1
Confidential © Nokia 2017
474802A ARPA AirScale RFM 6T6R B28 360W
Technical Datasheet
V2.2
2 © 2018 Nokia
AirScale High Power RFM
benefits
• 3-sector optimised site solution
• Connectivity with FSMF/AirScale BBU
• High RF OP 6x60 W
• Support for 4G/5G
• Deployment flexibility for different
use cases with multiple mounting options
474802A ARPA
Specification Details
Standard 3GPP/ETSI
Supported RAT* FDD-LTE, 5G NR
Band / Frequency range 3GPP band28 TX 758-788 MHz, RX 703-733 MHz
Max. supported modulation* 256 QAM
Number of TX/RX paths* 6T6R
Instantaneous bandwidth (IBW)* 30 MHz
Occupied bandwidth (OBW)* 30 MHz
Max. RF output power* 60W per TX antenna, Total 360W
Dimensions (H×W×D) 118mm x 441mm x 402mm (H x W x D)
Volume 21L
Weight (excluding mounting bracket) 23kg
Supply voltage / Connector type DC -48V / -36 to -60 VDC / three pole screw terminal
Antenna ports 6 x 4.3-10
Optical ports* 3x SFP+ CPRI 9.8Gbit/s, Nokia IP seal
Other interfaces / Connector type RET, EAC MDR26
Operational temperature range -40°C to 55°C
Cooling Forced cooling with fans
Installation options 19” rack, Wall, Stacked, Pole, Rail
Ingress / Surge protection IP65, Class II 5 kA DC-port
474802A ARPA AirScale RFM 6T6R B28 360W
Technical data
*HW specifications, capabilities are subject to relevant feature support
3 © 2018 Nokia
Functional Block Diagram
474802A ARPA AirScale RFM 6T6R B28 360W
