CBI: 2
Xx15 1 INV xx System
Fault
INV_OFF / Truck Speed
Limit
Inverter xx DSC/PSC Yes TMC: 3
DAB: communication error, DAB: 2
SYSTEM EVENT
DSC/PSC direction
request missing or
opposite truck travel
CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
No Direction
Called for
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
66 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2
Calling Forward
moving
backward
INV_OFF / Truck Speed
LimitYes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
3
Calling
backward
moving foward
INV_OFF / Truck Speed
Limit
Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
4 Input Voltage
too low
INV_OFF / Truck Speed
Limit
input voltage too low Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
5 Link Filter
Voltage too low
INV_OFF / Truck Speed
Limit
Run request from DSC/
PSC is active while
Inverter xx DC Link
voltage feedback is
low
Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
6 No High Speed
Data from PSC
INV_OFF / Truck Speed
Limit
Inverter xx DSC/PSC
communication link
lost
Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 67
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
7 Link Voltage not
OK
INV_OFF / Truck Speed
Limit
Link Voltage not OK Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
8 Line Current not
OK
INV_OFF / Truck Speed
Limit
Line Current not OK Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
9
System
Communication
TIC not updating
INV_OFF / Truck Speed
Limit
Inverter xx DSC/PSC
communication link
lost
Yes TMC: 3
DAB: DAB: 2
SYSTEM EVENT CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
10
Chopper
Junction Too
Hot
INV_OFF / Truck Speed
Limit
Inverter xx detects
both
Yes TMC: 3
 DAB:
Chopper Mod- ules
IGBT’s are
DAB: 2
SYSTEM EVENT hot CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
68 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
11 Inverter
Junction too Hot
INV_OFF / Truck Speed
Limit
Inverter xx detects one
or
Yes TMC: 3
DAB:
more Phase Module
IGBT’s
DAB: 2
SYSTEM EVENT are hot CBI: 2
CBI: */
TRUCK_SPD_LIM_LOW
Xx16 1 Phase A Module
did not Turn off
INV_OFF / Truck Speed
Limit
A Phase Modules did
not turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Overcurrent on
Phase A
INV_OFF / Truck Speed
Limit
A Phase Modules Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
excessive over-
current
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
condition detected CBI: 2
4 IGBT Saturation
flt on A+
INV_OFF / Truck Speed
Limit
Phase A+ has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 69
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on A-
INV_OFF / Truck Speed
Limit
Phase A- has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6 Unequal current
sharing in A+
INV_OFF / Truck Speed
Limit
Unequal current
sharing in A+
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 Unequal current
sharing in A-
INV_OFF / Truck Speed
Limit
Unequal current
sharing in A-
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx17 1 INV x Phase A+
Fault
INV_OFF / Truck Speed
Limit
Phase Module A+ did
not turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A+
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase A+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module A+
did not turn OFF when
expected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
70 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase A+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A+ was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phae A+ and A-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx Phase
Module A+ turned ON
while Phase Module A-
was detected ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase A+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Mod- ule A+
did not turn ON when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase A+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Module A+
did not turn ON when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
A+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 71
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
Module A+ gate driver
power supply problem
detected
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx18 2 INV x Phase A+
(NR) Event
SYSEVENT / None
Inverter xx ,INV A+ NR
AUP Temp Short.
Yes TMC: 3
DAB: 2
INV A+ NR
AUP_TEMP_SHO
RT
CBI: 2
3
INV A+ NR
AUP_TEMP_OPE
N
SYSEVENT / None
Inverter xx ,INV A+ NR
AUP Temp open
Yes TMC: 3
DAB: 2
CBI: 2
4
INV A+ NR
AUP_TEMP_WAR
M
SYSEVENT / None
Inverter xx ,INV A+ NR
AUP Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV A+ NR
AUP_TEMP_HOT
SYSEVENT / None
Inverter xx ,INV A+ NR
AUP Temp hot
Yes TMC: 3
DAB: 2
CBI: 2
6
Phase A+ not Off
with Enable/DC
Volts
SYSEVENT / None
Inverter xx ,Phase A+
not Off with Enable/DC
Volts
Yes TMC: 3
DAB: 2
CBI: 2
7
A+ ON/OFF Edge
Delay out or
range
SYSEVENT / None
Inverter xx ,A+ ON/OFF
Edge Delay out or
range
Yes TMC: 3
DAB: 2
*For dual IGBT
systems only
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
72 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Xx19 1 INV x Phase A-
Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A- did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A- Module
did not Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase A-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module A-
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase A- Module
Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase A+ and A-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A- detected
ON while Phase
Module A+
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase A-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Mod- ule A-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 73
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOWCBI: 2
6 Phase A- Module
did not turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Mod- ule A-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
A-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A- gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx20 2 INV x Phase A-
(NR) Event
SYSEVENT / None
Inverter xx ,INV A+ NR
ADN Temp Short.
Yes TMC: 3
DAB: 2
INV A- NR
ADN_TEMP_SHO
RT
CBI: 2
3
INV A- NR
ADN_TEMP_OPE
N
SYSEVENT / None Yes TMC: 3
DAB: 2
Inverter xx , INV A+ NR
ADN Temp open
CBI: 2
4
INV A- NR
ADN_TEMP_WA
RM
SYSEVENT / None
Inverter xx , INV A+ NR
ADN Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV A- NR
ADN_TEMP_HOT
SYSEVENT / None
Inverter xx , INV A+ NR
ADN Temp hot
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
74 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
6
Phase A- Not off
with Enable/Dc
Volts
SYSEVENT / None
Inverter xx , Phase
Module A- is not OFF
when expected with
the DC Link energized
Yes TMC: 3
DAB: 2
CBI: 2
7
A - ON/OFF edge
delay out of
range
SYSEVENT / None
Inverter xx A- Phase
Module Edge Delay
Out Of Range
Yes TMC: 3
DAB: 2
CBI: 2
Xx21 1 INV x Phase A
Current Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase A
current sensor was
determined as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A Current
Sensor Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Current IA not
zero at Startup
INV_OFF / Truck Speed
Limit
Inverter xx , Phase A
Phase Modules current
sensor signal was not
zero at startup
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 A Phase Current
too HIgh
INV_OFF / Truck Speed
Limit
Current feedback from
Inverter xx , Phase A
Phase Modules is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx23 1 INV x phase A
Voltage Event
INV_OFF / Truck Speed
Limit
Inverter xx Phase A
voltage sensor was
determined failed
during VI test
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 75
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A Voltage
Sensor Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Phase A Voltage
too High
INV_OFF / Truck Speed
Limit
Inverter xx , Phase A
voltage feedback is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx25 1 INV x Phase B+/
B- Event
INV_OFF / Truck Speed
Limit
Inverter xx , B Phase
Modules did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase B Module
did not Turn off
2 Overcurrent on
Phase B
INV_OFF / Truck Speed
Limit
Inverter xx , B Phase
Modules excessive
current condition was
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 IGBT Saturation
flt on B+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B+ has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
76 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on B-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B- has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6 Unequal current
sharing in B+
INV_OFF / Truck Speed
Limit
Inverter xx , Unequal
current sharing in B+
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 Unequal current
sharing in B-
INV_OFF / Truck Speed
Limit
Inverter xx , Unequal
current sharing in B-
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx26 1 INV x Phase B+
Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B+ did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase B+
Module did not
Turn off
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 77
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2
Phase B+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module B+
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase B+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B+ was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase B+ and B-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B+ was ON
while Phase Module B-
is commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase B+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module B+
did not turn ON when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase B+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Mod- ule B+
did not turn ON when
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
78 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
7 IGBT PS Fault on
B+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B+ gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx27 2 INV x Phase B+
(NR) Event
SYSEVENT / None
Inverter xx , INV B+ NR
BUP Temp Short.
Yes TMC: 3
DAB: 2
INV B+ NR
BUP_TEMP_SHO
RT
CBI: 2
3
INV B+ NR
BUP_TEMP_OPE
N
SYSEVENT / None Yes TMC: 3
DAB: 2
Inverter xx , INV B+ NR
BUP Temp open
CBI: 2
4
INV B+ NR
BUP_TEMP_WAR
M
SYSEVENT / None
Inverter xx , INV B+ NR
BUP Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV B+ NR
BUP_TEMP_HOT
SYSEVENT / None
Inverter xx , INVB+ NR
BUP Temp hot
Yes TMC: 3
DAB: 2
CBI: 2
6
Phase B+ not Off
with Enable/DC
Volts
SYSEVENT / None
Inverter xx , Phase
Module B+ is not OFF
when expected with
the DC Link energized
Yes TMC: 3
DAB: 2
CBI: 2
07*
B+ ON/OFF Edge
Delay out or
range
SYSEVENT / None
Inverter XX B+ Phase
Module edge delay
Out of Range
Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 79
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
* for Dual IGBT
Systems only
CBI: 2
Xx28 1 INV x Phase B-
Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B- did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B- Module
did not Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase B-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module B-
did not turn OFF when
expected
Yes TMC:3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase B- Module
Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase B+ and B-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx Phase
Module B- turned ON
while Phase Module B+
were com- manded
ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase B-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Mod- ule B-
did not turn ON when
com- manded
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
80 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6 Phase B- Module
did not turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Mod- ule B-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
B-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B-gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx29 2 INV x Phase B-
(NR) ) Event
SYSEVENT / None
Inverter xx , INV B- NR
BDN Temp Short.
Yes TMC: 3
DAB: 2
INV B- NR
BDN_TEMP_SHO
RT
CBI: 2
3
INV B- NR
BDN_TEMP_OPE
N
SYSEVENT / None Yes TMC: 3
Inverter xx, DAB: 2
INV B- NR BDN Temp
open
CBI: 2
4
INV B- NR
BDN_TEMP_WA
RM
SYSEVENT / None
Inverter xx , INV B- NR
BDN Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV B- NR
BDN_TEMP_HOT
SYSEVENT / None
Inverter xx , INV B- NR
BDN Temp hot
Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 81
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: 2
6
Phase B- Not off
with Enable/Dc
Volts
SYSEVENT / None
Inverter xx , Phase
Module B- is not OFF
when expected with
the DC Link energized
Yes TMC: 3
DAB: 2
CBI: 2
7
B - ON/OFF edge
delay out of
range
SYSEVENT / None
Inverter XX B- Phase
Module Edge Delay
Out of Range
Yes TMC: 3
DAB: 2
CBI: 2
Xx30 1 INV x Phase B
Current Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B current
sensor was
determined as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B Current
Sensor Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Current IB not
zero at Startup
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B current
sensor signal was not
zero at startup
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 B Phase Current
too HIgh
INV_OFF / Truck Speed
Limit
Current feedback from
Inverter xx , B Phase
Modules current is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
82 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Xx32 1 INV x phase B
Voltage Event
INV_OFF / Truck Speed
Limit
Inverter xx , B Phase
Modules voltage
sensor failed during VI
test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B Voltage
Sensor Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Phase B Voltage
too High
INV_OFF / Truck Speed
Limit
Inverter xx , B Phase
Modules voltage
feedback is higher
than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx34 1 INV x Phase C+/
C- Event
INV_OFF / Truck Speed
Limit
Inverter xx , C Phase
Modules did not turn
off when commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C Module
did not Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Overcurrent on
Phase C
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Modules C overcurrent
condition was
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 IGBT Saturation
flt on C+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 83
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on C-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- has
experienced an
overcurrent
(saturation) condition
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6 Unequal current
sharing in C+
INV_OFF / Truck Speed
Limit
Inverter xx , Unequal
current sharing in C+
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 Unequal current
sharing in C-
INV_OFF / Truck Speed
Limit
Inverter xx , Unequal
current sharing in C-
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx35 1 INV x Phase C+
Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C+
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase C+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module C+
did not turn OFF when
expected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
84 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase C+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase C+ and C-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ turned ON
while Phase C-
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase C+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module C+
did not turn ON when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase C+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ did not turn
ON when commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
C+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C+ gate driver
power supply problem
detected
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 85
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx36 2 INV x Phase C+
(NR) Event
SYSEVENT / None
Inverter xx , INV C+ NR
CUP Temp Short.
Yes TMC: 3
DAB: 2
INV C+ NR
CUP_TEMP_SHO
RT
CBI: 2
3
INV C+ NR
CUP_TEMP_OPE
N
SYSEVENT / None Yes TMC: 3
DAB: 2
Inverter xx , INV C+ NR
CUP Temp open
CBI: 2
4
INV C+ NR
CUP_TEMP_WAR
M
SYSEVENT / None
Inverter xx , INV C+ NR
CUP Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV C+ NR
CUP_TEMP_HOT
SYSEVENT / None
Inverter xx , INV C+ NR
CUP Temp hot
Yes TMC: 3
DAB: 2
CBI: 2
6
Phase C+ not Off
with Enable/DCVolts
SYSEVENT / None
Inverter xx , Phase
Module C+ is not OFF
when expected with
the DC Link energized
Yes TMC: 3
DAB: 2
CBI: 2
7
* C+ ON/OFF
Edge Delay out
or range
SYSEVENT / None
Inverter XX C+ Phase
Module Edge Delay
Out of Range
Yes TMC: 3
DAB: 2
*for Dual IGBT
Systems only
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
86 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Xx37 1 INV x Phase C-
Event
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- did not turn
OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C- Module
did not Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase C-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module C-
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase C- Module
Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase C+ and C-
modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- detected
ON while Phase C+
was commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase C-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module C-
did not turn ON when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 87
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6 Phase C- Module
did not turn ON
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- did not turn
ON when commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
C-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C- gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx38 2 INV x Phase C-
(NR) Event
SYSEVENT / None
Inverter xx , INV C- NR
CDN Temp Short.
Yes TMC: 3
DAB: 2
INV C- NR
CDN_TEMP_SHO
RT
CBI: 2
3
INV C- NR
CDN_TEMP_OPE
N
SYSEVENT / None Yes TMC: 3
DAB: 2
Inverter xx , INV C- NR
CDN Temp open
CBI: 2
4
INV C- NR
CDN_TEMP_WA
RM
SYSEVENT / None
Inverter xx , INV C- NR
CDN Temp warm
Yes TMC: 3
DAB: 2
CBI: 2
5 INV C- NR
CDN_TEMP_HOT
SYSEVENT / None
Inverter xx , INV C- NR
CDN Temp hot
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
88 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
6
Phase C- Not off
with Enable/Dc
Volts
SYSEVENT / None
Inverter xx , Phase
Module C- is not OFF
when expected with
the DC Link energized
Yes TMC: 3
DAB: 2
CBI: 2
7
* C- ON/OFF
edge delay out
of range
SYSEVENT / None
Inverter XX C- Phase
Module Edge Delay
Out of Range
Yes TMC: 3
DAB: 2
CBI: 2
Xx39 1 Inv X Phase C
Current Event
INV_OFF / Truck Speed
Limit
Inverter xx Phase C
Current Sensor Failed
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2

CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase C Current
Sensor Failed
3 C Phase Current
too High
INV_OFF / Truck Speed
Limit
 Inverter xx C Phase
Current signal too
High
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx41 1 INV x phase C
Voltage Event
INV_OFF / Truck Speed
Limit
Inverter xx, C Phase
Modules voltage
sensor determined
failed during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C Voltage
Sensor Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 89
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2 Phase C Voltage
too High
INV_OFF / Truck Speed
Limit
Inverter xx, C Phase
Modules voltage
feedback is higher
than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx43 1 INV x Tach 1
Event
INV_OFF / Truck Speed
Limit
 Inverter xx motor
(TM1) Speed Sensor
(SS) rate of change is
too high
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Tach 1 High
Rate of Speed
2 Tach 1 No
Frequency Input
INV_OFF / Truck Speed
Limit
 Inverter xx motor (TM)
Speed Sensor (SS)
indicates 0 speed,
other sensors show
speed
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Tach
Intermittant
INV_OFF / Truck Speed
Limit
 Inverter xx motor (TM)
Speed Sensor (SS)
feedback signal is
intermittent
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx44 1 INV x Tach 1 (NR)
Event
SYSEVENT / None
Tach 1 single channel
operation
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
90 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Tach 1 single
channel
operation
2 Tach 1 high rate
of change
SYSEVENT / None
Tach 1 high rate of
change
Yes TMC: 3
DAB: 2
CBI: 2
3 Tach 1 no
frequency input
SYSEVENT / None
Tach 1 no frequency
input
Yes TMC: 3
DAB: 2
CBI: 2
Xx47 1 INV x Chopper 1
Event
SPD_LIM & ENGSPD_RP /
None
Chopper 1 did not turn
off
Yes TMC: 3
DAB: 2
CBI: 2
Chop1 did not
turn off
2 Overcurrent on
chopper 1
SPD_LIM & ENGSPD_RP /
None
Overcurrent on
chopper 1
Yes TMC: 3
DAB: 2
CBI: 2
4 IGBT sat fault on
chopper 1
SPD_LIM & ENGSPD_RP /
None
IGBT saturation fault
on chopper 1
Yes TMC: 3
DAB: 2
CBI: 2
5
IGBT power
supply fault on
chopper 1
SPD_LIM & ENGSPD_RP /
None
IGBT ps flt on chopper
1
Yes TMC: 3
DAB: 2
CBI: 2
6 Chopper 1 on-
state current hi
SPD_LIM & ENGSPD_RP /
None
Chopper 1 on-state
current hi
Yes TMC: 3
DAB: 2
CBI: 2
7
Chopper 1 on-
state current
low
SPD_LIM & ENGSPD_RP /
None
Chopper 1 on-state
current low
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 91
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
8
Chopper 1 on-
state current
OOR
SPD_LIM & ENGSPD_RP /
None
Chopper 1 on-state
current Out of range
Yes TMC: 3
DAB: 2
CBI: 2
Xx48 1 INV x Chopper 1
(NR) Event
SPD_LIM & ENGSPD_RP /
None
Chopper Module 1
(CM1) not OFF when
commanded, Inverter
1 controlling
Yes TMC: 3
DAB: 2
CBI: 2
Chopper 1
feedback not
OFF
2
Chopper 1
Feedback not
ON
SPD_LIM & ENGSPD_RP /
None
Chopper Module 1
(CM1) not ON when
commanded, Inverter
1 controlling
Yes TMC: 3
DAB: 2
CBI: 2
3
INV DB1
CHOPA_TEMP_S
HORT
SPD_LIM & ENGSPD_RP /
None
INV DB1 Chop A temp
short
Yes TMC: 3
DAB: 2
CBI: 2
4
INV DB1
CHOPA_TEMP_O
PEN
SPD_LIM & ENGSPD_RP /
None
INV DB1 Chop A temp
open
Yes TMC: 3
DAB: 2
CBI: 2
5
INV DB1
CHOPA_TEMP_
WARM
SPD_LIM & ENGSPD_RP /
None
INV DB1 Chop A temp
warm
Yes TMC: 3
DAB: 2
CBI: 2
6
INV DB1
CHOPA_TEMP_H
OT
SPD_LIM & ENGSPD_RP /
None
INV DB1 Chop A temp
hot
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
92 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information7
Chopper 1 Not
OFF with DC
Volts
SPD_LIM & ENGSPD_RP /
None
Chopper Module 1
(CM1) not OFF when
expected with DC Link
energized, Inverter xx
controlling
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 1 off
state current -
short
SPD_LIM & ENGSPD_RP /
None
Chopper 1 off state
current short
Yes TMC: 3
DAB: 2
CBI: 2
9
Excessive
chopper 1 null
current offset
SPD_LIM & ENGSPD_RP /
None
Excessive chopper 1
null current offset
Yes TMC: 3
DAB: 2
CBI: 2
10
IGBT sat flt on
chopper 1 --
nuisance
SPD_LIM & ENGSPD_RP /
None
IGBT saturation
faulton chopper 1 --
nuisance
Yes TMC: 3
DAB: 2
CBI: 2
11
IGBT sat flt on
chopper 2 --
nuisance
SPD_LIM & ENGSPD_RP /
None
IGBT saturation fault
on chopper 2 --
nuisance
Yes TMC: 3
DAB: 2
CBI: 2
Xx49 1 INV x Chopper 2
Event
SPD_LIM & ENGSPD_RP /
None
Chopper 2 did not turn
off
Yes TMC: 3
DAB: 2
Chop2 did not
turn off
CBI: 2
2 Overcurrent on
chopper 2
SPD_LIM & ENGSPD_RP /
None
Overcurrent on
chopper 2
Yes TMC: 3
DAB: 2
CBI: 2
4 IGBT sat fault on
chopper 2
SPD_LIM & ENGSPD_RP /
None
IGBT saturation fault
on chopper 2
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 93
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
5
IGBT power
supply faulkt on
chopper 2
SPD_LIM & ENGSPD_RP /
None
IGBT ps flt on chopper
2
Yes TMC: 3
DAB: 2
CBI: 2
6 Chopper 2 on-
state current hi
SPD_LIM & ENGSPD_RP /
None
Chopper 2 on state
current hi
Yes TMC: 3
DAB: 2
CBI: 2
7
Chopper 2 on-
state current
low
SPD_LIM & ENGSPD_RP /
None
Chopper 2 on state
current low
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 2 on-
state current
OOR
SPD_LIM & ENGSPD_RP /
None
Chopper 2 on state
current OOR
Yes TMC: 3
DAB: 2
CBI: 2
Xx50 1 INV x Chopper 2
(NR) Event
SPD_LIM & ENGSPD_RP /
None
Chopper Module 2
(CM2) not OFF when
commanded, Inverter
xx controlling
Yes TMC: 3
DAB: 2
Chopper 2
feedback not
OFF
CBI: 2
2
Chopper 2
Feedback not
ON
SPD_LIM & ENGSPD_RP /
None
Chopper Module 2
(CM2) not ON when
commanded, Inverter
xx controlling
Yes TMC: 3
DAB: 2
CBI: 2
3
INV DB2
CHOPB_TEMP_S
HORT
SPD_LIM & ENGSPD_RP /
None
INV DB2 Chop B temp
short
Yes TMC: 3
DAB: 2
CBI: 2
4
INV DB2
CHOPB_TEMP_O
PEN
SPD_LIM & ENGSPD_RP /
None
INV DB2 Chop B temp
open
Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
94 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
5
INV DB2
CHOPB_TEMP_
WARM
SPD_LIM & ENGSPD_RP /
None
INV DB2 Chop B temp
warm
Yes TMC: 3
DAB: 2
CBI: 2
6
INV DB2
CHOPB_TEMP_H
OT
SPD_LIM & ENGSPD_RP /
None
INV DB2 Chop B temp
hot
Yes TMC: 3
DAB: 2
CBI: 2
7
Chopper 2 Not
OFF with DC
Volts
SPD_LIM & ENGSPD_RP /
None
Chopper Module 2
(CM2) not OFF when
expected with DC Link
energized, Inverter xx
controlling
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 2 off
state current -
short
SPD_LIM & ENGSPD_RP /
None
Chopper 2 off state
current, short
Yes TMC: 3
DAB: 2
CBI: 2
9
Excessive
chopper 2 null
current offset
SPD_LIM & ENGSPD_RP /
None
Excessive chopper 2
null current offset
Yes TMC: 3
DAB: 2
CBI: 2
Xx51 1 INV x tach
differential Fault
SYSEVENT / None
Too much speed
difference
Yes TMC: 3
DAB: 2
CBI: 2
Too much speed
difference
Xx52 7
Miscellaneous
non-restrictive
fault
SYSEVENT / None
Level 1 wheel velocity
deviation
Yes TMC: 3
DAB: 2
Level 1 wheel
velocity
deviation
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 95
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
8
Level 2 wheel
velocity
deviation
SYSEVENT / None
Level 2 wheel velocity
deviation
Yes TMC: 3
DAB: 2
CBI: 2
9
Level 3 wheel
velocity
deviation
SYSEVENT / None
Level 3 wheel velocity
deviation
Yes TMC: 3
DAB: 2
CBI: 2
10
Level 4 wheel
velocity
deviation
SYSEVENT / None
Level 4 wheel velocity
deviation
Yes TMC: 3
DAB: 2
CBI: 2
11
Level 5 wheel
velocity
deviation
SYSEVENT / None
Level 5 wheel velocity
deviation
Yes TMC: 3
DAB: 2
CBI: 2
12
Level 6 wheel
velocity
deviation
SYSEVENT / None
Level 6 wheel velocity
deviation
Yes TMC: 3
DAB: 2
CBI: 2
13
High half order
engine
frequency
SYSEVENT / None
High half order engine
frequency
Yes TMC: 3
DAB: 2
CBI: 2
14
High fund
engine
frequency
SYSEVENT / None
High fund engine
frequency
Yes TMC: 3
DAB: 2
CBI: 2
15
High 1.5 x fund
engine
frequency
SYSEVENT / None
High 1.5 x fund engine
frequency
Yes TMC: 3
DAB: 2
CBI: 2
16
High second
order engine
frequency
SYSEVENT / None
High second order
engine frequency
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
96 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
17
High 2.5 x fund
engine
frequency
SYSEVENT / None
High 2.5 x fund engine
frequency
Yes TMC: 3
DAB: 2
CBI: 2
18
High third order
engine
frequency
SYSEVENT / None
High third order
engine frequency
Yes TMC: 3
DAB: 2
CBI: 2
19 IGBT phA temp
sensor bad
SYSEVENT / None
IGBT phA temp sensor
bad
Yes TMC: 3
DAB: 2
CBI: 2
20 IGBT phB temp
sensor bad
SYSEVENT / None
IGBT phB temp sensor
bad
Yes TMC: 3
DAB: 2
CBI: 2
21 IGBT phC temp
sensor bad
SYSEVENT / None
IGBT phC temp sensor
bad
Yes TMC: 3
DAB: 2
CBI: 2
22 Engineering Test
Flag 1
SYSEVENT / None
Engineering Test Flag
1
Yes TMC: 3
DAB: 2
CBI: 2
23 Engineering Test
Flag 2
SYSEVENT / None
Engineering Test Flag
2
Yes TMC: 3
DAB: 2
CBI: 2
24 Engineering Test
Flag 3
SYSEVENT / None
Engineering Test Flag
3
Yes TMC: 3
DAB: 2
CBI: 2
25 Engineering Test
Flag 4
SYSEVENT / None
Engineering Test Flag
4
Yes TMC: 3
DAB: 2
CBI: 2
26 Engineering Test
Flag 5
SYSEVENT / None
Engineering Test Flag
5
Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 97
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: 2
Xx53 1 INV x Motor fault
INV_OFF / Truck Speed
Limit
One of more phases of
motor circuit open
during VI Test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Motor
Connection
Open
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Motor
Connection
Short
INV_OFF / Truck Speed
Limit
 Inverter xx motor 1
(TM1)
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
phase-to-phase short DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
detected during VI
Test
CBI: 2
4 Motor overload
INV_OFF / Truck Speed
Limit
Motor overload Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx54 1 INV x Motor
Faults (NR)
SYSEVENT / none Motor rotor temp high Yes TMC: 3
DAB: 2
Motor Rotor
Temperature
High
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
98 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2
Motor Stator
Temperature
High
SYSEVENT / none
Motor stator temp
high
Yes TMC: 3
DAB: 2
CBI: 2
3 Motor type 0
detected
SYSEVENT / none Motor type 0 detected Yes TMC: 3
DAB: 2
CBI: 2
4 Motor type 1
detected
SYSEVENT / none Motor type 1 detected Yes TMC: 3
DAB: 2
CBI: 2
6
Current
approaching
pullout
SYSEVENT / none
Current approached
pullout
Yes TMC: 3
DAB: 2
CBI: 2
7 Filtered slip
close to pullout
SYSEVENT / none
Filtered slip close to
pullout
Yes TMC: 3
DAB: 2
CBI: 2
Xx56 1 INV x secondload (NR) Event
SYSEVENT / none Zero seq voltage high Yes TMC: 3
DAB: 2
Zero sequence
voltage high
CBI: 2
2 Zero sequence
current high
SYSEVENT / none Zero seq current high Yes TMC: 3
DAB: 2
CBI: 2
3
Negative
sequence
voltage high
SYSEVENT / none Neg Sys voltage high Yes TMC: 3
DAB: 2
CBI: 2
4
Negative
sequence
current high
SYSEVENT / none Neg seq current high Yes TMC: 3
DAB: 2
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 99
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
6
DAB transformer
primary winding
too hot
SYSEVENT / none
DAB transformer
primary winding too
hot
Yes TMC: 3
DAB: 2
CBI: 2
7
DAB transformer
secondary
winding too hot
SYSEVENT / none
DAB transformer
secondary winding too
hot
Yes TMC: 3
DAB: 2
CBI: 2
Xx57 1 Filter Event SYSEVENT / none
Inverter xx capacitor
over pressure
Yes TMC: 3
DAB: 2
Inverter
capacitor
overpressure
CBI: 2
2
Line-Neutral
voltage on cap
high
SYSEVENT / none
Line-neutral voltage
on cap high
Yes TMC: 3
DAB: 2
CBI: 2
3
Filter capacitor
value out of
tolerance
SYSEVENT / none
Filter cap value out of
tolerance
Yes TMC: 3
DAB: 2
CBI: 2
4
Filter inductance
value out of
tolerance
SYSEVENT / none
Filter inductance value
out of tolerance
Yes TMC: 3
DAB: 2
CBI: 2
Xx60 1 INV x Chopper 3
Fault
INV_OFF / None
Chopper 3 did not turn
off
Yes TMC: 3
DAB: 2
Chopper 3 did
not turn off
CBI: 2
2 Chopper 3
overcurrent
INV_OFF / None Chopper 3 overcurrent Yes TMC: 3
DAB: 2
CBI: 2
4 Chopper 3 IGBT
sat fault
INV_OFF / None
Chopper 3 IGBT
saturation fault
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
100 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
5 Chopper 3 IGBT
sat fault
INV_OFF / None
Chopper 3 IGBT
saturation fault
Yes TMC: 3
DAB: 2
CBI: 2
6 Chopper 3 on-
state current hi
INV_OFF / None
Chopper 3 on state
current hi
Yes TMC: 3
DAB: 2
CBI: 2
7
Chopper 3 on-
state current
low
INV_OFF / None
Chopper 3 on state
current lo
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 3 on-
state current
OOR
INV_OFF / None
Chopper 3 on state
current OOR
Yes TMC: 3
DAB: 2
CBI: 2
Xx61 1 INV x Chopper 3
(NR) Fault
Spd Lim-Eng RP / None
Chopper 3 feedback
not off
Yes TMC: 3
DAB: 2
Chopper 3
feedback not
OFF
CBI: 2
2
Chopper 3
Feedback not
ON
Spd Lim-Eng RP / None
Chopper 3 feedback
not on
Yes TMC: 3
DAB: 2
CBI: 2
7 Chopper 3 not
off with DC volts
Spd Lim-Eng RP / None
Chopper 3 not off with
DC volts
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 3 off
state current –
short
Spd Lim-Eng RP / None
Chopper 3 off state
current short
Yes TMC: 3
DAB: 2
CBI: 2
9
Excessive
chopper 3 null
current offset
Spd Lim-Eng RP / None
Excessive chopper 3
null current offset
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 101
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
CBI: 2
Xx62 1 INV x Chopper 4
Fault
INV_OFF / None
Chopper 4 did not turn
off
Yes TMC: 3
DAB: 2
Chopper 4 did
not turn off
CBI: 2
2 Chopper 4
overcurrent
INV_OFF / None Chopper 4 overcurrent Yes TMC: 3
DAB: 2
CBI: 2
4 Chopper 4 IGBT
sat fault
INV_OFF / None
Chopper 4 IGBT
saturation fault
Yes TMC: 3
DAB: 2
CBI: 2
5 Chopper 4 IGBT
sat fault
INV_OFF / None
Chopper 4 IGBT
saturation fault
Yes TMC: 3
DAB: 2
CBI: 2
6 Chopper 4 on-
state current hi
INV_OFF / None
Chopper 4 on state
current high
Yes TMC: 3
DAB: 2
CBI: 2
7
Chopper 4 on-
state current
low
INV_OFF / None
Chopper 4 on state
current low
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 4 on-
state current
OOR
INV_OFF / None
Chopper4 on state
current OOR
Yes TMC: 3
DAB: 2
CBI: 2
Xx63 1 INV x Chopper 4
(NR) Fault
Spd Lim-Eng RP / None
Chopper 4 feedback
not off
Yes TMC: 3
DAB: 2
CBI: 2
Chopper 4
feedback not
OFF
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
102 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2
Chopper 4
Feedback not
ON
Spd Lim-Eng RP / None
Chopper 4 feedback
not on
Yes TMC: 3
DAB: 2
CBI: 2
7 Chopper 4 not
off with DC volts
Spd Lim-Eng RP / None
Chopper 4 not off with
DC volts
Yes TMC: 3
DAB: 2
CBI: 2
8
Chopper 4 off
state current -
short
Spd Lim-Eng RP / None
Chopper 4 off state
current short
Yes TMC: 3
DAB: 2
CBI: 2
9
Excessive
chopper 4 null
current offset
Spd Lim-Eng RP / None
Excessive chopper 4
null current offset
Yes TMC: 3
DAB: 2
CBI: 2
Xx64 1 INV x2 Phase
A2+/A2- Fault
INV_OFF / Truck Speed
Limit
Inverter xx phase
module A2+ did not
turn off
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase A2
Module did not
Turn off
2 Overcurrent on
Phase A2
INV_OFF / Truck Speed
Limit
Inverter xx phase
module A2+
overcurrent
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 IGBT Saturation
flt on A2+
INV_OFF / Truck Speed
Limit
Inverter xx phase
module A2+ IGBT
saturation fault
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 103
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on A2-
INV_OFF / Truck Speed
Limit
Inverter xx phase
module A2- IGBT
saturation fault
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx65 1 INV x2 Phase
A2+ Fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2+ did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A2+
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase A2+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module A2+
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase A2+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2+ was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
104 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
4 Phae A2+ and
A2- modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2+ detected
ON while Phase
Module A+
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase A2+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module A2+
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase A2+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Mod- ule
A2+ did not turn ON
when com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
A2+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2+ gate
driver power supply
problem detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx66 1 INV x2 Phase
A2+ (NR) Fault
SYSEVENT / None
Inverter xx A2+ Phase
Modulefault
Yes TMC: 3
DAB: 2
CBI: 2
Phase A2+ (NR)
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 105
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
6
Phase A2+ not
Off with Enable/
DC Volts
SYSEVENT / None
Inverter xx A2+ Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
Xx67 1 INV x2 Phase
A2- fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2- did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A2-
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase A2-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module A2-
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase A2-
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase A2+ and
A2- modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2- detected
ON while Phase
Module A+
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
106 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase A2-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module A2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase A2-
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Module A2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
A2-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module A2- gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx68 1 INV x2 Phase
A2- (NR) fault
SYSEVENT / None
Inverter xx A2- Phase
Module fault
Yes TMC: 3
DAB: 2
Phase A2- (NR) CBI: 2
6
Phase A2- Not
off with Enable/
Dc Volts
SYSEVENT / None
Inverter xx A2- Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 107
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Xx69 1 INV x2 Phase A2
Current fault
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module A2 current
sensor was
determined as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase A2
Current Sensor
Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Current IA2 not
zero at Startup
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module A2 current
sensor signal was not
zero at startup
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 A2 Phase
Current too High
INV_OFF / Truck Speed
Limit
Current feedback from
Inverter xx, Phase
Module A2 current is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx73 1 INV x2 Phase
B2+/B2- Fault
INV_OFF / Truck Speed
Limit
Inverter xx phase
module B2+ did not
turn off
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Phase B2
Module did not
Turn off
2 Overcurrent on
Phase B2
INV_OFF / Truck Speed
Limit
Inverter xx phase
module B2+
overcurrent
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
108 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 IGBT Saturation
flt on B2+
INV_OFF / Truck Speed
Limit
Inverter xx phase
module B2+ IGBT
saturation fault
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on B2-
INV_OFF / Truck Speed
Limit
Inverter xx phase
module B2- IGBT
saturation fault
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx74 1 INV x2 Phase
B2+ Fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2+ did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B2+
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase B2+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module B2+
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase B2+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2+ was
detected as failed
during VI test
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 109
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phae B2+ and
B2- modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2+ detected
ON while Phase
Module B2-
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase B2+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module B2+
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase B2+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase ModuleB2+
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
B2+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2+ gate
driver power supply
problem detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx75 1 INV x2 Phase
B2+ (NR) Fault
SYSEVENT / None
Inverter xx B2+ Phase
Module fault
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
110 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: 2
Phase B2+ (NR) CBI: 2
6
Phase B2+ not
Off with Enable/
DC Volts
SYSEVENT / None
Inverter xx B2+ Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
Xx76 1 INV X2 Phase
B2- Fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2- did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B2-
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase B2-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module B2-
did not turn OFF when
expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase B2-
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase B2+ and
B2- modules on.INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2+ detected
ON while Phase
Module B2-
commanded ON
Yes TMC: 3
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 111
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase B2-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module B2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase B2-
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase ModuleB2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
B2-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module B2- gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx77 1 INV x2 Phase
B2- (NR) fault
SYSEVENT / None
Inverter xx B2- Phase
Module fault
Yes TMC: 3
DAB: 2
Phase B2- CBI: 2
6
Phase B2- Not
off with Enable/
Dc Volts
SYSEVENT / None
Inverter xx B2- Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
112 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
* for Dual IGBT
Systems only
CBI: 2
Xx78 1 INV x2 Phase B2
Current fault
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module B2 current
sensor was
determined as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase B2
Current Sensor
Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Current IB2 not
zero at Startup
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module B2 current
sensor signal was not
zero at startup
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 B2 Phase
Current too High
INV_OFF / Truck Speed
Limit
Current feedback from
Inverter xx, Phase
Module B2 current is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx82 1 INV x2 Phasea
C2+/C2- Fault
INV_OFF / Truck Speed
Limit
Inverter xx phase
module C2+ did not
turn off
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C2
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 113
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2 Overcurrent on
Phase C2
INV_OFF / Truck Speed
Limit
Inverter xx phase
module C2+
overcurrent
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 IGBT Saturation
flt on C2+
INV_OFF / Truck Speed
Limit
Inverter xx phase
module C2+ IGBT
saturation fault
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5 IGBT Saturation
flt on C2-
INV_OFF / Truck Speed
Limit
Inverter xx phase
module C2- IGBT
saturation fault
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx83 1 INV X2 Phase
C2+ Fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2+ did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C2+
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase C2+
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module
C2+did not turn OFF
when expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
114 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
3 Phase C2+
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2+ was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phae C2+ and
C2- modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2+detected
ON while Phase
Module B2-
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase C2+
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module C2+
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase C2+
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Module C2+
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
C2+
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2+ gate
driver power supply
problem detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 115
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx84 1 INV x2 Phase
C2+ (NR) Fault
SYSEVENT / None
Inverter xx C2+ Phase
Module fault
Yes TMC: 3
DAB: 2
Phase C2+ (NR) CBI: 2
6
Phase C2+ not
Off with Enable/
DC Volts
SYSEVENT / None
Inverter xx C2+ Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
Xx85 1 INV x2 Phase
C2- Fault
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2- did not
turn OFF when
commanded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C2-
Module did not
Turn off
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2
Phase C2-
Feedback not
OFF
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx , Phase Module C2-
did not turn OFF when
expected
Yes TMC: 3
DAB: /
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 Phase C2-
Module Failed
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2- was
detected as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
116 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
4 Phase C2+ and
C2- modules on.
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2+ detected
ON while Phase
Module B2-
commanded ON
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
5
Phase C2-
Feedback not
ON
INV_OFF / Truck Speed
Limit
During VI Test, Inverter
xx Phase Module C2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
6
Phase C2-
Module did not
turn ON
INV_OFF / Truck Speed
Limit
While running, Inverter
xx , Phase Module C2-
did not turn ON when
com- manded
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
7 IGBT PS Fault on
C2-
INV_OFF / Truck Speed
Limit
Inverter xx , Phase
Module C2- gate driver
power supply problem
detected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx86 1 INV X2 Phase
C2- (NR) Fault
SYSEVENT / None
Inverter xx C2- Phase
Module faultYes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 117
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
Phase C2- (NR) CBI: 2
6
Phase C2- Not
off with Enable/
Dc Volts
SYSEVENT / None
Inverter xx C2- Phase
Module did NOT turn
OFF when expected
while the DC Link is
charged
Yes TMC: 3
DAB: 2
* for Dual IGBT
Systems only
CBI: 2
Xx87 1 INV X2 Phase C2
Current Fault
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module B2 current
sensor was
determined as failed
during VI test
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
Phase C2
Current Sensor
Failed
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
2 Current IC2 not
zero at Startup
INV_OFF / Truck Speed
Limit
Inverter xx, Phase
Module B2 current
sensor signal was not
zero at startup
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
3 C2 Phase
Current too High
INV_OFF / Truck Speed
Limit
Current feedback from
Inverter xx, Phase
Module B2 current is
higher than expected
Yes TMC: 3
DAB: */
TRUCK_SPD_LIM_LOW
DAB: 2
* for Dual IGBT
Systems only
CBI: */
TRUCK_SPD_LIM_LOW
CBI: 2
Xx91 1 INV x generic
inverter event
SYSEVENT / None Generic Event Yes TMC: 3
DAB: 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
118 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2.3. ADDITIONAL SYSTEM EVENTS/DSC EVENT LIST (500 - 599)
2.3.1. Event Restriction
This is the restriction associated with the detection of the given event. Possible restrictions associated with a DSC
event are defined as follows:
Table 5. Event Restriction
2.3.2. Additional Events/DSC Event List (500 - 599)
Table 6. Additional Event/DSC Event List
Generic event CBI: 2
RESTRICTION OR ACTION DEFINITION OF RESTRICTED STATES
NO_PROPEL ”NO PROPEL” (Red) light illuminated in operator Cab. No propulsion effort
allowed, however, retard effort and DC link energization allowed. Loadbox
mode is also restricted
NO_POWER ”NO RETARD” (Red) Light illuminated in operator Cab. No Propulsion effort and
No retard effort allowed. DC Link is de-energized.
NO_RETARD Restricts retard mode but does not disable DC Link
SPD_LIM /
SYSWARN
”Propel System Caution” (Yellow) light illuminated in operator Cab. Propel,
Retard and DC link energization still allowed. The truck is under a speed limit
restriction of 10/15MPH (16/24KPH)
INV_OFF When Active, prohibits the system from enabling Inverter X’s run drive signal.
SYSEVENT There are no Restrictions. Event is for informational purposes only.
LDBX_HP Restrict loadbox to a certain HP
SPDLIM_LOW Set speed limit to a lower speed point of 5 MPH(8KPH)
DELAYED_SHTDWN Indicates a NO_PROPEL/NO_RETARD is imminent. Note, delayed shutdown
restrictions have an Operator Override feature where after the truck comes to a
stop the operator can operate the truck with a 50% torque de-rate and 5 MPH
(8KPH )speed limit by holding down the Dump Override / Reset switch. Unloaded
truck can be operated for 5 minutes and loaded truck can be moved 100M or 3
minutes. RETARD NOT AVAILABLE IN THIS MODE.
LOADBOX_DIS Load box is disabled
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
504 1
Aux Cooling Lim-
ited – DAB HP
Available Low
SPDLIM_LOW
LDBX_HP
Auxiliary cooling is limited due
to Dual Active bridge low HP.
Fault reset when required hp is
attained.
NO 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION
CAUSE OR
DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 119
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
504 2
Aux Cooling Lim-
ited - Cooling
Blwr Spd Low
SPDLIM_LOW
LDBX_HP
Auxiliary cooling is limited due
to Control group cooling blower
speed lower than expected.
Fault reset when required
speed is attained.
NO 2
504 3
Aux Cooling Lim-
ited - Wheel Blwr
Spd Low
SPDLIM_LOW
LDBX_HP
Auxiliary cooling is limited due
to wheel motor cooling blower
speed lower than expected.
Fault reset when required
speed is attained.
NO 2
504 4
Aux Cooling Lim-
ited - Grid Blwr 1
Spd Low
SPDLIM_LOW
LDBX_HP
Auxiliary cooling is limited due
to Grid cooling blower1 speed
lower than expected.
Fault reset when required
speed is attained.
NO 2
504 5
Aux Cooling Lim-
ited - Grid Blwr 2
Spd Low
SPDLIM_LOW
LDBX_HP
Auxiliary cooling is limited due
to Grid cooling blower2 speed
lower than expected.
Fault reset when required
speed is attained.
NO 2
505 1
Control Air Low –
Blwr HP FB Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Control group cooling blower
inverter HP feedback lower
than expected.
Fault reset when required hp
feedback is attained.
NO 0
505 2
Control Air Low –
Blwr Didn’t Start
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Control group cooling blower
inverter not running.
Fault Reset when Inverter 4 is
running.
NO 0
505 3
Control Air Low –
Blwr Spd TooLow
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Control group cooling blower
speed is below minimum speed
level.
Fault reset when blower speed
attains minimum speed.
NO 0
506 1
Wheel Air Low –
Blwr HP FB Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Wheel motor cooling blower
inverter HP feedback lower
than expected
Fault reset when required hp
feedback is attained.
NO 0
506 2
Wheel Air Low –
Blwr Didn’t Start
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Wheel motor cooling blower
inverter not running.
Fault Reset when Inverter 5 is
running.
NO 0
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
120 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
506 3
Wheel Air Low –
Blwr Spd Too Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Wheel motor cooling blower
speed is below minimum speed
level.
Fault reset when blower speed
attains minimum speed.
NO 0
508 1
Grid Blwr 1 Air
Low – Blwr HP FB
Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 1 inverter
HP feedback lower than
expected.
Fault reset when required hp
feedback is attained.
NO 0
508 2
Grid Blwr 1 Air
Low – Blwr Didn’t
Start
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 1 inverter
not running
Fault Reset when Inverter 6 is
running.
NO 0
508 3
Grid Blwr 1 Air
Low – Blwr Spd
Too Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 1 speed is
below minimum speed level.
Faul reset when blower speed
attains minimum speed.
NO 0
508 4
Grid Blwr 1 Air
Low – Grid Amps
w/ No Blwr
DELAYED_SHT-
DWN LOAD-
BOX_DIS
 Grid current present while grid
cooling blower 1 is not running
or Inverter 6 lost communica-
tion to DSC.
NO 0
509 1
Grid Blwr 2 Air
Low – Blwr HP FB
Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 2 inverter
HP feedback lower than
expected.
Fault reset when required hp
feedback is attained.
NO 0
509 2
Grid Blwr 2 Air
Low – Blwr Didn’t
Start
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 2 inverter
not running
Fault Reset when Inverter 7 is
running.
NO 0
509 3
Grid Blwr 2 Air
Low – Blwr Spd
Too Low
DELAYED_SHT-
DWN LOAD-
BOX_DIS
Grid cooling blower 2speed is
below minimum speed level.
Faul reset when blower speed
attains minimum speed.
NO 0
509 4
Grid Blwr 2 Air
Low – Grid Amps
w/ No Blwr
DELAYED_SHT-
DWN LOAD-
BOX_DIS
 Grid current present while grid
cooling blower 2 is not running
or Inverter 7 timeout.
NO 0
510
1
Chopper Module
1 Current Sensor:
CM1 Current Sen-
sor Reading Bad
SPD_LIM
Chopper Module 1 Current
Sensor bad reading.
NO 1
2
CM1 Current Sen-
sor Reading not
zero
Chopper Module 1 Current
Sensor reading not zero when
expected.
NO 1
EVENT
#
SUB
CODEEVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 121
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
511
1
Chopper Module
2 Current Sensor:
 CM2 Current
Sensor Reading
Bad
SPD_LIM
Chopper Module 2 Current
Sensor bad reading.
NO 1
2
CM2 Current Sen-
sor Reading not
zero
SPD_LIM
Chopper Module 2 Current
Sensor reading not zero when
expected.
NO 1
512
1
Chopper Module
3 Current Sensor:
CM3 Current Sen-
sor Reading Bad
SPD_LIM
Chopper Module 3 Current
Sensor bad reading.
NO 1
2
CM3 Current Sen-
sor Reading not
zero
SPD_LIM
Chopper Module 3 Current
Sensor reading not zero when
expected.
NO 1
513
1
Chopper Module
4 Current Sensor:
CM4 Current Sen-
sor Reading Bad
SPD_LIM
Chopper Module 4 Current
Sensor bad reading.
NO 1
2
CM4 Current Sen-
sor Reading not
zero
SPD_LIM
Chopper Module 4 Current
Sensor reading not zero when
expected.
NO 1
516 1
Operator Over-
ride Restricted –
Distance
Exceeded
NO_PROPEL
(long ramp)
NO_RETARD
LOADBOX_DIS
Operator Override Restricted –
Total allowed Distance
Exceeded without cooling
blowers running.
NO 0
517 1
Operator Over-
ride Restricted –
Temp Exceeded
NO_PROPEL
(long ramp)
Operator Override Restricted –
allowed system temperature
exceeded without cooling
blowers on.
NO 0
535 1
Ctrl Blwr Fault (L1)
– Locked Rotor
INV4_OFF
Control group cooling blower
detected with rotor restriction.
NO 2
535 2
Ctrl Blwr Fault (L2)
- Overspeed
INV4_OFF
Control group cooling blower
detected with over speed fault.
NO 2
536 1
Ctrl Blwr Fault (L2)
– HP FB too High
SPDLIM_LOW
LDBX_HP
Control group cooling blower
detected with higher HP than
expected.
NO 2
536 2
Ctrl Blwr Fault (L2)
– AC Gnd Fault
SPDLIM_LOW
LDBX_HP
Control group cooling blower
detected with AC Ground fault.
NO 2
536 3
Ctrl Blwr Fault (L2)
– Excessive inv
faults
SPDLIM_LOW
LDBX_HP
Control group cooling blower
detected with excessive num-
ber of inverter faults.
NO 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
122 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
537 1
Ctrl Blwr Fault (L3)
– Spd Too High
SPD_LIM LDBX-
_HP
Control group cooling blower
speed higher than command.
NO 2
538 1
Ctrl Blwr Fault (L4)
– HP Boost
Applied Short
SYSEVENT
 Dual Active Bridge Boost
applied.
NO 2
539 1
Ctrl CBI Comm
Loss – Comm
Loss to System
DELAYED_SHT-
DWN LOADBOX-
_DIS
Control group cooling blower
inverter 4 lost communication
to system.
NO 0
542 1
AC ground fault
on primary link –
Inverter 1/2
SPDLIM_LOW
LOADBOX_DIS
AC ground fault detected on
primary link for inverter 1 /2.
NO 2
543 1
DC ground fault
on primary link –
Inverter 1/2
SPDLIM_LOW
LOADBOX_DIS
DC ground fault detected on
primary link for inverter 1 /2.
NO 2
545 1
Transformer Hot
(L1) – Overtemp
DELAYED_SD
LOADBOX_DIS
Transformer temperature
exceeded red-line (maximum)
temperature.
NO 0
546 1
Transformer Hot
(L2) – Power Lim-
ited
SPDLIM_LOW
LOADBOX_DIS
Transformer temperature
exceeded yellow-line and
hence applied power is limited.
NO 2
547 1
Transformer Hot
(L3) – Air Flow
Increased
SYSEVENT
Transformer temperature ele-
vated, needing more air flow.
NO 2
548 1
DAB HP Margin
Low – Utilization
Near Max
SYSEVENT DAB HP margin low. NO 2
551 1
Cummins F1 ECU
Missing
SYSEVENT
No Communication to Cum-
mins Cense ECU.
Yes 0
555 1
Wheel Blwr Fault
(L1) – Locked
Rotor
INV5_OFF
Wheel motor cooling blower
detected with rotor restriction.
NO 2
555 2
Wheel Blwr Fault
(L2) - Overspeed
INV5_OFF
Wheel motor cooling blower
detected with over speed fault.
NO 2
556 1
Wheel Blwr Fault
(L2) – HP FB too
High
SPDLIM_LOW
LDBX_HP
Wheel motor cooling blower
detected with higher HP than
expected.
NO 2
556 2
Wheel Blwr Fault
(L2) – AC Gnd
Fault
SPDLIM_LOW
LDBX_HP
Wheel motor cooling blower
detected with AC Ground fault.
NO 2
556 3
Axle Blwr Fault
(L2) – Excessive
inv faults
SPDLIM_LOW
LDBX_HP
Wheel motor cooling blower
detected with excessive num-
ber of inverter faults.
NO 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 123
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
557 1
Axle Blwr Fault
(L3) – Spd Too
High
SPD_LIM LDBX-
_HP
Wheel motor cooling blower
speed higher than command.
NO 2
558 1
Wheel Blwr Fault
(L4) – HP Boost
Applied Short
SYSEVENT
Dual Active Bridge Boost
applied.
NO 2
559 1
Wheel CBI Comm
Loss – Comm
Loss to System
DELAYED_SHT-
DWN LOADBOX-
_DIS
Wheel motor cooling blower
inverter 5 lost communication
to system.
NO 0
565 1
Grid Blwr 1 Fault
(L1) – Locked
Rotor
INV6_OFF
Grid blower 1 detected with
rotor restriction.
NO 2
565 2
Grid Blwr 1 Fault
(L2) - Overspeed
INV6_OFF
Grid blower 1 detected with
over speed fault.
NO 2
566 1
Grid Blwr 1 Fault
(L2) – HP FB too
High
SPDLIM_LOW
LDBX_HP
Grid blower 1 detected with
higher HP than expected.
NO 2
566 2
Grid Blwr 1 Fault
(L2) – AC Gnd
Fault
SPDLIM_LOW
LDBX_HP
Grid blower 1 detected with AC
Ground fault.
NO 2
566 3
Grid Blwr 1 Fault
(L2) – Excessive
inv faults
SPDLIM_LOW
LDBX_HP
Grid blower 1 detected with
excessive number of inverter
faults.
NO 2
567 1
Grid Blwr 1 Fault
(L3) – Spd Too
High
SPD_LIM LDBX-
_HP
Grid blower 1 speed higher
than command.
NO 2
568 1
Grid Blwr 1 Fault
(L4) – HP Boost
Applied Short
SYSEVENT
Dual Active Bridge Boost
applied.
NO 2
569 1
Grid 1 CBI Comm
Loss – Comm
Loss to System
DELAYED_SHT-
DWN LOADBOX-
_DIS
Grid blower 1 inverter 5 lost
communication to system.
NO 0
570 1
DAB Fault – Sec
Link V Delta
SPD_LIM_LOW
LDBX_HP
Dual Active bridge secondary
link voltage not tracking.
NO 2
570 2
DAB Fault –
Excessive Faults
SPD_LIM_LOW
LDBX_HP
Dual Active bridge detected
excessive number of faults.
NO 2
570 3
DAB Fault –
Comm Loss to
System
SPD_LIM_LOW
LDBX_HP
Dual Active bridge inverter lost
communication to system.
NO 2
570 4
DAB Fault – DC
Gnd Fault on Pri-
mary
SPD_LIM_LOW
LDBX_HP
Dual Active bridge detected DC
ground fault on primary link.
NO 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
124 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
570 5
DAB Fault – AC
Gnd Fault on Pri-
mary
SPD_LIM_LOW
LDBX_HP
Dual Active bridge detected AC
ground fault on primary link.
NO 2
571 1
Gnd Fault – Sec-
ondary DC
SPDLIM_LOW
LDBX_HP
 Secondary DC link detected DC
ground fault.
NO 2
572 1
Dual Active
Bridge Fault – FB
Off
DELAYED_SHT-
DWN LOADBOX-
_DIS
Dual Active bridge is not ON
when expected.
NO 0
572 2
Dual Active
Bridge Fault – Sec
LinkV too Low
DELAYED_SHT-
DWN LOADBOX-
_DIS
Dual Active bridge detected
secondarty DC link voltage is
too low.
NO 0
575 1
Grid Blwr 2 Fault
(L1) – Locked
Rotor
INV7_OFF
Grid blower 2 detected with
rotor restriction.
NO 2
575 2
Grid Blwr 2 Fault
(L2) – Overspeed
INV7_OFF
Grid blower 2 detected with
over speed fault.
NO 2
576 1
Grid Blwr 2 Fault
(L2) – HP FB too
High
SPDLIM_LOW
LDBX_HP
Grid blower 2 detected with
higher HP than command.
NO 2
576 2
Grid Blwr 2 Fault
(L2) – AC Gnd
Fault
SPDLIM_LOW
LDBX_HP
Grid blower 2 detected with AC
Ground fault.
NO 2
576 3
Grid Blwr 2 Fault
(L2) – Excessive
inv faults
SPDLIM_LOW
LDBX_HP
Grid blower 2 detected with
excessive number of inverter
faults.
NO 2
577 1
Grid Blwr 2 Fault
(L3) – Spd Too
High
SPD_LIM LDBX-
_HP
Grid blower 2 speed higher
than command.
NO 2
578 1
Grid Blwr 2 Fault
(L4) – HP Boost
Applied Short
SYSEVENTDual Active Bridge Boost
applied.
NO 2
579 1
Grid 2 CBI Comm
Loss – Comm
Loss to System
DELAYED_SHT-
DWN LOADBOX-
_DIS
Grid blower 2 inverter 5 lost
communication to system.
NO 0
580 1
Engine - After-
treatmnt Fault
(7934-15)
SYSEVENT
Engine - Aftertreatment Fault
(7934-15).
NO 0
580 2
Engine - eFault
(7935-15)
SYSEVENT
Engine - Aftertreatment Fault
(7935-15).
NO 0
580 3
Engine - After-
treatmnt Fault
(7932-15)
SYSEVENT
Engine - Aftertreatment Fault
(7932-15).
NO 0
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 125
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
580 4
Engine - After-
treatmnt Fault
(7933-15)
SYSEVENT
Engine - Aftertreatment Fault
(7933-15).
NO 0
581 1
Engine - After-
treatmnt Fault
(7934-16)
SPDLIM_LOW
Engine - Aftertreatment Fault
(7934-16).
NO 0
581 2
Engine - After-
treatmnt Fault
(7935-16)
SPDLIM_LOW
Engine - Aftertreatment Fault
(7935-16).
NO 0
581 3
Engine - After-
treatmnt Fault
(7932-16)
SPDLIM_LOW
Engine - Aftertreatment Fault
(7932-16).
NO 0
581 4
Engine - After-
treatmnt Fault
(7933-16)
SPDLIM_LOW
Engine - Aftertreatment Fault
(7933-16).
NO 0
582 1
Engine - After-
treatmnt Fault
(7934-0)
NO_POWER
(long ramp)
Engine - Aftertreatment Fault
(7934-0).
NO 0
582 2
Engine - After-
treatmnt Fault
(7935-0)
NO_POWER
(long ramp)
Engine - Aftertreatment Fault
(7935-0).
NO 0
582 3
Engine - After-
treatmnt Fault
(7932-0)
NO_POWER
(long ramp)
Engine - Aftertreatment Fault
(7932-0).
NO 0
582 4
Engine - After-
treatmnt Fault
(7933-0)
NO_POWER
(long ramp)
Engine - Aftertreatment Fault
(7933-0).
NO 0
590 1
Firmware update
available - FB191
E-switch 1
SYSEVENT
Firmware update available -
FB191 E-switch 1.
NO 0
590 2
Firmware update
available - FB191
E-switch 2
SYSEVENT
Firmware update available -
FB191 E-switch 2.
NO 0
590 3
Firmware update
available - FM763
E-switch 1
SYSEVENT
Firmware update available -
FM763 E-switch 1.
NO 0
590 4
Firmware update
available - FM763
E-switch 2
SYSEVENT
Firmware update available -
FM763 E-switch 2.
NO 0
590 5
Firmware update
available – FB191
E-switch 1
SYSEVENT
Firmware update available –
FB191 E-switch 1.
NO 0
590 6
Firmware update
available – FB191
E-switch 2
SYSEVENT
Firmware update available –
FB191 E-switch 2.
NO 0
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
126 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
590 7
Firmware update
available – INV1
SYSEVENT
Firmware update available –
INV1.
NO 0
590 8
Firmware update
available – INV2
SYSEVENT
Firmware update available –
INV2.
NO 0
590 9
Firmware update
available – INV3
SYSEVENT
Firmware update available –
INV3.
NO 0
590 10
Firmware update
available – INV4
SYSEVENT
Firmware update available –
INV4.
NO 0
590 11
Firmware update
available – INV5
SYSEVENT
Firmware update available –
INV5.
NO 0
590 12
Firmware update
available – INV6
SYSEVENT
Firmware update available –
INV6.
NO 0
590 13
Firmware update
available – INV7
SYSEVENT
Firmware update available –
INV7.
NO 0
590 14
Firmware update
available – INV8
SYSEVENT
Firmware update available –
INV8.
NO 0
591 1
Effective Grade
Alert
SYSEVENT
System torque (based on nomi-
nal GVW) indicates an equiva-
lent grade above 12.7% for a
time more than 30 seconds in a
10-minute rolling window. Ver-
ify Truck Configuration/Setup,
Tire Rolling Radius, Rolling
Resistance, Actual Grade, GVW/
Payload.
NO 0
592 1
Effective Grade
Warning
SYSEVENT
System torque (based on nomi-
nal GVW) indicates an equiva-
lent grade above 13.3% for a
time more than 30 seconds in a
10-minute rolling window. Ver-
ify Truck Configuration/Setup,
Tire Rolling Radius, Rolling
Resistance, Actual Grade, GVW/
Payload.
NO 0
593 1
Effective Grade
Restriction-Warn-
ing
SYSEVENT
System torque (based on nomi-
nal GVW) indicates an equiva-
lent grade above 14% for a
time more than 30 seconds in a
10-minute rolling window. Ver-
ify Truck Configuration/Setup,
Tire Rolling Radius, Rolling
Resistance, Actual Grade, GVW/
Payload.
NO 0
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 127
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
2.4. DSC/TCI EVENT LIST (600 - 699)
2.4.1. Event Restriction
This is the restriction associated with the detection of the given event. Possible restrictions associated with a TCI
event are defined as follows:
Table 7. Event Restriction
2.4.2. DSC/TCI Event List (600 - 699)
Table 8. DSC/TCI Event List
594 1
Effective Grade
Restriction Warn-
ing
SPD_LIM
System torque (based on nomi-
nal GVW) indicates an equiva-
lent grade above 14% for a
time more than 5 minutes in a
10-minute rolling window. Ver-
ify Truck Configuration/Setup,
Tire Rolling Radius, Rolling
Resistance, Actual Grade, GVW/
Payload.
NO 0
RESTRICTION DEFINITION OF RESTRICTED STATES
PROPEL_INH
No propulsion effort allowed, however, retard effort and DC link ener-
gization allowed. In addition, when TCI asserts a No Propel fault it shall
also send an ACCEL INHIBIT across the serial link to PSC and illumi-
nate the NO PROPEL light in the operator cab.
TCI_SPDLIM
Requests the PSC to impose a 10 /15 MPH ((16/24KPH) speed limit.
Lights the Syswarn (yellow) light.
TCI_EVENT There are no restrictions. This is called a non-restrictive event.
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
601 1
CPU Card FB144/FB174 –
10 ms task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 2
CPU Card FB144/FB174 –
20 ms task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 3
CPU Card FB144/FB174 –
50 ms task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 4
CPU Card FB144/FB174 –
100 ms task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 5
CPU Card FB144/FB174 –
200 ms task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
EVENT
#
SUB
CODE
EVENT
DESCRIPTION
RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
128 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
601 6
CPU Card FB144/FB174 –
50 ms fault mgr task
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 7
CPU Card FB144/FB174 –
Flash CRC
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 9
CPU Card FB144/FB174 –
Maint task failed to init
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
601 10
CPU Card FB144/FB174 –
Excess timeouts
PROPEL_INH
TCI CPU Card Software or
problem with
I/O card communication.
NO 2
601 11
CPU Card FB144/FB174 –
Invalid pointers
PROPEL_INH
TCI CPU Card Initialization
Problem
NO 2
601 12
CPU Card FB144/FB174 –
Digital I/O card fault
PROPEL_INH
TCI CPU Card Hardware
problem detected
NO 2
602 FB104 Digital I/O PROPEL_INH
TCI card has lost commu-
nication with FB104 Digital
I/O
NO 2
603 FB160 Analog I/O PROPEL_INH
TCI card has lost commu-
nication with FB160 Ana-
log I/O
NO 2
604 1
PSC communication fault –
TCI detected PSC RS422
communication fault
TCI_SPDLIM
TCI CPU card has lost com-
munication
with the PSC CPU card.
NO 0
605
Aux Comm Fault
930E-1/2 only
TCIEVENT
TCI lost communication
with the Aux
Blower Control
NO 2
607 Positive 5 Volts TCI_SPDLIM
Positive (+) 5 VDC power
supply is out of range
NO 3
608 Positive 15 Volts TCI_SPDLIM
Positive (+) 15 VDC power
supply is out of range
NO 3
609 Negative 15 Volts TCI_SPDLIM
Negative (–)15 VDC power
supply is out of range
NO 3
610 Pot Reference TCI_SPDLIM
 Pot Reference voltage is
out of range
NO 3
613 1
Analog input out of limits –
Ground
TCI_SPDLIM
 Analog card internal
ground signal outside
range
NO 2
613 2
Analog input out of limits –
Gain check
TCI_SPDLIM
Analog card internal 10-
volt signal outside range
NO 2
614 1
Battery separate – Battery
separate failure
TCIEVENT
Battery separate contac-
tor failure
NO 2
614 2
Battery separate – Crank
battery > control battery
TCIEVENT
While engine running,
crank battery voltage >
control battery voltage
NO 2
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 129
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
614 3
Battery separate – Control
battery > crank battery
TCIEVENT
While engine running,
control battery voltage>
crank battery voltage
NO 2
616
Directional signal mis-
match
PROPEL_INH
Both Forward and Reverse
request ON
NO 3
617 1
Engine start request denied
– Engine warn while crank
TCIEVENT
Engine Warning signal
while cranking
NO 0
617 2
Engine start request denied
– Engine kill while crank
TCIEVENT
Engine Kill signal while
cranking
NO 0
618
Engine start request denied
– Non restrictive
Note: Only active for belaz.
Belaz can choose between
logging event 618 or 619
TCIEVENT
Engine warning signal
NO 0
619 Engine Warning received PROPEL_INH
Engine warning signal
received from engine con-
troller
NO 0
620 Engine Kill while moving PROPEL_INH
Engine Kill while truck is
moving
NO 2
622 1
Parking brake fault – Com-
mand/feedback failure
PROPEL_INH
Park brake command and
feedback mismatch
NO 3
622 2
Parking brake fault – Set
above max speed
PROPEL_INH
Park brake fault while
truck is moving
NO 3
623 1
Hydraulic brake fluid hot -
Hydraulic tank
TCIEVENT
Hydraulic brake fluid temp
high
NO 0
623 2
Hydraulic brake fluid hot –
Left front
TCIEVENT
Hydraulic brake fluid -left
front high
NO 0
623 3
Hydraulic brake fluid hot –
Right front
TCIEVENT
Hydraulic brake fluid -right
front high
NO 0
623 4
Hydraulic brake fluid hot –
Left rear
TCIEVENT
Hydraulic brake fluid -left
rear high
NO 0
623 5
Hydraulic brake fluid hot –
Right rear
TCIEVENT
Hydraulic brake fluid -right
rear high
NO 0
624 Body up with payload PROPEL_INH
Dump body up with pay-
load
NO 2
625 Dump Body up with speed TCIEVENT
Dump Body transitions
from down to up when
truck is in speed
NO 2
626
Load Brake Applied at
speed
TCIEVENT
Load Brake Applied at
speed
 NO 2
628 1
Battery connected out of
limits – Control battery low
TCI_SPDLIM Control battery low NO 0
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
130 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
628 2
Battery connected out of
limits – Control battery
high
TCI_SPDLIM Control battery high NO 0
629 1
Barometric pressure out of
limits - Low
TCIEVENT
Barometric pressure read-
ing is Low
NO 0
629 2
Barometric pressure out of
limits - High
TCIEVENT
Barometric pressure read-
ing is high
NO 0
630 1
Motor pressure out of limits
– Low air detected
TCI_SPDLIM
Digital axle box pressure
sensor indicates low air
NO 4
630 2
Motor pressure out of limits
– Sensor bad – V Low
TCI_SPDLIM
Analog axle box pressure
sensor reading low
NO 4
630 3
Motor pressure out of limits
– Sensor bad – V High
TCI_SPDLIM
Analog axle box pressure
sensor reading high
NO 4
630 4
Motor pressure out of limits
– Sense reversed
TCI_SPDLIM
 Analog Axle box pressure
sensor reveresed
NO 4
630 5
Motor pressure out of limits
– Digital sensor high with
engine off
TCI_SPDLIM
Digital axle box pressure
sensor reading high with
engine Off
NO 4
631 1
Amb Temp out of limits -
Low
TCIEVENT
Ambient temperature
reading low
NO 0
631 2
Amb Temp out of limits –
High
TCIEVENT
Ambient temperature
reading high
NO 0
632 1
Config data not valid – GE
config file
PROPEL_INH
The PSC or TCI CPU card
does not detect a valid GE
configuration file loaded
NO 0
632 2
Config data not valid –
Mine config file
PROPEL_INH
The PSC or TCI CPU card
does not detect a valid
mine configuration file
loaded
NO 0
632 3
Config data not valid – ver
incorrect
PROPEL_INH
The PSC or TCI CPU card
does not detect a valid
configuration file loaded
NO 0
632 6
Config data not valid – TCI
config file incorrect
PROPEL_INH
TCI CPU card incorrect
configuration
NO 0
632 9
Config data not valid – Old
version
PROPEL_INH Config file is older version NO 0
632 12
Config data not valid – GE
Config File Incorrect
PROPEL_INH
GE configuration file is not
as expected
NO 0
633 TCI BBRAM corrupted TCIEVENT
 TCI BBRAM corrupted
(FB144/FB174 only)
NO 1
634
Truck Overloaded – restric-
tive
PROPEL_INH
Restrictive, Truck payload
system has signaled the
truck is overloaded
NO 0
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 131
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
635
Truck Overloaded –non
restrictive
TCIEVENT
Non-restrictive Truck pay-
load system
has signaled the truck is
overloaded
NO 0
636 1
Aux Inv Fault – Low DC bus
V detected during pwrup
TCIEVENT
Aux blower controller
detected low DC bus volt-
age detected during
powerup
NO 5
636 2
Aux Inv Fault – High DC bus
V detected during pwrup
TCIEVENT
Aux blower controller
detected
high DC bus voltage
during powerup
NO 5
636 3
Aux Inv Fault – Overcur-
rent condition detected
during operation
TCIEVENT
Aux blower controller
detected overcurrent
during operation
NO 5
636 4
Aux Inv Fault – Blwr control
batt power loss (Ignore if
operates OK after reset)
TCIEVENT
Aux blower controller lost
battery power
NO 5
636 5
Aux Inv Fault – High DC bus
V detected during opera-
tion
TCIEVENT
Aux blower controller
detected high DC bus volt-
age during operation
NO 5
636 6
Aux Inv Fault – High DC bus
V detected after phase
controller pwrup
TCIEVENT
Aux blower controller
detected high DC bus volt-
age after power up
NO 5
636 7
Aux Inv Fault – Low DC bus
V detected after phase
controller pwrup
TCIEVENT
Aux blower controller
detected low DC bus volt-
age detected after
powerup
NO 5
636 8
Aux Inv Fault – High DC bus
V detected during opera-
tion
TCIEVENT
Aux blower controller
detected high DC bus volt-
age during operation
NO 5
636 9
Aux Inv Fault – Overcur-
rent detected after phase
controller pwrup
TCIEVENT
Aux blower controller
detected overcurrent after
power up
NO 5
636 10
Aux Inv Fault – Sustained
current overload below
safe component operating
range
TCIEVENT
Aux blower controller
detected sustained cur-
rent overload
NO 5
636 11
Aux Inv Fault – Overcur-
rent condition due to low
DC bus V
TCIEVENT
Aux blower controller
detected overcurrent due
to low dc bus voltage
NO 5
636 12
Aux Inv Fault – Sustained
current overload due to
low DC bus V
TCIEVENT
Aux blower controller
detected sustained cur-
rent overload due to low
dc bud voltage
NO 5
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
132 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
636 13
Aux Inv Fault – IGBT protec-
tion circuit detected an
overcurrent condition
TCIEVENT
Aux blower controller
detected IGBT overcurrent
NO 5
636 14
Aux Inv Fault – Zero input V
detected
TCIEVENT
Aux blower controller
detected insufficient input
voltage
NO 5
637 Aux link hot – main link off
TCIEVENT
930E1/2 ONLY
Aux blower controller
detected aux dc bus volt-
age while aux blower is offNO 5
638 Engine Cranking Timeout TCIEVENT
Engine cranking active
for more than 20 seconds
NO 0
639
Engine Start Request while
running
TCIEVENT
A request for diesel
engine start while the
diesel engine is running
NO 0
640 1
Accel pedal out of limits –
Too high
PROPEL_INH
The Accel Pedal input
voltage was greater than
Pot Reference voltage
NO 2
641 1
Accel pedal out of limits –
Too low
TCIEVENT
The Accel Pedal control
input voltage was lower
than expected
NO 2
642 1
Engine Started using Over-
ride
TCIEVENT
Engine crank protection
ON with engine start
request and reset/dump
body override ON
YES 9
643 1
Cabinet pressure out of
limits – Low air detected
TCI_SPDLIM
Control group Digital Con-
trol air pressure switch
indicates low pressure
with engine running
NO 4
643 2
Cabinet pressure out of
limits – Sensor high with
engine off
TCI_SPDLIM
Control group Digital Con-
trol air pressure switch
indicates high pressure
with engine not running
YES 4
643 3
Cabinet pressure out of
limits – Control group cool-
ing air
TCI_SPDLIM
Control group Digital Con-
trol air pressure switch
indicates low pressure
with engine running and
AFSE high temperature
YES 4
644 1
Cabinet heater circuit –
HCR failed open
TCIEVENT
Relay HCR commanded
closed (ON) and feedback
indicates HCR is open
(OFF)
NO 2
644 2
Cabinet heater circuit –
HCR failed close
TCIEVENT
Relay HCR commanded
open (OFF and feedback
indicates HCR is closed
(ON)
NO 2
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 133
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
644 3
Cabinet heater circuit –
HR1 did not close/blown
fuse
TCIEVENT
Relay HCR commanded
closed (ON) and HR1
feedback indicates open
(OFF)
NO 2
644 4
Cabinet heater circuit –
HR1 failed open
TCIEVENT
Relay HCR commanded
open (OFF) and HR1
feedback indicates
closed (ON)
NO 2
644 5
Cabinet heater circuit –
HR2 did not close/blown
fuse
TCIEVENT
Relay HCR commanded
closed (ON) and HR2
feedback indicates open
(OFF)
NO 2
644 6
Cabinet heater circuit –
HR2 failed open
TCIEVENT
Relay HCR commanded
open (OFF) and HR2
feedback indicates
closed (ON)
NO 2
644 7
Cabinet heater circuit –
HR3 did not close/blown
fuse (if used)
TCIEVENT
Relay HCR commanded
closed (ON) and HR3 (if
equipped) feedback
indicates open (OFF)
NO 2
644 8
Cabinet heater circuit –
HR3 failed open
TCIEVENT
Relay HCR commanded
open (OFF) and HR3 (if
equipped) feedback
indicates closed (ON)
NO 2
645 1
Pre-Shift brake test – Ser-
vice brake test
TCIEVENT
Pre-shift Service Brake
test active and specified
torque achieved for test
NO 0
645 2
Pre-Shift brake test – Park-
ing brake test
TCIEVENT
Pre-shift Parking Brake
test active and specified
torque achieved for test
NO 0
645 3
Pre-Shift brake test –
Retard test passed
TCIEVENT
Pre-shift retarder test
active and retarder
circuit passed test
NO 0
645 4
Pre-Shift brake test –
Momentary switch failed
TCIEVENT
Pre-shift retarder test
active and retarder
circuit failed test
NO 0
645 5
Pre-Shift brake test –
Momentary switch stuck
TCIEVENT
Pre-shift test activation
button input remains ON
for more than 60
seconds, brake is stuck
NO 0
646 1
E-Stop pressed – Digital
retard request active
PROPEL_INH
Dash Full Retard Request
button pressed and truck
speed is more than 1
mph (1.6 kph)
NO 0
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
134 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
647 1 Service Brake @ Speed TCIEVENT
Service Brake applied at
higher than preset truck
speed
NO 0
648 1
Wheel Motor Heater – Fail-
ure or Wiring
TCIEVENT
Wheel motor heater cir-
cuit-heater failure or wir-
ing issue
NO 2
648 2
Wheel Motor Heater – HR1
Failed to close/Bad Fuse
TCIEVENT
Wheel motor heater cir-
cuit- HR1 failed to close or
bad fuse
NO 2
648 3
Wheel Motor Heater – HR1
stuck closed
TCIEVENT
Wheel Motor Heater cir-
cuit – HR1 stuck closed
NO 2
648 4
Wheel Motor Heater – HR2
failed to close or bad fuse
TCIEVENT
Wheel Motor Heater cir-
cuit – HR2 failed to close
or bad fuse
NO 2
648 5
Wheel Motor Heater – HR2
stuck closed
TCIEVENT
Wheel Motor Heater cir-
cuit – HR2 stuck closed
NO 2
649 1
Speed Limit Config Error -
PSC-TCI Speed Limit Mis-
match
TCI_SPDLIM
PSC-TCI Speed Limit Mis-
match (configuration is
different)
NO 0
650 1
Pedal Calibration Needed –
Accel
TCIEVENT
Accel Pedal values are
outside the preset
numbers
NO 0
650 2
Pedal Calibration Needed –
Retard
TCIEVENT
Retard Pedal values are
outside the preset
numbers
NO 0
650 3
Pedal Calibration Needed –
Full HP
TCIEVENT
Accel Pedal does not regis-
ter
100% over an extended
period of time
NO 0
650 4
Pedal Calibration Needed -
Startup
TCIEVENT
Pedals (Accel/Retard)
must be calibrated after
replacement of any CPU
card or software load
NO 0
651 1 Truck ID not Set TCIEVENT
Truck Identification (ID)
has not been set or
programmed
NO 0
652 1
Incorrect DID Config – TCI
SW Incorrect
174 only
TCIEVENT
DID Panel configuration
incorrect for DID Panel
hardware
NO 0
653
1
Transformer Pressure out
of limits – Low Air Detected
TCI_SPDLIM
Transformer Pressure
switch – Low Air Detected
NO 4
2 Sensor high with engine off TCI_SPDLIM
Transformer Pressure
switch sesor high with
engine off
NO 4
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTO
RESET
OPER.
RESET
GE Proprietary and Confidential Information 135
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
654 2
Sys Boot not from Pwrup –
Slow Watchdog
TCIEVENT
TCI CPU card reset due to
slow watchdog timer
expiring
YES - 30
Sec.
N/A
654 3
Sys Boot not from Pwrup –
SW Request
TCIEVENT
TCI CPU card reset due to
request from software
YES - 30
Sec.
N/A
654 4
Sys Boot not from Pwrup –
Normal
TCIEVENT Normal powerup
YES - 30
Sec.
N/A
654 6
Sys Boot not from Pwrup –
Power Monitor
TCIEVENT
TCI CPU card reset due to
Power +5vdc monitor
YES - 30
Sec.
N/A
654 7
Sys Boot not from Pwrup –
Push Button Reset
TCIEVENT
TCI CPU card reset due to
Reset Pin being jumpered
YES - 30
Sec.
N/A
654 8
Sys Boot not from Pwrup –
Fast Watchdog
TCIEVENT
TCI CPU card reset due to
fast watcdog expiring
YES - 30
Sec.
N/A
654 9
Sys Boot not from Pwrup –
1.2 Vdc Pwr Supply
TCIEVENT
TCI CPU card reset due to
1.2 V Power Supply out of
Tolerance
YES - 30
Sec.
N/A
654 10
Sys Boot not from Pwrup –
1.25 Vdc Pwr Supply
TCIEVENT
TCI CPU card reset due to
1.25 Vdc Power Supply
out of Tolerance
YES - 30
Sec.
N/A
654 11
Sys Boot not from Pwrup –
2.5 Vdc Pwr Supply
TCIEVENT
TCI CPU card reset due to
2.5 Vdc Power Supply out
of Tolerance
YES - 30
Sec.
N/A
654 12
Sys Boot not from Pwrup –
3.3 Vdc Pwr Supply
TCIEVENT
TCI CPU card reset due to
3.3 Vdc Power Supply out
of Tolerance
YES - 30
Sec.
N/A
654 17
Sys Boot not from Pwrup –
Vehicle Moving at Reboot
TCIEVENT
Vehicle Speed was >
1mph (1.6 kph) when TCI
CPU card
booted.
YES - 30
Sec.
N/A
655 1
Too Many Boots not from
Pwrup – Multiple 654
Events
TCI_SPDLIM
TCI Event 654 logged 3
times within a 30 minute
window
NO 0
656 1
Excessive Brake Applica-
tion – Add. Cooling in Prog-
ress
TCIEVENT
Additional wheel motor
cooling requested by OEM NO 0
657 1
Barometric Pressure Sen-
sor
TCIEVENT
 GE Sensor and engine
sensor are not matching
NO 0
696
Unexpected CPU reset
174 only
TCIEVENT
The PSC or TCI CPU card
reset while truck was in
an operational mode
YES 2
698 PTU Data Store TCIEVENT
A Data Store process was
manually initiated
NO 9
699 Old Version of Primary OS TCIEVENT
Primary operating system
is of older version
NO 0
EVENT #
SUB
CODE
EVENT DESCRIPTION RESTRICTION CAUSE OR DEFINITION
AUTORESET
OPER.
RESET
136 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
3. HISTORICAL DATA COUNTERS
The historical data counters maintain a numerical count for each occurrence of the Counter Number listed in the
Counter Table. Each Counter Number of the Counter Table counts:
• LCOUNT — The lifetime count which is associate with its date, LCOUNT START. It can be reset to zero by a pass-
word level privileged user, and the LCOUNT START will automatically be set to the date on the CPU board when
the reset occurred.
• LAST MONTH — This is the total number of counts for the monitored parameter over the last month. This
counter has the same value throughout the duration of a month. At midnight during a month change, this
counter is overwritten by the THIS MONTH value, since at this time THIS MONTH becomes LAST MONTH.
• THIS MONTH — This counter maintains a moment by moment count of the occurrences of the parameter. The
counts are not reset to zero until midnight of the next month.
• LAST QTR — This is the total number of counts for the parameter over the last fiscal quarter, also known as the
last three months. This counter has the same value throughout the duration of a quarter. At midnight during a
quarter change, this counter is overwritten by the THIS QTR value, since at this time THIS QTR becomes LAST
QTR.
• THIS QTR — This counter maintains a moment by moment count of the occurrences of the parameter. The
counts are not reset to zero until midnight of the next quarter.
• YESTERDAY — This is the total number of counts for the parameter over the last 24 hours. This counter has the
same value throughout the duration of a day. At midnight this counter is overwritten by the THIS DAY value.
• THIS DAY — This counter maintains a moment by moment count of the occurrences of the parameter. The
counts are reset to zero every midnight, whether or not it is quarter change.
If the TCI electronic control panel is shutoff before midnight, any necessary resetting of counters shall be done when
the panel next powers up after midnight.
Whenever TCI is programmed, i.e., the TCI CPU card has the contents of the FLASH proms altered, the Lcount, Last
Qtr and This Qtr counts are not changed. However, the This Day count shall be reset to zero.
In order to effectively use the statistical data to monitor maintenance of the vehicle, it is recommended that an
office spread sheet or data base computer program be used to keep quarterly records of the statistical data. In
order to facilitate the upload of statistical data from the CPU card to an office computer, a feature called UPLOAD
STATISTICAL DATA TO A FILE shall be provided via PTU communication. This feature shall put all the collected statisti-
cal data into an ASCII file which can then be processed in the office to keep records on truck use.
3.1. MINE HISTORICAL COUNTERS (301 - 399)
This section details the Mine Counters. A counter is a single stat that is incremented by 1 whenever a defined event
occurs.
Table 9. Mine Truck Counters
EVENT # DESCRIPTION UNITS COUNT CONDITIONS
301 Truck Life Hours Calendar hours that have elapsed since the CPU has been loaded
with its current version of software. NOTE: This counter only has
non-zero values in Lifetime Counter column.
302 Control Power
On
Hours Number of hours that the control power relay (CPR) has been ener-
gized.
GE Proprietary and Confidential Information 137
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
303 Engine Oper-
ate
Hours Number of hours of engine operation above the engine
running threshold criteria.
304 Engine Idle Hours Number of hours when engine is idling and truck is stationary.
305 Truck Operate Hours The summation number of hours that the propulsion system has
operated in propulsion, retard, ready and test.
306 Truck Parked Hours Summation number of hours that the Park Brake applied
feedback is true while drive is energized.
307 Truck Travel Miles Cumulative miles travelled by the truck. Calculated average value of
the four wheel motor speed signals.
308 Truck Travel Kilometers Cumulative miles travelled by the truck. Calculated average non-
directional value of the four wheel motor speed signals.
309 Wheel 1 Oper-
ate
Hours Number of hours that wheel #1 was providing torque in either pro-
pulsion or retard, and was moving.
310 Wheel 2 Oper-
ate
Hours Number of hours that wheel #2 was providing torque in either pro-
pulsion or retard, and was moving.
311 Propel For-
ward
Hours Number of hours that the truck was moving forward in the propul-
sion mode of operation.
312 Retard For-
ward
Hours Number of hours that the truck was moving forward in the retard
mode of operation.
313 Propel Mode Hours Number of hours that the truck was moving in the propulsion mode
of operation.
314 Retard Mode Hours Number of hours that the truck was moving in the retard mode of
operation.
315 CPR Pickup Occurrences Number of times when the Keyswitch was moved from the STOP to
the ON position.
316 GF Pickup Occurrences Number of times that the GF contactor feedback has
indicated GF picked up (turned on).
317 GFR Pickup Occurrences Number of times that the GFR relay feedback has indicated GFR
picked up (turned on).
318 RP1 Pickup Occurrences Number of times that the RP1 relay feedback has indicated RP1
picked up (turned on).
319 RP2 Pickup Occurrences Number of times that the RP2 relay feedback has indicated RP2
picked up (turned on).
320 RP3 Pickup Occurrences Number of times that the RP3 relay feedback has indicated RP3
picked up (turned on).
321 Dump Body
Up
Occurrences Number of times the dump body up sensor indicated the dumped
body moved up from the down position.
322 Loaded Truck Occurrences Number of times that the Full Payload system input has changed to
indicate loaded.
323 Speed Set 1 Occurrences Number of times that the programmable speed set point #1 has
been exceeded.
324 Speed Set 2 Occurrences Number of times that the programmable speed set point #2 has
been exceeded.
EVENT # DESCRIPTION UNITS COUNT CONDITIONS
138 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
325 Engine Start
Switch
Occurrences Number of times that the engine start request was actuated by the
operator’s Keyswitch.
326 Engine On
and Start
Occurrences Number of times that engine start request received while the
engine above its running threshold criteria.
327 Separate
Batteries
Occurrences Number of times that the control and cranking batteries were com-
manded to separate.
328 Engine Crank Occurrences Number of times that a crank command has been issued to the
engine.
329 Engine Starts Occurrences Number of times that the measured engine RPM has exceeded the
engine running criteria.
330 Engine Off Occurrences Number of times that the Engine Kill push button was
actuated.
331 Park Brake
Request
Occurrences Number of times that the Operator’s Park Brake switch was actu-
ated.
332 Park Brake
Applied
Occurrences Number of times that the Park Brake pressure switch feedback indi-
cates switching from release to apply.
333 Selector
Switch to
Reverse
Occurrences Number of times that the Selector Switch was moved to the
REVERSE position.
334 Selector
Switch to For-
ward
Occurrences Number of times that the Selector Switch was moved to the FOR-
WARD position.
335 Selector
Switch When
Moving
Occurrences Number of times that the Selector was moved to command a direc-
tion change while the truck was moving.
336 RSC Switch On Occurrences Number of times that the Retard Speed Control (RSC) switch was
moved from OFF to ON.
337 Rest Request Occurrences Number of times that the rest request was received by
actuation of the Rest Request switch.
338 Override
Switch
OccurrencesNumber of times that the override command was received by actu-
ation of the Override switch.
339 Lamp Test
Switch
Occurrences Number of times, that the Lamp Test switch has been operated.
340 Engine Cau-
tions
Occurrences Number of times that the Engine Cautions signal received from the
Engine Controller.
341 Engine OEM
Overspeed
Occurrences Number of times that the Engine Speed increases above an OEM–
selected limit.
342 Load Brake Occurrences Number of times that the Load Brake input transitioned from OFF to
ON (specific applications).
343 Load Brake Seconds The amount of time that the Load Brake is applied (specific applica-
tions).
344 Service Brake
at Speed
Occurrences Number of times that the Service Brake is applied at speed.
EVENT # DESCRIPTION UNITS COUNT CONDITIONS
GE Proprietary and Confidential Information 139
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
345 Service Brake
at Speed
Seconds The amount of time that the Service Brake is applied at speed.
347 Starter Failure Occurrences Number of times the engine starter fail signal transitioned from OFF
to ON (if equipped).
348 Coasting Hours Number of hours truck coasting when ready mode is active and
Wheel #1 or #2 speed is above 50 RPM.
349 Rest Hours Number of hours that are spent in the Rest mode.
350 Test Hours Number of hours that are spent in the Test mode.
351 Enter READY Occurrences Number of times that the READY mode has been entered.
352 Enter Test Occurrences Number of times that the Test mode has been entered.
353 Enter Propel Occurrences Number of times that the Propel mode has been entered.
354 Enter Retard Occurrences Number of times that the Retard mode has been entered.
355 Speed Con-
trol Active
Occurrences Number of times that propel torque is regulated in the speed limit
mode.
356 M1 Spin Time Seconds Number of seconds that Wheel #1 Spin Control is active.
357 M1 Slide Time Seconds Number of seconds that Wheel #1 Slide Control is active.
358 M2 Spin Time Seconds Number of seconds that Wheel #2 Spin Control is active.
359 M2 Slide Time Seconds Number of seconds that Wheel #2 Slide Control is active.
360 M1 Spin Count Occurrences Number of times that Wheel #1 Spin Control is active.
361 M1 Slide
Count
Occurrences Number of times that Wheel #1 Slide Control is active.
362 M2SpinCount Occurrences Number of times that Wheel #2 Spin Control is active.
363 M2 Slide
Count
Occurrences Number of times that Wheel #2 Slide Control is active.
364 Service Brake
Time
Seconds Number of seconds that the wet brake is applied and truck is in
motion.
365 Service Brake
Applied
Occurrences Number of times that the wet brake is applied and truck is in
motion.
366 Load Box
Mode
Seconds Number of seconds that the system is in load box mode.
367 Battery Char-
ger Failure
Seconds Number of seconds the Battery Voltage is outside of a defined
range while the Battery charger should be active.
368 Pedal
Calibrations
Occurrences Number of times that the DID Pedal Calibration routine was run.
369 Pedal Failures Occurrences Number of times that the DID Pedal Calibration routine failed.
370 Payload
Communica-
tion Error
Occurrences Number of times that the Serial Payload Interface has
experienced a communication error.
371 Overpayload Occurrences Number of times that the Overload Payload signal
372 Overpayload Seconds Number of seconds that the Overpayload signal is ON.
373 Parking Brake
Test
Occurrences Number of times that the Pre-Shift Brake test for the Parking Brake
is run.
EVENT # DESCRIPTION UNITS COUNT CONDITIONS
140 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
3.2. DSC AND PSC HISTORICAL EVENT COUNTER
The DSC and PSC Event counters are in the Range 1001 through 1099 and correspond to the DSC or PSC Event num-
ber + 1000 listed in section 2.1.. The units for all the Event counters are number of occurrences, adding a count each
time an Event becomes active. Each Counter presents the counts in Lifetime, Last Month, This Month, Last Quarter,
This Quarter, and This Day as detailed in section 3.. The DSC and PSC Event Counters are not shown since they follow
the same pattern as the related Event List.
3.3. INVERTER 1 HISTORICAL EVENT COUNTER
The Inverter 1 counters are in the Range 1100 through 1199 and correspond to the Inverter 1 Event number + 1000
listed in section . The units for all the Event counters are number of occurrences, adding a count each time an Event
374 Service Brake
Test
Occurrences Number of times that the Pre-Shift Brake test for the Service Brake
is run.
375 Retarder Test Occurrences Number of times that the Pre-Shift Retarding test for the Retarder is
run.
376 Warm-up
Mode
Hours Number of hours that the Engine Warm-up mode is active.
377 Spin Disable Occurrences Number of times that the Spin Disabled switch is activated by the
operator.
378 Cruise Active Seconds Number of seconds, that the Cruise Control is active.
379 Wheel Brake
Lock
Occurrences Number of times, that the Wheel Brake Lock is applied.
380 Neutral Occurrences Number of times, that the Neutral direction is requested.
381 Alternator
KW Hours
KW_Hours This is accumulated Alternator Kilowatt hours.
382 Retard Engine
Increment 1
Occurrences Number of times, that the Engine rpm increases to level 1 during
retard.
383 Retard Engine
Increment 2
Occurrences Number of times, that the Engine rpm increases to level 2 during
retard.
384 Wheel Motor
Heater Time
Sec This is the amount of time the wheel motor heater has run.
385 Wheel Motor
Heater Cycles
times This is the number of cycles the wheel motor heater has run.
386 Fuel Saver
Disabled by
Temp Times
times This is the number of times fuel saver was disabled by temperature.
387 Fuel Saver
Disabled by
Temp Total
Sec This is the number of times fuel saver was disabled by temperature.
388 Fuel Saver 2
Active
Sec This is the amount of time fuel saver 2 was activated.
389 Fuel Saver 1a
Active
Sec This is the amount of time fuel saver 1a was activated.
EVENT # DESCRIPTION UNITS COUNT CONDITIONS
GE Proprietary and Confidential Information 141
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
becomes active. Each Counter presents the counts in Lifetime, Last Month, This Month, Last Quarter, This Quarter,
and This Day as detailed in section 3.. The Inverter 1 Event Counters are not shown since they follow the same pat-
tern as the related Event List.
3.4. INVERTER 2 HISTORICAL EVENT COUNTER
The Inverter 2 counters are in the Range 1200 through 1299 and correspond to the Inverter 2 Event number + 1000
listed in section . The units for all the Event counters are number of occurrences, adding a count each time an Event
becomes active. Each Counter presents the counts in Lifetime, Last Month, This Month, Last Quarter, This Quarter,
and This Day as detailed in section 3.. The Inverter 2 Event Counters are not shown since they follow the same pat-
tern as the related Event List.
3.5. DSC AND TCI HISTORICAL EVENT COUNTER
The DSC and TCI Event Counters are in the range 1600 - 1699 and correspond to the DSC or TCI Event number + 1000
listed in section Table 6.. The units for all the Event Counters are number of occurrences, adding a count each time
an Event becomes active. Each Counter presents the counts in Lifetime, Last Month, This Month, Last Quarter, This
Quarter, and This Day as detailed in section 3.. The DSC or TCI Event Counters are not shown since they follow the
same pattern as the related Event List.
142 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
4. HISTORICAL PROFILES
A Histogram for each parameter of the Historical Statistical Data Profiles is created with seventeen ranges,some-
times called “buckets.” A count in units is added to the range or bucket when the parameter is within one of the
ranges.
Table 10 outlines the Historical Statistical Data Profiles portion of the Control System.
4.1. MINE HISTORICAL STATISTICAL DATA PROFILES (401 - 441)
Table 10. Mine Historical Statistical Data Profiles
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
401 Alt HPNET In Seconds Histogram of alternator input horsepower. The count
starts whenever the truck is in the propel state. It is a
calculated value. Ranges indicate horsepower is
greater than (>) and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Net Input Horsepower Ranges
<= 650
> 650 to <= 850
> 850 to <= 1050
> 1050 to <= 1250
> 1250 to <= 1450
> 1450 to <= 1650
> 1650 to <= 1850
> 1850 to <= 2050
> 2050 to <= 2250
> 2250 to <= 2450
> 2450 to <= 2650
> 2650 to <= 2850
> 2850 to <= 3050
> 3050 to <= 3250
> 3250 to <= 3450
> 3450 to <= 3650
> 3650
GE Proprietary and Confidential Information 143
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
402 Control Battery Seconds Histogram of Control Battery Voltage. The count starts
whenever CPR is on. Ranges indicate battery voltage is
greater than (>) and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Battery Voltage Ranges
<= 12
> 12 to <= 14
> 14 to <= 16
> 16 to <= 18
> 18 to <= 20
> 20 to <= 22
> 22 to <= 24
> 24 to <= 26
> 26 to <= 27
> 27 to <= 28
> 28 to <= 29
> 29 to <= 30
> 30 to <= 32
> 32 to <= 34
> 34 to <= 36
> 36 to <= 38
> 38
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
144 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
403 Crank Battery Seconds Histogram of crank battery voltage. Ranges indicate
crank battery voltage is greater than (>) and less than
(<) or equal to (=) values as shown. Time is shown in sec-
onds for each range.
Battery Voltage Ranges.
<= 2
> 2 to <= 4
> 4 to <= 6
> 6 to <= 8
> 8 to <= 10
> 10 to <= 12
> 12 to <= 14
> 14 to <= 16.5
> 16.5 to <= 18
> 18 to <= 20
> 20 to <= 22
> 22 to <= 24
> 24 to <= 26
> 26 to <= 28
> 28 to <= 30
> 30 to <= 32
> 32
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 145
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
405 Retard Mode HP Seconds Histogram of link horsepower. The count starts when-
ever the truck is in the retard mode. It is a calculated
value. Ranges indicate Retard
horsepower is greater than (>), and less than (<) or
equal to (=) values shown. Time is shown in
seconds for each range.
Retard Horsepower Ranges
<= 800
> 800 to <= 1200
> 1200 to <= 1600
> 1600 to <= 2000
> 2000 to <= 2400
> 2400 to <= 2800
> 2800 to <= 3200
> 3200 to <= 3600
> 3600 to <= 4000
> 4000 to <= 4200
> 4200 to <= 4400
> 4400 to <= 4600
> 4600 to <= 4800
> 4800 to <= 5000
> 5000 to <= 5200
>5200 to <= 5400
> 5400
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
146 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
407 Truck Spd MPH Seconds Histogram of truck speed in MPH. The count starts
whenever CPR is on. Ranges indicate truck MPH is
greater than (>), and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Truck Speed Ranges (MPH)
<= 2.0
> 2.0 to <= 4.0
> 4.0 to <= 5.0
> 5.0 to <= 6.0
> 6.0 to <= 8.0
> 8.0 to <= 10.0
> 10.0 to <= 12.0
> 12.0 to <= 17.0
> 17.0 to <= 22.0
> 22.0 to <= 27.0
> 27.0 to <= 32.0
> 32.0 to <= 37.0
> 37.0 to <= 39.0
> 39.0 to <= 41.0
> 41.0 to <= 43.0
> 43.0 to <= 45.0
> 45.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 147
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
408 Truck Spd KPH Seconds Histogram of truck speed in KPH. The count starts
whenever CPR is on. Ranges indicate truck KPH is
greater than (>), and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Truck Speed Ranges (KPH)
<= 3.0
> 3.0 to <= 6.4
> 6.4 to <= 8.0
> 8.0 to <= 9.6
> 9.6 to <= 12.8
> 12.8 to <= 16.0
> 16.0 to <= 19.0
> 19.0 to <= 27.0
> 27.0 to <= 35.0
> 35.0 to <= 43.0
> 43.0 to <= 51.0
> 51.0 to <= 60.0
> 60.0 to <= 63.0
> 63.0 to <= 66.0
> 66.0 to <= 69.0
> 69.0 to <= 72.0
> 72.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
148 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
409 Motor 1 RPM Seconds Histogram of Traction Motor 1 electric motor RPM in all
modes of operation. The count starts
whenever CPR is on. Ranges indicate motor RPM is
greater than (>), and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Motor 1 RPM Ranges
< 70
> 70 to <= 287
> 287 to <= 452
> 452 to <= 567
> 567 to <= 735
> 735 to <= 900
> 900 to <= 1050
> 1050 to <= 1200
> 1200 to <= 1500
> 1500 to <= 1800
> 1800 to <= 2100
> 2100 to <= 2400
> 2400 to <= 2700
> 2700 to <= 3000
> 3000 to <= 3150
> 3150 to <= 3300
> 3300
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 149
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
410 Motor 2 RPM Seconds Histogram of Traction Motor 2 electric motor RPM in all
modes of operation. The count starts
whenever CPR is on. Ranges indicate motor RPM is
greater than (>), and less than (<) or equal to (=) values
shown. Time is shown in seconds for each range.
Motor 2 RPM Ranges
< 70
> 70 to <= 287
> 287 to <= 452
> 452 to <= 567
> 567 to <= 735
> 735 to <= 900
> 900 to <= 1050
> 1050 to <= 1200
> 1200 to <= 1500
> 1500 to <= 1800
> 1800 to <= 2100
> 2100 to <= 2400
> 2400 to <= 2700
> 2700 to <= 3000
> 3000 to <= 3150
> 3150 to <= 3300
> 3300
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
150 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
411 Event 636 SUB IDs Counts Histogram provides the number of times each SUB ID
(specific fault category) occurs for Auxiliary Inverter
fault.
SUB ID ranges
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 151
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
412 Service Brakes Counts Histogram of the number of times the Service Brake is
applied in truck speed (MPH) ranges. Ranges indicate
truck speed (MPH) is greater than (>), and less than (<)
or equal to (=) values shown. Time is shown in seconds
for each range.
Service Brake Application at Speed Ranges
<= 2.0
> 2.0 to <= 4.0
> 5.0 to <= 6.0
> 6.0 to <= 8.0
> 8.0 to <= 10.0
> 10.0 to <= 12.0
> 12.0 to <= 17.0
> 17.0 to <= 22.0
> 22.0 to <= 27.0
> 27.0 to <= 32.0
> 32.0 to <= 37.0
> 37.0 to <= 39.0
> 39.0 to <= 41.0
> 41.0 to <= 43.0
> 43.0 to <= 45.0
> 45.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
152 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
413 Ambient Tempera-
ture
Seconds Histogram of Ambient temperature (in °C). The count
starts whenever CPR is on. Ranges indicate ambient
temperature is greater than (>), and less than (<) or
equal to (=) values shown. Time is shown in seconds for
each range.
Ambient Temperature Ranges in °C<= -40
> -40 to <= -30
> -30 to <= -25
> -25 to <=-20
> -20 to <= -15
> -15 to <= -10
> -10 to <= -5
> -5 to <= 0
> 0 to <= 5
> 5 to <= 10
> 10 to <= 15
> 15 to <= 20
> 20 to <= 25
> 25 to <= 30
> 30 to <= 35
> 35 to <= 40
> 40
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 153
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
414 High Ambient
Temperature
Seconds Histogram of high Ambient temperature (in °C). The
count starts whenever CPR is on. Ranges
indicate ambient temperature is greater than (>), and
less than (<) or equal to (=) values shown. Time is shown
in seconds for each range.
High Ambient Temperature Ranges in °C
<= 35.0
> 35.0 to <= 37.0
> 37.0 to <= 39.0
> 39.0 to <= 41.0
> 41.0 to <= 43.0
> 43.0 to <= 45.0
> 45.0 to <= 47.0
> 47.0 to <= 49.0
> 49.0 to <= 51.0
> 51.0 to <= 53.0
> 59.0 to <= 61.0
> 61.0 to <= 63.0
> 63.0 to <= 65.0
> 65
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
154 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
415 Engine Speed Seconds Histogram of engine speed in RPM for all modes of
operation. The clock starts whenever CPR is on. The
count starts whenever CPR is on. Ranges
indicate engine RPM is greater than (>), and less than
(<) or equal to (=) values shown. Time is shown in sec-
onds for each range.
Engine RPM Ranges
<= 750
> 750 to <= 850
> 850 to <= 950
> 950 to <= 1050
> 1050 to <= 1150
> 1150 to <= 1250
> 1250 to <= 1350
> 1350 to <= 1450
> 1450 to <= 1550
> 1550 to <= 1650
> 1650 to <= 1750
> 1750 to <= 1850
> 1850 to <= 1950
> 1950 to <= 2050
> 2050 to <= 2150
> 2150 to <= 2250
> 2250
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 155
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
416 Engine Crank Com-
mand
Seconds Histogram of the time the engine cranking
commands are active for each attempted engine crank.
The count starts whenever the engine crank command
is active. Ranges indicate engine crank time is greater
than (>), and less than (<) or equal to (=) values shown.
Occurrence is shown in seconds for each range.
Engine Crank Active Time Interval
<= 1
> 2 to <= 4
> 4 to <= 6
> 6 to <= 8
> 8 to <= 10
> 10 to <= 15
> 15 to <= 20
> 20 to <= 25
> 25 to <= 30
> 30 to <= 40
> 40 to <= 50
> 50 to <= 60
> 60 to <= 70
> 70 to <= 80
> 80 to <= 90
> 90 to <= 100
> 100
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
156 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
417 Engine Cranking
Interval
Minutes Histogram of the time between engine cranking
attempts in minutes. The count starts after the engine
crank command is active and before the next engine
crank command. Ranges indicate time between engine
crank attempts is greater than (>), and less than (<) or
equal to (=) values shown. Occurrence is shown in min-
utes for each range.
Time Between Engine Crank Attempts
<= 0.5
> 0.5 to <= 1
> 1 to <= 2
> 2 to <= 3
> 3 to <= 4
> 4 to <= 5
> 5 to <= 6
> 6 to <= 7
> 7 to <= 8
> 8 to <= 9
> 9 to <= 10
> 10 to <= 11
> 11 to <= 12
> 12 to <= 13
> 13 to <= 14
> 14 to <= 15
> 15
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 157
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
418 Accel Pedal % Seconds Histogram of the Accel Pedal percentage applied during
Propel mode. Ranges of Accel Pedal
percent applied indicate time greater than (>), and less
than (<) or equal to (=) values shown.
Occurrence is shown in seconds for each range.
Ranges Accel Pedal Applied %
<= 6%
> 6% to <= 12%
> 12% to <= 18%
> 18% to <= 24%
> 24% to <= 30%
> 30% to <= 36%
> 36% to <= 42%
> 42% to <= 48%
> 48% to <= 54%
> 54% to <= 60%
> 60% to <= 66%
> 66% to <= 72%
> 72% to <= 78%
> 78% to <= 84%
> 84% to <= 90%
> 90% to <= 96%
> 96%
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
158 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
419 RSC % Seconds Histogram of the RSC setting in retard mode. Ranges of
RSC setting mapped in MPH indicate time greater than
(>) and less than (<) or equal to (=) values as shown.
Occurrence is shown in seconds for each range.
Ranges Accel Pedal Applied %
<= 7%
> 7% to <= 9%
> 9% to <= 11%
> 11% to <= 13%
> 13% to <= 15%
> 15% to <= 17%
> 17% to <= 19%
> 19% to <= 21%
> 21% to <= 23%
> 23% to <= 25%
> 25% to <= 27%
> 27% to <= 29%
> 29% to <= 31%
> 31% to <= 33%
> 33% to <= 35%
> 35% to <= 37%
> 37%
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 159
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
420 Pot Reference Seconds Histogram of the pot reference voltage value. Ranges
indicate pot reference voltage is greater than (>), and
less than (<) or equal to (=) values shown. Time is shown
in seconds for each range.
Pot Reference Voltage Ranges
<= 5
> 5 to <= 8
> 8 to <= 8.5
> 8.5 to <= 9
> 9 to <= 9.5
> 9.5 to <= 10
> 10 to <= 10.5
> 10.5 to <= 11
> 11 to <= 11.5
> 11.5 to <= 12
> 12 to <= 12.5
> 12.5 to <= 13
> 13 to <= 13.5
> 13.5 to <= 14
> 14 to <= 14.5
> 14.5 to <= 15
> 15
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
160 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
421 Speed Unloaded Seconds Histogram of the truck speed in MPH while the truck is
unloaded. Ranges indicate speed is greater than (>),
and less than (<) or equal to (=) values shown. Time is
shown in seconds for each range.
Unloaded Truck Speed MPH Ranges
<= 2.5
> 2.5 to <= 5
> 5 to <= 7.5
> 7.5 to <= 10
> 10 to <= 12.5
> 12.5 to <= 15
> 15 to <= 17.5
> 17.5 to <= 20
> 20 to <= 22.5
> 22.5 to <= 25
> 25 to <= 27.5
> 27.5 to <= 30
> 30 to <= 32.5
> 32.5 to <= 35
> 35 to <= 37.5
> 37.5 to <= 40
> 40
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 161
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
422 Truck Speed Loaded Seconds Histogram of the truck speed in MPH while the truck is
loaded. Ranges indicate speed is greater than (>), and
less than (<) or equal to (=) values shown. Time is shown
in seconds for each range.
Loaded Truck Speed MPH Ranges
<= 2.5
> 2.5 to <= 5
> 5 to <= 7.5
> 7.5 to <= 10
> 10 to <= 12.5
> 12.5 to <= 15
> 15 to <= 17.5
> 17.5 to <= 20
> 20 to <= 22.5
> 22.5 to <= 25
> 25 to <= 27.5
> 27.5 to <= 30
> 30 to <= 32.5
> 32.5 to <= 35
> 35 to <= 37.5
> 37.5 to <= 40
> 40
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
162 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
423 Hydraulic Brake
Fluid Temperature
Seconds Histogram of Hydraulic brake fluid temperature. Range
indicates temperature (in Deg Celsius) is greater than
(>) and less than(<) or equal to (=) values shown. Time is
shown in seconds for each range.
Brake Fluid Temperature Ranges
> 20
> 20 to <= 40
> 40 to <= 50
> 50 to <= 60
> 60 to <= 70
> 70 to <= 80
> 80 to <= 90
> 90 to <= 95
> 95 to <= 100
> 100 to <= 105
> 105 to <= 110
> 110 to <= 115
> 115 to <= 120
> 120 to <= 125
> 125 to <= 130
> 130 to <= 140
> 140
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information163
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
424 Baro Pressure Seconds Histogram of the Barometric Pressure. The count is
active whenever CPR is ON. Range indicates
barometric pressure (in PSI) is greater than (>), and less
than (<) or equal to (=) values shown. Time is shown in
seconds for each range.
Barometric Pressure in PSI Range
< 7.5
> 7.5 to <= 8.0
> 8.0 to <= 8.5
> 8.5 to <= 9.0
> 9.0 to <= 9.5
> 9.5 to <= 10.0
> 10.0 to <= 10.5
> 10.5 to <= 11.0
> 11.0 to <= 11.5
> 11.5 to <= 12.0
> 12.0 to <= 12.5
> 12.5 to <= 13.0
> 13.0 to <= 13.5
> 13.5 to <= 14.0
> 14.0 to <= 14.5
> 14.5 to <= 15.0
> 15.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
164 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
425 Loadbox HP Seconds Histogram of Loadbox Horsepower. The count is active
whenever Loadbox mode is active. Range indicates
horsepower is greater than (>), and less than (<) or
equal to (=) values shown. Time is shown in seconds for
each range.
Ranges of Horsepower
<= 100
> 100 to <= 650
> 650 to <= 850
>850 to <= 1050
> 1050 to <= 1250
> 1250 to <= 1450
> 1450 to <= 1650
> 1650 to <= 1850
> 1850 to <= 2050
> 2050 to <= 2250
> 2250 to <= 2450
> 2450 to <= 2650
> 2650 to <= 2850
> 2850 to <= 3250
> 3250 to <= 3450
> 3450 to <= 3650
> 3650
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 165
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
426 Motor 1 Hi RPM Seconds Histogram of the Motorized Wheel Motor 1 electric
motor high RPM. Range indicates RPM is greater than
(>), and less than (<) or equal to (=) values shown. Time
is shown in seconds for each range.
Motor 1 High RPM Ranges
<= 3300
> 3400 to <= 3500
> 3500 to <= 3600
> 3600 to <= 3700
> 3700 to <= 3800
> 3800 to <= 3900
> 3900 to <= 4000
> 4000 to <= 4100
> 4100 to <= 4200
> 4200 to <= 4390
> 4300 to <= 4400
> 4400 to <= 4500
> 4500 to <= 4600
> 4600 to <= 4700
>4700 to <= 4800
> 4800
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
166 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
427 Motor 2 Hi RPM Seconds Histogram of the Motorized Wheel Motor 2 electric
motor high RPM. Range indicates RPM is greater than
(>), and less than (<) or equal to (=) values shown. Time
is shown in seconds for each range.
Motor 2 High RPM Ranges
<= 3300
> 3300 to <= 3400
> 3400 to <= 3500
> 3500 to <= 3600
> 3600 to <= 3700
> 3700 to <= 3800
> 3800 to <= 3900
> 3900 to <= 4000
> 4000 to <= 4100
> 4100 to <= 4200
> 4200 to <= 4390
> 4300 to <= 4400
> 4400 to <= 4500
> 4800
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 167
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
428 Cruise MPH Seconds Histogram of Cruise speed in MPH. Range indicates
Cruise speed is greater than (>) and less than (<) or
equal to (=) values shown. Time is shown in seconds for
each range.
Cruise Speed in MPH Ranges.
<= 2
> 2 to <= 4
> 4 to <= 5
> 5 to <= 6
> 6 to <= 8
> 8 to <= 10
> 10 to <= 12
> 12 to <= 17
> 17 to <= 22
> 22 to <= 27
> 27 to <= 32
> 32 to <= 37
> 37 to <= 41
> 41 to <= 43
> 43 to <= 45
> 45
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
168 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
430 IM Ambient Seconds Histogram of Ambient Temperatures (in °C). Range indi-
cates temperature is greater than (<), and less than (>),
or equal to (=) values shown. Time is shown in seconds
for each range.
Ambient Temperatures Ranges
<= 35.0
> 35.0 to <= 37.0
> 37.0 to <= 39.0
> 39.0 to <= 41.0
> 41.0 to <= 43.0
> 43.0 to <= 45.0
> 45.0 to <= 47.0
> 37.0 to <= 49.0
> 49.0 to <= 51.0
> 51.0 to <= 53.0
> 53.0 to <= 55.0
> 55.0 to <= 57.0
> 57.0 to <= 59.0
> 59.0 to <= 61.0
> 61.0 to <= 63.0
> 63.0 to <= 65.0
> 65.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 169
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
431 Brake Pressure Seconds Histogram of Brake Pressure shown in psi. Range indi-
cates pressure is greater than (>), and less than (<), or
equal to the values shown. Time is shown in seconds for
each range.
Brake Pressure Ranges
<= 150
> 150 to <= 300
> 300 to <= 450
> 450 to <= 600
> 600 to <= 750
> 750 to <= 900
> 900 to <= 1050
> 1050 to <= 1200
> 1200 to <= 1350
> 1350 to <= 1500
> 1500 to <= 1750
> 1750 to <= 1900
> 1900 to <= 2050
> 2050 to <= 2100
> 2100 to <= 2250
> 2250 to <= 2500
> 2500
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
170 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
432 Incline Percentage Seconds Histogram of the Incline Percentage. Range indicates
pressure is greater than (>), and less than (<), or equal
to the values shown. Time is shown in seconds for each
range.
Incline Percentage Range
<= 1.0
> 1.0 to <= 2.0
> 2.0 to <= 3.0
> 3.0 to <= 4.0
> 4.0 to <= 5.0
> 5.0 to <= 6.0
> 6.0 to <= 7.0
> 7.0 to <=8.0
> 8.0 to <= 9.0
> 9.0 to <= 10.0
> 10.0 to <= 11.0
> 11.0 to <= 12.0
> 12.0 to <= 13.0
> 13.0 to <= 14.0
> 14.0 to <= 15.0
> 15.0 to <= 16.0
> 16
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 171
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
433 Incline Percentage Seconds Histogram of the Incline Percentage. Range indicates
pressure is greater than (>), and less than (<), or equal
to the values shown. Time is shown in seconds for each
range.
Incline Percentage Range
<= -15.0
> -15.0 to <= -14.0
> -14.0 to <= -13.0
> -13.0 to <= -12.0
> -12.0 to <= -11.0
> -11.0 to <= -10.0
> -10.0 to <= -9.0
> -9.0 to <= -8.0
> -8.0 to <= -7.0
> -7.0 to <= -6.0
> -6.0 to <= -5.0
> -5.0 to <= -4.0
> -4.0 to <= -3.0
> -3.0 to <= -2.0
> -2.0 to <= -1.0
> -1.0 to <= 0.0
> 0.0
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
172 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
434 Grid Blower Amps
Delta
Seconds Histogram shows the delta of Grid blower currents
(Amps) between two blower motors wherever used.
Range indicates delta current (in amps) is greater than
(>) and less than (<) or equal to (=) values shown. Time is
in seconds for each range.
Grid Blower Delta Range
<= 0
> 0 to <= 2
> 2 to <= 4
> 4 to <= 6
> 6 to <= 8
> 8 to <= 10
> 10 to <= 12
> 12 to <= 14
> 14 to <= 16
> 16 to <= 18
> 18 to <= 20
> 20 to <= 22
> 22 to <= 26
> 26 to <= 28
> 28 to <= 30
> 30
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 173
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
435 CBI1 Speed Seconds This is a histogram of CBI1. The sample time is every 1.0
seconds. The clock starts when the control power is on.
All Values are in RPM. The histogram breaks the Speed
spectrum into 17 buckets, and displays the time that
was spent in each bucket. The buckets are defined as
follows:
Speed (RPM)
<= 50
> 50 to <= 500
> 500 to <= 750
> 750 to <= 1000
> 1000 to <= 1250
> 1250 to <= 1500
> 1500 to <= 1750
> 1750 to <= 2000
> 2000 to <= 2250
> 2250 to <= 2500
> 2500 to <= 2750
> 2750 to <= 3000
> 3000 to <= 3250
> 3250 to <= 3500
> 3500 to <= 3750
> 3750 to <= 4000
> 4000
PROFILE
NUMBER
DESCRIPTIONUNITS PROFILE DESCRIPTIONS
174 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
436 CBI2 Speed Seconds This is a histogram of CBI2. The sample time is every 1.0
seconds. The clock starts when the control power is on.
All Values are in RPM. The histogram breaks the Speed
spectrum into 17 buckets, and displays the time that
was spent in each bucket. The buckets are defined as
follows:
Speed (RPM)
<= 50
> 50 to <= 500
> 500 to <= 750
> 750 to <= 1000
> 1000 to <= 1250
> 1250 to <= 1500
> 1500 to <= 1750
> 1750 to <= 2000
> 2000 to <= 2250
> 2250 to <= 2500
> 2500 to <= 2750
> 2750 to <= 3000
> 3000 to <= 3250
> 3250 to <= 3500
> 3500 to <= 3750
> 3750 to <= 4000
> 4000
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 175
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
437 GBI1 Speed Seconds This is a histogram of GBI1. The sample time is every 1.0
seconds. The clock starts when the control power is on.
All Values are in RPM. The histogram breaks the Speed
spectrum into 17 buckets, and displays the time that
was spent in each bucket. The buckets are defined as
follows:
Speed (RPM)
<= 50
> 50 to <= 500
> 500 to <= 750
> 750 to <= 1000
> 1000 to <= 1250
> 1250 to <= 1500
> 1500 to <= 1750
> 1750 to <= 2000
> 2000 to <= 2250
> 2250 to <= 2500
> 2500 to <= 2750
> 2750 to <= 3000
> 3000 to <= 3250
> 3250 to <= 3500
> 3500 to <= 3750
> 3750 to <= 4000
> 4000
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
176 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
438 GBI2 Speed Seconds This is a histogram of GBI2. The sample time is every 1.0
seconds. The clock starts when the control power is on.
All Values are in RPM. The histogram breaks the Speed
spectrum into 17 buckets, and displays the time that
was spent in each bucket. The buckets are defined as
follows:
Speed (RPM)
<= 50
> 50 to <= 500
> 500 to <= 750
> 750 to <= 1000
> 1000 to <= 1250
> 1250 to <= 1500
> 1500 to <= 1750
> 1750 to <= 2000
> 2000 to <= 2250
> 2250 to <= 2500
> 2500 to <= 2750
> 2750 to <= 3000
> 3000 to <= 3250
> 3250 to <= 3500
> 3500 to <= 3750
> 3750 to <= 4000
> 4000
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 177
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
439 Secondary Link Volts Seconds This is a histogram of secondary link volts. The sample
time is every 1.0 seconds. The clock starts when the
control power is on. All Values are in Volts. The histo-
gram breaks the Voltage spectrum into 17 buckets, and
displays the time that was spent in each bucket. The
buckets are defined as follows:
Volts
<= 20
> 20 to <= 500
> 480 to <= 500
> 500 to <= 520
> 520 to <= 540
> 540 to <= 560
> 560 to <= 580
> 580 to <= 600
> 600 to <= 620
> 620 to <= 640
> 640 to <= 660
> 660 to <= 680
> 680 to <= 700
> 700 to <= 720
> 720 to <= 740
> 740 to <= 760
> 760
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
178 GE Proprietary and Confidential Information
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
440 Secondary Link HP Seconds This is a histogram of secondary link HP. The sample
time is every 1.0 seconds. The clock starts when the
control power is on. All Values are in HP. The histogram
breaks the HP spectrum into 17 buckets, and displays
the time that was spent in each bucket. The buckets are
defined as follows:
HP
<= 2
> 2 to <= 20
> 20 to <= 40
> 40 to <= 60
> 60 to <= 80
> 80 to <= 100
> 100 to <= 120
> 120 to <= 140
> 140 to <= 160
> 160 to <= 180
> 180 to <= 200
> 200 to <= 220
> 220 to <= 240
> 240 to <= 260
> 260 to <= 280
> 280 to <= 300
> 300
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
GE Proprietary and Confidential Information 179
GEK-91756C
GE OHV AC Control System Events, Historical Counters and Profiles Information
PROFILE
NUMBER
DESCRIPTION UNITS PROFILE DESCRIPTIONS
441 Fuel saver disabled
Time of Day
Seconds Histogram shows particular time of the day when Fuel
saver has been disabled.
Time of the Day (Hours) Range
<= 2
> 2 to <= 4
> 4 to <= 6
> 6 to <= 8
> 8 to <= 10
> 10 to <= 12
> 12 to <= 14
> 14 to <= 16
> 16 to <= 18
> 18 to <= 20
> 20 to <= 22
> 22 to <= 24
180 GE Proprietary and Confidential Information
	1. GENERAL INFORMATION
	1.1. INTRODUCTION
	2. EVENT LISTS
	2.1. DSC/PSC EVENT LIST (000 - 099)
	2.1.1. RESTRICTIONS
	2.1.2. DSC/PSC Event List (000 - 099)
	2.2. INVERTER EVENT LIST (Xx00 - Xx99)
	2.2.1. Restrictions
	2.2.2. Numbering Scheme and Inverter Number Allocations
	2.2.3. Inverter Event List (Xx00 - Xx99)
	2.3. ADDITIONAL SYSTEM EVENTS/DSC EVENT LIST (500 - 599)
	2.3.1. Event Restriction
	2.3.2. Additional Events/DSC Event List (500 - 599)
	2.4. DSC/TCI EVENT LIST (600 - 699)
	2.4.1. Event Restriction
	2.4.2. DSC/TCI Event List (600 - 699)
	3. HISTORICAL DATA COUNTERS
	3.1. MINE HISTORICAL COUNTERS (301 - 399)
	3.2. DSC AND PSC HISTORICAL EVENT COUNTER
	3.3. INVERTER 1 HISTORICAL EVENT COUNTER
	3.4. INVERTER 2 HISTORICAL EVENT COUNTER
	3.5. DSC AND TCI HISTORICAL EVENT COUNTER
	4. HISTORICAL PROFILES
	4.1. MINE HISTORICAL STATISTICAL DATA PROFILES (401 - 441)
