Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
April 2020 • Volume 130 • Number 4 www.anesthesia-analgesia.org 831
DOI: 10.1213/ANE.0000000000004403
GLOSSARY
CO2 = carbon dioxide; ETT = endotracheal tube; Fio2 = fraction of inspired oxygen; FRC = functional
residual capacity; H2FNOS = humidified, high-flow nasal oxygenation systems; NEAR4KIDS =
National Emergency Airway Registry for Children; NEAR4NEOS = National Emergency Airway
Registry for Neonates; O2 = oxygen; PeDI-R = Pediatric Difficult Intubation Registry; THRIVE =
transnasal humidified rapid insufflation ventilatory exchange; TIVA = total intravenous anesthetic
Providing oxygenation is an essential compo-
nent of anesthetic care, yet hypoxemia remains
an all too familiar complication in the pediatric
operating room. Children have a high rate of oxygen
consumption for body mass as compared to adults.1,2
They also have a propensity to alveolar collapse and
reduction in functional residual capacity (FRC) under
anesthesia.3 These physiological differences contrib-
ute to short apnea times that are dependent on age.4,5
Predictably, hypoxemia is the most common compli-
cation during pediatric airway management.6–9 The
rate of hypoxemia in intubation of infants— typically
otherwise healthy patients—with pyloric stenosis
has been reported at 20%–40%.10,11 In an analysis of
the Pediatric Difficult Intubation Registry (PeDI-R),
Fiadjoe et al6 found that hypoxemia occurred in 9% of
difficult intubations. The National Emergency Airway
Registry for Children (NEAR4KIDS) reported a desat-
uration rate of 13% in all intubations and in almost half
of the difficult intubations.7,8 The National Emergency
Airway Registry for Neonates (NEAR4NEOS)
reported an even higher rate of hypoxemia during
intubation with an incidence of 42% in nondifficult
intubations and 75% in difficult intubations.9 As
expected, all cases of cardiac arrest were preceded by
hypoxemia in the PeDI-R cohort.6 Parallel problems
arise during endoscopic evaluation and surgical inter-
vention of the airway. These procedures often require
a significant depth of anesthesia with an unsecured
airway leading to periods of hypoventilation or apnea
and predisposing the patient to hypoxemia.12,13
As hypoxemia is a common occurrence which can
lead to serious adverse events, continued efforts must
be directed to reduce the incidence of hypoxemia. This
review will discuss current trends in pediatric anes-
thesia for the use of apneic oxygenation and oxygen
Hypoxemia is a common complication in the pediatric operating room during endotracheal intu-
bation and airway procedures and is a precursor to serious adverse events. Small children and
infants are at greater risk of hypoxemia due to their high metabolic requirements and propensity
to alveolar collapse during general anesthesia. To improve the care and safety of this vulnerable
population, continued efforts must be directed to mitigate hypoxemia and the risk of subsequent
serious adverse events. Apneic oxygenation has been shown to significantly prolong the safe apnea
time until desaturation in infants, children, and adults and may reduce the incidence of desaturation
during emergency intubation of critically ill patients. Successful apneic oxygenation depends on ade-
quate preoxygenation, patent upper and lower airways, and a source of continuous oxygen delivery.
Humidified, high-flow nasal oxygenation systems have been shown to provide excellent conditions
for effective apneic oxygenation in adults and children and have the added benefit of providing some
carbon dioxide clearance in adults; although, this latter benefit has not been shown in children.
Humidified, high-flow nasal oxygenation systems may also be useful during spontaneous ventilation
for airway procedures in children by minimizing room air entrainment and maintaining adequate oxy-
genation allowing for a deeper anesthetic. The use of apneic oxygenation and humidified, high-flow
nasal oxygenation systems in the pediatric operating room reduces the incidence of hypoxemia and
may be effective in decreasing related complications. (Anesth Analg 2020;130:831–40)
A Narrative Review of Oxygenation During Pediatric
Intubation and Airway Procedures
Scott D. N. Else, MD,* and Pete G. Kovatsis, MD†
See Article, p 828
From the *Department of Anesthesiology and Pain Medicine, Stollery
Children’s Hospital, Edmonton, Alberta, Canada; and †Department of
Anesthesiology, Critical Care and Pain Medicine, Boston Children’s Hospital,
Harvard Medical School, Boston, Massachusetts.
S. D. N. Else is currently affiliated with the Department of Anesthesiology,
Perioperative and Pain Medicine, Alberta Children’s Hospital, Cumming
School of Medicine, University of Calgary, Calgary, AB, Canada.
Accepted for publication July 23, 2019.
Funding: None.
Conflicts of Interest: See Disclosures at the end of the article.
Reprints will not be available from the authors.
Address correspondence to Scott D. N. Else, MD, Department of Anes-
thesiology, Perioperative and Pain Medicine, Alberta Children’s Hos-
pital, 28 Oki Dr, Calgary, AB, Canada T3B 6AC. Address e-mail to
scott.else@ahs.ca.
Copyright © 2019 International Anesthesia Research Society
E NARRATIVE REVIEW ARTICLE
Pediatric Anesthesiology
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
mailto:scott.else@ahs.ca
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
832 www.anesthesia-analgesia.org ANESTHESIA & ANALGESIA
Oxygenation During Pediatric Airway Procedures
supplementation during endotracheal intubation and
airway procedures.
APNEIC OXYGENATION
Physiology of Apneic Oxygenation
Apneic oxygenation has long been described in the
medical literature.14 This technique delays the onset
of hypoxemia after cessation of ventilation via con-
tinued oxygen delivery and depends on the condi-
tions described in Figure 1. Adequate preoxygenation
minimizes the partial pressure of nitrogen in the
alveoli thereby maximizing the driving pressure for
the movement of oxygen from the airspace into the
blood.15 After the onset of apnea, oxygen uptake from
the alveoli continues in proportion to the patient’s
metabolic requirements as long as the oxygen tension
in the alveoli is maintained. Due to the high solubil-
ity in blood and a low driving gradient for diffusion,
carbon dioxide (CO2) is excreted into the alveoli at a
significantly lower rate than the rate at which oxygen
is absorbed.16 This increased flow of oxygen from the
alveoli and into the blood relative to the excretion of
CO2 into the alveoli creates a pressure gradient along
which gasses flow from the upper airway into the
alveoli. If the airways do not remain patent, no gas
will flow and the continued absorption of the remain-
ing intrapulmonary oxygen results in decreasing lung
volume leading to shunt and hypoxemia. If the air-
ways remain patent but the patient is left exposed
to room air, the oxygen in the alveoli is replaced by
nitrogen and CO2 leading to exhaustion of the alveolar
oxygen gradient and hypoxemia. If, however, a reser-
voir of oxygen is created in the upper passageways
by insufflation, the alveolar oxygen gradient will be
maintained, and the patient may remain oxygenated
for a prolonged period of time.
Clinical Application of Apneic Oxygenation
The clinical application of apneic oxygenation during
airway management is intuitive. During a classic rapid
sequence induction, patients are left apneic until mus-
cle relaxation is achieved, an adequate laryngoscopic
view is obtained, and an endotracheal tube (ETT) is
placed. After adequate preoxygenation,the amount of
time that passes before desaturation ensues, or the safe
apnea time, is more than sufficient in healthy patients
with normal airways. However, in obese or small chil-
dren and in patients with cardiopulmonary illness, the
safe apnea time is reduced. Similarly, this time frame
is challenged in patients with difficult laryngoscopy
and intubation due to a prolonged total apnea time.17
These conditions increase the risk of hypoxemia.
Unfortunately, there are very limited clinical studies
in the pediatric literature looking at the effectiveness
of apneic oxygenation in preventing hypoxemia dur-
ing intubation or airway procedures. A retrospective
study by Vukovic et al18 looking at rates of hypoxemia
during intubation in a pediatric emergency depart-
ment before and after instituting apneic oxygenation
as the standard of care found that the rate of hypox-
emia was reduced from 50% to 277
Riva et al21: Randomized Controlled Trial in Elective Surgery
Summary Low-flow O2 with nasal prongs had comparable apnea times to THRIVE 100%. THRIVE 30% had significantly
shorter apnea times than the other 2 groups. There was no difference in the rate of rise of transcutaneous
CO2 among the 3 groups (median, 4.28 mm Hg/min).
 Apnea time until desaturation to 95% (s),
median (interquartile range)
Patient age group THRIVE 30% O2 (2.0 L/kg/min) THRIVE 100% O2 (2.0 L/kg/min) Low-flow 100% O2 (0.2 L/kg/min)
 1–6 y 180 (144–222) 456 (372–546) 414 (342–468)
Humphreys et al5: Randomized Controlled Trial in Elective Surgery
Summary THRIVE was effective in significantly delaying the onset of hypoxia during apnea but had no effect on CO2
clearance.
 Apnea time until desaturation to 92% or double the published age-specific apnea times (seconds)
Patient age group Published apnea time,4 mean (SD) Control, mean (95% CI) THRIVEa
 0–6 mo 96 (12.7) 109.2 (28.8) 192
 6–25 mo 118 (9.0) 147.3 (18.9) 236
 2–5 y 160 (30.7) 190.5 (15.3) 320
 6–10 y 215 (34.9) 260.8 (37.3) 430
Steiner et al22: Randomized Controlled Trial in Elective Surgery
Summary Time to desaturation in apneic oxygenation group more than doubled the apnea time in standard care group
 Apnea time until 1% O2 desaturation (seconds)
Data are given as 25th percentile (95% confidence limits)
Patient age group Standard care O2 insufflation during video
laryngoscopy
O2 insufflation during direct
laryngoscopy
 1–17 y 30 (23–39) 67 (35–149) 75 (37–122)
Windpassinger et al23: Blinded, Randomized Controlled Trial in Elective Surgery
Summary Insufflation of O2 during intubation prolonged measured time to desaturation by 35 s.
 Mean apnea time until desaturation to 95% (seconds ± SD)
Patient age group Control O2 insufflation during laryngoscopy
 0–2 y 131 ± 39 166 ± 47
Abbreviations: CI, confidenceinterval; CO2, carbon dioxide; O2, oxygen; SD, standard deviation; THRIVE, transnasal humidified rapid insufflation ventilatory
exchange.
aNo statistical measures are reported because in the THRIVE arm, the study was terminated when double the published apnea time was reached which occurred
in all patients. O2 was delivered at weight-dependent flow rates of 0–15 kg at 2 L/kg/min, 15–30 kg at 35 L/min, 30–50 kg at 40 L/min, and >50 kg at 50 L/min.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
834 www.anesthesia-analgesia.org ANESTHESIA & ANALGESIA
Oxygenation During Pediatric Airway Procedures
studies, Humphreys et al5 found no difference in the
rate of CO2 rise between the 2 groups (Table 2). This
lack of a ventilatory effect was confirmed in a sub-
sequent randomized controlled trial by Riva et al21
(Tables 1–2). The current evidence would suggest that
while THRIVE can greatly prolong apnea time until
desaturation in children, it has no effect on ventilation.
Physiology of CO2 Clearance in THRIVE: Adults
Versus Children
Given the conflicting data from these studies, why is
there an apparent CO2 clearance in adults but not in
children? This may be explained by the physiologi-
cal and anatomical differences between children and
adults: children have higher metabolic rates, smaller
airways, and experience a greater decrease in FRC
with supine positioning and during anesthesia. The
proposed mechanism for CO2 clearance in adults is
a cascading vortex of flows and has been modeled in
computer simulations by Laviola et al.37 High flows
in the upper airway introduce a turbulent vortex of
100% oxygen in the supraglottic region leading to
pharyngeal pressure variations and microventila-
tion.37 Simultaneous cardiogenic oscillations cause
small volumes of air to be flushed between the turbu-
lent vortex and the intrathoracic airways eventually
leading to the exchange of CO2 from the alveoli.37
This reliance on turbulent flow may underpin the
reason that this technique has not proven effective
in children and infants. The small airway caliber in
children results in much higher resistance to flow
which may limit the propagation of the turbulent
vortex into the alveoli. Children are also more prone
to airway and alveolar collapse under anesthesia,
causing further decreases in FRC and resulting in
less lung volume available for gas exchange dur-
ing apnea.3 Another possible explanation is that
higher flows than utilized to date may be necessary
to achieve a ventilatory effect in children. Using
Brody’s number38 for allometric scaling of CO2 pro-
duction as described in 1984 by Lindahl et al39 to
determine appropriate flow rates shows that, partic-
ularly in small children and infants, the rates used
by Humphreys et al5 and Riva et al21 are not equiva-
lent to 70 L/min in adults (Table  3). Additionally,
THRIVE studies in children may not have allowed
an adequate apneic time to reach a steady state of
CO2 accumulation and clearance. In the initial min-
ute of apnea, the rise of arterial CO2 tension is rapid
(13–18 mm Hg) and mostly related to the equili-
bration of arterial and venous CO2. After this first
minute, the rate of rise of arterial CO2 slows and
reaches a constant.16 With the shorter apnea times
used in the pediatric studies (and
infants are prone to desaturation when spontaneously
breathing under general anesthesia as increasing anes-
thetic depth leads to hypoventilation followed by atel-
ectasis and decreasing FRC.3 In addition to high-flow
systems, other options for oxygen supplementation
include simple nasal cannula, a ventilating broncho-
scope, a laryngoscopic side port, or the positioning of an
ETT or other oxygen catheter in the pharynx. Another
option described in the literature is to modify a naso-
pharyngeal airway by inserting the 15-mm connector
from an ETT into the proximal end of the airway so that
it may be connected to an oxygen supply.42 These tech-
niques are feasible for oxygen supplementation during
airway procedures or for apneic oxygenation during
intubation. The advantages and disadvantages of these
techniques are described in Table 4.43–47
Clinical Application of H2FNOS for Airway
Procedures
Given the anesthetic challenges presented by airway
procedures, there has been growing interest in the
use of H2FNOS. In a prospective observational study,
Humphreys et al48 reported on their experience of
using H2FNOS in 20 spontaneously breathing chil-
dren with abnormal airways during total intravenous
anesthesia (TIVA). The cases were separated into 4
categories: tubeless airway surgery, flexible bronchos-
copy, management of difficult airways, and patients
who were at increased risk of respiratory issues due
to comorbidities. The average lowest saturation
observed in the study was 96%. The lowest saturation
value was 77% in a 5-day-old infant with obstructing
upper airway pathology which, as detailed, would
make H2FNOS less effective. This was also the only
patient who required interruption of the procedure
for rescue oxygenation and intubation after 3 min-
utes. The authors concluded that a high-flow oxygen
system was a safe and effective method to provide
oxygenation to spontaneously breathing infants and
children. In another prospective observational study,
Riva et al34 reported on the use of H2FNOS under
apneic conditions for endoscopic treatment of upper
airway obstructive surgery. In this study, 6 patients
underwent a total of 14 endoscopic procedures includ-
ing tracheal dilation and debridement, laser debride-
ment, supraglottoplasty, and laryngeal cleft repair.
High-flow nasal oxygen was delivered at flow rates
of 4 L/kg/min for patientsclosed
No CO2 clearance
Attaching circuit
may partially
obstruct airway
procedure and
additional weight
may accidentally
remove nasal
airway
Nasal placement
risks nasal
bleeding
Risk of barotrauma
such as gastric
distension
or rupture if
misplaced46,47
Ineffective if glottis
is obstructed
by airway
instrumentation
or in children
with obstructive
upper airway
pathology
Low Fio2 during
spontaneous
ventilation
Lack of
humidification
Inability to titrate
Fio2
No CO2 clearance
Nasal placement
risk nasal
bleeding
Risk of barotrauma
such as gastric
distension
or rupture if
misplaced46,47
Inability to deliver
O2 if glottis
is obstructed
by airway
instrumentation
Periods without O2
delivery during
placement and
removal
Low Fio2 during
spontaneous
ventilation
Lack of
humidification
Inability to titrate
Fio2
No CO2 clearance
Periods without O2
delivery during
placement and
removal or when
luminal access
port is open
to atmosphere
while exchanging
intraluminal
equipment
Low Fio2 during
spontaneous
ventilation
Lack of
humidification
Inability to titrate
Fio2
No CO2 clearance
Abbreviations: CO2, carbon dioxide; Fio2, fraction of inspired oxygen; O2, oxygen.
aCatheters include endotracheal tubes and nonstandard catheters such as suction catheters or feeding tubes.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
 E NARRATIVE REVIEW ARTICLE
April 2020 • Volume 130 • Number 4 www.anesthesia-analgesia.org 837
induction.45 Finally, H2FNOS with an oxygen blender
allows delivery of a specific Fio2 which is advanta-
geous if laser or cautery is utilized.
The main disadvantages of the H2FNOS are higher
cost and complexity requiring time and familiarity to
use. Another disadvantage is that while simple nasal
cannulas provide minimal interference with bag mask
ventilation26 or, at the very least, are quick to add and
remove, the larger size of the high-flow cannula is
not conducive to effective mask ventilation given the
more complex apparatus and is not as easy to rapidly
replace.
As spontaneous breathing is often utilized during
invasive airway procedures, H2FNOS may have the
added advantage in this setting of better preserv-
ing denitrogenation. When spontaneously breathing
with low-flow nasal oxygen, a considerable amount
of room air is entrained into the inhaled gas revers-
ing the effects of preoxygenation. If the patient
becomes apneic and the physiological conditions
needed for effective apneic oxygenation (Figure  1)
are not met, the patient will desaturate quickly. The
ability of H2FNOS to deliver oxygen at flow rates
which are higher than the patient generates during
normal tidal breathing means that minimal room
air, if any, is entrained allowing the Fio2 to remain
near 100%. This preserves a high oxygen tension in
the alveoli akin to preoxygenation, allowing contin-
ued adequate oxygenation during hypoventilation
or even unintentional apnea that may be encoun-
tered during the procedure. However, the provider
may err on the side of a deeper plane of anesthesia
thereby optimizing surgical conditions and avoid-
ing complications associated from initiating reactive
airway reflexes. To reiterate, the air-oxygen blender
in high-flow systems allows for accurate delivery of
a reduced oxygen concentration during airway laser
surgery, and H2FNOS provide humidification benefi-
cial for the longer duration of procedures which can
occur while spontaneous ventilation is supported
with H2FNOS.
During Intubations
The primary goal of oxygen supplementation while
intubating is to prolong the time from onset of apnea
until desaturation. Generally, the time until intuba-
tion is not long enough to be clinically concerned with
the accumulation of CO2. Therefore, even in situations
where a ventilation effect is possible with H2FNOS,
this benefit is clinically irrelevant except in the most
at-risk patients such as those with critical pulmonary
or intracranial hypertension. Given that both high-
flow and low-flow nasal oxygenation equally prolong
the time until desaturation occurs during apnea,21
intubation with a simple nasal cannula is favored in
most clinical situations when considering the added
benefits of decreased expense, less interference with
bag mask ventilation, and a simple setup that is avail-
able easily and everywhere an intubation may occur.
A stepwise approach to apneic oxygenation during
intubation is described in Figure 2.
During Difficult Intubations
H2FNOS may have the advantage in the patient with
an expected difficult airway because these intubations
may be prolonged and are often done using spontane-
ously breathing techniques. In these situations, such
as a challenging flexible fiberscopic intubation or the
added complexity of a difficult airway and advanced
cardiopulmonary disease, the advantages described
above of preserving denitrogenation and possible
CO2 clearance could safely add additional time that
may be essential for a successful intubation.
Figure 2. Suggested procedure to create
conditions for effective apneic oxygenation
in the operating room during airway man-
agement in children. In cooperative chil-
dren and in high-risk intubations, consider
placing nasal cannula as the first step and
performing steps 2–4 before induction of
anesthesia. In higher-risk patients, con-
sider using a high-flow, humidified oxygen-
ation system. IV indicates intravenous; O2,
oxygen; PEEP, positive end expiratory pres-
sure; V/Q, ventilation to perfusion ratio.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
838 www.anesthesia-analgesia.org ANESTHESIA & ANALGESIA
Oxygenation During Pediatric Airway Procedures
FUTURE DIRECTIONS
Current literature on the clinical effectiveness of dif-
ferent oxygen supplementation techniques in children
is limited, and there has not been a demonstrated CO2
clearance effect for H2FNOS during apnea. Future
studies of apneic oxygenation designed using higher-
flow rates (Table  3) and longer apnea times may be
useful in exploring this issue further. Computer
simulations, such as those done in adults,37 could
be run using various pediatric models to attempt to
elucidate the reasons for the lack of CO2 clearance.
Furthermore, it would be interesting to study how
H2FNOS performs in other tubeless anesthetics such
as for gastroenterology, pulmonology, and radiology.
Prospective randomized studies analyzing the use of
these methods in higher-risk pediatric patients in the
operating rooms are nonexistent. Such prospective
studies would be very challenging to pursue. Instead,
utilizing large databases (eg, PeDI-R, NEAR4KIDS,
and NEAR4NEOS) to analyze high-flow versus low-
flow systems on hypoxemia and other complications
may be instructive and provide the necessary founda-
tion and support to develop prospective, randomized
trials in these high-risk patients. If further investi-
gations continue verifying the utility to support the
safety of H2FNOS, perhaps, these systems could even
be built into the anesthetic workstation.
CONCLUSIONS
Apneic oxygenation is a technique that has long been
described in the literature but has only recently begun
to gain significant traction in pediatric anesthesiology.
Apneic oxygenation has been shown to significantly
prolongtime until desaturation in infants, children,
and adults. The efficacy of apneic oxygenation in
intubation of critically ill patients is up for debate par-
ticularly in patients with pulmonary air-space disease
and significant shunting. Overall, apneic oxygenation
is likely to be more efficacious in the operating room
setting. With H2FNOS, apneic oxygenation has shown
ventilatory effects during apnea in adults, but this has
not been shown in infants and children. Thus, while
H2FNOS may have a role as the sole airway manage-
ment technique for tubeless airway surgery in apneic
adults, it is not clinically equivalent in apneic children
at the currently published flow rates.
In children, using high flow versus low flow for
apneic oxygenation has not been shown to have a sig-
nificant difference in time until desaturation. Using
H2FNOS may have an advantage during spontane-
ously breathing tubeless airway surgery in children
by allowing delivery of 100% Fio2, titrating to a lower
Fio2 when appropriate, and providing humidification.
The main disadvantages of these systems are cost,
complexity, and interference with mask ventilation.
In summary, although no high-quality, adequately
powered, pediatric, randomized controlled studies
on both the ventilation effects and potential com-
plications have been published making any clinical
recommendations regarding apneic oxygenation
preliminary, in our opinion, apneic oxygenation with
simple nasal cannula at a flow rate of at least 0.2 L/
kg/min21 should be considered during airway man-
agement when difficulty is anticipated or in patients
susceptible to rapid desaturation. The goal is to min-
imize the chance of a clinically significant desatura-
tion leading to premature abortion of an attempt or
a serious adverse event and hopefully improving
intubation success rate and patient safety.6,50 Apneic
oxygenation is also useful during airway manage-
ment with trainees allowing more time, reducing
the stress on the trainee and the supervisor while
maintaining the saturation and hopefully the safety
of the patient.20 H2FNOS during spontaneously
breathing tubeless airway surgery are advantageous
in patients at higher risk of desaturation events
and during longer operations to prevent drying of
the mucosa. Apneic oxygenation and supplemental
oxygenation during pediatric airway management
and airway procedures have a nascent foundation in
science. To fully support the use of either high-flow
or low-flow methods of oxygenation, further inves-
tigations are essential both to compare the 2 meth-
ods and to uncover any potential complications.
Additional research studying higher-flow rates and
longer apnea times with high-flow nasal oxygen sys-
tems during apnea in children to clarify the ventila-
tory effects, if any, are also needed. E
DISCLOSURES
Name: Scott D. N. Else, MD.
Contribution: This author helped review the literature, write
large portions of the text, and review and edit the manuscript.
Conflicts of Interest: None.
Name: Pete G. Kovatsis, MD.
Contribution: This author helped review the literature, write
large portions of the text, and review and edit the manuscript.
Conflicts of Interest: P. G. Kovatsis is a medical advisor to
Verathon.
This manuscript was handled by: James A. DiNardo, MD,
FAAP.
REFERENCES
 1. Schibler A, Hall GL, Businger F, et al. Measurement of lung
volume and ventilation distribution with an ultrasonic flow
meter in healthy infants. Eur Respir J. 2002;20:912–918.
 2. Bancalari E, Clausen J. Pathophysiology of changes in abso-
lute lung volumes. Eur Respir J. 1998;12:248–258.
 3. Humphreys S, Pham TM, Stocker C, Schibler A. The effect
of induction of anesthesia and intubation on end-expiratory
lung level and regional ventilation distribution in cardiac
children. Paediatr Anaesth. 2011;21:887–893.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
 E NARRATIVE REVIEW ARTICLE
April 2020 • Volume 130 • Number 4 www.anesthesia-analgesia.org 839
 4. Patel R, Lenczyk M, Hannallah RS, McGill WA. Age and
the onset of desaturation in apnoeic children. Can J Anaesth.
1994;41:771–774.
 5. Humphreys S, Lee-Archer P, Reyne G, Long D, Williams T,
Schibler A. Transnasal humidified rapid-insufflation venti-
latory exchange (THRIVE) in children: a randomized con-
trolled trial. Br J Anaesth. 2017;118:232–238.
 6. Fiadjoe JE, Nishisaki A, Jagannathan N, et al. Airway
management complications in children with difficult tra-
cheal intubation from the Pediatric Difficult Intubation
(PeDI) registry: a prospective cohort analysis. Lancet
Respir Med. 2016;4:37–48.
 7. Parker MM, Nuthall G, Brown C III, et al; Pediatric Acute
Lung Injury and Sepsis Investigators (PALISI) Network.
Relationship between adverse tracheal intubation associ-
ated events and PICU outcomes. Pediatr Crit Care Med.
2017;18:310–318.
 8. Graciano AL, Tamburro R, Thompson AE, Fiadjoe J,
Nadkarni VM, Nishisaki A. Incidence and associated factors
of difficult tracheal intubations in pediatric ICUs: a report
from National Emergency Airway Registry for Children:
NEAR4KIDS. Intensive Care Med. 2014;40:1659–1669.
 9. Sawyer T, Foglia EE, Ades A, et al. Incidence, impact and
indicators of difficult intubations in the neonatal intensive
care unit: a report from the National Emergency Airway
Registry for neonates. Arch Dis Child Fetal Neonatal Ed.
2019;104:F461–F466.
 10. Cook-Sather SD, Tulloch HV, Cnaan A, et al. A comparison
of awake versus paralyzed tracheal intubation for infants
with pyloric stenosis. Anesth Analg. 1998;86:945–951.
 11. Park RS, Rattana-arpa S, Peyton J, et al. Risk of hypoxemia by
induction technique among infants and neonates undergoing
pyloromyotomy. Anesth Analg. 2019 [Epub ahead of print].
 12. Ferrari LR, Zurakowski D, Solari J, Rahbar R. Laryngeal
cleft repair: the anesthetic perspective. Paediatr Anaesth.
2013;23:334–341.
 13. Jaquet Y, Monnier P, Van Melle G, Ravussin P, Spahn DR,
Chollet-Rivier M. Complications of different ventilation
strategies in endoscopic laryngeal surgery: a 10-year review.
Anesthesiology. 2006;104:52–59.
 14. Frumin MJ, Epstein RM, Cohen G. Apneic oxygenation in
man. Anesthesiology. 1959;20:789–798.
 15. McNamara MJ, Hardman JG. Hypoxaemia during open-
airway apnoea: a computational modelling analysis.
Anaesthesia. 2005;60:741–746.
 16. Eger EI, Severinghaus JW. The rate of rise of PaCO2 in the
apneic anesthetized patient. Anesthesiology. 1961;22:419–425.
 17. Baillard C, Boubaya M, Statescu E, et al. Incidence and risk
factors of hypoxaemia after preoxygenation at induction of
anaesthesia. Br J Anaesth. 2019;122:388–394.
 18. Vukovic AA, Hanson HR, Murphy SL, Mercurio D, Sheedy
CA, Arnold DH. Apneic oxygenation reduces hypoxemia
during endotracheal intubation in the pediatric emergency
department. Am J Emerg Med. 2019;37:27–32.
 19. Overmann KM, Boyd SD, Zhang Y, Kerrey BT. Apneic oxy-
genation to prevent oxyhemoglobin desaturation during
rapid sequence intubation in a pediatric emergency depart-
ment. Am J Emerg Med. 2018;37:1416–1421.
 20. Soneru CN, Hurt HF, Petersen TR, Davis DD, Braude DA,
Falcon RJ. Apneic nasal oxygenation and safe apnea time
during pediatric intubations by learners. Paediatr Anaesth.
2019;29:628–634.
 21. Riva T, Pedersen TH, Seiler S, et al. Transnasal humidified
rapid insufflation ventilatory exchange for oxygenation of
children during apnoea: a prospective randomised con-
trolled trial. Br J Anaesth. 2018;120:592–599.
 22. Steiner JW, Sessler DI, Makarova N, et al. Use of deep laryn-
geal oxygen insufflation during laryngoscopy in children: a
randomized clinical trial. BrJ Anaesth. 2016;117:350–357.
 23. Windpassinger M, Plattner O, Gemeiner J, et al. Pharyngeal
oxygen insufflation during airTraq laryngoscopy slows
arterial desaturation in infants and small children. Anesth
Analg. 2016;122:1153–1157.
 24. Fiadjoe JE, Litman RS. Oxygen supplementation during
prolonged tracheal intubation should be the standard of
care. Br J Anaesth. 2016;117:417–418.
 25. Semler MW, Janz DR, Lentz RJ, et al; FELLOW Investigators;
Pragmatic Critical Care Research Group. Randomized trial
of apneic oxygenation during endotracheal intubation of
the critically Ill. Am J Respir Crit Care Med. 2016;193:273–280.
 26. Brown DJ, Carroll SM, April MD. Face mask leak with nasal
cannula during noninvasive positive pressure ventilation: a
randomized crossover trial. Am J Emerg Med. 2018;36:942–948.
 27. Parke RL, Bloch A, McGuinness SP. Effect of very-high-
flow nasal therapy on airway pressure and end-expira-
tory lung impedance in healthy volunteers. Respir Care.
2015;60:1397–1403.
 28. Parke RL, McGuinness SP. Pressures delivered by nasal
high flow oxygen during all phases of the respiratory cycle.
Respir Care. 2013;58:1621–1624.
 29. Hernández G, Roca O, Colinas L. High-flow nasal cannula
support therapy: new insights and improving performance.
Crit Care. 2017;21:62.
 30. Papazian L, Corley A, Hess D, et al. Use of high-flow nasal
cannula oxygenation in ICU adults: a narrative review.
Intensive Care Med. 2016;42:1336–1349.
 31. Corley A, Caruana LR, Barnett AG, Tronstad O, Fraser JF.
Oxygen delivery through high-flow nasal cannulae increase
end-expiratory lung volume and reduce respiratory rate in
post-cardiac surgical patients. Br J Anaesth. 2011;107:998–1004.
 32. Fraioli RL, Sheffer LA, Steffenson JL. Pulmonary and
cardiovascular effects of apneic oxygenation in man.
Anesthesiology. 1973;39:588–596.
 33. Patel A, Nouraei SA. Transnasal Humidified Rapid-
Insufflation Ventilatory Exchange (THRIVE): a physio-
logical method of increasing apnoea time in patients with
difficult airways. Anaesthesia. 2015;70:323–329.
 34. Riva T, Theiler L, Jaquet Y, Giger R, Nisa L. Early experience
with high-flow nasal oxygen therapy (HFNOT) in pediatric
endoscopic airway surgery. Int J Pediatr Otorhinolaryngol.
2018;108:151–154.
 35. Lyons C, Callaghan M. Apnoeic oxygenation with high-
flow nasal oxygen for laryngeal surgery: a case series.
Anaesthesia. 2017;72:1379–1387.
 36. Gustafsson IM, Lodenius Å, Tunelli J, Ullman J, Jonsson
Fagerlund M. Apnoeic oxygenation in adults under general
anaesthesia using Transnasal Humidified Rapid-Insufflation
Ventilatory Exchange (THRIVE) - a physiological study. Br J
Anaesth. 2017;118:610–617.
 37. Laviola M, Das A, Chikhani M, Bates DG, Hardman JG.
Computer simulation clarifies mechanisms of carbon diox-
ide clearance during apnoea. Br J Anaesth. 2019;122:395–401.
 38. Brody S. Bioenergetics and Growth. New York, NY: Reinhold;
1945.
 39. Lindahl SG, Hulse MG, Hatch DJ. Metabolic correlates in
infants and children during anaesthesia and surgery. Acta
Anaesthesiol Scand. 1984;28:52–56.
 40. Benjamin B. Anesthesia for laryngoscopy. Ann Otol Rhinol
Laryngol. 1984;93:338–342.
 41. Mausser G, Friedrich G, Schwarz G. Airway manage-
ment and anesthesia in neonates, infants and children
during endolaryngotracheal surgery. Paediatr Anaesth.
2007;17:942–947.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
Copyright © 2019 International Anesthesia Research Society. Unauthorized reproduction of this article is prohibited.
840 www.anesthesia-analgesia.org ANESTHESIA & ANALGESIA
Oxygenation During Pediatric Airway Procedures
 42. Yoon U, Yuan I. Modified nasal trumpet for airway manage-
ment. Anesthesiology. 2016;125:596.
 43. Omori C, Schofield BH, Mitzner W, Freed AN. Hyperpnea
with dry air causes time-dependent alterations in muco-
sal morphology and bronchovascular permeability. J Appl
Physiol (1985). 1995;78:1043–1051.
 44. Williams R, Rankin N, Smith T, Galler D, Seakins P.
Relationship between the humidity and temperature of
inspired gas and the function of the airway mucosa. Crit
Care Med. 1996;24:1920–1929.
 45. Lodenius Å, Piehl J, Östlund A, Ullman J, Jonsson
Fagerlund M. Transnasal humidified rapid-insufflation
ventilatory exchange (THRIVE) vs facemask breathing pre-
oxygenation for rapid sequence induction in adults: a pro-
spective randomised non-blinded clinical trial. Anaesthesia.
2018;73:564–571.
 46. Yao HT MV, McNally C, Smith M, Usatoff V. Gastric rupture
following nasopharyngeal oxygen delivery - a report of two
cases. Anaesth Intensive Care. 2015;43:244–248.
 47. Grude O, Solli HJ, Andersen C, Oveland NP. Effect of nasal
or nasopharyngeal apneic oxygenation on desaturation
during induction of anesthesia and endotracheal intubation
in the operating room: a narrative review of randomized
controlled trials. J Clin Anesth. 2018;51:1–7.
 48. Humphreys S, Rosen D, Housden T, Taylor J, Schibler A.
Nasal high-flow oxygen delivery in children with abnormal
airways. Paediatr Anaesth. 2017;27:616–620.
 49. Booth AWG, Vidhani K, Lee PK, Thomsett CM. SponTaneous
Respiration using IntraVEnous anaesthesia and Hi-flow
nasal oxygen (STRIVE Hi) maintains oxygenation and air-
way patency during management of the obstructed airway:
an observational study. Br J Anaesth. 2017;118:444–451.
 50. Park R, Peyton JM, Fiadjoe JE, et al; PeDI Collaborative
Investigators; PeDI collaborative investigators. The efficacy
of GlideScope® videolaryngoscopy compared with direct
laryngoscopy in children who are difficult to intubate: an
analysis from the paediatric difficult intubation registry. Br
J Anaesth. 2017;119:984–992.
D
ow
nloaded from
 http://journals.lw
w
.com
/anesthesia-analgesia by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsI
H
o4X
M
i0hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
1y0abggQ
Z
X
dgG
j2M
w
lZ
LeI=
 on 10/01/2024
