IEEE Std 1682™-2023
(Revision of IEEE Std 1682-2011)
IEEE Standard for Qualifying
Fiber Optic Cables, Connections,
and Optical Fiber Splices for Use
in Safety Systems in Nuclear
Power Generating Stations
Authorized licensed use limited to: Instituto Nacional De Telecomunicações (INATEL). Downloaded on November 18,2024 at 12:50:38 UTC from IEEE Xplore. Restrictions apply.
IEEE Std 1682™-2023
(Revision of IEEE Std 1682-2011)
IEEE Standard for Qualifying
Fiber Optic Cables, Connections,
and Optical Fiber Splices for Use
in Safety Systems in Nuclear
Power Generating Stations
Developed by the
Nuclear Power Engineering Committee
of the
IEEE Power and Energy Society
Approved 29 June 2023
IEEE SA Standards Board
Recognized as an American National Standard
Authorized licensed use limited to: Instituto Nacional De Telecomunicações (INATEL). Downloaded on November 18,2024 at 12:50:38 UTC from IEEE Xplore. Restrictions apply.
Abstract: The general requirements, directions, and methods for qualifying fiber optic cables,
connections, and optical fiber splices for use in safety systems of nuclear power generating stations,
including fuel reprocessing stations and other related installations, are provided in this standard.
Cables, optical fibers, and splices within or integral to other devices (e.g., sensors, instruments,
panels, etc.) shall be qualified using the requirements in the applicable device standard or IEC/
IEEE 60780- 323:2016, as appropriate. However, the requirements of this standard may be applied
to the fiber optic cable and interfaces within these devices.
Keywords: Class 1E, connectors, fiber, fiber optic cable, fibers, IEEE 1682™, nuclear, optical fiber,
safety, splices
The Institute of Electrical and Electronics Engineers, Inc.
3 Park Avenue, New York, NY 10016-5997, USA
Copyright © 2023 by The Institute of Electrical and Electronics Engineers, Inc.
All rights reserved. Published 15 December 2023. Printed in the United States of America.
IEEE is a registered trademark in the U.S. Patent & Trademark Office, owned by The Institute of Electrical and Electronics Engineers,
Incorporated.
PDF: ISBN 979-8-8557-0134-0 STD26481
Print: ISBN 979-8-8557-0135-7 STDPD26481
IEEE prohibits discrimination, harassment, and bullying.
For more information, visit https:// www .ieee .org/ about/ corporate/ governance/ p9 -26 .html.
No part of this publication may be reproduced in any form, in an electronic retrieval system or otherwise, without the prior written permission
of the publisher.
Authorized licensed use limited to: Instituto Nacional De Telecomunicações (INATEL). Downloaded on November 18,2024 at 12:50:38 UTC from IEEE Xplore. Restrictions apply.
http://www.ieee.org/web/aboutus/whatis/policies/p9-26.html
3
Copyright © 2023 IEEE. All rights reserved.
