This easy-to-build mobile tool
stand packs a shop full of
convenience in a small package.
 Quick-convert
Tablesaw/Router Station
Raise the
wings for full
workpiece
support.
A router table
and accessories
stow away in
the drawer.
Voilà! A router table
with fence and
plenty of infeed and
outfeed support.
Tools needed:
 Overall dimensions when folded are
 32 7⁄8" wide × 29 3⁄8" deep × 31 1⁄4" high.
 Unfolded: 72×48×31 1⁄4".
 Materials needed: Birch plywood and
 medium-density fiberboard (MDF).
Skill Builders
 Discover an easy way to table-mount
 a router.
 Use guides to accurately position and
 install hinges.
Project Highlights
With a footprint of less than 7
square feet when folded, this
mobile tool stand expands into
a massive 17-square-foot tablesaw work-
surface. And it’s multitalented—to switch
to a router table, simply slide out the on-
board router drawer. See More Resources,
page 6, for an idea about compatible stor-
age for the tablesaw.
MD-00931
Page 2 of 10
Note: The dimensions in this project
assume a material thickness of 3⁄4". Most
sheet goods will be slightly undersize.
In order to ensure that dimensions of
subassemblies are correct, measure the
thickness of your materials and adjust
the length of adjoining project parts to
compensate.
Construct the carcase
1From 3⁄4" plywood, cut the sides (A),
back (B), shelf (C), and base (D) to
size. (See Materials List, page 10 .) Predrill
and screw the sides to the back as shown
[Drawing 1, Photo A].
2With the case on its back, slide the
shelf (C) into place [Drawing 1] and
secure with screws. Now, flip the case
onto its top. Center the base (D) side-to-
side, positioning it 1" from the front of
the case, and screw it into place. Drill
holes to fit the caster stems and, before
A
a brace squares the case
C
quick scrapwood Guides ease hiNGe pLaceMeNt
D
A squaring brace (see More Resources, page 32)
aligns and steadies the sides (A) and back (B) for
drilling and screwing.
A scrapwood guide held against the back edge of the wing
support correctly positions the hinge at 90° while you
secure it.
Clamp a spacer to the case (1" for the front; 1 1⁄2"
for the back). Position the wing support (E) flush
with the case top, and secure the hinge.
A
A
B
cut two supports froM oNe bLaNk
Firm support, a 10-tpi or higher blade, a slow-but-steady
cut rate, and zero orbital action ensure a smooth, straight
jigsaw cut.
E
E
Scrapwood
guide1¼"
E
A
1" spacer
righting the case, install the casters to
ease mobility during assembly.
3From 3⁄4" plywood cut three 12×12"
blanks, and lay out the wing support
(E) dimensions [Drawing 1a]. Use a jigsaw
to cut the blank into two supports along
the diagonal [Pho to B]. Then, smooth
the cuts with a sanding block.
4Use a scrapwood guide as a straight-
edge to locate and secure the 2 1⁄2"
butt hinges to the wing supports (E)
[Photo C]. Be sure to attach the hinges on
the inside faces of the wings, creating
three mirrored pairs of wing supports.
Use scraps to position and secure the
wing supports to the case sides (A) and
back (B) [Photo D].
While we show this mobile base with the
Bosch GTS1031 benchtop tablesaw (find a
review of this saw at woodmagazine.com/
benchtopbosch), the base was designed to fit
many similar-size tablesaws. Before building,
measure your chosen tablesaw’s dimensions
carefully and adjust the base to match your
E
B
saw if necessary. Likewise, measure your
router’s height to ensure it fits in the bin.
Page 3 of 10
FI
LE
N
A
M
E:
 2
13
Tb
lR
te
rS
ta
tio
n1
_#
10
06
73
40
7.
ai
D
at
e:
 1
-1
2
Lo
rn
a
J.
Fi
le
na
m
e:
 2
13
Tb
ls
aw
Ro
ut
er
St
at
io
n
Lj
 1
-1
1,
 k
b
1-
18
 #8
 x
 1
½
" F
.H
.

 s
cr
ew
2½
"
bu
tt
 h
in
ge
#8
 x
 ¾
" F
.H
. s
cr
ew
#8
 x
 1
½
" F
.H
.

 s
cr
ew
D
us
t-
co
lle
ct
io
n
ho
le
32
7⁄8
"
29
3⁄8
"
23
7⁄8
"
D
E
A
E
E
E
24
5⁄8
"
B
E
E
N
N
1"
3¾
"
3¾
"
¾
"
1¼
"
½
" h
ol
e
1"
¾
"
1"
26
¼
"
23
7⁄8
"
1½
"
12
"
10
"
1
CA
RC
A
SE
Lo
ca
tio
n
of



C
10
½
"
A
FI
LE
N
A
M
E:
 2
13
Tb
lR
te
rS
ta
tio
n1
a_
#1
00
67
34
08
.a
i
D
at
e:
 1
-1
2
Lo
rn
a
J.
Fi
le
na
m
e:
 2
13
Tb
ls
aw
Ro
ut
er
St
at
io
n
Lj
 1
-1
1,
 k
b
1-
18
, L
P
2-
29

1a
 W
IN
G
 S
U
PP
O
RT
10
"
12
"
2"
E
C
A
RC
A
sE
1 W
in
g
 s
u
PP
o
RT
1a
Page 4 of 10
steady parts with a cLaMp
A clamp holds the corners of the wing bracing
assembly (F/g) flush and steady while you predrill, then
secure it with screws.
triM up the tops
Trim the wing top with a flush-trim bit. set the bit
depth so the bearing doesn’t dip into screwhead
depressions, which could gouge the edge.
G
F
I
G
Now give it wings
1From 3⁄4" plywood, cut the wing outer
bracing (F), wing bracing (G), and
outfeed bracing (H) to size. Then,
assemble the bracing with screws
[Drawing 2, Photo E].
2From 1⁄4" medium-density fiberboard
(MDF), cut the side wing tops (I) and
outfeed top (J) 1⁄8" larger than the width
and length listed in the Materials List.
Apply a bead of glue to the top edge of
each wing bracing assembly (F/G and
F/H) and clamp the tops in place
[Drawing 2] with 1⁄16" overhang on all
sides. After the glue has dried, trim the
edges flush [Photo F].
3Attach 2 1⁄2" butt hinges to the inside
of each wing (F/G/I and F/H/J)
[Drawing 2], centering the hinge barrel
on the bottom edge. Rest one side wing
(F/G/I) on the wing supports (E),
positioning its front flush with the front
of the case. Then secure the hinges to
the case. Repeat with the opposite side
wing. Then, center the outfeed wing
(F/H/J) on the rear wing supports and
secure the hinges.
shop tip
Baseplate helps you target mounting
holes with template precision
The fine-threaded screws used to table-mount your router
require a certain degree of precision when locating mounting
holes. Fortunately,your router has a built-in template: its
baseplate.
Retrieve one of the tray assemblies (K/L/M) for use as the
router-table top. Mark a centerpoint for the bit access hole,
centered 8 3⁄4" from one end [drawing 3]. Remove and position
your router’s baseplate, centered on the marks. Be sure to
orient it so that the router, when mounted in the same
position, will have its controls easily accessible. Mark the
locations of the mounting screws (and lift screw, if your router
has one); then, drill and counterbore holes to fit the mounting
screws. Next, drill a 1 1⁄2" bit access hole on the center mark.
Now, test-fit the router. You may have to purchase longer
screws of the same diameter and thread pitch in order to reach
the router base. Remove the router to continue the
construction.
You only need to center the bit access hole to “eyeball” precision.
once located, however, hold the subbase firmly to mark the
mounting holes accurately.
Router
subbase
Add two trays, fence,
and bin
1From 3⁄4" plywood, cut the long edging
(K), the short edging (L), and the tray
panels (M) to size. Next, assemble the
edging with screws before gluing and
clamping the panels in place [Drawing 2].
After the glue dries, see the Shop Tip, below,
E F
F
Page 5 of 10
The purchase of these plans does not
transfer any copyright or other ownership
interest in the plans, the design, or the
finished project to the buyer. Buyer may
neither reproduce the plans for sale nor offer
for sale any copies of the finished project.
FILENAME: 213TblRterStation2_#100673409.ai
Date: 1-12
Lorna J.
Filename: 213TblsawRouterStation
Lj 1-11, kb 1-18
2 EXPLODED VIEW
½" washer, lock washer, and nut
 #8 x 1½"
F.H. screws
 #8 x 1½"
F.H. screw
2½"
G
2½"
butt hinge
 #8 x ¾"
F.H. screw
A
G
I
J
K
M
F
B
C
E
H
F
F
F
GG
L
N
237⁄8"
FCenter on .
2½"
223⁄8"
237⁄8"
237⁄8"
237⁄8"
307⁄8"
¾" 293⁄8"
¼"
237⁄8"
23¾"
237⁄8"
237⁄8"
22¼"
¾" 237⁄8"
2"
3" locking swivel caster
F
E
3"
K
L
H
H
I
A
D
#8 x 1½" F.H. screw
1½"
10"
10"
ExPlodEd viEW2
Page 6 of 10
to locate the mounting holes for your
router in one of the tray assemblies
(K/L/M).
2Cut the tray supports (N) to size. To
position the lower supports, measure
and add the height of your tablesaw table
to the height of the tablesaw tray
assembly (K/L/M). Measure and mark
this distance down from the top edge of
the case. Now, use screws to fasten the
supports to the case with the top flush
with these marks [Drawing 2]. Next,
secure the upper tray supports flush with
the top of the case. Then, rest the
tablesaw tray assembly on the lower tray
support, and the router tray assembly on
the top tray support.
3Cut the fence face (O) and fence base
(P) to size. Lay out and jigsaw the
3"-diameter semicircles, centered, where
shown [Drawing 3]. Sand the cuts smooth;
then glue and clamp the face to the base.
4 After the glue dries, drill the 1⁄4" pivot
holes in the fence (O/P). Position the
fence where shown [Drawing 3], and
clamp it in place. Using one fence pivot
Lay out the pivot sLot for a fuLLy adjustabLe feNce
Pivot the fence about 2" away from the bit access hole
while drawing a pencil line first on one side of the
hole, then the other.
Connect the two arcs to complete the pivot-slot layout
before drilling the ends and cutting away the waste
with a jigsaw.
O
P
Pivot bolt
Pivot-slot
location
 The tool trays in this mobile base were made to be compatible with the Bench-tool
System from the October 2007 issue of WOOD® magazine. You can find the plan here for a
small fee: woodstore.net/besy.html
 For a free right-angle clamping brace plan, see woodmagazine.com/clampingbrace
More Resources
Produced by Lucas Peters with Kevin Boyle
Project design: John Olson
Illustrations: Lorna Johnson
5Cut the bin front and back (Q), bin
sides (R), bin bottom (S), and bin
cleats (T) to size. Lay out, drill, then
jigsaw the handle cutouts in the front
and back [Drawing 4]. Then, sand the
cuts smooth and round over the edges
with a 1⁄8" round-over bit. Assemble the
sides, front, and back with screws before
gluing and clamping the bottom in
place. After the glue is dry, screw the bin
cleats to the bin side half in, half out of
the bin.
6 Bolt or screw the tablesaw to the
tablesaw tray and slide the tray into
place. If your tablesaw has a dust-
collection port, mark the location and
lay out a hole slightly larger than your
dust hose [Drawing 1]. Drill a blade start
hole and cut out the dust-collection hole
with a jigsaw.
Mount the router in the router-tray
assembly (K/L/M). Store the fence and
router accessories in the bin, cap it with
the router-table tray, and get to work!
hole as a guide, drill through the tray
assembly (K/L/M). Remove the clamps
and temporarily pin that end of the fence
to the table using a 1⁄4" carriage bolt. Now,
rotate the fence to mark the location of
the pivot slot [Photos G and H], drill 1⁄4"
holes at either end of the arc, and cut
away the remainder of the slot with a
jigsaw.
G H
Page 7 of 10
FILENAME: 213TblRterStation3_#100673410.ai
Date: 1-12
Lorna J.
Filename: 213TblsawRouterStation
Lj 1-11, kb 1-18
3 ROUTER TRAY
2"-long pivot slot
K
L
M
1½"
11⁄8"
2¼"
1½" hole
3"
22"
9"
8"
¼" pivot holes
3"-diam. arcs
¼" carriage bolt 2" long
¼" knob ¼" washer
P
O
8¾"
RouTER TRAY3
Page 8 of 10
FI
LE
N
A
M
E:
 2
13
Tb
lR
te
rS
ta
tio
n4
_#
10
06
73
41
1.
ai
D
at
e:
 1
-1
2
Lo
rn
a
J.
Fi
le
na
m
e:
 2
13
Tb
ls
aw
Ro
ut
er
St
at
io
n
Lj
 1
-1
1,
 k
b
1-
18

4
BI
N
Q
S
23
¾
" 7"
23
7⁄8
"
7"
22
¼
"
23
7⁄8
"
¾
"
¾
"
¾
"
87
⁄8"
4½
"
1¾
"
1½
" h
ol
e
R
R
Q
T
T
#8
 x
 1
¼
" F
.H
. s
cr
ew #8
 x
 1
½
" F
.H
. s
cr
ew
22
¼
"
2"
1⁄8
" r
ou
nd
-o
ve
r a
lo
ng
ed
ge
s
of
 o
pe
ni
ng
Bi
n
4
Page 9 of 10
Materials List
fiNished siZe
Part
Carcase
t w L Matl. qty.
A sides 3⁄4" 24 5⁄8" 26 1⁄4" BP 2
B back 3⁄4" 23 7⁄8" 26 1⁄4" BP 1
C shelf 3⁄4" 23 7⁄8" 23 7⁄8" BP 1
D base 3⁄4" 29 3⁄8" 32 7⁄8" BP 1
E wing supports 3⁄4" 10" 12" BP 6
Wings
F wing outer
bracing
3⁄4" 2 1⁄2" 23 7⁄8" BP 6
G wing bracing 3⁄4" 2 1⁄2" 22 3⁄8" BP 6
H outfeed bracing 3⁄4" 2 1⁄2" 29 3⁄8" BP 3
I* side wing tops 1⁄4" 23 7⁄8" 23 7⁄8" MDF 2
J* outfeed top 1⁄4" 23 7⁄8" 30 7⁄8" MDF 1
Trays
K long edging 3⁄4" 2" 23 7⁄8" BP 4
L short edging 3⁄4" 2" 22 1⁄4" BP 4
M tray panels 3⁄4" 23 3⁄4" 23 7⁄8" BP 2
N tray supports 3⁄4" 1" 23 7⁄8" BP 4
Router fence
O face 3⁄4" 2 1⁄4" 22" BP 1
P base 3⁄4" 3" 22" BP 1
Router bin
Q front and back 3⁄4" 7" 22 1⁄4" BP 2
R sides 3⁄4" 7" 23 7⁄8" BP 2
S bottom 3⁄4" 23 3⁄4" 23 7⁄8" BP 1
T cleats 3⁄4" 2" 22 1⁄4" BP 2
*Parts initially cut oversize. See the instructions.
Materials key: BP–birch plywood, MDF–medium-density
fiberboard.
Supplies: 3" locking swivel casters (4), 1⁄2" washers, lock
washers, and nuts (4 each), 2 1⁄2" butt hinges (9 pairs needed),
#8×3⁄4" F.H. screws (for hinges), #8×1 1⁄2" F.H. screws, #8×1 1⁄4" F.H.
screws; 1⁄4" knobs, 1⁄4×2" carriage bolts, and washers (2 each).
Bits: Flush-trim and 1⁄8" round-over router bits; 1 1⁄2" Forstner
bit.
Page 10 of 10
Cutting Diagram
FILENAME: 213TblRterStationCD_#100673412.ai
Date: 3-12
Lorna J.
Filename: 213TblsawRouterStation
Cutting Diagram Lj 3-1
CUTTING DIAGRAM
I I J
¼ x 24 x 96" Medium-density �berboard
D
¾ x 48 x 48" Birch plywood
BA A
¾ x 48 x 96" Birch plywood
C
E
E
E
E
E
E
SM M
PO
¾ x 48 x 96" Birch plywood
T
QR R Q
H
G
L T KN N
FF
The purchase of these plans does not
transfer any copyright or other ownership
interest in the plans, the design, or the
finished project to the buyer. Buyer may
neither reproduce the plans for sale nor offer
for sale any copies of the finished project.
On this info-filled disc you’ll find more than...
Includes an easy-to-use article index!
For more product information or updated versions of thisDVD-ROM,
go to woodmagazine.com/DVDLibrary
W
OOD M
agazine Septem
ber 1984 – D
ec/Jan 2011/2012 Issues 1–209
325
Furniture Projects
270
Shop Projects
940
Weekend Projects
 6 45
1,70 0
Shop Tips
 875
Tool Reviews
and Features
Skill-Building
Techniques
Issues 1–209
Easy-to-makeWine Cabinet
WOOD
Better Homes and Gardens®
ISSUE 172 OCTOBER 2006
D
®
W
OOD
 172 O
C
TO
B
ER
 2006
$6.99 U.S. / $7.95 CAN.
Display until October 10, 2006
A GREAT WEEKEND PROJECT!
p.82
END-GRAIN CUTTING BOARD
21 Workshop Clutter Busters
 p.90
Add to Your Skills• Cut Perfectly Straight Edges p.76• Tune Up your Bandsaw p.52• Kerf-Bend Plywood p.32
Improve Your Shop• Space-saving Tool Storage p.46• 10 Air Cleaners Tested p.70
Better Homes and Gardens®
ISSUE 178 SEPTEMBER 2007
®
FREE FULL-SIZE
PATTERNS INSIDE
TE ACH KI DS WOO DWO R KI NG : A PROVE N 4 -STE P PL AN !
$6.99 U.S. / $7.95 CAN.
Display until August 28, 2007
Heirloom CradleCraft it this weekend.Cherish it for generations.
47
Time- and Money-Saving Tips Inside!
20 Tools Tested
• 12" Mitersaws
• Parallel Jaw Clamps
• Steel Rules
More Great Projects
• Space-saving Outfeed Table
• Tablesaw
 Alignment Jig
• Catchall Box
• Tower Shelves
• Bistro Stool
Build Your Skills• Clamping Secrets
• No-slip Miters
• Template Routing
• Faux Finishes
Stores flat in it’s own case!
Better Homes and Gardens®
ISSUE 186 OCTOBER 2008
®
$6.99 U.S.
D
is
p
la
y
u
n
ti
l O
ct
o
b
er
 7
, 2
0
08
11 Easy-to-Build Projects Inside
200 m.p.h. & made of wood!You need to see it to believe it. p. 50
TRIO OF TABLES p.32 CHINESE CHECKERS p.72 MITERSAW STAND p.44
EXCLUSIVE!
PLUS
31 TOOLS TESTED
IN THIS ISSUEWO OD
We Test & Rank the Newest 18-Volt Lithium-Ion Drills
ISSUE 209 DEC/JAN 2011/2012 Better Homes and Gardens®
Tur n Stock C abinets into Fur ni ture!
p.32
Make this
tall chest,
and other
fine furniture,
the EASY way.Great Projects!
Jewelry Box p.38
Carousel Music Box p.45Backgammon Board p.50Rockin’ Truck p.63
We Test & Rank the Newest 18-Volt Lithium-Ion Drills p.58
$6.99 U.S.
Display until January 17, 2012
®
53Shop Tips Inside!
September 1984 – Dec/Jan 2011/2012
In a Searchable Digital Format
27
Years of
Issues!
WOOD® Complete Back Issues
NOTICE: Reproduction or distribution of the content of this product is strictly
prohibited. Purchase of this product does not transfer any title or rights of own-
ership in the content to the purchaser. The content of this product is protected
by copyright and may not be used for any other purpose without the written
permission of the copyright owner. © Copyright Meredith Corporation 2012.
All rights reserved. Produced in the USA.
Browse more than 1,300 woodworking project plans, DVDs, back-issue collections, videos, tool reviews, books, & more.
Everybody’s a tool critic. Now it’s your turn!
Readers rely on WOOD magazine for unbiased reviews of
woodworking tools
and accessories.
You’ll find them here,
all in one place. While
you’re there, add
reviews about the
tools in your shop.
Just click to compare
specs, prices,
and more.
toolreviews.woodmagazine.com
Plans “Complete Guide” DVD-ROM’s Videos Back-Issue Collections
The biggest names in woodworking
help you build your skills with
affordable videos (up to 2 hours long).
Save money by doing the download.
Watch free videos of other
woodworkers showing their stuff,
from shop tips, to favorite jigs, to...
well, just about anything!
Don’t spend a penny on a tool until
you learn how it works. Tool School is
like having a free woodworking show
on your desktop!
WOOD magazine editors provide
videos that enhance the content in
the magazine. New videos added
regularly.
A wealth of information just a click away.
WOODmagazine.com speaks to woodworkers of all skill levels with
free woodworking
plans, helpful
forums, hundreds
of articles, and
more services to
help you become a
better woodworker.
Visit the WOOD®
 family
of helpful Web sites!
WOODmagazine.com
WOODmagazine.com/videos
Watch a demo before you buy
FREE magazine support 24/7DVDs or downloads
By woodworkers, for woodworkers
WOODStore.net
