Course notes
ODIS Technical Training.

Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Course notes
ODIS Technical Training.

2
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course Objectives:
At the end of this course participants will.......
Understand the benefits of the ODIS system and its place in the service core process
Be able to start and navigate efficiently through the ODIS system.
Understand the functions of ODIS such as Test Instruments, Flashing, Diagnosis, Info,
and Admin.
Be able to carry out basic operations on the vehicle using ODIS such as resetting
service indicators, key coding and switching off transport mode.
Be able to carry out Guided Fault Finding and add tests to the Test Plan using the
“Select own test” function.
Be able to carry out Guided Functions on the vehicle.
Be able to carry out Vehicle Self Diagnosis on the vehicle.
Be able to utilise the test instruments function through the ODIS system.
Be able to carry out the “Flashing” function in ODIS.
Know how to access vehicle information such as current flow diagrams, technical
product information, vehicle history, production codes, and workshop manuals through
the ODIS system.
Be able to print and save diagnostic logs, or send them online.
Be able to stop and resume diagnostic sessions.
Be able to activate the “Test drive mode”.
Understand the “HotFix” function.
Be able to access the “Online help” function for ODIS.
Know how to send support requests online.
Course notes
ODIS Technical Training.

3
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

4
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

5
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Notes______________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
Course notes
ODIS Technical Training.

6
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Please take notes on the next page.
Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Introduce a fault to the vehicle (for example a sensor or an actuator on
the engine).
Start diagnosis and enter vehicle data.
Let Guided Fault Finding interrogate all of the control units, and then
see if it is possible to check the TPIs using ODIS.
_________________________________________________________
_________________________________________________________
With the assistance of Guided Fault Finding, carry out the guided test in
the test plan for the fault you have introduced.
Add your own test to the test plan (select the test e.g. “Rear lid lock unit
F256) and process the test.
Is it possible to search for a function in the “Select own test” tab?
_____________________________________________________________
_____________________________________________________________
Remove the fault from the vehicle
Exit guided fault finding, so that the fault memories are erased, and the
diagnostic log is sent online.
Practical exercises session 1.
Course notes
ODIS Technical Training.

7
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

8
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Please take notes on the next page.
Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Start diagnosis and enter vehicle data.
Deselect Guided Fault Finding and click “Apply”.
How can transport mode be activated and deactivated. Carry out the
procedure using Guided Functions?
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
How can the service interval be reset? Carry out the procedure in
Guided Functions.
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
How can the keys be coded online? Carry out the procedure in Guided
Functions.
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

Practical exercises session 2.
Course notes
ODIS Technical Training.

9
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Notes__________________________________________________________________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
Course notes
ODIS Technical Training.

10
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Please take notes on the next page.
Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Start diagnosis and enter vehicle data.
Deselect Guided Fault Finding and click “Apply”.
How can the Gateway installation list be accessed?
_____________________________________________________________
_____________________________________________________________
What information can the Gateway installation list provide?
_____________________________________________________________
_____________________________________________________________
Can we tell if a control unit is not connected to the Networking system
by monitoring the Gateway installation list? ____________________
What does “SB” signify?
_________________________________________________________
Is it possible to sort the installation list by Address, System, Event, and
SB?
_____________________________________________________________
How is the list refreshed? ____________________________________
Practical exercises session 3.
Course notes
ODIS Technical Training.

11
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Carry out the function “event memories for entire system”.
____________________________________________________________
____________________________________________________________
Carry out the function “Transport mode”. With which vehicles is it possible
to deactivate transport mode using this function.
____________________________________________________________
____________________________________________________________
Course notes
ODIS Technical Training.

12
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Please take notes on the next page.
Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Start diagnosis and enter vehicle data.
Deselect guided fault finding and click on apply.
Enter the “control unit self diagnosis” function for a control unit that uses
a KWP diagnostic protocol.
Carry out the function for checking the fault memory. What is the tab
designated as? ________________
Carry out the function “Actuator Diagnosis”. What is the tab designated
as? ____________________
Carry out the function “Adaptation”.. What is the tab designated as?
____________________
Carry out the function “Encoding”. What is the tab designated as?
___________________
Carry out the function “Measured values”. What is the tab designated
as?__________________

Practical exercises session 4.
Course notes
ODIS Technical Training.

13
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

14
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Practical exercises session 5.
Please take notes on the next page.
Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Start diagnosis and enter vehicle data.
Deselect guided fault finding and click on apply.
Enter the control unit self diagnosis function for a control unit that uses a
UDS diagnostic protocol.
Carry out the function for checking the fault memory. Note the difference
in functionality when compared to the KWP control unit.
Carry out the function “Actuator Diagnosis” . Note the difference in
functionality when compared to the KWP control unit.
Carry out the function “Adaptation”. Note the difference in functionality
when compared to the KWP control unit.
Carry out the function “Encoding” . Note the difference in functionality
when compared to the KWP control unit.
Carry out the function “Measured values”. Note the difference in
functionality when compared to the KWP control unit.
Is it possible it possible to filter the list of MVBs? If so, carry out the
function.

Course notes
ODIS Technical Training.

15
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Notes______________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
________________________________________________________________________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
Course notes
ODIS Technical Training.

16
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

17
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

18
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

19
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Course notes
ODIS Technical Training.

20
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Connect the diagnostic tester to the training vehicle and start the ODIS
programme.
Start diagnosis and enter vehicle data.
Work with Guided Fault Finding, and go to the test plan when the
system test is complete.
Which function in ODIS contains information from ElsaPro?
_________________________________________________________
Does ODIS require a network connection in order to access information
from ElsaPro?
_________________________________________________________
Which functions from ElsaPro are available in ODIS?
_________________________________________________________
_________________________________________________________
_________________________________________________________
What information is contained within the “Documents” tab?
_________________________________________________________
_________________________________________________________
In the “Test plan” tab, sort and view documents by “Test Plan”, and “Test
Programme”?
_________________________________________________________
_________________________________________________________
_________________________________________________________

Practical exercises session 6.
Course notes
ODIS Technical Training.

21
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

22
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Use the “online help” function to assist you with the following exercises.
What is the purpose of the DISS tab?
_____________________________________________________________
_____________________________________________________________
How can the customer coding be selected for a DISS report?
_____________________________________________________________
_____________________________________________________________
How can the TPIs be accessed from the ODIS system?
_____________________________________________________________
_____________________________________________________________
Open a TPI from the ODIS system.
_____________________________________________________________
_____________________________________________________________
After carrying out the customer coding, is it possible to extend the test
plan?
_____________________________________________________________
_____________________________________________________________

Practical exercises session 6.
Course notes
ODIS Technical Training.

23
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

24
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Workshop scenario. You are currently carrying out Guided Fault Finding
using ODIS. Another technician wishes to use the tester to carry out a
function on another vehicle. Is it possible for you to save your diagnostic
session and resume it again later. Carry out the exercises below.

Stop the current diagnostic session. List the sequence of the procedure
for carrying out this function.

_____________________________________________________________
__________________________________________________________________________________________________________________________
From the start screen of ODIS, resume the diagnostic session that you
have stopped. List the sequence of the procedure for carrying out this
function.

Practical exercises session 7.
Course notes
ODIS Technical Training.

25
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

The button to print the current view is sometimes greyed out. What
might the cause of this be. Use the “Online help” function to assist you.
_____________________________________________________________
_____________________________________________________________
What are the functions of the buttons below. Use the “Online help”
function to assist you.

_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

26
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
Course notes
ODIS Technical Training.

27
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Test Drive Mode
Follow the instructions below in order to activate test drive mode.
Test drive mode can only be activated when the tester is connected to a
network. In “Extras” press the test drive button.

Then click on “Activate test drive mode”.

All of the required data is now copied to the diagnostic tester. Then click ok.

Practical exercises session 8.
Course notes
ODIS Technical Training.

28
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Test Drive Mode
What is the function of this button.
_____________________________________________________________
_____________________________________________________________

When ending the test drive mode, all of the data you have accumulated
during the test drive is synchronised with the network. Which of the buttons
below should you click on. “Cancel test drive mode” or “End test drive
mode”. Use the online
help function to assist
you.

_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

Course notes
ODIS Technical Training.

29
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Test Drive Mode
Using the online help function, answer the following questions:
In relation to “Test drive mode” what does the status of the following symbols
indicate?

Deactivate “Test drive mode” on the vehicle.

30
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Hotfix
Using the online help function, answer the following questions:
Where on the ODIS programme is the “Hotfix” function?
_____________________________________________________________
What is the purpose of the “Hotfix” function?
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
Is it possible to remove an installed “Hotfix” from the tester. If so, how is
it done, and which of the buttons below do you click on?
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

Practical exercises session 9.
Course notes
ODIS Technical Training.

31
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Flashing

Remember, before using “Flash” mode ensure that the radio head VAS5054
is hard wired to the vehicle.
Flash mode can be accessed from the start screen by clicking on the
“Flashing” button.

The Flashing mode functions may differ depending on the Brand you are
working with.

Course notes
ODIS Technical Training.

32
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Flashing

Select vehicle data and click ok.

Course notes
ODIS Technical Training.

33
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Flashing
Overview of functions for Audi.

Course notes
ODIS Technical Training.

34
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Flashing
Overview of functions for Volkswagen, Skoda, and SEAT.

Course notes
ODIS Technical Training.

35
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Flashing
Begin the flashing function and take note of the functions that are
available for the Brand that you work with.
Describe the purpose of each of the functions in “Flashing” to the
Trainer.
__________________________________________________________________________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

Practical exercises session 10.
Course notes
ODIS Technical Training.

36
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Test Instruments
Ensure that the URDI, DSO, and Amp clamp cable are correctly
connected to the VAS5051B or the VAS6356.
Familiarise yourself with the layout and the operation of the multimeter
and oscilloscope in the Test instruments function of ODIS.
Do the DSO channels A and B automatically select the DSO leads 1 and
2, as they did with the VAS programme on VAS5051B?
_____________________________________________________________
_____________________________________________________________

Practical exercises session 11.
Course notes
ODIS Technical Training.

37
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Support Request.
You have noticed an issue with the ODIS programme and you wish to send a
support request. Please carry out this function. Attach at least two screen
shots, a diagnostic log, and text to the support request.

Practical exercises session 12.
Course notes
ODIS Technical Training.

38
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland

Administration
Remember!! You should not make any adjustments to the settings
in the administration function of ODIS, unless instructed to do so
by the Importer. The function of the ODIS programme may be
impeded if the settings are changed.
The settings you may adjust are “Brand design” and “Language”. Please
carry out the procedure for changing the Brand design and language.
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________

Practical exercises session 13.
Course notes
ODIS Technical Training.

39
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Click on the “DiagStarter.bat” icon on the desktop. This is a yellow icon
with a picture of an engine check lamp.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

40
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Alternatively, you can start the ODIS programme from the programmes
listing as can be seen above.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

41
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
After double clicking on the “DiagStarter.bat” icon a window appears on
the screen.
Here you can whose if you want to open the ODIS programme or the VAS
PC programme.
Click on the ODIS programme (Offboard Diagnostic Information System).
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

42
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
As the ODIS programme is opening, error messages may pop up on the
screen. Click “OK” to these messages.
Note: These error messages only appear on the pilot version of ODIS.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

43
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The ODIS programme starts up.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

44
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Read through and observe the warnings and click OK.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

45
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
You are now at the ODIS start page which has automatically defaulted to
the “Diagnosis” function.
Click “Start Diagnosis”.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

46
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The ODIS system begins communication with the vehicle and determines
the VIN (vehicle identification number).

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

47
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Input the model, model year, variant, and engine code from the drop
down menus.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

48
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
After selecting the vehicle information, ensure the check box is ticked in
order to work with Guided Fault Finding. Then click “Apply”.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

49
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Input your user ID and password and click “Apply”.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

50
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The system determines if any orders for the vehicle have been created
using ElsaPro.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

51
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
No orders have been found. Click ok to this message.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

52
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Click on “Without Order”, as no order number was created using ElsaPro.
This will be possible in the future when ElsaPro will be connected to the
dealer management system.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

53
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The system queries the fault memories of all the control units connected
to the vehicles networking system. There is also a progress bar at the
lower right hand corner of the screen.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

54
Status: 06/2011
Version 4
Developedby Paul O’Flynn - Volkswagen Group Ireland
When the system has finished querying the control units, this window ap-
pears. Click on OK to continue.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

55
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Read the note on the screen and click on Done/Continue.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

56
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Read the note on the screen and click on Done/Continue.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

57
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
This screen now appears. If you are working with an ElsaPro order num-
ber, and a DISS report was created by the Service Advisor, you have the
opportunity of coding the DISS report from the workshop point of view
here. If not, click on the “Control units” tab.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

58
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
This is a list of all the control units that were queried during Guided Fault
Finding. You also have the options of changing the view by clicking on the
tabs at the lower left of the screen called Block diagram, Control unit list,
and Event memory list.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

59
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The is the Block diagram view of control units that were queried during
Guided Fault Finding.
Control units highlighted in black are fitted but have no faults logged.
Control units in red are fitted to the vehicle and have fault memories
logged.
Control units in grey are not fitted to the vehicle.
Click on “Test plan” to access the test plan.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

60
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
This is the “Test plan” tab. In this example there is one test in the plan that
the system has generated.
Highlight the test you wish to perform, and click on “Perform test”.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

61
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Process the guided test as you would using the VAS PC programme.
Click “Done/Continue” to proceed through the test.
Click on “Cancel test” if you wish to return to the test plan.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

62
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
This is the test plan tab. If you wish to find your own guided test for a
component or a function (function/component selection in VAS PC), click
on “Select own test”.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

63
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
After clicking on the “Select own test” button a pop up window appears.
This are the same options that were available in the function/component
selection menu in VAS PC.
Browse through the folders to locate the component or function you are
seeking.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

64
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Highlight the function or component you wish to test and click on “Attach
to test plan”.
The system then adds the test you have selected to the test plan.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

65
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The test you have chosen has been added to the test plan.
If you wish to perform the test, highlight it, and then click on perform test.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

66
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
If you wish to exit guided fault finding after completing your test plan, click
on the “Control units” tab at the top left of the page.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

67
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
To end diagnosis and exit guided fault finding click on
which can be located at the lower left of the screen.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

68
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
If you really want to end the diagnostic session click on “Yes”.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

69
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
If the test plan was not completed this pop up window will appear on the
screen. Click “Yes” to go back to guided fault finding, or click on “No” if
you still wish to exit.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

70
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The fault memory is being erased. You can view the progress at the lower
right of the screen.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

71
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Not all faults may have been erased. If not this window appears. Click on
“Yes” to generate a new test plan, or click on “No” to continue to exit the
diagnostic session.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

72
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Do you wish to generate the readiness code. Click on “Yes” or “No”.

Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

73
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Click on “Done/Continue” to send a diagnostic log online.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

74
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Enter the job number for the order.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

75
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Enter your user ID and password.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

76
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
The diagnostic log has been sent.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

77
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
You have the option to print or save the diagnostic log. Click on “Next” to
continue.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

78
Status: 06/2011
Version4
Developed by Paul O’Flynn - Volkswagen Group Ireland
Diagnosis is being ended.
Quick start guide to using Guided Fault Finding.
Course notes
ODIS Technical Training.

79
Status: 06/2011
Version 4
Developed by Paul O’Flynn - Volkswagen Group Ireland
You are now back at the start screen again. Click on to end the
ODIS programme.
Quick start guide to using Guided Fault Finding.
