Manual for Detailing Reinforced
Concrete Structures to EC2
Detailing is an essential part of the design process. This thorough reference guide for the
design of reinforced concrete structures is largely based on Eurocode 2 (EC2), plus other
European design standards such as Eurocode 8 (EC8), where appropriate.
With its large format, double-page spread layout, this book systematically details 213 structural
elements. These have been carefully selected by Jose Calavera to cover relevant elements used
in practice. Each element is presented with a whole-page annotated model along with commen­
tary and recommendations for the element concerned, as well as a summary of the appropriate
Eurocode legislation with reference to further standards and literature. The book also comes
with a CD-ROM containing AutoCAD files of all of the models, which can be directly developed
and adapted for specific designs.
Its accessible and practical format makes the book an ideal handbook for professional engi­
neers working with reinforced concrete, as well as for students who are training to become
designers of concrete structures.
Jose Calavera is Honorary President of the Technical Institute of Materials and Construction
(INTEMAC- lnstituto Tecnico de Materiales y Construcciones) and Emeritus Professor, School
of Civil Engineering, Polytechnic University of Madrid.
Manual for Detailing Reinforced
Concrete Structures to EC2
Jose Calavera
W Span Press
~ an imprint of Taylor & Francis
LONDON AND NEW YORK
First published 2012
by Spon Press
2 Park Square, Milton Park, Abingdon, Oxon OX14 4RN
Simultaneously published in the USA and Canada
by Spon Press
711 Third Avenue, New York, NY 10017
Spon Press is an imprint of the Taylor & Francis Group, an informa business
Copyright © 2012 Jose Calavera
The right of Jose Calavera to be identified as author of this work has been asserted by him in
accordance with sections 77 and 78 of the Copyright, Designs and Patents Act 1988.
All rights reserved. No part of this book may be reprinted or reproduced or utilised in any form or by
any electronic, mechanical, or other means, now known or hereafter invented, including photocopying
and recording, or in any information storage or retrieval system, without permission in writing from the
publishers.
This publication presents material of a broad scope and applicability. Despite stringent efforts by all
concerned in the publishing process, some typographical or editorial errors may occur, and readers are
encouraged to bring these to our attention where they represent errors of substance. The publisher and
author disclaim any liability, in whole or in part, arising from information contained in this publication.
The reader is urged to consult with an appropriate licensed professional prior to taking any action or
making any interpretation that is within the realm of a licensed professional practice.
Trademark notice: Product or corporate names may be trademarks or registered trademarks, and are
used only tor identification and explanation without intent to infringe.
British Library Cataloguing in Publication Data
A catalogue record tor this book is available from the British Library
Library of Congress Cataloging-in-Publication Data
Calavera Ruiz, Jose.
Manual tor detailing reinforced concrete structures to EC2 I Jose Calavera.
p.cm.
Includes bibliographical references and index.
1. Reinforced concrete construction-Details. 2. Reinforced concrete construction­
Standards-Europe. I. Title.
T A683.28.C35 2012
624.1 '8341-dc22
ISBN: 978-0-415-66348-9
Typeset in Helvetica by RefineCatch Ltd, Bungay, Suffolk
" ...,/ -u' Paper from
reeponelble sources
~~~ FSC- C004839
MIX
Printed and bound in Great Britain by the MPG Books Group
2011009904
Contents
List of tables
Foreword
The author
Author's curriculum vitae
Acknowledgements
Citations
General notes
The three golden rules for pouring concrete on site
1 General rules for bending, placing, anchoring and welding
reinforcing bars
1 . Introduction
1.1 Summary of codes and standards on construction details
1.1.1 Permissible mandrel diameters for bent bars (See EC2, 8.3)
1.1.2 Standard bends, hooks and loops
1.1.3 Cover
1.1.4 Bar spacing
1.1.5 Bundled bars
1.1.6 Surface reinforcement
1.2 Tying bars
1.2.1 Tying method
1.2.2 Tie points
1.3 Spacers and chairs
1.3.1 Types of spacer and chair
1.3.2 Graphic representation
1.3.3 Placement rules
1.4 Welding reinforcing bars
1.4.1 Types of weld
1.4.2 Welded joint details
1.5 Verification of the anchorage limit state
1.5.1 Bond anchorage
1.5.2 Welded transverse bar anchorage
1.6 Anchorage rules for welded transverse bars
1.6.1 Bars where 14 s <Prs 32 mm, 14 s </JL s 32 mm
1.6.2 Bars where <Prs 12 mm, </JL s 12 mm
1.7 Relationship between construction details and durability
2 Constructive details
Group 01 Foundations
CD-01.01 Wall footing supporting a reinforced concrete wall
CD-01.02 Wall footing supporting a brick wall
CD-01.03 Spread footing
v
xiii
xv
xvii
xix
xxi
xxiii
xxv
xxvii
1
1
1
1
3
4
7
8
9
11
12
12
14
14
16
17
22
22
24
27
28
29
30
30
31
32
33
35
36
38
40
CD-01.04 Spread footing with variable depth 42
CD-01.05 Circular footing (Circular reinforcement) 44
CD-01.06 Circular footing (Reinforced with two welded panels) 46
CD-01.07 Spread footing and expansion joint 48
CD-01.08 Strap footing 50
CD-01.09 Self-centred edge footing 52
CD-01.10 Combined edge footing (Variation 1) 54
CD - 01.11 Combined edge footing (Variation 2) 56
CD-01.12 Strap footing at corner (1 of 2) 58
CD-01.12 Strap footing at corner (2 of 2) 60
CD-01.13 Self-centred corner footing 62
CD-01.14 Combined footing (Variation 1) 64
CD-01.15 Combined footing (Variation 2) 66
CD-01.16 Tie beam between footings 68
CD-01.17 Foundation beam (Variation 1) 70
CD-01.18 Foundation beam (Variation 2) 72
CD-01.19 Grid foundation (Variation 1) (1 of 2) 74
CD-01.19 Grid foundation (Variation 1) (2 of 2) 76
CD-01.20 Grid foundation (Variation 2) (1 of 2) 78
CD-01.20 Grid foundation (Variation 2) (2 of 2) 80
CD-01.21 Foundation slab (1 of 2) 82
CD-01.21 Foundation slab (2 of 2) 84
CD-01.22 Caisson 86
CD-01.23 Wall footing 88
CD-01.24 Bored pile 90
CD-01.25 Pile cap 92
CD-01.26 Two-pile cap 94
CD-01.27 Three-pile cap 96
CD-01.28 Four-pile cap 98
CD-01.29 Group pile cap (N > 4) 100
CD-01.30 Centring beam for one- or two-pile caps 102
Group 02 Retaining walls and basement walls 105
CD-02.01 Cantilever retaining walls. Nomenclature 106
CD-02.02 Cantilever retaining walls. Footing 108
CD-02.03 Cantilever retaining walls. Stem 110
CD-02.04 Cantilever retaining walls. Variations 112
CD-02.05 Cantilever retaining walls. Key 114
CD-02.06 Cantilever retaining walls. Construction joints in footings 116
CD-02.07 Cantilever retaining walls. Vertical contraction joints in the stem 118
CD-02.08 Cantilever retaining walls. Horizontal construction joints in
architectural concrete 120
CD-02.09 Cantilever retaining walls. Vertical contraction joints 122
CD-02.10 Cantilever retaining walls. Expansion joints 124
CD-02.11 Cantilever retaining walls. Fill and drainage 126
CD-02.12 Buttress walls. Buttress nomenclature and distribution 128
CD-02.13 Buttress walls. Footing 130
CD-02.14 Buttress walls. Stem 132
vi
CD-02.15 Buttress walls. Inside buttress 134
CD-02.16 Buttress walls. End buttress 136
CD-02.17 Tray walls 138
CD-02.18 Tray walls. Tray details 140
CD-02.19 Basement walls. Facade footing 142
CD-02.20 Basement wall. Centred footing 144
CD-02.21 Basement wall. Vertical contraction joint 146
CD-02.22 Basement walls. Special details (1 of 2) 148
CD-02.22 Basement walls. Special details (2 of 2) 150
CD-02.23 Diaphragm walls. General reinforcement 152
CD-02.24 Diaphragm walls. Crown beam 154
CD-02.25 Diaphragm wall-beam bond (Variation 1) 156
CD-02.26 Diaphragm wall-beambond (Variation 2) 158
CD-02.27 Diaphragm wall-beam bond (Variation 3) 160
CD-02.28 Diaphragm wall-slab bond (Variation 1) 162
CD-02.29 Diaphragm wall-slab bond (Variation 2) 164
CD-02.30 Walls. Drainage chamber and channel in diaphragm wall 166
Group 03 Columns and joints 169
CD-03.01 Columns springing from the footing. Tie bar arrangement 170
CD-03.02 Columns in intermediate storeys. Tie bar arrangement 172
CD-03.03 Columns in top storey. Tie bar arrangement 174
CD-03.04 Intermediate joint in edge columns (Variation 1) 176
CD-03.05 Intermediate joint in edge columns (Variation 2) 178
CD-03.06 Intermediate joint in edge columns (Variation 3) 180
CD-03.07 Intermediate corner joint (Variation 1) 182
CD-03.08 Intermediate corner joint (Variation 2) 184
CD-03.09 Intermediate corner joint (Variation 3) 186
CD-03.10 Facade or corner joint on last storey 188
CD-03.11 Inside joint in intermediate storeys (Variation 1) 190
CD-03.12 Inside joint in intermediate storeys (Variation 2) 192
CD-03.13 Intermediate joint in circular columns 194
CD-03.14 Transition from circular to rectangular columns 196
CD-03.15 Corner joint in large span portal frames 198
CD-03.16 Bar arrangement and shapes of ties in columns 200
CD-03.17 Bundled bar arrangements 202
CD-03.18 Arrangement of laps in columns with bundled bars 204
CD-03.19 Edge schedule. Column schedule 206
Group 04 Walls subjected to axial loads 209
CD-04.01 Walls, shear walls and cores. General arrangements 210
CD-04.02 Walls, shear walls and cores. Joint detail 212
CD-04.03 Walls, shear walls and cores. Corners, joints and edges 214
CD-04.04 Walls, shear walls and cores. Detail of openings 216
CD-04.05 Walls, shear walls and cores. Special details for slip forms
(Variation 1 ) 218
CD-04.06 Walls, shear walls and cores. Special details for slip forms
(Variation 2) 220
vii
Group 05 Beams and lintels 223
CD-05.01 Beams. Simply supported beams 224
CD-05.02 Beams. Header joist 226
CD-05.03 Beams. Continuous lintels with constant depth 228
CD-05.04 Beams. Continuous lintels with variable depth 230
CD-05.05 Beams. Staggered lintels 232
CD-05.06 Beams. Stepped lintels 234
CD-05.07 Beams. Edge soffit beam 236
CD-05.08 Beams. Internal soffit beam 238
CD-05.09 Beams. Soffit beam-edge beam intersection (1 of 2) 240
CD-05.09 Beams. Soffit beam-edge beam intersection (2 of 2) 242
CD-05.10 Beams. Transition from internal soffit beams to normal beams 244
CD-05.11 Beams. Transition from edge soffit beams to normal beams 246
CD-05.12 Beams. Joint details 248
CD-05.13 Beams. Industrialised joint 250
CD-05.14 Beams. Cantilevered beams 252
CD-05.15 Beams. Arrangement of reinforcement at cross-section 254
CD-05.16 Beams. Contraction joints 256
CD-05.17 Beams with architectural concrete. Contraction joints and
construction joints 258
Group 06 Slabs, ribbed slabs and precast slabs with beam-block
and hollow core floor systems 261
CD-06.01 Slabs. General types: longitudinal and cross-sections 262
CD-06.02 Solid slab. Connection to brick wall and concrete beams 264
CD-06.03 Ribbed slab. Connection to brick wall and concrete beams 266
CD-06.04 Slabs with self-supporting reinforced concrete joists.
Connections to brick wall 268
CD-06.05 Slabs with self-supporting reinforced concrete joists.
Connections to reinforced concrete beams 270
CD-06.06 Slabs with self-supporting reinforced concrete joists.
Connections to soffit beams 272
CD-06.07 Slabs with self-supporting prestressed concrete joists.
Connections to brick wall 274
CD-06.08 Slabs with self-supporting prestressed concrete joists.
Connections to reinforced concrete beams 276
CD-06.09 Slabs with self-supporting prestressed concrete joists.
Connections to soffit beams 278
CD-06.10 Slabs with semi-self-supporting reinforced concrete joists.
Connections to brick wall 280
CD-06.11 Slabs with semi-self-supporting reinforced concrete joists.
Connections to concrete beams 282
CD-06.12 Slabs with semi-self-supporting reinforced concrete joists.
Connections to soffit beams 284
CD-06.13 Slabs with semi-self-supporting reinforced concrete lattice joists.
Connections to brick wall 286
viii
CD- 06.14 Slabs with semi-self-supporting reinforced concrete lattice joists.
Connections to concrete beams 288
CD-06.15 Slabs with semi-self-supporting reinforced concrete
lattice joists. Connections to soffit beams 290
CD-06.16 Slabs with semi-self-supporting prestressed joists.
Connections to brick wall 292
CD-06.17 Slabs with semi-self-supporting prestressed joists.
Connections to concrete beams 294
CD-06.18 Slabs with semi-self-supporting prestressed joists.
Connections to soffit beams 296
CD-06.19 Precast beam and block floor systems. Change in
beam direction 298
CD-06.20 Precast beam and block floor systems. Connection
to wall parallel to beams 300
CD-06.21 Precast beam and block floor systems. Cantilever with
extended joists 302
CD-06.22 Precast beam and block floor systems. Cantilever without
extended joists 304
CD-06.23 Beam and block floor systems. Openings 306
CD-06.24 Slabs lightened with embedded tubing 308
CD-06.25 Hollow cores. General details 310
CD-06.26 Hollow cores. Connections 312
CD-06.27 Hollow cores. Tip and edge tie hoops in cantilevers 314
CD-06.28 Hollow cores. Vertical panel and beam supports 316
CD-06.29 Hollow cores. Supports on vertical panels 318
CD-06.30 Hollow cores. Supports on vertical panels and beams 320
CD-06.31 Hollow cores. Openings in the slab 322
Group 07 Flat slabs 325
CD-07.01 Flat slabs. Top reinforcement 326
CD-07.02 Flat slabs. Bottom reinforcement 328
CD-07.03 Flat slabs. Arrangement of flexural reinforcement (1 of 2) 330
CD-07.03 Flat slabs. Arrangement of flexural reinforcement (2 of 2) 332
CD-07.04 Flat slabs. General details 334
CD-07.05 Flat slabs. Punching shear reinforcement (Variation 1) (1 of 2) 336
CD-07.05 Flat slabs. Punching shear reinforcement (Variation 1) (2 of 2) 338
CD-07.06 Flat slabs. Punching shear reinforcement (Variation 2) (1 of 2) 340
CD-07.06 Flat slabs. Punching shear reinforcement (Variation 2) (2 of 2) 342
CD-07.07 Flat slabs. Punching shear reinforcement (Variation 3) (1 of 2) 344
CD-07.07 Flat slabs. Punching shear reinforcement (Variation 3) (2 of 2) 346
CD-07.08 Flat slabs. Punching shear reinforcement (Variation 4) (1 of 2) 348
CD-07.08 Flat slabs. Punching shear reinforcement (Variation 4) (2 of 2) 350
CD-07.09 Flat slabs. Drop panels 352
CD-07.10 Flat slabs. Column with drop and head 354
CD-07.11 Flat slabs. Openings (Variation 1) 356
CD-07.12 Flat slabs. Openings (Variation 2) (1 of 2) 358
CD-07.12 Flat slabs. Openings (Variation 2) (2 of 2) 360
ix
Group 08 Stairs 363
CD-08.01 Stairs. General layout details 364
CD-08.02 Stairs. Reinforcement scheme for double flight 366
CD-08.03 Stairs. Reinforcement arrangement for stairs with three flights 368
CD-08.04 Stairs. Foundation for starting flight 370
CD-08.05 Flying stairs (1 of 2) 372
CD-08.05 Flying stairs (2 of 2) 374
Group 09 Bearings 377
CD-09.01 Bearings. Device for centring loads 378
CD-09.02 Bearings. Confinement for linear loads 380
CD-09.03 Bearings. Elastomer bearings 382
CD-09.04 Flat jack housing to change bearings 384
CD-09.05 Bearings. Plastic hinge 386
Group 10 Brackets and dapped-end beams 389
CD-10.01 Brackets (Variation 1) 390
CD-10.02 Brackets (Variation 2) (Suspended load) 392
CD-10.03 Brackets. Double bracket 394
CD-10.04 Dapped-end beams 396
Group 11 Ground slabs and galleries 399
CD-11.01 Ground slabs. Typical section 400
CD-11.02 Ground slabs. Joints (1 of 2) 402
CD-11.02 Ground slabs. Joints (2 of 2) 404
CD-11.03 Ground slabs. Contraction joints 406
CD-11-04 Ground slabs. Expansion joints 408
CD-11.05 Ground slabs. Strengthening free edge of slab 410
CD-11.06 Galleries. Ductways 412
Group 12 Chimneys, towers and cylindrical hollow columns 415
CD-12.01 Chimneys, towers and cylindrical hollow columns.General layout 416
CD-12.02 Chimneys, towers and cylindrical hollow columns. General
arrangement of reinforcement 418
CD-12.03 Chimneys, towers and cylindrical hollow columns. Crown details 420
CD-12.04 Chimneys, towers and cylindrical hollow columns. Bracket to
support lining 422
CD-12.05 Chimneys, towers and cylindrical hollow columns. Duct inlets 424
CD-12.06 Chimneys, towers and cylindrical hollow columns. Circular slab
around the top 426
CD-12.07 Chimneys, towers and cylindrical hollow columns. Circular slab
foundations 428
CD-12.08 Chimneys, towers and cylindrical hollow columns. Annular footings 430
CD-12.09 Chimneys, towers and cylindrical hollow columns. Plastic
water inflow pipes in submerged hollow columns 432
CD-12.10 Chimneys, towers and cylindrical hollow columns. Reinforcement laps 434
x
Group 13 Silos, caissons and rectangular hollow columns 437
CD -13.01 Silos, caissons and rectangular hollow columns. Silo sections 438
CD-13.02 Silos, caissons and rectangular hollow columns. Intersections
and connections (Horizontal sections) (1 of 2) 440
CD-13.02 Silos, caissons and rectangular hollow columns. Intersections and
connections (Horizontal sections) (2 of 2) 442
CD-13.03 Silos, caissons and rectangular hollow columns. Plastic water inflow
pipes in submerged columns 444
CD-13.04 Silos, caissons and rectangular hollow columns. Hoppers 446
CD-13.05 Silos, caissons and rectangular hollow columns. Foundations 448
CD-13.06 Silos, caissons and rectangular hollow columns. Reinforcement laps 450
Group 14 Reservoirs, tanks and swimming pools 453
CD -14.01 Reservoirs, tanks and swimming pools. Rectangular open tanks.
General details 454
CD-14.02 Reservoirs, tanks and swimming pools. Circular open tanks.
General details 456
CD-14.03 Reservoirs, tanks and swimming pools. Roofed reservoirs and tanks.
General details 458
CD-14.04 Reservoirs, tanks and swimming pools. Corner details (1 of 2) 460
CD-14.04 Reservoirs, tanks and swimming pools. Intersection details (2 of 2) 462
CD-14.05 Reservoirs, tanks and swimming pools. Joints and bearings in walls 464
CD-14.06 Reservoirs, tanks and swimming pools. Contraction and expansion
joints in slabs on grade 466
CD-14.07 Reservoirs, tanks and swimming pools. Joints in walls 468
CD-14.08 Reservoirs, tanks and swimming pools. Specific details for improving
construction joint watertightness 470
Group 15 Special construction details for earthquake zones 473
CD -15.01 Summary of basic aspects 474
CD-15.02 Geometrical constraints 476
CD-15.03 Particular aspects of detailing (1 of 2) 478
CD-15.03 Particular aspects of detailing (2 of 2) 480
CD-15.04 Coupling elements in coupled walls 482
CD-15.05 Reinforcement anchorage 484
CD-15.06 Splicing of bars 486
CD-15.07 Concrete foundations elements 488
References 491
Index 493
xi
List of tables
T-1.1
T-1.2
T-1.3
T-1.4
T-1.5
T-1.6
T-1.7
T-1.8
T-1.9
T-1.10
Minimum mandrel diameter to prevent damage to reinforcement (EC2)
Mandrel diameters for reinforcing bars in accordance with Table T-1.1
(B 400 or B 500 steel) (in mm) (EC2)
Minimum cover, c . b' bond-related requirements (EC2) mm,
Recommended structural classification (EC2)
Values of minimum cover, cmin,dur' requirements with regard to durability
for reinforcement steel in accordance with EN 10080 (1) (EC2)
Maximum bundles general specifications
Bundles compressed bars in vertically cast members and overlap areas
in general
Bundles equivalent diameters in mm
Welding processes permitted and examples of application
Concrete. Indicative strength classes
xiii
2
3
5
6
6
8
9
9
23
32
Foreword
The aim of this book is to present a fairly full and systematic description of the construction
details used in concrete structures.
While I paid particular attention to construction details in my previous books, all dealing primar­
ily with structural design and engineering, I was naturally unable to address the issue in depth
in any of them.
I have decided to do so today, acknowledging the importance of detailing and convinced that
it is one of the areas of expertise that professionals must quickly learn to master. Construction
details have a substantial impact not only on the quality of both the design and the building
processes, but on concrete structure maintenance and durability as well.
Forty-five to fifty per cent of the problems arising around concrete structures are widely known
to be attributable to the design stage. That half of those problems are due to errors in, or the
lack of, construction details is a fact much less generally recognised.
Detailing is always the outcome of a synthesis of four areas of knowledge:
• a command of the theory underlying structural concrete engineering
• on-site professional practice
• experimental information obtained from laboratory trials
• the experience obtained in forensic engineering studies.
The extraordinary complexity resulting from such diversity is deftly reflected in the expression
'the art of detailing', which alludes to the mix of technical skill and creativity entailed in good
detailing.
Someone inevitably decides how details are to be built: otherwise construction could not
proceed. But the task is actually incumbent upon the designer. The further 'downstream' the
detailing is done, the greater is the risk of malfunction.
This book begins with an introductory chapter that summarises specifications on concrete cov­
er, reinforcing bar placement and spacing, hook bending radii, anchorages and bar welding. It
also briefly discusses questions that have been scantily addressed in most countries' codes,
such as how bars should be tied or spacers and chairs placed.
The second chapter is a description of the 213 construction details that comprise the book.
Divided into 15 groups, they embrace what I believe to be a sufficient range of issues arising in
reinforced concrete construction.
In this chapter each page on the left shows a drawing of a construction detail. The Notes set out
on the page opposite on the right contains further information, as specified below.
(a) A series of Recommendations that supplement and help to interpret the drawing, in
some cases with concise reference to specific engineering questions.
xv
(b) Reference to Statutory Legislation in the European Union.
(c) Reference to Recommended Alternative Codes to enable the reader to fill in the gaps
where no statutory legislation is in place in the European Union, or in a number of spe­
cific cases, to resort to variations of interest.
(d) Finally, a list of Specific References that deal explicitly and directly with the detail in
question.
Version 2005 AutoCAD software is furnished with the book to enable designers to adapt each
detail to the reinforcing bars used in their designs and print the results on a printer or plotter.
In closing, I owe a word of thanks to the people who collaborated in the preparation of this book.
My gratitude goes to Antonio Machado for coordinating the draughting, Maribel Gonzalez and
Mercedes Julve for the typing; and Antonio Machado, Fernando Marcos and Julio Cesar Lopez
for draughting the details from my sketches, which were not always as carefully drawn as would
have been desired.
Many thanks as well to Margaret Clark and Mc LEHM Language Services for the translation of
my original Spanish manuscript into English.
I am also indebted to Jorge Ley for his assistance in many respects.
Lastly, I wish to express my very special gratitude to Taylor & Francis for the support received
in connection with the publication of this book, and particularly to Tony Moore and Siobhan
Poole for their assistance.
xvi
Jose Calavera
Madrid, March 2011
The author
Jose Calavera graduated in civil engineering in 1960 and earned his doctorate in the field in
1967, both from the School of Civil Engineering, Polytechnic Universityof Madrid. From 1960 to
1967 he headed the Engineering Department at Tetracero, a Spanish producer of ribbed bars
for reinforced concrete.
In 1967 he founded the Technical Institute of Materials and Construction (INTEMAC - lnstituto
Tecnico de Materiales y Construcciones), an independent quality control organisation that cov­
ers design, materials and workmanship in both building and civil engineering. He is presently
the lnstitute's Honorary President.
In 1982 he was appointed Professor of the Building and Precasting Department at the School
of Civil Engineering, Polytechnic University of Madrid, where he is now Emeritus Professor.
He is a Fellow of the American Concrete Institute (ACI), the American Society of Civil Engineers
(ASCE) and the International Association for Bridge and Structural Engineering (IABSE). He
holds the International Federation for Structural Concrete's (FIB) Medal of Honour, and has
been awarded the Italian Association of the Prefabrication Prize for Outstanding Achievement
in Engineering and the Eduardo Torroja Medal.
He has written 15 books in Spanish, one in Italian and two in English on structural concrete­
related subjects. His most prominent designs include the Fuente De Aerial Cableway, the roof
over the Real Madrid Sports Centre and the space frame roofs over the National Livestock
Market at Torrelavega. He is also a renowned specialist in forensic engineering.
xv ii
Author's curriculum vitae
Jose Calavera
• PhD in Civil Engineering.
• BSc in Civil Engineering.
• Emeritus Professor of Building and Prefabrication at the School of Civil Engineering,
Polytechnic University of Madrid.
• Honorary President of the Technical Institute of Materials and Construction (INTEMAC -
lnstituto Tecnico de Materiales y Construcciones).
• Member of the Commission on Prefabrication of the International Federation for
Structural Concrete (Federation lnternationale du Seton - FIB).
• Member of the Working Group 2.2 on Design by Testing of the Commission 2 on Safety
and Performance Concepts of the International Federation for Structural Concrete (FIB).
• Editor for Europe of the international Council on Tall Buildings.
Previously, he was:
• Chairman of Commission VII on Reinforcement: Technology and Quality Control
of the Euro-International Concrete Committee (Comite Euro-International du Seton -
CEB).
• Chairman of the Joint Committee on Tolerances (CEB - FIB).
• Chairman of the Working Group on Precast Beam-Block Floor Systems of the
International Federation for Structural Concrete (FIB).
• Member of the Administrative Council of CEB.
• Member of the Model Code CEB-FIB 1990 Drafting Committee.
• Chairman of the Eurocode Drafting Committee for the Design of Concrete
Foundations.
• Chairman of the Working Group on Precast Prestressed Bridges of the International
Federation for Structural Concrete (FIB).
• Chairman of the Working Group on Treatment of Imperfections in Precast Concrete of
the International Federation for Structural Concrete (FIB).
• Chairman of Scientific-Technical Association of Structural Concrete (ACHE)
• Medal of the Spanish Technical Association for Prestressing (ATEP) (1978).
• Honorary Professor of the Civil Construction Faculty, Pontifical Catholic University of
Chile (1980).
• Member of Honour of the Engineering Faculty, Pontifical Catholic University of Chile
(1980).
• Elected Fellow of the American Concrete Institute (ACI) (1982).
• Medal of Honour of the Civil Engineering College (1987).
• Eduardo Torroja Medal (1990).
• Medal of the Spanish Road Association (1991 ).
• Honorary Doctorate of the Polytechnic University of Valencia (1992).
xix
• Institutional Medal of the Lisandra Alvarado' Central Western University, Venezuela
(1993).
• Medal of the International Federation for Structural Concrete (FIB) (1999).
• Medal of Honour of the Fundaci6n Garcfa-Cabrerizo (1999).
• Award of the Spanish Group of IABSE (2000).
• Great Figures of Engineering Award of the Italian Association of Prefabrication (CTE)
(2000).
• Award of the Spanish National Association of Reinforced Bars Manufacturers (ANIFER)
(2001 ).
• Member of Honour of the Spanish Association of Structural Consultants (ACE) (2001 ).
• Honorary Member of the Academy of Sciences and Engineering of Lanzarote (2003).
• Member of Honour of the Argentine Structural Engineering Association (2004).
• Camino de Santiago Award of Civil Engineering (2004).
• Elected Fellow of IABSE (International Association for Bridge and Structural Engineering)
(2006).
• Member of the Board of Trustees of the Fundaci6n Juanelo Turriano (2006).
• Member of Honour of the Association of BSc Civil Engineers (2008).
• Best Professional Profile in Forensic Construction Engineering Award of the Latino
American Association of Quality Control and Forensics Engineering (ALCONPAT) (2009).
• Elected Fellow of ASCE (American Society of Civil Engineers) (2009).
• Among his most important projects are the Fuente De Aerial Cableway (Cantabria), the
space frame roofs of the Real Madrid Sports Centre and the Mahou Beer Factory (Ma­
drid), the space frame roofs of the National Livestock Market of Torrelavega (Santander)
and numerous industrial buildings, especially for paper manufacturers and the prefabrica­
tion of concrete and steel industry.
• He is author of 15 books in Spanish, two in English and one in Italian, three monographs
and 176 publications on matters concerning structural design, reinforced and prestressed
concrete, structural safety, prefabrication, quality control and pathology of structures. He has
been thesis director for 27 doctoral theses.
xx
Acknowledgements
The publishers wish to thank the lnstituto Tecnico de Materiales y Construcciones (INTEMAC)
for granting permission to reproduce parts of the following books authored by J. Calavera.
Manual de detalles constructivos en obras de hormig6n armada, [Manual for detailing
reinforced concrete structures], Madrid, 1993.
Calculo de estructuras de cimentaci6n [Foundation concrete design], 4th edn, Madrid,
2000.
Muros de contenci6n y muros de s6tano [Retaining walls and basement walls], 3rd edn,
Madrid, 2000.
Calculo, construcci6n, patologfa y rehabilitaci6n de forjados de edificaci6n [Design,
construction, pathology and strengthening of slabs in buildings], 5th edn, Madrid, 2002.
Proyecto y calculo de estructuras de hormig6n [Structural concrete design], 2nd edn,
Madrid, 2008.
xxi
Citations
• Symbols and abbreviations. The conventions adopted in Eurocode 2 (EC2) have been
used as a rule, except in Group 15 (Special construction details for earthquake zones),
where the Eurocode 8 (EC8) conventions were followed.
• For greater clarity and brevity, references are shown as a number in brackets, which match­
es the number under which the publication is listed in the References at the end of the book.
For instance: (3) refers to the third reference, namely EN ISO 3766:2003, Construction
Drawings. Simplified Representation of Concrete Reinforcement.
• References to sections of the book itself are cited directly.
For instance: 1.2 refers to section 1.2, Tying bars, in Chapter 1, General rules for bend­
ing, placing, anchoring and welding reinforcing bars.
• References to other construction details cite the designation shown at the top of each page.
For instance: see CD - 01.02 refers to detail CD - 01.02, Wall footing supporting a brick
wall.
• References to recommendations sometimes specify another CD. For instance: R-3 in 01.03
refers to Recommendation 3 in CD - 01.03. On occasion, the word 'recommendation' is
written out in full, rather than as the abbreviation 'R'.
• References to formulas are placed in square brackets.
For instance: [1.1] is the first formula in Chapter 1, item 1.1.1.
• The figures in Chapter 1 are designated as Figures 1-1 to 1-45.
• When figures are (very occasionally) shown in the Notes, they aredesignated by letters:
(a), (b) and so on.
• The book is logically subject to EC2 specifications in particular and European Committee
for Standardization (CEN) standards in general. When a given subject is not included in the
CEN system of standards, explicit mention is made of that fact and an alternative standard
is suggested.
• Inevitably, as in any code, the author's opinion occasionally differs from the criteria set out
in CEN standards. Such recommendations are clearly labelled AR (author's recommenda­
tion). In these cases readers are invited to use their own judgement.
xxiii
General notes
1. Chapter 1 summarises the specifications in Eurocode 2 on concrete cover, bar spacing,
bending radii, spacer placement and welding, or alternative codes when no CEN standard
is in place (for spacers and tying bars, for instance).
2. Many details assume a 2.5 cm or 1 <I> cover (abbreviated throughout this book as a lower
case r), which is the value for the most usual case, i.e. exposure classes XC2/XC3 in struc­
tural class S4. For other conditions, the cover can be changed as described in 1.1.3.
The cover values in the drawings are the Cmin values. A further 10 mm must be added to
accommodate the spacers. (Members cast against the ground are an exception: in such
cases the 7.5 cm specified includes the 10-mm margin.) The minimum cover value was not
simply enlarged by 10 mm, because while this is the EC2 recommendedvalue, countries
are free to set their own value in their National Annexes.
3. Details on spacers and tying are indicative only. Their number and specific position are
given in Chapter 1. The symbols for spacers and chairs are shown in Figure 1-21.
4. In some cases, more than one page was required to describe a detail. This is clearly speci­
fied in the heading ('1 of 2', for instance). In all such cases, the same Notes apply to both
drawings and are repeated on the page opposite on the right for the reader's convenience.
5. In keeping with standard terminology in many English-speaking countries, in this book the
word 'stirrups' has been used to designate transverse reinforcement in beams and 'ties' to
signify transverse reinforcement in columns. In Eurocode EC2, the word 'links' is applied
in both situations.
In most structures these two types of reinforcement serve very different purposes, and
perhaps for that reason, in (US) English, French and Spanish, different terms are used for
each.
xxv
The three golden rules for pouring concrete on site
Construction details have a heavy impact on the actual quality of the concrete in a structure.
RULE No.1
CONCRETE MUST BE CAST INTO ITS FINAL POSITION ACROSS AN ESSENTIALLY
VERTICAL PATH
Horizontal paths must be avoided. This must be taken into consideration in the design drawings
for reinforcing bar arrangements.
75mm 75mm nn
RIGHT
Figure (a)
25mm -11--
WRONG
Figure (b)
Figure (a) depicts the right way to reinforce a beam to ensure that the forms are filled speedily
and satisfactorily. If the bars are arranged as depicted in Figure (b), the coarse aggregate will
not pass readily between them. As a result, the concrete will have to flow horizontally, inducing
segregation and lengthening the time needed to fill the formwork. Moreover, such arrange­
ments leave insufficient space for the vibrator.
Concrete should not be dumped in a pile for subsequent spreading with vibrators. Rather, it
should be poured in each and every spot where it is needed.
xxvii
RULE No. 2
THE VIBRATOR MUST BE ABLE TO REACH THE BOTTOM REINFORCEMENT
Figure (c) shows the right way to reinforce a beam. With 65-mm spacing (somewhat smaller on
site due to the height of the ribs), a standard 50-mm vibrator will be able to reach the bottom
reinforcement. The solution depicted in Figure (d) is wrong, for it leaves insufficient room for
the vibrator.
65mm 65mm
MM
e. 06
E
E
0
0
LO
2 016
E
E
01
~
30 m~ . -+--(22 mm
~mm _ __j
RIGHT. The vibrator can be
readily introduced into the
beam and the joint.
Figure (c)
41mm 41mm 41mm
--n nn-
e.0 6
212116
·~·
E
g
E
E
0
(')
E
E
0
0
LO
30ml11_j---l- I I 30mm
~250mm .
WRONG. The vibrator cannot
be introduced into the beam or
the joint.
Figure (d)
Figures (e) and (f) show two further cases in which the vibrator is able, or unable, to reach the
bottom reinforcement.
RIGHT. The vibrator reaches the
bottom layer of reinforcement.
Figure (e)
xxviii
I 300 mm
30 mm
1
. i 130 mm
E
E
0
(')
E
E
49m~h-j~mm
~49mm
E
E
0
0
LO
WRONG. The vibrator cannot
reach the bottom layer of
of reinforcement.
Figure (f)
RULE No. 3
CONCRETE CONSISTENCY MUST BE IN KEEPING WITH THE REINFORCEMENT
ARRANGEMENT. AS A GENERAL RULE THE CONCRETE SLUMP SHOULD BE NO
SMALLER THAN 60 mm
Unless the reinforcement is arranged very openly and spaciously or powerful vibration methods
are used, overly dry concrete is characterised by the following.
• The required strength can be reached in test specimens (but not on site) with a lower pro­
portion of cement. The real strength of concrete can be lower.
• Since the control specimens can be compacted with no difficulty, the laboratory trials will
furnish good information.
• In situ placement and a good surrounding of the reinforcement will be difficult to achieve and
the loose consistency will lower actual on-site strength.
xxix
1 General rules for bending, placing,
anchoring and welding reinforcing bars
1 INTRODUCTION
The present summary, based largely on Eurocode 2 (EC2), covers details of a general nature
whose inclusion in all the relevant chapters of this book would be unnecessarily repetitious.
Nonetheless, certain characteristics specific to each type of structural member are addressed
in the respective chapters.
Eurocode 2 (EC2) is supplemented by a number of other standards, the following in particular:
EN 10080
EN ISO 17760
EN ISO 3766:2003
Eurocode 8
Steel for the reinforcement of concrete (1)
Permitted welding process for reinforcement (2)
Construction drawings. Simplified representation of concrete rein­
forcement (3)
Design of structures for earthquake resistance (4).
Further to EC2 (5), for buildings located in seismic areas, the construction details in this and the
following chapter may be modified as described in Chapter 2, Group 15 below.
1.1 SUMMARY OF CODES AND STANDARDS ON CONSTRUCTION DETAILS
1.1.1 PERMISSIBLE MANDREL DIAMETERS FOR BENT BARS (see EC2, 8.3)
EC2 (5) stipulates that:
• the minimum diameter to which a bar may be bent shall be defined as the smallest diameter
at which no bending cracks appear in the bar and which ensures the integrity of the concrete
inside the bend of the bar;
• in order to avoid damage to the reinforcement, the diameter to which the bar is bent (man­
drel diameter) should not be less than <P m,min'
1
TABLE T-1.1
MINIMUM MANDREL DIAMETER TO PREVENT DAMAGE
TO REINFORCEMENT (EC2)
(a) for bars and wire
Bar diameter Minimum mandrel diameter for bends, hooks and loops
<P-:::; 16 mm 4</J
</J>16mm 7 <P
(b) for bent welded reinforcement and wire mesh bent after welding
Minimum mandrel diameter
( • or ( < or / • WW
5</J
d ~ 3 <jJ: 5</J
d < 3 <P or welding within the curved zone: 20 <P
Note: The mandrel size for welding within the curved zone may be reduced to 5 <P where
welding is performed as specified in EN ISO 17660 Annex B (2).
The mandrel diameter need not be checked to avoid concrete failure if the following conditions
exist:
• the length of the bar anchorage beyond the end of the bend is not over 5 </J;
• the bar is not in an end position (plane of bend close to concrete face) and a cross bar with a
diameter ~ <P is duly anchored inside the bend;
• the mandrel diameter is at least equal to the recommended values given in Table T-1.1.
Otherwise, the mandrel diameter, <P m,min' must be increased as per Expression[1.1]
where:
[1.1]
Fbt is the tensile force of the ultimate loads in a bar or bundle of bars at the start of
a bend
ab for a given bar (or group of bars in contact) is half of the centre-to-centre dis­
tance between bars (or groups of bars) perpendicular to the plane of the bend.
For a bar or bundle of bars adjacent to the face of the member, ab should be
taken as the cover plus <jJ/2.
The value of fed must not be taken to be greater than the value for class C55/67 concrete.
2
TABLE T-1.2
MANDREL DIAMETERS FOR REINFORCING BARS
IN ACCORDANCE WITH TABLE T-1.1(B400 or B 500 steel) (in mm) (EC2)
case (a) case (b)
<P MANDREL
lll L. (' (' t~ or
I or
<P d ~ 30 d< 3 0 or welding
within the curved
m (mm) m mm zone
MANDREL (mm)
MANDREL (mm)
6 24 6 30 30 120
8 32 8 40 40 160
10 40 10 50 50 200
12 48 12 60 60 240
14 56 14 70 70 280
16 64 16 80 80 320
20 140 20 100 100 400
25 175 25 125 125 500
28 196 28 140 140 560
32 224 32 160 160 640
40 280 40 200 200 800
50 350 50 250 250 1000
The same rules are applicable to ties and stirrups.
AR. In cases routinely found in practice, such as depicted in Figure 1-1, the use of 12-mm </>or
larger stirrups leaves the corner unprotected. Consequently, joining two smaller diameter
stirrups is preferable to using 14-mm and especially 16-mm </> elements.
50mm
25 mm~ _ i j_0 12
Figure 1-1
1.1.2 STANDARD BENDS, HOOKS AND LOOPS
EC2 specifies the bends, hooks and loops depicted in Figure 1-2 for rebar in general. Ties and
stirrups call for special shapes, as specified in EC2, 8.4 and 8.5, and shown in Figure 1-3.
3
90°:5 a < 150°
(a) Equivalent anchorage length for
standard bend
(c) Equivalent anchorage length for
standard loop
(b) Equivalent anchorage length for
standard hook
(d) Equivalent anchorage length for
welded transverse bar
Figure 1-2. Anchorage methods other than straight bars
(See EC2, Table 8.21 for side cover specifications)
0
(a)
Notes:
--+
10 0, but
<::70m~
(b)
AR. For (a) usually the hook is at 45°
2:20
2:20mm
<:: 0.7 0_L___L---.- s 50 mm
(c)
-t;:: 10 mm
~2: 1.4 0
(d)
For (c) and (d) the cover should not be less than either 3 0 or 50 mm. See 1.6 for more detail.
Figure 1-3. Link anchorage
Welding must be performed as specified in EN ISO 17660 (2) and the welding capacity must
be as stipulated in 1.6.
1.1.3 COVER
The EC2 specifications are summarised below.
(a) General
The concrete cover is the distance between the surface of the reinforcement closest to the
nearest concrete surface (including ties and stirrups and surface reinforcement where rele­
vant) and the nearest concrete surface. For these intents and purposes, groups of reinforcing
bars cannot be replaced by the equivalent circle: rather, the cover refers to the actual bars in
the group.
4
The nominal cover shall be specified on the drawings(*). Such cover is defined as the minimum
cover, cmin' plus a design allowance for deviation, ,1cdev·
cnom = cmin + .dcdev [1.2]
(b) Minimum cover, cmin
Minimum concrete cover, cmin' shall be provided in order to ensure:
• the safe transmission of bond forces
• the protection of the steel against corrosion
• adequate fire resistance.
The greatest value of cmin that meets the requirements for both bond and environmental condi­
tions shall be used.
where:
cmin,b = minimum cover stipulated to meet the bond requirement
cmin,dur = minimum cover stipulated for the environmental conditions.
(For the use of stainless steel or additional protection, see EC2 4.4.1.2)
The minimum cover, cmin,b' needed to transmit bond forces is given in Table T-1.3
TABLE T-1.3
MINIMUM COVER, cmin,b' BOND-RELATED REQUIREMENTS (EC2)
Bond requirement
Arrangement of bars Minimum cover cmin b (**)
Discrete Bar diameter
Bundled Equivalent diameter (</> n)
(**) If the nominal maximum aggregate size is greater than
32 mm, cmin,b must be increased by 5 mm.
[1.3]
The minimum cover for reinforcement in normal weight concrete for each exposure and
structural class is given by cmin,dur'
Note: The recommended structural class (50-year design service life) is S4 for the indicative
concrete strengths given in EC2, Annex E, while the recommended modifications to the
structural class are given in Table T-1.4. The recommended minimum structural class
is S1.
(*) Given that the EC2 'recommends' Llcdev = 10 mm, but allows the choice to each Member State of the
European Union to determine another value in its National Annex, in this manual are indicated the
values of cmin'
5
The recommended values of c . d are given in Table T-1.5 (reinforcing steel). mm, ur
TABLE T-1.4
RECOMMENDED STRUCTURAL CLASSIFICATION (EC2)
Structural class
Criterion
Exposure class (see EC2, Table 4.1 and notes)
XO XC1 XC2/XC3 XC4 XD1 XD2/XS1 XD3/XS2/XS3
Design working increase increase increase increase increase increase increase class
life of 100 years class by 2 class by 2 class by 2 class by 2 class by 2 class by 2 by2
;::.: C30/37 ;::.: C30/37 ;::.: C35/45 ;::.: C40/50 ;::.: C40/50 ;::.: C40/50 ;::.: C45/55
Strength class reduce reduce reduce reduce reduce reduce reduce
class by 1 class by 1 class by 1 class by 1 class by 1 class by 1 class by 1
Member with
slab geometry
(position of
reduce reduce reduce reduce reduce reduce reduce class
reinforcement
class by 1 class by 1 class by 1 class by 1 class by 1 class by 1 by 1
not affected by
construction
process)
Special quality
control of
reduce reduce reduce reduce reduce reduce reduce class
the concrete
class by 1 class by 1 class by 1 class by 1 class by 1 class by 1 by 1
production
ensured
TABLE T-1.5
VALUES OF MINIMUM COVER, cmin,dur' REQUIREMENTS WITH REGARD
TO DURABILITY FOR REINFORCEMENT STEEL IN ACCORDANCE
WITH EN 10080 (1) (EC2)*
Environmental requirement for cmin,dur (mm)
Structural class
Exposure class (see EC2, Table 4.1)
XO XC1 XC2/XC3 XC4 XD1/XS1 XD2/XS2 XD3/XS3
81 10 10 10 15 20 25 30
82 10 10 15 20 25 30 35
83 10 10 20 25 30 35 40
84 10 15 25 30 35 40 45
85 15 20 30 35 40 45 50
86 20 25 35 40 45 50 55
(*) Fire safety may call for higher values.
AR. Except in special cases, covers of under 15 mm should not be used.
Where in situ concrete is placed on other (precast or in situ) concrete elements, the minimum
concrete cover from the reinforcement to the interface may be reduced to a value meeting the
bond requirement only, providing that:
• the concrete strength class is at least C25/30;
• the concrete surface is exposed to an outdoor environment for only a short time ( < 28 days);
• the interface is roughened.
6
For uneven surfaces (e.g. exposed aggregate) the minimum cover should be increased by at
least 5 mm.
AR. If the surface is roughened mechanically, this value should be 20 mm, for mechanical
treatment generates microcracks in the concrete surface.
(c) Allowance in design for deviation
When calculating the design cover, cnom' the minimum cover must be increased to allow for de­
viations (Llcde) by the absolute value of the tolerance for negative deviation. The recommended
allowance is 10 mm.
For concrete poured onto uneven surfaces, the minimum cover should generally be increased
by allowing larger deviations in design. The increase should compensate for the difference de­
riving from the unevenness, maintaining a minimum cover of 40 mm for concrete poured onto
prepared ground (including blinding) and 75 mm for concrete poured directly onto the soil.(*l
The value
[1.4)
reflects the spacer size.
AR. The 40-mm cover for blinding would appear to be excessive. Where the blinding is
reasonably flat, 25 mm or 1 <P would appear to suffice.
1.1.4 BAR SPACING
Bars must be spaced in such a way that the concrete can be poured and compacted for sat­
isfactory bonding and strength development. See the 'three golden rules of concrete pouring'
that precede Chapter 1.
The clear (horizontal and vertical) distance between individual parallel bars or horizontal
layers of parallel bars should not be less than the larger of (d9 + 5 mm), where d9 is the
maximum aggregate size, and 20 mm (Figure 1-4).
Where bars are positioned in separate horizontal layers, the bars in each successive layer
should be vertically aligned with the bars in the layer below. Sufficient space must be left
between the resulting columns of bars for vibrator access and good concrete compaction.
Lapped bars may be allowed to touch one another within the lap length.
{
20mm
a > QJ (bar diameter or diameter of the
- largest bar if bars vary in size)
d9 +5 mm
{
20mm
b QJ (bar diameter or diameter of the
~ largest bar if bars vary in size)
d9 +5 mm
Figure 1-4
(*) Under certain circumstances, European standard EN 1536 (24) allows smaller values for bored piles.
7
AR. The 20-mm limit for a and b is too narrow to ensure satisfactory concrete casting. For
single layers, a 25-mm space is suggested, and 35 mm for two or more: a should be
2.5 times the diameter of the vibrator needle for bars in any other than the bottom layer
in the beam. Note that the longitudinal ribs on bars usually constitute 0.07 to 0.1 O of the
diameter and that bar placement inevitably entails deviations.
1.1.5 BUNDLED BARS
(a) Bundled bars versus large diameter bars
The standard series of large diameter (</J 2 32 mm) reinforcing bars includes two diameters in
Europe, 40 mm and 50 mm, and three in the United States, 11 (</J 35 mm), 14 (</J 44 mm) and
18 (</J 57 mm). (*l While using these diameters provides for more compact reinforcement, which
is a clear advantage, it also entails two drawbacks. On the one hand, the substantial load trans­
fers generated call for carefully designed anchorage. On the other, since such large diameter
bars cannot be lap spliced, construction is more complex and costly. Indeed, even lap splicing,
if it were allowed, would be extremely expensive because of the extra steel needed for the long
overlap lengths that would be required.
The alternative solution is to use bundled bars, which afford the advantages of compact distri­
bution without the aforementioned drawbacks.
(b) Possibly usable bundles
The EC2 specifications are summarised below.
• As a rule, no more than three bars can be bundled (and their axes must not be in the same plane).
• In overlap areas and when using compressed bars in vertically cast members in which no
splicing is needed, four bars are required.
• The equivalent diameter (for the ideal bar whose area is the same as the area of the bundle)
must not be over 55 mm.
(c) Equivalent diameters, areas and mechanical strength
The specifications laid down in Tables T-1.6 and T-1.7 are applicable to bars with an equivalent
diameter </Jn = </J Jil:, where nb is the number of bars and <jJ is the diameter of each individual
bar (Table T-1.8).
TABLE T-1.6.
MAXIMUM BUNDLES GENERAL SPECIFICATIONS
<jJ in mm
n 25 28 32 40
2 YES YES YES NO
3 YES YES YES NO
4 Only in overlaps NO NO NO
(*) In the United States and Canada, bars are designated by their diameter expressed in eighths of an inch.
8
TABLE T-1.7
BUNDLES COMPRESSED BARS IN VERTICALLY CAST MEMBERS
AND OVERLAP AREAS IN GENERAL
</>in mm
n 25 28 32 40
2 YES YES YES NO
3 YES YES YES NO
4 YES NO NO NO
TABLE T-1.8
BUNDLES EQUIVALENT DIAMETERS in mm
</>in mm
n 25 28 32 40
2 35 40 45 57
3 43 48 55 69
4 50 56 64 80
( d) Cross-sectional arrangement of bundles
• Distances between bundles or bundles and bars. The provisions of 1.1.4 apply. The mini­
mum distance must be equal to the equivalent diameter, </> n' whose values are given in
Table T-1.8. Note that the minimum spacing between bundles is the physical space be­
tween two points on the perimeter of the bar closest to the nearest bar in another bundle.
The space between two bundles should always be large enough to accommodate a vibrator
during concrete casting.
• Cover. The cover must be at least equal to the equivalent diameter, <l>n' measured as the
distance to the closest bar.
• For anchorage and overlaps in bundled bars, see item 8.9.3 of EC2.
1.1.6 SURFACE REINFORCEMENT
For bars with a diameter of over 32 mm, the following rules supplement the specifications in
EC2, 8.4 and 8.7.
When such large diameter bars are used, cracking may be controlled either with surface rein­
forcement or by calculating crack widths.
As a general rule, large diameter bars should not be lapped. Exceptions include sections
whose smallest dimension is 1.0 m or where the stress is no greater than 80 per cent of
the design's ultimate strength. In any event, such bars should be lapped with mechanical
devices.
In addition to shear reinforcement, transverse reinforcement should be placed in anchorage
zones with no transverse compression.
9
(a) Additional reinforcement
For straight anchorage lengths (see Figure 1-5), such additional reinforcement should be at
least as described below.
(i) In the direction parallel to the stressed surface:
(ii) In the direction perpendicular to the stressed surface:
where:
As is the cross-sectional area of the anchored bar
n1 is the number of layers with bars anchored at the same point in the member
n2 is the number of bars anchored in each layer.
[1.5]
[1.6]
The additional transverse reinforcement should be uniformly distributed in the anchorage
area and bars should not be spaced at more than five times the diameter of the longitudinal
reinforcement.
I I
o Anchored bar
• Continuing bar
Example: On the left, n1 = 1, and n2= 2 and on the right,
n1 =2,n 2 =2
ADDITIONAL REINFORCEMENT IN AN ANCHORAGE FOR LARGE
DIAMETER BARS WHERE THERE IS NO TRANSVERSE COMPRESSION
Figure 1-5
For surface reinforcement, (i) and (ii) apply, but the area of the surface reinforcement should not
be less than 0.01 Act.ext in the direction perpendicular, and 0.02 Act.ext in the direction parallel, to
the large bars. Act.ext is the area of the tensile concrete external to the stirrups (see Figure 1-6).
(b) Additional surface reinforcement
Surface reinforcement may be needed either to control cracking or to ensure adequate
cover resistance to spalling. EC2 addresses this question in Informative Annex J, summarised
below.
10
Surface reinforcement to resist spalling should be used where the main reinforcement com­
prises:
• bars with diameters of over 32 mm;
• bundled bars with an equivalent diameter of over 32 mm.
The surface reinforcement, which should consist of welded-wire mesh or narrow bars, should
be placed outside the stirrups, as shown in Figure 1-6.
Assurf~0.Q1Actext
/\
Act, ext /\
L,_. -""?-
As.surf
I I I I I I I I I I I
I
~1 :S150mm
x is the depth of the neutral axis at ULS
Figure 1-6. Example of surface reinforcement
The area of the surface reinforcement As.sun should not be less than 0.01 Act.ext in the directions
parallel and perpendicular to the tension reinforcement in the beam.
Where the reinforcement cover is over 70 mm, similar surface reinforcement should be used,
with an area of 0.005 Act.ext in each direction for enhanced durability.
The longitudinal bars in surface reinforcement may be regarded as constituting reinforcement
to resist any other action effects whatsoever.
AR. If such additional reinforcement is included, concrete with a suitable slump should be used
and poured and compacted with utmost care.
1.2 TYING BARS
This issue is not addressed in the EC2 or in any CEN standard. Three excellent References
((6), (7) and (8)) are available on the subject:
• The Concrete Society, Spacers for reinforced concrete Report CS 101, Concrete Society,
1989.
• Comite Euro-International du Beton (CEB), Spacers, chairs and tying of steel reinforcement,
Lausanne, 1990.
• BS 7973:2001, Spacers and chairs for steel reinforcement and their specifications.
111.2.1 TYING METHOD
Reinforcing bars are always tied with tempered steel wire, generally 1.6 mm in diameter.
Figure 1-7 Figure 1-8
Standard practice is to use wires fitted with hooks (Figure 1-7) that are marketed in three or
four lengths to adjust to the standard bar diameters. They are tied with the tool depicted in
Figure 1-8, consisting of a worm spindle with which the steel fixer first hooks the two loops in
the wire together (Figure 1-7) and then pulls outward on the tool, joining the bars in just two
or three movements (Figure 1-9). The use of tongs leads to bonds such as that depicted in
Figure 1-10, which often work loose. A valid alternative is mechanical joiners that tie the bars
securely (Figure 1-11).
Figure 1-9 Figure 1-10 Figure 1-11
1.2.2 TIE POINTS
The following recommendations are made.
• Slabs and plates. All the intersections between bars around the perimeter of the reinforce­
ment panel should be tied.
In the rest of the panel, where the bar diameter is 20 mm or less, every second intersection
should be tied. Where the bars are 25 mm or larger, the distance between tied intersections
should not exceed 50 diameters (Figure 1-12) of the thinnest tied bar.
I a i-----·--------<
Figure 1-12
12
• Beams. All the corners of the stirrups must be tied to the main reinforcing bars. If welded-wire
fabric reinforcement is used to form the stirrups, the main reinforcing bars at the corners should
be tied at intervals no larger than 50 times the diameter of the main reinforcing bars.
All the bars not located in the corner of the stirrup should be tied at intervals no larger than
50 times the bar diameter.
Multiple stirrups should be tied together (Figure 1-13).
Corner bars in all stirrups
(a)
Every 50 0 1
All other bars
(b)
Figure 1-13
Multiple stirrups
(c)
• Columns. All the ties should be tied to the main reinforcement at the intersections. When
welded-wire fabric cages are used, the vertical wires should be tied to the main reinforce­
ment at intervals measuring 50 times the bar diameter.
• Walls. The bars are tied at every second intersection.
For the intents and purposes of tying reinforcing bars, precast walls manufactured with the
mid-plane in a horizontal position are regarded to be slabs.
The rules for slabs and plates are applicable to walls cast in situ (Figure 1-14).
-
Figure 1-14
• Footings. The horizontal part of the starter bars should be secured at each right-angle
intersection between starter bar and foundation reinforcement. All the ties in footings
should be secured to the vertical part of the starter bars.
AR. The footing assembly should have at least two tie bars.
13
1.3 SPACERS AND CHAIRS
This subject is not addressed in the EC2 or in any CEN standard. Here also, references (6), (7)
and (8) are excellent sources of information.
Spacers and chairs are elements made of sundry materials used to ensure a suitable concrete
cover or to hold bars in position. The specific definition for each is given below (see (1.3.1 a)
and (1.3.1 b)).
1.3.1 TYPES OF SPACER AND CHAIR
(a) Spacers
The are plastic or galvanised or stainless steel wire or steel plate or mortar elements designed
to ensure a satisfactory concrete cover for reinforcing bars. Three general types of spacer can
be distinguished.
• Wheel or clip spacers, which are tied with a wire or clipped to bars or act as unsecured sup­
ports (Figure 1-15). Figure 1-16 shows a manual procedure for making this type of spacer
where necessary. (*)
Semi-circular impression
made with a round bar
(a)
Figure 1-15
_Wire
The length of mortar is cut into
separate spacers with a trowel
(b)
Figure 1-16
(*) 'Home-made' spacers are not usually permitted.
14
• Linear spacers designed to support the bottom beam and slab reinforcement where the
bars must be prevented from toppling (Figure 1-17).
(a)
(c) (d)
Figure 1-17
(e)
• End spacers (Figure 1-18), placed at the ends of bars to ensure they remain at a sufficient
distance from the formwork.
(a) (b)
Figure 1-18
(b) Chairs
Chairs are usually made of galvanised or stainless steel wire. They may be discrete, to support
bars in a specific position, or continuous, for continuous support (Figure 1-19). Type ( c); which~
may be made of welded-wire fabric, is especially suitable for slabs and flooring. Plastic tubes
are required where the slab soffit is tobe exposed.
A Plastic e tube
~)
~asticcap
A
Plastic cap
(a) (b) (c)
Figure 1-19
15
In all cases their purpose is to separate the top reinforcement in slabs from the formwork or the
soil, or the various layers of reinforcement in walls or similar.
Linear chairs should in turn rest on suitable spacers to prevent corrosion.
(c) Special chairs
The standard sizes in which chairs are manufactured are limited for reasons of economy.
Nonetheless, similar elements are needed in very deep slabs or very wide walls to secure the
reinforcing bars.
These elements, known as 'special chairs', are normally made with the off cuts metal gener­
ated when assembling concrete reinforcement (Figure 1-20 (a)). Their diameter and dimen­
sions should be in keeping with the depth of the member and, in slabs, with the weight of the
top layer of reinforcement.
If they rest on the formwork, they should be supported by spacers (Figure 1-20 (b)). They are
tied to the bottom layer, when present (Figure 1-20 (c)).
(a)
t J 1 :~ l
. : ::J :
'
(b) (c)
Figure 1-20
(d) Price
The price of spacers, chairs and special chairs is usually included in the kilo of reinforcing steel
assembled at the worksite. While the financial impact of these elements is small, their cost
should be estimated where large slabs and plates are involved.
Important note: Spacers, chairs and special chairs must be positioned in such a way that they
ensure that all cover distances are 1 O mm greater than called for in the design. The reason is to
provide the necessary tolerance for bar deformation between spacers so that the actual cover
or distance is not less than the minimum values.
1.3.2 GRAPHIC REPRESENTATION
The conventional signs listed in the box below (Figure 1-21) are used in drawings to symbolise
spacers, chairs and special chairs.
16
1.3.3 PLACEMENT RULES
(a) Slabs and footings
(a) WHEEL OR CLIP SPACER
A LATERAL VIEW
• SUPPORT SIDE VIEW
(b) LINEAR TYPE SPACER
- LATERAL VIEW
- PLANVIEW
(c) END SPACER
c::J4 LATERAL VIEW
=-o PLAN VIEW
(d) DISCRETE CHAIR
/\ LATERAL VIEW
0 PLANVIEW
(e) CONTINUOUS CHAIR
SIDE VIEW (PROFILE)
---D-- PLAN VIEW
(f) SPECIAL CHAIR
L_ SIDE VIEW (PROFILE)
l PLANVIEW
Figure 1-21
• Bottom reinforcement layers should rest on and be attached to spacers positioned at
intervals measuring no more than 50 times the bar diameter and never over 1 OOO mm
(Figure 1-22) .
. Q i t SECTION ' 0 i t SECTION
x
Cl)
E
E
E
0
0
I.()
-
-
II
'I
•
II
I~
I
.
500 mm I max.
II
II~
• .
Individual bars Welded fabric
w ~
01
SPACERS FOR BOTTOM REINFORCEMENT IN SLABS AND FOOTING
Figure 1-22
17
PLAN
• The top reinforcement should rest on:
continuous chairs set at intervals measuring not over 50 times the bar diameter.
These continuous chairs rest, in turn, on the bottom reinforcement, if any (Figure
1-23 (a)) and where there is none, on linear chairs spaced at no more than 500 mm
(Figure 1-23 (b));
It 0 / 0 t+ SECTION
PLAN
sSO 01, not exceeding
SOO mm for welded fabric
(a)
II
IO
PLAN
Is 50 0 1, for bars or I
500mm for welded fabric
(b)
CONTINUOUS CHAIRS FOR TOP REINFORCEMENT IN SLABS AND FOOTINGS
WITH BOTIOM REINFORCEMENT
Figure 1-23
- discrete chairs spaced in both directions at no more than 50 times the diameter of
the supported bar (Figure 1-24);
u
'C:
..... .0
oJ!1
IA I\
.0 32
~~
~al[
&.E
oE
IO E
VI o
0
IO
[_ _____ __j
s50 0 1, for bars or
500 mm for weldedfabric
SECTION
PLAN
CHAIRS FOR TOP REINFORCEMENT IN SLABS AND
FOOTINGS WITHOUT BOTIOM REINFORCEMENT
Figure 1-24
18
- special chairs spaced at the intervals shown in Figure 1-25.
E
E
0 ..,.
0 .....
1200 mm
PLAN
SPECIAL CHAIRS FOR TOP REINFORCEMENT IN SLABS
Figure 1-25
(b) Spacers on slab edges
• In the absence of horizontal reinforcement along the slab edges, spacers are placed
on alternate bars, as in Figure 1-26 (a).
SECTION tt i ~ ~ tt
(a) Without horizontal reinforcement
SECTION
I Spacers on I
alternate bars
Spacers at 500 and not
exceeding 1000mm
(b) With horizontal reinforcement
SPACERS FOR SLAB EDGES
Figure 1-26
ELEVATION
ELEVATION
• When the slab has horizontal reinforcement on the edges, the spacers should be
placed as in Figure 1-26 (b).
19
(c) Spacers for ribbed slabs
Spacing is as shown in Figure 1-27.
Max. distance 50 0 1 not exceeding 1000 mm
(a) Without stirrups
(d) Beams
Figure 1-27
l
h
- Max. distance 1000 mm
(b) With stirrups
Spacers should be set in the stirrups at intervals of no more than 1 OOO mm longitudinally
(Figure 1-28), with a minimum of three planes of spacers per span.
Cross-wise placement must be as shown in Figure 1-28.
~1°1 over 1000 mm ..__ ___ --··----·-~- -----<
!SI
0
0 ...-
c: 01
"' £ ....
* ~
C)
E
"' Q)
.0
a.
Q)
Q)
0
(d)
< 250 mm
(b)
(a)
250 mm - 500 mm
(c)
Spacers at intervals
not exceeding 50 0 1 ~
] > 500 ""'m""'m __ ---1
(e)
Figure 1-28 Spacers in beams
End or ordinary spacers are needed at the ends of beams in contact with the formwork,
depending on the case (Figure 1-29).
20
Figure 1-29
(e) Columns
Lengthwise along the member, spacers should be placed in the stirrups at no more than 100
times the minimum diameter of the main reinforcement, with at least three planes of spacers
per member or section (Figure 1-30).
(a)
SPACER ARRANGEMENT IN COLUMNS
Figure 1-30
Spacers at intervals
not exceeding 50 0 1
1-1
II[ : J-.:,
I Face ~-5_0_0_,_1 _-<
(b)
Spacers at intervals
not exceeding 50 0,
II
Double links
(c)
I Spacers at intervals
~ ~ot exceeding 50 0 1•
a
~\ least 4 per group
I
One spacer per 50 0 1
~ar :'reach facet
O·,
0,
Circular columns
(d)
Multifaceted columns
(e)
MULTIFACETED COLUMNS
Figure 1-31
Crosswise placement should be as shown in Figure 1-31.
21
(f) Walls
Spacers should be staggered in each layer of reinforcement at intervals measuring the
larger of 500 mm or 50 times the diameter of the reinforcing bars. Spacers for reinforcement
on opposite sides of the member must be placed at the same height. Spacing between the
reinforcement on the two sides must be ensured with continuous chairs set at intervals of
not over 1000 mm. In large retaining walls, special chairs must be used instead of chairs
(Figure 1-32).
In precast concrete walls whose mid plane is in a horizontal position, the spacers must be set
as described for slabs.
Continuous chairs at intervals not
exceeding 1 OOO mm
ELEVATION
Spacers at intervals not exceeding the
greater of 50 0 1 or500 mm
in both directions
n', : : : :\ : t PLAN
I ::;1000 mm I
I : SECTION
I
I
-,,.
~- I
I I
SPACERS AND CONTINUOUS CHAIRS FOR WALLS
Figure 1-32
1.4 WELDING REINFORCING BARS
Bars are commonly welded together, using any of a number of procedures. The following is a
summary of standard ENISO 17660-1, Welding of Reinforcing steel (11 ).
1.4.1. TYPES OF WELD
Two types of welded joints can be distinguished:
(a) load-bearing
(b) non-load-bearing.
22
In addition, such joints can be classified by their position or the welding procedure used.
The welding procedures allowed for reinforcing bars are set out in Table T-1.9 (EC2, Table 3.4)
and weldability requirements are established in EN 10080 (1 ).
TABLE T-1.9
WELDING PROCESSES PERMITTED
AND EXAMPLES OF APPLICATION
Loading conditions Welding method Tension bars1 Compression bars1
flash welding butt joints
manual metal arc
butt joints with </> 2 20 mm, splice, lap and
welding and metal
arc welding with
cross joints3 and joints with other steel
filling electrode
members
Predominantly
metal arc active welding2 splice, lap and cross3 joints and joints with
static
other steel members
- butt joints with</> 2 20 mm
friction welding butt joints, joints with other steel members
resistance spot welding lap joints4
cross joints2• 4
flash welding butt joints
manual metal arc welding - butt joints with </> 2 14 mm
Not predominantly
metal arc active welding2 butt joints with </> 2 14 mm -
static
resistance spot welding lap joints4
cross joints2• 4
Notes:
1. Only bars with approximately the same nominal diameter may be welded.
2. Allowable ratio for mixed diameter bars 2 0.57
3. For load-bearing joints with </> s 16 mm
4. For load-bearing joints with</> s 28 mm
All reinforcing bars shall be welded as specified in EN ISO 17760 (2).
The welds joining wires along the anchorage length of welded-wire fabric shall be strong
enough to resist the design loads.
The strength of the welds in welded-wire fabric may be assumed to be adequate if each welded
joint can withstand a shearing force equal to at least 25 per cent of the characteristic yield
stress times the nominal cross-sectional area of the thicker of the two wires, if they differ in
size.
AR. In cross joints with hardened concrete arm.rnd the bars, the strength of the joint is
25 per cent higher than in exposed joints.
23
1.4.2. WELDED JOINT DETAILS
(a) Butt joints
In all such joints, the edges are prepared as shown in Figure 1-33.
"'60°
\/
f--------=--¥,---=x-y -----i
(a) Double V butt weld (b) Single V butt weld
(c) Double bevel butt weld (d) Single V butt weld with backing
Note: x and y depend on the welding process.
EXAMPLES OF BUTT JOINT PREPARATION
Figure 1-33
(b) Lap joints
Key
x root gap
y depth of root face
These joints call for no preparation. The procedure is as shown in Figures 1-34 and 1-35.
<::40 I;:: 212l
Key
1 Weld
a Throat thickness
0 Nominal diameter of the thinner of the two welded bars
£0 Overall lap length
w Weld width
-- ~ =f
·~ w
Note: Welding is also possible on both sides with minimum weld length of 2.5 0.
A conservative estimate of the effective throat thickness can be taken as
a:::::0.5w.
LAP JOINT
Figure 1-34
24
<:40 <:4 0
>--------+-----+--- - -----l
I
--------,--------
I
- 10
"-----;,~"-~'"~'"~'"~"-~"~"--~'"~' -"-~~~~~-~ _ _!
Key
1 Weld
a Throat thickness
0 Nominal diameter of the thinner of the two welded bars
w Weld width
a~0.3 0
Note: Welding is also possible on both sides with minimum weld length of 2.5 0.
(c) Cross joints
A conservative estimate of the effective throat thickness can be taken as
a'= 0.4 W,
STRAP JOINT
Figure 1-35
Cross joints can be resistance-welded (with machines with widely varying characteristics) or
metal-arc-welded (Figures 1-36 and 1-37).
~- ---- - -----_ _] _ -t-
(a) Double-sided weld
-~------- ___ L_t-
(b) Single-sided weld
F ___.
Key
1 Longitudinal bar
2 Transverse bar
F Force to be anchored by transverse bar
CROSS JOINTS WELDED BY RESISTANCE MANUAL ARC WELDING
Figure 1-36
-P--~- -l-
CROSS JOINTS WELDED BY RESISTANCE
SPOT WELDING
Figure 1-37
25
( d) Bar-to-steel structure joints
The most common use of and details for these joints are shown in Figures 1-38 and 1-39.
I 0.40St,but tmin=4mml
(a) Side lap joint, single-sided welded
Key
1 Weld
QI Nominal diameter of the welded bars
e Distance between the bars
t Thickness of the web of a section or of a
plate to be welded
tmin Minimum thickness of the web of a section
or of a plate to be welded
I 0.4 0 s t, but t min - 4 mm I
(b) Side lap joint, double-sided welded
SIDE LAP JOINT ON STRAIGHT REINFORCING STEEL BARS
Figure 1-38
I 0.4 0 s t, but t min = 4 mm I
(a) Set-throughbar
I 0.4 QI s t, but tmin = 4 mm I
In case of a gap, the fillet weld size shall be
increased by the dimension of the gap.
(c) Set-on bar
(b) Set-in bar
Key
a Throat thickness
b Excess of the bar
0 Nominal diameter of the welded bars
t Plate thickness
tmin Minimum thickness of the web of a section
or of a plate to be welded
TRANVERSE END PLATE JOINT
Figure 1-39
26
1.5 VERIFICATION OF THE ANCHORAGE LIMIT STATE
The method used is applicable to both flexible ( v ~ 2h) and stiff footings with a ratio of ~ > 1 .
h
The following is a more detailed description of the method than that found in EC2, 9.8.2.2.
v 1- ---------<
a 2 j
~·------
(a) (b)
Figure 1-40
A 8° shear crack is assumed to be possible, as depicted in Figure 1-40 (a). Given the low
bending reinforcement ratios, d may be accepted to be 0.9h and the height of the point where
cracking begins, 0.9d or 0.81 h.
For the sake of simplification, the moments used in the calculations below are the moments on
the column face. A 75-mm side cover is also assumed, as in footings poured onto soil.
The reinforcement anchor length should be as required to anchor the bar force from the point
where the reinforcement intersects with the crack onward, i.e. point A. (The reinforcement is
assumed to be constant across the entire width.)
Taking the moments at B
Fsx · 0.81h = xa1d • (v -;J
where
x= v- 0.81h cot()
and operating, yields
Fsx · 0.81h = ~d (v2 - 0.66h2 cot 2 e)
a1d (v2 -0.66h2 cot 2 e)
F = ---'--------"-
sx 1.62h
[1. 7)
In addition to the equation above and in keeping with the bending moment applied, the following
must hold:
2 2
A f 0 81h . ~ ~ A f = (]'Id v
s yd . • = (J'td 2 s yd 1.62h
27
from which it follows that:
.e = Fsx . .e . As.req = ( v2
- 0.66h2 cot 2 8) . .e . As,req
b,net A f b A 2 b A
s yd s,prov V s,prov
[1.8]
(.eb reflects bonding position I, given the position of the bars.)
.e = [1 - 0.66 ( h )
2
cot 2 e] .e · As,req (*l b,net V b A
s,prov
[1.9]
1.5.1 BOND ANCHORAGE
Given X= v-0.81 h cote:
If .eb,net '.5,x-75 =V-0.81h cot8-70 use straight anchorage [1.1 O]
If 0.7.eb,net ,_:::, x - 75 = v - 0.81h cot 8- 70 use hook anchorage [1.11]
If 0.7.Cbnet >X-75 =V-0.81h COt8-70 lengthen .e' 1 [1.12]
(See Figure 1-40 (b))
(Dimensions in mm)
Since length .e'1 is in bonding position I:
.e =x-75+.e' =v-0.81hcote-75+.e'
b,net 0.7 1 0.7 1
and consequently:
.e· = .e _ v -0.81h cote- 75
1 b,net 0.7
[1.13]
where .eb,net is calculated as per [1.9].
Since:
x = v -0.81h cote:
The minimum value of x is found with the maximum value of cot () which, according to
EC2, is equal to cot() = 2.5, yielding:
or
x = v -2.03h = h(~ - 2.03)
x v
-=--2.03
h h
[1.14]
(*) [1.9] is a more general expression than the formulas set out in EC2, in which critical value x is simpli­
fied to be equal to 0.5h. See the discussion below.
28
2+---+---+-----1
1.97
(~)
D---~~-+&--~~+--~--1
1 2 2.03 3 4
a2- a1
2 v
-h-=h
Figure 1-41
The graph in Figure 1-41 shows the distance x in terms of h for different values of ~.
h
If ~ ~ 2.5, a conservative value for x is 0.5h, as adopted in Eurocode EC2. Direct calcula­
h
tion is preferable.
1.5.2 WELDED TRANSVERSE BAR ANCHORAGE
In this case, the force to be anchored at the end of the bar, assuming a 75-mm cover, is defined
as shown in Figure 1-42.
75mm
Welded
bar
Figure 1-42
x-75 [ x-70] F0 = Fsx -----e;-·Fsx =Fsx 1-----e;- where Fsx was deduced from [1.7]
and substituting
F = CY1d (v2 -0.66h2 cot 2 e) [1- v-75-0.81hcot el
0 1.62h £b
. 1.62hA/yd
and given CY,d = 2
v
[1.15]
hence, according to the discussion in section 1.6, with welding strength 0.5 A/yd' the
number of welded transverse bars required, n, is calculated as:
29
n= ~(1-o.66 (h)2 cot2 e]cb. As.req [ 1-v-75-0.81h cot BJ
2 V As,prov C b
[1.16]
Inasmuch as expression [1.16] is always less than one, anchorage is attained with a
welded transverse bar of the same diameter as the main bars.
1.6 ANCHORAGE RULES FOR WELDED TRANSVERSE BARS
This issue has been researched in a number of countries. The results are summarised below<*)
in somewhat greater detail than in EC2. In this method, the strength of the welded joint can be
found assuming that the cross-joined bars are surrounded by concrete.
1.6.1 BARS WHERE 14:::; </>r:::; 32 mm, 14:::; </>L:::; 32 mm
The design value of the anchorage capacity of a welded transverse joint can be found from the
following formula:
where:
Fbtd = design value of the anchorage capacity of the welded transverse joint
= 1.16~ r; ~Lr
~~
[1.17]
[1.18]
Lr = in single transverse bars, bar length, or spacing between longitudinal bars, as appropriate
<Pr = transverse bar diameter.
(The assumption is that <PT :s; <PL and that the welded joint is at least 50 per cent of the design
mechanical strength of the longitudinal bar).
f. +a td0.05 cd < 3 f
- cd y atd [1.19]
t,d0,05 = design characteristic tensile strength of the concrete surrounding the welded joint. Its
sign is positive
fed = design compressive strength of the concrete
acd = design compressive stress in the concrete in the direction normal to the axes of the
two bars (positive for compression)
y = 0.015 + 0.14 e<-0•1sx)
c
[1.20] X=2-+1
~
c = cover in the direction perpendicular to the axes of the two bars
Fwd = guaranteed design strength for the welded joint (where y s = 1.15).
(*) The following formulas are based essentially on research conducted by Finnish construction and
reinforcing steel companies. Of particular note are the studies conducted by Statens Tekniska Forsk­
ingscentral and Pekka Nykyri (9), which were included in the Annex to the final version of Eurocode
2, Part 3 (Concrete foundations) (10). (It presently forms parts of Part of EC2 (5)).
30
The foregoing is illustrated graphically in Figure 1-43.
Anchored bar h
1~---ti---~---+ + -~~--t-J0r
~- T~20 j
bar
Cross weld to anchor bar
(a)
Figure 1-43
If two transverse bars are welded to opposite longitudinal sides, the anchorage strength found
with the aforementioned formula is doubled (Figure 1-44 (a)). By contrast, if two transverse para­
llel bars are welded at the minimum spacing of 3 rj>T' strength is multiplied by 1.4 (Figure 1-44 (b)).
0r
II
0Lf= f : > 9
---W-J"r
(a)
Figure 1-44
1.6.2 BARS WHERE </>TS 12 mm, <PL s 12 mm
(b)
The strength of a welded transverse joint in a concrete mass is at least 25 per cent greater than
the strength of the same welded joint found with the standard uncovered joint test.
The design value of the anchorage capacity of a welded transverse joint can be found from the
following formula:
- <Pr Fbtd -1.25Fwd s 16AsL ·fed -
rpL
[1.21]
where the minimum bar length or spacing between parallel longitudinal bars, as appropriate,
must be 2 7 1> L:
Fwd = design guaranteed strength for welded joint
<PT = transverse bar diameter, <Prs 12 mm
<j>L = anchored bar diameter, 1>L s 12 mm
AsL = area of the transverse bar cross-section.
(The assumption is that 1>T s <PL and that the strength of the welded joint is at least 50 per cent
of the design mechanical strength of the longitudinal bar.)
31
If two transverse bars (Figure 1-45) are welded at the minimum spacing of 4 </>T' strength is
multiplied by 1.4.
• i<•••q. •
Figure 1-45
1.7 RELATIONSHIP BETWEEN CONSTRUCTION DETAILS AND DURABILITY
The insufficient durability of many concrete structures is one of the most severe problems
encountered in this type of construction today.
Satisfactory construction detailing plays an essential role in concrete structure durability. Such
details affect performance in any number of ways, including the aspects listed below.
(a) They contribute to appropriate cover over reinforcement, preventing corrosion during the
expected design life.
(b) They control shrinkage and thermal contraction cracking.
(c) They controlcracking due to reinforcement elongation.
(d) They prevent cracking in anchorage and curved areas.
(e) They prevent cracking due to excessive local compressive stress in the concrete.
Construction detailing in the design not only has an impact on the safety and cost of built struc­
tures, but on their durability as well.
Table E.1 Nin Annex E of EC2 (reproduced as Table T-1.1 O below) recommends the minimum
concrete strength for each exposure class.
Indicative
strength class
Indicative
strength class
TABLE T-1.10
INDICATIVE STRENGTH CLASSES
Exposure class according to Table 4.1
Corrosion
Carbonation-induced Chloride-induced
Chloride-induced
corrosion
corrosion corrosion
from sea water
XC1 XC2 XC3IXC4 XD1 I XD2 XD3 XS1 XS2 I XS3
C20/25 C25/30 C30/37 C30/37 C35/45 C30/37 C35/45
Damage to concrete
No risk Freeze/thaw attack Chemical attack
XO XF1 XF2 XF3 XA1 I XA2 XA3
C12/15 C30/37 C25/30 C30/37 C30/37 C35/45
32
2 Constructive details
Group 01 Foundations
Group 02 Retaining walls and basement walls
Group 03 Columns and joints
Group 04 Walls subjected to axial loads
Group 05 Beams and lintels
Group 06 Slabs, ribbed slabs and precast slabs with beam and block and hollow core floor
systems
Group 07 Flat slabs
Group 08 Stairs
Group 09 Bearings
Group 1 O Brackets and dapped-end beams
Group 11 Ground slabs and galleries
Group 12 Chimneys, towers and cylindrical hollow columns
Group 13 Silos, caissons and rectangular hollow columns
Group 14 Reservoirs, tanks and swimming pools
Group 15 Special construction details for earthtiuake zones
33
Group 01
Foundations
CD- 01.01
WALL FOOTING SUPPORTING
A REINFORCED CONCRETE WALL
01
Off cuts 0 2 = 0 1 I 2
;~Every fifth pair of vertical
/ bars in the wall)
. Construction jo~ ~:.:_®®© ®
,',.':~~
,:r---------'-l:f~'°ft-'------,---+---J:\,~~,' Spacers
r1
R=20orl J
a
Off cuts
02
CROSS- SECTION
PLAN
ELEVATION
L4 ~~~ (every fifth 3.50 5 0
36
bar)
Ur
J12
See@
f
@
----]
r1
R
13
I
©
@
ARRANGEMENT WHEN TINO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN
reinforcement 0 3
CD - 01.01 NOTES
1. RECOMMENDATIONS
1. The <j>1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the <1> 1 bar lap length.
3. AR. The starter bars are diameter <j>1 bars. L4 should be 2'. ebd, but length ebd is defined in EC2 for the least
favourable case. In this case the side covers for the <1> 1 bars are very large. See (12), p. 69. A safe value
would be e'bd = ~ebd . If L4 <~ ebd, often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every <j> 1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the <1>1 bar cross-section, but their diameter should be such that ~ ebd < L4 , where ebd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar
cover is 2'. 10 <I> but not under 10 cm.
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <j>4 •
6. See 1.5 to determine when to use anchor type a, b or cat the end of the <j>4 reinforcing bar.
7. Length L2 shall suffice to tie the <j> 1 starter bars securely to two <j>5 transverse bars. (It may not be less than
2s, where s is the space between <j>5 bars.)
8. The bars with diameters <j>2 and <j>3 are supports whose sole purpose is to keep the starter bar assembly
firmly in place while the concrete is cast in the foundations. The starter bar assembly is to be tied at all cross
points. Depending on the case, these ties may be supplemented or replaced by positioning reinforcement <j>6
in lapping length L1 before pouring the concrete in the footing.
9. The top of the footing is smoothed with floats or a power float except in the contact area with the future wall,
where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The foundation subgrade must be compacted before the blinding is poured.
12. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the concrete to form the wall, the joint surface should be cleaned and pressure hosed. The
concrete should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
37
CD-01.02 WALL FOOTING SUPPORTING A BRICK WALL
a
v
i
'--- Compacted subgrade
r----v ____ _j
-04 I ····· End spacer
LAsphalt membrane (if any)
CROSS-SECTION
38
®
r1
R = 20 or-I J
3.50 50
i::::::===~'
©
CD-01.02 NOTES
1. RECOMMENDATIONS
1. r, = 7.5 cm if the concrete for the footing is poured directly against the soil.
2. r2 = 2.5 cm but not less than $4 •
3. See 1.5 to determine when to use anchor type a, b or cat the end of the $4 reinforcing bar.
4. The top is smoothed with floats or a power float. The mortar bed under the wall that interfaces with the foot­
ing shall be 1 O mm thick.
5. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
6. The foundation subgrade should be compacted before the blinding is poured.
7. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
8. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
9. Before the first bed mortar is laid under the wall, the area of the joint that will interface with it should be
pressure hosed. The mortar should not be placed until the surface of the footing dries.
1 O. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
The articles in the Code on spread footings are partially applicable.
39
CD-01.03 SPREAD FOOTING
h
v
A ..
Scm
v
Construction joint
See@
and note 8
Compacted subgrade
ELEVATION
f-----------a ________ __,
i r 1
-~--
'
I
,-- /~\ ,-...,
I \_ y
a I [/,, I
L __ __ _J
l ---
r1
PLAN
@)
ARRANGEMENT WHEN TWO STARTER
BARS ARE USED PER MAIN BAR IN THE
COLUMN. (SEE NOTE 3)
I r1
I
See @
v
~
D
®
DETAIL OF STARTER BAR STIRRUPS
40
VIEW FROM A
r1
R=20orl J
3.50 50
~====~'
----j
R
©
CD - 01.03 NOTES
1. RECOMMENDATIONS
1. The $1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the $, bar lap length.
3. AR. The starter bars are diameter $1 bars. L4 should be 2 £bd' but length £bd is defined in EC2 for the least
favourable case. In this case the side covers for the$, bars are very large. See (12), p. 69. A safe value
would be £'bd =~ £bd . If L4 <~ £bd, often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every $1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the $1 bar cross-section, but their diameter should be such that ~ cbd < L4, where £bd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar
cover is 2 10 $but not under 10 cm.
4. r1 = 7.5 cm if the concrete for the footing is poured directly againstthe soil.
5. r2 = 2.5 cm but not less than $4 •
6. See 1.5 to determine when to use anchor type a, b or c at the end of the $4 reinforcing bar.
7. Length L2 shall suffice to tie the $, starter bars securely to two $5 transverse bars. (It may not be less than
2s, where sis the space between the $5 bars.)
8. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the foundations. The starter bar assembly is to be tied at all cross points. These are
not the same ties as in the column.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed . .
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour-
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The foundation subgrade must be compacted before the blinding is poured.
12. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
16. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
17. Rectangular footings can be set out in exactly the same way, although the resulting grid is logically not
symmetrical.
41
CD-01.04 SPREAD FOOTING WITH VARIABLE DEPTH
v I- ------~-i v
r1
-
"
I
" " '
" "
"
I
I
a
/
/
/
/
/
/ I
/ +---
' i r1
See@®©
See@ I ®
h
~---+- 10 cm @
f1
---11-
Blinding ---'
121• I AsphaH membrane (if any)
~ Compacted subgrade
JL3
ELEVATION
a
-
I/
"
/
"
/
// -
,-- ;:::--=-i \ I
I
I
\ _ __.1· I
I
I I
I
I 1#.
L __ __ __J
I
- -
/ " / " / " I'-
PLAN
/
/
/
/
/
/
'
"
"
" " '
-
42
/
I
'
r1
Se e@
®
@)
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN.
(SEE NOTE 3)
~D~l ·~
®
DETAIL OF STARTER
BAR STIRRUPS.
t$'-t$"
~\)
~cr;,""/
CD-01.04 NOTES
1. RECOMMENDATIONS
1. The qi1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the qi1 bar lap length.
3. AR. The starter bars are diameter qi1 bars. L4 should be ~ ebd' but length ebd is defined in EC2 for the least
favourable case. In this case the side covers for the qi1 bars are very large. See {12), p. 69. A safe value
would be fl'bd =3.ebd • If L4 <3. ebd, often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every qi1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the qi1 bar cross-section, but their diameter should be such that 3. fibd < L4, where ebd is the
3
anchorage length. The arrangement detail is as in alternative (d).
Particular care should be taken with edge or corner columns, because there either L4 ~ L1, or the two starter
bars per qi1 bar arrangement should be adopted (detail (d)).
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than 4>4•
6. See 1.5 to determine when to use anchor type a, b or cat the end of the 4>4 reinforcing bar.
7. The square base with side length L5 should be at least 15 cm2 to provide for assembly of the column
formwork.
8. Length L2 shall suffice to tie the qi1 starter bars securely to two 4>5 transverse bars. (It may not be less than
2s, where sis the space between 4>5 bars.) •
9. The sole purpose of the starter bar ties is to keep the starter bar assembly firmly in place while the concrete
is cast in the foundations. The starter bar assembly is to be tied at all cross points. These are not the same
ties as in the column.
1 O. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The foundation subgrade must be compacted before the blinding is poured.
13. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
17. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
18. Rectangular spread footings can be set out in exactly the same way, although the resulting grid is logically
not symmetrical.
19. This type of footing is usually cost-effective for large loads. Even in that case, a s 25° to ensure that the
concrete slope can be maintained during vibration.
20. In large footings, top surface reinforcement may be advisable to prevent drying shrinkage and thermal con­
traction.
43
CD-01.05 CIRCULAR FOOTING (CIRCULAR REINFORCEMENT)
NOTE: This footing, out of use for years, has recently made a comeback in windmill
foundations. See also CD-01.06 for a variation of considerable interest.
._... _______ D ---·-----···-···-··-·-·-·-·-·-·--·-··-··-
v
Construction joint
~r,
~
'/_End spacers on one
per five radial bars
h
10 cm
L Asphalt membrane (if any)
CROSS-SECTION
04
05-- . ----+---=--~
05 / '
01~ 0a_J
PLAN
44
See@ @
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN.
(SEE NOTE 3)
ID
®
DETAIL OF STARTER
BAR STIRRUPS.
CD - 01.05 NOTES
1. RECOMMENDATIONS
1. The <1> 1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the <1>1 bar lap length.
3. AR. The starter bars are diameter <1>1 bars. L4 should be 2 Rbd' but length Rbd is defined in EC2 for the least fa­
vourable case. In this case the side covers for the <1> 1 bars are very large. See (12), p. 69. A safe value would
be R'bd =~Rbd • If L4 <~ Rbd, often a more suitable solution than increasing the depth of the footing is to use
3 3
two starter bars for every <1>1 bar in the wall. The sum of the cross-sections of these two bars should not be
less than the <1>1 bar cross-section, but their diameter should be such that ~ fbd < L4, where Rbd is the anchor-
• 3
age length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar cover is
2 10 <I> but not under 10 cm.
4. r, = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <1>0.
6. The L5 wide circular base should measure at least 15 cm to provide a base for the column formwork.
7. Length L2 shall suffice to tie the starter bars securely to the reinforcing bars. (Normally L2 = 2s, where sis the
spacing for circular reinforcement.)
8. The sole purpose of the starter bar ties is to keep the starter bar assembly firmly in place while the concrete
is cast in the foundation.The starter bar assembly is to be tied at all cross points. These are not the same
ties as in the column.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The foundation subgrade must be compacted before the blinding is poured.
12. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
16. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
17. This type of footing is usually cost-effective for large loads. Even in that case, a ::::; 25° to ensure that the
concrete slope can be maintained during vibration.
18. In large footings, top surface reinforcement may be advisable to prevent drying shrinkage and thermal
contraction.
AR. According to EC2, lapping in circumferential reinforcement should be spaced at L5 • Any other length is
preferable. (See (13), (14)).
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
45
CD-01.06 CIRCULAR FOOTING (REINFORCED WITH
TWO WELDED PANELS)
D
v
Construction
joint
Spacer
,.__ Asphalt membrane (if any)
9 ~1 ~: ]\ 9 9 9 ~ ;: ~:
.___ __ Blinding
-
9 ~39 8 9 9 9 9 9 9 9 9 9 9 ~ 9 9
See@
CROSS-SECTION
ty
0.50
PLAN
46
x a
l.O
0
0 2
@
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN.
(SEE NOTE3)
D
®
DETAIL OF STARTER
BAR STIRRUPS.
CD-01.06 NOTES
1. RECOMMENDATIONS
1. The <j>1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the <j>1 bar lap length.
3. AR. The starter bars are diameter <j>1 bars. L4 should be ;:o:fbd' but length fbd is defined in EC2 for the least
favourable case. In this case the side covers for the <j>1 bars are very large. See (12), p. 69. A safe value
would be R'bd =~fbd . If L4 <~ Rbd, often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every <j>1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the <j>1 bar cross-section, but their diameter should be such that ~ fbd < L4 , where fbd is the
3
anchorage length. The arrangement detail is as in alternative {d).This rule can be applied wherever the bar
cover is ;:: 10 <j> but not under 10 cm.
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <j>2 .
6. The L5-wide circular base should measure at least 15 cm to provide a base for the column formwork.
7. Length L2 shall suffice to tie the starter bars securely to the reinforcing bars. (It should not be less than 2s,
where s is the space between bars <j>2).
8. The sole purpose of the starter bar ties is to keep the starter bar assembly firmly in place while the concrete
is cast in the foundations. The starter bar assembly is to be tied at all cross points. These are not the same
ties as in the column.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The foundation subgrade must be compacted before the blinding is poured.
12. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
16. See 1.6 for panel welding.
17. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
18. In large footings, top surface reinforcement may be advisable to prevent drying shrinkage and thermal con­
traction.
2. SPECIFIC REFERENCES
This solution was first used in northern Europe, together with welded panels (see 1.6). It was included in Part 3
of EC2 in 1998 (10). Part 3 presently forms part of EC2 (see 9.8.2.1 ). This solution is only cost-effective in small
footings where the circular trenches can be dug mechanically.
The design is given in (12). Further to those calculations, the total longitudinal reinforcement in each panel can
be found as:
As,tot,x =A = ~
s,tot,y 3itd fyd
where Fd is the design load on the column.
47
CD-01.07 SPREAD FOOTING AND EXPANSION JOINT
r1
f--
Asphalt
Construction
ioint
Off cuts
membrane (if any) subgrade
ELEVATION
a
a
PLAN - TOP REINFORCEMENT
J_
Tr1
-H f--r 1 - .......... -
>-- - See@
r -- , r - - -~ '
' ' '' ,,,
' '' ' ' L -- " L - - -.J -.......... - 04 -1-1- ,..__
>-- 04 r--
/
v
v v
VIEW FROM A
(Reinforcement recommended when
pouring concrete in warm weather).
Establish an area equal to 1 /8 of the
04 main bottom bar.
®
DETAIL OF STARTER
BAR STIRRUPS
L NO r1
f PLAN - BOTTOM REINFORCEMENT
~: See details @@@and@) in CD-01.03
48
CD-01.07 NOTES
1. RECOMMENDATIONS
1. The <j>1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the <j>1 bar lap length.
3. AR. The starter bars are diameter <j>1 bars. L4 should be 2fbd' but length fbd is defined in EC2 for the least
favourable case. In this case the side covers for the <jl1 bars are very large. See {12), p. 69. A safe value would
be f'bd =~fbd . If L4 <~ fbd, often a more suitable solution than increasing the depth of the footing is to use
3 3
two starter bars for every <j>1 bar in the wall. The sum of the cross-sections of these two bars should not be
less than the <j> 1 bar cross-section, but their diameter should be such that ~ fbd < L4, where fbd is the anchor-
3
age length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar cover is
2 10 <j> but not under 10 cm.
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <jl4 •
6. See 1.5 to determine when to use anchor type a, b or cat the end of the <j>4 reinforcing bar.
7. Length L2 shall suffice to tie the <j> 1 starter bars securely to two <j>4 transverse bars. {It may not be less than
2s, where sis the space between <j>4 bars.)
8. The sole purpose of the starter bar ties is to keep the starter bar assembly firmly in place while the concrete
is cast in the foundations. The starter bar assembly is to be tied at all cross points.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils,the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The foundation subgrade must be compacted before the blinding is poured.
12. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
16. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
17. Rectangular footings can be set out in exactly the same way, although the resulting grid is logically not sym­
metrical.
18. Unless calculated in the design, the width of the expansion joint should be 20-30 mm.
19. Reinforcement <l>s is placed to control possible cracking on the top surface between two columns as the tem­
perature drops in the two frames, which pull in opposite directions.
49
CD-01.08
Construction CD
joint \--'----~
Piece of off cuts
tied to the 0 1
bar to secure the
0 3 bars
Scm
STRAP FOOTING
CROSS-SECTION A-A
Blinding
ELEVATION
I -r ~1 ~ ----r -1 ·-·
r
r1 i
-~ >-- Iv ~~+03 5cm
l ·1 ,__ r:3 / b.::
\ T " "
See@
\ " ; II II II II II 11 11 11 11 II II / f I
\ " nl nl nl nl nl i1 i~ i1 -ii , Al nl1 / f I a
6::: \ "
IMl&l\llWWWWWW - - / '-
\ - I \i.' 05
\ ____ --03
Iv -
<---
• ~-
L
I r 1
NOTES:
Reinforcement for column
~ not specified. See
CD-01.03 for details.
See details®@©@ and®
in CD-01.03. h
04
I
_l
PLAN ---
Off cuts
frr.see@
I ,,,,--
50
;--,
I
I
'.J
CD-01.08 NOTES
1. RECOMMENDATIONS
1. The <j>1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the <1> 1 lap bar length.
3. The starter bars are diameter <1>1 bars, except where L4 < fbd' If L4 < fbd' often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every <j>1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the <1> 1 bar cross-section, but their diameter should
be such that ebd' their anchorage length, should be< L4.
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <j>4 •
6. See 1.5 to determine when to use anchor type a, b or cat the end of the <j>4 reinforcing bar.
7. Length L2 must suffice to tie the <j>1 starter bars securely to two <J>5 transverse bars. (It may not be less than
2s, where sis the space between <j>5 bars.)
8. Length L5 is the <j>2 bar anchorage length.
9. If the tops of the beam and footing are flush, the beam should be at least 5 cm less deep to ensure that its
reinforcement does not interfere with the reinforcing bars in the footing.
10. In this case the column starter bars need ties of the same diameter and maximum spacing as in the column.
They differ in size.
11. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
12. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
13. The subgrade is compacted before pouring the blinding for the footing and beam.
14. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
15. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
16. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
17. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
EC2 (5).
51
CD-01.09 SELF-CENTRED EDGE FOOTING
r1
f-----
-
"
v
03
I .
Construction
joint
See@@@
J
Compacted
subgrade Spacer End spacer
ELEVATION
r1 i See@ -0 4
I
-, I
~ f I
_J
-r- -:-1 \
"J/
I
.....
:'.:..I ---
1
_L
rd
a
PLAN
_J . @
.
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN.
(SEE NOTE 3)
-
52
02
b
-I
r1
~
.I
SE .
DETAIL OF STARTER
BAR STIRRUPS.
VIEW FROM A
®
CD-01.09 NOTES
1. RECOMMENDATIONS
1. The <!>, bars rest directly on the top of the footing, with no hooks needed.
2. L, is the lap length in the larger of the reinforcing bars, <!>, or <j>2 . L2 is the<!>, bar lap length.
3. The starter bars are diameter <!>, bars, except where L4 < L,. If L4 < L,, often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every <j>2 bar in the column. The sum of the
cross-sections of these two bars should not be less than the <j>2 bar cross-section, but their diameter should
be such that Rbd' their anchorage length, should be < L4•
4. r, = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <j>3 .
6. See 1.5 to determine when to use anchor type a, b or c at the end of the <1>2 and <j>3 reinforcing bars.
7. The <j>4 distribution steel has a straight extension at the end.
8. Length L5 should suffice to tie <!>, starter bars to <j>2 bars; 20 cm is the suggested length.
9. In this case the column starter bars need ties of the same diameter and maximum spacing as in the column.
They differ in size.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding for the footing and beam.
13. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
EC2 (5).
53
CD-01.10 COMBINED EDGE FOOTING (VARIATION 1)
Asphalt
membrane (if any)
-
-
-
---
a (( 111
di I
~
-
IL61
-1
lb.. I
~-
r~~
3~
LONGITUDINAL SECTION
I I I I I I I
' \
\ -- ·-
:Jr JI:
~ .~
-H
PLAN - TOP REINFORCEMENT
See@ 0 - :.i
-
, -
I "\"'" I
I Ll
- ~
PLAN - BOTTOM REINFORCEMENT -=i
STIRRUP ARRANGEMENTS
f ]
VARIATION1
Skin reinforcement
__r
a
r on 2.5 cm t=~~~~~~~~~-a-
0 5 -->:.:!ll
~o.1Wo cm I .. al ~Lb
r2
10 cm
VARIATION 2
NOTE:
See details@@@@and @in CD-01.03
54
CD-01.10 NOTES
1. RECOMMENDATIONS
1. The <!>, and <1>2 bars rest directly on the top of the footing, with no hooks needed.
2. L, is the lap length in the <!>, bar and L5 is the lap length in the <1>2 bar.
3. AR. The starter bars in the inner column are diameter <j>2 bars. L4 should be 2ebd'but length ebd is defined in
EC2 for the least favourable case. In this case the side covers for the <1>2 bars are very large. See (12), p. 69.
A safe value would be e·bd =~ebd . If L4 <~ ebd, often a more suitable solution than increasing the depth of
3 3
the footing is to use two starter bars for every <1>2 bar in the column. The sum of the cross-sections of these
two bars should not be less than the <j>2 bar cross-section, but their diameter should be such that ~ ebd < L4,
where ebd is the anchorage length. The arrangement detail is as in alternative (d). 3
Particular care should be taken with edge and corner columns, because there either L4 2 L,, or the two starter
bars per <1>2 bar arrangement should be adopted (detail (d)).
4. r, and r3 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than <j>5 .
6. See 1.5 to determine when to use anchor type a, b or cat the end of the <j>4 reinforcing bar.
7. Length L2 shall suffice to tie <I>, or <j>2 starter bars to two <j>4 transverse bars. (It may not be less than 2s, where
sis the space between the <j>4 bars.)
8. In this case the edge <!>,column starter bars need ties of the same diameter and maximum spacing as in the
column. They differ in size. See CD - 01.03 for inner column ties.
9. Sole stirrups may only be used where a:<> 65 cm. If a> 65 cm, multiple stirrups are needed, except where
the concrete absorbs the shear stress entirely. The vertical legs must be spaced at no more than 0.75d :<>
60cm.
10. If multiple stirrups are used, the horizontal legs must overlap along a distance of at least Lb, where Lb is the
<j>5 bar lap length. (This is required for the horizontal leg of the stirrup to act as transverse bending reinforce­
ment.)
11. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
12. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
13. The subgrade is compacted before pouring the blinding for the footing and beam.
14. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
15. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
16. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
17. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2.
55
CD-01.11 COMBINED EDGE FOOTING (VARIATION 2)
a
h
I
Scm
--tr
~
-
11 111111
-
~
~
L
Construction
joint
I L b
1,
V1 ,
==
== 02
~
Scm Scm
--tr-tr-
PLAN - TOP REINFORCEMENT
See (cf)
r., '
11 11 11 11
11 ,I 1 11 ,11 I~· ,I 11 11 ~
II II II IJI Ill II II II I
. .._
PLAN - BOTTOM REINFORCEMENT
a
Asphalt :~ ', , '· ', · '· < , '· < ·, '· ', , ··, ·, '·
membrane (if any) 04 0s See@@©
CROSS-SECTION
-04
11 11
II 11 _
~
BETWEEN COLUMNS AT THE COLUMNS
NOTE: See details@@@@and@ in CD-01.03
56
CD-01.11 NOTES
1. RECOMMENDATIONS
1. The <J>1 and <J>2 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the lap length in the <1>1 bar and L5 is the lap length in the <1>2 bar.
3. AR. The starter bars in the inner column are diameter <1>2 bars. L4 should be 2£bd, but length fibd is defined in
EC2 for the least favourable case. In this case the side cover on the <j>2 bars is usually very large. See (12),
p. 69. A safe value would be fi'bd =~fibd • If L4 <~ fibd, often a more suitable solution than increasing the
3 3
depth of the footing is to use two starter bars for every <1>2 bar in the wall. The sum of the cross-sections of
these two bars should not be less than the <1>2 bar cross-section, but their diameter should be such that ~ fibd
3
< L4 , where fibd is the anchorage length. The arrangement detail is as in alternative (d}. (If the side cover on
the web in the <1>1 or <1>2 bars is less than ten times their diameter, or less than 10 cm, substitute ~ fi bd for fibd
3
in the above formulas.
Particular care should be taken with edge and corner columns, because there either L4 2 L1, or the two starter
bars per <1>2 bar arrangement should be adopted (alternative (d)).
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm 2 <J>5 ; r3 = 2.5 cm 2 <J>6 .
6. See 1.5 to determine when to use anchor type a, b or cat the end of the <J>4 and <j>5 reinforcing bars.
7. Length L2 shall suffice to tie <1> 1 or <1>2 starter bars to two <j>4 transverse bars. (It may not be less than 2s, where
sis the space between <J>4 bars.)
8. In this case the edge column starter bars need ties of the same diameter and maximum spacing as in the
column. The starter bars on the inner columns need ties of the same diameter and maximum spacing as in
the column if the side cover over the T-section web is less than ten times their diameter, or less than 10 cm.
Otherwise two ties suffice (see CD - 01.03) across depth h1 and two along the height of the web.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future
column, where a rough surface such as is generated by the vibrator is needed. The flange-to-web joint is
treated similarly.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The subgrade is compacted before pouring the blinding for the footing and beam.
12. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries. The flange-to-web joint should be treated similarly.
15. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
57
CD - 01.12 STRAP FOOTING AT CORNER (1 of 2)
c
D
~A
0 _:__J
~A
c
~B
~~2.5cm
I~---'---- 05
CROSS-SECTION E-E
CROSS-SECTION F-F
L
D
58
PLAN
r.
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN.
01 --+-tt----1
l===::====i*=l=*==I
1r---tr-t--tt--t-- 02
(See @) ==rr===:r=!'=TI'=1
c
CD- 01.12 NOTES
1. RECOMMENDATIONS
1. The $1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the $1 bar lap length.
3. The starter bars are diameter $1 bars, except where L4 < L1• If L4 < L1 , often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every $1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the $1 bar cross-section, but their diameter should
be such that Lb< L4 , where Lb is the anchorage length. The arrangement detail is as in alternative (e).
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm 2 $4 •
6. See 1.5 to determine when to use anchor type a, b or c at the end of the $2 reinforcing bars.
7. Length L2 must suffice to tie the $1 starter bars securely to two $2 transverse bars. (It may not be less than
2s,where s is the space between $2 bars.)
8. L6 is the $4 bar anchorage length.
9. In this case the column starter bars need ties of the same diameter and maximum spacing as in the column.
They differ in size.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding for the footing and beam.
13. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2.
59
CD- 01.12 STRAP FOOTING AT CORNER (2 of 2)
h
Asphalt ~
membrane (if any)
-.------%1--'-f+r-----t-t---------t--'--YS9f-----'- 2. 5 cm
h
See@@@
02 Blinding'
CROSS-SECTION B-8
@
G)
Construction joint
l3
CROSS-SECTION C-C
2.5 cm-'----l~+---~;...\----H+-'-l'~
See@@@
Blinding
CROSS-SECTION D-D
60
CD- 01.12 NOTES
1. RECOMMENDATIONS
1. The ~1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the ~1 bar lap length.
3. The starter bars are diameter ~1 bars, except where L4 < L1 . If L4 < L1, often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every ~1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the ~1 bar cross-section, but their diameter should
be such that Lb< L4, where Lb is the anchorage length. The arrangement detail is as in alternative (e).
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm 2 ~4 .
6. See 1.5 to determine when to use anchor type a, b or c at the end of the ~2 reinforcing bars.
7. Length L2 must suffice to tie the ~1 starter bars securely to two ~2 transverse bars. (It may not be less than
2s, where s is the space between ~2 bars.)
8. L6 is the ~4 bar anchorage length.
9. In this case the column starter bars need ties of the same diameter and maximum spacing as in the column.
They differ in size.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding for the footing and beam.
13. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
61
CD - 01.13 SELF-CENTRED CORNER FOOTING
-
i I
F-" J
c
a
02
f----
D -
I 2
""'
c
'\
v),_
~
~
"
~
PLAN
v
Construction
joint
r1
D
2.5cm
DETAIL A
r.
ARRANGEMENT WHEN TWO
STARTER BARS ARE USED PER
MAIN BAR IN THE COLUMN
v
01-~~~i=Fi~~~=i=ii§=T-1 r-~~~;:::::::;;=t::::::;:~~~~, '01
fj---~~ 03 h h 03 ~ 02
\TI;~~bdbd~~8-I r2 r2 > See
~~~~~=~~~~--.10 cm 10 cm.---~~~~~-~~m."",,~~~ detail A
CROSS-SECTION A-A
Asphalt
membrane (if any)
See@@©
-~~~~-<-m'~~~~~-+-----.10cm
Spacer
CROSS-SECTION C-C
03
CROSS-SECTION B-B
Blinding ---~
CROSS-SECTION D-D
NOTE: See detail @@@in CD-01.03
62
CD- 01.13 NOTES
1. RECOMMENDATIONS
1. The $1 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the $1 bar lap length.
3. The starter bars are diameter $1 bars, except where L4 < L1 • If L4 < L1, often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every $1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the $1 (bar cross-section, but their diameter should
be such that Lb< L4 , where Lb is the anchorage length. The arrangement detail is as in alternative (e).
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm but not less than $2•
6. See 1.5 to determine when to use anchor type a, b or c at the end of the $2 and $3 reinforcing bars.
7. Length L2 shall suffice to tie the $1 starter bars securely to two $3 transverse bars. (It may not be less than
2s, where s is the space between $3 bars.)
8. In this case the column starter bars need ties of the same diameter and maximum spacing as in the column.
They differ in size.
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The subgrade is compacted before pouring the blinding for the footing and beam.
12. The blinding is floated or smoothed with a float or power float. Its standard 10-cm thickness may be varied
to absorb tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
63
CD - 01.14 COMBINED FOOTING (VARIATION 1)
La
~, ', ---1-1--s2 --1--1--s3 l -06' - Blinding
Asphalt membrane (if any)
End spacer 0 4
03
\ ~
\ ' / I
\
\ ' / I
- - - I
a :~ ]:
.., -r
' /
/ '
Construction
joint
' /
' /
r - -,
:~ ]: .., .,,.
' /
/ '
Le
~
I
Special chair
See@@©
05\ ,'
' '
0a
I
,__r 1
~r1 ~
PLAN - TOP REINFORCEMENT
0 0 s @ 5- rLs-j ee 7
~ ~
' /
n - II
--- ' / II -- - h m-1- I ' / I
I "'- I I
~ '" ' / I" - II - ' / II - u
/ '
PLAN - BOTTOM REINFORCEMENT
VARIATION - 1 Skin reinforcement
(if any)
F OD
<075D--1 ~s0.75d LJ~Lb
s 60 cm VARIATION - 2 s 60 cm
NOTE:
See details@@©@® in CD-01.03
V3
I • -1
Construction
joint
2.5 cmt===~~FF~~~ff~IT-r
0a-~I
r2b~~~~~~~~
~*3
CROSS-SECTION
64
a
h
10 cm
CD - 01.14 NOTES
1. RECOMMENDATIONS
1. The <!>, and <j>2 bars rest directly on the top of the footing, with no hooks needed.
2. L, is the lap length in the <!>, bar and L5 is the lap length in the <j>2 bar.
3. AR. The starter bars are diameter <!>, bars. L4 should be 2£bd' but length £bd is defined in EC2 for the least
favourable case. In this case the side covers for the<!>, bars are verylarge. See (12), p. 69. A safe value
would be £'bd =~£bd . If L4 <~ £bd• often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every<!>, bar in the column. The sum of the cross-sections of these two bars should
not be less than the <!>, bar cross-section, but their diameter should be such that ~ £bd < L4 , where £bd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar
cover is 2 10 <!> but not under 10 cm.
4. r, and r3 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm.
6. See 1.5 to determine when to use anchor type a, b or c at the end of the <j>6 and <j>7 reinforcing bars.
7. Length L2 shall suffice to tie<!>, or <j>2 starter bars to two <j>6 or <j>7 transverse bars. (It may not be less than 2s,
where sis the space between <j>6 or <j>7 bars.)
8. L6 is the lap length in the larger of the <j>3 or <j>4 bars, L7 is the lap length in the larger of the <j>4 or <j> 5 bars and
L8 is the lap length in the larger of the <j>6 or <j>7 bars.
9. Sole stirrups may only be used where a~ 65 cm. If a> 65 cm, multiple stirrups are needed, except where
the concrete absorbs the shear stress entirely.
10. If multiple stirrups are used, the horizontal legs should overlap along a length of at least Lb, where Lb is the
anchorage length of the <j>8 bars. (This is required for the horizontal leg of the stirrup to act as transverse
bending reinforcement.)
11. The sole purpose of the starter bar ties is to keep the starter bar assembly firmly in place while the concrete
is cast in the foundations. The starter bar assembly is to be tied at all cross points. These are not the same
ties as in the column.
12. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
13. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
14. The subgrade is compacted before pouring the blinding.
15. The blinding is floated or smoothed with a float or power float. Its standard 10-cm thickness may be varied
to absorb tolerances in foundation subgrade levelling.
16. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
17. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
18. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
65
CD- 01.15 COMBINED FOOTING (VARIATION 2)
La I 1 Le
_f V2 == i--------~-<
----+----- 02 ==
03
5cm 5cm 04 5cm 5cm 05 f1
• 11 • · 11 --tt---tt--
a }
~4~1 • I IS3 1s:1~1 • I Is~ I S7 I
PLAN - TOP REINFORCEMENT
L See@) - r- 8--j ~ 7 0
' /
"
II
' / II I
JI. v "
II II II I 111 - II II II II II II II II/ II II II II I 111m11 II II II 11---II II II I 111 - 111 II II II II II II I 11 1 1 11 II II
Construction
joint
h
Asphalt membrane
(if any)
NOTE:
' / -
' /
/ '
PLAN - BOTTOM REINFORCEMENT
a
See@@©
See details @@©@® in CD-01.03
66
CD- 01.15 NOTES
1. RECOMMENDATIONS
1. The <j>1 and <j>2 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the lap length in the <j> 1 bar and L5 is the lap length in the <j>2 bar.
3. The starter bars are diameter <j> 1 bars, except where L4 < ~ L1• If L4 <~ L,, often a more suitable solution
than increasing the depth of the footing is to use two starter bars for every <j>1 bar in the column. The sum
of the cross-sections of these two bars should not be less than the <j>1 bar cross-section, but their diameter
should be such that ~Lb < L4 , where Lb is the anchorage length. The arrangement detail is as in alternative
3
(d) The foregoing is equally applicable to <j>2 bars. (If the side cover on the web in the <j>1 or <j>2 bars is less than
ten times their diameter, or less than 10 cm, substitute ~ L1 for L1 in the above formulas).
3
4. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r2 = 2.5 cm 2 <j>8 ; r3 = 2.5 cm 2 <j>9 •
6. See 1.5 to determine when to use anchor type a, b or c at the end of the <j>6 , <j>7 and <j>8 reinforcing bars.
7. Length L2 shall suffice to tie<!>, or <1>2 starter bars to two <j>6 or <j>7 transverse bars. (It may not be less than 2s,
where s is the space between <j>6 or <j>7 bars.)
8. L6 is the lap length in the larger of the <j>3 or <j>4 bars, L7 is the lap length in the larger of the <j>4 or <j>5 bars and
L8 is the lap length in the larger of the <j>6 or <j>7 bars. (Laps need not be used if the commercial length of the
bars suffices.)
9. The starter bars on the columns need ties of the same diameter and maximum spacing as in the column if
the side cover over the T-section web is less than ten times their diameter, or less than 10 cm. Otherwise
two ties suffice (see CD - 01.03) across depth h1 and two along the height of the web.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future
column, where a rough surface such as is generated by the vibrator is needed. The flange-to-web joint is
treated similarly.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding for the footing and beam.
13. The blinding is floated or smoothed with a float or power float. Its standard 10-cm thickness may be varied
to absorb tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries. The flange-to-web joint is treated similarly.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
67
CD- 01.16 TIE BEAM BETWEEN FOOTINGS
PLAN
Seismic area
PLAN
Compacted subgrade
/
/
L Compacted subgrade
VARIATION FOR FOOTINGS CAST IN FORMS I
(See note 11 ) Construction
201 joint
-20, /
h
~>50mm
'20 3=1
Asphalt membrane (if any)
Blinding
CROSS-SECTION A-A
68
CD- 01.16 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm ;::>: cj>1 - cj>2 •
2. r2 = 7.5 cm if the concrete for the footing is poured directly against the soil.
3. In beams cast in an excavation width b should be at least 40 cm, for mechanised excavation.
4. L1 is the cj>1 bar anchorage length.
5. The top of the beam is floated or smoothed with a power float.
6. The bottom of the excavation is compacted before pouring the blinding.
7. The blinding under the footing is floated or smoothed with a power float. Its standard 10-cm thickness may
be varied to absorb tolerances in foundation subgrade levelling.
8. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
1 O. Care should be taken to avoid beam breakage when compacting fill over tie beams.
11. If the footing is cast in forms, footing and tie beams may be cast separately as shown. L2 is the cj>1 bar anchor­
age length.
2. STATUTORY LEGISLATION
See EC2, 9.8.3 (5).
69
CD-01.17 FOUNDATIONBEAM (VARIATION 1)
- -
a 16 ~:
I
-
-
L_
-
f.--
L-l
so.IM/
s60 cm
NOTE:
4\ i-----=-1 5\ t--"-1 6\
I ' I \ I I
I I ' 7 \
' ~-- I 1- - --
:[ jJ: :1~ ]:
~
_,, re... - -A
'
,
, .
PLAN - TOP REINFORCEMENT
0 8 See@ - II - -
" /
n n
II II IR II II " /
lf~/JI_:
~' " / ~I
I .. l
" / - u --
a
II II
II II " /
" " ,
'
PLAN - BOTTOM REINFORCEMENT r1--l f---
f
Skin reinforcement
(if any)
f 0 '1
L-l
~75d
S60 cm
VARIATION - 2
I .. I~ Li,
V3
I • -1
Construction
joint
2.5 cm:j=~~~~s:g~~~H---.
09-~I
r2b~~~~~~~fil < ... 10 cm
~~
01or08
Blinding
See details @@©@® in CD-01.03 CROSS-SECTION
70
CD-01.17 NOTES
1. RECOMMENDATIONS
1. The <j>1, <j>2 and <j>3 bars rest directly on the top of the footing, with no hooks needed.
2. L, is the lap length in the <j>1 bar, L5 is the lap length in the <j>2 bar and L6 is the lap length in the <j>3 bar.
3. The starter bars are diameter <j>1 bars, except where L4 < L1 • If L4 < L1, often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every <j>1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the <j>1 bar cross-section, but their diameter should
be such that Lb< L4 , where Lb is the anchorage length. The arrangement detail is as in alternative (d). For the
inner columns, see CD - 01.03.
4. L8 is the lap length in the larger of the <j>4 or <j>5 bars, L9 in the larger of the <j>5 or <j>6 bars and L10 in the larger of
the <j>7 or <j>8 bars.
5. r1 and r3 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
6. r2 = 2.5 cm ;::: <j>9 •
7. See 1.5 to determine when to use anchor type a, b or c as end anchors.
8. Length L2 shall suffice to tie <j>1, <j>2 or <j>3 starter bars to two <j>7 or <j>8 transverse bars. (It may not be less than
2s, where s is the space between <j>7 or <j>8 bars.)
9. The edge column starter bars need ties of the same diameter and maximum spacing as in the column. For
the inner column starter bars, see CD - 01.03.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding for the footing and beam.
13. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
16. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
71
CD - 01.18 FOUNDATION BEAM (VARIATION 2)
1 La 1 lti 1 Le
~~ I ~~ ~ ~ 0 0 3 ,,;,,,. V1
: _(IJ,_ :: ~-' ,\Construe:~ joint - : _ See ®@©
== 5 L1 0 04 5 C""' == Ls 0 0 "'= L5 0 7 == cnn 1 4 "" == 1 s s 0 5\ScT "'= ,. 6 ;,
.._ ~ 1 1 == "'= r'rf:"
~ ~ ~ 0 1'= / 02 \ 03 ;: I ~0:0hJ1 h
~ l~I ~ "'=" - -- -- -- - - ~ - -- -- ~\ - -- -- == -- -- --~
~ -~
~ ~~·
:s - / ""= I' / ' / == VJ ~I
' . '·· 0'·::::: ::::::::::::::::::·:· ::···::::.:· :::·: ·:· ·::·:·. :. .:·:· ·: _::: -: :-. ::~ :: ::-::::::::. ·:::. :::·:::::::::::::::::::::::::1~: ::i ~~I
~~;~~~::~K::~'~'"~~~:::::::~:~~::;T f·~~~;;":~:~?J T~~~~~
a
PLAN - TOP REINFORCEMENT See@
0, 7 ~ /.-08
I ' /
I I
I ' / I
1111 II
II II I I II II I ' / II II I I II II I II II I I II II I II II " I II II - ' / I ~~
~~ ,, /
I/ ' I
PLAN - BOTTOM REINFORCEMENT
L
a
Construction
joint
See®@®
h
NOTE: See details@@@@and@ in CD-01.03
72
CD - 01.18 NOTES
1. RECOMMENDATIONS
1. The $1, $2 and $3 bars rest directly on the top of the footing, with no hooks needed.
2. L1 is the lap length in the $1 bar, Ls is the lap length in the $2 bar and L6 is the lap length in the $3 bar.
3. The starter bars are diameter $1 bars, except where L4 < L 1. If L4 < L1, often a more suitable solution than
increasing the depth of the footing is to use two starter bars for every $1 bar in the column. The sum of the
cross-sections of these two bars should not be less than the $1 bar cross-section, but their diameter should
be such that Lb< L4, where Lb is the anchorage length. The arrangement detail is as in alternative (d). For the
inner columns, see CD - 01.03. (If the side cover on the web in the $2 bars is greater than or equal to ten
times their diameter, or more than 10 cm, the condition is L4 > ~ Ls . If it is less, L4 > Ls.) The same applies
to $3 .
4. L8 is the lap length in the larger of the $4 or $s bars, L9 is the lap length in the larger of the $s or $6 bars and
L10 is the lap length in the larger of the $7 or $8 bars. (Anchorages need not be used if the commercial length
of the bars suffices.)
5. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
6. r2 = 2.5 cm but not less than $9; r3 = 2.5 cm but not less than $10•
7. See 1.5 to determine when to use anchor type a, b or c as end anchors.
8. Length L2 shall suffice to tie $1, $2 or $3 starter bars to two $7 or $8 transverse bars. (It may not be less than
2s, where s is the space between $7 or $8 bars.)
9. The edge column starter bars need ties of the same diameter and maximum spacing as in the column. The
starter bars on the inner columns need ties of the same diameter and maximum spacing as in the column
if the side cover over the T-section web is less than ten times their diameter, or less than 10 cm. Otherwise
two ties suffice (see CD - 01.03) across depth h1 and two along the height of the web.
10. The top of the footing is smoothed with a float or power float except in the contact area with the future
column, where a rough surface such as is generated by the vibrator is needed. The flange-to-web joint is
treated similarly.
11. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
12. The subgrade is compacted before pouring the blinding.
13. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
14. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
15. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries. The flange-to-web joint should be treated similarly.
16. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
73
CD- 01.19 GRID FOUNDATION (VARIATION 1) (1 of2)
1 - /\-I
- + +- /
\
T \
1 ,~ --
/
11 5cm
I
/ 15 cm 0 14
/ E"t_
/
13' 5cm
"' -05 j\:._06-1
4 I \
' l " I
l J
11 ... /
~cm /
D / i 01~ t /
0
,_,' 014 12 "'
0
~
- ! /
·-···-- t-! I'\ /
\ 7 -T 0s
See detail 3 1
v.
2 - /-
t ·~ v
I/
v
~cm4A ~
~ l,..E 't
~15
B 5cm
,l-/ ~5 cmi=-t
5 ~ I
F I " ~
L ..J "
4s 0 ";)
/
I/
-05
~ 5 C.!!1_.
---._ ~c I
- " ..
I- --< "'\ I
8 - x
PLAN - TOP REINFORCEMENT
Asphalt membrane
(if any)
Construction
/joint
02
74
3 3
03
- _j __________ ~e det
----- -- ~_/~,
)
'--r--- r-----'
017
\ ~cm -
_t-F"\
."\
>---
""'
018
6
v-06 F n
L u v-
\
""' p._cm I"\-
·--- 017
- 018
/ 5cm
7
09
____, - "
-· -
9
ail 2
CD - 01.19 NOTES
1. RECOMMENDATIONS
1. r, = 2.5 cm ~ $, - $3 •
2. r2 = 2.5 cm.
3. r4 and r5 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
4. The $w $13 and $16 bars lie on the $1 , $4 and $7 bars, respectively.
5. The $11 , $14 and $17 bars lie on the $2 , $5 and $8 bars, respectively.
6. If the shear stress cannot be entirely absorbed by the concrete, the stirrups must be arranged in such a way
that their vertical legs are not separated by more than 60 cm or 0.75d. Cross-ties, as shown, or multiple stir­
rups (see CD - 01.17) may be used.
7. If multiple stirrups are used, the horizontal legs must be lapped along a distance of at least Lb, where Lb is the
stirrup anchorage length. (This is required for the horizontal arm of the stirrup to act as transverse bending
reinforcement; see CD - 01.17.)
8. The corner column starter bars need ties of the same diameter and maximum spacing as in the column. Two
stirrups suffice for the inner column starter bars (see CD - 01.03).
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The subgrade is compacted before pouring the blinding.
12. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
75
CD - 01.19 GRID FOUNDATION (VARIATION 1) (2 of2)
La
I •
0 r)A 0 0 1 - 1 /\:~ 3 2 I 1- // 3 I
/
- + j- /
'\ J / I -t-I /
I \: ~ ~ ~
/ /
See detai 1 ,,~ -- -- /
)
0 5 cm J f-~m4A
f.E_cm 013 - E-t_ '.t-E t
5cm B 5cm -0 -1 -1
-- 4 /\. 06 ~5cmi---
4 I ' 5 1 6
T - - " r-
I
" r\
0 5cm
0))
- I 04- I-· 013
D lo 4s
_t'
013 5cm
~c -~· -·
0
-
_L ! ' / - ~ °' I -
- + -H " / F -'-\ ""' I j-
7 I \ ~ ~ -- 8 9
See detail 3 \ 0-r
PLAN - BOTTOM REINFORCEMENT
76
'3
--'
~
..,.--,
-
~
-
Le
-· 1
v-1--
v--
'-- ~----....~
( ) i
',_~- '-·\§ ee
etail 2 d
+-§cm 015
l_t'F
016
····- -------
-
0 6
f-:7
~ 04
+-~cm
I
I 015
i5Cm ,_
-
~
v-
010
DETAIL3
CD- 01.19 NOTES
1. RECOMMENDATIONS
1. r, = 2.5 cm 2 cji, - cji3 .
2. r2 = 2.5 cm.
3. r4 and r5 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
4. The cjiw cji, 3 and cji16 bars lie on the cji,, cji4 and cji7 bars, respectively.
5. The cji,,, cji, 4 and cji17 bars lie on the cji2 , cji5 and cji8 bars, respectively.
6. If the shear stress cannot be entirely absorbed by the concrete, the stirrups must be arranged in such a way
that their vertical legs are not separated by more than 60 cm or 0.75d. Cross-ties, as shown, or multiple
stirrups (see CD - 01.17) may be used.
7. If multiple stirrups are used, the horizontal legs must be lapped along a distance of at least Lb, where Lb is the
stirrup anchorage length. (This is required for the horizontal arm of the stirrup to act as transverse bending
reinforcement; see CD - 01.17.)
8. The corner column starter bars need ties of the same diameter and maximum spacing as in the column. Two
stirrups suffice for the inner column starter bars (see CD - 01.03).
9. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
10. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
11. The subgrade is compacted before pouring the blinding.
12. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
13. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
14. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
15. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
77
CD-01.20 GRID FOUNDATION (VARIATION 2) (1 of2)
1
Le
020
I~
I
10347
L_~
021 D
____j'-
5cm
035
Construction
joint
h
r1f==i,~~~~~~~$W
'/'>n*'7>7'7h~"""~7777'77-J.~-+10cm
01 Blinding
CROSS-SECTION A-A
5cm
4c
PLAN - TOP REINFORCEMENT
r 5 Construction
(Joint
--011
022 °26
CROSS-SECTION E-E
78
CD-01.20 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
2. r2 = 2.5 cm.
3. r3 = 2.5 cm.
4. r4 and r6 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r5 = 2.5 cm.
6. The <j> 17, <j>22 and <j>28 bars lie on the <j> 1, <j>6 and <j> 12 bars, respectively.
7. The <l>w <j>23 and <j>29 bars lie on the <j>2 , <j>7 and <j> 13 bars, respectively.
8. The <j>20, <j>25 and <j>31 bars lie on the <j>4 , <j>9 and <j> 15 bars, respectively.
9. L2 = 20 cm.
10. The corner and edge column starter bars need ties of the same diameter and maximum spacing as in the
column. The starter bars on the inner columns need ties of the same diameter and maximum spacing as in
the column if the side cover over the T-section web is less than ten times their diameter, or less than 1 O cm.
Otherwise two ties suffice (see CD - 01.03) across depth h1 and two along the height of the web.
11. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
12. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
13. The subgrade is compacted before pouring the blinding.
14. The blinding is floated or smoothed with a power float. Its standard 1 0-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
15. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
16. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries. The flange-to-web joint should be treated similarly
17. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
79
CD-01.20 GRID FOUNDATION (VARIATION 2) (2 of2)
La 1
1-1+-++-11+-+11,__1_1
_, _, -- -7 --~-
v
5cm
' .... r - - --1--~..5.
I
021~
Vi
I
i I
Le \ I
I
017 ;'\•
- I T
I
- I I
- I
I
I
I
:
I
;
I
I
L
1-1
I I
:-1
\ _tE
r--026
I 022
- - - --
5c"T
~
5cm
-- - - -
1_
I I
1-1
: :
I
I I
I I
: :
I I
I I
I I
I- I
I I
I-:
-
I I
\
028 See
I>- / detail 2
032
I
See
I -05detail 3
\
- -:::-- --
.. t::':;: L _ _ _ __ _ -- _ _ _ _ __
0
J l L _ _ _ ---- _ _ _ _ J I L _ ::,,,_ ___ --~·
-~- · -1±: +~,··: ~H±::±±:±ll::~l ..... *=±::±~±:'±1-:±~fdiffi:l ±:!~~::±~±::±!:I -:±±1~· ffim~;-:::±!*l!::f:~~~~
7 I 012 - ~016 8 I 012- ~016 9 I 012 \L_016
c
&110270,,
n-050~~60~:1032 n
lb 034 035 035-u
STIRRUP
ARRANGEMENT
PLAN - BOTTOM REINFORCEMENT
~
90° BEND
See@@®
in CD-01.03
Skin
reinforcement
DETAIL 4
80
0a
07~f-ff--~-tt-~-tt-~it-'N
010---10rt1t----tttt----tt1r----t1
NOTES:
See@@®
in CD-01.03
spacer
FOR SIMILAR STARTER BAR LAYOUT AND
COLUMN ANCHORAGE SEE CD-01.08.
BARS WITH SUBSCRIPTS 2, 3, 7, 8, 13, 14, 18,
19, 23, 24, 29 AND 30 CONSTITUTE SKIN
REINFORCEMENT AND ARE PLACED
CONTINUOUSLY ALONG THE ENTIRE SECTION.
CD-01.20 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
2. r2 = 2.5 cm.
3. r3 = 2.5 cm.
4. r4 and r6 are equal to 7.5 cm if the concrete for the footing is poured directly against the soil.
5. r5 = 2.5 cm.
6. The <j> 17 , <j>22 and <j>28 bars lie on the <j>1 , <j>6 and <j> 12 bars, respectively.
7. The <1>18' <j>23 and <j>29 bars lie on the <j>2 , <j>7 and <j> 13 bars, respectively.
8. The <1>20' <j>25 and <j>31 bars lie on the <j>4 , <j>9 and <j>15 bars, respectively.
9. L2 = 20 cm.
10. The corner and edge column starter bars need ties of the same diameter and maximum spacing as in the
column. The starter bars on the inner columns need ties of the same diameter and maximum spacing as in
the column if the side cover over the T-section web is less than ten times their diameter, or less than 10 cm.
Otherwise two ties suffice (see CD - 01.03) across depth h1 and two along the height of the web.
11. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
12. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
13. The subgrade is compacted before pouring the blinding.
14. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
15. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
16. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries. The flange-to-web joint should be treated similarly.
17. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
81
CD- 01.21 FOUNDATION SLAB (1 of 2)
Le
0b1(Top)
0b2(Bottom)
Le
La
rl» B 2 3
---f ;;;+-+ - --C~t- -
I I I
- --fe¥+- - - -{~j---t-
·:o..r·· ~··
A 1 +-+--+-+-+-+-+--+-+--+-+---+-+-+--+--+---+----+---+-+--<>-+-+----+---+->--+-+-+-+-+--+-+---+-+~ A
t t
7 i 48 8 i 0b3(Top) 9 i
0b4(8ottom)
PLAN - GENERAL TOP AND BOTTOM REINFORCEMENT
5 6
----+-+---+--ll---+----+-+-----1--4-
PLAN - SUPPLEMENTARY BOTTOM REINFORCEMENT
82
CD - 01.21 NOTES
1. RECOMMENDATIONS
1. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
2. r2 = 2.5 cm. (The cover over the main reinforcement should not be smaller than its diameter.)
3. L1 is the lap length in the larger of the <j>b3 or <j>b4 bars.
4. L2 is the lap length in the larger of the <j>b1 or <j>b2 bars.
5. The corner and edge column starter bars need ties of the same diameter and maximum spacing as in the
column. Two stirrups suffice for the inner column starter bars (see CD - 01.03).
6. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
7. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
8. The subgrade is compacted before pouring the blinding.
9. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
10. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
11. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
12. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
13. Placement of a polyethylene membrane over the blinding may be advisable to prevent thermal contraction
and shrinkage-induced tensile stress generated by the bond between the slab and the blinding concrete.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
3. SPECIFIC REFERENCES
See (18), (20) and (23).
83
~
Construction
JOint
0b3 Standee r 0b3 0b1
Construction
joint
End
10c:Ilt;'i ::c.: ~ .; .. ::c:.·: ! :·J:;.~ : :·'. r, :;: '.':·.: '.>; .;;e;E;~~~~~
Construction
joint _ 0 b
1
CROSS-SECTION A-A
Standee
Construction
joint
~j'L ' ;; n cle 9 9
1
, , / (5, ' e e e s ?. h c I a e c , I I 4 a p\lc a i !\~ , 2
r I \ ( Q Q Q 8 8 Q~ .5 cm ( I' //
10 cm .. . b2
/ y/;;/····;· / / . 0, \c:O;;.Paci;.; '2
End subgrade
spacer
CROSS-SECTION B-B
NOTES:
~sphalt membrane
(if any)
Anchorage in columns 7 and 8: for similar
details see CD-01.12.
Anchorage in columns 2, 3, 4, 8 and 9: for
similar details see CD-01.08.
Anchorage in columns 5 and 6: for similar
details see CD-01.03.
(See the respective recommendations).
n
0
I
0 ........ .
N ........
'Tj
0
~
tl
~ -~
\/).
l"
~
,,-..__
N
0
.-+i
N __,
CD- 01.21 NOTES
1. RECOMMENDATIONS
1. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
2. r2 = 2.5 cm. (The cover over the main reinforcement should not be smaller than its diameter.)
3. L1 is the lap length in the larger of the cpb3 or cpb4 bars.
4. L2 is the lap length in the larger of the cpb1 or cpb2 bars.
5. The corner and edge column starter bars need ties of the same diameter and maximum spacing as in the
column. Two stirrups suffice for the inner column starter bars (see CD - 01.03).
6. The top of the footing is smoothed with a float or power float except in the contact area with the future col­
umn, where a rough surface such as is generated by the vibrator is needed.
7. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
8. The subgrade is compacted before pouring the blinding.
9. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
10. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
11. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until the surface dries.
12. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
13. Placement of a polyethylene membrane over the blinding may be advisable to prevent thermal contraction
and shrinkage-induced tensile stress generated by the bond between the slab and the blinding concrete.
2. STATUTORY LEGISLATION
This type of footing is not addressed in EC2 (5).
3. SPECIFIC REFERENCES
See (18), (20) and (23).
85
CD-01.22
See detail A
Structural concreteConstruction joint
for placing the
starter bars
____ _,
CAISSON
Construction
joint
C 5/6 concrete
ELEVATION
DETAIL A
86
CD-01.22 NOTES
1. RECOMMENDATIONS
1. The <j>1 bars in the column rest directly on the top of the foundation shaft.
2. L1 is the <j>1 bar lap length.
3. L2 is the <j>1 bar anchorage length.
4. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the foundations. These are not the same ties as in the column.
5. The <j>1 diameter starter bars should be positioned as shown in Detail A. Stability should be monitored during
concrete pouring.
6. In soft soils, the bottom 35 cm should not be excavated until shortly before placing the concrete to ensure
that the soil is not softened by rainfall immediately before pouring the blinding.
7. The foundation shaft subgrade must be compacted before the blinding is poured.
8. The top surface of the C 5/6 concrete should not be smoothed. (The last layer should be vibrated.)
9. The top surface of the foundation is smoothed with a float or power float except in the contact area with the
future column, where a rough surface such as is generated by the vibrator is needed.
10. Before pouring the column concrete, the joint surface should be cleaned and pressure hosed. The concrete
should not be cast until it dries.
11. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
12. Where calculations are very tight, the mid plane in pairs of lapped bars should be perpendicular to the direc­
tion of the greatest bending moment acting on the column springing.
2. STATUTORY LEGISLATION
None, to the author's knowledge.
87
CD-01.23 WALL FOOTING
a
f3 03
STIRRUP
~ ARRANGEMENT
ijtA;00 D 06 0
h HOOK
2.5 cm
f
~
04 ) 05
h1 04
10 cm (Blinding)
90° BEND
Spacer Asphalt
membrane 100 ;::::70 mm
b (if any) I .
I
CROSS-SECTION f.:
DETAIL A
See
detail A
0 I 4 ~ 1 2
' .
01 r-- I
~· I
·1~.
~
0---t-
~ It--~ t---
15 :::m 01 I
-~ -
1~5cm
L04 I I
--
5cm
H_§cm
04
02+0J 04
I I
'
CORNER DETAIL - PLAN
88
CD - 01.23 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
2. r2 = 7.5 cm if the concrete for the footing is poured directly against the soil.
3. r3 = 2.5 cm.
4. r4 = 2.5 cm.
5. The top of the stem and base are smoothed with a float or power float except at the joint, where a rough
surface such as is generated by the vibrator is needed.
6. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
7. The foundation subgrade must be compacted before the blinding is poured.
8. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
9. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
10. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
11. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
89
CD-01.24
SOLUTION A
ELEVATION
CROSS-SECTION
Future cap
Spacer
5cm
10 cm
10 cm
90
BORED PILE
SOLUTION B
ELEVATION
CROSS-SECTION
Future cap
5cm
10 cm
10 cm
CD-01.24 NOTES
1. RECOMMENDATIONS
1. Cover r1 is taken to be 7.5 cm. Under certain circumstances, European standard EN 1536 (24) allows smaller
values for bored piles.
2. Transverse reinforcement shall be tied or welded at all intersections with the main reinforcing bars.
3. The reinforcement should protrude upward from the top of the pile after removal of the concrete above the
cutoff level.
4. At least six cj>1 longitudinal bars should be used. (Five may exceptionally suffice in small diameter piles.)
5. cj>2 2 ~ cj>1 (cj>1 2 16 mm). (See EN 1536 ((24)), which allows smaller diameters.)
4
6. s :S;20cj>1.
7. L1 is the cj>2 bar lap length.
8. Lb is the cj>1 bar anchorage length.
9. The standard 15-cm blinding depth may be changed to absorb levelling tolerances at the bottom of the cap.
10. Wheel spacers should be used and attached to the transverse reinforcement with sufficient clearance to
turn.
2. STATUTORY LEGISLATION
EC2 (5), EN 1536 (24).
91
CD - 01.25
10-15 cm
<?:{25 cm
D/2 ELEVATION
PILE CAP
H<?:{40 cm
1.50
Blinding
SIDE VIEW
See@
in CD-01.03
Panel welded as AR. Maximum eccentricities I per 1.6
I
I/~ /--::::
a TTlill"" 'ii-fr\
, I IL. lJLLl
'- ,__..--
-0
a
PLAN
NOTE: See CD-01.30
See@
in CD-01
02
.03
92
{
5 cm (Intense site supervision)
AR. em., 10 cm (Standard site supervision)
15 cm (Limited site supervision)
(em., is the maximum eccentricity in any
direction)
CD - 01.25 NOTES
1. RECOMMENDATIONS
1. In the following notes, caps are always assumed to be cast into forms.
2. The reinforcement panel rests on the pile surface at the cutoff level.
3. r1 = 2.5 cm.
4. Length L2 shall suffice to tie the <!>, starter bars securely to two <j>2 transverse bars. {It may not be less than
2s, where sis the space between <j>2 bars.)
5. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the cap. The starter bar assembly is to be tied at all cross points. These are not the
same ties as in the column.
6. The top of the cap is smoothed with a float or power float except in the contact area with the future column,
where a rough surface such as is generated by the vibrator is needed.
7. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
8. The cap subgrade must be compacted before the blinding is poured.
9. The blinding is floated or smoothed with a power float. Its standard 15-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
10. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
11. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
EC2 (5), EN 1536 {24).
93
CD-01.26
01
Construction
joint
>{25 cm
- DI D minimum 20
ELEVATION
REINFORCEMENT PANEL
WELDED AS PER 1.6
0 See@
-
D
-1· 2
in CD-01.03
/ - _L'- /
/ "' '--- /
\ II 'l I
\ / ~- - I\
'- '- ~-
I a
PANEL DETAIL
\
\
I
/
94
TWO-PILE CAP
b
Blinding
>{25 cm D - D/2 --1---+------1
SIDE VIEW
b
{
5 cm (Intense site supervision)
emax 1 O cm (Standard site supervision)
15 cm (Limited site supervision)
r~~
(emax is the maximum eccentricity
orthogonal to the plane containing
both axis of piles).
03
b
I~
CD-01.26 NOTES
1. RECOMMENDATIONS
1. In the following notes, caps are always assumed to be cast into forms.
2. The reinforcement lattice rests on the pile surface at the cutoff level.
3. AR. The starter bars are diameter <j> 1 bars. L4 should be ~t'bd' but length t'bd is defined in EC2 for the least
favourable case. In this case the side covers for the <J>, bars are very large. See (12), p. 69. A safe value
would be t''bd =~t'bd" If L4 <~ t'bd' often a more suitable solution than increasing the depth of the cap is to
3 3
use two starter bars for every <j>1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the <P, bar cross-section, but their diameter should be such that ~ t'bd < L4 , where t'bd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule canbe applied wherever the bar
cover is~ 10 <P but not under 10 cm.
4. Length L2 shall suffice to tie the <1>1 starter bars securely to two <j>3 transverse bars. (It may not be less than
2s, where sis the space between cj>3 bars.)
5. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the cap. The starter bar assembly is to be tied at all cross points. These are not the
same ties as in the column.
6. The top of the cap is smoothed with a float or power float except in the contact area with the future column,
where a rough surface such as is generated by the vibrator is needed.
7. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
8. The cap subgrade must be compacted before the blinding is poured.
9. The blinding is floated or smoothed with a power float. Its standard 15-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
10. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
11 . See 1 .2 and 1.3 for descriptions of how to tie bars and place spacers.
12. AR. In large caps, top and side reinforcing grids may be advisable to prevent shrinkage and thermal contrac­
tion cracking.
2. STATUTORY LEGISLATION
See EC2 (5), EN 1536 (24).
95
CD-01.27
H>{40 cm
- 1.50
10 cm
-/­
/
Spacer
THREE-PILE CAP
minimum 20
ELEVATION
\I
I \
I
a
\
PLAN
96
Construction joint
See@
in C0-01.03
Blinding
Cover r1 is regarded to be perpendicular to
the cap surface.
See@
in CD-01.03
§
ff;~
~
~I
\
\
..
0 3
0 2 -
PANEL DETAIL
CD-01.27 NOTES
1. RECOMMENDATIONS
1. In the following notes, caps are always assumed to be cast into forms.
2. The reinforcement panels rest on the pile surface at the cutoff level.
3. r1 = 2.5 cm.
4. AR. The starter bars are diameter <1>1 bars. L4 should be ~ebd' but length ebd is defined in EC-2 for the least
favourable case. In this case the side covers for the <1> 1 bars are very large. See (12), p. 69. A safe value
would be e'bd =3.ebd' If L4 <3. ebd• often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every <1>1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the <1>1 bar cross-section, but their diameter should be such that 3. ebd < L4, where ebd is the
3
anchorage length. The arrangement detail is as in alternative (d}. This rule can be applied wherever the bar
cover is ~ 10 cjJ but not under 10 cm.
5. The L2 length on the starter bars should suffice to tie them to two <1>2 reinforcing bars. (It may not be less than
2s, where sis the space between <1>2 bars.)
6. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the cap. The starter bar assembly is to be tied at all cross points. These are not the
same ties as in the column.
7. The top of the cap is smoothed with a float or power float except in the contact area with the future column,
where a rough surface such as is generated by the vibrator is needed.
8. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
9. The cap subgrade must be compacted before the blinding is poured.
1 O. The blinding is floated or smoothed with a power float. Its standard 15-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
11. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
12. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
13. AR. In large caps, top and side reinforcing grids may be advisable to prevent shrinkage and thermal contrac­
tion cracking.
2. STATUTORY LEGISLATION
See EC2 (5), EN 1536 (24).
97
CD-01.28
H~{40 cm
1.50
10 cm
End
spacer
a
Spacer
20 minimum
ELEVATION
,..--
/ '
I '
I
I
' ' ........ __ ,..,,
a
PLAN
FOUR-PILE CAP
Construction joint
See®
in CD-01.03
,,,.--- .......
' \
I
I
' I
10-15 cm
..
0 3
0 2 -
PANEL DETAIL
See@
in CD-01.03
>{25 cm
- D/2
D
minimum 20
D
' / __ ,.. -t--H------'-
98
CD-01.28 NOTES
1. RECOMMENDATIONS
1. In the following notes, caps are always assumed to be cast into forms.
2. The reinforcement grid rests on the pile surface at the cutoff level.
3. r, = 2.5 cm.
4. AR. The starter bars are diameter <j>1 bars. L4 should be 2£bd' but length £bd is defined in EC-2 for the least
favourable case. In this case the side covers for the <j>1 bars are very large. See (12), p. 69. A safe value
would be £'bd =~£bd' If L4 <~ fw often a more suitable solution than increasing the depth of the footing is
3 3
to use two starter bars for every <j>1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the <j>1 bar cross-section, but their diameter should be such that ~ fbd < L4, where £bd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar
cover is 2 10 <j> but not under 10 cm.
5. The L2 length on the starter bars should suffice to tie them to two <j>2 reinforcing bars. (It may not be less than
2s, where sis the space between <j>2 bars.)
6. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the cap. The starter bar assembly is to be tied at all cross points. These are not the
same ties as in the column.
7. The top of the cap is smoothed with a float or power float except in the contact area with the future column,
where a rough surface such as is generated by the vibrator is needed.
8. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
9. The cap subgrade must be compacted before the blinding is poured.
1 O. The blinding is floated or smoothed with a power float. Its standard 15-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
11. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
12. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
13. AR. In large caps, top and side reinforcing may be advisable to prevent shrinkage and thermal contraction
cracking.
2. STATUTORY LEGISLATION
See EC2 (5), EN 1536 (24).
99
CD - 01.29 GROUP PILE CAP (N > 4)
0 2 -
03
Construction joint
See@
in CD-01.03
Scm
ELEVATION
PANEL DETAIL
See@
'Tr1 CD-01.03 ~{25 cm
ff~-------------+--------------~ ---,-0/2
I
b
...... -- ......
I \
I \
I I
\ / , __ .......
' \
\
I
I
I
/
I
\
'-
0
r1
minimum 20
0
minimum 20
/ --,.------,-, -r---1
/ \
I \
I I
\ / , __ ,,,.,,
a
PLAN
100
CD-01.29 NOTES
1. RECOMMENDATIONS
1. In the following notes, caps are always assumed to be cast into forms.
2. The reinforcement grid rests on the pile surface at the cutoff level.
3. r1 = 2.5 cm.
4. AR. The starter bars are diameter $1 bars. L4 should be ~ £bcl' but length £bd is defined in EC-2 for the least
favourable case. In this case the side covers for the $1 bars are very large. See (12), p. 69. A safe value
would be £'bd =~£bd' If L4 <~ £bd• often a more suitable solution than increasing the depth of the footing is
3 3
to use two starterbars for every $1 bar in the wall. The sum of the cross-sections of these two bars should
not be less than the $1 bar cross-section, but their diameter should be such that ~ Rbd < L4, where £bd is the
3
anchorage length. The arrangement detail is as in alternative (d).This rule can be applied wherever the bar
cover is ~ 10 $ but not under 10 cm.
5. The L2 length on the starter bars should suffice to tie them to two $3 reinforcing bars. (It may not be less than
2s, where sis the space between $3 bars.)
6. The starter bar ties are supports whose sole purpose is to keep the starter bar assembly firmly in place while
the concrete is cast in the cap. The starter bar assembly is to be tied at all cross points. These are not the
same ties as in the column.
7. The top of the cap is smoothed with a float or power float except in the contact area with the future column,
where a rough surface such as is generated by the vibrator is needed.
8. In soft soils, the 25 cm over the level of the future blinding should not be excavated until shortly before pour­
ing the concrete to ensure that the soil is not softened by rainfall immediately before placement.
9. The cap subgrade must be compacted before the blinding is poured.
1 O. The blinding is floated or smoothed with a power float. Its standard 15-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
11. Before casting the concrete, the joint surface should be cleaned and pressure hosed. The concrete should
not be cast until the surface dries.
12. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
13. In large caps, top and side reinforcing grids may be advisable to prevent shrinkage and thermal contraction
cracking.
2. STATUTORY LEGISLATION
This type of pile is not addressed in EC2 (5).
101
CD-01.30 CENTRING BEAM FOR ONE- OR TWO-PILE CAPS
l
'!
I
' .-------'- -!- ___.__---.
-~,
~------:---i~rn~l_---: ----~-
, I
'i-
i
'---~-1-
1
l
ONE-PILE CAP - PLAN
Construction joint
5cm
201 01
Asphalt membrane
(if any)
h
ELEVATION
1~~-Spacer
lf---tij;.;.--- 02
Asphalt Blinding
membrane
(if any) CROSS-SECTION A-A
102
-t---
/' I ' -r-1---\-
I I I
\ I I ' / -- ...........
I
I
~-------: -ID-:---~,_
I
I -r---/ ' / ' \ --.--i-+
\ I I
',J_,,
TWO-PILE CAP- PLAN
Blinding
90° BEND
CD - 01.30 NOTES
1. RECOMMENDATIONS
1 . The beam is assumed to be cast in formwork.
2. r1 = 2.5 cm.
3. r2 = 2.5 cm.
4. r3 = 2.5 cm.
5. L1 is the <1> 1 bar anchorage length.
6. The bottom of the excavation is compacted before pouring the blinding.
7. The top of the beam is smoothed with a float or power float.
8. The blinding is floated or smoothed with a power float. Its standard 10-cm thickness may be varied to absorb
tolerances in foundation subgrade levelling.
9. Where the footing is to be poured on soils that constitute an aggressive medium, it should be protected by
an asphalt membrane as specified.
10. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
11. Care should be taken to avoid beam breakage when compacting fill over centring beams.
12. This beam is built to resist the action effects induced by accidental eccentricity. See CD - 01.25.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See (7).
4. SPECIFIC REFERENCES
See Section 12 in EC2 (5).
103
Group 02
Retaining walls
and
basement walls
CD-02.01 CANTILEVER RETAINING WALLS.
NOMENCLATURE
Stem
Exposed face
Earth face
~--~
Heel
Toe
106
CD-02.01
1. RECOMMENDATIONS
None.
2. LEGISLATION
EC2 makes no reference to this member.
It is mentioned in EC7 (26), but essentially in connection with geotechnical aspects.
3. SPECIFIC REFERENCES
See (23) and (27).
107
NOTES
CANTILEVER RETAINING WALLS.
FOOTING
CD-02.02
Construction v
See@@©
joint 10'
End spacer
h
--~10cm
!
Spacer
Blinding
See@®®®
Asphalt membrane (if any)
r1
r1 - ;---
r1
1--- L3[
R
1 A
® ® ©
r r1
lr1 -ir-
]s0
------/--.,:
]L4
-------1---'
j r1 R R
_j r1 End spacer
(Every fifth bar)
@) @ CD ®
108
CD-02.02 NOTES
1. RECOMMENDATIONS
1. See 1.5 to determine when to use anchorage type a, b or c on the <J>1 reinforcing bars.
2. The use of anchor type d, e, for g in <J>3 bars should be determined on the grounds of the anchorage calcula­
tions. See 1.5.
3. Lower values can be obtained applying table 8.3 F EC-2. Length L1 is 2.0 times the <j> 1 bar lap length
(see EC2, 8.7.3).
4. L5 is the <j>6 bar lap length.
5. r1 = 7.5 cm if the concrete is poured directly against the soil.
6. r2 = 2.5 cm but not smaller than <J>1•
7. If the <J>3 bar diameter is not large and cantilever Vis not overly long, the bars may be tied to the <J>1 and <J>6 bars
to hold them in place, in which case the bar spacing must be coordinated accordingly. Otherwise, special
chairs must be used or solution (g) must be implemented.
8. To keep the <j> 1 starter bars in place during concrete pouring, they should be tied to the <J>5 bars. Similarly, the
<J>6 bars should be tied to the <J>7 bars and, advisably, to the <J>3 bars to ensure stiffness while the foundations
are poured.
9. The top of the foundations is smoothed with a float or power float except in the contact area with the future
vertical member (construction joint), where a rough surface such as is generated by the vibrator is needed.
Before casting the concrete to form the vertical member, the foundation surface should be cleaned and
moistened. The new concrete should not be cast until the surface of the existing concrete dries.
10. In soft soils, the top 25 cm underneath the blinding concrete should not be excavated until shortly before
pouring the concrete to ensure that the soil is not softened by rainfall immediately before casting.
11. The subgrade should be compacted before pouring the blinding.
12. This blinding is floated or smoothed with a power float. Its 10-cm depth can be varied to absorb the levelling
tolerances at the bottom of the foundations.
13. In humid soils that constitute an aggressive medium, an asphalt membrane should be used as specified to
protect the concrete.
14. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. SPECIFIC REFERENCES
See Chapter 5 in (23) and (27).
109
CANTILEVER RETAINING WALLS.
STEM
CD-02.03
2.5 cm 2.5 cm
lr 11~
1 2.5cm
~pacer
See wall crown detail
H
I
I
I
~~
(
0a
07
Spacer
WALL CROWN, DETAIL
05
0a
-t 01
- Chair
m01
Spacer
05
Special chair
I
End spacer
\
\ \__See details @ ® CD cID
\ at CD-02.02
\___ Asphalt membrane (if any)
110
012
016
020
-
CD- 02.03 NOTES
1. RECOMMENDATIONS
1. Length L1 is 1.5 times the cj>1 bar lap length (see EC2, 8.7.3).
2. L5 is the cj>6 bar lap length.
3. r3 (cover of cj>6 ) is 2.5 cm but not smaller than cj>6 •
4. r4 (cover of cj>1) is 2.5 cm but may not smaller than cj>1 if formwork is placed against the soil. r4 = 7.5 cm if the
concrete is poured directly against the soil.
5. In the upper part of the wall, the two grids can be separated with chairs. In high or very high walls, special
chairs must be used.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
7. The cj>8 reinforcing bars are used to control drying shrinkage and thermal contraction at the top of the wall.
2. SPECIFIC REFERENCES
See Chapter 5, (23) and (27).
111
CD-02.04
See wall crown
detail in CD-02.03
50
Spacer
/
\
HEELLESS WALL
See wall crown detail
in CD-02.03 ---------=--1
/
_.>-----nT(l])l"'.'""""cl.U
50 03
01
CANTILEVER RETAINING WALLS.
Construction
joint
VARIATIONS
See wall crown
detail in CD-02.03
-----:J
. ""'
/
50
Construction joint
04 ; 02
l
r-------;;;;;:~~~~~~ 1 End
I I spacer
~~~~~----2 See details
@®CD@in
WALL WITH TOE AND HEEL CD-02.02
Constructionjoint
Construction
joint
Construction
joint
\ \.
r1
,-02
@ CD
~~~~~1
I I
L See details
\_see @CDCD @®CD@ in
CD-02.02
TOELESS WALL
112
CD-02.04 NOTES
1. RECOMMENDATIONS
1. The Recommendations set out in CD - 02.02 and CD - 02.03 are applicable to these variations.
2. For toeless walls, the total length of the <!>, bar that is embedded in the foundations must be greater than or
equal to its anchorage length.
2. STATUTORY LEGISLATION
None in place. EC7 (26) is applicable for calculating thrust only.
3. SPECIFIC REFERENCES
See Chapter 5 in (23) and (27).
113
CD-02.05 CANTILEVER RETAINING WALLS.
KEY
/ ""' ...._ __ !:...., r-~-----1
\ )
Seed~ _ ___,
Spacer
Construction joint
Asphalt membrane (if any)
__l r1
-=r 10 cm
Blinding
DETAIL 1
114
CD-02.05 NOTES
1. RECOMMENDATIONS
1. L1 is the ~9 bar lap length.
2. Cover r1 should be 2.5 cm but not smaller than ~9 .
3. Cover r2 should be 7.5 cm.
4. In soft soils, the top 25 cm underneath the blinding concrete should not be excavated until shortly before
pouring the concrete to ensure that the soil is not softened by rainfall immediately before casting.
5. The subgrade should be compacted before pouring the blinding.
6. The blinding is floated or smoothed with a power float. Its 10 cm depth can be varied to absorb the levelling
tolerances at the bottom of the foundations.
7. A rough surface such as is generated by vibration is needed at construction joint AB, which should not
be smoothed. Before casting the concrete to form the vertical member, the foundation surface should be
carefully cleaned and moistened. The new concrete should not be cast until the surface of the existing con­
crete dries.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place. EC7 (26) is applicable for calculating thrust only.
3. SPECIFIC REFERENCES
See Chapter 5 in (23) and (27).
115
CD- 02.06
CANTILEVER RETAINING WALLS.
CONSTRUCTION JOINTS IN FOOTINGS
~A
r
I I
I I
A-A
MAXIMUM DISTANCE
lrnax. BY SEASON
CLIMATE
WARM I COLD
DRY 12 m 16 m
HUMID 16 m 22 m
NOTE: The joint may adopt the natural slope of the vibrated concrete
(a:::: 25°) or be formed with welded-wire mesh.
116
CD-02.06 NOTES
1. RECOMMENDATIONS
1. With the use of galvanised welded-wire mesh as 'formwork', the resulting joint can be positioned vertically.
2. In this case, the welded-wire mesh should be tied to the reinforcement perimeter and stiffened with pieces
of off cuts steel. (See CD - 02.10.)
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
None in place.
4. SPECIFIC REFERENCES
See Chapter 14 in (23) and (27).
117
CD-02.07
WALL HEIGHT
H:S2.4m
2.40 < H::; 3.6m
H > 3.6m
CANTILEVER RETAINING WALLS.
VERTICAL CONTRACTION JOINTS IN THE STEM
RECOMMENDED DISTANCE BETWEEN
VERTICAL CONTRACTION JOINTS
3H
2H
H (*)
(*)AR. The maximum distance should not exceed 7.Sm
118
CD-02.07 NOTES
1. RECOMMENDATIONS
1. See CD - 02.09 for details.
2. The distances specified entail observance of the minimum shrinkage reinforcement ratios and curing rules.
2. STATUTORY LEGISLATION
EC2 makes no reference to this subject.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (29).
4. SPECIFIC REFERENCES
See (23) and Chapter 14 in (27).
119
CD- 02.08
CANTILEVER RETAINING WALLS.
HORIZONTAL CONSTRUCTION JOINTS IN
ARCHITECTURAL CONCRETE
Lath nailed to liner
Plastic tube ,-
/
Board liner
Tie-rod
Plastic tube
Board liner
Rib
~10 cm
-J-10-15cm
--Ht---+---++--t+---+t--f''l---t--IH -
~t---+--++-++------"..---J+--+-'1--'-+""'--11-.-
Tie-rod
120
CD- 02.08
1. RECOMMENDATIONS
1. The holes in the plastic tube may be:
(a) plugged with plastic stoppers;
NOTES
(b} filled with mortar, except the 3 or 4 cm closest to the exposed surfaces, to be able to identify the holes;
(c) filled flush with mortar.
2. If solution 1 (c) is adopted, a tentative mortar should be prepared by mixing around two parts of the cement
used in the works with about one part of white cement for a perfect long-term blend with the wall colour.
(The proportions should be adjusted as needed by trial and error.)
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (29).
4. SPECIFIC REFERENCES
See Chapter 14 in (27).
121
CD-02.09 CANTILEVER RETAINING WALLS.
VERTICAL CONTRACTION JOINTS
(a)
Waterstop
(d-2)
Induced
crack
40mm
40mm
Asphalt paint
(c)
0
Formwork
(b)
Waterstop
(d-1)
Induced
crack
Wedged strip of wood or
rubber, removed during
formwork release
Triangular lath
Nails
Wire (threaded through the
waterstop) for securing the
waterstop to the reinforcement
during concrete pouring
~--------··---
Waterstop nailed to formwork
during concrete pouring
Wire (threaded through the
waterstop) for securing the
waterstop to the reinforcement
during concrete pouring
122
(e)
0 Induced E
crack E
0
'V
CD-02.09 NOTES
1. RECOMMENDATIONS
1. Joints (a) and (b) can transmit stress. Joint (c) can only transmit horizontal bending stress. Joints (a) and (b)
may require corrosion protection in the area around the reinforcing bar that crosses the crack if significant
amounts of water seep in through the outer side of the member.
2. Joints (a), (b) and (c) are scantly waterproof.
3. Joints (d) and (e) are fully waterproof.
4. Vigorous vibration must be conducted with extreme care around waterstops.
5. The waterstop should penetrate at least 30 cm into the wall foundation. Welding must be performed very
meticulously in long splices.
6. The bevelled and sunken edges in joints (a), (b) and (e) must reduce the wall section by at least 25 per cent
to ensure that the crack will form.
2. STATUTORY LEGISLATION
See ACI (29).
3. SPECIFIC REFERENCES
See Chapter 14 in (27).
123
CD-02.10 CANTILEVER RETAINING WALLS.
EXPANSION JOINTS
CD
® J
Fill
(a)
EXPANSION JOINTS ARE IMPERATIVE IN ALL SOIL TYPE OR
FOUNDATION SUPPORT LEVEL CHANGES.
MAXIMUM INTER-JOINT SPACING, ::;; 25 m.
THEY ARE ALSO NECESSARY IN CHANGES OF DIRECTION,
WHERE THE FILL IS IN THE CONCAVE AREA (CASES (a) AND
(b)) ®·
CD
J
® J
Fill
(b)
Expanded
polystyrene Seal
Expanded
polystyrene
CD
Waterstop
1120-30 mm
(c)
Expanded
polystyrene
Wire (threaded through the
waterstop) for securing the
waterstop to the reinforcement
during concrete pouring
(e)
124
CD
Seal
1120-30 mm
(d)
Waterstop Seal
11 ~0-30 mm
Wire (threaded through the
waterstop) for securing the
waterstop to the reinforcement
during concrete pouring
(f)
CD-02.10 NOTES
1. RECOMMENDATIONS
1. The failure to make J-J joints in (a) and (b) places horizontal tensile stress in the stems and may induce tor-
sion in the footings. In this case, the members affected should be designed accordingly.
2. Expanded polystyrene may be replaced by any readily compressed material.
3. The seal for joint (d) should rest on the polystyrene.
4. Vigorous vibration must be conducted with extreme care around waterstops.
5. The waterstop should penetrate at least 30 cm into the wall foundation. Welding must be performed very
meticulously in long splices.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (29).
4. SPECIFIC REFERENCES
See Chapter 14 in (27).
125
CD-02.11 CANTILEVER RETAINING WALLS.
A
Precast concrete gutter at
the top of the wall to drain
runoff
Asphalt paint or waterproof
membrane
End
spacer
FILLAND DRAINAGE
Mass concrete base
for gutter
Clayey soil surface layer
to seal fill
Geotextile
Permeable granular fill
Geotextile-wrapped grooved
plastic drainage pipe
126
CD-02.11 NOTES
1. RECOMMENDATIONS
1. Angle e must be calculated.
2. Granular fill should be used to ensure effective drainage. Otherwise,the thrust cannot be assessed using the
usual Rankine and Coulomb theories on earth pressure.
3. For water proofing the wall there are two systems, (b), (c). In solution (b), waterproofing consists of a mere
coat of asphalt paint. In (c), a waterproofing membrane is used.
4. Alternative (c) is the solution of choice when watertightness must be guaranteed.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See (27).
127
CD - 02.12
BUTTRESS WALLS.
BUTTRESS NOMENCLATURE AND DISTRIBUTION
Stem
Buttress
Toe
Footin_g .. I Heel
(a)
L t t L L L t t t L t
I..-..--.
1111 11 11 11! I
,,,,_
~,,..
(c)
L t -0 82L t t L t -0 82L t L L t L
11 11 11 11
···--···---·.
I 11
~~ -0.41L
1- ~1L "'~
II II
(d)
128
CD- 02.12 NOTES
1. RECOMMENDATIONS
1. Solution (a) is the standard solution.
2. While distributing the buttress as in (c) means duplication along the expansion joint, the advantage to this
approach is that the formwork is the same for all the cells. Solution (d) calls for different formwork for the cells
alongside joints.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
None in place.
4. SPECIFIC REFERENCES
See Chapter 8 in (27).
129
CD - 02.13
Se~ details @@©
in CD-02.02
BUTTRESS WALLS.
FOOTING
Construction joint
05
Blinding
R
130
End spacer
See detail @
\ Asphalt membrane (if any)
CD- 02.13 NOTES
1. RECOMMENDATIONS
1. L, is 1.5 times the lj>5 bar lap length.
2. L2 is the $8 bar lap length.
3. L3 is the $7 bar lap length. The length that the $7 bars are embedded in the foundations should not be smaller
than their anchorage length.
4. L4 is 1.5 times the lj>8 bar lap length.
5. Lengths L5 and L6 should not be under 2 s, where s is the space between the $2 bars, to ensure that the lj>5
and lj>6 starter bars are tied securely to the grid at the bottom of the foundations. Analogously, the preceding
arrangements are applicable to the lj>7 starter bars and the minimum value of L8.
6. L7 is the $3 bar lap length.
7. Cover r, should be 7.5 cm if the concrete is poured directly against the soil.
8. Cover r2 should be 2.5 cm but not smaller than IJ>,.
9. r4 = 2.5 cm 2 lj>5 •
10. r5 = 2.5 cm 2 lj>6 .
11. To keep the lj>5 , lj>6 and lj>7 starter bars in place during concreting, they should be tied to the lj>3 or lj>4 bars.
12. See 1.5 to determine when to use anchor type a, b or c on the IJ>, reinforcing bars.
13. In soft soils, the top 25 cm underneath the blinding concrete should not be excavated until shortly before
pouring the concrete to ensure that the soil is not softened by rainfall immediately before casting.
14. The subgrade should be compacted before pouring the blinding.
15. The blinding is floated or smoothed with a power float. Its 10-cm depth can be varied to absorb the levelling
tolerances at the bottom of the foundations.
16. The top of the foundations is smoothed with a float or power float except in the contact area with the future
vertical member (construction joint), where a rough surface such as is generated by the vibrator is needed.
Before casting the concrete to form the vertical member, the foundation surface should be cleaned and
moistened. The new concrete should not be cast until the surface of the existing concrete dries.
17. Where the tooting is to be poured against soils that constitute an aggressive medium, it should be protected
by an asphalt membrane as specified.
18. See 1.2 and 1.3 tor descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 8 in (27).
131
CD-02.14
Spacer
Lg
n
BUTTRESS WALLS.
STEM
See wall crown detail
Chair
1-1----05
ff cm -=t r6 =2.5 cm
AR. 0 11 == 20 mm
~~
DETAIL OF WALL CROWN
L1 =2Lb
Construction ·oint
132
CD-02.14 NOTES
1. RECOMMENDATIONS
1. A.R. L1 is 2.0 times the <j>5 bar lap length, Lb. Lower values can be obtained applying table 8.3 of EC2.
2. L2 is the <j>6 bar lap length.
3. L9 is the <j>9 bar lap length.
4. L10 is the <1>10 bar lap length.
5. r4 = 2.5 cm ~ <j>5•
6. r5 = 2.5 cm ~ <j>6 •
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
8. In exposed concrete walls, the solution for horizontal construction joints is as specified in CD - 02.08.
9. Vertical contraction joints are to be made further to CD - 02.07, types (a) or (b) in CD - 02.09, or CD - 02.21.
They will, in any case, be positioned midway between buttresses.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 8 in (27).
133
CD-02.15
A
I\
I I
I I
I I
Chair
Lr"[ _,
-- ---0a \'
~~
" \
~~···
L12L
I'- I'- I'-
I'-' 1, I/ I, 1,
' \'
J --
07
~
' ~. I
I
""'
~ ~ ~ ~ ~ ~
L3j !>- :;\\~
I/ I/ I/ I/ I/ v
'-- "--- "--- '-- '\............. '--- '---~
BUTTRESS WALLS.
INSIDE BUTTRESS
-----
Spacer
I
II
i 1L-+-- Chair I I
DETAIL A
VARIATIONS IN 0 12 REINFORCING
BAR SHAPE
134
r7{=~:=;2~
0a
SECTION A-A
CD - 02.15 NOTES
1. RECOMMENDATIONS
1. L9 is the <j>9 bar lap length.
2. L10 is the <1> 10 bar lap length.
3. L11 is deduced from the <1>12 stirrup anchorage. See variations in arrangement. The <j>12 anchorage length is
counted from its point of entry in the wall.
4. L4 is 1.5 times the <j>8 bar lap length. (Note that the lap length may be conditioned by the use of paired or
bundled bars.)
5. The <j>8 bars rest directly on the top of the foundations.
6. In thick stirrups, the bend radius must not be overly sharp.
7. L12 is the <1>1 bar lap length.
8. L13 is the <j>8 bar lap length.
9. r4 = 2.5 cm 2 <j>5 .
10. r5 = 2.5 cm 2 <j>6 •
11. r6 = 2.5 cm 2 <1>12 •
12. r7 = 2.5 cm 2 <I>. - <1>12 , where <1>0 is the equivalent diameter for bundled bars, if used. (<I>. = <j>8 if no paired or
bundled bars are used.)
13. In exposed concrete walls, the solution for horizontal construction joints is as specified in CD - 02.08.
14. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 8 in (27).
135
CD-02.16
Chair
\i-
\
BUTTRESS WALLS.
END BUTTRESS
~Spacer
r7, actual measured size
136
VARIATIONS IN 0 12 REINFORCING
BAR SHAPE
CD-02.16 NOTES
1. RECOMMENDATIONS
All the Recommendations in CD - 02.15 are applicable, in addition to the following.
1. L14 is deduced from the <j>9 anchorage length.
2. L13 is deduced from the q,10 anchorage length.
3. In exposed concrete walls, the solution for horizontal construction joints is as specified in CD - 02.08.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 8 in (27).
137
CD-02.17
1- B -1
CANTILEVER TRAY
(a)
H
138
TRAY WALLS
Trf!y
Tra
TRAYS MAY BE PRE CAST OR CAST
IN PLACE OVER CORBELS
(b)
CD-02.17 NOTES
1. RECOMMENDATIONS
None.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 9 in (27).
139
CD - 02.18
r1
11 i+A
01
r2
L5L
L2L
r3
Lu
+1
4A
02
TRAY WALLS.
TRAY DETAILS
02
~--!h;:::;::;;±:;~;;;;;;;;;;;;;~=I ~ r1
*'
End spacer
Chair on linear spacers
(a)
03
il=r2 End spacer L4 < {1001
01 Tu 10cm
r2 02
I
0e
=f r4
~r4
204 2041
(b) I min. 2001 + 12 cm
SECTION A-A
[06
30mm
r
140
CD- 02.18 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm z $1 .
2. r2 = 2,5 cm.
3. r3 = r4 = 2.5 cm.
4. L1 is deduced from the $1 bar anchorage length.
5. Ls is deduced from the $3 bar anchorage length.
6. L2 should be s, where s is the spacing between the outer side horizontal bars, to ensure its attachment to
these bars. This should also be the minimum value for Ls.
7. L3 is deduced from the $3 bar anchorage conditions. (See Recommendation 6 in CD - 01.10.)
8. L6 is the $s bar lap length.
9. At its narrowest, the corbel must be wide enoughto support the trays and absorb any tolerances.
10. In solution (a), the trays may be cast in situ in formwork or over the corbels, in turn poured against the fill on
the outer side of the wall.
11. Solution {b) calls for cast-in-place corbels and precast trays.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 9 in (27).
141
CD-02.19
See detail A
02
01+02 05
07
]L1
~ )
L 0 1+03 or 0 1+04
··01or01+03
05··-
01
Special chair
L3l
BASEMENT WALLS.
FACADE FOOTING
Construction joint
Construction joint
r~ -+;.!6
. DETAIL B
NOTE:
See CD-01.03 for column
reinforcement anchorage
''t } 1 ort.
10 c: ~ I ----j. ~---,-----.------L+-____LP---'1-l =f r 2
End spacer 1 S acer
/ Blinding
/See details @@©
DETAIL C
142
\ Asphalt membrane (if any)
in CD-02.02
CD- 02.19 NOTES
1. RECOMMENDATIONS
NOTE: In the remarks below, the same designations have sometimes been used for bars and covers whether
one or two basements are involved. In each case, they should be interpreted as required for the wall
to which they refer.
1. r, = 7.5 cm if the concrete for the footing is poured directly against the soil.
2 {
~ <j>1 and ~ <j>3 (one basement) r6 = 2.5 cm ~ <j>4 r2 = .5 cm
~ <!>4 and ~ <j>5 (two basements)
r3 = 2.5 cm ~ {
<j>5 (one basement)
<1> 1 (two basements)
r4 = 2.5 cm ~ <j>2 (one and two basements)
r5 = 2.5 cm ~ <j>3 (two basements)
r = 7
r = B
{
r3 (one basement)
r5 (two basements)
{ r4 (one basement)
r5 (two basements)
2. The horizontal part of the starter bar anchorage area should be tied to hold these bars in place during con­
crete pouring. A diagonal made of off cuts may be required in addition to the chairs to stiffen the assembly.
For Lw see CD - 01.03, recommendation 3.
3. See 1.5 to determine when to use anchor type a, b or c for bars <j>1, <j>3 , <j>4 and <j>5 •
4. L, is the lap length of the thicker of the <1>2 or <j>3 bars, or of the thicker of the <1>2 or <j>4 bars.
5. L2 is the <j>5 bar lap length.
6. L3 is the<!>, bar lap length.
7. L4 is the lap length of the thicker of the <j>2 or <j>4 bars.
8. L5 is the <j>3 bar lap length.
9. L6 is the <j>4 bar lap length.
1 O. Note that, according to the calculations for a wall in a single basement, the foundations may either be rein­
forced only with<!>, bars or also require <j>3 bars, in which case no <j>4 starter bars are used.
11. L11 is the <j>1 bar lap length (detail B).
12. L12 should be at least 2 s long, where s is the spacing between the transverse bars to which the respective
bar is tied.
13. In detail B, if the two walls in the two basements differ in thickness, they should be tied with bar cutting off cuts.
14. In soft soils, the top 25 cm underneath the blinding concrete should not be excavated until shortly before
pouring the concrete to ensure that the soil is not softened by rainfall immediately before casting.
15. The subgrade should be compacted before pouring the blinding.
16. The blinding is floated or smoothed with a power float. Its 10-cm depth can be varied to absorb the levelling
tolerances at the bottom of the foundations.
17. The top of the foundations is smoothed with a float or power float except in the contact area with the future
vertical member (construction joint), where a rough surface such as is generated by the vibrator is needed.
Before casting the concrete to form the vertical member, the foundation surface should be cleaned and
moistened. The new concrete should not be cast until the surface of the existing concrete dries.
18. Where the concrete is to be poured against soils that constitute an aggressive medium, it should be protected
by an asphalt membrane as specified.
19. In walls enclosing two basements, a rough surface such as is generated by vibration is needed for the horizontal
joints. Before pouring the new concrete, the joints should be cleaned and moistened and the surface allowed to
dry before proceeding.
20. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 1 O in (27).
143
CD-02.20
05
Special chair
V1
05
See detail A
in CD-02.19
See detail A
....___---+--,~~-~D-02.19
01--
05
Special chair
02+04
L3
01--+
See detail H
BASEMENT WALL.
CENTRED FOOTING
05 02
01
~ 05
010
(See recommendations 5 and 11)
Ends acer
DETAIL H
r1il -rrs
Construction "oint
in CD-02.02
144
See details @ ® f 9
in CD-02.02
CD-02.20 NOTES
1. RECOMMENDATIONS
1. r1 = 7.5 cm if the concrete for the footing is poured directly against the soil.
r2 = 2.5 cm { 2 $10 (one basement)
;:: $7 (two basements)
r6 = 2.5 cm ;:: $4
r3 = 2.5 cm ;:: {
$5 (one basement)
$1 (two basements)
r4 = 2.5 cm ;:: $2 (one and two basements)
r5 = 2.5 cm 2 $3 (two basements)
r = 7
r = 8
{
r3 (one basement)
r5 (two basements)
{ r4 (one basement)
r6 (two basements)
2. The horizontal part of the starter bar anchorage area should be tied to hold these bars in place during con­
crete pouring. A diagonal made of off cuts may also be required to stiffen the assembly, in addition to chairs.
For L15, see CD - 01.03, recommendation 3.
3. See 1.5 to determine when to use anchor type a, b or c in <1>1 or $10 reinforcing bars.
4. L1 is the <1>2 bar lap length.
5. L2 is the <l>s bar lap length.
6. L3 is the <1>1 bar lap length.
7. L4 is the lap length of the thicker of the $2 or <1>4 bars.
8. L5 is the <1>3 bar lap length.
9. L6 is the <1>4 bar lap length.
10. L11 is the <1>1 bar lap length (detail B).
11. L12 should be at least 2 s long, where s is the spacing between the transverse bars to which the respective
bar is tied.
12. In detail B, if the two walls in the two basements differ in thickness, they should be tied with bar cutting off
cuts.
13. L13 is the length of in the wall of two basements bars anchorage length.
14. In soft soils, the top 25 cm underneath the blinding concrete should not be excavated until shortly before
pouring the concrete to ensure that the soil is not softened by rainfall immediately before casting.
15. The subgrade should be compacted before pouring the blinding.
16. The blinding is floated or smoothed with a power float. Its 10-cm depth can be varied to absorb the levelling
tolerances at the bottom of the foundations.
17. The top of the foundations is smoothed with a float or power float except in the contact area with the future
vertical member (construction joint), where a rough surface such as is generated by the vibrator is needed.
Before pouring the concrete to form the vertical member, the foundation surface should be cleaned and
moistened. The new concrete should not be cast until the surface of the existing concrete dries.
18. Where the concrete is to be poured against soils that constitute an aggressive medium, it should be protected
by an asphalt membrane as specified.
19. In walls enclosing two basements, a rough surface such as is generated by vibration is needed at the horizontal
joints. Before pouring the new concrete, the joints should be cleaned and moistened and the surface allowed to
dry before proceeding.
20. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 1 O in (27).
145
BASEMENT WALL.
CD-02.21 VERTICAL CONTRACTION JOINT
(a) VERTICAL CONTRACTION JOINT
Angle shaped with formwork
(See CD-02.08) · / 1 ___ L,,__ _1
Wire (threaded through the
waterstop) for securing the
waterstop to the reinforcement
during concrete pouring
\~-----
\
\\
\ Wire mesh (20x20 mm)
\_~~~~E~~~e(j~~etal Waterstop / ----- ____ __}
Expanded metal
\
\
I.
Wire mesh (20x20 mm) /
or expanded metal ~
(a-1)
(a-2)
S acer
Wire (threaded through the
; waterstop)for securing the
I waterstop to the reinforcement
duringconcrete pouring
(b) EXPANSION JOINT (See CD-02.10). The specifications for
expansion joints in basement walls are the same as in retaining
walls
146
CD - 02.21 NOTES
1. RECOMMENDATIONS
1. The solution depicted refers to basement walls that are also foundations, i.e. subjected to vertical bending
stress. In any other case, the solutions set out in CD - 02.09 are simpler and easier.
2. Lb is the $1 bar lap length.
3. Galvanised expanded metal or small-mesh welded-wire 'formwork' must be tied to the grids and stiffened with
off cuts from $3 bars, tied to the $1 bars. Off cuts 12 mm in diameter and spaced at 50 cm suffice and may be
withdrawn before the concrete is poured.
4. Vigorous vibration around waterstops must be conducted with extreme care.
5. The joint must be left open for two days in winter and three in summer in cold, humid environments; and three
days in winter and five in summer in warm, dry climates.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 1 O in (27).
147
CD-02.22
A---+
Construction joint
Scm
r 4 t- ,------t~n-"-..,.,.,
Off cuts for !
securing
bars 01 _,
02
S acer
j:
r3---W-
VARIATION 1
Construction joint
Scm
rd--=-­
Off cuts for I
securing
bars
05~
Spacer
02
VARIATION 2
-04
L1
01. 3
04
03
BASEMENT WALLS.
SPECIAL DETAILS (1 of 2)
r4 i-- .------+~'I+------~--~
Off cuts for
securing
bars
®
Off cuts for
securing
bars
®
148
VIEW FROM A
VIEW FROM B
l
CD-02.22 NOTES
1. RECOMMENDATIONS
1. If the column width is the same or narrower than the wall width, the bond is as shown in detail A. Variation 1
affords a straightforward solution. Variation 2 is an alternative, in which the column is set back by a certain
length from the outer side of the wall (3/4 cm generally suffices) to accommodate the starter bars. (Solutions
involving starter bar deviation may also be adopted. See CD - 03.04, for instance.) (The horizontal reinforce­
ment may have to be strengthened due to the concentration of loads in the column.)
2. The cj>1 starter bars are tied to two straight pieces of off cuts. Care must be taken to ensure that the tips are
covered.
3. The starter bars must have stirrups of the same diameter and spacing as in the column unless the side cover
of concrete over all the bars is ten times their diameter, in which case two assembly stirrups suffice.
4. L1 is the cj>1 bar lap length.
5. If the column protrudes from the wall, its reinforcing bars and respective stirrups must reach into the founda­
tions (see detail G). L2 must be at least 2 s, where sis the spacing between distribution bars in the founda­
tions.
6. See 1.5 to determine when to use anchor type a, b or c in the cj>1 reinforcing bars.
7. The reinforcement is arranged at wall corners as shown in details E and F. L5 is the cj>8 bar lap length.
8. Further to calculations, L6 , which is initially the cj>6 bar lap length, may need to be lengthened to withstand
horizontal bending.
9. See CD - 02.11 for recommendations on fillers, waterproofing and drainage.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 10 in (27).
149
CD-02.22
©
m
See detail H
~7__
( \
I I
\ )
@
®
REINFORCEMENT IN CORNER
OF WALL
BASEMENT WALLS.
SPECIAL DETAILS (2 of 2)
Construction 'oint
I
p
I
p
I
CJ
DETAIL G (Reinforcement in column)
Construction joint
Spacer --See detail ®@ ©
--{- i~CD-_0_2._02 __ ~___..,...---~-.-i
h
R
- 01
End spacer
DETAIL H (Reinforcement in wall)
20cm
H
REINFORCEMENT IN FOOTING
150
CD-02.22 NOTES
1. RECOMMENDATIONS
1. If the column width is the same or narrower than the wall width, the bond is as shown in detail A. Variation
1 affords a straightforward solution. Variation 2 is an alternative, in which the column is set back by a
certain length from the outer side of the wall (3/4 cm generally suffices) to accommodate the starter bars.
(Solutions involving starter bar deviation may also be adopted. See CD-03.04, for instance.) (The horizontal
reinforcement may have to be strengthened due to the concentration of loads in the column.)
2. The q,1 starter bars are tied to two straight pieces of off cuts. Care must be taken to ensure that the tips are
covered.
3. The starter bars must have stirrups of the same diameter and spacing as in the column unless the side cover
of concrete over all the bars is ten times their diameter, in which case two assembly stirrups suffice.
4. L1 is the <1>1 bar lap length.
5. If the column protrudes from the wall, its reinforcing bars and respective stirrups must reach into the founda­
tions (see detail G). L2 must be at least 2 s, where s is the spacing between distribution bars in the founda­
tions.
6. See 1.5 to determine when to use anchor type a, b or c in the <jl 1 reinforcing bars.
7. The reinforcement is arranged at wall corners as shown in details E and F. L5 is the <jl8 bar lap length.
8. Further to calculations, L6 , which is initially the <jl6 bar lap length, may need to be lengthened to withstand
horizontal bending.
9. See CD - 02.11 for Recommendations on fillers, waterproofing and drainage.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 1 O in (27).
151
CD- 02.23
Spacer
\
PLAN
L1
~ 1~
v
02 /
r---
Sp acer
\
l l
ELEVATION
DIAPHRAGM WALLS.
GENERAL REINFORCEMENT
=tr 3
-
--r-J1
~
'
I"
"' ~
152
See detail A
-~
Special chair
R= 20
v0~50mm
DETAIL A
Sp~9_ial chair
r 2 f= L----+----+---~
*}-
SECTION A-A
CD-02.23 NOTES
1. RECOMMENDATIONS
1. r1 =7.5cm.
2. r2 = 7.5 cm.
3. Use revolving wheel spacers, positioned on the horizontal reinforcement.
4. L1 is the $2 bar lap length.
5. The length of L2 can be greater for constructional reasons.
6. A rough surface such as is generated by vibration is needed ai the top.
7. All' reinforcement ties should be welded.
8. The special chairs should be welded to the $2 bars.
9. See 1.4 for welding details.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
153
DIAPHRAGM WALLS.
CROWN BEAM
CD-02.24
b
Construction ·oint
Special chair
154
CD-02.24 NOTES
1. RECOMMENDATIONS
1. For the diaphragm wall, see CD - 02.23.
2. The construction joint surface is cleaned and moistened before pouring the concrete for the beam. The beam
is cast when the surface of the joint dries.
3. The top of the beam is smoothed with a float or power float.
4. If b > 65 cm, use multiple stirrups.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
155
CD-02.25
. I r2.L+-
DIAPHRAGM WALL-BEAM BOND
(VARIATION 1)
Steel plate -:f:. 1 Omm
0 5 spaced at s
I ' I I f
--t-t-1
ELEVATION
But_t_weld
DETAIL A
11 ··· · -- 0 5 spaced at s
--1>.----
··-min. 20 cm
S acer
PLAN
156
CD-02.25 NOTES
1. RECOMMENDATIONS
1. See Recommendations in CD - 02.23.
2. r1 = 7.5 cm; r2 = 2.5 cm; r3 = 2.5 cm; r4 = 2.5 cm; r5 = 2.5 cm.
3. See 1 .4 for welding details.
4. Particular care is needed when welding <J>3 to <j>2 and <j> 1 bars.
5. Ensure plate attachment stiffness. In any event, the design for the plate-beam bond must make allowance
for plate sliding and shifting when the diaphragm wall concrete is poured.
6. L1 is the <j>3 bar lap length.
7. L2 is the <j>4 lap length.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
157
CD-02.26
§P.~_ce_r __
DIAPHRAGM WALL-BEAM BOND
(VARIATION 2)
Bar straigh~ened in this direction
0 5 spaced at s
r-~-+-, ---~+-~-l----\--~~~_.__- =tl4
\
I
\
\ Bar ~_tr_ai_g_htened in this direction
ELEVATION
Construction joint r--
r2
Spacer
PLAN
158
CD-02.26 NOTES
1. RECOMMENDATIONS
1. See Recommendationsin CD - 02.23.
2. r1 = 7.5 cm; r2 = 2.5 cm; r3 = 2.5 cm; r4 = 2.5 cm; r5 = 2.5 cm.
3. See 1 .4 for welding details.
4. The <j>3 bars designed to be straightened are to be welded to the <j>1 and <j>2 bars and must be left uncovered
at the inner side of the diaphragm wall.
5. Radius R should be the standard bend radius.
6. Ensure plate attachment stiffness. In any event, the design for the plate-beam bond must make allowance
for plate sliding and shifting when the diaphragm wall concrete is poured.
7. L1 is the <j>3 bar lap length.
8. L2 is the <j>4 lap length.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in {27).
159
CD- 02.27
See detail @© ©
for 0 3 bars
Spacer ------
DIAPHRAGM WALL-BEAM BOND
(VARIATION 3)
Void left by wood or expanded
polystyrene void former
-\ -03
.,.,...,._ __ -++-.....,-rr---"'IJ'liiiiiiiiijo~----~--...._'([>111/~G
111 ul n' -t
111 111 111
1r 1r 1r
II II II
II II II
II II II
II 11 II
II II 11
II 11 11
----+J-----fl----fl-e--- 0 5 spaced at s
w
ELEVATION
Spacer
Construc.QC'.?n joint
PLAN
160
®
l~------
1
I
I
... t-
1
I
I
r-
1
I
I
\~-----
(~-----
1
I
I
-t-
1
I
I
' I
I
I
\~-----
©
I
I
I
I
CD-02.27 NOTES
1. RECOMMENDATIONS
1. See Recommendations in CD - 02.23.
2. r1 = 7.5 cm ; r2 = 2.5 cm ; r3 2 $3 ; r4 2 $4 ; r5 2 $3 ; $5 2 $4 •
3. The void formers must be carefully tied to the diaphragm wall cage. In any event, the design for the plate­
beam bond must make allowance for void formers and shifting when the diaphragm wall concrete is poured.
4. Before casting the concrete to form the vertical member, the concrete around the void area should be
cleaned and moistened. The new concrete should not be cast until the surface of the existing concrete dries.
5. Special care must be taken during concrete pouring and compacting in the void area.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
161
CD-02.28 DIAPHRAGM WALL-SLAB BOND
(VARIATION 1)
S acer
Steel plate ~ 10 mm
See detail A in CD-02.25
See detail ® @ @ __ f<:>~_!!!_~_ 0 9 bars
I
/09
~"""""----""Hi-41~~~~~""!-~--"':"""~~=i=~
----010
r4-J__
I '
~
_Spacer
ELEVATION
PLAN
II _____ u_ -
-----rr---
11
II
II II -- __ u ______ u__
-----11-------IT-
ll II
II II
~1-------1...=~~=~~-=i=~=~~=~=
II II
II 11
II II __ u _______ u.__
- --rr-------rr-
11 II
II 11
II II
II 11 __ u _______ u__
--11-------IT-
ll II
II II
l"9-.... ------r- - 11 5 cm : : -- --$-------ll--- --11 -----IT-
F~====- - - II
c=======
II II
II II
II II _____ u _______ 1_1_
~=c~==f==~~-.. ----~-------~-
11 II
II 11
II 11 _____ u _______ 1...L_
--"- ---- - -,,.--
1 11
II 11
II I
II I
II I
0 6 spaced at s
162
s0[
®
R
©
CD-02.28 NOTES
1. RECOMMENDATIONS
1. See the Recommendations in CD - 02.23 for the diaphragm wall.
2. r1 = 7.5 cm ; r2 = 2.5 cm ~ <j>9.
3. r3 = 2.5 cm ~ <j>4•
4. r4 = 2.5 cm.
5. See 1.4 for welding details.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
163
CD-02.29 DIAPHRAGM WALL-SLAB BOND
(VARIATION 2)
~A
==~r====,r====TI=====n
II II II 11
II II 11 I
JI II II 11 IJ
__ Jl ____ j~---- 1: II 11
--~r----,r----~=====~=====~===
II II 11 11 II
II II II II
==~~====~~====~=====~=====~===
IJ II II 11 11
II rr IJ II II
ll II II 11 11
___ :.L ____ J~--- l: II 11
--~rT---,r---=TI=====~=====~===
:t ~ :: :: :: II
II II 11 11 ::
II II 11 11 II
__ _1.,L ____ ..JL ____ .LI
--~r- - ,r----n=====~=====~===
II II II 11 11
II II 11 rt II
ELEVATION
I
I
I
I
I
SECTION A-A
~..,. ...... ...118:F--~-~;;.;;,;;..;;.~;;.;;.;;.., ... .., __ .,._
I
I
I
I
I
I
I ""'...iit------.... 111~----y---~.;.y;;~.;;.;i ...................
I
I
I
I
I
I
I
~--i----..ltlllll"lp----,-~;.;;.;~~=;;i,,/ol-•-..a.-
1
r4-t-
PLAN
164
Construction joint
I L1
Spacer
PERSPECTIVE
CD-02.29 NOTES
1. RECOMMENDATIONS
1. See the Recommendations in CD - 02.23 for the diaphragm wall.
2. For the bend radius R see Table T-1.1.
3. The <j>3 bars are welded to the vertical diaphragm wall reinforcement. They must be uncovered on the inner
side, to be readily visible with superficial chipping.
4. See 1.4 for welding details.
5. r1 = 7.5 cm.
6. r2 = 2.5 cm.
7. L1 is the lap length of the thicker of the <j>3 or <j>5 bars.
8. L2 is the lap length of the thicker of the <j>3 or <j>6 bars.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
165
CD-02.30
Spacer
WALLS. DRAINAGE CHAMBER AND
CHANNEL IN DIAPHRAGM WALL
Brick wall
Chair
166
CD-02.30 NOTES
1. RECOMMENDATIONS
1. This is the solution to be used to prevent water from seeping across the diaphragm wall.
2. The detail shows a diaphragm wall-slab bond analogous to the bond described in CD - 02.28. The system
can be adapted to any other circumstance.
3. The channel should slope toward the downpipes.
4. Openings must be left in the brick wall to allow water seeping across the diaphragm wall to evaporate.
2. STATUTORY LEGISLATION
None in place.
3. SPECIFIC REFERENCES
See Chapter 11 in (27).
167
Group 03
Columns and joints
CD- 03.01 COLUMNS SPRINGING FROM THE FOOTING.
r
A
r
B
Construction
joint
----i
A
Construction
joint
----i
~=1==: --8 ls cm
See CD-01.03 for
footing details
TIE BAR ARRANGEMENT
Construction
-joint--
VIEW FROM A
~ a
SECTION A-A
HOOK
SECTION B-B
20
goo HOOK goo BEND
s < 40 cm {
20 01
THE SMALLER OF a OR b
NOTES:
s SHOULD BE REDUCED TO 0.6 s IN TRANSVERSE
SECTIONS AT A DISTANCE FROM THE COLUMN
OF LESS THAN THE LARGEST TRANSVERSE
DIMENSION COUNTING FROM THE BEAM OR
SLAB. IN LAP AREAS IF 0 <!16mm,A MINIMUM OFTHREE
TIES IS REQUIRED.
0 1 IS THE DIAMETER OF THE THINNEST
LONGITUDINAL BAR.
170
CD- 03.01 NOTES
1. RECOMMENDATIONS
1. L, is the cl>, bar lap length. L2 is the cj>2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r, = 2.5 cm.
4. Cover r2 may not be less than cj>,.
5. The tie bars are bent in the starter bars and hooked in all others.
6. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
7. See CD - 03.16 for tie bar shapes and bar layouts.
8. See 1.2 for bar tying procedures and 1.3 for spacer placement.
9. Before pouring the concrete for the column, the bottom joint should be cleaned and moistened, and the new
concrete should not be cast until the existing concrete surface dries.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
171
CD-03.02
Construction
--iornt\ :=;====
['-. /
A .. -
~?==
5cm J_ I~
! :=;===
~~ ,'~
j -- ~
I°"
5cmr- -
Sp~
r
A
r1 - I -
...
L2 r
B
,
!
I '-
COLUMNS IN INTERMEDIATE STOREYS.
~
--
L1
---- Ts1
~"'"
_!s1
"'~Constructio
joint
02
.... v.----
-i
A
....... T
i S1
__ __l_
r2
>----
Construction
II joinf--
I; -i
- ~--15 cm
n
TIE BAR ARRANGEMENT
Construction
-Tofnt
VIEW FROM A
SECTION A-A SECTION B-8
100 ~70 mm
h
20 20
t
~ ~\J: ~"'"
HOOK goo HOOK goo BEND
\\ -Construction /
joint
j
S2J
__ 1 __
/
,
I
--,5cm
03
~
NOTES:
20 01
s s 40 cm
THE SMALLER OF a OR b
s SHOULD BE REDUCED TO 0.6 s IN TRANSVERSE
SECTIONS AT A DISTANCE FROM THE COLUMN
OFLESSTHANTHELARGESTTRANSVERSE
DIMENSION COUNTING FROM THE BEAM OR
SLAB. IN LAP AREASIF 0 ~16mm.A MINIMUM OFTHREE
TIES IS REQUIRED.
0 1 IS THE DIAMETER OF THE THINNEST
LONGITUDINAL BAR.
172
CD-03.02 NOTES
1. RECOMMENDATIONS
1. L1 is the <1> 1 bar lap length. L2 is the <1>2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 :::: <1>2 •
5. The tie bars are bent in the starter bars and hooked in all others.
6. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
7. See CD - 03.16 for tie bar shapes and bar layouts.
8. See 1.2 for bar tying procedures and 1.3 for spacer placement.
9. Before pouring the concrete for the column, the bottom joint should be cleaned and moistened, and the new
concrete should not be cast until the existing concrete surface dries.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
173
CD - 03.03
- ......
~~
j
Semi
~
r
A
r1 - ~
~
L1 r .. B '
I
A
I
_J_s1
·"'-
"~t;mstructio
joint
Spacer
01
,_V-
--i
A
Qs1
r2 ,__
COLUMNS IN TOP STOREY.
n
TIE BAR ARRANGEMENT
Construction
joint
VIEW FROM A
a
SECTION A-A SECTION B-B
Construction
Se-~ 100H mm
~00 ~=== I/ joint
I! --i
20 20 20
8 Scm ----·---~I I
b
M-1: "'~ ,>..
HOOK goo HOOK goo BEND
\\
~
Construction ,/
joint
s~r=
/
'
I
~--·--1 5 cm
02
v--
{
20 01
s:S 40 cm
THE SMALLER OF a OR b
NOTES:
s SHOULD BE REDUCED TO 0.6 s IN TRANSVERSE
SECTIONS AT A DISTANCE FROM THE COLUMN
OF LESS THAN THE LARGEST TRANSVERSE
DIMENSION COUNTING FROM THE BEAM OR
SLAB. IN LAP AREAS IF 0 ::>:16mm.A MINIMUM OF THREE
TIES IS REQUIRED
0 1 IS THE DIAMETER OFTHE THINNEST
LONGITUDINAL BAR
174
CD-03.03 NOTES
1. RECOMMENDATIONS
1. L, is the <J>, bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r, = 2.5 cm.
4. Cover r2 ~ <J>,.
5. The tie bars are bent in the starter bars and hooked in all others.
6. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
7. See CD - 03.16 for tie bar shapes and bar layouts.
8. See 1.2 for bar tying procedures and 1.3 for spacer placement.
9. Before pouring the concrete for the column, the bottom joint should be cleaned and moistened, and the new
concrete should not be cast until the existing concrete surface dries. Analogously, the top joint should be
cleaned and moistened before pouring the concrete for the lintel.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
175
CD-03.04
t! .r
A
INTERMEDIATE JOINT IN EDGE COLUMNS
(VARIATION 1)
T5cm
1.§ cm
1.
A
Construction
joint
04
{
tan as 1/6
AR. If tan a> 1/6 use CD-03.05
SECTION A-A
SECTION C-C
R=20 or
3.50
r1
SECTION B-B
'
I
L3 i
I
0
~
~
VIEW FROM A
100 ~70 mm
ii
Fr
HOOK 90° HOOK 90° BEND
176
{
2001
s s 40 cm
THE SMALLER OF a2 OR b2
{
20 02
t s 40 cm
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0<::16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD-03.04 NOTES
1. RECOMMENDATIONS
1. L, is the<!>, bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r, = 2.5 cm.
4. Cover r2 :2: <j>2 •
5. To calculate lengths L3 and L4 , see EC2, anchorage lengths.
6. The tie bars are bent in the starter bars and hooked in all others.
7. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2 for bar tying procedures and 1.3 for spacer placement.
10. Angle a is understood to be the actual measured magnitude. According to EC2, tie bars need not be calcu­
lated if tan a ~ J_ . ACI 318-08 simply recommends tan a ~ _!_ .
12 6
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
177
CD-03.05 INTERMEDIATE JOINT IN EDGE COLUMNS
(VARIATION 2)
A-+
See
@@©
!
L1 I
L
Construction
joint--
P':'.'hc~""i':"'~
5cm
VIEW FROM A
100 ~ 70 mm
H
t
R = 20 or
3.50
Off cuts
FF
HOOK goo HOOK goo BEND
178
{
This CD is used when in CD-03.04
AR. tan a> 1/6
If tan a> 1/6 use CD-03.06
a1
:-~~----1
IF~~~!
SECTION A-A
SECTION C-C
R = 20 or
3.50
!
i b1
s s 40 cm
SECTION B-B
'
~~
A A
{
2001
THE SMALLER OF a2 OR b2
{
2002
t:::;; 40 cm
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0:2:16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD-03.05
1. RECOMMENDATIONS
1. L1 is the tj>1 bar lap length. L2 is the tj>2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 2 tj>2•
5. To calculate lengths L3 and L4 , see EC2, anchorage lengths.
6. The tie bars are bent in the starter bars and hooked in all others.
7. For tie bars in the joint, see the respective details.
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2 for bar tying procedures and 1.3 for spacer placement.
10. Angle a is understood to be the actual measured magnitude.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
179
NOTES
CD - 03.06 INTERMEDIATE JOINT IN EDGE COLUMNS
(VARIATION 3)
r1_
Construction 8
joint \
Ar+ r
IC
5cm~
See t
@@©/
See ~
detail1
Construction / v
joint
L2
t~
r1_
,f
A
t~
I' " /
-
s T
B
_j I I L, 1.c [\ 03
[/ ' I/ '- I
I ' -- -- /
M '({ / r I
\
LA- -1
/
115cm
~ '\
['._
"~ l-5 cm
~ 04
Off cuts
~ ['._ "'
~ i---·-- r----· 02
,.__ - _fa
1.
A
1--1, 50 I Construction
A
~
~ joint r
~~~':-:Ji.-!-~ 5 cm 1'I
VIEW FROM A DETAIL 1
{
This CD is used when in CD-03.04 tan a > 1/6
R. and when in CD-03.05 tan a 1 >1/6
SECTION A-A
50I
SECTION C-C
R=20
or 3.50
s s 40 cm
SECTION 8-8
' .
I
L3 I
I
'
{
2001
THE SMALLER OF a2 OR b2
t s 40 cm
HOOK goo HOOK goo BEND
{
20 02
THE SMALLER OF a1 OR b1
180
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0<::16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
>.
CD - 03.06 NOTES
1. RECOMMENDATIONS
1. L1 is the 4> 1 bar lap length. L2 is the 4>2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. The tie bars are bent in the starter bars and hooked in all others.
5. For tie bars in the joint, see the respective details.
6. Cover r2 :::>: 4>2 •
7. To calculate lengths L3 and L4, see EC2, anchorage lengths.
8. See 1.2 tor bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
181
CD - 03.07
r1
Construction
joint
A_.
See St.
a (6) c +-"I~=-===!>
Constructio
joint
t
SECTION A-A
I
Se 100 :2: 70 mm
L3
A
INTERMEDIATE CORNER JOINT
(VARIATION 1)
AR. {it tan a> 1/6 use CD-03.08
tana.:51/6
I s0J
A
Construction
jofn_t_
VIEWFROM A
R=20 or
3.50
s s 40 cm
µR >.
,..
~so H
~'/'""> fi;= ~
~ (0 (0
{
2001
THE SMALLER OF a2 OR b2
{
20 02
t s 40 cm
THE SMALLER OF a1 OR b1
HOOK goo HOOK goo BEND
182
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF Ql~16 mm, A
MINIMUM OFTHREETIES IS REQUIRED.
'211 AND '212 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD-03.07 NOTES
1. RECOMMENDATIONS
1. L1 is the <1>1 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 ?: <j>2•
5. To calculate lengths L3 and L4 , see EC2, anchorage lengths.
6. The tie bars are bent in the starter bars and hooked in all others.
7. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2 for bar tying procedures and 1.3 for spacer placement.
10. Angle a is understood to be the actual measured magnitude.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
183
CD - 03.08 INTERMEDIATE CORNER JOINT
(VARIATION 2)
Construction ----,
joint A,P-
A _.
See@@©
Construction _ ·
-----------~
jo~
1.A
R = 20 or L1
3.50
15 cm t ~====~~=$ ~ 5 cm
. ~=====~~M~--'?J~3 __
L2 L_r1- 0~ Off cuts
a1 r-----------<
j a2
I~~~~~
I
b21
__L~~~~
SECTION A-A
A
I
L3
I
~
~
A A
100 ~ 70 mm
H
FF
HOOK 90° HOOK 90° BEND
184
{
This CD is used when in CD-03.07
AR. tan a> 1/6
If tan a 1 > 1 /6 use CD-03.09
r
L1 i ~~===9"'1
I l_ ~~=le
Construction
joint
VIEW FROM A
R = 20 or
3.50
~JR
A
{
20 01
s s 40 cm
THE SMALLER OF a2 OR b2
{
20 02
t s 40 cm
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0~16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD - 03.08 NOTES
1. RECOMMENDATIONS
1. The limitation on angle a is understood to be the actual spatial magnitude. The main bars are on different
planes in this arrangement. Reinforcement schedules should be formulated with care. The arrangement
specified does not reduce bending strength in the lap area.
2. L1 is the <1> 1 bar lap length. L2 is the <1>2 bar lap length.
3. See Tables T-1.1 and T-1.2 for bend radii.
4. Cover r1 = 2.5 cm.
5. Cover r2 ;:o: <j>2 •
6. To calculate lengths L3 and L4, see EC2, anchorage lengths.
7. The tie bars are bent in the starter bars and hooked in all others.
8. For tie bars in the joint, see the respective details.
9. See CD - 03.16 for tie bar shapes and bar layouts.
10. See 1.2 for bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
185
CD - 03.09 INTERMEDIATE CORNER JOINT
(VARIATION 3)
Construct
····················Joint
r1 -
ion
·- --·-·,,
r A .. A
5cmJ __
-t-
/ See@)(l?)@ /
See .... /~
aetan1
,~c.-
T
.,t
!
2
Construction
··Joint ~
tI
r1_
-
1,- AR·
' _~_Js " ["' /
~
'
\ --iA L1
~- 03
I\
/ I; I/'.'-
'
k '{( j I \
\
Ls H
/
~5cm
"" ~"\ ['-..
~
I- 5cm
04
Off cuts
!'!'- t~
~- ............. _
1----·-1-·
~,02
-·
',_
---+-=
_r2
---+ ........ -
Construction · JoinT __ _
! L 1 f- ... --~---1
'
{
This CD is used when in CD-03.07 tan a > 1/6
and when in CD-03.08 tan a 1> 1/6
SECTION A-A
50
II
~0or I JJ0
DETAIL -1
VIEW FROM A 0
HOOK
100;:: 70 mm
f----'
I
FF
90° HOOK 90° BEND
186
{
20 01
s s 40 cm
THE SMALLER OF a2 OR b2
{
20 02
t s 40 cm
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0~16 mm, A
MINIMUM OF THREE TIES IS REQUIRED
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS_
CD - 03.09 NOTES
1. RECOMMENDATIONS
1. L1 is the $1 bar lap length. L2 is the $2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 ~ $2 •
5. To calculate lengths L4 and L5, see EC2, anchorage lengths.
6. The tie bars are bent in the starter bars and hooked in all others.
7. For tie bars in the joint, see the respective details.
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2 for bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
187
CD- 03.10 FACADE OR CORNER JOINT ON LAST STOREY
'
r
sl
_l __ I
I
/
/
Construction/
joint
--------
r1 - -··
.r
A
S-e
1~0
~/00
II
0
Li
;
;
... r
i
I L3
I
L1 I
;
----r 5 cm
- 1--5cm
01
-~----- v-,.. r .• - 2
]s
1.
A
'
20
HOOK goo HOOK goo BEND
NOTES:
;-
s SHOULD BE REDUCED BY A FACTOR OF 0.6 IN TRANSVERSE
SECTIONS AT A DISTANCE FROM THE COLUMN
OF LESS THAN THE LARGEST TRANSVERSE
DIMENSION COUNTING FROM THE BEAM OR
SLAB. IN LAP AREAS IF 0 <::16 mm. A MINIMUM OF THREE
TIES IS REQUIRED.
0 1 IS THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS_
188
.
r-- ~ -j
r1 I .
~I
.
~// .
f
!b
i
_l
l-- a
I
SECTION A-A
{
2001
s:::; 40 cm
THE SMALLER OF a OR b
CD - 03.10 NOTES
1. RECOMMENDATIONS
1. L2 is the lap length of the thicker of the <1>1 or <1>2 bars.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 ~ <1>1•
5. To calculate length L1, see EC2, anchorage lengths.
6. L3 should not be shorter than the <1> 1 bar anchorage length.
7. See CD - 03.16 for tie bar shapes and bar layouts.
8. See 1.2 for bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 {22) and (15).
189
I
I .
-
'
CD-03.11
' r1 _
I~
A,f
sl
_L I' '-
Construction
--·-·-
·····Joint··············~
Scm~
I/" /
a
INSIDE JOINT IN INTERMEDIATE STOREYS
(VARIATION 1)
'
"'v
1.A
{
tan as 1/6
AR. If tan a> 1/6 use CD-03.12
/
- .. T
I
j L1
1.s I
'
- . I
St ·- ~~ ~
.~ SECTION A-A
J
=
11~
Scm-- /
S~m~ ?L2
Construction/
joint
r2 - ,__
.r
c
' r
100 ~ 70 mm
1---1
20
HOOK 90° HOOK
St
~ ,..
St
-
:---s cm
---~----..... 02
r --
I - 1
I
LJ_t
1.
c
60~70 mm
i-1
"'
I
""" ,.,
• - ill ~
~ ~ ~
,., ..
SECTION B-B
The position of
hook and bend
should alternate
up the column l -- ·----------·---- 1
20
90° BEND
190
AR VARIATION SECTION C-C
s s 40 cm {
20 01
THE SMALLER OF a2 OR b2
{
20 02
t s 40 cm
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0~16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD-03.11 NOTES
1. RECOMMENDATIONS
1. L1 is the «1>1 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 2 cj>2•
5. L2 is the lap length.
6. The tie bars are bent in the starter bars and hooked in all others.
7. As a rule, the tie bars in the upper and lower lengths of the column can be used in the joints if appropriately
slanted (solid line). Otherwise, special tie bars are needed (dashed line).
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2for bar tying procedures and 1.3 for spacer placement.
1 O. Angle a is understood to be the actual measured magnitude.
11. The variation shown in section C-C, taken from ACI 318-08 (22) greatly simplifies placing of the reinforce­
ment. It may not be used in areas subject to seismic risk.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
191
CD-03.12 INSIDE JOINT IN INTERMEDIATE STOREYS
(VARIATION 2)
I
A ..
' r1
t.,.___····•
...... -- !'--
A
' I/ ,,,
"' / i.. A
L1 ~~=====~l ___ J s
AR.
This CD is used when in CD-03.11 tan a > 1/6
This CD is applicable in soffit beams and flat
slabs. In flat slabs, no column ties are needed at
the joint None are needed in soffit beams either if
the side cover on the vertical bars is at least 10
times their diameter and no less than 10 cm
Cons~r~ction , 8 .f 1. 8 See detail 1
JOlnt '~~ /~
5 cm i +-~ ... I/ , v'/ R = 20 or 3.50
I C._'" i, /'I !-"
~H
50
5 cm~ :; v J / I./ -. 5 cm
Construction// $~/~ ,/,~./:.~~~~~,_ 1- 5 cm
joint 11~ ~ ~::,,. v-- L3
Off cuts ~ .__~ :
,.,-'/ __ l
- ·-··-·· .. . .... ~======·-·---==· . ~·==···· ·==·-==········=;··-~
/ _,_r1
1. c t c .r
.
~
I r2 .
L1
Construction
joint
02
s s 40 cm
VIEW FROM A
01
re}
{
20 01
THE SMALLER OF a2 OR b2
{
2002
t s 40 cm
SECTION A-A
I 50 i
~0or I J.J0
DETAIL 1
SECTION B-8
SECTION C-C
192
THE SMALLER OF a1 OR b1
NOTES:
s AND t SHOULD BE REDUCED BY A FACTOR OF
0.6 IN TRANSVERSE SECTIONS AT A DISTANCE
FROM THE COLUMN OF LESS THAN THE LARGEST
TRANSVERSE DIMENSION COUNTING FROM THE
BEAM OR SLAB. IN LAP AREAS IF 0<:16 mm, A
MINIMUM OF THREE TIES IS REQUIRED.
0 1 AND 0 2 ARE THE DIAMETERS OF THE THINNEST
LONGITUDINAL BARS.
CD-03.12 NOTES
1. RECOMMENDATIONS
1. L1 is the <1> 1 bar lap length. L3 is the <1>2 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. Cover r2 ;:>: <1>2 .
5. L2 is the lap length.
6. The tie bars are bent in the starter bars and hooked in all others.
7. For tie bars in the joint, see the respective details.
8. See CD - 03.16 for tie bar shapes and bar layouts.
9. See 1.2 for bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
193
CD-03.13 INTERMEDIATE JOINT IN CIRCULAR COLUMNS
~--
~
f4B If tan a:::;; 1/6 (actual magnitude)
'
.r
A
L1
5 cmJ_
5cm~
~
-,..---.-·-··
t
-~
I
0s I __ J
I -,
.. /
/
4B
I
! I
r--...._~ I
Ls I
A
/
'\.
/
1.
A
Construction
v--jOinf ---
04 r-
a __,.. -·
I
~~~cm
T
~ ~3
~Construction
joint ····
"
~~--<?';?
- J1
- ,!2
SECTION A-A
194
fr
I' / =:Is
1.
A L1
Consj~~~tion ~
04
J_ !'>... '
v----
p I y ...
R = 20 or I - I
·······-·-
3.50 I I 03 I I
I I v--I I
02
I I
I I I
~ ttH~/
1/.- ______ J
L,[
~ / '
_ _l
SECTION B-8
CD- 03.13 NOTES
1. RECOMMENDATIONS
1. L1 is the <1>1 bar lap length. L2 is the <j>3 bar lap length.
2. See Tables T-1 .1 and T-1 .2 for bend radii.
3. Cover r1 = 2.5 cm.
4. The tie bars are bent in the starter bars and hooked in all others.
5. L3 is the <j>2 bar lap length.
6. The joint calls for special tie bars.
7. See 1.2 for bar tying procedures and 1.3 for spacer placement.
8. Angle a is understood to be the actual measured magnitude.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
195
CD - 03.14
T
·········-··---
I r
L1 ! A
i
l i-1
St+ -
St I j
St
L
5 cm -I
! I/
t :
l_
I
~
~B
'
L2
'
4B
'
,/
'\.
TRANSITION FROM CIRCULAR TO
RECTANGULAR COLUMNS
/
]s
1.
A Construction
// joint
.L 5cm
L1
Construction
joint 304
2.5 cm +~=r----L.11!-~~~----· ~=~ii 1
~ I
,_
T5cm
~ ;-····· 5 cm
I
/03
If tan a S 1/6
(actual
magnitude)
~9onstruction
~~02
joint
'-
--: J1
- .!2
.,
SECTION B-B
50~50 mm
H
f;;0or I °"'~
DETAIL 1
SECTION A-A
196
CD-03.14 NOTES
1. RECOMMENDATIONS
1 . L1 is the $1 bar lap length. L2 is the $3 bar lap length.
2. See Tables T-1.1 and T-1.2 for bend radii.
3. Cover r1 = 2.5 cm.
4. The tie bars are bent in the starter bars and hooked in all others.
5. L3 is the $5 bar lap length.
6. The joint calls for special tie bars.
7. See 1.2 for bar tying procedures and 1.3 for spacer placement.
8. Angle a is understood to be the actual measured magnitude.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
197
CD-03.15
/~
L
Construction
joint
CORNER JOINT IN LARGE SPAN PORTAL FRAMES
5cm
k-----r
5cm
198
CD-03.15 NOTES
1. RECOMMENDATIONS
1. To calculate length L2 , see EC2, anchorage lengths.
2. L1 is the lap length of the thicker of the <1>1 or <1>2 bars.
3. Bar <j>3 reinforces the web. It has a conventional anchorage (L3). An arrangement calling for 20 <j>3 ;;:.: 15 cm is
suggested.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
None in place.
199
CD - 03.16
(a) n=4
s135°
(e) n=8
~t
S15 cm l_
BAR ARRANGEMENT AND SHAPES OF TIES
IN COLUMNS
(b) n=6
(f) n=10
J
>15 cm
L
60:?:70 mm The position of
(c) n=6
~ T rr===d= hook and bend
1_ ~ should alternate
up the column
AR. VARIATION
s1s1cm
_I_
1-------1 s 15 cm
(d) n=8
r See variation
/
(g) n=10 (h) n=12
[[~ I[ .~J ~: ] [ X JI : I[ ll
~---1 s1s cm f----.j >15cm
(i) n=14 (j) n=12
200
CD - 03.16 NOTES
1. RECOMMENDATIONS
1. See CD - 03.01, CD - 03.02 and CD - 03.03 for the distribution of tie bars along the column, cover and
spacers, respectively.
2. The maximum spacing between longitudinal reinforcing bars is 35 cm (not specified in EC2}.
3. The tie bars should brace the longitudinal reinforcement at an angle of ::; 135Q (details (e), (f), (g) and (h}}
(not specified in EC2).
4. AR. Only every other bar need be braced if they are spaced at more than 15 cm (details (c), (j)). This provi­
sion is laid down in ACl-318-08 (22).
5. The general principle is that the smallest possible number of bars should be used (see CD - 03.17 on pos­
sible bundling).
6. In long columns, the use of thick bars is advisable, with preference given to detail (i) over detail U) arrange­
ments.
7. Rather than very thick tie bars, the use of bundled ties is recommended.
8. When two or more ties are used, different shapes may be jointed or staggered at 10 cjJ, provided ties of the
same type are spaced within the maximum allowable distance. This second solution is preferable when,
following the preceding recommendation, double ties are used rather than four-ties.
9. Complex tie bar arrangements lead to segregation during concrete pouring and consequently to lower con­
crete strength.
2. STATUTORY LEGISLATION
This subject is scantly dealt with in EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
201
CD-03.17
:::;35 cm
.
: ;
~ I"
I I .
8 BARS
BUNDLED BAR ARRANGEMENTS
See variation
................ ·-·-·-· ......... ·-··--··· ··--··\
in CD-03.16 \
\
---\1 12-15 cm
12 BARS 16 BARS 16 BARS
--1 ~5 cm --1 ~5 cm . --l ~5 cm --1 ~5 cm
See variation-+-----~
in CD-03.16
20 BARS 20 BARS 24 BARS 24 BARS
--1 ~5 cm >15 cm ··--l r-215 cm
28 BARS 32 BARS 36 BARS
0
(Seenote5)
202
CD-03.17 NOTES
1. RECOMMENDATIONS
1. In 20-<j> tie bar spacing, where <j> is the diameter of the main reinforcement, <j> is defined to be the diameter of
the individual bars comprising the bundle. Note that the maximum spacing between bundles is 35 cm.
2. For tie bar diameter, "> ]_" , where <j> is the equivalent diameter of the thickest bundle (see Table T-1.8
't' 4 't'e e
for equivalent diameters for bundles).
3. Rather than very thick tie bars, the use of bundledpairs of tie bars is recommended.
4. When two or more tie bars are used, different combinations (such as the 24-bar solution shown opposite)
may be bundled or staggered at 24 <j>, provided ties of the same type are spaced within the maximum allow­
able distance. This second solution is preferable when, following the preceding recommendation, double tie
bars are used rather than four-tie bundles.
5. Note that the bundle cover may not be smaller than the equivalent diameter, but must be measured to the
actual physical position of the bars in the bundle.
6. See 1.2 for bar tying procedures and 1.3 for spacer placement.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
203
CD - 03.18
-
-
I
I
5cm r--1
5cm
r
A
r
B
5cm
~ !--
ARRANGEMENT OF LAPS IN COLUMNS
WITH BUNDLED BARS
i
--1 s cm !
I
I
-i D A
SECTION A-A
L1
-i
B
204
(a)
l
PLAN VIEW OF 90° ~
HOOK STARTERS STARTER BAR
(b)
=r1.3~
_11.3~
=r1 .3Li,
(c)
D
SECTION 8-B
CD-03.18 NOTES
1. RECOMMENDATIONS
1. The column over-width with respect to the beam should be carefully studied to ensure that the reinforcing
bars do not interfere with one another at beam-column crossings (detail (a)).
2. In one-storey columns, the four bars in a bundle may all be active (detail (b)).
3. L1 should be greater than or equal to the group anchorage length (L1 = 1.3 Lb, where Lb is the anchorage
length of the individual bars).
4. L2 should be less than double the spacing between bars in the footing grid.
5. Since no more than four starter bars can be accommodated in several-storey columns, the most suitable
solution is to butt splice (but not weld) the bundles from the second storey up, which entails assuming only
three bars for strength calculations. While the fourth bar is merely a splice bar, it is more practical to place it
along the entire length of the bundle than in the splice area only.
2. STATUTORY LEGISLATION
See EC2.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and (15).
205
CD-03.19
EDGE SCHEDULE.
COLUMN SCHEDULE
~------------~
I I
I I
I I
I I
I I
~------------~-------------~============~ I I
I I
I I
I I
~============~============~============~ I I
I I
I I
I I
I I
t1r-------------f0-------------~------------~
PLAN OF STRUCTURE
B C r-1 Column with reference at vertex B
Vertical lines to
AL_J and sides AB and BC
be maintained in
all the height of -<
the building
8 EJ Column with reference at side AB
and centreline
A
~ Column with reference at centreline
COLUMN
1-3-5-9
2-4
6-8-10-12
13-15-20
14-16-17 -18
-19
Ground
2{D
I 35 -~
6 BARS
A
STOREY
206
35x 25
612120 - B
Tiesl2l6mm
to 20 cm
2{D
I 35 I
6 BARS
B
CD-03.19 NOTES
1. RECOMMENDATIONS
1. With the schedule shown, a clear indication can be given of the loads transmitted on each storey.
2. Note that cases ABC and AB appear not only in corner and edge columns, but in many other circumstances
(such as courtyards, stairwells or machinery shafts, to name but a few).
3. The position of the reinforcing bars in each column is specified by an 'A' or 'B' in the respective cell on the
column schedule.
A diagram to distinguish between A and B should be included in a note attached to the schedule.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
None in place.
207
Group 04
Walls subjected to axial loads
CD- 04.01
WALLS, SHEAR WALLS AND CORES.
GENERAL ARRANGEMENTS
Spacer·~
HORIZONTAL SECTION
@ MINIMUM THICKNESS
HORIZONTAL SECTION
@WALLS REINFORCED ON
ONE SIDE ONLY
i r1
~=rr±=f===7T~~==tr-~==~=1 =t
~~~~J
, L0 f r1
1 ::; 50 cm 1 1
~--·-· .. 1
HORIZONTAL SECTION
r1' 1\02
+-F===;;="==F~===~i====1 ~ f2
~ r2 d::= i===~===±=F====~==j
r11 01 Spacer
HORIZONTAL SECTION
@COVER
HORIZONTAL SECTION
@WALLS WITH e ~ 25 cm
(REINFORCEMENT MANDATORY
ON BOTH SIDES)
HORIZONTAL SECTION
a) On the horizontal plane the cross-ties should be placed alternately on each side with the 90° hooks.
b) The 90° hooks should be placed alternately in the vertical direction.
\ __
::>50 cm -
j j A A
v v v v
' '
' '
~,.. ~~
;02
I
1
::; 50cm
I' I' '
~,.. ~,..
/--02
' '
'
-01
~,.. ~,,..
' '
_J ~01
~,.. ~,..
' ' ' ' I' '
A j A A
y y v '
@ELEVATION CD ELEVATION
s0;::: 50 mm
-+---+-~
Js0~70mm
TIE DETAIL
210
CD- 04.01 NOTES
1. RECOMMENDATIONS
1. For ease of pouring and to prevent segregation, the minimum recommended thickness is 15 cm. Nonethe­
less, particular care is required when pouring walls with e < 25 cm.
2. r1 = 2.5 cm; r2 :::: Q>2 •
3. AR. Structural calculations permitting, where e < 25 cm the reinforcement may be placed on one side only
(the outer side if the wall is a facade). Where e ~ 25 cm, reinforcement is needed on both sides. The re­
quired drying shrinkage and thermal contraction ratios must be observed. See details (c) and (d).
4. If the geometric ratio of the <j> 1 vertical reinforcement is ~ 2 per cent, Q> ~ 16 mm, or if welded-wire mesh rein­
forcement is used with a cover of 2 <j>, no tie bars are required. Otherwise, four ties per m2 are required.
5. AR. If the conditions specified in recommendation 4 are not met, and:
(a) <j>1 ~ 12 mm, tie bars must be spaced, horizontally and vertically, at no more than 50 cm; or
(b) Q> > 12 mm, and in all cases where vertical compression reinforcement is needed, tie bars must be placed
at all intersections and spaced vertically at no more than 20 Q>1•
6. See CD - 02.08 for horizontal construction joints in exposed concrete.
7. If vertical contraction joints are required, see CD - 02.09 and in particular, CD - 02.21.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. Recommendations 3 and 5 are taken from ACI 318-08 (22).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22), which deals with the subject more extensively than EC2 (5).
211
CD-04.02 WALLS, SHEAR WALLS AND CORES.
Construction joint
v--
-,,.. ,...
& &
@FOOTING SPRINGLINE
See detail 1 Co~-~~~uction joint
@ BOND TO ROOF SLAB
I
t- -
--?-
0 0 0 0
& &
' p
"' I>"
' A
p
'
DETAIL 1
See detail 3
Construction
joint
@) ROOF JOINT
212
JOINT DETAIL
Construction joint
5 cm t- ,.......__..__....~--L---1 +----<
1--- ------ 3 --- 03
02 0 5 See detail 2
@HORIZONTAL JOINT
ON STOREY
Construction joint
I
' p -
<
' 0
&
'
~
"'~acer
A
v
DETAIL 2
' 0 - " "
~"""
' 0 0 0
a
' 0
.. °'
' _A 0
v
DETAIL 3
CD-04.02 NOTES
1. RECOMMENDATIONS
1. For cover, minimum thickness and the need for and placement of ties, see CD - 04.01.
2. Foundation springing a) is built exactly as described in CD - 01.01. See the recommendations included
therein as well.
3. L1 is the $1 bar lap length.
4. L2 is the lap length in the thicker of the $4 or $5 reinforcing bars; is the lap length L3 in the thicker of $3 or $5
bars; $5 is equal to the thicker of the $3 or $4 bars.
5. L4 is the lap length in the thicker of the $4 or $5 bars; L5 is the lap length L5 in the thicker of the $5 or $6 bars;
$6 is equal to the thicker of the $4 or $5 bars.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22), which deals with the subject more extensively than EC2 (5).
213
CD-04.03 WALLS, SHEAR WALLS AND CORES.
CORNERS, JOINTS AND EDGES
See detail 1
' A ' A
~~
• . • .
-r-- 03
~ p '~ L3 -- 5cm
p '
~p '~
l 01
p '
02
A
v
HORIZONTAL SECTION DETAIL 1
(a) CORNER DETAIL
See detail 2
HORIZONTAL SECTION DETAIL 2
(b) JOINT DETAIL
1---------- L3 -------j See detail 3
f: :
HORIZONTAL SECTION DETAIL 3
(c) EDGE DETAIL IN SHEAR WALLS
214
CD-04.03 NOTES
1. RECOMMENDATIONS1. For cover, minimum thickness and the need for and placement of tie bars, see CD - 04.01.
2. In detail (a), L1 is the lap length in the thicker of the cj>4 or cj>5 bars; and L2 is the lap length in the thicker of
the bars. cj>3 or cj>5• The cross-ties are tied to the horizontal reinforcing bars. cj>5 is equal to the thicker of the
cj>3 or cj>4 bars.
3. In details (a), (b) and (c), L3 is the lap length in the horizontal reinforcement. The hairpins are tied to the
intersecting horizontal reinforcing bars.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22), which deals with the subject more extensively than EC2 (5).
215
CD-04.04 WALLS, SHEAR WALLS AND CORES.
DETAIL OF OPENINGS
203
See detail A
See detail B
-----·-·
AR. + 2::lii;::: 60 cm ELEVATION
i /203
' ' I 2::lii;::: 60 cm
--+-----~
1- L1 --1 02
20'-<tt: : : : t~
\ ~
\ --01
• A
\
\_--203
DETAIL A
.. See cl~t?ti1_1J
A
-203
b ---i
203 1-­
-T-~'k--~-~~
e
_L_ .___..__ __ ___.
SECTION B-B
SECTION A-A
DETAIL 1
502::50 mm
~'----+---, !~__..~I J ~~
Spacer
TIES HOOK
~· 2::lii ;::: 60 cm
4-c
• B
DETAIL B
@
SECTION C-C
216
90° BEND
'
'
See detail 2
DETAIL2
CD-04.04 NOTES
1. RECOMMENDATIONS
1. For cover, minimum thickness and the need for and placement of tie bars, see CD - 04.01.
2. In details A and B, the anchorage length is diameter ~3 .
3. L1 is the lap length in the ~2 horizontal reinforcement. The cross-ties are tied to the vertical reinforcing bars.
4. In detail B, L2 is the ~1 bar lap length. The cross-ties are tied to the vertical reinforcing bars.
5. Care must be taken in areas such as Min detail B. If b:::; 40 , for all intents and purposes, such areas must be
designed as if they were columns. See CD - 03.16.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22), which deals with the subject more extensively than EC2 (5).
217
CD- 04.05 WALLS, SHEAR WALLS AND CORES.
SPECIAL DETAILS FOR SLIP FORMS (VARIATION 1)
~A
ELEVATION
n ~ !!,
1 I 1 I 1 I 1 I
====11====1~====:r===~~==
====~:====~: ====~!====~: ==
II II II II
II II II II
====oil==== =i±o=====ll= ====!lo== II II II II
II II II II
PLAN
218
SECTION A-A
I
I --
- I
I
I --
- -L---
---,---
1
I
I
---~<~2------
PERSPECTIVE
CD-04.05 NOTES
1. RECOMMENDATIONS
1. L1 is the lap length in the thicker of the <j>3 or <j>4 bars.
2. L2 is the lap length in the thicker of the <j>3 or <j>5 bars.
3. <j>3 is equal to the thicker of the <j>4 or <j>5 bars.
4. <j>2 bars should be in the bent position, securely tied to the grids and in contact with the formwork.
5. After the forms are stripped, contact surface AB is superficially chipped and the hairpins are straightened.
6. The <j>2 bars are tied to <j>4 and <j>5 bars, which must be designed to the same spacing.
7. See 1.2 and 1.3 tor descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22), which deals with the subject more extensively than EC2 (5).
219
CD-04.06 WALLS, SHEAR WALLS AND CORES.
SPECIAL DETAILS FOR SLIP FORMS (VARIATION 2)
TRANSVERSE CROSS-SECTION
Polystyrene in void area
along the entire length
of the slab
~.· .. ?:!~
~ ··¥
:~·~
~--t~I~
5cm
DETAIL A
220
CD-04.06 NOTES
1. RECOMMENDATIONS
1. L1 is the <j>3 bar lap length.
2. L2 is the <j>6 bar lap length.
3. Depending on the model of the coupler, its threading should be protected against contact with the concrete.
4. L3 is the anchorage length of the coupler anchorage bars.
5. After the forms are raised, the couplers are exposed and the <j>4 and <j>5 splice bars are positioned. (Where
necessary, the splice bars may have a larger diameter than the slab bars.)
6. The <j>4 and <j>5 splice bars are tied to the <j>3 and <j>5 general bars, which should be designed to the same
spacing.
7. Before casting the slab, the polystyrene should be removed from the void area. This area should be cleaned
and moistened and the concrete should not be poured until its surface dries.
8. See CD - 02.28 for an alternative procedure.
9 See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
221
Group 05
Beams and lintels
CD- 05.01 BEAMS.
SIMPLY SUPPORTED BEAMS
See CD@®
~A
_______1_ r s
~~~~~~~~~~~~~~~~~~?f:::~-----r
~~~~===~~~~~~l_.~A~S~p~a~ce~r~~~t=-~~"' ~r3
S04aS2 S03aS1 I
01 I
__,.~~~~~~~~~~~~~~~~~~---;-!
'-lf-'°1
I ,
i ij:
I i
0
~! ~c:~--~s
90° BEND
j End s!acer CD
~
I t ..••...
r PI
I
®
HOOK
®
r 3_ ~~'="'T='~=
t r}_u _____ b_3_-----1
SECTION A-A SECTION A-A SECTION A-A
® ® ®
w
"
224
CD-05.01
1. RECOMMENDATIONS
1. See CD - 09 for information on support members.
2. r1 = 2.5 cm 2 $2 .
r2 = 2.5 cm.
r3 2 $2.
NOTES
AR. If the top of the beam is horizontal and exposed to rain or condensed water, r4 = 3 cm.
rs 2 $1.
3. See EC2, anchorage lengths, to determine when to use anchor type f, g or h at the end of the $2 reinforcing
bar. (The length is measured from the centreline of the support.)
4. The double tie solution (C) is only valid where b1 s 65 cm and s 0.75 d. Where 65 cm< b2 s 125 cm, use
solution (D).Where 125 cm< b3 s 185 cm, use solution (E).
5. Note that the web may need to be reinforced with skin reinforcement.
6. The top of the beam is smoothed with a float or power float.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
225
CD- 05.02
BEAMS.
HEADER JOIST
r See@@@) of reinforcement 0 1
301 201
_______,_ I I / '\
.\;" 11
/ <? (
I I
I
~I, ~ ~ ~ I~
I
l~rr ~ L.A f~
5 cm 803 5 cm
-----
1 201 !
i~----------]!
'~~ 10, 101 --j ~1
:r 10, 11
, I
: 20, i
I~ ~ _l_r _l_
-,rs t -,s
Li s0I R=20 or R
r1 ~ r1 ~ 3.50 -
I r1 I-
® ® ©
r2
,__.._...__----+-t---,1 _l_ r4 S acer
SECTION A-A 90° BEND HOOK
226
CD - 05.02
1. RECOMMENDATIONS
1. r1 = 2.5 cm ~ ~1 •
r2 = 2.5 cm.
r3 ~ ~2·
NOTES
AR. If the top of the beam is horizontal and exposed to rain or condensed water, r4 = 3 cm.
r5 ~ ~1
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or cat the end of the ~1 reinforcing
bar.
3. See EC2 for information on calculating length L3.
4. Note that the web may need to be reinforced with skin reinforcement.
5. The top of the beam is smoothed with a float or power float.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
227
BEAMS.
CONTINUOUS LINTELS WITH CONSTANT DEPTH
CD-05.03
L
I~
50 _i R=20 or R
r1 I- 3.50
® ® @)
SECTION A-A 90° BEND HOOK
228
CD- 05.03
1. RECOMMENDATIONS
1. r1 =2.5 cm.
r2 = 2.5 cm.
r31 ~ 4>1
~4>a
r4 = 2.5 cm.
If the top of the beam is horizontal and exposed to rain or condensed water, r4 = 3 cm.
rs ;::: 4>2·
NOTES
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or c at the end of the cj>1 and cj>2
reinforcing bars.
3. See EC2 for information on calculating length L3 .
4. L4 is the lap length in the thicker of the cj>2 or cj>3 bars, L5 is the lap length in the thicker of the cj>8 or cj>10 bars L6
is the lap length in the thicker of cj>3 or cj>4 bars and L1 is the lap length in the thicker of the cj>10 or cj> 14 bars.
5. Note that the web may need to be reinforced with skin reinforcement.
6. The top of the beam is smoothed with a float or power float.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
229
CD-05.04 BEAMS.
CONTINUOUS LINTELS WITH VARIABLEDEPTH
I
See®®® 0 2+05+06
01+02 02 02+05
~ r~,,f.~
i Ii Ii
02
L4
03+05+05 03+011+012
03+05 03+012
03
lS01s
51 1
I
0:r 03
~ 106
07
0s
®
SECTION A-A
09
010
s0I R=20or
r1 I- 3.50
®
90° BEND
230
04+011+012
04+012
04
I
!
Ls
-11- 04
I 011
4012
013 m 014
R
HOOK
CD-05.04
1. RECOMMENDATIONS
r2 = 2.5 cm.
r3 ~ cj>B.
If the top of the beam is horizontal and exposed to rain or condensed water, r4 = 3 cm.
rs ~ cj>2.
NOTES
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or c at the end of the cj>1 reinforcing
bar.
3. See EC2 for the procedure to calculate L3•
4. L4 is the lap length in the thicker of the cj>2 or cj>3 bars, L6 is the lap length in the thicker of the cj>3 or cj>4 bars and
L7 is the lap length in the thicker of cj> 10 or cj> 14 bars.
5. See EC2 for information on calculating anchorage lengths L5 and L8•
6. Note that the web may need to be reinforced.
7. The top of the beam is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
231
CD-05.05
(
I-
®
Construction
4 A joint
SECTION A-A
BEAMS.
STAGGERED LINTELS
See@®®
®
Construction
joint
See@®®
s0I R=20 or
r1 ~ 3.50~---l
®
90° BEND
232
@
I
I
I
I
Lsm
I
R
02+010+011
012+010
012
0 013
14---
HOOK
CD-05.05 NOTES
1. RECOMMENDATIONS
1. See the notes for CD - 05.04. The following refers to the present CD only.
2. See EC2, anchorage lengths, to determine when to use a, b or c at the end of the <j>2 , <j>1, <j>3 , <j>5 and <j>7 reinforc­
ing bars.
3. See EC2 for information on calculating L3 and L4 •
4. Note the construction joints in column 2.
2. STATUTORY LEGISLATION
See EC2 (5).
233
CD-05.06
See details@@@)
in CD-05.02
ELEVATION
PLAN
(TOP 0 1 AND 0 2 REINFORCING BARS SHOWN
ONLY)
DETAIL A
BEAMS.
STEPPED LINTELS
See details@®@)
in CD-05.02
See detail B 02+03
234
5 CIJJ.I
05
ELEVATION
PLAN
\~s
(BOTTOM 0 4 AND 0 5 REINFORCING BARS
SHOWN ONLY)
DETAIL B
CD - 05.06 NOTES
1. RECOMMENDATIONS
1. See the notes for CD - 05.04. The following refers to the present CD only.
2. See EC2, anchorage lengths, to determine when to use a, b or c at the end of the <j>, <1>2 and <j>3 reinforcing
bars.
3. See EC2 for information on calculating L3 and L4 .
4. L5, L6, L7 and L8 are the anchorage lengths for the <j>2, <j> 1, <j>5 and <j>4, bars respectively.
5. Concrete is poured in the beam in the upward direction.
2. STATUTORY LEGISLATION
See EC2 (5).
235
BEAMS.
EDGE SOFFIT BEAM
CD - 05.07
See detail A [----- 02
j 01+04 01
,
\ I
09+012 w --+- I I
' 1s01~ ---~015 to s2
I a~ 5
' 014
I
4A
011+014
I
' L3 Ls
I 01 H 02 II 03
04 05 07
0s 0a 09 L4 010
012 H I~ 011 013
014
ELEVATION
Construction
joint
DETAIL A
Cross-tie
b
SECTION A-A
236
L1 r--
l
®
R=20 or
3.50
®
®
~~/==J
V)~
HOOK 90° BEND
STIRRUPS
CD-05.07 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
1 4>1
r2 ~
4>12
l <Ps
r3 ~
4>12
r4 ~ 4>1·
If the top is horizontal and exposed to rain or condensed water, r4 = 3 cm.
r5 = 2.5 cm J 2 <1>1
12<1>4
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or cat the end of the <j>1 and <j>4
reinforcing bars.
3. See EC2 for information on calculating length Lr
4. L3 is the lap length in the thicker of the <j>1 or <j>2 bars, L4 is the lap length in the thicker of the <j>12 or <j>13 bars, L5
is the lap length in the thicker of the <j>2 or <j>3 bars and L6 is the lap length in the thicker of the <j> 13 or <j>14 bars.
5. The top of the beam is smoothed with a float or power float.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
237
CD-05.08
See detail A
I
\
'f-
I
I
'
I
I
'
I
04
Construction
joint
01
09
012
ls01~
to s1
012
4A
05
DETAIL A
b
SECTION A-A
:-t h
:_l_
BEAMS.
INTERNAL SOFFIT BEAM
H L3
0s
L4 010 1-1
013
ELEVATION
STIRRUP
ARRANGEMENT
238
02
w 5
014
011+014_
Ls
II 03
07
0s
Pl 011
014
®
R=20 or
3.50
®
©
HOOK 90° BEND
CD-05.08
1. RECOMMENDATIONS
1. r1 =2.5 cm.
r2 ~ <1>1·
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
l <1>9
r3 ;:::
<1>12
1 <1>1
r4 = 2.5 cm;:::
<1>4
NOTES
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or cat the end of the <1>1 and <j>4
reinforcing bars.
3. See EC2 for information on calculating length Lr
4. L3 is the lap length in the thicker of the <1>1 or <1>2 bars, L4 is the lap length in the thicker of the <1> 12 or <j>13 bars, L5
is the lap length in the thicker of the <1>2 or <j>3 bars and L6 is the lap length in the thicker of the <j> 13 or <j>14 bars.
5. The top of the beam is smoothed with a float or power float.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
239
BEAMS. CD - 05.09
SOFFIT BEAM-EDGE BEAM INTERSECTION (1 of 2)
Construction
joint
See details®®@
--r--1~---d in CD-05.07
A
'
' '
-j I~ cm
h I s I s
ELEVATION
PLAN
EDGE BEAM
240
Construction
/ joint
1Seedetails ® @@
~-'\~--.-; inCD-05.07
-j f cm
~ ~~:;;;;;;;::=~~]h
'
' - - - _J
'
h s s
ELEVATION
PLAN
INTERNAL SOFFIT BEAM
CD-05.09 NOTES
1. RECOMMENDATIONS
1. See CD - 05.07 and CD - 05.08 for details in general and cover dimensions.
2. In special open stirrups, Lb is the lap length of the bar with the respective diameter.
3. The top of the beam is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
241
CD- 05.09
End spacer
' '
5 crnl r
I I
I
I i\ I
I \ I
~ - - - - _J
5cm-I ~
~
'
PLAN
BEAMS.
SOFFIT BEAM-EDGE BEAM INTERSECTION (2 of 2)
I\
Construction
joint
See details@®@
in CD-05.07-
5 cm
--1 r-
~l~s-1~
ELEVATION ,,,-
.
.
Sc ml
~
~ Special open stirru ps
( )
' '-ti
' '
f .
~
I
I
' .
I
: I\
j~ \
5cm ~pecial o~en stirrup s
PLAN
INTERNAL SOFFIT BEAM EDGE SOFFIT BEAM
242
CD-05.09 NOTES
1. RECOMMENDATIONS
1. See CD - 05.07 and CD - 05.08 for details in general and cover dimensions.
2. In special open stirrups, Lb is the lap length of the bar with the respective diameter.
3. The top of the beam is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
243
CD - 05.10 BEAMS. TRANSITION FROM INTERNAL SOFFIT
BEAMS TO NORMAL BEAMS
I
I
\
5cm
I
Lstl
07
0a
013
ELEVATION I~
04 01 06 ' I ()et>' ,-,- r I > ~
'-":_C\ \ lb --~-, I
:1
1
J :
-
I I I I 11 J><f I 1 I
I I -\ _____ J
L j v lb ' /',/
\01 05 ~ I 2b
L .. ·--·-·- I
PLAN - TOP REINFORCEMENT
r2
rt
Ll_
'r3
____ b1 _______ _j
SECTION A-A
90° BEND
STIRRUPS
h
244
~
SECTION B-B
014
03
014 011
I 1
:1 :_J_ h
'
CD-05.10 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm
1 4>1
r2 2
«1>5
If the top of the beam is horizontal and exposed to rain or condensed water, r2 = 3 cm.
r3 ;;:: 4>12
2. See CD - 05.08 for anchorage and lap lengths.
3. Stirrups of varying dimensions are needed in the transition area.
4. The top of the beam is smoothed with a float or power float.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
245
CD-05.11
I
I
\
;-
i
I
I
90° BEND
STIRRUPS
~
I
I\
I
BEAMS. TRANSITION FROM EDGE SOFFIT
BEAMS TO NORMAL BEAMS
Ls
02
H 03
07
0s
010
013 011 014
ELEVATION ~
07
~
I ~
I r-..,~I
lb I --P:-~
I I 111 i'l I I
~ L3i 01+02
2b ~
PLAN - TOP REINFORCEMENT
h h
SECTION A-A
SECTION B-B
246
CD-05.11 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
l <P1
r2 ;:o: <P2
<PsIf the top of the beam is horizontal and exposed to rain or condensed water, r2 = 3 cm.
r3 ~ <P12·
2. See EC2 for anchorage and lap lengths.
3. Stirrups of varying dimensions are needed in the transition area.
4. The top of the beam is smoothed with a float or power float.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
247
BEAMS.
JOINT DETAILS
CD-05.12
~2
ELEVATION A ELEVATION B
PLANA PLAN B
~3
ELEVATION C SECTION A-A SECTION B-B SECTION C-C
248
CD - 05.12 NOTES
1. RECOMMENDATIONS
1. See CD - 05.01 to CD - 05.05 for general details.
2. In solution A, the beam reinforcement bars must be shaped.
3. The solutions of choice are B and C, the former in general and the latter for specific cases.
4. See CD - 03.01 to CD - 03.12 for details on reinforcing bar arrangement in nodes.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22) and ACI (15).
249
CD-05.13
'
BEAMS.
INDUSTRIALISED JOINT
PERSPECTIVE
~JI____,_
: 11 V II :
I I
-+ +----------------
I
I
I
I
il~===m1!
/
~--------------~ ~------ --
: ll#===="i'i11 :
I I
f- " I I
I I
_l__ A I
VIEW FROM A
250
CD-05.13 NOTES
1. RECOMMENDATIONS
1. This detail is applicable to highly industrialised systems, in which the 'cages' for each span are prepared in
the shop (usually by welding the stirrups to the bars). It is taken from the CEB manual (45).
2. Such systems provide for much speedier reinforcement assembly.
2. SPECIFIC REFERENCES
See CEB (45).
251
CD-05.14 BEAMS.
CANTILEVERED BEAMS
A
01 r 01 204
L2 ==1L1
Drip
l_.A 40mm
5cm~ Ls cm 03 02
Construction
joint
S acer
SECTION A-A
252
CD-05.14 NOTES
1. RECOMMENDATIONS
1 . See CD - 05.01 and CD - 05.03 for general considerations.
2. Members exposed to the elements should be fitted with a dripstone.
3. r1 = 2.5 cm.
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
r2 ~ <1>1·
r3 = 2.5 cm.
r4 ~ <1>3
rs J ;:>:<J>1
1 ;:>: <1>3
r6 = 2.5 cm ~ <1>1•
4. If thick bars are used in short cantilevers, length L1 must be verified.
5. L2 is the lap length of the thicker of the <j>2 or <j>3 bars.
6. The top of the beam is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
253
CD-05.15
®
,..,
n=6
(a)
Positive
moments
BEAMS. ARRANGEMENT OF REINFORCEMENT AT
CROSS-SECTION
® ©
CROSS-SECTIONAL VARIATIONS
n=9 n = 12
USE OF BUNDLES
Off cuts
r-
(b)
Negative
moments
o - Bars
• - Wires
Off cuts
r--·---~
n = 18
Spacer
USE OF WELDED-WIRE MESH
IN PLACE OF STIRRUPS
BEAM SUPPORTING THE OUTER
LAYER OF FACADE ENCLOSURES
TO REDUCE THERMAL BRIDGES
254
CD-05.15 NOTES
1. RECOMMENDATIONS
1. See CD - 05.01 to CD - 05.03 for cover dimensions and associated details.
2. Note that where bundles are used, while the cover dimension is determined in terms of the equivalent diam­
eter, the cover must actually be measured from the outermost bar in the bundle.
2. STATUTORY LEGISLATION
See EC2 (5).
255
CD-05.16
TYPEG)
TYPE®
BEAMS.
CONTRACTION JOINTS
2
lrnax
[]]
.
h
' b I
f I
POSITION: Points with a nil (or very small) bending moment
SLANT: ::::45°
EXECUTION: For b::; 30 cm, the natural slope is::::: 45°.
For b > 30 cm, form with galvanised welded
wire with mesh size under 20 mm or galvanised
metal lath, at a 45° angle
FINISH: Natural roughness
POSITION: Points with nil (or very small) shear
SLANT: Vertical
EXECUTION: Form with galvanised welded wire with mesh size
under 20 mm or galvanised metal lath
DISTANCE (Lmax) BETWEEN JOINTS
TYPE OF SEASON OF YEAR
CLIMATE WARM COLD
DRY 16 m 20m
HUMID 20m 24m
256
CD-05.16 NOTES
1. RECOMMENDATIONS
1. AR. The suggested times for keeping contraction joints open are listed in the chart below.
Cement content, C SUMMER WINTER
C ~ 250 kg/m3 3days 2 days
250 < C ~ 400 kg/m3 4days 3days
C > 400 kg/m3 MUST BE STUDIED MUST BE STUDIED
Construction joints need not be left open for any specified time.
2. Two joints may be set close to one another (providing they are in positions 1 or 2) while concrete pour­
ing continues. The area left open would subsequently be filled in as per the preceding recommendation.
A second option is simply to interrupt concrete pouring during the times specified. (This applies to contrac­
tion joints.)
3. Note the specifications for architectural concrete to prevent rough edges from forming (see CD - 05.17).
2. SPECIFIC REFERENCES
See (14), Vol. I, pages 502 to 522.
257
CD-05.17
Slats nailed to
thesides I
BEAMS WITH ARCHITECTURAL CONCRETE.
CONTRACTION JOINTS AND CONSTRUCTION JOINTS
ARCHITECTURAL CONCRETE VARIATIONS
TYPE CD JOI NT
ELEVATION SECTION A-A
ELEVATION
\_Slat nailed to bottom
of form
TYPE ®JOINT
SECTION B-B
Slats nailed to
the sides Wire mesh or metal lath
ELEVATION
1.
c
ELEVATION Slat nailed to bottom
of form
SECTION C-C
258
CD-05.17 NOTES
1. RECOMMENDATIONS
1. AR. The suggested times for keeping contraction joints open are listed in the chart below.
Cement content, C SUMMER WINTER
C ~ 250 kg/m3 3days 2 days
250 < C ~ 400 kg/m3 4days 3days
C > 400 kg/m3 MUST BE STUDIED MUST BE STUDIED
Construction joints need not be left open for any specified time.
2. Two joints may be set close to one another (providing they are in positions 1 or 2 (see CD - 05.16)) while
concrete pouring continues. The area left open would subsequently be filled in as per the preceding recom­
mendation. A second option is simply to interrupt concrete pouring during the times specified. (This applies
to contraction joints.)
3. Note the specifications for architectural concrete to prevent rough edges from forming.
2. SPECIFIC REFERENCES
See (14), Vol. I, pages 502 to 522.
259
Group 06
Slabs, ribbed slabs and precast slabs with
beam-block and hollow core floor systems
CD-06.01
SLABS. GENERAL TYPES: LONGITUDINAL AND
CROSS-SECTIONS
SOLID SLAB
I I
I \
I \
r)-~--~..___'-----i
t I 02 Spacer Spacer
LONGITUDINAL SECTION
RIBBED SLAB
02
LONGITUDINAL SECTION
BEAM-BLOCK FLOOR SYSTEM
(SELF-SUPPORTING JOIST)
LONGITUDINAL SECTION
BEAM-BLOCK FLOOR SYSTEM
(SEMI-SELF-SUPPORTING JOIST)
LONGITUDINAL SECTION
NOTE: See CD-05.16 for contraction joints
262
Chair
CROSS-SECTION
CROSS-SECTION
CROSS-SECTION
CROSS-SECTION
CD- 06.01
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
r1 2 $1.
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
r2 = 2.5 cm.
r3 { 2 $2
21.4 $5
r4 = 2.5 cm.
r5 = 2.5 cm.
r6 = 2.5 cm.
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm.
2. The top is smoothed with a float or power float.
3. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
NOTES
4. The detail for contraction joints is CD - 05.16. In slabs, the joint is usually as specified in type 1.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See {30) and (31).
263
CD-06.02
SOLID SLAB. CONNECTION TO BRICK WALLAND
CONCRETE BEAMS
30 mm 0drip if
exposed to rain
CD END REINFORCEMENT
IN CANTILEVER
See@@@
Lacing course axis
~ 40a
, 04s at 20 cm
03
<J) SUPPORT ON EDGE
SOFFIT BEAM
End
spacer
End
spacer
@
264
4 cm~ 30mm0dripif
exposed to rain
@ EDGE REINFORCEMENT
ON FREE SIDE
@) SUPPORT ON INSIDE WALL
@ SUPPORT ON INTERNAL
CONCRETE BEAM
~
90° BEND
CD-06.02
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r1 = 2.5 cm.
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
r2 = 2.5 cm z lj>2 •
r3 = 2.5 cm z lj>1•
r4 = 2.5 cm z lj>3 .
NOTES
4. See EC2, anchorage lengths, to calculate L1and L2 and to determine when to use a, b, c, d, e or f for anchor­
ing the 4> 1 bars, and to calculate L1 and L2•
5. L3 is calculated bearing in mind the following.
The force, T, at the beginning of the anchor (Figure (a)) is in equilibrium with Figure (b).
Figure (a) Figure (b)
where eb is the anchorage length in the 4>2 bar.
6. For negative moments (interior supports), L4 is calculated as follows.
Figure (c)
(Md is the design moment at the interior support.)
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See(31).
4. SPECIFIC REFERENCES
See (14).
265
(Shear friction with p = 1)
CD-06.03
RIBBED SLAB. CONNECTION TO BRICK WALL
AND CONCRETE BEAMS
G) END REINFORCEMENT IN
CANTILEVER
See@@©
Ends acer
~_.,,----i~ min.5cm
@ SUPPORT ON OUTSIDE WALL
See@@©
@ SUPPORT ON EDGE
CONCRETE BEAM
See@@CD
----1 ~Column's axis
/--l' 01
(J) SUPPORT ON EDGE
SOFFIT BEAM
End
spacer
30 mm 121 drip if
exposed to rain 0 1 and 0 2 may not be smaller
than ordinary ribs
@ EDGE REINFORCEMENT
ON FREE SIDE
40a
@) SUPPORT ON INSIDE WALL
@ SUPPORT ON INTERNAL
CONCRETE BEAM
02 02
@ SUPPORT ON INTERNAL
SOFFIT BEAM
~
~
~/);/);
~L20
HOOK
90° BEND
266
CD-06.03
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r1 = 2.5 cm 2 <j> 1 .
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
r2 = 2.5 cm 2 <j>2.
r3 = 2.5 cm 2 <j>1•
r4 = 2.5 cm 2 <j>3 •
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b, c, d, e or f for anchor-
ing the <1> 1 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See(31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
267
CD-06.04
SLABS WITH SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO BRICK WALL
min.20s
~~~{Th
h 4 cm_µ_ l 30 mm 0 drip if h 4 c~ l 30 mm 0 drip if
2 1:10 cmL exposed to rain 2 1:10 cm L exposed to rain
CD END REINFORCEMENT IN ® EDGE REINFORCEMENT ON
CANTILEVER FREE SIDE
Lacing course axis r 40s
04s at20 cm
in CD-06.02
~
@ SUPPORT ON OUTSIDE
WALL (Solution I)
~ Lacing course axis
, 40s
I 04s at 20 cm
_......,.___--+-+,.,,._ 0s
I~
@ SUPPORT ON OUTSIDE
WALL (Solution II)
®
Us Us
2 2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES (j) AND@)
r1
268
40s
~ ~
© SUPPORT ON INSIDE
WALL (Solution I)
40s
--- -
min.5cm
~ ~
® SUPPORT ON INSIDE
WALL (Solution II}
@ SUPPORT ON INSIDE
WALL (Solution Ill)
6&
~o'>J">
ijl20 ~
HOOK 90° BEND
~r6
CD-06.04
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm ?: <Pr
r4 = 2.5 cm ?: <j>8 •
r6 = 2.5 cm ?: <Pr
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm?:: ~a·
Ls is the lap length of the joist reinforcing bar.
NOTES
4. See Recommendation 4 in CD - 06.02 to calculate L1 and L2 and to determine when to use a, b or c for an-
choring the <j> 7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 7 and 8, special attention must be paid to spacer positioning to hold the pieces of anchorage bar
in place during concrete pouring (detail (g)). A practical solution is shown in Figure (a) below.
C-------~
Figure (a)
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
269
~?rs0
~
CD-06.05
SLABS WITH SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO REINFORCED CONCRETE BEAMS
G) EDGE CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution I)
@ EDGE CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution II)
End spacer
See ®@© ~'N: ~~~;;;;;i;;;;;;;;;;;;;;;;t;;;;;~~~~~
in CD-06.02 \.
@ EDGE CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution Ill)
®
Us
2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES @AND@
270
Spacer
(g) INTERNAL CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution I)
@)INTERNAL CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution II)
@ INTERNAL CONNECTION WITH
REINFORCED CONCRETE BEAM
(Solution Ill)
~
~o~~
HOOK 90° BEAM
CD- 06.05
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and tie beams.
3. r3 = 2.5 cm 2 <l>r
r6 = 2.5 cm 2 <l>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm 2 <1>8 •
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L, and L2 and to determine when to use a, b or c for anchoring the
<1>7 bars.
5. To calculate L3, see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See {31 ).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
271
CD-06.06
SLABS WITH SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO SOFFIT BEAMS
Spacer
in CD-06.02
G) CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution I)
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution 11)
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution 111)
Us
2
Us
2 HOOK
®
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@AND @)
272
See@
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution II)
Solid
concrete
Solid
concrete
I I I Jrs
~r7
L4I II Lsjkcm
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution Ill)
Stirrups
90° BEND 3±1cmLJ LJ3±1cm
®
(CASES G) AND@)
CD-06.06
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <l>r
r6 = 2.5 cm 2 <l>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm 2 <j>8•
L5 is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use d, e or f for anchoring the
<j>7 bars.
5. To calculate L3, see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
10. Note that in cases 1 and 2, the stirrups in the soffit beam must be positioned so that each joist has one on
each side, as shown in detail (h).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODESSee (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
273
CD-06.07
SLABS WITH SELF-SUPPORTING
PRESTRESSED CONCRETE JOISTS.
CONNECTIONS TO BRICK WALL
h 30 mm 0 drip if 4cme
2 <10 cm exposed to rain
CD TIP REINFORCEMENT IN
CANTILEVER
End spacer
U 10cm
@ SUPPORT ON OUTSIDE
WALL (Solution I)
r---_ Lacing course axis
I 40s
End spacer 04s at 20 cm
See@@©
L':2l
@ SUPPORT ON OUTSIDE
WALL (Solution II)
Lacing course axis
~ 40s
End spacer ' 04s at 20 cm
,---++----'r+ffl- Solid concrete
0a rs
See@@©
in CD-06.02
Us Us
2 Us 2
®
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES ([) AND @)
274
min.20a
30 mm 0 drip if
exposed to rain
EDGE REINFORCEMENT
ON FREE SIDE
5 cm W (..___j 5 cm
@) SUPPORT ON INSIDE
WALL (Solution I)
~~
@ SUPPORT ON INSIDE
WALL (Solution II)
@ SUPPORT ON INSIDE
WALL (Solution Ill)
.S-e-
~000
HOOK 90° BEND
CD-06.07
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD-05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <l>r
r4 = 2.5 cm 2 <j>6•
r6 = 2.5 cm 2 <l>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm 2 <j>8•
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
<j>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 7 and 8, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
275
CD-06.08
SLABS WITH SELF-SUPPORTING
PRESTRESSED CONCRETE JOISTS.
CONNECTIONS TO REINFORCED CONCRETE BEAMS
G) CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution I)
End spacer
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution II)
End spacer -0e
Ntj;;~;;;;;;~~;;;;;;;;;~~ Jr5
See _@@_@Lll. 0r7
in CD-06.02 .
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution Ill)
Us
2
®
Us
2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@AND@)
276
® CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution I)
-07
rrp ~~-"""-~-----~4 r5
L4
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution II)
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution 111)
HOOK 90° BEND
CD-06.08
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm~ 4>r
r6 = 2.5 cm~ 4>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm ~ lj>8 .
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
lj>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring {detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
277
CD-06.09
SLABS WITH SELF-SUPPORTING
PRESTRESSED CONCRETE JOISTS.
CONNECTIONS TO SOFFIT BEAMS
See@@CD
in CD-06.02
Spacer
G) CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution I)
Spacer
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution II)
See ®@CDT I
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution Ill)
Us Us
2 2 HOOK
®
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@ AND@)
278
See@
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution II)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution 111)
Stirrups
90° BEND 3 ± 1 cm LJ LJ 3 ± 1 cm
®
(CASES CD AND@)
CD-06.09
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm ~ <l>r
r6 = 2.5 cm ~ <l>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L. is the lap length of the joist reinforcing bar.
r7 = 2.5 cm~ <j>8•
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to used, e or f for anchoring the
<j>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
10. Note that in cases 1 and 2, the stirrups in the soffit beam must be positioned so that each joist has one on
each side, as shown in detail (h).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See(31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
279
CD-06.10
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO BRICK WALL
h 4c~ 30mm121dripif
2 .;: 1 o cm L exposed 10 rain
G) TIP REINFORCEMENT IN
CANTILEVER
1 _,,Lacing course axis
: 40a
End spacer 04s at 20 cm
0a
t::Pt~~~;;;;;;;;;t;;;;;~t;;;;;;.~4r a
See®@©
in CD-06.02
I~
@ SUPPORT ON OUTSIDE
WALL (Solution I)
I'--- Lacing course axis
I 40s
End spacer 04s at 20 cm
See®@©
in CD-06.02
~
0s
@ SUPPORT ON OUTSIDE
WALL (Solution II)
Lacing course axis
~ 40a
End spacer ' 04s at 20 cm
~+.i---++HI- Solid concrete
0 r6
See@@@
in CD-06.02
1---1~+--tl Ls
i~
(J) SUPPORT ON OUTSIDE
WALL (Solution Ill)
Us Us
2 Us 2
CD
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES <J) AND @)
4 c~ "I 30 mm 121 drip if
~ <10 cmL exposed to rain
280
@ EDGE REINFORCEMENT ON
FREE SIDE
40a
04s at 20 cm
~~
@ SUPPORT ON INSIDE
WALL (Solution I)
~~
@ SUPPORT ON INSIDE
WALL (Solution II)
@ SUPPORT ON INSIDE
WALL (Solution Ill)
Se
~<lO,,,.,,
ijl20 ~
HOOK 90° BEND
07
CD- 06.10
1. RECOMMENDATIONS
1 . See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm z <Pr
r4 = 2.5 cm z <Pa·
r6 = 2.5 cm z <Pr
r7 = 2.5 cm z <Pa·
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L5 is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
<j>7 bars.
5. To calculate L3, see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 7 and 8, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail U)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVECODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
281
CD-06.11
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO CONCRETE BEAMS
G) CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution I)
End spacer
See@@© ~H: ;;+;;;;;;;;;;;;;;;;;;;~~;;;;;;.~~~~~
in CD-06.02 l.
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution II)
Spacer
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution Ill)
CD
Us Us
2 2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@ AND@
282
07
r +~ ~;;;;;;;;;;l=;;;;;;;;;;;;;;;;;;;;;;;;;;;;t;;;;;;;;;;;;~=f r5
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution I)
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution 11)
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution 111)
HOOK 90° BEND
CD-06.11
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD- 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <l>r
r6 = 2.5 cm 2 <l>r
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm 2 <j>8•
L5 is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
cji7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail 0)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2.
3. RECOMMENDED ALTERNATIVE CODES
See (31 ).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
283
CD-06.12
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE JOISTS.
CONNECTIONS TO SOFFIT BEAMS
r3_...___._._
End spacer ·
\~~~~~~~
See@@CD(
in CD-06.02
G) CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution I)
See@@CD
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution II)
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution Ill)
Us Us
2 2
HOOK
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@ AND@)
284
® CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution II)
Solid Solid
concrete concrete
I 0%0a 01~1 I
fl •' w;1°" >,~J" "*~t:
2c~LJL4 L4LJ~cm
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution Ill)
Stirrups
90° BEND 3 ± 1 cmJl J_8 ± 1 cm
®
(CASES CD AND@)
CD- 06.12
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm z <Pr
r6 = 2.5 cm 2 <Pr
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
r7 = 2.5 cm 2 <j>8 .
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use d, e or f for anchoring the
<j>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4, see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail G)). See Recommendation 9 in CD - 06.04 for an alternative solution.
10. Note that in cases 1 and 2, the stirrups in the soffit beam must be positioned so that each joist has one on
each side, as shown in detail (k).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
285
CD-06.13
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE LATTICE JOISTS.
CONNECTIONS TO BRICK WALL
h 4 cm_µ_ 1 30 mm 0 drip if
2<10 cmb exposed to rain
(D TIP REINFORCEMENT IN
CANTILEVER
End spacer
See@@©
in CD-06.02
_t=:~:::t::::L
'~
@ SUPPO~T ON OUTSIDE
WALL (Solution I)
I-'- Lacing course axis
' 40s
I 04s at 20 cm
See@@©
in CD-06.02
~
02
@ SUPPORT ON OUTSIDE
WALL (Solution II)
Lacing course axis
~ 40s
End spacer 04s at 20 cm
~->r1---++1-1r- Solid concrete
0a r5
See@@©
in CD-06.02
02 i~
(J) SUPPORT ON OUTSIDE
WALL (Solution 111)
Us Us
2 Us 2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES <J) AND @)
r4 min.20a
h 4 cm-+J_ l 30mm0dripif
2<10 Cmfu exposed to rain
286
@ EDGE REINFORCEMENT
ON FREE SIDE
40s
04s at 20 cm
07
~;;;;;;;;;;;~~~~~~~~~_J r5
r 1 +-i"'Fft=~t===;r==i-ie. :-T
~~
@ SUPPORT ON INSIDE
WALL (Solution I)
~~
@ SUPPORT ON INSIDE
WALL (Solution II)
40s
02
@ SUPPORT ON INSIDE
WALL (Solution 111)
~
~
~000
~L20 ~
HOOK 90° BEND
CD- 06.13
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2': <Pr
r4 = 2.5 cm 2': <Pa·
r6 = 2.5 cm 2': <Pr
r7 = 2.5 cm 2': <Pa·
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L5 is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b, or c for anchoring the
tj>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 7 and 8, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (m)). See Figure (a) below for an alternative solution.
Figure (a)
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
287
CD-06.14
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE LATTICE JOISTS.
CONNECTIONS TO CONCRETE BEAMS
End spacer
G) CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution I)
End spacer
See@@©);
in CD-06.02 l.
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution II)
See@@©);
in CD-06.02 l.
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAM
(Solution Ill)
Us
2
>-----++----------< Us
2
Us
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES @ AND @)
288
® CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution I)
@) CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution II)
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution Ill)
HOOK 90° BEND
CD-06.14
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm~ 4>r
r6 = 2.5 cm~ 4>r
r7 = 2.5 cm~ cj>8•
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
cj>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (m)). See Recommendation 9 in CD - 06.13 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
289
CD-06.15
SLABS WITH SEMI-SELF-SUPPORTING
REINFORCED CONCRETE LATTICE JOISTS.
CONNECTIONS TO SOFFIT BEAMS
End spacer
l.~~~~~:=::::::::::::::::::=::=:J
See@@CD(
in CD-06.02
G) CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution I)
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution II)
!Column axis
® CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution II)
Solid concrete Solid concrete r L ' Solid concrete
Endspacer
3f1i. : J2 @+~::
See @@CD( I IL3ll a 112 cm
I §_08 01JI I
~Cif" : J; i&~;:
2 cmll a ILJL4 L41 II a II 2 cm
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution 111)
@ CONNECTION TO CONCf{ETE
INTERNAL SOFFIT BEAM
(Solution Ill)
Us
2
f-----------1+-"....,....___, Us
2
Us
NOTE:
a is the lap length, but it may be no
shorter than the distance between
two consecutive welds.
Stirrups
3 ± 1crclJ_JJl±1 cm
CROSS-SECTION THROUGH @ SOLID CONCRETE AREA
(CASES @ AND @) (CASES CD AND@)
290
90° BEND
~
~000
HOOK
CD-06.15
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <Pr
r6 = 2.5 cm 2 <Pr
r7 = 2.5 cm 2 <j>8•
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L5 is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use d, e or f for anchoring the
<j>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1 .3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (m)). See Recommendation 9 in CD - 06.13 for an alternative solution.
1 o. Note that in cases 1 and 2, the stirrups in the soffit beam must be positioned so that each joist has one on
each side, as shown in detail (n).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See(31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
291
CD - 06.16
SLABS WITH SEMI-SELF-SUPPORTING
PRESTRESSED JOISTS.
CONNECTIONS TO BRICK WALL
min.20s
0i
h ' 30 mm 0 drip if 4cm~
·2 <10 cm ' exposed to rain
CD TIP REINFORCEMENT IN
CANTILEVER
1
_,,, Lacing course axis
: 40s
En<:t~cer I 04s at 20 cm
See@@©
in CD-06.02
I~
@ SUPPORT ON OUTSIDE
WALL (Solution I)
r---
'
Lacing course axis
40s
Ends acer
See@@©
in CD-06.02
I 04s at 20 cm
I~
@ SUPPORT ON OUTSIDE
WALL (Solution II)
Lacing course axis
~ 40s _
End spacer 04s at 20 cm
~-1.1----+-1c1-11- Solid concrete
!--.--i--1 0s r a
i 3
(J) SUPPORT ON OUTSIDE
WALL (Solution Ill)
Us Us
2 2
CD
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES (J) AND @)
min.20s
4 cm_µ_ l 30mml2Jdripif
~ .;: 10 cm~ exposed to rain
292
@ EDGE REINFORCEMENT
ON FREE SIDE
40s
min.5 cm
~~
@) SUPPORT ON INSIDE
WALL (Solution I)
~~
@ SUPPORT ON INSIDE
WALL (Solution II)
40s
04s at 20 cm
Solid 07
LJ+~;;;;i;;i-;;;;;~---...:;-~.,1-=I-=~.l,-~-<;;;;c"'or~c~re~te~~J rs
r1 ::-r
@ SUPPORT ON INSIDE
WALL (Solution 111)
.Se-
~o
/);/);
0
HOOK 90° BEND
CD- 06.16
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <Pr
r6 = 2.5 cm 2 <Pr
r7 = 2.5 cm 2 <j>8•
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L. is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
<J>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 7 and 8, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail (g)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
293
CD-06.17
SLABS WITH SEMI-SELF-SUPPORTING
PRESTRESSED JOISTS.
CONNECTIONS TO CONCRETE BEAMS
G) CONNECTION TO REINFORCED
CONCRETE EDGE BEAMS
(Solution I)
End spacer
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAMS
(Solution 11)
End spacer r 3 0 8
~~;;;;;;;;;::;;;;i;;;;;;;~~;;;;;;;;/~~~
@ CONNECTION TO REINFORCED
CONCRETE EDGE BEAMS
(Solution Ill)
CD
Us
2
Us
2
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@ AND@
294
07
r1p. ~~~~;;;;;;;;;;;;~;;;;;;;;;;;~ =f rs
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution I)
L4
Spacer
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution II)
@ CONNECTION TO REINFORCED
CONCRETE INTERNAL BEAM
(Solution 111)
HOOK 90° BEND
CD-06.17
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm 2 <l>r
r6 = 2.5 cm 2 <l>r
r7 = 2.5 cm 2 lj>8•
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
L, is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage lengths, to calculate L1 and L2 and to determine when to use a, b or c for anchoring the
lj>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attention must be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail U)). See Recommendation 9 in CD - 06.04 for an alternative solution.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
295
CD - 06.18
SLABS WITH SEMI-SELF-SUPPORTING
PRESTRESSED JOISTS.
CONNECTIONS TO SOFFIT BEAMS
G) CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution II)
!Column axis
L , Solid concrete
r5 .
1 0 7 0a~
\ · S30° I ry
See @®CD( I IL3ll Ls 112 cm
in CD-06.02
@ CONNECTION TO CONCRETE
EDGE SOFFIT BEAM
(Solution Ill)
CD
See®
(g) CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution I)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution II)
@ CONNECTION TO CONCRETE
INTERNAL SOFFIT BEAM
(Solution 111)
Us Us
2 2 HOOK 90° BEND 3 ± 1 c'!!LL m ± 1 cm
CROSS-SECTION THROUGH
SOLID CONCRETE AREA
(CASES@ AND@
296
®
(CASES CD AND@)
CD-06.18
1. RECOMMENDATIONS
1. See CD - 06.01 for the general arrangement.
2. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
3. r3 = 2.5 cm ~ cl>r
r6 = 2.5 cm ~ cl>r
r7 = 2.5 cm ~ cj>8 •
If the top is horizontal and exposed to rain or condensed water, r6 = 3 cm.
Ls is the lap length of the joist reinforcing bar.
NOTES
4. See EC2, anchorage ·lengths, to calculate L1 and L 2 and to determine when to used, e or f for anchoring the
cj>7 bars.
5. To calculate L3 , see Recommendation 5 in CD - 06.02.
6. To calculate L4 , see Recommendation 6 in CD - 06.02.
7. The top is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
9. In cases 5 and 6, special attentionmust be paid to spacer positioning to hold the pieces of anchorage bar in
place during concrete pouring (detail U)). See Recommendation 9 in CD - 06.04 for an alternative solution.
10. Note that in cases 1 and 2, the stirrups in the soffit beam must be positioned so that each joist has one on
each side, as shown in detail (k).
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
297
PRECAST BEAM AND BLOCK FLOOR SYSTEMS.
CHANGE IN BEAM DIRECTION CD-06.19
0s--
Spacer
La
k ~
I I ~
I I ~
I I I
I I
I
I
I C:::::::=
I I
I
I
I
C:::::::= I
I I
I I I
I I I
I I
I I I
-~ I I I -,..
I I I
I
I
I
I I
: I :
I I I
I I I t::::=
I I I
I I I
I I
t::::=
I I I
I I I
I k I : ~
~ I ~
I
I
~ ~ ~
298
CD- 06.19 NOTES
1. RECOMMENDATIONS
1. The detail shows a floor slab with semi-self-supporting joists. The arrangement is analogous to other types
of joist.
2. See CD - 06.01 for the general arrangement.
3. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
4. See CD - 06.01 for the concrete cover.
5. Note the negative moment ~9 reinforcing bar on the right of the floor slab. It should be anchored in the top
slab on the left side of the floor slab for a length L. equal to its anchorage length.
6. The top is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31 ).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
299
CD-06.20 PRECAST BEAM AND BLOCK FLOOR SYSTEMS.
CONNECTION TO WALL PARALLEL TO BEAMS
DO
Solid concrete
if space too small
for pan form
300
Spacer
CD-06.20 NOTES
1. RECOMMENDATIONS
1. The detail shows a floor slab with semi-self-supporting joists. The arrangement is analogous to other types
of joist.
2. See CD - 06.01 for the general arrangement.
3. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and tie beams.
4. See CD - 06.01 for the concrete cover.
5. Particular care must be taken when placing the $8 reinforcing bars and their anchorage in the beam or tie
beam. This is essential to prevent cracks from appearing parallel to the joists on the inner side of the floor
slab.
6. The top is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31 ).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
301
CD - 06.21
ELEVATION
PRECAST BEAM AND BLOCK FLOOR SYSTEMS.
CANTILEVER WITH EXTENDED JOISTS
I
I I I
Spacer
30 mm 0 drip ju b cm
exposed to rain
t I r :
~~~;;~~;;3~;:;;;~;:~=~'.~1~~i' ~1~:~~~~~~~~~~~~/~/_,r-09
: le~
I I I
: I :
I I I
: I :
_L 1' ,---------l-: . ' i/_,,,----09
~~~~~~~~~~~~~~~~~~~~~~~~A-~~/~
=;le~
: i :
I I I
I I
0a
PLAN
302
CD - 06.21 NOTES
1. RECOMMENDATIONS
1. The detail shows a floor slab with semi-self-supporting joists. The arrangement is analogous to other types
of joist.
2. See CD - 06.01 for the general arrangement.
3. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
4. See CD - 06.01 for the concrete cover.
5. The to!)' is smoothed with a float or power float.
6. AR. The maximum value for deviation e is e ::; r.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See {31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
303
CD-06.22
ELEVATION
PRECAST BEAM AND BLOCK FLOOR SYSTEMS.
CANTILEVER WITHOUT EXTENDED JOISTS
Spacer
30 mm 0 drip if 7-! 14 cm
exposed to rain
~ ~_0_._8V---'------~~-'---~~~~V~~~~~
Solid concrete
~
I
l
~
I I
~1 . -···
17
~ .. L .····.· L I
I. < .. :·:...<· ... · .. .. ·.I·: r. ·. ............. ·. >
·. 1· ··. : I .:: :.·
~ ~ ·.•.:: : \ 1: H:-:-.. :.:.:.:::.::.;_:.::.~ I. .. ··: I< .. I I
-,,.. I I I
I
I
I
I I I
..... I:···:.:.·· .. .. I
:.: :: ::·': J .. J: ........
'·· ·:· .. .. .. ..
'· .:: ... / ·:: ·.:·. :·: : .·· · .. :::i.
.. .... ... ... .. . .. l l ·, ..
-_.. I
I I I
I I I
·:: . ........ ·:: .::>·:. .. .. __ ._. _ _._ .. _.
l [:::.:·:~ ...
..
1:.: .. : .. : :. ·.
.. . . ·. :: .. 1· .... . .... -.......... _ r .. :-r:: _ .. :-...
.. ::··· . ' I ..... .... : I ···~ 1·.:
- ~
I I I ~
~ I ~
PLAN
304
CD-06.22 NOTES
1. RECOMMENDATIONS
1. The detail shows a floor slab with semi-self-supporting joists. The arrangement is analogous to other types
of joist.
2. See CD - 06.01 for the general arrangement.
3. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
4. See CD - 06.01 for the concrete cover.
5. In the solid concrete area on the left, the blocks should be sealed off to protect them from the flowing con­
crete. Care should be taken to maintain the concrete within the specified width.
6. The top is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
305
CD-06.23
BEAM AND BLOCK FLOOR SYSTEMS.
OPENINGS
A.-J
Spacer
ELEVATION
I L2
I L1
-7
-,..
PLAN
I I , ,
I I
~ ,
SECTION A-A (See detail CD-06. 12
for design values of L3 , L5)
306
-,..
-,..
CD-06.23 NOTES
1. RECOMMENDATIONS
1. The detail shows a floor slab with semi-self-supporting joists. The arrangement is analogous to other types
of joist.
2. See CD - 06.01 for the general arrangement.
3. See CD - 05.01 to CD - 05.14 for the concrete cover in beams and lacing courses.
4. See CD - 06.01 for the concrete cover.
5. L1 is the anchorage length in the <1>1 bar and L2 is the anchorage length in the <1>2 bar.
6. The top is smoothed with a float or power float.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See (31).
4. SPECIFIC REFERENCES
See (14) pages 487 to 516.
307
CD- 06.24 SLABS LIGHTENED WITH EMBEDDED TUBING
h
Spacer I D/2 I b I D/2 I
4A Wire tied to bottom form
CROSS-SECTION
r2 f i--ii--....._ _ __._....._...,.
--+-
D h
Continuous chair
LONGITUDINAL SECTION A-A THROUGH TUBE CROWN
HOOK 90° BEND
VARIATION1 VARIATION 2
STIRRUPS
308
CD-06.24 NOTES
1. RECOMMENDATIONS
1. This solution is worthwhile only for bridge decks, floor slabs with very long spans and similar.
2. r1 = 2.5 cm 2 <j> 1•
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
This is likewise applicable for bridge decks if the top is not waterproofed.
r2 2 <1>2·
r3 = 2.5 cm 2 <j>1'
r4 2 <1>3·
The <j>6 and <j>7 bars are tied at all bar-stirrup intersections.
3. If the <j>2 and <j>3 reinforcing bar spacing is coordinated, the stirrups may be tied to them with no need to wrap
around reinforcing bars.
4. If the deck is prestressed, the variation 2 stirrup should be used to allow space for positioning the ducts.
5. Particular attention should be paid to the possible flotation of the cardboard tubes used to lighten the struc­
ture. One possible solution is to use a <j>7 bar as in arrangement 1, winding wires around the tubes and tying
them to the bottom forms.
6. The tubes rest on spacers or continuous chairs set underneath them, depending on the case, and on the <j>6
bar.
2. STATUTORY LEGISLATION
See EC2 (5).
309
CD-06.25
CD GENERAL VIEW
Da.:'.·:::::::::.::::::·.::·:::.·:. ·~·:-:.:.:::· ····:-:-:.:-:·:-:-:::·
,.·-::> ·:::-:·
. . . .. -.mO •....
~ v ~ jQt a <;r Nobe.el : .............. ~ .. o: .............................. ......... . .... .- ..... . .............................. ..............................
(a)
(b)
@ BOTTOM BEVELLED EDGE
FOR HOLLOW CORES WITH
EXPOSED UNDERSIDE
HOLLOW CORES.
GENERAL DETAILS
<!30 mm
Area to houseIQVQ
reinforcement ••••• , •.••.•.••••••• 4::. s•:•••:······················
~~-.,..---___,
310
(a)
(c) (d)
@ TYPE OF JOINTS
~ .. ·~ . '..~ :::::.·.·::::::.·.·::::::.·:::.·:. ... ::::::::::::::::::.·:::.·:::::
>· :· .. \ ~-. />' . <://'
-:: .<<·. ~·: :-: -:: . .... ..... ..... .. ..
""" ...... ..... . .... . . . . . . . . . . . . . . . . . . . . . . . . . . . :o.~ .... o.i:
=30mm
fooToot
(a)
I 300 mm IJ_
F:: 1
~·I 70mm
(b)
@ JOINTVIBRATION
(Not necessary if self-compacting
mortar is used)
CD-06.25 NOTES
1. RECOMMENDATIONS
1. The width of a standard hollow core panel is usually 1.20 m (4 ft in the US). Other widths can be made to
order, however.
2. The cores are normally circular. In large depths they may be oval, with the long axis in the vertical direction.
3. The joints are standardised in European Standard prEN 1168-1 (32).
4. Hollow cores can be used for normal spans and live loads with no concrete topping. For long spans or large
loads, concrete topping is needed.
5. Note detail 5. If the hollow core is exposed to view, the bevelled edge is always essential, but particularly if
the members are prestressed.
6. Today self-compacting mortar is recommended to fill in the joints. Otherwise, the concrete would have to be
vibrated and since normal vibrators cannot fit in the joint, a plate would have to be attached to the tip.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
311
HOLLOW CORES.
CONNECTIONS CD-06.26
Slot in top
Reinforcement in core
Tie point or
x assembly weld
(a)
(D SUPPORT ON BEAM OR WALL OVER RUBBER OR NEOPRENE STRIP
Joint reinforcement
(a) (b)
---i ---.J
~ 750
~ ~crit
@ CONTINUOUS SUPPORT ON RUBBER OR NEOPRENE STRIP
(a) (b)
@ REINFORCEMENT HOUSED IN CONCRETE-FILLED CORES, BY CUTTING
THROUGH THE TOP SLAB
312
CD-06.26 NOTES
1. RECOMMENDATIONS
1. If plastic stoppers are used to close off the cores, they are fitted to the end of the core, whereas if polystyrene
stoppers are used, they are inserted a certain distance into the core. The second solution yields better con­
nections.
2. The slots in the top slab are made with special machinery.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
313
HOLLOW CORES.
TIP AND EDGE TIE HOOPS IN CANTILEVERS CD- 06.27
Reinforcement in joint
20a
Spacer
G) TIE BEAM IN CANTILEVER TIP
20s
4cm
Slot cut into core with a saw
@ LACING COURSE IN CANTILEVER EDGE
314
CD-06.27 NOTES
1. RECOMMENDATIONS
1. Tip and edge lacing courses are needed for many reasons, but especially to secure the railings.
2. The slot in solution 2 is cut with a circular saw.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
315
CD-06.28 HOLLOW CORES.
VERTICAL PANEL AND BEAM SUPPORTS
/
I
Connection reinforcement ,,----
in the joint '---
Polystyrene stopper to prevent
concrete from flowing into the cores
~Rubber or neoprene joint
~
Connection
stirrup
(a)
x Tie point or
assembly weld
Plastic or gummed paper strip to prevent
concrete from dripping into core
(b)
G) SIMPLY SUPPORTED CONNECTION ON EDGE
/
/
/
/
/
/
/
/
/
///"',
/
(a) (b)
@ SIMPLY SUPPORTED CONNECTION ON EDGE
WITH SLOT IN TOP PLATE
>---++-- Connection stirrup
Connection stirrup
mm
x Tie point or
assembly weld Plastic or gummed paper strip to prevent
concrete from dripping into core
VIEW (a) (b)
@ SIMPLY SUPPORTED CONNECTION IN INTERMEDIATE
SUPPORTS
316
CD-06.28 NOTES
1. RECOMMENDATIONS
1. Hollow cores should never rest directly on beams or vertical panels. A rubber strip or neoprene pad must
always be placed in between the two members. Otherwise, transverse bending stress will appear in the
hollow core that may cause longitudinal cracking.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
317
HOLLOW CORES.
SUPPORTS ON VERTICAL PANELS
CD- 06.29
Mortar
(a) (b)
Stopper limiting fill width to panel I INCORRECT SOLUTION I
When the fill is included in the
cores, cracks tend to form due to
the discontinuity generated
(c)
Polystyrene, foam rubber
or similar
(d)
SIMPLY SUPPORTED INTERMEDIATE CONNECTIONS IN BUILDINGS
WITH PANELS
318
Mortar
CD-06.29
1. RECOMMENDATIONS
1. Particular attention should be paid to solution b, which is complex.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
319
NOTES
CD-06.30 HOLLOW CORES.
SUPPORTS ON VERTICAL PANELS AND BEAMS
Negative moment reinforcement
housed in the joint
J1 Tie stirrup
X Tie point or assembly
weld
CD REINFORCEMENT HOUSED IN JOINTS
@ REINFORCEMENT HOUSED IN CONCRETE-FILLED CORES
@ REINFORCEMENT HOUSED IN TOP SLAB
n Tie stirrup
@) SUPPORT ON BEAM WITH REINFORCEMENT IN JOINTS
320
CD-06.30
1. RECOMMENDATIONS
1. Solution 2 calls for cutting through the top slab in the respective cores.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
321
NOTES
CD-06.31 HOLLOW CORES.
OPENINGS IN THE SLAB
Al
SECTION A-A
PLAN
(a)
G) DETAIL OF STEEL HEADER
B_. --------
~----------~
-------------
SECTION A-A
Al
PLAN
SECTION B-B
{b)
@ DETAIL OF STEEL HEADER
322
CD-06.31 NOTES
1. RECOMMENDATIONS
1. A steel beam is the most practical solution. See (32) for the distribution of the point support reactions.
2. STATUTORY LEGISLATION
See EN 1168-1 (32).
3. SPECIFIC REFERENCES
See (33).
323
Group 07
Flat slabs
CD- 07.01
FLAT SLABS.
TOP REINFORCEMENT
c
§.g. --0"'
(..)
c
E.9-
::::1 ..... --0 "' (..)
Q.
·;:: -"' Q)
=a
12
~
c
E.9-
::::1 ..... --0"'
{)
Column
~ strip '
Middle strip Column
strip
'
Middle strip
LACING COURSE AT TIP OF CANTILEVER
-
1r w
~
::J
0
()
('.)
z
0
:5
w
('.)
0
w
-
-
:3-
I
I\
3--
I/
I\
J-
v
1...- '
I,.- '
I/ '
1...- '
I '-I
I\ I\
1...- '-
1...- '
1,...- '
v 'v
I\ I\
/
/ '
/ '
I '1
~
--y
I/
-f G- v
I/
v I I 1
I\ I\ ,, I\
1...-
-f 8-
I/
I/
I/ 11 v v
I\ I\ I\ I\
1...-
-{ }-
v
1...-
I/ 'I I l1
/~
WELDED-WIRE FABRIC IS LAID ON TOP AS DISTRIBUTION
REINFORCEMENT ~ 0{ 0 1· S( s1
20cm
II
LAPPING IN WIRE FABRIC DISTRIBUTION REINFORCEMENT
326
CD- 07.01 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and other details.
2. The top reinforcement runs in the direction of the larger span, on top of and in contact with the perpendicular
reinforcement.
3. See CD - 07.05, CD- 07.06, CD - 07.07 and CD - 07.08 for possible punching shear reinforcement, which
is not shown in this solution.
4. The general arrangement is valid for slabs with pockets and solid slabs, although in that case the parallel
reinforcing bars should be spaced at no more than 25 cm.
5. The top is smoothed with floats or a power float.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5) (although the code contains scant information on the subject).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
327
CD-07.02
c
E.9-
::::i ..... --orn
0
c
Ea.
::i·c --orn
0
c
Ea.
::i·c --0 (/)
0
UJ
(/)
a::
:::>
0
0
(!)
z
u
:)
UJ
(!)
0
UJ
Column
~ strip f
- J--:
I
\ \
I
- J;?
l/(A
I I
\ \
- J--
I I
FLAT SLABS.
BOTTOM REINFORCEMENT
Middle strip Column
strip
LACING COURSE AT TIP OF CANTILEVER
~
I'-
1-.....
' / 1-..... / n
' : --f J-: \ \
'
I'-
l~v
I I I I I I'- / ,,
1, /I'-
I'- /I'-
I'- /I'-
\ \ \ \ \ \ \ \ \
I'-
I' /I'-
: : ~" -f G-
"
' I , I '1, ' I
;I, '
I'- /I'-
" /I'-
" / 1-.....
' \ ' \ \ \ \ \ '
"
I'- /I'--
~ ~I'- -B G-
1-.....
I I I I I I'- I I .),, /
/ /
I I
'
Middle strip
/
/ 2 /
/
)
•' ~
/
.) I
/
/
/
\ \ \
/ 2
/
, I
\
/
/
' I I
/
/
/
/
\ \ \
/ 2
/
~
I
\
/
/
I .) I
THE ENTIRE BOTTOM OF ABACUS SHOULD BE REINFORCED WITH
WELDED-WIRE FABRIC
£0
~
DETAIL AtL
J az J
DETAILS
DETAIL OF LAPPING BETWEEN WELDED­
WIRE FABRIC ON BOTTOM AND EDGE
TIE BEAM
328
CD-07.02 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and other details.
2. The top reinforcement runs in the direction of the larger span, on top of and in contact with the perpendicular
reinforcement.
3. See CD - 07.05, CD - 07.06, CD - 07.07 and CD - 07.08 for possible punching shear reinforcement, which
is not shown in this solution.
4. The general arrangement is valid for slabs with pockets and solid slabs, although in that case the parallel
reinforcing bars should be spaced at no more than 25 cm.
5. AR. The two $1 reinforcing bars (integrity reinforcement) overlap by their lap length in the area over the col­
umn (see (22)).
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5) (although the code contains scant information on the subject).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
329
CD-07.03 FLAT SLABS. ARRANGEMENT OF FLEXURAL
REINFORCEMENT (1 of2)
(A) COLUMN STRIP
See detail A
09+ 010 1
0e
03 I 07
8cmmax. * ____ 0_4 __ e_c_m_ma_x_* _____ 0_e_~_-c_m_ma_x_. * 0 11
I 8 cm max. I 8 cm max. 20i 8 cm max. ----- y
LONGITUDINAL SECTION
See detail ~
(
I I
013
0i is the integrity reinforcement
See@@@ See@@@
5 cm --+--t--- L/--
DETAIL A D ET Al L B
(THE DETAIL FOR THE EDGE LACING COURSE SHOWN IN CD-07.04)
330
CD-07.03 NOTES
1. RECOMMENDATIONS
1. See CD - 07 .04 for concrete cover and other details.
2. The top reinforcement runs in the direction of the larger span, on top of and in contact with the perpendicular
reinforcement.
3. See CD - 07.05, CD - 07.06, CD - 07.07 and CD - 07.08 for possible punching shear reinforcement, which
is not shown in this detail.
4. The general arrangement is valid for slabs with pockets and solid slabs, although in that case the parallel
reinforcing bars should be spaced at no more than 25 cm.
5. See 1.6 to determine when to use anchor type a, b or c in details A and B.
6. See EC2 (5) for the procedure to calculate L1 (detail B).
7. The top is smoothed with floats or a power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5) {although the code contains scant information on the subject).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See {30).
331
CD-07.03
(B) MIDDLE STRIP
See detail B
4
FLAT SLABS. ARRANGEMENT OF FLEXURAL
REINFORCEMENT (2 of 2)
See detail A
022 1
LONGITUDINAL SECTION
(r-;:::::~::::::::::::--~~~-:::::::::::::::::::::::::::=t==::::::i::::::::::::::;--1
CROSS-SECTION
R=20 or 3.50
@ @
(THE DETAIL FOR THE EDGE LACING COURSE SHOWN IN CD-07.04)
332
CD - 07.03 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and other details.
2. The top reinforcement runs in the direction of the larger span, on top of and in contact with the perpendicular
reinforcement.
3. See CD - 07.05, CD - 07.06, CD - 07.07 and CD - 07.08 for possible punching shear reinforcement, which
is not shown in this detail.
4. The general arrangement is valid for slabs with pockets and solid slabs, although in that case the parallel
reinforcing bars should be spaced at no more than 25 cm.
5. See 1.6 to determine when to use anchor type a, b or c in details A and B.
6. See EC2 for the procedure to calculate L1 (detail B).
7. The top is smoothed with floats or a power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5) (although the code contains scant information on the subject).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
333
FLAT SLABS.
GENERAL DETAILS CD-07.04
(A) CROSS-SECTIONAL DRAWING OF REINFORCEMENT ARRANGEMENT
(INCLUDING WELDED-WIRE FABRIC)
09 0A
~------r-----------==------;lr
--------1T 4
l
T
(NB: The perpendicular 0 A bars rest on the welded-wire fabric. The parallel bars run underneath.)
(B) WELDED-WIRE FABRIC IN AREAS NOT CALLED FOR IN THE DESIGN
•
( See note in A re the position of #01)
(C) EDGE LACING COURSE (See detail Bin CD-07.03)
ra
til-
ra
02 c
•
STIRRUPS
r2
90° HOOK 90° BEND
(D) LACING COURSE AT TIP OF CANTILEVER (See detail A in CD-07.03)
334
CD-07.04
1. RECOMMENDATIONS
1. r1 = 2.5 cm 2 cj>0•
r2 = cl>c·
NOTES
r3 must be large enough to accommodate the concrete; in any case ;;:.: q,0 and never less than 2.5 cm.
r4 = 2.5 cm 2 cj>A.
r5 = 2.5 cm 2 cj>6•
r6 = 2.5 cm 2 cj>1.
r1 2 cl>2·
r8 = 2.5 cm 2 cj>2•
r9 2 q,2•
The maximum aggregate size should be chosen carefully.
2. L1 should be sized so that the stirrup closure complies with the lap length.
3. If the top is horizontal and exposed to rain or condensed water, concrete covers r6 and r8 should be 3 cm.
4. See Recommendation 2 in CD - 07.01 and CD - 07.02.
2. STATUTORY LEGISLATION
See EC2 (5) (although the code contains scant information on the subject).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
335
CD-07.05
) l
I (
FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 1) (1 of2)
INTERNAL COLUMN
0.5 d 0.75 d 0.75 d 0.75 d
ELEVATION
) l
0.75 d
0.5 d
L _J
I (
PLAN
336
I I I I
) l ) l
I ( I (
CD - 07.05 NOTES
1. RECOMMENDATIONS
1. The symbol dis the effective depth in the respective direction.
2. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
3. See 1 .2 and 1 .3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
337
CD-07.05
FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 1) (2of2)
EDGE COLUMN CORNER COLUMN
0.75 d 0.75 d 0.75 d 0.5 d 0.75 d 0.75 d 0.75 d 0.5 d
I I I I I I I I
ELEVATION ELEVATION
~
I I ~ I I
) l ) l
~ ____., ..____ - ____,, '----
~ ------- 0.75 d
I 0.75 d
I 0.75 d
) 0.75 d
- ____.,
0.5 d
0.75 d
---.. rr: - -~
I
u l
I I
( I (
) L - ____., - -~
PLAN
- -------
I
I
""'7 )
- ____.,
~ ------- ,--- - ---- .---- - -
I ( I (
6e
s~~~
20-7
0
I I I I HOOK 90° BEND
PLAN STIRRUPS
338
CD - 07.05 NOTES
1. RECOMMENDATIONS
1. The symbol dis the effective depth in the respective direction.
2. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
3. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
339
CD-07.06
) l
I (
FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 2) (1 of2)
INTERNAL COLUMN
0 1 (See detail A)
2d min.
ELEVATION
L _ _) ) l
S0.25 d S0.25 d
IH----IH-------01
11---11---il----+1---H--01
(~-I
PLAN
340
S0.25d
S0.25 d
I (
CD-07.06 NOTES
1. RECOMMENDATIONS
1. The symbol d is the effective depth in the respective direction.
2. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
3. L1 is the <1>1 bar anchorage length.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
. See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
341
CD- 07.06 FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 2) (2 of2)
EDGE COLUMN
- -- -- 1 .
11 ' I
JI JI I
I
-fjj--fjj-- J
See@@©
in CD-07.03
0 1 (See detail A)
ELEVATION
A
I v I I
L __ _J L_
1-
I
I
I
L_
j S0.25 d
--. 1-
I
I
I
__l_ L_
l S0.25 d
1-
I ;».
01 I
01 I
L_ ,--, ,-
I I I
v
PLAN
342
~
CORNER COLUMN
See®@@
in CD-07.03
0 1 (See detail A)
ELEVATION
I~Im
Ill
I
I I
I~ I
I ___l --m-_J
l S0.25 d ,-
I "',,.
01 I
01 I
L_ ,--, ,-
I I I
v
PLAN
DETAIL A
CD-07.06 NOTES
1. RECOMMENDATIONS
1. The symbol dis the effective depth in the respective direction.
2. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
3. L1 is the cj>1 bar anchorage length.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
343
CD - 07.07 FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 3) (1 of 2)
\
I
\
A) INTERNAL COLUMN
®
©
B) EDGE COLUMN
®
©
See detail 1
®
See detail 1
®
344
CD- 07.07 NOTES
1. RECOMMENDATIONS
1. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
2. r1 = 2.5 cm ;:>: cj>8 • r3 ;:>: cJ>c·
r2 ;:>: cj>A. r4 = 2.5 cm;:>: cj>0 •
3. Particular attention should be paid to vibration near and underneath the profiles.
2. STATUTORY LEGISLATION
This type of solution is not envisaged in EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
345
CD-07.07 FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 3) (2 of 2)
C) CORNER COLUMN
®
See@@©
in CD-07.03
See detail 1
©
0
r2
r l_
31
I
0o 0c
DETAIL 1
®
®
0A
0s
_l r ,1
r I
I
I
I
,r4
I
346
CD-07.07 NOTES
1. RECOMMENDATIONS
1. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
2. r1 = 2.5 cm 2 <j>8 • r3 2 <l>c·
r2 2 <j>A. r4 = 2.5 cm 2 <j>0 •
3. Particular attention should be paid to vibration near and underneath the profiles.
2. STATUTORY LEGISLATION
This type of solution is not envisaged in EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
347
CD-07.08 FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 4) (1 of2)
INTERNAL COLUMN
Studs with
base rail
S0.75 d
S0.75 d
Sd/2
SECTION A-A
348
Av = cross-sectional
area of studs on a
peripheral line
CD- 07.08
1. RECOMMENDATIONS
None.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
NOTES
349
CD - 07.08 FLAT SLABS. PUNCHING SHEAR REINFORCEMENT
(VARIATION 4) (2of2)
Slab edges
EDGE COLUMN
Slab edges~-----------
CORNER COLUMN
350
CD - 07.08
1. RECOMMENDATIONS
None.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
NOTES
351
FLAT SLABS.
DROP PANELS CD-07.09
Construction joint
Spacer
INTERNAL COLUMN
See@@©
Construction joint
Spacer
EDGE OR CORNER COLUMN
352
End
spacer
R=20 or 3.50
R
CD - 07.09
1. RECOMMENDATIONS
1. L4 =10$1•
2. r1 =2.5cm;?:$1 •
r2 = 2.5 cm;::: $1.
NOTES
3. For column transition details, depending on whether tan a is smaller or greater than 1/6, see CD - 03.04 to
CD-03.14.
4. While column ties are not needed in the node or drop areas of inner columns, they are necessary in edge
and corner columns.
5. See EC2, anchorage lengths, to calculate lengths L1 and L2 in details a, b and c.
6. See Recommendation 5 in CD - 06.02 for the procedure to calculate L3 .
7. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
353
CD-07.10
FLAT SLABS.
COLUMN WITH DROP AND HEAD
Construction joint
5cm
Q:s~~==~=f======~~~~~i:=::-j~- 0 r1
2Dmin.
n02 bars
distributed evenly
along the side
surface
D
354
r2
CD - 07.10 NOTES
1. RECOMMENDATIONS
1. See the Recommendations for CD- 07.09.
2. r3 = 2.5 cm.
3. r4 ~ <1>2·
4. Length L5 is the <1>2 bar anchorage length.
5. Ties are not needed in the upper part of the head, the drop or the slab.
6. See CD - 07.03 and CD - 07.04 for concrete cover and other details.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
355
CD-07.11
I
I CD I
0
0
I CD I
l
FLAT SLABS. OPENINGS
(VARIATION 1)
l
I CD I
LJ
0
I CD I
J
[] l_~D DO~_: El
PLAN
201
~
<!> 4 est. 0 3
Q;Q;
as cm
20
202 HOOK 90° BEND
SECTION A-A STIRRUPS
356
CD-07.11 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and general details.
2. Width b may be larger than the normal rib width in the edge area. If necessary around the supports, fill area
1 totally or partially with concrete.
3. Length Lis the length of the <1> 1 (top) and <1>2 (bottom) reinforcing bars.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
357
CD - 07.12
- + -
- + -
a
c
FLAT SLABS. OPENINGS
(VARIATION 2) (1 of2)
I
-[±J-
I
I
-[±J-
I
PLAN
358
CD - 07.12 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and general details.
2. The header width in the support areas may be greater than the rib width. In this case, areas 1 or 2 must be
totally or partially filled in with concrete.
3. Lengths L1 , L3 and L5 are the anchorage lengths of the cj>1, cj>3 and cj>5 bars, respectively.
4. To calculate lengths L3 , L4 and L6 , see Recommendations 5 and 6 in CD - 06.02.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
359
CD- 07.12
FLAT SLABS. OPENINGS
(VARIATION 2) (2 of2)
-----,
Lacing
course C-D
I
I
Lacing course C-D Lacing course C-D
L1
LACING COURSE A-B
Lacing course C-D
I L4 II s cm
Strp 07
SECTION 1-1
Lacing course C-D
203 L
~
\ I
r--­
' I
Lacing course A-B
LACING COURSE C-D
Lacing course A-8
,----
' I
LACING COURSE E-F
360
.s-e
~~0004
HOOK 90° BEND
STIRRUPS
Lacing course C-D
-------,
I
I
SECTION 3-3
Str 0 9
CD-07.12 NOTES
1. RECOMMENDATIONS
1. See CD - 07.04 for concrete cover and general details.
2. The header width in the support areas may be greater than the rib width. In this case, areas 1 or 2 must be
totally or partially filled in with concrete.
3. Lengths L1, L3 and L5 are the anchorage lengths of the cj>1, cj>3 and cj>5 bars, respectively.
4. To calculate lengths L3, L4 and L6, see Recommendations 5 and 6 in CD - 06.02.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (30).
361
Group 08
Stairs
STAIRS.
GENERAL LAYOUT DETAILS
CD - 08.01
A) TREAD AND RISER DIMENSIONS
(a) (b) (c)
nh :____] ,rh j.··.··:__J·· ....
c ~ . c
.. ... ... ...
:<:::·::·:::.::.::·::
tan a= c/h
Most common expressions relating tread and riser c and h
CD (Blondel) h + 2c = k { k = 59 cm (residential buildings)
k = 66 cm (public buildings)
~ (Neufert) 2c + h = 61 to 64 cm
or h-c=12cm
B) LANDINGS
Facade
® j(]
Edge
beam
PLAN
(a) (b)
Facade
© J[J
Edge
beam PLAN
(a) (b)
Facade
© j(]
Edge
beam PLAN
(a) (b)
364
CD - 08.01 NOTES
1. RECOMMENDATIONS
1. Construction details vary depending on the landing solution chosen, particularly in the landing itself.
2. STATUTORY LEGISLATION
Some countries have nationwide and others merely municipal codes.
3. SPECIFIC REFERENCES
See Chapter 62 in (30).
365
STAIRS.
REINFORCEMENT SCHEME FOR DOUBLE FLIGHT
CD-08.02
See detail A
See@@©
---------~---"
i· ..-+r )--------
\_ /
End spacer
r c-01
DETAIL A DETAIL OF CONCRETE STEPS
r--.s__-1
=f=r2 +r2 ~r2
r1 T R
L' l
r1
@ ® ®
366
CD-08.02
1. RECOMMENDATIONS
1.r1 = 2.5 cm~ <1>1 .
r2 = 2.5 cm ~ <1>1'
r3 = 2.5 cm ~ <j>3•
NOTES
2. See EC2, anchorage lengths, to determine when to use anchor type a, b or c at the end of the <1> 1 reinforcing
bar.
3. See Recommendation 5 in CD - 06.02 for the procedure to calculate L3•
4. Where the steps are to be made of concrete, the <j>6 , <1>2 and <1>3 reinforcing bars should be spaced equally for
attachment of the <1>6 and <l>5 bars during concrete pouring.
5. Concrete is laid from the bottom up in stairs.
6. The top of the stairs is smoothed with a float or power float, unless the design calls for some special treat­
ment.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See (30), Chapter 62.
367
CD-08.03 STAIRS. REINFORCEMENT ARRANGEMENT FOR
STAIRS WITH THREE FLIGHTS
A
B
PLAN SECTION A-A
SECTION B-B
See detail A
~ElEl ___ @_@_®>---"
1: -, 1----
"-__ _/
See detail B
End spacer
I
I \-01
~~~~~r2
-i~~~+.~ ~r3
\_03
DETAIL A
®
h
SECTION C-C
End spac~r
011°1
1==;-r=t-'="-'====='--1----~--ll --l t r 2
l==='--'-'====;;=====c-T------/"'-H l r 3
' I r
~----+"-'··~--+- \ I
If 03 09
DETAIL B
®
368
See detail A
---·-·-·------·-·-----·-
---~!
--:;;o=-~=:t:::::::::it=;:::;-"·)
DETAIL OF CONCRETE
STEPS
®
CD-08.03
1. RECOMMENDATIONS
1. See CD - 08.02.
2. STATUTORY LEGISLATION
See CD - 08.01.
3. SPECIFIC REFERENCES
See Chapter 62 in (30).
NOTES
369
CD-08.04
A
/
/
/
/
/
/
/ /
/ / / /
/ /
/ / /
/ / /
STAIRS.
FOUNDATION FOR STARTING FLIGHT
Construction joint -
/ / /
/ / /
/ / /
/ / /
/
/
, B
/
/
/
/
/
/
/
/
/
/ / / / ;//:
/ / / ,/ /~//
Plain concrete footing
370
CD-08.04 NOTES
1. RECOMMENDATIONS
1. See CD - 08.02.
2. L1 is the lap length in the ~1 bar and L2 is the lap length in the ~2 bar.
3. Plane AB is a construction joint plane on which the rebar rests.
4. Dimension L3 varies depending on the forms used for the stairflight, but should not be less than 1 O cm.
2. STATUTORY LEGISLATION
See CD - 08.01.
3. SPECIFIC REFERENCES
See Chapter 62 in (30).
371
CD- 08.05
SECTION 8-8
End spacer
FLYING STAIRS
(1 of 2)
SECTION A-A
372
CD- 08.05
1. RECOMMENDATIONS
1. r1 = 2.5 cm ~ tj>5 .
r2 = 2.5 cm~ tj>3 •
r3 = 2.5 cm~ tj>1•
r4 = 2.5 cm~ $1•
2. If the cantilevered landings are exposed, r1 = 3 cm.
3. Concrete is laid in the stairflight of stairs from the bottom up.
4. The top of the stairs is smoothed with a float or power float.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See Chapter 62 in (30).
373
NOTES
CD-08.05
SECTION C-C
FLYING STAIRS
(2of2)
DETAIL OF CONCRETE STEPS
374
CD-08.05
1. RECOMMENDATIONS
1. r1 = 2.5 cm ~ $5•
r2 = 2.5 cm~ $3•
r3 = 2.5 cm~ $1.
r4 = 2.5 cm~ $1•
2. If the cantilevered landings are exposed, r1 = 3 cm.
3. Concrete is laid in the stairflight from the bottom up.
4. The top of the stairs is smoothed with a float or power float.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See Chapter 62 in (30).
375
NOTES
Group 09
Bearings
BEARINGS.
DEVICE FOR CENTRING LOADS CD-09.01
See@@©
5cm/ ----11-
/
'X
~
'i
..___
~-1.
'
•••••
, I
l j,
End spacer Space
""'---;- ; ~---
~ I ~Smooth fibre ceme
I or elastomer strip
@) End spac nt, lead
I
I Spacer
I
I
I
~
r
ELEVATION @
Spacer
I /
I I I
I I - -
I
I
I I
I I
I I
~,... ~,...
I I I
I I I
~R
I
~ Spacer
j
PLAN r
©
378
CD - 09.01 NOTES
1. RECOMMENDATIONS
1. See CD - 05.01 for concrete cover and general details.
2. See 1.5 to determine when to use a, b or c for anchorage of the bottom reinforcement.
3. The bearing strip can be held in position by setting it in a layer of plaster on the top of the column. The plas­
ter, which serves as a bed for the formwork, is subsequently removed. Alternatively, an appropriate glue may
be used.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See (30).
379
CD- 09.02
03
01
Spacer
a
a
b
ELEVATION
b
PLAN
(VARIATION 1)
BEARINGS.
CONFINEMENT FOR LINEAR LOADS
b
Elastomer bearings
WL-1
PLAN
50~50~
~
01
HOOK 90° BEND
r1
Spacer ~1 50~50mm e
---+-+--r2 HOOK
STIRRUP BEND RADII
l~---H--~++--+1-~--tt----t--'<-~03
380
PLAN
(VARIATION 2)
01
CD-09.02
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
r2 ~ <1>1·
NOTES
2. The bearing pad can be held in position by setting it in a bed of plaster on the top of the column. The plaster,
which serves as a bed for the formwork, is subsequently removed. Alternatively, an appropriate glue may be
used.
2. STATUTORY LEGISLATION
See EC2.
3. RECOMMENDED ALTERNATIVE CODES
See EN 1337-1 (34), EN 1337-3 (35).
4. SPECIFIC REFERENCES
See (30).
381
CD - 09.03
End spacer
BEARINGS.
ELASTOMER BEARINGS
5cm
See@@©
in CD-09.01
------~.~~~~~
'
Spacer
'
\
End spac~~-
Spacer
-~
5cm
!I
382
Spacer
ELEVATION
VARIATION 1
See@@©
in CD-09.01
ELEVATION
VARIATION 2
CD- 09.03 NOTES
1. RECOMMENDATIONS
1. To hoop the bearing, the solution set out in CD - 09.01 may suffice, or the arrangement in CD - 09.02 may
be required.
2. The purpose of the second solution is to prevent the bearing from 'creeping' in the event of longitudinal varia­
tions in the lintel due to thermal effects or creep.
2. STATUTORY LEGISLATION
See EN 1337-1 (34) and EN 1337-3 (35).
3. SPECIFIC REFERENCES
See (30).
383
CD-09.04 FLAT JACK HOUSING TO CHANGE BEARINGS
Cast-in-place concrete slab
-\
\
Precast girder
-\
I
SECTION
Housing for flat jacks to
/ change bearings
Spac~_;c::=::::::========!=========~==!:==;::::===
DETAIL
384
CD-09.04 NOTES
1. RECOMMENDATIONS
1. Provision for housing flat jacks may often be advisable to change bearings in precast girder bridges.
2. Dimension L should be established in accordance with the flat jacks to be used.
3. r1 = 2.5 cm.
r4 = 2.5 cm.
r2 = 2.5 cm;:: <j>6 •
r5 = 2.5 cm ;:: <j>4 .
2. STATUTORY LEGISLATION
See EN 1337-1 (34) and 1337-3 (35).
3. SPECIFIC REFERENCES
See (30).
385
r3 = 2.5 cm;:: <j> 1•
r6 = 2.5 cm;:: <j>4 .
CD- 09.05
A ..
-
-
\
\
==
0 4-----<--++-- ······-·-- -.
\
\
BEARINGS.
PLASTIC HINGE
' '
Spacer
.... _J
Spacer
~~~~~~~~~~~~
... \L -~ . -·-03
~~~~~~~~~~
02--+--++----_l
\ <----++--->+-- --++---++----~-- 01 + 0 4
01
__ a _ _j b
ELEVATION
s0;::: 50 mm
~~
HOOK 90° BEND
HOOK
TIES
03
Spacer\
VIEW FROM A
0 4 ---==t--tt:r
fl=7'=71r==~"'==~-~~fl
b
---- -----i
PLAN
386
a
CD-09.05 NOTES
1. RECOMMENDATIONS
1. r1 =2.5 cm.
2. r2 2 <j>1 •
3. The <j>4 bars may not be necessary, depending on the case.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See (30), (39), (37).
387
Group 10
Brackets and dapped-end beams
CD-10.01
{~
{ ~====1~====+¥
~~~,~--'++---r1
-r3
ELEVATION
BRACKETS
(VARIATION 1)
A
'
~
/
--
~
/
+ ---
A
J I
--
A
'
SIDE VIEW
02~
.lo
I
PLAN SECTION A-A
Constructio
joint
-03
1,,
A
ARRANGEMENT ALTERNATIVES FOR THE 0 3 REINFORCING BAR
®
0 3 Detail1 ,,,-,,r-
=~;t;::;;;J;:l ~ j
"'-- '
DETAIL 1
~--,,,___.,..~ Welded off cuts
from the
0 3 reinforcing
!...:::::::::=:::::::::::::=~bar
PLAN
390
ELEVATION 0
/~ 3
®
PLAN
n
CD-10.01 NOTES
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
2. r2~~1·
3. r3 ~ ~2·
4. r4 ~ ~3·
5. r5 ~ ~3 . If the top of the bracket is exposed to rain or condensed water, r5 = 3 cm.
6. L1 is the ~1 bar lap length.
7. L2 can be calculated as per EC2, anchorage lengths.
8. The top of the bracket is smoothedwith a float or power float.
9. See 1.4 for welding details.
10. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (38) and (39).
391
CD- 10.02
BRACKETS
(VARIATION 2) (SUSPENDED LOAD)
0 1 -
I
1
Ll
I
I
LzI
0
I v
3_/
____,,,/
0 2-
I
s T
A
r -01
- __lj
/ l
Js1
" l r4
~ --scmH-1
''
'\_
~ ~
/ ~~ /
/
" ~ 11003
~02
r1 - -
A
r - >----
r3
ELEVATION
PLAN
=r::
r1 I
l
Js3
I
392
-
-
-
• A
A
r
-~
~ L1
v
./ -
---.
A ...... ......
A
y
SIDE VIEW
SECTION A-A
Constructi
joint
on
CD- 10.02 NOTES
1. RECOMMENDATIONS
1. For cover specifications, see CD - 10.01.
2. L1 is the $1 bar lap length.
3. L2 can be calculated as per EC2, anchorage lengths.
4. L3 is the lap length in the larger of the reinforcing bars, $1 or $4 .
5. The top of the bracket is smoothed with a float or power float.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (38) and (39).
393
BRACKETS. CD- 10.03
DOUBLE BRACKET
See detail 1 for __ _
the 0 2 reinforcing
bar
r2
-ri-
l i -y-01
Construction
joint----
S3
~~+==+===lr=n===;7Y-1t
--03
~=~,~Y +- /1003
S2! "~-02
+-~~r--~
---H-­
r3
ELEVATION
r2 r2
-H-- -H-
~='===#'11 _ 7 _ 0 1 Construction
·/" joint
'1t====:f. r1 - - --
f - S1
,scm
~c----~._._,-=t 1 r,
1-~i='==f'~imf-1
S3;
-----02
03
-1-
~=l=~ml' S acer
03----·
SIDE VIEW
394
PLAN
50
rR=20
or 3.50
02
DETAIL 1
CD- 10.03 NOTES
1. RECOMMENDATIONS
1. r1 2 2.5 cm.
2. r2 2 <j>1•
3. r3 2 <j>2 •
4. r4 2 <j>3 •
5. r5 2 <j>3• If the top of the bracket is exposed to rain or condensed water, r5 = 3 cm.
6. L1 is the <1>1 bar lap length.
7. The top of the bracket is smoothed with a float or power float.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
4. SPECIFIC REFERENCES
See (38) and (39).
395
CD - 10.04 DAPPED-END BEAMS
L2
L1
I f3
~01(03 - >----
I r1 I - ~
r3 r=
1 t f
L3l
I
"
II
04---+--+--·ll
rz 1= I I
Spacer I L r1 l
02
ELEVATION
PLAN
396
CD- 10.04
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
r2 2 ~2·
r3 2 ~1·
2. Care should be taken with regard to inward deviation in the vertical zones of the ~2 bar.
3. L1 is the ~3 bar lap length.
4. L2 is the ~ 1 bar lap length.
5. L3 is the ~2 bar lap length.
6. For bearings, see CD - 09.01 to CD - 09-04.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. SPECIFIC REFERENCES
See (39).
397
NOTES
Group 11
Ground slabs and galleries
GROUND SLABS.
TYPICAL SECTION CD- 11.01
Chair
_l
L------++-----~r------===J r1
Ground slab
Possible
water vapour
barrier
Subbase
400
CD-11.01 NOTES
1. RECOMMENDATIONS
1. Welded-wire mesh is normally used for ~1 to s1 grids (# ~1 to sJ
2. Inter-mesh lapping need be no greater than 20 cm in any direction.
3. r1 = 5 cm. (This is to ensure that the gravel will not roll over the transverse wires as the slab is finished with
a vibrating screed.)
4. A water vapour barrier will be needed if moisture-sensitive materials are to be stored on the slab.
5. The percentage of silt in the subbase should ensure a smooth post-compaction surface.
6. The equipment needed for the surface finish must be specified.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
401
CD-11.02
Wall
Wall
GROUND SLABS.
JOINTS (1 of 2)
Separation
joint
Transverse
contraction joint
Column
L See detail A
Column
Separation joint
See detail B
Longitudinal contraction
joint
Expansion joint
GENERAL LAYOUT. PLAN VIEW
20mm
Separation joint
Com ressible fill
DETAIL A
Chair
~round slab
/ ;-= Possible
water vapour
barrier
WALL SEPARATION JOINT
402
CD- 11.02 NOTES
1. RECOMMENDATIONS
1. Welded-wire mesh is normally used for <j>1 to s1 grids{# <j> 1 to s1).
2. Inter-mesh lapping need be no greater than 20 cm in any direction.
3. A water vapour barrier will be needed if moisture-sensitive materials are to be stored on the slab.
4. The percentage of silt in the subbase should ensure a smooth post-compaction surface.
5. The equipment needed for the surface finish must be specified.
6. The maximum distance between contraction joints is 7 m.
7. The maximum distance between expansion joints ranges from 20 m to 40 m, depending on the climate.
8. A subbase should be laid between the slab and the top of the footing to avoid direct contact that would cause
the slab to crack.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
403
CD-11.02
GROUND SLABS.
JOINTS (2 of 2)
Separation 'oint
Contraction 'oints
DETAIL B
COLUMN SEPARATION JOINT
Joint seal
Ground slab
Compressible
fill
ELEVATION (VARIATION 1)
REINFORCEMENT 0 2
404
Possible water
vapour barrier
Joint seal
Compressible
fill
ELEVATION (VARIATION 2)
SECTION A-A
CD- 11.02 NOTES
1. RECOMMENDATIONS
1. Welded-wire mesh is normally used for q,1 to s1 grids(# <1>1 to s1).
2. Inter-mesh lapping need be no greater than 20 cm in any direction.
3. A water vapour barrier will be needed if moisture-sensitive materials are to be stored on the floor.
4. The percentage of silt in the subbase should ensure a smooth post-compaction surface.
5. The equipment needed for the surface finish must be specified.
6. The maximum distance between contraction joints is 7 m.
7. The maximum distance between expansion joints ranges from 20 m to 40 m, depending on the climate.
8. A subbase should be laid between the slab and the top of the footing to avoid direct contact that would cause
the slab to crack.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
405
CD-11.03
®
®
©
@
GROUND SLABS.
CONTRACTION JOINTS
Joint, cut and sealed
Induced crack
Wood or lastic
shape
Min.0.2 h
Min.0.2 h
TRANSVERSE CONTRACTION JOINT
I\
I I
I \
I I
LONGITUDINAL CONTRACTION JOINT
Joint, cut and sealed
Induced crack
I\
I I
I I
I I
Wood or lastic
shape
Min.0.2 h
Min.0.2 h
I\
I I
I I
I
TRANSVERSE CONTRACTION JOINT
Joint, cut and sealed
Induced crack
Min.0.2 h 0
~---- 1
I\
I \
Min.0.2 h
I\
I \
I I
I I
Plan bar. The right half should
be greased or painted to
prevent bonding
Wood or plastic
shape
3020 per metre
TRANSVERSE CONTRACTION JOINT FOR
HEAVY LOADS
406
Chair
Chair
CD- 11.03 NOTES
1. RECOMMENDATIONS
1. Welded-wire mesh is normally used for <j>1 to s1 grids (# <j> 1 to s1).
2. Inter-mesh lapping need be no greater than 20 cm in any direction.
3. A water vapour barrier will be needed if moisture-sensitive materials are to be stored on the floor.
4. The percentage of silt in the subbase should ensure a smooth post-compaction surface.
5. The equipment needed for the surface finish must be specified.
6. The maximum distance between contraction joints is 7 m.
7. The maximum distance between expansion joints ranges from 20 m to 40 m, depending on the climate.
8. Variations A and Bare not recommended where traffic is heavy.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVECODES
See ACI (40).
407
CD- 11.04
Sealing JQ__in_t __
Compressible fill
h/2i
\
GROUND SLABS.
EXPANSION JOINTS
Plastic tube, closed
at one end
t---
h/2f
I\
I\
I I
I \
I I
.....---......~-l
======r~~l====T~~ I
Subbase
l
I
J
! 20mm
3020 per metre. Smooth bar. The right
half should be greased or painted to
prevent bondin~L __
(These bars are not necessary where
traffic is light or non-existent)
408
!
CD- 11.04 NOTES
1. RECOMMENDATIONS
1. Welded wire mesh is normally used for cj>1 to s1 grids (# cj> 1 to sJ
2. Inter-mesh lapping need be no greater than 20 cm in any direction.
3. A water vapour barrier will be needed if moisture-sensitive materials are to be stored on the floor.
4. The percentage of silt in the subbase should ensure a smooth post-compaction surface.
5. The equipment needed for the surface finish must be specified.
6. The maximum distance between expansion joints ranges from 20 m to 40 m, depending on the climate.
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
409
CD -11.05
2h
2h
GROUND SLABS.
STRENGTHENING FREE EDGE OF SLAB
2h
410
f-- __ 2_h __ --i
I
~Se
CD- 11.05 NOTES
1. RECOMMENDATIONS
1. The edge should be strengthened when it is exposed to rain-induced softening the subbase.
2. In addition, the surface of the ground around the area strengthened may also be sealed.
3. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
411
CD- 11.06
©
GALLERIES.
DUCTWAYS
Spacer
412
r3 - BREAKDOWN OF THE
0 1 LONGITUDINAL
REINFORCING BAR
CD- 11.06
1. RECOMMENDATIONS
1. The details refer to galleries and ductways to house ducts or machinery.
2. r1 = 5 cm.
r2 = 5 cm. A thicker cover may be needed if required by the supports for the lids.
r3 = 7.5 cm.
r4 = 7.5 cm.
3. See CD - 11 .01 for all other cover specifications.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI (40).
413
NOTES
Group 12
Chimneys, towers and cylindrical
hollow columns
CD- 12.01 CHIMNEYS, TOWERS AND CYLINDRICAL HOLLOW
COLUMNS. GENERAL LAYOUT
See CD-12.03 ,.r-.-~.
See CD-12.04
- --------y m-:i=:~
See CD-12.05
~
See CD-12.07
See CD-12.03
See CD-12.06
.A
(See CD-12.02)
I
Se~g_c:>_~J~. ()~_/
416
.A
(See CD-12.02)
CD- 12.01 NOTES
1. RECOMMENDATIONS
1. This group addresses details specific to this type of structure only. See also Group 01, Group 04 and Group
10.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
417
CD- 12.02
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS.
GENERALARRANGEMENTOFREINFORCEMENT
COVERS
LL IL2 L2I =ry
I'.
\
~Constr uction
. • joint
•
• •
•
•
~
~ '• =ry I =12 L2L ' •
7 ------ .....
•
Construction /
I
•
joint •
VERTICAL SECTION
See lap reinforcement detail in CD-12.10
418
CD-12.02
1. RECOMMENDATIONS
1. r1 = 2.5 cm.
~ = {:::: 2.5 cm (in submerged columns = 4 cm)
2 ;::: 4>4
(Attention should be paid to operating temperature-related requirements.)
r3 ;::: 4>1 ·
r4;::: 4>2·
NOTES
2. L1 is the cj>1 bar lap length, L2 is the cj>2 bar lap length, L3 is the cj>3 bar lap length and L4 is the cj>4 bar lap length.
See CD-12.10 for lap distribution.
3. Where the cj>1 and cj>2 bars cantilever (see CD-12.10), the assembly should be duly stiffened during construc­
tion to prevent oscillation under wind action, which would break the bond with the concrete.
4. The horizontal joints should not be smoothed, for a rough surface such as is generated by the vibrator is
needed. They should be cleaned and moistened and their surface allowed to dry before concrete pouring is
resumed.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
419
CD- 12.03
Construction
joint
#09to s2
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS.
CROWN DETAILS
@CHIMNEY
Chair
~------,
I
I I
I I
I
I \
I
\
2005
Spacer
Iorio
~
\
\Construction
~~~------~ ~------~~~ joint
@TOWER
4 cm I I : 3 cm
DETAIL A
420
CD- 12.03
1. RECOMMENDATIONS
1. See CD - 12.02 for cover specifications.
2. The <j>5 bars should be covered with 3 cm of concrete.
3. r5 = 2.5 cm~ <j>8 .
r6 ~ 2.5 cm+ <j>8 .
re= r? + <l>g·
4. The top in A is smoothed with a float or power float.
NOTES
5. If the transverse slope on the slab in B is under 3 per cent, the cover over <j>3 should be 3 cm.
6. The slab surface in B is smoothed with a float or power float.
7. The horizontal joints should not be smoothed, for a rough surface such as is generated by the vibrator is
needed. They should be cleaned and moistened and their surface allowed to dry before concrete pouring is
resumed.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
421
CD- 12.04
Construction
joint
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS.
b
BRACKET TO SUPPORT LINING
Construction
joint
VERTICAL SECTION
422
Spacer
CD-12.04 NOTES
1. RECOMMENDATIONS
1. See CD - 12.02 for cover specifications.
2. The cover over the q,11 bar must be at least 3 cm, but may be conditioned by the chimney operating tempera­
ture.
3. Since the q,11 bars are tied to the <j>1 bars, their positions must be coordinated.
4. The top of the bracket is smoothed with a float or power float.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
423
CD-12.05 CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS. DUCT INLETS
, ,
' ' v /~\ \
II /! \\ \ \
~]L,
IL3
_____ L
\ \ \, y I I/
\ I\ ~ I I
' ' '
, ,
ELEVATION DETAIL A
Spacer
PLAN
424
CD-12.05 NOTES
1. RECOMMENDATIONS
1. See CD - 12.02 for cover specifications.
2. L, is the lap length in the larger of reinforcing bars <j>4 or <1>13'
3. L2 is the lap length in the larger of reinforcing bars <j>3 or <j>13•
4. Diameter <j>13 is equal to the larger of <j>3 or <j>4 •
5. On the outer surface, L3 is the lap length of the <1>1 bars, and on the inner surface, L3 is the lap length of
the <1>2 bars.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88(41).
4. SPECIFIC REFERENCES
See (42).
425
CD-12.06
Construction
joint
Spacer
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS.
CIRCULAR SLAB AROUND THE TOP
See detail A
/ . See detail B
~;::::;:;;;:=;;;~
i-------
a
VERTICAL SECTION
(See @@@) in CD-05.02)
~/
0 4 (circumferential)
DETAIL A DETAIL B
426
CD-12.06
1. RECOMMENDATIONS
1. See CD - 12.02 for concrete cover specifications and general details.
2. r1 = 2.5 cm ~ <j>1•
If the top is horizontal and exposed to rain or condensed water, r1 = 3 cm.
r2 s <1>2·
r3 = 2.5 cm~ <j>3 .
r4 ~ <1>4·
3. The <j>1 reinforcing bars are tied to the outer horizontal bars.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
427
NOTES
CD- 12.07
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOWCOLUMNS.
CIRCULAR SLAB FOUNDATIONS
See detail A
\
\
Special chair
----\
(See CD-01.06)
ELEVATION
Construction
'-----+--
joint
Blinding
(See CD-01.01)
DETAIL A
428
CD-12.07 NOTES
1. RECOMMENDATIONS
1. See CD - 12.02 for general cover specifications.
2. See CD - 01.06 for cover specifications for the foundation.
3. See CD - 01.01 for the wall springing at foundation level.
4. See CD - 01.05 and CD - 01.06 for the reinforcement in the circular foundation.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
429
CD- 12.08
06 to S1
/(M~asured on
; outer edge)
DETAIL A
Blinding
CHIMNEYS, TOWERS AND
CYLINDRICAL HOLLOW COLUMNS.
ANNULAR FOOTINGS
ELEVATION
3071 h
i
'
DETAIL B
The 0 5 reinforcing bars are placed circumferentially
The 0 6 reinforcing bars are placed radially
HOOK
(See CD-01.01) 90° BEND
DETAIL C
STIRRUPS
430
CD-12.08
1. RECOMMENDATIONS
1. See CD - 12.02 for general cover specifications.
2. r1 = 2.5 cm.
r2 = 2.5 cm + <j>6•
r3 = 7.5 cm if the concrete is poured directly against the soil.
r4=r3+<l>s·
r5 = 2.5 cm ~ <j>6.
rs s <l>s·
3. The top is smoothed with floats or a power float.
NOTES
4. The horizontal joints should not be smoothed, for a rough surface such as is generated by the vibrator is
needed. They should be cleaned and moistened and their surface allowed to dry before concrete pouring is
resumed.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (12) and (42).
431
CD - 12.09
100 mm 0
pipe
plastic
CHIMNEYS, TOWERS AND CYLINDRICAL HOLLOW
COLUMNS. PLASTIC WATER INFLOW PIPES IN
SUBMERGED HOLLOW COLUMNS
A f-i
2012
I
;f'_ .~ II
'\_ .,J
~
I~ 2012
A ._J
ELEVATION
432
0
12 mm0
off cuts
SECTION A-A
CD-12.09 NOTES
1. RECOMMENDATIONS
1. See CD - 12.02 for general cover specifications.
2. The plastic pipes should be stiff and thick enough to withstand the pressure of fresh vibrated concrete without
warping. They should be provisionally lidded to prevent the concrete or grout from flowing inside during con­
crete placement.
3. In columns in rivers or reservoirs, the pipes should preferably be placed on the downstream side to reduce the
risk of clogging due to substances carried by the water.
4. See 1 .2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
433
CD- 12.10 CHIMNEYS, TOWERS AND CYLINDRICAL HOLLOW
COLUMNS. REINFORCEMENT LAPS
REINFORCEMENT LAP
@ VERTICAL BARS
l
Maximum percentage of
lapped bars in the same
horizontal section:
33%
AR. Vertical centre-to-centre
distance between lap
series:
- - - I- - f-- -- f----- --·- ·-· ·--·· ~
v
ELEVATION
@ HORIZONTAL BARS
I lii21~2 i L~2 I lii2 i lii2 I
' I
I I I
I '
ELEVATION
A T
v
434
Maximum percentage of
lapped bars in the same
vertical section:
33%
AR. Horizontal centre-to-centre
distance between lap
series:
CD - 12.10 NOTES
1. RECOMMENDATIONS
1. Cantilevered bars should be duly stiffened during construction to prevent oscillation under wind action, which
would break the bond with the concrete.
2. The specified spacing refers to both the inner and outer sides.
3. Laps may concur on the two sides.
4. See Recommendation 4 in CD - 12.02 for construction joints.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
None in place.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 307-88 (41).
4. SPECIFIC REFERENCES
See (42).
435
Group 13
Silos, caissons and rectangular
hollow columns
CD - 13.01
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. SILO SECTIONS
\ ~
- ___,<\ See CD-12.03
See@
---~I'.
I 1....----'-'-'T--\----'-'----.
~ I _ _,/
ELEVATION
£
~ ./"
"~
'\.
\\
Possible bar \
for slipform \
@ CIRCULAR SILO
\
\ \LeJ
\ 3
\
Eventual bar \
for slip form .
@ CIRCULAR SILO
~
~
"'
,#
v,
I
7 \§pacer
@ RECTANGULAR SILO @ FOOTING
438
Construction
joint
(See CD-01.01)
CD - 13.01
1. RECOMMENDATIONS
1. r1 = 2.5 cm or 3 cm, depending on the case (see EC2, Table 4.1 ),
but always ~ <j>2 .
r2 ~ <1>1·
r3 = 2.5 cm or 3 cm, depending on the case (see EC2, Table 4.1 ),
but always ~ <j>4•
r4 ~ <1>3·
2. See the recommendations in CD - 12.03 for the roof slab.
3. See CD - 01.01 for the wall springing at foundation level.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and ACI 350.2R (44).
439
NOTES
CD- 13.02
0
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. INTERSECTIONS AND CONNECTIONS
(Horizontal Sections) (1 of 2)
INTERSECTION IN CIRCULAR SILOS
®
CORNERS OF RECTANGULAR SILOS
r -04
04
04
03
04 #2
#
0/1 r2
~~~~~~#
~~~~~0#
02 1 r3 r4 -01 02 r3 r4
02
§
04
02
r1 r2
#
#
02 r3 r4
440
CD- 13.02 NOTES
1. RECOMMENDATIONS
1. See CD - 13.01 for general cover specifications.
2. In details C-1 and C-2, the angled «1>2 bars overlap with the straight «1>2 bars along their lap length.
3. L1 is the $5 bar lap length and L2 is the $2 bar lap length.
L3 is the lap length in the larger of the reinforcing bars, $4 or $6, and L4 is the lap length in the larger of the «1>2
or $6 bars.
4. Diameter $6 is equal to the larger of $2 or $4 •
5. L5 is the $6 bar lap length.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and ACI 350.2R (44).
441
CD- 13.02
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. INTERSECTIONS AND CONNECTIONS
(Horizontal Sections) (2of2)
CONNECTION IN RECTANGULAR SILOS (Horizontal Sections)
_s~pacer. 0 6
442
CD- 13.02 NOTES
1. RECOMMENDATIONS
1. See CD - 13.01 for general cover specifications.
2. In details C-1 and C-2, the angled $2 bars overlap with the straight $2 bars along their lap length.
3. L1 is the $5 bar lap length and L2 is the $2 bar lap length.
L3 is the lap length in the larger of the reinforcing bars, $4 or <j>6, and L4 is the lap length in the larger of the <j>2
or <j>6 bars.
4. Diameter <j>6 is equal to the larger of $2 or <j>4 •
5. L5 is the <j>6 bar lap length.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2.
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and ACI 350.2R (44).
443
CD- 13.03
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. PLASTIC WATER INFLOW PIPES IN
SUBMERGED COLUMNS
100 mm 0 plastic
A~
/pipes
~
~ I/ ~
I
-,.. fe12
! /
-,..
r;~,
' ~ __.} ' /
/
/ \
' /
\ 12mm0
~-
off cuts
; ' \
\ 2012
-~ ~~
~
~ ~
A~
ELEVATION SECTION A-A
444
CD-13.03 NOTES
1. RECOMMENDATIONS
1. See CD - 13.01 for general cover specifications.
2. The plastic pipes should be stiff and thick enough to withstand the pressure of fresh vibrated concrete without
warping. They should be provisionally lidded to prevent the concrete or grout from flowing inside during concrete
placement.
3. In columns in rivers or reservoirs, the pipes should preferably be placed on the downstream side to reduce
the risk of clogging due to substances carried by the water.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
445
CD - 13.04
ELEVATION
PLAN
DETAIL A
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS.HOPPERS
See detail A x I
I
\ I
" J I f------""'~
-~~Se~ilB
See CD-01.21
Columns supporting
the hopper
446
HOPPER SECTION
DETAIL B
CD - 13.04 NOTES
1. RECOMMENDATIONS
1. See Group 05 for beam reinforcement cover specifications.
2. See Group 06 for slab reinforcement cover specifications.
3. See CD - 01-21 for the column springing.
4. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and ACI 350.2R (44).
447
CD- 13.05
SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. FOUNDATIONS
0
(See CD-12.07)
@ INDIVIDUAL FOOTING WITH
CIRCULAR SLAB
()()
00
00
0()
(See CD-12.08)
@ INDIVIDUAL FOOTING WITH
ANNULAR SLAB
OCJ
00
()0
00 (See CD-01.21)
@ GROUP OF SILOS WITH COMMON SLAB FOUNDATION
448
CD-13.05 NOTES
1. RECOMMENDATIONS
1. See CD - 01.05, CD - 01.06, CD - 12.07 and the respective recommendations for circular slab foundations.
2. See CD -12.08 and the respective recommendations for annular foundations.
3. See CD - 01.21 and the respective recommendations for foundation slabs.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and ACI 350.2R (44).
449
CD-13.06 SILOS, CAISSONS AND RECTANGULAR HOLLOW
COLUMNS. REINFORCEMENT LAPS
r-r{
7"
lii1
lii1
lii1
lii1 '
~?"
-
-
-
lii1t
~
T
·-
-
- -
-
1-- I- -
A
v
REINFORCEMENT LAP
@ VERTICAL BARS
~
-~·- - ~ - - - - ~ ~ -- -
f-- - 1-- - f-- ,~ ~ - --
I-- --- f -- - ~ - ~
~
ELEVATION
~
~
~·-
~
"
A
@ HORIZONTAL BARS
L L L I L
r2 i b2
1
b2
1
'-b2
1
b2
1
I i
ELEVATION
-
I"
450
'""""'"
~
-+----------
-·-·--
I~
"' ~
1~7
Maximum percentage of
lapped bars in the same
horizontal section:
33%
A R. Vertical centre-to-centre
distance between lap
series:
2Lb1
2Lb1
Construct ion
joint
Maximum percentage of
lapped bars in the same
vertical section:
33%
AR. Horizontal centre-to-centre
distance between lap
series:
CD- 13.06 NOTES
1. RECOMMENDATIONS
1. Cantilevered bars should be duly stiffened during construction to prevent oscillation under wind action, which
would break the bond with the concrete.
2. The spacing specified refers to both the inner and outer sides.
3. Laps may concur on the two sides.
4. See Recommendation 4 in CD - 12.02 for construction joints.
5. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 313 (43) and 350.2R (44).
451
Group 14
Reservoirs, tanks and swimming pools
CD- 14.01
RESERVOIRS, TANKS AND SWIMMING POOLS.
RECTANGULAR OPEN TANKS. GENERAL DETAILS
See detail A
See detail C --------------/ ---
0 ---"\
\--1
i \
L1I \
I
;
0 ___ _/ 1 1 1 L. ~gon!)truction joint
1 --++-- --j-. -r2 .
DETAIL A
Blin~ing (7cm)
~"
DETAIL D
------------/ '
See detail B
/
See detail D
Construction joint
DETAIL B
See@@@ in CD-05.02
I Construction joint
l -- 01
il4 02 ~\
\ \,
\
DETAILC
I
454
See CD-01.01
Construction joint
Chair
Blir:)ding (7 cm)
Compacted subgrade
CD-14.01
1. RECOMMENDATIONS
1. Covers:
r, = 7.5 cm if the concrete is poured directly against the soil.
r2 2 <1>2·
r3 = 2.5 cm 2 <j>4 •
r4 :::; <1>3·
r5 = 3 cm 2 <j>5 .
r6 = 3 cm.
r7 = 3 cm.
2. L, is the lap length of the thicker of the <!>, or <j>5 bars.
3. L2 is the lap length of the vertical bars.
4. r8 = 5 cm.
r9 = 3 cm 2 <j>1•
NOTES
5. The tops are smoothed with a float or power float. The bottom is smoothed with a vibrating screed. This is
why a 5 cm cover is needed. Otherwise, the vibrating screed would cause the coarse aggregate to rise up
over the transverse reinforcement, making it difficult to smooth the surface.
6. The blinding is floated or smoothed with a power float.
7. A rough surface such as is generated by vibration is needed in the construction joints. These joints should
be cleaned and moistened and their surface allowed to dry before concrete pouring is resumed.
8. See CD - 14.08 for the use of waterstops where watertightness is desired.
9. See 1 .2 and 1 .3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
455
CD- 14.02
,,,------
02~
i
I
i
01
02
See detail B
RESERVOIRS, TANKS AND SWIMMING POOLS.
CIRCULAR OPEN TANKS. GENERAL DETAILS
03
.. _04
03
DETAIL A
03
Construction joint Chair
Blinding (7 cm) / I
Compacte~ _s_':'.lb_g_r~-~~/
Construction joint t--
T
L3I Chair
I ~J,
i~~~f-.>-~~~r--_,..__,,_~--1-~~-r---+--~
DETAIL B
456
\
Compacted subgrade \
CD - 14.02 NOTES
1. RECOMMENDATIONS
1. See CD -14.01 for cover specifications.
2. L3 is the <1>1 bar lap length.
3. L4 is the <j>4 bar lap length.
4. See wall crown detail in CD - 02.03. for the value of <j>4 (detail A), which depends on the height of the tank.
5. The top is smoothed with a float or power float. The bottom is smoothed with a vibrating screed. This is why
a 5 cm cover is needed. Otherwise, the vibrating screed would cause the coarse aggregate to rise up over
the transverse reinforcement, making it difficult to smooth the surface.
6. A rough surface such as is generated by vibration is needed in the construction joints. These joints should
be cleaned and moistened and their surface allowed to dry before concrete pouring is resumed.
7. See CD -14.08 for the use of waterstops where watertightness is desired.
8. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
457
CD- 14.03
1-1L2
~
RESERVOIRS, TANKS AND SWIMMING POOLS.
ROOFED RESERVOIRS AND TANKS.
GENERAL DETAILS
Slope 2%
Co~~!r~~!~C>l1 joint
01 03
,,,-------
See CD-01.01
for general details
Construction j()int
Chair
~
{I I
~
~:r~~~~~~~~S~p~acer
/ ', ' ' ", ' ', ' ' ' ', ' ', ' '· i ~', '; ', ', ', ', ', ', "', ', ', ', ',
See <::;(?~_Q~:_Q_~_for anchorage / / Blindin9 (7 cm) ~c~e~~~bgrade
@ EDGEWALL
See CD-04.02
for connec-t-io-n-to-sl-ab ~ ,,----. ,
See CD-04.02
~Construction join!
Construction joint
Chair
@ INTERMEDIATE WALL
458
CD- 14.03 NOTES
1. RECOMMENDATIONS
1. See CD - 14.01 for cover specifications.
2. L1 is the lap length of the thicker of the $1 or $2 bars.
3. L2 is the $1 bar lap length.
4. L3 is the $3 bar lap length.
5. L4 is the lap length of the thicker of the $1 or $3 bars.
6. The tops are smoothed with a float or power float. The bottom is smoothed with a vibrating screed. This is
why a 5 cm cover is needed. Otherwise, the vibrating screed would cause the coarse aggregate to rise up
over the transverse reinforcement, making it difficult to smooth the surface.
7. A rough surface such as is generated by vibration is needed in the construction joints. These joints should
be cleaned and moistened and their surface allowed to dry before concrete pouring is resumed.
8. See CD - 14.08 for the use of waterstops where watertightness is desired.
9. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
459
CD-14.04 RESERVOIRS, TANKS AND SWIMMING POOLS.
CORNER DETAILS (1 of 2)
® ®
02 04 02_ 04
04
(06 02
L3
06
05 05 !-------------~ ~~1 L4
©
460
CD-14.04 NOTES
1. RECOMMENDATIONS
1. See CD - 14.01 for cover specifications.
2. In details A and B, the <1>2 angled bar overlaps with the <1>2 straight bars along their lap length.
3. L1 is the $8 bar lap length.
4. L2 is the $6 bar lap length.
5. L3 is the lap length in the larger of the $4 or $6 reinforcing bars; L4 is the lap length inthe larger of the <1>2 or $6
bars.
6. Diameter $6 is equal to the larger of <1>2 or $4 .
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22).
461
CD-14.04
RESERVOIRS, TANKS AND SWIMMING
POOLS. INTERSECTION DETAILS (2 of 2)
@
®
®
462
CD-14.04 NOTES
1. RECOMMENDATIONS
1. See CD - 14.01 for cover specifications.
2. In details A and B, the $2 angled bar overlaps with the $2 straight bars along their lap length.
3. L1 is the $8 bar lap length.
4. L2 is the $6 bar lap length.
5. L3 is the lap length in the larger of the $4 or $6 reinforcing bars; L4 is the lap length in the larger of the $2 or $6
bars.
6. Diameter $6 is equal to the larger of $2 or <j>4 •
7. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
3. RECOMMENDED ALTERNATIVE CODES
See ACI 318-08 (22)
463
CD- 14.05 RESERVOIRS, TANKS AND SWIMMING POOLS.
JOINTS AND BEARINGS IN WALLS
•See CD-02.09 for contraction joints in walls
• See CD-02.10 for expansion joints in walls
~-~~--©_(_ID@_
in CD-05.01
Chair r---
1
Compressible fill Elastomer bearing
Waters to
DETAIL A
ROOF -WALL SLIDE BEARING
Elastomer bearing
Nominal assembling
reinforcement \g'fj'cuts
DETAIL B
WALL- FOUNDATION SLIDE BEARING
DETAIL C
WALL-FOUNDATION SLIDE BEARING
464
CD - 14.05 NOTES
1. RECOMMENDATIONS
1. See CD - 09.02 and CD - 09.03 for elastomer bearing placement.
2. See CD - 02.09 and CD - 02.1 O for waterstop placement.
3. Detail C may only be used when the weight of the wall can ensure the effectiveness of the seal.
2. STATUTORY LEGISLATION
See EC2 (5).
465
CD - 14.06
Chair
Blindin
Chair
Blinding
Chair
RESERVOIRS, TANKS AND SWIMMING POOLS.
CONTRACTION AND EXPANSION JOINTS
IN SLABS ON GRADE
Induced crack
Joint, cut and sealed
4 cm r1
@ CONTRACTION JOINT
Sealing joint
Compacted subgrade
@ EXPANSION JOINT (VARIATION 1)
Sealin ·oint
Waterstop /
@ EXPANSION JOINT (VARIATION 2)
466
CD - 14.06 NOTES
1. RECOMMENDATIONS
1. Covers:
r1 = 5 cm. (Since the slab is to be finished with a vibrating screed, if a thinner cover were used, the gravel
would rise up over the transverse wires to the detriment of the finish.)
r2 = 3 cm ~ <j> (diameter of the bottom bar).
2. The blinding is floated or smoothed with a power float.
3. The area around the waterstops must be vigorously and meticulously vibrated.
4. The watertight band is difficult to position correctly with expansion joint type B.
2. STATUTORY LEGISLATION
See EC2 (5).
467
CD- 14.07 RESERVOIRS, TANKS AND SWIMMING POOLS.
JOINTS IN WALLS
•See CD-02.09 for contraction joints
•See CD-02.10 for expansion joints
DISTRIBUTION OF CONTRACTION JOINTS
Wall1
Wall3 Wall2
\~
\ ~~~~~~~~~~~~~~~~~~~~--""---~~~~~~~~ I
I I
I
I
I
I
I
I
I
I
I I I I I I I
>--- - - - -1- - - - - I - - - - -1- - - - -1- - - - - I - - - - -1- - - - -1- - - - - -
PLAN
WALL 1
WALL2
I I I I I I
I I I I I I
I I I I I I
I I I I I I
I I I I I I
I I I I I I
I I I I I I
I I I I I I
I I I I I I
See CD-02.10
(max. 7.5m)
-1
468
Wall1
WALL3
CD- 14.07
1. RECOMMENDATIONS
1. See CD-14.06.
2. STATUTORY LEGISLATION
None in place.
NOTES
469
CD- 14.08
L1 !
Construction I
jOlnr-
01 G?J~-
05
Construction
joint \
L1
01 05
RESERVOIRS, TANKS AND SWIMMING POOLS.
SPECIFIC DETAILS FOR IMPROVING
CONSTRUCTION JOINT WATERTIGHTNESS
®
Waterstop
05 04 Chair /1 ;- 1--
~;;;;;r=;;;'====t;r=~~==;;====;=~i===ce;==j ==t 5 cm
07
Waterstop
04
;-
Blinding / , \ / 0u
470
®
05 Chair
r-
\_qJ_1_ \
\ Compactedsubgrade
CD-14.08 NOTES
1. RECOMMENDATIONS
1. See CD - 14.01 for cover and lapping specifications.
2. The area around the waterstops must be vigorously and meticulously vibrated.
3. See CD - 02.09 and CD - 02.10 on securing the watertight band during concrete pouring.
4. The blinding is floated or smoothed with a power float.
5. A rough surface such as is generated by vibration is needed in the construction joints. These joints should
be cleaned and moistened and their surface allowed to dry before concrete pouring is resumed.
6. See 1.2 and 1.3 for descriptions of how to tie bars and place spacers.
2. STATUTORY LEGISLATION
See EC2 (5).
471
Group 15
Special construction details
for earthquake zones
CD - 15.01 SUMMARY OF BASIC ASPECTS
1. Eurocode 8 (EN 1998-1 ): Design of structures for earthquake resistance - Part 1: General rules, seismic
actions and rules for buildings (hereinafter EC8) (4) is the one that is relevant to Group 15.
EC8 (Part 1) is supplemented by the following Parts:
• EN 1998-2 contains specifications for bridges.
• EN 1998-3 contains specifications for seismic assessment and retrofitting of existing buildings.
• EN 1998-4 contains specifications relevant to silos, tanks and pipelines.
• EN 1998-5 contains specifications relevant to foundations, retaining structures and geotechnical aspects.
• EN 1998-6 contains specifications relevant to towers, masts and chimneys.
2. SEISMIC ZONES
For the purposes of EC8, the national authorities will have to subdivide their territory into seismic zones.
For most applications of EC8, the hazard is described in terms of a single parameter, which is the peak accelera­
tion value A8R.
In cases of low seismicity, simplified calculation procedures may be used for certain structures. This information
is included in each country's National Annex.
In cases of vel}' low seismicity, application of the specifications in EC8 is not required. This information is also
included in each country's National Annex.
3. SEISMIC MEMBERS
EC8 makes a distinction between:
• Primal}' seismic members. Members considered to form part of the structural system that withstands the seismic
action.
• Secondal}' seismic members. Members that are not considered to form part of the structural system that with­
stands the seismic action and whose strength and rigidity is diminished by these effects.
4. CRITICAL REGIONS
This is the zone of a primary seismic member that is subject to the most adverse combination of action effects
possible and where plastic hinges could form.
5. MATERIALS
• Steel reinforcement. In primary seismic elements, the steel reinforcement must be class B or C, as specified in
EC2, Table C.1.
• With the exception of closes, stirrups and cross-ties, only corrugated bars should be used as reinforcing in critical
regions of primary seismic elements.
• Wire meshes may be used if they have ribbed wires and are class B or C.
• Concrete. Concrete lower than C 16/20 may not be used in primary seismic elements.
474
CD - 15.01 NOTES
1. RECOMMENDATIONS
1 . Some countries of the European Union have not published their National Annexes yet.
2. Some countries of the European Union have territorial zones located on other continents.
3. AR. The requirement of C 16/20 concrete appears to be very modest. A lower limit of C 20/25 would be
preferable.
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
475
CD-15.02 GEOMETRICAL CONSTRAINTS
1. BEAMS
1.1 Eccentricity of joints: the value of e (Figures 1 and 2) between the axes of the columns and the beams must
be limited to:
e
Slab
Figure
+
Soffit
beam
Figure 2
Slab
where be is the longest dimension of the cross-section of the column perpendicular to the beam axis.
AR. It is understood that this limitation must be fulfilled on the two pillars that are joined to the beam
(e1 and e2 in Figures 1 and 2).
1.2 To take into account the favourable effect of the column compression on the bond of the horizontal bars
passing the joints (Figure 3), the width bw of a primary seismic beam must satisfy the following condition:
bw :s: min. {be+ hw; 2be}
Figure 3
wherebe has already been defined in the previous clause
hw is the depth of the beam.
2. COLUMNS
2.1 Unless 8 :s: 1, the dimensions of the cross-section of primary seismic columns must not be less than one-tenth
of the greatest distance between the points of inflection of the deformed axis of the column and the ends of the
column.
3. DUCTILE WALLS
The thickness of the web, bwo' in meters, must fulfil the following condition:
bwo ~ max. { 0.15, h. /20}
where h. is the free floor height, in metres.
476
CD-15.02
1. RECOMMENDATIONS
1. The angle e is the inter-storey drift resistivity coefficient. See EC-8 (4).
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
3. RECOMMENDED ALTERNATIVE CODES
See Chapter 21 in ACI 318-08 (22).
477
NOTES
CD- 15.03 PARTICULAR ASPECTS OF DETAILING
(1 of 2)
1. BEAMS
1.1 The regions of a primary seismic beam at a distance fer = hw (where hw is the depth of the beam) from the
end section where the beam joins to a beam or column joint, as well as on both sides of any section that is
susceptible to yielding in the seismic design situation, must be considered to be critical regions.
1.2 Unless more detailed studies of the local ductility requirements are done, they could, in a simplified
manner, be considered to be fulfilled on both flanges of the beam, provided that the following requirements
are met.
• In the compressed reinforcing zone, there is at least half of the reinforcing installed in the tension zone.
(This is apart from the compression reinforcing needed to satisfy the U.L.S.).
• The reinforcement ratio of the tension zone, p, does not reach the value
, 0.0018 fed
Pmax =p +--·-
µ, Esy,d fyd
where the reinforcement ratios of the tension zone and compression zone, p and p' are both normalised
to bd, where:
b is the width of the compression flange of the beam.
Esy.d is the design value of steel strain at yield
µ0 is the curvature ductility factor.
• Along the entire length of the beam, the reinforcement ratio of the tension zone, p, must not be less than
the following value:
Pmin = 0.5 (fetm J
fyk
• Within the critical regions of primary seismic beams, the stirrups must fulfil the following requirements:
(a) the diameter must not be less than 6 mm;
(b) the spacings, of stirrups, in mm, must not exceed the following value:
S =min. { hw I 4; 24 dbw; 225; 8dbL}
where
dbL is the diameter of the narrowest longitudinal bar
hw is the beam depth in mm
dbw is the stirrup diameter in mm;
(c) the first stirrup will not be more than 50 mm from the end surface on the beam (Figure 4).
Figure 4
2. COLUMNS. DETAILING OF PRIMARY SEISMIC COLUMNS FOR LOCAL DUCTILITY
2.1 The total longitudinal reinforcement ratio, p1 , must be between 0.01 and 0.04. In members with symmetrical
cross-sections, the reinforcing must also be symmetrical (p = p').
2.2 At least one intermediate bar must be installed on each side of the piece to ensure the integrity of the beam­
column joints.
2.3 The regions at a distance £er from the ends of a primary seismic column must be considered to be critical regions.
2.4 In the absence of more precise calculations, the length of the critical region £er (in metres) can be calculated
based on the following equation:
478
CD- 15.03
1. RECOMMENDATIONS
1. In most cases, condition 1.2 prevents the use of soffit beams in seismic zones.
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
3. RECOMMENDED ALTERNATIVE CODES
See Chapter 21 in ACI 318-08 (22).
479
NOTES
CD- 15.03 PARTICULAR ASPECTS OF DETAILING
(2 of2)
where
he is the longer dimension of the column's cross-section (in metres)
fe1 is the clear length of the column (in metres).
2.5 If fe/he < 3, the entire height of the column must be considered to be critical and reinforced accordingly.
2.6 In confinement of columns, a minimum value of cowd equal to 0.08 must be provided in the critical zone at the
base of the primary seismic columns. The value of cowd is given by the equation
volume of confining hoops fyd co - -
wd - volume of concrete core ·fed
be
A
'
A
' Figure 5
2.7 The spacing, s, of the hoops (in mm) must not exceed the value
s =min. {b0 /2; 175; 8dbL}
where
b0 (in mm) is the minimum dimension of the concrete core
dbL is the diameter of the narrowest longitudinal bar.
2.8 The distance between consecutive longitudinal bars engaged by hoops or cross-ties must not exceed
200 mm.
3. DUCTILE WALLS
3.1 The height of the critical region, above the base of the wall, can be estimated by applying the equation:
where
but
fw is the length of the wall cross-section
hw is the height of the wall
l2fw
h <
er - { hs for n s 6 storeys
2h5 for n ::=: 7 storeys
where hs is the open height between floors.
3.2 Premature web shear cracking of walls shall be prevented by providing a minimum ratio of web reinforce­
ment: Ph.min = Pv.min = 0.002.
3.3 The web reinforcement should be provided in the two grids of bars, one at each face of the wall. The grids
should be connected by cross-ties spaced about 500 mm apart.
3.4 Web reinforcement must have a diameter of not less than 8 mm, but not greater than one-eighth of the width
of the wall. Spacing must not exceed 250 mm or 25 times the diameter of the bars, whichever is less.
480
CD-15.03
1. RECOMMENDATIONS
1. In most cases, condition 1.2 prevents the use of soffit beams in seismic zones.
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
3. RECOMMENDED ALTERNATIVE CODES
See Chapter 21 in ACI 318-08 (22).
481
NOTES
CD- 15.04 COUPLING ELEMENTS IN COUPLED WALLS
1. COUPLING ELEMENTS OF COUPLED WALLS
D
D
D
D
D
D
Figure 6
1.1 Wall coupling using just the floor slabs is not effective in the case of seismic zones (Figure 6).
1.2 To ensure against prevailing flexure mode of failure, it is necessary that
i.:::: 3
h
1.3 When diagonal reinforcing is used, it should be arranged in column-like elements with side lengths at
least equal to 0.5 bw; its anchorage length should be 50 per cent greater than the value required by EC2
(Figure 7).
E
0
~o
·;:: N
O> 0 -No
II ..-
0::: lSl
< c:: .E
AR.= 2 016 min.
h
AR.= 2 016 min.
Figure 7
Hoops should be provided around these column-like element to prevents buckling of the longitudinal bars.
482
CD - 15.04
1. RECOMMENDATIONS
None.
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
3. RECOMMENDED ALTERNATIVE CODES
See Chapter 21 in ACI 318-08 (22).
NOTES
483
CD-15.05 REINFORCEMENT ANCHORAGE
1. COLUMNS
1.1 When designing the length of the lap of the main reinforcing bars of a column, A •. ,./As.prov shall be assumed to
be 1.
1.2 If, in the seismic design situation, the axial force on a column is tensile, the anchorage lengths must be
increased by 50 per cent with respect to the values specified in EC2.
2. BEAMS
2.1 The part of the longitudinal reinforcing of the angle beam at the joints to anchor it must always be inside the
corresponding column hoops.
2.2 If it is not possible to fulfil the anchorage lengths specified in EC8, 5.6.2.2. P (4) on the outside of the beam­
column joint, one of the solutions shown in Figure 8 may be adopted.
he
-.-.-I __,t---1 I I
he
~_I_
IL i---------·
/
' --
&/ ~---\Ji
-""-
I' ---------·
~ A
(a) (b) (c)
A Anchor plate
B Hoops around column bars
Figure 8
484
CD-15.05 NOTES
1. RECOMMENDATIONS
1. Specification 1.1 is included to guarantee that the bars reach their yield point in the failure of the structure.
2. STATUTORY LEGISLATION
See EC2 (5) and EC8 (4).
3. RECOMMENDED ALTERNATIVE CODES
See Chapter 21 in ACI 318-08 (22).
485
CD - 15.06 SPLICING OF BARS
1. Welded laps should not be located inside critical regions of elements.
2. Mechanical couplers can be used in columns and walls if they have been tested and shown to have the nec­
essary ductility.
3. In addition to fulfilling the specifications in
