FTIR Spectroscopy for Carbon Family Study
Vasilica Ţucureanu, Alina Matei, and Andrei Marius Avram
National Institute for Research and Development in Microtechnologies, IMT Bucharest, Bucharest, Romania
ABSTRACT
Fourier transform Infrared (FTIR) spectroscopy is a versatile technique for the characterization of materials
belonging to the carbon family. Based on the interaction of the IR radiation with matter this technique
may be used for the identification and characterization of chemical structures. Most important features of
this method are: non-destructive, real-time measurement and relatively easy to use. Carbon basis for all
living systems has found numerous industrial applications from carbon coatings (i.e. amorphous and
nanocrystalline carbon films: diamond-like carbon (DLC) films) to nanostructured materials (fullerenes,
nanotubes, graphene) and carbon materials at nanoscale or carbon dots (CDots). In this paper, we present
the FTIR vibrational spectroscopy for the characterization of diamond, amorphous carbon, graphite,
graphene, carbon nanotubes (CNTs), fullerene and carbon quantum dots (CQDs), without claiming to
cover entire field.
KEYWORDS
Carbon nanotube (CNT);
carbon quantum dot (CQD);
diamond; diamond-like
carbon (DLC); Fourier
transform Infrared (FTIR)
spectroscopy; fullerene;
graphene; graphite
Introduction to FTIR spectroscopy
The infrared (IR) spectroscopy was the first structural spectro-
scopic technique and is an analytical method used to character-
ize the bonding structure of atoms based on the interaction of
the IR radiation with matter, and measures the frequencies of
the radiation at which the substance absorbs and lead to the
production of vibrations in molecules. IR spectroscopy pro-
vides a fast technique of identification and characterization of
chemical structures to obtain information from biological to
composite materials, from liquids to gases samples (Son et al.,
2001; Vaghri et al., 2012).
The vibrational spectroscopy history begins with the first IR
spectrum, obtained by Coblentz (in 1905), and achievement of
first IR spectrometer (in 1930s). FTIR spectrometry combines
an old tool, the interferometer (developed by Albert Michelson
in 1877) with an older mathematical principle, the Fourier
transform to convert the output from an interferometer (inter-
ferogram) to a spectrum and a new approach, computerization.
But the complexity of calculations stopped the development of
FTIR spectrometry until 1969 when the first commercial FTIR
spectrometer with a dedicated minicomputer was developed.
Now, using the computer, an interferogram is transformed
instantaneously into a spectrum and a modern software algo-
rithm allows the use of FTIR spectroscopy as a tool for qualita-
tive and quantitative analysis (Tanase, 1995; Ryczkowski, 2001;
Murali Krishna et al., 2013). Generally, a FTIR spectrum is a
graphical representation of the transmittance, in percent (T%)
or absorption, in units (A) versus IR frequency in terms of
wavenumber (cm¡1). In an IR spectrum the absorption bands
are characterized by a wavenumber at which absorption occurs
(corresponding to chemical bonds) and the intensity of absorp-
tion (proportional to the amount of substance from sample).
The IR spectrum can be divided into three spectral areas,
named in relation to the visible range: (1) near infrared (NIR),
near the visible region, may excite overtone or higher harmonic
vibrations – range: »13000–4000 cm¡1 (»770–2500 nm, 0.77–
2.5 mm), (2) mid infrared (MIR) excites mainly fundamental
vibrations—range: 4000–400 cm¡1 (2500–25000 nm, 2.5–25
mm) and (3) far infrared (FIR) excites lattice vibrations and
below 300 cm¡1 it can be used for rotational spectroscopy—
range: 400–10 cm¡1 (25000–1000000 nm, 25–1000 mm). Many
IR studies use the MIR region (including in our paper), but the
NIR and FIR regions can also provide important information
(Derrick et al., 1999; Reichenbacher et al., 2012; Singh et al.,
2012; Murali Krishna et al., 2013).
FTIR spectrometry is a non-destructive and real-time mea-
surement analytical method, enabling the identification of
unknown materials (quantitative determination) and their con-
centration (qualitative determination) from organic and inor-
ganic substances, from solid, liquid or gas samples. In some
molecules during vibration there is a change of the electric
dipole moment (selection rule). In this case, we speak of IR
active substances and the absorption of the radiation corre-
sponds to a change of the dipole moment. For IR inactive sub-
stances the electric dipole moment is zero, no matter how long
the bond is in the molecule (IR-active: polar bonds, asymmetri-
cal molecules. IR inactive: non-polar bond, symmetrical mole-
cule) (Stuart et al., 2004; Reichenb€acher et al., 2012; Singh et al.,
2012; Murali Krishna et al., 2013). In IR spectrometry each
chemical bond has a specific vibration frequency corresponding
to an energy level. E D hn D hc/λ and ṽ D 1/λ D n/c (where: h
D Planck’s constant, n D frequency, c D speed of light, λ D
wavelength and ṽ D wavenumber). The IR absorption appears
when radiant energy corresponds to energy of a molecular
CONTACT Vasilica Ţucureanu vasilica.tucureanu@imt.ro, vasilica.schiopu@gmail.com National Institute for Research and Development in Microtechnologies,
IMT Bucharest, 126A Erou Iancu Nicolae Str., code 077190 Bucharest, Romania
© 2016 Taylor & Francis Group, LLC
CRITICAL REVIEWS IN ANALYTICAL CHEMISTRY
2016, VOL. 46, NO. 6, 502–520
http://dx.doi.org/10.1080/10408347.2016.1157013
http://dx.doi.org/10.1080/10408347.2016.1157013
vibration. The vibrational mode of a molecule can involve a
variation in inter-atomic bond length (stretching, n) or bond
angle between two bonds (bending or deformation, d) (Stuart
et al., 2004; Reichenbacher et al., 2012; Singh et al., 2012). In
Table 1, the vibration modes that may appear in a molecule are
presented. The vibration mode may occur at: ṽ (symmetrical
stretching)be observed at about 1600–1450 cm¡1 (Li et
al., 2010; Zhang et al., 2012; Mewada et al., 2013; Wu et al.,
2013; Hao et al., 2015). In Table 8, some possible aassign-
ments for CQDs may be seen.
Table 7. (Continued ).
Wavenumber [cm–1] Probable assignment Characteristic vibration mode for: Ref.
et al., 1991; Menon et al.,
1996
586 d (>C=C=C=CC=C) C20, tadpole isomer Zamani et al., 2014
545–525 e1
’ or a1
”or a2
’ or a2
” or e2
” C70 Bethune et al., 1991; Iglesias-
Groth et al., 2011; Meilunas
et al., 1991; Menon et al.,
1996
544 d ( >CC=C) C20, tadpole/bowl isomer, e2 Galli et al., 1998; Zamani et al.,
2014
490 d ( C–C) C60(OH)n Alves et al., 2006; Krishna et al.,
2010; Tianbao et al., 1999
486 d (>C=C=C=Cdecreases with
increasing pH, indicating gradual deprotonation
of ¡COOH.
Hao et al., 2015
1335 C–O–C indicating the existence of CQDs in a complex Zhang et al., 2012
1260–1250 C–O–C indicating the existence of CQDs in a complex Fan et al., 2015; Zhang et al., 2012
1200–1190 n (C–O) CQDs Li et al., 2010; Wang et al., 2014
1080–1010 n (C–O) ! CQDs, carboxylic (COOH) group Fan et al., 2015; Li et al., 2010; Wu et al., 2013
! GQD
