International Journal of Biological Macromolecules 191 (2021) 483–491
Available online 23 September 2021
0141-8130/© 2021 Elsevier B.V. All rights reserved.
A TEMPO-oxidized cellulose nanofibers/MOFs hydrogel with temperature
and pH responsiveness for fertilizers slow-release
Xiangyu Lin a,1, Lizhen Guo a,1, Hiba Shaghaleh b, Yousef Alhaj Hamoud b, Xu Xu a,*, He Liu c,*
a College of Chemical Engineering, Advanced Analysis and Testing Center, International Innovation Center for Forest Chemicals and Materials, Nanjing Forestry
University, Jiangsu Provincial Key Lab for the Chemistry and Utilization of Agro-Forest Biomass, Jiangsu Key Lab of Biomass-Based Green Fuels and Chemicals, Nanjing
210037, Jiangsu Province, China
b College of Agricultural Science and Engineering, Hohai University, Nanjing 210098, China
c Institute of Chemical Industry of Forestry Products, Chinese Academy of Forestry, Key Laboratory of Biomass Energy and Material, Co-Innovation Center of Efficient
Processing and Utilization of Forest Resources, Key Lab. of Chemical Engineering of Forest Products, National Forestry and Grassland Administration, National
Engineering Laboratory for Biomass Chemical Utilization, Nanjing 210042, Jiangsu Province, China
A R T I C L E I N F O
Keywords:
Cellulose
Hydrogel
Slow-release
A B S T R A C T
In this work, a kind of MOF MIL-100(Fe)@CNFs hydrogel (MC) based on TEMPO-oxidized cellulose nanofibers
(CNFs) for fertilizers slow-release was prepared by free-radical polymerization, where N-vinyl caprolactam
(NVCL) and CNFs were involved to exhibit temperature and pH response, respectively. Particularly, porous MIL-
100(Fe), a kind of metal organic frameworks (MOFs), was introduced to optimize the load and slow-release
capabilities. The Fourier transform infrared spectroscopy, X-ray diffraction, scanning electron microscopy, and
thermogravimetric analysis were used to characterize. The swelling behaviors and water-retention capabilities of
hydrogels were evaluated. Using urea as the model fertilizer, the slow-release mechanism was revealed. Wheat
was used as the model crop to evaluate the practical growth status. Compared with MC-0% hydrogels, the MC-
10% hydrogels exhibited a better swelling capacity (37 g/g), water-retention (22.78%) and slow-release per-
formance (40.84%). It also exhibited sensitivities to temperature and pH for regulating urea release. Besides, the
number of tillers and leaves of wheat fertilized with MC hydrogels significantly increased, as did the photo-
synthetic rate. In conclusion, the MC-0% hydrogels had a positive influence on crops growth, and promoted the
possible utilization of hydrogels in slow-release fertilizers.
1. Introduction
The efficient use of fertilizers and water resources can greatly in-
crease crops yields, and meet increased demands. However, the usage
efficiencies of conventional fertilizers (urea) are generallyof the hydrogels was characterized by FT-IR, XRD,
and SEM. The swelling ratio, urea release behavior, temperature-
responsive nature, and pH-responsive properties of the MC hydrogel
were investigated. Finally, the obtained MC hydrogels were applied in
the growth of wheat.
2. Materials and methods
2.1. Materials
2,2,6,6-Tetramethylpiperidine-1-oxyl (TEMPO, 98%), 1,3,5-
benzenetricarboxylic acid (H3BTC, 98%), ammonium persulfate (APS,
98%), sodium hypochlorite (NaClO, 14%), N,N-dimethylacrylamide
(DMAA, 98%), N-vinyl caprolactam (NVCL, 99%), and N,N-methyl-
enebisacrylamide (MBA, 99%) were purchased from Aladdin Chemical
Co., Ltd. (Shanghai, China). Sodium hydroxide (NaOH, 97%), N,N-
dimethylformamide (DMF, 99.5%), hydrochloric acid (HCl), sodium
alginate (SA), and urea were purchased from Nanjing Chemical Reagent
Co., Ltd. (Nanjing, China). Eucalyptus pulp was purchased from
ARAUCO Co., Ltd. (Chile).
2.2. Synthesis of the TEMPO-oxidized cellulose nanofibers (CNFs)
NaBr (0.5 g) and TEMPO (0.08 g) were dissolved in deionized water
(500 mL) and mechanically stirred in a three-neck round-bottomed flask
(1000 mL). After adding the previously pulverized eucalyptus pulp (5 g),
a solution of NaClO (8.5 mL, pH 10), whose pH value was adjusted using
a 0.1 mol/L HCl solution, was slowly added to the flask at 25 ◦C. A 0.1
mol/L NaOH solution was added at the same time to maintain the pH of
the system at ~10. The CNFs were obtained via a suction filtration pu-
rification process, in which the CNFs were washed with deionized water
until the conductivity of the washed solution wasout from the bottom, and the
setup was weighted once again when there was no water seeping from
the bottom (w1). The Hr (%) of the hydrogel in the soil was calculated as
follows:
Hr = (w1 − w0)/w0 × 100% (7)
2.9. Slow-release behavior
Load and release experiments were carried out on the MC-0% and
MC-10% hydrogels using urea as a fertilizer model. To obtain hydrogels
loaded with urea, the dried hydrogels were dipped into the aqueous urea
solution (25 mg/mL) for 72 h at 25 ◦C. To investigate their urea release
behaviors, hydrogels loaded with urea were placed in water at different
temperatures and pH values. In each case, the soaking solution (1 mL)
was collected at regular intervals, and the amount of urea released was
characterized using UV–visible spectrophotometry. The cumulative
release rate (%) of urea was calculated as follows:
Cummulative release (%) = mt
/
m0 × 100% =
mt
m1
× 100% (8)
where mt (g) and m0 (g) represent the quantity of urea released at a
certain time and the urea loading, respectively.
To investigate their release behaviors in soil, the urea-loaded
hydrogels (1 g) were buried in dry sand (800 g) at a depth of approxi-
mately 5–6 cm below the surface for 30 d at room temperature. During
the experiment, distilled water (200 mL) was irrigated every 5 d. Three
sets of experiments were performed in parallel. Samples of the soil (1.5
g) were removed at different periods (1, 3, 5, 7, 10, 15, 20, 25, and 30 d)
and the cumulative amount of urea released was calculated using the
Kjeldahl method, which can indicate the total nitrogen content present
in the soil. The cumulative release rate (%) of urea was calculated using
Eq. (8).
To elucidate the urea release mechanism in soil, four kinetic math-
ematical models (i.e., the zero-order, first-order, Higuchi, and
Korsmeyer-Peppas models) were used to fit and analyze the data ob-
tained [4,41,42]:
①Zero − order release kinetics model : Mt/M∞ = k0t (9)
②First − order release kinetics model : Mt
/
M∞ = 1 − e− k1t (10)
③The Higuchi model : Mt
/
M∞ = kHt1/2 (11)
④The Korsmeyer − Peppas model : Mt
/
M∞ = kkptn (12)
where M∞ and Mt represent the mass of urea at the release equilibrium
and a different release time ‘t’, respectively. k0, k1, kH and kkp represent
the diffusional kinetic constant, the release constant, the dissolution
constant, and the rate constant, respectively. ‘n’ is a diffusional expo-
nent, and according to its value, one of three diffusion mechanisms can
be identified. The diffusion mechanism is Fickian if ‘n’ is ≤0.43, while
where 0.43con-
taining MIL-100(Fe)) showed an irregular micropore structure (Fig. 4d).
Moreover, the results of EDAX analysis (Fig. S4) indicated that MIL-
100(Fe) distributed homogeneously in the hydrogels. Thus, to verify
whether MOF MIL-100(Fe) can function properly in hydrogels, the BET
adsorption-desorption isotherms were obtained (Fig. 4f and Table S3).
As indicated, the MC-10% hydrogel exhibited a type II adsorption
isotherm, as did MOF MIL-100(Fe) (Fig. S5). The MC-10% hydrogel also
possessed a higher specific surface area, thereby suggesting that the
combination of MOF MIL-100(Fe) with hydrogels was beneficial to
enhance the adsorption of fertilizers and water.
3.2. Swelling behavior and the swelling dynamic mechanism at room
temperature
As a controlled release carrier for fertilizers and water, the swelling
behavior and dynamic swelling mechanism should be explored in a
Fig. 2. Schematic of the preparation process for CNFs a, MIL-100 (Fe) b and
MOF MIL-100(Fe)@CNFs hydrogels c d.
Fig. 3. a FTIR spectra of CNFs, MIL-100 (Fe), NVCL, MC-0% hydrogel and MC-
10% hydrogel, and b MC hydrogels with different MIL-100 (Fe) contents. c XRD
spectra and d XPS spectra of CNFs, SA, MIL-100 (Fe), MC-0% and MC-
10% hydrogels.
X. Lin et al.
International Journal of Biological Macromolecules 191 (2021) 483–491
487
hydrogel. During the swelling process, the free adsorption of water
occurred initially [43], as indicated in Fig. 5, where the swelling be-
haviors of the different hydrogels at room temperature were shown. The
swelling rates of all MC hydrogels increased rapidly during the initial 6
h, and then increased slowly until equilibrium was reached. This was
attributed to the expansion of the 3D network structure due to repulsion
between the carboxylate groups in the hydrogels, which promoted the
penetration of water into the 3D structure, and improved the swelling
ratio. Compared with the MC-0% hydrogel, the MC-10% hydrogel
showed the maximum increase in swelling capacity, i.e., from 27 to 37
g/g (Fig. 5b). This was due to the inhibiting of the physical entanglement
of the CNFs and the SA chains by MOF MIL-100(Fe), which led to a
reduction in the hydrogel cross-linking density and an increased
swelling ratio. However, as the content of MOF MIL-100(Fe) was
increased further (i.e., in the case of the MC-20% hydrogel), the swelling
rate decreased. It was likely due to increased cross-linking, which
limited expansion of the network structure and hindered the infiltration
of water molecules. Fig. 5f showed the results of the hydrogel reuse
experiment, from which their good ability to absorb and release water
repeatedly can be clearly observed.
To explore the dynamic swelling mechanism of MC hydrogels in the
initial stage, the Korsmeyer-Peppas model (Eq. (13)) and Schott's
second-order swelling kinetics model (Eq. (14)) were introduced [41].
For Korsmeyer-Peppas model, wt and we denoted the weight of water
absorbed at any time t and at theoretical equilibrium respectively; K was
a constant that describes the characteristic of hydrogels and n was the
exponent that described the type of diffusion. Both K and n can be
calculated from the plots of log(F) versus log(t). For Schott's second-
order swelling kinetics model, SR and ESR denoted the swelling ratios
at any time t and at equilibrium respectively, and k represented the
swelling rate constant.
F =
wt
we
= Ktn (13)
Fig. 4. a Photograph of (i) MC-0%, (ii) MC-10%. SEM images of b MIL-100 (Fe), c MC-0% hydrogel and d e MC-10% hydrogel at different magnifications. f Nitrogen
adsorption-desorption isotherms of MC-0% and MC-10% at 77 K.
Fig. 5. a Swelling ratios and b equilibrium swelling ratios of different hydro-
gels in distilled water at 25 ◦C. c Photograph of hydrogels before and after
swelling equilibrium. d Korsmeyer-Peppas model and e Schott's second-order
kinetic model for different hydrogels in water. f The reusable swelling and
deswelling behaviors of different hydrogels.
Fig. 6. a ESR of different hydrogels in distilled water at different temperature.
b Cycle analysis for swelling ratios at different temperatures. c Swelling ratios
at different pH values under 25 ◦C. d Cycle analysis for swelling ratios at
different pH.
X. Lin et al.
International Journal of Biological Macromolecules 191 (2021) 483–491
488
t
SR
=
1
kESR2 +
1
ESR
t (14)
As shown in Fig. 5d, good linear correlation coefficients were ob-
tained (R2 > 0.95) for the Korsmeyer-Peppas model, and the values of n,
K, and R2 were given in Table S4. According to the obtained values of n
(0.43 0.99, thereby indicating that this model was
suitable for describing the MC hydrogel swelling behaviors. Moreover,
the values of ESRcal matched well with the experimental values (ESRexp)
(Table S4).
3.3. Temperature- and pH-responsive behaviors
It is well known that the conformations of the thermosensitive
monomer NVCL chains in hydrogels change when the temperature is
lower or higher than the low critical solution temperature (LCST), and
this effect leads to the volume-phase transition of hydrogels [44]. More
specifically, when the temperature is above the LCST, the hydrogels
shrink rapidly. Thus, the prepared MC hydrogels were swollen in
deionized water at various temperatures, and their equilibrium swelling
ratios were calculated. As shown in Fig. 6a, the equilibrium swelling
ratios of the MC hydrogels decreased as the temperature was increased,
indicating that these MC hydrogels exhibited a high temperature
response performance. In addition, the hydrogels were found to absorb
water easily at temperatures below the LCST (25 ◦C). It can therefore be
interpreted that the PNVCL chains showed great hydrophilicity at tem-
peratures below the LCST, but collapsed into a hydrophobic structure
above the LCST [45] (Fig. S6a).
In the context of actual application, it is essential for hydrogels to
achieve repeatable shrinkage and swelling. Therefore, the cycling
properties of the different MC hydrogels in terms of their swelling and
shrinking behaviors were investigated at 25 ◦C (below the LCST) and at
55 ◦C (above the LCST). As shown in Fig. 6b, all of the examined MC
hydrogels exhibited good repeatable shrinkage and swelling behaviors,
and showed a slightly consecutive reduction over time.
The pH-responsive behaviors of the MC hydrogels were subsequently
evaluated by investigating the swelling ratios at various pH values. As
shown in Fig. 6c, the swelling ratios of all hydrogels increased with the
pH increasing from 3 to 11. From this result, it can be interpreted as that
the –COOH groups dissociated into –COO¡ groups under alkaline con-
ditions, thereby leading to an increase in the hydrophilicity and the
electrostatic repulsion of the structure [46], and resulting in the
observed improved water absorption ability (Fig. S6b). As shown in
Fig. 6d, the examined MC hydrogels also exhibited good repeatable
shrinkage and swelling behaviors at pH = 3 and pH = 11, presenting
pleasuring pH-responsiveness.
Fig. 7a showed the water-retention capabilities of the different MC
hydrogels in distilled water at 55 ◦C (above the LCST). As shown, the
introduction of MOF MIL-100(Fe) increased the water-retention of the
hydrogelsfrom 60.28% (MC-0%) to 77.53% (MC-10%). Moreover, the
maximum water-holding capacity of MC-10% was found to be higher
than that of MC-0% in a soil environment (Fig. S7). Besides, the sample
mixed with MC-10% (1.0 g) presented the greatest water-retention ca-
pacity of the various samples examined (Fig. 7b), which still remained
22.78% in soil on day 30. For all the other samples, the water-retention
reached to zero on day 30 or earlier. These observations suggested that
the application of MC-10% hydrogels in agricultural production was a
good choice to provide a suitable growth environment for crops.
3.4. Urea release behaviors of the MC hydrogels
To evaluate the application potentials of MC hydrogels in the field of
slow-release fertilizers, the urea release behaviors of our prepared
hydrogels were studies at different pH values and temperatures. Thus,
Fig. S8 showed the FTIR spectra of MC hydrogels loaded with urea, and
Fig. 8 showed the effects of pH and temperature on the cumulative
release of urea. Overall, the obtained results illustrated a general trend
wherein urea was released rapidly in the initial 3 h, followed by the
subsequent slower release due to the fact that the urea loaded on the
hydrogel surface was more easily released than that inside the hydrogel.
Due to the pH responsiveness, the hydrogels exhibited lower fertilizer
release rates in alkaline environments (Fig. 8a and b), so as to ensure a
better fertilizer utilization efficiency in the environment (pH is around
7.5) where crops are suitable for growth. Similarly, a higher temperature
(around 30 ◦C) is beneficial to crops growth. Because of the temperature
responsiveness, the hydrogels exhibited higher fertilizer release rates at
the higher temperature (Fig. 8c and d), which also ensured sufficient
nutrients for crops to sustain their growth. Overall, the MC-10%
hydrogels presented the greatest slow-release performance under a
range of conditions, and this was attributed to the fact that the MC-10%
hydrogels possessed an abundant microporous structure and a tortuous
diffusion path provided by MOF MIL-100(Fe) in the network, which
inhibited the diffusion of urea, and improved its slow-release. To
examine the release of urea in soil samples (Fig. S9), the cumulative
release rates of MC-0% and MC-10% were determined, i.e., 49.74 and
40.84% on day 30, respectively, which indicated that MC-10% exhibited
a better sustained release performance. Moreover, the measured nitro-
gen contents in the soil samples also confirmed the better slow-release
capacities of the MC-10% hydrogels (Fig. S10).
The data displayed in Table 1 revealed the mechanisms involved in
Fig. 7. a Water-retention behaviors of different hydrogels in distilled water at
55 ◦C. b Water-retention behaviors of (1) soil only, (2) soil mixed with 0.5 g
MC-0%, (3) soil mixed with 1.0 g MC-0%, (4) soil mixed with 0.5 g MC-10%
and (5) soil mixed with 1.0 g MC-10%.
Fig. 8. The urea release curves of different hydrogels in pH = 3 a and pH = 11
b solution and in solution at 25 ◦C c and 45 ◦C d.
X. Lin et al.
International Journal of Biological Macromolecules 191 (2021) 483–491
489
the above release behaviors. According to the linear correlation coeffi-
cient (R2), the Higuchi model showed a good fit to the release data. In
addition, based on the Korsmeyer-Peppas model and the calculated n
values, as described above, the release mechanisms of the MC-0% and
MC-10% hydrogels were determined to be non-Fickian and skeleton
dissolution, respectively.
3.5. Practical applications
To explore the effect of the MC-10% hydrogel on the seed germina-
tion rates and nitrogen nutrition statuses of plants, wheat was used as a
model crop to study the growth status under different fertilization
methods. Thus, Fig. 9a showed the growth of wheat treated with
different fertilization methods, from which it can be seen that the
samples treated with the MC-10% and MC-0% hydrogels were signifi-
cantly healthier than those treated with either no urea or free urea. In
particular, the sample treated with the MC-10% hydrogel was more
luxuriant than that treated with the MC-0% hydrogel. These results
confirmed that the MC-10% hydrogel exhibited pleasuring water and
fertilizer retention properties, and that its 3D structure and porous MIL-
100(Fe) component were beneficial to the growth of crops. Finally, we
calculated the release percent of urea and its exhaustion of MC-10%
hydrogels by measuring the remaining N content. During the whole
process of wheat growth, the overall release percent of urea and its
amount of exhaustion was 80%.
As previously reported, the amide structure, which is the main
chemical structure of nitrogen in plants, can be divided into amide I and
amide II groups [47]. The spectral region of amide II is in the range of
1500–1600 cm− 1, and the signals in this region correspond to the C–N
stretching vibrations and the N–H bending vibrations. The spectral
region of amide I is 1600–1700 cm− 1, and the signals in this region
correspond to the C––O stretching vibration of the peptide bond. Thus,
the nitrogen content of wheat can be assessed by examination of the
Table 1
Corresponding release kinetic parameters obtained from different models.
Sample Zero-order First-order Higuchi Korsmeyer-Peppas
R2 k0 R2 k1 R2 kH R2 k n
MC-0% 0.810 1.540 0.873 − 0.0220 0.958 9.781 0.927 6.658 0.652
MC-10% 0.819 1.373 0.867 − 0.0183 0.953 8.660 0.882 3.568 0.823
Fig. 9. a Growth status of wheat treated with different fertilization methods: (I)
MC-10%, (II) MC-0%, (III) Free-urea, (IV) No-urea. Deconvolution fitting curves
of wheat leaves treated with different fertilization methods: b MC-10%, c MC-
0%, d Free-urea, e No-urea.
Table 2
Various parameters of different materials reported in the relevant studies.
Literatures Materials Stimulus response Swelling
capacity
(g/g)
Fertilizer slow-
release
in soil
Water-
retention
in soil
Model crops
This study Cellulose
/MOFs/DMAA
pH and temperature
response
37.0
(3 d)
40.84%
(30 d)
22.78%
(30 d)
Wheat
Reference [4] CMC/Acrylamide
/Acrylic acid /HNTs
No 110.2
(12 d)
98.7%
(6 d)
30.6%
(6 d)
No
Reference
[23]
Methylcellulose /Hydroxypropyl
methylcellulose
/K2SO4
pH and temperature
response
~20.0
(8 h)
47.5%
(500 min)
31.3%
(30 d)
Chinese
cabbage
Reference
[24]
N, N-dimethyl-aminoethyl methacrylate
/Dopamine
pH and temperature
response
No 54. 13%
(30 d)
No No
Reference
[31]
SA/Acrylamide/
Acrylic acid/HNTs
No 107.9
(3 d)
79.5%
(4 d)
14.4%
(10 d)
No
Reference
[42]
Starch/HNTs No 71.90
(70 h)
97%
(5 d)
21.6%
(6 d)
No
Reference
[49]
Cellulose-g-poly (acrylic acid-co-
acrylamide)
No 420.0
(70 h)
~100%
(10 d)
7.2%
(25 d)
No
Reference
[50]
Collagen/Acrylic acid /Maleic anhydride No 2208 70%
(30 d)
No No
Reference
[51]
Attapulgite clay/
CMC/HEC
No 76
(1 h)
95%
(20 d)
15.5%
(28 d)
No
Reference
[52]
Cellulose/SA/
MOFs/DMAA
pH response 100
(pH = 11)
50%
(30 d)
~0
(30 d)
Wheat
X. Lin et al.
International Journal of Biological Macromolecules 191 (2021) 483–491
490
absorption bands belonging to amide I and amide II. Relative study has
reported that the intensity ratio of amide II to amide I can well reflect the
total N of the leaves [48]. Photoacoustic spectroscopy was then used to
investigate the absorption intensities of thesesignals in the crop leaves,
and their corresponding ratios were calculated (Fig. 9b–e). As shown,
the amide II/amide I ratio of the sample treated with the MC-10%
hydrogel (0.72) was clearly the highest among the various samples,
which was consistent with the wheat growth results discussed above.
The germination rate, tiller number, photosynthetic rate, and chlo-
rophyll content of wheat were also tested for each sample, as outlined in
Table S5. Compared with other groups, all values for the above prop-
erties were higher for the wheat treated with the MC-10% hydrogel,
again indicating that the MC-10% hydrogel was beneficial in terms of
continuously providing fertilizer and water to seeds, as well as pro-
moting the growth of crops. In addition, the comparison of various pa-
rameters between this study and the relevant literature studies has been
supplied as Table 2. Although the swelling capacity in this work was
inferior, the water-retention and fertilizer slow-release performance of
this study both performed well, especially the slow-release of fertilizer,
which was also the reason for the use of MOFs. The fertilizers slow-
release performance in soil of this study (40.84%) was better than that
reported in other literature. Besides, the water-retention in soil of this
study was also a level in the forefront (22.78%).
4. Conclusion
In summary, we developed a kind of hydrogel to enhance the utili-
zation rate of fertilizers and water by integrating MOF MIL-100(Fe) and
cellulose-based hydrogels with temperature- and pH-responsiveness.
Owing to the microporous structure of MOF MIL-100(Fe), the pre-
pared MC-10% hydrogels exhibited higher water-retention and better
urea slow-release performance. The water-retention increased from
60.28% (MC-0%) to 77.53% (MC-10%) in deionized water after 12 h,
and the cumulative release rates of MC-10% hydrogels reached to
40.84% in soil on day 30. Also, NVCL and CNFs provided temperature-
and pH-sensitivities for regulating urea release. For the wheat sample
treated with the MC-10% hydrogel, germination rate, tiller number,
photosynthetic rate, and chlorophyll content were significantly
increased.
Declaration of competing interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Acknowledgments
We gratefully acknowledge the Fundamental Research Funds of CAF
(CAFYBB2020QC003) and the Opening Project of Guangxi Key Labo-
ratory of Forest Products Chemistry and Engineering (GXFK2008) for
financial support of this research.
Appendix A. Supplementary data
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.ijbiomac.2021.09.075.
References
[1] C.O. Dimkpa, J. Fugice, U. Singh, T.D. Lewis, Development of fertilizers for
enhanced nitrogen use efficiency - trends and perspectives, Sci. Total Environ. 731
(2020), 139113.
[2] M.Y. Naz, S.A. Sulaiman, Slow release coating remedy for nitrogen loss from
conventional urea: a review, J. Control. Release 225 (2016) 109–120.
[3] S. Fertahi, M. Ilsouk, Y. Zeroual, A. Oukarroum, A. Barakat, Recent trends in
organic coating based on biopolymers and biomass for controlled and slow release
fertilizers, J. Control. Release 330 (2021) 341–361.
[4] Y. Shen, H. Wang, Z. Liu, W. Li, Y. Liu, J. Li, H. Wei, H. Han, Fabrication of a water-
retaining, slow-release fertilizer based on nanocomposite double-network
hydrogels via ion-crosslinking and free radical polymerization, J. Ind. Eng. Chem.
93 (2021) 375–382.
[5] A. Di Martino, Y.A. Khan, S. Durpekova, V. Sedlarik, O. Elich, J. Cechmankova,
Ecofriendly renewable hydrogels based on whey protein and for slow release of
fertilizers and soil conditioning, J. Clean. Prod. 285 (2021), 124848.
[6] X. Liu, Y. Li, Y. Meng, J. Lu, Y. Cheng, Y. Tao, H. Wang, Pulping black liquor-based
polymer hydrogel as water retention material and slow-release fertilizer, Ind. Crop.
Prod. 165 (2021), 113445.
[7] S. Liu, Q. Wu, X. Sun, Y. Yue, B. Tubana, R. Yang, H.N. Cheng, Novel alginate-
cellulose nanofiber-poly(vinyl alcohol) hydrogels for carrying and delivering
nitrogen, phosphorus and potassium chemicals, Int. J. Biol. Macromol. 172 (2021)
330–340.
[8] H. Li, M. Eddaoudi, M. O'Keeffe, O.M. Yaghi, Design and synthesis of an
exceptionally stable and highly porous metal-organic framework, Nature 402
(6759) (1999) 276–279.
[9] L.N. Rosi, Hydrogen storage in microporous metal-organic frameworks, Science
300 (5622) (2003) 1127–1129.
[10] D. Desantis, J.A. Mason, B.D. James, C. Houchins, J.R. Long, M. Veenstra, Techno-
economic analysis of metal-organic frameworks for hydrogen and natural gas
storage, Energy Fuel 31 (2) (2017) 2024–2032.
[11] P. Horcajada, S. Surble, C. Serre, D.Y. Hong, Y.K. Seo, J.S. Chang, J.M. Greneche,
I. Margiolaki, G. Ferey, Synthesis and catalytic properties of MOF MIL-100(Fe), an
iron(III) carboxylate with large pores, Chem. Commun. (Camb.) (27) (2007)
2820–2822.
[12] A.U. Czaja, N. Trukhan, U. Muller, Industrial applications of metal-organic
frameworks, Chem. Soc. Rev. 38 (5) (2009) 1284–1293.
[13] J. Nie, H. Xie, M. Zhang, J. Liang, S. Nie, W. Han, Effective and facile fabrication of
MOFs/cellulose composite paper for air hazards removal by virtue of in situ
synthesis of MOFs/chitosan hydrogel, Carbohydr. Polym. 250 (2020), 116955.
[14] H. Lima, C. Silva, V.L. Kupfer, J. Rinaldi, A.W. Rinaldi, Synthesis of resilient hybrid
hydrogels using UiO-66 MOFs and alginate (hydroMOFs) and their effect on
mechanical and matter transport properties, Carbohydr. Polym. 251 (2020),
116977.
[15] Y. Cui, B. Chen, G. Qian, Lanthanide metal-organic frameworks for luminescent
sensing and light-emitting applications, Coord. Chem. Rev. 273–274 (2014) 76–86.
[16] L. Wang, H. Xu, J. Gao, J. Yao, Q. Zhang, Recent progress in metal-organic
frameworks-based hydrogels and aerogels and their applications, Coord. Chem.
Rev. 398 (2019), 213016.
[17] P.H. Corkhill, C.J. Hamilton, B.J. Tighe, Synthetic hydrogels VI Hydrogel
composites as wound dressings and implant materials, Biomaterials 10 (1) (1989)
3–10.
[18] X. Li, Q. Li, X. Xu, Y. Su, Q. Yue, B. Gao, Characterization, swelling and slow-
release properties of a new controlled release fertilizer based on wheat straw
cellulose hydrogel, J. Taiwan Inst. Chem. Eng. 60 (2016) 564–572.
[19] L. Sun, Z. Mo, Q. Li, D. Zheng, X. Qiu, X. Pan, Facile synthesis and performance of
pH/temperature dual-response hydrogel containing lignin-based carbon dots, Int.
J. Biol. Macromol. 175 (2021) 516–525.
[20] N. Jommanee, C. Chanthad, K. Manokruang, Preparation of injectable hydrogels
from temperature and pH responsive grafted chitosan with tuned gelation
temperature suitable for tumor acidic environment, Carbohydr. Polym. 198 (2018)
486–494.
[21] R. Yoshida, Y. Kaneko, K. Sakai, A. Kikuchi, Y. Sakurai, T. Okano, K. Uchida, Comb-
type grafted hydrogels with rapid deswelling response to temperature changes,
Nature 374 (6519) (1995) 240–242.
[22] T. Li, S. Lu, J. Yan, X. Bai, C. Gao, M. Liu, An environment-friendly fertilizer
prepared by layer-by-layer self-assembly for pH-responsive nutrient release, ACS
Appl. Mater. Interfaces 11 (11) (2019) 10941–10950.
[23] Y.C. Chen, Y.H. Chen, Thermo and pH-responsive methylcellulose and
hydroxypropyl methylcellulose hydrogels containing K2SO4 for water retention
and a controlled-release water-soluble fertilizer, Sci. Total Environ. 655 (2019)
958–967.
[24] C. Feng, S. Lü, C. Gao, X. Wang, X. Xu, X. Bai, N. Gao, M. Liu, L. Wu, “Smart”
fertilizer with temperature- and pH-responsive behavior via surface-initiated
polymerization for controlled release of nutrients, ACS Sustain. Chem. Eng. 3 (12)
(2015) 3157–3166.
[25] H. Du, W. Liu, M. Zhang, C. Si, X. Zhang, B. Li, Cellulose nanocrystals and cellulose
nanofibrils based hydrogels for biomedical applications,Carbohydr. Polym. 209
(2019) 130–144.
[26] B. Wang, Q. Peng, Y. Yan, Y. Ding, Z. Wang, Biomimetic, strong, and tough
hydrogels by integrating cellulose nanocrystals into polymer networks, Ind. Crop.
Prod. 158 (2020), 112973.
[27] S. Mishra, N. Thombare, M. Ali, S. Swami, Applications of biopolymeric gels in
agricultural sector, Polym. Gels (2018) 185–228.
[28] W. Lan, M. Liu, Preparation and properties of chitosan-coated NPK compound
fertilizer with controlled-release and water-retention, Carbohydr. Polym. 72 (2)
(2008) 240–247.
[29] Z. Mohammadbagheri, A. Rahmati, P. Hoshyarmanesh, Synthesis of a novel
superabsorbent with slow-release urea fertilizer using modified cellulose as a
grafting agent and flexible copolymer, Int. J. Biol. Macromol. 182 (2021)
1893–1905.
X. Lin et al.
https://doi.org/10.1016/j.ijbiomac.2021.09.075
https://doi.org/10.1016/j.ijbiomac.2021.09.075
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951273535
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951273535
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951273535
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951281128
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951281128
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951291283
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951291283
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951291283
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951300515
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951300515
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951300515
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951300515
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951308533
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951308533
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951308533
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947175107
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947175107
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947175107
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951320509
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951320509
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951320509
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951320509
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951330196
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951330196
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951330196
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947182488
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947182488
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951338168
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951338168
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951338168
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947470316
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947470316
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947470316
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947470316
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951344888
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951344888
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951363631
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951363631
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951363631
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947523213
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947523213
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947523213
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201947523213
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201948072698
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201948072698
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951371192
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951371192
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951371192
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950299341
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950299341
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950299341
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951379762
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951379762
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951379762
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951388634
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951388634
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951388634
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951400576
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951400576
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951400576
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951400576
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950317658
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950317658
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950317658
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951410932
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951410932
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951410932
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951418325
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951418325
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951418325
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951418325
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951428033
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951428033
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951428033
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951428033
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951438309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951438309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951438309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950333228
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950333228
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950333228
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950468275
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950468275
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950486175
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950486175
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950486175
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951456121
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951456121
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951456121
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951456121
International Journal of Biological Macromolecules 191 (2021) 483–491
491
[30] Y. Wang, M. Sun, D. Qiao, J. Li, Y. Wang, W. Liu, C. Bunt, H. Liu, J. Liu, X. Yang,
Graft copolymer of sodium carboxymethyl cellulose and polyether polyol (CMC-g-
TMN-450) improves the crosslinking degree of polyurethane for coated fertilizers
with enhanced controlled release characteristics, Carbohydr. Polym. 272 (2021),
118483.
[31] Y. Shen, H. Wang, W. Li, Z. Liu, Y. Liu, H. Wei, J. Li, Synthesis and characterization
of double-network hydrogels based on sodium alginate and halloysite for slow
release fertilizers, Int.J. Biol. Macromol. 164 (2020) 557–565.
[32] M. Bhattacharya, M.M. Malinen, P. Lauren, Y.R. Lou, S.W. Kuisma, L. Kanninen,
M. Lille, A.C. Orlu, C. Guguen-Guillouzo, O. Ikkala, Nanofibrillar cellulose
hydrogel promotes three-dimensional liver cell culture, J. Control. Release 164 (3)
(2012) 291–298.
[33] D. Klemm, B. Heublein, H.P. Fink, A. Bohn, Cellulose: fascinating biopolymer and
sustainable raw material, Angew. Chem. Int. Ed. 44 (22) (2005) 3358–3393.
[34] X.M. Cai, Y. Lin, X. Chen, X. Chen, F. Wang, Linker regulation: synthesis and
electrochemical properties of ferrocene-decorated cellulose, J. Inorg. Organomet.
Polym. Mater. 30 (9) (2020) 3771–3780.
[35] X.M. Cai, X. Chen, X. Chen, Y. Li, F. Wang, A luminescent cellulose ether with a
regenerated crystal form obtained in tetra(n-butyl)ammonium hydroxide/dimethyl
sulfoxide, Carbohydr. Polym. 230 (2020), 115649.
[36] J. Wei, Y. Chen, H. Liu, C. Du, H. Yu, J. Ru, Z. Zhou, Effect of surface charge
content in the TEMPO-oxidized cellulose nanofibers on morphologies and
properties of poly( N -isopropylacrylamide)-based composite hydrogels, Ind. Crop.
Prod. 92 (2016) 227–235.
[37] T.H.M. Nguyen, C. Abueva, H.V. Ho, S.-Y. Lee, B.-T. Lee, In vitro and in vivo acute
response towards injectable thermosensitive chitosan/TEMPO-oxidized cellulose
nanofiber hydrogel, Carbohydr. Polym. 180 (2018) 246–255.
[38] S. Durkut, Y.M. Elçin, Synthesis and characterization of thermosensitive poly(N-
vinyl caprolactam)-grafted-aminated alginate hydrogels, Macromol. Chem. Phys.
221 (2) (2020) 1900412.
[39] A. Mignon, G.J. Graulus, D. Snoeck, J. Martins, N.D. Belie, P. Dubruel, S.
V. Vlierberghe, pH-sensitive superabsorbent polymers: a potential candidate
material for self-healing concrete, J. Mater. Sci. 50 (2) (2015) 970–979.
[40] C. Wu, Y. Dan, D. Tian, Y. Zheng, S. Wei, D. Xiang, Facile fabrication of MOF(Fe)
@alginate aerogel and its application for a high-performance slow-release N-
fertilizer, Int. J. Biol. Macromol. 145 (2020) 1073–1079.
[41] Hans Schott, Swelling kinetics of polymers, J. Macromol. Sci. Part B Phys. 31 (1)
(1992) 1–9.
[42] H. Wei, H. Wang, H. Chu, J. Li, Preparation and characterization of slow-release
and water-retention fertilizer based on starch and halloysite, Int. J. Biol. Macromol.
133 (2019) 1210–1218.
[43] C.G.D. Kruif, S.G. Anema, C. Zhu, P. Havea, C. Coker, Water holding capacity and
swelling of casein hydrogels, Food Hydrocoll. 44 (2015) 372–379.
[44] H. Feil, Y.H. Bae, J. Feijen, S.W. Kim, Effect of comonomer hydrophilicity and
ionization on the lower critical solution temperature of N-isopropylacrylamide
copolymers, Macromolecules 26 (10) (1993) 2496–2500.
[45] X. Yang, Z. Li, H. Liu, L. Ma, X. Huang, Z. Cai, X. Xu, S. Shang, Z. Song, Cellulose-
based polymeric emulsifier stabilized poly(N-vinylcaprolactam) hydrogel with
temperature and pH responsiveness, Int. J. Biol. Macromol. 143 (2020) 190–199.
[46] N. Masruchin, B.-D. Park, V. Causin, Dual-responsive composite hydrogels based on
TEMPO-oxidized cellulose nanofibril and poly(N-isopropylacrylamide) for model
drug release, Cellulose 25 (1) (2017) 485–502.
[47] S. Sharma, A.K. Singh, M.K. Tiwari, K.N. Uttam, Prompt screening of the
alterations in biochemical and mineral profile of wheat plants treated with
chromium using attenuated total reflectance fourier transform infrared
spectroscopy and X-ray fluorescence excited by synchrotron radiation, Anal. Lett.
53 (3) (2020) 482–508.
[48] K. Wu, C. Du, F. Ma, Y. Shen, D. Liang, J. Zhou, Rapid diagnosis of nitrogen status
in rice based on fourier transform infrared photoacoustic spectroscopy (FTIR-PAS),
Plant Methods 15 (1) (2019) 94.
[49] Y. Zhang, X. Liang, X. Yang, H. Liu, J. Yao, An eco-friendly slow-release urea
fertilizer based on waste mulberry branches for potential agriculture and
horticulture applications, ACS Sustain. Chem. Eng. 2 (7) (2014) 1871–1878.
[50] Z.-Y. Hu, G. Chen, S.-H. Yi, Y. Wang, Q. Liu, R. Wang, Multifunctional porous
hydrogel with nutrient controlled-release and excellent biodegradation, J. Environ.
Chem. Eng. 9 (5) (2021), 106146.
[51] B. Ni, M. Liu, S. Lü, L. Xie, Y. Wang, Environmentally friendly slow-release nitrogen
fertilizer, J. Agric. Food Chem. 59 (18) (2011) 10169–10175.
[52] Y. Wang, H. Shaghaleh, Y.A. Hamoud, S. Zhang, P. Li, X. Xu, H. Liu, Synthesis of a
pH-responsive nano-cellulose/sodium alginate/MOFs hydrogel and its application
in the regulation of water and N-fertilizer, Int. J. Biol. Macromol. 187 (2021)
262–271.
X. Lin et al.
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951467377
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951467377
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951467377
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951467377
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951467377
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951479538
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951479538
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951479538
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951087653
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951087653
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951087653
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951087653
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951493148
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951493148
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950494309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950494309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950494309
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951517665
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951517665
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951517665
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950505995
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950505995
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950505995
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950505995
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951521305
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951521305
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951521305
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951536016
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951536016
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951536016
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950514730
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950514730
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950514730
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951540516
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951540516
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951540516
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952123670
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952123670
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952135179
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952135179
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952135179
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951227968
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201951227968
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952145106
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952145106
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952145106http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952154139
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952154139
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952154139
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950524729
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950524729
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201950524729
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952158038
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952158038
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952158038
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952158038
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952158038
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952167677
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952167677
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952167677
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952173942
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952173942
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952173942
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952284984
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952284984
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952284984
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952293242
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952293242
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952303466
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952303466
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952303466
http://refhub.elsevier.com/S0141-8130(21)01996-6/rf202109201952303466
	A TEMPO-oxidized cellulose nanofibers/MOFs hydrogel with temperature and pH responsiveness for fertilizers slow-release
	1 Introduction
	2 Materials and methods
	2.1 Materials
	2.2 Synthesis of the TEMPO-oxidized cellulose nanofibers (CNFs)
	2.3 Synthesis of MOF MIL-100(Fe)
	2.4 Synthesis of the MC hydrogels
	2.5 Material characterization
	2.6 Swelling behavior
	2.7 Temperature and pH responsiveness
	2.8 Water-retention behavior
	2.9 Slow-release behavior
	2.10 Application in growth of crops
	3 Results and discussion
	3.1 Characterization of the CNFs, MOF MIL-100(Fe), and the MC hydrogels
	3.2 Swelling behavior and the swelling dynamic mechanism at room temperature
	3.3 Temperature- and pH-responsive behaviors
	3.4 Urea release behaviors of the MC hydrogels
	3.5 Practical applications
	4 Conclusion
	Declaration of competing interest
	Acknowledgments
	Appendix A Supplementary data
	References
