One of the most delicate responsibilities of pilots occurs during berthing and unberthing operations.
Carefully berthing a ship, often after a long pilotage mission, is almost a work of art. Of critical assistance
in this task is the support of tugs and their skippers. Today, this is probably true more than ever, as
ships become ever larger, e.g., ultra large container vessels with their huge windage, while often being
significantly less powerful or able to manoeuvre themselves in confined waters. These vessels may have
proportionately smaller rudders coupled with engines that, often deliver less power, notably as a result of
software-managed fuel consumption.
Furthermore, margins in ports and fairways are often small and a continuing occurrence of ship engine
problems in port and port approaches can be noted. There is also an increased need for escort, such as for
LNG carriers, bulk carriers and sometimes large container vessels. This all means that both masters and
pilots greatly rely on the presence of powerful, manoeuvrable tugs aptly handled by skilful skippers.
In addition, tugs are becoming more and more powerful and also more complicated. A small mistake can
havea nautical dashboard
for the tug master and a technical dashboard for the chief
engineer. Information is displayed on the bridge, main deck
and switchboard locations to ensure safety and efficiency of
operations. The screens – with day and night view – are clear,
supporting the tug master and chief engineer by showing
only what is needed during operations, whilst allowing
operators to select more detailed data when desired.
The nautical dashboard shows relevant information for
the navigation of the tug, such as heading and speed, echo
sounding, fuel consumption and thruster and engine data.
The in-house developed Electronic Stability Protection
system assists the tug master in assessing the tug’s
limitations. This measures the tug’s performance against its
capabilities and signal to the tug master when he approaches
a critical limit. See also in paragraph 9.6.2 Stability. For
more information see References for `Human Machine
Interface for Tugs’.
Raymarine DockSense Alert
Using advanced stereo vision camera technology, DockSense
Alert detects objects above the waterline and creates an
intuitive map of potential hazards around the tug. Live video
feeds enhance the tug master’s view while audible and visible
alerts inform the captain when an object is close to the vessel.
DockSense Alert also offers helpful notifications tuned to the
captain’s preferred proximity alert distance. DockSense Alert
uses several cameras and DockSense heading sensors.
14 Tug Use in Port
Moulded modular or block fender systems offer many of the
advantages of extruded fenders and, in addition, allow for
secure attachment and ease of repair since with this type
individual blocks can be replaced.
A tug’s bow and/or stern can be equipped with horizontal
fendering, for instance extruded fenders of cylindrical
profile, or with vertical block fendering. A combination of
these types is often used. Block fenders can easily be replaced
when damaged, and for fenders on bow and stern which
are intensively used, basic vertical block fendering is very
suitable.
The main type of tug fenders are:
•	 Cylindrical tug fenders.
•	 D-shaped fenders.
•	 Block fenders.
•	 M-shaped fenders.
•	 W-shaped fenders.
Cylindric fenders form the main fendering installed on
a tug’s stern and bow. These fenders are used for pushing
against ship hulls of all types and in all sea conditions.
D-shaped fenders are similar to cylindric fenders, but with
one flat surface. They can be used on the main deck sheer
lines, on the forecastle deck and stern of tugs to provide
protection.
Block fenders can have better grip than cylindric fenders
because of their shape and grooved surfaces. They have large
contact surfaces that reduce contact pressure per m2 between
ship and tug, which makes them more suitable than other
fender types for heavy-duty applications in wave and swell
conditions.
M-shaped fenders are usually fitted to the bow and aft
section of tugs to protect the tug and ship from damage
during operations. They have a low weight and a large flexible
surface area that reduces the forces per m2 on the attended
ship during pushing operations. M-shaped fenders can be
fitted around tight curves and provide additional grip due
to their grooved surface. They are suitable for heavy duty
operations.
Fenders are constructed of rubber or synthetic rubber
products. Beyond the mechanical requirements of load
versus deflection and energy absorption, which is given
in curves, attachment methods and structural limits,
consideration should also be given to the material used in
the fender. The material used should have good resistance
to polluted water, ozone, UV radiation and high and low
temperatures.
The following factors are of importance in the choice of a
tug’s bow and/or stern fendering:
•	 The way the tug is assisting vessels, for instance towing
on a line or push-pull, and whether the tug will push by
the stern and/or by the bow.
•	 The size and engine power of the tug which are
important factors for the horizontal load and kinetic
energy transmitted during contact and pushing.
•	 Size of contact area.
•	 The type and size of vessels to be handled eg ships with
large bow flare and/or overhanging stern. Tugs pushing
near the bow or stern of these ships may need extra
fendering on top of the bow to prevent damage to tug or
ship.
•	 The environmental conditions such as waves and swell.
These conditions will give rise to additional forces in the
fendering, for which it must be able to compensate.
•	 The tug’s bow and stern construction.
Additional fendering might be needed for tugs handling
submarines and aircraft carriers, such as:
•	 Underwater fendering.
•	 Fendering at the outside and top of wheelhouse.
Tug fendering varies enormously. One frequently used fender
system is the extruded profile type. Extruded fenders are
produced in different lengths and in a wide variety of profiles
and sizes. They can have a hollow D-shape profile, can be
rectangular, cylindrical or solid, can be precurved to fit the
tug bow or stern, be chamfered or drilled. Extruded fenders
are very flexible from the point of view of design. Extrusion
is a manufacturing method whereby uncured rubber is
forced through a die to produce the required profile and then
the lengths of formed rubber are vulcanised.
Figure 2A5: Tug with cylindrical bow fenders. Large cylindrical fenders
are usually used to push against flared hulls and in open sea conditions.
Their round shape is ideal for working with large bow flares of eg
container vessels. Cylindrical fenders are often used on the bow in
combination with M or W fenders. Photo: Trelleborg Marine Systems
Figure 2A6: Tyres are often used in combination with fenders.
Photo: Piet Sinke
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 15
Bow fenders should have a large contact area and radius to
reduce the pressure on the ship’s hull. The same applies to
the stern fenders of tractor-tugs since these tugs are pushing
with their stern. Tyres are often used in addition to bow and
stern fenders to protect the fenders and enlarge the contact
area and are often used along tug sides since they can easily
be replaced when damaged.
However, tyres are basically not designed as fender and a
suitable way of mounting is problematic.
The following is an indication of some permissible hull
pressures, which vary by ship’s type and size:
General cargo ships of
20,000 dwt and less 400-700kN/m2
Oil tankers of more than
60,000 dwttyres which are cut to a specific size and
compressed on to steel supporting rods. This fender type,
made in the USA, is suitable for bow fenders, stern fenders
and side fenders. There is one specific type which has a large
absorption ability and is very soft, thus having a large contact
area and ‘sticking ability’ when under load.
Tugs may also be fitted with foam-filled or pneumatic
fenders, especially when working in exposed areas.
Sometimes ‘non-marking’ fenders are required, for instance
when ships with white or grey hulls have to be handled, such
as cruise or navy vessels. In that case manila rope fenders
or tarpaulins, in addition to the standard tug fendering,
may be used or the tugs may be equipped with grey rubber
fendering.
A new type of fender material is coming on the market.
Fendercare offers fenders that are manufactured with
polymer products. Note: The name polymer is probably
too general a term as it does cover a multitude of different
materials, including natural and synthetic rubber.
The materials from which the fenders are made are from a
specially formulated polyurethane which has been developed
by Polymarine in Holland  and proven  to outperform the
generic polyurethanes  in that they are lighter and stronger.
Trials have proven that this specific  product is more resilient
and protects vessels better than either rubber copolymers
or standard polyurethane and in terms of through life
cost presents a significant advantage. The fenders are more
resistant to chemicals and ultra-violet light. The fenders have
a high elasticity and will not mark ship’s hulls.
Figure 2A7: Crew preparing a tarpaulin around the fenders
so preventing the light coloured hull of the ship to be assisted
get marked by the tug fenders. Photo: Piet Sinke
Figure 2A8: All type of fenders can be found. Photo: Ole Peter Dahl
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
16 Tug Use in Port
2.2.5 Specific requirements for tugs operating
in hazardous areas
Tugs that have to handle gas carriers and are operating close
to LNG/LPG terminals are subject to additional and specific
safety requirements.
Specific requirements apply also to tugs operating in ice
conditions.
The requirements for these tugs will be addressed later in this
chapter when dealing with these tugs.
2.2.6 Environmentally friendly tugs
The need for more environmentally friendly tugs can
found in many ports. These tugs are called eco tugs, E-tugs
or hybrids. Different systems exist to achieve this. More
information about this subject can be found in paragraph 2.
22.
From a tug and ship handling point of view two aspects
are most important, that is the ease of handling of such
system. Changing to full power should be simple so that
in stress situation, when full power is immediately needed,
no mistakes will be made. Secondly, if full power is indeed
needed it should be possible to have it available without any
delay.
The various tug types will now be discussed.
steel is approximately 0.8. The friction force F = c x P, where
P is the impact force of the tug and c the friction coefficient.
UHMW polyethylene has a friction coefficient of 0.15.
Specific types of fenders can be provided with water
lubrication to reduce the friction between tug and ship
and so prevent damage and wear, especially when pushing
against a slab-sided ship in swell conditions.
The height of a tug’s fendering above water level is a factor to
be considered. When pushing under an angle at a ship’s side
while the ship has headway or sternway, the hydrodynamic
forces on the tug create a list. It is evident that the higher the
bow fender above the water the larger the resulting heeling
moment will be.
As mentioned already, harbour tugs assisting submarines
may also have underwater fendering to avoid contact
damage to the submarine’s hull. In addition, an ASD or
reverse-tractor tug’s hull may be expanded with fendered
steel sponsons on the quarters to ensure that the nozzles
of the tug’s azimuth propellers never come in contact with
the submarine being assisted, the so-called ‘propulsion unit
protective sponsons’.
Suitable and reliable towing equipment is also important
for good harbour tug performance and safe working. This is
dealt with in Chapter 7.
Types of Harbour Tug 17
where tugs are used for towing on a line, conventional tugs
can be found with a more forward lying towing point.
Some new innovative small tugs are coming on the market,
such as the Smart tug (Super Silent Smart tug) built by
Uzmar Shipyards, Turkey and the Container tug.
2.3.1 General
Conventional tugs can be seen all over the world and are still
built but in decreasing numbers. Conventional tugs are used
for push-pull assistance, alongside towing and in particular
in European ports for towing on a line.
Th ere is a large variety of conventional tugs. Th e most
simple one is a single screw tug with a single plate rudder.
Mainly due to the location of the towing point, the tugs
have limitations regarding performance and safety. When
towing on a line the main risk is of girting. A towing winch
with a quick release mechanism and a quick release towing
hook lower this risk, providing they work under the extreme
condition of girting, which is not always the case. Th e astern
power of conventional tugs is generally low. When making
fast near the bow of a ship, interaction forces between the
ship and the tug should be allowed for, which can better
be done with tugs that can produce good side thrust, such
as tractor-tugs. Girting and interaction are dealt with in
Chapters 4 and 6.
Th e towing point of these tugs generally lies about 0.45 x
LWL from aft , although shorter distances may be found. Th e
aft towing point on American conventional tugs lies further
aft , which allows the opportunity to extend the deckhouse
further aft . A more aft placed towing point limits the tug’s
eff ectiveness when towing on a line at speed but this way
of towing is not normal practice in the USA. In USA ports
Figure 2B.1: Conventional twin screw tug Stan tug 3011.LOA 30.66m, beam 11.13m, BP 70 tons. Damen Shipyards, The Netherlands
Figure 2B.2: Container Tug which can be transported in a container.
Photo: DutchWorkBoats
2.3 Conventional types of tug
Chapter 2
PART B
Basic tug types
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
18 Tug Use in Port
the wheelhouse. It has the great advantage that it can deliver
any propeller shaft speed ahead and astern without delay.
In the past initial costs of diesel-electric propulsion
were rather high, however in recent years the differences
have become small particularly due to the lower costs of
generators and frequency drives as a result of larger mass
productions.

Operational costs depend strongly on the way of
employment. In case of one constant diesel engine load
(typically 85 per cent of MCR) as in cargo liners, diesel
direct propulsion has the highest efficiency and the lowest
operational cost, however in case of varying power loads,
as is the case with tugs, the efficiency of diesel-electric
propulsion increases and operational costs are reduced.
The larger the variations in loads, the larger the advantages
of diesel-electric propulsion. In case of varying loads, the
environmental performance of a diesel-electric system is
clearly superior to normal diesel engines. Diesel-electric
engines are subject to more wear and tear due to the constant
high engine revolutions.
Other important points are maintenance and downtime. A
diesel-electric tug has more redundancy and maintenance
can be carried out quicker; for instance changing one or
more generators can be carried out rather quickly.
Diesel-electric propulsion has additional advantages in tug
use:
1. Power is faster availablesince generators are already
running at full speed in contrast to diesel engines
which need to speed up. Especially important in critical
situations where every second counts!
2. Power can be controlled from zero upward and reverse,
offering smooth and convenient manoeuvring without
constant clutch operations and instantly reversing.
Most common nowadays on harbour tugs are high and
medium speed diesel engines with reduction gears and
pneumatic-hydraulic couplings. (See References for
‘Operational benefits of high-speed electronic diesel
engines’). Other types of couplings can be used. On tugs with
fixed propellers the propeller thrust is reversed by means
of a reverse-reduction gear, while on tugs with controllable
pitch propellers (CPP) thrust is reversed by changing the
propeller pitch. Torque problems may arise when a fixed
pitch propeller is reversed at high tug speeds. These problems
can be reduced or overcome by proper design (= the correct
combination of engine, propeller and gear) and tuning of the
whole propulsion system. Shaft brakes are used, depending
on engine and propeller type.
Engine revolutions and propeller pitch are remotely
controlled from the wheelhouse. Manoeuvring, especially
with a CPP, is very smooth and the tug can accelerate fast.
When the CPP control system is equipped with a combinator
control, propeller revolutions are regulated in accordance
with propeller pitch. The pitch of a CPP is regulated by a
hydraulic system. CPP control systems, including remote
control systems, the hydraulic system and emergency stop,
require regular check-ups and good maintenance. Failure
in the hydraulic or remote control system can cause serious
The Smart tug is a 20.4m long line-handling tug with a
bollard pull of 19 tons. It is a twin screw tug with propellers
in nozzles and triple high efficiency rudder systems. The tug
is designed for a wide range of mooring operations, oil spill
response included.
The container tug is a new design of a very small tug which
can be transported in a 20ft container by road, sea or even
by air. It came on the market in 2016. The tug is 6m long
and fitted with a single fixed pitch open propeller and a
large rudder. It is designed by Ben3D BV Naval Architecture
in The Netherlands. The tug has a large deck space and a
bollard pull of maximum 1.5tons. It has a draft of 1.05m and
a weight of 7.5 tons. It is an all-round mini support vessel
able to push and tow, and can easily be transported wherever
work is to be done.
More ‘mini-tugs’ will be dealt with in Chapter 8.

Experience is an important factor in handling conventional
tugs safely while assisting ships under speed. With a
well qualified captain these tugs can be very effective for
rendering assistance. To increase the tug’s effectiveness and/
or manoeuvring capabilities there are several possibilities, as
explained below.
2.3.2 Propulsion and rudders
Propulsion and propeller control
Nearly all tugs are still equipped with diesel engines
although an occasional old harbour tug with a steam engine
may still be found somewhere outside a maritime museum.
Although it does not yet apply to conventional tugs, more
and more hybrid tugs can be found which can operate diesel-
direct, diesel-electric and on battery packages. Tugs which
use LNG as fuel are also coming on the market.
Note 1: It is good to keep in mind that some items discussed in
this paragraph apply to other tug types as well, as is the case
with propulsion systems, nozzles and bow thrusters.
Note2: The term LNG is somewhat misleading. LNG is a natural
gas kept in liquid condition for storage and transport. Only if
converted to gas – natural gas (NG) – can it be used as fuel.
Diesel engines on harbour tugs are high or medium speed
engines. The high engine revolutions have to be brought
down by reduction gearing to the required propeller
revolutions. To reverse the propeller thrust, different systems
are in use. The direct-reversing system is the oldest and can
still be found on some conventional tugs. The engine has to
be started on ahead and on astern. On some tugs engines can
be controlled from the wheelhouse, while on others it still
has to be done by an engineer. The number of manoeuvres is
limited by the volume of starting air available. The response
time from ahead to astern and back differs by tug and by the
direct-reversing handling system fitted.
Full diesel-electric propulsion systems can be found in some
harbour tugs. The diesel engine(s) drives electric generators
which in turn drive electric motors. These electric motors
drive the propeller. This system is easily controllable from
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 19
Conventional tugs with controllable pitch propellers in
nozzles (nozzle type 37) achieve, when pulling astern, about
45 per cent of maximum ahead bollard pull, while this
figure is about 65 per cent for tugs equipped with fixed pitch
propellers and the same type of nozzles. With a specific
propeller design a much higher value can be reached for
astern performance of controllable pitch propellers, but then
ahead efficiency will be lower.
Note 3: The 19A nozzle, and several variations more or less on
this design, are used for azimuth thrusters, either with fixed
or with controllable pitch propellers, because astern thrust is
achieved by turning the nozzle.
A nozzle seen on several tugs with azimuth propulsion is the
Nautican nozzle, which is the same as the Lips HR (= high
efficiency) nozzle. Ahead efficiency of this nozzle is higher
than of nozzle type 19A and 37, approximately 8-12 per cent
in bollard pull conditions, while astern performance of the
Nautican nozzle is better than of nozzle type 19A, but not
better than of nozzle type 37. As said, astern performance is
not relevant for tugs with azimuth thrusters.
A nozzle often used is the Optima nozzle. It has an
improved forward thrust performance comparable with the
conventional 19A nozzle, combined with the good reverse
thrust performance of the 37 nozzle.
There is a continuous research towards ever better nozzles for
various types of ship, including tugs. One of the latest nozzle
type is Schottel’s VarioDuct SDV45 nozzle, shown in figure
2B.4. Given the same propulsive power, it offers a greater
bollard pull than previous nozzles such as the 19A nozzle
and, at the same time, gives considerably greater efficiency
in the medium and high speed range, if used in combination
with an optimum designed propeller. The small outer
diameter of the nozzle makes it also ideally suited to shallow-
water operations. The new compact nozzle is suitable for
harbour tugs as well.
damage to tug, ships or berths. Modern CPP systems have
reliable backup systems.
Propeller efficiency and manoeuvrability
The propellers of conventional tugs can be fitted in open
frames or fitted in nozzles. Going full astern, an open fixed
pitch propeller will, in general, develop about 60 per cent
of its maximum ahead thrust. An open CPP going astern
develops some 40-45 per cent of maximum ahead thrust. The
lesser efficiency astern of a CPP has to do with the specific
design and working of a CPP. Propellers are designed for
maximum efficiency going ahead. A fixed pitch propeller
will turn, when astern thrust is required, with the same
pitch in the reverse direction as on ahead. The propeller
blades of a standard CPP have a smaller width near the hub
and therefore, when the blades are set for ahead, a larger
forward pitch angle than near the tip of the propeller. When
the blades are turned for astern thrust, the lower part of the
blades will consequently have a smaller pitch than the top
of the blades, which results in less efficiency going astern
compared to a fixed pitch propeller.
Nozzles increase thrust and consequently bollardpull
significantly. Ludwig Kort, an aerodynamicist, designed the
first nozzles as far back as 1927. The first one was introduced
into service in 1932 and was originally designed to protect
canal banks from propeller wash. The effect of a nozzle is
most pronounced with high propeller loads at low speeds.
Harbour tugs have to perform in that way. Nozzles increase
thrust by 15-25 per cent in towing and pushing conditions
and by about 30 per cent at zero speed..
Brief explanation:
The working of a nozzle is mainly twofold:
Around a nozzle an increase of water speed is created, which
causes the nozzle to work like a wing. An inward force is
so created, that has a forward component. The nozzle itself
therefore has a positive forward thrust.
In the nozzle the inflow water velocity is increased leading to
a lower loaded propeller, which has a higher efficiency.
Furthermore the small clearance between the propeller and
nozzle reduces tip vortex, increasing also efficiency.
As nozzle drag increases with increasing speed, at a certain
speed it will become larger that the added thrust. Tugs often
sail with low speed and heavily loaded propellers and are
therefore fitted with nozzles.
Various types of nozzles (figure 2B.3) have been developed.
Nozzle type 19A is very common because of its cost-effective
design and is typical for ahead thrust requirements. Nozzle
type 37, a ‘backing nozzle’, has been developed to give better
efficiency going astern, which results in only a little less
efficiency going ahead. The same applies to the Hannan Ring
Nozzle, which is a normal type 19A nozzle with slots cut in at
the after end giving good astern thrust – about 70 per cent of
the ahead value with fixed pitch propellers and special blades
and 60-65 per cent with ordinary blades. Nozzle type 37 is a
type of nozzle often used for conventional harbour tugs.
Figure 2B.3: Two commonly used nozzle types
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
20 Tug Use in Port
The manoeuvrability of conventional tugs can be increased
by the use of specific rudder types or rudder systems. Several
different rudder systems are in use, often in combination
with nozzles, such as:
Movable flap rudders
There are several types of movable flap rudders, such as
Rolls-Royce, Stuwa, Barke, while the most used one is Becker
(see figure 2B.6 and 2B.7, opposite page).
At the end of the rudder blade is a movable flap, controlled
by a linkage, comprising about 20-30 per cent of the total
main rudder area. Maximum helm angle of the main rudder
differs by type and is about 45-65°, while the flap can turn
45° further, up to a maximum angle of 90-110°. Each type
of flap has its own specific characteristics. The flap angle is a
function of the helm angle.
Maximum lift, which is achieved at a rudder angle of
approximately 30°, is increased by 60-70 per cent, compared
with a conventional rudder of the same shape, size and area.
Sideways thrust ranges up to 50 per cent of ahead thrust.
Becker claims for his movable flap rudder that at maximum
rudder angle the propeller stream will, depending on rudder
size and balance, be reduced so that 95-97 per cent of the
propeller thrust will be covered by the rudder and used for
manoeuvring the vessel.
At speed the vessel can turn very quickly and speed will
drop fast. When dead in the water the vessel can turn on the
spot and it may even happen that the tug moves backwards.
Performance of the rudder when the tug has speed astern is
in general lower as that of an unflapped rudder. Tugs may
have more than one movable flap behind a nozzle. To protect
damage to the flap in ice, the flap rudder of a Becker movable
flap rudder will be designed with a special ice knife.
Schilling rudders (fishtail rudder)
Schilling rudders (figure 2B.8) can also be found on tugs
eg, the tug Sayyaf at Abu Dhabi. Schilling Monovec
As already said, nozzles increase the efficiency of the
propeller but decrease steering capabilities. The fitting of a
nozzle is equivalent to increasing the lateral area of skegs.
Special rudder systems are therefore often used.
Nozzles can be also be steerable. Their manoeuvring
performance is superior to normal rudder arrangements.
Rudder angles of no more than 25°-30° are used due to the
greater side thrust. A tug’s manoeuvrability when going
astern with a nozzle rudder system is very good. When
going astern the tug can be steered by the steerable nozzle. A
vertical fin or a movable flap may be fitted at the end of the
steering nozzle (see figure 2B.5).
Some twin screw tugs have two independently controlled
steerable nozzles, so increasing the tug’s manoeuvrability
further.
Conventional tugs can be single screw, twin screw and
even triple screw, eg, the USA harbour tug Scott T. Slatten.
Manoeuvrability of twin and triple screw tugs will, in
general, be better than of single screw tugs.
In general tugs are equipped with balanced, semi-balanced
or spade rudders. By far most tugs have balanced rudders.
Single plate rudders are also still used. With the spade,
balanced or semi-balanced rudder the leading edge of the
rudder extends forward of the rudder shaft. This, together
with the shape of the rudder, results in higher propeller
efficiency and a lower steering couple, so a smaller steering
gear can be used. Spade rudders are hanging free, are
not attached to a heel, and are consequently more stoutly
constructed than a balanced rudder. Single plate rudders
decrease propeller efficiency, need a higher steering couple
and consequently a larger steering gear. The decrease of
propeller efficiency is mainly caused by the flow separation
at the leading (forward) edge of the flat plate resulting in
additional turbulence and resistance. If the forward edge
would be rounded some of the lost rotational energy would
be recovered.
Figure 2B.4: New nozzle type Schottel VarioDuct SD45. Test model.
Source: Schottel GmbH
Figure 2B.5: The working of a steerable nozzle with movable flap.
©Becker Marine systems
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 21
outboard and 40° inboard. A maximum side thrust of 70
per cent of ahead thrust can be achieved. Depending on
the two rudder angles, it allows the degree of thrust from a
conventionally mounted propeller to be controlled and the
thrust direction vectored through 360°. Thus the need to
reverse the shaft direction or propeller pitch is eliminated.
Flanking rudders
Flanking rudders (figure 2B.10) are installed in front of
the tug’s propeller and both single screw and twin screw
tugs may be so fitted. Flanking rudders are often installed
in conjunction with other rudder systems, such as a single
rudders have no movable parts. Horizontal slip stream
guide plates are fitted at the top and bottom of the rudder.
The rudder itself has a high lift blade profile with a wedge
profile, so-called ‘fishtail’, at the end of the rudder blade.
The rudder develops 30-40 per cent more lift compared to
a conventional rudder and maximum lift is obtained at a
rudder angle of approximately 40°. The rudder can be used
up to 70° angle and at this angle the propeller slipstream
is thus deflected 90°and works more like a side thruster.
When moving astern the rudder is more effective than
normal rudders (see figure 2B.9). With a Schilling Monovec
rudder, turning on the spot is almost possible while speed is
dropping very fast.
Two Schilling rudders, called Schilling VecTwin, can
be used behind a propeller and make the vessel very
manoeuvrable. Each rudder has a separate steering gear.
The rudders can be turned by joystick a maximum of 105°
Figure 2B.6: The system of a movable flap rudder. ©Becker Marine systems Figure 2B.7: A movable flap rudder behind a controllable pitch propeller
in a nozzle. ©Becker Marine systems
Figure 2B.8: Schilling rudder. ©Becker Marine systems Figure 2B.9: Comparison between fishtail rudder and conventional rudder
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
22 Tug Use in Port
Other systems
Besides the rudder systems mentioned above, many other
systems exist, such as different types of fishtail rudders, triple
rudder systems (see figure 2B.12) and for instance the triple
screw tug Scott T. Allen with her three rudders, of which
the centre rudder can be operated independently from the
outboard rudders.
Bow thruster
Harbour tugs are sometimes equipped with a tunnel bow
thruster. The effectiveness of a tunnel thruster is not high
when the tug has speed ahead. With only two knots speed
the effectiveness of the bow thruster may already be reduced
by 50 per cent. Seagoing harbour tugs operating in port
areas as well as at sea for offshore work often have a bow
thruster, which enables them to keep position better near oil
platforms.
Conventional tugs may be equipped with a (retractable) 360°
steerable bow thruster. These bow thrusters are much more
effective and can operate in any direction. Tugs with this
kind of bow thruster are the previously mentioned combi-
tugs.
2.3.3 Manoeuvring conventional tugs
Single screw tugs
Not many single screw tugs are left for ship handling in
ports.
Three aspects are important in manoeuvring a normal single
screw conventional tug:
•	 The aft location of the rudder and propulsion.
•	 The transverse effect of the propeller when turning for
astern.
•	 The low astern power.
rudder behind the propeller or a Towmaster rudder system
and are especially used in conjunction with fixed nozzles.
In general there are two flanking rudders situated before
the propeller nozzle. The flanking rudders are operated by
separate controls and enhance steering performance when
moving astern or when towing astern on a towline from the
tug’s bow. When going ahead they are kept amidships.
Towmaster system
The Towmaster rudder system (figure 2B.11) is a shutter
rudder type used in conjunction with fixed nozzles. It
consists of several rudders mounted behind and sometimes
also ahead (flanking rudders) of each nozzle. Behind
the nozzle are normally three and ahead of the nozzle
two rudders. Rudder angles are possible up to 60°. The
Towmaster system provides good thrust and steering
characteristics ahead and astern at the expense of increased
complexity.
Figure 2B.10: Shutter rudder system with a fixed nozzle
and two flanking rudders
Figure 2B.11: Towmaster rudder system of tug
Hazam (LOA 38m, beam 11m, BP 70 tons ahead and
50 tons astern. Photo: Damen Shipyards, The Netherlands Figure 2B.12: Triple rudder system. Photo: Nautican, USA
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 23
sideways to starboard without gathering headway, depending
on trim, wind and current influence. The transverse effect of
the inner propeller will enhance the side thrust although this
effect will be much less with the propeller in a nozzle.
2.3.4 Conventional tugs in ship handling
Conventional tugs are used for all methods of tug assistance
but are not equally suitable for all methods. When assisting
a vessel under speed a conventional tug is effective when
towing on a line but as a stern tug, owing to the location of
the towing point, it has severe limitations. When the ship has
more than approximately three knots headway the after tug
can only assist at one side of the ship and cannot shift to the
other side nor is it able to control the speed of the assisted
ship. The towing point being near midships implies a risk of
girting.
When towing on a line, conventional tugs are not suitable to
changing over to pushing at the ship’s side while the towline
is still fastened. This might be desirable, for instance, on
arrival at a berth. For a quick change-over from pulling to
pushing and vice versa while the towline is still fastened
the conventional tug would have to push with the stern.
The manoeuvre itself is already difficult unless the tug is
equipped with a bow thruster or if it is a twin screw tug.
However, when pushing with the stern the tug’s propellers
are so close to the ship’s hull that the interrupted water flow
towards the propellers will result in low propeller efficiency.
In addition, the stern fendering of conventional tugs are
normally not designed for pushing with the stern. In such a
situation it is better to release the tug from the bow or stern
in order to be able to push at the ship’s side.
For tug operations at the ship’s side a normal conventional
tug can push but it is not the most efficient one for pulling
on a tug’s bow line, due to the limited astern power. Specific
rudder configurations, such as the Towmaster system for
example, will increase astern thrust. Normal single screw
conventional tugs can neither pull at right angles because of
the transverse effect of the propeller, nor can a single screw
tug pull at right angles with a cross current or strong cross
winds. The same kind of problem arises when the assisted
When ahead thrust is applied with port or starboard helm,
the tug’s stern moves in a direction opposite to the intended
direction of turn due to the aft location of the propeller and
rudder. This contrasts with tractor tugs where the steering
forces are applied in the direction of turn. This is a subject
further dealt with in Chapter 6 when discussing interaction
effects between tug and ship.
Turning on the spot, or nearly on the spot, is only possible
with the previously mentioned high lift rudders. No sideways
movement of a single screw tug is possible, not even with
high lift rudders, though sideways movement is possible with
high lift rudders in conjunction with a bow thruster.
The transverse effect or ‘paddle wheel effect’ is caused by
the propeller wash hitting the stern at right angles when the
propeller is turning for astern. Nearly all single screw tugs
have a right handed propeller, which means a clockwise
turning propeller going ahead in case of a fixed pitch
propeller and an anti-clockwise turning propeller in case of
a controllable pitch propeller. When the propeller is set for
astern, propeller wash hits the tug’s stern on the starboard
side and the stern moves to port – consequently the bow
turns to starboard. The more sternway the tug has the more
effective the rudder is and it may even be possible to bring
the tug onto a straight course by applying rudder. The paddle
wheel effect together with the low astern power results in
poor performance going astern in single screw tugs.
When moving astern a tug’s stern can be controlled when the
tug is equipped with a steering nozzle or with Towmaster or
flanking rudders. Steering nozzles or flanking rudders can be
set for the direction the stern has to move.
Twin screw tugs
Twin (or triple) screw tugs are much more manoeuvrable
than single screw tugs. They can turn on the spot without
making headway and can more easily manoeuvre straight
astern. Turning can be done by reversing one propeller
and setting theother for ahead while applying helm in the
intended direction.
Propellers of twin screw tugs, whether controllable or fixed
pitch, are often inward turning except on tugs designed
to operate in ice conditions. The advantage of in-turning
propellers is higher propeller efficiency. A disadvantage with
fixed pitch propellers is the larger turning diameter, because
the starboard propeller is left handed and the port one is
right handed. When using the propellers as a couple, the
transverse effect of the screws opposes the turn. This effect
will be smaller in case of nozzle, but is still there.
With inward turning fixed pitch propellers a tug can move
sideways (see figure 2B.13), so-called ‘flanking’. When the
tug has to move sideways to starboard, one would think
of setting the starboard propeller to ahead and the port
propeller to astern. This works only when the tug is equipped
with a bow thruster. However, without a bow thruster this
propeller setting does not move the whole tug sideways, but
only the stern to starboard. By setting the propellers in the
opposite way, with the starboard propeller astern, the port
propeller ahead and the rudder to port, the tug will move
Figure 2B.13: Twin screw tug moving sideways to starboard, also called
flanking, by setting the port engine on ahead and starboard engine on
astern while applying port helm. In the case of in-turning fixed pitch
propellers the transverse thrust of the inner propeller will enlarge the side
thrust to starboard, which is in particular the case with open propellers.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
24 Tug Use in Port
low, unless the tug is equipped with a special rudder and/or
propeller arrangement which increases propeller efficiency.
By installing a conventional single screw tug with a 360°
steerable bow thruster, also called an azimuth bow thruster,
these disadvantages can be overcome (see figure 2B.15). Tugs
equipped with such a bow thruster are the so-called combi-
tugs. The first combi-tugs appeared in the early 1960s. A tug
equipped with this type of bow thruster can, with the aid of
the main propulsion and the bow thruster, turn on the spot,
sail straight astern at a fair speed and move sideways as well
(see figure 2B.16 opposite). Setting this type of bow thruster
in the same direction as the propulsion also gives additional
bollard pull ahead and astern and increases maximum
speed. In most cases this type of bow thruster is equipped
with a nozzle and can be of retractable or fixed type. An
azimuth bow thruster with a nozzle propeller below the keel,
in contrast to a tunnel bow thruster, achieves high efficiency
in any direction even when the tug is moving quickly. This
provides an additional increase in the tug’s manoeuvrability.
As an example, an azimuth bow thruster of 400hp can
increase the top speed of a tug of 27 metres length and
engine power of 1,500bhp by half a knot. With just the bow
thruster working a speed of about five knots can be achieved.
The towing force of the tug is increased by five tonnes if the
main propulsion and the bow thruster work in the same
direction. This is all in addition to better manoeuvrability.
For older tugs this is a satisfactory and inexpensive way of
improving manoeuvrability and bollard pull. As examples
of converted tugs, in Amsterdam, the Netherlands, some
older tugs were converted into combi-tugs and at San Pedro,
California, USA, the tug San Pedro (now Pacific Combi) has
been converted into a combi-tug. The San Pedro has been
equipped with a 600bhp bow thruster, which has increased
ship is moving ahead or astern while the tugs are pulling.
It will then be impossible to stay pulling at right angles.
Additional measures should then be taken, such as a line
from the stern of the tug to the ship to keep the tug in the
best pulling direction. A bow thruster does not improve
the situation as the conventional tug operates while pulling
with the tug’s bow headed towards the ship’s hull. Steering
nozzles, Towmaster and flanking rudders make it easier
to keep the tug at right angles when pulling. Twin screw
conventional tugs can make use of their propellers to keep
the tug at right angles, although this will be at the expense of
loss of effectiveness.
The capabilities and limitations of conventional tugs in
relation to other tug types are discussed in Chapter 4. Some
assisting methods with conventional tugs are shown in figure
2B.14.
Capabilities of conventional tugs can be increased by a gob
rope system and by a carrousel system. The latter system,
which will be discussed later in this chapter, increases a tug’s
capability considerably. The gob rope system will be dealt
with in Chapter 7.
Installing an azimuth bow thrusters will also increase a
conventional tug’s capabilities. This will be discussed in the
next paragraph.
2.4 Combi-Tugs
2.4.1 Designing and manoeuvring combi-tugs
As discussed above, the manoeuvrability of single screw
conventional tugs can be improved by the use of high lift
rudders. However, the disadvantage of many single screw
tugs without steerable nozzles, Towmaster system and/or
flanking rudders, is that moving straight astern is hardly
possible and no single screw tug can move sideways unless
fitted with a tunnel bow thruster in combination with high
lift rudders. The astern power of single screw tugs is also
Figure 2B.14: Some assisting methods with conventional tugs
Figure 2B.15: Fairplay’s combi-tug Serwal 3, the former Petronella J.
Goedkoop. LOA 28.5m, beam 6.9m. Main engine 900 bhp. One cpp in
fixed nozzle and twin rudders. Retractable 3600 steerable bow thrusters
of 420bhp, type Aquamaster UL 316/2600. BP of main engine 15 tons.
Bollard pull of main engine + bow thruster 20 tons. Maximum speed
ahead 11.9 knots, astern 10.2 knots when using both main engine and
bow thrusters. The tug is equipped with a special fairlead at the stern and
a towing winch. Line ‘1’ shows the towline in its 1 ‘normal’ position and
‘2’ the towline passing through the fairlead.
Types of Harbour Tug 25
an eyelet or swivel fairlead at the tug’s stern. At the free end
of the wire is a large shackle which can be put around the
towline. By heaving on the gob rope winch the towing point
can thus be brought as far as possible aft.
This system is further explained in paragraph 7.2.1. A gob
rope arrangement normally needs two persons on deck.
With the reduced numbers in tug’s crews a handier and safer
system was developed by the former Goedkoop Harbour
Towage Company of The Netherlands (now Wijsmuller
Harbour Towage Amsterdam). A strong fairlead has been
attached to the deck close to the tug’s stern. This fairlead can
be opened at one side so that the towline can easily be put in
or taken out. With this additional towing point at the tug’s
after end the combi-tug can operate similarly to a tractor-
tug, that is with the stern towards the assisted ship.
To show the capabilities of a combi-tug consider an arriving
ship. The combi-tug makes fast aft and approaches stern first
to the stern of the ship to pass the towline (see figure 2B.17
position 1). The ship to be assisted may still have rather a
high speed, eg about seven to eight knots. As soon as the
towline has been secured and the aft towing point is in use
by means of a gob rope or fairlead, the combi-tug can control
the vessel’s speed (position 5) or assist in steering (positions
the tug’s bollard pull by 40 per cent, from 25 to 35 tons and
has improved the manoeuvring capabilities. Moran Towing
Company, USA, revitalised its fleet of single screw tugs by
installing retractable azimuth bow thrusters and a large
fairlead aft. Some newer tugs are also equipped with azimuth
bow thrusters, allof them of the retractable type.
If the azimuth bow thruster is not in use it causes extra
resistance. This is one of the reasons for making the bow
thruster retractable. In shallow waters a retractable type
is necessary. Care is required in using the azimuth bow
thruster when underkeel clearance is small and it should be
retracted in good time. A good working alarm system when
the water depth is not sufficient for safe working of the bow
thruster is strongly recommended.
2.4.2 Combi-tugs in ship handling
Combi-tugs can tow on a line forward as well as aft. As a
forward tug the combi-tug operates like a conventional
tug, but has the advantage of increased maximum speed,
manoeuvrability and bollard pull. Also, the risk of girting
is reduced and response time is less due to the higher
manoeuvrability.
As a stern tug combi-tugs can operate as a conventional
tug at low speeds and can easily work over the tug’s stern
at higher speeds because of the azimuth bow thruster.
However, since conventional tugs have their towing point
approximately 0.45 x LWL from aft, working over the tug’s
stern needs an additional towing point near the stern to
prevent girting, especially when the assisted ship has a higher
speed. On conventional tugs the towing point can be moved
aft by a gob rope, and on some tugs by a gob rope from a gob
rope winch. The gob rope is then led from the winch through
Figure 2B.16: Free sailing manoeuvres with a combi-tug
Figure 2B.17: Some assisting methods with a combi-tug
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
26 Tug Use in Port
Schneider propulsion system, was developed in the early
1920s by Professor Frederic Kirsten of the Aeronautical
Engineering Faculty at the University of Washington in
Seattle, USA.
Tugs with Voith Schneider propulsion system appeared in
the 1920s and 1930s. In the 1950s Wolfgang Bear of the Voith
Company designed a ship handling tug with the cycloidal
propulsion under the tug’s forebody and the towing gear on
the aft deck. The oldest Voith tug was the Biene, built at the
Clausen shipyard in Oberwinter.
Many limitations of conventional tugs were overcome by the
introduction of this totally new concept, which was called a
Voith Water Tractor.
Note: All pictures in this paragraph have been generously
made available by Voith Turbo GmbH & Co. KG, Marine
Division, Heidenheim, Germany, unless indicated otherwise..
The cycloidal propulsion system is, in fact, a kind of
controllable pitch propeller. The engine works at constant
rpm and magnitude of thrust and the thrust direction is
regulated from the wheelhouse.
New Voith tugs, like the VectRA 3000, may be equipped
with a system having engine and thrust (better to say
pitch) regulated in the combinator mode, comparable with
controllable pitch propellers. This Voith Remote Control
system regulates automatically engine rpm and thrust/pitch
in the most effective way in accordance with a predefined
graph.
The VS propulsion system for tugs consists of two units with
vertical propeller blades whose pitch and thrust direction
can be regulated uniformly through 360° without delay. The
protection plate (2) protects the propeller blades and works
like a nozzle, thus increasing propeller efficiency. During
docking the tug stands on these protection plates and on the
skeg (3). See figure 2B.19 below.
Different engine rpm settings can be selected. The following
pitch settings are recommended:
•	 Maximum pitch pushing about 9.
•	 Maximum pitch pulling about 8.
•	 Maximum pitch free running about 10.
To avoid engine overload during pulling and pushing,
the pitch restrictor, located on the control stand, must be
engaged. Engine overload will be indicated by overload
warning lights flashing at 110 per cent power and acoustic
alarm on the VSP control stand.
The large skeg is typical for tractor tugs and in particular for
VS tractor tugs. It gives course stability and brings the centre
of hydrodynamic pressure further aft, which is advantageous
to both safety and towing performance when towing on a
line, especially towing performance when operating as stern
tug at higher speeds.
The towing winch is located aft of midships. It may also
be just a towing hook. The towing point, a large fairlead or
towing staple (4), through which the towing line passes, lies
2 and 3). To reduce ship’s speed, the tug’s propulsion and the
bow thruster will be set in the same direction to increase the
tug’s pulling force. Assisting steering is achieved by the tug
sheering out to port or starboard with the main propulsion
going astern and the bow thruster working sideways. In
positions 2 and 3 the incoming water flow creates lift forces
on the tug and consequently a force in the towline. When the
ship’s speed reduces, the effect of the tug in position 2 and 3
will become less due to the reduced lift forces. The gob rope
is then released or the towline taken out of the fairlead. The
original towing point is then in use again and the tug can
operate again as a normal conventional tug (position 4).
In circumstances where there are strong cross winds and/
or currents, and much effort is required from the tug to
compensate for those forces, the tug is more effective when
it proceeds with the assisted ship as a normal conventional
tug (position 4) and thus can use its full ahead power. When
required, the bow thruster can be used to increase bollard pull.
The lift forces on the tug caused by the water flow increase the
force in the towline.
If so required the tug can, even when the assisted ship has
forward speed, shift to a position behind the ship’s stern
by using the gob rope or fairlead, bow thruster and main
propulsion (position 4 —> 5). This can be done faster
compared to a normal conventional tug. Conversely, moving
from a position abaft the stern to a position moving with
the assisted ship is, because of the bow thruster, possible at a
somewhat higher speed than with a normal conventional tug.
It has been made clear that the advantages of a combi-tug
are greatest when the tug operates as a stern tug on a line.
For that reason this type of tug often assists during quite
long passages as a stern tug for speed and steering control.
The combi-tug can also be used at the ship’s side, such as for
push-pull operations.
When operating at the ship’s side, a combi-tug has many of
the disadvantages of a normal conventional tug. The combi-
tug can either push with the bow or with the stern. When
pushing with the bow while the ship has some speed, the
bow thruster can be helpful to keep the tug’s bow in position
and prevent sliding along the ship’s hull. The bow thruster
will also give an additional transverse pushing force (see
figure 2B.17, lower picture).
When pushing with the stern, the effectiveness of the tug
is reduced due to the restricted water flow towards the
propeller and it is more difficult to bring or hold the tug at
right angles to the ship’s hull when the ship has some speed,
due to the low power of the bow thruster. In particular, when
working over the tug’s bow, pulling effectiveness at speed is
low.
2.5 Tractor-tugs with cycloidal propellers
2.5.1 Design
Tractor tugs have their propulsion under the forebody.
Those with a vertical blade system, or cycloidal propulsion
system, are the so-called Voith- Schneider or Voith tugs (VS
tugs). The first vertical axis propeller, similar to the Voith
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Lápis
Pgua_Supplay
Destacar
Types of Harbour Tug 27
the other one in the
transverse direction. The
propeller blades create
a thrust in a direction
depending on the
location of the steering
centre N. In sketch 1
there is no thrust; the
propellers are ‘idling’.
In sketch 2 the steering
centre is moved by one
hydraulic cylinder to
port. Thisoffset location
of the steering centre N
results in forward thrust.
In sketch 3 the steering
point N is moved by the
two hydraulic cylinders
to port and forward,
which gives thrust in
the indicated direction
S. So, the thrust can
be regulated for any
direction by moving N.
The nominal direction of
thrust is perpendicular
to the line O-N and the
magnitude of thrust
is proportional to the
distance O-N. In tugs,
there are always two VS
propeller units, which
are installed side by side,
except for the new CRT
(Carrousel RAVE Tug)
which has one propulsion unit forward and one aft..
The maximum draft, including the propulsion units, of a VS
tug is relatively larger than that of conventional tugs, due to
the weight and height of the propulsion units, the propeller
location and dimensions. The location of the propulsion
units is approximately 0.25 - 0.30 x LWL from forward. The
towing point lies 0.1 - 0.2 x LWL from aft, although this may
differ by tug depending on operational requirements.
2.5.2 Propeller control
The direction and magnitude of propeller thrust is remotely
controlled from the wheelhouse. The remote control can
be mechanically operated, which is a very reliable system
for tugs and best when the distance between wheelhouse
and propeller is short. With longer distances between the
bridge/wheelhouse and propeller control and when several
manoeuvring stands are installed other remote control
systems are recommended such as an electronic control.
How propeller thrust is regulated can be seen in figures
2B.21, and 2B.22, on the next few pages.
Some attention will be paid to the specific Voith controls for
steering and thrust. Transverse thrust is controlled by the
wheel and longitudinal thrust is controlled by pitch levers. So
thrust setting is a combination of transverse and longitudinal
far aft and usually exactly above the middle of the skeg The
hull is relatively wide and flat to provide sufficient space for
the two propulsion units. VS tugs have heavy duty fendering,
especially at the stern, because when pushing, the tugs push
with the stern.
Most modem tugs have relatively small wheelhouses with
optimal visibility. The same applies to modem VS-tugs,
like the one shown in figure 2B.18. The small and optimum
wheelhouse (6) often has one central manoeuvring panel for
propeller control.
The principle of a cycloidal VS propeller is shown in figure
2B.20. Links leading to the steering centre N are fitted to
the vertical propeller blades. The steering centre N can be
moved out of the centre O by two hydraulic cylinders. One
hydraulic cylinder works in the longitudinal direction and
Figure 2B.18: The total concept of a Voith tractor tug
Explanation of figure 2B.18:
1. Voith-Schneider propeller. 2 Propeller guard plate.
3. Skeg 4 Towing staple. 5 Second towing position.
6. Wheelhouse with specific Voith controls.
Note 4: A second towing point is only fitted in a small number
of VS tugs, and is discussed further in Chapters 4 and 9.
Figure 2B.19: Voith propulsion units with protection blades.
Photo: Andries Looijen, Multraship
Figure 2B.20: Principle of Voith propulsion.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
28 Tug Use in Port
ship’s hull is less compared to tugs with azimuth thruster
which have a more concentrated propeller wash.
The full bow of tractor-tugs and the flat and wide hull
bottoms which are necessary to create sufficient room for the
propulsion units sometimes adversely affect their sea keeping
behaviour. According to the experience of some VS tug
captains, so do the bottom plates of the VS propulsion units
in rough sea conditions.
Note 5:
There is a general problem of course stability often applying to
modern tugs with a small length to beam ratio. For instance,
such Voith tugs may veer somewhat to port and starboard
– which had to do with the stern design, and caused by the
water flow sticking to the tug’s hull and stern, but at a certain
moment the flow becomes loose of the stern and forms a
vortex. This may not happen symmetrically, causing the stern
to be pushed from one side to the other and starting to sway. It
may happen on one tractor tug, but not another. Voith, having
wide experience with their tractor tugs, solved the problem in
various ways, for instance by putting baffles on the stern side
of the fin. Another system is mounting vertical strips on the
thrust. Transverse direction has priority. For older tugs,
when full transverse thrust is used (e.g. wheel hard to port)
no longitudinal thrust will be available, even when the pitch
levers are set in pitch position. For newer VS tugs, there will
be some ahead thrust (see figure 2B.22). It can be seen that the
full 100 per cent thrust cannot be applied in any direction.
The two units of a VS tug can be controlled independently or
together for longitudinal thrust but only controlled together
for transverse thrust.
2.5.3 Manoeuvring
VS tractor-tugs are highly manoeuvrable, can turn on
the spot, deliver a high amount of thrust in any direction
and sail straight astern at high speed. Astern thrust is
nearly equal to ahead thrust. Many of the disadvantages of
conventional – especially single screw – tugs, such as low
astern power, no or low side thrust and in some situations
transverse effect of the propeller, do not apply to VS tugs.
Because it is possible to apply side thrust tractor tugs are also
safer when making fast near the ship’s bow and interaction
forces can be better compensated.
Some Voith Water Tractors are specially designed for high
speed escorting. These VWTs are of the Fin First Design
(Fin first), ie, the fin (skeg) side is the bow and the free
sailing is done fin first. This, however, does not alter the basic
principles of the tractor tug. The standard VWTs have the
VSPs in the bow (VSP first), the free sailing is generally done
VSP first. Sailing ahead as well as astern is easily achieved by
use of the wheel. Turning on the spot can be done by setting
the wheel hard to port or starboard as shown in figure 2B.23.
A VS tug can be moved sideways, for example to port (see
figure 2B.24). The port pitch lever is set for ahead and the
starboard for astern, while turning the wheel to port. The
turning moment of the propellers is eliminated by the
action of the wheel and the tug moves sideways. Propeller
effectiveness is less on astern therefore ahead pitch should be
set somewhat lower than astern pitch.
VS tug propulsion produces little wash, which is invaluable
when skimming oil and, for example, when working with
full thrust close to deep loaded lighters as can be the case
in narrow harbour basins. Furthermore, loss of pulling
effectiveness due to the propeller wash impinging on the
Figure 2B.21: Voith mechanical control – steering wheel
and thrust handles.
Figure 2B.23: Turning
Top: Wheel moves the bow to starboard.
Bottom: Pitch levers move the stern to starboard.
Figure 2B.24: Casting off; moving sideways.
stern of the tug so these vortices could no longer be formed,
improving course stability. Voith patented this system and
implemented the solution with Robert Allan Ltd – who call it
StRAke stabilisers – which have also been applied to azimuth
tractor tugs as well. The first application on Voith tugs was on
VectRA tugs built at Sanmar Shipyard, Turkey.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 29
With both pitch levers set to full ahead (pitch 10), the wheel changes the direction of thrust.
With the pitch levers set to full ahead (astern) and the wheel set to approx 5 port (starboard), the thrust ahead (astern)
is approx 55 per cent, the transverse thrust is approx 45 per cent.
With the pitch levers set to full ahead (10) (astern) and the wheel set to 10 port (starboard),the thrust ahead (astern)
is 25 per cent and the transverse thrust is 75 per cent.
With pitch levers set to zero and the wheel set to 10 port (starboard), the resulting thrust to the side is 100 per cent.
Lateral transition is generally done using the wheel which overrides longitudinal thrust.
See also: http://voith.com/corp-en/drives-transmissions/voith-schneider-propeller-vsp.html where a program can
be downloaded to handle a virtual Voith tug.
Figure 2B.22 : Wheel and pitch lever settings.
30 Tug Use in Port
VS tugs can also make fast directly to a ship’s side as push-
pull tugs, approaching the ship either stern or bow first.
Ship’s speed should then not be more than about five knots.
Although VS tugs are not the most effective type of tug as
a forward tug towing on a line for a ship under speed, due
to performance restrictions imposed by the location of the
towing point, they are very suitable as after tug for course
and speed control. Course control can then be carried out
with ships having headway and, contrary to what is possible
with conventional tugs, to starboard as well as to port.
Note 6: The different manoeuvres shown and also additional
manoeuvres can be found in the Voith Water Tractor
Maneuver Manual, including a very important guideline how
to make fast at the bow of a ship having headway.
2.6 Tractor tugs with azimuth propellers
2.6.1 Design
Tractor tugs with azimuth propellers have two 360°
steerable thrusters under the forebody. There are several
manufacturers of azimuth thrusters, including Rolls-Royce,
Schottel, Niigata, HRP, Wärtsilä, Kawasaki, Veth, Caterpillar,
etc. Some of the European manufacturers mentioned have
merged. Different names are used for azimuth thrusters,
such as Z-pellers, Rexpellers and Duckpellers, among others.
Although the thruster systems are generally similar, each
manufacturing company has its own specific design.
2.5.4 VS tugs in ship handling
To get some basic insight into the ship handling capabilities
of a VS tug, various ship handling manoeuvres are shown
on this page. These manoeuvres can be executed by well-
designed azimuth tractor tugs too.
Course control can be carried out at high speeds by the
indirect method (see figure 2B.25A, situation b), making
use of the hydrodynamic forces on the tug’s hull, or at lower
speeds by the direct method (see figure 2B.25A situation a).
Forces in the indirect method can be far higher than the
tug’s bollard pull. When braking forces are required, pitch
levers should be adjusted to ship’s speed to avoid overloading
the engine and a minimum of wheel should be used.
While towing on a line a VS tug forward or aft can change to
pushing without releasing the towline, which is very handy
while approaching the berth (see figure 2B.25, situations
C,D). The forward tug can change to a pushing position
at a ship’s speed up to approximately two knots. A towing
winch is always useful with this kind of operation in order to
control the length of the towline and to enhance safety.
VS tugs are used for towing on a line and for operations
like push-pull (see figure 2B.25, situation E). For towing
and pushing operations the maximum longitudinal pitch
is limited (to approximately pitch 8 for towing/pulling and
pitch 9 for pushing) to avoid overloading the engine. In
push-pull operations the disadvantages of conventional tugs,
among others, of having low astern power and/or not being
able to pull at right angles to the ship do not apply to VS
tugs. As already mentioned, VS tugs have nearly equal power
astern and ahead and can apply thrust in any direction.
Figure 2B.25: Various assist modes
Figure 2B.25A: Direct and indirect assist modes.
Figure 2B.25B: This special manoeuvre can be employed, if the pilot
wants to have a light pull on the line. Normally, when braking forces are
ordered, the tug should stay in line behind the ship, using pitch levers and
a minimum of wheel. Pitch levers must be adjusted according to ship’s
speed to avoid engine overload.
Figure 2B.25C and D: Fast forward/aft: Changing position to come
alongside for pushing. To be done at low speeds, up to about 2 knots.
Figure 2B.25E: Push-pull while berthing.
Ship’s speed around 5 knots
B
A
C
D
E
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Types of Harbour Tug 31
hull openings for the VS units. An azimuth tractor tug of the
same dimensions and engine power will therefore have less
hull draft.
Towing point location is generally similar to that in VS tugs.
The skeg is sometimes smaller and the location of the towing
point is often less strictly related to the location of the skeg
as with VS tractor tugs. Twin skegs are also used (see below).
The towing point lies approximately 0.1 x LWL from aft and
the propellers are fitted at 0.30 - 0.35 x LWL from forward. A
smaller distance is found, 0.25 x LWL for instance, on some
Italian tractor-tugs at Genoa, Italy. Thrusters placed further
forward increase a tug’s effectiveness while assisting. The
thrusters deliver practically the same amount of thrust in
any direction, though astern thrust might be about 5 per cent
less. When the thrusters interact, as when producing side
thrust, total thrust efficiency will be less. Thrusters should
then be set at a small angle to each other.
For azimuth tractor tugs (ATD) various names can be found,
such as the Azitrac designed by Offshore Ship Designers in
the Netherlands.
Twin skegs
As mentioned before, azimuth tractor tugs may be equipped
with a patented twin skeg The reason why will be explained
now (see References for paper: Damen ATD Tug 2412 Twin
Fin Concept).
The ATD Tug 2412 has unconventional main dimensional
ratios, a L/B ratio of 1.89. An observation from full-scale
trials and model scale trials was that the tug had to be steered
(when sailing ahead) with about 5-10° of azimuth angle and
allowing a drift of 3-5 degrees. Sailing astern showed the tug
as directionally stable.
Opportunities to improve on this peculiar steering behaviour
when sailing ahead were sighted in a study initiated to
further enhance the design.
The first azimuth propellers were introduced into service
in the 1960s. The first tug fitted with Schottel azimuth
propellers was the German harbour tug Janus (1967).
Azimuth propellers can be fixed pitch, eg, often with Niigata,
or controllable pitch. Fixed pitch propeller revolutions can
be regulated by a speed modulating clutch, which enables
the propeller speed to be controlled in a stepless manner
from zero up to maximum. This more or less eliminates
the need for controllable pitch propellers and is much less
expensive. A new system to modulate propeller speed of fixed
pitch propellers of azimuth thrusters is the CAT Advanced
Variable DriveTM (CAT AVD TM) which is installed on a
RAmparts 2400 SX ASD-tug and which could probably be
used on azimuth tractor tugs as well. The systems consist of
a pair of dual input, continuously variable transmissions,
located in the shaft lines between the main engines and the
azimuth propellers. The AVD TM system can modulate
propeller speed down to zero like a slipping clutch. See
References for article ‘Flower Power’.
On the other hand, controllable pitch propellers have, apart
from the faster acceleration, the advantage that a fire-fighting
system can be operated through the main propulsion unit
without the need for a complicated coupling arrangement.
Azimuth propellers are fitted in nozzles to increase propeller
efficiency (for nozzle types, see par. 2.3.2). In the event
of grounding, propeller protection is provided either by
protection or docking plates. Docking plates are fitted
underneath or in front of the propeller and give only limited
protection for the propellers. Protection plates serve also
when docking.
The basic design of the tug itself does not differ much from
VS tractor tugs. The displacement of a VStug is more than
that of a comparable azimuth tractor tug of the same engine
power, due to the higher weight of the VS propulsion systems
and to the requirements for more stiffening due to the wider
Figure 2B.26:
Construction of a thruster
Source: Thrustmaster
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
Pgua_Supplay
Destacar
32 Tug Use in Port
Various alternative designs were tested in MARIN’s
seakeeping and manoeuvring basin.
The Twin Fin arrangements showed a nearly conventional
directional stability. In addition, the turning velocity at
higher rudder angles increased as well, which demonstrated
that the Twin Fin gives a somewhat higher turning ability.
The Twin Fin configuration enables a directionally stable
compact tractor tug with perfect steering behaviour both
sailing ahead and astern.
Some further information about the ATD 2412 Twin Fin:
•	 Bollard pull maximum 70 tons.
•	 Maximum speed ahead and astern 12 knots.
•	 Tonnagebig consequences. Therefore, highly experienced tug masters are required with proper knowledge of
the capabilities and limitations of their tugs, including the risks involved when assisting ships.
Thankfully, this guide by the renowned author Captain Hensen is now available in its 4th edition for all to
learn from and refer to. Such is its relevance and authority that IMO itself has recognised its significance.
I am delighted to write the foreword to such a distinctive publication which is of immense benefit to my
profession and, I know, to tug and ship masters too and to all other professionals involved in ship handling
with tugs.
Simon Pelletier
President, International Maritime Pilots’ Association
Tug Use in Port vii
This book is specifically written for maritime professionals involved in the day-to-day practice and
training of ship handling with tugs, particularly pilots, tug masters and training instructors. It is also of
great value to towing companies, shipmasters and mates of seagoing vessels, training institutes, and all
other people or organisations involved, in one way or another, in tugs, tug operations and ship handling.
The basic principles of ship handling with tugs do not change very much. However, the tug world is fast
changing, with the ongoing development of new tug types, the growth of environmentally friendly tugs,
the increase of operations in areas with unfavourable conditions, the progress of automation on board
tugs, smart navigation and collision avoidance systems and more.
At the centre of these developments are the practical people – tug masters and crews, pilots and ship
captains – who have to deal with new developments and should be able to handle newly designed tugs in
the locations where they have to operate in a safe and efficient way. Training and effective training tools,
therefore, become more and more crucial. For the same reasons training institutes should stay abreast of
new developments.
This is not the only reason for training. Accidents still do happen – more than once with dramatic
consequences for the tug master and/or crew – which is of continuous concern. The reasons why these
accidents happen should be investigated carefully and findings be included in the training programs.
When reading accident reports it can be concluded that very often a lack of experience and knowledge
is the cause. It is therefore incumbent upon towing companies, port authorities, training institutes and
trainers to ensure that tug crews are fully aware of the capabilities of their vessels. Despite all the safe tug
designs, they are worthless if the people on board do not understand their capabilities and limitations,
along with the risks involved and the safe procedures to be followed.
If training is carried out in an efficient and purposeful way by professional and experienced instructors,
tug masters, pilots and ship captains will benefit from it, as will towing companies, shipping companies
and port authorities. In addition, dedicated training and interaction between practitioners and designers
will help the industry to achieve an ever-higher level of safety and efficiency.
Safety starts at the highest organisational level. Top management of a company and department directors
set the organisational structure, allocate resources and budgets and create the safety culture, but often they
are distanced from the operation both in time and locality. The causes of accidents are often embedded in
the way a company is organised, work is prepared, and changes are managed. From this perspective, risk
management is an important issue, together with essential risk assessment tools.
This book focuses on safe and efficient ship handling with tugs either normal tug operations, operations at
terminals, or escorting. Not all the relevant aspects of tugs and ship handling with tugs can be addressed
in detail in a single volume, but I hope this book will act as a guide to the reader, while at the same time
encourages further research in topics of interest. The references at the end of the book may prove useful.
It is again the author’s earnest hope that this fourth edition of the book will contribute to an enhanced
safety culture, an improved knowledge of tugs through nautical colleges, training institutes or by self study,
and will lead to increasing safety during ship handling operations with tugs in ports, port approaches and
offshore terminals around the world.
Henk Hensen
June 2021
AUTHOR’S PREFACE
viii Tug Use in Port
To complete a book like this, the knowledge and experience of people across a wide range of disciplines is needed. It is most
surprising how many people were so helpful in sharing their knowledge and experience with me. It enabled me to create an
update of the book Tug Use in Port in the best possible way. As the author I am very grateful for the generosity of all these
people and their organisations.
I will start by thanking all those who have provided photos or permitted the use of their photos from the collections shown on
internet. Their names are mentioned with the photos in the book.
Many maritime professionals have helped in one way or another based on their knowledge and practical experience in ship
handling with tugs. The marine pilots who have helped: John Betz, Los Angeles Pilot Service; Wim van Buuren, Rotterdam
pilot, simulator instructor; Rafael Cabal Alvarez, Barcelona pilot, co-ordinator and instructor of the New Technologies course
for Spanish pilots; Luke Felsinger, Gladstone marine pilot, Dir AMPI, and Sergei Shabal, pilot, St Petersburg, Russia.
The harbour masters: Captain Paul Bryant, Deputy Harbour Master, Shetland Islands Council; Harbour Master, Associated
British Ports Southampton, and Cor Oudendijk, former COO, Port of Amsterdam.
I also acknowledge the help of tug masters and representatives from several towing companies:
Pierre Jourdain, tug master and ice pilot; Gregory V Brooks, tug master, Principal Towing Solutions Inc; Arie Nygh, FNI, tug
master/instructor, Managing Director, SeaWays Consultants Pty Ltd; Daan Merkelbach, Manager Training and Consultancy,
Tug Training & Consultancy BV; Roger Ward, former tug master and Operational Manager, Marine Consultant; Jarkko Toivola,
Director/Vice President, Alfons Håkans Øy,Turku; Anna Fong, Senior Management Executive, Corporate Services Department,
PSA Marine (Pte) Ltd.; Andy Perry, Regional Marine Manager-Fleet & Operations, Svitzer Australia Pty Ltd; David Mcinnes,
Svitzer Fleet Training and Check Master, Fleet & Operations Australia; Scott Ward, HSEQ Marine Standards Officer UK,
Svitzer; Hiroyuki Saito, President Tokyo Kisen Co Ltd; Sveinung Zahl, Fleet Manager Towage, Østensjø Rederi AS; Carl Pepin,
MBA Director Operations, Towing and Navigation, Ocean Group, Québec; John Armstrong, Marine Advisor, Saam Smit
Canada Inc, and Brent Lirette RG, Operations Manager, Edison Chouest Offshore Alaska.
Of great importance for this book has been the contribution of naval architects, maritime researchers and research and training
institutes. Therefore I am thankful for the help of naval architects Dr Markus van der Laan, Owner IMC Corporate Licensing;
Arie Aalbers; Frans Sas, SASTECH; and of James R Hyslop, Manager, Project Development Principal, Robert Allan Ltd.
Likewise, the professionals of research and training institutes MARIN (Maritime Research Institute Netherlands) Johan H de
Jong, MSc, International Co-operation; Dr Thijs Hasselaar, MSc, Project Manager, Trials & Monitoring and Jos van Doorn, Msc,
Manager MARIN's Nautical Centre MSCN. Furthermore, Ismael Verdugo, Technical Director SiPort21; Vladimir Ponomarev,
Vice President Solutions, Transas Marine Ltd, Ireland; Peter Jensen Schjeldahl, MScEng, PhD, Senior Specialist Simulation,
Training & Ports, Force Technology, and Cliff Beazley, AM FNI, Managing Director, Port Ash, Australia.
The contributions of Gordon Meadow MSc, PgCLTHE, PgCERM, FHEA, Associateaft often lies
too far aft to be effective if these tugs were to tow on a line at
speed like a conventional tug. Sometimes the towing point
lies nearly above the thrusters aft. The Japanese concept of
tugs is among others such a tug and is further being dealt
with in paragraph 2.8.
ASD-tugs are dealt with in paragraph 2.9. These tugs also
operate more and more over the bow, and as a reverse-
tractor tug as well.
For the azimuth propeller systems in use, fixed pitch or
controllable pitch, please see the tractor tug paragraph.
Because the thrusters are fitted under the stern the
maximum draft of reverse-tractor tugs is less than that
of comparable real tractor tugs. Hull draft is less than the
hull draft of a similar VS tractor tug, for reasons already
explained when discussing azimuth tractor tugs.
The propulsion units are located approximately 0.1 x LWL
from aft. The pushing point and forward towing point is
at the forward part of the bow. Wheelhouse construction
is completely adjusted to the assisting method. The
manoeuvring station is designed in such a way that the tug
captain has an unobstructed view of the forepart of the tug,
the towline and the assisted ship, while seated behind the
manoeuvring panel with the assorted instrumentation and
control handles around him.
2.6.4 Azimuth tractor tugs in ship handling
The assisting capabilities of azimuth tractor tugs are
comparable to those of VS tractor tugs. They are suitable
either for operating at the ship’s side or for towing on a line
(see figure 2B.32). Azimuth tractor tugs, and also VS tractor
tugs if fitted with a smaller skeg and/or a towing point not
located at the correct position, are less effective as a stern
tug compared to the VS tractor tugs, when operating in the
indirect towing method at higher speeds.

On the other hand, because of their lower underwater
resistance – mainly due to the relatively shallower draft –
and the ability to provide nearly 100 per cent thrust in any
direction, azimuth tractor tugs will be more effective at speed
when direct towing as a stern tug and as a forward tug when
towing on a line, again depending on a proper location of
the towing point. The influence of the location of the towing
point on the performance of tractor tugs is further discussed
in Chapter 4.
Note 8:
Robert Allan Ltd designed a new tug concept of which the
hull could be outfitted as either a 25m tractor tug (TRAktor
2500-SX) with bollard pulls up to 70 tons or a 25m Rotortug
(ART-60-25SX) with bollard pull up to 60 tons. The stern of
the hull features the simple but effective StRAke stabilisers,
a system developed by Voith and implemented by Robert
Allan Ltd, which improve tractor tug course and directional
stability, allowing for a reduced size skeg and improved
manoeuvrability.

2.7 Reverse-tractor tugs
2.7.1 Design
Reverse-tractor tugs, formerly also called pusher tugs, are
tugs with two azimuth propellers under the stern. They are
more or less specifically designed for the assisting method
Figure 2B.32: Some assisting methods with azimuth tractor tugs.
Figure 2B.33: Typical reverse-tractor tug. LOA 25.4m, beam 8.5m,
BP 45 tons. Images courtesy: Cliff Chow and Jerry Low, HKST
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 35
the direct method reverse-tractor tugs might be some more
effective because of the lesser draft. The effectiveness of tugs
is dealt with in more detail in Chapter 4.
Please see note at paragraph 2.6.2 about thrusters’ controls.
2.8 Japanese tug concept
2.8.1 Design
A specific type of a reverse tractor tug is the Japanese tug
concept, also adopted by Taiwanese, Chinese and South
Korean designers. These tugs have some remarkable
differences with, let us say, the European and American
ASD-tug types.
Note 9: The name Japanese tugs will be used here.
The most remarkable differcences are:
•	 The large flared bow hanged with tyres.
•	 The transom stern extending below the waterline.
•	 The sheer.
•	 Long deckhouse.
•	 The winch located relatively far aft.
•	 The relative high working deck in front of the winch,
which can be reached by a connection bridge.
•	 The relative small width.
•	 The relatively small draft.
•	 The high free-sailing speed of 15 knots and even more.
Some of these Japanese ASD-tugs have just one winch
forward, others have a double winch forward, while there are
also tugs of this type with three winches, two forward and
one aft.
The tugs have two azimuth thrusters aft, often Niigata (see
figure 2B.40), and no skeg except for a small skeg in front
of the propellers. Bilge keels can be found on these tugs (see
figure 2B.41). Several of these tug types have no funnels, but
engine exhausts are then taken out via the transom, which
creates a all around clear view from the wheelhouse.
Main reason for the typical bow is to reduce the wave
making resistance by a fine and, more recently, a bulbous
bow. This creates the possibility for a bow deck which can be
opened widely with a big flare, which is necessary for braking
bow waves at high speed and so creating a dry working deck.
One of the other reasons is to keep the tug’s GT below a
certain level.
2.7.2 Propeller control, manoeuvring
capabilities and ship handling
Propeller control with reverse tractor tugs is the same as with
azimuth tractor tugs. Because of the two azimuth thrusters
and the forward lying towing point reverse-tractor tugs are
highly manoeuvrable and safe working tugs. They can turn
on the spot and move sideways (see figure 2B.44). The astern
bollard pull of these tugs is generally about 5-10 per cent
less than ahead power, due to the shape of the after hull.
The name reverse-tractor tug implies that the tugs operate
similarly to tractor tugs but in the opposite way. Tractor tugs
always operate with the towing point towards the assisted
ship and the propulsion units away from the assisted ship.
Reverse-tractor tugs do the same but are then heading in the
reverse direction. That’s why these tugs are called reverse-
tractor tugs.
What has been mentioned about azimuth tractor tugs with
respect to manoeuvring also applies to a large extent to
reverse-tractor tugs. They can be used for towing on a line
or for assisting at the ship’s side as shown in figure 2B.35.
They can easily change, when towing over the tug’s bow, to
a pushing position at the ship’s side or for push-pull while
berthing. A towing winch is useful to enable the towing line
always to be set at a suitable length or to pick up any slack in
the line. When operating at the ship’s side these tugs are very
effective at speed.
Although this type of tug is also used for towing on a line,
as a forward tug it will not be very effective in steering ships
having headway. The tug has to move astern and its towing
point lies at the forwardmost end of the tug, giving a similar
decrease in steering efficiency when speed increases as with a
tractor tug.
As a stern tug, reverse-tractor tugs are very suitable for
steering and speed control for ships at speed, whether
making use of the indirect or direct method. In the indirect
method reverse-tractor tugs are in general somewhat less
effective in steering compared to a similar VS tug in the same
situation, although much depends on skeg design, but in
Figure 2B.34: Thrusters with cpp propellers on SD Stingray.
Photo: Jacco van Niewenhuyzen
Figure 2B.35: Assisting methods with a reverse tractor tug.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
36 Tug Use in Port
A bulbous bow will increase the waterline length as does the
transom stern, resulting in a higher freesailing speed. This is
needed because the high speeds needed for escorting of large
ships and ships with hazardous cargoes in the inland traffic
routes.
Tugs may have fire-fighting and oil recovery equipment.
A shallow draft is required for areaswith a small waterdepth.
2.8.2 Propeller control, manoeuvring
and ship handling capabilities
Thruster control is often by a Uni-lever system. See
paragraph 2.10.
The tugs are very seaworthy and, as said, the typical bow
design results in hardly any waves or spray coming on the
foreward working deck. In case waves are coming from aft
or from abreast, the transom and low aft deck may result in
waves coming over the aft deck.
There are mainly two tug types:
•	 Tugs for berthing and unberthing. The assising method
is usually push-pull and direct towing at the bow.
•	 Tugs for escorting as well. These powerful tugs are able
to operate even in stormy weather. As mentioned above,
free-sailing speed of the escort tugs should be high and
can be even be 15 knots or more. The tugs don’t make
fast during escorting of ships.
Figure 2B.36: FLNG Prelude; assisting tugs with long steep towlines.
Photo: Shell International Ltd
Figure 2B.37: Tug Oghi with forward working deck, no handrail.
Photo: Piet Sinke
Figure 2B.38: Tug Sagami with forward working deck. Deck crew with
safety jacket and helmet. Photo: Piet Sinke
Figure 2B.40: An azimuth thruster from Niigata, Japan.
Source: Niigata, Japan
Figure 2B.39: Tug’s transom extending under the waterline.
Photo: Piet Sinke
Types of Harbour Tug 37
tractor tugs, they have two azimuth propellers fitted under
the stern at roughly the same location, about 0.1 x LWL from
the stern.
Skegs of ASD-tugs have developed during the past years,
consequently ASD-tugs have different skeg types. See for
instance figures 2B.43a and 2B.43b and paragraph 4.2.2.
The azimuth thrusters of ASD-tugs are made by the same
manufacturers as the azimuth thrusters of tractor tugs. Their
maximum draft is less than that of comparable tractor tugs,
as mentioned when discussing reverse-tractor tugs. They
may be equipped with a tunnel bow thruster, especially when
used for offshore operations. Tunnel bow thrusters are not
very effective when a tug has speed ahead, but are very useful
for position keeping. There is a large interest in this type
of tug because of their manoeuvrability and multipurpose
capabilities. Sometimes an azimuth bow thruster is installed
– as is the case with the 4,000hp ASD-tug Erin McAllister of
McAllister Towing and Transportation Company, USA. A
retractable azimuth bow thruster of approximately 1,000hp
was installed, so increasing the tug’s manoeuvrability, its
position keeping abilities, maximum bollard pull ahead and
astern and maximum achievable sideways thrust.
A very few ASD-tugs have only one azimuth thruster at the
stern – for instance, the converted US Navy YTBs (yard tug
boats) Kaleen McAllister and Donal G. McAllister.
There is a large variety in ASD harbour tugs with respect to
design, size and bollard pull. ASD-tugs may have different
brand names, such as the RAmparts series of tugs designed
by Robert Allan Ltd, of Vancouver. Another specific name
for an ASD-tug is the Azistern tug designed by Offshore Ship
Designers in the Netherlands. Azistern tugs can be delivered
with lengths of 24-37m and bollard pulls of 60-120 tons.
Glosten, Seattle, designed a new ASD-tug type, the HT-67,
a 20.4m long tug for versatile service on inland and near
coastal waters. The tug has an aluminium deck house, towing
winch and stern roller. And Sanmar Shipyards, Turkey, has
the Yeniçay class tugs – small tugs with a length of 18.7m and
a bollard pull of 30 tons.
A new concept is the Schottel SYDRIVE M which can for
longer sailing distances, connect the port and starboard
azimuth thruster, allowing both thrusters to be driven
together by only one of the main engines. This leads to
reduced operating hours of the main engines, resulting in
lower maintenance costs, less fuel consumption, and lower
Escorting is compulsory around Japan for ships with
hazardous cargoes or a certain length.
Exept for Tokyo Bay escorting can be carried out by any type
of ship, provided the ship is equipped with FiFi equipment,
which means in practice that all escorting is done by
tugboats.
Escort tugs do not make fast to the ship but stay standby at
short distance to the ship, unless tug services are needed.
Indirect towing is not an option for the relative small beam
tugs. It can even be dangerous.
The specific design has a number of large advantages:
They can work under the large flares and overhanging sterns
of particulary large container vessels.
The flared bow has bow has a large radius, which reduces the
pushing forces on ships’ hulls.
Due to the typical flared bow a large working deck is
created enabling the crew to pass the towline to the ship to
be assisted, or to retrieve the towline, in a handy way. See
figures 2B.37 and 2B.38.
Due to the aft positioned forward fairlead the tugs can
operate somewhat better than other tug types with steep
towlines, which is often the case in dockyards. See figure
2B.36.
2.9 Azimuth Stern Drive (ASD) tugs
2.9.1 Design
Conventional tugs have certain advantages and so do
reverse-tractor tugs. ASD-tugs are nearly the same as
reverse-tractor tugs but are designed in such a way that
they can operate like a reverse-tractor tug as well as a
conventional tug, thus combining the advantages of both
types. ASD-tugs have a towing winch forward and a towing
winch (can be optional) or towing hook aft. Some ASD-tugs
have only one winch which is capable to operate over the bow
as well as over the stern. When operating over the stern the
towline runs via a trunk through the deckhouse to aft. This,
for instance, is the case with the TundRA 3000 ice class tugs
for Svitzer and the ASD 2312 tug Jupiter of Boluda Towage
Europe. The winches of these tugs are located in an enclosed
area in the superstructure.
The aft towing point is at a suitable location for towing on
a line, namely 0.35-0.4 x LWL from the stern. Like reverse-
Figure 2B.41: Photo clearly showing the bilge keels, bow fenders with
tyres, and just a small skeg aft can be seen. Source: Tokyo Kisen
Figure 2B.42: Hong Kong tug braking ship’s speed. Source: Alan Loynd
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
Pgua_Supplay
Destacar
38 Tug Use in Port
 2.9.2 Propeller control, manoeuvring
capabilities and ship handling
Propeller control is the same as with azimuth tractor tugs,
either control of each thrusters separately or by Uni-lever
or master pilot system. An example of the Uni-lever system
is shown in paragraph 2.10. See also note about thrusters
handling at the end of paragraph 2.62.
Th e manoeuvring capabilities of free sailing ASD-tugs and
reverse-tractor tugs are shown in fi gure 2B.44, over page.
Th ese tugs can deliver thrust in any direction, though
maximum stern thrust is some 5 to 10 per cent less than on
ahead.
Conventional tugs are eff ective as forward tugs towing on
a line, while reverse-tractor tugs are eff ective aft and are
also very suitable for push-pull operations. ASD-tugs are
very eff ective and suitable for all kinds of ship handling,
owing to their ability to assist like both a reverse-tractor
tug and a conventional tug. When towing forward on a line
like a conventional tug (see fi gure 2B.45, 1, opposite page)
the ASD-tug is very eff ective, although the risk of girting
exists. Th e risk is minimised when the tug is equipped with a
reliable quick release system.
As a stern tug on a line an ASD-tug works over the bow
(situation 1 and 2). Th is is eff ective for speed control and
course control to both sides. Eff ectiveness when assisting in
indirect mode (situation 2) is generally somewhat less when
compared to VS tractor tugs, but ASD-tugs may be somewhat
more eff ective when direct pulling (situation 1).
Like reverse-tractor tugs, ASD-tugs can also easily change
from towing on a line to push-pull without releasing or
changing the towline position (situation 3). Th e forward
ASD-tug should then assist like a reverse-tractor tug
(situation2) which is very oft en the case. A bow thruster is,
as for a reverse-tractor tug, useful for bringing and keeping
emissions. Th e 30m long ASD-tug of Ramparts 3000 design
with a bollard pull of 65 tons, equipped with this system,
is ready for operation in the Port of Aarhus around mid
2021. Please see: https://www.youtube.com/watch?v=b-
Ho4CULVvQ
Figure 2B.43a: ASD3212 – tug Mars, LOA 32.70m, BOA 12.82m, BP ahead 82.5 tons, BP astern 76.1 tons, fi xed pitch propellers. Source: Damen Shipyards
Figure 2B.43b. ASD-tug 2312 with twin skegs.
Length 23m; beam 12m; high freeboard.
BP ahead 70 tons, bp astern 65 tons.
One winch for operations forward and aft. Bridge with safety glass.
Twin skegs: increase course stability when sailing astern, increase
turning moment, reduce interaction between thrusters and skegs, more
forward lying point of application of hydrodynamic forces increase
performance in indirect mode, increase performance when operating
bow-to-bow. Note: black lines underneath the tug are pipes for engine
cooling, this instead of box coolers. Source: Damen Shipyards
Pgua_Supplay
Destacar
Types of Harbour Tug 39
Figure 2B.44, left: Free sailing manoeuvring capabilities of an ASD-tug and reverse tractor tug.
Figure 2B.45, above: Some assisting methods with an ASD-tug.
Figure 2B.46: ASD-tug
Smit Seine (LOA 28.67m,
beam 10.43m; bollard pull
ahead 60 tons, astern 57
tons) assisting Maersk
McKinney Moller in the Port
of Rotterdam. ASD-tugs are
mainly operating over the
bow; Smit Seine is
operating over the stern.
Photo: Martin Menninga,
KotugSmit
40 Tug Use in Port
This is in particular the case on tugs in Western Pacific ports
– Korea, Japan, China and Taiwan. Attention will therefore
be paid to the Uni-lever system often found on these tugs,
namely, the Niigata Uni-lever control system. A cross section
of a Niigata thruster with the most essential parts, such as
input shaft coupling, rope guard, propeller, nozzle, etc, is
shown in figure 2B.40.
Figure 2B.47 shows the various settings of the Uni-
lever control handle and the corresponding thruster
configurations and tug movements. On the right is the main
engine speed control handle.
Figure 2B.48 shows separate controls of the same make,
which can be found on similar tugs not having a Uni-lever
system.
the tug’s bow in position at the ship’s side. For this kind of
operation a towing winch is very useful in order to control
the length of the towline and to pick up the slack when
necessary. ASD-tugs are also very suitable for assisting at the
ship’s side, because of their high reversing power and their
360° steerable thrusters.
If an ASD-tug is equipped with an azimuth bow thruster,
then the manoeuvres discussed can be performed faster and
more effectively.
2.10 Uni-lever system
Although most often separate controls can be found on tugs
with azimuth propulsion systems, many tugs are equipped
with a Uni-lever or master pilot thruster control system.
Figure 2B.47: Uni-lever system, Niigata.
Source: Niigata, Japan
Figure 2B.48: Separate controls for each
thruster: either two GSO Levers for fixed
pitch propellers or two GSP control for
controllable pitch propellers.
Source: Niigata, Japan
Pgua_Supplay
Destacar
Types of Harbour Tug 41
Most Rotortugs have standard winches and fixed pitch
propellers. Only four have controllable pitch propellers of
which the latest is Serco’s tug SD Tempest.
Depending on the requirements, Rotortugs may have also
have fire-fighting capabilities.
The azimuth thrusters, engines and winches are
manufactured by the same equipment manufacturers and
the Rotortugs are built at the same shipyards at similar rates
as ASD and tractor tugs. Their distinguishing features relate
to active steering and braking forces which can be provided
in both direct and indirect mode over the full 10-0 knots
speed range, their versatility, and their ability to operate in
confined spaces such as locks and bridges – as is to certain
extent also the case with fast tugs and the present compact
ASD-tugs of 24m length.
2.11.2 Rotortugs in use
The first generation Rotortugs were RT Innovation, RT
Pioneer, RT Spirit and RT Magic. These tugs are still
operational in Bremerhaven and Mozambique today.
Rotortugs can be found in several large European ports,
and also in ports in Australia (Port Hedland), some USA
ports, and Africa. Sometimes the tugs are owned by separate
towing companies or by a joint venture with Kotug. In mid-
2018 there were 44 Rotortugs operational and 12 being built.
2.11.3 Propeller control and manoeuvring
capabilities
Propeller control is similar to that of azimuth tractor and
stern driven tugs, with individual thruster control units
controlling respectively thruster steering and propeller
revolutions or pitch (the latter if applicable). Rotortugs with
fixed pitch propellers are fitted with speed modulating
slipping clutches.
During fire-fighting duties the portside thruster is fully
disengaged and the portside engine is used to drive the
fire-fighting pump. This arrangement has a significant
station-keeping advantage over other main engine driven
fire-fighting pump arrangements.
Thanks to the third thruster, and in some cases also to the
second towing winch, and consequently to the double-
ended control ability, capabilities of Rotortugs are superior
to those of other tug types. The Rotortug’s manoeuvring
characteristics enable tug masters to provide fast reaction
times. The tugs can compensate safely for the interaction
effects working on the tug and the towing points at both ends
of the tug create safe working tugs.
In this section the related tug types as mentioned in table
2A.1 will be discussed:
•	 The Rotortug.
•	 The Z-Tech tug.
•	 The RSD tug.
•	 The Carrousel tug.
•	 The DOT tug.
Why the name ‘related tug types’? This is because the
capabilities of these tugs can to a large extent be compared
with the basic tug types discussed in Chapter 2, part B.
2.11 Rotortug
2.11.1 Design
Rotortugs are triple azimuth thruster driven tugs with the
thrusters arranged in a triangular configuration with a
towing – or escort – winch forward and a towing winch
aft. Basically it is a conventional tractor tug with azimuth
thrusters, and the skeg replaced by a third azimuth thruster.
This creates the possibility to design a versatile tug with
unique capabilities for ship handling and with good active
steering and braking capabilities.
Since the first Rotortug concept, Robert Allan Ltd has
exclusively designed Rotortugs of various dimensions and
designs. The company’s research capabilities mean they
are able to optimise hull forms and course controllability
characteristics for sailing ahead, astern and transverse.
Combined with about 20 years of operating experience
with the first Rotortugs, the latest generation of Rotortugs
are called ARTs (Advanced Rotortugs) and provide a
sophisticated design.
Main dimensions of three ART tug types :
The ART(W) (Advanced Rotortug Wide body) is a tug
with a larger beam, such as the ART 85-32W designed
for operations in Port Hedland. Increasing a tug’s width
increases stability. The point is, however, that with ASD-
tugs the propulsion units counteract the heeling angle in the
indirect mode (see Tug Stability. A Practical Guide to Safe
Operations), while with the Rotortugs the thrusters increase
the heeling angle (see figure 2C.3). On the other hand if
the heeling angle becomes too large it can be decreased by
lowering the thrust.
Type ART 65-28 ART80-32 ART 85- 32W
Length 27.50m 31.95m 31.5m
Beam 12.50m 12.6m 13.8m
Bollard Pull 65 tons 80 tons 85 tons
Chapter 2
PART C
Related tug types
Pgua_Supplay
Destacar
Pgua_Supplay
Oval
Pgua_Supplay
Seta
42 Tug Use in Port
Rotortugs can operate in various ways, whether when towing
on a line or operating at the ship’s side. The tugs can always
operate bow-first, both as sternand as bow tug., They have
good tug control capabilities when operating around the
bow of a ship at speed or in the ship’s propeller wash. This
feature makes them especially suited for center lead forward
and center aft operations. Furthermore, the third azimuth
thruster provides additional redundancy.

A Rotortug’s aft towing point is located perpendicular above
the centre line of the aft thruster, providing easy course
control of the tug as bow tug. The tug’s large side-stepping
capability is of great help for repositioning of the tug. When
operating as stern tug, the tugs can provide relatively high
steering and braking forces in the direct mode up to 10 knots
speed, which is also called combination-arrest mode. When
operating in this mode there is hardly any heel.
Rotortugs can provide active steering and braking forces
between 6 and 10 knots using both direct thruster forces and
hydrodynamic lift forces; the latter in the indirect mode.
Performance in the direct and indirect modes are shown in
figures 2C.4 and 2C.5, opposite page.
Figure 2C.1: Rotortug ART 80 32. Left: side view, middle: aft view, right: forward view. Source: Rotortug
Figure 2C.2: Forward tug applies the method of rotoring. Photo: Rotortug
The tugs use a specific manoeuvre at low ship’s speed – what
is called ‘rotoring’. With rotoring, steering forces can be
applied within the beam of the assisted ship which is of
great help in confined spaces such as locks and when passing
bridges (see figure 2C.3). This furthermore creates the
possibility of operating with fewer tugs during most weather
conditions.
In this way the first generation Rotortugs assisted high
windage car carriers through the locks in Bremerhaven.
With rotoring with the towline fastened forward (at the end
with the two thrusters) the tug can generate a force of 70 per
cent of the tug’s bollard in transverse direction to the ship’s
centre line with quick response to the pilot’s commands.
Rotoring can also be applied during mooring operations. In
doing so the ship can be brought as close as possible to the
quay or jetty (see figure 2C.2).
There are some aspects to keep in mind. Three thrusters
within a relatively short distance of each other may
cause some loss of effectiveness due to thruster-thruster
interactions, depending on the thruster settings. Thrusters
underneath the hull will, as with normal tractor tugs,
increase the tug’s resistance.
Types of Harbour Tug 43
To benefit from the Rotortug’s capabilities it is highly
recommended that tug masters follow a specific Rotortug
training before they start operations. Tug handling with
three thrusters can be challenging without prior instructions
and training.
Kotug has a Rotortug simulator with a 360° arc of view,
where training is given in handling a Rotortug, as well as ship
handling with the Rotortug. With this simulator an optimal
training can be given to new and experienced tug masters.
Furthermore, Kotug has a 15m long training Rotortug – see
Chapter 8, Training and Tug Simulation.
Figure 2C.3: Various Rotortug manoeuvres with related thruster settings.
 Figure 2C.4: Comparison performance Rotortug with ASD-tug.
In the 4-8 knots speed range the Rotortug performs better and above 8
knots the ASD-tug performs better. Note: For an explanation of various
assist modes, see escort chapter. Source: Kotug
Figure 2C.5: Performance diagrams of Rotortug ART80-32, LOA 31.95m,
beam 12.60m, BP 80 tons, operating as stern tug in direct (yellow) and
indirect (red) mode at 8 knots speed.
44 Tug Use in Port
2.11.5 FLNGs and tugs providing in-field
support
Three Rotortugs ART100-42, called in-field support vessels
(ISVs), were specifically built for the Prelude FLNG
(floating liquefied natural gas) project. Another ART100-
46 was built for the ConocoPhilips Bayu Undan Field. The
ART100-46 tug RT Raven was launched in January 2018.
The number of scheduled FLNG projects, and consequently
ISV requirements, is gradually increasing with global energy
demands.
The ART100-42 tugs have a length of 42m, width 16m,
maximum draft 7.40m, bollard pull 100 tons and are
equipped with FiFi1 with water spray. The ART100-46 (LOA
47m, beam 16m) is fitted with DP2 capacity and has similar
characteristics; an additional length of 5m provides, with
a retractable towing fairlead, more deck space aft and gives
additional support capability.
ISVs provide a range of services and are generally customised
to suit each project’s requirements. Their capabilities include
(but are not limited to):
•	 Assisting gas carriers coming alongside the FLNG for
loading and when leaving.
•	 Emergency response. The ART100-42 is able to
accommodate 85 people in case of an emergency on
board the FLNG which involves people having to leave
the vessel.
•	 Condensate hose-handling and maintenance.
•	 Safety stand-by and surveillance.
•	 In-field cargo and personnel transfer.
•	 Dive and ROV support.
Also in wave conditions, gas carriers have to be brought
alongside. This can, in particular, be a problem when pushing
at the ship’s side. The tugs should be able to push in such a
way that the fenders don’t get damaged and the hull pressure
on the gas carrier does not get too high. The Rotortug ISVs
with their propulsion units arrangement below the bottom
should be able to do so up to a certain wave height/period.
When sea conditions worsen, the tugs can then tow on a line
and use the method called ‘rotoring’, mentioned above.
2.11.4 Summarising
The advantages of the tugs are:
•	 Excellent manoeuvrability, which includes among other
things turning on the spot with a high rate of turn,
astern speed equal to ahead speed and a side-stepping
speed of approximately six knots.
•	 Fast positioning and re-positioning and a large variety of
assist modes with short response times.
•	 A high bollard pull or, alternatively, the same bollard
pull with less draft, compared to a normal tractor tug
with two azimuth thrusters.
•	 High side thrust up to 95 per cent of bollard pull to assist
vessels through narrow passages, locks and bridges.
•	 Better reliability because two units bring sufficient
manoeuvrability and bollard pull for day-to-day ship
handling work; in case of breakdown of an engine, the
tug is still operational and repairs can be postponed
until a suitable time.
•	 There is hardly any risk of damaging the azimuth
thrusters on the bulb of an assisted ship as can happen
with stern drive tugs, due to the thruster location and
protection.
•	 Safe tug for operations near the bow of a ship having
speed.
•	 Specific assist modes that can be utilised by a Rotortug
enable them to operate within the breadth of a ship,
reducing the number of tugs normally required, and
bring ships as close as possible to the quay.
•	 Dynamic positioning systems can be installed for
offshore operations.
•	 Escort work with high towline forces is possible over the
stern as well as over the bow of the tug at relatively high
speeds.
The Rotortug is a highly manoeuvrable and reliable tug
and can generate high towline forces. But it is also a rather
complex tug with its three thrusters and two winches,
which does increase underwater resistance and may affect
purchasing and maintenance costs compared to various
other tug types.
 Figure 2C.6: RT Evolution in the indirect assisting mode
at 8 knots speed. Photo: Rotterdam pilot Marijn van Hoorn
 Figure 2C.7: RT Evolution in the direct assisting mode
at 6 knots speed. Photo: Rotterdam pilot Marijn van Hoorn
Types of Harbour Tug 45
Since the first Z-tech tug based on practical experience, the
tug has undergone modifications such as with the skeg which
was first closed and is now open.
By mid-2017 Cheoy Lee Shipyards had built 45 Z-tech
tugs, from 60-70 tons bollard pull, and 27-30m in length.
At the same date, there were approximately 70 Z-tech tugs
worldwide.
As with theASD-tug, the skeg provides directional stability
when sailing astern and does not impede ahead steering
performance and or create too large additional interaction
forces when coming alongside a ship at speed.
The Z-tech tugs built for the Panama Canal are specifically
adapted to the operational needs of the Panama Canal
Authority. These include:
•	 A wider beam in order to ensure a higher clearance
angle when working under the flare of ships.
•	 The height of the wheelhouse is lower than on other tugs
of this class.
•	 Two independent winches, because the tugs use two
towlines.
•	 A dayboat accommodation arrangement.
Developments of Z-Tech tugs are continuing. In May 2017,
USA-based Bay-Houston Towing Co. and Suderman &
Young Towing Company awarded construction contracts to
Gulf Island Shipyards for four Z-tech 30-80 class terminal/
escort tugs of 80 tons bollard pull for each company; tugs
to be designed by Robert Allan Ltd. with sponsons to suit
the Z-tech hull form. CFD (computational fluid dynamics)
simulations demonstrate escort capabilities increase by 15
per cent compared to the original Z-Tech.
The Prelude is a 488m long floating unit which will be
stationed 230km off the Australian cost in 240m deep water
for 25 years and will operate continuously in terms of gas
processing and the loading of LNG, LPG and condensate
tankers. For such a project, specific tugs are needed, because
the tugs have to operate during a long time in remote areas
where redundancy is of great importance and local wind and
sea conditions play an important role.
2.12 Z-tech tug
2.12.1 Design
The Z-tech tug can be found in many ports and is an iniative
of PSA Marine, Singapore. They consulted with the tug
masters, crew and operation managers on their operational
needs and specific requirements. It became clear that some
had a distinctive preference for tractor-style tugs while
others preferred the ASD type. The solution was to develop a
single design that would incorporate the best characteristics
of both the tractor and ASD type tug. In 2003 the first Z-tech
tug was born, designed by Robert Allan Ltd.
The Z-tech tug is especially configured to allow to work
closely under the extreme flares of large container vessels,
although the Singapore tugs handle all kinds of vessels, such
as bunker barges, coastal tankers with very low freeboard,
car carriers, bulk carriers, tankers and handle oil rigs as well.
Still leaving sufficient room to install/withdraw the thruster
units , the wheelhouse is situated well aft, which means
towards the thrusters, creating a relatively large working
deck forward and enabling the tug to work close to a ship.
The working deck is furthermore free of anchor chains,
because anchors are located at the thruster end of the tug.
Because of the need to work in either push or pull mode
under the flare ends of large container ships and car carriers,
the Z-tech tug also has a flat forward sheer and a wide,
heavily fendered bow, which is the skeg-end of the the tug.
The stern of the the tug has a strong vertical sheer to creat
good sea-keeping capabilities. According to PSA Marine,
speed and bollard pull astern are at least 95 per cent of that
going ahead.
Figure 2C.8: Z-tech tug Star Ruby, owned by PSA Marine.
Photo: Piet Sinke
Figure 2C.9: Z-tech tug 6500 class tug built for service in the Panama
Canal and approaches. LOA 27.40m, beam 12.20m, BP ahead 65 tons.
See also double winches forward. Courtesy Cheoy Lee Shipyards
46 Tug Use in Port
to some extent with a reverse-tractor tug. These tug types
usually have only one winch and do ship handling only by
the towing winch and towing staple at the skeg end, which
is the bow for the Z-tech tug and reverse-tractor tug and the
stern for the ATT. On an ATT and Z-tech tug the working
deck is rather flat, and no anchor winch limits the working
place.
ATTs and Z-tech tugs sail ‘skeg first’ or ‘thrusters first’
depending on the situation. At somewhat longer distances
and in sea conditions, the Z-tech and the tractor tug sail
‘thrusters first’ with the higher deck forward. The Z-tech tug
and several tractor tugs can manoeuvre well with the skeg
end under the flare or overhanging stern of a ship.
How Z-tech tugs operate in, for instance the Port of
Singapore, can be seen in figure 2C.10 which shows how the
tugs approach a ship and how they make fast.
2.13 RSD tug
2.13.1 Design and manoeuvrability
The RSD (Reverse Stern Drive) tug is a new tug type designed
and built by Damen Shipyards. It is a new concept which
combines the advantages of both ASD-tugs and ATD-tugs,
as was the orginal idea for the design of the Z-tech tug. The
forward end of the RSD tug is the thruster end.
The skeg generates extra hydrodynamic forces on the tug
when operating in the indirect mode and shifts the centre
of hydrodynamic forces more in the direction of the towing
point. When the tug is operating in the indirect mode the
effect of a skeg on the steering forces that can be delivered is
largest when the towing point is, horizontally seen, as close
as possible to the location of the centre of hydrodynamic
pressure on the tug’s hull. On tugs such as the Z-tech tug
and the ASD-tug, due to their design and skeg location with
respect to this an ideal situation is difficult to realise. This is
further addressed in the Escort chapter.
Furthermore, the distance between this hydrodynamic
centre of pressure centre and location of the propulsion units
should be as large as possible. Of course, the vertical distance
between the centre of pressure and the towing point should
be as small as possible in order to reduce heeling angles.
2.12.2 Propeller control and manoeuvring
All Z-Tech tugs built by Cheoy Lee Shipyards Ltd – and as
far as is known by other yards as well – are fitted with fixed
pitch azimuth thruster without speed modulating clutches,
although Z-tech tugs built for the Panama Canal Authority
have such a facility, called an MCD (marine control
device). The thrusters have separate controls, one on each
port and starboard wheelhouse console.

Seen from an operational point of view, the Z-tech tug can
best be compared with an azimuth tractor tug (ATT) or
Figure 2C.10:
General Z-tech
manoeuvres for
approaching
a ship and
passing a
towline.
Types of Harbour Tug 47
As indicated above, there are similarities with the Z-tech tug.
Th e tug manoeuvres shown and mentioned for the Z-tech
tug can be carried out in the same safe way by an RSD tug.
2.14 Carrousel tug
Th e basic principle of a carrousel tug is a radial system. New
with the system as applied on the carrousel tug is that it is
not a half-circle, or less, but a full circle and has basically a
diameter equal to the tug’s beam.
Th e radial system itself is not new. It has been applied for
decades on several harbour tugs and in former times on tugs
on the River Rhine. With a radial system, a tug’s heel due
to a transverse towline force is limited. Performance and
safety of several conventional tugs has thus been increased
signifi cantly. Th e carrousel is initially situated above the
lateral centre of pressure for a crosswise water fl ow. Th e
advantages of the carrousel are:
•	 Th e tug can safely cope with large towline forces
generated by the hydrodynamic forces working on the
tug hull, while heeling angles are smaller than without
such a system. Capsizing due to high athwart ships
towline forces is not possible.
•	 It enables the tug to turn freely, in no way restricted by
the towline coming in contact with the superstructure.
•	 In addition, it off ers the possibility to use highly effi cient
and robust conventional shaft propellers and turn the
whole hull including propulsion in line with the towline
force instead of turning only the thrusters.
Th e fi rst aspect is related to speed. Th e higher the speed the
higher the forces that can safely be generatedin the towline
and applied to the ship to be assisted. Also, high braking
forces can be achieved because the system enables a stern tug
to operate safely broadside behind the ship.
Th e second aspect is not related to speed. It greatly enlarges
the capabilities of particularly conventional tugs and combi-
An ASD-tug when sailing astern, for instance in the case of
bow-to-bow operations, has the disadvantage that the stern is
not designed as ‘bow’. Th e same applies when a tractor tug is
operating as a stern tug on a line.
Bow and stern of the RSD are about of equal height. Th is
enables the tug to operate safely as a bow tug. It then operates
like a real tractor tug and also like a reverse tractor tug,
which is an ASD-tug operating over the bow. Th e latter has
the disadvantage of the low stern facing the incoming water
fl ow and incoming waves.
Bow and stern of equal height also enables the tug to operate
safely as stern tug on a line. As such, it will operate as a
reverse tractor tug (ASD-tug operating over the bow) with
the skeg forward and as a real tractor tug. Th is tug (ASD-tug
operating over the bow or tractor tug) has the diasadvantage
of having the low stern in the direction of movement, so
facing the incoming water fl ow and waves with the low stern.
It could be said that the RSD tug has two bows.
Th e tug has furthermore a twin fi n, as has been discussed
with the azimuth tractor tug. It creates a highly
manoeuvrable compact ship-handling tug with perfect
steering behaviour both sailing ahead and astern. Th e tug
has also a very good sea-keeping behaviour.
Tractor tugs are safe when operating near the bow of a ship
at speed. Th is applies to the RSD-tug as well, because when
making fast at the bow it will sail thrusters fi rst, like a tractor
tug, and in doing so it can overcome the interaction forces.
It would be good to consider this tug type as a safe
replacement for an ASD working over the bow. In addition,
when the topmast is taken down, the tug is suitable to
work under the overhanging fl are and stern of large ships,
especially container ships.
Th e fi rst RSD-tug is the RSD tug 2513, with a LOA of 24.75m,
a beam of 13.13m, power 4,480bkW, bollard pull ahead 70
tons, astern 67 tons. New designs are being developed.
Figure 2C.11: The RSD (Reverse Stern Drive) tug 2513.
Source: Damen Shipyards
Figure 2C.12: Complete view of the RSD tug 2513.
Source: Damen Shipyards
48 Tug Use in Port
in ship’s speed and a turning moment, which should be
avoided.
Carrousel tug designs, accurate model studies for the
optimum location of the carrousel in relation to the
locations of centre of pressure at different angles of inflow,
focusing on such aspects as the overall behaviour and
optimum performance of the carrousel tug when towing,
while appropriate reserve buoyancy, freeboard and hull
shape, and in particular safety of operations and safe limits,
should be studied as well. Further aspects to be considered
are workable heel angles, safe abort manoeuvres and
performance in wave conditions.
While high steering forces can be generated, attention is also
needed to determine whether high and controllable braking
forces can be delivered without giving the ship a rate of turn
if the latter is not wanted.
tugs. It creates the possibility to turn the tug freely with
respect to the direction of the towline, for instance enabling
a stern tug to apply steering assistance to starboard as well as
to port at a ship having headway. The lack of this capability
is a large disadvantage of conventional tugs. If necessary for
some reason, the tug can turn 180° with the towline attached.
Advantages with respect to stability will be dealt with in
paragraph 4.2.3.
Development of first carrousel tug Multratug 12
In 2000 plans started to investigate the carrousel principle
on a real-size vessel. As test tug, an existing conventional
combi-tug was selected for conversion. In 2001 various
model test were performed.
In 2002 Multratug 12 was converted into the first carrousel
tug by removing part of the accommodation, by adding a
large rectangular deck box as support for the carrousel and
additional buoyancy.
Since 2002 the tug has been in operation and demonstrating
the remarkable dynamic performance, however, limited by
the small installed engine power and the tug age.
Model tests
As mentioned before, model tests have been carried out with
a model of the Dutch combi-tug Multratug 12 (see figure
2C.13). Right below the carrousel two vertical skegs were
fitted, representing full scale skegs with a length of 6m and a
depth of 0.4m. Each skeg was located at a quarter of the tug’s
width from the side.
High towline forces were achieved during model testing at
Delft University of Technology, as shown in figure 2C.14.
Full scale tests
Full scale tests have been carried out with the tug Multratug
12 fitted with a carrousel and with skegs as used for the
model tests. The tests confirmed the working of the system
as well as the forces measured during the model tests. Even
higher towline forces could be achieved due to a more stable
position of the full scale tug. The photo (figure 2C.15, over
page) shows the carrousel tug applying steering forces.
Aspects that require attention or further study
As the carrousel is now in a phase of further employment,
some aspects require attention, although a number of the
aspects to be mentioned have already been addressed in
newer designs. Aspects requiring attention are:
•	 The lead of the towline for all possible ships to
be assisted, assist manoeuvres, conditions and
circumstances, needs to be considered.
•	 Safety of deck operations, including efficient and safe
towline handling under all working conditions and with
minimum crew, requires attention.
•	 The possibility to install an appropriate towing winch,
strong enough to withstand the high towline forces that
can be generated, needs further study. A towing winch
is of particular importance when the carrousel tug will
also be used for escort operations.
•	 The carrousel requires a constant tension in the towline,
because for most tug manoeuvres even a small constant
tension in the towline may create an unwanted increase
Figure 2C.13: Combi-tug Multratug 12 (LOA 28.5m, beam 6.6m, BP 21
tons, retractable bow thruster 450hp).
Figure 2C.14: Towing forces based on model tests with a model
of the 21 tons BP tug shown in figure 2C.13.
Types of Harbour Tug 49
The DOT and the Allrounder tug discussed in the next
paragraphs have a comparable system.
As it is a very safe system that increases the capabilities of
particularly conventional tugs, but also of other tug types
such as the ones with one propulsion unit forward and one
aft, more applications may be seen in the future.
2.15 DOT tug
The DOT (Dynamic Oval Towing)-tug is a conventional
tug type with a movable towing point which is realised by
a heavy rail around the superstructure along which the
towing hook (or towing point) can travel. The system allows
the tug to turn in any direction with the towline fastened;
consequently the tug can pull either over the bow or over the
stern without releasing the towline. Furthermore, the system
prevents capsizing of the tug when the towline under high
tension comes at right angles to the tug. Basically the DOT
system is the same as the movable towing point system on a
carrousel tug. As can be seen with Multratug 12 the original
carrousel system is located at a lower height above the deck,
which results in smaller heeling angles.
A small number of DOT tugs have been built, mainly smaller
conventional tugs.
2.16 The All-Rounder AR360T
A recently specifically designed conventional tug type with
a movable circular towing point like the carrousel is the
All-Rounder.
The All-Rounder 360 Tug (AR360T) is a high-powered twin
propeller shaft compact tug equipped with an all-around
radial winch support anda new hull shape to enhance
hydrodynamic forces. Hereby effective towing and braking
performance can be achieved at bow and stern of ships from
zero speed to making headway without risk of capsizing,
apart from the pushing and pulling capabilities at the ship’s
side. Aiming at port operations, escort tasks and ship to ship
assistances.
Carrousel tug applications
Basically the carrousel tug makes effective use of the
hydrodynamic forces working on a tug hull, which means
that with increasing speed towline forces increase. When
speed decreases the effectiveness of the carrousel tug
decreases. This is in contrast with the requirements for
tug assistance in many ports. In harbour operations tug
assistance is generally needed at speeds below approximately
six knots. Full tug power is then often needed for steering,
braking and controlling a ship’s position. This means that for
a carrousel tug, bollard pull is an important factor as well.
The carrousel tug is not specifically designed for tug
operations at the ship’s side as applied in many ports
around the world. For this operating mode, tugs with
omni-directional propulsion systems and a towing point
at the tug’s end are most suitable. However, the carrousel
system can improve the capabilities and safety of operations
of harbour tugs to a large extent and particularly of the
conventional type of harbour tugs and of combi-tugs. As
a forward or aft tug, among others, high steering forces
can safely be handled, while the tug is not restricted by the
direction of the towline.
Basically, the carrousel tug design can most effectively be
applied in situations where tug assistance is required during
a transit, such as in channels, fairways and port approaches,
more or less as an escort tug. However, if sufficient bollard
pull, it can be used during mooring/unmooring operations
as well. The carrousel tug Multratug 12 showed remarkable
dynamic forces, but was limited in bollard pull due to the
small installed power. However, in a new carrousel tug the
required power can be installed to achieve the requested
bollard pull. This can be done with either conventional
highly efficient propeller shaft lines or with thrusters to
enhance manoeuvrability. For tug operations in confined
spaces a short and wide-bodied twin propeller shaft tug can
be used or, if considered necessary, with twin thrusters.
The carrousel system is also applied on the Carrousel RAVE
Tug (CRT) which is dealt with in paragraph 2.20. The CRT
has one Voith propulsion unit forward and one aft.
Figure 2C.15: Combi-tug Multratug 12 modified as carrousel tug
during full scale trials
Figure 2C.16: DOT tug Ugie Runner.
Source: Macduff Ship Design, UK
50 Tug Use in Port
Operational safety is integrated in the tug design. On the
outside of the accommodation a fixed walkway with hand
railing is mounted. Hereby the crew can observe the deck
situation before entering the deck zone with rotating winch
and towline. Before the crew enters the deck area, e.g.
during making the towline (dis)connection, the winch will
be fixed in position by a parking brake. Simultaneously the
drum brakes are opened to prevent significant loads on
the towline. Before releasing this park brake all crew must
leave the deck area. Both doors to the accommodation and
wheelhouse are positioned at centerline to prevent early
submersion and are clearly visible from the wheelhouse.
Further the tug is also equipped with SaferVents, (See book
‘Tug Stability’ p71) ensuring that even at large heeling angles
the engine room will not be flooded.
Operational training of the crew for this new tug type is an
important factor and for instance simulator training centre
in ALAM (MY) will provide the training including a special
tug model using Wartsila Transas software.
Note:
For more information about the effect of a carrousel system
on stability, please see the book `Tug Stability’ (p47-50).
Summarising: This tug with conventional twin shaft
propulsion, with towards the bow upward sloping central
deck, the seaworthy hull shape, and in particular with the
radial winch support, has become a tug with extensive ship
assist capabilities in sheltered as well in unsheltered waters.
In 2021, the first tug was ordered in Malaysia by owner
Harbour 360 Sdn Bhd and built afterwards at Labuan
Shipyard & Engineering Sdn Bhd.

The tug features compact outer dimensions of 24 m length
and 10 m width and offers a high bollard pull up to 65 ton by
efficient and robust large sized shaft driven twin fixed pitch
propellers in nozzles. The propellers are positioned wide
apart to offer large steering lever in both ahead and astern
conditions. Steering is further enhanced by independent
high lift (flap) rudders and a strong bow thruster.
The tug has a new specific hull design shape with lateral
area centered at half length and upward sloping bow and
stern lateral area in order to facilitate easy turning even
under various flow angles and speeds. Below the tug, two
large skegs are mounted to enhance the hydrodynamic
towing performance and in addition offering protection of
aft propulsion against ground contact, integrated engine
foundation and finally docking support.
The towing installation is mounted on a slightly, towards
the bow, upward sloping central deck enabling significant
accommodation area under the bow deck, easy access from
aft deck and large bow buoyancy (enabling working in
unsheltered waters). For this tug also a new winch type has
been developed with an instant automatic overload release to
prevent high peak loads and prevent towline breaking. The
winch moves around the accommodation on two rail tracks
and distributes the towline load over two carriages. On both
sides of the winch a hydraulic power pack is fitted for the
winch motor and the brakes, operated by remote control.
The whole deck and rail structure has been analyzed in detail
with Finite Element Calculations (FEM) resulting in an
efficient and strong steel structure for easy manufacturing,
building and maintenance.
Figure 2C.17. The All-Rounder AR360T tug
Types of Harbour Tug 51
In both cases, and also when there is a failure with the
thruster at the end where the towline is not fastened, the
other thruster is still available and can be used to try to avoid
an accident, although when operating as forward tug on a
line, the situation might become risky. If the tug is equipped
with a carrousel system, however, these aspects don’t play a
role.
The usefulness and benefits of such new designs have to be
proven during daily practice, not only regarding the design,
but also with respect to training needs. After the initial
design, sometimes modifications take place – as has been
the case with the SDMs andGiano tug. For both tug types,
modifications of the original skegs or number of skegs were
needed.
Although the tugs that are already operational, such as the
SDMs, EDDYs and Giano tug, perform satisfactorily, some
aspects require attention:
•	 In the first place, as mentioned above, the consequences
should be well understood of the fact that the large
power a tractor tug/reverse tractor has at the forward
end of the tug is much less with these FAST tugs.
•	 When free-sailing close to a ship, it should be well-
known how to compensate for the interaction effects
working on the tug, especially near the bow of a ship
having speed. If the wrong thruster is used, it may
introduce the same risks as when a conventional tug is
trying to enlarge the distance between tug and ship’s
hull.
•	 Seaworthiness is another important point requiring
attention.
•	 Skeg-thruster interaction is always an item that requires
attention.
•	 Location of thruster handles: thruster handles should be
positioned such that no mistakes can be made between
which handle is for the forward thruster and which one
for aft.
•	 Quickly stopping a free-sailing tug or makinga crash-
stop: how this should be done in the most effective way
while not diverting from the track or heading – which
can be necessary in busy shipping areas – should be
known for each particular tug type. One tug may set
the CPP propellers on astern with the loss of about 55
per cent propeller thrust (which can be less with specific
propeller designs), or in the case of diesel-electric
propulsion the fixed pitch propeller revolutions may be
reversed, also with a loss astern thrust, or another tug
may turn the thrusters so creating on unstable tug, or
a tug has the same thrust ahead an astern without the
need/possibility to turn the propulsion units.
•	 Fail safe. When a forward tug is towing on a line to assist
a ship having speed, will the tug be in danger in case of
2.17 Introduction
This section deals with tugs with Forward and Aft a Single
Thruster or a single Voith propulsion unit (so-called FAST-
tugs), of the following types:
•	 SDM (Ship Docking Modules) / ATT (Asymmetric
Tractor Tugs)( see paragraph 2.18).
•	 EDDY (Efficient Double-ended Dynamic) tugs ( see
paragraph 2.19).
•	 CRT (Carrousel RAVE Tug)( see paragraph 2.20).
•	 Giano tug ( see paragraph 2.21.)
FAST-tugs differ from all foregoing tug types, although
they could be compared to some extent with a combi-tug or
maybe even more with a Rotortug. With the same power fore
and aft, the handling of these tugs differs totally from the
usual tug types, as does ship handling with these tug types.
Other ways of ship handling are possible, but other risks are
introduced when not being fully trained in handling these
tugs.
There are some important facts to keep in mind with respect
to this type of tug. This is because because at each end of
the tug is only maximum 50 per cent of the total power
available, while tractor tugs and reverse tractor tugs have at
their forward end 100 per cent power available. Where tugs
are under influence of interaction effects, as can be the case
near the bow of a ship at speed, the tractor tugs and reverse
tractor tugs with their 100 per cent power at the forward part
of the tug, can much better compensate for the suction forces
and turning moments working on the tug by steering away
from the ship’s hull or by controlling the heading.
If FAST tugs are designed as hybrids, the power can even be
much less when sailing in economical mode with reduced
power, eg diesel-electric. This can become particularly
problematic when operating close to the bow of a ship
at speed, for instance when preparing to make a towline
connection, due to the interaction effects. With a tractor or
reverse tractor tug redundancy will also be larger, because
when one thruster fails these tugs can often still operate to
some extent.
There are, however, some other aspects. When towing on a
line at an angle at a ship having speed, the less power at the
tug’s end where the towline is NOT fastened has its effect on
the operation. The tug will not be able to veer away from the
ship as far as with a tractor tug or reverse tractor tug. The
hydrodynamic force will become too large and the tug may
swing around, unless other measures are taken to keep the
tug operational, for instance by fast slacking of the towline.
When operating aft in the direct mode, which will be
explained later in the book, a similar effect may play a role.
Chapter 2
PART D
FAST tug types
Pgua_Supplay
Destacar
52 Tug Use in Port
Towing of Tampa acquired two SDMs Mark II in the years
2000-2002, named Florida and Endeavor. Tug Florida has
been renamed as Mobile Point and now belongs to Seabulk
Towing, Florida.
Main particulars
The main particulars of the SDM Mark I and Mark II are as
follows:
Mark I Mark II
Length overall 27,4 m 27,4 m
Maximum beam 15,2 m 15,2 m
Draft 4,90 m 5,0 m
Engine power 4.000 hp 4200 hp
Bollard pull 55tons 60 tons
The main differences of the SDM design compared to other
harbour tugs are as follows:
•	 Shallow flat bottom and an elliptical form.
•	 Very wide beam compared to the more or less normal
length of a harbour tug.
•	 Two azimuth thrusters and two skegs in the following
configuration:
 – One azimuth thruster is located at approximately
a quarter of the tug’s length from forward and at
some distance to starboard from the tug’s centre
line,
 – and the other thruster is located at approximately
a quarter of the tug’s length from aft and at some
distance to port of the tug’s centre line.
 – In the centre line at each end of the tug one skeg is
placed, in total two skegs.
The original idea of the SDM was to have a highly
manoeuvrable harbour tug complying with the following
requirements typical for harbour towage:
•	 Maximum bollard pull in all directions.
•	 Getting in position quickly.
•	 High side-stepping performance.
•	 The possibility to work under the flare of large ships.
•	 Ability to work in confined areas and in semi-sheltered
waters.
a breakdown of one of the thrusters, in particular when
that thruster fails at the geatest distance from the towing
point? How to handle such cases should be known. When
the towing point is changed for this reason, as is the case
on one tug type, one should be careful not to introduce
other risks. In the past, the safe location of the towing
point has been the subject of an extensive study with
Voith tugs
•	 To what extent the effect of the thrusters is reduced
when for instance (sideways) pushing at a ship with
speed or with no speed. The thrusters are then rather
close to the vertical ship’s hull.
•	 Tug handling is not just handling a free-sailing tug,
but knowing how to use the tug in the most safe and
effective way to handle all kind of vessels in a safe and
efficient manner, including the risks involved.
•	 Proper training, because handling of these tugs differs
considerable from other tug types such as ASD or Voith
tugs.
•	 Not only tug masters have to be trained but pilots should
also learn the capabilities and possible limitations of the
new tug types.
•	 Performce in the indirect mode of the FAST tugs
could be compared with performance of, for instance,
Rotortugs to get an idea of the escort capabilities.
•	 Capabilities of the EDDY,Giano tug and SDM could be
increased by the use of a carrousel system as with the
Carrousel RAVE Tug.

Up until now only a few tugs have been built of these FAST
type tugs. The various types are addressed below.
2.18 SDM (Ship Docking Modules)
2.18.1 Design
This type of harbour tug has been developed by Hvide
Marine (USA), now Seabulk Towing in Tampa (USA), and
Elliot Bay Design Group.
Seabulk Towing has three SDMs Mark I and one SDM Mark
II. SDM Mark II is a follow-up of the original SDM design
with the same dimensions but somewhat higher bollard pull.
The first SDM was the New River, delivered in 1997, followed
by St ]ohns in 1998, Escambia in 1999 and the SDM Mark
II Suwannee River in 2000. Towing company Marine
Figure 2D.1: Forward view SDM Figure 2D.2: Side profile SDM
Types of Harbour Tug 53
release towing hook of 50 tons SWL is also fitted for
secondary use. The towing winch is placed beneath the
bridge deck, but can be observed by the tug master through a
window in the deck. The towline, 150m Dyneema with a 50m
long pendant of conventional fibre, can be deployed through
fairleads, one amidships and one right aft. The whole tug
concept is based on having a towing tug capable to produce a
high and equal bollard pull in any direction.
Safety aspects
•	 High stability.
•	 Large working deck aft increases safety of tug crew
during operations.
•	 As indicate above, the deckhouse construction is well
within the bulwarks, which enables the tug to operate
under the flare and/or overhanging stern of ships. Also
the distance of the superstructure to the towing point
avoids the possibility of collision with the vessel be
towed.
2.18.2 ManningThe crew accommodation on the USA SDMs, and in
particular on the Mark I, is minimal. They were initially built
as two-man day boats, but that has never been the case. So,
theoretically, two men can operate the tugs, although on the
Spanish SDMs there is requirement from Flag Authorities of
a crew of three persons in port and six persons outside.
2.18.3 Manoeuvring performance
Free sailing speed is approximately 12.5 knots and a side-
stepping speed of 6.5 knots can be achieved.
Due to the wide beam, stability of the tugs is large and
consequently the tugs can operate safely.
The sides of the tugs are flared in order to provide also larger
righting moments when heeling and to prevent contact
between the tug’s underwater part and the ship’s hull.
The two skegs improve course stability and aid in dry-
docking. There is a hole in the skegs to reduce the difference
in pressure between both sides of the skegs caused by the
accelerated water flow into the forward nozzle and exiting
from the aft nozzle. Without these holes the tug captains had
to correct the tug’s track by steering the aft thruster 5-10° to
starboard.
Loss of effectiveness will be the case when one, or both
thrusters, is operating close to the ship’s hull, which will often
be the case in the USA, where the tugs generally operate in
such a way. This loss of effectiveness may play a role when the
tug is pushing due to the obstructed water flow towards the
SDMs perform indeed well in confined areas as tight slips
and dry-docks.
In 2004 Remolques y Servicios Maritimos S.L. (Reyser), now
P&O Reyser, of Barcelona, Spain, was licensed to construct
five SDMs to be built in Spain. In Spain these tug types were
also named ATT, Asymmetric Tractor Tugs. The five Spanish
tugs are of two classes – see table at foot of page.
All the five units have the same dimensions as the SDMs
Mark II.
The Spanish version is almost identical to the USA Mk II
design with almost identical dimensions, but have a larger
bollard pull and larger crew accommodation. The tugs built
in 2005 have Caterpillar 3516B main engines and the tugs
built in 2008 have MTU main engines . The Caterpillar
engines produce 2 x 2,536 bhp at 1,600 rpm, giving a bollard
peak pull of 74.5 tons (65 tons average). Power from each
engine is transmitted to Rolls-Royce US 205 FP propellers in
fully steerable propulsion units via Twin Disc slipping clutch
units. The Twin Disc speed modulating clutches between
each engine and thruster are of heavy duty type, allowing
for precise propeller speed, even down to zero, irrespective
of engine speed. This is of great benefit for manoeuvring but
also when operating the FiFi1 system. The tugs with MTU
engines have also Twin Disc clutches but Schottel propeller.
Towing winch
The towing winch installed on the Spanish tugs has a
maximum brake holding capacity of 135 tons and a quick
 Figure 2D3: Large working deck aft of SDM Escambia with winch and
two fairleads. See also the ‘soft loop’ fenders made of recycled tyres.
Photo: Seabulk Towing & Seacor Island Lines
Class Name
Zamakona
Hull No
Year Built Operating Port
Main Engines
I Salvador Dalí 611 2005 Barcelona 2 x CAT 3516-1,840 kW @
1,600 rpm. BP 75 tons.I Ramón Casas 612 2005 Barcelona
II Eliseo Vázquez 651 2008 Ferrol 2 x MTU 16v4000M61
2,000 kW @ 1800 rpm.
BP 78 tons.
II Clara G 652 2008 Santander
II Willy T 653 2008 Barcelona
54 Tug Use in Port
View from the wheelhouse
Although the ATTs have an excellent view from the
wheelhouse, a negative point is that the large funnels limit
the all-round view of the tug master and especially in a more
or less athwartships direction, which can create problems
when coming alongside a ship or berth.
This is a problem often seen in other tug designs as well.
In the new ATT version, project ATT2020, this problem
is solved.
Water on deck
One of the other disadvantages of the current design is the
amount of overcoming water when sailing in waves, as the
height at the bow is low, around 3m above the waterline. On
the other hand, the superstructure protects the aft deck very
well, keeping it completely dry. This disadvantage is also
solved in the ATT2020 version.
propellers and in particular when pulling at close distance to
the ship’s hull (see figure 2D.4).
The original SDMs are mainly harbour tugs, which is
included in the name, and operate successfully inside the
ports of which prevailing conditions and circumstances will
have played a role in the design.
A tank test carried out by MARIN in the Netherlands in
2008 showed that the ATTs are also capable of working
outside the port in wave conditions and are able to carry
out escort duties. Simulation studies were also carried out
by Siport XXI in Madrid in 2010 to demonstrate the escort
capabilities.
For some specific ship assist manoeuvres, see paragraph
2.18.6.
2.18.4 Some disadvantages of the present design
As with all the tugs, also the SDM/ATT has some dis-
advantages, although it should be kept in mind that the tug
was designed as a pure harbour tug. Some disadvantages are:
 Figure 2D.4: SDM pushing at ship’s side.
Photo: Rafel Cabal Alvarez, Barcelona pilot
 Figure 2D.5: SDM as forward tug with towline through after fairlead.
Photo: Rafel Cabal Alvarez, Barcelona pilot
Figure 2D.6: SDM at dry dock. The two thrusters, skeg and hole in the
skeg can be clearly seen. Photo: Seabulk Towing & Seacor Island Lines
Types of Harbour Tug 55
2.18.6 Ship assist manoeuvres
As explained before, the SDM/ATT has such dimensions
and thruster-skeg confi guration because of the specifi c
requirements of harbours with narrow and confi ned spaces,
which is the case for example in Barcelona, where the ATT
has been proven a good design. Th e pictures over the page
show some specifi c assist manoeuvres with an SDM and
ATT.

Because of the high side forces that can be applied, the
tugs are very suitable to work in narrow areas, although
when operating at the ship’s side the large beam can be a
disadvantage when passing bridges, in locks and dry docks,
where the available width is mostly at a minimum. Th e tug
could then tow on a line, using either the centre staple or aft
staple. Th e latter enables the tug to apply sideways forces to
the ship within a smaller width, or working with a double
towline as shown in fi gure 2D.10.
More general assisting methods with SDMs
In the USA the tugs are usually operating at the ship’s side
(see fi gure 2D.11a; B,C,D) while in Spain tugs are usually
made fast by the centre lead forward and aft (see fi gure
2D.11a; A), although other assisting methods are used as well
(see fi gure 2D.11b).
2.18.5 New ATT design
Th e Spanish owner, P&O Reyser, designed new ATTs without
the present drawbacks. Th e fi rst tug Azabra of 75 tbp became
operational at the end of 2020. Th e new ATT version is called
ATT2020. Th e tugs would have following modifi cations:
•	 Foredeck will be made higher to improve the capability
to operate outside the port.
•	 An additional deck below the bridge so increasing height
and visibility.
•	 Stronger fenders of cylindrical shape all around the
waterline.
•	 New low emission engines.
•	 Oil recovery equipment.
•	 Improved accommodation with individual bathroom in
each cabin.
Figure 2D.8: Water on foreship of Clara G sailing in waves.
Photo: Oscar Martinez Lezcano
Figure 2D.9: ATT 2020.
Figure 2D.7: Simulation
of ATT’s escort
performance.
Photo: Simulation Centre
Siport21, Madrid
Figure 2D.10: ATT working in narrow space with double towline.
Photo: Oscar Martinez Lezcano (P&O Reyser Santander)
56 Tug Use in Port
Figures 2D.12 and 2D.13 show various common methods
which can be applied by ATTs. The direct towing mode is the
usually method in Spain. The figures also show the towing
points used and the thruster settings.

Note: In figure 2D.13-A the aft towing point is used. The
towline force creates with the hydrodynamicforce working on
the tug a large turning moment. This limits the aft thruster in
applying force in the towline, because it would then create an
extra turning moment. If the indirect towing mode would be
utilised more frequently it would then be recommendable to
investigate if the aft towing point could not be placed above
the aft thruster. Much higher towing line forces could then be
achieved in the indirect towing mode.
In figure 2D.12, positions B and C, the aft towing point is also
used. Using the midships towing point could probably create
higher towline forces at a ship having speed, due to the effect of
the hydrodynamic forces working on the tug.
2.19 EDDY
2.19.1 Design
Typical for all EDDY (Efficient Double-ended Dynamic)
tugs is the in-line thruster arrangement, with one thruster at
each end on the centreline of the tug, and the towing point in
between the thrusters. The designer claims this layout offers
superior effectiveness and competitiveness for ship-assist
and escort tugs in the range of 22-40m. The current EDDY
tug portfolio ranges from 24-37m and 45-100 tons bollard
pull.
Other important characteristics:
•	 The standard propulsion system is a diesel-electric/
diesel direct hybrid propulsion system, with batteries as
option.
Figure 2D.11a: Basic assisting modes in Spain (A)
and the USA (B, C, D).
Figure 2D.11b: Various SDM/ATT tug positions as used in Spain.
Figure 2D.12: ATT made fast forward centre lead.
Figure 2D.13: A: indirect towing mode; B: direct towing mode.
Types of Harbour Tug 57
and easy tug handling. A subdivision of the hull in
five compartments which are closed during operations
(certified unmanned engine room) and double outside
doors for the accommodation makes it virtually
unsinkable.
•	 From a builder’s viewpoint, EDDY tugs are developed
for simple construction and require significantly less
steel and only a minimum of equipment. Construction
of these tugs is thus not only economical but also fast.
•	 The intrinsic simplicity of the concept and forward
thinking during the development phase make EDDY
tugs fit for the installation of LNG or CNG tanks,
exhaust-gas after-treatment systems, all-electric
propulsion systems (including high-power podded
drives and rim-driven thrusters) and further automation
of propulsion control systems, such as a single-joystick
control system .
2.19.2 Steering and thruster control
Standard bridge equipment is two separate thruster controls.
Joystick, or master-pilot system, is an option.
Stopping the tug when having speed ahead can be done by
turning the thrusters, or faster by reversing revolutions of the
electromotor and consequently propeller revolution. Turning
the thrusters at full speed creates some temporary course
instability in tug’s behaviour.
•	 The 30m EDDY, for instance, when sailing in the hybrid
transit mode uses one 500kW generator for speeds up to
9 knots and two for speeds of up to 11 knots. For higher
transit speeds of up to 13.4 knots just one main diesel
engine can be used. Both main engines will only be
required during ship-assist operations or for maximum
towline pull.
•	 Very low fuel consumption (overall reductions from
30 per cent up to 50 per cent compared to tugs of
similar size and bollard pull and executing the same
manoeuvres at the same location, are proven). Two-
thirds of the fuel savings is attributable to the hull shape
and the lower displacement, while the hybrid propulsion
system counts for the other one-third of the savings.
•	 Low noise levels, mainly because the two thrusters have
no interference, but also due to the hybrid propulsion
system.
•	 Low wake: the absence of stern waves for speeds up to 10
knots for the 30mversion (and up to 8 knots for the 24m
version), allows the tug to maintain a high mobilisation
speed, resulting in fast ship assist round-trips and lower
fuel consumption.
•	 High static and dynamic stability, high freeboard,
well protected and in the centre line located thrusters
(avoiding steel-steel contact with the assisted vessel)
Figure 2D.16: The EDDY tug 30-65.
Figure 2D.17: The EDDY 1 (EDDY 30-65).
Photo: Hans Hoffmann, Rotterdam pilot
Figure 2D.14: Diagram showing pushing effectiveness.
Nett pushing force (bollard pull) is about 90 per cent of
maximum pushing force due to the not optimal flow of
the water towards the thrusters.
Figure 2D.15: SDM forward and aft handling an LNG carrier.
Photo: Rafel Cabal Alvarez, Barcelona pilot
58 Tug Use in Port
2.19.4 Ship handling
EDDY tugs operate very well in confi ned spaces. As indicated
above, due to their characteristically forward-aft in-line
thruster arrangement, EDDY tugs are capable of generating
towline tension continuously, and in any direction. When
operating in locks, the tug can move very close to the vessel,
the tug master being completely free in selecting the best
angle of attack for each situation including remaining
parallel to the lock’s side, as can be seen in the various
pictures below. Depending on the required towing force,
these tugs can thus keep the assisted vessel under control at
all times. Th ese manoeuvres can be executed either with a
single towline, as well as in a twin-towline confi guration. Th e
required space for EDDY tugs is thus lower compared to ASD
or tractor confi gurations of the same size particularly with
the twin-towline concept, because the EDDY can operate
within the breadth of the assisted ship. See fi gures 2D.20 and
2D.21.
Also, propeller wash can be directed such that it reduces
interference with the assisted vessel’s underwater body,
resulting in a more eff ective pulling power and consequently
better control over the vessel.
2.19.3 Manoeuvring
Specifi c EDDY ship-assist and escort performance features
are:
•	 High towline forces (close to maximum BP) are available
over 270°.
•	 High side-stepping speed of 7 knots and ease (and
safety) of side-stepping.
•	 High manoeuvrability in all directions.
•	 High steering-forces in the indirect mode, partly due
to the concept and hull shape but also due to the high
stability of the relatively wide hull (above water) and the
location of the thrusters.
•	 EDDY 1 has a SafeWinch, which will be dealt with
in Chapter 7, while Telstar has a standard winch
confi guration.
•	 Th e tug Telstar (EDDY type) has two separately driven
winch drums, allowing the tug master to use two
towlines if needed. See fi gure 2D.20.
•	 As an option the tug may be equipped with towing pins.
See fi gures 2D.20 and 2D.21.
•	 An aft winch is an option.
Figure 2D.18: Hybrid propulsion EDDY 24-75 – diesel direct/diesel-
electric (yellow: main engines; blue: electro motors; silver: generators –
two main generators for electric sailing and one is the harbour generator).
Figure 2D.20: Tug Telstar (EDDY 24-75) operating in the IJmuiden
locks with two towlines. Notice the towing pins. The two towline gives
a faster and better control capability than just one centre line.
Photo: Iskes Towage and Salvage
Figure 2D.21: Tug Telstar (LOA 25.45m, beam 12.20m, BP 75 tons),
effectively pulling the ship alongside in the locks. Photo: Henk Hensen
Figure 2D.19: All-electric EDDY with podded drives.
Types of Harbour Tug 59
2.20 Carrousel RAVE tug (CRT)
2.20.1 Design
The Carrousel-RAVE tug (CRT) concept is a novel
development in the tug industry. The design is a joint
co-operation of Robert Allan Ltd, Voith and the Dutch
companies Novatug and Multraship. The prototype design
is for a 70-ton static bollard pull tug with a carrousel system
and two Voith propulsion systems. Two CRTs have been
built for Multraship Towage and Salvage: Multratug 32 and
Multratug 33. Both started operations in the first half of
2018.

The Carrousel RAVE tug is a RAVE (Robert Allan Ltd Voith
Escort) type tug equipped with a carrousel system. The tug
has two Voith Schneider propulsion units, one aft and one
forward, both situatedProfessor Warsash School of Maritime
Science and Engineering, Southampton Solent University; Salman Nazir, PhD, Associate Professor, Head of Training and
Assessment Research Group (TARG), University College of Southeast Norway, and Sathiya Kumar Renganayagalu, Doctoral
Research Fellow, Faculty of Technology, Natural Sciences and Maritime Sciences, Department of Maritime Operations Campus
Vestfold, are also highly appreciated.
I am very grateful to the maritime organisations that have been willing to share their knowledge : Gijsbert de Jong, Marine
Marketing & Sales Director, Bureau Veritas Marine & Offshore; SJ Banfield, Managing Director, Optimoor; John Vanezos,
Technical Secretary, IACS; Rob Drysdale, Senior Technical Advisor, Oil Companies International Marine Forum (OCIMF);
Cherian Oommen of Sigtto; Deborah McKendrick, Information Officer, The International Tanker Owners Pollution Federation
Ltd (ITOPF); Naa Sackeyfio, Information Data Analyst ITOPF; Captain John Rose MNM, ExC, Director (Maritime), CHIRP;
Linas Kasparavičius, Head of the Maritime Supervision, Division Maritime Department, Lithuanian Transport Safety
Administration; Oessur Jarleivson Hilduberg, Head of DMAIB, and Svein Erik Enge, Emergency Preparedness Advisor,
Inspection and Emergency Preparedness, Norwegian Maritime Authority.
Alan Sorum – Maritime Operations Project Manager, Prince William Sound Regional Citizens’ Advisory Council, Valdez,
Alaska, was also very helpful in providing updated information, as were Bernabe Gallardo, Application Engineer II,
SamsonRope; Sarah Padilla, Technical Director, Cordage Institute; Peter Solis, Senior Marine Consultant, Glosten, and Hans
van de Veen, Consultant Ropes-Towing Gear.
ACKNOwLEdGEMENTS
Tug Use in Port ix
Justus Schoemaker, Dujam Desk KK, Tokyo, Japan, was a helpful intermediary, as was Alan Loynd, Managing Director,
Branscombe Marine Consultants Ltd, Hong Kong, and Sandra de Koster, Regional Co-ordinator, E-commerce, MOL (Europe)
B.V.
Dirk Degroote, Product Manager Tugs; Joop Jansen, Manager Research & Development; Jochem de Jong, Principal Research
Engineer; Leo de Jong, Design and Proposal Engineer Tugs, and Tim van den Heuvel, Development Engineer, of Damen
Shipyards, were always ready to answer my questions and provide me with the requested information.
Much work has been carried out by Karen van Vliet, MSc Offshore Engineering and MSc Sociology, and Jan-Hendrik Hensen,
Mechanical Engineering (BEng), Quality and Safety Management University of Antwerp, Leadership in Crisis Harvard Kennedy
School. They have made a unique contribution to this book.
Apart from the need for the information contained in this book to be correct, there was also the need to present the text in
suitable English. Additionally, the link with the daily practice of ship handling with tugs is an essential aspect of this book.
Therefore the work that has been done in checking all the chapters for these two aspects, initially by Ed Verbeek, FNI, MSc,
retired pilot, simulator instructor ship handling, former manager operations and training
 co-ordinator Amsterdam pilots, and later by Chris Stockman, tug master and SeaWays trainer, has been invaluable.
For the fourth edition I am incredibly grateful for all those who were again willing to share their knowledge and experience like;
LTZ2 A.A. (Bram) Kool of the Dutch Royal Navy, and Captain Max A. Newman D, Tugboat Operations Manager, Operations
Vice-presidency, Panama Canal, about tug assistance for aircraft carriers and submarines. The same applies to Tony Bannister,
Chief Admiralty Pilot QECP, HM Naval Base Portsmouth, UK and Captain Rob Hinton, tug master/instructor, UK, for their
support and what they did within the restrictions.
The information provided by LTLT Emily Wilkin USN, News Desk Officer Navy Office of Information (CHINFO), Washington,
USA; Captain Baykal Yaylali, Chief Pilot Port of Izmir, former pilot Turkish Straits and VTS operator Turkish Straits and Daan
Uiterwaal, Area Sales Manager, Royal IHC, The Netherlands, is also highly appreciated.
Most grateful to Alan Loynd, Managing Director Branscombe Marine Consultants Ltd., Hong Kong for his editing work and
helpful information; Vince Hertog and his colleagues of Robert Allan Ltd., Vancouver; Sascha Pristrom, Technical Officer
Subdivision for Marine Technology and Cargoes Maritime Safety Division IMO and her colleagues, experts of MARIN, OCIMF,
Samson ropes, IACS and of course Dr. Markus van der Laan, Owner, IMC Corporate Licensing, for their contributions and
answering my questions so generously.
Without the support of all those mentioned a book like this can not be written. Truly thankful to all those who helped in one
way or another with this and former editions.
x Tug Use in Port
Assisting methods The term used to describe the way in which harbour tugs assist seagoing vessels.
 Breasted/alongside towing: A tug securely lashed alongside a ship, usually with a minimum of three lines:
 head line, spring line and stern line. Also called ‘on the hip’ or ‘hipped up’.
 Push-pull: A tug made fast so that it can pull as well as push at a ship’s side. Depending on the type of
 tug, its location and the assistance required, it can be secured with one, two or three lines.
 Towing on a line: A tug assisting a ship while towing on a line as is in common use in many European ports.
BHP (winch) Brake Holding Power of the winch, which applies to the first layer on the drum.
Box keel An enclosed keel structure extending from the aft skeg (if fitted) to a point close to the forefoot of a
 tug. A box keel is sometimes installed on ASD escort tugs to provide a better course stability on astern
 and additional lift forces, resulting in higher towing forces, when operating as stern tug in the indirect
 towing mode. A box keel gives additional strength to the tug's hull and provides a better distribution of
 dock forces when in dry-dock.
Classification of ship types AHT – Anchor Handling Tug
 AHTS – Anchor Handling Tug/Supply vessel
 DVS – Diving Support Vessel
 ERRV – Emergency Rescue Response Vessel
 FS – Field Support Vessel
 IFS – Infield Support Vessel
 OMV – Offshore Maintenance Vessel
 OCV – Offshore Construction Vessel
 OR – Oil Revovery Vessel
 PSV – Platform Support Vessel
 SSV – Safety Standby Vessel
 SURV – Survey Vessel
 SV – Supply Vessel
CCTV Closed-circuit television. A TV system in which signals are not publicly distributed but are monitored,
 primarily for surveillance and security purposes.
CFD Computational Fluid Dynamics (CFD) is the analysis of fluid flows along moving ship hulls using numerical
 solution methods, including waves along the surface. CFD requires extensive computer calculations, but due
 to the ever increasing computer calculation capacity, this method is increasingly being used in ship design
 and prediction.
Classification Society The objective of ship classification is to verify the design, production and operation of a ship and all of
 its components. Classification societies aim to achieve this objective through the development
 and application of their own rules. The main classification societies are ABS (American Bureau of
 Shipping), DNV GL (Det Norske Veritas – Germanischer Lloyd), LR (Lloyd’s Register) and BV (Bureau
 Veritas). IACS is the International Association of Classification Societies.
Computational Fluid Dynamics
 The use of applied mathematics, physics and computational software to visualise how a gas or liquid
 flows, as well as how the gas or liquid affects objects as it flows past.
Course stability and directional stability
 Course stability is also called dynamic stability, stability of route or dynamic stability of route (see
 References: Hydrodynamics in Ship Design, Vol I . H.E. Saunders). It is that property of a ship (which
 includes tugs) that, when disturbed, damps out extraneous motions setsuch high fairleads is to have the towing line
running horizontally from the winch through the staple
without first running down from the winch and then
upwards to the ship. However, during ship assistance the
towline will often have an angle in the fairlead, either
horizontally or vertically at high sided ships, or both.
2.21.2 Manoeuvring
The two skegs form a kind of tunnel. These skegs have
underwater fendering, which enables the tug to push full
power sideways at a ship stopped in the water, without
getting a list (see figure 2D.31). When sideways pushing at
a ship having speed, a part of the power is needed to move
the tug forward with the ship, reducing the direct pushing
force, unless ship’s speed is very low and/or friction between
tug fendering and ship’s hull is such that the tug can be
more or less pulled through the water by the ship. However,
when pushing sideways flat against the the hull of a ship
having speed no use can be made of the hydrodynamic forces
working on the tug. When pushing at an angle to the ship,
these hydrodynamic forces can create high pushing forces
depending on tug’s pushing angle and ship’s speed.
There is another aspect to take into account. As with, for
Figure 2D.30: Giano tug with high positioned winches and fairleads.
Photo: Captain Ugo Savona,Giano tug
Figure 2D.32: Giano tug pushing sideways.
Photo: Captain Ugo Savona,Giano tug
Figure 2D.33: Giano tug in the indirect operating mode.
Photo: Captain Ugo Savona,Giano tug
Figure 2D.31: Giano tug.
Types of Harbour Tug 63
Furthermore, during normal ship handling usually
alternatively pushing and pulling is needed. Then a towline
is needed and pushing can be done by tug’s bow or stern,
instead of sideways.
Escort capabilities of the tug will be large. High steering
forces can be generated due to the fact the forward towing
point is situated only at a small horizontal distance away
from the forward thruster.
In the situation as shown in figure 2D.33 the centre of
hydrodynamical pressure will be situated forward creating
forces in the towline which increase with ship’s speed. The
forward thruster can create additional forces in the towline.
Figure 2D.34:Giano tug preparing to pass the towline at the bow of a ship having speed. Photo: Captain Ugo Savona,Giano tug
The aft thruster is needed to keep the tug in position with the
most effective heading. Escorting over the stern might create
higher forces because the aft towing point lies more directly
above the thruster. Provided the tug is handled well, it can
operate safely near the bow of a ship having speed. It can
compensate for the interaction forces, such as suction forces
and turning moments working on the tug, when taking into
account what has been said in paragraph 2.17.
64 Tug Use in Port
Additional or other requirements may apply, such as for
the new 80 and 85-ton ASD-tugs being operated by Svitzer
Australia on the Gorgon project – the Svitzer Euro, Svitzer
Boodie, Svitzer Dugong, Svitzer Perentie, and, at the
Wheatstone project, Svitzer Kadala, Svitzer Mulga, Svitzer
Dugite and Svitzer Gwardar. These tugs have been designed
and equipped as follows:
•	 Double hulls.
•	 LNG alarms, remote closing fire flaps and pressurised
accommodation.
•	 Dynamic escort winch with the capability to release the
line under full towing conditions, minimising slack rope
events and shock loads even in extreme weather.
•	 Side pocket ladder systems and wide opening bulwark
doors on both sides to assist in MOB recovery.
•	 Capability for pilot transfer through a specially designed
pilot-boarding platform.
•	 These tugs will also have the following eco-friendly
features:
•	 Diesel-electric propulsion
•	 Non-hydraulic deck equipment to ensure no oil or liquid
spillage (the equipment will be electric).
•	 Surfaces finished in a low-sheen silicon paint to reduce
water reflection.
•	 Low-spilling sodium deck lights to reduce water
penetration and disturbance during night operations;
also turtle friendly.
•	 Double-walled fuel tanks to prevent leakage.
•	 Solar panels for water heating.
•	 Water recycling plant from the AC systems to be re-used
for deck washdowns.
•	 Battery packs for electric driving – used for about 20
minutes at a time to get in or out of the tug pens (a
pen is a tug berth, well protected and sheltered, often
constructed of floating pontoons).
•	 Wind turbine for loading batteries when at tug berth.
Shell’s Prelude is a very special subject as mentioned earlier
in the Rotortugs section; it is one of the first FLNG (floating
liquefied natural gas) projects. The 488m (!) long floating unit
is to be stationed 230km off the Australian coast in 240m of
water for 25 years and will operate continuously, in terms of
gas processing and the loading of LNG, LPG and condensate
tankers.
KT Marine Services Australia supplies three 42m, 100 tons
bollard pull ISVs (Infield Support Vessels) for the Prelude.
These vessels are Rotortugs equipped with SafeWinches, type
ART 100-42, and named RT Beagle Bay, RT Roebuck Bay
and RT Kuru Bay.
2.22 Tugs handling LNG carriers.
LNG terminal tugs
Depending on the location and the service to be provided,
ship handling tugs at LNG terminals should comply with
certain requirements, apart from the requirements for
proper dynamic stability, behaviour in sea conditions
that are endurable for the crew, optimum fendering, all
around visibility from the manoeuvring stations, etc. These
requirements could also include:
•	 Seaworthy and be able to operate in wave conditions
appropriate to the client/terminal specific requirements
for intended ships visiting.
•	 Sufficient bollard pull to handle in the prevailing
environmental conditions of wind and waves the largest
floating object that can be expected at the terminal.
•	 A powerful escort towing winch with quick response
render-recovery capability.
•	 Escort capabilities.
Furthermore the following might be required:
•	 Gas detection alarm systems in the wheelhouse.
•	 Gas sensors with sensors around the deckhouse, at
engine room intakes and accommodation ventilation.
•	 Explosion-proof motors for air intake fans on main deck
and deckhouse.
•	 Main engines equipped with ‘rigsaver’ – a safety stop
system if gas is sucked in.
•	 Spark arresters in exhaust systems.
•	 Remotely operated ventilation dampers.
•	 Fire-Fighting 1, or above, with water-spray.
•	 Fendering with water lubrication for pushing operations
and with such characteristics that a very low contact
pressure can be realised of, for instance, not more than
14t/m2.
•	 Anti-spark fendering.
•	 All essential electrical equipment on deck of a certified
safety standard, suitable for use in the specific LNG
zone.
•	 Intrinsically safe external electrical points.
•	 Anti-static synthetic towlines.
•	 Additional FiFi requirements
Note:
Clear instructions are needed for the tug master and his crew
for how to handle events in case a dangerous situation is
developing with gas, due to a leakage or explosion, for example.
Should the tug release the towline and sail to a safe area,
with all the possible consequences? Or should the vessel being
handled be pulled away? Much depends on the source of the
gas flow. If staying in the dangerous area, how to save the crew
if engines are stopped with rigsavers? Clear instructions are
absolutely needed for such dangerous situations.
Chapter 2
PART E
Specific Tugs. Research. Performance
Types of Harbour Tug 65
Hazardous areas classification
Other requirements may apply to tugs handling LNG
carriers or operating in hazardous areas. Hazardous area
are classified into zones based on an assessment of the
frequency of the occurrence and duration of an explosive gas
atmosphere, as follows:
•	 Zone 0: An area in which an explosive gas atmosphere
is present continuously or for long periods. Unofficially:
explosive atmosphere for more than 1000h/yr.•	 Zone 1: An area in which an explosive gas atmosphere
is likely to occur in normal operations. Unofficially:
explosive atmosphere for more than 10, but less than
1,000h/yr.
•	 Zone 2: An area in which an explosive gas atmosphere
is likely to occur in normal operation and, if it occurs,
will only exist for a short time. Unofficially: explosive
atmosphere for less than 10, but still sufficiently likely as
to require controls over ignition sources.
Sources of ignition should be effectively controlled in all
hazardous areas by a combination of design measures, and
systems of work, such as:
•	 Using electric equipment and instrumentation classified
for the zone in which it is located.
•	 Earthing all plant/equipment.
•	 Prohibition of smoking/use of matches/lighters.
•	 Control of maintenance activities that may cause sparks/
hot surfaces/naked flames through a Permit to Work
system.
•	 Etc.

Other tasks include escorting and berthing LNG carriers,
condensate tanker tow-backs, pilot transfer, floating hose
handling, as well as an integral part in security, emergency
response, rescue and evacuation requirements.
For terminal tugs, such as the above mentioned tugs
operating in or near LNG terminals, other specific design
requirements exist with respect to operations in open waters.
These tugs usually operate over the bow and often proceed
with the stern into the waves. Therefore the aft deck of such
tugs should have a lot of shear and smooth upgoing lines
in the underwater hull form aft which should create the
tendency when proceeding astern the tug’s stern to climb
out of the water. It should be said this requirement does
not apply to terminal tugs alone, but also to all ASD tugs
operating bow-to-bow at a ship having speed.
Note 10:
Winch considerations.
In open sea exposed conditions, the relative motions between
tugs and vessel are relatively large and vary strongly due
to wave spectra and hull reflections. Many operations are
performed at a significant angle to wind and waves adding
also heeling effects. The situation is further complicated by
(very) short towlines with large vertical angles. Finally, many
towlines consist of high strength Dyneema fibres without the
use of a stretcher. The total combination requires a robust
render-recovery winch with very high response speed to
instantly release the towline at overload and instantly retrieve
the line a slack line, and well trained winch drivers to support
the Master.
FiFi
The possible need for FiFi (Fire-Fighting) classification has
been mentioned already. FiFi classes as given by DNV GL are
shown in Table 2E.1, below.
Water Monitor System Capacities
Class notation Fire Fighter (I) and
(II+)
Fire Fighter (II) Fire Fighter (III)
Number of monitors 2 2 3 4 3 4
Capacity of each monitor (m3/h) 1200 3600 2400 1800 3200 2400
Number of pumps 1-2 2-4 2-4
Total pump capacity (m3/h) 2400 7200 9600
Length of throw (m) 1) 120 180 150 180 150
Height of throw (m) 2) 50 110 80 110 90
Fuel oil capacity in hours 3) 24 96 110 90
1) For class notation qualifier I, measured horizontally from the monitor outlet to the mean impact area.
For I+, II and III, measured horizontally from the mean impact area to the nearest part of the vessel
when all monitors are in satisfactory operation simultaneously.
2) Measured vertically from sea level to mean impact area at a horizontal distance of at least 70 m from
the nearest part of the vessel.
3) Capacity for continuous operation of all monitors, to be included in the total capacity of the vessel’s
fuel oil tanks.
Table 2E.1.
66 Tug Use in Port
The forementioned actions to reduce air emissions of ships
also have their effect on tugs. The reason why more and
more Eco-tugs are built with the purpose of reducing fuel
consumption and/or air pollution. How this is achieved will
be discussed below.
Three basic systems will be addressed:
A. The system of reducing fuel consumption by hybrid
technique, which means the tug uses two or more
distinct types of power.
B. The system of using fuel that causes less air pollution.
C. Fully electric tugs causing no air pollution.
A – System of reducing fuel consumption
by hybrid technique
The various propulsion systems will be classified as follows
(based on the study Design and control of hybrid power
and propulsion systems for smart ships: A review of
developments. R.D. Geertsma, R.R. Negenborn, K.Visser,
J.J. Hopman. Elsevier Ltd. 2017)
•	 Mechanical propulsion.
•	 Electric propulsion.
•	 Hybrid propulsion systems, which include:
 – Electric propulsion with hybrid power supply.
 – Hybrid propulsion with hybrid power supply.
 – Electric propulsion with DC hybrid power supply.
The images shown on the following pages (also based on the
above mentioned study) give an indication of the various
systems.
2.23 Eco- tugs
Tugs that have been designed in such a way that they can
operate effectively in an environmentally friendly way by
reduced consumption of fossil fuel and/or reduction of air
pollution are referred to here as Eco-tugs.
Many actions have been undertaken in recent years to
significantly reduce air emissions from ships. These air
emissions include carbon dioxide (CO2), sulphur oxides
(SOx), nitrogen oxides (NOx) and particulate matter (PM)1.
Most of these actions (for Preventing of Air Pollution from
Ships) have been taken through Annex VI of MARPOL,
an international instrument developed through the
International Maritime Organization (IMO) that establishes
legally-binding international standards to regulate specific
emissions and discharges generated by ships. The IMO
emission standards are commonly referred to as Tier l - lll
standards.
In the IMO circular MEPC.1/Circ.778/Rev.2 of 6 April 2017
a list is presented of special areas, emission control areas and
particular sensitive areas in various parts in the world with
the specific MARPOL amendments, protective measures,
and the dates these amendments and measures come or
came into force.
See also Index of MERPC Resolutions and Guidelines related
to MARPOL Annex Vl (see References).
1 PM stands for particulate matter (also called particle
pollution): the term for a mixture of solid particles and liquid
droplets found in the air. Some particles, such as dust, dirt,
soot, or smoke, are large or dark enough to be seen with the
naked eye. Others are so small they can only be detected using
an electron microscope.
Figure 2E.1: Smoky harbour tug – ASD-tug, LOA 29.95m, breadth 10.20m. Photo: Michael Cassar, Malta
Types of Harbour Tug 67
A. Mechanical propulsion (fi gure 2E.2)
Th e propulsion can be with fi xed pitch propellers,
controllable pitch propellers, azimuth thrusters, VS
propulsion, etc.
Mechanical propulsion has only three power conversion
stages: the main engine, the gear box and the propeller,
which leads to low conversion losses.
However, mechanical propulsion is particularly effi cient at
design speed, which is between 80 per cent and 100 per cent
of the top speed.
Mechanical propulsion has a poor fuel effi ciency and high
emissions when sailing at speeds below 70 per cent of top
speed.
Tugs only require 20 per cent of their maximum power
requiring for towing during transit, which leads to poor
specifi c fuel consumption and high emissions. Th us, electric
or hybrid propulsion could be considered to improve part-
load fuel effi ciency. Nevertheless, this is yet only the case on a
limited number of tugs.
B. Electric propulsion (fi gure 2E.3)
Most electric propulsion systems utilise fi xed pitch
propellers, because the electrical drive can run at every speed
in forward and reverse direction and deliver full rated torque
at every speed. As such, the speed of the ship or tug can be
fully controlled without the need for a controllable pitch
propeller.
When engines are running on part load, which is oft en the
case with tugs, it will lead to poor fuelconsumption and
a lot of emissions. Only a few harbour tugs have electric
propulsion

Figure 2E.2: Typical mechanical propulsion system.
Figure 2E.3: Typical electrical propulsion system layout.
68 Tug Use in Port
C. Hybrid propulsion (fi gure 2E.4)
Ships that frequently operate at low speeds, such as tugs, can
benefi t from a hybrid propulsion system.
In hybrid propulsion, a mechanical drive provides propulsion
for high speeds or with high effi ciency. Additionally, an
electromotor (2), which is coupled to the same shaft through
a gearbox (3), provides propulsion for low speeds, thus
avoiding the main engines ineffi ciently in part load.
Hybrid propulsion is typically economical when the
operation profi le has distinct operating modes with a
signifi cant amount of time at low power, which is the case
with tugs.
When the electric drive is designed to run parallel with the
mechanical drive, it can be used to increase the top speed,
or maximum towing power, and so reduce engine thermal
loading and thus NOx emissions.
D. Electric propulsion with hybrid power supply (fi gure 2E.5)
In electric propulsion with hybrid power supply, a
combination of two or more types of power source can
provide electric power. Th e power sources can be:
1. Combustion power supply, from eg diesel engines.
2. Electric chemical power supply from fuel cells, and
3. Stored power supply from energy storage systems (see 2),
such as batteries and fl ywheels.
Fuel cells are still seldom used in the maritime environment.
Research is focused on more compact storage of hydrogen,
fuel cells that can use other fuels, such as LNG or even diesel
oil. At present the main type of energy storage is the battery.
Th e energy storage can provide the required electrical power
and enable switching off one or more engines when they
would be running ineffi ciently at part load. Th e energy
storage can then be recharged when the engine is running in
an operating point with lower emissions. Th is can save fuel,
reduce emissions, reduce noise, increase comfort and enable
temporarily sailing without emissions, noise and vibrations
from engines.
Furthermore, the battery can enable peak shaving: the
battery delivers power during periods where high power is
required and recharges when less power is required. Th e
battery can also provide back-up power during a failure of
combustion power supplies (diesel generators).
Popularity of batteries is growing fast. For tugs and ferries,
for example, the potential reduction of fuel consumption and
emissions has led to investigations and application of electric
propulsion with hybrid power supply.
Figure 2E.4: Typical hybrid propulsion system.
Figure 2E.5: Typical electric propulsion system with hybrid power supply.
Types of Harbour Tug 69
E. Hybrid propulsion with hybrid power supply
(fi gure 2E.6)
Th is system utilises the maximum effi ciency of the direct
mechanical drive (1) and the fl exibility of a combination of
combustion power from prime mover(s) (2) and stored power
from energy storage (3) for electric supply.
Hybrid propulsion with hybrid power supply has been
researched extensively and has been applied in harbour tugs.
Research at Delft University of Technology suggests that
hybrid propulsion with hybrid power supply can deliver
signifi cant savings in local emissions, partly by using energy
from batteries that are recharged with shore connection.
If the control mode of the plant is determined in an optimum
way by the operating mode of the vessel (towing, high
speed transit, low speed transit or stand by) and the battery
state of charge, positive results can be achieved because the
operating modes of the plant lead to very distinct loading of
the system. For example, in low speed transit or standby, the
main engine loading is very low and, therefore, switching off
the engine stops the engine operating ineffi ciently.
Th e hybrid propulsion confi guration allows designs in
which the main engines cannot deliver full bollard pull on
their own. However, a design that for delivery of full bollard
pull depends on an electro motor or batteries potentially
introduces reliability and safety risks. Th erefore, it would be
better to design the main engine such that it can deliver full
bollard pull without additional power from the electromotor.
F. Electric propulsion with DC hybrid power supply
(fi gure 2E.7)
Th e most important reasons for applying DC systems
are increased fuel effi ciency when running generators in
part load and reduced power conversion losses. Th e DC
architecture allows the diesel engine to run at variable
speed, potentially leading to a reduction fuel consumptions,
emissions, noise and engine mechanical and thermal
loading.
Applications that utilise DC hybrid power supply systems
are ferries, drilling ships, research vessels and wind farm
support vessels.
From the foregoing it has become clear how important
batteries are for hybrid vessels and, obviously, for only
battery-powered vessels. For that reason classifi cation society
DNV GL started a Joint Development Project (JDP), designed
to advance the understanding of the use of lithium-ion
batteries in the shipping industry. More than dozen partners
joined the initiative, including fl ag states, research institutes,
battery and propulsion suppliers, ship owners, operators and
yards. Including batteries in ships, whether as a hybrid or
fully electric system, off ers the industry the opportunity to
improve fuel economy, reliability and operational costs. Th e
project started in 2017 and results will become available in
2019.
Figure 2E.6: Typical hybrid propulsion system with hybrid power supply.
Figure 2E.7: Electric propulsion with DC hybrid power supply.
70 Tug Use in Port
Various hybrid systems have been briefly explained.
Operating modes may have following names and functions
(see paragraphs C and E above):
•	 PTI (power take in) – Booster mode: the shaft generator
then functions as an auxiliary motor, and works
concurrently to the main diesel engine.
•	 PTI – Fully electric mode. In this mode batteries
generate the energy for the propulsion. The main diesel
engine and the generator sets are off.
•	 PTI – diesel-electric mode. This mode is used at low
speeds and does not need the main diesel engine. The
generator sets are functioning and feed the tug’s loads
as well as the main propulsion. The shaft generator
functions as propulsion motor. The system can also be
used in the event of a main diesel engine failure (PTH:
power take home).
Other operating modes can be:
•	 PTO (power take of) – Parallel Mode. Additional
power of main diesel engine in case power required for
propulsion and vessel’s loads is higher than generator
sets can provide. PTO – Transit Mode. The main diesel
engine supplies power needed for the propulsion (and
ship’s consumers). Generator sets off. PTO – Shore
Connection Mode. All engines are switched off.
Different systems have been mentioned that can cut fuel
costs and make tugs more environment-friendly. Whatever
system is used, an optimum working power, or energy,
management system is needed to achieve the best results.
Figure 2E.8: Engine control system of Kotug’s hybrid tug RT Evolution
(LOA 32m, beam 12.6m, BP 83 tons). Photo: Piet Sinke
Figure 2E.9: Hybrid system of a Rotortug: hybrid propulsion system with
hybrid power supply. Source: Kotug
Explanation (see also figure 2E.9):
Top button left: selection between HYBRID and NON
HYBRID.
Middle button left: IDLE: On batteries only when moored,
waiting for a ship or waiting until pilot is on board. Thrusters
can be used, but only with propellers at very low speed.
TRNST 1: One generator running producing electricity for
the electro motors at the three thrusters (diesel-electric) and
the tug can sail with a speed up to 6 knots.
TRNST 2: One main engine running. Thismain engine
drives the propeller (diesel-direct) and the generator in the
propeller shaft which provides electricity for the electro
motors of the other two thrusters (diesel-electric). The tug
can then sail with a speed of 9 knots.
ASSIST: All main engines running, maximum speed and
power available.
When a diesel generator is running the batteries are loaded
at the same time.
Five aspects are of crucial importance for safe operations of
an Eco harbour tug:
•	 Full power should be available in a minimum of time
and preferably without extra handling of press buttons
or switches. In emergency and stressful situations,
the focus of the tug master is on the situation; extra
handlings distract the tug master from the immediate
actions to be taken and/or lead to mistakes.
•	 Full power should be available during at least some
hours to enable the tug to, for instance, stay pushing
over a long period to keep a large ship alongside during
stormy weather.
•	 Switching of the various drive systems should be simple
so that in stress situation no mistakes will be made.
•	 The eco-system should be fully reliable.
•	 Stability should not negatively be affected (applies to
section B).
B System of using fuel which causes
less air pollution
Apart from possible exhaust gas treatment systems, there
are other options to reduce air pollution by tugs, even in
combination with the above-mentioned systems:
•	 The possibility of running the engines on diesel and
LNG or hydrogen, so-called dual-fuel engines.
•	 LNG, hydrogen or ammonia only as fuel.
•	 Compressed natural gas (CNG) for which storage
requirements are less stringent than for LNG (see below).
•	 Studies are ongoing to see if methanol could be used
as fuel. Methanol is mainly produced by natural gas
synthesis. The most used alternative fuel after LNG,
it is available on a large scale. The RoPax ferry Stena
Germanica was the first ship that uses methanol as fuel.
Methanol is no more poisoning than diesel or gasoline.
It has a low flashpoint of only 120 C. For this reason
there are several requirements for storage and handling
of methanol on board ships. Methanol as a ship fuel
is interesting for ship operators because it does not
contain sulphur and is liquid in ambient air conditions,
which makes it easy to store on board ships. Converting
engines to the use of methanol is not complicated, and
Types of Harbour Tug 71
maintenance and noise level are lower. The problem with
LNG as fuel is the space and the location. Conventional tugs
store diesel fuel in tanks of all shapes, making use of tight
spaces that can be of limited use for other purposes. LNG
should be stored in specific tanks which have to comply with
specific requirements.
LNG is a liquid and should be kept at a temperature of -162°
C. The energy density of LNG is about half that of diesel.
This means it requires twice as much storage as diesel for
the same energy needed. In gaseous condition the volume of
LNG is about 600 times as large.
When it comes to the allowable locations of LNG storage
tanks on board a tug, there are specific classification society,
national authority, and international code safety-based
restrictions. LNG tanks should be kept at a certain distance
from the side shell, from the bottom, and from engine room
spaces. These major location restraints, along with the space
limitations, make it difficult to fit significant quantities of
LNG on board a tug, especially a compact tug. There are
furthermore specific mandatory and class requirements for
safety and gas systems that cover the ventilation of the LNG
system’s tank hold, tank connection spaces, gas regulation
units, engines, double walled piping systems, bunker
stations, air locks and the like. If an oil recovery system is
also required it becomes even more complicated.
The characteristics of LNG and all the specific requirements
make the storage of LNG on board a tug with rather small
dimensions and high powered engines a complex issue.
The LNG storage tank should not placed at such a height
that it will affect a tug’s stability in a negative way. The same
applies to a partly filled LNG storage tank, due to the effect
of the free liquid surface in the tank. Furthermore, work on
deck, lead of the towline, visibility, etc, should not be limited
by ventilation pipes and other constructions needed for LNG.
Contrary to what has been said above about the location of
the LNG fuel tank, Mitsui OSK Lines’ (MOL) new tug has the
fuel tank high up – on deck (see figure 2E.11). The tug, name
Ishin, entered service in Osaka Bay in 2019.
Particulars of the tug are:
Tug with azimuth thrusters; LOA: 43.6m; beam: 9.2m; engine
power: 2 x 1,618kW (2 x 2,200 hp); BP 50 tons. The tug can run
on LNG and on diesel (dual-fuel engines).
Locating the LNG in such a high position puts great demands
on the tug’s stability, especially with this slender tug, having a
length:beam ratio of approximately 5.
MOL declares that the size of the tank is such that good
stability is ensured, which should also be the case when the
tank is partly filled and the free liquid surface in the tank
it is available in many ports around the world. Costs of
methanol are lower than of hydrogen and ammonia.
•	 Ammonia as marine fuel is also being studied. One of
the first working engines run on ammonia was built
in 1935. Ammonia is liquid at a temperature of -34° C,
but the volume needed for the same energy is at least
three times as high as with conventional fuels. Costs
of ammonia is higher than of methanol. Agreements
are made between shipping companies, classification
societies, engine manufacturers, etc. to study the use of
ammonia as fuel for ships. In 2020 Japanese shipping
company NYK line, classification society ClassNK
and IHI Power systems signed a joint research and
development agreement for the world’s first ammonia-
fueled tugboat.
•	 Hydrogen – Ferries using hydrogen as fuel are scheduled
to enter into service in 2021. It is a clean energy source,
bountiful in supply, non-toxic and highly efficient; but
it is expensive, there are storage complications and it is
highly flammable. For the Port of Antwerp the dual-fuel
Hydrotug will be built with engines that burn hydrogen
in combination with diesel. It is the first hydrogen-
powered tug in the world and will be ready to enter
service in 2023. Costs of hydrogen are considerably
higher than of methanol.
•	 Lignin – with cellulose, the chief constituent of wood.
Dutch scientific institute Chemelot InSciTe said in 2018
that lignin will soon be processed on a commercial scale
through a biobased process, and the oil produced (crude
lignin oil – CLO) will be used as marine fuel that will
be more durable and environmentally friendly than the
bunker fuels that are currently used.
•	 Iron – Like some other metals, iron can burn and
produce heat. The iron powder used for this purpose
has a grain size comparable to the thickness of a
hair. Eindhoven University of Technology has been
researching metal fuels as a circular energy source for
some time and sees iron as a promising option for three
areas of application: power plants, the process industry
and shipping. It has a relatively high volumetric density
and meets the requirements for a future marine fuel.
LNG will be addressed separately below.
LNG
LNG as fuel for tugs is a growing market: in 2017 six gas-
powered tugs were in service and eight on order. It complies
with present and future emission requirements. Engine
Figure 2E.10: Hybrid tug Ginga, with mechanical and electric
propulsion (LOA 38m, width 10m, BP 55 tons, speed 14.8 knots),
Tokyo Kisen, Japan. Photo: Piet Sinke
Figure 2E.11: MOL LNG tug. Courtesy Mitsui OSK Lines, Japan
72 Tug Use in Port
Since LNG fuel is rather complicated to control properly
with rapidly varying loads, a practical solution is offered by
a stable generation of main power byLNG generators and
small fluctuation diesel generators.
Several eco-tugs have been built. Examples are Carolyn
Dorothy (Foss), Svitzer Gaia, Svitzer Boodie, Svitzer
Mulga, RT Evolution (Kotug), Ginga (Tokyo Kiso), EDDY-
1, Fairplay XI, Noordzee (Dutch Royal Navy), BB Power
(Bukser og Berging), Dux (Østensjø), etc, or the new eco-
friendly design Wärtsila HYTug series, launched in 2017.
Apart from a modular hybrid propulsion these tugs have a
wheelhouse design with a high visibility, semi-enclosure bow
winch, side shoulders and low hull resistance.
C: Fully electric tugs
There is an increasing interest in fully electric tugs. They
have almost zero emissions, are quiet, both onboard and
underwater.

The first operational all-electric tug in the world is the
Zeetug Gisas Power of GISAS Shipbuilding in Turkey. `Zee’
stands for Zero Emissions Electric Tug. It is an 18.7m long
tug with 32 tons bollard pull. Expectations are that the
lithion-ion batteries will have a lifespan of 10 years. At a
quick-charging station the batteries can be fully charged in
one hour. The tug has two redundant battery rooms, one for
and one aft, that are maintained at a constant temperature by
a cooling system. More Zeetugs have been ordered.
In July 2020 keel-laying took place of the all-electric Damen
tug RSD-E tug 2513 called Sparky, to be built for the Port of
Auckland. See for description of RSD tug 2513 paragraph 2.13.
For maximum redundancy, four identical and independent
battery packs are situated each in an insulated, temperature-
controlled battery room. The lifetime of the battery system
is expected to be approximately the same as the estimated
working life of the vessel.
The battery capacity is sufficient to perform at least two
berthing operations fully electric in an average harbour with
zero emissions. The tug can push-pull with 70 tons bollard
pull for at least 30 minutes. It then takes two hours to fully
recharge the batteries at the shore station.
starts to play a role. The LNG tank will hamper any towing
operations on the aft deck. However, these tugs operate over
the bow.
The 32m long harbour and terminal ASD-tug KST Liberty,
whose naming took place in April 2018, also has its LNG
tanks on the after deck.
With respect to LNG-fuelled tugs, a new mandatory safety
code for ships using gases or other low-flashpoint fuels
entered into force on 1 January 2017, along with new training
requirements for seafarers working on these ships. The
International Code of Safety for Ships using Gases or other
Low-flashpoint Fuels (IGF Code) aims to minimise the risks
to ships, their crews, and the environment, given the nature
of the fuels involved.
There are various standards and guidances focusing on LNG
bunkering, such as:
•	 ISO/DIS 20519 Specification for bunkering of gas fuelled
ships.
•	 SGMF (Society for Gas as a Marine Fuel) LNG
Bunkering Safety Guidelines.
•	 IACS Recommendations on LNG bunkering (Rec. 142).
June 2016.
•	 IAPH (International Organisation of Ports and
Harbours) LNG bunker checklist.
•	 EMSA (European Maritime Safety Agency)
Guidance on LNG bunkering to Port Authorities and
Administrations.
Note 11:
As mentioned earlier, although LNG is mentioned as fuel, it
cannot be used as fuel. It has to be reconverted to gas, which
can be used as fuel, if temperature etc is suitable
Finally: Diesel-electric
Diesel engines are very efficient and robust energy sources.
Their drawback is that efficiency and emissions are directly
related to the revolutions and cylinder loads. For a ship
sailing at one speed and power rating, diesel propulsion
offers an attractive and efficient solution. And for this given
speed and power rating, emissions can be further reduced by
exhaust treatment.
Tugs have large fluctuating revolutions and power rating
with large variations. As a result diesel direct propulsion
has lower efficiency and far higher emissions at non optimal
speed and power ratings. Exhaust treatments for off-design
conditions is very complicated.
For these varying conditions, diesel-electric propulsion
offers interesting perspectives. Due to the diesel-electric
configuration, revolutions and power can be better matched
to optimal efficiency.
LNG can be used as fuel for a combustion motor directly
driving the propeller shaft; however, for varying revolutions
and powers, this still remains a difficult and complex system.
For tugs, a more attractive solution is a LNG-electric system,
whereby LNG is used as fuel for a combustion motor driving
a generator. This also allows the inclusion of part diesel-
electric generators, whereby either LNG or diesel fuel can be
used, or an attractive combination.
Figure 2E.12: ASD-tugs Tornado, ASD2810 and Akmal working
in broken ice in the Port of St Petersburg, Russia.
Photo: Captain Sergei Milchakov, St Petersburg
Types of Harbour Tug 73
periods on arrival, departure or when berthed. With strong
off shore winds tugs are sometimes needed to keep ships
safely alongside the berth and this may take several hours.
Th e same may be the case with large empty tankers. In case
of groundings tug power may also be needed for hours.
Maximum operating time may increase in the coming years,
as batteries are improving continuously.
Wireless charging technology
Wireless charging is already employed. Th is technology uses
very high frequency waves.
Wärtsilä, for instance, has developed a wireless charging
system for easy transfer from shore to ship. Th is technology
is particularly suitable for fully electric vessels using
batteries.
A technology which can be employed for fully electric tugs
as well.
2.24 Ice tugs
Ice conditions and requirements
In general, at least the following local ice conditions should
be considered for requirements for tugs operating in ice,
including local environmental conditions such as wind and
current that may eff ect ice conditions:
•	 Type of ice, salinity, snow coverage.
•	 Level of ice thickness in normal and more extreme
situations.
•	 Ice coverage.
•	 Amount of severity of ridging, consolidation of ridges.
•	 Ice drift and ice pressure; the local ice condtions.
•	 Land fast and grounded ice.
Issues of importance for design or selection of ice tugs are:
•	 Required ice breaking capacity versus other required
capacities. Ice breaking performance for a given level of
power or, on the other hand, a reduced fuel consumption
for a given level of performance.
•	 Tug type: ASD or conventional, both being most suitable
for severe ice conditions.
•	 Main engine and propulsion system. Direct mechanical
fpp or CPP, or various diesel-electric arrangements. In
this selection, the most important issues are: torque/
rpm curves and the machinery’s ability to be used for
prolonged periods at high power, including tolerance
Another important advantage of the all-electric system is
that the extra oxygen in the engine room needed to run
fossil fuel-driven engines is not required anymore, making
it safer to operate in and around LNG terminals and other
hydrocarbon/chemical facilities. Also, it decreases the need
for large engine room air inlets and so increases tug safety in
case of capsizing.
Th e tug can be operated by two men thanks to the degree
of automation incorporated, the human machine interface
and the centralised alarm, monitoring and control system
connected to the Damen remote monitoring system. Please,
see for two-man tug operations paragraph 6.3.14.
More initiatives can be seen for fully electric tugs. For
instance, Vallianz Holdings has signed an agreement with
SeaTech Solutions, both situated in Singapore, to develop a
series of all-electric harbour tugs of the EVT-60 design with
a `brand new battery-powered concept’. Th e tugs will be 26m
long and have a bollard pull of 60 tons.
In March 2021 LNGCanada ordered for their LNG terminal
in the Port of Kitimat fully-electric tugs, the ElectRA2800battery-electric harbour tugs. Th e tugs of the ASD-type will
have a length of 28m, a battery capacity of 5240KWh, and a
bollard pull of approximately 70 tons. Th ey are expected to
be operational around 2025.
Also Crowley Engineering designed a fully electric tug. It is
25m long and has a bollard pull of about 60 tons. Th e battery
capacity should be enough for two ships assist jobs.
Lithium batteries
Care should be taken with lithium batteries. In August
2012, an explosion and fi re occurred in one of the l ithium
batteries on the tug Campbell Foss. Subsequent to that fi re,
Foss removed the remaining batteries from the tug, and it
returned in diesel confi guration without batteries.
Th e investigation resulted in several structural changes to
vessels and the installation of fi re suppression systems in the
battery room.
More lessons about fi re suppression were learned in a later
fi re on board the Norwegian ferry Ytterøyningen in 2019.
Also, on 11 March 2021, the all-electric excursion catamaran
MS Brim with two battery rooms with 790kWh of lithium
batteries installed got on fi re.
Th e reader is referred to the DNV report of the maritime
battery safety joint development project: ‘Technical
Reference for Li-ion Battery Explosion Risk and Fire
Suppression.’ (see References). It states, amongst other
fi ndings, that ventilation alone is not enough to prevent an
explosion if a very large number of battery modules (totally
4,000 amp hours or more) fail in the same compartment
at once. Th e battery design must have preventative safety
barriers so that the fi re and gas emissions are limited to as
small a part of the battery system as possible.
Maximum operating time of fully electric tugs
Th e maximum operating time of fully electric tugs should be
well considered with respect to the situation in the port, size
and type of ships and wind conditions. For instance, during
stormy winds full power of tugs may be needed for large
container vessels, LNG carriers and car carriers during long
Figure 2E.13: Stronger structural integrity is needed for ice tugs.
Courtesy Damen Shipyards
Pgua_Supplay
Destacar
74 Tug Use in Port
bays may also be required to ensure that the sea chest does
not become blocked with ice. Most of the stronger ice classes
require several forms of rudder and propeller protection.
Two rudder pintles are usually required, and strengthened
propeller tips are often required in the stronger ice classes.
More watertight bulkheads, in addition to those required
by a ship’s normal class, are usually required. In addition,
heating arrangements for fuel tanks, ballast tanks, and
other tanks vital to the ship’s operation may also be required
depending on the class.
Tug type and equipment
Much depends on the local situation, as described above,
and on the tasks to be performed. Tug type with respect
to propulsion and propeller type is a specific issue. The
following is based on designers and tug masters’ experience
and research:
ASD-tugs
What the best tug type is depends totally on prevailing ice
conditions and type of operations, although most versatile in
general is an ASD-tug. Experience with ASD-tugs equipped
with CPP propellers is optimal. CPP makes recovery of
thrust after ice blockage very fast and easy to perform, and
even reduces nozzle blockage incidents.
Voith tugs
Regarding Voith tugs in ice, opinions and experiences
differ. Some say Voith typically does not work in anything
over very light ice conditions, mainly due to ice blocking
and to some extent to vulnerability in real ice condtions.
In ice conditions the normal coupled Voith control system
limits the possibility of clearing ice of each propulsion unit
independently with propeller washes.
Experiences show that Voith tugs get easily blocked in
anything but lightest ice, partly also due to the tractor tug
concept which doesn’t have a hull ploughing ice away from
the propulsion units, as is the case with azimuth tractor tugs.
However, a recent report comes to a totally different
conclusion (see Maritime Journal, 16 February 2012. A study
of Voith tractors in ice). It was produced following testing
at the Aker Arctic Ice Laboratory in Helsinki, and in the
circulation tank at Voith’s headquarters in Heidenheim. It
indicated that even under extreme conditions, tugs with
Voith Schneider propellers have proved to be highly effective
icebreakers.
The findings are consistent with the practical experience of
Svitzer in Gothenburg, URAG in Bremerhaven and Bugsier
in Rostock.
The impact point of the ice floes at the propeller blade is
usually in the upper part of the blade near the bearings. This
results in a lower bending moment. The magnitude of the
bending moment has a significant influence on the service
life of the propeller blades.
1. Collision with the ice floes occurs at the leading edge of
the blades. In this load situation, the section modulus of
the blade profile is at its highest, which reduces the risk
of damage.
2. The ice floes are immediately pushed to the side after the
first impact with the propulsion system and do not get
caught in the VSP.
for extremely rapid load variations. The complete
propulsion line must be calculated, the propeller as
weakest point and engine as the strongest.
•	 Nozzle or open propellers.
•	 Torsion loads and vibrations in propulsion line owing
to propeller ice contact, ice between hull and propeller
blade and blockage of nozzles owing to ice.
•	 Engine cooling arrangements.
•	 Internal heating; noise control.
•	 Design and system solutions to minimise external ice
build-up; means to remove ice from deck, deckhouse,
winch, ladders, masts, aerials and superstructure.
•	 Towing gear operability to maintain workability of lines,
winches and fenders; protection against freezing spray
and snowfall. Towlines should be such that minimum
breaking load will not be negatively affected by low
temperatures.
•	 Extremely good searchlights, working lights, radar(s),
and general visibility issues, including window heating
and demisting arrangements, wiper heaters and
washing-line purging systems.
Furthermore:
•	 Stability requires specific attention because of the
possiblity of ice accretion on board the tug, which can
be very dangerous. Ice growth on superstructure, mast,
winch, etc, can occur very quickly during freezing
temperatures, quickly decreasing the tug’s stability. Ice
accretion should be a factor to be taken into account for
the tug’s stability.
Note 12: For those further interested in the severity of icing,
the Mertins Diagram gives an indication of how much ice
can be developed during various conditions of wind force,
seawater temperature and air temperature. See: ‘Operations of
ships in cold climates with emphasis on tankers and the new
requirements’. DNV. November 2003.

Not all ships are built to an ice class. Building a ship or tug
to an ice class means that the hull must be thicker and more
scantlings (aggregate of girders, beams, and bulkheads
resulting in stronger structural integrity) must be in place.
Sea chests (openings in the hull for seawater intake) may
need to be arranged differently depending on the class. Sea
Figure 2E.14: ASD-tugs Tornado, ASD2810 and Akmal working in ice in
the Port of St Petersburg, Russia. Photo: Captain Sergei Milchakov, St Petersburg
Types of Harbour Tug 75
thrust. However, bollard pull in relation to installed power is
signifi cant lower with an open propeller. It should furthermore
be well considered that tugs in ice might well be using over
80 per cent of time over 80 per cent of MCR. You really need
power, machinery built for that type of usage, and thrust
to make you move and/or clear the ice with independently
controlled propeller washes.
Much also depends on tug design and really on how you
operate the tug and plan the whole assistance operation.
Various ice class notations exist. Table2E.2 gives an
indication of the various ice class notations.For ice class
vessels from diff erent countries/registers, corresponding ice
classes are approximate and the fi nal decision on using a
vessel is the owner’s responsibility and risk.
Purpose built ice tugs
A purpose built ice tug is the Yuribey,built for the extreme
conditions at the Arctic Russian port of Sabetta, Yamal
peninsula, Kara Sea. Th e tug has LOA of 39.54m, beam 14m,
draft with skeg 7.1m, bollard pull ahead 97 tons, speed 14.4
knots and Ice Class ARC6. It has been designed for a wide
range of operations: ice breaking in the port and approach
channel, escort of LNG carriers, escort operations at speeds
3. Voith water tractors have the advantage of having VSPs
positioned close together and rotating outwards. Th e
general advantage of the tractor concept lies in the
deeply immersed propellers, which are less likely to get
in contact with ice.
Comments from Captain Siegfried Kempe, a tug master
aboard the Voith tractor tug Bugsier 16 since 1994, confi rm
the results of the study. “I have carried out numerous towing
jobs in ice. Quite frequently we have to clear the channel in
Rostock harbour but we have also had successful operations
in iced-up Swedish waters. Unlike jet (nozzle) propellers,
which are quickly blocked, Voith Schneider propellers have
no problem with ice fl oes. Th e VSP can push the ice aside
without any trouble. Th e propeller slipstream can be steered
in such a way that the ice is quickly and completely fl ushed
away and what’s more, the wake of the Voith Water Tractor
has another interesting eff ect, the channel clearance is much
wider. Th is is benefi cial for the ships that follow us.”
Further study might be needed to fi nd out why these
diff erences in experience exist.
Tugs with open propellers are favoured in very hard ice
conditions, because blocked ice in nozzles results in zero
Table 2E.2: Ice class notations. Source: mainly Worldwide Vancombe
76 Tug Use in Port
up to 10 knots, towing, pilotage of vessels and mooring
to berths, fire-fighting, participation in rescue operations
and oil spill cleaning, etc. The tug can also carry three 20ft
containers.
The tug has seven watertight compartments, double hull and
bottom, making it almost unsinkable.
Propulsion is by Azipods. Total power is 9,400 hp (7MW)
and the tug has four main engines.
Yuribey is designed for operating in temperatures down
to -50° C. This has been achieved by various measures:
forward and aft towing winches are located in enclosed
spaces, coamings of doors, covers, fittings, handrails,
Figure 2E.15: Tug Yuribey is engaged in ice breaking, escorting and
towing, etc; it has Azipod propulsion. Courtesy Donmar
Figure 2E.16: Forward enclosed winch. Courtesy Donmar
Figure 2E.17: Aft enclosed winch. Courtesy Donmar
Figure 2E.18: Tug Calypso with ice breaking bow Saimaa. Courtesy: Ilari Rainio / Finnish Transport Infrastructure Agency
Types of Harbour Tug 77
communication and navigation antennas and other devices
are electrically heated. The air take-in for the engine room
and living quarters, passes heaters, so ensuring preheating.
Two boilers are installed on the tug, providing heating of
incoming air, heating the vessel’s spaces and tanks.
Tug ice breaking bow
The tug ice breaking bow is a new development designed by
ILS Ship Design & Engineering. With such a removable bow
a typical pusher tug can be converted into an ice breaking
tug for inland waterway towage requirements. The removable
bow has a length of 25.30m and for propulsion two engines
of 800 hp each have been installed. See also figure 3.19 and
3.39 for tugs with ice-scrapers on the bow. It is claimed that
this first version will enable the tug to break 70cm ice at 2
knots and 40cm ice at 6 knots.
Training
Training is a necessity for tug masters operating in ice and
should focus on:
•	 Safe and effective handling of his tug in ice.
•	 The ability to read and predict ice and ice conditions,
visually, on radar information and on all available
preliminary information, in order to be able to find the
easy spots and cracks in ice, to assess the risk of nozzle
blocking, predict the possibility of passing through a
ridge without ramming, etc.
Much can be learned on simulators, but experience has to be
built up in daily practice.
Note: Much information comes from the paper Equipment
and operational Issues for Terminal and Escort Work in Ice
Conditions. See References. The reader is further referred to:
The IMO Polar Code 1024(26) ‘Ships operating in polar waters
and relevant classification rules’.
2.25 Research
Various new tug types have been developed during the last
years which have been addressed in the former paragraphs.
Although ongoing research results in continuous
improvements of modern tug types, only daily practice of
ship handling shows to what extent the new tugs meet the
expectations and what the capabilities and limitations really
are. Nevertheless, research is essential to produce ever better
tugs, be it for normal ship assistance, operations in waves, for
escorting or for the living conditions of the tug crew.
Research not only focuses on hull form, skegs, ropes, deck
equipment, operations in waves, etc, but also on such aspects
as liveability on board, automation and sensor information.
A very wide range of interest, all focused on increasing
performance and safety.
Apart from model tests and tank tests a method used in the
design stage is CFD (computational fluid dynamics). CFD
is the use of applied mathematics and physics implemented
in dedicated software to simulate how a fluid (gas or liquid)
flows, and how the fluid affects objects as it flows past. CFD
has been around since the early 20th century and many
people are familiar with it as a tool for analysing air flow
Figure 2E.19: Tank tests for escort performance with Damen
ASD tug 3212. Photo: Damen Shipyards
Figure 2E.20: Svitzer Deben ASD3212 escorting in the indirect mode
in real-life situation. Photo: Damen Shipyards
around cars and aircraft. It is also often used in ship and
tug design, for instance to optimise the tug’s underwater
body, the inflow of the propeller disk and to optimise nozzle
performance.
At the start (around year 2000) potential flow calculations
were possible, but since 2010 onward it has also been possible
to make viscous flow calculations to investigate complex
turbulent flows. Potential flow calculations can be valuable
to enable a ship designer to study smooth hull shapes and
slender bodies, particularly in the forward area. Gradually
the flow turns into turbulent flow along the hull’s length due
to friction and the formation of a boundary layer. For flow
and distribution into the propeller, detailed viscous flow
calculations are needed that can account for the frictional
effects and a correct representation of the boundary layer
around a ship.
Tug boats are typically full bodied vessels and introduce
large, turbulent, sometimes separated, flows along the thick
bodies. Today tugs are being calculated with CFD, and
reasonably accurate resistance and flow distribution into
the propeller area can be calculated for tugs; in recent years
even the flow around hull with appendages in indirect modes
can be determined. However, one has to consider that every
single condition calculation requires a significant amount
of computer power and time. And that analysing various
conditions and speeds is very costly and time consuming.
78 Tug Use in Port
Figure 2E.21: CFD simulations of flow pattern around a tug at speed.
Courtesy Damen Shipyards
Figure 2E.22: CFD of wave pattern around a tug at speed.
Courtesy Damen Shipyards
2.26 Tug performance
With respect to tug performance it is good to understand
some basic principles. The first item deals with performance
at speed, which is discussed in detail in Chapter 4, and the
second mainly withbollard pull conditions.
1) When the tug’s propeller wash is more or less with
the direction of the water flow, the propeller is said to be
operating in positive flow conditions. This is, for instance,
when a bow tug is pulling a ship having headway. When
the tug’s propeller wash is more or less against the direction
of the water flow, it is said to be operating in negative flow
conditions. This is, for instance, when a stern tug is braking a
ship’s speed.
Although greater thrust is produced when operating in a
negative flow, torque loadings on the propeller and engine
increase considerably, particularly with increasing speed
of the water flow. As the negative flow may also result in
an unstable flow through the propeller, it may produce
fluctuating loads and vibrations.
2) The line pull is essentially dependent on the square of the
propeller revolutions, and the engine power is dependent
on the cube of the revolutions. This means that if propeller
revolutions are doubled, the force will increase by a factor of
four, while the required engine power increases by a factor
of eight. This relationship not only applies to bollard pull
conditions, but approximately to most tug operations in port.
The efficiency of an open propeller – as already mentioned
– can be increased by fitting a nozzle. Tugs with the same
BHP may have a different bollard pull depending on whether
the propellers are fitted in a nozzle or not. Also, the type of
propeller and nozzle fitted is important. To determine the
towing force of a tug, bollard pull tests are carried out at
different engine ratings, particularly at the manufacturer’s
recommended continuous rating (MCR). Tests can also be
carried out at engine overload conditions, for instance with a
maximum rating that can be maintained for a minimum of
one hour, and also with just one propeller working.
Bollard pull tests are carried out with engines ahead and
increasingly, especially for azimuth tugs, on astern. Bollard
pull tests should be carried out with sufficient underkeel
clearance and line length to avoid the tugs’s propeller wash
having any influence on propulsor performance and hence
towline force. Other factors affecting the towline force are
current, waves and wind, which should be minimal during
testing. Bollard pull is measured by an electronic load cell
connected in series with the towline.
Classification societies issue different regulations for the
bollard pull tests. In 2016 a Joint Industry Project was
initiated by MARIN with the objective to derive requirements
regarding towline length, water depth, test duration,
environmental conditions and instrumentation based on
scientific proof. Together with more than 30 companies clear
definitions and procedures were developed to ensure the
reported performance of a tug represents the tug’s maximum
performance that can be realised in service conditions,
irrespective of trial conditions, that can represent contractual
performance obligations.
Thus, CFD simulations provide the designer with high
quality information on the entire flow around a tug.
Among others, Lloyd’s Register gives guidelines for CFD
Escort Performance (publication ShipRight. Design and
Construction. May 2016). However, to successfully use
CFD for practical calculations of complex turbulent flow,
a thorough understanding of the errors involved in such
simulations is required, and the relation to the computational
set-up employed. Adding complexity to the simulations
has an effect on the errors. Therefore, a procedure of
verification and validation should be followed. Verification
to quantify the numerical uncertainty can for instance be
done by systematically reducing the cell size of the grid, and
validation focuses on the modelling uncertainty.
Considering the ever increasing computer power, there is
a bright future for CFD in the shipping and tug industry.
However, there is also a clear need of good designers and
users, as indeed the well known statement applies to CFD as
well : Garbage in, Garbage out!
Note 13: When seeing the flow pattern around the tug in figure
2E.21 it can be observed that there is an increased water speed
along the sides of the tug (the blue coloured lines) and a retarded
flow (red lines) at the bow and stern. This is exactly in line with
the water flow around a ship to be discussed in Chapter 6.
Publication of research results are always very welcome so
that all involved in one way or another in tug design, tug
building and tug operations can learn from the results and/
or make use of them when needed and applicable.
An example: Based, among others, on the results of the
research carried out during the SafeTug JIP (joint industrial
project) at MARIN, the Netherlands, which reported in 2010,
Bureau Veritas published the Safety Guidelines for Design,
Construction and Operation of Tugs in July 2014.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Types of Harbour Tug 79
with controllable pitch propellers is given. The astern thrust
of conventional tugs with fixed pitch propellers is higher
and around 65 per cent of maximum ahead thrust, but it
depends strongly on the nozzle type, propeller/rudder design
and configuration. For example, the Towmaster system may
improve ahead thrust to even more than 1.50 tons BP/100
BHP, while a very good astern thrust of more than 70 per
cent of maximum ahead thrust can be achieved.
Note 14: Particularly for the more sideways thrust, it is difficult
to say how accurate the thrust vector diagrams are. Simulated
or calculated performance diagrams should therefore, as far as
possible, be validated in full scale trials.
These diagrams show the achievable thrust at zero speed
in different directions for a number of tug types with equal
power installed. The achievable ahead thrust per 100bhp
installed power as shown in the diagrams is 1.1 tons for a VS
tug, 1.4 tons for tugs with azimuth thrusters and 1.5 tons for
conventional tugs with propellers in nozzles.
Note 15. A good indication of a tug’s ship assist performance
over a range of speeds can be given by so-called polar diagrams
as is shown in Chapter 4.
Based on a large matrix of model and full scale bollard pull
tests it shows that for most tugs no performance degradation
takes place when the water depth is approximately 6x
the propeller immersion depth with a line length of 50x
propeller diameter. In conditions lower than these thresholds
performance degradation can be expected. Water density also
affects bollard pull, whereby the thrust in high density water
is higher for the same power compared to the thrust in fresh
water. The largest uncertainty in bollard pull is, however, the
sensitivity of the load cell measurement device for alignment,
incorrect calibration procedures, temperature, torsion and
instrumentation drift. Frequent recalibration and proven
insensitivity to these factors is necessary for accurate bollard
pull measurement.
During bollard pull trials, the towline force should be
recorded electronically using a sampling rate of 1Hz or better
to avoid aliasing (= digital disturbance, distortion).The figure
certified as the tug’s continuous bollard pull is the towing
force recorded as being maintained without any tendency to
decline for a duration of not less than 5 minutes for harbour
tugs. Repeat measurements are recommended to give insight
in the repeatability of the load cell and stability of the tug
and towline force. The bollard pull trial code is schedule to be
finalised and published in 2018.
Table 2E.3, opposite, gives a range of the ratio bhp - bollard
pull for different propeller configurations. Because the relation
between bollard pull and engine power depends on several
factors, such as hull form, nozzle and propeller type and size,
etc. these values do vary.
The relationship between engine power and bollard pull varies
also with the extent of engine powerand in such a way that a
conventional tug with 700bhp and a fixed propeller can attain
two tons/100bhp, while for conventional tugs with about
6,000bhp with nozzles, towing force may even be less than 1.3
tons/100bhp.
Propeller performance is also shown in so-called thrust
vector diagrams. Several kinds of these diagrams exist, all of
them giving different information. Thrust vector diagrams
give information on propulsion performance with zero speed
in different directions, which is also important information
to assess the tug’s assisting performance. An example of
thrust vector diagrams with an indication of thrust forces is
given in figure 2E.23. It gives propulsion performance at zero
speed for equal installed power. Side thrust and the influence
of interaction of propellers on side thrust are clearly shown
in the diagram.
In this thrust vector diagram the ahead values given are also
more or less maximum values. The astern thrust of ASD-
tugs may vary between 90 per cent and 95 per cent of ahead
thrust. In the diagram the astern thrust of conventional tugs
Tug propulsion type Bollard Pull in
Tons/100kW
Bollard Pull in
Tons/100bhp
Azimuthing thrusters
Stern drive 1.5 – 1.7 1.1 – 1.3
Tractor 1.3 – 1.5 1.0 – 1.1
Voith Schneider tractor 1.2 – 1.4 0.9 – 1.0
Conventional drive
Nozzled propeller 1.8 – 2.0 1.3 – 1.5
Open propeller 1.3 – 1.5 1.0 – 1.1
CPP* -2%
ICE* -2 - -4% according to ice class
*Not applicable on Voith Schneider propulsion
Table 2E.3 Ranges in relationship between brake horsepower and bollard
pull for different tug types. Brake horsepower (bhp) is measured at the
flywheel; shaft horsepower (shp) is measured at the propeller shaft (shp
= ± 0.97 x bhp). Source: Damen Shipyards, the Netherlands
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
80 Tug Use in Port
Figure 2E.23: Example of a thrust vector diagram.
Legend a) Tractor tug: Voith; b) Tractor tug: azimuth propeller in nozzles; c) Stern drive tug:
azimuth propeller in nozzles; d) Conventional tug: twin screw (cpp) nozzles and bow thruster;
e) Conventional tug: twin screw (cpp) with nozzles.
Assisting Methods 81
the performance of the different tug types in relation to the
assisting methods is considered. Tug assistance as may be
required in ports is first addressed in more detail to obtain a
better insight into what tugs should be capable of doing.
Tug assistance during a transit may comprise:
•	 Passage through a river or channel.
•	 Entry manoeuvres into a harbour or turning basin from
river, channel or sea.
•	 Passage through narrow harbour basins.
•	 Passing narrow bridges or locks.
Over the larger part of a transit route the speed of a vessel is
mostly within the range of about 3-6 knots and sometimes
even higher. At these relatively low ship’s speeds the
influence of wind, current and waves is more pronounced,
affecting the required path width adversely due to the larger
drift angle. Steering ability is less at lower speeds, and is
adversely influenced by wind and current. On the other
hand, speeds up to 6 knots may become rather high for
effective tug assistance.
When port configuration is such that tugs are mainly used
for mooring and unmooring operations, then tug assistance
may comprise:
•	 The approach phase towards turning basin or berth.
•	 Turning in a turning basin.
•	 Mooring and unmooring operations.
Contrary to transit speeds, ship’s speed during these
manoeuvres is normally very low or zero. Although tugs
should be capable of controlling a ship’s heading and speed
and compensating for the influence of wind and current
while approaching the turning circle or berth, the influence
of ship’s speed on the performance of different tug types is
less predominant.
Tugs assisting during transits, taking into account the
assisting method applied, should be capable of:
Giving steering assistance and controlling ship’s speed
Steering assistance while the ship has headway may be
necessary in narrow passages, when passing bridges or
negotiating sharp and/or narrow bends in the fairway, river
or channel, or when entering harbour or turning basins
under the varying influence of current and wind conditions.
Controlling ship’s heading and speed may be required when
approaching the harbour or turning basin or when entering
a lock.
Compensating for wind and current during transit
while a ship has speed
While transiting a channel, river or harbour basin a ship
under the influence of wind and/or current may experience
drift. This can be compensated for by steering a drift angle
or by a higher speed. A higher speed is normally not possible
Figure 3.1: Port of Baltimore. Mortrac tug Harriet Moran (LOA 28.2m,
beam 8.9m, 3,005hp) and reverse-tractor tug April Moran (LOA 26.5m,
beam 10.5m, 5,100 hp) pushing at the stern of a ship dead in the water.
A Mortrac tug is a combi-tug. Harriet Moran is a single screw tug with a
triple rudder system and a retractable azimuth bow thruster of 640hp.
Photo: Pilot John Traut
3.1 Introduction
In the first chapter different types of port were discussed. In
these ports tugs may render one of the following services:
•	 Tug assistance during a transit to or from a berth,
including assistance during mooring and unmooring
operations.
•	 Tug assistance mainly during mooring and unmooring
operations only.
To what extent tug assistance is considered to be necessary
depends on particulars of:
•	 The ship – including type, size, draft, length/width ratio,
loading condition, windage and manoeuvrability.
•	 The berth and nearby manoeuvring area – including
type and size of berth, alignment, berthing space,
manoeuvring space near the berth, size of turning
circle, water depth, influence of current and wind, and
availability of mooring boats.
•	 The transit route – such as width, length and depth,
the bends in that route, maximum allowable speed,
traffic to be expected and whether moored ships have
to be passed, plus the influence of current, wind, waves,
shallow water and banks.
The important difference between tug assistance during
mooring/unmooring operations and during a transit lies
in the difference in ship’s speed, which is a major factor
of importance for selecting the most appropriate type of
tug and method of tug assistance. The various methods
of tug assistance employed in ports around the world are
reviewed in this chapter, including the types of tugs used.
In the next chapter the large influence of ship’s speed on
Chapter 3
ASSISTING METHODS
max allowable speed wtf
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
82 Tug Use in Port
3.2 Assisting methods
3.2.1 Assisting methods in use
The different ways ships are handled by tugs in various areas
and ports around the world can indeed mainly be traced
back to large differences in local circumstances. Methods of
assistance that different tug types are used for have already
been mentioned briefly while discussing the various types.
Assessment of assisting methods in use all over the world
shows only two markedly different methods:
•	 Tugs towing on a line.
•	 Tugs operating at a ship’s side.
Irrespective of tug type, both methods can be applied by
almost all tug types, although for some tugs effective towing
on a line can be somewhat problematic. The capabilities
of modern and new tug types are large and this sometimes
results in different ways of shiphandling. This has been
shown in the former chapter but are still related to the two
methods mentioned.
In European ports towing on a line is mainly used, while
in the USA and West Pacific ports tugs usually operate at a
ship’s side, although in differentup by the disturbance and to
 reduce them progressively to zero. Course stability should not be confused with directional stability,
 which is, strictly speaking, the ability of a ship to follow a certain direction, eg by means of an automatic
 steering system. A ship closely following a selected heading has directional stability but may be course
 unstable (see below), which results in frequent rudder (or thruster) actions to hold the ship on its course.
Course stable ship With a constant position of the steering systems (rudders, thrusters, etc), a ship is defined to be course stable
if, after experiencing a brief disturbance, it will resume the original manoeuvre without any use of the means
of steering. Course stability on a straight course, with the rudder in the equilibrium position, is mostly only
considered. A turn initiated by a brief disturbance of a course stable ship will thus not continue. However, after
the disturbance has vanished, the actual course of the ship will generally be altered. A course stable ship needs
relatively large rudder angles for course changing. A course stable ship has good yaw checking ability.
Course unstable ship A ship is called course unstable, if, after it is disturbed, it will immediately start to turn. Course
 changing, with relatively high rates of turn, can be achieved with relatively small rudder angles. A
 course unstable ship therefore generally has poor yaw checking ability.
Cross lines/gate lines Separate lines from either side of the tow to the opposite quarter of the tug or the opposite side of the
 tug's H-towing bitt.
GLOSSARY OF TERMS
Pgua_Supplay
Destacar
Tug Use in Port xi
CRT Carrousel RAVE (Robert Allan Voith Escort) Tug – a tug with one Voith Schneider propulsion unit
 forward and one aft. It has a ring around the wheelhouse along which the towing winch and towing
 point travel.
Dead ship A ship which cannot use her own propulsion.
Density of air as used 1.28kg/m3
Density of sea water as used 1,025kg/m3
DOF Degrees of freedom refers, among other things, to the ability of simulators to reproduce ship and tug
 motions, whether by the projection screen or by a hydraulic platform. Ship and tug motions are
 expressed in sway, surge and yaw, being the motions in the horizontal plane, and heave, pitch and roll,
 being the motions in the vertical plane. There are in total six degrees of freedom of movement for a
 vessel that is unrestricted in its motions.
DOT Dynamic Oval Towing: A system whereby the towing point travels along an oval ring around the tug’s
 superstructure.
Escort tugs Tugs specifically built for escorting at high speeds.
Escorting tug Any type of tug escorting a ship underway.
FLNG Floating Liquefied Natural Gas
F(P)SO Floating (Production) Storage and Offloading Unit.
FSRU Floating Storage and Regasification Unit
Free sailing A tug sailing independently.
Girting Risk of capsizing, especially with conventional tugs, due to high athwartships towline forces. Also
 known as girding, girthing or tripping.
Gob rope/gog line A rope or steel wire used on conventional tugs to shift the towing point.
HMPE High-modulus polyethylene fibre, under the trade names Spectra and Dyneema, used for high
 performance ropes.
Hockle Kinking or twisting of a strand in a rope which makes it unfit for use.
IMO International Maritime Organization.
Lateral centre of pressure
 The point of application of the hydrodynamic forces in the longitudinal centre plane of a ship or tug
 This point changes with varying angle of attack of the incoming water flow and with draft, trim and
 heel.
Lbp Length between perpendiculars.
LOA Length overall.
LWL Length at the waterline.
MBL Minimum Breaking Load (of a rope).
Maritime Autonomous Surface Ships (MASS)
 Defined by IMO as a ship which, to a varying degree, can operate independently of human interaction.
GM Initial Metacentric Height.
Messenger A light rope attached to the towline in order to heave the towline on board a ship.
Norman pins Short iron bars fitted in the gunwales of the transom to prevent the towline from slipping over the side
 gunwales. Sometimes called ‘king pins’.
Nozzle A tube around the propeller to increase propeller performance. The nozzle can be fixed or steerable.
OCIMF Oil Companies International Marine Forum.
PIANC Permanent International Association of Navigation Congresses.
Pendant/pennant A separate part at the final part of a towline which is most liable to wear on board an assisted ship, at
 ship's fairleads, etc. The pendant can be of different construction to the towline.
Pen (tug pen) A tug pen is a special protective berth from cyclonic winds and is enclosed on three sides.
Propulsion (types of) Azimuth propellers: 360° steerable propellers, which can deliver thrust in any direction.
 Also called: ‘Z-pellers’, ‘Rexpellers’, ‘Duckpellers’ (azimuth propellers in nozzles).
 CPP: Controllable pitch propeller(s).
 FPP: Fixed pitch propeller(s).
 VS: Voith Schneider propulsion: propulsion system with vertical propeller blades, also called
 cycloidal propulsion system.
PRT Prevention and Response Tug.
Significant wave height
 The approximate wave height as seen by an experienced observer when estimating the height visually.
Snag resistance Resistance of a rope to single yarns being pulled out of the rope when it slides along a surface, such as
 over a deck or through a fairlead. A snag is a loop of a yarn.
Pgua_Supplay
Destacar
xii Tug Use in Port
SPM Single Point Moorings.
Sponson A strongly flared section in the side of a tug, commencing at or just below the waterline, which results
 in substantial increase in deck area and reserve buoyancy without increasing the beam at the waterline.
Stemming A tug coming under the bow of a ship at speed.
Stretcher That part of a towline, between the original towline and pennant, which absorbs the dynamic forces in
 the towline. Also called a spring and often made of nylon, polyester or a polyester/polypropylene
 combination.
Towing point Point of application of the towline force. It is the point from where the towline goes in a straight line
 towards the ship.
Towline A flexible hawser used for towing purposes.
Tripping A tug towing on a line swinging around and coming alongside a ship's hull due to excessive speed by
 the ship in relation to a tug’s capabilities and towing angle. The expression ‘tripping’ is also used for
 girting.
Tug/engine power BHP Brake Horse Power: power delivered by the engine.
 SHP: Shaft Horse Power: power delivered to the propeller shaft (approximately 97% of BHP).
 BP: Bollard Pull, which in this book is expressed in the practical units of tons, equal to
 1,000 kgf (= 9.80665 kN).
 MCR: Maximum Continuous Rating (of tug engine).
Ton The practical unit used in this book for force, eg for bollard pull, equal to 1000 kg force, and for 'weight',
 equal to 1,000kg.
Tug simulation
 Interactive tug: A tug simulated on a bridge manoeuvring simulator, able to interact with other
 bridge manoeuvring simulators, which are simulating other tugs and/or the assisted
 ship.
 Vector tugs: Tugs simulated by just a force vector.
UHMW polyethylene (UHMW PE)
 Ultra High Molecular Weight polyethylene. Material used for dock fendering and for fenders of tug
 boats at places where a low friction coefficient is required.
VS-tug A tug with VS propulsion.
The Overview 1
Figure 0.1: Reverse tractor tugs Seaspan Falcon (LOA 24.6m, beam 9.8m; BP ahead 39 tons) and Seaspan Eagle
(LOA 28.2m, beam 12.6m, BP 71 tons) keeping bulk carrier alongside. Photo: SeaspanMarine, Canada
The contents of this book are outlined below.
•	 A general review is presented first of factors which affect
operational requirements for a harbour tug, such as the
different tasks for which they are used, the particulars of
a port, the environmentalways depending on the type
of tug used. Particularly in Europe and in the USA there is a
tendency towards the use of more flexible types of tug. This
tendency has an impact on the assisting methods used in
Europe as well as in the USA, which should be kept in mind
when reading this paragraph.
In some ports combinations of methods are used, or
introduced, depending on the local situation or new tug type.
For specific situations or circumstances, assisting methods
are applied other than those in normal use. So it is possible
that in ports where tugs normally work alongside, they will
occasionally assist while towing on a line, for example when
narrow bridges have to be passed or when ships have to enter
a dry dock. Changing the assisting method can become
necessary at seaside terminals, where tug assistance is
affected by waves. If in calm weather it is normal practice to
assist alongside a vessel, it may be considered safer to tow on
a line when weather and sea conditions deteriorate in order
to avoid parting towlines and losing control of the vessel.
in confined port areas and due to the limited width in
narrow passages only small drift angles are acceptable. Tug
assistance is then necessary.
Tugs assisting ships during a transit normally also assist
during mooring/unmooring operations and the final
approach and departure manoeuvres as tugs used for
mooring/unmooring operations only. All these tugs should,
with the assistance method applied, be capable of effectively:
Controlling transverse speed towards a berth while
compensating for wind and current during mooring/
unmooring operations
During mooring operations a ship’s longitudinal ground
speed is practically zero and, when there is no current, the
ship has hardly any speed through the water. The same
applies when a ship has to be turned in a turning basin.
Mainly crosswise pushing and/or pulling forces have to be
applied by the tugs.
The tug assistance required as outlined above has been
somewhat simplified. In any particular case the complete tug
assistance procedure may consist more of a combination of
the separate aspects that have been described. Environmental
conditions have a large influence. For instance, when tugs
are used mainly for mooring/unmooring, the influence of
currents can be such that although ship’s ground speed is
low, say two knots, the speed through the water can be rather
high. With a bow current of two knots, the speed through
the water is already four knots. Situations then become
comparable to tug assistance during a transit with the
higher ship’s speeds and the associated requirements for the
assisting tugs.
Additional services such as mooring boats also affect the
extent and method of tug assistance. When no mooring
boats are available the tugs must be stationed and operated in
such a way that the ship can be pushed/pulled up to a berth.
It can be concluded that the port configuration, the influence
of the environmental conditions and port services have a
prominent bearing on the requirements for tugs and the
method of tug assistance, while ship’s speed is an essential
factor.
Figure 3.2: Combination
of tug towing on a line
and tug at the ship’s
side (shoulder). Tanker
Gener8 Ulysses; ASD-
tugs Smit Schelde (LOA
28.67m, beam 10.43m,
BP ahead 59 tons, astern
56 tons) and Fairplay
24 (LOA 34.75m, beam
10.80m, BP ahead 52
tons. Photo: Kees Torn
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Assisting Methods 83
be steered by a tug pushing at the ship’s bow. Pushing at the
port side of the bow will give the ship a swing to starboard,
pushing at the starboard side of the bow will give the ship a
swing to port (see figure 3.10).
In some ports in the USA and in the Panama Canal a stern
tug is used as shown in figure 3.8. A rudder tug can control
a ship’s speed and a conventional tug can steer a ship in the
required direction by giving forward thrust and applying
starboard or port rudder. Other types of tug such as VS tugs
and ASD-tugs also use this method. A similar method is
sometimes used on Dutch inland waters.
Forward tug alongside and aft tug on a line during
approach towards a berth and push-pull while mooring
This method, which does not differ much from that
mentioned above, is mainly found in the ports of Japan,
According to research carried out in 1996 into assisting
methods in use in ports around the world, the two methods
are generally applied in the following ways, assuming two
tugs assist a vessel:
Tugs alongside during approach to the berth and pushing
or push-pull while mooring
This method is normally used in the majority of ports in the
USA, Canada, Australia, Malaysia, South Africa and also
at large oil terminals in Norway. While the method used in
these ports is similar, the type of tug differs. The way tugs are
secured using this method depends mainly on the type of
tug. When using tugs with omnidirectional propulsion they
are made fast at the forward and aft shoulder, generally with
one bow line from the tug in case of ASD/reverse-tractor tugs
and with a line from the tug’s stern when tractor tugs are
used (see figure 3.3).
In the USA tugs may be secured alongside a ship by one,
two or three lines, depending on the type of tug, the local
situation and the assistance required. Conventional tugs
normally operate with two or three lines made fast, though
in some cases only one line is deemed sufficient (see figure
3.4). The forward line is a tug’s backing line to be made fast
to the ship. The spring may come from the forward winch
through a tug’s most forward bow chock or fairlead. On
other tugs both lines may come from a winch. The third
line, the stern line, is needed when a tug has to work at right
angles to a ship to prevent the tug from falling alongside
when the ship has forward or astern movement through
the water, or to compensate for the transverse effect of a
tug’s propeller when going astern. This line may come from
a winch or be fastened on a bitt. It also compensates for
the influence of the ship’s propeller wash when the ship’s
propeller is going astern. A forward as well as an aft tug may
be secured in this way.
Owing to their better manoeuvrability, twin screw tugs or
tugs with steerable nozzles normally operate with fewer lines
when assisting at a ship’s side. Usually one or two lines will
then be sufficient.
In the USA other methods are also used by tugs operating
at the ship’s side. When breasted or alongside towing, also
called ‘on the hip’ or ‘hipped up’, tugs forward and/or aft
are lashed up solidly alongside a vessel (see figure 3.5). This
alongside towing is also operated in many other ports in the
world, but mainly when handling barges.
When a tug is lashed up, tug and ship work like a twin screw
ship with two independent rudders. When lashed up forward
to a ship with the tug’s bow facing aft, the tug’s engine and
rudder combined act like a kind of steerable bow thruster
(see figure 3.6). A ship can then turn on the spot or move
sideways. Alongside towing is also used in USA ports to
handle a ‘dead ship’, and occasionally applied in a similar
way in some other ports – for instance in the port of Cape
Town ships up to 100 M in length are sometimes handled as
a ‘dead ship’ by a VS tug lashed up alongside (see figure 3.7).
In USA ports, methods are also used that differ from those
discussed above. For example, in certain situations tugs may
work stem to stem with a vessel. A ship moving astern can
Figure 3.3: Tugs alongside at approach and push-pull while mooring/
unmooring.
Figure 3.4: Conventional USA tug secured with backing, spring and
stern lines. In situation 2 the ship moves astern. If ship moves ahead
the stern line will lead forward. Depending on the assistance required
and local situation, one, two or three lines may be required.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_SupplayDestacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
84 Tug Use in Port
They are reverse-tractor tugs or sometimes ASD-tugs, with
360° steerable thrusters under the stern and made fast with
a line from the tug’s forward winch. For certain specific
manoeuvres these tugs have to assist while towing on a
line, for example when assisting ships to enter dry docks or
floating docks.
Taiwan and Hong Kong (see figure 3.11). The after tug is
made fast by a tug’s bow line amidships or at the starboard
or port quarter aft and follows the ship. The forward tug
is made fast at the forward shoulder, also with a bow line.
The after tug is used for steering and speed control. During
berthing manoeuvres the tugs change over to the push-pull
method. Tugs in these ports are all of similar design, more
or less specifically constructed for this type of operation.
Figure 3.5: Alongside towing (USA).
Figure 3.6: Forward tug secured alongside. As shown the ship can
turn on the spot and when the tug applies hard port rudder and engine
ahead, the ship moves crosswise. Ship’s ahead power to be equal to
tug’s ahead power.
 Figure 3.9: Tug Cerro Picacho, tractor tug (LOA 28.9m, beam 13.5m,
BP 82 tons), operating as steering tug in the Panama Canal.
Courtesy Panama Canal Authority
Figure 3.8: Rudder or steering tug.
Figure 3.7: Alongside towing in Cape Town for a ‘dead ship’
up to 100m in length.
Figure 3.11: At approach, forward tug alongside and stern tug
on a line; push-pull while berthing.
Figure 3.10: ASD tug Gramma Lee T Moran (LOA 26.7m, breadth 9.8m,
engines 5,100 bhp) pushing the bow of Queen Mary II to port on her
maiden voyage to New York, April 2004.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Assisting Methods 85
Apart from the countries mentioned above this method is
applied in some other ports around the world either with
reverse-tractor tugs or with tractor tugs. Furthermore,
conventional tugs are sometimes used for this method, as is
the case in some USA ports whereby the stern tug operates
like a rudder tug. While berthing this tug stays close behind
the ship’s stern and pushes it towards the berth on the tug’s
bow line.
Tugs towing on a line during transit towards a berth
and while mooring
This is the assisting method used specifically in Europe, most
often when conventional tugs are assisting vessels, but other
types of tugs are also used for this method. The method is
also applied in many other ports of the world, especially in
ports working with conventional tugs (see figure 3.12). In
many of these ports, ships are assisted by tugs during transit
towards the berth, eg, on the river, from the river into the
harbour and through harbour basins up to a berth. The
advantage of this method of assistance is that it can be used
in narrow waters. This method is also used, therefore, when
passing narrow bridges or entering locks and dry-docks. In
such situations the forward tug sometimes has two towlines,
so-called cross lines or gate lines or both lines may come
from a double winch at the tug’s bow as can be the case
on some reverse-tractor tugs. The tug can then react very
quickly and only a little manoeuvring space is required (see
figure 3.13).
The type of tugs used were originally conventional tugs
with a small engine and a streamlined underwater body.
These were very effective when a ship had some speed, by
making use of the tug’s mass and the hydrodynamic forces
on the tug’s hull. The increasing size of ships required the
introduction of more powerful tugs. Modern conventional
tugs are more manoeuvrable and have more engine power
and generally a smaller length/width ratio. These tugs are
still effective when a ship has speed. Due to the limitation in
capabilities of conventional tugs, new tug types have been
introduced such as tugs with azimuth propulsion. Also, VS
tugs have for many years been used for towing on a line.
When more than two tugs are used during berthing the
forward and aft tug will usually stay on the towing line to
control approach speed towards a berth while the other tugs
push at the ship’s side.
Tugs towing on a line during approach towards a berth
and push-pull while mooring
This assisting method is becoming common practice in
ports where towing on a line is carried out with highly
manoeuvrable tugs such as tractor, reverse-tractor or
ASD-tugs (see figure 3.14). The more familiar pilots and tug
captains become with the capabilities of these tugs, the better
the capabilities are applied to shiphandling. The method is
practised where mainly tractor, reverse-tractor or ASD-tugs
are used.
Combinations of the above systems
In many ports various tug types are operated and to assist
larger ships more than two tugs are often required. Moreover,
port entry or berthing manoeuvres can be so complicated
that not just one assisting method is used but a combination.
Figure 3.12: Towing on a line at the approach and while mooring.
Figure 3.13: Ship is passing a narrow bridge and a conventional
tug forward is assisting with two crossed towlines. The tug can react
quickly and only a little manoeuvring space is required.
Figure 3.14: Towing on a line at the approach and push-pull
while mooring.
Figure 3.15: Combination of different assisting methods. Reverse-tractor
tugs or ASD-tugs alongside and on a line aft. A conventional tug forward.
A good configuration for steering and, in particular, when only a short
stopping distance is available. Nearer the berth one of the tugs alongside
has to shift to the other side to push.
As an example of a combined method the assisting method
applied in an Australian port for large bulk carriers entering
the harbour is shown in figure 3.15.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
86 Tug Use in Port
3.2.2 Push-pull versus towing on a line
The push-pull method has been discussed as well as towing
on a line, and even the possibility of using a combination of
both methods.
Tugs operating alongside in the push-pull mode have
the advantage that they can act rather quickly with short
response times, which is of particular importance during
berthing operations. The risks associated with tugs working
in close proximity to the bow of a ship having speed, such as
interaction forces and turning moments, are negated.
On the other hand, there are some drawbacks having tugs
operating in this way:
•	 Towlines are often very short which presents a problem
in wave conditions.
•	 When pulling with short towlines, there is a loss of
pulling effectiveness caused by the tug’s propeller wash
hitting the ship’s hull at right angles. Tugs may lengthen
the towline if equipped with a towing winch and so
decrease the negative effect.
•	 In case of conventional tugs, pulling effectiveness is low
due to the low propeller performance when engines are
running astern.
•	 Combined width of ship and tugs can be a problem in
narrow passages such as locks and bridges.
•	 Tugs must be used on the opposite side to which ship is
to berth. There is no flexibility in berthing side as soon
as the tugs are fastened alongside.
•	 When the ship has to be turned, the turning lever is
relatively short, namely, the distance between the two
tugs at ship’s side.
•	 With high windage ships and tugs fastened at the
leeside, the tugs may become jammed between ship and
shore or quay if the winds or gusts become too strong.
Speed control by stern tug
Omni-directional stern tugs are sometimes used to:
•	 brake the ship’s speed or;
•	 to keep the ship’s speed at a low level of, eg, 3-4 knots
which is lower than the ship’s Dead Slow Ahead speed,while the ship keeps its engine running in order to be
able to steer.
The first can be necessary in case of an engine break-
down and the ship has to be stopped, or perhaps when
approaching the turning circle to help in braking the
speed. Simultaneously, the method can be used to avoid the
transverse effect of the ship’s propeller when the engine is
running astern which could have a negative effect on the
manoeuvre. The time that the tug is pulling is usually only
short.
The second method is utilised when approaching a lock
(see figure 3.16), when passing a narrow bridge in windy
conditions with a high windage vessel, or when moored
ships have to be passed with a low speed. It is also used when
the Dead Slow Ahead speed of the ship is too high, more
than 6-7 knots, too high for the forward tugs to make fast
safely, and continuously stopping the engine is not an option
because of the wind or because poor steering performance
with stopped engine. In these cases, the time that the stern
tug is pulling can take much longer.
Keeping ship’s speed under control is becoming more
commonly utilised. Tugs should be capable of doing so but
vibration on board the tugs can be tremendous. For this
reason tug masters may be unhappy with the speed control
method when it is used for long periods of time. See also
paragraph 4.3.4.

Figure 3.16: Azimuth
tractor tug Arion (LOA
28.75m, beam 9.1m,
BP 45 tons, pulling
backwards on tanker
Torm Loke and so
enabling the tanker to
keep engine running
and ship steerable.
Photo: Port Towage
Amsterdam
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Assisting Methods 87
In the ports of Japan, Taiwan and Hong Kong there is one
assisting method and mainly one type of tug. The reverse-
tractor tug with its omnidirectional propulsion at the stern is
well suited to operate the assisting method in use – on a line
at a ship’s stern and alongside at the forward shoulder. ASD-
tugs are, however, also used for this method. It is anticipated
that for these ports the reverse-tractor tug is the type that
will usually be ordered in the future.
There is often a steady development towards a particular tug
type. For instance, years ago there were still several VS tugs
in the Port of Yokohama. This type has now been replaced by
the typical Japanese type of tug, the reverse-tractor type.
In Europe towing on a line is general practice, originally
just with conventional tugs. Due to the limitations of
conventional tugs, various tug types with omni-directional
propulsion are now increasingly being used, resulting in a
change to more flexible assisting methods. This is the case in
many other ports where originally mainly conventional tugs
were used.
In the USA tugs operate at a ship’s side most of the time,
and for many years the conventional tug was practically
the only type to be found. The limited manoeuvrability and
•	 The tug masters have only little insight into the
manoeuvres being undertaken by the pilot.

When tugs are towing on a line the risks of interactions do
play a role, in particular when passing a towline near the
bow. Response times may also be somewhat longer. There
may also be a loss of towing effectiveness when the propeller
wash impinges on the ship’s hull, depending on the length of
the towline and towing direction.
Towing on a line has a number of important advantages:
•	 Towlines are longer, consequently effect of waves and
even waves of passing ships are smaller.
•	 If necessary total path width can be decreased to
approximately the width of the assisted ship, which is
important for bridge and lock passages. The capability to
do so is enhanced with conventional tugs and ASD-tugs
working over the stern. Total path width can be further
reduced by using two towlines ( see figures 3.9 and 3.13)
and by specific tug types, such as the Rotortug and the
new types of tugs with one propulsion unit forward and
one aft.
•	 With a tug towing on a line forward and aft, the ship can
either moor with starboard or with port side alongside.
•	 Tugs operate at the safe side in case of crosswinds or
cross currents and avoid getting jammed.
•	 In case where the ship has to be turned, the turning lever
is as large as possible.
•	 Tug master has a better view of how the ship is behaving,
eg, does it drift, turn in the wrong direction or too
slowly, and can anticipate if necessary.
•	 During mooring tug masters have a good view of
distances forward and aft and can inform the pilot if
there is a risk of hitting any obstacles.
3.2.3 Locks and tug assistance
Large ships entering locks are assisted by tugs in various
ways. In most cases just one towline is used (see figures 3.16
and 3.18). However it might also be possible that the assisting
tugs use two towlines from two independent winches as is
the case in the new locks of the Panama Canal (see figures
3.9 and 3.17). These tugs are well equipped for this type of
operations. The advantage of using two lines is to enable
the tug to be effective in the limited width of the locks and
to reduce response times. However, securing tugs with two
towlines can be problematic with the trend toward minimum
numbers of crew members on board ships.
More modern tug types such as Rotortugs and the tugs
with one propulsion unit forward and one aft have specific
manoeuvring capabilities that are also able to assist within
the ships width. See paragraph 2.11.3 and 2.19.3.
3.2.4 Relationship between type of tug
and assisting method
As can be seen, there is a relationship between type of tug
and assisting method used. An essential factor is whether
a tug should be suitable to operate at a ship’s side, tow on a
line, or both. For the attentive reader it will also be clear that
the most suitable tugs are not always available or used.
Figure 3.17: Ship entering the new Panama Canal Lock with forward
tug with two towlines. Courtesy Panama Canal Authority
Figure 3.18: Ship entering locks at Terneuzen with forward tug
Multratug 14 (Voith Schneider tug, LOA 34.50m, beam 11.60m,
BP 75 tons, with one towline. Photo: Adri van de Wege
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
88 Tug Use in Port
vessels which may damage their propellers or rudders when
they have sternway and/or when a ship’s engine is working
astern and light draft vessels with bronze propellers which
cannot be ballasted or trimmed sufficiently require tug
assistance.
Note 1:
Tests in ice conditions in the North of the Bay of Bothnia in
March 2016 with newly developed bronze propellers showed
that these propellers can be suitable for vessels in 1A Super
ice conditions. The testing conditions gave reliable results and
input for the propeller design for 1A and 1A Super ice class
vessels (for Ice Class notations, see paragraph 2.24).
With respect to berthing procedures ships can be divided
into two main groups:
•	 Ships that can work with their engines on Dead Slow on
a spring line, without the danger of parting: eg, small
vessels and ships with controllable pitch propellers.
•	 Ships with large engines, high starting power and high
propeller thrust at minimum propeller revolutions, not
able to work at Dead Slow without parting the spring line,
even when a double line is used.
3.3.3 Preparation before berthing or
unberthing
Before mooring, a berth should be prepared by an icebreaker
or by tugs when ice is too thick for the ship itself. Ice should
be broken near the berth and an approach route towards
the berth should be made. Prior to departure ice should be
broken around a ship and a departure route should be made.
3.3.4 Tugs and tug assistance
The way ships are handled by tugs in ice conditions depends
largely on the type of tug. Tugs need to be adapted to work
in ice conditions. Those with light draft and propellers fitted
in nozzles have very limited capabilities, because when they
are moving astern the nozzles immediatelyfill with ice. Even
with tug engines on ahead ice can fill the nozzles. When
this happens the tug should immediately be stopped and the
nozzles cleared by repeatedly reversing propeller thrust. That
is why this type of tug, and other tugs having problems in
ice, should not tow on a line. The assisted vessel might not
react fast enough and/or not be able to stop immediately to
avoid danger of collision or worse.
For these tugs in particular, but also in general, towing on a
line in ice conditions is not without risk, as explained later.
Towing on a line is only acceptable when a ship is moving
at a very controlled low speed on a straight course or when
taking easy bends in a channel or river and during berthing
or unberthing operations. Assistance in ice conditions
during arrival and departure is then carried out mainly by
pushing and includes breaking the ice and sweeping away the
ice from between ship and berth. Without the help of tugs
it is almost impossible, in most cases, to remove ice from
between a ship and berth.
Note 2:
In thick ice in the Port of St Petersburg, the ASD-tugs, when
operating as bow tug, use ship lines which are taken on the aft
low astern power of these tugs is partly compensated for by
the use of extra towlines, installation of high engine power,
specific propeller/rudder configurations and/or specific
assisting methods. Also in many ports of the USA and
Canada there is a tendency towards the use of more flexible
tug types – tractor tugs as well as reverse-tractor or ASD-
tugs. As in many ports elsewhere, conventional tugs will
nevertheless continue to be built in the future.
In Australian, New Zealand and South African ports tugs
mainly operate at a ship’s side. The majority of the tug fleet
already consists of those with omnidirectional propulsion
and new buildings will mainly comprise this type.
As can be seen in Chapter 2, after the Voith tugs, ASD-
and reverse tractor tugs, many new tug types have been
developed with new and more extensive capabilities. These
are sometimes in response to the needs of a specific port
or just as a new idea. The increasing variation in tug types
offers an opportunity to select the most suitable tug for a
port, taking into account port particulars, existing assisting
methods and future developments in port and shipping.
3.3 Tug assistance in ice
3.3.1 Introduction
During winter months, shipping traffic to and from several
ports in the world is impeded by ice. Ports are kept open as
long as possible by icebreakers so that ships can be berthed.
When ice is not too thick, ships themselves may be able to
break it. In other cases an icebreaker, if available, or tugs
otherwise, are required to do so. But all an icebreaker and
tugs can do before a ship’s arrival is to break the ice. They
cannot completely remove ice from a berth, so certain
procedures have to be followed for berthing and unberthing.
Depending on a ship’s size, strength and engine power, berth
location and ice conditions, ships may berth or unberth
with or without tug assistance. How tugs can be used during
berthing and unberthing in ice is considered in this section.
For tugs that are designed for operations in ice condition,
please see Chapter 2.
Mooring in icy conditions is usually time consuming. Each
port has its own method of assistance in ice conditions. The
methods discussed here are based on experience in one of
the largest Baltic ports, where shipping is impeded by ice for
several months each year. Methods in other ice ports may
not differ greatly.
3.3.2 Types of ship for manoeuvring in ice
As mentioned before, ships may berth or unberth in ice with
or without tug assistance. It depends on the size of ships,
strength and engine power, berth location and ice conditions.
Regardless of a ship’s size, strength and engine power, not
all vessels can pass independently through ice owing to their
construction and/or loading condition. A vessel operating
in ice should be so ballasted and trimmed that the propeller
and rudder are completely submerged. If this cannot be done
and the propeller blades are exposed above the water or are
just under the surface, the risk of damage due to propellers
striking the ice is greatly increased. Such vessels and other
Assisting Methods 89
In this paragraph the tugs referred to are ASD-tugs operating
over the stern, because the percentage of conventional tugs in
the world total tug fleet is becoming ever smaller.
3.3.5 Ice blockage and nozzle clearing
Performance of tugs with azimuth thrusters in nozzles
operating in ice can be improved by proper designs such as
adequate clearance between the hull and the thrusters and
by short reaction times for pitch changes or for turning the
thrusters adequately to remove ice blockages as quickly as
possible. Nevertheless, the thrusters will inevitably become
blocked now and then, although much depends on the ice
condition.
The following is based on the experience of tug masters
skilled at operating in ice conditions.
 A key factor is that the tug master should basically operate
in such a way that the risk of ice blockage is minimised.
The tug master be able to recognize ice blockage problems
quickly and react rapidly when needed.
A signal for ice blockage is that one or both propellers/
thrusters start to vibrate. It may also be seen on the meters
which propeller is affected, or which one is most serious.
Conventional tugs with fixed pitch propellers in nozzles,
should reverse the propeller revolutions to clear the ice out of
the nozzles.
In case of controllable pitch propellers, if possible, pitch
should be reversed to get the ice out.
With ASD-tugs and comparable tugs possibilities are greater.
If the tug still has speed through the water, one thruster can
be declutched and thruster turned to wash the ice out. When
cleared, the thruster can be turned back, clutched-in and
rpm be increased. If the other thruster is blocked as well, it
can then be declutched and turned till the ice is washed out.
Then it can be turned back and be clutched-in and rpm be
increased. It may even happen that this has to be done three
times in five minutes.
Other methods often used are:
A. Thrusters with fixed pitch propellers (see figure 3.20).
•	 Tug master feels a vibration of the propeller. Propeller
will be stopped and declutched.
•	 Both thrusters will be set crosswise in such a way that
the working propeller can blow out the ice out of the
blocked thruster. Care should be taken that the working
propeller does not get blocked by ice.
•	 In addition, the blocked thruster can be turned 180°
several times, until the ice is out of the thruster.
B. ASD-tugs with variable pitch propellers.
1. As soon as the tug master feels vibration of the propeller,
the clearing procedure starts.
2. The loss of power will be first compensated by increasing
the power of the other propeller.
3. Then the propeller of the blocked thruster will be set for
30 per cent astern. The tug’s speed will drop unless the
power of the other propeller is sufficiently increased,
especially important during operations.
hook (no aft winch available) and then proceed with the bow
into the ice to protect propellers and nozzles.
While preparing a berth location, tugs often work very close
to the dockside. Some objects may stick out or overhang, so
tug sides should be clear of overhanging fenders, etc. Tugs
should, of course, always be very careful when working
between a ship and the dockside.
With respect to tug towing wires or ropes, they should
retain their strength in low temperatures but should never
be allowed into icy water because it will then be very hard to
handle them.
The most reliable tugs in ice conditions are normal ice
strengthened conventional tugs with open propellers.
Twin screw tugs are preferable because of their better
manoeuvring properties.
Propellers and rudders may have ice protectionand nozzles
may be fitted with protection bars or ice knives fore and aft
of the nozzle. Although nozzle construction itself may be
adapted to ice conditions, in particular shallow draft tugs
with nozzles are very limited in their performance when
operating in ice, due to the fact that nozzles are often blocked
with ice. This does not mean however that this type of tug is
worthless in those conditions. They can create an effective
surface stream for moving ice in situations as explained later.
Deep draft tugs are more reliable during towing operations.
The best type of tug for operating in ice conditions are:
•	 Conventional twin screw tugs, preferably with open
propellers and
•	 ASD- tugs and comparable tugs.
Voith tugs are sometimes used as well.
With regard to open propellers, full scale trials were carried
out in 1984 in Finland with two ice-going tugs, one fitted
with an open propeller and the other with a steerable nozzle,
to investigate their performance in ice conditions. During
a twenty hour test the nozzle of the latter tug was blocked
twelve times and the tug had to be stopped each time.
 Figure 3.19:Tug with ice scraper on the bow to clear ice from dock
and lock walls. See also figure 3.39. Photo: René Beaumont, Canada
90 Tug Use in Port
The risks mentioned above are further illustrated in the
pictures in the following paragraphs.
3.3.6 Berthing in ice
A berth should be approached at a small angle. As soon as
the forward spring is secured the engine should be set to
Dead Slow Ahead. Propeller revolutions or propeller pitch
should be increased gradually, just avoiding breaking the
spring. It is best to double the spring and the rudder should
be used to swing the stern of a vessel in and out and away
from the dockside. The water flow caused by the propeller
will force ice out from between the ship and the dockside and
wash it away astern of the ship. The engine should be kept
running until the propeller wash has swept away all loose ice.
The ship can then be berthed. In this way, provided it is weak
ice, it can be removed completely from between the ship and
berth. In the case of dense and thick ice the assistance of tugs
is required.
In some cases berth location could be such that a berth can
be approached parallel to the dock (see figure 3.21). In this
case ice may be pushed away by the bow. If there is unbroken
ice on the starboard side it will push the ship towards the
berth and prevent her swinging out. Care should be taken
to avoid any ice getting between ship and dock. It may be
necessary to move the ship forward and astern a few times to
move the ice out or to press the ice together between ship and
dock. This can only be done in the case of young and weak
ice.
Sometimes, approaching parallel to the dock may not be
possible due to the presence of large pans of ice or dense,
thick ice directly in the ship’s track. Other methods should
then be adopted such as the use of tugs. Several procedures
for the use of tugs in ice during an approach towards a berth
while berthing or unberthing are now considered.
In general, while approaching a berth in ice, the bow of the
vessel should be kept as close as possible to the berth with the
assistance of a tug pushing at the bow (see figure 3.22 A, B).
The ice between the bow and the dock will tend to push the
bow aside. After the forward spring has been secured the tug
can break the ice outside the ship and then wash the ice away
from between the ship and the dock (see figure 3.22 C, D).
The ship itself can swing its stern in and out by rudder action
and use of the engine, as explained.
Sweeping ice away from round the bow area can also be done
effectively by a tug just ahead of the ship (see figure 3.24).
With its stern directed towards the ship’s bow, the tug can
sweep ice away by putting its engines ahead. In this case the
4. Mostly it works, otherwise same system should be used
as with fixed pitch propeller.
It is also possible that ice blocks become trapped between two
blades of a controllable pitch propeller. The tug master is then
not able to adjust propeller pitch affecting operations. This can
lead to damage. In this case also, the same system should be
used as with fixed pitch propellers.
It will be clear that ice blockage can be risky during tug
operations, in particular when a tug is fastened by its towline
to a ship having way on, depending on the location of the tug
and the way the tug is operating.
Regardless of good clearing procedures, nozzles and
propellers often do become damaged when working in ice,
or sometimes nozzles get even lost. Thruster removal at ship
yards is sometimes considered, although this is not a simple
process.
Figure 3.20: Schematic overview clearing procedure.
Figure 3.21: Ship approaches the berth nearly parallel to the dock. Ice is pushed away by the bow. The ship is pressed towards the berth
by unbroken ice on the starboard side.
Assisting Methods 91
Another method by which good results are obtained is
moving the ship astern towards the berth to moor with its
starboard side alongside (see figure 3.27). After approaching
the berth at a small angle and securing the back spring,
the engine should be set for astern. The propeller stream is
normally very strong and will move the ice between the ship
ship should not pass any head lines, which would prevent the
tug working in this way.
Since ice at the bow is usually squeezed between bow and
dock, getting it out is very difficult. Good results can be
achieved when there are 20-30m of free berth ahead of a
ship’s planned position. The ship should approach its berth
ahead of the planned position (position 1 of figure 3.25).
Breaking ice at the outer side of the ship and sweeping ice
away from between the ship and dock are then carried out.
The ship can then be brought alongside and moved astern
while the tug is constantly pushing the bow towards the
dock.
A bow thruster can also be very effective in sweeping ice
away (see figure 3.26). A ship should approach the berth at an
angle. After the forward springs and head lines are ashore,
the stern is taken as far as possible out by rudder and ship’s
engine. The bow thruster should then be set to take the bow
off in order to create a water flow between ship and dock. The
bow should be held to the dockside by the ship’s ropes and
by the pushing tug. The water flow of the bow thruster will
sweep ice away from between the ship and dock.
Figure 3.22: Tug assistance
in ice during approach to the
berth and while mooring.
Figure 3.24: Tug sweeping ice away from between ship and dock.
Figure 3.23: Tug Tornado (ASD-tug type 2810; 4,250hp) sweeping ice
away between ship and berth. Ship’s spring line is ashore.
Photo: Captain Sergei Milchakov, St Petersburg
Figure 3.25: Mooring in ice when some 30m free berth is available in
front of the bow position.
Figure 3.26: Combination of tug and bow thruster while mooring.
92 Tug Use in Port
In some cases, when possible, it is better to approach the
berth astern with a stern tug towing on a line (see figure
3.29). By giving short ‘kicks ahead’ on the ship’s engine to
stop the vessel, ice will be pushed away from the dock in the
direction of ship’s movement.
With large ships, good results in removing ice from between
ship and berth are sometimes obtained with two tugs
working bow-to-bow. These two tugs, moving together
forward and astern between the ship and berth, sweep ice
away. The safety of these tugs is ensured by an additional
three tugs keeping the ship in position as shown in figure
3.30. Obviously, a large number of tugs is required in this
case. In case of a small ship one tug could be use for clearing
ice by setting one thruster on ahead and one on astern, so
both thrusters in opposite direction.
3.3.7 Unberthing in ice
Before unberthing, tugs should break ice around the ship and
in areas of about 20-40m distance fromthe bow and stern.
Some vessels can be taken off the berth by the stern with the
assistance of a stern tug towing on a line (see figure 3.32). At
the bow the ice between bow and dock will prevent the ship
from coming too close to the berth. In addition, the stern
tug will drift the ice between the ship and dock, which again
prevents the ship from coming too close to the dock when
moving astern.
Figure 3.27: Good results when approaching the berth astern
and mooring starboard side alongside.
Figure 3.28: Tug assistance when mooring in ice with ships
and powerful engines.
Figure 3.29: Ship approaching the berth astern. One aft tug secured.
Occasional bursts ahead on the engine blow away the ice.
Figure 3.30: Two tugs operating bow-to-bow clearing ice between
ship and berth while other tugs keep the ship in position.
Figure 3.31: Tug sweeping ice away between ship and berth.
A second tug, ASD-tug Akmal near the bow, is making room for the ice
coming out. Photo: Captain Sergei Milchakov, St Petersburg
Figure 3.32: Ship of medium size departing. Before departure tugs have
broken ice around her in areas some 20-40m from bow and stern.
and dock quickly in the direction of the bow. The bow should
be swung in and out by tug or bow thruster. This method is
used and suitable for larger vessels, as propeller thrust astern
is lower than on ahead and consequently the tension in the
spring line(s) will be less.
These berthing procedures whereby a ship uses engine and
spring lines is not suitable for ships with large engines and
high starting power and/or high power on Dead Slow. All
operations in ice with these ships are normally carried out by
tugs. After approaching the berth at a small angle, a spring
line and head line are made fast forward (see figure 3.28). One
stern tug on a line is used to take the stern from the berth and
a second tug is used for pushing the stern towards the berth.
This tug will also clear the ice between ship and berth. Ship’s
propeller wash is not used. Berthing will, in general, take a
long time.
Assisting Methods 93
Sometimes it may be necessary to unberth the ship bow first
(see figure 3.33). A second tug may then be needed to break
ice near the stern and to prevent the stern from coming too
close to the berth. Sometimes even the assistance of a third
tug may be required to crush ice at the outer side of the ship.
Figure 3.33: Unmooring bow first. A stern tug is required when ice near
the stern needs to be broken and when the stern may touch the berth
when the bow is pulled off. Sometimes a third tug is required to break ice
alongside the vessel.
Figure 3.34: ASD-tugs Tornado and Akmal preparing a turning circle in
ice for the ship to be turned. Photo: Captain Sergei Milchakov, St Petersburg
Figure 3.35: Channel through the ice prepared by icebreakers or strong
tugs. A ship moving astern through the ice is safest. When the stern tug
is stopped in or by ice the ship can immediately be stopped by propeller.
Figure 3.36: Ship entering the port backwards through the ice with after
tug fastened with ship’s line. Photo: Captain Sergei Milchakov, St Petersburg
Figure 3.37: Ship moving backwards with after tug fastened
with two ship’s lines – ASD-tug Sevruga (3,200 hp).
Photo: Captain Sergei Milchakov, St Petersburg
When a departing ship has to be swung around after being
unberthed this should be carried out in a prepared area or
channel in the ice. This area or channel should be prepared
by large tugs or icebreakers prior to departure. Tugs handling
the ship can assist the ship in swinging and break ice when
necessary.
94 Tug Use in Port
3.4 Assisting navy ships
Navy ships do visit commercial ports regularly. In navy ports
they know how to handle their ships and they often have
purpose-designed tugs with well-trained tug masters. This is
not the case in commercial ports. As the frequency of visits
is low, the level of knowledge and experience to handle these
ships is equally low while tugs are not specifically designed
for handling all types of navy ships.
Prior to an arrival of a navy ship, and particularly in case of
large navy ships, berth location and arrival procedures will
be discussed between navy officials, port authorities, towing
companies, and pilots. Tug masters will be instructed how to
handle the navy ships.
3.3.8 Safety of tugs in ice
Tugs are at great risk when towing on a line through a
channel in ice. As previously mentioned, when a tug has to
stop due to nozzle blockage with ice, the ship should also
be stopped immediately. The tug may also enter dense ice
and consequently lose speed very quickly. The assisted ship,
therefore, should always use engines with utmost care. Even
then the safety of the tug is still at risk. It is for these reasons
that the safest method of towing on a line is moving a ship
astern (see figure 3.35). The engine should at all times be
ready to go ahead. When necessary, the ship can be stopped
immediately.
3.3.9 Finally
Assisting ships when berthing or unberthing is an important
task in ice covered waters, a task which takes much time and
effort.
However, engine and/or rudder failures may happen on
board ships when proceeding through ice. In that case the
available tugs should also be able to assist, as is shown in
figure 3.38.
The tugs may have to carry out specific duties in ice, for
instance scraping ice from the walls of docks and locks.
Some tugs on the St Lawrence Seaway are equipped to do so;
they have on the bow ice scrapers as can be seen on the tug in
figure 3.39.
Further practical and useful information regarding
navigating and manoeuvring in ice can be found in:
Handling Ships in Ice by Captain J Buysse. The Nautical
Institute
Polar Ship Operations by Captain Duke Snider. The Nautical
Institute
Figure 3.38: Tugs operating in ice. Docking bulker Panagia in Quebec Harbour after steering failure. Photo: Jean Hémond, Canada
Figure 3.39: ASD-tug Ocean Serge Genois with ice-scraper on the bow
(7 January 2018). Photo: René Beauchamp, Canada
Assisting Methods 95
Aspects tug masters should be aware of when approaching
and handling submarines
While discussing the various aspects requiring attention, the
specific terms used will be addressed too. See figure 3.40.
a. Specific hull form. When a submarine is on the surface,
due to the almost round form and deep draught the
widest part is below water.
b. Protruding parts
 i. Sail or fin
 No. 1 in figure 3.40 is called the sail (USA) or
fin (Europe/Commonwealth), also known as a
fairwater.
 When on the water surface, the sail serves as an
observation platform. It also provides an entrance
and exit point when enough freeboard to prevent
being swamped. Under water, the sail acts as a
vertical stabilizer.
 With some submarines, the sail also supports diving
planes (or fairwater planes). See figures 3.41 and
3.47.
 ii. Hydrovanes or vanes, also called diving planes or
hydroplanes
 With the planes the vertical motion of a submarine
can be controlled. It allows the submarine
to pitch its bow and stern up or down to assist in the
process of submerging or surfacing. No. 2 in figure
3.40 shows the port fore plane. Tugs should be aware
of these vanes, particularly in reduced visibility.
 Instead of fore planes, planes can be installed at
each side of the sail or fin as mentioned above.
These planes can be a problem for tugs operating
alongside.
 Aft, just abreast of the top rudder blade (see no. 3)
are the after planes. They are underwater and can
not be seen. Tugs should therefore take utmost care
when approaching the after part of a submarine.
 Several submarines have the rudder and aft planes
combined in a crossway system as shown in figures
3.41 and 3.45.
Several of the navy ship types can be handled in the same
way as merchant navy ships. Although, information about
allowable maximum hull force is important when tugshave
to push.
However, there are two types of navy ships that require
specific attention, viz. submarines and aircraft carriers.
These two ship types will be dealt with below.
In some ports, tugs might not be needed, where aircraft
carriers can safely anchor within the harbour limits,
although tugs will then be stand by for in case they are
needed.
3.4.1 Submarines
General information
There are various submarine designs, and they differ in size.
Generally, submarines can be classified as follows:
•	 Diesel-electric attack submarine ranges from 60 to 90
meters in length with a draught of approximately 8m.
•	 Nuclear powered attack submarine (SSNs) ranges
from 90 to 120 meters in length with a draught of
approximately 10m.
•	 Nuclear powered ballistic missile submarine (SSBNs)
ranges from 100 to 180 meters in length with a draught
of maximum about 12m.
This information is very generalized and can differ by
submarine.
An important aspect of all submarines to be kept in mind
is that submarines are like icebergs. This means the largest
part, about 90%, is below the waterline. For rather small
vessels they have a very large draft. As with icebergs they
should be approached with care, as will be explained below.
Although there are twin screw submarines, most of them
are single screw. They have generally good steerage at about
two knots and more. Submarine turning circles are naturally
large.
Figure 3.40. HMS Astute. Source: UK Ministry of Defence
Figure 3.41. Australian submarine pushed along the berth.
1: Fairwater planes; 2: combined after planes - rudder system
Photo: Arie Nijgh
96 Tug Use in Port
Many submarines can tow a sonar (line-array) and have
therefore equipment near the stern rudder (a tow-box);
depending on the submarine an anchor light may also be
placed there (see figure 3.45). Other submarines may have the
anchor light on top of the rudder.
Care should be taken by tugs that the tow-box and/or anchor
light are not damaged by a towline or a tug. This can easily
happen when a towline under tension must be replaced
from port to starboard and vice versa. However, such a
tug manoeuvre is only possible with submarines that have
the planes and rudder in an X-configuration that only just
appears above the waterline. With all other submarines the
rudder is in the way.
Merchant navy ships have indicated on the hull where tugs
can push. On submarine it is the opposite way. There are
No Pushing/`No Push’ areas where sensitive equipment
is located. These will be marked on the casing above the
waterline and the information has to be passed by the pilot
during their pilot/tug master exchange (see figures 3.44 and
3.45).
Note:
An anchor must be carried to meet international maritime
regulations. Submarines rarely use them. The anchor is stowed
beneath the hull in such a way that the flukes make a flat
surface with the hull.
Tug assistance and requirements for tugs
In navy ports tugs are often designed for the work to be
carried out. In most cases these are highly manoeuvrable
tugs with good fendering. The profile of such tugs together
with the underwater fendering these tugs have, fits well with
the profile of the submarines to be assisted whether alongside
or when pushing. Tugs in commercial ports do not have
these features.
How tug assistance is carried out in the various commercial
ports depends on the local situation, environmental
conditions, and available tugs and tug types.
As tugs in commercial ports are not fitted out as tugs in well-
equipped navy ports, the way tug assistance to be carried
out should be such that submarines will not be damaged by
 iii Propulsor
 The propeller is called propulsor and is the utmost
aft end of a submarine. Contrary to normal surface
ships the propulsor is behind the rudder instead
of in front of it. This means that a kick ahead with
hard rudder has no turning effect. Tugs should also
take care and keep away from the propulsor and the
propulsor wash, which can be strong. Figure 3.42
shows the propulsor and the after planes.
 iv Tiles
 Tiles are another important aspect for tug masters
to be aware of when handling submarines. Tiles
on the hull of a submarine absorb the sound waves
of active sonar from another vessel, reducing and
distorting the return signal, thereby reducing
its effective range. Furthermore, they reduce the
sounds emitted from the submarine, particularly
its engines, and reduce the range at which it can be
detected by passive sonar (a passive sonar listens).
Source: Wikipedia.
 It will be clear that these tiles are crucial for a
submarine. As they are costly and can easily be
damaged by tugs, care should be taken that they
stay intact and not be damaged.
Deck equipment submarine
Deck equipment differs completely from merchant vessels as
can be seen in figure 3.40 and 3.41. A submarine is equipped
with bollards which are below the deck when at sea to create
a smooth deck. For fastening tugs and for mooring, the
bollards are lifted from below the deck.
On the most forward and aft end of the deck are the so-called
bull rings, a kind of panama fairleads. The sets of bollards on
the submarines casings are usually referred to by a number
and a letter, beginning with number 1̀’ forward, and an s̀’
for starboard or `p’ for port.
Note:
The SWL (Safe Working Load) will differ by submarine size
and by navy. Tugs should be informed about the SWL of the
deck fittings which is most important when current powerful
tugs handle submarines.
Figure 3.43. HMSTriumph. Anechoic tiles on the hull. Two patches of missing tiles are visible
towards the forward edge of the sail. Source: NetMarine
Figure 3.42. Rudder, after planes and
propulsor. Courtesy of Paolo Ulivi
Assisting Methods 97
Figure 3.44. Dimensions Dutch
Walrus class submarine and
indications of bollards and
‘no-push’ points (coloured red)
Courtesy of the Royal Dutch Navy
the assisting tugs. This means that towing on a line, with
tugs fastened fore and aft via the bull ring on the bollards
of the submarine, will be the best, this in combination with
the push-pull method. ASD-tugs are therefore preferred, as
they push with the bow. If pushing is needed and the bow
fendering is not suitable enough for the submarine, then
extra fendering on the bow of the tug is required.
Fastening tugs alongside should be avoided because of the
risk of damaging the submarine. This method is applied
where tugs have underwater fendering such as in navy ports.
See figure 3.47 and read there how the specific tugs are
fastened. The recommended tug types are Voith tugs, ATD-
tugs or ASD-tugs.
When the submarine has no propulsion, the same method is
applied often together with a tug forward on a long line. Tugs
with underwater fendering can also be found in the Panama
Canal and are also assisting submarines without propulsion
alongside. The method is applied in the narrow areas of the
Panama Canal and especially through the locks.
With propulsion and when going through the locks with
locomotives, tugs will only escort and only assist if the pilot
considers it to be necessary.
Figure 3.46 Tug ASD 2509 in profile with a submarine
Courtesy: Damen Shipyards
Figure 3.45:
‘No push’ area
between red
lines
Courtesy Royal
Dutch Navy
Pgua_Supplay
Destacar
Pgua_Supplay
Máquina de escrever
REPARE QUE TRATOR NAO E AQUI NAO FALOU DE CONVENCIONAL
98 Tug Use in Port
In Hong Kong tugs never attempted to go alongside, because
most submarines would tie up to a mooring buoy in the
harbour. So generally, the submarines were escorted by a tug
with a towline attached. The tug did very little unless a gentle
pull was needed to get the bow near the mooring buoy.
So, it can be seen that it depends on the port, the waterway,
the tug types and how the tugs are equipped, how
submarines will be assisted.
In short the following tug assist methods can be applied forsubmarines:
•	 One tug fastened forward when submarine is mooring
on a buoy.
•	 Towing on a line, with one tug fastened fore and one aft
via the bull ring on the bollards of the submarine, this in
combination with the push-pull method. Best suited tug
type is the ASD-tug.
•	 Fastening tugs alongside when these tugs have
underwater fendering. Recommended tug types: Voith,
ASD-tug, ATD-tug.
•	 Fastening tugs alongside and one on a long line forward
in case the submarine has no propulsion. Recommended
tug type: See above.
Berths
Although beyond the context of this subject, a few words
about submarine berths. When berthing at a commercial
quay care should be taken that the berth is suitable for a
submarine with her specific wide underwater design and
deep draft. Large fenders might be needed. In tidal ports,
also tidal range should be considered.
Mooring can also take place alongside a pontoon. A
submarine needs such a floating pontoon that the widest part
of the submarine (under the waterline) is kept away from the
shore or embankment. As said before, submarines may also
be tied up to a mooring buoy (see figure 3.48). So, it depends
on the port how submarines are moored.
Figure 3.49. Aircraft carrier Kitty Hawk in Hong Kong
with two tugs stand by. Courtesy of Michael Luk
Figure 3.48: Royal Australia submarine HAMAS Farncomb moored
on buoy in Sydney Harbour. Source: The Mariner 4291_Shutterstock
3.4.2 AIRCRAFT CARRIERS
Introduction
There are about 45 aircraft carriers. Dimensions vary
between approximately 180m and 335m in length and can
be 76,8m wide (flight deck width). Steering and propulsion
may consist of up to 4 propellers. Several aircraft carriers are
nuclear powered.
It is of importance that all involved in the handling of
the aircraft carrier are informed carefully about the tug
locations, procedures to be followed and manoeuvres to be
carried out. So it is vital that information about the various
tasks is passed to pilots and tug masters well in advance. The
pilot should also hold a pilot/tug master exchange with the
tug masters when he has boarded the submarine in order to
confirm the intentions.
How aircraft carriers are handled by tugs in commercial
ports depends, as with submarines, again on the local
situation, fairway width and alignment, environmental
conditions and available tugs and tug types.
Figure 3.47. Ballistic missile submarine USS Alaska
Please note: The submarine is heading towards you. Two tugs with
underwater fendering are alongside for `Active Escort’. As it is ATD-tugs,
they are moving backwards with the propulsion units close to the stern of
the submarine to be able to give effective steering assistance, if needed.
See also clearance between fairwater planes and tugs. Photographer: LPhot
Stevie Burke/Source: US Defence Government
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Assisting Methods 99
Figure 3.51. Tug under de flare of a UK aircraft carrier
HMS Queen Elizabeth with indications of clearance.
Courtesy of: A P Bannister MBE | Chief Admiralty Pilot QECP
wind speed during 30secs wind gust is then almost 19m/sec
(gust factor 1.21; see Port Designer’s Handbook). This results
in a required total tug power of approximately 190 tons,
which includes a safety factor of 20%. Four pushing tugs,
or four tugs towing on a rather long line, of about 50 tons
bollard pull would then be needed to keep the ship under
control. Ship bollards and fairleads should be strong enough
to cope with these forces.
Note:
When tugs have to pull to keep the ship up into the wind,
a large loss in pulling effectiveness can occur when the tug
propeller wash is hitting the ship’s hull near right angles. The
larger the distance between ship and tug the smaller the loss.
This factor should be taken into account for the total required
bollard if such as situation may happen.
Summarizing: Tug assistance for aircraft carriers depends on
port lay-out, available tugs, local tug procedures and wind
conditions. The following is recommended:
•	 Usually four suitable tugs, which can be employed as
follows:
 – Two tugs forward and two tugs aft on a line via
fairleads on or near the centre line of the aircraft
carrier.
 – One tug forward and one tug aft via fairleads on or
near the centre line and two tugs alongside
 – Four tugs alongside.
•	 When the aircraft carrier must anchor in the port, two
passive escorting tugs.
•	 Tugs that have to assist alongside should be able to lower
their masts. Extra fenders between tug and aircraft
carrier might be needed.
•	 For the required bollard pull of tugs the wind condition
should be taken into account.
•	 Aircraft carriers require much manoeuvring room.
•	 SWL of bollards and fairleads should be known as well
as maximum allowable hull pressure or pushing points.
Tug requirements and tug assistance
In general aircraft carriers have sufficient bollards and
fairleads on the mooring deck and sunken bollards in the
sites to secure towing lines. It is again important for towing
companies and tug masters to know the SWL of the bollards
as well as the maximum allowable hull pressure. If the
aircraft carrier would anchor within the port limits two
suitable and powerful escorting tugs are recommended.
If the aircraft carrier has to berth, four tugs are generally
recommended for commercial ports. Depending on tug,
the way tug assistance is carried out, and aircraft carrier
design, additional fenders between tug and ship might be
needed. Figure 3.50 gives an indication of the clearances of a
tug under the overhang, although this differs as said by tug
and aircraft carrier design. There is one basic requirement
for tugs handling aircraft carriers and that is that due to the
large overhanging parts of aircraft carriers, tugs should be
able to lower their mast, especially in ports where tugs are
operating alongside, although it depends again on aircraft
carrier design.
The recommended tug types are Voith tugs and tugs with
azimuth propulsion and all with proper fendering.
Aircraft vessels are huge vessels and require much
manoeuvring room. An indication:
For the Nimitz class aircraft carriers, being the largest in
the world, a minimum entrance channel width outside the
breakwater should be about 240m and inside the breakwaters
about 180m; the optimal turning circle diameter is 670 m,
which is two times the length. (See References for Ìnterim
Technical Guidance – Facilities Homeporting etc.’)
Aircraft carriers have a large windage. The Nimitz class
aircraft carriers will be considered for total required tug
power. A windage area of approximately 6000-6700m2 is
estimated. A windage area of 6500m2 will be taken into
account. How much tug power is then needed to keep the
ship under control?
Suppose the middle wind speed of 7 Beaufort which is 15.5m/
sec, being a 10-minute average wind speed. The aircraft
carrier will most probably react on 30secs gusts. Average
Figure 3.50. Aircraft carrier George H. W. Bush with tugs alongside
with masts down. Source: Shutterstock
Main deck to
waterline 1.7m
Tug accomodation to ships
huil 9.7m
Airdraft main deck at
towing staple 7.9m
100 Tug Use in Port
choice of operating positions for the assisting tugs. When a
ship is dead in the water and forward thrust is applied with
port or starboard rudder, the pivot point lies far forward. As
soon as a ship gathers speed the pivot point moves aft. Once a
ship is in a steady turn with rudder hard over the pivot point
settles in a position approximately one third of the ship’s
length from the bow (see figure 4.1 A).
For a good understanding, figure 4.1 requires a little
explanation. In this figure three ships are shown with
different forces working on the ships. A force applied to
a ship, for instance a tug force or a rudder force, gives a
transverse force and a turning moment, resulting in a lateral
Figure 4.1: Locationof the pivot point for a ship at speed
Situation A: Ship turning with starboard rudder. The pivot point
lies between bow and amidships
Situation B: A tug is pushing forward. Although the pivot point lies
further aft, the effect forward is low because of the opposing
hydrodynamic forces also centred forward. When starboard rudder
is also applied the pivot point moves further forward
Situation C: A tug is pushing aft. The lateral resistance forward
contributes to the swing. The pivot point lies far forward, particularly
when starboard rudder is also applied.
4.1 Introduction
Now that various assisting methods and types of tug have
been introduced to the reader the more practical subject –
effective ship handling with tugs – is addressed.
When a ship is stopped in the water, meaning she has no
speed through the water, the effect of, let us say, a 30 tons
BP tug is the same irrespective of type, assuming that the
tug operates in the most effective way. Differences in tug
performance mainly become apparent when a ship has speed
through the water. The emphasis in this chapter, therefore, is
on tug performance while assisting ships under way.
When considering effective ship handling with tugs there
are, apart from the essential issue of bollard pull, two very
important aspects to be considered:
•	 Correct tug positioning.
•	 The right type of tug.
Different tug operating positions are considered in relation
to their effect on a ship. The performance of different basic
tug types are discussed, taking into account both the various
assisting methods and the different tug positions relative
to the ship. With respect to type of tug, specific aspects of
various tug types are necessarily discussed in a fairly general
way, since there are so many variations in design within each
type. Reviewing them all individually goes far beyond the
scope of this book. However, knowing the basic principles
may also result in a better understanding of the variations in
design of these tug types. The same applies to the Related tug
types and the FAST tugs, the tugs with one thruster forward
and one aft. The related tug types have a certain similarity
with the basic tug types. Both tug types have been addressed
in Chapter 2, along with their specific capabilities.
4.2 Basic principles and definitions
For a good understanding of tug performance and ship
handling with tugs some basic principles and definitions are
first considered. These include the pivot point, towing point,
pushing point and lateral centre of pressure, direct and
indirect towing and tug stability.
4.2.1 Pivot point
The pivot point is an imaginary floating point, situated
somewhere in the vertical plane through stem and stern,
around which a vessel turns when forced into a directional
change. The form of the submerged body, rudder size and
type, trim, underkeel clearance and direction of movement
all affect the position of the pivot point of a vessel. The exact
location of the pivot point is therefore not stationary but
variable.
For effective tug assistance the location of the pivot point
of the vessel to be assisted is very important. It affects the
Chapter 4
TUG CAPABILITIES AND LIMITATIONS
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Máquina de escrever
nao fala da localização do propulsor ... wtf
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
Pgua_Supplay
Lápis
Pgua_Supplay
Seta
Tug Capabilities and Limitations 101
forces from an external origin, such as tugs, are applied.
When, in order to assist a ship under speed and in a turn, a
tug starts pushing at the bow in the direction of the turn, the
pivot point moves aft. This is because the ship tends to turn
around a point which lies further aft than when only rudder
force is applied. Although the lever arm of tug force would
be rather long the effect is not very pronounced, so there is
another aspect to be considered. As explained earlier, a tug
pushing forward tries to move the bow to starboard, say.
This creates an opposing hydrodynamic force, also centred
forward (see figure 4.1B). The hydrodynamic moment
counteracts the turning moment exercised by the tug. The
effect of the pushing tug is very small. This is also one of the
reasons why the effect of a bow thruster is small on a ship
making slow to moderate speed ahead. In addition, the tug’s
underwater resistance counteracts the turn.
It should however be noticed that the effect of the forward
tug differs with ship’s hull form, draft and trim. For
conventional ship forms, on even keel in deep or shallow
water, the opposing hydrodynamic force is indeed centred
forward, as mentioned in ‘Performance and effectiveness of
omni-directional stern drive tugs’ (see References). When,
for instance, taking a tanker in ballast and trimmed by the
stern, the opposing hydrodynamic force is centred much
more aft, resulting in a much larger effect of the pushing tug
forward.
When a tug starts pushing a ship underway at a position aft,
the pivot point shifts forward. The pushing force has a long
lever arm and the lateral resistance forward then contributes
to the swing (see figure 4.1C). It is evident that the further
forward and/or aft of the pivot point that tug forces are
exerted on a ship, the longer the lever arm and hence the
more effective the assistance will be.
A ship dead in the water (see figure 4.2A) with one tug
pushing (or pulling) forward and one with the same bollard
pull, pushing (or pulling) aft, pivots around its midships
when on even keel. For the same size of vessel and same
conditions, rate of turn depends on the tug’s bollard pull and
on the lever arms between tugs. The longer the lever arm the
larger the turning effect of the tugs. When a tug pushes at the
bow or stern of a ship that is stopped in the water, the ship
velocity and a rate of turn. The arrow V is the direction
ship’s centre of gravity (g) may move as a result of the lateral
velocity caused by the rudder force or tug force, and the
forward velocity of the ship. The lateral movement of the
ship is opposed by the hydrodynamic forces centred forward
on the ship having headway, which also creates a turning
moment. This turning moment opposes (situation B) or
assists (situation C) the turning moments created by the tugs.
The location of the pivot point (PP) results from the motion
of the ship caused by the various forces mentioned working
on the ship.
Donkey effect
In addition to this explanation about the hydrodynamic
forces centred forward, if in situation B of figure 4.1 the tug
would push a bit more aft, it may push behind the forward
lying centre of hydrodynamic forces. The result would be that
the ship will turn to port instead of turning to starboard.
This is called the Donkey Effect. If this happens, the tug has
to push at a more forward lying position. The location of
the centre of hydrodynamic forces depends on ship form,
draught and trim.
Beamy full bodied ships have a smaller turning diameter and
a further forward lying pivot point than slender ships. When
a ship is down by the head turning diameter is also less and
the pivot point lies further forward than when on an even
keel.
Turning diameter is independent of ship’s speed as long as
engine propeller revolutions or propeller pitch match a ship’s
speed but is dependent on rudder angle applied. When in
shallow water, such as in most port areas, turning diameter
increases considerably, due to the larger hydrodynamic
forces opposing the turn.
A ship moving astern has its pivot point somewhere between
stern and midships when turning, eg, by use of a bow
thruster. The exact position of the pivot point, therefore,
is different for each individual ship, ship condition and
circumstances.
The pivot point also changes position when, in addition to
rudder force, otherforces such as bow thruster or push/pull
Figure 4.2: Location of the
pivot point in a ship with zero
speed
Situation A: Tugs of equal
power pushing/pulling
forward and aft. The pivot
point lies amidships. The tugs
towing on a line have a longer
lever and so a larger effect.
Situation B: Forward tug
pushing; the pivot point lies
far aft. When an after tug is
pushing, the pivot point lies
far forward.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
102 Tug Use in Port
•	 carrousel system and DOT system (see Chapter 2);
•	 azimuth friction free towing point, auto position escort
winch, certain staple designs.
The last three systems mentioned shift the towing point to
the lower side of a tug heeling due to the towline force and
so decrease the heeling lever, as will be shown in the stability
paragraph below. These systems have a positive effect on a
tug’s performance and on a tug’s stability. In particular the
effect of a carrousel system is largely positive on safety of
operations regarding stability and performance. Some tugs
have more than one towing point, eg, some Voith tugs have
an additional towing point at the tug’s aft end.
The gob rope system allows the towing point to be shifted in
a longitudinal direction, increasing tug’s performance. If the
towing point is shifted to the after end of the tug, it has also a
positive effect on safety of the tug.
Deck equipment will be further addressed in Chapter 7.
For tugs pushing at a ship’s side the contact point or pushing
point is of importance.
Before discussing the capabilities and limitations of different
tug types the towing and pushing point in relation to the
location of propulsion and centre of pressure are considered.
The lateral centre of pressure
The lateral centre of pressure is a non-stationary point. Its
location depends on the underwater hull form including
appendages such as rudder, propellers and skeg, on the trim
of the tug and the angle of attack of the incoming water flow.
The influence of rudder and propellers on the location of the
centre of pressure seems to be rather high.
Tractor tugs and especially VS tugs have a large skeg aft,
resulting in an aft lying location of the centre of pressure.
Incoming water flow exerts a force on the tug. The point
of application of this force is the lateral centre of pressure.
The direction and magnitude of the force depends on the
turns around a point located approximately a ship’s width
from the stern or bow respectively (see figure 4.2B).
Other forces of external origin that affect the position of
the pivot point are wind and current. In port areas, wind
and current may vary in speed and direction depending
on location. Relative wind and current directions may also
vary during a transit to or from a berth due to changes in a
ship’s heading. For instance, when entering a harbour basin
from a river the current gradually decreases but also changes
in relative direction. As a result, the influence of wind and
current on a ship fluctuate. Depending on the angle of attack
and point of application, wind and current may decrease
or increase the rate of turn, moving the pivot point further
forward or aft, or may have only a sideways effect.
4.2.2 Towing point, pushing point and lateral
centre of pressure. Direct towing and indirect
towing. Skegs
The relative positions of the centres of three different
resultant forces are mainly responsible for a tug’s
performance. These are centre of thrust, the towing or
pushing point and the lateral centre of pressure of the
incoming water flow. In particular, the mutual relationships
between towing or pushing point, centre of thrust and centre
of pressure affect not only the effectiveness but also the safety
of a tug.
The towing point
For tugs towing on a line, the towing hook or towing winch
is not necessarily the towing point. The towing point is that
point from where the line goes in a straight line from the
tug towards the ship. In most cases it is the staple or fairlead.
The location of the towing point is extremely important with
respect to stability, safety and performance of a tug.
The towing points shown in figures 4.3 and 4.4 are fixed
points.Towing points can also be movable, as is the case with
the:
•	 gob rope system;
•	 radial towing hook;
Figure 4.3: Staple on Voith tractor tug Velox – see red arrow (LOA 37.0m,
beam 14.0m, BP 65 tons, steering force at 10 knots 131 tons). Source:
VoithTurbo Schneider Propulsion
Figure 4.4: Double fairleads on ASD-tug Venus (LOA 24.47m, beam
11.33m, BP ahead 67.4 tons, astern 65.6 tons). Photo: Piet Sinke
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Tug Capabilities and Limitations 103
the towline in combination with force L creates a counter-
clockwise turning moment.
Consider two locations of propulsion – position Ps for stern
driven tugs, a conventional tug for example, and position Pt
for tractor tugs. The smaller the distance between T and C
the smaller is the turning moment. Thus less steering power,
by either rudder deflection or omnidirectional propellers, is
needed to counteract that turning moment. Consequently,
more engine power is available for towing. If propulsion
is located aft at Ps, starboard rudder or thrust is needed,
giving a little more drag but also an additional force in the
towline. If propulsion is located forward (Pt) then sideways
steering power is needed, but in the opposite direction. This
consequently decreases the towline force.
With increasing speed, force F increases and consequently
lift force L. The higher the speed the more steering effort
is needed. Therefore, the higher the speed the larger the
difference in towline forces between a conventional and
tractor tug.
Towline forces also create list. Considering the direction of
steering forces it is evident that with the propulsion located
in position Ps the sideways steering forces increase the tug’s
list, while with propulsion located in Pt steering forces
counteract the list caused by the towline force. When an
ASD-tug is operating like a conventional tug its high steering
forces result in larger heeling forces. This is also due to the
fact that the centre of pressure of this tug type lies generally
further forward than with conventional tugs, resulting in
a larger turning moment to overcome. The larger heeling
moment is more or less compensated for by the large beam of
this tug type.
Although the towline position discussed here is the most
effective for both conventional and tractor tugs when
operating as a forward tug on a line, the towing point on
tractor tugs is located further aft for safety reasons and
for better performance as stern tug. This is explained
later. The consequence of the further aft towing point on
a tractor tug is an even less effective tug as forward tug.
More sideways steering power is needed to counteract the
larger anticlockwise turning moment, resulting in a further
decrease in towline force. By giving more engine power in
order to achieve the same towline force as a conventional tug
would exert, the tug comes more in line with the towline,
resulting in higher turning moment and drag force to be
overcome. At higher speeds drag force may become so large
that a tug is unable to react sufficiently to the force and
swings around.
The consequence is that when working forward a
conventional tug is more effective when towing on a line
than a tractor tug in case the ship has speed on. The better
the omnidirectional thrust performance of a tractor tug
the more effective it will be. Reducing the underwater
resistance of a tractor tug would increaseconditions and ships calling at
the port.
•	 The various types of harbour tug are discussed in
a general way, addressing the diversity of design,
propulsion, steering and manoeuvring capabilities.
•	 After reviewing assisting methods in use worldwide,
tug types are considered in more detail, including the
performance of different types of tug resulting from the
location of propulsion devices, towing point and lateral
centre of pressure. Tug capabilities, limitations and
effectiveness with respect to different assisting methods
and operating positions relative to a ship are discussed.
•	 The number of tugs required to handle a vessel safely
is frequently a topic for discussion between pilots and
shipmasters. This important subject is discussed taking
into account the effects of wind, current, shallow water
and confined waters. The number of tugs and total
bollard pull used in several ports around the world is
mentioned.
•	 Much attention is given to dangerous operational
situations for tugs, such as interaction and girting, and
to environmental conditions such as fog.
•	 Towing equipment is dealt with, particularly in relation
to safe and efficient shiphandling.
•	 Escorting and escort tugs, being a subject of specific
interest nowadays, is dealt with separately.
•	 Proper training for a tug captain and crew is essential in
order that they handle the tug safely and efficiently. The
same applies to the pilot and/or master for shiphandling
with tugs. Training is therefore an important subject in
the book, including simulator training and research.
•	 Risk assessment and safety management systems are
important items with respect to safety and are dealt with
in a separate chapter.
All subjects are, as far as possible, related to situations
encountered in practice.
TUG USE IN PORT: THE OVERVIEW
2 Tug Use in Port
Figure 0.2: Tanker Hayon Spirit (95,000dwt; LOA 244m) entering the lock in IJmuiden with tug assistance. Aft ASD-tug Titan,
LOA 30m, beam 9.50m, BP 50 tons. The whole waterflow can clearly be seen. Photo: Henk Koning, The Netherlands
Tug Design Factors 3
This reduction in the number of assisting tugs per ship places
the individual tug in a more crucial role. It requires a high
level of operational safety and reliability from the tug and a
high level of suitability for the job to be carried out.
In order to keep a port’s tug services up to date and to ensure
safe, smooth shiphandling, it is essential to keep abreast of
developments in harbour towage and shipping, to have the
most suitable tugs available and to have well trained crews
for the specific situation in the port. This is all the more
important when the investment required for new tugs is so
very high. It may be necessary to reconsider the traditional
approach.
It requires extensive research and knowledge of tugs before
an answer to the question ‘which type of tug or which
working method is the best for a certain port?’ can be given.
It requires a profound knowledge of the different tug types,
their capabilities and limitations, and a good insight into the
local situation.
The capabilities and limitations of different tug types are
dealt with in the following paragraphs.
The operational requirements that harbour and also terminal
tugs must conform to, with respect to ship assistance, are
mainly determined by the following factors:
•	 The kind of port or harbour and approaches, foreseeable
future developments and the existing geographical
environmental conditions.
1.1 Differences in tug design and
assisting methods
Methods of assistance provided by tugs in ports and port
approaches around the world differ due to local conditions
and specific situations and have often grown from long
standing customs and traditions. These differences in
assistance methods and practices are often reflected in the
requirements for the tugs and hence in the development of a
range of tug types.
Over the past few years, rapid development has been
observed among harbour tugs. New types have been
designed with high manoeuvrability and considerably
increased engine power. Modern steering devices, new
towing appliances and new materials for towlines, to name
just a few, have been fitted. These developments affect
methods of tug assistance and the number of tugs used.
Following the Exxon Valdez disaster, the requirement to
escort tankers in certain port approaches has resulted in
the development of specially built escort tugs and tugs with
escort capabilities.
As a result of the improved manoeuvring capabilities of
many modern ships on the one hand, and the improved
towing performance of modern tugs on the other, the
number of tugs required for assistance in port areas is
decreasing. Due to the economic factors faced by shipping
companies, captains and pilots are often under pressure to
use the minimum number of tugs.
Figure 1.1: Atlantic Bridge entering the lock at IJmuiden with azimuth tractor tug Arion at the bow. Tug dimensions: LOA 28.75m,
beam 9.1m, BP 45 tons. Tugs should be able to assist ships through locks. Photo: Port Towage Amsterdam
Chapter 1
TUG DESIGN FACTORS
4 Tug Use in Port
b. Ports with mainly terminals
The location of ports with terminals, such as container
terminals, can be such that there is plenty of room available
for manoeuvring and manoeuvres can then be more
standardised. Such terminals are very well suited for the so-
called ‘push- pull’ method and tugs are specifically designed
for this type of operation.
c. Ports with mainly piers and jetties
Jetties can be divided into those in the open sea and those
in protected waters. A major difference between a jetty and
a normal harbour or terminal is the method of mooring
and unmooring. With jetties, mooring is mostly done on
dolphins or on a finger- or T-pier, allowing tugs to operate
on both sides of the vessel assisted. In harbour basins and at
terminals, however, mooring is done alongside a quay where
assistance is, in most cases, restricted to one side.
d. Mooring facilities at remote locations
For mooring locations offshore, such as jetties and LNG
terminals, ships are often made fast under windy conditions
and in waves. This demands special requirements for tugs,
such as good stability, sturdy fendering, render-recovery
winches and high engine power.
Tugs handling SPMs and particular F(P)SOs and FNLGs
have to meet specific requirements with respect to engine
power, manoeuvrability and towing winches, depending on
the situation, conditions and size of ships.
Ports under development
In many ports, developments take place – such as new
berths or harbour basins – and new ports are still being
•	 The type of ships calling at the port.
•	 The services required in and around the port and, if
relevant, at offshore locations, such as jetties, LNG
terminals, SPMs, F(P)SOs, FLNGs, or oil rigs.
1.2 Factors influencing tug type
and tug assistance
1.2.1 Categories of port and their approaches
Ports can, in general, be divided into four categories:
a. Conventional ports
Conventional ports make up the majority of ports around
the world, often with a long history as such. Ships are
berthed in harbour basins or docks, along river berths and
often have to pass locks and/or bridges. This creates specific
requirements for tugs and tug assistance. The development
of these ports has taken place alongside that of shipping –
including the tugs. Ports such as Rotterdam, Le Havre and
Hong Kong have a good, short connection with the open sea.
Others – like Antwerp, Calcutta and New Orleans – have a
long and sometimes complicated connection with the open
sea. In all these ports, tugs should not only be suitable for
assistance in the harbour areas, but for assistance outside
the harbour as well, i.e. on the river or at sea. Development
of conventional ports does not always keep abreast of the
increase in dimensions of ships that call at the ports. This
can resultits effectiveness as
a forward tug. However, this would have consequences for
its effectiveness as stern tug when operating in the indirect
mode whereby use is made of the hydrodynamic forces
on the tug’s hull. Therefore a compromise has often to be
underwater lateral plane and shape, the angle of attack,
the under keel clearance and on the speed squared. Speed,
therefore, is a dominant factor.
The exact location of the lateral centre of pressure and the
magnitude and direction of the resultant force created by the
incoming water flow for different angles of attack and speeds
can best be determined in a towing tank. The locations of the
centre of pressure mentioned later are merely an indication
and are based on observations and information, eg from
Voith.
When water flow towards a tug comes from abeam, caused
either by crosswise movement of a tug through the water or
by a current at right angles, the centre of pressure generally
lies behind midships in a position about 0.3 to 0.4 x LWL
from aft. For conventional tugs it is probably more often in
the vicinity of 0.3 x LWL from aft and for tractor tugs closer
to 0.4 x LWL from aft. Reverse-tractor tugs and ASD-tugs
may have a more forward lying centre of pressure, depending
on the hull and skeg design.
When a tug turns with its bow into the direction of water
flow, the centre of pressure moves forward. The smaller the
angle between incoming water flow and tug’s heading the
more forward the centre of pressure lies. For conventional
and tractor tugs the centre of pressure does not generally
move forward of amidships (0.5 x LWL). Reverse-tractor
tugs and ASD-tugs may experience a position of centre of
pressure forward of midships with a forward incoming water
flow. When a tug is turning with the stern into the water flow
the centre of pressure moves aft and with an acute angle of
incoming water flow will lie far aft.
Figure 4.5 shows a tug moving ahead, towing on a line,
assisting a ship under speed. The resultant force created
by incoming water flow is force F, assumed to be centred
approximately near amidships, location C. Force F can be
resolved into lift force L and drag force D, comparable with
the lift and drag forces on rudders or aeroplane wings. Lift
force L gives an additional force on the towline and drag
force D has to be overcome by the tug’s thrust. Towing point
T lies a little behind the centre of pressure C. The force in
Figure 4.5: Forces created on assisting tug moving ahead.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
104 Tug Use in Port
moving ahead or astern using the tug’s engine. By shifting the
towing point to a position at the stern of the tug, the tug can
be pulled astern by a vessel without the danger of capsizing.
The tug can then use its engine to control the ship’s speed.
Conventional twin screw tugs often use the propellers instead
of a gob rope to keep the tug in the position as indicated in
figure 4.7.
As can be seen at figure 4.7 the use of the ship’s engine on
ahead can become very dangerous for the tug. The ship’s
propeller wash will hit the underwater hull of the tug and
so given it an extra heeling force, in addition to the heeling
force created by the towline force.
Relationship of movable towing points and centre of pressure
is of even greater importance.
In figure 4.7 is shown how a gob rope works in relation with
the location of the towing point. If the towing point would be
shifted far aft, as can be done with a gob rope winch, the tug
will swing with the stern towards the attended ship.
Therefore, the location of a carrousel system and DOT
system is very critical. With a towline force at about right
angles to the tug, the location of the towing point should
be such that no turning moment is created with the
hydrodynamic force working at the centre of pressure.
The other systems, such as the radial towing hook, azimuth
friction free towing point, auto position escort winch and
certain staple designs, don’t move or move only a little in
a longitudinal direction. This means that the horizontal
distance between towing point and centre if pressure do not
change much. The focus of these systems is mainly on the
crosswise movement of the towing point.

found for the location of the towing point and also for the
underwater profile of a tug.
In figure 4.6 the tug is moving astern through the water. The
centre of pressure lies much further aft, eg, at location C for
conventional tugs as well as for tractor tugs.

Tractor tugs are considered first. The towing point T is very
dangerous, not only because of the large heeling moment
caused by the hydrodynamic force on the tug’s hull, but
also because large crosswise steering forces (at Pt) have
to be exerted by the tug in order to compensate for the
turning moment created by the incoming water flow, giving
additional forces in the towline and additional heeling
forces. At higher speeds and/or too large angles of attack of
incoming water flow the resulting heeling forces may cause
capsizing of the tug. The large vertical distance between the
propulsion units and towing point also contributes to the
high heeling moment. Therefore although towline forces
are high for tractor tugs it is much safer to locate the towing
point aft at a small distance abaft C, the centre of pressure for
smaller angles of attack. (In VS tractor tugs the towing point
lies generally just above the middle of the skeg) The tug then
comes in line with the towline when its engines are stopped
and very little steering power is needed to keep the tug in the
most effective position when the indirect towing method is
applied.
Neither do conventional tugs operate as shown in figure 4.6,
because with higher speeds it is almost impossible to steer
the tug safely and is therefore very dangerous. If the angle of
attack increases, the increase in towline forces might cause
the tug to capsize. At very low speeds conventional tugs may
operate broadside, for instance as a forward tug steering a
ship which is moving astern or as a stern tug steering a ship
moving ahead. Especially on single screw tugs, this can only
be done with a gob rope or by passing the towline through
a fairlead situated aft, as is the case on some combi- tugs.
The gob rope system is dealt with in more detail in Chapter 7.
Using a gob rope the towing point can be shifted to a position
somewhere between the after end of the tug and the towing
bitt or winch. By shifting the towing point from T1 to T2 (see
figure 4.7), the tug can stay broadside on and steer the ship by
Figure 4.6: Forces created on assisting tug, moving astern
Pt is centre of propulsion for tractor tugs;
Ps centre of propulsion for conventional tugs and ASD-tugs.
Figure 4.7: Tug working on a gob rope. Ship has a very low speed
ahead. Tug can steer the vessel by going ahead or astern on the engine.
Conventional twin screw tugs don’t always need a gob rope; they can
make a couple by the propellers
to stay broadside.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Tug Capabilities and Limitations 105
tug, and consequently the small distance between towing
point (T) and centre of pressure (C), implies that only a little
crosswise steering power of a tug is needed to keep the tug in
the most effective position to exert the highest steering forces
to the assisted ship.
The ASD-tug/reverse-tractor tug has generally a larger
distance between the towing point (T) and centre of pressurein increasingly complicated manoeuvres on arrival
or departure, and additional requirements for the harbour
tugs with regard to engine power, manoeuvrability and
dimensions.
Figure 1.2: Reverse tractor tugs Seaspan Osprey (LOA 28.20m, breadth 12.60m, BP 80 tons) and Seaspan Resolution (LOA 30m, beam 12.2m,
BP 80 tons) assisting container vessel with push-pull method towards the container terminal. Photo: Seaspan Marine
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Tug Design Factors 5
Ports close to the sea may be influenced by waves and swell,
leading to additional requirements for tugs. The same applies
to tugs that have to operate at offshore locations or in ports
in colder areas where ice may be encountered. Limited water
depths in port areas where harbour tugs have to operate
will give rise to special requirements with regard to a tug’s
maximum draft.
Tugs used should, as long as safety permits, always be capable
of working effectively under the environmental conditions in
and around the port and, if relevant, in the port approaches
or at offshore locations, whether during strong winds,
currents or ice, waves and/or swell. When water depth is
restricted, manoeuvring space is limited, or locks or bridges
have to be passed, the type of harbour tug used should
obviously be such that it is capable of performing well in
these situations.
designed. At an early stage, it is desirable that tugboat
companies and pilots should participate in design studies
for these new ports, harbour basins, terminals, etc. In this
way, tugboat companies and pilots can give advice based on
their experience of shiphandling with the available harbour
tugs. Moreover, tug companies can take account of these new
developments when ordering new tugs suitable for the new
situation. Regular consultation between port authorities,
port designers, tugboat companies and pilots will favourably
affect the accessibility of ports and harbours.
In container ports, especially where space is limited, the
requirement for large land space to stack containers may not
correspond with the minimum manoeuvring area required
for ships and tugs. Specific requirements for tug assistance
may be necessary, such as the type of tug, engine power,
towing equipment and assisting method.
Port approaches
Port approaches are under the influence of the open sea and
can be wide or narrow, with sandy or rocky banks, winding
or straight entrances. Depending on the local situation, tugs
may be used in the port approaches and should be capable
of working in more open sea conditions with waves and/or
swell. Following the Exxon Valdez disaster there is a growing
tendency to require an escort for oil and gas tankers in port
approaches. Tugs used for escorting must comply with very
specific requirements.
1.2.2 Environmental conditions
Geographical environmental conditions are very important
from a tugboat company’s point of view. The majority of
older ports are situated in river estuaries and are particularly
subject to the influence of tides or seasonal effects. Fairways
and rivers are constantly subject to changes. Differences in
water depth, bridge passages and lock entries may require
the adoption of time windows. The accessibility of these
ports, therefore, can be rather complicated. Tugs have to
handle ships safely and efficiently. Especially in these ports,
therefore, the requirements to which a tug must conform
may change continuously from the entrance or approach
up to the berth and the final mooring. In some ports this
problem is solved by using different types of tugs for the
various parts of the route.
Figure 1.4: Depending on the location of the port, tugs should be capable
to operate in wave conditions. Hybrid ASD-tug Multratug 28, type
ASD 2810, operating in the Rotterdam area. LOA 28.67m, beam 10.43m,
BP ahead 60.7 tons. Photo: Kees Torn, the Netherlands
Figure 1.3: Port Hedland: open jetty. Photo: Piet Sinke
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
6 Tug Use in Port
1.2.5 Assisting method in use
The method of assistance used by tugs will depend on:
•	 Port, jetty, terminal layout and/or offshore installation.
•	 Types of ship.
•	 Environmental conditions.
•	 Navigational complexity of river, channels and port
approach.
•	 Whether bridges and locks have to be passed.
•	 Whether escorting is needed.
•	 Often on tradition.
The type of tug used depends largely on the assisting method.
Tugs have to meet, as far as possible, the requirements
related to the assisting method. The assisting method may
also depend on the availability of mooring boats. When no
mooring boats are available a ship has to be brought up very
close to the berth or even alongside to be able to pass the
mooring lines. In these circumstances tugs should be able to
push at the ship’s side.
In a number of ports, tugs are used to brake and control the
ship’s speed, eg when approaching a lock or passing a bridge.
Tugs should be capable of doing so.
Blackouts do happen on ships arriving in ports. Tugs, tug
type and power should be such that they are able to keep the
ship under control as far as possible by braking ship’s speed
and/or controlling the heading.
1.2.6 Available experience
Pilots and tug captains are accustomed to the assisting
methods used in the port and to the types of tugs in
the port. They have built up their experience with these
tugs and with the tug’s crews. They know the advantages
and the shortcomings of their tugs and are thus able to
anticipate. Changing over to a new system or to a new
type of tug may introduce difficulties, will take time and
should be weighed carefully. Training and instruction will
1.2.3 The ships concerned
Another important factor is the type of ships to be assisted,
such as large LNG or LPG tankers, FSPOs, FLNGs , bulk
carriers, oil tankers, container ships, car carriers, ro-ro
ships and so on. Different types of ship give rise to specific
requirements on the assisting tug, with regard to such engine
power, towing equipment, fendering, manoeuvrability and
superstructure.
For example, in a port where only tankers moor alongside
an oil jetty, it is not too difficult to determine what kind of
tug, and what power, is required. However, a large variety of
types and sizes of ships means the requirements of tugs will
vary too.
1.2.4 Services required in and around
the harbour
The most important activities of harbour tugs have been
mentioned above. In many ports these activities also include
assisting at dock yards. Harbour tugs are often used for
activities other than assisting seagoing vessels, such as:
•	 Towing offshore material, such as oil rigs and crane
barges.
•	 Towing inland barges, elevators, floating cranes.
•	 Assisting push-tow barges.
•	 Fire-fighting and pollution control duties.
These activities also demand a specific type and size of tug,
as well as specific manoeuvrability, equipment and towing
methods, as is the case with tugs that have to operate, for
example, at SPMs, F(P)SOs, FNLGs, LNG terminals or at oil
rigs.
Figure 1.6: Other services required. Transport of tunnel segments over
the river and through bridges. The pulling tugs are two Rotortugs
RT Claire and RT Stephanie. Dimensions: LOA 27.7m, beam 11.2m,
BP 65 tons. Tugs should be able to do this kind of work as well,
including bridge passages. Photo: Kotug
Figure 1.5: In colder areas tugs should be able to operate in freezing
conditions and in ice. Tug Texas, diesel-electric single screw, on
Lake Michigan. Built 1916 (!), 1,200bhp, LOA 24.7m, beam 6.1m.
Still operational as ship assist tug. Photo: Scott Best,USA
Tug Design Factors 7
1.3 Types of tug
The factors mentioned above have resulted in the use of
different types of tug all over the world. At present mainly
the following types are used:
•	 Single screw tugs.
•	 Twin screw tugs.
•	 Tractor type tugs.
•	 Tugs with azimuth propellers aft.•	 Rotor®tugs
•	 Tugs with one propulsion unit forward and one aft.
Single and twin screw tug types are generally well known.
To increase towing power, many of them are fitted with
nozzles. They may be equipped with fixed or variable pitch
propellers. In some cases, to improve their manoeuvrability,
a bow thruster or, in particular on single screw tugs, a 360°
steerable and often retractable bow thruster is installed,
which also increases the towing force.
Tractor types of tug have propellers under the forebody of
the tug. These propellers may be Voith propellers or 360°
steerable azimuth propellers.
Tugs with azimuth propellers aft resemble twin screw tugs.
However, because of the 360° steerable thrusters they are
much more manoeuvrable.
Rotortugs have two azimuth propulsion units forward and
one aft and are very manoeuvrable.
Various tug types exist with one propulsion unit forward and
one aft.
The different tug types are discussed in more detail in
Chapter 2.
1.4 Assisting methods
Depending on local experience and circumstances, the
following assisting methods or combinations of these
methods are mainly used:
•	 Tugs towing on a line.
•	 Tugs operating at the ship’s side.
be needed, especially when the type of tug and the way it
operates is totally different from the existing system. A well
planned changeover to the new system will be necessary.
All this should be taken into account when considering the
introduction of a new tug type or assisting method.
1.2.7 Safety requirements
Sometimes tugs have to operate in hazardous areas, for
instance when handling LNG carriers or operating at LNG
terminals. Tugs should then often meet certain safety
requirements.
Tug assistance always includes risks for the tug and her crew.
These risks can be minimised by good training and by a well
designed and equipped tug. The type of tug also influences
the level of safety. Depending on the type of port, the
environmental conditions, the ships assisted, the assisting
methods and the port regulations, the safety requirements
may differ by port. On the other hand, tug owners should
require, regardless of the port situation, the highest level
of safety, which could dictate a certain type of tug and tug
equipment.
1.2.8 Summary
No two ports are the same. Many factors influence the
choice of tug type, such as local customs, environmental
conditions, water depth, type of ships using the port and
escort requirements. These factors can differ enormously
from port to port and so will affect the type of harbour
tugs. Requirements for harbour tugs that have to operate at
offshore installations may be an additional factor to take into
account. It should be noted that the factors mentioned not
only influence the type of tug needed, but also the assisting
method used and that method has, in turn, a strong relation
with the type of tug.
An overview of the factors influencing the operational
requirements for tugs is given in the table at the end of this
chapter.
Figure 1.7: Tugs might be needed for other services than just ship
handling.Three tugs transporting the FSPO Western Island over the river
to the yard. Photo: Mark de Bruin, the Netherlands
Figure 1.8: Brand-new MOL Tradition, Geoje, Korea.
Tugs should be able to assist at dockyards. Photo: Ole Peter Dahl
8 Tug Use in Port
When a new tug is needed a simple answer to the question
‘which type of tug and/or which towing method is most
suitable for the port?’ cannot easily be given. Too many
factors play a role. It takes reliable research, weighing all the
advantages and disadvantages, to establish the requirements
for the most suitable tug for the port. Most important is not
just what forces have to be considered but how, when and
under what conditions and circumstances do these forces
play a role – for instance with regard to ship's speed, confined
areas, environmental conditions and underkeel clearance.
This is the way more and more modern ports and/or tug
companies work nowadays. The outcome may be a tractor
type with azimuth propellers or Voith propulsion or even a
conventional type of tug. Escorting of tankers will involve
additional requirements.
On the other hand, tug owners want to operate as few
different types of tug as possible and prefer that the available
types are put into action as frequently as possible. Harbour
tugs should, therefore, be as versatile as possible.
When towing on a line, the towline is made fast at the bow or
stern of the assisted ship. The tugs operate at a distance from
the ship’s bow and stern on a towline length normally at least
one and half times the tug’s length.
Depending on the assistance required, local situation and
type of tugs used, tugs operating at the ship’s side can be
made fast with one, two or three lines. Different methods
are used, such as the push-pull method, whereby the tug is
usually made fast with one line. Alongside towing is another
method. Tugs are then securely lashed alongside the ship
with a minimum of three lines.
Different assisting methods are discussed in Chapter 3.
1.5 Conclusion
It is clear that no port is the same with respect to tug
requirements. Port layouts differ, as do the types of ship
frequenting the port, the environmental conditions, local
traditions and consequently the types of tug and the assisting
methods.
Figure1.10: Tugs may be required to handle submarines, which
sets specific demands for the assisting tugs. ASD-tugs
SD Independent (type ASD 2509, LOA 25.14m, beam 9.44m,
BP 40 tons) and SD Dependable (type ATD 2909, LOA 29.13m,
beam 9.98m, BP 43 tons). Photo: BAE Systems, UK
Figure 1.9: Tugs might be needed to handle navy vessels, such as
aircraft carriers, which will result in specific demands for the tugs.
Photo: Moran Tugs
Figure 1.11: Summary of factors influencing harbour tug choice
Types of Harbour Tug 9
Chapter 2
TYPES OF HARBOUR TUG
PART A
Classification of tugs and operational design aspects
Ta
bl
e
2A
.1
: C
la
ss
ifi
ca
tio
n
of
 h
ar
bo
ur
 tu
gs
 .
No
te
: T
he
 A
ll-
Ro
un
de
r b
ei
ng
 b
ui
lt
in
 2
02
1
ca
n
be
 a
dd
ed
 to
 th
e
Re
la
te
d
Tu
g
Ty
pe
s
10 Tug Use in Port
2.1 Classification of basic harbour
tug types
Tug types are named after their main characteristics, ie, the
type of propulsion, propulsion manufacturer, location of
propulsion or steering system. Names include conventional
tugs, Voith-Schneider tugs, Z-peller tugs, Kort nozzle tugs
and tractor tugs, among others. There is no uniform naming
system in use and this can be confusing. For example, when
talking about a Z-peller tug, what is meant? Is this a tug with
azimuth propellers forward or with azimuth propellers aft?
The difference does not seem so great, but considering tug
performance while rendering assistance, it is. After all, that is
what tugs are used for – to render assistance. As will be seen
later, it is better to classify tugs according to their location
of propulsion and towing point. It makes things easier to
understand.
Some history...
When discussing the various tug types it may give the
impression that azimuth thrusters are a product of the 20th
century. But that is not the case. The general principle of
today’s azimuth thrusters was patented under the heading
of ‘steering propellers’ in the early 1870s. Not only patented,
but actually made and used in several applications. Colonel
WH Mallory developed the ideas in the USA and was able
to patent them in Britain, setting up the Mallory Propeller
Co in London. In 1881 he patented an azimuth thruster with
twin propellers, designed to balance out the torque reactions
and requiring less power to turn the thrusters (see figure
2A.1). There is even evidence that Mallory also experimented
a with a podded thruster with an electromotor in the
underwater unit.
Even the Voith Schneider propeller had a predecessor. The
USS Alarm, commissioned in 1874,was equipped with
a Fowler propeller, which was a vertical axis propulsion
resembling a feathering paddle wheel set on one end. It had
some similarities with the well-known Voith Schneider
propeller, but lacked the sophisticated linkage and blade
design. See figure 2A.2.
Through tug development, a large number of different tug
types have emerged. These tug types can be categorised in
three groups – as shown in Table 2A.1.
First, attention will be paid to the basic tug types, because
the other tug types have to some extent a relation with
these tugs. Classifying the basic tug types according to their
thruster and towing point location results in the following
two main groups:
a) Tugs with their propulsion aft and towing point near
midships. These are basically conventional types of tug.
This category includes all normal conventional types such as
single screw and twin screw tugs.
b) Tugs with their towing point aft and propulsion forward
of midships. These are tractor tugs.In this category are:
•	 Tractor tugs with Voith propulsion.
•	 Tractor tugs with azimuth propellers.
There are types of tug that can be classified either as
conventional or tractor tugs, depending on the way they
operate. These are:
•	 Reverse-tractor or pusher tugs (more and more also
called ASD-tugs) – tugs with azimuth propellers aft
and towing point forward, built to operate mainly over
the tug’s bow, as can be seen for example in Japan,
Hong Kong and Taiwan. Tractor tugs normally work
with their towing point – the tug’s stern – towards the
ship and their propellers – near the tug’s bow – away
from the ship. Reverse-tractor tugs operate in the same
way regarding the towing point and the propellers,
consequently the tug itself lies in the reverse direction.
•	 Azimuth stern drive (ASD) tugs – multi-purpose tugs
with azimuth propellers aft which are built to operate
over the tug’s bow as a reverse-tractor tug as well as over
the tug’s stern like a conventional tug. Most ASD-tugs
have a towing winch forward and one on the after deck
while some have simply a towing hook instead of a
towing winch aft, or have the option to be fitted with a
towing winch later. Because an ASD-tug can operate as
a reverse-tractor tug, it is often mentioned together with
reverse-tractor tugs.
•	 Modified older tugs with a 360° steerable bow thruster
(combi-tugs) and equipped with an additional towing
point at the after end of the tug. These tugs can operate
as a normal conventional tug or like a tractor tug when
using their aftermost towing point.
Figure 2A.1: Colonel WH Mallory steerable propeller. 1870s Figure 2A.2: USS Alarm, 1874 Source: USA Naval History and Heritage Command
Pgua_Supplay
Destacar
Types of Harbour Tug 11
or towing direction should be as small as possible. The
effectiveness and safety of a tug is also related to factors such
as the tug’s stability and suitability of towing equipment.
Required manoeuvring space
The manoeuvring space required by assisting tugs should,
depending on the situation, be as small as possible.
This can be achieved by a suitable tug type with good
manoeuvrability, limited tug dimensions and proper towing
equipment.
Other practical aspects of importance for good tug
performance and safety of operations are as follows:
2.2.2 Wheelhouse construction and layout
Visibility
A tug’s wheelhouse should be placed and constructed such
that, at his/her manoeuvring station, the tug captain has a
good view of the tug’s fore and aft ends and tug sides. He/she
must also have a good view of:
•	 The towline and towing equipment.
•	 The working deck.
•	 Contact areas between tug and ship.
•	 The assisted ship.
•	 Other assisting tug boats.
•	 The direction of operation.
This requires a field of view at the manoeuvring station(s) as
unobstructed as possible, with an angle of view as close as
possible to 360°.
In addition to the all round view, well designed wheelhouses
also have small windows that face upwards, which is
important when making fast to vessels with a high forecastle,
stern or freeboard. On some modern tugs very small
wheelhouses are constructed with large windows and a
nearly 360° view.
Manoeuvring stations
When making fast to a vessel and while assisting, a tug
captain should be able, to see in one glance from his
manoeuvring station, the most essential outside information
needed to operate his tug in a safe and efficient way, without
jumping from side to side in his wheelhouse and without
getting painful legs, neck or back. The essential outside
information comes from:
a) The towline(s) – their direction and tension.
b) The assisted ship: such as relative heading and speed,
distance off and the way the assisted ship reacts to the
applied tug forces. When pushing, essential information also
comes from the contact area between tug and ship.
c) The combined ship/tug direction of movement with
regard to channel or fairway boundaries, other traffic and
nearby berths and banks.
Depending on the type of tug and the assisting method
in use, this essential information may come from totally
different or even opposite directions. The directions may
change during one and the same trip and are dependent,
in any case, on the assisting method. In a reverse-tractor
So the following basic types of tug can be seen, all belonging
to one or both of the above groups:
•	 Conventional tugs.
•	 Tractor tugs with azimuth propellers or Voith
propulsion.
•	 ASD-tugs.
•	 Reverse-tractor tugs.
•	 Combi-tugs.
There are, of course, many differences in construction, hull
design, propulsion and rudder configuration and so on
within each basic tug type. The different basic types of tug
are therefore discussed in more detail starting with some
general aspects regarding tug performance and safety of
operations.
The ‘related tug types’ as shown in Table 2A.1 – eg, Rotortug,
Z-tech tug and RSD tug – have much common with the basic
tug types. The Rotortug has three azimuth thrusters and the
other two tug types have two azimuth thrusters under one of
the tug’s ends.
A more recent development is the FAST (Forward-Aft-
Single-Thruster) tugs, which have thrusters, either azimuth
or Voith, at each end of the tug. These are the SDM, EDDY,
Giano tug and RAVE tug. The latter has Voith propulsion
units.
More attention will be paid to all tug types later in this
chapter.
2.2 Important general requirements
for good tug performance
For good harbour tug safety and performance, the following
factors are important:
2.2.1 Tug performance and safety
Response time
Harbour tugs should have a short response time and their
manoeuvrability should be such that the tug can react in a
minimum of time. It is therefore important that measures
are taken to increase the manoeuvrability of harbour tugs
and shorten their response time.
Not only is a short response time required when assisting
a vessel, but also for making fast. Due to ever decreasing
numbers in a ship’s crew, the time taken to make tugs fast is
increasing. Thus the requirement for tugs regarding fast and
easy handling of towing equipment becomes an element of
increasing importance in order to improve their response
time.
Effectiveness and safety of operations
It is not only manoeuvrability, but also bollard pull and
underwater shape that make a tug effective and therefore
suitable for the job. For example, large container vessels with
containers stacked six high or more on deck need powerful
tugs in case of strong winds. When a ship is underway at
speed, loss of tug’s effectiveness due to the ship’s speed and/
12 Tug Use in Port
coming alongside a ship or berth. Modern tugs often have
one central manoeuvring panel in an optimal designed small
wheelhouse, like a kind of cockpit.
At the manoeuvring stations the captain should also
have a good view of his instruments, including the radar.
Communication and quick release systems, which will
be discussed lateron, should be within hand reach at all
manoeuvring panels. Towing winch control from the
wheelhouse is also recommended for harbour tugs. The
towline length can then always be adjusted when required
without calling a man to the towing winch. The number
of crew members on modern harbour tugs is very limited
nowadays.
Communication
Good co-operation between the pilot and tug captain is
a basic requirement for safe and efficient ship handling
with tugs. Such co-operation is only possible with good
procedures and efficiently working communication systems.
Radio communication systems on board tugs should
therefore be reliable. A double VHF set is recommended.
This is sometimes an advantage for the pilot as well. On
ships with open bridges the pilot is, during manoeuvring,
often standing on the bridge wing busy with his own VHF
set on the working channel with the tug. He has then often
no possibility to listen to the traffic control channel. The tug
master, having one VHF on the traffic control channel, can
then pass the information to the pilot.
tug, which is assisting from over the tug’s bow, nearly all
the essential outside information comes from forward
and should be available in one outside look from the
manoeuvring station. This can be achieved with one forward
facing station. If the manoeuvring station is well planned,
the tug captain may have an unobstructed view in the
working direction, even from a seated position, of the winch,
working deck, bow and side fenders and the assisted ship.
For all other types of tug and/or other assisting methods
the visibility requirements may be totally different. For
instance, a tractor tug used for push-pull operations works
over the stern. Then an aft facing manoeuvring panel
is needed. When the same tug is free sailing a forward
facing manoeuvring panel is required. Depending on the
wheelhouse construction, a central manoeuvring panel for
this type of tug could be useful, capable of being operated
in both directions, forward and aft. On other tugs more
manoeuvring panels may be required, of course, depending
on the wheelhouse size and construction. Some harbour tugs
even have three manoeuvring panels facing forward and one
facing aft. Care should be taken in order that reliable change-
over between manoeuvring panels is possible without the
risk of failures or mistakes.
Controls at the manoeuvring panels should be arranged such
that they can be operated in a logical way in relation to the
tug’s direction of movement. Pushing a lever down and away
in the direction the tug captain is facing should result in
an increase of movement in that direction. Turning a wheel
or moving a joystick to the left should turn the tug in that
direction, regardless of whether the direction of movement
is ahead or astern. Any illogical way of control or complexity
in control easily leads to human control failures, particularly
when under tension.
It is clear that the wheelhouse layout and the number,
location and orientation of manoeuvring panels depend
largely on the type of tug and the usual assisting method and
should be carefully considered, also taking into account the
optimum view needed from the manoeuvring station when
Figure 2A.3: Tug RT Stephanie (Rotortug; LOA 28.3m, beam 11.7,
BP 68 tons) having a wheelhouse with a clear overall view. A good
view abreast is also important for when coming alongside a ship
having speed or when berthing. Photo: Piet Sinke
Figure 2A.4: View of the wheelhouse with the tug master handling
the tug with the Uni-lever system (right) and speed control handles.
Photo: Piet Sinke
Types of Harbour Tug 13
FlyingView bird’s eye view
This system which monitors a 3600 field of view around the
tug is studied by Mitsui OSK lines and Oki Electric Industry.
Four fish-eye cameras were installed on the tug Asaka Maru
with a digital compositing system and display on the tug’s
bridge. The system was able to automatically calculate the
distance to nearby obstacles and other vessels. The project
forms part of a wider ongoing initiative named Focus Eye,
which tries to make marine operations safer and more
efficient.
Note: Cameras have a large drawback. They don’t work
properly in case of reduced visibility, dust, smog, etc. A
better alternative is 3D sonar sensors, which don’t have these
drawbacks.
Augmented technology (AR)
AR technology, an element of XR (extended reality), is dealt
with in paragraph 8.5. New maritime AR applications are
emerging all the time. The European Union (EU) funds
a project for AR bridge systems, designed to improve
navigation safety and efficiency on ships.
An AR headset having maps, radar, alarms, warnings and
interacting with the real view out of the bridge window will
be a valuable option regarding the improvement in safety
and situational awareness. AR is not just a PC or virtual
reality content; AR combines natural and digital experience
along with the interaction between the objects of both worlds
made possible in real time. When purposefully designed
such a system might be useful for tugs and tug master’s as
well.
These are just a few systems. The development of remote-
controlled tugs (see paragraph 10.2) and automation
on board tugs will closely be associated with further
developments of decision support systems, data sensing and
remote control systems. Such systems may become more
common on board tugs.
2.2.3 Tug superstructure and underwater
design
Tugs regularly have to work near a ship’s bow or stern, where
the flare and overhang are often fairly pronounced. It is
necessary, therefore, that the tug’s superstructure is located
well inboard of the deck edge, so that risk of tug damage
can be avoided as much as possible when working near the
ship’s bow or stern or when the vessel or tug is rolling when
alongside a ship.
Underwater design of the tug should be such that the
propulsion units will not hit the ship’s hull when the tug is
rolling alongside. In this regard harbour tugs have to assist
all kind of vessels, including submarines in some ports. Tug
propellers may hit the submarine hull when a tug is required
to come alongside for assistance or for bringing the pilot on
board.
2.2.4 Fendering
Tugs should be equipped with good fendering. Appropriate
fendering protects both the assisted ship and tug from
damage and decreases the tendency to slide along the ship’s
hull when the tug is pushing at an angle to the ship’s hull.
Decision support systems
Various systems are developed and/or introduced intended
to support the tug master. A very welcome development.
Some will be mentioned below. Daily practice is the real
test of such systems whereby such questions as mentioned
below are of value to verify if or to what extent these systems
support a tug master. Focus should then not only be on the
standard manoeuvres but in particular on the more critical
situations a tug master has to deal with.
Five crucial questions regarding the development and
introduction of decision support systems for a tug master
are:
•	 Does it affect the tug master’s workload?
•	 Does it distract the tug master’s eye from òut of the
window’ visual clues which remain paramount for
manoeuvring alertly, especially in the more critical
situations.
•	 Does the decision support system indeed support the
tug master in critical situations and adverse weather
conditions, such as in case of operating near the bow of a
ship at speed or in reduced visibility?
•	 Does the decision support system warn the tug master if
a critical situation with respect to speed, direction, rate
of turn, distances off, etc. develops and tells him to take
action and what actions he has to take?
•	 Does the system inform the tug master about the level of
tug’s stability and safe heeling angels limits?
Damen Human Machine Interface
Damen Shipyards has developed a Human Machine Interface
with a range of possibilities, comprisingits effectiveness as
a forward tug. However, this would have consequences for
its effectiveness as stern tug when operating in the indirect
mode whereby use is made of the hydrodynamic forces
on the tug’s hull. Therefore a compromise has often to be
underwater lateral plane and shape, the angle of attack,
the under keel clearance and on the speed squared. Speed,
therefore, is a dominant factor.
The exact location of the lateral centre of pressure and the
magnitude and direction of the resultant force created by the
incoming water flow for different angles of attack and speeds
can best be determined in a towing tank. The locations of the
centre of pressure mentioned later are merely an indication
and are based on observations and information, eg from
Voith.
When water flow towards a tug comes from abeam, caused
either by crosswise movement of a tug through the water or
by a current at right angles, the centre of pressure generally
lies behind midships in a position about 0.3 to 0.4 x LWL
from aft. For conventional tugs it is probably more often in
the vicinity of 0.3 x LWL from aft and for tractor tugs closer
to 0.4 x LWL from aft. Reverse-tractor tugs and ASD-tugs
may have a more forward lying centre of pressure, depending
on the hull and skeg design.
When a tug turns with its bow into the direction of water
flow, the centre of pressure moves forward. The smaller the
angle between incoming water flow and tug’s heading the
more forward the centre of pressure lies. For conventional
and tractor tugs the centre of pressure does not generally
move forward of amidships (0.5 x LWL). Reverse-tractor
tugs and ASD-tugs may experience a position of centre of
pressure forward of midships with a forward incoming water
flow. When a tug is turning with the stern into the water flow
the centre of pressure moves aft and with an acute angle of
incoming water flow will lie far aft.
Figure 4.5 shows a tug moving ahead, towing on a line,
assisting a ship under speed. The resultant force created
by incoming water flow is force F, assumed to be centred
approximately near amidships, location C. Force F can be
resolved into lift force L and drag force D, comparable with
the lift and drag forces on rudders or aeroplane wings. Lift
force L gives an additional force on the towline and drag
force D has to be overcome by the tug’s thrust. Towing point
T lies a little behind the centre of pressure C. The force in
Figure 4.5: Forces created on assisting tug moving ahead.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Destacar
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
Pgua_Supplay
Seta
104 Tug Use in Port
moving ahead or astern using the tug’s engine. By shifting the
towing point to a position at the stern of the tug, the tug can
be pulled astern by a vessel without the danger of capsizing.
The tug can then use its engine to control the ship’s speed.
Conventional twin screw tugs often use the propellers instead
of a gob rope to keep the tug in the position as indicated in
figure 4.7.
As can be seen at figure 4.7 the use of the ship’s engine on
ahead can become very dangerous for the tug. The ship’s
propeller wash will hit the underwater hull of the tug and
so given it an extra heeling force, in addition to the heeling
force created by the towline force.
Relationship of movable towing points and centre of pressure
is of even greater importance.
In figure 4.7 is shown how a gob rope works in relation with
the location of the towing point. If the towing point would be
shifted far aft, as can be done with a gob rope winch, the tug
will swing with the stern towards the attended ship.
Therefore, the location of a carrousel system and DOT
system is very critical. With a towline force at about right
angles to the tug, the location of the towing point should
be such that no turning moment is created with the
hydrodynamic force working at the centre of pressure.
The other systems, such as the radial towing hook, azimuth
friction free towing point, auto position escort winch and
certain staple designs, don’t move or move only a little in
a longitudinal direction. This means that the horizontal
distance between towing point and centre if pressure do not
change much. The focus of these systems is mainly on the
crosswise movement of the towing point.

found for the location of the towing point and also for the
underwater profile of a tug.
In figure 4.6 the tug is moving astern through the water. The
centre of pressure lies much further aft, eg, at location C for
conventional tugs as well as for tractor tugs.

Tractor tugs are considered first. The towing point T is very
dangerous, not only because of the large heeling moment
caused by the hydrodynamic force on the tug’s hull, but
also because large crosswise steering forces (at Pt) have
to be exerted by the tug in order to compensate for the
turning moment created by the incoming water flow, giving
additional forces in the towline and additional heeling
forces. At higher speeds and/or too large angles of attack of
incoming water flow the resulting heeling forces may cause
capsizing of the tug. The large vertical distance between the
propulsion units and towing point also contributes to the
high heeling moment. Therefore although towline forces
are high for tractor tugs it is much safer to locate the towing
point aft at a small distance abaft C, the centre of pressure for
smaller angles of attack. (In VS tractor tugs the towing point
lies generally just above the middle of the skeg) The tug then
comes in line with the towline when its engines are stopped
and very little steering power is needed to keep the tug in the
most effective position when the indirect towing method is
applied.
Neither do conventional tugs operate as shown in figure 4.6,
because with higher speeds it is almost impossible to steer
the tug safely and is therefore very dangerous. If the angle of
attack increases, the increase in towline forces might cause
the tug to capsize. At very low speeds conventional tugs may
operate broadside, for instance as a forward tug steering a
ship which is moving astern or as a stern tug steering a ship
moving ahead. Especially on single screw tugs, this can only
be done with a gob rope or by passing the towline through
a fairlead situated aft, as is the case on some combi- tugs.
The gob rope system is dealt with in more detail in Chapter 7.
Using a gob rope the towing point can be shifted to a position
somewhere between the after end of the tug and the towing
bitt or winch. By shifting the towing point from T1 to T2 (see
figure 4.7), the tug can stay broadside on and steer the ship by
Figure 4.6: Forces created on assisting tug, moving astern
Pt is centre of propulsion for tractor tugs;
Ps centre of propulsion for conventional tugs and ASD-tugs.
Figure 4.7: Tug working on a gob rope. Ship has a very low speed
ahead. Tug can steer the vessel by going ahead or astern on the engine.
Conventional twin screw tugs don’t always need a gob rope; they can
make a couple by the propellers
to stay broadside.
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Pgua_Supplay
Destacar
Tug Capabilities and Limitations 105
tug, and consequently the small distance between towing
point (T) and centre of pressure (C), implies that only a little
crosswise steering power of a tug is needed to keep the tug in
the most effective position to exert the highest steering forces
to the assisted ship.
The ASD-tug/reverse-tractor tug has generally a larger
distance between the towing point (T) and centre of pressure
