© 2018 Hogrefe Vasa (2018), 47 (5), 403–407
 https://doi.org/10.1024/0301-1526/a000719
 403
Original communication
Staged ultrasound-guided
liposuction for hidden arteriovenous
fi stulas in obese patients
Gabor Cs.Nagy1, Reiner Verwiebe2, and Matthias Wunsch3
1 Department of Vascular Surgery, St. Bernward Hospital, Hildesheim, Germany
2 Department of Nephrology and Dialysis, St. Bernward Hospital, Hildesheim, Germany
3 Department of Vascular Surgery, Königin Elisabeth Herzberge Hospital, Berlin, Germany
Summary: Background: In obese patients with end stage renal disease, puncturing matured arteriovenous fi stulas (AVF) that
run deep under the skin surface may prove diffi cult. To achieve reliable puncturability, there are several surgical solutions.
Superfi cialization with mobilization is common. With some newer options (lipectomy and liposuction) subcutaneous adipose
tissue is surgically reduced. There are only a few authors who have published their experience with liposuction and we want
to add our own results. Patients and methods: We report our experience with ultrasound-guided liposuction (USGL). We intro-
duce liposuction cannulas via small incisions to reduce the subcutaneous adipose tissue overlying the planned cannulation
zones under ultrasound control using tumescent anaesthesia till the prospective needle access segments become easily
palpable. So far, we have used this technique for cephalic forearm and upper arm fi stulas only. Furthermore, we review the
relevant literature. Results: From February 2014 through November 2016, six patients were treated using USGL. Their body
mass indices ranged from 30.8 to 53.8 kg/m2 (mean 37.6). The mean depths of the AVFs beneath the skin surface were 13.3
(8–20) mm before and 5.1 (3.5–6) mm after surgery. The mean time of the procedure was 15 minutes. There were no postop-
erative complications. In fi ve patients, the AVFs could reliably be punctured after three weeks. One patient is not yet on dialy-
sis. During the follow-up period of 24 (11–43) months, all six AVFs remained primarily patent. In the literature, we found nine
reports on altogether 81 patients undergoing USGL. Almost all noteworthy complications occurred only after ultrasound-
powered liquefaction of adipose tissue, which was only used by a single investigator. Conclusions: USGL is a method that can
be learned easily, is minimally invasive, seems to be safe, and requires only short operation times.
Keywords: Arteriovenous fi stula, vascular access, obesity, liposuction, superfi cialization, ultrasound-guided
Introduction
With an increasing prevalence of obesity in the general pop-
ulation, the same tendency can also be observed in patients
on dialysis [1, 2]. Thus, puncturing fi stulas in obese patients
with end stage renal disease constitutes a growing chal-
lenge. If the access site vein is located deeper than 6  mm
beneath the skin surface, the inability to insert fi stula nee-
dles, or complications of miscannulation such as haema-
toma formation, infections, false aneurysms, and fi stula
failures become more frequent. Apart from traditional tech-
niques for superfi cialization of the vein by mobilization or
lipectomy, new options like USGL as well as the so-called
minimally incision superfi cialization technique (MIST), and
the implantation of a titanium device (venous window nee-
dle guide, VWING) for repeated, easy buttonhole punctur-
ing have emerged in the last decade. We share our own ini-
tial experience with USGL, and summarize the literature.
Combining our own results with the available data pro-
vided by the literature, we would like to draw attention
to, and encourage the use of, the ultrasound-guided li-
posuction technique, which is simple, eff ective, and most
minimally-invasive.
Patients and methods
Surgical technique
The intended needle access segment of the matured fi stula
is marked under ultrasound visualization. We use tumes-
cent anaesthesia (25  ml lidocaine 1 % w/v, epinephrine
0.1 mg, 475 ml normal saline). The liposuction cannula (di-
ameter 3–4 mm), which is connected to the surgical aspira-
tor pump (60–80 kPa), is introduced and advanced under
ultrasound guidance via a 4 mm skin incision (ESM 1). We
perform repetitive back-and-forth movements with simul-
taneous rotations in a space (1.5–2.5  cm wide) extending
over the entire length of the plannedcannulation zone.
404 G. Cs.Nagy et al., Liposuction for deep AV fi stulas
Vasa (2018), 47 (5), 403–407 © 2018 Hogrefe

This procedure must be performed with care in order not to
get too close to the matured vein and is fi nished when the
entirety of the needle access segment becomes easily pal-
pable. We do not insert any drains. To prevent haematoma
formation, we place a folded piece of gauze over the newly-
formed shallow fossa and wrap the arm to exert suffi cient
elastic pressure. It is important to check for the typical thrill
so as not to occlude the fi stula.
The literature lists technical variations. Instead of tu-
mescent anaesthesia, others prefer undiluted 1 % lido-
caine with epinephrine [3]. As an alternative to a suction
pump, suction may also be created manually with a syringe
[3, 4]. To protect the fi stula from surgical injury, a protec-
tive shield may be used [5]. Likewise, this procedure can
be performed under videoscopic control [6] instead of ul-
trasound guidance. Not only superfi cial, but also lateral
adipose tissue surrounding the fi stula may be removed [3].
Only Ladenheim et al. [7] mentioned the use of additional
ultrasound-powered liquefaction, which led to a higher
complication rate. The same authors also introduced tour-
niquets to prevent haematomas.
Patients
From February 2014 through November 2016, six pa-
tients were included in a prospective follow-up study us-
ing USGL. Their body mass indices (BMI) ranged from
30.8 to 53.8 kg/m2 (mean 37.6). Four patients were treated
before starting dialysis, but after their fi stulas had ma-
tured. In the remaining two patients, the suitable access
segments proved too short for puncturing. We used USGL
with forearm cephalic fi stulas in four cases. Two cases
involved the upper arm cephalic vein. The mean depth of
the needle access segments under the skin surface was
determined pre- and postoperatively in each patient by
ultrasound (Figure 1). Four patients underwent surgery
under continued antiplatelet aggregation inhibitors, in-
cluding one who was also under clopidogrel and phenpro-
coumon. Follow-up ultrasound imaging was scheduled
after one week, one month, and six months. Technical
success meant that the needle access segments were eas-
ily palpable. Clinical success meant easy and safe cannu-
lation. Table I shows the patient data.
Figure 1. Ultrasound examination of the arteriovenous fi stula. Note the distance between the skin surface and the vein before (A) and after (B)
liposuction.
G. Cs.Nagy et al., Liposuction for deep AV fi stulas 405
© 2018 Hogrefe Vasa (2018), 47 (5), 403–407

noteworthy complications originated from one single
study [7] that used a special technique diff ering from all
others, i. e. the additional use of ultrasound-powered liq-
uefaction of adipose tissue in the fi rst nine out of thirteen
patients. The investigator abandoned the additional ul-
trasound-powered liquefaction during the course of the
study after serious adverse events (large haematomas,
wound necroses, and otherwise unobserved ultrasound
burn) had occurred in fi ve out of eight included patients
treated with this method. For the last four patients, he
utilised simple liposuction only, as did the investigators
of all other studies. So for the remaining 74 out of 87 pa-
tients (85 % of all cases) who did not belong to this par-
ticular study group, there were no serious adverse events.
Discussion
It is commonly agreed “that autogenous arteriovenous fi stu-
lae should be preferred over AV grafts, and AV grafts should
be preferred over catheters”, as stated by the European Best
Practice Guidelines on Haemodialysis [11]. There is a wide
armamentarium to treat deeply located arteriovenous fi stu-
las. We summarised the diff erent methods in Figure 2.
Standard techniques, which have traditionally been used
for the brachiobasilic fi stula with mainly single long inci-
sions, comprise elevation, tunnelled transposition, and ele-
vation transposition [12]. They all have in common that the
outfl ow vein is freed from the surrounding tissue and that
all side branches are ligated. Vessel wall lesions, stenoses
caused by wrongly-placed ligatures, torsion, tortuosity, and
increased tension may lead to early and late complications.
The absence of small side branches may reduce the longev-
ity of the access in case of proximal stenoses. Tunnelled
transposition can also be achieved endoscopically. A recent
technique for tunnelled transposition of venous segments,
named MIST (minimally incision superfi cialization tech-
nique) by the authors [13], includes two short oblique skin
incisions over the outfl ow vein, and placing the vein in a
subcutaneous tunnel between those two incisions.
Literature search
Our PubMed search of the literature yielded four papers
 [4, 5, 7, 8] and one letter to the editor [9]. We also found
three relevant congress abstracts [3, 6, 10] while searching
the internet. The keywords were liposuction, suction-as-
sisted, vascular access, arteriovenous fi stula, superfi ciali-
zation, and obesity.
Results
Own results
There were no complications in our patients. The mean
time required for such a procedure was 15  minutes. The
maximum mass of adipose tissue removed during a single
procedure was 130  g. Technical success was achieved in
every case. The mean depths of the AV fi stulas beneath the
skin surface were 13.3 (8–20)  mm before and 5.1 (3.5–
6) mm after surgery. After liposuction, fi ve patients could
be punctured easily after a delay of three weeks. One pa-
tient did not need dialysis thus far. The mean follow-up
time was 24 months (11–43). All fi stulas remained patent
and free from stenoses during the follow-up period.
Literature
In ESM 2, we provide an overview of the literature as well
as our data by listing complications, BMI of patients, pre-
operative mean depths of the matured veins, mean tissue
removed, time to access after intervention, primary and
secondary patency rates, and authors’ evaluations. Super-
fi cialization with liposuction was mainly used for cephal-
ic veins but also proved to be successful with arterio-
venous prosthetic grafts [3], which supposedly were
placed too deep originally. We found a total of 81 cases, to
which we added our own six patients. All patients with
Table I. Patient data.
# Gender Age
(years)
BMI
(kg/m2)
Cephalic AVF Preop. mean
vein depth (mm)
Postop. mean
vein depth (mm)
Time from AVF creation
till USGL (weeks)
ASA Follow-up
(months)
1 f 53 33.5 radiocephalic 12 5.5 15 yes 43
2 m 55 30.8 brachiocephalic 11.5 5.5 56 no 27
3 m 23 53.8 radiocephalic 20 5 48 yes 25
4 m 60 33.6 radiocephalic 8 5 118 yes 23
5 f 69 38.5 brachiocephalic 20 6 7 no 15
6 m 61 35.6 radiocephalic 8.5 3.5 23 yes 11
BMI: Body mass index; AVF: arteriovenous fi stula; USGL: ultrasound-guided liposuction; ASA: acetylsalicylic acid.
406 G. Cs.Nagy et al., Liposuction for deep AV fi stulas
Vasa (2018), 47 (5), 403–407 © 2018 Hogrefe

Conclusions
Ultrasound-guided liposuction is a minimally invasive
method for the superfi cialization of AVF outfl ow veins
with the smallest possible incision. Not having to mobilize
the vein excludes a number of complications. Without ul-
trasound-powered liquefaction, liposuction shows promis-
ing results. It requires only short operation times and can
easily be learned. No special plastic surgery training is nec-
essary for this simple procedure. Larger studies are needed
to determine its signifi cance and range of application.
Acknowledgement
We thank Maria Parecker for her technical help.
Electronic supplementary material
The electronic supplementary material is available with
the online version of the article at https://doi.org/10.1024/
0301-1526/a000719.
ESM 1. Figure.
Handling of the liposuction cannula under ultrasound
guidance.
ESM 2. Table.
Overview of the literature on liposuction for superfi cializa-
tion of deeparteriovenous fi stula outfl ow veins.
References
 1. Kramer HJ, Saranathan A, Luke A, Durazo-Arvizu RA, Guichan
C, Hou Susan, et al. Increasing body mass index and obesity in
the incident ESRD population. J Am Soc Nephrol. 2006;17:
453–1459.
 2. Postorino M, Mancini E, D’Arrigo G, Marino C, Vilasi A, Tripepi G,
et al. Body mass index trend in haemodialysis patients: the
More recent papers present techniques without mobili-
zation of the outfl ow vein, i. e. lipectomy, liposuction, and
the implantation of a so-called VWING (venous window
needle guide) device [14, 15], which is a palpable titanium
implant that facilitates buttonhole puncturing.
Staged (excisional) lipectomy also shows fair results [16]
despite a few major complications. However, USGL is less
invasive and more likely to be faster.
The literature on liposuction – also called suction lipec-
tomy or suction-assisted lipectomy – is limited [3–10]. We
could not fi nd any papers published by European authors
concerning this matter. Unlike lipectomy studies, most
liposuction cases have only been published as congress
abstracts. USGL avoids risks that the mobilization of the
outfl ow vein fi stula involves. There is no denudation, no
torsion, no stenosis caused by ligation of tributaries, and
no excessive tension. Also, not having to create a new
anastomosis as in a staged elevation procedure or MIST
saves time.
We could not confi rm concerns raised in the literature
[17, 18], according to which during USGL the AVF outfl ow
vein is at a particularly high risk of being injured by the
close passage of the liposuction cannula, as none of the
published cases reported any outfl ow vein lesions. Consid-
ering the total number of published lipectomies (170) vs.
liposuction cases (87), there is no substantial diff erence.
Nevertheless, caution needs to be exercised for liposuc-
tion. It seems likely that the method is limited, probably
once the depth of the vein exceeds 25  mm. The rather
broad strip directly above and then also on both sides of
the vein, which consequently would need to be freed from
fat, would lead to a larger cavity that might entail a higher
complication risk.
The small number of patients our study on USGL is
based on, also shows its limitations. As all fi stulas re-
mained primarily open during the follow-up period, sta-
tistical analysis of patency rates is not helpful. Our results
seem to compare favourably with one-year primary pa-
tency rates of 62 % after MIST procedures [13] and 71 %
after lipectomies [17]. The same is true for McMillan’s
[10] liposuction study with a one-year primary patency
rate of 93 %.
Figure 2. Surgical options for deeply located
arteriovenous fi stula outfl ow vein.
surgical options for
deeply located AVF
outfl ow vein
superfi cialization
with mobilization
simple
elevation
tunneled
transposition
elevation
transposition
lipectomy liposuction
venous window
needle guide
superfi cialization
without mobilization
G. Cs.Nagy et al., Liposuction for deep AV fi stulas 407
© 2018 Hogrefe Vasa (2018), 47 (5), 403–407

14. Hill AA, Vasudevan T, Young NP, Crawford M, Blatter DD, Marsh
E, et al. Use of an implantable needle guide to access diffi cult
or impossible to cannulate arteriovenous fi stulae using the
buttonhole technique. J Vasc Access. 2013;14(2):164–9.
15. Jennings WC, Galt SW, Shenoy S, Wang S, Ladenheim ED, Glick-
man MH, et al. The Venous Window Needle Guide, a hemodialy-
sis cannulation device for salvage of uncannulatable arterio-
venous fi stulas. J Vasc Surg. 2014;60(4):1024–32.
16. Bourquelot P, Tawakol JB, Gaudric J, Natário A, Franco G, Tur-
mel-Rodrigues L, et al. Lipectomy as a new approach to sec-
ondary procedure superfi cialization of direct autogenous fore-
arm radial-cephalic arteriovenous accesses for hemodialysis. J
Vasc Surg. 2009;50(2):369–74.
17. Bourquelot P, Karam L, Robert-Ebadi H, Pirozzi N. Transposi-
tion, elevation, lipectomy and V-Wing for easy needling. J Vasc
Access. 2015; Suppl 9:108–13.
18. Maliska CM, Jennings W, Mallios A. When Arteriovenous Fistu-
las Are Too Deep: Options in Obese Individuals. J Am Coll Surg.
2015;221(6):1067–72.
Submitted: 03.03.2018
Accepted after revision: 20.04.2018
Published online: 19.07.2018
There are no confl icts of interest existing.
Correspondence address
Dr. Gabor Cs.Nagy
Department of Vascular Surgery
St. Bernward Hospital
Treibestr. 9
31134 Hildesheim
Germany
csnagy@web.de
shift of nutritional disorders in two Italian regions. Nephrol Dial
Transplant. 2016;31(10):1699–705.
 3. Miller G, Latif W, Savransky Y, Koh E, Preddie D, Khariton. Suc-
tion Lipectomy of AVF and AVG Dramatically Reduces Central
Venous Catheter Exposure. J Vasc Access. 2014;15(2):143–56.
 4. Causey MW, Quan R, Hamawy A, Singh N###suchmich###.
Superfi cialization of arteriovenous fi stulae employing minimal-
ly invasive liposuction J Vasc Surg. 2010;52(5):1397–400.
 5. Ochoa DA, Mitchell RE, Jennings WC. Liposuction over a shield-
ed arteriovenous fi stula for hemodialysis access maturation. J
Vasc Access. 2010;11:69–71.
 6. Isaak A, Schlunke S, Stierli P, Wolff T, Gürke L. Endoscopic Su-
perfi cialisation of arteriovenous fi stulae. J Vasc Access.
2015;16(2):e74.
 7. Ladenheim ED, Krauthammer JP, Burnett J, Dunaway T, Parvez
S. Liposuction for superfi cialization of deep veins after creation
of arteriovenous fi stulas. J Vasc Access. 2014;15(5):358–63.
 8. Krochmal DJ, Rebecca AM, Kalkbrenner KA, Casey WJ, Fowl RJ,
Stone WM, et al. Superfi cialization of deep arteriovenous ac-
cess procedures in obese patients using suction-assisted
lipectomy: A novel approach. Can J Plast Surg. 2010;18(1):25–7.
 9. Lastfogel J, Spera L, Flores R, Eppley B, Lester M, Tholpady S.
Adjunctive liposuction for optimizing surgical access in the
obese patient. J Plast Reconst Aesth Surg. 2016;691:142–5.
10. McMillan W, Hale C. Liposuction-Assisted Brachio-cephalic
Fistula in the Morbidly Obese: Functional Patency and Reim-
bursement. J Vasc Surg. 2013;58(5):1436.
11. Tordoir J, Canaud B, Haage P, Konner K, Basci A, Fouque D, et al.
EBPG on vascular access. Nephrol Dial Transplant. 2007;22
(suppl 2):88–117.
12. Wu S, Kalva SP. Dialysis Access Management 2015 Springer
International Publishing Switzerland. 253.
13. Inkollu S, Wellen J, Beller Z, Zhang T, Vachharajani N, Shenoy S.
Successful use of minimal incision superfi cialization tech-
nique for arteriovenous fi stula maturation. J Vasc Surg. 2016;
63(4):1018–25.
View publication stats
https://www.researchgate.net/publication/326503640
