Journal of Cleaner Production 368 (2022) 133098
Available online 18 July 2022
0959-6526/© 2022 Elsevier Ltd. All rights reserved.
A pH-responsive/sustained release nitrogen fertilizer hydrogel based on
aminated cellulose nanofiber/cationic copolymer for application in
irrigated neutral soils
Hiba Shaghaleh a,1, Yousef Alhaj Hamoud b,1, Xu Xu a,*, Shifa Wang a,**, He Liu c
a College of Chemical Engineering, Jiangsu Provincial Key Lab for the Chemistry and Utilization of Agro-forest Biomass, Co-Innovation Center of Efficient Processing and
Utilization of Forest Resources, Jiangsu Key Lab of Biomass-based Green Fuels and Chemicals, Nanjing Forestry University, Nanjing, 210037, China
b College of Agricultural Science and Engineering, Hohai University, Nanjing, 210098, China
c Institute of Chemical Industry of Forestry Products, Chinese Academy of Forestry, Key Laboratory of Biomass Energy and Material, National Engineering Laboratory for
Biomass Chemical Utilization, Key and Open Laboratory of Forest Chemical Engineering, State Forestry Administration, Nanjing, 210042, Jiangsu Province, China
A R T I C L E I N F O
Handling Editor: M.T. Moreira
Keywords:
pH-responsive release fertilizer hydrogel
Aminated nanofibrillated cellulose
Sustained-release mechanisms
Neutral soil
Biodegradability
Nitrogen use efficiency
A B S T R A C T
Stimuli-responsive release nitrogen (N)-fertilizer hydrogels are new materials recently introduced to improve
control and sustained release N-fertilizer hydrogels efficacy by adding additional functionality for greater N use
efficiency. However, the stimuli-responsive behavior and release mechanisms of these fertilizer hydrogels in
response to irrigated-soil stimulus fluctuations during different plant growth stages are still facing limitations and
have not been considered. Herein, a novel N-fertilizer nanocomposite hydrogel with the function of N pH-
responsive/sustained release (pHRSRNFH) was prepared based on wheat straw aminated-cellulose nanofibers
(A-CNFs) and cationic poly(acrylamide-co-2-aminoethyl methacrylate hydrochloride) (PAM-PAEM) by direct
ammonium nitrate (AN) fertilizer encapsulation. The fertilizer hydrogel structure, properties, and effects on N
use efficiency and N metabolism process were characterized by FTIR, zeta potential, SEM, porosity, swelling-
release behaviors, TEM, flowcytometric analysis, and N use efficiency indicators. The hydrogel nanocomposite
with 3 wt% A-CNFs and 4 wt% AEM (pHRSRNFH4) exhibited desirable enhancement of characterizations, pH-
responsive/sustained behaviors, and biodegradability. The soil and buffers release kinetic studies in-vitro
revealed the best pH-dependent/sustained AN release of 3.00 and 2.69 mg.day− 1 at pH 5.5 and 0.92 and 0.55
mg.day− 1 at pH 7.4 from 1g pHRSRNFH4 for 58 and 65 days, respectively, desirably synchronizing with the pH
fluctuations of irrigated-neutral soil. The whole lifetime of AN release data revealed that the three sustained
delivery stages were governed by the First-order mechanism, followed by Zeroth-order, and finally via the
Higuchi mechanism, covering the N crop requirements during different plant growth phases. Application of
pHRSRNFH4 at 1 g kg− 1 irrigated-neutral soil successfully improved water-holding capacity and N recovery ef-
ficiency by 15.7% and 38.6%, respectively, compared with free AN treated soil with over 90-days sustained AN
release. Furthermore, positive impacts on rice growth indicators, N-nutrition status, and cell progression were
achieved with a feasible-compatible application, demonstrating its further significant potential to be a viable
alternative fertilizer formulation for N/water management of cropping systems in the irrigated-neutral soils.
1. Introduction
Agriculture is now facing the challenge of water scarcity, food se-
curity, and environmental sustainability, which are adversely affected
by the inefficient input of water and fertilizers (Mateo-Sagasta et al.,
2017; Rosa et al., 2020). Nitrogen (N) is the most essential plant
nutrient, and N-fertilizers are widely applied, playing a vital role in
agricultural productivity and quality in most agricultural cropping sys-
tems (Maheswari et al., 2017). Globally, agricultural production has
improved over the last 50 years due to the excessive enlargement in
N-fertilizer inputs which increased by 800%, of which 35% is used in
* Corresponding author.
** Corresponding author. Longpan Road, Nanjing, 210042, Jiangsu Province, China.
E-mail addresses: xuxu200121@hotmail.com (X. Xu), WSfyyq@njfu.com.cn (S. Wang).
1 These authors contributed equally to this work.
Contents lists available at ScienceDirect
Journal of Cleaner Production
journal homepage: www.elsevier.com/locate/jclepro
https://doi.org/10.1016/j.jclepro.2022.133098
Received 14 January 2022; Received in revised form 9 June 2022; Accepted 8 July 2022
mailto:xuxu200121@hotmail.com
mailto:WSfyyq@njfu.com.cn
www.sciencedirect.com/science/journal/09596526
https://www.elsevier.com/locate/jclepro
https://doi.org/10.1016/j.jclepro.2022.133098
https://doi.org/10.1016/j.jclepro.2022.133098
https://doi.org/10.1016/j.jclepro.2022.133098
http://crossmark.crossref.org/dialog/?doi=10.1016/j.jclepro.2022.133098&domain=pdf
Journal of Cleaner Production 368 (2022) 133098
2
China (Zhang et al., 2014). However, further increases in N-fertilizer
consumption are unlikely to be effective in increasing crop yields as
50–70% of the conventionally delivered N-fertilizers are lost into the
environment via volatilization, denitrification, and leaching, leading to
severe environmental pollution, and low nitrogen use efficiency (NUE)
(Zhou et al., 2018). Therefore, there is an urgent need to develop new
N-fertilization techniques in an appropriate and timely supply manner
that consistently matches high yield production and significant N utili-
zation for sustainable crop production.
Intensive accomplishments in fertilizers production technologies
have been introduced to improve fertilizer use efficiency by reducing
fertilizer application rate and increasing plant productivity. Thus, fer-
tilizer immobilization, coating, or encapsulation into controlled-release
fertilizer systems (CRFs) based on natural/synthetic polymeric materials
have been introduced to allow a slow nutrient release to be better co-
ordinated with the plant life cycle with less nutrient loss, improving
fertilizer use efficiency while reducing environmental risk (Zhou et al.,
2018; Rop et al., 2018). However, the vulnerability of CRFs to response
to soil stimulus fluctuations of soil pH, soil moisture contents, and plant
root activity can significantly affect the fertilizer release rate and pre-
vent matching plant-nutrient demands during the critical growth pe-
riods. Moreover, the feasibility, long-term active quality, and
degradability of CRFs are still demanding challenges.
Alternatively, fertilizer embedded into stimuli-responsive materials
that can alter their release behavior in response to surrounding soil
fluctuations have the potential to provide an efficient fertilizer delivery
that precisely synchronizes with plant nutrients demand in proper
quantity and optimal time. Yet, very few attempts to innovate stimuli-
responsive release fertilizer systems based on different polymeric ma-
terials have been recently made, i.e., poly(N, N-dimethylaminoethyl
methacrylate)/polydopamine/H4NO4PZn composite, methylcellulose/
hydroxypropyl/methylcellulose/K2SO4 hydrogel, nanocellulose/so-
dium alginate/MOF hydrogel, and TEMPO-oxidized nanocellulose/MOF
hydrogel composites (Feng et al., 2015; Chen and Chen, 2019; Wang
et al., 2021; Lin et al., 2021). Hydrogels play an astonishing role in the
fabrication of such a new branch of fertilizer materials and the elder
CRFs generation due to their restricted 3D hygroscopic multidimen-
sional network structure, retaining a large amount of water/liquid fer-
tilizerat
affordable cost, providing high-quality N/wter management approaches
supporting environment-agriculture sustainably.
CRediT authorship contribution statement
Hiba Shaghaleh: Conceptualization, Methodology, Data curation,
Software, Writing – original draft, Writing – review & editing. Yousef
Alhaj Hamoud: Conceptualization, Methodology, Data curation, Soft-
ware, Writing – original draft, Writing – review & editing. Xu Xu:
Visualization, Supervision, Validation, Writing – review & editing. Shifa
Wang: Visualization, Supervision, Validation, Writing – review & edit-
ing. He Liu: Visualization, Supervision, Validation, Writing – review &
editing.
Declaration of competing interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Acknowledgments
This work was supported by the Major Program of the National
Natural Science Foundation of China (Grant No.31890774), the Opening
Fig. 7. (a) Percentages of mass loss of PHRSRNFH4 and CRNFH and related in-vivo biodegradation rate as a function of application time and hydrogel formulation. (b)
are SEM micrographs showing physical/chemical biodegradation after 1 (I), 2 (II), 3 (III) months of incubation and (IV) optical graphs after 3 months’ incubation of
PHRSRNFH4 and CRNFH, respectively.
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
15
Project of Guangxi Key Laboratory of Forest Products Chemistry and
Engineering (GXFK2008), the Top-notch Academic Programs Project of
the Jiangsu Higher Education Institutions (ATPP), and the Priority Ac-
ademic Program Development of the Jiangsu Higher Education In-
stitutions (PAPD).
Appendix A. Supplementary data
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.jclepro.2022.133098.
References
Ahiabu, A., Serpe, M.J., 2017. Rapidly responding pH- and temperature-responsive poly
(N-Isopropylacrylamide)-Based microgels and assemblies. ACS Omega 2,
1769–1777. https://doi.org/10.1021/acsomega.7b00103.
Alhaj Hamoud, Y., Shaghaleh, H., Sheteiwy, M., Guo, X., Elshaikh, N.A., Ullah Khan, N.,
Oumarou, A., Rahim, S.F., 2019. Impact of alternative wetting and soil drying and
soil clay content on the morphological and physiological traits of rice roots and their
relationships to yield and nutrient use-efficiency. Agric. Water Manag. 223, 105706
https://doi.org/10.1016/j.agwat.2019.105706.
Blockx, J., Verfaillie, A., Eyley, S., Deschaume, O., Bartic, C., Muylaert, K.,
Thielemans, W., 2019. Cationic cellulose nanocrystals for flocculation of microalgae:
effect of degree of substitution and crystallinity. ACS Appl. Nano Mater. 2,
3394–3403.
Boyandin, A.N., Zhila, N.O., Kiselev, E.G., Volova, T.G., 2016. Constructing slow-release
formulations of metribuzin based on degradable poly(3-hydroxybutyrate). J. Agric.
Food Chem. 64, 5625–5632. https://doi.org/10.1021/acs.jafc.5b05896.
Chamas, A., Moon, H., Zheng, J., Qiu, Y., Tabassum, T., Jang, J.H., Abu-Omar, M.,
Scott, S.L., Suh, S., 2020. Degradation rates of plastics in the environment. ACS
Sustain. Chem. Eng. 8, 3494–3511. https://doi.org/10.1021/
acssuschemeng.9b06635.
Chen, Y.-C., Chen, Y.-H., 2019. Thermo and pH-responsive methylcellulose and
hydroxypropyl methylcellulose hydrogels containing K2SO4 for water retention and
a controlled-release water-soluble fertilizer. Sci. Total Environ. 655, 958–967.
https://doi.org/10.1016/j.scitotenv.2018.11.264.
Datta, A., Ullah, H., Ferdous, Z., 2017. Water management in rice. In: Chauhan, B.S.,
Jabran, K., Mahajan, G. (Eds.), Rice Production Worldwide. Springer International
Publishing, Cham.
Ding, C., Du, S., Ma, Y., Li, X., Zhang, T., Wang, X., 2019. Changes in the pH of paddy
soils after flooding and drainage: modeling and validation. Geoderma 337, 511–513.
https://doi.org/10.1016/j.geoderma.2018.10.012.
Feng, C., Lü, S., Gao, C., Wang, X., Xu, X., Bai, X., Gao, N., Liu, M., Wu, L., 2015. Smart”
fertilizer with temperature- and pH-responsive behavior via surface-initiated
polymerization for controlled release of nutrients. ACS Sustain. Chem. Eng. 3,
3157–3166. https://doi.org/10.1021/acssuschemeng.5b01384 10.1016/j.
jclepro.2021.129274.
Hamsan, M., Shukur, M., Kadir, M., 2017. The effect of NH4NO3 towards the
conductivity enhancement and electrical behavior in methyl cellulose-starch blend
based ionic conductors. Ionics 23 (5), 1137–1154. https://doi.org/10.1007/s11581-
016-1918-4.
Huang, M., Chen, J., Cao, F., Zou, Y., 2018. Increased hill density can compensate for
yield loss from reduced nitrogen input in machine-transplanted double-cropped rice.
Field Crop. Res. 221, 333–338. https://doi.org/10.1016/j.fcr.2017.06.028.
Jackson, M.L., 2005. Soil Chemical Analysis: Advanced Course. UW-Madison Libraries
Parallel Press.
Jun, S.-H., Park, S.-G., Kang, N.-G., 2019. One-pot method of synthesizing TEMPO-
oxidized bacterial cellulose nanofibers using immobilized TEMPO for skincare
applications. Polymers 11, 1044.
Levy, G.J., Warrington, D.N., 2015. Polyacrylamide Addition to Soils: Impacts on Soil
Structure and Stability. Functional Polymers in Food Science. Wiley, Hoboken,
pp. 9–31. https://doi.org/10.1002/9781119108580.ch2.
Lin, X., Guo, L., Shaghaleh, H., Hamoud, Y.A., Xu, X., Liu, H., 2021. A TEMPO-oxidized
cellulose nanofibers/MOFs hydrogel with temperature and pH responsiveness for
fertilizers slow-release. Int. J. Biol. Macromol. 191, 483–491.
Maheswari, M., Murthy, A., Shanker, A., 2017. Nitrogen nutrition in crops and its
importance in crop quality. In: The Indian Nitrogen Assessment. Elsevier,
pp. 175–186. https://doi.org/10.1016/B978-0-12-811836-8.00012-4.
Mahfoudhi, N., Boufi, S., 2016. Poly (acrylic acid-co-acrylamide)/cellulose nanofibrils
nanocomposite hydrogels: effects of CNFs content on the hydrogel properties.
Cellulose 23, 3691–3701.
Materu, S.T., Shukla, S., Sishodia, R.P., Tarimo, A., Tumbo, S.D., 2018. Water use and
rice productivity for irrigation management alternatives in Tanzania. Water 10,
1018. https://doi.org/10.3390/w10081018.
Mateo-Sagasta, J., Zadeh, S.M., Turral, H., Burke, J., 2017. Water Pollution from
Agriculture: a Global Review. Executive summary.
Mays, T.J., 2007. A new classification of pore sizes. In: Llewellyn, P.L., Rodriquez-
Reinoso, F., Rouqerol, J., Seaton, N. (Eds.), Studies in Surface Science and Catalysis,
vol. 160. Elsevier, pp. 57–62.
Park, C., Kim, E.Y., Yoo, Y.T., Im, S.S., 2003. Effect of hydrophilicity on the
biodegradability of polyesteramides. J. Appl. Polym. Sci. 90 (10), 2708–2714.
https://doi.org/10.1002/app.12925.
Pastor, E.L., Reguera-Nuñez, E., Matveeva, E., Garcia-Fuentes, M., 2015. Pore size is a
critical parameter for obtaining sustained protein release from electrochemically
synthesized mesoporous silicon microparticles. PeerJ 3, e1277. https://doi.org/
10.7717/peerj.1277.
Rizwan, M., Rubina Gilani, S., Iqbal Durani, A., Naseem, S., 2021. Materials diversity of
hydrogel: synthesis, polymerization process and soil conditioning properties in
agricultural field. J. Adv. Res. 33, 15–40.
Rop, K., Karuku, G.N., Mbui, D., Michira, I., Njomo, N., 2018. Formulation of slow
release NPK fertilizer (cellulose-graft-poly (acrylamide)/nano-hydroxyapatite/
soluble fertilizer) composite and evaluating its N mineralization potential. Ann.
Agric. Sci. (Cairo) 63, 163–172. https://doi.org/10.1016/j.aoas.2018.11.001.
Rosa, L., Chiarelli, D.D., Rulli, M.C., Dell’Angelo, J., D’Odorico, P., 2020. Global
agricultural economic water scarcity. Sci. Adv. 6 https://doi.org/10.1126/sciadv.
aaz6031 eaaz6031.
Sahrawat, K.L., Prasad, R., 1975. A rapid method for determinationof nitrate, nitrite, and
ammoniacal nitrogen in soils. Plant Soil 42, 305–308. https://doi.org/10.1007/
BF02186992.
Shaghaleh, H., Wang, S., Xu, X., Guo, L., Dong, F., Hamoud, Y.A., Liu, H., Li, P.,
Zhang, S., 2021. Innovative two-phase air plasma activation approach for green and
efficient functionalization of nanofibrillated cellulose surfaces from wheat straw.
J. Clean. Prod. 297, 126664 https://doi.org/10.1016/j.jclepro.2021.126664.
Shaghaleh, H., Xu, X., Wang, S., 2018. Current progress in production of biopolymeric
materials based on cellulose, cellulose nanofibers, and cellulose derivatives. RSC
Adv. 8 (2), 825–842. https://doi.org/10.1039/C7RA11157F.
Sparks, D.L., Page, A., Helmke, P., Loeppert, R.H., 2020. Methods of Soil Analysis, Part 3:
Chemical Methods. John Wiley & Sons.
Tang, Z., Li, W., Lin, X., Xiao, H., Miao, Q., Huang, L., Chen, L., Wu, H., 2017. TEMPO-
oxidized cellulose with high degree of oxidation. Polymers 9, 421.
Wang, Y., Shaghaleh, H., Hamoud, Y.A., Zhang, S., Li, P., Xu, X., Liu, H., 2021. Synthesis
of a pH-responsive nano-cellulose/sodium alginate/MOFs hydrogel and its
application in the regulation of water and N-fertilizer. Int. J. Biol. Macromol. 187,
262–271. https://doi.org/10.1016/j.ijbiomac.2021.07.154.
Wu, H.B., Chan, M.N., Chan, C.K., 2007. FTIR characterization of polymorphic
transformation of ammonium nitrate. Aerosol. Sci. Technol. 41, 581–588. https://
doi.org/10.1080/02786820701272038.
Wu, J., Zhang, Z., Gu, J.g., Zhou, W., Liang, X., Zhou, G., Han, C.C., Xu, S., Liu, Y., 2020.
Mechanism of a long-term controlled drug release system based on simple blended
electrospun fibers. J. Contr. Release 320, 337–346. https://doi.org/10.1016/j.
jconrel.2020.01.020.
Wu, K., Du, C., Ma, F., Shen, Y., Liang, D., Zhou, J., 2019. Rapid diagnosis of nitrogen
status in rice based on Fourier transform infrared photoacoustic spectroscopy (FTIR-
PAS). Plant Methods 15, 94. https://doi.org/10.1186/s13007-019-0482-0.
Xiong, B., Loss, R.D., Shields, D., Pawlik, T., Hochreiter, R., Zydney, A.L., Kumar, M.,
2018. Polyacrylamide degradation and its implications in environmental systems.
npj Clean Water 1, 17. http://creativecommons.org/licenses/by/4.0/.
Zaharia, A., Radu, A.-L., Iancu, S., Florea, A.-M., Sandu, T., Minca, I., Fruth-Oprisan, V.,
Teodorescu, M., Sarbu, A., Iordache, T.-V., 2018. Bacterial cellulose-poly(acrylic
acid-co-N,N′-methylene-bis-acrylamide) interpenetrated networks for the controlled
release of fertilizers. RSC Adv. 8, 17635–17644.
Zhang, A., Liu, R., Gao, J., Yang, S., Chen, Z., 2014. Regulating N application for rice
yield and sustainable eco-agro development in the upper reaches of Yellow River
basin. China TheScientificWorldJOURNAL 2014, 239279–239290. https://doi.org/
10.1155/2014/239279.
Zhou, T., Wang, Y., Huang, S., Zhao, Y., 2018. Synthesis composite hydrogels from
inorganic-organic hybrids based on leftover rice for environment-friendly controlled-
release urea fertilizers. Sci. Total Environ. 615, 422–430. https://doi.org/10.1016/j.
scitotenv.2017.09.084.
H. Shaghaleh et al.
https://doi.org/10.1016/j.jclepro.2022.133098
https://doi.org/10.1016/j.jclepro.2022.133098
https://doi.org/10.1021/acsomega.7b00103
https://doi.org/10.1016/j.agwat.2019.105706
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref3
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref3
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref3
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref3
https://doi.org/10.1021/acs.jafc.5b05896
https://doi.org/10.1021/acssuschemeng.9b06635
https://doi.org/10.1021/acssuschemeng.9b06635
https://doi.org/10.1016/j.scitotenv.2018.11.264
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref7
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref7
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref7
https://doi.org/10.1016/j.geoderma.2018.10.012
https://doi.org/10.1021/acssuschemeng.5b01384 10.1016/j.jclepro.2021.129274
https://doi.org/10.1021/acssuschemeng.5b01384 10.1016/j.jclepro.2021.129274
https://doi.org/10.1007/s11581-016-1918-4
https://doi.org/10.1007/s11581-016-1918-4
https://doi.org/10.1016/j.fcr.2017.06.028
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref12
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref12
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref13
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref13
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref13
https://doi.org/10.1002/9781119108580.ch2
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref15
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref15
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref15
https://doi.org/10.1016/B978-0-12-811836-8.00012-4
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref17
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref17
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref17
https://doi.org/10.3390/w10081018
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref19
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref19
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref20
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref20
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref20
https://doi.org/10.1002/app.12925
https://doi.org/10.7717/peerj.1277
https://doi.org/10.7717/peerj.1277
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref24
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref24
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref24
https://doi.org/10.1016/j.aoas.2018.11.001
https://doi.org/10.1126/sciadv.aaz6031
https://doi.org/10.1126/sciadv.aaz6031
https://doi.org/10.1007/BF02186992
https://doi.org/10.1007/BF02186992
https://doi.org/10.1016/j.jclepro.2021.126664
https://doi.org/10.1039/C7RA11157F
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref30
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref30
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref31
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref31
https://doi.org/10.1016/j.ijbiomac.2021.07.154
https://doi.org/10.1080/02786820701272038
https://doi.org/10.1080/02786820701272038
https://doi.org/10.1016/j.jconrel.2020.01.020
https://doi.org/10.1016/j.jconrel.2020.01.020
https://doi.org/10.1186/s13007-019-0482-0
http://creativecommons.org/licenses/by/4.0/
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref38
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref38
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref38
http://refhub.elsevier.com/S0959-6526(22)02687-7/sref38
https://doi.org/10.1155/2014/239279
https://doi.org/10.1155/2014/239279
https://doi.org/10.1016/j.scitotenv.2017.09.084
https://doi.org/10.1016/j.scitotenv.2017.09.084
	A pH-responsive/sustained release nitrogen fertilizer hydrogel based on aminated cellulose nanofiber/cationic copolymer for ...
	1 Introduction
	2 Experimental section
	2.1 Material
	2.2 A-CNFs production from WS
	2.3 Fabrication of AN-loaded A-CNF/PAM-PAEM hydrogels for pH-responsive/sustained AN fertilizer delivery
	2.4 Characterization
	2.5 Water uptake capacity (S) of fertilizer hydrogel and water holding capacity (WHC) in soil
	2.6 In-vitro AN release kinetic studying of AN fertilizer hydrogel formulations
	2.7 Greenhouse pot trials with pHRSRNFH-based responsive/sustained AN delivery system
	2.7.1 Experimental site and design
	2.7.2 An release kinetic in the irrigated soil, plant, and N efficiency indicators with rice model
	2.7.3 Biodegradation testing
	2.8 pHRSRNFH feasibility
	2.9 Statistical analysis
	3 Results and discussion
	3.1 Synthesis and characterization
	3.2 Surface morphology
	3.3 In-vitro AN kinetic release of fertilizer hydrogel formulations
	3.4 AN release in the irrigated-neutral soil cultivated with rice under the greenhouse conditions
	3.5 The effects of PHRSRNFH4 application on the Nnutrition status, cell ultrastructure, cell cycle progression, and efficien ...
	3.6 The biodegradability and feasibility evaluation of PHRSRNFH4
	4 Conclusions
	CRediT authorship contribution statement
	Declaration of competing interest
	Acknowledgments
	Appendix A Supplementary data
	Referencesfor a longer time and releasing it slowly in a stressed environment
(Rizwan et al., 2021). However, the fabrication of fertilizer hydrogels for
stimuli-responsive/sustained fertilizers delivery in response to actual
soil/plant root stimulus fluctuations during wetting/drying cycles of
irrigation in soil with a particular pH category has never been investi-
gated. In addition, detailed knowledge on how their sustained release
mechanisms synchronize with nutrient plant demands at the different
critical growth stages is still largely scarce. Four key factors inform the
adaption of smart/steady fertilizer hydrogel systems: (1) the system
sensing interfaces including soil/root signals, (2) the
stimulus-responsive release behavior of the adapted system against
these signals and plant growth stages, (3) system biodegradability, and
(4) feasibility, all of which need to be considered.
Regarding the sensing interfaces, it has been observed that soil
drying/re-wetting cycles during water-saving irrigation have a sche-
matic impact on pH soil property resulting in a relatively dramatic
change in soil pH environment according to soil pH category (Alhaj
Hamoud et al., 2019). Mainly, in the neutral soils, with an initial pH ≥
6.5 up to pH of 7.5, the soil pH in the plant root zone decreases linearly
by more than 1 unit during the wetting shifts and shows the opposite
pattern in the drying shifts under short-term cropping conditions (Ding
et al., 2019). Besides, the plant roots are highly motivated during the
re-wetting shifts, producing a high organic acids rate, thus, increasing
the plant root zone acidity 0.3–0.9 times. Such changes in soil pH values
can be potentially employed as sensing interfaces to switch on/off the
pH-responsive fertilizer hydrogel device. In practice, alternate wetting
and drying (AWD) irrigation, a commonly applied water-saving tech-
nique, can lead to considerable changes in soil pH patterns (Alhaj
Hamoud et al., 2019). Rice (Oryza sativa. L) is a water-intensive food
crop, feeding over 40% of the global population (Datta et al., 2017),
which is threatened by the inefficient use of fertilizer and water; thus,
AWD-irrigated rice cropping systems have been widely implemented to
cope with water scarcity (Alhaj Hamoud et al., 2019). However, the
lower yields resulting from greater N-volatilization/leaching loss and
lower water availability under AWD irrigation compared to the
flooded-rice cropping systems is still the key challenge in ensuring food
security and environmental sustainability (Materu et al., 2018). There-
fore, the fabrication of a pH-responsive/sustained release N-fertilizer
hydrogel (pHRSRNFH) system fits the variable pH-stimulus in the
irrigated-neutral soils under AWD irrigation during different tempera-
tures growth phases of the rice crop as a model is urgently required.
Regarding the adapted hydrogel material, a platform of PAM which
is the most commercially common approved soil conditioner and
structure stabilizing agent with an application rate of 1–20 kg/ha and
900-18,000 tons/year (Levy and Warrington, 2015; Xiong et al., 2018),
has been chosen. A cationic-modified food-grade PAM with a viable
vinyl monomer of 2-aminoethyl methacrylate hydrochloride (AEM)
holding a primary amine is a suitable positively charged surface prep-
aration. This cationic copolymer could be adsorbed easily onto nega-
tively charged clays in the soil (Xiong et al., 2018) and potentially
Abbreviations
A-CNFs Aminated-cellulose nanofibers
AM Acrylamide
AEM 2-aminoethyl methacrylate hydrochloride
A-CNF/PAM-PAEM A-CNFs/cationic poly(AM-co-AEM)-based
hydrogel
AN N-fertilizer ammonium nitrate
ANA-CNF/PAM-PAEM AN-loaded A-CNF/PAM-PAEM hydrogel
(pHRSRNFH)
pHRSRNFH pH-responsive/sustained release AN fertilizer hydrogel
CRNFH Control release AN-fertilizer Hydrogel (AN-loaded PAM)
TPAP Two-phase air plasma pretreatment approach
WS Wheat straw
WSFs Wheat straw fibers
WSCFs Wheat straw cellulosic fibers
FTIR Fourier transform infrared spectroscopy
FESEM Field emission scanning electrons
BET Brunauer-Emmett-Teller surface area analysis
AWD Alternate wetting and drying
NUE Nitrogen use efficiency
TEM Transmission electron microscope
WHC Water holding capacity
Qt Cumulative percentage AN release as a function of time
k Kinetic constant related to the release rate
RD Root diameter (cm)
RWD Root weight density (g.cm− 3)
NCR Nitrogen crop removal (mg.plant− 1)
NAG and NAS Nitrogen accumulation in grain and straw (g)
DWG and DWS Dry weight of the grain and straw (g)
NCG and NCS Nitrogen content in the grain and straw (%)
ANRE Apparent nitrogen recovery efficiency (%)
PFPN Partial factor productivity of nitrogen (g.g− 1)
NHI Nitrogen harvest index (%)
NI Nitrogen input (mg.soil− 1)
GY Grain yield (g.plant− 1)
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
3
introduce preferred release behavior in response to neutral soil pH sig-
nals withHydrochlo-
ride (EDC-HCl), N-hydroxysuccinimide (NHS), 1,4 diaminobutane, 2-
aminoethyl methacrylate hydrochloride (AEM, 99%), 2-2′-azobis-(2-
amidinopropane hydrochloride) (V50), N, N-methylene bisacrylamide
(MBA), 1, 2-di (dimethylamino) ethane (TMEDA, 99%), phosphate-
buffered saline (PBS), potassium dihydrogen phosphate (KH2PO4,
≥89%), NaOH, HCL, methanol, and food-grade acrylamide (AM, 99%)
were obtained from Sinopharm Chemical Reagent Co Ltd. In all exper-
iments, deionized water was used. Soil cores were collected from
Nanjing, Jiangsu (31◦53′05.5′′N, 118◦51′42.1′′E).
2.2. A-CNFs production from WS
For efficient, feasible, and green A-CNFs production with high amino
substation degree (DSNH2) of free terminal amino-decorated surface, a
three-step TPAP pretreatment which is followed by TEMPO-oxidation
free-amine protecting amidation of WS has been applied according to
our previous work (Shaghaleh et al., 2021). Briefly, 90s-air plasma
activation using dielectric barrier discharge plasma reactor step-wisely
occurred through two phases on the WS fibers (WSFs) and subse-
quently on WS cellulosic fibers (WSCFs), combined with mild NaOH
pretreatment (Fig. 1). The TEMPO-oxidation was carried out by the
desperation of 5 g of the obtained pretreated WSCF powder, 0.075 g of
TEMPO, and 0.5 g of Na Br in 1-L deionized water at 1% (w/v), initiated
by adding 12%, 5 mmol/g o.d.p NaClO solution at 25 ◦C with stirring at
10 pH until no further decrease in pH was observed. The oxidized sub-
strate was then homogenized to obtain TO-CNFs. To prepare A-CNFs, the
resulting TO-CNF suspension (4.88 g, carboxyl substation degree
(DSCOOH) = 1.02, 2.55 mmol COO− /g) was sonicated with MES buffer
(150 mL, pH = 5.5) for 20 min, then mixed with EDC-HCl (4.8 g, 24.88
mmol) and NHS (2.86 g, 24.88 mmol) and stirred at 25 ◦C for 15 min. 1,
4-Diaminobutane (1.62 g, 37.32 mmol) was finally added, and the
mixture was stirred for 24 h at room temperature. The mixture was
dialyzed against saturated sodium chloride solution for 24 h and then
deionized water until no more free diamines were detected in the dial-
ysate. Purified A-CNFs were obtained by freeze-drying. Millipore
deionized water from the Millipore Milli-Q system (>18 M Ω cm; Merck,
Darmstadt, Germany) was prepared for the diluted samples.
2.3. Fabrication of AN-loaded A-CNF/PAM-PAEM hydrogels for pH-
responsive/sustained AN fertilizer delivery
A series of physically entrapped A-CNF-based hydrogels were syn-
thesized via typical in situ radical copolymerization in the water of 10%
wt food-grade AM solution with variable mass ratios of 0.5 %wt AEM
monomer solution around 1%wt A-CNF nanofiller suspension relative to
AM amount as expressed in Table 1. The mixture was then stirred at
room temperature under a nitrogen environment and vigorous stirring
until homogenous. The NH4NO3 (AN) fertilizer-encapsulated hydrogel
samples (CRNFH and pHRSRNFH) were prepared by adding 25%wt of
the total mixture solution of dissolved 0.5 %wt AN solution into the
prepared A-CNF/AM/AEM mixture before crosslinking reactions with
10 mg of MBA as a cross-linker agent. The solution was stirred at 250
rpm for 30 min with a nitrogen purge to eliminate oxygen at 40 ◦C. Then
0.2 mL of KPS aqueous solution (16 mg/mL) and 0.5 mL of an aqueous
solution of V50 (16.28 mg/mL) were added as the initiators with 0.045
mL of TEMED as an accelerator to start the copolymerization. The
copolymerization was allowed to continue up to 12 h at 40 ◦C and
maintained under an inert atmosphere before the stirring was stopped.
The resultant hydrogel precursor solutions were cast at regular PVC pans
to form dry weight granular hydrogels (1g). Synthesis steps and condi-
tions are shown in Fig. 1 and Table 1. The freshly prepared fertilizer
hydrogel granules were left overnight at room conditions and purified
by washing several times with deionized water to remove unreacted
chemical residues. After that, a part of the wet hydrogel samples was
centrifuged and then rapidly frozen in a freezer at about − 30 ◦C for 12 h,
which were then transferred to a freeze-dryer (Free-Zone plus 2.5 L,
Labconco, Kansas, MO, USA) at a temperature of − 50 ◦C and freeze-
dried for 5 days. These fully freeze-dried hydrogels were used for
FTIR, zeta potential, SEM observation, swelling ratios, and water hold-
ing capacity experiments. The other part of purified hydrogel granules
was dried in a vacuum oven at 30 ◦C before incubation in buffers and soil
for the kinetic release in vitro and greenhouse pot trial studies. The
unloaded AN in the supernatant was concentrated to 1 mL using a rotary
vacuum evaporator and quantified spectrophotometrically at 305 nm.
AN encapsulation efficiency (EE, w/w%) is calculated using the
following equation,
EE ​ = ​
WE
WT
​ × ​ 100 (1)
Where, WE is the amount of entrapped AN in the hydrogel, and WT is the
theoretical weight of AN added during preparation.
2.4. Characterization
The morphological structure of the prepared A-CNFs was studied by
atomic force microscopy (AFM, Bruker, Santa Barbara, CA, USA). The
carboxyl/amine group contents and the relative degree of substitution of
TO-CNFs (DSCOOH) and A-CNF (DSNH2) surfaces during A-CNFs pro-
duction steps were determined according to our previous study (Sha-
ghaleh et al., 2021), seeing the supportive information. The surface and
cross-section morphology of the as-prepared fertilizer hydrogels before
and after their application was observed using field emission scanning
electrons (FESEM, Hitachi S-4800, Japan). For SEM observation,
Table 1
The feed composition ratios of the synthesized AN-fertilizer hydrogel formulations, their related codes, Brunauer-Emmett-Teller (BET) surface area, and AN encap-
sulation efficiency.
Fertilizer hydrogelsa Code AM (mL)b AEM(mL) A-CNF (mL) AN (%)c Surface area (m2.g− 1) EE (w/w%)
ANPAM CRNFH 10 0 0 25 44.05 75.2
ANPAM-PAEM4
pHRSRNFH1 10 1 0 25 86.48 83.6
ANA-CNF3/PAM pHRSRNFH2 10 0 0.45 25 93.27 88.1
ANA-CNF3/PAM-PAEM2.5
pHRSRNFH3 10 0.5 0.45 25 186.62 94.4
ANA-CNF3/PAM-PAEM4
pHRSRNFH4 10 1 0.45 25 213.05 99.9
ANA-CNF1.5/PAM-PAEM4
pHRSRNFH5 10 1 0.225 25 138.11 90.6
a The letters n and m of A-CNFm and AEMn represent the wight ratios (wt%) of AEM and A-CNF relative to AM monomer amount.
b 10 wt%, 0.5 wt%, and 1 wt% of AM, AEM, and A-CNF (DS = 1.42) solutions were used, respectively.
c The wt% of NA is relative to the total prepared A-CNF/AM/AEM pre-gel mixture solution amount. AN fertilizer solution was prepared by dissolving 50 g of NH4NO3
to make a 100 ml aqueous solution.
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
5
hydrogel samples were cut into slices, frozen using liquid nitrogen,
transferred into a vacuum freeze drier for dehydration, and finally
spray-coated with gold using a Fine Coat Ion Sputter JFC-1100. Pore
diameters and the BET surface areas were determined by N2, adsorp-
tion/desorption method (Micromeritics ASAP2020 HD88, USA). Varia-
tions in the surface functional groups and structural properties
A-CNF/PAM-PAEM hydrogels were identified by a Nicolet 6700 FTIR
spectrophotometer (Thermo Scientific, USA) at every production/syn-
thesis stage. Zeta potential analysis of A-CNFs, A-CNF/PAM-PAEM, and
ANA-CNF/PAM-PAEM hydrogels were measured using Zetasizer Nano ZS
Malvern instruments at 25 ◦C for different pH values.
2.5. Water uptake capacity (S) of fertilizer hydrogel and water holding
capacity (WHC) in soil
For S investigation, 0.1 g (Wd) of dry hydrogel sample was entirely
immersed into 100 mL of deionized water at 25 ◦C, removed at regular
time intervals, wiped superficially with filter paper, and weighted (Ws).
The percentage of maximum swellingat equilibrium (S, %) was
measured gravimetrically by the following equation:
S ​ = (Ws − Wd)
Wd
× ​ 100 (2)
The efficiency of hydrogel to retain water in soil was expressed using
a WHC indicator a 10 g of dried fertilizer hydrogel was mixed separately
with 10 kg of dried field soil, placed in an enabled water filtration-PVC
tube with 200 mesh nylon led, weighed (m1), and followed by slow
watering from the top of the tube until water passed down through the
soil from the tube bottom. After water percolation stopped, the weight of
the loaded tube with the mixture was labeled (m2). The wight of pure
dried soil was used as control (m0). The WHC (%) of the samples was
calculated using the following equation:
WHC ​ =(m2 − m1)
m1
× ​ 100 (3)
2.6. In-vitro AN release kinetic studying of AN fertilizer hydrogel
formulations
For in-vitro AN release experiments, the release kinetics from the
different AN-entrapped fertilizer hydrogel formulations were assessed in
60 days laboratory test systems with PBS buffer solutions and soils at
25 ◦C as a function of varying pH levels applied of pH 5.5 and 7.4. To
determine the AN release in the buffer solutions, 1 mL of the soaking
solution samples were collected at predetermined time intervals and
analyzed for total N content by converting NH4–N and NO3–N forms
resulting from AN release to NH4–N state using the micro-Kjeldahl
method (Sparks et al., 2020). To investigate AN release in soil, 8 g of
each fertilizer hydrogel was buried in 10 kg of field soils with pH 5.5 and
7.4 at a depth of approximately 10–15 cm below the soil surface. The
percentages of AN released in the soil were quantified after the specified
intervals using the micro-Kjeldahl method (Sparks et al., 2020), which
indicates the total N content presented in the soil resulting from AN
release in both ammonium and nitrate forms. Organic N in soil was
omitted. The results were presented in terms of cumulative percentage
AN release as a function of time ( ​ Qt, %) using the following formula:
​ Qt =
Mt
M∞
× ​ 100 (4)
Where, Mt is the cumulative amount of AN released from the fertilizer
hydrogel formulation at time t, and M∞ is the total amount of AN loaded
into the hydrogel released at the infinite time.
Mathematical modeling was performed to characterize the
sustained/pH-dependent AN release kinetics from CRNFH and
pHRSRNFH4 formulations as a function of pH at a time and assay how
they match N plant requirements during the growing season. The release
profiles of CRNFH and pHRSRNFH4 were divided into one and three
stages, respectively, according to their slopes changes and fitted with the
following typical models (Wu et al., 2020):
Zero-order model
​ Qt = Q0 + k0(t − t0 ) (5)
First-order model
​ Qt = Q0 +
(
1 − e− k1(t− t0 )
)
(6)
Higuchi model
​ Qt = Q0 + kH(t − t0 )
0.5 (7)
Where Q0 and t0 are constants to adjust the starting point of the release
mechanism in response to changes in fertilizer hydrogel structure in the
case where the initial fitting point is not the zero time in stages II or III. k
is a kinetic constant that characterizes the release rate. Linear/nonlinear
curve fitting using Origin software was applied to all the AN release
profiles. The Korsmeyer-Peppas model equation is
​ Qt = kK-Ptn (8)
Where n is the release exponent. This model fits the entire release profile
to illustrate a more detailed physical picture.
2.7. Greenhouse pot trials with pHRSRNFH-based responsive/sustained
AN delivery system
To confirm the actual situation, the ability of the desired experi-
mental PHRSRNFH4 to release the AN steadily in response to the pH-
stimulus of neutral soil/rice root under AWD irrigation in line with N
plant demands during growth stages, water holding capacity, and
biodegradability were tested.
2.7.1. Experimental site and design
The greenhouse pot experiment was conducted at the experimental
agricultural farm (longitude 118◦83′E and latitude 31◦95′N) of the Soil
and Water Engineering Department, Hohai University, Nanjing, China.
The soil texture is clay loam with low total organic matter (27%) and is
categorized as neutral soil (pH, 7.4). Thirty-three PVC pots were
installed as an experimental group, and each pot (length: 80 cm,
diameter: 16 cm) was filled with 10 kg of dry-grounded soil (see sup-
portive information). The experiment was laid out in a split-plot design
with three replications. The main factor was the N-fertilizer delivery
form, including three different N-fertilizer formulations as the following:
positive control group treated with mineral AN-fertilizer (MF); group
treated with control release AN-fertilizer hydrogel (CRNFH), and a
group treated with the best formula of pH-responsive/sustained release
AN-fertilizer hydrogels (pHRSRNFH4). The rate of N application in all the
experimental pots under the different treatments corresponds to the N
level of 175 mg.kg-1 soil (~138 kg N.ha− 1), which is the recommended
level for rice production globally (Huang et al., 2018). In the MF group,
1745 mg of free AN was injected into each pot at a depth of 10 cm below
the soil surface to achieve the rate of 175 mg kg− 1 soil. Before planting,
the dry granules of CRNFH and pHRSRNFH4 (containing 127.8 and
172.5 mg N. granule− 1, respectively, with particles size ranging from 0.8
to 10 mm) were buried in each experimental pot at a depth of 10 cm
below the soil surface at a concentration of 0.14% and 0.10%, respec-
tively, to reach the N recommended level (Fig. 2S). AWD cycles are
served by flooding soil with 5 cm water depth once the soil water con-
tent reaches 80-70% of saturation. A time-domain reflectometer moni-
tored soil water content.
2.7.2. An release kinetic in the irrigated soil, plant, and N efficiency
indicators with rice model
To examine the AN release pattern from different N-fertilizer
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
6
formulations in the AWD-irrigated soil, 20 g of soil samples were
collected at 10 days’ intervals through the wall holes of the tube in
which sampling sippers were used to sample soil from the 0–40 cm layer
of the root zone. Soil samples were air-dried, sieved, and bulked to make
composite samples during the entire growing season, in addition to three
months after harvest. Soil pH was measured in the composite samples
during wetting/drying shifts in 1:5 soil-water extract using a calibrated
pH meter. The contents of total N and mineral N forms (NH4–N +
NO3–N) in the composite samples resulting from AN release to the soil
were determined by extraction with Morgan’s solution followed by
determination of NH4–N/NO3–N by Nessler’s reagent, and phenol-
sulphuric acid, respectively according to a standard method (Sahrawat
and Prasad, 1975).
To assess the efficiency of the experimental PHRSRNFH4 formulation,
N nitration status, cell ultrastructure, and cell cycle progression in rice
under different AN-fertilizer formulations application and AWD irriga-
tion in the neutral filed soil were evaluated. Therefore, FT-IR, trans-
mission electron microscopy (TEM), and flow cytometry analysis of rice
leaves at the full panicle growth stage were carried out. Also, growth,
yield, N crop removal (NCR), and NUE indicators of rice were observed
(see supportive information for detailed methods). Root diameter (RD
mm) and root weight density (RWD, g.cm − 3) is calculated as the
following:
RD =
̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅̅
RDW × 1
3.14 × RL
√
(9)
RWD =
RDW
V
(10)
Where RDW (g), RL (cm), and V (cm3) are the root dry weight, root
length, and the soil core volume, respectively.
The NCR (mg.plant− 1) was calculated by the following equations
(Alhaj Hamoud et al., 2019):
NCR= NAG + NAS =
(
NCG × DWG
100
)
+
(
NCS × DWS
100
)
(11)
where NAG (g) and NAS (g) are the N accumulation in grain and straw.
NCG (%) and NCS (%) are the N content in the grain and straw,
respectively, measured according to (Jackson, 2005). (see supportive
information) DWG (g) and DWS (g) are the dry weight of the grain and
straw, respectively.
The NUE was determined as the apparent N recovery efficiency
(AREN, %), partial factor productivity (PFPN, g.g− 1), and the N harvest
index (NHI, %) of N applied through different AN-fertilizer formulations
by the following equations:
AREN =
NCR
NI
× 100 (12)
PFPN =
GY
NI
× 100 (13)
NHI =
NAG
NAS + NAG
× 100 (14)
Where NI (mg. soil− 1) is the nitrogen input, GY (g. plant− 1) is the grain
yield.
2.7.3. Biodegradation testing
Masses of 10 g of fertilizer hydrogel granule samples were wrapped
by 0.5 mm of polyethylene fine elastic-flexible net, and buried in 10 kg
of field soil of the experimental greenhouse pot before planting at a
depth of 10 cm below the soil surface. The amount of physical degra-
dation indicator at intervals of a month was monitored. The experiment
was carried out in two alterations: samples of CRNFH and samples of
pHRSRNFH4. For each alteration, further 12 independent biological
replicates of the greenhouse pot experiment with a rice model were
conducted. The fertilizer hydrogel granules in soil were regularly
exhumed, washed free from soil, dried at 40 ◦C for 24 h, and weighed
Fig. 2. (a) FTIR spectra and (b) zeta potential at varied pH of WS-substrates during the steps of ANA-CNF/PAM-PAEM hydrogels synthesis.
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
7
during the rice-growing season and after harvest to gauge the mass loss
until the complete biodegradation (Boyandin et al., 2016).
2.8. pHRSRNFH feasibility
The economic evaluation of PHRSRNFH4 production was investigated
regarding raw materials, operating costs, fixed capital investment (FCI)
charges, general expenses of administration, and selling costs to deter-
mine the total production cost (TOC) per kilogram. The primary input
data used in the TOC calculation are shown in Table 1S.
2.9. Statistical analysis
The IBM-SPSS statistical package version 19.0 was used to analyze
the experimental data. The values of different variables were compared
using the analysis of variance at (Pfree amine groups and the
existence of electrostatic interactions or complexation in the different
hydrogel formals during ANA-CNF/PAM-PAEM synthesis can also be
confirmed and examined by zeta potential analysis. As shown in Fig. 2b,
zeta potential values exhibited dependence on both pH, functionaliza-
tion, and activation with AN, which consequently will contribute to the
pH-responsive swelling, AN release behavior, and the isoelectric point of
the resultant hydrogel. Interestingly, the PAM functionalization with
AEM increased the zeta potential of the resulting PAM-PAEM to +12.0-
+31.4 mV in the acidic conditions, which corresponded to the related
positive charge of AEM free amino group (NH3
+). Although the A-CNF
incorporation into the hydrogel network rapidly further increases the
related zeta potential of A-CNF/PAM-PAEM up to +43.2 mV due to free
NH3
+ increase in the conjugates at the acidic conditions, AN embedding
into ANA-CNF/PAM-PAEM slightly decreases zeta potential values close
to +19.5-+39.8 mV again. This phenomenon agrees with FTIR finding
that indicates the complex formation between AN anionic form with the
hydrogel network, which may reduce the burst effect and result in sus-
tained AN release behavior of ANA-CNF/PAM-PAEM hydrogel.
In practice, the higher positive charges of pHRSRNFH at the acidic
media give the advantage of the greatest swelling, water uptake, and AN
release in the lower soil pH during the wetting shifts applied in the
neutral soil. In the meantime, the plant N requirements are maximal as
the plant roots are activated by increasing water soil availability during
wetting shifts. In the natural-to-alkaline media, the free NH3
+ is mostly
protonated, and Zeta potential of ANA-CNF3/PAM-PAEM4 hydrogel de-
creases linearly, reaching the isoelectric point at pH ~7.4–7.8, which
corresponds to the lowest swelling and AN release of the hydrogel. In
practice, the isoelectric pH of ANA-CNF3/PAM-PAEM4 favorably
matches the soil pH during drying shifts of the irrigation intervals
(Fig. 4c), reducing N-volatilization/leaching loss when the N plant de-
mands are minimal as the roots are inactivated under low soil moisture
content.
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
8
3.2. Surface morphology
Morphological examination of the surface and pore structure was
conducted using SEM images (Fig. 3) and BET analysis. The architectural
structures of the swelled freeze-dried granule hydrogels embedded with
AN-fertilizer were compared for differences due to their composition.
The surface and cross-section of the ANPAM hydrogel (CRNFH) pre-
sented homogeneous and macroporous morphologies with the largest
pores size and open-interconnected channels (Fig. 3a) that seemed to be
the reason behind the relative highest/fastest AN release rate (Fig. 4).
The solid crystalline structure of AN fertilizer was clearly highlighted in
the structure of hydrogels, spotted and distributed homogeneously on
Table 2
The best-fitted parameters of the kinetic model for AN release from fertilizer hydrogels at various pH levels and incubation mediums.
Media Hydrogel formulation Release stage Best-fitted Release parameters
R2 K ( × 102, h− 1)
pH 5.5 pH 7.4 pH 5.5 pH 7.4
Buffer solutions pHRSRNFH4 I* First-order 0.997 0.997 0.068Aa 0.0599Ba
II Zero-order 0.985 0.989 0.0027Aa 0.0025Ba
III Higuchi 0.971 0.982 0.0281Aa 0.0276Ba
VI Korsmeyer-Peppas 0.995 0.996 0.122Aa 0.114Ba
CRNFH VI Zero-order 0.991 0.991 0.0071Aa 0.0071Aa
VI Korsmeyer-Peppas 0.995 0.995 0.161Aa 0.161Aa
Soil pHRSRNFH4 I First-order 0.997 0.999 0.060Ab 0.0575Bb
II Zero-order 0.985 0.996 0.0025Ab 0.0023Ab
III Higuchi 0.984 0.979 0.277Ab 0.0268Bb
IV Korsmeyer-Peppas 0.996 0.995 0.115Ab 0.071Bb
CRNFH VI Zero-order 0.968 0.968 0.0043Aa 0.0043Aa
VI Korsmeyer-Peppas 0.994 0.994 0.126Aa 0.126 Ab
*Stage I = 0–72 h, II = 144–504 h, III = 720–1660 h, and IV is the whole lifetime. Different uppercase letters within the same row and different lowercase within the
same column indicate significant differences under different pH levels and media, respectively, at the same release stage (Plations was studied and modulated in the buffer solution and soil in the
laboratory-test system at the targeted pH levels. As shown in Fig. 4 a-b
and Table 2, the AN release studies indicated a dependence of AN release
kinetics and its transport mechanisms on the hydrogels composition, the
surrounding environment pH, and the release media itself. From Fig. 4 a-
b, it was observed that the ANPAM hydrogel (CRNFH) copolymerization
with up to 4 wt% AEM and 3 wt% A-CNFs, significantly improved their
pH-sensitive properties and leading to much more sustained release
behavior and slower release over time. The unique pH-sensitive profiles
of ANA-CNF/PAM-PAEM (pHRSRNFH2-4) are attributed to the relative
amino-functionalized surfaces, which introduced a special moiety elec-
trostatic repulsion/attraction status according to pH levels. Further-
more, the observed ionic interactions and hydrogen bonding between
the AN anionic/cationic forms with the carbonyl, amine, and hydroxyl
groups in pHRSRNFH2-4 networks (Fig. 2a) and their relative smaller
pore sizes (Fig. 3b and c) effectively reduced their burst effect and AN
diffusion rate (Table 2), improving sustained-release properties.
As the pH range in the physiological conditions of neutral soils under
AWD irrigation wetting/drying shifts is located at acidic/neutral-to-
alkaline pH values, the pHRSRNFH2-4 was investigated within pH 5.5
and pH 7.4 levels. The pHRSRNFH2-4 showed a significant pH-dependent
AN release as a function of the targeted pH levels with the lowest and
slowest rates in the neutral media while recording the fastest and highest
rates in the acidic condition (Fig. 4 a-b). To explain this phenomenon, it
has been previously indicated that the hydrogel swelling behavior is
correlated with the isoelectric point and moieties repulsion, which
subsequently govern the release of the loaded compound in this
hydrogel material system. The ANA-CNF/PAM-PAEM hydrogel backbone
contains ammonium moieties of –NH2 functional groups, which
deprotonate and positively charge to NH3
+ in the acidic media, causing
significant electrostatic repulsions (Fig. 2b), higher swelling, and
eventually faster/higher AN release rate. With increasing the pH around
the system, the amino groups gradually protonate, causing dramatically
swelling decrease up to the net charge of the hydrogel becoming zero at
the isoelectric pH of the corresponding hydrogel, pH 7–7.7 (Fig. 2a),
resulting in the minimum AN release rates.
Particularly, CRFNH exhibited the most rapid AN release rate (Kk-p =
0.161-0.126 × 102, h− 1) with a controlled release manner via Zeroth-
order and no pH-responsive properties in an average of 19.4 and 14.5
mg AN. Day− 1 from 1g of hydrogel for 9 and 12 days, in buffers and soil
mediums, respectively, (Table 2). On the other hand, the pHRSRNFH4, as
the best representative, showed typical pH-dependent/sustained AN
release average of 3.00 and 2.69 mg.day− 1 at pH 5.5, while 0.92 and
0.55 mg.day− 1at pH 7.4 from 1g of hydrogel for 58 and 65 days in
buffers and soil, respectively (Fig. 4a and b, Table 2).
In practice, the irrigated-neutral soil shows a dramatic pH decrease
up to pH 4.9–5 after ~ 6–12 h of wetting shifts interval, followed by a
dramatic pH increase during the drying shifts till reaching the initial soil
pH value in the range of 6.5–7.5 (Fig. 5a). Herein, the lower soil pH
environments under wetting shifts conditions combined with activated
plant root acidity during these periods of irrigation intervals will
favorably switch the faster/higher AN release rates from the pHRSRNFH4
into the directly contacted soil and root surfaces in a sustained manner
(Fig. 4c, Table 2). In contrast, the neutral soil pH during drying shifts
(after 30–72 h application of irrigation intervals) will sufficiently reduce
AN release rats from pHRSRNFH4 when the plant N requirements are
minimal as the plant roots are inactive. These application properties of
HRSRNFH4 will prevent N volatilization loss and improve N uptake and
N use efficiency indicators (Table 3).
As shown in Table 2, the whole lifetime of sustained AN release
profiles of pHRSRNFH4 was divided into three release stages for the
quantitative analysis of the AN release data according to their relative
slopes changes and then best fitted with the suitable typical models.
Under the different incubation media and pH levels, the PHRSRNFH4
revealed the fastest AN release in the first stage with a short duration
within 0–72 h incubation governed by the First-order mechanism (k1 =
0.068–0.0575). In this stage, A-CNFs in the PHRSRNFH4 begin to swell
after incubation in buffer/soil mediums. Then, some of the uniformly
distributed AN on the hydrogel network will diffuse, according to pH
level, especially from the swollen regions of A-CNF surfaces into the
inter-fiber spaces and the external medium. However, as the incubation
time increases, the swelling continues. The diameter of A-CNFs increases
until they fuse, leading to the denser matrix and fewer AN release
channels and resulting in stage II release mechanism. From Table 2, it
can be seen that, during stage II, the PHRSRNFH4 exhibited control
release manners with the slowest AN release governed by the Zeroth-
order mechanism with a longer duration (144–504 h). In this stage,
the significant decreases in the AN release rate (k0 = 0.0023–0.0027)
result in AN maintenance for a long time until the hydrogels begin to
degrade. Finally, at the last release stages (720–1540 h), the hydrogel
polymeric network was degraded after a long-time incubation, espe-
cially in the soil. Herein, A-NFCs mostly disappeared, the polymeric
matrix broke up into oligomeric fragments, large pores were presented
(Fig. 7b I-III), and the trapped AN in the dense hydrogel matrix was
released by the Higuchi module with more rapid release rates again (kH
= 0.0281–0.0268). Interestingly, the soil nature significantly slowed the
AN release rate at all release stages and pH levels, leading to more stable
AN release than buffer mediums.
The starting point of each release stage related to a specific release
mechanism was distinguished according to the relative slope changes of
AN release data. These different three pH-dependent AN release stages
are attributed to the changes in fertilizer hydrogel membrane structure
as a function of the incubation time, A-NFC fibers swelling status, and
hydrogel material degradation under different environmental condi-
tions changing found in the root zone as a result of irrigation, soil or-
ganism activity, and relative temperatures.
Bringing AN release mechanisms/pH-responsive profiles of
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
11
pHRSRNFH4 and N plant requirements during different growth stages
and conditions together, it is worth noting that pHRSRNFH4 offers
optimal sustained AN doses delivery, covering N crop requirements
during all the critical growth stages (e.g., from leafing to filling, Fig. 4c),
compared to MF, and CRNFH that limited AN availability during the first
growth stages only (Fig. 4a and b, and Fig. 5a). Another attractive point
is that obtaining such a pH-responsive release profile of pHRSRNFH4
favorably resulted in the highest/faster AN release at a lower pH soil
environment after rewetting shifts, synchronizing with the maximum
root activation periods at the higher water availability (Fig. 4a–c, and
Fig. 5b), and improving root nutrients uptake. Conversely, the lowest/
slowest AN release at neutral pH mediums during drying shifts in the
neutral soils reduces the AN loss; meanwhile, the roots are un-activated
at low water availability.
These unique pH-responsive properties and relativelysustained fer-
tilizer release mechanisms of pHRSRNFH4 are completely different from
the situation where the fertilizer release is governed by control release
mechanisms with no responsive properties in the elder CRNFH genera-
tion. Under the current study conditions, the related three sustained-
release mechanisms of pHRSRNFH4 was founded to be comparable
with that of CRNFH produced in this study which was followed the zero-
order mechanism and released the total AN loaded after ~200–250 h
incubation in buffers and soil, respectively, compared to 1600 h incu-
bation of pHRSRNFH4. Also, the release mechanisms and NA release time
of pHRSRNFH4 are comparable with that resultes in several in-
vestigations on previous CRNFH generation based on cellulose and/or
acrylamide hydrogels. For example, Poly (acrylic acid-co-acrylamide)/
cellulose nanofibrils nanocomposite hydrogels present urea desorption
after about 192–240 h in a control release manner (Mahfoudhi and
Boufi, 2016). Also, CRNFH based on bacterial cellulose-poly(acrylic
acid-co-N, N′-methylene-bis-acrylamide) composite hydrogel exhibits
nitrate ions desorption after about 80 h with no responsive behavior
(Zaharia et al., 2018). The results were somehow expected because the
addition of A-CNFs and AEM in the hydrogel composites not only led to
denser polymeric networks and pH-responsive properties that resulted
in a prolonged AN release from the pHRSRNFH4 but also the relative free
amino group which resulted in interaction with the anionic part of AN
together with the interaction between AN cationic form with the
carbonyl group of PAM at pHRSRNFH4 backbone (Fig. 2), leading to less
amount of AN on the hydrogel surface and retarding the release of AN
over a longer period. While the poor interaction between the fertilizer
and polymer, with no sensitive properties, and/or larger fiber size and
pore size leads to a large amount of AN on the polymer surface that
rabidly released in the elder CRNFH generation.
3.4. AN release in the irrigated-neutral soil cultivated with rice under the
greenhouse conditions
The AN release in the irrigated-neutral soil was evaluated in three
groups of greenhouse pots with rice (Fig. 2S) that were separately
treated by different AN-fertilizer formulations of PHRSRNFH4, CRNFH,
and MF. As shown in Fig. 5a and b, the main factors determining the AN
release in the irrigated soil were the AN-fertilizer formulation, time after
application, and soil pH fluctuations related to the soil water content
changes during wetting/drying shifts of AWD irrigation (Fig. 5b). As
Fig. 5. (a) The total N and mineral N contents in the irrigated-neutral soil resulting from AN release of different AN-fertilizer formulations under the greenhouse-test
system with rice. (b) The total N content resulting from AN release of different 25 days AN-fertilizer formulations as a function of soil pH related to time after ADW
irrigation intervals application.
Table 3
Development of the rice/N efficiency indicators as a function of the application
of different AN-fertilizer formulations under AWD irrigation of the neutral field
soil.
Indicator AN fertilizer hydrogel formulation
PHRSRNFH4 CRNFH MF
Growth RD (mm) 0.57 ± 0.02a 0.47 ±
0.04b
0.39 ±
0.02c
RWD (g.cm− 3) 0.52 ± 0.04a 0.30 ±
0.01b
0.21 ±
0.02c
Number of tillers (tiller.
plant− 1)
43.0 ± 4.07a 33.7 ±
1.2b
27.7 ±
1.7c
Yield Panicles’ number
(panicle.plant− 1)
41.3 ± 4.6a 25.7 ±
1.9b
21.0 ±
1.4b
Total biomass (g.
plant− 1)
60.6 ± 1.8a 47.0 ±
2.7b
33.4 ±
1.6c
Grain yield (g.plant− 1) 29.6 ± 2.6a 21.6 ±
1.7b
15.9 ±
1.6c
NCR NAG (mg.plant− 1) 579.5 ±
17.5a
357.8 ±
21.5b
169.5 ±
11.8c
NAS (mg.plant− 1) 215.4 ±
21.8a
170.4 ±
15.6b
94.4 ±
12.8c
NUE AREN (%) 57.8 ± 1.7a 38.4 ±
1.4b
19.2 ±
0.4c
PFPN (g.g− 1) 21.5 ± 0.6a 15.7 ±
0.9b
11.5 ±
0.3c
NHI (%) 74.9 ± 2.6a 67.6 ±
5.8b
64.3 ±
4.6b
Note: Different uppercase letters within the same raw indicate significant
differences (PN nutrition when
rice plant root is activated.
Further investigation at the cell ultrastructure level of rice leaves was
explored by TEM analysis (Fig. 6b). Under MF treatments, the TEM
analysis showed thick cell wall (CW), a lot of the vacuoles (Va), raptured
chloroplasts (Chl), small thylakoids (Thy), and abnormal starch grains
(SG), indicating induced cell development as a result of the poor N
nutrition status. Conversely, the optimal N nutrition status under
pHRSRNFH4 treatment considerably improved the cell ultrastructure of
the typical cell walls, developed chloroplasts, uniform-large thylakoids,
typical starch grains, and vacuoles absence was observed. Also, the
nuclear DNA contents by flow cytometry for rice leaves were assayed to
investigate whether the various fertilizer formulations affect the cell
cycle progression during a specific cell cycle phase. As shown in Fig. 6c,
the results demonstrated that each treatment affects the cell cycle
development in a different range manner. Unsurprisingly, the optimal N
nutrition status resulting under pHRSRNFH4 treatment greatly encour-
aged the progress of plant cells through the cell cycle compared to the
changes in cell progression induced by CRNFH and MF treatments.
In agreement with the development in N nutrition status and cell
progression after serving PHRSRNFH4, the growth, yield, crop N
removal, and NUE indicators showed significant enhancement
compared to their values after CRNFH free AN application (Table 3). In
particular, under PHRSRNFH4, the RWD and RD considerably boosted
compared to that under CRNFH and MF treatments, producing superior
rice root growth in contact with the soil and the dense penetration into
fertilizer hydrogel themselves (Fig. 7bIV, Fig. S2). The vigorous roots
were due to N availability within the rhizosphere during the root activity
periods and the rice’s different growth stages (Figs. 4 c, Fig. 5 a-b),
which consequently improved N plant uptake (Alhaj Hamoud et al.,
2019). These results can coordinate with the largest shoot biomass,
producing 43 tiller/plant, contributing to the best N uptake, overall
plant growth, and thus rice productivity (Table 3). The maximum N
concentration in the root zone throughout the growing season (Fig. 5a)
and the superior plant root/shoot activity eventually led to the largest
responsiveness to N. Subsequently, an abundant amount of N ions were
fixed in plant particles which corresponded to the maximum NCR values
under PHRSRNFH4 treatments. As the PHRSRNFH4 application maxi-
mally increased N availability, rice root/biomass activities and their
utilization efficiency regarding N uptake thus, resulted in the most sig-
nificant N accumulation in larger biomass and the highest values of
ANRE, PFPN, and NHI.
Furthermore, the ideal AN supply in a sustained/pH-responsive
manner reduced the N loss by volatilizing/leaching and increased the
N recovery by 19.4% and 38.6% compared to the AN supply via control
release manner using CRNFH and free AN treatment, respectively.
Equally, the worse N nutrient regime created by MF sharply increased N
loss and decreased N availability, especially after 30 days’ application.
This reduced the utilization of AN applied and subsequently N accu-
mulation in the plant, resulting in the lowest NUE of N applied (Table 3).
3.6. The biodegradability and feasibility evaluation of PHRSRNFH4
As shown in Fig. 7a, the initial mass loss began in the first month in
the PHRSRNFH4, followed by steady degradation ending with approxi-
mately 52% of its original mass at harvest until the complete degrada-
tion at 10th month after incubation. Despite being subjected to a large
amount of water exposure of irrigation and to plant root activity during
the growing season, CRNFH was able to avoid initial mass loss about the
first 3 months, and only 23% of their original mass was observed at
harvest until the complete degradation at 16th month after incubation.
The faster degradation was attributed to A-CNFs biocompatibility and
the hydrophilic aggregation of amino groups at the PHRSRNFH4
network, which increased its hydrophilicity, water uptake, and water-
holding capacities (Fig. 3d, f) (Park et al., 2003). Thus, promoting a
dense root-penetration feature (Fig. 7bIV), soil degradation organisms
attach to its polymeric matrix, further accelerating its physical/chemical
biodegradation rate (Chamas et al., 2020; Xiong et al., 2018). Interest-
ingly, the presence of AN crystals at the 3rd month of PHRSRNFH4
application (Fig. 7bIII) explained the stage III of sustained AN release
that was governed by Higuchi module (720–1660 h) (Fig. 4) resulted by
hydrogel biodegradation.
To evaluate production facilities and highlight the advantage of
PHRSRNFH4 over the elder generation of superabsorbent hydrogels
(SAH) and CRFH, a preliminary economic evaluation to estimate the
TPC of PHRSRNFH4 was established. The TPC was calculated based on
manufacturing costs, which include the raw materials costs estimated
according to actual consumption from experimental results, and
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
13
Fig. 6. (a) Deconvolution Curve-fitting, (b) TEM micrographs, and (c) ungated histogram and a scatterplot of flow cytometry analysis of cell cycle with leaf bio-
masses graphs under different AN fertilization formulations at the full panicle growth stage.
H. Shaghaleh et al.
Journal of Cleaner Production 368 (2022) 133098
14
operating costs which contain A-NFC production costs mainly, and other
components related to FCI charges (Table 1S), in addition to general
expenses of administration and selling costs. According to the input
parameters for calculations presented in Table 1S for TPC estimation,
the raw materials with A-NFC production cost were 1.28 USD.kg− 1, and
the TPC of PHRSRNFH4 was about 2.59 USD.kg− 1, which is comparable
to SAH and CRFH costs. For example, according to Alibaba international
prices, the polymer-coated urea and SAH-based polyacrylate hydrogels
cost about 0.88–1.51, and 3.55–4.25 USD.kg-1, respectively significant
potential of PHRSRNFH4 to serve as an alternative fertilizer formulation.
4. Conclusions
In this study, AN-loaded A-CNF/PAM-PAEM hydrogel for developing
a pH-responsive/sustained release N-fertilizer delivery system in
response to pH triggers fluctuation of the neutral soils during wetting/
drying shifts of irrigation and different growing season stages was suc-
cessfully synthesized. The AEM and A-CNF addition leads to desirable
enhancement of surface characterization, water uptake, fertilizer
loading efficiency, pH-responsive/sustained release behavior, and
biodegradability of as-prepared fertilizer hydrogels. The selectively
functionalized PHRSRNFH4 exhibits the preferred slowest/lowest AN
release at a neutral pH medium compared to the most active AN release
rates at the lower pH conditions with sustained AN supplying over 90-
days the neutral-irrigated soil cultivated with rice. Such fertilizer de-
livery pattern leads to desired N-fertilizer management being synchro-
nized with plant demands along with the critical growth periods and
root activation under short-term pH changes of neutral soils during
wetting/drying of irrigation intervals. Consequently, applying this new
pH-responsive/sustained AN delivery system considerably improved
plant/N use efficiency indicators by offering optimal N application rate
with suitable water holding capacity and biodegradation rate
