Journal Pre-proof
Performance Comparison of Several Explainable Hybrid Ensemble Models for
Predicting Carbonation Depth in Fly Ash Concrete
Meng Wang, Hani S. Mitri, Guoyan Zhao, Junxi Wu, Yihang Xu, Weizhang Liang,
Ning Wang
PII: S2352-7102(24)02814-6
DOI: https://doi.org/10.1016/j.jobe.2024.111246
Reference: JOBE 111246
To appear in: Journal of Building Engineering
Received Date: 23 July 2024
Revised Date: 11 October 2024
Accepted Date: 4 November 2024
Please cite this article as: M. Wang, H.S. Mitri, G. Zhao, J. Wu, Y. Xu, W. Liang, N. Wang, Performance
Comparison of Several Explainable Hybrid Ensemble Models for Predicting Carbonation Depth in Fly
Ash Concrete, Journal of Building Engineering, https://doi.org/10.1016/j.jobe.2024.111246.
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition
of a cover page and metadata, and formatting for readability, but it is not yet the definitive version of
record. This version will undergo additional copyediting, typesetting and review before it is published
in its final form, but we are providing this version to give early visibility of the article. Please note that,
during the production process, errors may be discovered which could affect the content, and all legal
disclaimers that apply to the journal pertain.
© 2024 Published by Elsevier Ltd.
https://doi.org/10.1016/j.jobe.2024.111246
https://doi.org/10.1016/j.jobe.2024.111246

1
Performance Comparison of Several Explainable Hybrid 1
Ensemble Models for Predicting Carbonation Depth in Fly 2
Ash Concrete 3
Meng Wang 1, Hani S. Mitri 2, Guoyan Zhao 1, Junxi Wu 1, Yihang Xu 1, Weizhang Liang 1 and Ning Wang 1* 4
1School of Resource and Safety Engineering, Central South University, Changsha, Hunan 410083, PR China; 5
2Department of Mining and Materials Engineering, McGill University, 3450 University Street, Montreal, Quebec, Canada, H3A 0E8. 6
*Correspondence: ningwang98@csu.edu.cn 7
 8
Abstract: The carbonation of fly ash concrete critically impacts the lifespan of structures, necessitating 9
precise prediction of carbonation depth for the construction industry. This study establishes an original 10
database comprising 883 cases, which are divided into training and testing sets in a 4:1 ratio. The Sand Cat 11
Swarm Algorithm (SCSO) was developed to optimize the hyperparameters of three ensemble models: 12
Gradient Boosting Decision Trees (GBDT), Light Gradient Boosting Machine (LGBM), and Categorical 13
Boosting (CatBoost), resulting in the development of three hybrid ensemble models: SCSO-GBDT, 14
SCSO-LGBM, and SCSO-CatBoost. Five classic models were included in the comparison, and all models 15
used five-fold cross validation. Models’ performance was rigorously evaluated using Correlation coefficient 16
(R²), Mean Absolute Error (MAE), Root Mean Square Error (RMSE), and Variance Accounted For (VAF), 17
with VIsekriterijumska optimizacija i KOmpromisno Resenje (VIKOR) method and Taylor diagrams utilized 18
for optimal model selection. The SCSO-CatBoost model demonstrated superior performance, with R² = 19
0.9657, MAE = 2.0062, RMSE = 8.2147, and VAF = 96.6177. Shapley additive explanations (SHAP) 20
analysis of the SCSO-CatBoost model identified time of exposure as the most significant factor influencing 21
carbonation depth, followed by fly ash content and carbon dioxide concentration. To facilitate practical 22
application by non-algorithm engineers, an intelligent program was developed, allowing for straightforward 23
testing with the three hybrid ensemble models. This study presents three precise models for predicting the 24
carbonation depth of fly ash concrete. These models serve as valuable tools for estimating the service life of 25
concrete structures and can be utilized as simulation instruments in durability engineering. 26
Keywords: Carbonation Depth; Fly Ash Concrete; Hybrid Ensemble Models; Prediction27
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

2
Nomenclature
Adaboost Adaptive boosting MAE Mean absolute error
ANN Artificial neural network ML Machine learning
B Binder NIS Negative ideal solution
BPNN Back propagation neural network PIS Positive ideal solution
CatBoost Categorical boosting PSO Particle swarm optimization
CD Carbonation depth R2 Coefficient of determination
CNN Convolutional neural networks RF Random forest model
CO2 CO2 concentration RH Relative humidity
CSO Chicken swarm optimization RMSD Root means square deviation
EFB Exclusive feature bundling RMSE Root means square error
EL Ensemble learning RNN Recurrent neural network
FA Fly ash content SC Sand cat
FAC Fly ash concrete SCMs Supplementary cementitious materials
GBDT Gradient boosting decision trees SCSO Sand cat swarm algorithm
GOSS Gradient-based one-side sampling SHAP Shapley additive explanations
GU Computing group utility value SOA Seagull optimization algorithm
GUI Graphical user interface SVR Support vector regression
GWO Grey wolf optimization t Time of exposure
IR Individual regret values VAF Value accounted for
KNN K-nearest neighbor VIKOR Visekriterijumska optimizacija i kompromisno resenje
LGBM Light gradient boosting machine w/b Water-to-binder ratio
LR Linear Regression X Carbonation depth (When used as the output of a model)
LSTM Long short-term memory XGBoost Extreme gradient boosting
 28
1. Introduction 29
Concrete structures are extensively used in industrial construction due to their superior mechanical 30
properties and relatively low construction costs[1, 2]. However, as these buildings age, they are subjected to 31
various environmental factors, leading to gradual changes in the micro structure of the concrete due to 32
carbonation. This process results in rebar corrosion, diminished mechanical performance, and ultimately a 33
reduction in the lifespan of the structures [3, 4]. Currently, concrete carbonation is recognized as one of the 34
critical factors affecting the durability of reinforced concrete structures [5, 6]. If not properly addressed, this 35
issue can result in significant economic losses and environmental pollution [7, 8]. Quantifying and predicting 36
the carbonation depth (CD) is essential to mitigate these problems. 37
Carbonation takes place when carbon dioxide (CO2) in the atmosphere infiltrates microcracks in 38
concrete, reacting with hydrated cementitious materials to form calcium carbonate [9]. This process lowers 39
the pH of the concrete, which leads to the corrosion of embedded steel reinforcements and undermines 40
structural integrity [10]. In typical concrete, carbonation peaks at a relative humidity of 50-60% but 41
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado

3
decreases in dry or water-saturated conditions. High concentrations of CO2 also accelerate the carbonation 42
process [11]. The global cement industry accounts for 5% to 7% of total CO2 emissions [12]. To minimize 43
environmental impact, supplementary cementitious materials (SCMs) are increasingly being used as 44
alternatives to cement and coarse aggregates in concrete [13, 14]. For instance, Ahmed [15] proposed using 45
rubber tires as a substitute, which not only enhances the properties of concrete but also benefits the 46
ecological environment and the construction industry. Fly ash (FA), a byproduct of coal combustion, is 47
widely utilized in concrete due to its numerous benefits, including reduced permeability and enhanced 48
workability [16, 17]. The use of FA in concrete addresses environmental concerns associated with its disposal 49
and contributes to more sustainable and resilient concrete structures [18, 19]. 50
However, the carbonation resistance of fly ash concrete (FAC) is controversial. Some studies indicate 51
thatMaterials, 29 (2012) 263-269. 640
[38] M. Castellote, C. Andrade, Modelling the carbonation of cementitious matrixes by means of the 641
unreacted-core model, UR-CORE, Cem. Concr. Res., 38 (2008) 1374-1384. 642
[39] V.G. Papadakis, C.G. Vayenas, M.N. Fardis, A reaction engineering approach to the problem of 643
concrete carbonation, AIChE, 35 (1989) 1639-1650. 644
[40] V.G. Papadakis, M.N. Fardis, C.G. Vayenas, Effect of composition, environmental factors and 645
cement-lime mortar coating on concrete carbonation, Mater. Struct., 25 (1992) 293-304. 646
[41] V.G. Papadakis, Experimental investigation and theoretical modeling of silica fume activity in concrete, 647
Cem. Concr. Res., 29 (1999) 79-86. 648
[42] X.-Y. Wang, H.-S. Lee, A model for predicting the carbonation depth of concrete containing 649
low-calcium fly ash, Construction and Building Materials, 23 (2009) 725-733. 650
[43] H. Torres, E. Correa, J.G. Castaño, F. Echeverría, Simplified Mathematical Model for Concrete 651
Carbonation, J. Mater. Civ. Eng., 29 (2017) 04017150. 652
Jo
urn
al
Pre-
pro
of

34
[44] A. Zurek, Numerical approximation of a concrete carbonation model: Study of the -law of propagation, 653
Numerical Methods for Partial Differential Equations, 35 (2019) 1801-1820. 654
[45] R.A. Patel, S.V. Churakov, N.I. Prasianakis, A multi-level pore scale reactive transport model for the 655
investigation of combined leaching and carbonation of cement paste, Cem. Concr. Compos., 115 (2021) 656
103831. 657
[46] I. Monteiro, F.A. Branco, J. de Brito, R. Neves, Statistical analysis of the carbonation coefficient in 658
open air concrete structures, Construction and Building Materials, 29 (2012) 263-269. 659
[47] M. Wang, G. Zhao, W. Liang, N. Wang, A comparative study on the development of hybrid SSA-RF 660
and PSO-RF models for predicting the uniaxial compressive strength of rocks, Case Studies in Construction 661
Materials, 18 (2023) e02191. 662
[48] X. Zhang, M.Z. Akber, W. Zheng, Prediction of seven-day compressive strength of field concrete, 663
Construction and Building Materials, 305 (2021) 124604. 664
[49] C. Zhao, J. Li, Z. Zhu, Q. Guo, X. Wu, Z. Wang, R. Zhao, Research on the carbonation resistance and 665
carbonation depth prediction model of fly ash- and slag-based geopolymer concrete, KSCE Journal of Civil 666
Engineering, (2024). 667
[50] J.-s. Zhang, M. Cheng, J.-h. Zhu, Carbonation depth model and prediction of hybrid fiber fly ash 668
concrete, Advances in Civil Engineering, 2020 (2020). 669
[51] Y. Wei, P. Chen, S. Cao, H. Wang, Y. Liu, Z. Wang, W. Zhao, Prediction of carbonation depth for 670
concrete containing mineral admixtures based on machine learning, Arabian Journal for Science and 671
Engineering, 48 (2023) 13211-13225. 672
[52] I.D. Uwanuakwa, Deep learning modelling and generalisation of carbonation depth in fly ash blended 673
concrete, Arabian Journal for Science and Engineering, 46 (2021) 4731-4746. 674
[53] I. Nunez, M.L. Nehdi, Machine learning prediction of carbonation depth in recycled aggregate concrete 675
incorporating SCMs, Construction and Building Materials, 287 (2021). 676
[54] Y. Kellouche, M. Ghrici, B. Boukhatem, Service life prediction of fly ash concrete using an artificial 677
neural network, Frontiers of Structural and Civil Engineering, 15 (2021) 793-805. 678
[55] E.F. Felix, R. Carrazedo, E. Possan, Carbonation model for fly ash concrete based on artificial neural 679
network: Development and parametric analysis, Construction and Building Materials, 266 (2021). 680
[56] Z. Chen, J. Lin, K. Sagoe-Crentsil, W. Duan, Development of hybrid machine learning-based 681
carbonation models with weighting function, Construction and Building Materials, 321 (2022). 682
[57] K. Liu, M.S. Alam, J. Zhu, J. Zheng, L. Chi, Prediction of carbonation depth for recycled aggregate 683
concrete using ANN hybridized with swarm intelligence algorithms, Construction and Building Materials, 301 684
(2021) 124382. 685
[58] R. Biswas, E. Li, N. Zhang, S. Kumar, B. Rai, J. Zhou, Development of hybrid models using 686
metaheuristic optimization techniques to predict the carbonation depth of fly ash concrete, Construction and 687
Building Materials, 346 (2022) 128483. 688
[59] J. Zhou, Y. Qiu, S. Zhu, D.J. Armaghani, M. Khandelwal, E.T. Mohamad, Estimation of the TBM 689
advance rate under hard rock conditions using XGBoost and Bayesian optimization, Underground Space, 6 690
(2021) 506-515. 691
[60] Y. Kellouche, B. Boukhatem, M. Ghrici, A. Tagnit-Hamou, Exploring the major factors affecting 692
fly-ash concrete carbonation using artificial neural network, Neural Computing and Applications, 31 (2019) 693
969-988. 694
[61] C.-F. Chang, J.-W. Chen, The experimental investigation of concrete carbonation depth, Cem. Concr. 695
Res., 36 (2006) 1760-1767. 696
[62] H. Cui, W. Tang, W. Liu, Z. Dong, F. Xing, Experimental study on effects of CO2 concentrations on 697
concrete carbonation and diffusion mechanisms, Construction and Building Materials, 93 (2015) 522-527. 698
Jo
urn
al
Pre-
pro
of

35
[63] J. Balayssac, C.H. Détriché, J. Grandet, Effects of curing upon carbonation of concrete, Construction 699
and Building Materials, 9 (1995) 91-95. 700
[64] E. Roziere, A. Loukili, F. Cussigh, A performance based approach for durability of concrete exposed to 701
carbonation, Construction and Building Materials, 23 (2009) 190-199. 702
[65] S. Hussain, D. Bhunia, S. Singh, Comparative study of accelerated carbonation of plain cement and 703
fly-ash concrete, Journal of Building Engineering, 10 (2017) 26-31. 704
[66] A. Younsi, P. Turcry, A. Aït-Mokhtar, S. Staquet, Accelerated carbonation of concrete with high content 705
of mineral additions: effect of interactions between hydration and drying, Cem. Concr. Res., 43 (2013) 25-33. 706
[67] P. Turcry, L. Oksri-Nelfia, A. Younsi, A. Aït-Mokhtar, Analysis of an accelerated carbonation test with 707
severe preconditioning, Cem. Concr. Res., 57 (2014) 70-78. 708
[68] Y. Chen, P. Liu, Z. Yu, Effects of environmental factors on concrete carbonation depth and compressive 709
strength, Materials, 11 (2018) 2167. 710
[69] C.H. Huang, G.L. Geng, Y.S. Lu, G. Bao, Z.R. Lin, Carbonation depth research of concrete with 711
low-volume fly ash, Applied Mechanics and Materials, 155 (2012) 984-988. 712
[70] Y. Gao, L. Cheng, Z. Gao, S. Guo, Effects of different mineral admixtures on carbonation resistance of 713
lightweight aggregate concrete, Construction and Building Materials, 43 (2013) 506-510. 714
[71] Q. Zhao, X. He, J. Zhang, J. Jiang, Long-age wet curing effect on performance of carbonation 715
resistance of fly ash concrete, Construction and building materials, 127 (2016) 577-587. 716
[72] R. Kurda, J. de Brito, J.D. Silvestre, Carbonation of concrete made with high amount of fly ash and 717
recycled concrete aggregates for utilization of CO2, Journal of CO2 Utilization, 29 (2019) 12-19. 718
[73] C.-f. Lu, W. Wang, Q.-t. Li, M. Hao, Y. Xu, Effects of micro-environmental climate on the carbonation 719
depth and the pH value in fly ash concrete, Journal of Cleaner Production, 181 (2018) 309-317. 720
[74] E.F. Felix, R. Carrazedo, E. Possan, Carbonation model for fly ash concrete based on artificial neural 721
network: Development and parametric analysis, Construction and Building Materials, 266 (2021) 121050. 722
[75] Y. Kellouche, B. Boukhatem, M. Ghrici, A. Tagnit-Hamou, Exploring the major factors affecting 723
fly-ash concrete carbonation using artificial neural network, Neural Computing and Applications, 31 (2017) 724
969-988. 725
[76] J.H. Friedman, Greedy function approximation: a gradient boosting machine, Annals of statistics, 726
(2001) 1189-1232. 727
[77] J.H. Friedman, Stochastic gradient boosting, Comput. Stat. Data Anal., 38 (2002) 367-378. 728
[78] Y. Zhang, A. Haghani, A gradientboosting method to improve travel time prediction, Transportation 729
Research Part C: Emerging Technologies, 58 (2015) 308-324. 730
[79] T. Li, Q. Xia, Y. Ouyang, R. Zeng, Q. Liu, T. Li, Prospectivity and Uncertainty Analysis of Tungsten 731
Polymetallogenic Mineral Resources in the Nanling Metallogenic Belt, South China: A Comparative Study of 732
AdaBoost, GBDT, and XgBoost Algorithms, Natural Resources Research, 33 (2024) 1049-1071. 733
[80] Z. Chen, Z. Li, H. Xia, X. Tong, Performance optimization of the elliptically vibrating screen with a 734
hybrid MACO-GBDT algorithm, Particuology, 56 (2021) 193-206. 735
[81] X. Sun, M. Liu, Z. Sima, A novel cryptocurrency price trend forecasting model based on LightGBM, 736
Finance Research Letters, 32 (2020) 101084. 737
[82] G. Ke, Q. Meng, T. Finley, T. Wang, W. Chen, W. Ma, Q. Ye, T.-Y. Liu, Lightgbm: A highly efficient 738
gradient boosting decision tree, Adv. Neural Inf. Process. Syst., 30 (2017). 739
[83] W. Zhang, C. Wu, L. Tang, X. Gu, L. Wang, Efficient time-variant reliability analysis of Bazimen 740
landslide in the Three Gorges Reservoir Area using XGBoost and LightGBM algorithms, Gondwana Res, 123 741
(2023) 41-53. 742
[84] A.V. Dorogush, V. Ershov, A. Gulin, CatBoost: gradient boosting with categorical features support, 743
arXiv preprint arXiv:1810.11363, (2018). 744
Jo
urn
al
Pre-
pro
of

36
[85] L. Prokhorenkova, G. Gusev, A. Vorobev, A.V. Dorogush, A. Gulin, CatBoost: unbiased boosting with 745
categorical features, Adv. Neural Inf. Process. Syst., 31 (2018). 746
[86] G.Y. Zhao, M. Wang, W.Z. Liang, A Comparative Study of SSA-BPNN, SSA-ENN, and SSA-SVR 747
Models for Predicting the Thickness of an Excavation Damaged Zone around the Roadway in Rock, 748
Mathematics, 10 (2022). 749
[87] M. Wang, G. Zhao, W. Liang, N. Wang, A Comparative Study on the development of Hybrid SSA-RF 750
and PSO-RF Models for Predicting the Uniaxial Compressive Strength of Rocks, Case Studies in Construction 751
Materials, (2023) e02191. 752
[88] S. Opricovic, Multicriteria optimization of civil engineering systems, Faculty of civil engineering, 753
Belgrade, 2 (1998) 5-21. 754
[89] Á. Delgado-Panadero, B. Hernández-Lorca, M.T. García-Ordás, J.A. Benítez-Andrades, Implementing 755
local-explainability in gradient boosting trees: Feature contribution, Information Sciences, 589 (2022) 756
199-212. 757
[90] N. Kumar, S. Prakash, S. Ghani, M. Gupta, S. Saharan, Data-driven machine learning approaches for 758
predicting permeability and corrosion risk in hybrid concrete incorporating blast furnace slag and fly ash, 759
Asian Journal of Civil Engineering, (2024) 1-13. 760
[91] M. Kumar, M. Kumar, S. Singh, S. Kim, A. Anand, S. Pandey, S.M.M. Hasnain, A.E. Ragab, A.F. 761
Deifalla, A hybrid model based on convolution neural network and long short-term memory for qualitative 762
assessment of permeable and porous concrete, Case Studies in Construction Materials, 19 (2023). 763
[92] H. Qin, J. Wang, Probabilistic prediction model of concrete carbonation depth considering the influence 764
of multiple factors, Structural Concrete, 24 (2023) 6209-6238. 765
 766
Jo
urn
al
Pre-
pro
of

1
1. This study establishes the largest and highest-quality database for predicting carbonation depth
in fly ash concrete, consisting of 883 cases. A reliable database forms the foundation for model
accuracy.

2. This study proposes three novel hybrid ensemble learning models (SCSO-GBDT, SCSO-LGBM,
and SCSO-CatBoost) for predicting carbonation depth in fly ash concrete, offering a reliable
solution for long-term predictions.

3. The hybrid models outperform classical models (RF, BPNN, KNN, LR, and SVR) in predictive
performance (R² > 0.95) on the current dataset, demonstrating strong robustness and stability.

4. SHAP analysis of the best-performing model, SCSO-CatBoost, identified time of exposure as the
key factor influencing carbonation depth, followed by fly ash content and carbon dioxide
concentration. To facilitate practical application, a user-friendly GUI program is developed,
enabling non-algorithm engineers to use the three hybrid ensemble models effectively.
Jo
urn
al
Pre-
pro
of
Declaration of interests

☒ The authors declare that they have no known competing financial interests or personal relationships
that could have appeared to influence the work reported in this paper.

☐ The authors declare the following financial interests/personal relationships which may be considered
as potential competing interests:

Jo
urn
al
Pre-
pro
ofreplacing cement with FA accelerates carbonation [20-23]. In contrast, other studies, such as those by 52
Khunthongkeaw et al. [13], found that concrete containing 10% FA showed minimal carbonation effects. 53
They also discovered that reducing the water to cement ratio (w/b) and the percentage of FA can improve 54
carbonation rate. Atis [24] indicated that concrete with 70% FA has a higher degree of carbonation compared 55
to concrete with 50% FA replacement. Khunthongkeaw et al. [25] pointed out that the CD increases with 56
higher levels of FA, CO2, and w/b. 57
Regardless, carbonation shortens the service life of FA concrete [26, 27]. If improperly managed, 58
carbonation can lead to the damage of FA concrete, that is threats to structural integrity and overall safety [28, 59
29]. Accurate prediction of CD is crucial for evaluating structural durability, identifying risks, and 60
formulating maintenance strategies. In past studies, the CD of concrete has typically been estimated using 61
empirical formulas or theoretical models. Empirical formulas are derived by obtaining relevant data through 62
accelerated carbonation tests in the laboratory or from natural carbonation cases, followed by fitting the data 63
using mathematical statistical methods [4, 13, 30-37]. However, this method often relies on a small amount 64
of data and lacks generalizability to different environmental conditions. Theoretical models, on the other 65
hand, commonly use Fick's law to predict the carbonation process of concrete [16, 38-45], Despite this, they 66
tend to have significant errors and each parameter requires a clear physical meaning, which is not well-suited 67
to the complex mechanisms of concrete carbonation [46]. Therefore, there is a need for a more efficient and 68
effective method. 69
Recently, machine learning (ML) has become one of the most effective methods for addressing civil 70
engineering challenges [47, 48]. Numerous studies have utilized ML models to fitting carbonization 71
relationship of FAC [49-56]. For instance, Chen et al. [56] introduced a method based on weighted functions 72
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

4
to predict the CD of concrete. Liu et al. [57] explored the prediction of recycled aggregate concrete CD using 73
a combination of artificial neural network models and meta-heuristic algorithms. Biswas et al. [58] applied 74
support vector regression models combined with meta-heuristic algorithms to predict the CD of FAC. These 75
studies demonstrate the superiority of meta-heuristic algorithms. 76
However, research on the carbonation prediction of SCMs concretes (especially those with FA) remains 77
relatively sparse, with publications on this topic accounting for only 7% of all studies on concrete 78
carbonation prediction [58]. This scarcity can be attributed to the difficulty in developing a comprehensive 79
formula that considers all variables affecting CD, particularly the types and amounts of additives in the 80
concrete. The literature indicates that no studies have yet utilized meta-heuristic algorithms and ensemble 81
models to predict the CD of FAC. Furthermore, the development of ensemble learning (EL) in this field is 82
also relatively limited [60-62]. EL significantly enhances model accuracy and stability by combining the 83
predictions of multiple base learners. Compared to single ML models, EL more effectively handles data 84
noise and biases, reduces the risk of overfitting, and exhibits greater robustness and generalization ability in 85
complex problems. Recent studies have further indicated that ensemble models incorporating meta-heuristic 86
algorithms outperform traditional ensemble models [59]. 87
Therefore, this study developed three hybrid ensemble models to predict the CD of FAC. First, 883 88
cases were collected to establish the latest database, followed by statistical analysis of the data. Next, the 89
SCSO was used to find the optimal hyperparameter combinations for GBDT, LGBM, and CatBoost, 90
developing hybrid ensemble models. These models were compared with several classical models to achieve 91
the best performance. As research progresses, the number of existing models continues to increase, making 92
the development of an evaluation tool for model selection essential. This study developed the VIKOR 93
method for model selection, which yielded favorable results. Subsequently, the SHAP was applied to the best 94
hybrid ensemble model for interpretability analysis, aiding in feature selection for future research. Lastly, to 95
facilitate the application of our findings by non-algorithm engineers, we developed a user-friendly program 96
that outputs the CD of FAC based on input feature values. This study effectively predicted the CD of FAC, 97
allowing for the estimation of the lifecycle of concrete structures based on material properties and 98
environmental characteristics. This research deepens the understanding of concrete carbonation, improves 99
durability assessment, and promotes interdisciplinary innovation between EL and civil engineering. 100
2. Data analysis 101
Constructing a robust and comprehensive database is pivotal for enhancing the efficacy of model training 102
and validation. This study meticulously undertook the construction of an extensive database by integrating 103
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

5
insights from a thorough literature review. This endeavor incorporated data from 17 distinct research sources, 104
resulting in a dataset encompassing 883 case sets [13, 16, 24, 60-73]. These cases represent a broad spectrum 105
of scenarios, providing a rich collection of sample data for model training. Detailed references and pertinent 106
information about this database are enumerated in Fig. 1. 107
 108
Fig. 1. Detailed references and pertinent information about database. 109
Considering the primary factors influencing CD and the distinct characteristics of various ML models [57, 110
74, 75], this study incorporates seven variables: six inputs and one output. Detailed statistical information is 111
presented in Table 1. The input variables include binder ( B ), fly ash content ( FA ), water to binder ratio 112
( /w b ), carbon dioxide concentration ( 2CO ), relative humidity ( RH ), and time of exposure ( t ), while the 113
output variable is carbonation depth ( X ). These parameters are selected for their significant influence on the 114
carbonation process: B and FA affect the concrete's fundamental properties and pore structure; /w b 115
determines its density and porosity; 2CO and RH influence the carbonation reaction kinetics; and t 116
dictates the progression of carbonation over time. The variable t is measured in days, with a minimum of 3 117
days and a maximum of 365 days. To improve the efficiency of model training, and based on relevant 118
literature, we applied a square root transformation to t . When developing the GUI in the future, users will 119
still be able to input the time directly in days, and the transformation will be automatically applied in the 120
code to fit the model. Collectively, these variables provide a robust framework for assessing concrete CD and 121
durability. 122
Table 1. Statistics of each feature. 123
Indicator Min Median Max Mean Standard deviation
48个 (5.4%)
18个 (2%)
5个 (0.6%)
8个 (0.9%)
33个 (3.7%)
24个 (2.7%)
20个 (2.3%)
15个 (1.7%)
72个 (8.2%)
140个 (15.9%)
64个 (7.2%)
40个 (4.5%)
16个 (1.8%)
18个 (2%)
60个 (6.8%)
2个 (0.2%)
300个 (34%)
 Kellouche et al.
 Chang et al.
 Cui et al.
 Jiang et al.
 Balayssac et al.
 Rozière et al.
 Hussain et al.Younsi et al.
 Turcry et al.
 Chen et al.
 Khunthongkeaw et al.
 Huang et al.
 Gao et al.
 Zhao et al.
 Kurda et al.
 Lu et al.
 Atis et al.
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

6
B (kg/m3) 120.00 350.00 500.00 354.21 70.92
FA (%) 0.00 25.00 70.00 22.70 22.52
/w b (-) 0.28 0.46 0.65 0.46 0.09
2CO (%) 0.03 6.50 100.00 13.97 16.77
RH (%) 40.00 65.00 100.00 66.43 9.70
t (-) 1.73 5.29 23.24 6.94 4.77
X (mm) 0.00 9.80 67.20 13.20 12.75
Fig. 2 illustrates the correlation matrix and distribution of variables used in predicting CD in FAC. This 124
figure illustrates the relationships between multiple variables through a combination of scatter plot matrices, 125
histograms, and a correlation matrix. The lower-left section consists of scatter plot matrices, where the 126
scatter plots and red linear fit lines depict the relationships between pairs of variables. The diagonal displays 127
histograms, showing the distribution of each variable. The upper-right section contains a correlation matrix, 128
where the color intensity indicates the strength of the correlation, and the numerical values represent the 129
correlation coefficients. This figure provides a clear visualization of the linear relationships, distribution 130
characteristics, and interdependencies among the variables, aiding in comprehensive data analysis. 131
The correlation matrix indicates that B has a low correlation with other variables, with a particularly 132
weak negative correlation with FA and /w b . FA shows a positive correlation with X (0.27), 133
suggesting that increased FA may enhance CD. Similarly, /w b has a positive correlation with X (0.23), 134
aligning with the notion that higher /w b reduce concrete density, thereby accelerating carbonation. t 135
exhibits the strongest correlation with X (0.46), indicating that CD increases over time. The diagonal 136
histograms display the distribution of each variable, with B and /w b distributions being more 137
concentrated, while FA shows a more dispersed distribution. 2CO concentration and RH exhibit 138
relatively uniform distributions, reflecting a wide range of controlled experimental conditions. Scatter plots 139
with regression lines in the lower triangle highlight linear relationships between variables, notably the 140
positive trends between FA and X , and between /w b and X . The strong positive relationship between 141
t and X is also evident. The correlations among all features are not very strong (construct a new decision tree that corrects the residuals from the previous iteration. Unlike random forests 205
which train trees in parallel, GBDT adopts a sequential training approach where each tree's training objective 206
is to minimize the error between the predictions of the previous tree and the actual values. 207
Due to its iterative optimization approach, GBDT has gained widespread popularity across various 208
application domains. To enhance its performance in practical engineering applications, researchers [79, 80] 209
have focused on optimizing key hyperparameters. These optimizations aim to improve model accuracy and 210
applicability. A schematic diagram illustrating the working mechanism of GBDT is depicted in Fig. 5. 211
G
C

G
C

GC
 G
C
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

11
 212
Fig. 5. Architecture of GBDT algorithm. 213
3.3 Light Gradient Boosting Machine (LGBM) 214
LGBM regression is a machine learning model based on decision tree algorithms. It predicts target 215
variables by using an ensemble of decision trees, with each tree being trained on the residuals of all previous 216
trees in a gradient boosting framework [81, 82]. its iterative process helps to progressively minimize the 217
prediction error. LGBM uses a leaf-wise growth strategy for constructing trees, which involves splitting the 218
tree nodes based on leaf nodes rather than depth, allowing it to handle large-scale data more efficiently [82, 219
83]. 220
LGBM is known for its fast-training speed and efficient memory usage, making it suitable for handling 221
large datasets and high-dimensional features. The model accelerates the tree-building process with a 222
histogram-based algorithm[82], significantly improving training speed, as illustrated in Fig. 6. Additionally, 223
LGBM implements a leaf-wise growth method with constraints on depth. This approach enables faster 224
identification of the optimal split points. 225
 226
Fig. 6. Illustration of the histogram and leaf-wise growth strategies. 227
To significantly enhance training speed, LGBM employs several advanced techniques. One such technique 228
Jo
urn
al
Pre-
pro
of

12
is gradient-based one-side sampling (GOSS), which selectively retains samples with larger gradients. This 229
approach ensures that the most informative samples are prioritized during training, thereby speeding up the 230
process. Furthermore, LGBM introduces exclusive feature bundling (EFB). This method consolidates 231
mutually exclusive features into a single bundle, effectively reducing the computing time. The detail of this 232
method is advisable to consult the original research by Ke et al [82]. 233
3.4 Categorical Boosting (CatBoost) 234
CatBoost is a powerful gradient boosting algorithm, it is particularly useful for regression tasks [84, 85]. 235
Fig. 7 illustrates the fundamental principles of CatBoost. Starting with a dataset comprising N samples and 236
M features, including categorical features, CatBoost transforms these categorical features into numerical 237
values through a technique known as "weight expansion". This transformation helps in maintaining the 238
predictive power of categorical features without the need for extensive preprocessing [84]. 239
During the training phase, CatBoost develops a series of decision trees, each designed to minimize the 240
residual errors from the preceding models. Illustrated in the figure, every subsequent predictor is trained 241
using the weighted dataset from the previous step. These weights are modified to emphasize the samples that 242
were previously mispredicted, facilitating a gradual correction of the model's errors. Ultimately, the final 243
regression output is derived by averaging the weighted predictions from all the individual trees, resulting in a 244
robust and precise model that accurately captures the data's intrinsic patterns. 245
 246
Fig. 7. Explanation of the CatBoost regressor. 247
3.5 Development process of hybrid models 248
The core objective of this study is to develop hybrid ensemble models for predicting the CD in FAC. 249
Jo
urn
al
Pre-
pro
of

13
The training efficiency of these hybrid ensemble models are significantly decided by their hyperparameters. 250
Given the proficiency of meta-heuristic algorithms in addressing optimization problems, this study employs 251
the SCSO algorithm to optimize the hyperparameters of GBDT, LGBM, and CatBoost models, thereby 252
enhancing their performance and achieving superior results. The framework of the study is shown in Fig. 8, 253
and the specific steps are detailed as follows: 254
(1) Dataset Preparation: A total of 883 measured datasets were acquired from engineering cases and 255
laboratory experiments. Utilizing a random seed, the dataset was divided into a training set (80%) and a test 256
set (20%). 257
(2) Population Initialization: During the application of the SCSO algorithm, a set of hyperparameters for 258
the GBDT, LGBM, and CatBoost models was randomly generated as the initial solution. Algorithm 259
parameters were also set, predominantly using randomly generated values within specified ranges. 260
(3) Fitness Calculation: The positions of all sand cats were updated, and the fitness values of different 261
individuals within the population were calculated. The individual with the lowest fitness value represented 262
the closest approximation to the optimal solution. In this context, the fitness function was based on the 263
RMSE values derived from fivefold cross validation using the training set. 264
(4) Iterative Updating: The positions of all sand cats were continuously updated, and at each new 265
position, a new GBDT, LGBM, or CatBoost model was constructed, followed by the computation of its 266
fitness value. If the new model exhibited superior performance compared to the previous one, it was adopted 267
as the current model. Otherwise, the preceding model was retained. This iterative process persisted until the 268
maximum number of iterations was reached or a termination criterion was satisfied. 269
(5) Optimal Hyperparameters Selection: The optimal hyperparameters were used to construct GBDT, 270
LGBM, and CatBoost models, which were subsequently tested using the test set. A comprehensive 271
evaluation method and Taylor diagrams were employed to thoroughly assess the models, culminating in the 272
selection of the most suitable model. 273
(6) SHAP Analysis: Perform a SHAP value analysis on the selected optimal model to evaluate the 274
influence of each feature on the model's output. This ensures the model's interpretability and reliability. 275
(7) Prediction Program Development: Create a simple application for non-algorithm engineers to input 276
feature values and obtain the predicted CD of FAC. This will make the model's predictions accessible and 277
easy to use. 278
In conclusion, this study presents an innovative approach to optimizing the hyperparameters of GBDT, 279
LGBM, and CatBoost models through the use of the SCSO algorithm. The findings substantiate the efficacy 280
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
Influencia de parametros en la prediccion output
francisco.wong
Resaltado

14
of this method in markedly enhancing model performance. 281
 282
Jo
urn
al
Pre-
pro
of

15
Fig. 8. Hybrid SCSO-Ensemble Models. 283
3.6 Performance Evaluation method 284
There were four indexes used to evaluate the performances of the all models, namely R2, MAE, RMSE, 285
VAF [86, 87]. 286
( ) ( )
2
2 1 1 1
2 22 2
1 1 1 1
R
( ( ) )( ( ) )
n n n
i i i i
i i i
n n n n
i i i i
i i i i
n CD C CD C
n CD CD n C C
= = =
= = = =
=
− −
  
   
（ - ）
 , (10) 287
where n is thetotal sample number, iCD represents the predicted CD value, iC represents the measured 288
CD value. 289
1
1
MAE
n
i i
i
CD C
n =
= − . (11) 290
( )
2
1
1
RMSE
n
i i
i
CD C
n =
= − . (12) 291
var( )
1 100
var( )
i i
i
X CD
VAF
C
 −
= −  
 
 . (13) 292
Among the evaluation indicators, the closer the values of R2 and VAF are to 100, the better the model. The 293
closer the values of MAE and RMSE are to 0, the better the model is. 294
Selecting models solely through scoring and plotting methods can be subjective and ineffective, especially 295
when performance differences are minimal. This study introduces a comprehensive evaluation method for 296
model selection: the VIKOR method (VIsekriterijumska optimizacija i KOmpromisno Resenje), is proposed 297
by Professor Opricovic in 1998 [88]. The VIKOR method involves four main steps: determining weights, 298
calculating the ideal solution, computing group utility and individual regret values, and ranking the 299
compromise solution. 300
Step 1: Determining weights. In this study, the model evaluation metrics used are R², MAE, RMSE, and 301
VAF. For the VIKOR method, equal weights are assigned to each metric in the calculations. 302
Step 2: Calculating the ideal solution. The positive ideal solution (PIS) maximizes beneficial metrics and 303
minimizes detrimental metrics, while the negative ideal solution (NIS) minimizes beneficial metrics and 304
maximizes detrimental metrics. The formulas for calculating the ideal solutions are as follows: 305
1jp+ = , (14) 306
0jp− = , (15) 307
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

16
where
jp+ is the PIS for the thj evaluation index，
jp− is the NIS for the thj evaluation index. 308
Step 3: Computing group utility value (GU) and individual regret values (IR). GU measure 309
decision-makers' subjective preferences and biases towards gains and losses, while IR reflect the loss from 310
incorrect judgments by comparing other values to the highest value. The VIKOR method traditionally uses 311
only PIS for these calculations, overlooking the unique information in NIS. This study calculates group 312
utility and individual regret values using both PIS and NIS. The formulas are as follows: 313
Using the PIS as a Reference: 314
1
n
j ij
i j
j j j
p r
S w
p p
+
+
+ −
=
−
=
−
 , (16) 315
j ij
i j j
j j
p r
R Max w
p p
+
+
+ −
−
=
−
, (17) 316
Using the NIS as a Reference: 317
1
n
ij j
i j
j j j
r p
S w
p p
−
−
+ −
=
−
=
−
 , (18) 318
ij j
i j j
j j
r p
R Min w
p p
−
−
+ −
−
=
−
, (19) 319
The formulas for calculating the GU and IR of a solution are as follows: 320
I
i
I
S
S
S
+
−
= , (20) 321
I
i
I
R
R
R
+
−
= , (21) 322
where iS + and iR + are the GU and IR for the thi solution using the PIS as a reference, respectively. 323
Similarly, iS − and iR − are the GU and IR for the thi solution using the NIS as a reference. iS and iR324
represent the overall GU and RU for the thi solution, respectively. 325
Step 4: Calculating the compromise solution for ranking. 326
The calculation of the compromise solution combines GU and IR. The decision-making coefficient v in 327
the VIKOR method allows for the maximization of GU and the minimization of IR. A larger v indicates a 328
greater emphasis on maximizing GU and less concern for IR. The compromise solution results are ranked in 329
descending order, with lower values indicating better outcomes. 330
min min
max min max min
(1 )i i i i
i
i i i i
S S R R
Q v v
S S R R
− −
= + −
− −
, (22) 331
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado

17
where iQ is the compromise solution, and v is the decision-making coefficient. 332
4. Results and discussion 333
4.1 Parameter settings 334
The performance of models is influenced by various parameter settings. Meta-heuristic optimization 335
algorithms can directly obtain the optimal hyperparameter combinations for models, offering time-saving 336
and convenient advantages. Therefore, this study employs the SCSO to optimize the hyperparameters of 337
ensemble models. To determine the parameters for SCSO, we utilized a trial-and-error approach with 338
multiple training iterations. Specifically, we trained each base ensemble model with nine different population 339
sizes of 10, 20, 30, 40, 50, 75, 100, 150, and 200, respectively. Each model was trained for 500 iterations, 340
using the average RMSE value from fivefold cross validation on the training set as the fitness function. The 341
nine hybrid ensemble models trained for each base model are referred to as a group, resulting in a total of 342
three groups of hybrid ensemble models. Ultimately, the convergence curves of the different hybrid ensemble 343
models were calculated and are illustrated in Fig. 9. Fig. 9(a) shows the convergence curves of the nine 344
SCSO-GBDT models, Fig. 9(b) shows the convergence curves of the nine SCSO-LGBM models, and Fig. 345
9(c) shows the convergence curves of the nine SCSO-CatBoost models. It is clear from the figures that the 346
convergence curves of the SCSO-GBDT models are relatively slow, stabilizing only after approximately 250 347
iterations, with the optimal fitness values varying across different population sizes. The SCSO-LGBM 348
models converge relatively faster, stabilizing around 150 iterations, although there are differences in optimal 349
fitness values across population sizes. The SCSO-CatBoost models exhibit the best performance, with all 350
models rapidly converging and stabilizing around smaller fitness values after approximately 150 iterations. 351
Through comparative analysis of the convergence curves, it is evident that the SCSO-CatBoost model 352
performs the best, achieving rapid and stable convergence to the optimal fitness value, followed by the 353
SCSO-LGBM model, with the SCSO-GBDT model performing slightly worse. Therefore, in practical 354
applications, the SCSO-CatBoost model can be prioritized for hyperparameter optimization. 355
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

18

(a) (b)

(a): SCSO-GBDTmodels
(b): SCSO-LGBM models
(c): SCSO-CatBoost models
(c)
Fig. 9. Optimization of hybrid ensemble models for different population sizes. 356
Relying solely on the fitness curve to identify the optimal model within each group may be overly 357
simplistic. Consequently, we meticulously recorded the results of each computation, which are detailed in 358
Table 2-4. Table 2 presents the outcomes for nine SCSO-GBDT models with varying population sizes, 359
Table 3 details the results for nine SCSO-LGBM models, and Table 4 illustrates the results for nine 360
SCSO-CatBoost models, each with different population sizes. 361
To determine the optimal ensemble model within each group, we developed a comprehensive scoring 362
system. For each performance index, the model with the best value was awarded 9 points, the second-best 363
received 8 points, and models with equivalent values were given the same score. This ranking was applied 364
across four evaluation indexes. Notably, we scored the results of the training and test sets separately for each 365
model group, and the total score for each model was the sum of these scores. 366
0 100 200 300 400 500
3.30
3.35
3.40
3.45
3.50
3.553.60
3.65
3.70
F
it
n
es
s
v
al
u
e
Iteration
 Population:10 Population:20
 Population:30 Population:40
 Population:50 Population:75
 Population:100 Population:150
 Population:200
0 100 200 300 400 500
3.30
3.35
3.40
3.45
3.50
3.55
3.60
3.65
3.70
3.75
3.80
3.85
3.90
3.95
F
it
n
es
s
v
al
u
e
Iteration
 Population:10 Population:20
 Population:30 Population:40
 Population:50 Population:75
 Population:100 Population:150
 Population:200
0 100 200 300 400 500
2.95
3.00
3.05
3.10
3.15
3.20
3.25
F
it
n
es
s
v
al
u
e
Iteration
 Population:10 Population:20
 Population:30 Population:40
 Population:50 Population:75
 Population:100 Population:150
 Population:200
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado

19
Applying this methodology, we found that the highest total scores were 51 for the SCSO-GBDT model, 66 367
for the SCSO-LGBM model, and 66 for the SCSO-CatBoost model, thereby identifying the optimal model 368
within each group. Based on these findings, we set the population size to 20 for the SCSO-GBDT model, 50 369
for the SCSO-LGBM model, and 30 for the SCSO-CatBoost model. These configurations will serve as the 370
foundation for our subsequent research endeavors. 371
Table 2 Performance comparison of SCSO-GBDT models under different population sizes. 372
Population R2 Rank MAE Rank RMSE Rank VAF Rank Total
Training
10 0.9873 7 0.5488 9 1.8028 5 98.7312 6 27
20 0.9877 9 0.5543 6 1.7536 7 98.7657 8 30
30 0.9865 6 0.6966 4 1.9248 4 98.6459 5 19
40 0.9825 3 0.9417 1 2.4884 1 98.2532 2 7
50 0.9860 5 0.7288 3 1.9856 3 98.6039 4 15
75 0.9875 8 0.5797 5 1.7791 6 98.7480 7 26
100 0.9841 4 0.8626 2 2.2560 2 98.4145 3 11
150 0.9877 9 0.5513 8 1.7420 9 98.7740 9 35
200 0.9877 9 0.5520 7 1.7427 8 98.7735 9 33
Testing
10 0.9543 4 2.2077 4 10.9529 4 95.4567 1 13
20 0.9570 5 2.1102 6 10.2912 5 95.7484 5 21
30 0.9625 7 2.0852 7 8.9758 7 96.2787 8 29
40 0.9661 9 2.0277 9 8.1304 9 96.6227 9 36
50 0.9604 6 2.1162 5 9.4872 6 96.0695 6 23
75 0.9541 2 2.2362 2 10.9909 1 95.4608 2 7
100 0.9626 8 2.0504 8 8.9664 8 96.2749 7 31
150 0.9542 3 2.2360 3 10.9804 2 95.4698 3 11
200 0.9542 3 2.2386 1 10.9726 3 95.4713 4 11
 373
Table 3 Performance comparison of SCSO-LGBM models under different population sizes. 374
Population R2 Rank MAE Rank RMSE Rank VAF Rank Total
Training
10 0.9833 4 0.9163 4 2.3674 3 98.3336 3 14
20 0.9845 7 0.8512 6 2.2000 6 98.4515 6 25
30 0.9828 2 0.9468 2 2.4458 1 98.2784 1 6
40 0.9829 3 0.9526 1 2.4345 2 98.2864 2 8
50 0.9856 9 0.7838 9 2.0450 9 98.5605 9 36
75 0.9837 6 0.9016 5 2.3165 5 98.3694 5 21
100 0.9834 5 0.9234 3 2.3540 4 98.3431 4 16
150 0.9847 8 0.8415 8 2.1709 8 98.4719 8 32
200 0.9845 7 0.8506 7 2.1996 7 98.4518 7 28
Testing
10 0.9615 3 2.0905 8 9.2355 3 96.1562 3 17
20 0.9626 5 2.1162 5 8.9557 5 96.2632 4 19
30 0.9613 2 2.0896 9 9.2618 2 96.1342 2 15
40 0.9585 1 2.2342 1 9.9466 1 95.8607 1 4
50 0.9636 8 2.1083 7 8.7294 8 96.3674 7 30
75 0.9640 9 2.1322 4 8.6350 9 96.4223 9 31
100 0.9634 7 2.1362 3 8.7583 7 96.3992 8 25
150 0.9632 6 2.1152 6 8.8090 6 96.3323 6 24
200 0.9621 4 2.1712 2 9.0711 4 96.2828 5 15
 375
 376
Jo
urn
al
Pre-
pro
of

20
Table 4 Performance comparison of SCSO-CatBoost models under different population sizes. 377
Population R2 Rank MAE Rank RMSE Rank VAF Rank Total
Training
10 0.9873 9 0.6600 8 1.8084 8 98.7271 8 33
20 0.9872 8 0.6676 5 1.8115 7 98.7249 7 27
30 0.9873 9 0.6593 9 1.8079 9 98.7275 9 36
40 0.9872 8 0.6616 7 1.8115 7 98.7249 7 29
50 0.9873 9 0.6600 8 1.8084 8 98.7271 8 33
75 0.9872 8 0.6616 7 1.8115 7 98.7249 7 29
100 0.9872 8 0.6625 6 1.8130 6 98.7239 6 26
150 0.9873 9 0.6600 8 1.8084 8 98.7271 8 33
200 0.9873 9 0.6600 8 1.8084 8 98.7271 8 33
Testing
10 0.9657 8 2.0045 9 8.2087 8 96.6205 8 33
20 0.9659 9 2.0205 5 8.1772 9 96.6365 9 32
30 0.9657 8 2.0062 8 8.2147 7 96.6177 7 30
40 0.9657 8 2.0085 6 8.2207 4 96.6161 6 24
50 0.9657 8 2.0045 9 8.2087 8 96.6205 8 33
75 0.9657 8 2.0085 6 8.2200 5 96.1640 5 24
100 0.9657 8 2.0063 7 8.2156 6 96.6177 7 28
150 0.9657 8 2.0045 9 8.2087 8 96.6205 8 33
200 0.9657 8 2.0045 9 8.2087 8 96.6205 8 33
 378
The hyperparameters for the SCSO-GBDT, SCSO-LightGBM, and SCSO-CatBoost models were settled. 379
Notably, the hyperparameters of each model are tailored to optimize performance. To demonstrate the 380
effectiveness of the proposed model, we compared it against several established regression models. The 381
hyperparameters for these conventional models were fine-tuned using standard approaches, such as trial and 382
error and analysis of learning curves. Detailed parameter configurations for these models are listed in Table 383
5. 384
Table 5 Hyperparameter settings for different models. 385
Models hyprparameters value
SCSO-GBDT
n_estimators 453
learning_rate 0.0959
max_depth 99
min_samples_split 59
population size 20
Iterations 500
SCSO-LightGBM
n_estimators 360
learning_rate 0.4604
max_depth 61
min_samples_split 11
population size 50
Iterations 500
SCSO-CatBoost
learning_rate 0.2605
max_depth 4
population size 30
Iterations 500
BPNN
Number of input layer nodes 6
Number of hidden layer nodes 9
Number of output layer nodes 1
learning_rate 0.01
SVR c 60
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

21
g 0.2783
RF
n_estimators 100
max_depth 7
min_samples_split 5
KNN n_neighbors 3
 386
4.2 Analysis the performance of models 387
Based on the aforementioned study, all hybrid ensemble models and classical models have been 388
parameterized and trained according to their specific configurations. Subsequently, we utilized a randomly 389
partitioned test set to evaluate the performance of all models, with a primary focus on comparing the 390
performance of the three hybrid ensemble models. The performance of these three hybrid ensemble models 391
on the test set is illustrated in Fig. 10. In the figure, the performance on both the training and test sets for 392
each of the three models is visualized. Each subplot is annotated with the model label in the lower right 393
corner and the evaluation index values for either the training or test set in the upper left corner. Additionally, 394
a color bar is included to indicate the density of the points, with denser areas appearing in purple and sparser 395
areas in red. The figure clearly shows that most points are concentrated along the line y=x, falling between 396
y=1.1x and y=0.9x, indicating minimal differences between the actual and predicted CDs. This demonstrates 397
that the proposed three hybrid ensemble models exhibit robust performance and are suitable for predicting 398
the CD of FAC. 399
Jo
urn
al
Pre-
pro
of

22
 400
Fig. 10. Predictive performance of hybrid ensemble models. 401
To provide a more convincing comparison and highlight the necessity of the models developed in this 402
study, we introduced several classical models for comparison: Random Forest (RF), Linear Regression (LR), 403
k-Nearest Neighbors (KNN), Support Vector Regression (SVR), and Back Propagation Neural Network 404
(BPNN). These classical models have been widely applied across various fields, and their performance is 405
(a) (b)
(c) (d)
(e) (f)
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

23
well-validated. The computational results for all models are presented in Table 6. The results indicate that 406
the three hybrid ensemble models exhibit significantly superior predictive performance. Among the classical 407
models, RF also shows relatively good performance metrics, demonstrating the advantage of EL over 408
traditional ML models.409
Table 6. Performances of prediction models. 410
Model R2 MAE RMSE VAF
 Training
SCSO-GBDT 0.9877 0.5543 1.7536 98.7657
SCSO-LGBM 0.9856 0.7838 2.0450 98.5605
SCSO-CatBoost 0.9873 0.6593 1.8079 98.7275
RF 0.9116 2.6052 12.5597 91.1593
LR 0.4577 6.4206 77.0499 45.7651
KNN 0.8465 2.9762 21.8105 84.6538
SVR 0.7934 3.6857 31.1248 78.5924
BPNN 0.8026 3.5107 28.0420 80.2619
 Testing
SCSO-GBDT 0.9570 2.1102 10.2912 95.7484
SCSO-LGBM 0.9636 2.1083 8.7294 96.3674
SCSO-CatBoost 0.9657 2.0062 8.2147 96.6177
RF 0.8657 3.8197 32.1809 86.6868
LR 0.4645 8.1121 128.2978 47.2912
KNN 0.8229 4.4205 42.4321 82.4224
SVR 0.7566 4.7833 58.3084 75.8353
BPNN 0.7698 4.5613 55.1392 77.2669
 411
The Taylor diagram presents the performance indexes of various models, including classical models (SVR, 412
LR, BPNN, KNN, and RF) and the proposed hybrid ensemble models (SCSO-GBDT, SCSO-LGBM, and 413
SCSO-CatBoost), the details are shown in Fig. 11. The diagram compares these models based on their R2, 414
standard deviation, and root mean square deviation (RMSD). Among the classical models, RF demonstrates a 415
higher correlation coefficient and lower RMSD, indicating superior performance relative to other classical 416
models. The hybrid ensemble models, shown on the right side of the diagram, exhibit even higher correlation 417
coefficients and lower RMSD values, clustering closely near the reference point. This indicates that the 418
hybrid ensemble models significantly outperform the classical models, highlighting their robust predictive 419
performance. The color gradient from purple to yellow represents increasing RMSD values, with models 420
closer to the reference point exhibiting better performance. This diagram effectively demonstrates the 421
superiority of the hybrid ensemble models developed in this study. 422
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

24
 423
Fig. 11. Taylor diagrams of hybrid ensembles and classical models. 424
The performance of different models was comprehensively evaluated using the VIKOR method. From the 425
perspective of GU, the SCSO-CatBoost algorithm exhibited the lowest GU, indicating the best overall 426
performance across multiple evaluation criteria. In contrast, LR had the highest GU, suggesting relatively 427
poor comprehensive performance. IR reflect the performance loss of each algorithm under a single criterion. 428
The SCSO-CatBoost algorithm had the lowest IR, while RF and KNN had relatively higher values. The 429
compromise solution (Q), which integrates both GU and IR, also demonstrated that the SCSO-CatBoost 430
algorithm performed the best, whereas LR performed the worst. 431
In the final ranking, the SCSO-CatBoost algorithm achieved the highest position due to its excellent GU 432
and low IR, highlighting its significant advantages when multiple evaluation criteria are considered. 433
Conversely, the LR algorithm ranked the lowest due to poor performance across all evaluation criteria. Other 434
algorithms, such as SCSO-GBDT, SCSO-LGBM, RF, KNN, SVR, and BPNN, received intermediate 435
rankings based on their performance across different criteria. The results of VIKOR comprehensive 436
evaluation is shown in Table 7. 437
Table 7 Results of VIKOR comprehensive evaluation. 438
Model GU IR Q Rank
SCSO-CatBoost 0.0025 0.0022 0.0001 1
SCSO-GBDT 0.0087 0.0022 0.0031 2
SCSO-LGBM 0.0102 0.0049 0.0148 3
RF 0.1951 0.0334 0.2236 4
KNN 0.3081 0.0516 0.3543 5
BPNN 0.3930 0.0630 0.4433 6
SVR 0.4227 0.0667 0.4733 7
LR 1.0000 0.1250 1.0000 8
SVR
LR
BPNN
RF
KNN
Reference
SCSO GBDT
SCSO LGBM
SCSO Catboost
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

25
4.3 Shapley Additive explanations (SHAP) 439
SHAP is crucial for understanding the contribution and interaction of each feature in a model, providing 440
insights that enhance interpretability and improve feature selection [89]. The SHAP summary plot is shown 441
in Fig. 12. The figure indicates that t is the most influential feature on the model output, followed by FA , 442
2CO , B , /w b , and RH . Higher values of t and 2CO generally have a positive impact on the model, 443
while lower values have a negative impact. The features FA and /w b show mixed impacts, with both 444
high and low values influencing the model output in various ways. It is worth noting that while all features in 445
the model influence carbonation, t exhibits a clear positive correlation with carbonation depth, making it a 446
key predictive feature in the model. However, other variables, such as B and FA , also play important roles 447
in the carbonation process. Their effects, being more complex and nonlinear, result in a less direct impact on 448
the model’s predictions. This complexity does not diminish their significance but rather highlights the 449
intricate interactions between these factors and carbonation depth. The plot further emphasizes that 450
understanding the specific influence of each variable is crucial for interpreting model outputs and optimizing 451
feature selection. 452
 453
Fig. 12. The SHAP summary plot of SCSO-CatBoost model. 454
The parallel coordinates plot of SCSO-CatBoost model is shown in Fig. 13. The figure illustrates the 455
influence of different features on the model output. The features, listed by their influence from top to bottom, 456
include t , FA , 2CO , B , /w b , and RH . The x-axis represents the model output value ranging from -40 457
to 60, while the color bar indicates feature values, with blue for lower values and red for higher values. 458
Higher t generally lead to higher model outputs, while FA and /w b show varied impacts without a 459
clear trend. 2CO follows a pattern where lower values result in lower outputs and higher values in higher 460
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado

26
outputs. Both B and RH exhibit mixed effects, with lower values pushing outputs lower and higher 461
values pushing them higher. This visualization helps to understand the complex interactions and relative 462
importance of each feature in determining the model's predictions. 463
 464
Fig. 13. The SHAP parallel coordinates plot of SCSO-CatBoost model. 465
The SHAP interaction plot illustrates how pairs of features interact to influence the model output, the 466
detail is shown in Fig. 14. Each subplot represents the interaction between two features, with SHAP 467
interaction values ranging from -10 to 10 on the x-axis, and color-coding indicating feature values. Notable 468
observations include significant self-interactions for t , 2CO , B , and /w b . t shows strong interactions 469
with 2CO and RH , while FA interacts notably with 2CO . 2CO has strong interactions with FA and 470
RH , B interacts substantially with /w b , and RH interacts significantly with 2CO . These interactions 471
highlight the importance of considering feature pairs in model interpretation and feature selection. 472
 473
Jo
urn
al
Pre-
pro
of

27
 474
Fig. 14. The SHAP interaction plot of SCSO-CatBoost model. 475
4.4 Prediction program development and application 476
FAC is an eco-friendly material that is widely used due to its economic efficiency and environmental 477
benefits. However, the durability issues of concrete, particularly CD, significantly impact the service life of 478
structures. To provide a simple and accurate tool for non-algorithm engineers, we have developed a 479
convenient application with a GUI design based on three models from our research: SCSO-GBDT, 480
SCSO-LGBM, and SCSO-CatBoost. Through this application, users can choose any of these three ensemble 481
models for prediction. These efficient gradient boosting algorithms capture complex nonlinear relationships 482
and provide high-precision prediction results.The development of this tool not only enhances work 483
efficiency but also helps in optimizing concrete mix proportions, improving construction quality and 484
durability, while promoting the recycling of industrial waste such as FA, thus holding significant importance. 485
The GUI interface of the application is shown in Fig. 15. 486
Jo
urn
al
Pre-
pro
of

28
 487
Fig. 15. The GUI interface of the application. 488
4.5 Comparison with related studies 489
In additional, this study compared the proposed models with several advanced previous studies. We 490
selected literature with higher data scales and feature correlations for comparison. The results are shown in 491
Table 8, which lists relevant literature from the past six years. Some studies utilized data included in this 492
study's database, clearly demonstrating that the performance of the three hybrid ensemble models proposed 493
in this study improved even with the expansion of data scale. In Kumar et al.'s latest study in 2024 [90], the 494
ensemble learning models were used, yielding significant results, highlighting the trend of applying 495
ensemble learning in this field. However, their study used more features and fewer datasets, underscoring the 496
advantages of this study. 497
Table 8 Comparison with related studies. 498
Year Reference Models Number of inputs Dataset size Performance
2019 Kellouche et al.[75] ANN model 6 300 R2=0.9468
2021 Uwanuakwa et al.[52] RNN 18 534 R2=0.9400
2021 Liu et al.[57] ANN-PSO model 9 593 R2=0.9380
2021 Felix et al.[74] ANN model 6 272 R2=0.9460
2022 Biswas et al. [58]
CSO-SVR model 6 300 R2=0.9593
PSO-SVR model 6 300 R2=0.9575
SOA-SVR model 6 300 R2=0.9592
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

29
GWO-SVR model 6 300 R2=0.9585
2023 Kumar et al. [91] 1D-CNN-LSTM model 3 265 R2=0.8000
2023 Qin et al. [92] Stepwise Regression model 4 433 R2=0.9025
2024 Kumar et al. [90]
Adaboost 9 766 R2=0.9700
XGBoost 9 766 R2=0.9100
RF 9 766 R2=0.9200
2024 This study
SCSO-GBDT model 6 883 R2=0.9570
SCSO-LGBM model 6 883 R2=0.9636
SCSO-CatBoost model 6 883 R2=0.9657
 499
4.6 Research significance and limitations 500
This study has developed several explainable hybrid ensemble models for predicting carbonation depth in 501
fly ash concrete (FAC), offering significant economic benefits while advancing the understanding of 502
carbonation processes. By enhancing prediction accuracy, these models not only facilitate cost-effective 503
maintenance planning and reduce unnecessary repairs but also improve the assessment of long-term 504
structural durability. This supports better decision-making in infrastructure design and maintenance. 505
Additionally, the models enable engineers and researchers to evaluate the effects of varying environmental 506
conditions, material compositions, and exposure durations on carbonation progression, leading to more 507
accurate risk assessments. Ultimately, this research contributes to the sustainability and resilience of concrete 508
structures, ensuring their safety and functionality over extended lifecycles while delivering substantial 509
economic savings across large-scale construction and maintenance projects. 510
While the study has yielded promising results, the models developed are currently best suited for 511
predicting the carbonation depth of FAC. Future research should focus on expanding and refining the 512
database by incorporating carbonation cases from various types of concrete, different geographical locations, 513
and diverse environmental conditions. Numerical simulations could offer a viable method to augment the 514
dataset, thereby improving the models' generalization and applicability. Moreover, further exploration of 515
methods combining different features and examining various data partitioning ratios are areas that have yet 516
to be fully explored in this study. 517
Overall, the three hybrid ensemble models proposed in this study demonstrate strong performance and are 518
well-suited for predicting the carbonation depth of FAC. This provides a valuable tool for assessing the 519
durability of engineering structures and contributes to more efficient lifecycle management. 520
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

30
5. Conclusions 521
The phenomenon of carbonation is one of the key factors in the deterioration of concrete structures, 522
significantly impacting their durability and lifespan. Although FA, an industrial byproduct, is widely used in 523
engineering projects due to its environmental and economic benefits, it also affects the carbonation process 524
of concrete. Therefore, it is crucial to develop a model that can accurately predict the CD of FA containing 525
concrete. Such a model would not only provide a scientific basis for the safety assessment of actual 526
engineering projects but also assist engineers and decision-makers in understanding the long-term 527
performance changes in concrete. Furthermore, it would offer valuable guidance for determining the optimal 528
timing for repair and reinforcement, ensuring that concrete structures maintain a high level of safety and 529
stability throughout their lifecycle. 530
(1) This study began by compiling and organizing data from extensive literature on indoor accelerated 531
carbonation tests and natural carbonation cases, resulting in the creation of a reasonable, stable, and reliable 532
database. This comprehensive database includes 883 cases, making it the most extensive carbonation 533
database for FAC in current research. 534
(2) Three hybrid ensemble models were developed: SCSO-GBDT, SCSO-LGBM, and SCSO-CatBoost. 535
The performance of these models was thoroughly evaluated using four metrics: R², MAE, RMSE, and VAF. 536
The evaluation results demonstrated the superiority of these hybrid ensemble models in this field. Five 537
classical models (RF, BPNN, KNN, LR, and SVR) were introduced for comparison. The proposed hybrid 538
ensemble models exhibited significant advantages over these classical models. Additionally, the RF model 539
highlighted the superiority of ensemble learning over traditional machine learning models. 540
(3) This study developed an innovative model preferred method, combining VIKOR with Taylor 541
diagrams to select the optimal model from multiple candidates. The method objectively addresses the 542
challenge of minimal differences in performance indexes when models exhibit similar performance. As the 543
field of artificial intelligence advances and the number of models increases, the method proposed in this 544
study offers an effective means for model selection. Using this method, it was determined that 545
SCSO-CatBoost is the most suitable model for predicting the CD of FAC. The next best models, in order, are 546
SCSO-GBDT, SCSO-LGBM, RF, KNN, BPNN, SVR, and LR. 547
(4) A SHAP analysis was conducted on the best-selected model, SCSO-CatBoost, revealing that t is 548
the key factor influencing carbonation, followed by FA and 2CO . This insight provides valuable 549
recommendations for future feature selection. To facilitate the application of these research findings by 550
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado
francisco.wong
Resaltado

31
non-algorithm engineers, a program with a user-friendly GUI was developed. This allows users to utilize the 551
three developed hybrid ensemble models. By combining the results of these models, it is possible to estimate 552
the CD of FAC, enabling early reinforcement measures and ensuring the sustainable application of buildings.553
In the future, we will focus on significantly expanding our high-quality database, with a particular 554
emphasis on natural carbonation cases, and aim to apply these findings to a wider range of concrete types 555
and scales. Additionally, we plan to explore the use of numerical simulation techniques for building the 556
database, as a large-scale, high-quality dataset will be essential for strengthening the application of deep 557
learning methods. We also intend to further develop the GUI, adding more functionalities to enable 558
predictive modeling for different types of concrete. Lastly, we will compare various intelligent optimization 559
algorithms and data partitioning strategies to further enhance the model’s accuracy.560
Jo
urn
al
Pre-
pro
of
francisco.wong
Resaltado

32
References 561
[1] K. Zhang, K. Zhang, R. Bao, X. Liu, A framework for predicting the carbonation depth of concrete 562
incorporating fly ash based on a least squares support vector machine and metaheuristic algorithms, Journal of 563
Building Engineering, 65 (2023). 564
[2] B. Bennett, P. Visintin, T. Xie, Global warming potential of recycled aggregate concrete with 565
supplementary cementitious materials, Journal of Building Engineering, 52 (2022). 566
[3] F. Aslani, M. Dehestani, Probabilistic impacts of corrosion on structural failure and performance limits 567
of reinforced concrete beams, Construction and Building Materials, 265 (2020) 120316. 568
[4] S. Hussain, D. Bhunia, S.B. Singh, Comparative study of accelerated carbonation of plain cement and 569
fly-ash concrete, Journal of Building Engineering, 10 (2017) 26-31. 570
[5] D.E.A. Ramirez, G.R. Meira, M. Quattrone, V.M. John, A review on reinforcement corrosion 571
propagation in carbonated concrete–Influence of material and environmental characteristics, Cem. Concr. 572
Compos., (2023) 105085. 573
[6] Y. Pu, L. Li, Q. Wang, X. Shi, C. Luan, G. Zhang, L. Fu, A.E.-F. Abomohra, Accelerated carbonation 574
technology for enhanced treatment of recycled concrete aggregates: A state-of-the-art review, Construction 575
and Building Materials, 282 (2021) 122671. 576
[7] L. Peng, P. Shen, C.-S. Poon, Y. Zhao, F. Wang, Development of carbon capture coating to improve the 577
durability of concrete structures, Cem. Concr. Res., 168 (2023) 107154. 578
[8] T.L.P. Ortolan, P.M. Borges, L. Silvestro, S.R. da Silva, E. Possan, J.J. de Oliveira Andrade, Durability of 579
concrete incorporating recycled coarse aggregates: carbonation and service life prediction under 580
chloride-induced corrosion, Construction and Building Materials, 404 (2023) 133267. 581
[9] R. Rumman, M.R. Kamal, T. Manzur, M.A. Noor, Optimum proportion of fly ash or slag for resisting 582
concrete deterioration due to carbonation and chloride ingress, Structures, 41 (2022) 287-305. 583
[10] Y. Liu, J. Shi, Recent progress and challenges of using smart corrosion inhibitors in reinforced concrete 584
structures, Construction and Building Materials, 411 (2024) 134595. 585
[11] H.-J. Ho, A. Iizuka, E. Shibata, H. Tomita, K. Takano, T. Endo, Utilization of CO2 in direct aqueous 586
carbonation of concrete fines generated from aggregate recycling: Influences of the solid–liquid ratio and CO2 587
concentration, Journal of Cleaner Production, 312 (2021) 127832. 588
[12] C. Chen, G. Habert, Y. Bouzidi, A. Jullien, Environmental impact of cement production: detail of the 589
different processes and cement plant variability evaluation, Journal of cleaner production, 18 (2010) 478-485. 590
[13] J. Khunthongkeaw, S. Tangtermsirikul, T. Leelawat, A study on carbonation depth prediction for fly ash 591
concrete, Construction and building materials, 20 (2006) 744-753. 592
[14] X.-Y. Wang, Design of low-cost and low-CO2 air-entrained fly ash-blended concrete considering 593
carbonation and frost durability, Journal of Cleaner Production, 272 (2020) 122675. 594
[15] A.F. Ahmed, Experimental investigation of waste rubber admixtures in concrete, Mesopotamian 595
Journal of Civil Engineering, 2023 (2023) 1-9. 596
[16] L. Jiang, B. Lin, Y. Cai, A model for predicting carbonation of high-volume fly ash concrete, Cem. 597
Concr. Res., 30 (2000) 699-702. 598
[17] T. Chen, M. Bai, X. Gao, Carbonation curing of cement mortars incorporating carbonated fly ash for 599
performance improvement and CO2 sequestration, Journal of CO2 Utilization, 51 (2021) 101633. 600
[18] J.-s. Zhang, M. Cheng, J.-h. Zhu, Carbonation Depth model and prediction of hybrid fiber fly ash 601
concrete, Advances in Civil Engineering, 2020 (2020) 9863963. 602
[19] V.Q. Tran, H.-V.T. Mai, Q.T. To, M.H. Nguyen, Machine learning approach in investigating 603
carbonation depth of concrete containing fly ash, Structural Concrete, 24 (2023) 2145-2169. 604
[20] N. Bouzoubaâ, A. Bilodeau, B. Tamtsia, S. Foo, Carbonation of fly ash concrete: laboratory and field 605
data, CaJCE, 37 (2010) 1535-1549. 606
Jo
urn
al
Pre-
pro
of

33
[21] K. Sisomphon, L. Franke, Carbonation rates of concretes containing high volume of pozzolanic 607
materials, Cem. Concr. Res., 37 (2007) 1647-1653. 608
[22] P. Sulapha, S. Wong, T. Wee, S. Swaddiwudhipong, Carbonation of concrete containing mineral 609
admixtures, J. Mater. Civ. Eng., 15 (2003) 134-143. 610
[23] D. Ho, R. Lewis, Carbonation of concrete and its prediction, Cem. Concr. Res., 17 (1987) 489-504. 611
[24] C.D. Atiş, Accelerated carbonation and testing of concrete made with fly ash, Construction and 612
Building Materials, 17 (2003) 147-152. 613
[25] J. Khunthongkeaw, S. Tangtermsirikul, Model for simulating carbonation of fly ash concrete, J. Mater. 614
Civ. Eng., 17 (2005) 570-578. 615
[26] S. Ekolu, Implications of global CO2 emissions on natural carbonation and service lifespan of concrete 616
infrastructures–reliability analysis, Cem. Concr. Compos., 114 (2020) 103744. 617
[27] L. Chen, R.K.L. Su, Service life modelling of carbonated reinforced concrete with supplementary 618
cementitious materials considering early corrosion propagation, Construction and Building Materials, 413 619
(2024) 134861. 620
[28] G. Chen, Y. Lv, Y. Zhang, M. Yang, Carbonation depth predictions in concrete structures under 621
changing climate condition in China, Eng. Failure Anal., 119 (2021) 104990. 622
[29] W.Z. Taffese, E. Sistonen, J. Puttonen, CaPrM: Carbonation prediction model for reinforced concrete 623
using machine learning methods, Construction and Building Materials, 100 (2015) 70-82. 624
[30] P. Liu, Z. Yu, Y. Chen, Carbonation depth model and carbonated acceleration rate of concrete under 625
different environment, Cem. Concr. Compos., 114 (2020) 103736. 626
[31] P. Woyciechowski, P. Woliński, G. Adamczewski, Prediction of Carbonation Progress in Concrete 627
Containing Calcareous Fly Ash Co-Binder, Materials, 12 (2019) 2665. 628
[32] V. Carević, I. Ignjatović, J. Dragaš, Model for practical carbonation depth prediction for high volume 629
fly ash concrete and recycled aggregate concrete, Construction and Building Materials, 213 (2019) 194-208. 630
[33] K. Zhang, J. Xiao, Prediction model of carbonation depth for recycled aggregate concrete, Cem. Concr. 631
Compos., 88 (2018) 86-99. 632
[34] S.C. Paul, B. Panda, Y. Huang, A. Garg, X. Peng, An empirical model design for evaluation and 633
estimation of carbonation depth in concrete, Measurement, 124 (2018) 205-210. 634
[35] L. Czarnecki, P. Woyciechowski, Concrete carbonation as a limited process and its relevance to 635
concrete cover thickness, ACI Mater. J., 109 (2012) 275. 636
[36] A. Silva, R. Neves, J. de Brito, Statistical modelling of carbonation in reinforced concrete, Cem. Concr. 637
Compos., 50 (2014) 73-81. 638
[37] I. Monteiro, F.A. Branco, J.d. Brito, R. Neves, Statistical analysis of the carbonation coefficient in open 639
air concrete structures, Construction and Building
