TA918C(1s2024) - Aula 8 - PROCESSO CONTINUO

Prévia do material em texto

Prof. Andreas K. Gombert
TA918C - Microbiologia
e Fermentações
Aula 8 - 09/05/2024
BIOPROCESSOS CONTÍNUOS
constant physico-chemical conditions. Furthermore, chemostat cultures
enable studies on the growth of micro-organisms at specific growth rates
below their mmax. Thus, even when microbial strains or growth conditions
are compared that have or cause a different mmax, chemostat cultivation
enables a comparison of their physiology at an identical specific growth rate
chosen and set by the researcher.
A chemostat (Fig. 2) can be defined by five key elements: (i) an ideally
mixed fermentation vessel (bio-reactor), (ii) a continuous inflow of fresh
growth medium, (iii) a medium composition in which a single nutrient of
choice limits biomass formation and in which all other nutrients are present
in excess, (iv) a continuous outflow of culture broth with an identical
chemical composition and biomass concentration to that in the bio-reactor
and (v) a constant ratio between effluent flow rate and culture volume in the
bio-reactor. The unique option of chemostats to ‘‘dial in’’ a specific growth
rate can best be understood by combining these five defining elements with a
mass balance of the biomass:
dðVcxÞ=dt ¼ jincx;in $ foutcx;out þ mcx;bioreactorV
Figure 2 Experimental setup for chemostat cultivation. Panel A, early design by
Monod (from Monod, 1950) where N indicates the medium reservoir; B the bio-
reactor in which cells are grown; P the effluent reservoir; E the inoculation flask and
M the stirring engine. Panel B, photograph of a current chemostat setup where 1
indicates the medium reservoir, 2 the bio-reactor, 3 the effluent reservoir, 4 the
inoculation flask and 5 the stirring engine. Adapted from Monod (1950) with
permission from Institut Pasteur.
MICRO-ARRAY ANALYSIS IN BAKER’S YEAST 265
Author's personal copy
FORMAS DE CONDUÇÃO DO PROCESSO:
- BATELADA (= descontínuo)
- BATELADA-ALIMENTADA (=descontínuo-alimentado)
- CONTÍNUO
SCRIT
Processo contínuo
(=continuous)
X

The CONTINUOUS reactor
Compounds are
constantly fed and
being removed along
the process
TYPICAL AIM IS TO CALCULATE THE VOLUME.
Flow/volume = residence time-1
V.C. = Volume de Controle
EQUAÇÃO GERAL DO BALANÇO DE MASSA
ACÚMULO = ENTRA - SAI + PRODUÇÃO
Produção ≠ 0 quando o componente é consumido ou gerado numa reação
Produção = 0 quando não houver reação ou quando o B.M. total
Acúmulo = 0 quando a situação for de regime permanente (=estado estacionário)
Acúmulo ≠ 0 quando a situação for de regime transiente
Balanço de massa de células:
d(X.V)/dt = FE.XE - FS.XS + μ.X.V [massa de células/tempo]
Batelada: FE = FS = 0
Batelada-alimentada: FS = 0
Contínuo: normalmente, FE = FS e estado estacionário: d(XV)/dt = 0
Normalmente, XE = 0 (alimentação de meio estéril).
Hipótese de mistura perfeita: XS = X
0 = -FS.X + μ.X.V = X*(μ.V - FS)
• Balanços de massa em biorreatores
FE
XE
FS
X
Veloc. espec. de crescimento
μ = (1/X)*(dX/dt)
Veloc. espec. de consumo de S
μS = (1/X)*(-dS/dt)
Veloc. espec. de formação de P
μP = (1/X)*(dP/dt)
X
• Balanços de massa em biorreatores
FE FS
V.C. = Volume de Controle
EQUAÇÃO GERAL DO BALANÇO DE MASSA
ACÚMULO = ENTRA - SAI + PRODUÇÃO
Balanço de massa de substrato:
d(S.V)/dt = FE.SE - FS.SS - μS.X.V [massa de substrato/tempo]
Batelada: FE = FS = 0
Batelada-alimentada: FS = 0
Contínuo: normalmente, FE = FS e estado estacionário: d(SV)/dt = 0
Hipótese de mistura perfeita: SS = S
0 = FE.SE - FS.S - μS.X.V
Veloc. espec. de crescimento
μ = (1/X)*(dX/dt)
Veloc. espec. de consumo de S
μS = (1/X)*(-dS/dt)
Veloc. espec. de formação de P
μP = (1/X)*(dP/dt)
V.C. = Volume de Controle
EQUAÇÃO GERAL DO BALANÇO DE MASSA
ACÚMULO = ENTRA - SAI + PRODUÇÃO
Balanço de massa de produto:
d(P.V)/dt = FE.PE - FS.PS + μP.X.V [massa de produto/tempo]
Batelada: FE = FS = 0
Batelada-alimentada: FS = 0
Contínuo: normalmente, FE = FS e estado estacionário: d(PV)/dt = 0
Normalmente, PE = 0 (alimentação de meio estéril).
Hipótese de mistura perfeita: PS = P
0 = - FS.P + μP.X.V
• Balanços de massa em biorreatores
FE FS
V.C. = Volume de Controle
Veloc. espec. de crescimento
μ = (1/X)*(dX/dt)
Veloc. espec. de consumo de S
μS = (1/X)*(-dS/dt)
Veloc. espec. de formação de P
μP = (1/X)*(dP/dt)
Balanço de massa de células:
d(X.V)/dt = FE.XE - FS.XS + μ.X.V (XE = 0, V = cte, XS = X)
V.dX/dt = - FS.X + 𝜇.X.V (defino vazão específica D = F/V)
dX/dt = (-D + 𝜇).X (em estado estacionário, dX/dt = 0)
D = F/V = 𝜇 (desde que 𝜇 < 𝜇MAX) O QUE ISTO SIGNIFICA?
Processo contínuo
9
Description of the Chemostat
Author(s): Aaron Novick and Leo Szilard
Source: Science, New Series, Vol. 112, No. 2920 (Dec. 15, 1950), pp. 715-716
Published by: American Association for the Advancement of Science
Stable URL: http://www.jstor.org/stable/1678964 .
Accessed: 10/02/2011 06:03
Your use of the JSTOR archive indicates your acceptance of JSTOR's Terms and Conditions of Use, available at .
http://www.jstor.org/page/info/about/policies/terms.jsp. JSTOR's Terms and Conditions of Use provides, in part, that unless
you have obtained prior permission, you may not download an entire issue of a journal or multiple copies of articles, and you
may use content in the JSTOR archive only for your personal, non-commercial use.
Please contact the publisher regarding any further use of this work. Publisher contact information may be obtained at .
http://www.jstor.org/action/showPublisher?publisherCode=aaas. .
Each copy of any part of a JSTOR transmission must contain the same copyright notice that appears on the screen or printed
page of such transmission.
JSTOR is a not-for-profit service that helps scholars, researchers, and students discover, use, and build upon a wide range of
content in a trusted digital archive. We use information technology and tools to increase productivity and facilitate new forms
of scholarship. For more information about JSTOR, please contact support@jstor.org.
American Association for the Advancement of Science is collaborating with JSTOR to digitize, preserve and
extend access to Science.
http://www.jstor.org
QUIMIOSTATO
10
Monod, J. (1950) La technique de culture continue theorie et applications. Annales de l’Institut Pasteur 79, 390–410.
constant physico-chemical conditions. Furthermore, chemostat cultures
enable studies on the growth of micro-organisms at specific growth rates
below their mmax. Thus, even when microbial strains or growth conditions
are compared that have or cause a different mmax, chemostat cultivation
enables a comparison of their physiology at an identical specific growth rate
chosen and set by the researcher.
A chemostat (Fig. 2) can be defined by five key elements: (i) an ideally
mixed fermentation vessel (bio-reactor), (ii) a continuous inflow of fresh
growth medium, (iii) a medium composition in which a single nutrient of
choice limits biomass formation and in which all other nutrients are present
in excess, (iv) a continuous outflow of culture broth with an identical
chemical composition and biomass concentration to that in the bio-reactor
and (v) a constant ratio between effluent flow rate and culture volume in the
bio-reactor. The unique option of chemostats to ‘‘dial in’’ a specific growth
rate can best be understood by combining these five defining elements with a
mass balance of the biomass:
dðVcxÞ=dt ¼ jincx;in $ foutcx;out þ mcx;bioreactorV
Figure 2 Experimental setup for chemostat cultivation. Panel A, early design by
Monod (from Monod, 1950) where N indicates the medium reservoir; B the bio-
reactor in which cells are grown; P the effluent reservoir; E the inoculation flask and
M the stirring engine. Panel B, photograph of a current chemostat setup where 1
indicates the medium reservoir, 2 the bio-reactor, 3 the effluent reservoir, 4 the
inoculation flask and 5 the stirring engine.Adapted from Monod (1950) with
permission from Institut Pasteur.
MICRO-ARRAY ANALYSIS IN BAKER’S YEAST 265
Author's personal copy
QUIMIOSTATO = Cultivo contínuo em estado
estacionário, com um nutriente limitante do
crescimento no meio de alimentação.
Criado simultaneamente por Monod ;-)
Balanço de massa de células:
d(X.V)/dt = FE.XE - FS.XS + μ.X.V (XE = 0, V = cte, XS = X ou mistura perfeita)
V.dX/dt = - FS.X + 𝜇.X.V (defino vazão específica D = F/V)
dX/dt = (-D + 𝜇).X (em estado estacionário, dX/dt = 0)
D = 𝜇 O QUE ISTO SIGNIFICA?
Balanço de massa de substrato:
d(S.V)/dt = FE.SE - FS.SS - μS.X.V (FE = FS = F, V = cte, SS = S ou mistura perfeita)
V.dS/dt = F(SE - S) - μS.X.V (em estado estacionário, dS/dt = 0)
0 = D(SE - S) - μS.X (lembrando que YX/S = 𝜇/μS)
0 = D(SE - S) - (𝜇/YX/S)*X (D = 𝜇, do B.M. de células acima)
0 = D(SE - S) - (D/YX/S)*X
0 = D(SE - S - X/YX/S)
X = YX/S*(SE - S) —> X dentro do reator, no estado estacionário
Quimiostato
• Por que um cultivo contínuo tende ao estado estacionário?
dX/dt = (-D + 𝜇).X imaginemos que por algum motivo 𝜇 > D, então X cresce
X = YX/S(SE - S) se X cresce, então S tem que diminuir, pois Y e SE são ctes
𝜇 = 𝜇MAX.S/(KS + S) equação de Monod* —> 𝜇 diminui e o sistema tende a 𝜇=D
(pode-se fazer o raciocínio inverso, 𝜇 < D, e chega-se à mesma conclusão)
* considera apenas o fenômenos de limitação por S, ou seja, 𝜇 é somente função de
uma eventual limitação por S e não também função de outros fenômenos, como
por exemplo inibição por S ou inibição por P
sempre se inicia como um cultivo em batelada, mas…
Modelo cinético de Monod
https://www.cs.montana.edu/webworks/projects/stevesbook/contents/chapters/chapter002/section002/black/page001.html
SCRIT
forma da equação é idêntica à de
Michaelis & Menten, para
cinética enzimática. Mas, enquanto
a primeira é baseada
num mecanismo de reação (modelo
fenomenológico), a de
 Monod é baseada
em observação experimental
somente (modelo empírico)!
14
