10 H-01 M01 S-01 H-01 Parameter Value Unit Heat duty 595121 W Stream 1 2 3 4 9 10 Stream 1 2 3 4 9 10 Unit Pressure 1 1 1 1 1 1 Pressure 1 1 1 1 1 1 atm Temperature 50 25 27.2872 80 80 80 Temperature 50 25 27.2872 80 80 80 'C Flow rate 28 140 168 168 42 126 Flow rate 28 140 168 168 42 126 kg min Mole frac Ethanol 1 0 0.0725377 0.0725377 0.0725377 0.0725377 Mass frac Ethanol 1 0 0.166667 0.166667 0.166667 0.166667 Mole frac Water 0 1 0.927462 0.927462 0.927462 0.927462 Mass frac Water 0 1 0.833333 0.833333 0.833333 0.833333 Flow Ethanol 28 0 28 28 7 21 Flow Ethanol 28 0 28 28 7 21 kg min Flow Water 0 140 140 140 35 105 Flow Water 0 140 140 140 35 105 kg min Liquid phase Liquid phase Density 803.696 1007.28 967.338 923.511 923.511 923.511 Density 803.696 1007.28 967.338 923.511 923.511 923.511 g
