Ade Odusanya
HAKORCONSULTING INC.
DEPLOYING A WEBSITE
ON AWS USING AN
ARCHITECTURE DIAGRAM
AS TEMPLATE


1

TABLE OF CONTENTS
CHAPTER 1 - PROVISION YOUR VPC 4
CHAPTER 2 - PROVISION YOUR SUBNETS 7
CHAPTER 3 – CREATE YOUR INTERNET GATEWAY 12
CHAPTER 4 – SPINNING UP INSTANCES 15


















2




USING THIS SIMPLE VPC ARCHITECTURE ABOVE WE ARE GOING TO
PROVISION RESOURCES FOR A COMPANY WEBSITE.

USE CASE PARAMETERS

1. COMPANY NAME: ABSAI
2. VPC CIDR BLOCK- 10.0.0.0/16
3. SUBNET CIDR BLOCK – 10.0.0.0/20-PUBLIC
 10.0.16.0/20-PRIVATE





3

NAMING CONVENTION

1. VPC: COMPANYNAME-VPC
2. SUBNETS: COMPANYNAME-WEBSERVER-PUBLIC
 COMPANYNAME-DATABASE-PRIVATE
3. INTERNET GATEWAY: COMPANYNAME-IGW
4. INSTANCES: COMPANYNAME-WEBSERVER-EC2
 COMPANYNAME-DATABASE-EC2
5. SECURITY GROUP: COMPANYNAME-WEBSERVER-SG
 COMPANYNAME-DATABASE-SG
6. S3 BUCKET: COMPANYNAME-OBJECTS (NOTE: S3 BUCKET NAMES ARE GLOBAL, SO
THEY ARE UNIQUE. 2 BUCKETS CAN’T HAVE THE SAME NAME)
7. KEY PAIRS: WEBSERVER-KP
 DATABASE-KP






LET’S BEGIN
CLOUDTICIANS…

LOG INTO YOUR
AWS
DEVTEST ACCOUNT


4




CHAPTER 1- PROVISION YOUR VPC


1. NAVIGATE TO YOUR VPC SERVICE DASHBOARD (WE WILL BE USING THE NEW VPC
EXPERIENCE).
2. SELECT YOUR VPCS ON THE LEFT-HAND SIDE



3. CLICK ON CREATE VPC ON THE RIGHT-HAND SIDE (IF YOU ARE USING THE
OLD EXPERIENCE IT WILL BE ON THE LEFT AND IT WILL BE BLUE)
5




4. ENTER UNDER NAME TAG
ABSAI-WEBSITE-VPC
IPV4 CIDR BLOCK
10.0.0.0/16



5. CLICK CREATE VPC (NOTE WITH THE NEW EXPERIENCE TAGS ARE ADDED
AUTOMATICALLY)

6



6. A GREEN BAR WILL SHOW STATING THAT YOUR VPC IS CREATED.





















7

CHAPTER 2 PROVISION YOUR SUBNETS

WE ARE GOING TO CREATE 2 SUBNETS HERE. A PUBLIC SUBNET WHERE OUR
WEBSERVER WILL SIT AND A PRIVATE SUBNET WHERE OUR DATABASE WILL SIT.

1. ON THE VPC DASHBOARD CLICK SUBNETS ON THE LEFT-HAND SIDE.











2. CLICK ON CREATE SUBNET ON THE RIGHT-HAND SIDE.







8

3. SELECT THE VPC THAT WE CREATED.




4. UNDER SUBNET 1 OF 1 ENTER THE FOLLOWING INFO

SUBNET NAME:
ABSAI-WEBSERVER-PUBLIC
AVAILABILITY ZONE:
US-EAST-1A
IPV4 CIDR BLOCK
10.0.0.0/20

9



(NOTE: IN THE NEW EXPERIENCE YOU CAN CREATE MULTIPLE SUBNETS AT ONCE)

5. CLICK ON ADD NEW SUBNET TO CREATE THE PRIVATE SUBNET




10

6. UNDER SUBNET 2 OF 2 ENTER THE FOLLOWING

SUBNET NAME:
ABSAI-DATABASE-PRIVATE
AVAILABILITY ZONE:
US-EAST-1A
IPV4 CIDR BLOCK
10.0.16.0/20

















11

7. CLICK CREATE SUBNET





8. YOU WILL SEE IN THE GREEN BOX THAT SUBNETS WERE SUCCESSFULLY
CREATED.







12

CHAPTER 3
 CREATE AN INTERNET GATEWAY





1. CLICK INTERNET GATEWAY ON THE LEFT-HAND SIDE



2. CLICK CREATE INTERNET GATEWAY ON THE RIGHT-HAND SIDE



13

3. ENTER THE INTERNETGATEWAY NAMETAG
ABSAI-IGW




4. THE GREEN BAR ON TOP WILL SHOW THE INTERNET GATEWAY HAS BEEN
CREATED AND YOU NEED TO ATTACH IT TO A VPC. SO CLICK ATTACH TO A VPC
IN THE GREEN BAR




14

5. SELECT THE VPC (ABSAI-VPC) AND CLICK ATTACH INTERNET GATEWAY ON
THE BOTTOM RIGHT.



6.THE GREEN BAR SHOWS THAT THE INTERNET GATEWAY HAS BEEN ATTACHED TO THE
VPC.









15

CHAPTER 4
SPINNING UP OF INSTANCES




1. NAVIGATE TO THE EC2 SERVICE DASHBOARD.



2. SELECT INSTANCES ON THE LEFT-HAND SIDE








16

3. SELECT LAUNCH INSTANCES IN THE RIGHT-HAND SIDE



4. SELECT YOUR AMI (AMAZON MACHINE IMAGE)
HERE WE ARE SELECTING THE AMAZON LINUX 2 AMI SSD VOLUME TYPE


















17

5. THEN WE CHOOSE AN INSTANCE TYPE (HERE WE CHOSE THE T2 MICRO) AND
THEN WE SELECT THE NEXT CONFIGURE INSTANCE DETAILS.




6. ON THIS STEP WE WILL SELECT
NETWORK: ABSAI-VPC
SUBNET: ABSAI-WEBSERVER-PUBLIC (BECAUSE THIS IS THE SUBNET FOR THE
WEBSERVER)

THEN WE CLICK ON NEXT: ADD STORAGE









18




7. ON THIS PAGE JUST SELECT NEXT ADD TAGS



8. ADD A TAG HERE
KEY: NAME
VALUE: ABSAI-WEBSERVER-EC2

NEXT: CONFIGURE SECURITY GROUP









19

9. CREATE A NEW SECURITY GROUP
SECURITY GROUP NAME: ABSAI-WEBSERVER-SG
DESCRIPTION: ABSAI-WEBSERVER-SG

SSH ACCESS INTO THE WEBSERVER
AND THEN CLICK REVIEW AND LAUNCH.




10. HERE REVIEW THE INSTANCE AND THEN CLICK LAUNCH.






20

11. HERE CREATE A NEW KEY PAIR
KEY PAIR NAME: WEBSERVER-KP

DOWNLOAD KEY PAIR

CLICK LAUNCH INSTANCES




12. CLICK VIEW INSTANCES








21



13. WE NEED TO SPIN UP ANOTHER INSTANCE FOR THE DATABASE. CLICK LAUNCH
INSTANCE.

14. ON THIS PAGE CHECK THE FREE TIER ONLY FILTER ON THE LEFT-HAND SIDE



15. HERE WE SELECTED MICROSOFT WINDOWS SERVER 2019 BASE AS OUR AMI












22



16. HERE WE ENTER
NETWORK: ABSAI-VPC
SUBNET: ABSAI-DATABASE-PRIVATE

CLICK ADD STORAGE



17. HERE JUST SELECT NEXT: ADD TAGS










23




18. HERE
KEY: NAME
VALUE: ABSAI-DATABASE-EC2

CLICK NEXT CONFIGURE SECURITY GROUP




19. HERE CREATE A NEW SECURITY GROUP
SECURITY GROUP NAME: ABSAI-DATABASE-SG
DESCRIPTION: ABSAI-DATABASE-SG CREATED --------

DESCRIPTION: RDP ACCESS INTO DATABASE

REVIEW AND LAUNCH


24





20. HERE CLICK LAUNCH







21. HERE CREATE A NEW KEY PAIR
KEY PAIR NAME: DATABASE-KP

DOWNLOAD KEY PAIR

CLICK LAUNCH INSTANCES

25



22. CLICK VIEW INSTANCES



23. NOW STOP YOUR INSTANCES FROM RUNNING.
