A comprehensive guide to
extracellular vesicle counting,
size determination, and
characterization
How flow cytometry enables sensitive,
consistent, and flexible EV analysis
Flow cytometry enables sensitive, consistent, and flexible EV analysis:
• EVs mediate cell-cell communication in the human body.
Studying them can help researchers understand and
characterize physiological mechanisms as well as diseases, and
develop new treatments.
• To thoroughly understand EVs, researchers must be able to
quantify them with count and concentration, determine their
size and characterize them.
• Many techniques can be used to analyze EVs, including
some that can provide a combination of counting, size and
characterization - but each has drawbacks.
• Nanoscale flow cytometry is emerging as a tool to bring
depth, efficiency, and quality to EV research, enabling analysis
of even small EVs.
INTRODUCTION
Accelerating answers
2
Contents
1. Introduction
2. EVs: A goldmine of information
3. How to count and characterize EVs
4. Simplify EV analysis with multi-measurement platforms
5. The growing promise of flow cytometry
6. Nanoscale flow cytometry: Bring clarity to EV analysis
3
01 Introduction
What are EVs and why is it
important to study EVs?
Extracellular vesicles, or EVs, are lipid bound vesicles, secreted by cells into the extracellular space. They are
carriers of biologically active molecules and can travel to different targets to execute specific biological functions.
The term EV refers to a broad range of carriers that were previously classified into three groups depending on
their cellular origin — exosomes, microvesicles, and apoptotic bodies. However, there is not yet a consensus on EV
subtypes, such as exosomes. As a result, nomenclature is being steered towards operational terms that refer to :1
• Their physical characteristics, such as size and density
 - Small EVs: 200 nm
 - Low, medium, or high density EVs
• Biochemical composition, for example CD9+, CD63+, CD81+ EVs, RNA, lipids, etc...
• Descriptions of conditions or cell of origin — podocyte EVs, for instance
EVs are found throughout the human body, including in the brain, eyes, lungs, and reproductive organs, as well
as in the circulatory, digestive, and urinary systems. Owing to this ubiquity, and their ability to mediate cell-cell
communication and help maintain homeostasis, EVs offer deep insights to those who study them. Crucially, they
provide insights about the health and disease profile of their cell and organ of origin, making it easier to diagnose
and characterize diseases. What’s more, EVs are an ideal candidate for novel drug delivery methods in areas such
as oncology.
As researchers in a range of fields realize the potential value of better understanding EVs, it is vital they get as
much information from them as possible — which requires using the most appropriate tools.
APPLICATION NOTES & CASE STUDIES
• INTO THE WORLD OF EXTRACELLULAR VESICLES (EVs)
Extracellular vesicles (EVs) are non-replicating structures surrounded by a lipid bilayer that are naturally
released by all cell types. These tiny particles have become a subject of great interest for scientists
worldwide, who seek to understand their biological roles and explore their potential as therapeutic cargo.
By unraveling the heterogeneity of EVs, we can enhance our understanding of cell-to-cell communication
and gain insights into the role they may play in various diseases. This document aims to provide you with
essential information about EVs and shed light on why they have emerged as crucial entities in the fields
of biology, immunology, virology, oncology, microbiology, and more.
4
To prepare EVs for analysis, they must be isolated by one of several approaches. Ultracentrifugation is
the gold standard for EV isolation, as it can reproducibly isolate specific subpopulations of EVs. Additionally,
researchers can use density modifiers to increase purity, making it a highly effective technique. Size-exclusion
chromatography (SEC), which separates particles by size, is also a viable option, and is particularly strong at
removing high-abundance proteins.
Newer approaches have emerged that simultaneously concentrate and purify the sample. Tangential flow
filtration, for example, is growing in popularity as a rapid, reproducible, and scalable EV purification approach.
Another method, dielectrophoresis, can achieve high purity, recovery, and throughput, and is compatible with
multiple applications including immunochemistry and mass spectrometry.
Preparation is key
01 Introduction
5
CELL CULTURE
Cultivate productive sources
of extracellular vesicles with
automated cell culture, viability
measurements, and media
analysis.
SEPARATION
FROM CELLS, MEDIA
Efficiently refine culture
supernatant and separate
desirable microparticles
from debris and large
particulates.
PURIFICATION
Flexibly purify the desired
size and density of extracellular
vesicle from a heterogeneous sample.
Customizable protocols can be fit
to your specific needs.
 VESICLE ANALYSIS
Discover the potential of your
purified extracellular vesicles:
perform small particle analyses
to study physical characteristics,
and extract RNA to understand
 vesicle cargo.
After purification, EVs are ready for analysis — but this can be challenging for three key reasons:
• Size: Small EVs are difficult to resolve from noise, so often require specialized tools.
• Heterogeneity: Particles have broad size ranges and variation in cargo, which need accurate
characterization.
• Lack of standardization: There are limited reference materials or standardized measurement systems for
EV composition determination, and few standard cell-based platforms to produce EVs. Additionally, the EV
research community has not yet reached any consensus on standardization, further exacerbating the issue.
The EV research community is taking steps to try to improve EV analysis. The International Society for Extracellular
Vesicles (ISEV), for example, has tried to overcome a lack of standardization by publishing guidelines for
Minimal Information for Studies of Extracellular Vesicles (MISEV), which have been created using feedback
compiled from ISEV expert task forces and more than 1000 researchers.1, 2 However, getting the data needed to
meet standardization guidelines often requires specialized techniques. Without them, researchers may obtain
inconclusive and non-reproducible results, which will ultimately stall scientific breakthroughs.
To gain true understanding of EVs, accurate, precise, and reproducible techniques are vital. Thankfully, the field is
continually and rapidly evolving, and powerful ways to analyze EVs — such as nanoscale flow cytometry — are on
the horizon.
The complexities of
EV analysis
By the end of this eBook,
you will understand:
• What information about EVs is useful to obtain
• The techniques available to analyze EVs, and their
strengths and limitations
• How nanoscale flow cytometry is emerging as a useful
tool for EV analysis
01 Introduction
6
A goldmine of information
EVs contain a wealth of information just waiting to be extracted. Researchers can gather single particle data,
where they analyze each EV individually for a more detailed, granular picture. However, bulk methods can also
provide detailed insights into a biological system.
Ultimately, whether performing bulk
or single analysis, there are three key
goals that researchers wants to reach —
EV concentration, size determination
and EV characterization.

Key takeaways
To get deeper insights from EVs, researchers must:
• Count:
 Ascertain how many EVs there are per sample
• Determine their size:
 Calculate individual EV size and distribution
• Characterize:
 Determine cargo composition of each EV02 EVs: A goldmine of information
7
In EV counting, researchers determine the number of EVs per sample. Counting is highly useful for biomarker
discovery and disease diagnosis, as it can be used to determine physiological activity in the cellular and
organ systems where the EVs originated.
The measurement can also help researchers monitor disease progression and therapeutic efficacy, too.
For example, increased EV levels may show disease progression, whereas a decrease may indicate a positive
response to therapy.
Determine count and
concentration
02 EVs: A goldmine of information
Size determination
APPLICATION NOTES & CASE STUDIES
• History of EV Research & Methods
THE DISCOVERY OF EXTRACELLULAR VESICLES (EVs):
TRACING THE JOURNEY FROM INCEPTION TO PRESENT DAY

Researchers also need to characterize the EV itself and identify protein cargo. Analyzing EVs in this way helps
researchers achieve three important goals:
• Understand EV biological functions: Decipher specific messages/signals that EVs carry between cells.
• Diagnose diseases: Uncover disease-specific molecules (DNA, RNA, microRNAs etc.) in cargo.
• Investigate therapeutic potentials: Discover EV composition and ensure they provide precise/consis-
tent dosing when used therapeutically.
Characterization
8
When working with EVs, researchers usually deal with polydisperse samples. By measuring EV size, it is possible
to differentiate between different subtypes, helping better understand their origin/function. It can also help them
determine size distribution, which is vital to understand physiological or pathological conditions. And finally,
measuring EV size is pivotal to standardization and quality control of EV preparations, which is particularly useful
for therapeutic applications.
03 How to count and characterize EVs
Size determination
Characterization
9
ELISA: Analyze cargo and determine heterogeneity
Strengths

✔ Compatible with a range of samples
✔ High resolution
✔ High specificity
✔ Quantitative
✔ Reproducible
✔ Simple to perform
Count
Characterization
Many approaches to count and characterize EVs and determine their sizes exist, each having its own strengths
and limitations. In this chapter, we explore the different methods available to researchers to either count or
characterize EVs as described in Chapter 2.
Spectrophotometry: Quantifying EVs
Strengths

✔ High resolution
✔ High sensitivity
✔ Simple to perform
✔ Requires no other reagents
Limitations
x Affected by impurities
x Indirect (measures protein content in
μg/mL, but not EV concentration)
x Low throughput
EVs
Limitations
x Limited dynamic range
x Sample preparation can alter protein
structure, affecting accuracy
x Target-dependent
Mass spectrometry-based proteomics: Analyze cargo in bulk
Strengths
✔ Can identify protein aggregates
 and contaminants
✔ High resolution
✔ High specificity and sensitivity
✔ High throughput
Immunoblotting/SDS-PAGE: Identify cargo in bulk
Strengths
✔ Compatible with small volumes
✔ Cost-effective
✔ Multiplexing capabilities
✔ High specificity and sensitivity
✔ Rapid turnaround time
✔ Simple to perform
03 How to count and characterize EVs
Characterization
EVs
10
EV array and bead capture: Use for protein profiling/phenotyping
Strengths

✔ Easy to perform
✔ High throughput
✔ Multiplexing capabilities
✔ High sensitivity
Limitations
x Biased by dependency on tetraspa-
nin or other singular affinity site
x Difficult to standardize
x Doesn’t define true EV heterogenei-
ty (array consists of one marker per
bead)
x Limited to known targets
Limitations
x Complex sample preparation
x Limited quantifiability
x Potential for antibody cross-reactivity
x Prone to variability
Limitations
x Complex data analysis
x Difficult to detect/quantify low ab-
undance components in complex
samples
x Expensive
x Long run time per sample
x Requires larger sample volume
Analyzing one aspect of
EVs at a time: effective but
complicated
Many techniques are available to count or characterize EVs, each with its own strengths. However, they also have
their own limitations, which need to be carefully assessed and balanced in line with research aims. What’s more, as
each technique only provides one type of measurement, researchers will need to combine multiple approaches to
get the EV data they need — which can be complex, time-consuming, and costly. There are, however, techniques
that provide multiple measurements, simplifying EV analysis, which are explored in Chapter 4.

Key takeaways
• Researchers can use spectrophotometry to count EVs
indirectly, but it is affected by impurities
• Many techniques are available to characterize EVs, but
each has its own drawbacks that need to be considered
• Methods that obtain multiple measurements can
 simplify EV analysis
Mass spectrometry-based proteomics: Analyze cargo in bulk
Strengths
✔ Can identify protein aggregates
 and contaminants
✔ High resolution
✔ High specificity and sensitivity
✔ High throughput
Immunoblotting/SDS-PAGE: Identify cargo in bulk
Strengths
✔ Compatible with small volumes
✔ Cost-effective
✔ Multiplexing capabilities
✔ High specificity and sensitivity
✔ Rapid turnaround time
✔ Simple to perform
03 How to count and characterize EVs
11
EV array and bead capture: Use for protein profiling/phenotyping
Strengths

✔ Easy to perform
✔ High throughput
✔ Multiplexing capabilities
✔ High sensitivity
Analytical ultracentrifugation (AUC):
Isolate EVs, quantify them, and measure size, heterogeneity, and shape
Strengths

✔ Can be analyzed during the same step
✔ Good for broad size ranges
✔ High resolution
✔ Wide range of data obtained
Resistive pulse sensing:
Quantify and determine size profile of single EV particles
Strengths

✔ Compatible with small volumes
✔ Cost-effective
✔ Multiplexing capabilities
✔ High specificity and sensitivity
✔ Rapid turnaround time
✔ Simple to perform
04
Rather than needing to perform different techniques for the analyses needed, some methods allow you to obtain
multiple measurements at once. For instance, many systems can be used to both quantify EVs and determine their size.
12
Limitations
✘ Difficult to analyze highly heterogeneous samples
✘ Relatively high upfront cost
Limitations
✘ Complex sample preparation
✘ Limited quantifiability
✘ Potential for antibody cross-reactivity
✘ Prone to variability
Quantification and size measurements
Transition electron microscopy (TEM):
Quantify EV and measure their size. Individual EVs can be counted in micrographs to determine concentration.
Strengths

✔ Can elucidate specific EV features (e.g., surface proteins)
 when used with immunolabelling
✔ Direct visualization
✔ High resolution (can see detailed morphology of individual EVs)
✔ High sensitivity
* The sample section analyzed may not represent the whole EV population.
Limitations
✘ Access limitations
✘ High running costs
✘ Laborious sample preparation, making it low
throughput and challenging to standardize
✘ Potential bias*
Simplify EV analysis with
multi-measurement platforms
04
13
Simplify EV analysis with
multi-measurement platforms
Simplify EV analysis with
multi-measurement platforms
Super-resolution microscopy (SRM):
Determine EV size and enables detection and quantification of single proteins and nucleic acids at the
sub-vesicular level.
Strengths

✔ Accurate
✔ High resolution
✔ Precisely images/analyzes EVs in cells or solution
✔ Uses low sample volume
* The sample section analyzed may not represent the whole EV population.
As well as quantifying and determining the size of EVs, some techniques can characterize them, too.
Combined quantification, size profiling,
and characterization
Nanoparticle tracking analysis (NTA):
Measure EV size and concentration. Enables phenotyping with limitations.
Strengths

✔ Allows real-time visualization
✔ High sensitivity✔ Rapid turnaround time
✔ Relatively wide dynamic range
✔ Simple to perform
* The right concentration is essential for accurate results. † Larger particles more strongly influence the profile obtained. ‡ NTA uses Brownian motion and cannot see all
Limitations
✘ Laborious sample preparation*
✘ Less reproducible owing to time/test and operator
variation
✘ Poor results for polydisperse suspensions†
✘ Requires high concentration
✘ Uses estimates‡
Limitations
✘ Complex sample preparation
✘ Manual process-heavy, limiting speed and throughput
✘ No size distribution analysis
✘ Potential bias*
Dynamic Light Scattering (DLS):
Determine EVs size and size distribution.
Strengths

✔ Low hands-on time
✔ Low running costs
✔ Low sample volume required
✔ Measures a wide range of particle sizes
✔ Rapid turnaround
✔ Simple to perform
* The sample section analyzed may not represent the whole EV population.
Limitations
✘ Poor results for polydisperse suspensions*
✘ Low resolution
Simpler EV analysis
requires a trade-off
14
04
Simplify EV analysis with
multi-measurement platforms
Researchers can potentially reduce instrumentation and reagent costs, save time, and simplify their EV analysis
by determining size and quantity using the same instrument. Both SRM and DLS can characterize, count and
determine the size of EVs, making them highly useful techniques.
However, these methods also have drawbacks. Not only is SRM low throughput, for example, but it is time-
consuming — despite the many types of data it can obtain. DLS has a quicker turnaround time than SRM, but the
resolution is poorer, and it isn’t as effective when there are a range of particle sizes.
So, is there a more optimal technique available, where researchers don’t have to make a trade-off between
throughput and resolution? Flow cytometry may be the answer, providing higher resolution and higher throughput
— even for polydisperse samples.
 Key takeaways
• Multi-measurement platforms can simplify EV analysis,
combining multiple approaches in one system
• Both DLS and SRM can count, quantify, and
 characterize EVs
• DLS is simple-to-use and rapid, but is lower resolution
and only suitable for monodisperse samples
• SRM offers higher resolution, but has limited
 throughput and risks potential bias
While flow cytometry is a well-established technique for analyzing cells and particles, it is currently underused for
EV analysis, yet it can count, determine the size of, and characterize EVs. So how does it work?
Flow cytometry detects and measures the physical and chemical characteristics of a particle by measuring
fluorescence intensity produced by fluorescently labeled antibodies specific to proteins on or in the EVs.
Accordingly, researchers can obtain detailed characterization by identifying specific subsets and assessing cargo.
Flow cytometry brings
three benefits to EV
research: depth,
efficiency, and
quality.
Confidential - Company Proprietary
mLV Diameter (nm)
(RI 1.455)-H
Polystyrene (nm)-H Violet SSC-HViolet SSC-H
C
ou
nt
C
ou
nt
FI
TC
-H
FI
TC
 M
ES
F-
A
80, 100, 150 and 300 nm beads mixed rEV GFP 1/200 dilution
05 How to count and characterize EVs
15
Depth
• Compatible with
 limited sample sizes
• High sensitivity
• Single-particle
 resolution
Efficiency
• High throughput*
• Rapid turnaround
(hours)
• Simultaneous
 multi-parametric data
collection
Quality
• High dynamic
range and precision,
to characterize hete-
rogeneous and poly-
disperse samples
• Quantitative data
• Reproducible
*Flow cytometry can measure thousands of events per second.
Despite all its strengths, flow cytometry has one significant drawback: it does not provide precise size
measurements for EVs lower than 100 nm. It is also important to note that when using positive or negative
pressure, the flow cytometer needs a hall sensor to accommodate a counting estimate.
“While traditional flow cytometry has many strengths,
it does not provide precise size measurements
for EVs lower than 100 nm”
Flow Cytometry
Key takeaways
• Flow cytometry brings depth, efficiency, and quality
 to EV research
• The technique doesn’t provide precise measurements
for smaller EVs
• Nanoscale flow cytometry is emerging as a tool
 to help researchers analyze smaller EV subpopulations
Nanoscale flow cytometry is emerging as an alternative to traditional flow cytometry for EV analysis. While
it is built on similar principles to flow cytometry, as the name implies, nanoscale flow cytometry works on
the nanoscale — making it ideal for analyzing small EVs. With nanoscale flow cytometry, researchers could
reproducibly:
• Fully characterize diverse EVs
• Accurately quantify, measure, and identify EV subpopulations
• Obtain robust and high-quality data, even for small EVs
So far, this promising technology is not yet widely adopted. However, new advances are continually happening,
and highly sensitive, consistent, and flexible nanoscale flow cytometers will soon be within reach. To get the most
from nanoscale flow cytometry, researchers will need a system that can simultaneously count, measure,
and identify EV subpopulations below 100 nm.
“New advances are happening all the time, and highly sensitive,
consistent, and flexible nanoscale flow cytometers
will soon be within reach”
Characterization
16
05 How to count and characterize EVs
EVs play a vital role across the human body, and their precise, sensitive, and reproducible analysis is key to better
understanding and characterizing diseases and developing innovative therapies. Many techniques can be used
to analyze EVs: from single parameter characterization using ELISA, to multi-measurement platforms such as DLS
and SRM. However, most existing technologies require researchers to make a trade-off, whether it is throughput,
accuracy, or resolution.
With flow cytometry, researchers can quickly, accurately, and reproducibly count, determine the size of, and
characterize EVs at high throughput. And soon, nanoscale flow cytometry will redefine what it is
possible to achieve, allowing characterization of even small EVs. Armed with this technology,
researchers will be able to unlock new insights into biological systems, such as the detection and characterization
of biomarker EVs in liquid biopsy samples — making it quicker and simpler to advance understanding in areas such
as health and disease than ever before.
Interested in learning how to advance
your EV research? Whether you have
questions or are interested in a demo,
we’re here to help.
 TALK TO AN EXPERT

06
17
Characterization
Nanoscale flow cytometry:
Bring clarity to EV analysis
beckman.com
2024-GBL-EN-104736-v1
Unveil the full picture of your EV experiment with the CytoFLEX
nano flow cytometer. With the ability to count, size, and characterize
EVs using a single technique, it propels your research forward.
Experience greater sensitivity, consistent instrument performance,
and flexibility to study your sample. With the CytoFLEX nano flow
cytometer, we have lowered the limits of detection, so you can
achieve more.
beckman.com
Breaking the boundries of EV detection
SHIFT PERSPECTIVE.
ACHIEVE MORE.
For Research Use Only. Not for use in diagnostic procedures.
© 2024 Beckman Coulter, Inc. All rights reserved. Beckman Coulter, the stylized logo, and the Beckman Coulter
product and service marks mentioned herein are trademarks or registered trademarks of Beckman Coulter,
Inc. in the United States and other countries.
1 Théry C, Witwer KW, AikawaE, et al. Minimal information for studies
of extracellular vesicles 2018 (MISEV2018): A position statement of
the International Society for extracellular vesicles and update of the
MISEV2014 guidelines. Journal of Extracellular Vesicles. 2018;7(1). doi:1
0.1080/20013078.2018.1535750
2 Welsh JA, Goberdhan DC, O’Driscoll L. Minimal information for
studies of extracellular vesicles (MISEV2023): From basic to advanced
approaches. Journal of Extracellular Vesicles. 2024 Feb;13(2):e12404.
doi: 10.1002/jev2.12404.
https://www.beckman.com/flow-cytometry/research-flow-cytometers/cytoflex-analyzer-platform/cytoflex-nano-2024
18
THE DISCOVERY OF
EXTRACELLULAR VESICLES (EVs):
TRACING THE JOURNEY
FROM INCEPTION TO
PRESENT DAY
1. UNVEILING THE
SECRETS OF BLOOD
CLOTTING: THE EARLY
DAYS OF EV RESEARCH
Chargaff: During his work to establish a
centrifugation protocol for separating clotting
factors from cells, Chargaff observed that
“the addition of the high-speed sediment to
the supernatant plasma brought about a very
considerable shortening of the clotting time.”
1945
Wolf: Wolf’s work involved the identification of
platelet dusts, which he described as a “material
in minute particulate form, sedimentable by
high-speed centrifugation and originating
from platelets but distinguishable from intact
platelets.” This study also provided the first
electron microscopy images of EVs.
1967
Nunez: Nunez’s study focused on the presence
of small extracellular vesicles in the bat thyroid
gland during arousal from hibernation. The authors
observed multivesicular bodies (MVBs) near the
apical membrane and proposed that the fusion of
the MVB’s outer membrane with the apical plasma
membrane could lead to the release of the vesicles
into the luminal space.
1974
1946
Chargaff and West: In their study, Chargaff
and West identified a particulate fraction that
“sedimented at 31,000 x g and had high clotting
potential.” They suggested that this fraction
likely included “a variety of minute breakdown
products of blood corpuscles” in addition to the
thromboplastic agent.
Aaronson and others: Studies conducted by
Aaronson and colleagues on various organisms
indicated that vesicular structures extruded
from cells were not unique to mammals. For
example, they observed vesicles budding from
cells and isolated them through centrifugation in
Ochromonas danica, a flagellated alga. EVs were
also shown to be released by Candida tropicalis,
Corynebacterium, Acinetobacter, Escherichia coli,
and other species.
1971–1979
Crawford: Crawford’s research demonstrated
that EVs contain lipids and carry cargo such as
ATP and contractile proteins.
1971
2. UNRAVELING THE EV
ENIGMA: ACCUMULATING
EVIDENCE, UNCERTAIN ROLE
Multiple Researchers: During this period,
researchers actively searched for “virus-like
particles” that could potentially cause diseases,
including infections and cancer. However, it
was noted that labeling structures with the
morphological characteristics of naturally
occurring vesicles from multivesicular bodies and
microvesicles associated with epithelial cells as
“virus-like” was unwarranted.
1956–1975
1986
Gawrisch: Gawrisch’s study revealed that the
lateral diffusion of lipids and proteins in vesicle
membranes differed between extracellular vesicles
(EVs) and red blood cells (RBCs). The diffusion
was higher in EVs, likely due to their lower protein
content and random lipid composition compared
to RBC membranes.
Smalley: Smalley’s research highlighted
the production of extracellular vesicles by
Porphyromonas gingivalis and showed their
interaction with human polymorphonuclear
leukocytes.
1990
Vidal & Stahl: Their work led to a better
understanding of vesicular trafficking,
including the components of EVs.
1993
Escola: Escola’s study confirmed the presence
of tetraspanins as components of EVs.1998
1983
Johnstone and Stahl: Their work demonstrated
the release of intraluminal vesicles from cells, using
reticulocyte maturation as a model. They defined
these vesicles as exosomes, which were released
from the lumen of multivesicular bodies upon fusion
with the plasma membrane. This discovery unveiled
the exosome secretion pathway.
Johnstone: Based on the internalization and
shedding of EV components at different times,
it was suggested that exosomes served as a
major route for externalizing obsolete membrane
proteins. This finding challenged the perception of
EV release as solely a waste disposal mechanism.
1991
Raposo: Raposo’s study revealed that EVs derived
from immune cells had the ability to present
antigens. This expanded the understanding of the
utility of EVs, particularly in the development of
therapeutic strategies, such as in cancer treatment
(as demonstrated by Zitvogel in 1998).
1996
Johnstone: This study demonstrated that
exosomes released from reticulocytes
retained enzymatic activity.
1989
19
Figure 1: Regulatory Functions of EVs. The central EVs express specific markers on their surface and interact with various immune cells,
including T cells, Natural Killer cells (NK), and dendritic cells (DC). Regulatory T cells (Treg), cytotoxic T lymphocytes (CTL), adenosine
triphosphate (ATP), and adenosine monophosphate (AMP) are involved in these interactions. Please note that the size of the extracellular
vesicle in the figure has been intentionally exaggerated for illustrative purposes.
EV or not EV
Currently, there is a faction of scientists within the scientific
community who use the term “exosome,” while originally
these structures were referred to as “microparticles.”
This discrepancy in nomenclature can lead to confusion,
particularly when arbitrary size ranges are assigned to
different types of vesicles. To address this issue, it has
been suggested that the umbrella term “extracellular
vesicles” (EVs) should be used to describe non-
replicating structures that are bounded by a lipid bilayer.
3. UNLOCKING THE FUNCTIONAL SECRETS OF EVs:
DECIPHERING THEIR ROLE IN CELLULAR PROCESSES
4. NAVIGATING THE GAPS IN THE FIELD OF EVs
The beginning of the 21st century marked a turning
point in understanding the role of extracellular vesicles
(EVs) in both physiological processes and diseases.
Scientists began to investigate the content of EVs using
different approaches, including proteomics, lipidomics,
genomics, and biochemistry. These studies shed light on
the potential roles of EVs in different contexts.
This research focused on immune cells, inspired
researchers in the field of immune therapies against
cancer, as demonstrated by the work of Chaput
(2003) and Zitvogel (2005). Ratajczak (2006) made
a breakthrough when demonstrating that cell-derived
microvesicles could reprogram other cells through the
horizontal transfer of mRNA and protein delivery, a
discovery highlighted the significant impact EVs could
have on cellular behavior.
Furthermore, it became evident that EVs could play
crucial roles in supporting healing processes, such as in
the case of infections (Colino, 2007) or trauma (Bruno,
2009). For example, compelling evidence suggests
that EVs have multiple roles in regulating the immune
response (Figure 1).
The establishment of the International Society for
Extracellular Vesicles (ISEV) in 2011 has played a crucial
role in fostering consensus on this terminology. The
definition of EVs as non-replicating structures delimited
by a lipid bilayer has been formalized in the current
recommendations outlined in the Minimal Information
for Studies of Extracellular Vesicles (MISEV) guidelines
(2018). The official journal of the society, the Journal
of Extracellular Vesicles (JEV), further reinforces the
accepted terminology and provides a platform for
research in the field.
20
© 2024 Beckman Coulter, Inc. All rights reserved. Beckman Coulter, the stylized logo, and the Beckman Coulter
product and service marks mentioned herein are trademarksor registered trademarks of Beckman Coulter, Inc.
in the United States and other countries. All other trademarks are the property of their respective owners. For
research use only.
For Beckman Coulter’s worldwide office locations and phone numbers, please visit Contact Us at beckman.com
2024-GBL-EN-104970-V2
Ensuring reproducibility
A major topic of debate in the field of extracellular
vesicles (EVs) revolves around the selection of methods
for their isolation and enrichment. Various techniques
are available, including ultracentrifugation, ultrafiltration,
size-exclusion chromatography, precipitation methods,
immunoaffinity-based assays, magneto-immunocapture,
microfluidic immunochips, and lipid nanoprobes. The
choice of method depends largely on the specific
objectives of the study.
In terms of EV characterization, several biophysical
approaches have been developed, such as nanoparticle
tracking analysis and reverse pulse sensing, which enable
the counting and sizing of EVs. Further characterization
involves methodologies like proteomics, genomics,
lipidomics, and more. While these techniques provide
insights into EV populations as a whole, flow cytometry
allows for the individual characterization of EVs. Single-
EV information is particularly valuable as it unravels the
heterogeneity within EV populations. However, ensuring
the accuracy and reproducibility of studies is crucial. To
address this, various working groups came together in
2011 to establish the International Society for Extracellular
Vesicles (www.isev.org), which has played a pivotal role
in advancing the EV field.
In 2018, the society published updated guidelines for EV
analysis known as MISEV (Minimal Information for Studies
of Extracellular Vesicles). These guidelines aim to address
controversies and questions surrounding EV research.
As stated by Ramirez et al., “a persistent concern in
flow cytometry is the reliable distinction between EVs
carrying specific protein markers and those that do
not, in order to accurately measure the proportion of
EVs of a particular type.” Quantitative and qualitative
analyses of EV heterogeneity within samples are crucial
for comprehensive understanding.
5. CONCLUSIONS
The research on extracellular vesicles (EVs) has evolved
into a distinct field, complete with its own dedicated
society and scientific conferences. The discovery of
EVs has illuminated a previously unknown realm that
plays a crucial role in regulating various physiological
processes. Further studies in this field hold the potential
to unravel the heterogeneity of EVs and elucidate
their diverse functions. Moreover, they could pave the
way for identifying novel biomarkers of diseases. By
monitoring cell-specific EVs, researchers can search for
specific biomarkers that are present on or within EVs.
This approach offers a non-invasive means of defining
disease biomarkers, as it only requires a simple blood
draw. Promising results have already been demonstrated
in the context of Alzheimer’s disease.
Furthermore, EVs are currently the subject of intense
investigation for their potential use as carriers to
transport therapeutic compounds to target cells or
organs. By engineering EVs loaded with drugs that
can specifically target certain cells, such as tumors,
researchers hope to overcome challenges associated
with conventional therapies. This targeted delivery
approach could improve the efficacy of treatments
and minimize unwanted side effects. This has important
implications, as current therapies are often systemically
adminisstered, resulting in suboptimal functionality and
potential to cause harm to health tissues
References
Asleh et al. Extracellular vesicle-based liquid biopsy biomarkers and their application in precision immuno-oncology. Biomark Res 11, 99, 2023.
Ramirez et al. Technical challenges of working with extracellular vesicles. Nanoscale 10, 881-906, 2018.
Théry et al. Minimal information for studies of extracellular vesicles 2018 (MISEV2018): a position statement of the International Society for Extracellular
Vesicles and update of the MISEV2014 guidelines. J. Extracell Vesicles. 7(1):1535750, 2018.
Couch et al. A brief history of nearly EV-erything – The rise and rise of extracellular vesicles. J. Extracell Vesicles. 10(14):e12144, 2021.
Tao-Ran et al. Extracellular vesicles as an emerging tool for the early detection of Alzheimer’s disease. Mech Aging and Dev. 184:111175, 2019.
21
22
exposure to radioactivity contributed to her developing
leukemia, serving as a costly lesson learned by mistake.
These anecdotes highlight the incredible journey of
scientific curiosity.
The story of extracellular vesicles (EVs) is akin to the
narrative of scientific curiosity crossing various disciplines
such as hematology, cell biology, virology, and more.
These diverse fields eventually converged to uncover the
existence of these small biologically active vesicles. The
knowledge gained from each domain played a crucial
role in unveiling the significance of EVs as an essential
component of our physiology.
EVs have gained significant interest in the field of
biodiscovery, despite being a relatively recent discovery.
THE DISCOVERY OF EVs
Science and medicine have been at the forefront of
some of the most fascinating discoveries in history. Take,
for example, the charming story of penicillium mold
accidentally falling into an agar plate filled with bacteria,
leading to the serendipitous discovery of antibiotics. This
discovery was a result of learning by chance. Another
remarkable story is that of Barry Marshall, who bravely
self-administered Helicobacter pylori to demonstrate its
effect on peptic ulcers. This bold experiment ultimately
earned him a Nobel Prize, showcasing the power of
learning through experimentation.
We mustn’t forget the extraordinary Marie Curie, who
used to carry radium tubes in her pocket. Sadly, her
INTO THE WORLD OF
EXTRACELLULAR
VESICLES (EVs)
Extracellular
Vesicles (EVs)
23
exposure to radioactivity contributed to her developing
leukemia, serving as a costly lesson learned by mistake.
These anecdotes highlight the incredible journey of
scientific curiosity.
The story of extracellular vesicles (EVs) is akin to the
narrative of scientific curiosity crossing various disciplines
such as hematology, cell biology, virology, and more.
These diverse fields eventually converged to uncover the
existence of these small biologically active vesicles. The
knowledge gained from each domain played a crucial
role in unveiling the significance of EVs as an essential
component of our physiology.
EVs have gained significant interest in the field of
biodiscovery, despite being a relatively recent discovery.
THE DISCOVERY OF EVs
Science and medicine have been at the forefront of
some of the most fascinating discoveries in history. Take,
for example, the charming story of penicillium mold
accidentally falling into an agar plate filled with bacteria,
leading to the serendipitous discovery of antibiotics. This
discovery was a result of learning by chance. Another
remarkable story is that of Barry Marshall, who bravely
self-administered Helicobacter pylori to demonstrate its
effect on peptic ulcers. This bold experiment ultimately
earned him a Nobel Prize, showcasing the power of
learning through experimentation.
We mustn’t forget the extraordinary Marie Curie, who
used to carry radium tubes in her pocket. Sadly, her
INTO THE WORLD OF
EXTRACELLULAR
VESICLES (EVs)
Extracellular
Vesicles (EVs)
Many scientists are now focused on understanding the
diversity of EVs, their role in physiological functions, and
their potential involvement in various diseases.
In the 1930s, a biochemist named Chargaff was working on
developing a centrifugation protocol to separate clotting
factors from blood. During this process, he observed that
adding the high-speed sediment to the supernatant plasmasignificantly shortened the clotting time.1 This observation
brought to light the existence of EVs, a distinct family of
biomolecules present in blood. With the assistance of
West,2 they further identified a “particulate fraction” that
sedimented at 31,000 x g and exhibited high clotting
potential and thromboplastic properties. This fraction
included EVs. Initially, it was hypothesized that these isolated
fractions were composed of various minute breakdown
products of blood corpuscles. However, it took nearly two
more decades of research to identify and differentiate
the material in minute particulate form, sedimentable by
high-speed centrifugation, and originating from platelets
but distinct from intact platelets. These findings align
closely with the characteristics of EVs.3 The first electron
microscopy images of this “platelet dust” provided
scientists with visual insights into the true appearance of
EVs (Figure 1).
• Extracellular vesicles (EVs) possess a phospholipid
membrane that typically has a thickness of
approximately 5 nm.
• These vesicles exhibit a wide range of sizes, with
most fluids containing EVs of varying sizes.
• The minimum size of EVs is dependent on their
composition and ranges from 30-50 nm in human
blood plasma.
• Generally, the size distribution of EVs has a peak
below 200 nm.
• In human blood, spherical EVs smaller than 500 nm
constitute around 95% of the total population.
EVs AT A GLANCE
Figure 1. Urinary EVs (uEVs) characterization by transmission electron
microscopy (TEM). Representative picture of TEM characterization
of uEVs isolated with ultracentrifugation. Bertolone et al. Front.
Endocrinol. 2023 14:1096441. Published under a Creative Commons
Attribution 4.0 International License: http://creativecommons.org/
licenses/by/4.0/
The subsequent work by Crawford played a crucial role
in identifying the presence of lipids and proteins within
the membrane of EVs, shedding light on their functional
properties.4 In a fascinating study on bat hibernation,
scientists initially observed how EVs are generated from
cells through the fusion of multivesicular bodies with the
plasma membrane before being released.5 This discovery led
to the realization that EVs are not exclusive to mammalian
cells but are produced by various cell types.6 During the
1980s, researchers focused on unraveling the intricacies of
membrane trafficking and the assembly of EVs, specifically
examining how proteins are included or excluded.7
Initially referred to as exosomes (small microvesicles), the
term “extracellular vesicles” was officially adopted in 2011 to
define these non-replicating structures enclosed by a lipid
bilayer. The same year witnessed the establishment of the
International Society of Extracellular Vesicles (ISEV), which
developed guidelines (MISEV) to standardize the analysis
and reporting of EV research.8 Since then, numerous topics
have emerged, including the study of cargo trafficking,
biomarkers, cancer, cardiovascular diseases, infectious
diseases, drug delivery, and many more. These areas of
research highlight the tremendous importance of EVs in
various fields of study.
THE IMPORTANCE OF EVs
IN SCIENCE AND MEDICINE
The discovery of the world of extracellular vesicles (EVs)
has brought to light previously unknown aspects of how
the body functions, how cancer cells spread, and how
pathogens disseminate. However, there is still much
investigation needed to fully decipher the secrets of EVs.
Scientists now recognize that EVs play a central role not
only in physiological processes but also in pathological
conditions. This recognition has led to a significant surge in
research over the past decade, with thousands of scientific
papers published in 2022 alone (Figure 2).
0
1000
2000
3000
4000
5000
6000
7000
1950 1960 1970 1980 1990 2000 2010 2020 2030
Figure 2. The number of publications related to extracellular vesicles
(EVs). This figure represents the number of publications retrieved
from 1950 to the present, using the keyword “extracellular vesicles”
(source: Pubmed.com).
24
EVs are produced by all cell types across different life
kingdoms. Their biogenesis can be categorized into two
types of release: (i) budding from the plasma membrane,
resulting in larger microvesicles and apoptotic bodies, and
(ii) release of vesicles derived from endosomes. 9 EVs are
small in size (ranging from 30 to 500 nm) and possess
an intraluminal region. Due to their size and ability to
carry proteins and nucleic acids, scientists are focused on
understanding their functions and exploring their potential
as biomarkers.
Research has revealed that EVs play a role in various
physiological processes, including angiogenesis, cellular
migration, and cell-to-cell signaling. Their abundance,
and their ability to easily enter target cells suggest their
involvement in numerous physiological processes, both in
peripheral circulation and tissues (Figure 3). In fact, EVs have
the capacity to cross the blood-brain barrier, indicating a
potential role in neurodegenerative diseases.10 Additionally,
EVs can serve as biomarkers for peripheral screening tools
in diseases like Alzheimer’s (among other applications).11
There is growing interest in the therapeutic potential
of EVs. Clinical trials are investigating the use of EVs as
cargo vehicles to deliver compounds to target cells. By
engineering EVs to express specific markers, they can be
targeted to specific sites in the body and deliver cargo
inside the cells. This targeted delivery offers advantages
in terms of specificity compared to conventional drug
delivery methods. Transmembrane proteins like tetraspanins
(e.g., CD9, CD63, CD81), often used as markers of EVs,
• EVs are derived from
the endosomal system,
leading to the formation
of multivesicular bodies.
• These EVs carry cell-
derived proteins on their
surface.
• Subsequently, they are
transported to the cell
membrane and fuse
with it.
• Once fused, they are
released from the cell into
the extracellular space.
• EVs can then bind to
target cells that express
the corresponding
receptor that they
themselves express.
• Once inside the target
cell, they have the ability
to release their cargo.
Figure 3. Biogenesis of vesicles from cells and their anchoring into target cells. EVs and their cargos are enclosed within microvesicular
bodies (MVB) that migrate to the plasma membrane for release into the extracellular space.
Secreting Cell
RNAs
Proteins
MVB
Cytosol
Cytosol
Microvesicles
RNAs
Recipient Cell
Extracellular
Vesicles
also play a role in this process.12 Once inside the cells, the
cargo interacts with intracellular components, influencing
signaling pathways and ultimately leading to desired
outcomes such as activation, suppression, or modulation
of cellular functions.
This constant physiological process, where EVs modulate
cellular functions from within, impacts the interaction of
target cells with their microenvironment, particularly in
tissues. It is through the release of EVs that some cancer
cells can spread to other tissues, as these vesicles have
the ability to modulate the tissue microenvironment in
favor of cancer cell dissemination.13 This area of research is
highly active, as finding ways to suppress this action could
potentially reduce the spread of cancer cells throughout
the body.14
CENTRIFUGATION AT THE
GENESIS OF EV DISCOVERY
The study of extracellular vesicles (EVs) and the
development of the EV field have heavily relied on
centrifugation protocols since Chargaff’s initial discovery.
Over the years, scientists have refined protocols to enrich,
isolate, and characterize EVs. The ideal separation protocol
would offer high yield, heterogeneity, and efficiency
while minimizing time and costs. Centrifugation, being a
well-established technique in laboratories, has been the
method of choice that has propelled the field toits current
state. There are various methods for isolating EVs, and the
How EVs Are Generated
25
specific downstream applications dictate the appropriate
protocol to employ, each with its own advantages and
disadvantages.15 Body fluids such as plasma, serum, urine,
cerebrospinal fluid, and milk are commonly used as starting
materials for EV separation.
Ultracentrifugation, including differential centrifugation,
is a widely employed isolation method for EVs. While a
combination of techniques may be utilized, centrifugation
is almost always included in the isolation protocols (Figure
4). Density gradient centrifugation, filtration, and size-
exclusion chromatography have gained interest among
researchers. However, subsequent purification methods still
involve ultracentrifugation, density gradient centrifugation,
or chromatography techniques. Magnetic bead separation,
although offering a targeted approach, may compromise
the true heterogeneity of EVs. The isolation of EVs entails
the removal of contaminants and the separation of EVs
from other particles, such as chylomicrons and lipids,
present in biological fluids or cell culture media (Figure
4). Ultracentrifugation utilizes centrifugal force to separate
components based on size and/or density. Differential
ultracentrifugation techniques involve multiple spins at
progressively increasing speeds to eliminate contaminants
and pellet EVs. Density gradient ultracentrifugation is a high-
resolution purification technique that separates particles
based on physical properties (size, shape, mass, and/or
density) by employing a medium with graded densities,
such as sucrose or iodixanol. While density cushion
ultracentrifugation strikes a balance between throughput
and purity, density gradient ultracentrifugation provides the
highest purity, and differential ultracentrifugation allows for
the highest throughput. Density gradient and differential
ultracentrifugation yield the cleanest samples and preserve
the structural integrity of EVs compared to other methods
like size exclusion chromatography or precipitation.
The question of scalability, especially in the context of
manufacturing and EV therapy, becomes important when
deciding which isolation method to employ.16-19
MOVING FORWARD WITH EV RESEARCH
From the initial discovery of EVs to the present day, several
decades have passed. The recent excitement surrounding
EVs stems from the potential applications that could arise
from a deeper understanding of their generation, regulation,
and manipulation for therapeutic purposes. Since EVs are
produced by all types of living cells and have the ability
to regulate numerous processes, the possibilities for their
applications are limitless. However, this also emphasizes
the need for further research to unravel the secrets of
EVs. The scientific community is eager to standardize
Figure 4. Isolating EVs involves the removal of contaminants and the separation of EVs from other particles, such as chylomicrons and
lipids, present in biological fluids or cell culture media. Ultracentrifugation utilizes centrifugal force to separate components based on
their size and/or density. Differential ultracentrifugation techniques employ multiple spins at progressively increasing speeds to first
eliminate contaminants and then pellet EVs. Density gradient ultracentrifugation is a high-resolution purification technique that relies on
a medium with graded densities, such as sucrose or iodixanol, to separate particles based on their physical properties such as size, shape,
mass, and density.
26
the isolation, characterization, and use of EVs, as this will
enhance reproducibility and facilitate the translation of
findings into clinical use.
There are still important characteristics of EVs that need
to be clarified. Firstly, their heterogeneity is a significant
aspect to explore. EVs are not a single entity, as their
composition and size can vary even within the same cell.
The generation and composition of EVs are likely to be
continuously regulated processes influenced by the cell’s
status and received signals (Figure 5). Characterizing EVs
individually, which can be achieved using technologies like
flow cytometry, will contribute to a better understanding
of their heterogeneity. Secondly, it is crucial to develop
scalable methods for generating EVs in vitro for delivery
to patients. Defining standard workflows will be essential
in this regard, and centrifugation plays a crucial role in the
manufacturing process. Lastly, mapping markers associated
with different classes of EVs (e.g., cells of origin, healthy
vs. cancer cells, activation status, disease biomarkers) is
necessary to expedite ongoing therapeutic efforts.
MORE INFORMATION
To learn more, please visit these resources on the Beckman
Coulter Life Sciences website.
Figure 5. Representation of the size and heterogeneity of EVs. High-density lipoproteins (HDLs), low-density lipoproteins (LDLs), and
very low-density lipoproteins (vLDLs) are included for comparison. The average sizes of antibodies, viruses, and bacteria are also shown.
10 nm 30 nm 50 nm 120 nm 200 nm 500 nm 1000 nm
Small EVs Large EVs
BacteriaVirus
HDLs LDLs vLDLs
Antibody
Extracellular Vesicles Overview
Flow Cytometry Overview
CytoFLEX nano for EV Research
27
1. Chargaff, E. J. (1945). Cell structure and the problem of blood
coagulation. 160(1), 351–359
2. Chargaff, E., & West, R. (1946). The biological significance of the
thromboplastic protein of blood. Journal of Biological Chemistry,
166(1), 189–197
3. Wolf, P. (1967). The nature and significance of platelet products in
human plasma. British Journal of Haematology, 13(3), 269–288
4. Crawford, N. (1971). The presence of contractile proteins in platelet
microparticles isolated from human and animal platelet-free
plasma. British Journal of Haematology, 21(1), 53–69
5. Nunez, E. A., Wallis, J., & Gershon, M. D. (1974). Secretory
processes in follicular cells of the bat thyroid. 3. The occurrence
of extracellular vesicles and colloid droplets during arousal from
hibernation. American Journal of Anatomy, 141(2), 179–201
6. Couch Y, Buzàs EI, Di Vizio D, Gho YS, Harrison P, Hill AF, Lötvall
J, Raposo G, Stahl PD, Théry C, Witwer KW, Carter DRF. A brief
history of nearly EV-erything - The rise and rise of extracellular
vesicles. J Extracell Vesicles. 2021 Dec;10(14):e12144
7. Harding, C., Heuser, J., & Stahl, P. (1983). Receptor-mediated
endocytosis of transferrin and recycling of the transferrin receptor
in rat reticulocytes. Journal of Cell Biology, 97(2), 329–339
8. Théry, C., Witwer, K. W., Aikawa, E., Alcaraz, M. J., Anderson, J.
D., Andriantsitohaina, R., Antoniou, A., Arab, T., Archer, F., Atkin-
Smith, G. K., Ayre, D. C., Bach, J.-M., Bachurski, D., Baharvand, H.,
Balaj, L., Baldacchino, S., Bauer, N. N., Baxter, A. A., Bebawy, M.,
& Zuba-Surma, E. K. (2018). Minimal information for studies of
extracellular vesicles 2018 (MISEV2018): A position statement of
the International Society for Extracellular Vesicles and update of
the MISEV2014 guidelines. Journal of Extracellular Vesicles, 7(1),
1535750
9. Welsh JA, Arkesteijn GJA, Bremer M, Cimorelli M, Dignat-George
F, Giebel B, Görgens A, Hendrix A, Kuiper M, Lacroix R, Lannigan
J, van Leeuwen TG, Lozano-Andrés E, Rao S, Robert S, de Rond
L, Tang VA, Tertel T, Yan X, Wauben MHM, Nolan JP, Jones JC,
Nieuwland R, van der Pol E. A compendium of single extracellular
vesicle flow cytometry. J Extracell Vesicles. 2023 Feb;12(2):e12299.
doi: 10.1002/jev2.12299. PMID: 36759917; PMCID: PMC9911638
10. Jeyaraman M, Rajendran RL, Muthu S, Jeyaraman N, Sharma
S, Jha SK, Muthukanagaraj P, Hong CM, Furtado da Fonseca
L, Santos Duarte Lana JF, Ahn BC, Gangadaran P. An update
on stem cell and stem cell-derived extracellular vesicle-based
therapy in the management of Alzheimer’s disease. Heliyon. 2023
Jun 29;9(7):e17808. doi: 10.1016/j.heliyon.2023.e17808.PMID:
37449130; PMCID: PMC10336689
11. Cheng, L., Doecke, J., Sharples, R. et al. Prognostic serum
miRNA biomarkers associated with Alzheimer’s disease shows
concordance with neuropsychological and neuroimaging
assessment. Mol Psychiatry 20, 1188–1196 (2015)
12. Ginini L, Billan S, Fridman E, Gil Z. Insight into Extracellular Vesicle-
Cell Communication: From Cell Recognition to Intracellular Fate.
Cells. 2022 Apr 19;11(9):1375. doi: 10.3390/cells11091375. PMID:
35563681; PMCID: PMC9101098
13. Kosaka N, Yoshioka Y, Fujita Y, Ochiya T. Versatile Roles of
Extracellular Vesicles in Cancer. J Clin Invest (2016) 126:1163–72
14. Xu Y, Yao Y, Yu L, Zhang X, Mao X, Tey SK, Wong SWK, Yeung CLS,
Ng TH, Wong MYM, Che CM, Lee TKW, Gao Y, Cui Y, Yam JWP.
Clathrin light chain A-enriched small extracellular vesicles remodel
microvascular niche to induce hepatocellular carcinoma metastasis.
J Extracell Vesicles. 2023 Aug;12(8):12359
15. Gardiner, C., Vizio, D. D., Sahoo, S., Théry, C., Witwer, K. W.,
Wauben, M., & Hill, A. F. (2016). Techniques used for the isolation
and characterization of extracellular vesicles: Results of a
worldwide survey. Journal of Extracellular Vesicles, 5, 32945
16. Dong X, Dong JF, Zhang J. Roles and therapeutic potential of
different extracellular vesicle subtypes on traumatic brain injury.
Cell Commun Signal. 2023 Aug 18;21(1):211
17. García-Fernández J, Fuente Freire M. Exosome-like systems:
Nanotechnology to overcome challenges for targeted cancer
therapies. Cancer Lett. 2023 May 1;561:216151. doi: 10.1016/j.
canlet.2023.216151
18. Li G, Chen T, Dahlman J, Eniola-Adefeso L, Ghiran IC, Kurre P, Lam
WA, Lang JK, Marbán E, Martín P, Momma S, Moos M, Nelson DJ,
Raffai RL, Ren X, Sluijter JPG, Stott SL, Vunjak-Novakovic G, Walker
ND, Wang Z, Witwer KW, Yang PC, Lundberg MS, Ochocinska MJ,
Wong R, Zhou G, Chan SY, Das S, Sundd P. Current challenges
and future directions for engineering extracellular vesicles for
heart, lung, blood and sleep diseases. J Extracell Vesicles. 2023
Feb;12(2):e12305. doi: 10.1002/jev2.12305. Erratum in: J Extracell
Vesicles. 2023 Mar;12(3):e12314. PMID: 36775986
19. Estes S, Konstantinov K, Young JD. Manufactured extracellular
vesicles as human therapeutics: challenges, advances, and
opportunities. Curr Opin Biotechnol. 2022 Oct;77:10277
References
© 2024 Beckman Coulter, Inc. All rights reserved. Beckman Coulter, the stylized logo, and the Beckman Coulter
product and service marks mentioned herein are trademarks or registered trademarks of Beckman Coulter, Inc.
in the United States and other countries. All other trademarks are the property of their respective owners. For
research use only. Not to be used in diagnostic procedures.
For Beckman Coulter’s worldwide office locations and phone numbers, please visit Contact Us at beckman.com
2024-GBL-EN-104940-V1
© 2024 Beckman Coulter, Inc. All rights reserved. Beckman Coulter, the stylized logo, and the Beckman Coulter product and service
marks mentioned herein are trademarks or registered trademarks of Beckman Coulter, Inc. in the United States and other countries.
All other trademarks are property of their respective owners.
For Beckman Coulter’s worldwide office locations and phone numbers, please visit Contact Us at beckman.com
2024-GBL-EN-105083-v1
Beckman Coulter Life Sciences
Service and Support
Maximize Your Instrument Performance
Timely service and preventive maintenance are essential for optimal instrument
performance and data quality. Beckman Coulter Life Sciences offers a wide range
of service contract options for the CytoFLEX platform family of instruments to fit
every lab’s needs and budget. Our application scientists have extensive experience
with flow cytometry workflows and provide support and training on all our product
offerings to help you maximize the use of your systems.
beckman.com
https://www.beckman.com/
http://beckman.com/
