Resources Policy 78 (2022) 102906
Available online 5 August 2022
0301-4207/© 2022 Elsevier Ltd. All rights reserved.
Medium- to long-term nickel price forecasting using LSTM and
GRU networks
Ali Can Ozdemir a,*, Kurtuluş Buluş b, Kasım Zor c
a Department of Mining Engineering, Çukurova University, Adana, 01330, Turkey
b Centre for Discovery Brain Sciences, University of Edinburgh, Edinburgh, UK
c Department of Electrical and Electronic Engineering, Adana Alparslan Türkeş Science and Technology University, Adana, Turkey
A R T I C L E I N F O
Keywords:
Nickel price forecasting
LSTM networks
GRU networks
Recurrent neural networks
Deep learning
A B S T R A C T
Recently, nickel is a critical metal for manufacturing stainless steel, rechargeable electric vehicle batteries, and
alloys utilized in the state-of-the-art technologies. The use of more environmentally friendly electric vehicles has
become widespread and brought tackling climate change to forefront, especially for reducing greenhouse gas
emissions. Therefore, the demand for rechargeable batteries that power electric vehicles and the need for the
nickel in the production of these batteries will increase as well. In addition to those, nickel prices significantly
impact mine investment decisions, mine planning, economic development of nickel companies, and countries
that depend on nickel resources. However, there is uncertainty about how the nickel price will trend in the
future, and the solution to this problem attracts the attention of researchers. For forecasting nickel price, this
paper proposes recurrent neural networks-based on long short-term memory (LSTM) and gated recurrent unit
(GRU) networks, classified as deep learning algorithms. Mean absolute percentage error (MAPE) was used as the
performance measure to compute the accuracy of the proposed techniques. As a result, it has been determined
that the LSTM and GRU networks are very useful and successful in forecasting the nickel price variations owing
to having average MAPE values of 7.060% and 6.986%, respectively. Furthermore, it has been observed that GRU
networks surpassed the LSTM networks by 33% in terms of average computational time.
1. Introduction
In recent years, nickel has been a crucial and strategic metal for
developing and modern societies. High resistance to corrosion and
tarnishing are some of the most important advantages of nickel in
comparison with other metals. Thus, it is widely used in many industries
such as household appliances, automotive, aerospace, military applica-
tions, coin making, and computer parts manufacturing (British
Geological Survey, 2008, 2018; Nickel Institute, 2019; Henckens and
Worrell, 2020). In particular, its use in stainless steel, alloys, and
rechargeable batteries significantly contributes to the economic growth
and development of any country (Eckelman, 2010; Yan et al., 2012;
Schmidt et al., 2016; Liu et al., 2017; Wang et al., 2018).
In parallel with the rapid development of the global economy,
releasing large amounts of greenhouse gas (GHG) emissions to the at-
mosphere has led to a dramatic increase in the global warming which
causes the climate change (Fu et al., 2021). Several multinational
agreements have been signed by the international community to
struggle with this problem. Herein, some examples can be stated as the
United Nations Framework Convention on Climate Change, the Kyoto
Protocol, the Paris agreement, the Europe 2020 strategy, the 2030 en-
ergy policy framework vision, and the European Green Deal (Tunç et al.,
2007; Karmellos et al., 2021). The common purpose of these actions is to
combat both the global warming and the climate change on a global
scale. For this purpose, the focus has been concentrated on reducing
carbon dioxide (CO2) emissions, which are the biggest contributors to
GHG emissions (Fukuzawa, 2012; Wang and Wang, 2019; US Environ-
mental Protection Agency, 2022). CO2 emissions originating from
transportation sector constitute 25% of total CO2 emissions and it is the
second sector that produces the most CO2 emissions after electricity
generation (IEA, 2022). At this point, electric vehicles (EVs) have great
potential to meet the goal of reducing CO2 emissions within the trans-
portation sector (Ma et al., 2019; McCollum et al., 2018). Between 2022
and 2025, it is expected that EVs will be able to compete with traditional
vehicles in terms of cost, range, and infrastructure criteria, and they will
be collectively adopted (Baker et al., 2019; Woodward et al., 2019;
* Corresponding author.
E-mail addresses: acozdemir@cu.edu.tr (A.C. Ozdemir), s1834500@ed.ac.uk (K. Buluş), kzor@atu.edu.tr (K. Zor).
Contents lists available at ScienceDirect
Resources Policy
journal homepage: www.elsevier.com/locate/resourpol
https://doi.org/10.1016/j.resourpol.2022.102906
Received 20 February 2022; Received in revised form 16 July 2022; Accepted 18 July 2022
mailto:acozdemir@cu.edu.tr
mailto:s1834500@ed.ac.uk
mailto:kzor@atu.edu.tr
www.sciencedirect.com/science/journal/03014207
https://www.elsevier.com/locate/resourpol
https://doi.org/10.1016/j.resourpol.2022.102906
https://doi.org/10.1016/j.resourpol.2022.102906
https://doi.org/10.1016/j.resourpol.2022.102906
http://crossmark.crossref.org/dialog/?doi=10.1016/j.resourpol.2022.102906&domain=pdf
Resources Policy 78 (2022) 102906
2
Bloomberg New Energy Finance, 2021). It has been also predicted that
the annual sales of EVs may be between 21 and 28 million in 2030
(Cooper and Schefter, 2018; IEA, 2019). Moreover, aggressive thinkers
estimate that this number may reach 43 million (Azevedo et al., 2018;
IEA, 2019).
From a technical point of view, nickel is an essential metal in the
production of EVs batteries due to its low-cost and high energy density
compared to its equivalents (Roskill Information Services Ltd, 2017; Li
and Lu, 2020; Nguyen et al., 2021; Yao et al., 2021). Elon Musk, CEO of
Tesla, which has become the most popular brand in the automobile in-
dustry, emphasizes the importance of nickel for the battery re-
quirements of EVs at every opportunity (Electrek, 2022). Also, Hamilton
(2018) stated that the use of nickel in batteries for EVs will increase by
39% annually between 2017 and 2025. The share of global nickel con-
sumption in the battery industry is estimated to increase from 3% in
2017 to 37% in 2030 (Yao et al., 2021). If this momentum continues, it is
forecasted that nickel demand in 2030 will be roughly one and a half
times of global nickel production in 2017 (British Geological Survey,
2018; BMO Capital Markets, 2018). It was observed that the world
nickel production increased by 3.1% annually between 1980 and 2015
(US Geological Survey, 2021). Henckens and Worrell (2020) stated that
when the average production increase rates in this period are adjusted to
the year 2100, nickel production in 2100 will be twelve times higher
than the nickel production in 2018. These observations indicate that
there will be an increase in the production of batteries as well as EVs. In
summary, it is clarified that nickel needs of EVs battery manufacturers
have been increasing and will continue to rise in the future.
It is a known fact that fluctuations in metal prices can have a sig-
nificant impact on both microeconomics and macroeconomics (Wang
et al., 2019; Khoshalan et al., 2021). These fluctuations have major in-
fluences especially on the countries whose metal export income consti-
tutes a large part of the total export income (He et al., 2015). In addition,
for metal producing companies, it is a situation that requires great
attention in the execution of mining activities, the preparation of short-
and long-term plans, cost analysis, and risk management (He et al.,
2017; Bhatia et al., 2018; Gong and Lin, 2018). It is considered that
metal price is at the center of mining activities, understanding future
metal price tendency is vital(Chatterjee and Dimitrakopoulos, 2020;
Madziwa et al., 2022). Abdel Sabour (2002) stated that if prices are
predicted to increase, production will increase; on the contrary, if prices
are predicted to decrease, production will decrease. Here, the impor-
tance of price forecasting for mine planning is emphasized once again.
Unsuccessful nickel price forecasts can increase the likelihood of errors
in economic assessments and result in large financial losses on in-
vestments (Hatayama and Tahara, 2018). Therefore, nickel price fore-
casts should be done by employing a method with high accuracy. Thus,
it will provide important contributions to nickel producers, such as the
mine planning, directing investments correctly, using resources effi-
ciently, and increasing profitability as much as possible (Cheng et al.,
2015; Liu and Li, 2017).
Meanwhile, Hong and Fan (2016) divided forecasting process into
four groups according to their horizons: very short-term forecast (VSTF),
short-term forecast (STF), medium-term forecast (MTF), and long-term
forecast (LTF). Here, the cut-off horizons are one day, two weeks, and
three years, respectively.
The main objective of this study is to propose RNN-based deep
learning techniques, namely, LSTM and GRU networks for forecasting
nickel prices in the medium- to long-term horizon. Within the scope of
the study, a data set containing monthly commodity prices of eight
metals (nickel, aluminum, copper, gold, iron, lead, silver, and zinc)
between March 1991 and May 2021 was created along with introducing
calendar variables. The validity of the proposed methods was tested on
this data set.
The original contributions of this study to the literature are mainly
reflected in several aspects:
(i) At least to one’s knowledge, this study presents the first research
in which nickel price forecasting has been performed by using
LSTM and GRU networks. These networks were proven for
robust, efficient, and reliable forecasting results for other pre-
diction problems (Liu et al., 2020; Li et al., 2022). However, their
implementations were not accomplished for nickel price
forecasting.
(ii) In this study, nickel price forecasting was carried out for the
medium- to long-term horizon. The data set consists of nickel,
aluminum, copper, gold, iron, lead, silver, and zinc prices for the
period between March 1991 and May 2021.
(iii) Both LSTM and GRU networks were implemented by incre-
menting the number of neurons in the hidden layer by 25 from
200 to 400, and the number of epochs by 25 between 50 and 150
as well. Hence, it produces findings on the question of how the
change in the number of neurons and epoch number in the hidden
layer affects the forecast accuracy and computational time.
(iv) This study can be a solution to the problem of nickel price un-
certainty in the mining industry, thereby increasing reliability in
the preparation and implementation of mining plans.
(v) This study also encourages researchers to predict commodity
prices for other critical resources (i.e gold, copper) using the
proposed methods.
The rest of this paper is organized as follows: the literature review is
given in Section 2. The data set and forecasting methods are described in
Section 3. The forecast results from the proposed LSTM and GRU net-
works and discussion are presented in Section 4. Finally, conclusions are
provided in Section 5.
2. Literature review
Over the last few decades, forecasting metal prices has remained
popular, and many researchers have applied different techniques to
improve the forecasting accuracy of metal prices. For example, Brunetti
and Gilbert (1995) conducted a study on the volatility of metal prices
and developed a model that relates the volatility of metals to metal
balance. The findings indicated that volatility showed no tendency to
increase over the period 1972–1995 for the six London Metal Exchange
(LME) metals such as nickel, aluminum, copper, lead, tin, and zinc.
Panas (2001) researched into price behavior in the London Metal Ex-
change (LME) and tested long memory and chaos analyses on the same
six metals to evaluate the behavior of metal prices. The results of the
study showed that the dynamics of the LME can be attributed to long
memory, short memory behavior, anti-persistent, and deterministic
chaotic processes. Cortez et al. (2018) proposed a model combining
chaos theory and a machine learning approach. It was emphasized that
both methods cannot be used alone and must work together to predict
long-term prices.
Dooley and Lenihan (2005) applied autoregressive integrated mov-
ing average (ARIMA) to predict monthly metal prices. The conclusions
of the study revealed that price forecasting is a tedious challenge and
ARIMA provides better forecast performance than the lagged forward
price. Behmiri and Manera (2015) investigated the role of outliers and
oil price shocks on the volatility of metal prices using the generalized
autoregressive conditional heteroskedastic and the glos-
ten–jagannathan–runkle models. It was found that outliers bias the
estimation models, and the price volatility of metals reacts differently
and asymmetrically to oil price shocks. Chen et al. (2015) evaluated the
performance of the modified grey wave forecast model by using monthly
prices of nickel and zinc belonging to the year 2015. Chen et al. (2016)
built a new grey wave model for the prediction of nickel and aluminum
prices. The results of these two studies demonstrated that the modified
grey wave method is better than the original grey wave method in terms
of prediction accuracy and computational efficiency.
Fernandez (2018) measured price and income elasticity using the
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
3
Divisia-moment approach for eight geographic regions and seven major
metals (nickel, aluminum, copper, lead, steel, tin, and zinc). The study
unveiled that South America’s per capita consumption of steel,
aluminum, and copper is the most price-elastic, and for nickel
price-elastic regions are North America, Africa, Oceania, and the Middle
East. Brown and Hardy (2019) showed that the Chilean exchange rate
can predict returns on the LME and the same six metals. The results of
the study indicated that the Chilean peso is heavily affected by the
fluctuations in the copper price. Drachal (2019) used various Bayesian
model combination schemes based on dynamic model averaging to
forecast lead, nickel, and zinc spot prices based on monthly data from
1996 to 2017. The findings of the study proved that analyzed model
combinations produce successful prediction results. Olafsdottir and
Sverdrup (2021) evaluated the sustainability of long-term nickel supply
using the WORLD7 model. In the study, an estimate of the nickel price
between 2000 and 2020 was carried out. The results demonstrated that
for nickel, extraction rates will reach their maximum in 2050, and most
primary nickel resources will be depleted by 2130. Madziwa et al.
(2022) utilized the autoregressive distribution lag (ARDL) model to
forecast annual gold prices. Then, in the study, the model that provides
the best ARDL estimation results was encountered with the stochastic
mean conversion and ARIMA methods. The ARDL model was deter-
mined to be the best forecasting method to predict annual gold prices.
Shao et al. (2019) proposed a model based on an improved particle
swarm optimization (PSO) algorithm combined with LSTM networks for
the prediction of nickel price. The improved PSO-LSTM model was
compared with the traditional LSTM networks and ARIMA. The results
showed that the improved PSO has a faster convergence rate and can
effectively improve the prediction accuracy ofthe LSTM networks.
Alameer et al. (2019) proposed a hybrid model integrating the whale
optimization algorithm (WOA) and the multilayer perceptron neural
networks (NN) for forecasting gold price fluctuations. The proposed
model compared with other models, including the classic NN, PSO for
NN, genetic algorithm for NN, and grey wolf optimization for NN. In this
study, it was concluded that the hybrid WOA-NN model was superior to
other models. Khoshalan et al. (2021) applied four different forecasting
models to predict the price of copper such as gene expression pro-
gramming, NN, adaptive neuro-fuzzy inference system (ANFIS), and a
combination of ANFIS and ant colony optimization algorithm. The NN
model showed the best performance among the applied models. Gu et al.
(2021) proposed a hybrid approach based on gradient boosting decision
tree, correlation analysis, and empirical wavelet transform, and applied
it to predict the nickel consensus price of the LME. The findings illus-
trated that the EWT–GBDT can achieve the best results.
Liu et al. (2022) introduced a hybrid NN with Bayesian optimization
and wavelet transform to forecast the copper price in both short- and
long-term horizons. Also, LSTM and GRU networks are utilized to train
the data and predict future copper prices. The results emphasized that
both LSTM and GRU networks can be employed for predicting copper
prices in the short- and long-term horizons.
3. Material and methods
This section defines the data set in detail as the material and briefly
explains the RNN-based LSTM and GRU networks as forecasting
methods.
3.1. Material
3.1.1. Data set information
The data set used in this study includes the historical data of metal
prices for a period of 30 years from March 1991 to May 2021. The data
set period covers the global financial crisis of 2008, the European debt
crisis period of 2009–2014, the oil price crash of 2014–2015, and the
ongoing COVID-19 pandemic. Thus, the analysis of the effects resulting
from such major events has been enabled. Monthly price data for eight
metals, namely nickel (Ni), aluminum (Al), copper (Cu), gold (Au), iron
(Fe), lead (Pb), silver (Ag), and zinc (Zn), was downloaded from
IndexMundi and demonstrated in Fig. 1.
3.1.2. Descriptive statistics of data set
The descriptive statistics of the data set are reported in Table 1. The
average value, which the data in a data set are gathered, is expressed as
the mean. The measure of spread, which represents the spread of vari-
able values around the mean, is the standard deviation (SD). Since the
mean values of all variables are larger than the SD values, it is under-
stood that they show a spread close to the mean. To indicate a normal
distribution according to Desgagné and de Micheaux (2018), the skew-
ness (SK) and kurtosis (KU) values of a data set should be in the range of
[− 1,+1] and [− 2,+2], respectively. It has been found that nickel has a
relatively large kurtosis value of 4.80 and therefore showed a sharpness
within the normal distribution. It can be interpreted that other input
variables show a distribution close to normal.
The correlation chart describing the relationship between all vari-
ables is illustrated in Fig. 2. Pearson’s correlation showed that nickel had
the highest correlation of 0.85 with Al and the lowest correlation of 0.47
with Au among all inputs. In addition, it was understood that there was a
generally significant relationship between other variables.
3.2. Forecasting methods
Prediction of the future price of properties such as metals, which are
heavily influenced by global market demands, is an arduous task. The
fluctuations caused by various dynamics make the data complex and
volatile. Hence, the development of a model that predicts the future
quantity must consider such complex factors to provide robust fore-
casting results.
There are many machine learning models which are used for fore-
casting purposes. Earlier approaches require a large amount of time for
preprocessing of the data. Achievement of these processes is such a
significant step that there is a dedicated title, feature engineering, that
was given to it. Feature engineering simply corresponds to the trans-
formation of the raw data to improve the prediction of the corre-
sponding forecasting model. In time series forecasting, this step involves
the removal of unnecessary information which associates with the se-
lection of useful features and transforming them into another mathe-
matical form.
Although classical machine learning models yielded robust, efficient,
and high-accuracy outcomes for forecasting problems, their imple-
mentations often require a considerable amount of expertise for expe-
rienced users to realize feature engineering. Recent efforts in machine
learning to automate the feature extraction steps led to the development
of deep learning. In this new frontier, feature engineering is not required
and the prediction is made by direct utilization of the raw data by
feeding the raw data into various types of NN (Goodfellow et al., 2016).
In terms of time series data, RNNs are the most common methods in deep
learning. In RNN, the data are processed as a sequence and each time
point is fed into the cells where the patterns of the data are captured.
These patterns are called cell memory and they are transferred to the
next points by using mathematical equations. The prediction of the
interesting quantity is then accomplished after the network is fitted to
the corresponding data by using sophisticated learning algorithms.
Although basic RNNs are capable of dealing with time series forecasting,
their implementation poses a significant challenge in backpropagation
due to vanishing or exploding gradient problems (Hu et al., 2018).
To solve the aforementioned problem, LSTM networks were pro-
posed in the late 1990s (Hochreiter and Schmidhuber, 1997; Buluş and
Zor, 2021). Since then LSTM networks set the standard for many prob-
lems in time series forecasting and some similar approaches are devel-
oped. Recently, one of the variants of the LSTM networks, which is
called the gated recurrent unit (GRU) network, was developed and
attracted lots of interest due to its computationally efficient structure
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
4
(Cho et al., 2014; Zor and Buluş, 2021). These networks use fewer re-
sources as well as provide better accuracy compared to LSTM networks.
Modern machine learning methods are working horses of many
forecasting problems. In machine learning, the forecasting process is
achieved in 3 steps; data preprocessing, model construction, and
training of the model to fit the data. In the data preprocessing step, a
matrix X, which has NxM dimensions, is defined. Here N represents the
number of observation which corresponds to each time point for time
series forecasting problem and M is the number of features which affect
the prediction of interested quantity. Each column in this matrix is called
as a feature vector. Since each feature might have different scales, this
matrix is normalized in order to prevent the prediction unbiased to the
feature which has higher or lower scales. The mathematical form of
feature matrix has significant effect on the prediction performance of the
model. Hence, in machine learning, but not in deep learning, the feature
space might be transformed to another mathematical form to obtain the
maximum of information from the data set. This process is often referred
as feature engineering. Once preprocessing is completed and relevant
features are extracted, a mathematical model is then constructed. The
mathematical model defines the rules of the relationship betweeninput
variables and predicted output variables. A sea of mathematical models
is available in machine learning literature and each has their own
assumption. Unfortunately, there is no single model that can work
effectively on every prediction problems. This is called as no free lunch
theorem in machine learning. Hence, it is often suggested to apply a set
of machine learning models to the interested problem and pick the one
that yields the best performance metrics. The generic equation of the
model to make a prediction is given below:
Fig. 1. IndexMundi monthly price data for eight metals (Wickham, 2016).
Table 1
The descriptive statistics of data set.
Metal Min Max Median Mean SD SK KU
Ni ($/t) 3871.93 52179.05 11118.29 12878.39 7635.90 1.83 4.79
Al ($/t) 1039.81 3071.24 1709.27 1767.19 428.64 0.80 0.19
Cu ($/t) 1377.28 10161.97 4269.34 4493.01 2500.95 0.29 − 1.38
Au ($/ounce) 256.08 1968.63 585.78 802.53 510.86 0.52 − 1.21
Fe ($/t) 26.47 207.72 58.05 70.19 47.92 1.05 0.02
Pb ($/t) 375.70 3719.72 1124.08 1328.52 793.64 0.34 − 1.21
Ag ($/ounce) 3.65 42.70 10.29 12.34 8.63 1.05 0.55
Zn ($/t) 747.60 4405.40 1518.00 1715.20 788.11 0.80 − 0.07
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
5
f (x)=w1x1 + w2x2 + … + wMxM =
∑m=M
m=1
wmxm = wTx (1)
where xi, i = 1, 2, … M is corresponding features and wi, i = 0, 1, …, M is
the associated weight for each feature. The model multiplies each
feature with the corresponding weight and then sum all the values to
obtain the target value. This process can also be described as a linear
vector multiplication, which is stated in the above equation as wTx. w
includes the parameters of the model which need to be fit to the cor-
responding data set. Fitting those parameters is then achieved in the
training step by utilization of gradient descent algorithms which iterate
each data point or group of data points over the entire training set to find
optimal settings in the parameter space (Goodfellow et al., 2016; Bishop
and Nasrabadi, 2006; Murphy, 2012).
State-of-the-art forecasting methods leverage the advancements in
deep learning due to the fact that their implementation does not require
any feature engineering and these methods performed very well in the
case of large data size because of their complex, yet efficient, optimi-
zation methods. Deep learning methods use deep neural networks to
extract the hidden patterns of the data set to approximate the underlying
mapping function between input and output variables. Backpropagation
is the main optimization method that is utilized in deep neural networks
to fit the parameters. However, sometimes backpropagation might pose
a challenge. For example, RNNs also use backpropagation to optimize
the model parameters. However, backpropagation may lead to vanish-
ing or exploding gradient problems. In order to overcome such a prob-
lem, LSTM and GRU networks were developed.
3.2.1. LSTM networks
To solve the vanishing or exploding gradient problems, LSTM net-
works have gating mechanisms in each cell where three different input
types are fed into. As illustrated in Fig. 3, these are xt, ht− 1, and Ct− 1. In
terms of the time series forecasting problems, xt represents the current
time point, ht is the hidden state, and Ct is the cell state.
The power of LSTM networks comes from the updating mechanisms
of the cell state and hidden state through a set of mathematical opera-
tions. These operations allow the network to keep track of long-term
patterns to supply reliable predictions based on historical data.
Another important advantage of such a complex gating mechanism is to
prevent the gradient calculation from approaching zero (vanishing) or
infinity (exploding). The governing mathematical equations in LSTM
networks are given as follows:
ft = σ
(
Wf ⋅ [ht− 1, xt] + bf
)
(2)
it = σ(Wi ⋅ [ht− 1, xt] + bi) (3)
ot = σ(Wo ⋅ [ht− 1, xt] + bo) (4)
Fig. 2. Correlation chart (Peterson et al., 2014).
Fig. 3. LSTM cell structure.
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
6
C̃t = tan h(Wc ⋅ [ht− 1, xt] + bc) (5)
Ct = ft ⊙ Ct− 1 + it ⊙ tan h(Ct) (6)
ht = ot ⊙ tan h(Ct) (7)
where ht and Ct are hidden layer vectors, xt is input vector, bf, bi, bc, and
bo are bias vectors, Wf, Wi, Wc, and Wo are parameter matrices, and
sigmoid and tanh are activation functions (Buluş and Zor, 2021).
Eq. (4) and Eq. (6) are called as input gate because these operations
use current input and hidden state to control the usefulness of infor-
mation in the short-term. To do so, hidden state is multiplied by current
input value and then pass through sigmoid function. The output of sig-
moid function is either one or zero, which means the information will be
either kept or removed, respectively. Similarly, Eq. (6) uses the same
input and pass it through the tanh activation function to regulate the
network. The output of these two equations gives the final result for
input gate. Eq. (2) is referred as forget gate and its main function is to
control the information for long-term memory. Hence, the output of
input gate is multiplied by the cell state to filter out unnecessary infor-
mation in the long-term. This multiplication is then summed with the
second layer of the input gate to construct the updated cell state to be
transmitted to the next cell in the network. Finally, the last gate, which is
referred as output gate, performs a mathematical operation in Eq. (7) to
obtain the updated hidden state. These processes is repeated in each cell
for each time step and the output of correspondent time step can be
obtained from the short-term memory, i.e. hidden state, ht.
3.2.2. GRU networks
GRU networks possess a similar cell structure to LSTM networks.
However, their simpler gating mechanisms in comparison with LSTM
networks allow the system to perform complex computations with fewer
resources in a lesser amount of time. Thus, the training of these networks
is performed at a higher speed. The cell mechanisms of GRU networks
are depicted in Fig. 4.
One of the main differences between GRU and LSTM networks is the
fact that, unlike LSTM networks, GRU networks combine the cell state
and hidden state in one variable, namely ht. The mathematical opera-
tions which allow GRU networks to accomplish the above operations are
given as follows:
zt = σ(Wz ⋅ [ht− 1, xt] + bz) (8)
rt = σ(Wr ⋅ [ht− 1, xt] + br) (9)
h’t = tan h(Wh ⋅ [rt ⊙ ht− 1, xt] + bh) (10)
ht =(1 − zt) ⊙ ht− 1 + zt ⊙ h’t (11)
where ht is hidden layer vectors, xt is input vectors, bz, br, and bh are bias
vectors, Wz, Wr, and Wh are parameter matrices (Zor and Buluş, 2021).
Eq. (8) and Eq. (9) perform the mathematical operations to receive
inputs from previous hidden state and current data point. Once these
inputs are processed with the corresponding weights, the output is then
passed through non-linear activation function, tanh, to filter out un-
necessary information as stated in Eq. (10). Hence, this section of the
network is referred as reset gate. As a final step, the network updates the
hidden states with the set of mathematical operations, which stated in
Eq. (11). The updated hidden state is then transmitted to the next cell.
Throughout the training phase, these steps are repeated.
4. Results and discussion
Experiments regarding the deep learning architectures were per-
formed on Linux Ubuntu OS which had the NVIDIA T500 GPU. PyTorch
(Paszke et al., 2019), an open-source machine learning libraryfor Py-
thon programming language, was utilized to implement both LSTM and
GRU networks. Since the measurements of each feature were not on the
same scale, the models would be biased toward the features which had
larger observations. To prevent this problem, a scaling operation was
performed. The scaling operation is called min-max normalization and
the following formula was used:
xscaled =
x − min(x)
max(x) − min(x)
(12)
where min(x) and max(x) correspond to the minimum and maximum of
the scaled feature vector, respectively.
In both LSTM and GRU networks, the long sequential data, which
have the form of a 1xD vector where the D number of time points in this
study, must be wrapped into N xM matrix form, in which N is the number
of rows and M is the number of columns. In this study, M was chosen as
12, meaning that each observation is made based on the recent 12 time
points. In most deep learning algorithms, during the training phase, the
390 data have processed batches to ease the training. To predict the
future nickel price, the batch was set to 5. Both models are optimized by
using the Adam optimizer (Kingma and Ba, 2014) and the back-
propagation of the error function was performed by using the L1 loss
function. Neural networks are prone to overfitting which causes the
predictions to be unreliable on unseen data. To prevent the network
from overfitting, a dropout layer was implemented and the drop out
probability was set to 0.2. Finally, the learning parameter was set to
0.001.
For the validation and robustness of both algorithms, the data were
split into two sets, namely, training sets and test sets in a random
manner. While training sets consisted of 80% of the all data set, the test
set formed 20% of it. To evaluate the performance results, mean abso-
lute percentage error (MAPE) was used and the calculation of the error
was achieved based on the following formula:
MAPE(%)=
100
n
∑n
i=1
|yi − ŷi|
|yi|
(13)
where yi is actual output, ŷ is forecasted output, and n indicates the
number of instances (Ozdemir, 2021).
In the analyzes for both LSTM and GRU networks, the number of
neurons in the hidden layer is varied between 200 and 400 by 25, while
the epoch number is changed from 50 to 150 by 25 as well. Fig. 5 shows
the change in MAPE and computational time for each year from 2022 to
2031. MAPE values filtered below 10% are indicated on the x-axis, while
the y-axis shows the computational time in seconds. When the forecast
Fig. 4. GRU cell structure.
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
7
performances are compared every year, it is observed that the best
forecast result for both networks is obtained in 2026. In the years 2029
and 2030, there are a few MAPE values below 10% for GRU networks,
while there is only one MAPE value appertaining to LSTM networks.
Therefore, it is deduced that the MAPE values belonging to the other
years are more successful than these years in terms of accuracy. This
circumstance can be also verified by observing Table 2 in which the
results of the average MAPE values for these years are the highest of all
years.
Table 2 shows the performance results of the applied algorithms
between the years 2022 and 2031. Although the models do not have
significant differences in terms of average MAPE values, the average
computational time of the GRU networks managed to reduce computa-
tional time to 33% less than LSTM networks. This is caused by the
Fig. 5. Illustration of MAPE (%) versus computational time (s) with respect to the years between 2022 and 2031.
Table 2
Performance results.
Year LSTM Networks GRU Networks
Size&Epoch Time (s) MAPE (%) Size&Epoch Time (s) MAPE (%)
2022 325&100 78.697 5.967 250&75 42.128 5.756
2023 325&100 31.334 5.814 350&125 34.298 5.806
2024 225&150 36.561 6.066 325&50 14.281 6.397
2025 200&125 29.018 6.322 250&75 18.028 6.048
2026 325&75 21.029 5.656 375&125 32.189 5.552
2027 225&100 17.046 6.145 225&75 14.129 6.883
2028 400&75 23.923 6.873 250&100 18.545 7.336
2029 400&125 35.899 9.681 325&100 19.724 9.385
2030 200&125 20.213 9.130 375&50 11.442 9.530
2031 375&100 24.984 8.949 250&50 7.975 7.164
Average 300&100 31.870 7.060 300&75 21.274 6.986
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
8
computationally efficient structure of the cell mechanisms of GRU net-
works which were discussed earlier. Thus, one of the original contri-
butions of this study is to unveil the outperforming characteristics of
GRU networks against LSTM networks in terms of computational time.
Moreover, Table 2 also reveals that the average number of hidden
sizes and epochs for LSTM and GRU networks are determined as
300&100 and 300&75 sequentially. These findings are crucial to give
precious insights to prospective researchers in the field for not only
narrowing the search limit in finding the optimal values along with
providing a canonical standard for future studies, but also reducing the
computational time for analyzes belonging to both LSTM and GRU
networks.
Fig. 6 shows the change in the historical and forecasted nickel price.
It is understood that the nickel price has entered an upward trend since
2007. In addition to this trend, the effect of the global financial crisis of
2008 brought the nickel price to a historical peak of $52,179.1 per ton.
Afterward, it is seen that there was descent at the same speed. However,
the European debt crisis between 2009 and 2014 caused the nickel price
to rise again. Although there were minor fluctuations after this crisis, it
entered a relatively stable period. Finally, it is noticed that the recent
COVID-19 pandemic has caused nickel prices to rise again. In the fore-
casted period, it is seen that the nickel price has taken on a more stable
structure for both models. Also, nickel price is expected to vary between
$10,000 and $20,000 per ton.
5. Conclusions
The main goal of this study is to forecast nickel prices in the medium-
to long-term. Unlike other approaches in the literature, two advanced
deep learning architectures were implemented, namely LSTM and GRU
networks. The proposed models are tested on a data set consisting of
monthly price data of eight metals (nickel, aluminum, copper, gold,
iron, lead, silver, and zinc). The MAPE performance criterion was used
to evaluate the obtained results. To conclude, the original findings of the
study are as follows:
1. The experiments on both networks showed that the networks are
capable of yielding successful forecasting results. The average MAPE
values for LSTM and GRU networks were calculated as 7.060% and
6.986%, respectively. For both models, it is estimated that the nickel
price might tend to vary between $10,000 and $20,000 per ton in the
2022–2031 period, and it has been observed that the best forecast
performance was obtained for the year 2026.
2. In this study, it is found that GRU networks were 33% faster than
LSTM networks, since the average computational time was calcu-
lated as 31.870 s for LSTM networks and 21.274 s for GRU networks.
This is a significant observation because the future forecasts might be
accomplished with bigger and high-resolution data which might be a
bottleneck with current computing resources.
3. The average number of hidden sizes and epochs for LSTM and GRU
networks were determined as 300&100 and 300&75, respectively.
These findings are valuable to prospective researchers in the field
who will try to narrow the search limits of LSTM orGRU networks in
finding optimal values and eventually provide a canonical standard.
4. Keeping in mind that GRU networks are one step ahead with the
advantage of computational time, it was expressed that both
methods would overcome the price uncertainty problem of mine
planning. This conclusion emphasizes that the proposed networks
will be beneficial in making investment decisions, using resources
efficiently, and increasing profitability.
5. Finally, the recommendation of the study is to apply the proposed
deep learning-based algorithms for forecasting the prices of other
critical resources.
Fig. 6. The historical and forecasted nickel prices.
A.C. Ozdemir et al.
Resources Policy 78 (2022) 102906
9
Credit authorship contribution statement
Ali Can Ozdemir: Conceptualization, Investigation, Project admin-
istration, Resources, Writing - original draft, Writing - review & editing,
Funding acquisition. Kurtuluş Buluş: Methodology, Resources, Soft-
ware, Validation, Formal Analysis, Visualization, Writing - original
draft, Writing - review & editing. Kasım Zor: Data curation, Investiga-
tion, Methodology, Resources, Software, Supervision, Validation, Visu-
alization, Writing - original draft, Writing - review & editing, Funding
acquisition.
Funding sources
This work was supported by the Scientific Project Unit of Çukurova
University [grant number FBA-2019-11998] and by the Scientific Proj-
ect Unit of Adana Alparslan Türkeş Science and Technology University
[grant number 21103013].
Declaration of competing interest
None.
Data availability
Data will be made available on request.
References
Abdel Sabour, S.A., 2002. Mine size optimization using marginal analysis. Resour. Pol.
28, 145–151. https://doi.org/10.1016/j.resourpol.2004.01.001.
Alameer, Z., Elaziz, M.A., Ewees, A.A., Ye, H., Jianhua, Z., 2019. Forecasting gold price
fluctuations using improved multilayer perceptron neural network and whale
optimization algorithm. Resour. Pol. 61, 250–260. https://doi.org/10.1016/j.
resourpol.2019.02.014.
Azevedo, M., Campagnol, N., Hagenbruch, T., Hoffman, K., Lala, A., Ramsbottom, O.,
2018. Lithium and cobalt: a tale of two commodities. https://www.mckinsey.com/in
dustries/metals-and-mining/our-insights/lithium-and-cobalt-a-tale-of-two-commo
dities.
Baker, T., Aibino, S., Belsito, E., Aubert, G., Sahoo, A., 2019. Electric vehicles are a
multibillion-dollar opportunity for utilities. https://www.bcg.com/publications/
2019/electric-vehicles-multibillion-dollar-opportunity-utilities.
Behmiri, N.B., Manera, M., 2015. The role of outliers and oil price shocks on volatility of
metal prices. Resour. Pol. 46, 139–150. https://doi.org/10.1016/j.
resourpol.2015.09.004.
Bhatia, V., Das, D., Tiwari, A.K., Shahbaz, M., Hasim, H.M., 2018. Do precious metal spot
prices influence each other? Evidence from a non-parametric causality-in-quantiles
approach. Resour. Pol. 55, 244–252. https://doi.org/10.1016/j.
resourpol.2017.12.008.
Bishop, C.M., Nasrabadi, N.M., 2006. Pattern Recognition and Machine Learning, 4.
Springer.
Bloomberg New Energy Finance, 2021. Electric Vehicle Outlook 2021. https://about.
bnef.com/electric-vehicle-outlook.
Brown, P.P., Hardy, N., 2019. Forecasting base metal prices with the Chilean exchange
rate. Resour. Pol. 62, 256–281. https://doi.org/10.1016/j.resourpol.2019.02.019.
Brunetti, C., Gilbert, C.L., 1995. Metals price volatility, 1972–1995. Resour. Pol. 21,
237–254. https://doi.org/10.1016/0301-4207(96)85057-4.
Buluş, K., Zor, K., 2021. A hybrid deep learning algorithm for short-term electric load
forecasting. In: 2021 29th Signal Processing and Communications Applications
Conference. SIU, pp. 1–4. https://doi.org/10.1109/SIU53274.2021.9477869.
Capital Markets, B.M.O., 2018. The EV Revolution and its Impact on Raw Materials. http
s://capitalmarkets.bmo.com/en.
Chatterjee, S., Dimitrakopoulos, R., 2020. Production scheduling under uncertainty of an
open-pit mine using Lagrangian relaxation and branch-and-cut algorithm. Int. J.
Min. Reclamat. Environ. 34, 343–361. https://doi.org/10.1080/
17480930.2019.1631427.
Chen, Y., Zou, Y., Wang, S., 2015. Grey wave forecasting with qualified unequal-interval
contour lines and its application in metal prices prediction. In: 2015 IEEE
International Conference on Grey Systems and Intelligent Services. GSIS,
pp. 261–265. https://doi.org/10.1109/GSIS.2015.7301865.
Chen, Y., He, K., Zhang, C., 2016. A novel grey wave forecasting method for predicting
metal prices. Resour. Pol. 49, 323–331. https://doi.org/10.1016/j.
resourpol.2016.06.012.
Cheng, C., Sa-Ngasoongsong, A., Beyca, O.F., Le, T., Yang, H., Kong, Z.J.,
Bukkapatnam, S.T.S., 2015. Time series forecasting for nonlinear and non-stationary
processes: a review and comparative study. IIE Trans. 47, 1053–1071. https://doi.
org/10.1080/0740817X.2014.999180.
Cho, K., van Merriënboer, B., Bahdanau, D., Bengio, Y., 2014. On the properties of neural
machine translation: encoder-decoder approaches. https://doi.org/10.3115/v1/W1
4-4012, 103-111.
Cooper, A., Schefter, K., 2018. Electric vehicle sales forecast and the charging
infrastructure required through 2030. https://www.edisonfoundation.net.
Cortez, C.A.T., Saydam, S., Coulton, J., Sammut, C., 2018. Alternative techniques for
forecasting mineral commodity prices. Int. J. Min. Sci. Technol. 28, 309–322.
https://doi.org/10.1016/j.ijmst.2017.09.001.
Desgagné, A., de Micheaux, P.L., 2018. A powerful and interpretable alternative to the
Jarque–Bera test of normality based on 2nd-power skewness and kurtosis, using the
Rao’s score test on the APD family. J. Appl. Stat. 45, 2307–2327. https://doi.org/
10.1080/02664763.2017.1415311.
Dooley, G., Lenihan, H., 2005. An assessment of time series methods in metal price
forecasting. Resour. Pol. 30, 208–217. https://doi.org/10.1016/j.
resourpol.2005.08.007.
Drachal, K., 2019. Forecasting prices of selected metals with Bayesian data-rich models.
Resour. Pol. 64, 101528 https://doi.org/10.1016/j.resourpol.2019.101528.
Eckelman, M.J., 2010. Facility-level energy and greenhouse gas life-cycle assessment of
the global nickel industry. Resour. Conserv. Recycl. 54, 256–266. https://doi.org/
10.1016/j.resconrec.2009.08.008.
Electrek, 2022. https://electrek.co/2022/01/10/tesla-signs-deal-source-nickel-battery-
production-upcoming-new-mine-us.
Fernandez, V., 2018. Price and income elasticity of demand for mineral commodities.
Resour. Pol. 59, 160–183. https://doi.org/10.1016/j.resourpol.2018.06.013.
Fu, R., Jin, G., Chen, J., Ye, Y., 2021. The effects of poverty alleviation investment on
carbon emissions in China based on the multiregional input–output model. Technol.
Forecast. Soc. Change 162, 120344. https://doi.org/10.1016/j.
techfore.2020.120344.
Fukuzawa, R., 2012. Climate change policy to foster pollution prevention and sustainable
industrial practices-A case study of the global nickel industry. Miner. Eng. 39,
196–205. https://doi.org/10.1016/j.mineng.2012.07.011.
Geological Survey, British, 2008. Nickel. https://www2.bgs.ac.uk/mineralsuk.
Geological Survey, British, 2018. Battery Raw Materials. https://www2.bgs.ac.uk/m
ineralsuk.
Geological Survey, U.S., 2021. Mineral Commodity Summaries. https://pubs.usgs.gov
/periodicals/mcs2021/mcs2021-nickel.pdf.
Gong, X., Lin, B., 2018. Structural breaks and volatility forecasting in the copper futures
market. J. Futures Mark. 38, 290–339. https://doi.org/10.1002/fut.21867.
Goodfellow, I., Bengio, Y., Courville, A., 2016. Deep Learning. MIT press.
Gu, Q., Chang, Y., Xiong, N., Chen, L., 2021. Forecasting nickel futures price based on the
empirical wavelet transform and gradient boosting decision trees. Appl.Soft
Comput. 109, 107472 https://doi.org/10.1016/j.asoc.2021.107472.
Hamilton, C., 2018. Battery Raw Materials-The Fundamentals. https://iea.blob.core.
windows.net/assets/imports/events/71/Session3ColinHamiltonBMO.pdf.
Hatayama, H., Tahara, K., 2018. Adopting an objective approach to criticality
assessment: learning from the past. Resour. Pol. 55, 96–102. https://doi.org/
10.1016/j.resourpol.2017.11.002.
He, K., Lu, X., Zou, Y., Lai, K.K., 2015. Forecasting metal prices with a curvelet based
multiscale methodology. Resour. Pol. 45, 144–150. https://doi.org/10.1016/j.
resourpol.2015.03.011.
He, K., Chen, Y., Tso, G.K.F., 2017. Price forecasting in the precious metal market: a
multivariate EMD denoising approach. Resour. Pol. 54, 9–24. https://doi.org/
10.1016/j.resourpol.2017.08.006.
Henckens, M.L.C.M., Worrell, E., 2020. Reviewing the availability of copper and nickel
for future generations. The balance between production growth, sustainability and
recycling rates. J. Clean. Prod. 264, 121460 https://doi.org/10.1016/j.
jclepro.2020.121460.
Hochreiter, S., Schmidhuber, J., 1997. Long short-term memory. Neural Comput. 9,
1735–1780. https://doi.org/10.1162/neco.1997.9.8.1735.
Hong, T., Fan, S., 2016. Probabilistic electric load forecasting: a tutorial review. Int. J.
Forecast. 32, 914–938. https://doi.org/10.1016/j.ijforecast.2015.11.011.
Hu, Y., Huber, A., Anumula, J., Liu, S.C., 2018. Overcoming the Vanishing Gradient
Problem in Plain Recurrent Networks. https://doi.org/10.48550/arXiv.1801.06105
arXiv.
IEA, 2019. Global EV outlook 2019: scaling-up the transition to electric mobility. htt
ps://www.iea.org/reports/global-ev-outlook-2019.
IEA, 2022, (https://www.iea.org).
Karmellos, M., Kosmadakis, V., Dimas, P., Tsakanikas, A., Fylaktos, N., Taliotis, C.,
Zachariadis, T., 2021. A decomposition and decoupling analysis of carbon dioxide
emissions from electricity generation: evidence from the EU-27 and the UK. Energy
231, 120861. https://doi.org/10.1016/j.energy.2021.120861.
Khoshalan, H.A., Shakeri, J., Najmoddini, I., Asadizadeh, M., 2021. Forecasting copper
price by application of robust artificial intelligence techniques. Resour. Pol. 73,
102239 https://doi.org/10.1016/j.resourpol.2021.102239.
Kingma, D., Ba, J., 2014. Adam: a method for stochastic optimization. arXiv. https://doi.
org/10.48550/arXiv.1412.6980.
Li, M., Lu, J., 2020. Cobalt in lithium-ion batteries. Science 367, 979–980. https://doi.
org/10.1126/science.aba9168.
Li, D., Sun, G., Miao, S., Gu, Y., Zhang, Y., He, S., 2022. A short-term electric load
forecast method based on improved sequence-to-sequence GRU with adaptive
temporal dependence. Int. J. Electr. Power Energy Syst. 137, 107627 https://doi.
org/10.1016/j.ijepes.2021.107627.
Liu, D., Li, Z., 2017. Gold price forecasting and related influence factors analysis based on
random forest. In: Proceedings of the Tenth International Conference on
Management Science and Engineering Management. Springer, Singapore,
pp. 711–723. https://doi.org/10.1007/978-981-10-1837-4_59.
A.C. Ozdemir et al.
https://doi.org/10.1016/j.resourpol.2004.01.001
https://doi.org/10.1016/j.resourpol.2019.02.014
https://doi.org/10.1016/j.resourpol.2019.02.014
https://www.mckinsey.com/industries/metals-and-mining/our-insights/lithium-and-cobalt-a-tale-of-two-commodities
https://www.mckinsey.com/industries/metals-and-mining/our-insights/lithium-and-cobalt-a-tale-of-two-commodities
https://www.mckinsey.com/industries/metals-and-mining/our-insights/lithium-and-cobalt-a-tale-of-two-commodities
https://www.bcg.com/publications/2019/electric-vehicles-multibillion-dollar-opportunity-utilities
https://www.bcg.com/publications/2019/electric-vehicles-multibillion-dollar-opportunity-utilities
https://doi.org/10.1016/j.resourpol.2015.09.004
https://doi.org/10.1016/j.resourpol.2015.09.004
https://doi.org/10.1016/j.resourpol.2017.12.008
https://doi.org/10.1016/j.resourpol.2017.12.008
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref7
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref7
https://about.bnef.com/electric-vehicle-outlook
https://about.bnef.com/electric-vehicle-outlook
https://doi.org/10.1016/j.resourpol.2019.02.019
https://doi.org/10.1016/0301-4207(96)85057-4
https://doi.org/10.1109/SIU53274.2021.9477869
https://capitalmarkets.bmo.com/en
https://capitalmarkets.bmo.com/en
https://doi.org/10.1080/17480930.2019.1631427
https://doi.org/10.1080/17480930.2019.1631427
https://doi.org/10.1109/GSIS.2015.7301865
https://doi.org/10.1016/j.resourpol.2016.06.012
https://doi.org/10.1016/j.resourpol.2016.06.012
https://doi.org/10.1080/0740817X.2014.999180
https://doi.org/10.1080/0740817X.2014.999180
https://doi.org/10.3115/v1/W14-4012
https://doi.org/10.3115/v1/W14-4012
https://www.edisonfoundation.net
https://doi.org/10.1016/j.ijmst.2017.09.001
https://doi.org/10.1080/02664763.2017.1415311
https://doi.org/10.1080/02664763.2017.1415311
https://doi.org/10.1016/j.resourpol.2005.08.007
https://doi.org/10.1016/j.resourpol.2005.08.007
https://doi.org/10.1016/j.resourpol.2019.101528
https://doi.org/10.1016/j.resconrec.2009.08.008
https://doi.org/10.1016/j.resconrec.2009.08.008
https://electrek.co/2022/01/10/tesla-signs-deal-source-nickel-battery-production-upcoming-new-mine-us
https://electrek.co/2022/01/10/tesla-signs-deal-source-nickel-battery-production-upcoming-new-mine-us
https://doi.org/10.1016/j.resourpol.2018.06.013
https://doi.org/10.1016/j.techfore.2020.120344
https://doi.org/10.1016/j.techfore.2020.120344
https://doi.org/10.1016/j.mineng.2012.07.011
https://www2.bgs.ac.uk/mineralsuk
https://www2.bgs.ac.uk/mineralsuk
https://www2.bgs.ac.uk/mineralsuk
https://pubs.usgs.gov/periodicals/mcs2021/mcs2021-nickel.pdf
https://pubs.usgs.gov/periodicals/mcs2021/mcs2021-nickel.pdf
https://doi.org/10.1002/fut.21867
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref32
https://doi.org/10.1016/j.asoc.2021.107472
https://iea.blob.core.windows.net/assets/imports/events/71/Session3ColinHamiltonBMO.pdf
https://iea.blob.core.windows.net/assets/imports/events/71/Session3ColinHamiltonBMO.pdf
https://doi.org/10.1016/j.resourpol.2017.11.002
https://doi.org/10.1016/j.resourpol.2017.11.002
https://doi.org/10.1016/j.resourpol.2015.03.011
https://doi.org/10.1016/j.resourpol.2015.03.011
https://doi.org/10.1016/j.resourpol.2017.08.006
https://doi.org/10.1016/j.resourpol.2017.08.006
https://doi.org/10.1016/j.jclepro.2020.121460
https://doi.org/10.1016/j.jclepro.2020.121460
https://doi.org/10.1162/neco.1997.9.8.1735
https://doi.org/10.1016/j.ijforecast.2015.11.011
https://doi.org/10.48550/arXiv.1801.06105
https://www.iea.org/reports/global-ev-outlook-2019
https://www.iea.org/reports/global-ev-outlook-2019
https://doi.org/10.1016/j.energy.2021.120861
https://doi.org/10.1016/j.resourpol.2021.102239
https://doi.org/10.48550/arXiv.1412.6980
https://doi.org/10.48550/arXiv.1412.6980
https://doi.org/10.1126/science.aba9168
https://doi.org/10.1126/science.aba9168
https://doi.org/10.1016/j.ijepes.2021.107627
https://doi.org/10.1016/j.ijepes.2021.107627
https://doi.org/10.1007/978-981-10-1837-4_59
Resources Policy 78 (2022) 102906
10
Liu, L.Y., Zhang, X., Li, H.X., Liu, B., Lang, J.W., Kong, L.B., Yan, X.B., 2017. Synthesis of
Co–Ni oxide microflowers as a superior anode for hybrid supercapacitors with
ultralong cycle life. Chin. Chem. Lett. 28, 206–212. https://doi.org/10.1016/j.
cclet.2016.07.027.
Liu, Y., Yang, C., Huang, K., Gui, W., 2020. Non-ferrous metals price forecasting based on
variational mode decomposition and LSTM network. Knowl. Base Syst. 188, 105006
https://doi.org/10.1016/j.knosys.2019.105006.
Liu, K., Cheng, J., Yi, J., 2022. Copper price forecasted by hybrid neural network with
Bayesian Optimization and wavelet transform. Resour. Pol. 75, 102520https://doi.
org/10.1016/j.resourpol.2021.102520.
Ma, Y., Shi, T., Zhang, W., Hao, Y., Huang, J., Lin, Y., 2019. Comprehensive policy
evaluation of NEV development in China, Japan, the United States, and Germany
based on the AHP-EW model. J. Clean. Prod. 214, 389–402. https://doi.org/
10.1016/j.jclepro.2018.12.119.
Madziwa, L., Pillalamarry, M., Chatterjee, S., 2022. Gold price forecasting using
multivariate stochastic model. Resour. Pol. 76, 102544 https://doi.org/10.1016/j.
resourpol.2021.102544.
McCollum, D.L., Zhou, W., Bertram, C., de Boer, H.S., Bosetti, V., Busch, S., Després, J.,
Drouet, L., Emmerling, J., Fay, M., Fricko, O., Fujimori, S., Gidden, M., Harmsen, M.,
Huppmann, D., Iyer, G., Krey, V., Kriegler, E., Nicolas, C., Pachauri, S., Parkinson, S.,
Poblete-Cazenave, M., Rafaj, P., Rao, N., Rozenberg, J., Schmitz, A., Schoepp, W.,
van Vuuren, D., Riahi, K., 2018. Energy investment needs for fulfilling the paris
agreement and achieving the sustainable development goals. Nat. Energy 3,
589–599. https://doi.org/10.1038/s41560-018-0179-z.
Murphy, K.P., 2012. Machine Learning: A Probabilistic Perspective. MIT press.
Nguyen, R.T., Eggert, R.G., Severson, M.H., Anderson, C.G., 2021. Global electrification
of vehicles and intertwined material supply chains of cobalt, copper and nickel.
Resour. Conserv. Recycl. 167, 105198 https://doi.org/10.1016/j.
resconrec.2020.105198.
Nickel Institute, 2019. Stainless Steel: the Role of Nickel. https://nickelinstitute.org/
about-nickel/stainless-steel.
Olafsdottir, A.H., Sverdrup, H.U., 2021. Modelling global nickel mining, supply,
recycling, stocks-in-use and price under different resources and demand assumptions
for 1850–2200. Mining Metall. Explor. 38, 819–840. https://doi.org/10.1007/
s42461-020-00370-y.
Ozdemir, A.C., 2021. Investigation of the usability of soft computing methods to
determine the quality distribution in metallic mine. J. Mult.-Valued Log. Soft
Comput. 37, 493–502. https://www.webofscience.com/wos/woscc/full-record/
WOS:000700374600003.
Panas, E., 2001. Long memory and chaotic models of prices on the London metal
exchange. Resour. Pol. 27, 235–246. https://doi.org/10.1016/S0301-4207(02)
00008-9.
Paszke, A., Gross, S., Massa, F., Lerer, A., Bradbury, J., Chanan, G., Killeen, T., Lin, Z.,
Gimelshein, N., Antiga, L., Desmaison, A., Köpf, A., Yang, E., DeVito, Z., Raison, M.,
Tejani, A., Chilamkurthy, S., Steiner, B., Fang, L., Bai, J., Chintala, S., 2019. Pytorch:
an Imperative Style, High-Performance Deep Learning Library. https://doi.org/
10.48550/arXiv.1912.01703 arXiv.
Peterson, B.G., Carl, P., Boudt, K., Bennett, R., Ulrich, J., Zivot, E., Lestel, M.,
Balkissoon, K., Wuertz, D., 2014. Performanceanalytics: Econometric Tools for
Performance and Risk Analysis. R package version 1.
Roskill Information Services Ltd, 2017. Nickel market beware e batteries can no longer
be ignored. https://roskill.com/news/nickel-market-beware-batteries-can-no-longe
r-ignored.
Schmidt, T., Buchert, M., Schebek, L., 2016. Investigation of the primary production
routes of nickel and cobalt products used for Li-ion batteries. Resour. Conserv.
Recycl. 112, 107–122. https://doi.org/10.1016/j.resconrec.2016.04.017.
Shao, B., Li, M., Zhao, Y., Bian, G., 2019. Nickel price forecast based on the LSTM neural
network optimized by the improved PSO algorithm. Math. Probl Eng. 2019, 1934796
https://doi.org/10.1155/2019/1934796.
Tunç, G.İ., Türüt-Aşık, S., Akbostancı, E., 2007. CO2 emissions vs. CO2 responsibility: an
input–output approach for the Turkish economy. Energy Pol. 35, 855–868. https://
doi.org/10.1016/j.enpol.2006.02.012.
US Environmental Protection Agency, 2022. https://www.epa.gov/ghgemissions/global-
greenhouse-gas-emissions-data.
Wang, Q., Wang, S., 2019. Decoupling economic growth from carbon emissions growth
in the United States: the role of research and development. J. Clean. Prod. 234,
702–713. https://doi.org/10.1016/j.jclepro.2019.06.174.
Wang, C., Sun, P., Qu, G., Yin, J., Xu, X., 2018. Nickel/cobalt based materials for
supercapacitors. Chin. Chem. Lett. 29, 1731–1740. https://doi.org/10.1016/j.
cclet.2018.12.005.
Wang, C., Zhang, X., Wang, M., Lim, M.K., Ghadimi, P., 2019. Predictive analytics of the
copper spot price by utilizing complex network and artificial neural network
techniques. Resour. Pol. 63, 101414 https://doi.org/10.1016/j.
resourpol.2019.101414.
Wickham, H., 2016. ggplot2: Elegant Graphics for Data Analysis. Springer-Verlag, New
York. https://ggplot2.tidyverse.org.
Woodward, M., Hamilton, J., Wu, H., Alberts, G., Hooper, J., Walton, B., 2019. New
Market. New Entrants. New Challenges battery electric vehicles. https://www2.del
oitte.com.
Yan, J., Fan, Z., Sun, W., Ning, G., Wei, T., Zhang, Q., Zhang, R., Zhi, L., Wei, F., 2012.
Advanced asymmetric supercapacitors based on Ni(OH)2/Graphene and Porous
Graphene Electrodes with high energy density. Adv. Funct. Mater. 22, 2632–2641.
https://doi.org/10.1002/adfm.201102839.
Yao, P., Zhang, X., Wang, Z., Long, L., Han, Y., Sun, Z., Wang, J., 2021. The role of nickel
recycling from nickel-bearing batteries on alleviating demand-supply gap in China’s
industry of new energy vehicles. Resour. Conserv. Recycl. 170, 105612 https://doi.
org/10.1016/j.resconrec.2021.105612.
Zor, K., Buluş, K., 2021. A benchmark of GRU and LSTM networks for short-term electric
load forecasting. In: 2021 International Conference on Innovation and Intelligence
for Informatics, Computing, and Technologies. 3ICT, pp. 598–602. https://doi.org/
10.1109/3ICT53449.2021.9581373.
A.C. Ozdemir et al.
https://doi.org/10.1016/j.cclet.2016.07.027
https://doi.org/10.1016/j.cclet.2016.07.027
https://doi.org/10.1016/j.knosys.2019.105006
https://doi.org/10.1016/j.resourpol.2021.102520
https://doi.org/10.1016/j.resourpol.2021.102520
https://doi.org/10.1016/j.jclepro.2018.12.119
https://doi.org/10.1016/j.jclepro.2018.12.119
https://doi.org/10.1016/j.resourpol.2021.102544
https://doi.org/10.1016/j.resourpol.2021.102544
https://doi.org/10.1038/s41560-018-0179-z
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref55
https://doi.org/10.1016/j.resconrec.2020.105198
https://doi.org/10.1016/j.resconrec.2020.105198
https://nickelinstitute.org/about-nickel/stainless-steel
https://nickelinstitute.org/about-nickel/stainless-steel
https://doi.org/10.1007/s42461-020-00370-y
https://doi.org/10.1007/s42461-020-00370-y
https://www.webofscience.com/wos/woscc/full-record/WOS:000700374600003
https://www.webofscience.com/wos/woscc/full-record/WOS:000700374600003
https://doi.org/10.1016/S0301-4207(02)00008-9
https://doi.org/10.1016/S0301-4207(02)00008-9
https://doi.org/10.48550/arXiv.1912.01703
https://doi.org/10.48550/arXiv.1912.01703
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref62
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref62
http://refhub.elsevier.com/S0301-4207(22)00350-6/sref62
https://roskill.com/news/nickel-market-beware-batteries-can-no-longer-ignored
https://roskill.com/news/nickel-market-beware-batteries-can-no-longer-ignored
https://doi.org/10.1016/j.resconrec.2016.04.017
https://doi.org/10.1155/2019/1934796
https://doi.org/10.1016/j.enpol.2006.02.012
https://doi.org/10.1016/j.enpol.2006.02.012
https://www.epa.gov/ghgemissions/global-greenhouse-gas-emissions-data
https://www.epa.gov/ghgemissions/global-greenhouse-gas-emissions-data
https://doi.org/10.1016/j.jclepro.2019.06.174
https://doi.org/10.1016/j.cclet.2018.12.005
https://doi.org/10.1016/j.cclet.2018.12.005
https://doi.org/10.1016/j.resourpol.2019.101414
https://doi.org/10.1016/j.resourpol.2019.101414
https://ggplot2.tidyverse.org
https://www2.deloitte.com
https://www2.deloitte.com
https://doi.org/10.1002/adfm.201102839
https://doi.org/10.1016/j.resconrec.2021.105612https://doi.org/10.1016/j.resconrec.2021.105612
https://doi.org/10.1109/3ICT53449.2021.9581373
https://doi.org/10.1109/3ICT53449.2021.9581373
	Medium- to long-term nickel price forecasting using LSTM and GRU networks
	1 Introduction
	2 Literature review
	3 Material and methods
	3.1 Material
	3.1.1 Data set information
	3.1.2 Descriptive statistics of data set
	3.2 Forecasting methods
	3.2.1 LSTM networks
	3.2.2 GRU networks
	4 Results and discussion
	5 Conclusions
	Credit authorship contribution statement
	Funding sources
	Declaration of competing interest
	Data availability
	References
